De’Longhi Beverage Cabinet
Model
DEBC 145
USER GUIDE
Please read this user guide carefully and retain for future reference
Contents
Features . ........................................................03
De’Longhi Safety Precautions . . . . . . . . . . . . . ............................04
Beverage Cabinet Safety Precautions . . . . . . .............................05
Installation Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ...07
Installation........................................................08
- Warnings
- Before using your Beverage Cabinet
- Installation of your Beverage Cabinet
- Reversing the door swing of your appliance
- Installing Stainless Steel handle
Using your Beverage Cabinet . . . . . . . . . . . . . . . . . . . . . ............ ........10
- ON/OFF power
- To lock the control panel
- Setting
- Interior light
- Door lock
- Shelves
the temperature control
Care and Cleaning . . . . . . . . . . . . . . . . . . . . ..... ........ ........ ........12
- Cleaning your Beverage Cabinet
- Power failure
- Moving your Beverage Cabinet
- Energy saving tips
Troubleshooting . . . . . . . ............................................13
Help us Help You ..................................................14
Warranty Information . . . . ............................................15
Page 2
Parts and Features
Model: DEBC 145
1
°F
°C
°F/
°C
8
2
3
4
5
6
7
Components:
1. Digital control panel
2. UV tinted triple glaze door
3. Glass shelf (total 1)
4. Wire shelf (total 2)
5. Door Lock
6. Front Ventilation
7. Levelling legs (4)
8. Cabinet
Dimensions:
Height 855mm
Width 595mm
Depth 615mm
Page 3
De’Longhi’s Safety Precautions
De’Longhi pride themselves on their
innovative range of the highest quality
consumer products.
De’Longhi ensures all of its products are
100% safe through quality design and
manufacture. All products meet or exceed
stringent laboratory-tested safety
requirements.
It is necessary for anyone using an electrical
appliance to be safety conscious. The
following precautions
safe use of an electrical appliance. Carefully
read all of the instructions provided with your
appliance:
Always turn the power off at the power
Ÿ
outlet before you insert or remove a plug.
Remove by grasping the plug, do not pull
on the cord.
Do not use your appliance with an
Ÿ
extension cord unless this cord has been
checked and tested by a qualified
technician or service person. The
extension cord must be a VDE-Listed, 3wire grounding extension cord that has a
grounding plug and outlet and that the
electrical rating of the cord is 220-240
volts and at least 10
Always use your appliance from a power
Ÿ
outlet of the voltage (A.C. only) marked on
the appliance.
Do not use an appliance for any purpose
Ÿ
other than its intended use.
Do not attempt to repair an electrical
Ÿ
appliance. Return a damaged or
malfunctioning appliance to a qualified
service centre for adjustment or repair if
required.
The appliance must be positioned so the
Ÿ
AC plug is accessible.
are essential for the
amperes.
This appliance is designed exclusively for
Ÿ
household use. All other uses are strictly
forbidden.
The appliance is not intended for use by
Ÿ
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless
they have been given supervision or
instruction concerning use of the
appliance by a person responsible for their
safety. Children should be supervised to
ensure that they do not play with the
appliance.
If
the power cable is damaged, it must be
Ÿ
replaced by the manufacturer, an
authorised service centre or a qualified
electrician in order to eliminate all risk.
WARNING: Do not damage the refrigerant
Ÿ
circuit.
Page 4
Beverage Cabinet Safety Precautions
Your safety and the safety of others is very
important. Safety messages are displayed in
this manual and on your appliance.
Read and obey these safety messages as they
will alert you to potential hazards and tell you
how to reduce the chance of injury.
Safety Alert Symbol
This symbol alerts you
to potential hazards.
DANGER
WARNING
CAUTION
Danger
Danger indicates a high level of risk to yourself and
others. Ensure that care is taken to avoid severe
injury or even death.
Warning
Warning indicates a moderate level of risk to
yourself, others and the product. Ensure that care
is taken to avoid extensive product damage or
injury.
serious
Caution
Caution indicates a level of risk to yourself, others
and the product. Ensure care is taken to avoid
moderate product damage or injuries.
Page 5
Beverage Cabinet Safety Precautions
Before the appliance is used, it
must be properly positioned
and installed as described in
this manual, so read the
manual carefully. To reduce the
risk of fire, electrical shock or
injury when using the
appliance, follow basic
precaution, including the
following:
DANGER
Plug into a grounded 3-prong outlet, do
Ÿ
not remove grounding prong, do not use
an adapter, and do not use an extension
cord.
It is recommended that a separate circuit,
Ÿ
serving only your appliance be provided.
Use receptacles that cannot be turned off
by a switch or pull chain.
Never clean appliance parts with
Ÿ
flammable fluids. These fumes can create
a fire hazard or explosion. And do not
store or use gasoline or other flammable
vapours and liquids in the vicinity of this or
any other appliance. The fumes can
create a fire hazard or explosion.
Do not connect or disconnect the electric
Ÿ
plug when your hands are wet.
Unplug the appliance or disconnect
Ÿ
power before cleaning or servicing. Failure
to do so can result in electrical shock or
death.
Do not attempt to repair or replace any
Ÿ
part of your appliance unless it is
specifically recommended in this material.
All other servicing should be referred to a
qualified technician.
WARNING
FOLLOW WARNINGS BELOW ONLY
WHEN APPLICABLE TO YOUR MODEL
Use two or more people to move and
Ÿ
install appliance. Failure to do so can
result in back or other injury.
To ensure proper ventilation for your
Ÿ
appliance, the front of the unit must be
completely unobstructed. Choose a wellventilated area with temperatures above
60°F (16°C) and below 90°F (32°C). This
unit must be installed in an area protected
from the element, such as wind, rain,
water spray or drips.
The appliance should not be located next
Ÿ
to ovens, grills or other sources of high
heat.
The appliance must be installed with all
Ÿ
electrical, water and drain connections in
accordance with state and local codes. A
standard electrical supply (240V AC only,
50 Hz), properly grounded in accordance
with the local codes and regulations.
Do not kink or pinch the power supply
Ÿ
cord of appliance.
The fuse (or circuit breaker) size should be
Ÿ
10 amperes.
It is important for the appliance to be
Ÿ
levelled in order to work properly. Yo u may
need to make several adjustments to level
it.
Never allow children to operate, play with
Ÿ
or crawl inside the appliance.
Do not use solvent-based cleaning agents
Ÿ
of abrasives on the interior. These
cleaners may damage or discolour the
interior.
Do not use this apparatus for other than its
Ÿ
intended purpose.
Page 6
Installation Safety Precautions
Electrical Connection
This appliance should be properly
Ÿ
grounded for your safety. The power cord
of this appliance is equipped with a threeprong plug which mates with standard
three prong wall outlets to minimise the
possibility of electrical shock.
Do not under any circumstances cut or
Ÿ
remove the third ground prong from the
power cord supplied. For personal safety,
this appliance must be properly
grounded.
This appliance requires a standard 240
Ÿ
Volt AC ~/50Hz electrical ground outlet
with three-prong. Have the wall outlet and
circuit checked by a qualified electrician
to make sure the outlet is properly
grounded. When a standard 2-prong wall
outlet is encountered, it is your
responsibility and obligation to have it
replaced with a properly grounded 3-
wall outlet.
prong
The cord should be secured behind the
Ÿ
appliance and not left exposed or
dangling to prevent accidental injury.
The appliance should always be plugged
Ÿ
into its own individual electrical outlet
which has a voltage rating that matches
the rating label on the appliance. This
provides the best performance and also
prevent overloading house wiring circuits
that could cause a fire hazard from
overheated. Never unplug the appliance
by pulling the power cord. Always grip
the plug firmly and pull straight out from
the receptacle. Repair or replace
immediately all power cords that have
become frayed or otherwise damaged.
Do not use a cord that shows cracks or
abrasion damage along its length or at
either end. When moving the appliance,
be careful not to damage
the power cord.
Extension Cord
Because of potential safety hazards under
Ÿ
certain conditions, it is strongly
recommended that you do not use an
extension cord with this appliance.
However, if you must use an extension
cord it must be checked and tested by a
qualified technician or service person.
The extension cord must be a VDE-Listed,
3-wire grounding extension cord that has
a grounding plug and outlet and that the
electrical rating of the cord is 220-240
Volts and at least 10 amperes.
Page 7
Installation
WARNING
To reduce the risk of fire, electrical
shock, or injury when using your
appliance, follow these basic
precautions:
Read all instructions before using the
Ÿ
Beverage Cabinet.
DANGER or WARNING: Risk of child
Ÿ
entrapment.
Child entrapment and suffocation are not
problems of the past. Junked or
abandoned appliances are still dangerous
. . . even if they will “just sit in the garage a
few days”.
Before you throw away your old
Ÿ
Beverage Cabinet: Take off the door.
Leave the shelves in place so that children
may not easily climb inside
Never allow children to operate, play with,
Ÿ
or crawl inside the appliance.
Never clean appliance parts with
Ÿ
flammable fluids. The fumes can create a
fire hazard or explosion.
Do not store or use gasoline or any other
Ÿ
flammable vapors and liquids in the
vicinity of this or any other appliance. The
fumes can create a fire hazard or
explosion.
Before using your Beverage Cabinet
Remove the exterior and interior packing.
Ÿ
Check to be sure you have all of the
Ÿ
following parts:
- 1 x Glass Shelf
- 2 x Wire Shelves
- 2 x Keys
- 1 x Stainless Steel Handle Assembly
with Hardware
- 2 x Decorative Screws.
- 1 x Instruction Manual.
Before connecting the Beverage Cabinet
Ÿ
to the power source, let it stand upright for
approximately 2 hours. This will reduce
the possibility of a malfunction in the
cooling system from handling during
transportation.
Clean the interior surface with lukewarm
Ÿ
water using a soft cloth.
Install the handle on the left side of the
Ÿ
door.
Installation of your Beverage Cabinet
This appliance is designed to be for free
Ÿ
standing installation or built-in (fully
recessed).
Place your Beverage Cabinet on a floor
Ÿ
that is strong enough to support it when it
is fully loaded. To level your Beverage
Cabinet, adjust the front levelling legs at
the bottom of the Beverage Cabinet.
Locate the Beverage Cabinet away from
Ÿ
direct sunlight and sources of heat (stove,
heater, radiator, etc.). Direct sunlight may
affect the acrylic coating and heat sources
may increase electrical consumption.
Extreme cold ambient temperatures may
also cause the unit not to perform
properly.
Avoid locating the unit in moist areas.
Ÿ
Plug the Beverage Cabinet into an
Ÿ
exclusive, properly installed-grounded
wall outlet. Do not under any
circumstances cut or remove the third
(ground) prong from the power cord. Any
questions concerning power and/or
grounding should be directed toward a
certified electrician or an authorised
service center.
Page 8
Installation
Clearances
Clearances required for the Beverage
Ÿ
Cabinet to adjacent surfaces are 10mm
from top and sides, and 50mm from rear.
10mm
(from sides)
°F
°F/°C
°C
Reversing the Door Swing of Your
Appliance
This appliance has the capability of the
Ÿ
door opening from either the left or right
side. The unit is delivered to you with the
door opening from the left side. Should
you desire to reverse the opening
direction, please call service for reversal
instructions.
10mm
(from top)
50mm
(from rear)
Pull away the door gasket (A) in the area
Ÿ
where the handle is to be installed on the
left side as in Illustration #1. The gasket is
easily displaced by hand, no tools are
necessary.
Align the handle (B) with the screws
Ÿ
installed. Tighten the screws (C) using a
Phillips head screwdriver until the handle
sets both flush and secured tightly
against the door frame. (DO NOT over
tighten as this will cause damage to the
handle assembly).
Replace the door gasket (A) to its original
Ÿ
position.
If you choose not to use the handle
Ÿ
supplied, simply follow step 1 to access
the installation screws and remove them
and then place the two decorative plugs
into the two holes separately. Continue on
to step 3 to replace the door gasket to its
original position.
A
1
Installing stainless steel handle
This Beverage Cabinet includes a stainless
steel handle that is not
this unit.
To install the handle please follow the below
instructions:
For your convenience the screws used in the
installation of the handle have been put in
place at the factory.
required to operate
C
2
B
Page 9
Using Your Beverage Cabinet
The temperature range of this Beverage
Ÿ
Cabinet is 2ºC to 10ºC.
It is recommended you install the
Ÿ
Beverage Cabinet in a place where the
ambient temperature is between 23º26ºC/ 72º-78ºF. If the ambient
temperature is above or below
recommended temperatures, the
performance of the unit may be affected.
For example, placing your unit in extreme
cold or hot conditions may cause interior
temperatures to fluctuate and the
2ºC to 10ºC may not be reached.
You can select temperature display
Ÿ
setting from Fahrenheit to Celsius degree
by touching the ºF/ºC mark. Fahrenheit or
Celsius degrees indicator will appear in
green color in the temperature display
window.
ON/OFF Power
To turn the appliance ON or OFF, press
Ÿ
and hold the POWER button for 2
seconds.
To Lock the Control Panel
Your Beverage Cabinet is equipped with
Ÿ
an automatic Control panel lock function.
This function will prevent any unwanted
changes to your temperature or power
settings.
The lock function will activate
Ÿ
automatically 12 seconds after the last
time a button is pushed on the control
panel.
range of
°C
°F/
Ÿ
Setting the Temperature Control
Ÿ
Ÿ
Ÿ
NOTE:
Ÿ
Ÿ
°F
°C
To unlock the control panel lock press and
hold the UP and DOWN arrow buttons
for 3 seconds the control panel will beep
and blink once indicating that the control
panel is active and the settings can be
changed.
You can set the temperature as you desire
by touching the UP or DOWN arrow
buttons. When you touch the two buttons
for the first time, the LED readout will show
the original temperature set at previous
time (the temperature preset at the factory
is 2ºC to 10ºC).
The temperature that you desire to set will
increase 1ºF or 1ºC if you touch the UP
button once, on the contrary the
temperature will decrease 1ºF or 1ºC if you
touch the DOWN button once.
The temperature inside the unit will
appear in blue in the display window.
If the unit is unplugged, power lost, or
turned off, you must wait 3 to 5 minutes
before restarting the unit. If you attempt to
restart before this time delay, the
Beverage Cabinet will not start.
When you use the Beverage Cabinet for
the first time or restart the Beverage
Cabinet after having been shut off for a
long time, there could be a few degrees
variance between the temperature you
select and the one indicated on the LED
readout. This is normal and it is due to the
length of the activation
Beverage Cabinet is running for a few
hours everything will be back to normal.
time. Once the
Page 10
Using Your Beverage Cabinet
Interior Light
You can turn the interior light ON or OFF
Ÿ
by touching the BULB button.
Door Lock
Your unit is provided with a lock and key
Ÿ
combination.
The keys are located inside the plastic bag
that contains the User's Guide. Insert the
key into the lock and tur n it
counterclockwise to unlock the door. To
lock the door do the reverse operation
making sure metal pin is engaged
completely. Remove the key and place it in
secure place for safekeeping.
a
Shelves
The Beverage Cabinet is equipped with one
glass shelf and two wire shelves. You can
move the shelves out and in smoothly.
To prevent damaging the door gasket,
Ÿ
make sure to have the door all the way
opened when pulling the shelves
outward.
For easy access to the storage content,
Ÿ
you can pull the shelves outward to gain
access to the items on the rear portion of
the shelf, however this unit was designed
with a plastic post on each sides of the
shelf track to prevent the shelves from
falling.
When removing the shelf out of the inner
Ÿ
rail, make sure to remove all items first.
Then move the shelf to the position where
the notch of shelf is exactly under the
plastic post and lift the shelf. In order to
replace the shelf, repeat steps described
above in reverse.
1 x Glass Shelf
2 x Wire Shelves
Page 11
Care and Cleaning
Cleaning your Beverage Cabinet
Tur n off the power, unplug the appliance,
Ÿ
and remove all items including shelves.
Wash the inside surfaces with a warm
Ÿ
water and baking soda solution. The
solution should be about 2 tablespoons of
baking soda to a quart of water.
Wash the shelves with a mild detergent
Ÿ
solution.
Wring excess water out of the sponge or
Ÿ
cloth when cleaning area of the controls,
or any electrical parts.
Wash the outside cabinet with warm
Ÿ
water and mild liquid detergent. Rinse well
and wipe dry with a clean soft cloth.
Do not use steel wool or steel brush on the
Ÿ
stainless steel. These will contaminate the
stainless steel with steel particles and
rusting may occur.
Power Failure
Most power failures are corrected within a few
hours and should not affect the temperature
of your appliance if you minimize the number
of times the door is opened.
If the power is going to
period of time, you need to take the proper
steps to protect your contents.
be off for a longer
Moving your Beverage Cabinet
Remove all items.
Ÿ
Securely tape down all loose items
Ÿ
(shelves) inside your appliance.
Tur n the adjustable leg up to the base to
Ÿ
avoid damage.
Tape the door shut.
Ÿ
Be sure the appliance stays secure in the
Ÿ
upright position during transportation.
Also protect outside of appliance with a
blanket, or similar item.
Energy Saving Tips
The Beverage Cabinet should be located in
the coolest area of the room, away from heat
producing appliances, and out of the direct
sunlight.
Page 12
Troubleshooting
Beverage Cabinet does not operate
Not plugged in.
Ÿ
The appliance is turned off.
Ÿ
The circuit breaker tripped or a blown
Ÿ
fuse.
Beverage Cabinet is not cold enough
Check the temperature control setting.
Ÿ
External environment may require a
Ÿ
higher setting.
The door is opened too often.
Ÿ
The door is not closed completely.
Ÿ
The door gasket does not seal properly.
Ÿ
Turns on and off frequently
The room temperature is hotter than
Ÿ
normal.
A large amount of contents has been
Ÿ
added to the Beverage Cabinet.
The door is opened too often.
Ÿ
The door is not closed completely.
Ÿ
The temperature control is not set
Ÿ
correctly.
The door gasket does not seal properly.
Ÿ
The Beverage Cabinet seems to make
too much noise.
The rattling noise may come from the flow
Ÿ
of the refrigerant, which is normal.
As each cycle ends, you may hear
Ÿ
gurgling sounds caused by the flow of
refrigerant in your Beverage Cabinet.
The Beverage Cabinet is not level.
Ÿ
The door will not close properly.
The Beverage Cabinet is not level.
Ÿ
The door was reversed and not properly
Ÿ
installed.
The gasket is dirty.
Ÿ
The shelves are out of position.
Ÿ
The light does not work
Not plugged in.
Ÿ
The circuit breaker tripped or a blown
Ÿ
fuse.
The light button is “OFF”.
Ÿ
Vibrations
Check to assure that the Beverage
Ÿ
Cabinet is level.
Consumer Help
If you have any concerns or questions
regarding the performance or use of your
appliance, please visit:
www.delonghi.com.au
or
www.delonghi.co.nz
Australia
Phone: 1800 126 659
Fax: 1800 007 289
New Zealand
Phone: 0508 200 300
Fax: 0508 200 301
Page 13
Help us Help You
Read this guide carefully, it is intended to help
you operate and maintain your new Beverage
Cabinet properly.
Keep it handy to answer your questions. If
you don't understand something or you need
more assistance, please call the De’Longhi
Helpline.
To help us provide prompt answers to your
queries, please record your
Cabinet model and serial numbers. You’ll find
them on a plate located on the rear outside
wall of the Beverage Cabinet.
Beverage Cabinet details
Beverage
Before you call for service
Check the Troubleshooting Section on page
13. It lists causes of minor operating
problems that you can correct yourself.
Page 14
Warranty Information
The De’Longhi Beverage Cabinet is warranted
against faults resulting from manufacturing or
material defects. The warranty period for normal
domestic installation and use is three years from
the date of installation in your home. In nondomestic use De’Longhi limits the voluntary
warranty to 6 months.
De’Longhi undertakes to repair or replace
Beverage Cabinet at our discretion if the product
is found to be defective due to a manufacturing
fault during the warranty period.
This warranty excludes any damage caused by
misuse, neglect, shipping accident, or incorrect
installation. Normal wear and tear is also
expressly excluded. The warranty claim is void if
no fault is found with the product or if work is
carried out by anyone other than an authorised
De’Longhi Service Agent.
In Australia, this warranty is additional to the
conditions and guarantees which are mandatory
as implied under the Trade Practices Act 1974
and State and Territory legislation.
the
How to contact us about a warranty claim
Talk to a De’Longhi representative for further
warranty or product information please call the
number in your country:
Australia
www.delonghi.com.au
Phone: 1800 126 659
New Zealand
www.delonghi.co.nz
Phone: 0508 200 300
NOTE: Warranty
serial number and date of installation.
is determined by unit
Page 15
5717010021 / 08.09
© 2009 De’Longhi Australia Pty Ltd.
Loading...
