PORTABLE FORCED
AIR HEATERS
R
OWNER’S MANUAL
Heater Sizes: 35,000 70,000 100,000 150,000 Btu/Hr
Models: BY35CEH, BY70CEH, BY100CEH and BY150CEH
IMPORTANT: Read and understand this manual before assembling, starting or servicing
heater. Improper use of heater can cause serious injury. Keep this manual for future reference.
TABLE OF CONTENTS
SAFETY INFORMATION ............................................................ 2
PRODUCT IDENTIFICATION ..................................................... 3
UNPACKING............................................................................... 3
FUELS......................................................................................... 3
ASSEMBLY................................................................................. 4
VENTILATION............................................................................. 4
THEORY OF OPERATION ......................................................... 4
OPERATION ............................................................................... 5
STORING, TRANSPORTING, OR SHIPPING............................ 5
PREVENTATIVE MAINTENANCE SCHEDULE ......................... 6
TROUBLESHOOTING ................................................................ 6
SERVICE PROCEDURES .......................................................... 8
WIRING DIAGRAM ................................................................... 14
SPECIFICATIONS .................................................................... 15
ACCESSORIES ........................................................................ 15
ILLUSTRATED PARTS BREAKDOWN
AND PARTS LIST .................................................................. 16
WHEELS AND HANDLES ........................................................ 24
EC CONFORMITY DECLARATION.......................................... 25
WARRANTY AND REPAIR SERVICE ...................................... 26
SAFETY INFORMATION
2
SAFETY INFORMATION
WARNINGS
IMPORTANT: Read this owner’s manual carefully and
completely before trying to assemble, operate, or service this heater. Improper use of this heater can cause
serious injury or death from burns, fire, explosion,
electrical shock, and carbon monoxide poisoning.
DANGER: Carbon monoxide poisoning may lead
to death!
Carbon Monoxide Poisoning: Early signs of carbon monoxide
poisoning resemble the flu, with headaches, dizziness, and/or nausea. If you have these signs, the heater may not be working properly.
Get fresh air at once! Have heater serviced. Some people are more
affected by carbon monoxide than others. These include pregnant
women, persons with heart or lung disease or anemia, those under
the influence of alcohol, and those at high altitudes.
Make certain you read and understand all warnings. Keep this
manual for reference. It is your guide to safe and proper operation
of this heater.
• Use only kerosene or No. 1 fuel oil to avoid risk of fire or
explosion. Never use gasoline, naphtha, paint thinners, alcohol, or other highly flammable fuels.
• Fueling
a)Personnel involved with fueling shall be qualified and thor-
oughly familiar with the manufacturer's instructions and applicable regulations regarding the safe fueling of heating units.
b)Only the type of fuel specified on the heater's data plate shall
be used.
c) All flame, including the pilot light, if any, shall be extin-
guished and the heater allowed to cool, prior to fueling.
d)During fueling, all fuel lines and fuel-line connections shall
be inspected for leaks. Any leaks shall be repaired prior to
returning the heater to service.
e)At no time shall more than one day's supply of heater fuel
be stored inside a building in the vicinity of the heater. Bulk
fuel storage shall be outside the structure.
f) All fuel storage shall be located a minimum of 762cm (25
feet) from heaters, torches, welding equipment, and similar
sources of ignition (exception: the fuel reservoir integral with
the heater unit).
g)Whenever possible, fuel storage shall be confined to areas
where floor penetrations do not permit fuel to drip onto or
be ignited by a fire at lower elevation.
h)Fuel storage shall be in accordance with the authority hav-
ing jurisdiction.
• Never use heater where gasoline, paint thinner, or other highly
flammable vapors are present.
• Follow all local ordinances and codes when using heater.
• Heaters used in the vicinity of tarpaulins, canvas, or similar
enclosure materials shall be located a safe distance from such
materials. The recommended minimum safe distance is
304.8cm (10 feet). It is further recommended that these enclosure materials be of a fire retardant nature. These enclosure
materials shall be securely fastened to prevent them from igniting or from upsetting the heater due to wind action.
• Use only in well-vented areas. Before using heater, provide at
least a 2800 square cm (three-square-foot) opening of fresh,
outside air for each 30 kw (100,000 Btu/Hr) of rating.
• Use only in places free of flammable vapors or high dust content.
• Use only the electrical voltage and frequency specified on
model plate.
• Use only a three-prong, grounded extension cord.
• Minimum heater clearances from combustibles:
Outlet: 250 cm (8 Ft.)
Sides, Top, and Rear: 125 cm (4 Ft.)
• Locate heater on a stable and level surface if heater is hot or
running or a fire may occur.
• When moving or storing heater, keep heater in a level position
or fuel spillage may occur.
• Keep children and animals away from heater.
• Unplug heater when not in use.
• When used with thermostat, heater may start anytime.
• Never use heater in living or sleeping areas.
• Never block air inlet (rear) or air outlet (front) of heater.
• Never move, handle, refuel, or service a hot, operating, or
plugged-in heater.
• Never attach duct work to front or rear of heater.
105522
PRODUCT IDENTIFICATION
UNPACKING
FUELS
3
3
PRODUCT IDENTIFICATION
Hot Air
Outlet
Upper
Shell
Lower
Shell
Fuel
Tank
Side Cover
ON/OFF Switch
with Light
Power
Cord
Figure 1 - BY35CEH and BY70CEH Models
Hot Air Outlet
Upper Shell
Handle
Fan Guard
Air Filter
End
Cover
Fuel Cap
UNPACKING
1. Remove all packing items applied to heater for shipment.
2. Remove all items from carton.
3. Check items for any shipping damage. If heater is damaged,
promptly inform dealer where you bought heater.
FUELS
WARNING: Use only kerosene or No. 1 fuel oil to
avoid risk of fire or explosion. Never use gasoline,
naphtha, paint thinners, alcohol or other highly
flammable fuels.
Do not use heavy fuels such as No. 2 fuel oil or No. 2 Diesel. Using
heavy fuels will result in:
• clogged fuel filter and nozzle
• use of non-toxic anti-icer in fuel during very cold weather
IMPORTANT:
storage container is clean. Foreign matter such as rust, dirt, or water
will cause the flame-out control to shut down heater. Foreign matter
may also require you to clean fuel system often.
Use a KEROSENE ONLY container. Be sure
Lower
Shell
Fuel
Cap
Side Cover
ON/OFF
Switch with
Light
Figure 2 - BY100CEH and BY150CEH Models
Fan
Guard
Fuel
Tank
Power Cord
105522
ASSEMBLY
4
VENTILATION
THEORY OF OPERATION
ASSEMBLY
(FOR BY100CEH AND BY150CEH MODELS
ONLY)
These models are furnished with wheels and handles. Wheels, handles,
and the mounting hardware are found in the shipping carton.
Tools Needed
• Medium Phillips Screwdriver
• 3/8" Open or Adjustable Wrench
• Hammer
1. Slide axle through wheel support frame. Install wheels on axle.
IMPORTANT:
wheels toward wheel support frame (see Figure 3).
2. Place cap nuts on axle ends. Gently tap with hammer to secure.
3. Place heater on wheel support frame. Make sure air inlet end
(rear) of heater is over wheels. Line up holes on fuel tank flange
with holes on wheel support frame.
4. Place front handle and rear handle on top of fuel tank flange.
Insert screws through handles, fuel tank flange, and wheel support frame. Attach nut finger tight after each screw is inserted.
5. After all screws are inserted, tighten nuts firmly.
Hot Air
Outlet
Fuel Tank
Flange
Wheel
Support
Frame
Wheel
Cap Nut
Figure 3 - Wheel and Handle Assembly
When installing wheels, point extended hub of
Front Handle
Screw
Rear
Handle
Air
Inlet
Nut
Extended
Hub
Axle
VENTILATION
WARNING: Follow the minimum fresh, outside air
ventilation requirements. If proper fresh, outside air
ventilation is not provided, carbon monoxide poisoning can occur. Provide proper fresh, outside air ventilation before running heater.
Provide a fresh air opening of at least 2800 square cm (three square
feet) for each 30kw (100,000 Btu/Hr) rating. Provide extra fresh air
if more heaters are being used.
Example:
A 44kw (150,000 Btu/Hr) heater requires one of the
following:
• a two-car garage door [4.9 meter (16 feet) opening] raised 9 cm
(3.5 inches)
• a single-car garage door [2.75 meter (9 feet) opening] raised 15.25
cm (6 inches)
• two, 76 cm (30 inch) windows raised 28 cm (11 inches)
THEORY OF OPERATION
The Fuel System: The air pump forces air through the air line. The
air is then pushed through the burner head nozzle. This air causes
fuel to lift from the tank. A fine mist of fuel is sprayed into the
combustion chamber.
The Air System: The motor turns the fan. The fan pushes air into
and around the combustion chamber. This air is heated and provides
a stream of clean, hot air.
The Ignition System: The ignition control assembly provides
power to the ignitor. This ignites the fuel/air mixture in the combustion chamber.
The Flame-Out Control System: This system causes the heater to
shut down if the flame goes out.
Combustion
Chamber
Clean
Heated
Air Out
Fuel
Tank
Air For Fuel
System
Figure 4 - Cross Section Operational View
Nozzle
Ignitor
Fuel
Filter
Air For
Combustion
And Heating
Motor
Fan
Air Line
To Burner
Air Pump
Air Intake
Filter
Cool
Air In
Air
Output
Filter
Ignition
Control
Assembly
Fuel
105522
OPERATION
STORING, TRANSPORTING, OR SHIPPING
5
5
OPERATION
WARNING: Review and understand the warnings
in the
needed to safely operate this heater. Follow all local
codes when using this heater.
TO START HEATER
1. Follow all ventilation and safety information.
2. Fill fuel tank with kerosene or No. 1 fuel oil.
3. Attach fuel cap.
4. Plug power cord of heater into standard 240 volt/50 hertz,
EXTENSION CORD WIRE SIZE
REQUIREMENTS
Up to 30.5 meters (100 feet) long, use 1.0 mm2 (16 AWG) conductor
30.6 to 61 meters (101 to 200 feet) long, use 1.5 mm2 (14 AWG)
conductor
Push ON/OFF switch to ON (|) position and heater should start in 5
seconds. If ON/OFF switch light does not come on or heater does
not start, see Troubleshooting (pages 6 and 7).
Safety Information
grounded (earthed) outlet. Use an extension cord if needed.
Use only a three-prong, grounded (earthed) extension cord.
section, page 2. They are
STORING, TRANSPORTING,
OR SHIPPING
Note:
If shipping, transport companies require fuel tanks to be
empty.
1. Drain fuel tank.
Note:
Some models have drain plug on underside of fuel tank.
If so, remove drain plug to drain all fuel. If heater does not
have drain plug, drain fuel through fuel cap opening. Be sure
all fuel is removed.
2. Replace drain plug if provided.
3. If any debris is noted in old fuel, add 1 or 2 quarts of clean
kerosene to tank, stir, and drain again. This will prevent excess debris from clogging filters during future use.
4. Replace fuel cap or drain plug. Properly dispose of old and
dirty fuel. Check with local automotive service stations that
recycle oil.
5. If storing, store heater in dry place. Make sure storage place is
free of dust and corrosive fumes.
IMPORTANT:
during next heating season. Using old fuel could damage heater.
Do not store kerosene over summer months for use
TO STOP HEATER
Push ON/OFF switch to OFF (O)position.
TO RESET HEATER
1. Push ON/OFF switch to OFF (O) position and wait 10 seconds (2 minutes if heater has been running).
2. Repeat steps under To Start Heater, above.
ON/OFF
|
|
ON/OFF Switch
O
with Light
Figure 5 - ON/OFF Switch,
BY35CEH and BY70CEH
Models
Figure 6 - ON/OFF Switch,
BY100CEH and BY150CEH
Models
Switch with
Light
O
105522
PREVENTATIVE MAINTENANCE SCHEDULE
6
TROUBLESHOOTING
PREVENTATIVE
MAINTENANCE SCHEDULE
Item
Fuel tank
Air output and lint filters
Air intake filter
Fuel filter
Ignitor
Fan blades
Motor
How Often
Flush every 150-200 hours of operation or
as needed
Replace every 500 hours of operation or
once a year
Wash and dry with soap and water every
500 hours of operation or as needed
Clean twice a heating season or as needed
No maintenance required
Clean every season or as needed
Not required/permanently lubricated
WARNING: Never service heater while it is plugged
in, operating, or hot. Severe burns and electrical
shock can occur.
How To
See Storing, Transporting, or Shipping, page 5
See Air Output, Air Intake, and Lint Filters, page 10
See Air Output, Air Intake, and Lint Filters, page 10
See Fuel Filter, page 8
See Fan, page 13
TROUBLESHOOTING
ATTENTION:
current overloads. Use the light in the ON/OFF switch to troubleshoot the fault condition.
FAULT CONDITION
Motor does not start five seconds after
heater is plugged in (ON/OFF switch light
remains on)
The ignition control has built-in protection against
POSSIBLE CAUSE
1. Bad electrical connection between motor
and ignition control assembly or ignition
control assembly and power cord
2. Binding pump rotor
3. Defective ignition control assembly
4. Defective motor
WARNING: Never service heater while it is plugged
in, operating, or hot. Severe burns and electrical
shock can occur.
REMEDY
1. Check all electrical connections. See
Wiring Diagram, page 14
WARNING: High voltage!
2. If fan does not turn freely, see Pump
Rotor, page 12
3. Replace ignition control assembly
4. Replace motor
105522
TROUBLESHOOTING
Continued
TROUBLESHOOTING
7
7
FAULT CONDITION
Motor starts and runs but heater does not
ignite (ON/OFF switch light remains on)
Heater ignites but ignition control assembly
shuts heater off after a short period of time
(ON/OFF switch light remains on)
POSSIBLE CAUSE
1. No fuel in tank
2. Pump pressure incorrect
3. Dirty fuel filter
4. Obstruction in nozzle assembly
5. Water in fuel tank
WARNING: High voltage!
6. Bad electrical connection between
ignitor and ignition control assembly
7. Defective ignitor
8. Defective ignition control assembly
1. Pump pressure incorrect
2. Dirty air intake, air output, and/or lint
filter
3. Dirty fuel filter
4. Obstruction in nozzle assembly
5. Photocell assembly not properly
installed (not seeing the flame)
WARNING: High voltage!
REMEDY
1. Fill tank with kerosene
2. See Pump Pressur e Adjustment, page 10
3. See Fuel Filter, page 8
4. See Nozzle Assembly, page 11
5. Drain and flush fuel tank with clean
kerosene. See Storing, Transporting, or
Shipping, page 5
6. Check electrical connections. See Wiring
Diagram, page 14
7. Replace ignitor, see page 9
8. Replace ignition control assembly
1. See Pump Pressur e Adjustment, page 10
2. See Air Output, Air Intake, and Lint
Filters, page 10
3. See Fuel Filter, page 8
4. See Nozzle Assembly, page 11
5. Make sure photocell boot is properly
seated in bracket
ON/OFF switch light does not come on
when switch is turned to the ON(|) position
and heater does not start
ON/OFF switch light comes on when switch
is turned to the ON(|) Position but turns off
after five seconds
6. Dirty photocell lens
7. Bad electrical connection between
photocell and ignition control assembly
8. Defective photocell
9. Defective ignition control assembly
1. No power to heater
WARNING: High voltage!
2. Bad electrical connections
3. Electrical short in ignitor
1. Electrical short in motor
WARNING: High voltage!
6. Clean photocell lens
7. Check electrical connections. See Wiring
Diagram, page 14
8. Replace photocell
9. Replace ignition control assembly
1. Verify that power cord is plugged into
an electrical outlet and that the circuit
breaker in the electral panel is reset
2. Check electrical wiring and connections.
See W iring Diagram, page 14
3. Check ignitor wiring. If no problems are
found, replace ignitor (see page 9)
1. Check motor wiring. If no problems are
found, replace motor
105522
SERVICE PROCEDURES
8
SERVICE PROCEDURES
WARNING: Never service heater while it is plugged
in, operating, or hot. Severe burns and electrical
shock can occur.
UPPER SHELL REMOVAL
1. Remove screws and lock washers along each side of heater
using 5/16" nut-driver. These screws attach upper and lower
shells together.
2. Lift upper shell off.
3. Remove fan guard.
Upper
Upper Shell
Fan
Guard
Shell
Fuel Filter
Fuel Line
Side Cover
Figure 9 - Fuel Filter Removal, BY35CEH and BY70CEH Models
Fan
Guard
Figure 7 - Upper Shell
Removal, BY35CEH and
BY70CEH Models
Figure 8 - Upper Shell
Removal, BY100CEH and
BY150CEH Models
FUEL FILTER
(BY35CEH and BY70CEH Models)
1. Remove side cover screws using 5/16" nut-driver.
2. Remove side cover.
3. Pull rubber fuel line off fuel filter neck.
4. Carefully pry bushing and fuel filter out of fuel tank.
5. Wash fuel filter with clean fuel and replace in tank.
6. Attach rubber fuel line to fuel filter neck.
7. Replace side cover.
FUEL FILTER
(BY100CEH and BY150CEH Models)
1. Remove side cover screws using 5/16" nut-driver.
2. Remove side cover.
3. Pull upper fuel line off fuel filter neck.
4. Carefully pry bushing, lower fuel line, and fuel filter out of
fuel tank.
5. Wash fuel filter with clean fuel and replace in tank.
6. Attach upper fuel line to fuel filter neck.
7. Replace side cover.
Fuel Filter, Bushing,
and Lower Fuel Line
Upper
Fuel Line
Side Cover
Figure 10 - Fuel Filter Removal, BY100CEH and BY150CEH
Models
105522
SERVICE PROCEDURES
Continued
IGNITOR
1. Remove upper shell and fan guard (see page 8).
2. Remove fan (see page 13).
3. Remove 4 side cover screws with a 5/16" nut driver. Remove
side cover (see Figure 9 or 10, page 8).
4. Disconnect ignitor wires (black) from ignition control assembly (see Figure 11). Pull the ignitor wires up through the hole
in the lower shell.
5. Disconnect fuel line hose and air line hose. Remove photocell
from photocell bracket (see Figure 11).
6. Remove combustion chamber. Stand combustion chamber on
end with nozzle adapter bracket on top (see Figure 12).
7. Remove ignitor screw with a 1/4" nut driver. Carefully remove
ignitor from nozzle adapter bracket.
CAUTION: Do not bend or strike ignitor element.
Handle with care.
SERVICE PROCEDURES
9
9
8. Carefully remove replacement ignitor from styrofoam packing.
9. Carefully guide ignitor into opening in nozzle adapter bracket.
Do not strike ignitor element. Attach ignitor to nozzle adapter
bracket with screw using a 1/4" nut driver (see Figure 12).
Torque .90 to 1.69 N-m (8 to 15 in-lbs) Do not over torque.
10. Replace combustion chamber.
11. Route the ignitor wires back down through the hole in the lower
shell. Connect wires to the ignition control assembly.
12. Replace side cover (see Figure 9 or 10, page 8).
13. Connect and route fuel line hose and air line hose to burner
head. See Fuel and Air Line Replacement and Proper Rout-
ing, page 12.
14. Replace photocell in photocell bracket. Route wires as shown
in either Figure 17, 18, or 19, page 11.
15. Replace fan (see page 13).
16. Replace fan guard and upper shell (see page 8).
Combustion
Chamber
Air Line
Hose
Fuel Line
Hose
Photocell
Bracket
Photocell
Assembly
Side Cover
Figure 11 - Disconnecting Ignitor Wires from Ignition Control
Assembly
Nozzle Adapter
Bracket
Ignitor
Ignitor
Wires
Ignition
Control
Assembly
Ignitor Screw/
Washer Assembly
Ignitor
Photocell
Bracket
Combustion
Chamber
Figure 12 - Ignitor Replacement
Element
Nozzle Adapter
Bracket Opening
Ignitor
Nozzle
Adapter
Bracket
105522
10
SERVICE PROCEDURES
SERVICE PROCEDURES
Continued
AIR OUTPUT, AIR INTAKE, AND LINT
FILTERS
1. Remove upper shell (see page 8).
2. Remove filter end cover screws using 5/16" nut-driver.
3. Remove filter end cover.
4. Replace air output and lint filters.
5. W ash or replace air intake filter (see Preventative Maintenance
Schedule, page 6).
6. Replace filter end cover.
7. Replace fan guard and upper shell.
IMPORTANT:
PUMP PRESSURE ADJUSTMENT
1. Remove pressure gauge plug and plastic cap (BY35CEH and
BY70CEH only) from filter end cover.
2. Install accessory pressure gauge (part number HA1180).
3. Start heater (see Operation, page 5). Allow motor to reach full
speed.
4. Adjust pressure. Turn relief valve to right to increase pressure.
Turn relief valve to left to decrease pressure. See specifications below for correct pressure for each model.
5, Remove pressure gauge. Replace pressure gauge plug and plas-
tic cap (BY35CEH and BY70CEH only) in filter end cover.
Do not oil filters
Air Intake
Filter
Lint Filter
Air Output
Filter
Figure 14 - Air Output, Air Intake, and Lint Filters, BY100CEH
and BY150CEH Models
Pressure
Gauge
Plug
Plastic Cap
Filter End
Cover
Fan
Guard
Relief
Valve
Air Intake Filter
Filter End
Cover
Lint Filter
Air Output
Filter
Fan Guard
Figure 13 - Air Output, Air Intake, and Lint Filters, BY35CEH and
BY70CEH Models
Figure 15 - Pressure Gauge Plug and Plastic Cap Removal
Pump
Pressure
Model (PSI/Bar)
BY35CEH 2.9/0.200
BY70CEH 4.9/0.338
BY100CEH 4.9/0.338
BY150CEH 5.5/0.380
Pressure
Gauge
Figure 16 - Adjusting Pump Pressure
105522
SERVICE PROCEDURES
Continued
NOZZLE ASSEMBLY
1. Remove upper shell (see page 8).
2. Remove fan (see page 13).
3. Remove fuel and air line hoses from nozzle assembly (see Figure 17, 18 or 19).
4. Turn nozzle assembly 1/4 turn to left and pull toward motor to
remove (see Figure 20).
5. Place plastic hex-body into vise and lightly tighten.
6. Carefully remove nozzle from the nozzle adapter using 5/8"
socket wrench (see Figure 21).
7. Blow compressed air through face of nozzle. This will free
any dirt in nozzle area.
8. Inspect nozzle seal for damage.
Combustion
Chamber
Nozzle
Adapter
Bracket
Photocell
Bracket
Air Line
Hose
Figure 17 - Removing Air and Fuel Line Hoses (BY35CEH and
BY70CEH Models Only)
Nozzle/Adapter
Assembly
Fuel Line Hose
SERVICE PROCEDURES
11
11
9. Replace nozzle into nozzle adapter until nozzle seats. Tighten
1/3 turn more using 5/8" socket wrench 4.5 to 5.1 N-m (40 to
45 in-lbs). See Figure 21.
10. Attach nozzle assembly to burner strap.
11. Attach fuel and airline hoses to nozzle assembly. See Fuel and
Airline Replacement and Proper Routing, page 12.
12. Replace fan (see page 13).
13. Replace fan guard and upper shell (see page 8).
Combustion
Chamber
Nozzle
Adapter
Bracket
Photocell
Bracket
Air Line
Hose
Figure 19 - Removing Air and Fuel Line Hoses (BY150CEH
Model Only)
Combustion
Chamber
Nozzle/
Adapter
Assembly
Fuel Line Hose
Nozzle/Adapter
Assembly
Combustion
Chamber
Nozzle Adapter
Bracket
Air Line Hose
Photocell Bracket
Figure 18 - Removing Air and Fuel Line Hoses (BY100CEH
Model Only)
105522
Nozzle/
Adapter
Assembly
Fuel Line
Hose
Figure 20 - Removing Nozzle/Adapter Assembly
Nozzle
Face
Nozzle
Nozzle Adapter
Figure 21 - Nozzle and Nozzle Adapter
Nozzle Seal
Air Line
Fitting
Fuel Line
Fitting
12
SERVICE PROCEDURES
SERVICE PROCEDURES
Continued
FUEL AND AIR LINE REPLACEMENT AND
PROPER ROUTING
1. Remove upper shell (see page 8).
2. Remove side cover screws using 5/16" nut driver.
3. Remove side cover.
4. Inspect fuel and air line hoses for cracks and/or holes. If fuel line
hose is damaged, disconnect from nozzle adapter (see Figure 17,
18, or 19, page 11) and from fuel filter (see page 8). If air line
hose is damaged, disconnect from nozzle adapter (see Figure 17,
18, or 19, page 11) and from barb fitting on pump end cover (see
Figure 22).
5. Install new air and/or fuel line. Attach one end of air line hose
to barb fitting on pump end cover (see Figure 22) and the other
end to nozzle adapter (see Figure 17, 18, or 19, page 11). Attach one end of fuel line hose to fuel filter (see page 8) and the
other end to nozzle adapter (see Figure 17, 18, or 19, page 11).
For BY35CEH and BY70CEH model heaters, route air and
fuel lines approximately as shown in Figure 17, page 11.
Note:
Hoses are not to be touching photocell bracket.
For BY100CEH model heater, route air and fuel lines approximately as shown in Figure 18, page 11.
Note
: Hoses are not to be touching photocell bracket.
For BY150CEH model heater, route air and fuel lines approximately as shown in Figure 19, page 11.
Note:
Hoses are not to be touching photocell bracket
6. Replace side cover.
7. Replace upper shell and fan guard (see page 8).
Pump End
Cover
Barb Fitting
7. Check for debris in pump. If debris is found, blow out with
compressed air.
8. Install insert and rotor.
9. Check gap on rotor. Adjust to .076/.101 mm (.003"/.004") if
needed (see Figure 25, page 13).
Note:
Rotate rotor one full turn to ensure the gap is .076/.101 mm
(.003"/.004") at tightest position. Adjust if needed.
10. Install blades, pump plate, air filters, and filter end cover.
11. Replace fan guard and upper shell.
12. Adjust pump pressure (see page 10).
Note:
If rotor is still binding, proceed as follows.
Blade
Pump Plate
Air Intake Filter
Filter End Cover
Insert
Figure 23 - Rotor Location, BY35CEH and BY70CEH Models
Rotor
Air Output
Filter
Fan Guard
Blade
Pump Plate
Air Hose
Figure 22 - Air Hose to Barb FItting
PUMP ROTOR
(Procedure if Rotor is Binding)
1. Remove upper shell (see page 8).
2. Remove filter end cover screws using 5/16" nut-driver.
3. Remove filter end cover and air filters.
4. Remove pump plate screws using 5/16" nut-driver.
5. Remove pump plate.
6. Remove rotor, insert, and blades.
Air Intake Filter
Filter End Cover
Rotor
Insert
Air Output
Filter
Fan Guard
Figure 24 - Rotor Location, BY100CEH and BY150CEH Models
105522
SERVICE PROCEDURES
Continued
SERVICE PROCEDURES
13
13
13. Perform steps 1 through 6, page 12.
14. Place fine grade sandpaper (600 grit) on flat surface. Sand rotor lightly in “figure 8” motion four times (see Figure 26).
15. Reinstall insert and rotor.
16. Perform steps 10 through 12, page 12.
Gap Adjusting
Screw
Blade
Rotor
Gap Adjusting
Screw
Figure 25 - Gap Adjusting Screw Locations
Sandpaper
.076/.101 mm
(.003"/.004") Gap
Measured With
Feeler Gauge
Fan
Setscrew
Fan
Flush
Motor
Shaft
Figure 27 - Fan, Motor Shaft,
and Setscrew Location
Motor
Shaft
Figure 28 - Fan Cross Section
Setscrew
IGNITION CONTROL ASSEMBLY
WARNING: Unplug heater before servicing.
Remove Old Assembly
1. Using the 5/16" nut driver or socket wrench, remove the four
side cover screws (see Figure 29).
2. Disconnect the nine wires from the ignition control assembly .
3. Using needle nose pliers, squeeze the tab on the printed circuit
board support and lift up on the edge of the ignition control
assembly (see Figure 30). Repeat this for the other four printed
circuit board supports then remove the assembly.
Figure 26 - Sanding Rotor
FAN
IMPORTANT:
motor from heater. The weight of the motor resting on the fan could
damage the fan pitch.
1. Remove upper shell (see page 8).
2. Use 1/8" allen wrench to loosen setscrew which holds fan to
motor shaft.
3. Slip fan off motor shaft.
4. Clean fan using a soft cloth moistened with kerosene or solvent.
5. Dry fan thoroughly.
6. Replace fan on motor shaft. Place fan hub flush with end of
motor shaft (see Figure 28).
7. Place setscrew on flat of shaft. Tighten setscrew firmly 4.5 to
5.6 N-m (40 to 50 in-lbs).
8. Replace fan guard and upper shell.
105522
Remove fan from motor shaft before removing
Side
Cover
Figure 29 - Removing Cover
Side Cover
Ignition Control
Assembly
Printed Circuit
Board Supports (5)
Figure 30 - Removing Circuit Board
14
SERVICE PROCEDURES
WIRING DIAGRAM
SERVICE PROCEDURES
Continued
Installing the New Assembly
CAUTION: Ignition control assembly contains
electrostatic components. Handle the assembly by
the edges of the printed circuit board. Do not touch
any of the quick connect terminals or electronic
components.
1. Align the five holes in the assembly with the five printed circuit board supports in the side cover.
2. Holding the assembly by the edges of the printed circuit board,
apply downward pressure until all five tabs on the printed circuit board supports springlock into place. Pull up on assembly
to verify this (see Figure 31).
3. Connect the nine wire leads to the ignition control assembly as
shown in the wiring diagram in column 2.
CAUTION: Double check connections. Connecting ignition control assembly wrong could result in
damage to the ignition control assembly and/or other
components in the heater assembly.
WIRING DIAGRAM
Power Plug
240 V/50Hz
Green-Yellow
Photocell
Blue
(2)(1)
Brown
Blue
White
Blue
(3) (4) (6)
White
(N)
Blue
(5)
Ignition Control
1b
1
1a
Brown/White
Green-Yellow
Motor
Red
ON/Off Switch
(7)
Ignitor
Black
(8)
Black
4. Using the 5/16" nut driver or socket wrench reinstall side cover
to heater. Tighten screws until snug. Do not over torque!
Unacceptable
Unacceptable Acceptable
Figure 31 - Attaching Circuit Board to Tabs
Acceptable
105522
SPECIFICATIONS
Output Rating (Btu/Hr\kw) 35,000 (10) 70,000 (20) 100,000 (30) 150,000 (44)
Fuel Use Only Kerosene or No. 1 Fuel Oil
Fuel Tank Capacity
(U.S. Gal./Liters) 3.0/11.4 5.0/18.9 9.0/34 13.5/51.1
Fuel Consumption
(Gal. Per Hr./Liters Per Hr.) .28/1.1 .52/1.97 .79/3.0 1.1/4.1
Electric Requirements 240 V/50 Hz (Same All Models)
Amperage (Normal Run) .8 1.0 1.2 1.2
Hot Air Output (CFM/CMM) 140/4 225/6.4 425/12 500/14.2
Motor Speed (RPM) 1425 2850 2850 2850
ACCESSORIES
SPECIFICATIONS
ACCESSORIES
15
15
Purchase accessories from your local dealer.
AIR GAUGE KIT - HA1180
For all models. Special tool to check pump pressure.
HEAVY DUTY WHEELS AND HANDLE KIT
HA1202
For heavy duty applications. Makes your heater even more portable
and convenient. For BY35CEH and BY70CEH models.
STANDARD WHEELS AND HANDLE KIT
HA1206
Makes heater even more portable and convenient. Easy to assemble.
For BY35CEH and BY70CEH models.
A 008
IGNITION CONTROL ASSEMBLY/
PHOTOCELL TESTER - HA1170
Special tool used to test the ignition control assembly and photocell.
105522
16
1
2
3
4
5
6
7
8
9
10
11
12
13
16
9-2
9-1
9-3
9-4
9-5
17
18
19
20
21
22
23
24
26
27
28
29
30
34
35
36
32
33
9-6
15
14
31
42
41
43
40
38
37
39
25
BY35CEH Model
ILLUSTRATED PARTS BREAKDOWN
BY35CEH MODEL
ILLUSTRATED PARTS BREAKDOWN
12-1
12-2
12-18
12-17
12-16
Motor and Pump Assembly
12-3
12-15
12-4
12-14
12-5
12-6
12-7
12-8
12-9
12-13
12-10
12-12
12-11
12-19
105522
PARTS LIST
BY35CEH Model
17
17
PARTS LIST
BY35CEH MODEL
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 M51104-01 Handle 1
2 098511-256 Upper Shell 1
3 M11084-29 Screw, #10-16 x 3/4" 2
4 102432-01 Screw/Lockwasher, 1/2" 6
5 098512-63 Combustion Chamber 1
6 M10908-2 Screw, #6-32 x 3/8" 2
7 103154-03 Photocell Bracket 1
8 M16656-24 Photocell Assembly 1
9 ∗∗ Burner Strap Assembly 1
9-1 HA3006 Nozzle Assembly 1
9-2 102548-05 Ignitor Kit 1
9-3 104056-01 Nozzle Adapter 1
9-4 102336-01 Nozzle Adapter Bracket 1
9-5 M10908-75 Screw, #6-32 x 7/8" 1
9-6 103347-01 Belleville Washer 1
10 102431-01 Screw/Lockwasher, 1/2" 2
11 103684-01 Fan 1
12 ∗∗ Motor and Pump Assembly 1
12-1 102001-25 Motor 1
12-2 079975-03 Pump Body 1
12-3 M22009 Insert 1
12-4 M22456-2 Rotor 1
12-5 M29608 Pump End Cover 1
12-6 M29632 Lint Filter 1
12-7 M29633 Intake Filter 1
12-8 M29609 Filter End Cover 1
12-9 M12461-31 Screw, #10-32 x 1" 3
12-10 M27694 Adjusting Screw 1
12-11 M10993-1 Pressure Relief Spring 1
12-12 M22997 Plug 1
12-13 M8940 Steel Ball, 1/4" Diameter 1
12-14 M29612-01 Output Filter 1
12-15 M12461-32 Screw #10-32 x 1
12-16 103676-01 Nylon Elbow, 90° 1
12-17 M8643-2 Blade 4
12-18 FHPF3-6C Screw, #10-32 x 3/4" 2
12-19 105780-01 Plastic Cap 1
13 M51105-01 Fan Guard 1
This list contains replaceable parts used in your heater. When ordering parts, be sure to
provide the correct model and serial numbers (from the model plate), then the part number
and description of the desired part.
1
/8"6
KEY PART
NO. NUMBER DESCRIPTION QTY.
14 098872-04 Power Cord 1
15 M50400 Strain Relief Bushing 1
16 NTC-4C Hex Lock Nut, 1/4-20 2
17 102431-01 Screw/Lockwasher, 1/2" 4
18 M50631 Rubber Bumper 2
19 097461-09 Side Cover 1
20 101205-01 Motor Bracket 1
21 M30865-02 Bushing 1
22 M11271-8 Clip Nut 6
23 M50104-02 Bushing 1
24 102431-01 Screw/Lockwasher, 1/2" 6
25 RF3-4B Screw, #10-32 x 1/2" 1
26 098511-237 Lower Shell 1
27 M50814-06 Rubber Airline 1
28 M29652-05 Fuel Line 1
29 108060-01 Fuel Filter 1
30 M10990-3 Rubber Bushing 1
31 102861-01 Nylon Locknut 1
32 102349-01 PCB Support 5
33 104068-04 Ignition Control Assembly 1
34 097702-01 Fuel Cap (Includes Gasket) 1
35 108088-01 Fuel Tank 1
36 M51108-01 Shell Heat-Shield 1
37 NPF-3B Nut, #10-32 3
38 097785-01 Vinyl Foam Gasket 1
39 WLE-3 Lockwasher, #10 1
40 079010-39 Wire Assembly (Brown/White) 1
41 105793-01 ON/OFF Switch 1
42 079919-01 Switch Cover 1
43 079010-40 Wire Assembly (White) 1
PARTS AVAILABLE - NOT SHOWN
HA2210 Filler Neck Screen 1
103814-01 Wire Tie 1
097649-01 Tradename Decal 2
106013-01 Decal Package 1
105880-01 Ignition Control Assembly Fuse 1
∗∗ Not available as an assembly; order parts separately
105522
18
1
2
3
4
5
6
7
8
9
10
11
12
13
16
9-2
9-1
9-3
9-4
9-5
17
18
19
20
21
22
23
24
26
27
28
29
30
34
35
36
32
33
9-6
15
14
31
42
41
43
40
38
37
39
25
BY70CEH Model
ILLUSTRATED PARTS
BREAKDOWN
BY70CEH MODEL
ILLUSTRATED PARTS BREAKDOWN
12-1
12-2
12-18
12-17
12-16
Motor and Pump Assembly
12-3
12-15
12-4
12-14
12-5
12-6
12-7
12-8
12-9
12-13
12-10
12-12
12-11
12-19
105522
PARTS LIST
BY70CEH Model
19
19
PARTS LIST
BY70CEH MODEL
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 M51104-01 Handle 1
2 098511-256 Upper Shell 1
3 M11084-29 Screw, #10-16 x 3/4" 2
4 102432-01 Screw/Lockwasher, 1/2" 6
5 098512-64 Combustion Chamber 1
6 M10908-2 Screw, #6-32 x 3/8" 2
7 103154-03 Photocell Bracket 1
8 M16656-24 Photocell Assembly 1
9 ∗∗ Burner Strap Assembly 1
9-1 HA3026 Nozzle Assembly 1
9-2 102548-05 Ignitor Kit 1
9-3 104056-01 Nozzle Adapter 1
9-4 102336-01 Nozzle Adapter Bracket 1
9-5 M10908-75 Screw, #6-32 x 7/8" 1
9-6 103347-01 Belleville Washer 1
10 102431-01 Screw/Lockwasher, 1/2" 2
11 103684-01 Fan 1
12 ∗∗ Motor and Pump Assembly 1
12-1 102001-23 Motor 1
12-2 079975-02 Pump Body 1
12-3 M22009 Insert 1
12-4 M22456-1 Rotor 1
12-5 M29608 Pump End Cover 1
12-6 M29632 Lint Filter 1
12-7 M29633 Intake Filter 1
12-8 M29609 Filter End Cover 1
12-9 M12461-31 Screw, #10-32 x 1" 3
12-10 M27694 Adjusting Screw 1
12-11 M10993-1 Pressure Relief Spring 1
12-12 M22997 Plug 1
12-13 M8940 Steel Ball, 1/4" Diameter 1
12-14 M29612-01 Output Filter 1
12-15 M12461-31 Screw #10-32 x 1" 6
12-16 103676-01 Nylon Elbow, 90° 1
12-17 M8643 Blade 4
12-18 FHPF3-5C Screw, #10-32 x 5/8" 2
12-19 105780-01 Plastic Cap 1
13 M51105-01 Fan Guard 1
This list contains replaceable parts used in your heater. When ordering parts, be sure to
provide the correct model and serial numbers (from the model plate), then the part number
and description of the desired part.
KEY PART
NO. NUMBER DESCRIPTION QTY.
14 098872-04 Power Cord 1
15 M50400 Strain Relief Bushing 1
16 NTC-4C Hex Lock Nut, 1/4-20 2
17 102431-01 Screw/Lockwasher, 1/2" 4
18 M50631 Rubber Bumper 2
19 097461-09 Side Cover 1
20 101205-01 Motor Bracket 1
21 M30865-02 Bushing 1
22 M11271-8 Clip Nut 6
23 M50104-02 Bushing 1
24 102431-01 Screw/Lockwasher, 1/2" 6
25 RF3-4B Screw, #10-32 x 1/2" 1
26 098511-237 Lower Shell 1
27 M50814-06 Rubber Airline 1
28 M29652-05 Fuel Line 1
29 108060-03 Fuel Filter 1
30 M10990-3 Rubber Bushing 1
31 102861-01 Nylon Locknut 1
32 102349-01 PCB Support 5
33 104068-04 Ignition Control Assembly 1
34 097702-01 Fuel Cap (Includes Gasket) 1
35 108088-03 Fuel Tank 1
36 M51108-01 Shell Heat-Shield 1
37 NPF-3B Nut, #10-32 3
38 097785-01 Vinyl Foam Gasket 1
39 WLE-3 Lockwasher, #10 1
40 079010-39 Wire Assembly (Brown/White) 1
41 105793-01 ON/OFF Switch 1
42 079919-01 Switch Cover 1
43 079010-40 Wire Assembly (White) 1
PARTS AVAILABLE - NOT SHOWN
HA2210 Filler Neck Screen 1
103814-01 Wire Tie 1
097649-01 Tradename Decal 2
106013-02 Decal Package 1
105880-01 Ignition Control Assembly Fuse 1
∗∗ Not available as an assembly; order parts separately
105522
20
ILLUSTRATED PARTS BREAKDOWN
BY100CEH Model
ILLUSTRATED PARTS
BREAKDOWN
BY100CEH MODEL
2
1
3
7-4
7
4
6
24
28
5
8
11
23
20
22
19
25
18
9
10
12
15
26
27
7-1
7-2
7-6
7-3
7-5
16
29
10-1
10-2
10-3
10-4
10-17
10-16
10-15
10-13
Motor and Pump Assembly
10-14
10-5
10-13
35
10-6
30
43
36
32
21
31
14
17
10-7
41
42
37
13
33
34
44
39
38
14
40
10-8
10-9
10-10
10-11
10-12
105522
PARTS LIST
BY100CEH Model
21
21
PARTS LIST
BY100CEH MODEL
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 098511-257 Upper Shell 1
2 102432-01 Screw/Lockwasher, 1/2" 8
3 098512-65 Combustion Chamber 1
4 103971-01 Photocell Bracket 1
5 M10908-2 Screw, #6-32 x 3/8" 2
6 M16656-24 Photocell Assembly 1
7 ** Burner Strap Assembly 1
7-1 HA3027 Nozzle Assembly 1
7-2 102548-05 Ignitor Kit 1
7-3 M10908-75 Screw, #6-32 x 7/8" 1
7-4 102336-01 Nozzle Adapter Bracket 1
7-5 104054-01 Nozzle Adapter 1
7-6 103347-01 Belleville Washer 1
8 102431-01 Screw/Lockwasher, 1/2" 2
9 102042-01 Fan 1
10 ** Motor and Pump Assembly 1
10-1 102001-24 Motor 1
10-2 079975-02 Pump Body 1
10-3 FHPF3-5C Screw, #10-32 x 5/8" 2
10-4 M22009 Rotor Insert 1
10-5 M22456-1 Pump Rotor 1
10-6 M50545 Pump End Cover 1
10-7 M12179 Intake Filter 1
10-8 M16545 Filter End Cover 1
10-9 M8940 Steel Ball, 1/4" Diameter 1
10-10 M10993-1 Relief Spring 1
10-11 M27694 Adjusting Screw 1
10-12 M22997 Plug 1
10-13 M12461-31 Screw, #10-32 x 1" 10
10-14 M12244-1 Output Filter 1
10-15 M11637 Lint Filter 1
10-16 M50820-02 Barb Fitting 1
10-17 M8643 Blade 4
11 M50631 Rubber Bumper 2
12 101206-01 Motor Mounting Bracket 1
13 101695-01 Button Plug 1
14 104068-04 Ignition Control Assembly 1
This list contains replaceable parts used in your heater. When ordering parts, be sure to provide the
correct model and serial numbers (from the model plate), then the part number and description of the
desired part.
KEY PART
NO. NUMBER DESCRIPTION QTY.
15 NTC-4C Hex Lock Nut, 1/4-20 2
16 M51114-01 Fan Guard 1
17 M27417 Drain Plug (Includes “o” Ring) 1
18 099213-01 Button Plug 1
19 M51345-01 Fuel Line 1
20 107961-01 Fuel Filter 1
21 M51151-01 Fuel Line Tube 1
22 M10990-3 Rubber Bushing 1
23 M50814-03 Airline 1
24 098511-236 Lower Shell 1
25 M50104-03 Bushing 1
26 M50104-01 Bushing 1
27 102431-01 Screw/Lockwasher, 1/2" 6
28 M11271-8 Clip Nut 8
29 RF3-4B Screw, #10-32 x 1/2" 1
30 108088-04 Fuel Tank 1
31 097702-01 Fuel Cap (Includes Gasket) 1
32 102349-01 P.C. Board Support 5
33 M50400 Strain Relief Bushing 1
34 098872-04 Power Cord 1
35 M51077-15 Side Cover 1
36 102431-01 Screw/Lockwasher, 1/2" 4
37 102861-01 Nylon Locknut 1
38 079010-39 Wire Assembly (Brown/White) 1
39 105793-01 ON/OFF Switch 1
40 079919-01 Switch Cover 1
41 WLE-3 Lockwasher, #10 1
42 NPF-3B Nut, #10-32 3
43 097468-01 Edge Liner 1
44 079010-40 Wire Assembly (White) 1
PARTS AVAILABLE - NOT SHOWN
HA2210 Filler Neck Screen 1
103814-01 Wire Tie 1
097650-01 Tradename Decal 2
106013-03 Decal Package 1
105880-01 Ignition Control Assembly Fuse 1
** Not available as an assembly; order parts separately
105522
22
ILLUSTRATED PARTS BREAKDOWN
BY150CEH Model
ILLUSTRATED PARTS
BREAKDOWN
BY150CEH MODEL
2
1
3
7-4
7
4
6
24
28
5
8
11
23
20
22
19
25
18
9
10
12
15
26
27
7-1
7-2
7-6
7-3
7-5
16
29
10-1
10-2
10-3
10-4
10-17
10-16
10-15
10-18
Motor and Pump Assembly
10-14
10-5
10-13
35
10-6
30
43
36
32
21
31
14
17
10-7
41
42
37
13
33
34
44
39
38
14
40
10-8
10-9
10-10
10-11
10-12
105522
PARTS LIST
BY150CEH Model
23
23
PARTS LIST
BY150CEH MODEL
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 098511-257 Upper Shell 1
2 102432-01 Screw/Lockwasher, 1/2" 8
3 098512-66 Combustion Chamber 1
4 103154-05 Photocell Bracket 1
5 M10908-2 Screw, #6-32 x 3/8" 2
6 M16656-24 Photocell Assembly 1
7 ** Burner Strap Assembly 1
7-1 100735-24 Nozzle Assembly 1
7-2 102548-05 Ignitor Kit 1
7-3 M10908-75 Screw, #6-32 x 7/8" 1
7-4 102336-01 Nozzle Adapter Bracket 1
7-5 104054-01 Nozzle Adapter 1
7-6 103347-01 Belleville Washer 1
8 102431-01 Screw/Lockwasher, 1/2" 2
9 102042-01 Fan 1
10 ** Motor and Pump Assembly 1
10-1 102001-24 Motor 1
10-2 079975-03 Pump Body 1
10-3 FHPF3-6C Screw, #10-32 x 3/4" 2
10-4 M22009 Rotor Insert 1
10-5 M22456-2 Pump Rotor 1
10-6 M50545 Pump End Cover 1
10-7 M12179 Intake Filter 1
10-8 M16545 Filter End Cover 1
10-9 M8940 Steel Ball, 1/4" Diameter 1
10-10 M10993-1 Relief Spring 1
10-11 M27694 Adjusting Screw 1
10-12 M22997 Plug 1
10-13 M12461-31 Screw, #10-32 x 1" 4
10-14 M12244-1 Output Filter 1
10-15 M11637 Lint Filter 1
10-16 M50820-02 Barb Fitting 1
10-17 M8643-2 Blade 4
10-18 M12461-32 Screw, #10-32 x 1
11 M50631 Rubber Bumper 2
12 101206-01 Motor Mounting Bracket 1
13 101695-01 Button Plug 1
14 104068-04 Ignition Control Assembly 1
This list contains replaceable parts used in your heater. When ordering parts, be sure to provide the
correct model and serial numbers (from the model plate), then the part number and description of the
desired part.
1
/8"6
KEY PART
NO. NUMBER DESCRIPTION QTY.
15 NTC-4C Hex Lock Nut, 1/4-20 2
16 M51114-01 Fan Guard 1
17 M27417 Drain Plug (Includes “o” Ring) 1
18 099213-01 Button Plug 1
19 M51345-04 Fuel Line 1
20 107961-01 Fuel Filter 1
21 M51151-02 Fuel Line Tube 1
22 M10990-3 Rubber Bushing 1
23 M50814-03 Airline 1
24 098511-236 Lower Shell 1
25 M50104-03 Bushing 1
26 M50104-01 Bushing 1
27 102431-01 Screw/Lockwasher, 1/2" 6
28 M11271-8 Clip Nut 8
29 RF3-4B Screw, #10-32 x 1/2" 1
30 108088-05 Fuel Tank 1
31 097702-01 Fuel Cap (Includes Gasket) 1
32 102349-01 P.C. Board Support 5
33 M50400 Strain Relief Bushing 1
34 098872-04 Power Cord 1
35 M51077-15 Side Cover 1
36 102431-01 Screw/Lockwasher, 1/2" 4
37 102861-01 Nylon Locknut 1
38 079010-39 Wire Assembly (Brown/White) 1
39 105793-01 ON/OFF Switch 1
40 079919-01 Switch Cover 1
41 WLE-3 Lockwasher, #10 1
42 NPF-3B Nut, #10-32 3
43 097468-01 Edge Liner 1
44 079010-40 Wire Assembly (White) 1
PARTS AVAILABLE - NOT SHOWN
HA2210 Filler Neck Screen 1
103814-01 Wire Tie 1
097650-01 Tradename Decal 2
106013-04 Decal Package 1
105880-01 Ignition Control Assembly Fuse 1
** Not available as an assembly; order parts separately
105522
24
WHEELS AND HANDLES
BY100CEH AND BY150CEH MODELS
WHEELS AND HANDLES
BY100CEH AND BY150CEH MODELS
KEY PART PART BY100CEH BY150CEH
NO. NUMBER DESCRIPTION QTY. QTY.
1 HA2203 Handles 2 —
HA2204 Handles — 2
2 M12345-33 Screw, #10-24 x 1 3/4"8 8
3 M12342-3 Wheel Support Frame 1 —
M12831-3 Wheel Support Frame — 1
4 NTC-3C Hex Nut, #10-24 8 8
5 107426-01 Wheel (2) 1 1
6 M28526 Cap Nut 2 2
7 M51015-01 Axle 1 —
M16801-2 Axle — 1
1
2
3
5
4
7
6
105522
EC CONFORMITY DECLARATION
EC CONFORMITY DECLARATION
EC CONFORMITY DECLARATION
SGB YOUNGMAN
Stanestreet, Slingfold, Horsham
West Sussex Rh13 7RD
United Kingdom (UK)
Manufacturer:
DESA International, Inc.
2701 Industrial Drive
Bowling Green, KY 42101 U.S.A.
25
25
Kerosene Portable Forced Air Heaters
Model Numbers: BY35CEH, BY70CEH, BY100CEH, BY150CEH
It is declared that these models conform to the Machinery Directive 98/37/EC,
including 91/368/EEC and the Low Voltage Directive 73/23/EEC. It is further
declared that these models conform to the EMC Directive 89/336/EEC, amended
by 92/31/EEC and including EN50081-1 and EN50082-1.
We declare that the models noted are in conformity.
Company DESA International, Inc.
Name Keith T eakell
Title Vice President, Heating Products Engineering
06/13/2001 — Bowling Green, KY
Date and Place Signature
105522
26
WARRANTY AND REPAIR SERVICE
CERTIFICATE OF GENERAL
EQUIPMENT - LIMITED 1 YEAR WARRANTY
SGB YOUNGMAN warrants new Products sold by it to be
free from defects in material or workmanship for a period of one
year after date of delivery to the first user and subject to the
following conditions:
SGB YOUNGMAN’s obligation and liability under this Warranty is expressly limited to repairing or replacing at SGB
YOUNGMAN’s option, any parts which appear to SGB
YOUNGMAN upon inspection to have been defective in material or workmanship when shipped from the factory. Such parts
shall be provided at no cost to the user, at the business
establishment of any factory authorized service center or the
factory during regular working hours. The Warranty shall not
apply to component parts or accessories of Products not manufactured by SGB YOUNGMAN and which carry the warranty of
the manufacturer thereof, or to normal maintenance (such as
pressure adjustments) or to normal maintenance parts (such as
filters and spark plugs). Replacement or repair parts installed in
the Product covered by this Warranty are warranted only for the
remainder of this Warranty as if such parts were original components of said Product. SGB YOUNGMAN MAKES NO OTHER
EXPRESS WARRANTY. TO THE EXTENT PERMITTED BY
LAW SGB YOUNGMAN MAKES NO IMPLIED WARRANTY
AND MAKES NO WARRANTY OF MERCHANTABILITY OR
FITNESS FOR ANY PARTICULAR PURPOSE. IN ANY
EVENT IMPLIED WARRANTIES INCLUDING THOSE OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE ARE LIMITED TO THE DURATION OF THIS
EXPRESS WARRANTY.
Any transportation charges, costs of installation, duty,
taxes or any other charges whatsoever must be borne by the
user. SGB YOUNGMAN’s obligation under this limited Warranty shall not include any liability for direct, indirect, incidental,
or consequential damage or delay. If requested by SGB
YOUNGMAN, Products or parts for which a warranty claim is
made are to be returned transportation prepaid by user to SGB
YOUNGMAN. Any improper use, including operation after
discovery of defective or worn parts, operation beyond capacity, substitution of parts not approved by SGB YOUNGMAN, or
any alteration or repair by others in such manner as in SGB
YOUNGMAN’s judgement affects the Product materially and
adversely, shall void this Warranty.
NO EMPLOYEE OR REPRESENTATIVE IS AUTHORIZED
TO CHANGE THIS WARRANTY IN ANY WAY OR GRANT
ANY OTHER WARRANTY UNLESS SUCH CHANGE IS
MADE IN WRITING AND SIGNED BY AN OFFICER OF SGB
YOUNGMAN AT ITS HOME OFFICE.
Printed in U.S.A.
WARRANTY SERVICE
Always specify model and serial numbers when communicating with the factory.
We reserve the right to amend these specifications at any time without notice. The only
Warranty applicable is our standard written Warranty. We make no other Warranty, expressed
or implied.
SGB YOUNGMAN
Stanestreet, Slingfold, Horsham
West Sussex Rh13 7RD
United Kingdom (UK)
105522 01
NOT A UPC
105522-01
Rev. D
06/01
105522
Loading...
