Denon AVR X540BT User Manual

Contents Connections Playback Settings Tips Appendix

.

AVR-X540BT

AV SURROUND RECEIVER

Owner’s Manual

Front panel Display Rear panel Remote Index

1

Contents Connections Playback Settings Tips Appendix

Contents

Accessories

Inserting the batteries
Operating range of the remote control unit

Features

High quality sound
High performance
Easy operation

Part names and functions

Front panel
Display
Rear panel
Remote control unit

Connections

Connecting speakers

Speaker installation
Speaker connection
Standard speaker configuration and connection

Connecting a TV

Connection 1 : TV equipped with an HDMI connector and
compatible with the ARC (Audio Return Channel)

Connection 2 : TV equipped with an HDMI connector and
incompatible with the ARC (Audio Return Channel)

Connection 3 : TV equipped without an HDMI connector

5

Connecting a playback device

6

Connecting a set-top box (Satellite tuner/cable TV)

6

Connecting a DVD player or Blu-ray Disc player

7

Connecting a video camcorder or game console

7

Connecting a USB memory device to the USB port

7

Connecting an FM/AM antenna

9

Connecting the power cord

10

Playback

10
13

Basic operation

14
16

20

20
22
24

25

26

27
28

Turning the power on
Selecting the input source
Adjusting the volume
Turning off the sound temporarily (Muting)
Playback a DVD player/Blu-ray Disc player

Playing a USB memory device

Playing files stored on USB memory devices

Listening to music on a Bluetooth device

Playing music from Bluetooth device
Pairing with other Bluetooth devices
Reconnecting to this unit from a Bluetooth device

29

30
31
32

33
34
36

38

38
38
39
39
39

40

41

42

43
45
46

Front panel Display Rear panel Remote Index

2

Contents Connections Playback Settings Tips Appendix

Listening to FM/AM broadcasts

Listening to FM/AM broadcasts
RDS search
PTY search
TP search
Radio Text
Tuning in to stations and presetting them automatically (Auto

Preset)
Presetting the current broadcast station (Preset Memory)
Listening to preset stations
Skipping preset broadcast stations (Preset Skip)
Cancelling Preset Skip

Convenience functions

Performing repeat playback (Repeat)
Performing random playback (Random)
Adjusting the tone (Tone)
Optimizing the night time listening volume (Night Mode)
Displaying your desired video during audio playback (Video

Select)

Selecting a sound mode

Selecting a sound mode

HDMI control function

Setting procedure

Adjusting the volume of each channel to match the input
source (Ch Level Adjust)

47

Sleep timer function

48
49
50
51
51

Using the sleep timer

Quick select plus function

Calling up the settings
Changing the settings

Settings

52

Menu map

53
53
54
54

55

56
56
57
58

59

60

60

64

64

65

Menu operations

Audio

Surr.Parameter
Restorer
Audio Delay
Volume
Room EQ

Video

HDMI Audio Out
HDMI PassThrough
Pass Source
HDMI Control
ARC
TV Audio Switching
Pow.Off Control

66

67

68

69
69

70

73

74

74
77
78
78
79

80

80
80
81
81
82
82
83

Front panel Display Rear panel Remote Index

3

Contents Connections Playback Settings Tips Appendix

Inputs

Input Assign
Source Level
Input Select

Speakers
Auto Setup

Procedure for speaker settings (Auto Setup)
Error messages

Manual Setup

Speaker Config.
Distances
Levels
Crossovers
Bass

General

Language
ECO
Bluetooth
Front Display
Firmware
Setup Lock

Checking the information

84

84
84
85

86
86

88
90

91

91
92
93
93
94

95

95
95
97
98
98
99

100

Tips

Tips
Troubleshooting

Resetting factory settings

Appendix

About HDMI
Playing back a USB memory devices
Playing back a Bluetooth device
Personal memory plus function
Last function memory
Sound modes and channel output
Sound modes and surround parameters
Types of input signals, and corresponding sound modes
Explanation of terms
Trademark information
Specifications
Index

102
103

115

116
119
120
121
121
122
123
124
125
130
132
136

Front panel Display Rear panel Remote Index

4

Quick Start Guide

Safety Instructions Notes on radio Power cord

R03/AAA batteriesRemote control unit

(RC-1216)

Sound calibration

microphone

AM loop antenna

FM indoor antenna

Cautions on Using Batteries

Contents Connections Playback Settings Tips Appendix

Thank you for purchasing this Denon product.
To ensure proper operation, please read this owner’s manual carefully before using the product.
After reading this manual, be sure to keep it for future reference.

Accessories

Check that the following parts are supplied with the product.

.

Front panel Display Rear panel Remote Index

5

Batteries

30°

30°

Approx. 7 m

Contents

Connections Playback Settings Tips Appendix

Inserting the batteries

Remove the rear lid in the direction of the arrow and

1

remove it.

Insert two batteries correctly into the battery

2

compartment as indicated.

.

Put the rear cover back on.

3

NOTE

To prevent damage or leakage of battery fluid:

0

Do not use a new battery together with an old one.

0

Do not use two different types of batteries.

0

Remove the batteries from the remote control unit if it will not be in use for long

0

periods.
If the battery fluid should leak, carefully wipe the fluid off the inside of the battery

0

compartment and insert new batteries.

Operating range of the remote control
unit

.

Point the remote control unit at the remote sensor when operating it.

.

Front panel Display Rear panel Remote Index

6

Contents

Features

Connections Playback Settings Tips Appendix

High quality sound

With discrete circuit technology, the power amplifier provides

0

identical quality for all 5-channels (90 Watts x 5-channels)

For optimum realism and stunning dynamic range, the power amplifier
section features discrete power devices (not integrated circuitry).
By using high current, high power discrete power devices, the amplifier
is able to easily drive high quality speakers.

High performance

4K 60Hz input/output supported

0

.

When 4K Ultra HD (High Definition) is used, an input/output speed of 60
frames per second (60p) is achieved for video signals. When connected
to 4K Ultra HD and 60p video signal input compatible TV, you can enjoy
the sense of realism only available from high-definition images, even
when viewing fast-moving video.
This unit also supports image processing for 4K 60p, 4:4:4 and 24-bit
videos. By processing the video at the original resolution, this unit lets
you enjoy flawless, high-definition picture quality.

This unit also supports HDR (High Dynamic Range) and BT.2020 wide
color gamut.

HDCP 2.2

0

This unit is compatible with HDCP 2.2 copyright protection standard.

Front panel Display Rear panel Remote Index

7

51

Out

In

Contents

Connections Playback Settings Tips Appendix

HDMI connections enable connection to various digital AV

0

devices (5 inputs, 1 output)

.

This unit is equipped with 5 HDMI inputs and 1 HDMI output enabling
connection to various HDMI compatible devices such as Blu-ray Disc
players, game consoles and HD video camcorders.

Wireless connection with Bluetooth devices can be carried out

0

easily (v

You can enjoy music simply by connecting wirelessly with your
smartphone, tablet, PC, etc.

Energy-saving design

0

This unit is equipped with an ECO Mode function that allows you to
enjoy music and movies while reducing the power consumption during
use, and also an auto-standby function that automatically turns off the
power supply when the unit is not in use. This helps reduce
unnecessary power use.

p. 42)

.

Front panel Display Rear panel Remote Index

8

Contents

Connections Playback Settings Tips Appendix

Easy operation

“Setup Assistant” provides easy-to-follow setup instructions

0

First select the language when prompted. Then simply follow the
instructions displayed on the TV screen to set up the speakers etc.

Easy to use Graphical User Interface

0

This unit is equipped with a Graphical User Interface for improved
operability.

Compatible with the “Denon 500 Series Remote” app performing

0

basic operations of the unit with an iPad, iPhone or Android™
devices (Google, Amazon Kindle Fire)

The “Denon 500 Series Remote”z application allows you to wireless
control this unit from an iPhone, iPad, Android smartphone or tablet
when paired and connected via Bluetooth. Basic functions include:
Power ON/OFF, volume, mute, and source selection.

Download the appropriate “Denon 500 Series Remote” for your iOS or Android

z

devices. In order to use “Denon 500 Series Remote”, your iOS or Android device
needs to be paired with this unit in advance.

Front panel Display Rear panel Remote Index

9

MASTER VOLUME

PHONES

SETUP MIC

TUNER

PRESET CH

TUNE

DIMMER STATUS

QUICK SELECT

BluetoothGAMECBL/SAT

3214

DVD/Blu-ray

SOURCE SELECT

re

Q1uoQ0i

tqw y

Q

4

Q

3

Q

2

Contents

Connections Playback Settings Tips Appendix

Part names and functions

Front panel

.

For details, see the next page.

Front panel Display Rear panel Remote Index

10

MASTER VOLUME

PHONES

SETUP MIC

TUNER

PRESET CH

TUNE

DIMMER STATUS

QUICK SELECT

BluetoothGAMECBL/SAT

3214

DVD/Blu-ray

SOURCE SELECT

trqw e y

uioQ0

Contents

.

Power operation button (X)

A

Connections Playback Settings Tips Appendix

Used to turn the power on/off (standby). (v p. 38)

Power indicator

B

This is lit as follows according to the power status:

Green: Power on

0

Off: Normal standby

0

Red:

0

When “HDMI PassThrough” is set to “On” (v p. 80)

0

0

When “HDMI Control” is set to “On” (v
When “BluetoothStandby” is set to “On” (v p. 97)

0

SOURCE SELECT knob

C

This selects the input source. (v p. 38)

p. 81)

Remote control sensor

D

This receives signals from the remote control unit. (v

Display

E

p. 6)

This displays various pieces of information. (v p. 13)

MASTER VOLUME knob

F

This adjusts the volume level. (v

Tuner preset channel buttons

G

p. 39)

(TUNER PRESET CH +, –)

These select preset broadcast stations. (v

Tuning buttons (TUNE +, –)

H

p. 53)

Select either FM broadcast or AM broadcast. (v p. 48)

DIMMER button

I

Each press of this switches the brightness of the display. (v p. 98)

STATUS button

J

Each press of this switches the status information that is shown on the
display.

Front panel Display Rear panel Remote Index

11

MASTER VOLUME

PHONES

SETUP MIC

TUNER

PRESET CH

TUNE

DIMMER STATUS

QUICK SELECT

BluetoothGAMECBL/SAT

3214

DVD/Blu-ray

SOURCE SELECT

Q

4

Q

3

Q

2

Q1

Contents

.

QUICK SELECT buttons

K

Connections Playback Settings Tips Appendix

With a single press of any of these buttons, you can call up various
settings you’ve registered to each button such as the input source,
volume level and sound mode settings. (v

Headphones jack (PHONES)

L

p. 68)

This is used to connect headphones.
When the headphones are plugged into this jack, audio will no longer
be output from the connected speakers or from the SUBWOOFER
connectors.

NOTE

To prevent hearing loss, do not raise the volume level excessively when using

0

headphones.

M

USB port (T)

This is used to connect USB storages (such as USB memory devices)
and the USB cable supplied. (v

SETUP MIC jack

N

p. 33)

This is used to connect the supplied Sound calibration microphone.

p. 89)

(v

Front panel Display Rear panel Remote Index

12

yutreqw

io

Contents

Connections Playback Settings Tips Appendix

Display

.

Input mode indicators

A

These light according to the audio input mode settings of each input
source. (v p. 85)

Decoder indicators

B

These light when Dolby or DTS signals are input or when the Dolby or
DTS decoder is running.

Tuner reception mode indicators

C

These light up according to the reception conditions when the input
source is set to “Tuner”.

TUNED: Lights up when the broadcast is properly tuned in.
STEREO: Lights up when receiving FM stereo broadcasts.
RDS : Lights up when receiving RDS broadcasts.

Sleep timer indicator

D

This lights when the sleep mode is selected. (v

Circle indicator

E

This is displayed when the input source is “USB” when you are playing
back music.

Volume indicator

F

MUTE indicator

G

This blinks while the sound is muted. (v

Information display

H

The input source name, sound mode, setting values and other
information are displayed here.

Input signal indicators

I

The respective indicator will light corresponding to the input signal.

p. 85)

(v

p. 66)

p. 39)

Front panel Display Rear panel Remote Index

13

r

ewq

iyt u

Contents

Rear panel

Connections Playback Settings Tips Appendix

.

For details, see the next page.

Front panel Display Rear panel Remote Index

14

rewq

i

yt u

Contents

.

Video connectors (VIDEO)

A

Connections Playback Settings Tips Appendix

Used to connect devices equipped with video connectors.

“Connection 3 : TV equipped without an HDMI

0

connector” (v p. 28)
“Connecting a set-top box (Satellite tuner/cable TV)” (v p. 30)

0

Digital audio connectors (DIGITAL AUDIO)

B

Used to connect devices equipped with digital audio connectors.

“Connection 2 : TV equipped with an HDMI connector and

0

incompatible with the ARC (Audio Return Channel)” (v
“Connection 3 : TV equipped without an HDMI

0

connector” (v
“Connecting a set-top box (Satellite tuner/cable TV)” (v p. 30)

0

p. 28)

p. 27)

HDMI connectors

C

Used to connect devices equipped with HDMI connectors.

“Connection 1 : TV equipped with an HDMI connector and

0

compatible with the ARC (Audio Return Channel)” (v p. 26)
“Connection 2 : TV equipped with an HDMI connector and

0

incompatible with the ARC (Audio Return Channel)” (v p. 27)
“Connecting a set-top box (Satellite tuner/cable TV)” (v

0

“Connecting a DVD player or Blu-ray Disc player” (v

0

“Connecting a video camcorder or game console” (v p. 32)

0

AC inlet (AC IN)

D

p. 31)

Used to connect the power cord. (v p. 36)

Analog audio connectors (AUDIO)

E

Used to connect devices equipped with analog audio connectors.
(v p. 30)

FM/AM antenna terminals (ANTENNA)

F

Used to connect FM antennas and AM loop antennas. (v p. 34)

PRE OUT connectors

G

Used to connect a subwoofer with a built-in amplifier. (v p. 23)

Speaker terminals (SPEAKERS)

H

Used to connect speakers. (v p. 22)

p. 30)

Front panel Display Rear panel Remote Index

15

w

r

e

t

q

Contents Connections Playback Settings Tips Appendix

Remote control unit

Input source select buttons

A

p. 38)

These select the input source. (v

Channel/page search buttons (CH/PAGE df)

B

These select radio stations registered to presets or switch pages.
(v

p. 53)

MUTE button (:)

C

This mutes the output audio. (v p. 39)

Information button (INFO)

D

This displays the status information on the TV screen. (v p. 100)

Cursor buttons (uio p)

E

These select items.

Front panel Display Rear panel Remote Index

16

Q2

Q1

Q0

o

i

u

y

Contents

Connections Playback Settings Tips Appendix

BACK button

F

This returns to the previous screen.

Channel level button (CH LEVEL)

G

p. 65)

p. 68)

p. 60)

Adjusting the volume of the speakers. (v

System buttons

H

These perform playback related operations.

Tuning up / Tuning down buttons (TUNE +, –)

These select either FM broadcast or AM broadcast. (v p. 48)

QUICK SELECT buttons (1 – 4)

I

These call up settings registered to each button, such as input source,
volume level and sound mode settings. (v

SOUND MODE buttons (0 1)

J

These select the sound mode. (v

Remote control signal transmitter

K

This transmits signals from the remote control unit. (v p. 6)

SLEEP button

L

This sets the sleep timer. (v p. 66)

Front panel Display Rear panel Remote Index

17

Q3

Q5

Q4

Q8
Q9

W0

Q6
Q7

W1

Contents

Connections Playback Settings Tips Appendix

POWER button (X)

M

This turns the power on/off. (v p. 38)

N

ECO Mode button (G)

p. 95)

p. 39)

p. 73)

p. 53)

This switches to ECO Mode. (v

VOLUME buttons (df)

O

These adjust the volume level. (v

OPTION button

P

This displays the option menu on the TV screen.

ENTER button

Q

This determines the selection.

SETUP button

R

This displays the menu on the TV screen. (v

Preset memory button (MEMORY)

S

The current broadcast station that is preset. (v

Tuning mode select button (MODE)

T

This switches the tune mode. (v p. 48)

AUDIO DELAY buttons (+, –)

U

Compensates for incorrect timing between video and audio.
(v

p. 78)

Front panel Display Rear panel Remote Index

18

R

L

R

L

Contents Connections Playback Settings Tips Appendix

Connections

o

Contents

Connecting speakers 20

Connecting a TV 25

Connecting a playback device 29

Connecting a USB memory device to the USB port 33

Connecting an FM/AM antenna 34

Connecting the power cord 36

NOTE

Do not plug in the power cord until all connections have been completed.

0

However, when the “Setup Assistant”is running, follow the instructions in the
“Setup Assistant” (page 7 in the separate “Quick Start Guide”) screen for making
connections. (During “Setup Assistant” operation, the input/output connectors do
not conduct current.)

Do not bundle power cords together with connection cables. Doing so can result in

0

noise.

o

Cables used for connections

Provide necessary cables according to the devices you want to
connect.

Speaker cable

.

Subwoofer cable

HDMI cable

Video cable

Optical cable

.

.

.

.

Audio cable

.

Front panel Display Rear panel Remote Index

19

FL

SW1

C

SL

FR

SR

SW2

Contents Connections Playback Settings Tips Appendix

Connecting speakers

Install speakers and connect them to this unit. (“Speaker installation” (v p. 20), “Speaker connection” (v p. 22))

Speaker installation

Determine the speaker system depending on the number of speakers you
are using and install each speaker and subwoofer in the room.
Speaker installation is explained using this example of a typical
installation.

.

Front panel Display Rear panel Remote Index

FL/FR

(Front speaker left/
right):

C
(Center speaker):

SL/SR

(Surround speaker left/
right):

SW 1/2

(Subwoofer) :

20

Place the FRONT left and right speakers an
equal distance from the main listening position.
The distance between each speaker and your TV
should also be the same.

Place the CENTER speaker in between the front
speakers and above or below your TV.

Place the SURROUND left and right speakers an
equal distance to the left and right sides of the
main listening position.

Place the SUBWOOFER at a convenient location
near the front speakers. If you have two
subwoofers, place them asymmetrically across
the front of your room.

GViewed from the sideH

Surround
speaker

Front speaker

z1

z2

FL

SW

C

SL

FR

SR

Contents

Use the illustration below as a guide for how high each speaker should be

0

Connections Playback Settings Tips Appendix

installed. The height does not need to be exactly the same.

When 5.1-channel speakers are installed

o

.

Front panel Display Rear panel Remote Index

.

21

z

1 22° - 30° z2 120°

Contents

Connections Playback Settings Tips Appendix

Speaker connection

Here we connect the speakers in the room to this unit.
This section explains how to connect them using typical examples.

NOTE

Disconnect this unit’s power plug from the power outlet before connecting the

0

speakers. Also, turn off the subwoofer.
Connect so that the speaker cable core wires do not protrude from the speaker

0

terminal. The protection circuit may be activated if the core wires touch the rear
panel or if the + and - sides touch each other. (“Protection circuit” (v

Never touch the speaker terminals while the power cord is connected. Doing so

0

could result in electric shock. When the “Setup Assistant” (page 7 in the separate
“Quick Start Guide”) is running, follow the instructions in the “Setup Assistant”
screen for making connections. (Power is not supplied to the speaker terminals
while the “Setup Assistant” is running.)

Use speakers with an impedance of 6 – 16 Ω/ohms.

0

p. 129))

o

Connecting the speaker cables

Carefully check the left (L) and right (R) channels and + (red) and –
(black) polarities on the speakers being connected to this unit, and be
sure to connect the channels and polarities correctly.

Peel off about 10 mm of sheathing from the tip of the

1

speaker cable, then either twist the core wire tightly or
terminate it.

.

Press the lever on the speaker terminal.

2

.

Holding the lever on the speaker terminal, insert the

3

core wire of the speaker cable all the way into the
speaker terminal.

.

Release your finger from the lever on the speaker

4

terminal.

.

Front panel Display Rear panel Remote Index

22

SW1 SW2

Contents

o

Connecting the subwoofer

Use a subwoofer cable to connect the subwoofer. Two subwoofers can
be connected to this unit.

The same signal is output from the respective subwoofer terminals.

.

Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

23

FL

SW C

SL

FR

SR

SW

SLFLFR C SR

Contents

Connections Playback Settings Tips Appendix

Standard speaker configuration and connection

This serves as a basic 5.1-channel surround system.
Sound modes such as Dolby Pro Logic g are supported.

.

.

Front panel Display Rear panel Remote Index

24

No

Yes

Is the TV equipped with an HDMI connector?

Is the TV compatible with the ARC (Audio Return Channel) ?

Yes No

Contents Connections Playback Settings Tips Appendix

Connecting a TV

Connect a TV to this unit so that the input video is output to the TV. You can also enjoy audio from the TV on this unit.
How to connect a TV depends on the connectors and functions equipped on the TV.
ARC (Audio Return Channel) function plays TV audio on this unit by sending the TV audio signal to this unit via HDMI cable.

.

“Connection 1 : TV equipped with an HDMI
connector and compatible with the ARC (Audio
Return Channel)” (v

p. 26)

“Connection 2 : TV equipped with an HDMI
connector and incompatible with the ARC (Audio
Return Channel)” (v p. 27)

“Connection 3 : TV equipped without
an HDMI connector” (v

p. 28)

Front panel Display Rear panel Remote Index

25

(ARC)

IN

HDMI

TV

Contents

Connections Playback Settings Tips Appendix

Connection 1 : TV equipped with an HDMI connector and compatible with the ARC
(Audio Return Channel)

Use an HDMI cable to connect a TV that is compatible with the ARC function to this unit.
Set “HDMI Control” to “On” when using a TV that supports the ARC function. (v

.

p. 81)

Front panel Display Rear panel Remote Index

26

OUT

OPTICAL

OUT IN

IN

HDMI

TV

Contents

Connections Playback Settings Tips Appendix

Connection 2 : TV equipped with an HDMI connector and incompatible with the ARC
(Audio Return Channel)

Use an HDMI cable to connect the TV to this unit.
To listen to audio from TV on this unit, use an optical cable to connect the TV to this unit.

.

Front panel Display Rear panel Remote Index

27

OUT

OPTICAL

OUTIN

IN

VIDEO

TV

Contents

Connections Playback Settings Tips Appendix

Connection 3 : TV equipped without an HDMI connector

Use a video cable to connect the TV to this unit.
To listen to audio from TV on this unit, use an optical cable to connect the TV to this unit.

.

Front panel Display Rear panel Remote Index

28

Contents Connections Playback Settings Tips Appendix

Connecting a playback device

This unit is equipped with two types of video input connectors (HDMI and composite video) and three types of audio input connectors (HDMI, digital audio
and audio).

Select input connectors on this unit according to the connectors equipped on the device you want to connect.
If the device connected to this unit is equipped with an HDMI connector, it is recommended to use HDMI connections.
In the HDMI connection, audio and video signals can be transmitted through a single HDMI cable.

“Connecting a set-top box (Satellite tuner/cable TV)” (v p. 30)

0

“Connecting a DVD player or Blu-ray Disc player” (v p. 31)

0

“Connecting a video camcorder or game console” (v p. 32)

0

Connect devices to this unit as indicated by the input sources printed on the audio/video input connectors of this unit.

0

The source that is assigned to the OPTICAL 1 and OPTICAL 2 connectors can be changed. See “Input Assign” on how to change the input source assigned to the input

0

connectors. (v
To play back audio signals that are input to this unit on a TV connected via HDMI, set “HDMI Audio Out” to “TV”. (v p. 80)

0

To enjoy content that is copyright protected by HDCP 2.2, use a playback device and TV compatible with HDCP 2.2 only.

0

To enjoy 4K content or content that is copyright protected by HDCP 2.2, connect the device to the HDMI 3, HDMI 4 or HDMI 5 input connector.

0

p. 84)

Front panel Display Rear panel Remote Index

29

R

L

R

L

or

OUT

HDMI

AUDIO

AUDIO

RL

OUT

OUT

VIDEO

VIDEO

(HDMI incompatible device)

Satellite tuner/

Cable TV

Satellite tuner/

Cable TV

OUT

OPTICAL

Contents

Connections Playback Settings Tips Appendix

Connecting a set-top box (Satellite tuner/cable TV)

This explanation uses the connection with a satellite tuner/cable TV STB as an example.
Select the input connectors on this unit to match the connectors on the device that you want to connect to.

.

Front panel Display Rear panel Remote Index

30

OUT

HDMI

DVD player/
Blu-ray Disc

player

Contents

Connections Playback Settings Tips Appendix

Connecting a DVD player or Blu-ray Disc player

This explanation uses the connection with a DVD player or Blu-ray Disc player as an example.
When connecting a 4K / HDCP 2.2 compatible player, connect to either the HDMI 3, HDMI 4 or HDMI 5 input connector.

.

Front panel Display Rear panel Remote Index

31

OUT

HDMI

Video camcorder

Contents

Connections Playback Settings Tips Appendix

Connecting a video camcorder or game console

This explanation uses the connection with a video camcorders as an example.
Connect a playback device to this unit, such as a video camcorder or game console.

.

Front panel Display Rear panel Remote Index

32

MASTER VOLUME

PHONES

SETUP MIC

TUNER

PRESET CH

TUNE

DIMMER STATUS

QUICK SELECT

BluetoothGAMECBL /SAT

3214

DVD/Blu-ray

USB memory

device

Contents Connections Playback Settings Tips Appendix

Connecting a USB memory device to the USB port

For operating instructions see “Playing a USB memory device” (v p. 40).

.

Denon does not guarantee that all USB memory devices will operate or receive power. When using a portable USB hard disk drive (HDD) which came with an AC adapter,

0

use that device’s supplied AC adapter.

NOTE

USB memory devices will not work via a USB hub.

0

It is not possible to use this unit by connecting the unit’s USB port to a PC via a USB cable.

0

Do not use an extension cable when connecting a USB memory device. This may cause radio interference with other devices.

0

Front panel Display Rear panel Remote Index

33

wqe

FM indoor antenna

(supplied)

White

Black

AM loop antenna

(supplied)

Contents

Connections Playback Settings Tips Appendix

Connecting an FM/AM antenna

Connect the antenna, tune in to a broadcast and then move the antenna to
the location where there is least noise. Then use tape, etc. to fix the
antenna in this location. (“Listening to FM/AM broadcasts” (v p. 47))

If you are unable to receive a good broadcast signal, we recommend installing an

0

outdoor antenna. For details, inquire at the retail store where you purchased the
unit.

NOTE

Make sure the AM loop antenna lead terminals do not touch metal parts of the

0

panel.

Front panel Display Rear panel Remote Index

.

34

Nail, tack, etc.

Projecting part

Square hole

Stand

Loop antenna

Contents

o

Using the AM loop antenna

Suspending on a wall

Suspend directly on a wall without assembling.

.

Standing alone

Use the procedure shown above to assemble.
When assembling, refer to “AM loop antenna assembly”.

Connections Playback Settings Tips Appendix

.

o

AM loop antenna assembly

Put the stand section through the bottom of the loop

1

antenna from the rear and bend it forward.

Insert the projecting part into the square hole in the

2

stand.

.

Front panel Display Rear panel Remote Index

35

To household power outlet

Power cord (supplied)

(AC 230 V, 50/60 Hz)

Contents

Connections Playback Settings Tips Appendix

Connecting the power cord

After completing all the connections, insert the power plug into the power outlet.

.

Front panel Display Rear panel Remote Index

36

Contents Connections Playback Settings Tips Appendix

o

Contents

Basic operation

Turning the power on 38

Selecting the input source 38

Adjusting the volume 39

Turning off the sound temporarily (Muting) 39

Selecting a sound mode 60

Playback

Convenience functions

Convenience functions 55

HDMI control function 64

Adjusting the volume of each channel to match the input source (Ch
Level Adjust) 65

Sleep timer function 66

Quick select plus function 68

Playback a device

Playing a DVD player/Blu-ray Disc player 39

Playing a USB memory device 40

Listening to music on a Bluetooth device 42

Listening to FM/AM broadcasts 47

Front panel Display Rear panel Remote Index

37

MUTE

POWER

VOLUME

df

X

:

Input source

select

buttons

Contents Connections Playback Settings Tips Appendix

Basic operation

Turning the power on

Press POWER X to turn on power to the unit.

1

You can press the input source select button when the unit is in standby mode to

0

turn on the power.
You can also switch the power to standby by pressing X on the main unit.

0

.

Front panel Display Rear panel Remote Index

Selecting the input source

Press the input source select button to be played back.

1

The desired input source can be selected directly.

You can also select the input source by turning SOURCE SELECT on the main

0

unit.

38

Contents Connections Playback Settings Tips Appendix

Adjusting the volume

Use VOLUME df to adjust the volume.

1

The variable range differs according to the input signal and channel level setting.

0

You can also adjust the master volume by turning MASTER VOLUME on the main

0

unit.

Turning off the sound temporarily
(Muting)

Press MUTE :.

1

MUTE indicator on the display flashes.

0

: appears on the TV screen.

0

The sound is reduced to the level set at “Mute Level” in the menu. (v p. 79)

0

To cancel mute, either adjust the sound volume or press MUTE : again.

0

Playback a DVD player/Blu-ray Disc
player

The following describes the procedure for playing DVD player/Blu-ray Disc
player.

Prepare for playback.

1

Turn on the power of the TV, subwoofer and player.

A

Change the TV input to the input of this unit.

B

Press POWER X to turn on power to the unit.

2

Press DVD/Blu-ray (4K not supported) or Blu-ray (4K

3

supported) to switch the input source of the player to
be played back.

Play the DVD player or Blu-ray Disc player.

4

o

Surround playback (v p. 60)

Front panel Display Rear panel Remote Index

39

1/3

8 9

USB

ui p

ENTER

BACK

OPTION

Contents Connections Playback Settings Tips Appendix

Playing a USB memory device

Playing back music files stored on a USB memory device.

0

Only USB memory devices conforming to mass storage class standards

0

can be played on this unit.
This unit is compatible with USB memory devices in “FAT16” or

0

“FAT32” format.
The audio format types and specifications supported by this unit for

0

playback are as follows.
See “Playing back a USB memory devices” for details. (v p. 119)

WMA

0

MP3

0

WAV

0

MPEG-4 AAC

0

0

FLAC

.

Front panel Display Rear panel Remote Index

40

Folder
Music

USB [1/2]

Option

OPTION

Contents

Connections Playback Settings Tips Appendix

Playing files stored on USB memory
devices

Connect the USB memory device to the USB port.

1

(v p. 33)

Press USB to switch the input source to “USB”.

2

.

Use ui p to select the file to be played, then press

3

ENTER.

Playback starts.

Operation buttons

1/3

8 9

ENTER

u i

PAGE d f

NOTE

Note that Denon will accept no responsibility whatsoever for any problems arising with

0

the data on a USB memory device when using this unit in conjunction with the USB
memory device.

o

Operations accessible through the option

Playback / Pause

Skip to previous track / Skip to next track

(Press and hold) Fast-reverse / Fast­forward

Playback / Pause

(Press and hold) Stop

Skip to previous track / Skip to next track

(Press and hold) Fast-reverse / Fast­forward

Switch to the previous page/next page in
the list display

Function

menu

“Performing repeat playback (Repeat)” (v

0

“Performing random playback (Random)” (v p. 56)

0

“Adjusting the tone (Tone)” (v

0

“Displaying your desired video during audio playback (Video

0

Select)” (v

p. 59)

p. 57)

p. 56)

Front panel Display Rear panel Remote Index

41

Bluetooth

ui

8 9

ENTER

OPTION

1/3

BACK

Contents Connections Playback Settings Tips Appendix

Listening to music on a Bluetooth device

Music files stored on Bluetooth devices such as smartphones, digital
music players, etc. can be enjoyed on this unit by pairing and connecting
this unit with the Bluetooth device.

Communication is possible up to a range of about 10 m.

NOTE

To play back music from a Bluetooth device, the Bluetooth device needs to

0

support the A2DP profile.

.

Front panel Display Rear panel Remote Index

42

Pairing Mode

Turn on Bluetooth from your mobile device’s
settings menu, then select
“Denon AVR-X540BT” when it appears
in the device list.

Bluetooth

Cancel

Contents Connections Playback Settings Tips Appendix

Playing music from Bluetooth device

In order to enjoy music from a Bluetooth device on this unit, the Bluetooth
device must first be paired with this unit.

Once the Bluetooth device has been paired, it does not need to be paired
again.

Press Bluetooth to switch the input source to

1

“Bluetooth”.

.

When using for the first time, the unit will go into the pairing mode
automatically and “Pairing...” will appear on the display of the unit.

Activate the Bluetooth settings on your mobile device.

2

Select this unit when its name appears in the list of

3

devices displayed on the screen of the Bluetooth
device.

Connect to the Bluetooth device while “Pairing” is being displayed
on the display of the unit.
Perform the connection with the Bluetooth device close to the unit
(about 1 m).

When a number appears on the display of this unit,

4

check that it is the same number as that shown on the
screen of the Bluetooth device and then select “Pair”
for both the Bluetooth device and the unit.

At the end of the pairing, the device name appears on the display of
this unit.

Play music using any app on your Bluetooth device.

5

The Bluetooth device can also be operated with the remote

0

control of this unit.
The next time the input source is switched to Bluetooth, this unit

0

automatically connects to the last Bluetooth device that was
connected.

Enter “0000” when the password is requested on the screen of the Bluetooth

0

device.

Front panel Display Rear panel Remote Index

43

Contents

Connections Playback Settings Tips Appendix

Operation buttons Function
1/3

Playback / Pause

Skip to previous track / Skip to next track

8 9

(Press and hold) Fast-reverse / Fast­forward

ENTER

Playback / Pause

(Press and hold) Stop

Skip to previous track / Skip to next track

u i

(Press and hold) Fast-reverse / Fast­forward

English letters, numbers and certain symbols are displayed. Incompatible

0

characters are displayed as “.” (period).

NOTE

To operate the Bluetooth device with the remote control of this unit, the Bluetooth

0

device needs to support the AVRCP profile.
The remote control of this unit is not guaranteed to work with all Bluetooth devices.

0

Depending on the type of Bluetooth device, this unit outputs audio that is coupled

0

to the volume setting on the Bluetooth device.

o

Operations accessible through the option
menu

“Pairing with other Bluetooth devices” (v p. 45)

0

“Performing repeat playback (Repeat)” (v p. 56)

0

“Performing random playback (Random)” (v p. 56)

0

“Adjusting the tone (Tone)” (v p. 57)

0

“Displaying your desired video during audio playback (Video

0

Select)” (v p. 59)

Front panel Display Rear panel Remote Index

44

Contents Connections Playback Settings Tips Appendix

Pairing with other Bluetooth devices

This unit can be paired with a maximum of 8 Bluetooth devices. When a 9th

Pair a Bluetooth device with this unit.

Activate the Bluetooth settings on your mobile device.

1

Press OPTION when the input source is “Bluetooth”.

2

The option menu screen is displayed.

Use ui to select “Pairing Mode”, then press ENTER.

3

The device will go into the pairing mode.

Select this unit when its name appears in the list of

4

devices displayed on the screen of the Bluetooth
device.

When a number appears on the display of this unit,

5

check that it is the same number as that shown on the
screen of the Bluetooth device and then select “Pair”
for both the Bluetooth device and the unit.

At the end of the pairing, the device name appears on the display of
this unit.

0

Bluetooth device is paired, it will be registered in place of the oldest registered
device.

Enter “0000” when the password is requested on the screen of the Bluetooth

0

device.
Press and hold the Bluetooth on the remote control for at least 3 seconds to go

0

into pairing mode.

Front panel Display Rear panel Remote Index

45

Contents

Connections Playback Settings Tips Appendix

Reconnecting to this unit from a
Bluetooth device

After pairing is completed, the Bluetooth device can be connected without
performing any operations on this unit.

This operation also needs to be performed when switching the Bluetooth
device for playback.

If a Bluetooth device is currently connected, deactivate

1

the Bluetooth setting of that device to disconnect it.

Activate the Bluetooth setting of the Bluetooth device

2

to be connected.

Select this unit from the Bluetooth device list on your

3

Bluetooth device.

Play music using any app on your Bluetooth device.

4

When the power of this unit is turned on, the input source will be automatically

0

switched to “Bluetooth” if a Bluetooth device is connected.
When the “BluetoothStandby” setting of this unit is set to “Auto-Select” setting of

0

this unit is set to “On”, and a Bluetooth device is connected with the unit in the
standby state, the power of the unit will be turned on automatically. (v p. 97)

Front panel Display Rear panel Remote Index

46

FM

CH/PAGE

df

AM

MODE

TUNE +, –

MEMORY

uio p

ENTER

OPTION

Contents Connections Playback Settings Tips Appendix

Listening to FM/AM broadcasts

You can use the built-in tuner of this unit to listen to FM broadcasts and
AM broadcasts.
Make sure the FM antenna and AM loop antenna are connected to this
unit first.

.

Front panel Display Rear panel Remote Index

47

01

Tuner

FM 87.5MHz

Tune Preset

-

+

TUNE

Option

OPTION

AUTO

CH d/f

01 FM 87.50MHz

GDisplay of this unitH

Contents Connections Playback Settings Tips Appendix

Listening to FM/AM broadcasts

Connect the antenna. (“Connecting an FM/AM

1

antenna” (v p. 34))

Use FM or AM to switch the input source to “FM” or

2

“AM”.

G TV screen H

.

.

Press MODE to select the tune mode, then press

3

ENTER.

AUTO
(Default) :

MANUAL:

Press TUNE + or TUNE - to select the station you want

4

listen to.

Scanning is performed until it finds an available radio station. When
it finds a radio station, it stops the scan automatically and tunes in.

In “AUTO” mode, you cannot tune in to radio stations if the reception is not good.

0

If this is the case, then use the “MANUAL” mode to tune in.
You can also scan the broadcast station by pressing TUNE + or TUNE - on the

0

unit.

Operation buttons Function
CH/PAGE d f

MODE Switching tune mode

MEMORY Register presets

TUNE +, - Selects the radio station (up/down)

Automatically search for and tune to a
receivable radio station.

Manually change the frequency one
step at a time each time the button is
pressed.

Selects preset radio stations

48

Front panel Display Rear panel Remote Index

Contents Connections Playback Settings Tips Appendix

o

Operations accessible through the option
menu

“RDS search” (v p. 49)

0

“PTY search” (v p. 50)

0

“TP search” (v

0

“Radio Text” (v p. 51)

0

“Tuning in to stations and presetting them automatically (Auto

0

Preset)” (v p. 52)
“Skipping preset broadcast stations (Preset Skip)” (v p. 54)

0

“Adjusting the tone (Tone)” (v p. 57)

0

“Displaying your desired video during audio playback (Video

0

Select)” (v

p. 51)

p. 59)

RDS search

RDS (works only on the FM band) is a broadcasting service which allows
a station to send additional information along with the regular radio
program signal.

Use this function to automatically tune to FM stations that provide the RDS
service.

Note that the RDS function only works when receiving RDS compatible
stations.

Press FM to switch the input source to “Tuner”.

1

Press OPTION.

2

The option menu screen is displayed.

Use ui to select “RDS Search”, then press ENTER.

3

Press ENTER.

4

The search for RDS stations begins automatically.

Front panel Display Rear panel Remote Index

49

Contents Connections Playback Settings Tips Appendix

PTY search

Use this function to find RDS stations broadcasting a designated program
type (PTY).

PTY identifies the type of RDS program.
The program types and their displays are as follows:

NEWS

AFFAIRS

INFO

SPORT

EDUCATE

DRAMA

CULTURE

SCIENCE

VARIED

POP M

ROCK M

EASY M

LIGHT M

CLASSICS

OTHER M

News

Current Affairs

Information

Sports

Education

Drama

Culture

Science

Varied

Pop Music

Rock Music

Easy Listening Music

Light Classical

Serious Classical

Other Music

WEATHER

FINANCE

CHILDREN

SOCIAL

RELIGION

PHONE IN

TRAVEL

LEISURE

JAZZ

COUNTRY

NATION M

OLDIES

FOLK M

DOCUMENT

Weather

Finance

Children’s program

Social Affairs

Religion

Phone In

Travel

Leisure

Jazz Music

Country Music

National Music

Oldies Music

Folk Music

Documentary

Press FM when the input source is “Tuner”.

1

Press OPTION.

2

The option menu screen is displayed.

Use ui to select “PTY Search”, then press ENTER.

3

Use ui to call out the desired program type.

4

Press ENTER.

5

PTY search begins automatically.

Front panel Display Rear panel Remote Index

50

Contents Connections Playback Settings Tips Appendix

TP search

TP identifies programs that carry traffic announcements.
This allows you to easily find out the latest traffic conditions in your area

before leaving home.
Use this function to find RDS stations broadcasting traffic programs (TP

stations).

Press FM when the input source is “Tuner”.

1

Press OPTION.

2

The option menu screen is displayed.

Use ui to select “TP Search”, then press ENTER.

3

Press ENTER.

4

TP search begins automatically.

Radio Text

RT allows RDS stations to send text messages that appear on the display.
“Radio text” appears on the display when radio text data is received.

Press FM when the input source is “Tuner”.

1

Press OPTION.

2

The option menu screen is displayed.

Use ui to select “Radio Text”, then press ENTER.

3

Use o p to select “On”, then press ENTER.

4

While receiving an RDS broadcast station, the text data

0

broadcast from the station is displayed.
If no text data is being broadcast, “NO TEXT DATA” is displayed.

0

Front panel Display Rear panel Remote Index

51

Contents Connections Playback Settings Tips Appendix

Tuning in to stations and presetting
them automatically (Auto Preset)

A maximum of 56 radio stations can be automatically preset.

Press OPTION when the input source is “FM”.

1

The option menu screen is displayed.

Use ui to select “Auto Preset”, then press ENTER.

2

The unit starts to tune in to radio stations automatically and preset
them.

When presetting is completed, “Completed” is displayed for about

0

5 seconds and the option menu screen turns off.

The preset memory is overwritten.

0

Front panel Display Rear panel Remote Index

52

Contents Connections Playback Settings Tips Appendix

Presetting the current broadcast
station (Preset Memory)

Your favorite broadcast stations can be preset so that you can tune them
in easily.
Up to 56 stations can be preset.

Tune in the broadcast station you want to preset.

1

(“Listening to FM/AM broadcasts” (v p. 48))

Press MEMORY.

2

Use ui to select the channel you want to preset.

3

Press MEMORY.

4

The current broadcast station that is preset.

To preset other stations, repeat steps 1 to 4.

0

Channel Default settings

1 – 8

9 – 16

17 – 24

25 – 32

33 – 40

41 – 48

49 – 56

87.50 / 89.10 / 98.10 / 108.00 / 90.10 / 90.10 / 90.10 /

90.10 MHz

522 / 603 / 999 / 1404 / 1611 kHz,

90.10 / 90.10 / 90.10 MHz

90.10 / 90.10 / 90.10 / 90.10 / 90.10 / 90.10 / 90.10 / 90.10
MHz

90.10 / 90.10 / 90.10 / 90.10 / 90.10 / 90.10 / 90.10 / 90.10
MHz

90.10 / 90.10 / 90.10 / 90.10 / 90.10 / 90.10 / 90.10 / 90.10
MHz

90.10 / 90.10 / 90.10 / 90.10 / 90.10 / 90.10 / 90.10 / 90.10
MHz

90.10 / 90.10 / 90.10 / 90.10 / 90.10 / 90.10 / 90.10 / 90.10
MHz

Listening to preset stations

Use CH/PAGE df to select the desired preset channel.

1

You can also select preset broadcast stations by pressing TUNER PRESET CH +

0

or TUNER PRESET CH - on the main unit.

Front panel Display Rear panel Remote Index

53

Contents Connections Playback Settings Tips Appendix

Skipping preset broadcast stations
(Preset Skip)

Perform auto preset memory to save all the broadcasting stations that can
be received in the memory. Selecting a broadcast station becomes easier
by skipping unnecessary memories.

Press OPTION when the input source is “FM” or “AM”.

1

The option menu screen is displayed.

Use ui to select “Preset Skip”, then press ENTER.

2

The “Preset Skip” screen is displayed.

Use ui to select the group of broadcast stations you

3

want to skip.

Skip all the broadcast stations that are included in the selected
group “Preset z-z”.

(z is the selected group number.)

Use o p to select “Skip”.

4

The station you selected is not displayed.

Cancelling Preset Skip

While the “Preset Skip” screen is displayed, use ui to

1

select a group of a broadcast stations to cancel the
skip for.

Use o p to select “On”.

2

The skip is cancelled.

Front panel Display Rear panel Remote Index

54

uio p

ENTER

OPTION

Contents Connections Playback Settings Tips Appendix

Convenience functions

This section explains how to use convenient functions that can be used for
each input source.

.

Front panel Display Rear panel Remote Index

55

Contents Connections Playback Settings Tips Appendix

Performing repeat playback (Repeat)

n

Supported input sources : USB / Bluetooth

While content is playing, press OPTION.

1

The option menu screen is displayed.

Use ui to select “Repeat”, then press ENTER.

2

Use o p to select repeat playback mode.

3

Off
(Default):

One: A file being played is played repeatedly.

All:

Folder:

Press ENTER.

4

The display returns to the playback screen.

“Repeat” settings are stored for each input source.

0

Repeat playback mode is canceled.

All files in the folder currently being
played are played repeatedly. (When
the input source is set to “Bluetooth”)

All files in the folder currently being
played are played repeatedly. (When
the input source is set to “USB”)

Performing random playback
(Random)

n

Supported input sources : USB / Bluetooth

While content is playing, press OPTION.

1

The option menu screen is displayed.

Use ui to select “Random”, then press ENTER.

2

Use o p to select random playback mode.

3

Off
(Default):

On:

Press ENTER.

4

The display returns to the playback screen.

During random playback, each time playback of a track is completed, another

0

track is randomly selected for playback from tracks in the folder. Therefore, it’s
possible that you may hear a track played back more than once during random
playback.

“Random” settings are stored for each input source.

0

Disable random playback.

Randomly play back all tracks in the
current playback folder.

Front panel Display Rear panel Remote Index

56

Contents

Connections Playback Settings Tips Appendix

Adjusting the tone (Tone)

Adjusts the tonal quality of the sound.

Press OPTION.

1

The option menu screen is displayed.

Use ui to select “Tone”, then press ENTER.

2

The “Tone” screen is displayed.

Use o p to set the tone control function to on/off.

3

On: Allow tone adjustment (bass, treble).

Off

(Default):

Playback without tone adjustment.

Select “On” in step 3 and press i to select the sound

4

range to be adjusted.

Bass: Adjust bass.

Treble: Adjust treble.

Use o p to adjust the tone, then press ENTER.

5

-6 dB – +6 dB (Default : 0 dB)

“Tone” settings are stored for each input source.

0

This cannot be set when the sound mode is set to “Direct”.

0

You cannot set this when no audio signal is input or in the menu “HDMI Audio Out”

0

is set to “TV”. (v

p. 80)

Front panel Display Rear panel Remote Index

57

Contents Connections Playback Settings Tips Appendix

Optimizing the night time listening
volume (Night Mode)

Compress dynamic range (difference between loud and soft sounds).
This can be set when a Dolby Digital signal is input.

Press OPTION.

1

The option menu screen is displayed.

Use ui to select “Night Mode”, then press ENTER.

2

The Night Mode setting screen is displayed.

Use o p to select “Night Mode”, then press ENTER.

3

Low : Set the adjusted value to low.

Medium : Set the adjusted value to middle.

High : Set the adjusted value to high.

Auto :

Off

(Default):

“Auto” can be set when a Dolby TrueHD signal is input.

0

The default setting is “Off”. The default setting when the input signal is Dolby

0

TrueHD is “Auto”.

Automatic dynamic range compression
on/off control according to the source.

Do not set.

Front panel Display Rear panel Remote Index

58

Contents Connections Playback Settings Tips Appendix

Displaying your desired video during
audio playback (Video Select)

This unit can display video from a different source on TV during audio
playback. You can set this for each input source.

n

Supported input sources :
USB / FM / AM / Bluetooth

Press OPTION during audio playback.

1

The option menu screen is displayed.

Use ui to select “Video Select”, then press ENTER.

2

Use o p to select the Video Select mode.

3

Off
(Default):

On: Enable Video Select mode.

Use o p to select the input source for video you want

4

to play back, then press ENTER.

“Video Select” settings are stored for each input source.

0

Front panel Display Rear panel Remote Index

Disable Video Select mode.

59

SOUND MODE

0 1

Contents Connections Playback Settings Tips Appendix

Selecting a sound mode

This unit allows you to enjoy various kinds of surround and stereo
playback modes.
Multi-channel audio formats are provided on popular movie and music
disc formats such as Blu-ray and DVD, as well as being supported by
digital broadcasting, and even by streaming movies.
This unit supports playback of almost all of these multi-channel audio
formats. It also supports surround playback of audio formats other than
multi-channel audio such as 2-channel stereo audio.

For audio formats recorded on a disc, see the disc jacket or label.

0

Selecting a sound mode

Press SOUND MODE 0 1 to select a sound mode.

1

If the content played back does not support the previously selected sound mode,

0

the most appropriate sound mode for the content is automatically selected.

.

Front panel Display Rear panel Remote Index

60

Contents Connections Playback Settings Tips Appendix

Description of sound mode types

o

Dolby sound mode

Sound mode type Description

Dolby PLg This mode can be selected when the Dolby PLg decoder is used to play back 2-channel sources in 5.1-channel surround

Dolby Digital This mode can be selected when playing sources recorded in Dolby Digital.

Dolby TrueHD This mode can be selected when playing sources recorded in Dolby TrueHD.

Dolby Digital Plus This mode can be selected when playing sources recorded in Dolby Digital Plus.

DTS sound mode

Sound mode type Description

DTS Neo:6 This mode can be selected when a DTS Neo:6 decoder is used to play back 2-channel source in 5.1-channel surround

DTS Surround This mode can be selected when playing sources recorded in DTS.

DTS 96/24 This mode can be selected when playing sources recorded in DTS 96/24.

DTS-HD This mode can be selected when playing sources recorded in DTS-HD.

DTS Express This mode can be selected when playing sources recorded in DTS Express.

PCM multi-channel sound mode

Sound mode type Description

Multi Ch In This mode can be selected when playing multi-channel PCM sources.

sound with an enveloping surround sound experience.

sound.

Front panel Display Rear panel Remote Index

61

Contents Connections Playback Settings Tips Appendix

Original sound mode

Sound mode type Description

Multi Ch Stereo This mode is for enjoying stereo sound from all speakers.

Virtual This mode lets you experience an expansive surround sound effect when playing back through just the front (L/R)

Stereo sound mode

Sound mode type Description

Stereo This mode plays 2-channel stereo audio with no additional surround sound processing.

Direct sound mode

Sound mode type Description

Direct This mode plays back audio as recorded in the source.

speakers only, and when listening with stereo headphones.

Sound is output from the front left and right speakers, and subwoofer if connected.

0

When multi-channel signals are inputted, they are mixed down to 2-channel audio and are played back with no

0

additional surround sound processing.

Front panel Display Rear panel Remote Index

62

q w

Contents

o

Views on the display

.

Shows a decoder to be used.

A

0

In the case of the Dolby Digital decoder, “x” is displayed.

0

In the case of the Dolby Digital Plus decoder, “w” is displayed.

Shows the name of the input source being played back.

B

Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

63

Contents Connections Playback Settings Tips Appendix

HDMI control function

A recent addition to the HDMI standard is CEC (Consumer Electronics Control), which allows control signals from one device to communicate with
another device via the HDMI cable connection.

Setting procedure

Enable the HDMI control function of this unit.

1

Set “HDMI Control” to “On”. (v p. 81)

Turn the power on for all the devices connected by

2

HDMI cable.

Set the HDMI control function for all devices connected

3

by HDMI cable.

Please consult the operating instructions for the connected

0

devices to check the settings.
Carry out steps 2 and 3 should any of the devices be unplugged.

0

Switch the television input to the HDMI input connected

4

to this unit.

Front panel Display Rear panel Remote Index

64

Switch the input source of this unit to check that video

5

from the player connected by HDMI is played back
correctly.

When you turn the TV’s power to standby, check that

6

the power of this unit also goes to standby.

NOTE

Some functions may not operate depending on the connected TV or player. Check

0

the owner’s manual of each device for details beforehand.

CH LEVEL

uio p

Contents Connections Playback Settings Tips Appendix

Adjusting the volume of each channel to match the input source (Ch Level Adjust)

The volume of each channel can be changed while listening to music. You
can set this for each input source.

Press CH LEVEL.

1

The “Ch Level Adjust” screen is displayed.

Use ui to select the channel that you wish to adjust.

2

Use o p to adjust the volume.

3

–12.0 dB – +12.0 dB (Default : 0.0 dB)

Select “Reset” and press ENTER if you want to restore the adjustment values of

0

the various channels to “0.0 dB” (default).
Headphone volume can be adjusted when a headphone is connected.

0

“Ch Level Adjust” settings are stored for each input source.

0

You can only set this for speakers that output audio. In addition, you cannot set

0

this when in the menu “HDMI Audio Out” is set to “TV”. (v

p. 80)

.

Front panel Display Rear panel Remote Index

65

SLEEP

Contents Connections Playback Settings Tips Appendix

Sleep timer function

You can have the power automatically switched to standby once a set time
has elapsed. This is convenient for viewing and listening while going to
sleep.

.

Front panel Display Rear panel Remote Index

66

Contents Connections Playback Settings Tips Appendix

o

Using the sleep timer

Press SLEEP and display the time you want to set.

1

The SLEEP indicator lights up on the display and the sleep timer

0

starts.
You can set the sleep timer in the range from 10 to 120 minutes in

0

steps of 10 minutes.

Checking the remaining time

Press SLEEP when the sleep timer is in operation.
The remaining time appears on the display.

o

To cancel the sleep timer

Press SLEEP to select “Off”.
The SLEEP indicator on the display turns off.

The sleep timer setting is canceled when the unit switches to standby mode.

0

NOTE

The sleep timer function cannot turn off the power of devices connected to this

0

unit. To turn off the power of those connected devices, set up sleep timers on the
connected devices themselves.

Front panel Display Rear panel Remote Index

67

QUICK
SELECT
1 – 4

Contents Connections Playback Settings Tips Appendix

Quick select plus function

Settings such as the input source, volume level and sound mode can be
registered to the QUICK SELECT 1 - 4 buttons.

You can simply press one of the registered QUICK SELECT buttons in
subsequent playbacks to switch to the group of saved settings in a batch.

By saving frequently used settings at the QUICK SELECT 1 – 4 buttons,
you will always be able to easily call up the same playback environment.

.

Front panel Display Rear panel Remote Index

68

Contents Connections Playback Settings Tips Appendix

Calling up the settings

Press QUICK SELECT.

1

The Quick Select settings registered to the button you pressed are
called up.

The default settings for the input source and volume are as shown

0

below.

Button Input source Volume

QUICK SELECT 1 CBL/SAT 40

QUICK SELECT 2 DVD/Blu-ray 40

QUICK SELECT 3 Game 40

QUICK SELECT 4 Bluetooth 40

Changing the settings

Set the items below to the settings you want to

1

register.

Input source (v p. 38)

A

Volume (v p. 39)

B

Video Select settings (v

C

Sound mode (v p. 60)

D

Press and hold the desired QUICK SELECT until

2

“Quickz Memory” appears on the display.

The current settings will be memorized.
z is displayed the number for the QUICK SELECT button you

pressed.

p. 59)

Front panel Display Rear panel Remote Index

69

Contents Connections Playback Settings Tips Appendix

Settings

Menu map

When using menu operations, connect this unit to a TV and operate this unit while viewing the TV.
The recommended settings are configured for this unit by default. You can customize this unit based on your existing system and your preferences.

Setting items Detailed items Description Page

Surr.Parameter Adjusts surround sound parameters. 74

.

.

Audio

Video

Restorer Expands the low and high frequency components of compressed audio content such as

Audio Delay Compensates for incorrect timing between video and audio. 78

Volume Make volume settings. 78

Room EQ Set whether to use the equalizer or not. 79

HDMI Audio Out Select HDMI audio output device. 80

HDMI PassThrough Selects how this unit will pass HDMI signals to the HDMI output in standby power mode. 80

Pass Source Sets the HDMI connector that inputs HDMI signals when in standby. 81

HDMI Control You can link operations with devices connected to HDMI and compatible with HDMI

ARC On the TV connected to the HDMI MONITOR connector, set whether to receive sound

TV Audio Switching Sets automatic switching to the “TV Audio” input when a TV connected via HDMI sends

Pow.Off Control Links the power standby of this unit to external devices. 83

MP3 files to enable richer audio playback.

Control.

from the TV via HDMI.

an appropriate CEC control command to this unit.

77

81

82

82

Front panel Display Rear panel Remote Index

70

Contents Connections Playback Settings Tips Appendix

Setting items Detailed items Description Page

Input Assign Changes input connector assignment. 84

Source Level Adjusts the playback level of the audio input. 84

Input Select Sets the audio input mode and decode mode. 85

.

Inputs

Auto Setup The acoustic characteristics of the connected speakers and listening room are

measured and the optimum settings are made automatically.

Manual Setup Sets up the speakers manually or changes the “Auto Setup” settings. 91

.

Speakers

86

Front panel Display Rear panel Remote Index

71

Contents Connections Playback Settings Tips Appendix

Setting items Detailed items Description Page

Language Changes the language of the display on the TV screen. 95

ECO Configures the ECO Mode and Auto Standby energy-saving functions. 95

Bluetooth Configures the Bluetooth settings. 97

.

General

.

Setup Assistant

Front Display Makes settings related to the display on this unit. 98

Firmware Update the firmware of this unit. 98

Setup Lock Protects settings from inadvertent changes. 99

Begin Setup... Performs basic installation/connections/settings from the beginning according to the

guidance indicated on the TV screen.

Page 7 of
the separate
manual
“Quick Start
Guide”

Front panel Display Rear panel Remote Index

72

uio p

ENTER

SETUP

BACK

Contents Connections Playback Settings Tips Appendix

Menu operations

Press SETUP.

1

The menu is displayed on the TV screen.

Use ui to select the menu to be set or operated, then

2

press ENTER.

Use o p to change to desired setting.

3

Press ENTER to enter the setting.

4

To return to the previous item, press BACK.

0

Exiting the menu, press SETUP while the menu is displayed. The

0

menu display disappears.

.

Front panel Display Rear panel Remote Index

73

Contents Connections Playback Settings Tips Appendix

Audio

Make audio-related settings.

o

Surr.Parameter

You can adjust the surround audio sound field effects to match your
preferences.
The items (parameters) that can be adjusted depend on the signal being
input and the currently set sound mode. For details on the adjustable
parameters, see “Sound modes and surround parameters” (v

Some setting items cannot be set while playback is stopped. Make the settings

0

during playback.
“Surr.Parameter” settings are stored for each sound mode.

0

p. 123).

Mode

Set the sound mode according to the input signal.

n

Dolby PLg Mode

Cinema :

Music :

Game :

Pro Logic : Dolby Pro Logic playback mode.

n

DTS Neo: 6 mode

Cinema :

Music :

“Music” mode is also effective for video sources that contain a lot of stereo

0

music.

Switches to the sound mode suitable for
enjoying movies and TV programs.

Switches to the sound mode suitable for
enjoying music.

Switches to the sound mode suitable for
enjoying games.

Switches to the sound mode suitable for
enjoying movies and TV programs.

Switches to the sound mode suitable for
enjoying music.

Front panel Display Rear panel Remote Index

74

Contents Connections Playback Settings Tips Appendix

o

Dynamic Comp.

Compress dynamic range (difference between loud and soft sounds).

Auto:

Low / Medium / High: These set the compression level.

Off:

“Auto” can only be set when Dolby TrueHD signals are input.

0

Automatic dynamic range compression
on/off control according to source.

Dynamic range compression is always
off.

o

Low Frequency

Adjust the low frequency effects level (LFE).

-10 dB – 0 dB (Default : 0 dB)

For proper playback of the different sources, we recommend setting to the

0

values below.

Dolby Digital sources : 0 dB

0

DTS movie sources : 0 dB

0

DTS music sources: -10 dB

0

o

Center Image

Distributes the dialogue output from the center channel to the front left
and right channels and widens the sound image in the front.

0.0 – 1.0 (Default : 0.3)

You can set this when the sound mode is DTS Neo:6 in the “Music” mode.

0

The smaller the value, the more dialogue is concentrated on the center

0

channel. The larger the value, the more dialogue is distributed to front left and
right channels, and the more the sound image widens in the front.

Front panel Display Rear panel Remote Index

75

Contents Connections Playback Settings Tips Appendix

o

Panorama

The front sound field is expanded further towards the back to create a
seamlessly inclusive sound impression.

On: Use “Panorama”.

Off

(Default):

You can set this when the sound mode is Dolby PLg in the “Music” mode.

0

Do not use “Panorama”.

o

Dimension

Shift sound image center to front or rear to adjust playback balance.

0 – 6 (Default : 3)

You can set this when the sound mode is Dolby PLg in the “Music” mode.

0

As you set a smaller number, the surround sound field shifts backward; as you

0

set a larger number, the surround sound field shifts forward.

o

Center Width

Distributes the dialogue output from the center channel to left and right
channels and widens the sound image in the front.

0 – 7 (Default : 3)

You can set this when the sound mode is Dolby PLg in the “Music” mode.

0

The smaller the value, the more dialogue is concentrated on the center

0

channel. The larger the value, the more dialogue is distributed to front left and
right channels, and the more the sound image widens in the front.

Front panel Display Rear panel Remote Index

76

Contents Connections Playback Settings Tips Appendix

o

Subwoofer

Turn subwoofer output on and off.

On
(Default):

Off: The subwoofer is not used.

This can be set when the surround mode is set to “Direct” or “Stereo”.

0

o

Set Defaults

The “Surr.Parameter” settings are returned to the default settings.

The subwoofer is used.

Restorer

Compressed audio formats such as MP3, WMA (Windows Media Audio)
and MPEG-4 AAC reduce the amount of data by eliminating signal
components that are hard for the human ear to hear. The “Restorer”
function generates the signals eliminated upon compression, restoring the
sound to conditions near those of the original sound before compression.
It also restores the original bass characteristics for a rich and expanded
tonal range.

On: Use “Restorer”.

Off

(Default):

This item can be set with analog signals or PCM signal (Sample Rate = 44.1/48

0

kHz) is input.
This cannot be set when the sound mode is set to “Direct”.

0

“Restorer” settings are stored for each input source.

0

Do not use “Restorer”.

Front panel Display Rear panel Remote Index

77

Contents Connections Playback Settings Tips Appendix

o

Audio Delay

Compensates for incorrect timing between video and audio.

0 ms – 200 ms (Default : 0 ms)

“Audio Delay” settings are stored for each input source.

0

The “Audio Delay” settings can be set even if AUDIO DELAY + or AUDIO DELAY -

0

is pressed on the remote control unit.

Volume

Make volume settings.

o

Scale

Set how volume is displayed.

0 - 98
(Default):

–79.5 dB – 18.0 dB:

Display in the range 0 (Min) to 98.

Display ---dB (Min), in the range –79.5 dB
to 18.0 dB.

Limit

Make a setting for maximum volume.

60 (–20 dB) / 70 (–10 dB) / 80 (0 dB)

Off (Default)

The dB value is displayed when the “Scale” setting is “ –79.5 dB – 18.0 dB”.

0

p. 78)

(v

o

Power On Level

Define the volume setting that is active when the power is turned on.

Last
(Default):

Mute:

1 – 98 (–79 dB – 18 dB) : The volume is adjusted to the set level.

The dB value is displayed when the “Scale” setting is “ –79.5 dB – 18.0 dB”.

0

p. 78)

(v

Use the memorized setting from the last
session.

Always use the muting on condition when
power is turned on.

Front panel Display Rear panel Remote Index

78

Contents Connections Playback Settings Tips Appendix

o

Mute Level

Set the amount of attenuation when muting is on.

Full
(Default):

–40 dB : The sound is attenuated by 40 dB down.

–20 dB : The sound is attenuated by 20 dB down.

The sound is muted entirely.

Room EQ

Set whether to use the equalizer or not.

On: Use “Room EQ”.

Off

(Default):

Speakers for which “Room EQ” can be set differ according to the sound mode.

0

Do not use “Room EQ”.

Front panel Display Rear panel Remote Index

79

Contents Connections Playback Settings Tips Appendix

Video

Make settings for HDMI Audio Out, HDMI PassThrough and HDMI Control settings.

NOTE

When “HDMI PassThrough” and “HDMI Control” is set to “On”, it consumes more standby power. (“HDMI PassThrough” (v p. 80), “HDMI Control” (v p. 81)) If you are

0

not using this unit for an extended period, it is recommended that you unplug the power cord from the power outlet.

HDMI Audio Out

Select HDMI audio output device.

AVR
(Default):

TV: Play back through TV connected to the unit.

When the HDMI control function is activated, priority is given to the TV audio

0

setting. (v
When the power of this unit is on and “HDMI Audio Out” is set to “TV”, audio is

0

output as 2-channel from the HDMI OUT connector.

p. 64)

Front panel Display Rear panel Remote Index

Play back through speakers connected to
the unit.

HDMI PassThrough

Selects how this unit will transmit HDMI signals to the HDMI output in
standby power mode.

On:

Off

(Default):

80

Transmits the selected HDMI input through
this unit’s HDMI output when this unit is in
standby power mode.

No HDMI signals are transmitted through
this unit’s HDMI output in standby power
mode.

Contents Connections Playback Settings Tips Appendix

Pass Source

Sets the HDMI connector that inputs HDMI signals when in standby.

Last
(Default):

CBL/SAT /
DVD/Blu-ray /
Game / Media Player:

“Pass Source” can be set when “HDMI PassThrough” is set to “On” or “HDMI

0

Control” is set to “On”. (“HDMI PassThrough” (v
Control” (v

p. 81))

The most recently used input source will go
into standby mode.

Pass through the selected input source.

p. 80), “HDMI

HDMI Control

You can link operations with devices connected to HDMI and compatible
with HDMI Control.

On: Use HDMI control function.

Off

(Default):

Please consult the operating instructions for each connected device to check the

0

settings.
Refer to “HDMI control function” for more information about the HDMI control

0

function. (v p. 64)

NOTE

If the “HDMI Control” settings have been changed, always reset the power to

0

connected devices after the change.

Do not use HDMI control function.

Front panel Display Rear panel Remote Index

81

Contents Connections Playback Settings Tips Appendix

ARC

On the TV connected to the HDMI MONITOR connector, set whether to
receive sound from the TV via HDMI.

On: Use ARC function.

Off

(Default):

You can adjust the volume of this unit using the TV remote control.

0

If using this function, use a TV compatible with ARC (Audio Return Channel) and

0

enable the HDMI control function of the TV.
When “HDMI Control” is set to “On”, the “ARC” settings automatically switch “On”.

0

p. 81)

(v

NOTE

If the “ARC” settings have been changed, always reset the power to connected

0

devices after the change.

Do not use ARC function.

TV Audio Switching

Sets automatic switching to the “TV Audio” input when a TV connected via
HDMI sends an appropriate CEC control command to this unit.

On
(Default):

Off:

“TV Audio Switching” can be set when “HDMI Control” is set to “On”. (v p. 81)

0

Select the “TV Audio” input automatically
when receiving a command from the TV.

Do not select the “TV Audio” input
automatically when receiving a command
from the TV.

Front panel Display Rear panel Remote Index

82

Contents Connections Playback Settings Tips Appendix

Pow.Off Control

Links the power standby of this unit to external devices.

All
(Default):

Video:

Off: This unit does not link with power to a TV.

“Pow.Off Control” can be set when “HDMI Control” is set to “On”. (v p. 81)

0

If power to a connected TV is turned off
independently of the input source, power to
this unit is automatically set to standby.

With an input source being selected that is
equipped “HDMI”, when you turn the power
of the TV off, power to this unit is
automatically set to standby.

Front panel Display Rear panel Remote Index

83

Input Assign

OPTICAL1

OPTICAL2
Set Defaults

TV Audio

CBL/SAT

Contents Connections Playback Settings Tips Appendix

Inputs

Perform settings related to input source playback.
You do not have to change the settings to use the unit. Make settings when needed.

Input Assign

By default, each item is set as follows.

By making connections as indicated by the input sources printed on the
audio/video input connectors of this unit, you can just press one of the
input source select buttons to easily play back audio or video from a
connected device.

Please change the assignment of the digital audio input connector when
connecting an input source that differs from that printed to the audio/video

0

Input source

Input connector

OPTICAL1

OPTICAL2

CBL/

SAT

S

DVD/

input terminals of this unit.

o

Set Defaults

The “Input Assign” settings are returned to the default settings.

Source Level

This function corrects the playback level of the selected input source’s
audio input.

Make this setting if there are differences in the input volume levels
between the different sources.

.

Front panel Display Rear panel Remote Index

-12 dB – +12 dB (Default : 0 dB)

“Source Level” settings are stored for each input source.

0

84

Blu-

ray

Media

Player

Blu-

ray

Game

TV

Audio

S

Contents Connections Playback Settings Tips Appendix

o

Input Select

Set the audio input mode and decode mode of each input source.
The input modes available for selection may vary depending on the input

source.

“Input Select” settings are stored for each input source.

0

o

Input Mode

Set the audio input modes for the different input sources.
It is normally recommended to set the audio input mode to “Auto”.

Auto
(Default):

HDMI: Play only signals from HDMI input.

Digital: Play only signals from digital audio input.

Analog: Play only signals from analog audio input.

When digital signals are properly input, the ~ indicator lights on the display.

0

If the ~ indicator does not light, check “Input Assign” and the connections.
(v p. 84)

If “HDMI Control” is set to “On” and a TV compatible with the ARC is

0

connected via the HDMI MONITOR connectors, the input mode whose input
source is “TV Audio” is fixed to ARC.

Automatically detect input signal and
perform playback.

Decode Mode

Set the audio decode mode for input source.
It is normally recommended to set the audio input mode to “Auto”. But

we recommend changing it to “PCM” or “DTS” if the start of the source
is clipped or noise occurs.

Auto
(Default):

PCM: Decode and play only PCM input signals.

DTS: Decode and play only DTS input signals.

This item can be set for input sources for which the HDMI input connector is

0

assigned or for which “OPTICAL1” or “OPTICAL2” is assigned under “Input
Assign” in the menu. (v p. 84)

Detect type of digital audio input signal
and decode and play automatically.

Front panel Display Rear panel Remote Index

85

FL SW C FR

SRSL

Surround speaker (R)

Surround speaker (L)

Subwoofer

Center speaker

Front speaker (R)

Front speaker (L)

Main listening position

FL
FR
C
SW
SL
SR

Contents Connections Playback Settings Tips Appendix

Speakers

The acoustic characteristics of the connected speakers and listening room are measured and the optimum settings are made automatically. This is called
“Auto Setup”.

You do not have to perform “Auto Setup” when you have already performed “Speaker Setup” in “Setup Assistant”.
To set up the speakers manually, use “Manual Setup” on the menu. (v p. 91)

Auto Setup

To perform measurement, place the Sound calibration microphone in the
main listening position.

.

Front panel Display Rear panel Remote Index

About the main listening position

o

The main listening position is the position where listeners would
normally sit or where one would normally sit alone within the listening
environment. Before starting “Auto Setup”, place the Sound calibration
microphone in the main listening position.

86

Contents

Connections Playback Settings Tips Appendix

NOTE

Make the room as quiet as possible. Background noise can disrupt the room

0

measurements. Close windows and turn off the power on electronic devices
(radios, air conditioners, fluorescent lights, etc.). The measurements could be
affected by the sounds emitted by such devices.

During the measurement process, place cell phones outside the listening room.

0

Cell phone signals could disrupt the measurements.
Do not stand between the speakers and Sound calibration microphone or allow

0

obstacles in the path while the measurements are being made. Also, install the
Sound calibration microphone at least 50 cm away from the wall. Failure to do so
will result in inaccurate readings.

During the measurement process, audible test tones will come from the speakers

0

and subwoofer(s), but this is part of normal operation. If there is background noise
in the room, these test signals will increase in volume.

Measurement cannot be performed when headphones are connected. Unplug the

0

headphones before performing “Auto Setup”.

Front panel Display Rear panel Remote Index

87

Finish

Measurement

Preparation

Contents Connections Playback Settings Tips Appendix

Procedure for speaker settings (Auto
Setup)

.

Mount the Sound calibration microphone on a tripod

1

and place it in the main listening position.

When installing the Sound calibration microphone, point the tip of
the microphone toward the ceiling and adjust the height to match the
height of the ears of a listener in a seated position.

If using a subwoofer capable of the following

2

adjustments, set up the subwoofer as shown below.

n

When using a subwoofer with a direct mode

Set the direct mode to “On” and disable the volume adjustment
and crossover frequency setting.

n

When using a subwoofer without a direct mode

Make the following settings:

Volume : 12 o’clock position

0

Crossover frequency : Maximum/Highest Frequency

0

Low pass filter : Off

0

Standby mode : Off

0

Front panel Display Rear panel Remote Index

88

When the Sound calibration microphone is
connected, the following screen is displayed.

Auto Setup

Your AVR can automatically measure the
acoustics of your room and the optimize
your speakers.

Start

Contents

Connections Playback Settings Tips Appendix

Connect the Sound calibration microphone to the

3

SETUP MIC jack of this unit.

.

.

Select “Start”, then press ENTER.

4

Select “Next”, then press ENTER.

5

Select “Begin Test”, then press ENTER.

6

7

Measurement requires several minutes.

0

NOTE

If “Caution!” is displayed on TV screen:

0

Go to “Error messages” (v

0

and perform the necessary procedures.

n

To cancel Auto Setup

Press BACK to display the popup screen.

A

Press o to select “Yes”, then press ENTER.

B

p. 90). Check any related items,

Unplug the Setup and measurement microphone from
the unit’s SETUP MIC jack.

Do not change the speaker connection or subwoofer volume after
“Auto Setup”. If these are changed, run “Auto Setup” again in order
to configure the optimum equalizer settings.

Front panel Display Rear panel Remote Index

89

Contents Connections Playback Settings Tips Appendix

Error messages

An error message is displayed if “Auto Setup” could not be completed due to speaker placement, the measurement environment, etc. If an error message
is displayed, perform the necessary measures. Be sure to turn off the power before checking speaker connections.

Examples Error details Measures

Front L: None

The displayed speaker could not be detected.

0

Check the connections of the displayed speaker.

0

Front panel Display Rear panel Remote Index

90

Contents Connections Playback Settings Tips Appendix

Manual Setup

Perform when setting the speakers manually or when changing settings
made in “Auto Setup”.

This unit can be used without changing “Manual Setup” settings. Please

0

set if necessary.

Speaker Config.

Select whether or not speakers are present, playback capacity for low
bass frequencies and speaker size.

o

Front

Set the front speaker size.

Large
(Default):

Small:

When “Subwoofer” is set to “No”, “Front” is automatically set to “Large”.

0

When “Front” is set to “Small”, “Center” and “Surround” can not be set to

0

“Large”.

Use a large speaker that can adequately
play back very low bass frequencies.

Use a small speaker that has inadequate
playback capacity for very low bass
frequencies.

Front panel Display Rear panel Remote Index

91

Contents Connections Playback Settings Tips Appendix

o

Center

Set the presence and size of the center speaker.

Large:

Small
(Default):

None:

Use a large speaker that can adequately
play back very low bass frequencies.

Use a small speaker that has inadequate
playback capacity for very low bass
frequencies.

Select when a center speaker is not
connected.

Distances

Set distance from listening position to speakers.
Measure beforehand the distance from the listening position to each

speaker.

o

Step

Set the unit of distance.

0.1 m / 0.01 m (Default: 0.1 m)

o

Subwoofer

Set the presence of a subwoofer.

Yes
(Default):

No:

o

Surround

Set the presence and size of the surround speakers.

Large:

Small
(Default):

None:

Use a subwoofer.

Select when a subwoofer is not
connected.

Use a large speaker that can adequately
play back very low bass frequencies.

Use a small speaker that has inadequate
playback capacity for very low bass
frequencies.

Select when the surround speakers are
not connected.

Front panel Display Rear panel Remote Index

o

Set Defaults

The “Distances” settings are returned to the default settings.

o

Set the distance

0.00 m - 18.00 m

The speakers that can be selected differ depending on the “Speaker Config.”

0

settings. (v
Default settings:

0

Front L / Front R / Center / Subwoofer: 3.60 m
Surround L / Surround R: 3.00 m

Set the difference in the distance between the speakers to less than 6.00 m.

0

p. 91)

92

Contents Connections Playback Settings Tips Appendix

Levels

Set the volume of the test tone to be the same at the listening position
when it is output from each speaker.

o

Test Tone Start

A test tone is output from the selected speaker.
While listening to the test tone, adjust the volume output from the

selected speaker.

–12.0 dB – +12.0 dB (Default : 0.0 dB)

The set “Levels” are reflected in all sound modes.

0

When headphones are connected to the PHONES connector on this unit, you

0

cannot set “Levels”.

o

Set Defaults

The “Levels” settings are returned to the default settings.

Crossovers

Set in accordance with the lower limit frequency of the base frequencies
that can be played back through each speaker.

o

Set the crossover frequency

40 Hz / 60 Hz / 80 Hz / 90 Hz / 100 Hz / 110 Hz / 120 Hz / 150 Hz /
200 Hz / 250 Hz (Default : 80 Hz)

“Crossovers” can be set when the “Subwoofer Mode” setting is “LFE+Main”, or

0

when you have a speaker that is set to “Small”. (v
The default crossover frequency is “80 Hz”, which will work best with the

0

widest variety of speakers. We recommend setting to a higher frequency that
the crossover frequency when small speakers are used. For example, set to
“250 Hz” when the frequency range of the speakers is 250 Hz – 20 kHz.

Sounds below crossover frequency is cut off in the output from the speaker set

0

up in “Small”. The cut off bass frequencies is output from the sub-woofer or
front speaker.

p. 94)

Front panel Display Rear panel Remote Index

93

Contents Connections Playback Settings Tips Appendix

o

Bass

Set subwoofer and LFE signal range playback.

o

Subwoofer Mode

Select low range signals to be reproduced by subwoofer.

LFE:

LFE+Main

(Default):

“Subwoofer Mode” can be set when “Speaker Config.” - “Subwoofer” is set to

0

other than “No”. (v
Play music or a movie source and select the mode offering the strongest bass.

0

If “Speaker Config.” - “Front” and “Center” are set to “Large”, and “Subwoofer

0

Mode” is set to “LFE”, no sound may be output from the subwoofers,
depending on the input signal or selected sound mode. (v
Select “LFE+Main” if you want the bass signals to always be produced from
the subwoofer.

The low range signal of the channel set to
“Small” speaker size is added to the LFE
signal output from the subwoofer.

The low range signal of all channels is
added to the LFE signal output from the
subwoofer.

p. 92)

p. 91)

LPF for LFE

Set LFE signal playback range. Set this when you want to change the
playback frequency (low pass filter point) of the subwoofer.

80 Hz / 90 Hz / 100 Hz / 110 Hz / 120 Hz/ 150 Hz /
200 Hz / 250 Hz (Default: 120 Hz)

Front panel Display Rear panel Remote Index

94

Contents

General

Make various other settings.

Connections Playback Settings Tips Appendix

Language

Set the language for display the menu on the TV screen.

English / Français / Español (Default : English)

“Language” can also be set up by the following operation. However, the menu

0

screen is not displayed. Watch the display while configuring the settings.

1. Press and hold the main unit’s TUNE +, TUNE - and DIMMER for at least 3

seconds.
“V.Format:< PAL >” appears on the display.

2. Press the main unit’s STATUS.

“Lang.:<ENGLISH >” appears on the display.

3. Use the main unit’s TUNER PRESET CH + or TUNE - and set the language.

4. Press TUNE - to enter the setting.

ECO

Configure the settings of the ECO Mode and auto standby mode.

o

ECO Mode

This mode can reduce the power consumption when the power of the
unit is on.

On:

Auto:

Off

(Default):

When you want to output audio at a high volume level, it is recommended to

0

set “ECO Mode” to “Off”.

0

Eco mode can also be switched by pressing ECO G on the remote control
unit.

The power consumption is always
reduced, regardless of the volume.

The power consumption is automatically
reduced to match the volume.

Do not reduce the power consumption.

Front panel Display Rear panel Remote Index

95

Contents Connections Playback Settings Tips Appendix

o

Pow.On Default

Set the mode to ECO when the power is on.

Last
(Default):

On:

Auto:

Off:

The ECO Mode will be set to the previous
setting before the power was switched
off.

When power is turned on, the mode will
always be switched to the “ECO Mode” in
“On”.

When power is turned on, the mode will
always be switched to the “ECO Mode” in
“Auto”.

When power is turned on, the mode will
always be switched to the “ECO Mode” in
“Off”.

o

Auto Standby

Set so the unit power automatically switches to standby.
Sets the time for switching to auto standby when there are no audio or

video signals input into this unit.
Before the unit enters standby mode, “Auto Standby” is displayed on

the unit display and the menu screen.

60 min:

30 min:

15 min
(Default):

Off:

The unit goes into standby after 60 minutes.

The unit goes into standby after 30 minutes.

The unit goes into standby after 15 minutes.

The unit does not go into standby
automatically.

Front panel Display Rear panel Remote Index

96

Contents Connections Playback Settings Tips Appendix

o

Bluetooth

Configures the Bluetooth settings.

o

BluetoothStandby

Set whether or not to turn the unit’s power on when a Bluetooth device
is operated.

On: Turns the Bluetooth standby function on.

Off

(Default):

When the “BluetoothStandby” setting is “On” and the connection operation is

0

performed on a Bluetooth device when this unit is in the standby state, this
unit’s power automatically switches on. In order to use this operation, the
device needs to be paired with this unit in advance.

NOTE

When using the “Denon 500 Series Remote” app, use with the

0

“BluetoothStandby” setting set to “On”.

Turns the Bluetooth standby function off.

Auto-Select

Set whether to automatically switch the source input to “Bluetooth”
when performing the connection operation from a Bluetooth device.

On
(Default):

Off:

Set “Auto-Select” to “Off” if you do not want the source input of this unit to

0

automatically switch to “Bluetooth” when connecting the “Denon 500 Series
Remote” app to this unit.

Some Bluetooth devices may automatically connect to this unit when they

0

enter this unit’s communication range. If this happens, setting “Auto-Select” to
“Off” will prevent unintended actions such as turning on this unit or switching
the source input to “Bluetooth”.

Select the “Bluetooth” source input
automatically when a Bluetooth device
connects to this unit.

Do not select to the “Bluetooth” source
input when a Bluetooth device connects
to this unit.

Front panel Display Rear panel Remote Index

97

Contents Connections Playback Settings Tips Appendix

Front Display

Adjust the display brightness of this unit.

o

Dimmer

Bright
(Default):

Dim: Reduced display brightness.

Dark: Very low display brightness.

Off: Turns the display off.

When the display brightness is set to “Off”, the display turns off as in the

0

standby state.
You can also adjust the display by pressing DIMMER on the main unit.

0

Normal display brightness.

Firmware

When new firmware is supplied, update this unit using the USB port.
Use a USB memory device to update the firmware.

o

Update Start

Start the firmware update.
To update the firmware, connect the USB memory device to the USB

port on this unit.

Front panel Display Rear panel Remote Index

98

Contents Connections Playback Settings Tips Appendix

Setup Lock

Protect settings from inadvertent changes.

o

Lock

On: Turn protection on.

Off

(Default):

Perform the following operations to set “Lock” to “Off”.

0

1. Press and hold SETUP for more than 3 seconds.

“Setup Lock:0On1” appears on the display.

2.

Use o p to select “Off”, then press ENTER.

NOTE

When “Lock” is set to “On”, no setting items are displayed except for “Setup

0

Lock”.

Turn protection off.

Front panel Display Rear panel Remote Index

99

INFO

SOURCE

SOUND

SOURCE

ROOM EQ

Digital

Multi Ch Stereo

Bluetooth

Off

40.0

Contents Connections Playback Settings Tips Appendix

Checking the information

Information on the main unit’s various settings (Status) and on input
signals (Audio Input Signal) is shown on the display.

Press INFO.

1

The information screen is displayed.

Press INFO to display current input source name, volume, sound mode, and other

0

information at the bottom of the screen.

.

NOTE

The status display screen cannot be displayed when playing the following video

0

signals.

Computer resolution video

0

Video with an aspect ratio other than 16:9 or 4:3

0

4K video

0

.

Front panel Display Rear panel Remote Index

100
