Denon PMA 2000 4R Service Manual

Hi-Fi Integrated Stereo Amplifier

X0141 337 NC 0204

SERVICE MANUAL

MODEL

INTEGRATED STEREO AMPLIFIER

PMA-2000

IV

R

 Some illustrations using in this service manual are slightly different from the actual set.

16-11, YUSHIMA 3-CHOME, BUNKYOU-KU, TOKYO 113-0034 JAPAN

Telephone: [phone]

PMA-2000IVR

SAFETY PRECAUTIONS

The following check should be performed for the continued protection of the customer and service technician.

LEAKAGE CURRENT CHECK

Before returning the unit to the customer, make sure you make either (1) a leakage current check or (2) a line to chassis
resistance check. If the leakage current exceeds 0.5 milliamps, or if the resistance from chassis to either side of the
power cord is less than 460 kohms, the unit is defective.

SPECIFICATIONS



 POWER AMPLIFIER SECTION



Rated Output Power:

Both channel driven
(8 Ω/ohms Load) 80 W + 80 W
20 Hz to 20kHz, T.H.D. 0.07 %
(4 Ω/ohms Load) 160 W + 160 W
DIN, 1 kHz, T.H.D. 0.7 %
Total Harmonic Distortion: 0.01 %
(−3 dB at rated output, 8 Ω/ohms) (1kHz)

Input Sensitivity/Input Impedance:

P. DIRECT: 0.9 V/47 kΩ/kohms
Amplification factor: 29 dB



 PRE AMPLIFIER SECTION



PHONO EQUALIZER
Rated Output: 150 mV

(Rec out Terminal)

Input Sensitivity/Input Impedance:

The value in parentheses ( ) refers to the input impedance when SOURCE DIRECT is ON.
PHONO: MM: 2.5 mV/47 kΩ/ohms

MC: 200 µV/100 Ω/ohms
CD, TUNER, DVD/AUX-1, AUX-2, 135 mV/47 kΩ/ohms
TAPE-1/CD-R, TAPE-2/MD: (135 mV/12 kΩ/ohms)

RIAA Deviation:

PHONO: 20 HZ ~ 20 kHz ±0.5 dB
Maximum Input: PHONO

MM: 130 mV/1 kHz

Rated Output: PRE PUT: 0.9 V



 OVERALL CHARACTERISTICS



SN Ratio (IHF A Network): PHONO
(input terminals short-circuited) MM: 89 dB (at 5 mV input)
(input terminals short-circuited) MC: 74 dB (at 0.5 mV input)
SOURCE-DIRECT: ON CD, TUNER, DVD/AUX-1, AUX-2, TAPE-1/CD-R, TAPE-2/MD: 108 dB

Tone Control Adjustable Range:

BASS: 100 Hz ±8 dB
TREBLE: 10 kHz ±8 dB



 OTHERS



Power Supply: AC 230 V, 50 Hz (Asia)

AC Outlets:

Switched × 2: 100 W (Total)
Unswitched × 1: 100 W

Power Consumption: 310 W (IEC)
Dimensions: 434 (W) × 180 (H) × 478 (D) mm (17-3/32" × 7-5/64" × 18-13/16")
Net Mass: 24.0 kg (52 lbs 14.6 oz)

MC: 10mV/1 kHz

(Input CD 135 mV)

AC220 V, 50 Hz (China)

}

Except for China model



 REMOTE CONTROL UNIT (RC-858)



Remote control system: Infrared pulse system
Power supply: 3 V DC, Two size R03 ("AAA") dry cell batteries
External dimensions: 56 (W) × 105 (H) × 19 (D) mm (2-3/16" × 4-1/8" × 23/32")
Mass: 70 g (Approx. 2.47 oz) (including batteries)

* Maximum dimensions include controls, jacks, and covers.

(W) = width, (H) = height, (D) = depth

* For improvement purposes, specifications and functions are subject to change without advanced notice.

2

DISASSEMBLY

(Do reverse manner when assembling.)

Top Cover

Remove 14 screws 1, 4 screws 2 and detach the Top Cover
in the arrow direction.

PMA-2000IVR

1

1

Front Panel

1. Remove 8 screws 3.

2. Pull out the knob 4 and remove the nut, then detach the
panel in the arrow direction.

1

2

Top Cover

2

1

Front Panel

3

3

4

Nut

3

3

PMA-2000IVR

Bottom Plate

Remove 24 screws 5 and detach it in the arrow direction.

Rear Panel

1. Remove 5 screws 6, 6 screws 7 and 2 screws 8.

2. Detach the Rear Panel in the arrow direction.

5

Bottom Plate

Heat Sink Ass'y

Remove 2 screws 9 and detach the Heat Sink Ass'y in the
arrrow direction.

9

Heat Sink
Ass'y

Rear Panel

8

6

7

7

4

METHOD OF ADJUSTMENTS

DC Voltmeter

Main Volume

1U-3432-2

Power Amp P.W.B. (R)

VR502

1U-3432-1

Power Amp P.W.B. (L)

VR501

Power

Trans

Power

Trans

PMA-2000IVR

IDLING CURRENT



 Setup



 Adjustment

1. Lay the unit at an ordinary position away from a direct current from an air condition or fan. Do the adjustment at a
temperature between 15°C (59°F) and 30°C (86°F).

2. Set control as follows.

POWER SWITCH
VOLUME CONTROL Fully counterclockwise in the minimum position ( ).

SPEAKER Terminals

1. Remove top cover. And then connect DC Voltmeter to test points of 1U-3432-1 (Lch) and 1U-3432-2 (Rch) Power Amp
Printing Wiring Board.

2. Connect power cord to AC wall outlet, and turn POWER switch "ON" (
VR502 (Rch) clockwise so that the DC Voltmeter reads 12 ±0.5mV.

3. Then after 2 minutes warmup adjust VR501 and VR502 so that the DC Voltmeter reads 12 ±0.5mV.

4. And after 10 minutes warmup adjust VR501 and VR502 so that the DC Voltmeter reads 12 ±0.5mV.

OFF ( ).

(Main Volume and Semifixed resistors [VR501, 502])

Open: do not connect the speakers, dummy load etc.

). Within 10 seconds turn VR501 (Lch) and

5

INPUT

REC OUT

PRE OUT

MAIN IN

P. AMP DIRECT 0.9V(-1dB)

CD etc.135mV(-17.4dB)

PHONO MM 2.2mV(-53dB)

PHONO MC 0.18mV(-75dB)

PHONO

CD

TUNER

DVD
/AUX-1

AUX-2

TAPE-1
/CD-R

TAPE-1
/CD-R

TAPE-2
/MD

TAPE-2
/MD

RIAA

MC

MM

47k 100

+

-

BASS

BUFFER

BALANCE

TREBLE

SOURCE

OFF

ON

DIRECT

MAIN VOLUME

POWER AMP DIRECT

FLAT AMP

TONE

POWER AMP

PROTECTOR

SPEAKER A
(MAIN)

SPEAKER B
(BI WIRING)

HEAD PHONE

POWER AMP

POWER AMP

POWER GND

VOLTAGE

REGULATOR

REC OUT SELECTOR

OFF ON

EQUALIZER

TONE AMP

POWER AMP

FLAT AMP

PROTECTOR

&

RELAY

+16V

-16V

GND

+16V

-16V

GND

+16V

-16V

GND

GND

+30V

+12V

-30V

GND

+

+

+

AC PLUG

80W/8ohm 25.3V(28dB)

40dB

-40dB

-50dB

-60dB

-70dB

-80dB

20dB

-20dB

10dB

-10dB

0dB

30dB

-30dB

(dBV)

BLOCK/LEVEL DIAGRAM

PMA-2000IVR

1 5678

32

4

A

B

C

D

E

6

PMA-2000IVR

21 22

(VASS)V

SS

VAREF

20 23

XOUT P60(AIN0)

19 24

XIN P61(AIN1)

18 25

RESET P62(AIN2)

17 26

TEST P63(AIN3)

16 27

P00 P64(AIN4)

15 28

P01 P65(AIN5)

14 29

P02 P66(AIN6)

13 30

P03 P67(AIN7)

12 31

P04 P10(INT0)

11 32

P05 P11(INT1)

10 33

P06 P12(INT2/TC1)

934

P07 P13(DVO)

835

(INT3/TC3)P70 P14(PPG)

736

(INT4)P71 P15(TC2)

637

(PDO/PWM)P72 P16

538

(SCK)P73 P17

439

(SI)P74 P20(INTS/STOP)

340

(SO)P75 P21(XIN)

241

(HSCK)P76 P22(XOUT)

142

(HSO)P77 V

DD

Power Supply
Terminal

Reset
I/O Terminal

Test Terminal

V

DD

V

SS

RESET

TEST

High Freq.
Oscillator
Connection
Terminal

XIN

P22

P20

I/O Port

VAREF

ALU

PSW Stack Pointer

Interrupt Control Circuit

Program Counter

Program Memory

(ROM)

Data memory

(RAM)

Unviersal register Blank

Flag RBS

System Control Circuit

Standby Control Circuit

Timing Generator

Time Base

Timer

16 bit

Timer/Counter

TC1

P2

8 bit

A/D Converter

P6 P0 P1 P7

TC2

8 bit

Timer/Counter

TC3 TC4

8 bit Serial

Interface

Command

register

Command

decoder

SIO HSO

Watch Dog

Timer

Clock

Generator

High Freq.

Use

Low Freq.

Use

Analog

Vref

XOUT

~

P67

P66

(Analog Input)

I/O Port

~

P07

P00

~

P17

P10

~

P77

P70

~

P65 (AIN5)

P60 (AIN0)

~

SEMICONDUCTORS



 IC’s



TMP87CC46N-4C08 (IC901)

TMP87CC46N-4C08 (IC901) Terminal Function

Pin
No.

1 P77 O C AC POWER RELAY DRIVE

2 P76 O C

3 P75 (SO) O C

4 P74 (SI) O C

5 P73 (SCK) O C

6 P72 O C MUTE/STAND-BY LED DRIVE

7 P71 (INT4) O C MOTOR VOLUME UP

8 P70 (INT3) I C REMOTE CONTROL SIGNAL INPUT

9 P07 O C TAPE-2 LED, ARELAY DRIVE

10 P06 O C TAPE-1 LED, ARELAY DRIVE

11 P05 O C

12 P04 O C AUX-2 LED, ARELAY DRIVE

13 P03 O C DVD/AUX-1 LED, ARELAY DRIVE

14 P02 O C TUNER LED, ARELAY DRIVE

15 P01 O C CD LED, ARELAY DRIVE

16 P00 O C PHONE LED, ARELAY DRIVE

17 TEST to VSS

18 RESET RESET

19 XIN X’tal

20 XOUT X’tal

21 Vss (VAss) GND

22 VAREF to VDD

23 P60 I C MODEL SETTING INPUT

24 P61 I C

25 P62 I C

26 P63 I C FUNCTION SELECTOR SW INPUT

27 P64 I C

28 P65 O C MUTING SIGNAL INPUT

29 P66 O C

30 P67 O C

31 P10 (INT0) I C PROTECTOR INPUT

32 P11 (INT1) I C POWER OFF

33 P12 (INT2) O C MOTOR VOLUME DOWN

34 P13 O C

35 P14 O C

36 P15 O C

37 P16 O C

38 P17 O C

39 P20 STOP O C STOP MODE CANCEL

40 P21 O C

41 P22 O C

42 VDD +5V

NOTE: Pin No. : Terminal number of microcomputer.

Port Name

Type

Port Name : The name entered on the data sheet of microcomputer.

I/O : Input or output of port.

"I" = Input port

"O" = Output port

Type : Composition of port in case of output port.

"C" = CMOS output

Function : Function and logical level explanation of signals to be interface.

FunctionI/O

7

PMA-2000IVR

LB1639 (IC902)

TOP VIEW

V

V

IN1

1

2

GND

3

CONT

V

4

V

IN2



OTHERS

OUT1

8

V

CC

7

N.C.

6

5

OUT2

V

V

IN1

1

GP1U27X (Remote Control Sensor)
(IC103)

TOP VIEW

BA4558 (IC701)

V

OUT1

V

OUT2

5

8

REF

V

CC

V

7

V

CONT

3

GND

2

V

IN2

4

N.C.

6

NJM2082D (IC201)

A OUTPUT

A –INPUT

A+INPUT

1

1

2

3

V

4

V

8

B OUTPUT

7

2

6

B –INPUT

B +INPUT

5

Vcc

Vout

GND



TRANSISTORS

2SA933S (S)
2SA988 (E/F)
2SA1145 (O/Y)
2SA1546 (M/L)
2SB1328 (P)
2SC1740S (S)
2SC1841 (E/F)
2SC2705 (Y)
2SC3421 (O/Y)
2SC4001 (M/L)
2SD2004 (P)

FRONT

VIEW

C

E

2SA1837 (Y)
2SC4793 (Y)

B

Head
Amp

FRONT

VIEW

BCE

Limiter
Amp

Detector &

BPF

Comparator

DTA114ES
DTC114ES
DTC143ES
DTC143ZS
DTC144WS

FRONT

VIEW

C

B

E

Integrator

GND

DTA114ES

Hysteresis
Comparator

Vcc

PNP Type

Vout

DTC114ES
DTC143ES
DTC143ZS
DTC144WS

NPN Type

C

R1

B

DTA114ES

R1

10kohm

R2

10kohm

DTC114ES

DTC143ES

DTC143ZS

DTC144WS

R2

R1

10kohm

4.7kohm

4.7kohm 47kohm

47kohm

R2

10kohm

4.7kohm

22kohm

E

8

PMA-2000IVR

11EQS06
31DQ06
1SS270A

HZS2B-1
HZS3B-2
HZS5C-1
HZS9B-1
HZS11A-1
HZS12A-1
HZS30-1
MTZJ3.3A
MTZJ7.5A
MTZJ7.5C
MTZJ18A

SLR-56VC (Red)

TOP VIEW

2SJ78
2SK215

FRONT

VIEW

GSD

2SK373 (Y)

FRONT

VIEW

SGD

2SK184C (GR/BL)
2SK369 (BL/GR)-C

FRONT

VIEW

DGS

2SK2967

FRONT

VIEW

GDS



DIODES (LED included)

FCH20A15

FRONT

VIEW

AKA

FRH20A15

FRONT

VIEW

KAK

SF0R3G42

A

G

K

PTH9M04BD222TS2F333

FRONT

VIEW

GAK

SEL2E10C (Blue)

TOP VIEW

SIDE VIEW

SLR-342MG (Green)



THYRISTOR



THERMISTOR

9

PRINTED WIRING BOARDS

PMA-2000IVR

1

2

1U-3432 POWER AMP P.W.B. UNIT Ass'y

1 5

3

4

5

1

5

76

15

8

A

15

18

1 5

1 3

1 8

B

8

15

15

12

1

4

5

110

C

D

16

1

16

18

1 5

14

13

110

10

1 2

COMPONENT SIDE

E

10

PMA-2000IVR

1

1U-3130 INPUT P.W.B. UNIT Ass'y

1

1

6

10

2

3

4

5

76

8

A

10

5

8

1

4

11 3

16

1

9

8

B

1 3

1

5

1

1 11

C

1 3

13

1 101 11

58

4

21

22

1 3

6

1

5

1

4

1

42

13

1

D

E

1

5

1

5

COMPONENT SIDE

11

PMA-2000IVR

1

2

1U-3433 FLAT AMP P.W.B. UNIT Ass'y

3

4

5

76

8

A

15

15

110

B

13

1 3

C

D

COMPONENT SIDE

E

12

NOTE FOR PARTS LIST

l Part indicated with the mark "" are not always in stock and possibly to take a long period of time for supplying, or in

some case supplying of part may be refused.

l When ordering of part, clearly indicate "1" and "I" (i) to avoid mis-supplying.
l Ordering part without stating its part number can not be supplied.
l Part indicated with the mark " " is not illustrated in the exploded view.
l Not including Carbon Film ±5%, 1/4W Type in the P.W.Board parts list. (Refer to the Schematic Diagram for those parts.)

WARNING:

Parts marked with this symbol
Use ONLY replacement parts recommended by the manufacturer.

have critical characteristics.

PMA-2000IVR

ll

l Resistors

ll

Ex.: RN 14K 2E 182 G FR

Type Shape Power Resist- Allowable Others

and per- ance error
formance

t

RD :Carbon 2B : 1/8W F : ±1% P : Pulse-resistant type
RC : Composition 2E : 1/4W G : ±2% NL : Low noise type
RS : Metal oxide film 2H : 1/2W J : ±5% NB : Non-burning type
RW : Winding 3A : 1W K : ±10% FR : Fuse-resistor
RN : Metal film 3D : 2W M : ±20% F : Lead wire for ming
RK : Metal mixture 3F : 3W

t

3H : 5W

Resistance

1 8 2 ⇒ 1800 ohm = 1.8 kohm

s

s

• Units: ohm

1 R 2 ⇒ 1.2 ohm

s

s

• Units: ohm

Indicates number of zeros after effective number.
2-digit effective number.

1-digit effective number.
2-digit effective number, decimal point indicated by R.

t

t

ll

l Capacitors

ll

Ex.: CE 04W 1H 2R2 M BP

Type Shape Dielectric Capacity Allowable Others

and per- strength error
formance

t

CE : Aluminum foil 0J : 6.3V F : ±1% HS: High stability type

electrolytic

CA : Aluminum solid 1A : 10V G : ±2% BP : Non-polar type

electrolytic
CS : Tantalum electrolytic 1C : 16V J : ±5% HR: Ripple-resistant type
CQ : Film 1E : 25V K : ±10% DL : For change and discharge
CK : Ceramic 1V : 35V M : ±20% HF : For assuring high

CC : Ceramic 1H : 50V Z : +80% U : UL part
CP : Oil 2A : 100V –20% C : CSA part
CM : Mica 2B : 125V P : +100% W : UL-CSA type
CF : Metallized 2C : 160V –0% F : Lead wire forming
CH : Metallized 2D : 200V C : ±0.25pF

t

2E : 250V D : ±0.5pF
2H : 500V = : Others
2J : 630V

t

Capacity (electrolyte only)

2 2 2 ⇒ 2200µF

s

s

• Units: µF.

2 R 2 ⇒ 2.2µF

s

s

• Units: µF.

Indicates number of zeros after effective number.
2-digit effective number.

1-digit effective number.
2-digit effective number, decimal point indicated by R.

Capacity (except electrolyte)

2 2 2 ⇒ 2200pF=0.0022µF

s

s

(More than 2) Indicates number of zeros after effective number.

• Units: pF.

2 2 1 ⇒ 220pF

s

s

(0 or 1) Indicates number of zeros after effective number.

• Units: pF.

• When the dielectric strength is indicated in AC, "AC" is included after the dieelectric

strength value.

2-digit effective number.

2-digit effective number.

t

requency

13

PMA-2000IVR

PARTS LIST OF P.W.B. UNIT ASS'Y

1U-3432 POWER AMP UNIT ASS'Y

Ref. No. Part No. Part Name Remarks Ref. No. Part No. Part Name Remarks

SEMICONDUCTORS GROUP

IC103 499 0290 007 IC GP1U271X

IC201 263 0743 007 IC NJM2082DD

TR453 274 0151 903 Transistor 2SD2004(P)T105

TR501-504 275 0055 015

TR505-508 273 0235 923 Transistor 2SC1841-T(E/F)

TR509-512 271 0304 007 Transistor 2SA1546(M/L)

TR513,514 273 0453 006 Transistor 2SC4001(M/L)

TR515,516 273 0323 000 Transistor 2SC3421 O/Y

TR517,518 273 0442 004 Transistor 2SC4793 (Y)

TR519,520 271 0282 006 Transistor 2SA1837 (Y)

TR525,526 273 0235 923 Transistor 2SC1841-T(E/F)

TR527,528 271 0131 924 Transistor 2SA988-T(E/F)

D101 276 0432 903 Diode 1SS270A TE

D453 276 0432 903 Diode 1SS270A TE

D501,502 276 0432 903 Diode 1SS270A TE

D505-508 276 0432 903 Diode 1SS270A TE

D513-516 276 0432 903 Diode 1SS270A TE

Transistor 2SK184C (GR)/(BL)

Note: The symbol in the column "Remarks" indicate the following destinations.

G1C: China model G1H: Hong Kong model
G2A: Singapore model KEU: U.S.A. model

R517,518 241 2446 001 Carbon film 8.2 kohm 1/2W RD05A2H822J(RMG)

R519-522 241 2315 983

R523-526 241 2377 947

R529,530 241 2377 921

R531,532 244 2068 048 Metal oxide 15 kohm 1W(NB)

R533,534 241 2424 926 Carbon film 5.6 kohm 1/4W

R535,536 241 2422 944 Carbon film 1 kohm 1/4W

R537-540 241 2371 930

R541,542 241 2429 963 Carbon film 1 Mohm 1/4W

R543,544 241 2423 969 Carbon film 3.3 kohm 1/4W

R545,546 244 2068 035 Metal oxide 390 ohm 1W(NB)

R547,548 244 2068 019 Metal oxide 200 ohm 1W(NB)

R549,550 244 2068 035 Metal oxide 390 ohm 1W(NB)

R553-556 244 2068 006 Metal oxide 100 ohm 1W(NB)

R557,558 244 2067 010 Metal oxide 0.1 ohm 2W(NB)

R559,560 241 2380 963

R565,566 244 2058 074 Metal oxide 22 ohm 1W(NB)

R567,568 241 2425 925 Carbon film 15 kohm 1/4W

R571,572 241 2447 796 Carbon film 51 kohm 1/2W RD05A2H513JF(RMG)

R573,574 241 2424 984 Carbon film 10 kohm 1/4W

R575,576 241 2426 908 Carbon film 33 kohm 1/4W

R585,586 244 2067 007 Metal oxide 10 ohm 2W(NB)

R997-999 241 2422 944 Carbon film 1 kohm 1/4W

Fusible resistor 330 ohm 1/4W

Carbon film 100 ohm 1/4W(NB)

Carbon film 82 ohm 1/4W(NB)

Fusible resistor 160 ohm 1/4W

Carbon film 2.2 kohm 1/4W(NB)

RD14B2E331GFRST

RD14B2E101JNBST

RD14B2E820JNBST

RS14B3A153JNBS RSFSV

RD14B2E562JT(PSNB)

RD14B2E102JT(PSNB)

RD14B2E161GFRST

RD14B2E105JT(PSNB)

RD14B2E332JT(PSNB)

RS14B3A391JNBS RSFSV

RS14B3A201JNBS RSFSV

RS14B3A391JNBS RSFSV

RS14B3A101JNBS RSFSV

RS14B3D0R1JNBF RSFKL

RD14B2E222JNBST

RS14B3A220JNBS RSFSV

RD14B2E153JT(PSNB)

RD14B2E103JT(PSNB)

RD14B2E333JT(PSNB)

RS14B3D100JNBF RSFKL

RD14B2E102JT(PSNB)

ZD471 276 0470 907 Zener diode HZS11A-1TD

ZD509,510 276 0468 906 Zener diode HZS9B-1TD

ZD511,512 276 0450 901 Zener diode HZS2B-1TD

LD108 393 9584 908 LED SEL2E10C

PT501,502 279 0034 041

RESISTORS GROUP

R201,202 241 2422 944 Carbon film 1 kohm 1/4W

R209,210 241 2427 965 Carbon film 150 kohm 1/4W

R233,234 241 2423 972 Carbon film 3.6 kohm 1/4W

R251,252 241 2313 985

R463 241 2422 944 Carbon film 1 kohm 1/4W

R471,472 241 2420 904 Carbon film 100 ohm 1/4W

R473,474 241 2429 963 Carbon film 1 Mohm 1/4W

R475-478 241 2427 923 Carbon film 100 kohm 1/4W

R501,502 241 2445 743 Carbon film 3.3 kohm 1/2W RD05A2H332JF(RMG)

R503-506 241 2424 900 Carbon film 4.7 kohm 1/4W

R507,508 241 2420 988 Carbon film 220 ohm 1/4W

R509,510 241 2450 796 Carbon film 1 Mohm 1/2W RD05A2H105JF(RMG)

R511,512 241 2422 973 Carbon film 1.3 kohm 1/4W

R513,514 241 2447 741 Carbon film 33 kohm 1/2W RD05A2H333JF(RMG)

R515,516 241 2444 760 Carbon film 1.2 kohm 1/2W RD05A2H122JF(RMG)

Thermistor PTH9M04BD222TS2F333

RD14B2E102JT(PSNB)

RD14B2E154JT(PSNB)

RD14B2E362JT(PSNB)

Fusible resistor 4.7 ohm 1/4W

RD14B2E4R7JFRST

RD14B2E102JT(PSNB)

RD14B2E101JT(PSNB)

RD14B2E105JT(PSNB)

RD14B2E104JT(PSNB)

RD14B2E472JT(PSNB)

RD14B2E221JT(PSNB)

RD14B2E132JT(PSNB)

VR201 211 0798 103 Variable resistor 100kohm V14V20FW104K

VR202 211 0834 012 Variable resistor 10kohm V14V20FA103K

VR203 211 0834 009 Variable resistor 30kohm V14V20FA303K

VR351 211 0873 002 Variable resistor 30kohm V1820V30FB303

VR501,502 211 8005 021 Semi fixed resistor 4.7kohm V06QB472

CAPACITORS GROUP

C101,102 253 8026 703 Ceramic 4700pF/250V(AC) CK45E2EAC472MC

C103 254 4558 702 Electrolytic 100uF/50V

C121 254 4313 963 Electrolytic 1uF/50V

C151 255 4235 934

C207,208 255 4237 929

C209,210 254 4583 955 Electrolytic 22uF/50V

C211,212 254 4260 980 Electrolytic 10uF/50V

C217,218 256 1058 913 Metalized 0.033uF/50V CF93A1H333JT (JL)

C219,220 254 4260 919 Electrolytic 0.22uF/50V

C221,222 254 4260 906 Electrolytic 0.1uF/50V

C223,224 254 4260 935 Electrolytic 0.47uF/50V

C225,226 255 4232 924

C351 256 1054 001 Metalized 1uF/50V CF93B1H105K(GSG)

C354 254 3055 918 Electrolytic 10uF/35V

C355 253 1181 917 Ceramic 0.022uF/50V

Polypropylene film 0.01uF/100V

Polypropylene film 56pF/100V

Polypropylene film 39pF/100V

CE04W1H101MC(RFS)

CE04W1H010MT(ASF)

CQ93P2A103JT(NH)

CQ93P2A560JT(NH)

CE04W1H220MT(ROB)

CE04W1H100MT (SME)

CE04W1HR22MT (SME)

CE04W1H0R1MT (SME)

CE04W1HR47MT (SME)

CQ93P2A390JT(NH)

CE04D1V100MBPT (SME)

CK45F1H223ZT(DD-3)

14

PMA-2000IVR

Ref. No. Part No. Part Name Remarks

C463 254 4313 921 Electrolytic 22uF/50V

C471,472 255 4251 976

C473-476 254 4313 918 Electrolytic 10uF/50V

C481 254 4313 921 Electrolytic 22uF/50V

C482 254 4313 934 Electrolytic 47uF/50V

C501,502 255 4251 976

C503,504 255 4255 972

C505,506 254 4557 949 Electrolytic 22uF/50V

C507,508 255 4250 993

C509,510 255 4242 901

C517,518 255 4252 975

C519,520 255 4251 976

C521-524 254 4558 715 Electrolytic 220uF/50V

C527,528 255 4251 976

C529-534 255 4256 955

C537-540 254 4558 715 Electrolytic 220uF/50V

C541,542 256 8036 006 Metalized 0.1uF/250V CF93B2E104K(WAG)

C545-548 254 4562 714 Electrolytic 100uF/100V

C557,558 254 4557 952 Electrolytic 47uF/50V

C561,562 254 4557 949 Electrolytic 22uF/50V

OTHER PARTS GROUP Q'ty

CN521-524 205 1230 063 6P Pin header (6035) 4

Polypropylene film 100pF/100V

Polypropylene film 100pF/100V

Polypropylene film 4700pF/100V

Polypropylene film 47pF/100V

Polypropylene film 15pF/100V

Polypropylene film 270pF/100V

Polypropylene film 100pF/100V

Polypropylene film 100pF/100V

Polypropylene film 0.01uF/100V

CE04W1H220MT(ASF)

CQ93P2A101JT(NH2)

CE04W1H100MT(ASF)

CE04W1H220MT(ASF)

CE04W1H470MT(ASF)

CQ93P2A101JT(NH2)

CQ93P2A472JT(NH2)

CE04W1H220MT(RFS)

CQ93P2A470JT(NH2)

CQ93P2A150JT(NH)

CQ93P2A271JT(NH2)

CQ93P2A101JT(NH2)

CE04W1H221MC(RFS)

CQ93P2A101JT(NH2)

CQ93P2A103JT(NH2)

CE04W1H221MC(RFS)

CE04W2A101MC(RFS)

CE04W1H470MT(RFS)

CE04W1H220MT(RFS)

Ref. No. Part No. Part Name Remarks Q'ty

F101 206 1046 043 Fuse 10A KEU 1

F108,109 206 1046 027 Fuse 5A KEU 2

F108,109 206 1015 016 Fuse 1.25A G2A 2

FF101 202 0040 909 Fuse clip 1

FF108,109 202 0040 909 Fuse clip G2A,KEU 2

FH101 202 0040 909 Fuse clip 1

FH108,109 202 0040 909 Fuse clip G2A,KEU 2

JK306 204 8530 006 4P Pin jack 1

JK501 204 8480 004 Head phone jack (SW) 1

RL101 214 0202 009 Relay DG1U TV-8 1

RL403 214 0127 003 Relay (RY-12W) 1

RL501,502 214 0195 006 Relay FTR-F1 2

S101 212 1176 002 Power switch 1

S201 212 1157 005 1P Push switch 1

S202 212 1147 002 Slide switch 1

ST201

ST203

ST205 205 1034 007 M3 Screw terminal 1



Style pin 1



Style pin 1

CW101 204 2315 023 10P EH-SCN Connector cord 1

CX011-016 205 0864 003 M3 Screw terminal 6

CX021 205 0348 024 2P Wrapping terminal 1

CX022 205 0581 001 2P VH Connector base 1

CX023,024 205 0348 024 2P Wrapping terminal 2

CX033 205 0343 032 3P Connector base (KR-PH) 1

CX041 205 0343 045 4P Connector base (KR-PH) 1

CX051 205 0277 056 5P EH Connector base (RD) 1

CX052 205 0279 054 5P PH SID Connector base 1

CX053 205 0343 058 5P Connector base (KR-PH) 1

CX054,055 205 0233 058 5P EH Connector base 2

CX056 205 0277 056 5P EH Connector base (RD) 1

CX062 205 0343 061 6P Connector base (KR-PH) 1

CX081 205 0233 087 8P EH Connector base 1

CX101 205 0275 003 10P EH Connector base 1

CX911-914 205 0864 003 M3 Screw terminal 4

CY022 205 0581 001 2P VH Connector base 1

CY035 205 0343 032 3P Connector base (KR-PH) 1

CY061 205 0233 061 6P EH Connector base 1

CY103 205 0502 006 10P EH Connector base (RD) 1

CZ057 205 0278 055 5P EH Connector base (BK) 1

CZ081 204 2311 001 8P EH-SCN Connector cord 1

T101 233 6257 017 Power trans mini G1C,G1H,G2A 1

T101 233 6267 007 Power trans mini KEU 1

TP501,502 205 0154 030 3P NH Connector base 2

W352 203 0629 019 1P Contact ass'y 1

W501 203 0526 073 1P Contact ass'y 1

415 0866 006 Condenser cover 2

513 3777 001 Fuse label (4A) G1C,G1H,G2A 1

513 3777 014 Fuse label (1.25A) G2A 1



Vinyl wire 4



Vinyl wire 2



P.V.C. Tube (L=20) 4

513 1873 075 Fuse label (10A) KEU 1

513 1873 088 Fuse label (5A) KEU 1

F101 206 1015 087 Fuse (4.0A) G1C,G1H,G2A 1

15

1U-3130H INPUT UNIT ASS'Y

Ref. No. Part No. Part Name Remarks

SEMICONDUCTORS GROUP

IC701 263 0322 004 IC BA4558

IC901 262 2581 002 IC TMP87CC46N-4C08

IC902 263 0476 002 IC LB1639

IC903 263 0648 005 IC MC7806CT

PMA-2000IVR

Ref. No. Part No. Part Name Remarks

ZD603 276 0645 907 Zener diode MTZJ18A T77

ZD604 276 0460 904 Zener diode HZS5C-1TD

ZD605 276 0473 904 Zener diodeÞ HZS12A-1TD

ZD902 276 0634 905 Zener diodeMTZJ3.3AT77

ZD903 276 0644 911 Zener diodeMTZJ7.5A T77

TR301 274 0151 903 Transistor 2SD2004(P)T105

TR302 275 0042 905 Transistor 2SK373(Y)TPE2

TR601-606 273 0303 910 Transistor 2SC1740S(S)-T

TR607 271 0192 905 Transistor 2SA933S(S)TP

TR608 273 0303 910 Transistor 2SC1740S(S)-T

TR611 272 0107 906 Transistor 2SB1328(P)T105

TR612 269 0112 908

TR613 269 0020 906

TR614 273 0303 910 Transistor 2SC1740S(S)-T

TR615 274 0151 903 Transistor 2SD2004(P)T105

TR618,619 273 0303 910 Transistor 2SC1740S(S)-T

TR620 269 0018 905

TR701-704 275 0038 045

TR901 269 0020 906

TR902 269 0046 906

TR903 269 0020 906

TR904 273 0303 910 Transistor 2SC1740S(S)-T

TR907 273 0303 910 Transistor 2SC1740S(S)-T

TR908 269 0020 906

TR909,910 269 0046 906

TR911-917 269 0160 905 Transistor DTC143ZSATP

TR921,922 269 0046 906

D301-307 276 0432 903 Diode 1SS270A TE

D601,602 276 0713 004 Diode V31DQ06

D603,604 276 0715 002 Diode 11EQS06

D606,607 276 0432 903 Diode 1SS270A TE

Transistor DTC144WS (47K-22K)T

Transistor DTC114ES(10K-10K)T

Transistor DTC143ES(4.7K-4.7K)T

Transistor 2SK369 (BL)/(GR)-C

Transistor DTC114ES(10K-10K)T

Transistor DTA114ES(10K-10K)T

Transistor DTC114ES(10K-10K)T

Transistor DTC114ES(10K-10K)T

Transistor DTA114ES(10K-10K)T

Transistor DTA114ES (10K-10K)T

LD901-907 393 9557 906 LED SLR-56VCTE7

SC601 279 0038 908 Thyristor SF0R3G42

RESISTORS GROUP

R301-310 241 2428 948 Carbon film 330 kohm 1/4W

R313,314 241 2428 948 Carbon film 330 kohm 1/4W

R607,608 241 2426 924 Carbon film 39 kohm 1/4W

R614 241 2424 984 Carbon film 10 kohm 1/4W

R623-626 244 2052 960 Metal oxide 220 ohm 1W(NB)

R627 241 2423 927 Carbon film 2.2 kohm 1/4W

R705,706 241 2420 904 Carbon film 100 ohm 1/4W

R707,708 241 2426 940 Carbon film 47 kohm 1/4W

R709,710 241 2417 962 Carbon film 10 ohm 1/4W

R711-714 241 2423 956 Carbon film 3 kohm 1/4W

R715,716 241 2420 975 Carbon film 200 ohm 1/4W

R717,718 241 2423 914 Carbon film 2 kohm 1/4W

R719,720 241 2419 986 Carbon film 82 ohm 1/4W

R721,722 241 2422 928 Carbon film 820 ohm 1/4W

R723,724 241 2327 913 Carbon film 2.2 Mohm 1/4W RD14B2E225JT

R725,726 241 2426 940 Carbon film 47 kohm 1/4W

R727,728 241 2423 985 Carbon film 3.9 kohm 1/4W

R729,730 241 2418 945 Carbon film 22 ohm 1/4W

R731,732 241 2420 988 Carbon film 220 ohm 1/4W

R733,734 241 2421 961 Carbon film 470 ohm 1/4W

R735,736 241 2429 918 Carbon film 620 kohm 1/4W

R737,738 241 2417 920 Carbon film 6.8 ohm 1/4W

R739,740 241 2313 985

Fusible resistor 4.7 ohm 1/4W

RD14B2E334JT(PSNB)

RD14B2E334JT(PSNB)

RD14B2E393JT(PSNB)

RD14B2E103JT(PSNB)

RS14B3A221JNBST(S)

RD14B2E222JT(PSNB)

RD14B2E101JT(PSNB)

RD14B2E473JT(PSNB)

RD14B2E100JT(PSNB)

RD14B2E302JT(PSNB)

RD14B2E201JT(PSNB)

RD14B2E202JT(PSNB)

RD14B2E820JT(PSNB)

RD14B2E821JT(PSNB)

RD14B2E473JT(PSNB)

RD14B2E392JT(PSNB)

RD14B2E220JT(PSNB)

RD14B2E221JT(PSNB)

RD14B2E471JT(PSNB)

RD14B2E624JT(PSNB)

RD14B2E6R8JT(PSNB)

RD14B2E4R7JFRST

D701,702 276 0432 903 Diode 1SS270A TE

D801 276 0706 008 Diode FCH20A15

D802 276 0707 007 Diode FRH20A15

D901,902 276 0704 903 Diode FRH20A15

D903,904 276 0432 903 Diode 1SS270A TE

D908-922 276 0432 903 Diode 1SS270A TE

ZD301 276 0473 904 Zener diode HZS12A-1TD

ZD601 276 0635 904 Zener diodeMTZJ7.5CT77

ZD602 276 0644 911 Zener diode MTZJ7.5A T77

R901 241 2387 940

R996-998 241 2417 962 Carbon film 10 ohm 1/4W

JV124 244 2050 904 Metal oxide 22 ohm 1W G1C,G1H

JV124 244 2052 928 Metal oxide 47 ohm 1W G2A

CAPACITORS GROUP

C311 254 4368 934 Electrolytic 100uF/25V

C312 254 4558 702 Electrolytic 100uF/50V

C313-317 254 4256 949 Electrolytic 100uF/25V

C319 254 4557 952 Electrolytic 47uF/50V

C320 255 4235 934

Carbon film 4.7 ohm 1/4W(NB)

Polypropylene film 0.01uF/100V

RD14B2E4R7JNBST

RD14B2E100JT(PSNB)

CE04W1E101MT(ASF)

CE04W1H101MC(RFS)

CE04W1E101MT (SME)

CE04W1H470MT(RFS)

CQ93P2A103JT(NH)

16

PMA-2000IVR

Ref. No. Part No. Part Name Remarks

C603 255 4257 938

C604 254 4576 700 Electrolytic 2200uF/35V

C607 254 4260 919 Electrolytic 0.22uF/50V

C608,609 254 4260 948 Electrolytic 1uF/50V

C610 254 4480 906 Electrolytic 330uF/6.3V CE04W0J331MT(ASF)

C611 254 4254 954 Electrolytic 220uF/16V

C612 254 4260 977 Electrolytic 4.7uF/50V

C613 254 4313 921 Electrolytic 22uF/50V

C615 254 4580 709 Electrolytic 220uF/50V

C616 255 4257 938

C619 255 4235 921

C620 254 4313 950 Electrolytic 100uF/50V

C703,704 255 4237 961

C705,706 255 4232 937

C707,708 254 4313 950 Electrolytic 100uF/50V

C711,712 255 4232 995

C713,714 254 4313 950 Electrolytic 100uF/50V

C715,716 254 4313 918 Electrolytic 10uF/50V

C717,718 255 4237 945

C719,720 255 4236 713

C721,722 255 4237 958

C723,724 255 4232 937

C731,732 254 4583 971 Electrolytic 47uF/50V

C805,806 254 4563 001 Electrolytic 2.2uF/100V

C808 256 1054 001 Metalized 1uF/50V CF93B1H105K(GSG)

Polypropylene film 0.022uF/100V

Polypropylene film 0.022uF/100V

Polypropylene film 270pF/100V

Polypropylene film 150pF/100V

Polypropylene film 1000pF/100V

Polypropylene film 3300pF/100V

Polypropylene film 1200pF/100V

Polypropylene film 0.068uF/100V

Polypropylene film 0.018uF/100V

Polypropylene film 1000pF/100V

CQ93P2A223JT(NH2)

CE04W1V222MC(RE3)

CE04W1HR22MT (SME)

CE04W1H010MT (SME)

CE04W1C221MT (SME)

CE04W1H4R7MT (SME)

CE04W1H220MT(ASF)

CE04W1H221MC(ROB)

CQ93P2A223JT(NH2)

CQ93P2A271JT(NH)

CE04W1H101MT(ASF)

CQ93P2A151JT(NH)

CQ93P2A102JT(NH)

CE04W1H101MT(ASF)

CQ93P2A332JT(NH)

CE04W1H101MT(ASF)

CE04W1H100MT(ASF)

CQ93P2A122JT(NH)

CQ93P2A683JC(NH)

CQ93P2A183JT(NH)

CQ93P2A102JT(NH)

CE04W1H470MT(ROB)

CE04W2A2R2M(ARSAG2)

Ref. No. Part No. Part Name Remarks

OTHER PARTS GROUP Q'ty

CX031 205 0653 036 3P VH Connector base 1

CX035 205 0343 032 3P Connector base (KR-PH) 1

CX061 205 0233 061 6P EH Connector base 1

CX102 205 0375 000 10PConnector base (KR-PH) 1

CX111 205 0279 012 11P PH SID Connector base 1

CX915-918 205 0864 003 M3 Screw terminal 4

CY033 205 0343 032 3P Connector base (KR-PH) 1

CY041 205 0343 045 4P Connector base (KR-PH) 1

CY051 205 0277 056 5P EH Connector base (RD) 1

CY052,053 205 0343 058 5P Connector base (KR-PH) 2

CY054 205 0233 058 5P EH Connector base 1

CY062 205 0343 061 6P Connector base (KR-PH) 1

CY111 205 0375 013 11P Connector base (KR-PH) 1

CZ102 205 0375 000 10P Connector base(KR-PH) 1

JK301-304 204 8530 006 4P Pin jack 4

JK305 204 8531 005 2P Pin jack (C-GND) 1

RL301-307 214 0127 003 Relay (RY-12W) 7

RL601 214 0127 003 Relay (RY-12W) 1

S301 212 4331 006 Slide switch (4-6) remote 1

S701 212 4728 004 1P Push switch 1

S901 212 0407 002 Rotaly switch (SRRM-12) 1

C903 254 4368 934 Electrolytic 100uF/25V

C905 254 4368 934 Electrolytic 100uF/25V

C906 255 4235 934

C907 254 4406 702 Electrolytic 3300uF/16V

C908 255 4235 934

C909 254 4368 934 Electrolytic 100uF/25V

C910 256 1058 971 Metalized 0.1uF/50V CF93A1H104JT (JL)

C911 255 4235 934

C913 256 1058 971 Metalized 0.1uF/50V CF93A1H104JT (JL)

C914 254 4260 919 Electrolytic 0.22uF/50V

C915 255 4235 934

C920 254 4313 918 Electrolytic 10uF/50V

C926 254 4260 951 Electrolytic 2.2uF/50V

C927 254 4313 918 Electrolytic 10uF/50V

Polypropylene film 0.01uF/100V

Polypropylene film 0.01uF/100V

Polypropylene film 0.01uF/100V

Polypropylene film 0.01uF/100V

CE04W1E101MT(ASF)

CE04W1E101MT(ASF)

CQ93P2A103JT(NH)

CE04W1C332MC(SMG)

CQ93P2A103JT(NH)

CE04W1E101MT(ASF)

CQ93P2A103JT(NH)

CE04W1HR22MT (SME)

CQ93P2A103JT(NH)

CE04W1H100MT(ASF)

CE04W1H2R2MT (SME)

CE04W1H100MT(ASF)

W602 203 0629 019 1P contact ass'y 1

W807,808 205 0864 003 M3 Screw terminal 2

W809 203 0616 006 1P SIN Cord ass'y 1

XL901 399 0107 900

471 3304 028 Screw 3X8 CBS-B 2

Ceramic resonator CST4.19MGW-TF1



Vinyl wire 1



Radiator 2

1

17

1U-3433 FLAT AMP UNIT ASS'Y

SEMICONDUCTORS GROUP

TR401-404 275 0042 905 Transistor 2SK373(Y)TPE2

TR405 273 0442 004 Transistor 2SC4793 (Y)

TR406 271 0272 003 Transistor 2SA1837-Y

TR407 273 0442 004 Transistor 2SC4793 (Y)

TR408 271 0272 003 Transistor 2SA1837-Y

TR421-424 273 0281 919 Transistor 2SC2705 (Y)TPE6

TR425-428 275 0038 045

TR429-432 273 0281 919 Transistor 2SC2705 (Y)TPE6

TR433-436 271 0168 900

TR437,438 275 0069 001 Transistor 2SK215

TR439,440 275 0068 002 Transistor 2SJ78

TR451 269 0020 906

D421-426 276 0432 903 Diode 1SS270A TE

D451,452 276 0432 903 Diode 1SS270A TE

ZD401,402 276 0483 907 Zener diode HZS30-1TD

ZD405,406 276 0645 907 Zener diode MTZJ18A T77

ZD421,422 276 0453 911 Zener diode HZS3B-2TD

ZD423,424 276 0460 904 Zener diode HZS5C-1TD

ZD451 276 0460 904 Zener diode HZS5C-1TD

Transistor 2SK369 (BL)/(GR)-C

Transistor 2SA1145 (O)/(Y)TPE6

Transistor DTC114ES(10K-10K)T

PMA-2000IVR

Ref. No. Part No. Part Name RemarksRef. No. Part No. Part Name Remarks

C413,414 254 4557 952 Electrolytic 47uF/50V

C415,416 254 4558 702 Electrolytic 100uF/50V

C421,422 255 4251 976

C423,424 254 4557 936 Electrolytic 10uF/50V

C425,426 255 4256 955

C427-430 254 4557 923 Electrolytic 4.7uF/50V

C431,432 255 4250 977

C433-436 255 4255 972

C439,440 255 4256 955

C441-444 254 4558 702 Electrolytic 100uF/50V

C451 254 4558 715 Electrolytic 220uF/50V

C453 254 4558 715 Electrolytic 220uF/50V

C455,456 255 4250 993

C461,462 254 4313 934 Electrolytic 47uF/50V

OTHER PARTS GROUP Q'ty

CW055 203 8468 036 5P EH-SCN Connector cord 1

CW056 203 8468 049 5P EH-SCN Connector cord 1

CW931 203 5179 027 3P SCN-SCN Connector cord 1

CX057 205 0278 055 5P EH Connector base (BK) 1

CX103 205 0502 006 10P EH Connector base (RD) 1

Polypropylene film 10pF/100V

Polypropylene film 0.01uF/100V

Polypropylene film 39pF/100V

Polypropylene film 4700pF/100V

Polypropylene film 0.01uF/100V

Polypropylene film 47pF/100V

CE04W1H470MT(RFS)

CE04W1H101MC(RFS)

CQ93P2A101JT(NH2)

CE04W1H100MT(RFS)

CQ93P2A103JT(NH2)

CE04W1H4R7MT(RFS)

CQ93P2A390JT(NH2)

CQ93P2A472JT(NH2)

CQ93P2A103JT(NH2)

CE04W1H101MC(RFS)

CE04W1H221MC(RFS)

CE04W1H221MC(RFS)

CQ93P2A470JT(NH2)

CE04W1H470MT(ASF)

LD421,422 393 9540 900 LED SLR-342MGTF7MN

RESISTORS GROUP

R401-404 241 2422 944 Carbon film 1 kohm 1/4W

R421,422 241 2429 963 Carbon film 1 Mohm 1/4W

R423,424 241 2420 988 Carbon film 220 ohm 1/4W

R425,426 241 2426 908 Carbon film 33 kohm 1/4W

R427,428 241 2426 940 Carbon film 47 kohm 1/4W

R429-432 241 2422 944 Carbon film 1 kohm 1/4W

R433,434 241 2421 929 Carbon film 330 ohm 1/4W

R435,436 241 2422 902 Carbon film 680 ohm 1/4W

R437,438 241 2429 963 Carbon film 1 Mohm 1/4W

R439,440 241 2424 926 Carbon film 5.6 kohm 1/4W

R441,442 241 2422 944 Carbon film 1 kohm 1/4W

R443,444 241 2377 947

R445-448 241 2376 964

R449,450 241 2428 980 Carbon film 470 kohm 1/4W

R451-454 244 2058 032 Metal oxide 47 ohm 1W(NB)

R457,458 241 2420 904 Carbon film 100 ohm 1/4W

F401,402 241 2387 940

CAPACITORS GROUP

C401,402 254 4562 701 Electrolytic 47uF/100V

C405,406 255 4256 955

C407,408 254 4557 952 Electrolytic 47uF/50V

C409,410 254 4558 728 Electrolytic 470uF/50V

C411,412 255 4239 707

Carbon film 100 ohm 1/4W(NB)

Carbon film 47 ohm 1/4W(NB)

Carbon film 4.7 ohm 1/4W(NB)

Polypropylene film 0.01uF/100V

Polypropylene film 0.047uF/100V

RD14B2E102JT(PSNB)

RD14B2E105JT(PSNB)

RD14B2E221JT(PSNB)

RD14B2E333JT(PSNB)

RD14B2E473JT(PSNB)

RD14B2E102JT(PSNB)

RD14B2E331JT(PSNB)

RD14B2E681JT(PSNB)

RD14B2E105JT(PSNB)

RD14B2E562JT(PSNB)

RD14B2E102JT(PSNB)

RD14B2E101JNBST

RD14B2E470JNBST

RD14B2E474JT(PSNB)

RS14B3A470JNBS(RSFSV)

RD14B2E101JT(PSNB)

RD14B2E4R7JT(NB)

CE04W2A470MC(ARS/2)

CQ93P2A103JT(NH2)

CE04W1H470MT(RFS)

CE04W1H471MC(RFS)

CQ93P2A473JC(NH)

CY031 205 0653 036 3P VH Connector base 1

RL401,402 214 0127 003 Relay (RY-12W) 2

ST401-403



Style pin 3

471 3304 028 Screw 3X8 CBS-B 4



Radiator 4

18

EXPLODED VIEW

1

104

101

60

81

61

66

83

1-4

101

67

63

92

PMA-2000IVR

101

53

47

4

7

101

29

113

39

42

48

101

91

101

30

101

48

109

85

115

74

108

110

73

113

41

101

101

104

65

1-5

56

3

89

91

108

112

107

58

104

96

14

101

1-7

57

59

109

1-1

107

101

25

19

76

101

113

23

71

101

46

46

101

2-2

2-4

2

104

66

23

104

101

3

107

106

8

13

107

12

1-3

1-6

6

119

62

22

93

106

11

9

79

101

52

72

101

5

55

30

51

77

115

42

116

97

29

117

94

31

28

44

43

71

23

113

1-8

24

113

71

74

106

45

5

G2A only

15

84

31

50

87 88

,

37

102

101

85

41

10

74

47

101

101

86

27

77

48

46

102

4

70

2-3

35

101

109

34

49

76

86

48

109

101

35

101

8

WARNING:

Parts marked with this symbol have critical
characteristics.
Use ONLY replacement parts recommended by the
manufacturer.

103

90

101

101

1-2

31

101

7

101

38

1-9

40

64

76

109

101

95

108

36

103

101

2-1

114

33

69

105

101

105

26

16

17

18

A

32

B

C

D

20

21

20

E

19

PARTS LIST OF EXPLODED VIEW

Ref. No. Part No. Part Name Remarks

1 1U-3432B

1U-3432A

1-1 Power amp unit (L)

1-2 Power amp unit (R)

1-3 Control unit

1-4 P.LED unit

1-5 S.direct switch unit

1-6 P.switch unit

1-7 Main VR. unit

1-8 AC outlet unit

1-9 Pre out unit

2 1U-3130H Input P.W.B. unit Ass'y

2-1 Input unit

2-2 Protector unit

2-3 Power supply unit

2-4 F. SW unit (R)

3 1U-3433 Flat amp P.W.B. unit Ass'y 1

4 206 1015 016 Fuse 1.25A (T) F108,G2A 1

206 1046 027 Fuse 5A KEU 1

5 206 1015 016 Fuse 1.25A (T) F109,G2A 1

206 1046 027 Fuse 5A KEU 1

6 204 8480 004 Head phone jack (SW) JK501 1

7 214 0195 006 Relay FTR-F1 RL501,502 2

8 212 1176 002 Power switch S101 1

9 212 1157 005 1P Push switch S201 1

10 233 6257 007 Power trans, mini G1C,G1H,G2A 1

233 6267 007 Power trans, mini KEU 1

11 211 0798 103 Variable resistor 100kohm VR201 (BALANCE) 1

12 211 0834 012 Variable resistor 10kohm VR202 (TREBLE) 1

13 211 0834 009 Variable resistor 30kohm VR203 (BASS) 1

14 211 0873 002 Variable resistor 30kohm VR351 (VOLUME) 1

15 203 3975 003 AC outlet G2A 1

203 3974 004 AC outlet KEU 1

16 214 0195 006 Relay FTR-F1 RL501,502 2

17 212 4331 006 Slide switch (4-6) remote S301 1

18 212 4728 004 1P Push switch S701 (MM/MC) 1

19 212 0407 002 Rotaly switch (SRRM-12)

20 204 8530 006 4P Pin jack JK301-304 4

21 204 8531 005 2P Pin jack (C-GND) JK305 1

22 411 1341 515 Front chassis 1

23 445 0048 016 Cord holder (L50) 1

24 411 1346 248 Trans chassis 1

25 462 0089 054 Bush 1

26 105 1339 075 Back panel G1C 1

105 1339 091 Back panel G1H 1

105 1339 062 Back panel G2A 1

105 1411 003 Back panel KEU 1

27 205 1014 218 4P Terminal ass'y 2

28 412 4141 003 Trans bracket 1

29 415 9092 017 Teflon plate (PT) 2

30 513 3457 004 Trans label (D) 2

31 462 0089 025 Bush 3

32 205 0071 016 Terminal ass'y 1

33 477 0018 014 Washer (P-87) D10 2

Power amp P.W.B. unit Ass'y

Power amp P.W.B. unit Ass'y

G1C,G1H 1

G2A 1

S901 (INPUT SELECTOR)

Note: The symbol in the column "Remarks" indicate the following destinations.

G1C: China model G1H: Hong Kong model
G2A: Singapore model KEU: U.S.A. model

Q'ty

Ref. No. Part No. Part Name Remarks

34 414 0765 311 Shield plate 1

35 412 4390 016 TC bracket 2

36 415 9016 019 P.C.B holder 4

37 412 4112 113 P.W.B bracket (A) 1

38 203 3970 008 AC inlet 1

39 105 1197 644 Bottom cover 1

40 212 1147 002 Slide switch S202 1

41 146 2088 106 Foot ass'y 4

146 2088 119 Foot ass'y KEU 4

42 233 6332 000 Power trans G1C,G1H 2

233 6330 002 Power trans G2A 2

233 0537 005 Power trans KEU 2

43 415 9032 006 P.C.B holder (T) 4

44 254 6204 041 Electrolytic 12000uF/71V CE62W==123M 2

45 417 0571 119 Power radiator (R) 1

46 275 0105 004 Transistor 2SK2967 TR521-524 4

47 415 0234 007 Insulating sheet 4

48 412 4127 014 P.W.B bracket (B) 4

49 412 4387 016 Radiator bracket (R) 1

50 412 4114 111 Radiator bracket (B) 1

51 417 0571 106 Power radiator (L) 1

52 412 4386 017 Radiator bracket (L) 1

53 412 4113 112 Radiator bracket (A) 1

55 412 4388 015 Support bracket (L) 1

56 144 2510 296 Front panel ass'y 1

144 2807 006 Front panel ass'y KEU 1

57 212 4799 004 Rotary remote switch

58 441 1780 216 Plate (M) 1

59 441 1781 202 Plate (F) 1

60 113 9303 101 Power knob ass'y 1

113 9303 114 Power knob ass'y KEU 1

61 112 0780 128 Knob (M) ass'y 1

112 0780 115 Knob (M) ass'y KEU 1

62 112 9125 108 Knob ass'y (F) 1

112 9125 137 Knob ass'y (F) KEU 1

63 112 0787 008 Knob (MARU) ass'y 4

1

112 0787 011 Knob (NARU) ass’y KEU 4

64 412 4389 014 Support bracket (R) 1

65 102 0574 133 Top cover 1

102 0574 159 Top cover KEU 1

66 461 9036 005 Spacer 2

67 441 1795 007 Plate (T/C) 1

69 209 0325 007 Short pin 2

70 206 1015 087 Fuse (4.0A) F101 G1C,G1H,G2A 1

206 1046 043 Fuse (10A) KEU 1

71 415 9080 003 Teflon spacer 7

72 412 4141 045 Trans bracket 1

73 475 3201 000 3 TWB 1

74 415 0809 005 Washer 12

76 475 1130 005 3 Washer 2

77 441 1890 203 Plate (RD) 2

79 113 9304 207 Push knob ass'y 1

113 9304 210 Push knob ass'y KEU 1

81 415 9093 003 Teflon washer (VR) 1

Q'ty

(REC OUT SELECTOR)

1

Ref. No. Part No. Part Name Remarks

83 461 0501 005 Rubber sheet 2

84 412 2814 015 Card spacer (L=14) 1

85 417 0540 205 CU plate 2

86 477 0096 007 Push rivet G2A,G1C,G1H 8

87 415 0680 017 Spacer G2A 1

88 461 0550 085 Rubber pad G2A 1

89 415 0847 009 PVC sheet G2A,G1C,G1H 1

90 513 1581 008 Serial No.sheet 1

91 462 0089 012 Bush 2

92 414 0958 005 Shield plate (A) 1

93 443 9015 002 P.W. spacer 4

94 412 4715 002 C. holder 1

95 441 1795 010 Plate (T/C) 1

96 412 4917 017 Shield plate 1

97 415 0860 002 Spacer 1

A 203 4930 021 3P VH-VH Connector cord CN022 1

B 203 5161 006 3P VH-VH Connector cord CN031 1

C 203 4872 037 3P KR-KR ribbonN 350 CN033 1

D 203 4871 096 3P KR-KR ribbon 250 CN035 1

E 203 6386 039 4P KR-KR ribbon 350 CN041 1

F 203 8356 009 5P EH-EH Connector cord CN051 1

G 203 8499 005 5P PH-PH Connector cord CN052 1

H 203 8342 039 5P KR-KR ribbon 350 CN053 1

I 203 8465 000 5P EH-EH Connector cord CN054 1

J 203 8439 036 5P EH-EH Connector cord CN057 1

K 204 0519 009 6P EH-EH Connector cord CN061 1

L 204 0379 032 6P KR-KR ribbon 350 CN062 1

M 204 2554 004 10P KR-KR ribbon 550 CN102 1

N 204 2921 006

O 204 6351 041 11P KR-KR ribbon 375 CN111 2

P 001 0202 021 Vinyl wire for AC inlet 1

Q 001 0202 034 Vinyl wire for AC inlet 1

R 001 0166 086 Vinyl wire for foil side 2

S 001 0197 055 Vinyl wire Red 18

T 001 0197 068 Vinyl wire Blue 1

445 8004 007 Wire clamper 10

203 5205 001 3P contact ass'y 2

415 0767 011 UL tube (16) BK 1

475 3201 000 3TWB (ZN) 1

203 0530 014 1P contact ass'y 2

415 0695 015 UL tube 2

445 8004 007 Wire clamper 95

445 0048 003 Cord holder (L76) 4

415 0847 009 PVC sheet 14

513 3815 002 Fuse caution label 1

513 3816 001 Fuse caution label 1

10P EH-EH Connector cord

CN103 1

Q'ty

PMA-2000IVR

Ref. No. Part No. Part Name Remarks

SCREWS

101 473 7002 021 Screw 3X8 CBTS (S)-B 6

102 471 3803 011 Screw 4X65 CBS 6

103 473 7508 017 Screw 3X10 CBTS (P)-B 8

104 477 0263 018 3P.Swelling screw 11

477 0263 005 3P.Swelling screw KEU 14

105 477 0064 107 Fixing screw 10

106 473 7501 014 Screw 3X14 CBTS (P)-Z 14

107 473 7500 015 Screw 3X8 CBTS (P)-Z 2

108 473 7007 000 Screw 4X8 CBTS (S)-B 16

109 473 8007 038 Cup screw 3X14 2

110 473 7003 004 Screw 3X8 CFTS (S)-Z 13

111 470 0009 022

112 473 7500 028 Screw 3X8 CFTS (P)-Z 8

113 473 8007 025 Cup screw 3X8 1

114 473 7003 017 Screw 3X8 CFTS (S)-B 1

115 473 7007 013

116 471 3409 017 Screw 4X16 CBS 1

117 475 6008 006 4N 1

118 473 8034 098 Screw 3X10 CBTS(B)-B 1

119 473 7002 005 Screw 3X6 CBTS(S)-Z 1

Screw 3X6 CPS (SW.W) ZNP

Screw 4X10 CBTS (S) ZNB

Q'ty

2

1

21

20

PACKING VIEW

209

PMA-2000IVR

210

207 208206203 204 205

201

202

212

212

PARTS LIST OF PACKING & ACCESSORIES

Ref. No. Part No. Part Name Remarks Q'ty

201 505 9102 019 Poly cover 1

202 504 9102 029 Stilen paper 1

203 505 8006 019 Envelope 1

204 206 2189 006 AC cord G1C 1

206 2209 009 AC cord (BS3P) G1H 1

262 2210 001 AC cord G2A 1

262 2157 009 AC cord KEU 1

205 399 0523 005

206



Remote control unit (RC-858)

Battery (R03X2) 1

Ref. No. Part No. Part Name Remarks Q'ty

1

209

211

Note: The symbol in the column "Remarks" indicate the following destinations.

G1C: China model G1H: Hong Kong model
G2A: Singapore model KEU: U.S.A. model

207 511 3893 002 Instruction manual 1

511 3917 001 Instruction manual KEU 1

208 515 0921 005 S.S.list (EX) 1

209 503 1221 109 Cushion ass'y 1

210 502 0944 002 Cushion ass'y 1

211 501 2019 068 Carton case 2

212

213 513 3540 018 Carton label G1C 1

215 513 9111 001 Color label (Gold) 1

216 515 0690 404 DEL warranty home KEU 1



Control card 1

21

WIRING DIAGRAM

PMA-2000IVR

1

CY103

1 2 3 4 5 6 7 8 9 10

RELAY

1U-3432-10

PRE OUT UNIT

GND

DIRECT

10P-EH

NC

OUT-L

IN-L

GND

OUT-R

RELAY

H/P-MUTE

RELAY

AUX-2

COMMON

GND

GND

NC

2

IN-R

CX041

1

4P-KR

2
3
4

CY035

1

3P-KR

2
3

CONTROL UNIT

+15V

1 2 3 4 5 6 7 8 9 10

3

1U-3432-3

-15V

L-TAP

L-CH

L-TONE

GND

SP-MUTE

GND

R-TONE

H/P-L

GND

H/P-R

GND

R-CH

R-TAP

1
2
3
4
5

CX054

5P-EH

CX103

1
2
3
4
5
6
7
8
9

10

CW101

10P-EH

CX101

1 2 3 4 5 6 7 8 9 10

+15V

1

GND

2
3

-15V

4

L-CH

5

GND

6

R-CH

CY061

+15V

-15V
L-TAP

L-CH

GND

L-TONE

GND

R-CH

R-TONE

R-TAP

+15V

-15V

L-TAP

GND
GND

R-TAP

SOURCE DIRECT SW UNIT

1U-3432-5

CX081

1
2
3

L

4

8P-EH

5
6
7
8

R

CW081

EQUALIZER/

INPUT UNIT

1U-3130-1

RELAY

AUX-2

COMMON

+15V

GND

-15V
L-CH
GND

R-CH

GND

NC

DRIVE

T2

T1
AU2
AU1

TU
CD
PH

CX035

1
2
3

1
2
3
4
5
6

1
2
3
4
5
6
7
8
9

10

CX061

6P-EH

CX102

4

RELAY
GND
DIRECT
NC
OUT-L

FLAT AMP UNIT

GND
OUT-R
IN-L
GND
IN-R

CX057

1

+15V

2

-15V

3

L

4

L-TAP

5

GND

6

GND

7

R-TAP

8

R

CY031

1 2 3

-55V

GND

+55V

1U-3433

+15V

-15VLGND

1 2 3 4 5

R

5P-EH

1 2 3 4 5

CY057

MAIN VR UNIT

1U-3432-9

UP

DOWN

1 2 3

+15V

-15V

GND
GND

+15V

-15V

GND
GND

CW055

1
2

L

3
4
5

CW056

1
2

R

3
4
5

5

CX055
5P-EH

CX056

5P-EH

1
2
3
4
5

1
2
3
4
5

POWER AMP(L)UNIT

+15V

-15V
R
GND
GND

+15V

-15V
R
GND
GND

1U-3432-1

-55V

-55V

POWER AMP(R)UNIT

1U-3432-2

+55V

GND

3C(RED,BLK,BLU)x2

+55V

GND

SP-RELAY

ASO

POSISTOR

GND

L-OUT

SP-RELAY

ASO

POSISTOR

GND

R-OUT

GND

1
2
3
4
5

1
2
3
4
5
6

BLKx2

CX053

5P-KR

CX062

6P-KR

BLKx2

WHTx2

BLKx2

BLKx2

BLKx2

BLKx2

WHTx2

76

8

A

+

-

SPEAKER OUTPUT

-

L-ch

+

B

+

-

SPEAKER OUTPUT

-

R-ch

+

C

TAPE2
TAPE1

AUX2
AUX1

TUNER

PHONO

FUNCTIN

STOPACT.

FUNCTION SW UNIT

1U-3130-5

LED MUTE

LED UNIT

1U-3432-4

CX111 CY111

1
2
3
4
5

11P-KR

6

CD

7
8

5V

9
10
11

GND

1
2

+5V

3

DATA

4

LED

5

GND

CX052

5P-KR

CY052

TAPE2

1

TAPE1

2

AUX2

3
4

AUX1

5

TUNER

6

CD

7

PHONO

8

5V

9

FUNCTIN

10

STOPACT.

11

GND

1

1

LED MUTE

2

+5V

3

DATA

4

LED

5

GND

CZ102

CD

PH

CY041

RELAY

GND

H/P-MUTE

NC

CY033

1 2 3

UP

DOWN

1 2 3 41 2 3 4

GND

H/P-L

POSISTOR

10P-KR

1 2 3 4 5 6 7 8 9 10 5

T2

T1

GND

NC

DRIVE

AU2

AU1

TU

PROTECTOR UNIT

1U-3130-2

POSISTOR

CY054

GND

H/P-R

SP-MUTE

SP-RELAY

ASO

GND

L-OUT

SP-RELAY

ASO

GND

R-OUT

GND

AC-LOW

GND

AC-LOW

12V

P ON/OFF

1
2
3
4
5

1
2
3
4
5
6

5
4
3
2
1

CY053

5P-KR

CY062

6P-KR

CY051

5P-EH

CX051

5

AC-LOW

4

GND

3

AC-LOW

2

12V

1

P. ON/OFF

-55V

1
2
3

+55V
GND

-55V

GND

CX031

3P-VH

BLK BLU BLK

AC OUTLET UNIT

1U-3432-8

3C(RED,BLK,BLU)x2

BLKx2

GNDGND

+55V

POWER SUPPLY

UNIT

1U-3130-3

BLU

YELWHT

1 2

AC INLET

WHT

POWER SW UNIT
1U-3432-6

YEL

D

E

22

SCHEMATIC DIAGRAMS (1/3)

1 2 3 4 5 6 7 8 9 10 11

PMA-2000IVR

A

9.5V

9.4V

8.8V

B

11.5V

C

D

11.5V

12.7V

+ B LINE

- B LINE
SIGNAL LINE

12.7V

NOTICE

ALL RESISTANCE VALUES IN OHM. k=1,000 OHM M=1,000,000 OHM
ALL CAPACITANCE VALUES IN MICRO FARAD. P=MICRO-MICRO FARAD
EACH VOLTAGE AND CURRENT ARE MEASUERD AT MO SIGNAL INPUT
CONDITION.
CIRCUIT AND PARTS ARE SUBJECT TO CHANGE WITHOUT PRIOR
NOTICE.

WARNING:

Parts marked with this symbol have critical characteristics.
Use ONLY replacement parts recommended by the manufacture.

CAUTION:

Before returning the unit to the customer, make sure you make either (1) a
leakage current check or (2) a line to chassis resistance check. If the leakage
current exceeds 0.5 milliamps, or if the resistance from chassis to either side
of the power card is less than 460kohms, the unit is defective.

WARNING:

DO NOT return the unit to the customer until the problem is located and
corrected.

SCHEMATIC DIAGRAMS (1/3)

1U-3130 INPUT UNIT

E

F

G

H

23

SCHEMATIC DIAGRAMS (1/3)

1 2 3 4 5 6 7 8 9 10 11

PMA-2000IVR

A

9.5V

9.4V

8.8V

B

A

A

B

B

11.5V

C

D

C

C

11.5V

12.7V

+ B LINE

- B LINE
SIGNAL LINE

12.7V

D

D

NOTICE

ALL RESISTANCE VALUES IN OHM. k=1,000 OHM M=1,000,000 OHM
ALL CAPACITANCE VALUES IN MICRO FARAD. P=MICRO-MICRO FARAD
EACH VOLTAGE AND CURRENT ARE MEASUERD AT MO SIGNAL INPUT
CONDITION.
CIRCUIT AND PARTS ARE SUBJECT TO CHANGE WITHOUT PRIOR
NOTICE.

WARNING:

Parts marked with this symbol have critical characteristics.
Use ONLY replacement parts recommended by the manufacture.

CAUTION:

Before returning the unit to the customer, make sure you make either (1) a
leakage current check or (2) a line to chassis resistance check. If the leakage
current exceeds 0.5 milliamps, or if the resistance from chassis to either side
of the power card is less than 460kohms, the unit is defective.

WARNING:

DO NOT return the unit to the customer until the problem is located and
corrected.

SCHEMATIC DIAGRAMS (1/3)

1U-3130 INPUT UNIT

E

F

G

H

23

SCHEMATIC DIAGRAMS (1/3)

1 2 3 4 5 6 7 8 9 10 11

9.5V

9.5V

PMA-2000IVR

A

9.4V

8.8V

B

11.5V

C

D

11.5V

12.7V

12.7V

E

F

+ B LINE

- B LINE
SIGNAL LINE

NOTICE

ALL RESISTANCE VALUES IN OHM. k=1,000 OHM M=1,000,000 OHM
ALL CAPACITANCE VALUES IN MICRO FARAD. P=MICRO-MICRO FARAD
EACH VOLTAGE AND CURRENT ARE MEASUERD AT MO SIGNAL INPUT
CONDITION.
CIRCUIT AND PARTS ARE SUBJECT TO CHANGE WITHOUT PRIOR
NOTICE.

WARNING:

Parts marked with this symbol have critical characteristics.
Use ONLY replacement parts recommended by the manufacture.

CAUTION:

Before returning the unit to the customer, make sure you make either (1) a
leakage current check or (2) a line to chassis resistance check. If the leakage
current exceeds 0.5 milliamps, or if the resistance from chassis to either side
of the power card is less than 460kohms, the unit is defective.

WARNING:

DO NOT return the unit to the customer until the problem is located and
corrected.

SCHEMATIC DIAGRAMS (1/3)

1U-3130 INPUT UNIT

G

H

23

SCHEMATIC DIAGRAMS (2/3)

1 2 3 4 5 6 7 8 9 10 11

PMA-2000IVR

A

B

11V

C

D

E

11V

+ B LINE

- B LINE
SIGNAL LINE

NOTICE

ALL RESISTANCE VALUES IN OHM. k=1,000 OHM M=1,000,000 OHM
ALL CAPACITANCE VALUES IN MICRO FARAD. P=MICRO-MICRO FARAD
EACH VOLTAGE AND CURRENT ARE MEASUERD AT MO SIGNAL INPUT
CONDITION.
CIRCUIT AND PARTS ARE SUBJECT TO CHANGE WITHOUT PRIOR
NOTICE.

WARNING:

Parts marked with this symbol have critical characteristics.
Use ONLY replacement parts recommended by the manufacture.

CAUTION:

Before returning the unit to the customer, make sure you make either (1) a
leakage current check or (2) a line to chassis resistance check. If the leakage
current exceeds 0.5 milliamps, or if the resistance from chassis to either side
of the power card is less than 460kohms, the unit is defective.

WARNING:

DO NOT return the unit to the customer until the problem is located and
corrected.

SCHEMATIC DIAGRAMS (2/3)

1U-3432 POWER AMP UNIT

F

G

H

24

SCHEMATIC DIAGRAMS (2/3)

1 2 3 4 5 6 7 8 9 10 11

PMA-2000IVR

A

B

A

A

B

B

C

11V

D

C

C

11V

D

D

+ B LINE

- B LINE
SIGNAL LINE

NOTICE

ALL RESISTANCE VALUES IN OHM. k=1,000 OHM M=1,000,000 OHM
ALL CAPACITANCE VALUES IN MICRO FARAD. P=MICRO-MICRO FARAD
EACH VOLTAGE AND CURRENT ARE MEASUERD AT MO SIGNAL INPUT
CONDITION.
CIRCUIT AND PARTS ARE SUBJECT TO CHANGE WITHOUT PRIOR
NOTICE.

WARNING:

Parts marked with this symbol have critical characteristics.
Use ONLY replacement parts recommended by the manufacture.

CAUTION:

Before returning the unit to the customer, make sure you make either (1) a
leakage current check or (2) a line to chassis resistance check. If the leakage
current exceeds 0.5 milliamps, or if the resistance from chassis to either side
of the power card is less than 460kohms, the unit is defective.

WARNING:

DO NOT return the unit to the customer until the problem is located and
corrected.

E

F

G

H

SCHEMATIC DIAGRAMS (2/3)

1U-3432 POWER AMP UNIT

24

SCHEMATIC DIAGRAMS (2/3)

1 2 3 4 5 6 7 8 9 10 11

PMA-2000IVR

A

B

11V

C

D

E

11V

+ B LINE

- B LINE
SIGNAL LINE

NOTICE

ALL RESISTANCE VALUES IN OHM. k=1,000 OHM M=1,000,000 OHM
ALL CAPACITANCE VALUES IN MICRO FARAD. P=MICRO-MICRO FARAD
EACH VOLTAGE AND CURRENT ARE MEASUERD AT MO SIGNAL INPUT
CONDITION.
CIRCUIT AND PARTS ARE SUBJECT TO CHANGE WITHOUT PRIOR
NOTICE.

WARNING:

Parts marked with this symbol have critical characteristics.
Use ONLY replacement parts recommended by the manufacture.

CAUTION:

Before returning the unit to the customer, make sure you make either (1) a
leakage current check or (2) a line to chassis resistance check. If the leakage
current exceeds 0.5 milliamps, or if the resistance from chassis to either side
of the power card is less than 460kohms, the unit is defective.

WARNING:

DO NOT return the unit to the customer until the problem is located and
corrected.

SCHEMATIC DIAGRAMS (2/3)

1U-3432 POWER AMP UNIT

F

G

H

24

SCHEMATIC DIAGRAMS (3/3)

1

PMA-2000IVR

2

3

4

5

76

8

A

B

NOTICE

ALL RESISTANCE VALUES IN OHM. k=1,000 OHM M=1,000,000 OHM
ALL CAPACITANCE VALUES IN MICRO FARAD. P=MICRO-MICRO FARAD
EACH VOLTAGE AND CURRENT ARE MEASUERD AT MO SIGNAL INPUT
CONDITION.
CIRCUIT AND PARTS ARE SUBJECT TO CHANGE WITHOUT PRIOR
NOTICE.

WARNING:

Parts marked with this symbol have critical characteristics.
Use ONLY replacement parts recommended by the manufacture.

CAUTION:

Before returning the unit to the customer, make sure you make either (1) a
leakage current check or (2) a line to chassis resistance check. If the leakage
current exceeds 0.5 milliamps, or if the resistance from chassis to either side
of the power card is less than 460kohms, the unit is defective.

WARNING:

DO NOT return the unit to the customer until the problem is located and
corrected.

+ B LINE

-

B LINE
Lch SIGNAL LINE
Rch SIGNAL LINE

SCHEMATIC DIAGRAMS (3/3)

1U-3433 FLAT AMP UNIT

C

D

E

25
