FTOS Configuration Guide

FTOS 8.4.2.6

E-Series TeraScale. C-Series,

S-Series (S50/S25)

Notes, Cautions, and Warnings

NOTE: A NOTE indicates important information that helps you make better use of your computer.

CAUTION: A CAUTION indicates potential damage to hardware or loss of data if instructions are not followed.

WARNING: A WARNING indicates a potential for property damage, personal injury, or death.

Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden. Trademarks used in this text: Dell™, the DELL logo, Dell Precision™, OptiPlex™, Latitude™, PowerEdge™, PowerVault™,

PowerConnect™, OpenManage™, EqualLogic™, KACE™, FlexAddress™ and Vostro™ are trademarks of Dell Inc. Intel Core™ and Celeron Opteron™, AMD Phenom™, and AMD Sempron™ are trademarks of Advanced Micro Devices, Inc. Microsoft

Server

, MS-DOS® and Windows Vista® are either trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries. Red Hat Enterprise Linux countries. Novell registered trademark of Oracle Corporation and/or its affiliates. Citrix or trademarks of Citrix Systems, Inc. in the United States and/or other countries. VMware

are registered trademarks of Intel Corporation in the U.S. and other countries. AMD® is a registered trademark and AMD

is a registered trademark and SUSE ™ is a trademark of Novell Inc. in the United States and other countries. Oracle® is a

and Enterprise Linux® are registered trademarks of Red Hat, Inc. in the United States and/or other

, Xen®, XenServer® and XenMotion® are either registered trademarks

, Virtual SMP®, vMotion®, vCenter®, and vSphere®

, Pentium®, Xeon®,

, Windows®, Windows

are registered trademarks or trademarks of VMWare, Inc. in the United States or other countries. Other trademarks and trade names may be used in this publication to refer to either the entities claiming the marks and names or their products.

Dell Inc. disclaims any proprietary interest in trademarks and trade names other than its own.

November 2011

1 About this Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Objectives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

Audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Information Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

Related Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

2 Configuration Fundamentals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

Accessing the Command Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

CLI Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

Navigating CLI Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

The do Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

Undoing Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

Obtaining Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

Entering and Editing Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

Command History . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

Filtering show Command Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45

Multiple Users in Configuration mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

3 Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Default Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48

Configure a Host Name . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Access the System Remotely . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49

Access the C-Series and E-Series Remotely . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Access the S-Series Remotely . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Configure the Enable Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Configuration File Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52

Copy Files to and from the System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Save the Running-configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54

View Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55

File System Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57

View command history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58

Upgrading and Downgrading FTOS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58

4 System Management. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Configure Privilege Levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59

Create a Custom Privilege Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Apply a Privilege Level to a Username . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63

Apply a Privilege Level to a Terminal Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Configure Logging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Log Messages in the Logging Buffer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Configuration Task List for System Log Management . . . . . . . . . . . . . . . . . . . . . . .64

Disable System Logging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64

Send System Messages to a Syslog Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65

Configure a Unix System as a Syslog Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65

| 3

Change System Logging Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65

Display the Logging Buffer and the Logging Configuration . . . . . . . . . . . . . . . . . . . . . . .66

Configure a UNIX Logging Facility Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68

Synchronize Log Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69

Enable Timestamp on Syslog Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69

File Transfer Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Configuration Task List for File Transfer Services . . . . . . . . . . . . . . . . . . . . . . . . . .70

Terminal Lines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .71

Deny and Permit Access to a Terminal Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Configure Login Authentication for Terminal Lines . . . . . . . . . . . . . . . . . . . . . . . . . .72

Time out of EXEC Privilege Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

www.dell.com | support.dell.com

Telnet to Another Network Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74

Lock CONFIGURATION mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74

Viewing the Configuration Lock Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75

Recovering from a Forgotten Password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76

Recovering from a Forgotten Enable Password . . . . . . . . . . . . . . . . . . . . . . . . . . . .77

Recovering from a Forgotten Password on S-Series . . . . . . . . . . . . . . . . . . . . . . . .78

Recovering from a Failed Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .79

5 802.1ag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Ethernet CFM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .81

Maintenance Domains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .82

Maintenance Points . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Maintenance End Points . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Implementation Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Configure CFM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .84

Related Configuration Tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .84

Enable Ethernet CFM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

Create a Maintenance Domain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85

Create a Maintenance Association . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .86

Create Maintenance Points . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .86

Create a Maintenance End Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .86

Create a Maintenance Intermediate Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

MP Databases . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Continuity Check Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

Enable CCM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90

Enable Cross-checking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90

Loopback Message and Response . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

Linktrace Message and Response . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90

Link Trace Cache . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91

Enable CFM SNMP Traps. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Display Ethernet CFM Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

4 |

6 802.3ah . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

Link Layer OAM Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .95

Link Layer OAMPDUs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

Link Layer OAM Operational Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Link Layer OAM Discovery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Link Layer OAM Events . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .98

Remote Loopback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Implementation Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Configure Link Layer OAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .99

Related Configuration Tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .99

Enable Link Layer OAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

Adjust the OAMPDU Transmission Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .101

Link Performance Event Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .101

Enable Error Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .101

Set Threshold Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .102

Execute an Action upon Exceeding the High Threshold . . . . . . . . . . . . . . . . . . . . . 104

Remote Failure Indication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104

Remote Loopback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .105

Display Link Layer OAM Configuration and Statistics . . . . . . . . . . . . . . . . . . . . . . . . . .106

Manage Link Layer OAM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .108

Enable MIB Retrieval Support/Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108

Adjust the Size of the Link OAM Event Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .108

7 802.1X . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109

Protocol Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .109

The Port-authentication Process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .111

EAP over RADIUS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .112

Configuring 802.1X . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .113

Related Configuration Tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .113

Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114

Enabling 802.1X . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114

Configuring Request Identity Re-transmissions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .116

Configuring a Quiet Period after a Failed Authentication . . . . . . . . . . . . . . . . . . . . 116

Forcibly Authorizing or Unauthorizing a Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

Re-Authenticating a Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .118

Periodic Re-Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118

Configuring Timeouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .119

Dynamic VLAN Assignment with Port Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . 121

Guest and Authentication-Fail VLANs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123

Configuring a Guest VLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .123

Configuring an Authentication-Fail VLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124

Multi-Host Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125

Multi-Supplicant Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .127

| 5

MAC Authentication Bypass . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129

MAB in Single-host and Multi-Host Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .130

MAB in Multi-Supplicant Authentication Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . .130

Dynamic CoS with 802.1X . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .132

8 IP Access Control Lists (ACL), Prefix Lists, and Route-maps . . . . . . . . . . . . . . . 135

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135

IP Access Control Lists (ACLs) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .136

CAM Profiling, CAM Allocation, and CAM Optimization . . . . . . . . . . . . . . . . . . . . . 136

Implementing ACLs on FTOS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .139

IP Fragment Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140

www.dell.com | support.dell.com

Configure a standard IP ACL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142

Configure an extended IP ACL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .145

Established Flag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148

Configuring Layer 2 and Layer 3 ACLs on an Interface . . . . . . . . . . . . . . . . . . . . . . . .148

Assign an IP ACL to an Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .149

Counting ACL Hits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150

Configuring Ingress ACLs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151

Configuring Egress ACLs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .151

Egress Layer 3 ACL Lookup for Control-plane IP Traffic . . . . . . . . . . . . . . . . . . . . 152

Configuring ACLs to Loopback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .153

Applying an ACL on Loopback Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153

IP Prefix Lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155

Implementation Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155

Configuration Task List for Prefix Lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155

ACL Resequencing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159

Resequencing an ACL or Prefix List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .160

Route Maps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162

Implementation Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 162

Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163

Configuration Task List for Route Maps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .163

6 |

9 Bidirectional Forwarding Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171

Protocol Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .171

How BFD Works . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172

Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177

Configuring Bidirectional Forwarding Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .177

Configuring BFD for Physical Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178

Configuring BFD for Static Routes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 182

Configuring BFD for OSPF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 184

Configuring BFD for BGP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .187

Configuring BFD for IS-IS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .195

Configuring BFD for VRRP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .197

Configuring BFD for VLANs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .200

Configuring BFD for Port-Channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .203

Configuring Protocol Liveness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .205

Troubleshooting BFD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .205

10 Border Gateway Protocol IPv4 (BGPv4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 207

Protocol Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .208

Autonomous Systems (AS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 208

Sessions and Peers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .210

Route Reflectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .211

Confederations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .212

BGP Attributes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .213

Best Path Selection Criteria . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .213

Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 216

Local Preference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 216

Multi-Exit Discriminators (MEDs) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .216

Origin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 217

AS Path . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 218

Next Hop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .219

Multiprotocol BGP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 219

Implementing BGP with FTOS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .219

4-Byte AS Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .220

AS4 Number Representation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .221

AS Number Migration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .223

BGP4 Management Information Base (MIB) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 225

Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .225

Configuration Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .226

BGP Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 227

Configuration Task List for BGP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 227

MBGP Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .268

BGP Regular Expression Optimization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 269

Retain NH in BGP Advertisement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 269

Debugging BGP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 269

Storing Last and Bad PDUs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .270

Capturing PDUs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .271

PDU Counters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 273

Sample Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .273

11 Content Addressable Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 283

Content Addressable Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 284

CAM Profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 284

Microcode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 286

CAM Profiling for ACLs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 287

| 7

Boot Behavior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 288

When to Use CAM Profiling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .289

Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 290

Differences Between EtherScale and TeraScale . . . . . . . . . . . . . . . . . . . . . . . . . . 290

Select CAM Profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 290

CAM Allocation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 291

Test CAM Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .292

View CAM Profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .293

View CAM-ACL settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .293

View CAM Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .294

Configure IPv4Flow Sub-partitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 295

www.dell.com | support.dell.com

Configure Ingress Layer 2 ACL Sub-partitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 297

Return to the Default CAM Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 299

CAM Optimization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 300

Applications for CAM Profiling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 300

LAG Hashing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .300

LAG Hashing based on Bidirectional Flow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .301

CAM profile for the VLAN ACL group feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . .301

Troubleshoot CAM Profiling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 301

CAM Profile Mismatches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .301

QoS CAM Region Limitation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .302

12 Content Addressable Memory for ExaScale . . . . . . . . . . . . . . . . . . . . . . . . . . . . 303

Content Addressable Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 303

Static Random Access Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .304

CAM-profile templates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 304

Default CAM-profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .305

Recommended CAM-profile templates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .306

CAM/SRAM region minimums and maximums . . . . . . . . . . . . . . . . . . . . . . . . . . . . 307

Microcode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 308

Boot Behavior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 309

Select a CAM-profile template . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .310

Select pre-defined CAM-profile template . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .310

Create new CAM-profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .312

Assign a microcode to the CAM-profile template . . . . . . . . . . . . . . . . . . . . . . . . . . . . .313

Validate CAM-profile templates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 313

Show CAM-profile templates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 313

13 Configuration Replace and Rollback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 317

Archived Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 317

Configuring Configuration Replace and Rollback . . . . . . . . . . . . . . . . . . . . . . . . . . . . .318

Related Configuration Tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .318

Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 318

8 |

Enabling the Archive Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 318

Archiving a Configuration File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 319

Viewing the Archive Directory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .319

Replacing the Current Running Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .319

Rolling Back to the Previous Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .320

Configuring an Archive File Maximum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .321

Configuring Auto-archive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 322

Copying and Deleting an Archive File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .323

Viewing and Editing the Contents of an Archive File . . . . . . . . . . . . . . . . . . . . . . . . . . .323

Viewing the Difference between Configuration Files . . . . . . . . . . . . . . . . . . . . . . . . 324

14 Dynamic Host Configuration Protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 327

Protocol Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .327

DHCP Packet Format and Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .328

Assigning an IP Address using DHCP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .329

Implementation Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 330

Configuration Tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 330

Configure the System to be a DHCP Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .330

Configuration Tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .331

Configure the Server for Automatic Address Allocation . . . . . . . . . . . . . . . . . . . . . 331

Specify a Default Gateway . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .332

Enable DHCP Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .333

Configure a Method of Hostname Resolution . . . . . . . . . . . . . . . . . . . . . . . . . . . . .333

Allocate Addresses to BOOTP Clients . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .334

Create Manual Binding Entries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .334

Check for Address Conflicts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .335

DHCP Clear Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 336

Configure the System to be a Relay Agent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .336

Configure Secure DHCP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .337

Option 82 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 338

DHCP Snooping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .338

Drop DHCP packets on snooped VLANs only . . . . . . . . . . . . . . . . . . . . . . . . . . . .341

Dynamic ARP Inspection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .341

Source Address Validation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .343

15 Equal Cost Multi-Path . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 347

ECMP for Flow-based Affinity (E-Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .347

Configurable Hash Algorithm (E-Series) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 347

Deterministic ECMP Next Hop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 348

Configurable Hash Algorithm Seed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .348

Configurable ECMP Hash Algorithm (C- and S-Series) . . . . . . . . . . . . . . . . . . . . . . . .350

| 9

16 Force10 Resilient Ring Protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 351

Protocol Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .351

Ring Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 352

Multiple FRRP Rings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .353

Important FRRP Points . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .354

Important FRRP Concepts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 355

Implementing FRRP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .356

FRRP Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .357

Troubleshooting FRRP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 361

Configuration Checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .361

Sample Configuration and Topology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .361

www.dell.com | support.dell.com

17 Force10 Service Agent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 363

Implementation Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 363

Configure Force10 Service Agent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .364

Related Configuration Tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .364

Enable Force10 Service Agent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .364

Specify an SMTP Server for FTSA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .365

Provide an Administrator E-mail Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .365

FTSA Messaging Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 366

Enable the FTSA Messaging Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .366

Add Additional Recipients of FTSA E-mails . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 367

Encrypt FTSA Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .368

Provide Administrator Contact Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .369

Set the Frequency of FTSA Type 3 Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . .370

Generate FTSA Type 4 Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 370

Set Parameters FTSA Type 5 Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 370

FTSA Message Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 371

FTSA Policies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 373

Create an FTSA Policy Test List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 374

Create a Policy Action List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .377

Create a Policy and Assign a Test and Action List . . . . . . . . . . . . . . . . . . . . . . . . .379

Additional Policy Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 380

FTSA Policy Sample Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 380

Debugging FTSA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 387

10 |

18 GARP VLAN Registration Protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 389

Protocol Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .389

Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .389

Configuring GVRP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 390

Related Configuration Tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .391

Enabling GVRP Globally . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .391

Enabling GVRP on a Layer 2 Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .392

Configuring GVRP Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .392

Configuring a GARP Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .393

19 High Availability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 395

Component Redundancy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .396

RPM Redundancy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 396

Online Insertion and Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .403

RPM Online Insertion and Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .403

Line Card Online Insertion and Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .403

Hitless Behavior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 405

Graceful Restart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .406

Software Resiliency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 406

Runtime System Health Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .407

SFM Channel Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .407

Software Component Health Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .408

System Health Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 408

Failure and Event Logging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .408

Hot-lock Behavior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .409

Warm Upgrade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .409

Configure Cache Boot . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .410

In-Service Modular Hot-Fixes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 414

Process Restartability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .415

20 Internet Group Management Protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 419

IGMP Implementation Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .419

IGMP Protocol Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .419

IGMP version 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .420

IGMP version 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .421

Configuring IGMP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 424

Related Configuration Tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .424

Viewing IGMP Enabled Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .424

Selecting an IGMP Version . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .425

Viewing IGMP Groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 425

Adjusting Timers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .426

Adjusting Query and Response Timers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .426

Adjusting the IGMP Querier Timeout Value . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 426

Configuring a Static IGMP Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 427

Enabling IGMP Immediate-leave . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .427

IGMP Snooping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 428

IGMP Snooping Implementation Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . .428

Configuring IGMP Snooping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .428

Enabling IGMP Immediate-leave . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .428

| 11

Disabling Multicast Flooding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .429

Specifying a Port as Connected to a Multicast Router . . . . . . . . . . . . . . . . . . . . . .429

Configuring the Switch as Querier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .429

Fast Convergence after MSTP Topology Changes . . . . . . . . . . . . . . . . . . . . . . . . . . . .430

Designating a Multicast Router Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 430

21 Interfaces. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 431

Interface Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .432

View Basic Interface Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 432

Enable a Physical Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 434

Physical Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .435

www.dell.com | support.dell.com

Configuration Task List for Physical Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . 435

Overview of Layer Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .436

Configure Layer 2 (Data Link) Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 436

Configure Layer 3 (Network) Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 437

Management Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .439

Configure Management Interfaces on the E-Series and C-Series . . . . . . . . . . . . . 439

Configure Management Interfaces on the S-Series . . . . . . . . . . . . . . . . . . . . . . . . 440

Displaying Information on a Management Interface . . . . . . . . . . . . . . . . . . . . . . . .441

VLAN Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .442

Loopback Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 443

Null Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 443

Port Channel Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .444

Bulk Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 456

Interface Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 456

Bulk Configuration Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 457

Interface Range Macros . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .459

Define the Interface Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .459

Choose an Interface-range Macro . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .460

Monitor and Maintain Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .460

Maintenance using TDR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 461

Link Debounce Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .462

Important Points to Remember about Link Debounce Timer . . . . . . . . . . . . . . . . . 462

Assign a debounce time to an interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 463

Show debounce times in an interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .463

Disable ports when one only SFM is available (E300 only) . . . . . . . . . . . . . . . . . .463

Disable port on one SFM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .464

Link Dampening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 464

Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .464

Enable Link Dampening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 465

Ethernet Pause Frames . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 466

Threshold Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .467

Enable Pause Frames . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 468

12 |

Configure MTU Size on an Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .469

Port-pipes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .470

Auto-Negotiation on Ethernet Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .471

View Advanced Interface Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .473

Display Only Configured Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 473

Configure Interface Sampling Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 474

Dynamic Counters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 476

22 IPv4 Addressing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 479

IP Addresses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .479

Implementation Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 480

Configuration Task List for IP Addresses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .480

Directed Broadcast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 484

Resolution of Host Names . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .484

ARP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .487

Configuration Task List for ARP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .487

ARP Learning via Gratuitous ARP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 489

ARP Learning via ARP Request . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .490

Configurable ARP Retries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .491

ICMP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 491

Configuration Task List for ICMP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .491

UDP Helper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .492

Configuring UDP Helper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 493

Important Points to Remember about UDP Helper . . . . . . . . . . . . . . . . . . . . . . . . . . . .493

Enabling UDP Helper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .493

Configuring a Broadcast Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .494

Configurations Using UDP Helper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 494

UDP Helper with Broadcast-all Addresses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 495

UDP Helper with Subnet Broadcast Addresses . . . . . . . . . . . . . . . . . . . . . . . . . . . 495

UDP Helper with Configured Broadcast Addresses . . . . . . . . . . . . . . . . . . . . . . . .496

UDP Helper with No Configured Broadcast Addresses . . . . . . . . . . . . . . . . . . . . .497

Troubleshooting UDP Helper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 497

23 IPv6 Addressing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 499

Protocol Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .499

Extended Address Space . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 500

Stateless Autoconfiguration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .500

IPv6 Headers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .501

Extension Header fields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .503

Addressing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .504

Implementing IPv6 with FTOS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .506

ICMPv6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .508

Path MTU Discovery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 508

| 13

IPv6 Neighbor Discovery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 509

IPv6 Neighbor Discovery of MTU packets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .510

Advertise Neighbor Prefixes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 510

QoS for IPv6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 510

IPv6 Multicast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .511

SSH over an IPv6 Transport . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 511

Configuration Task List for IPv6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .512

Change your CAM-Profile on an E-Series system . . . . . . . . . . . . . . . . . . . . . . . . . 512

Adjust your CAM-Profile on an C-Series or S-Series . . . . . . . . . . . . . . . . . . . . . . .513

Assign an IPv6 Address to an Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 514

Assign a Static IPv6 Route . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 515

www.dell.com | support.dell.com

Telnet with IPv6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 515

SNMP over IPv6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 516

Show IPv6 Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 516

Show an IPv6 Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 517

Show IPv6 Routes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 518

Show the Running-Configuration for an Interface . . . . . . . . . . . . . . . . . . . . . . . . . . 520

Clear IPv6 Routes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 520

24 Intermediate System to Intermediate System . . . . . . . . . . . . . . . . . . . . . . . . . . . 523

Protocol Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .523

IS-IS Addressing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 524

Multi-Topology IS-IS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 525

Transition Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .525

Interface support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .525

Adjacencies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .526

Graceful Restart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .526

Implementation Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 527

Configuration Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .528

Configuration Task List for IS-IS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .529

Configuring the distance of a route . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .539

Change the IS-type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .539

IS-IS Metric Styles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 547

Configure Metric Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .548

Maximum Values in the Routing Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .548

Changing the IS-IS Metric Style in One Level Only . . . . . . . . . . . . . . . . . . . . . . . .548

Leaking from One Level to Another . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .550

Sample Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 551

14 |

25 Link Aggregation Control Protocol. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 557

Introduction to Dynamic LAGs and LACP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .557

Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .558

LACP modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 559

LACP Configuration Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 559

LACP Configuration Tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .560

Monitor and Debugging LACP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .562

Shared LAG State Tracking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 562

Configure Shared LAG State Tracking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 563

Important Points about Shared LAG State Tracking . . . . . . . . . . . . . . . . . . . . . . . . 564

Configure LACP as Hitless . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 565

LACP Basic Configuration Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 565

26 Layer 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 575

Managing the MAC Address Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 575

Clear the MAC Address Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .576

Set the Aging Time for Dynamic Entries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 576

Set the Aging Time for Dynamic Entries on a VLAN . . . . . . . . . . . . . . . . . . . . .576

Configure a Static MAC Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .577

Display the MAC Address Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .577

MAC Learning Limit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 578

mac learning-limit dynamic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 579

mac learning-limit station-move . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .579

mac learning-limit no-station-move . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .580

mac learning-limit sticky . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 580

The sticky-MAC learning feature is supported on platforms:

Displaying MAC Learning-Limited Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 582

Learning Limit Violation Actions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 582

Station Move Violation Actions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 582

Recovering from Learning Limit and Station Move Violations . . . . . . . . . . . . . . . . . 583

Per-VLAN MAC Learning Limit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .583

NIC Teaming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .585

MAC Move Optimization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .586

Microsoft Clustering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .586

Default Behavior . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 586

Configuring the Switch for Microsoft Server Clustering . . . . . . . . . . . . . . . . . . . . . . 587

Enable and Disable VLAN Flooding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .588

Configuring Redundant Pairs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .589

Important Points about Configuring Redundant Pairs . . . . . . . . . . . . . . . . . . . . . . .590

Restricting Layer 2 Flooding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .592

Far-end Failure Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .593

FEFD state changes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .593

Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .594

Configuring FEFD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .594

Debugging FEFD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .596

c s. . . . . . . . .580

| 15

27 Link Layer Discovery Protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 599

802.1AB (LLDP) Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .599

Protocol Data Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .599

Optional TLVs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .601

Management TLVs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .601

TIA-1057 (LLDP-MED) Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .602

TIA Organizationally Specific TLVs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .603

Configuring LLDP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 607

Related Configuration Tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .607

Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 607

LLDP Compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 607

www.dell.com | support.dell.com

CONFIGURATION versus INTERFACE Configurations . . . . . . . . . . . . . . . . . . . . . . . .607

Enabling LLDP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 608

Disabling and Undoing LLDP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 608

Advertising TLVs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .608

Viewing the LLDP Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 610

Viewing Information Advertised by Adjacent LLDP Agents . . . . . . . . . . . . . . . . . . . . . . 610

Configuring LLDPDU Intervals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .611

Configuring Transmit and Receive Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .612

Configuring a Time to Live . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 613

Debugging LLDP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 614

Relevant Management Objects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .615

28 Multicast Listener Discovery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 621

Protocol Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .621

MLD Version 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .621

MLD Querier Router . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .622

Joining a Multicast Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 622

Leaving a Multicast Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .623

MLD version 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 623

Implementation Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 624

Enabling MLD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 624

Related MLD Configuration Tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .624

Change MLD Timer Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .625

Reduce Host Response Burstiness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .625

Reduce Leave Latency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .625

Last Member Query Interval . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 626

Explicit Tracking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 626

Configure a Static Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 626

Display the MLD Group Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .627

Clear MLD Groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .627

Change the MLD Version . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .627

Debug MLD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .627

16 |

MLD Snooping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .627

Enable MLD Snooping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .628

Disable MLD Snooping on a VLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 628

Configure the Switch as a Querier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .628

Disable Multicast Flooding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .628

Specify a Port as Connected to a Multicast Router . . . . . . . . . . . . . . . . . . . . . . . . . 628

Enable Snooping Explicit Tracking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 629

Display the MLD Snooping Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 629

MLDv2 Snooping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 629

Port Inheritance on Mixed MLD Mode VLANs . . . . . . . . . . . . . . . . . . . . . . . . . . . .629

29 Multicast Source Discovery Protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 631

Protocol Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .631

Implementation Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 632

Configuring Multicast Source Discovery Protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 633

Related Configuration Tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .633

Enable MSDP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 638

Manage the Source-active Cache . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .638

View the Source-active Cache . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 639

Limit the Source-active Cache . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .639

Clear the Source-active Cache . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .639

Enable the Rejected Source-active Cache . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .639

Accept Source-active Messages that fail the RFP Check . . . . . . . . . . . . . . . . . . . . . . .640

Limit the Source-active Messages from a Peer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .642

Prevent MSDP from Caching a Local Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .643

Prevent MSDP from Caching a Remote Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .644

Prevent MSDP from Advertising a Local Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .645

Log Changes in Peership States . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 646

Terminate a Peership . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .646

Clear Peer Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 647

Debug MSDP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 648

MSDP with Anycast RP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 648

Reducing Source-active Message Flooding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 650

Specify the RP Address Used in SA Messages . . . . . . . . . . . . . . . . . . . . . . . . . . .650

MSDP Sample Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .654

30 Multiple Spanning Tree Protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 659

Protocol Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .659

Implementation Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 660

Configure Multiple Spanning Tree Protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .660

Related Configuration Tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .660

Enable Multiple Spanning Tree Globally . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .661

Add and Remove Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 661

| 17

Create Multiple Spanning Tree Instances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .661

Influence MSTP Root Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 663

Interoperate with Non-FTOS Bridges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .663

Modify Global Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 664

Modify Interface Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .666

Configure an EdgePort . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 667

Configure a Root Guard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .668

Configure a Loop Guard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 669

Flush MAC Addresses after a Topology Change . . . . . . . . . . . . . . . . . . . . . . . . . . . . .670

Displaying STP Guard Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 670

MSTP Sample Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .671

www.dell.com | support.dell.com

Debugging and Verifying MSTP Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .676

31 Multicast Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 679

Implementation Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 679

Enable IP Multicast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .679

Multicast with ECMP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 680

Implementation Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 681

Multicast Policies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 681

IPv4 Multicast Policies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .681

IPv6 Multicast Policies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .689

Multicast Traceroute . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 690

Multicast Quality of Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .691

Optimize the E-Series for Multicast Traffic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .691

Allocate More Buffer Memory for Multicast WRED . . . . . . . . . . . . . . . . . . . . . . . . .692

Allocate More Bandwidth to Multicast using Egress WFQ . . . . . . . . . . . . . . . . . . . 692

Tune the Central Scheduler for Multicast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .692

18 |

32 Object Tracking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 693

Object Tracking Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .693

Tracking Layer 2 Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 694

Tracking Layer 3 Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 695

Tracking IPv4 and IPv6 Routes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 695

Setting Tracking Delays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .696

VRRP Object Tracking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 696

Object Tracking Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 697

Tracking a Layer 2 Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .697

Tracking a Layer 3 Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .698

Tracking an IPv4/IPv6 Route . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .700

Displaying Tracked Objects . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .704

33 Open Shortest Path First (OSPFv2 and OSPFv3) . . . . . . . . . . . . . . . . . . . . . . . 707

Protocol Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .708

Autonomous System (AS) Areas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .708

Area Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .709

Networks and Neighbors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .710

Router Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 710

Designated and Backup Designated Routers . . . . . . . . . . . . . . . . . . . . . . . . . . . . .712

Link-State Advertisements (LSAs) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .713

Virtual Links . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 714

Router Priority and Cost . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .714

Implementing OSPF with FTOS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .715

Graceful Restart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 716

Fast Convergence (OSPFv2, IPv4 only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 717

Multi-Process OSPF (OSPFv2, IPv4 only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .717

Processing SNMP and Sending SNMP Traps . . . . . . . . . . . . . . . . . . . . . . . . . . . .718

RFC-2328 Compliant OSPF Flooding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .718

OSPF ACK Packing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .719

OSPF Adjacency with Cisco Routers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .719

Configuration Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .720

Configuration Task List for OSPFv2 (OSPF for IPv4) . . . . . . . . . . . . . . . . . . . . . . . . . .720

Enable OSPFv2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .721

Enable Multi-Process OSPF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .723

Assign an OSPFv2 area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 724

Enable OSPFv2 on interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .725

Configure stub areas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .727

Configure OSPF Stub-Router Advertisement . . . . . . . . . . . . . . . . . . . . . . . . . . . . .728

Enable passive interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .729

Enable fast-convergence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .730

Change OSPFv2 parameters on interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .731

Enable OSPFv2 authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 733

Enable OSPFv2 graceful restart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .733

Configure virtual links . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .735

Filter routes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .736

Redistribute routes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 737

Troubleshooting OSPFv2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .738

Sample Configurations for OSPFv2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .741

Basic OSPFv2 Router Topology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .741

Configuration Task List for OSPFv3 (OSPF for IPv6) . . . . . . . . . . . . . . . . . . . . . . . . . .742

Enable IPv6 Unicast Routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .743

Assign IPv6 addresses on an interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .743

Assign Area ID on interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .743

Assign OSPFv3 Process ID and Router ID Globally . . . . . . . . . . . . . . . . . . . . . . . .744

Configure stub areas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .744

| 19

Configure Passive-Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .745

Redistribute routes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 746

Configure a default route . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 746

Enable OSPFv3 graceful restart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .747

OSPFv3 Authentication Using IPsec . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 750

Troubleshooting OSPFv3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .760

34 PIM Dense-Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 763

Implementation Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 763

Protocol Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .763

Refusing Multicast Traffic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .764

www.dell.com | support.dell.com

Requesting Multicast Traffic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .765

Configure PIM-DM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .766

Related Configuration Tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .766

Enable PIM-DM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .766

35 PIM Sparse-Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 771

Implementation Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 771

Protocol Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .772

Requesting Multicast Traffic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .772

Refusing Multicast Traffic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .772

Sending Multicast Traffic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .773

Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 773

Configure PIM-SM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 773

Related Configuration Tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .774

Enable PIM-SM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .774

Configurable S,G Expiry Timers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 775

Configure a Static Rendezvous Point . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .776

Override Bootstrap Router Updates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .777

Elect an RP using the BSR Mechanism . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .778

Configure a Designated Router . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 779

Create Multicast Boundaries and Domains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .779

Set a Threshold for Switching to the SPT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 780

PIM-SM Graceful Restart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .780

First Packet Forwarding for Lossless Multicast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .781

Monitoring PIM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .782

PIM-SM and IGMP Snooping: Usage Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .782

PIM-SM Snooping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .783

Feature Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .784

Configuration Notes and Restrictions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 785

PIM-SM Snooping Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 786

PIM-SM Snooping Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 788

20 |

36 PIM Source-Specific Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 793

Implementation Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 795

Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 795

Configure PIM-SM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 795

Related Configuration Tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .795

Enable PIM-SSM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 796

Use PIM-SSM with IGMP version 2 Hosts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .796

37 Power over Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 801

Configuring Power over Ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .802

Related Configuration Tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .803

Enabling PoE on a Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .803

Manage Ports using Power Priority and the Power Budget . . . . . . . . . . . . . . . . . . . . . . 805

Determine the Power Priority for a Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .805

Determine the Affect of a Port on the Power Budget . . . . . . . . . . . . . . . . . . . . . . .807

Monitor the Power Budget . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 808

Manage Power Priorities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 808

Recover from a Failed Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 809

Power Additional PoE Ports on the S-Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 810

Deploying VOIP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 811

Create VLANs for an Office VOIP Deployment . . . . . . . . . . . . . . . . . . . . . . . . . . . .811

Configure LLDP-MED for an Office VOIP Deployment . . . . . . . . . . . . . . . . . . . . . . 812

Configure Quality of Service for an Office VOIP Deployment . . . . . . . . . . . . . . . . . 813

38 Policy-based Routing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 817

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 817

Implementing Policy-based Routing with FTOS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 819

Non-contiguous bitmasks for PBR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .819

Hot-Lock PBR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .819

Configuration Task List for Policy-based Routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 820

Create a Redirect List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .820

Create a Rule for a Redirect-list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .821

Apply a Redirect-list to an Interface using a Redirect-group . . . . . . . . . . . . . . . . . .824

Show Redirect List Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .825

Sample Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 826

39 Port Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 829

Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 829

Port Monitoring on E-Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .830

E-Series TeraScale . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 831

E-Series ExaScale . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .831

Port Monitoring on C-Series and S-Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .832

| 21

Configuring Port Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .835

Flow-based Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .836

Remote Port Mirroring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .837

Remote Port Mirroring Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .837

Configuring Remote Port Mirroring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .838

Displaying Remote-Port Mirroring Configurations . . . . . . . . . . . . . . . . . . . . . . . . . .844

Sample Configuration: Remote Port Mirroring . . . . . . . . . . . . . . . . . . . . . . . . . . . .845

40 Private VLANs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 847

Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 848

Configure Private VLANs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 848

www.dell.com | support.dell.com

Related Configuration Tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .849

Configure PVLAN Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .849

Place PVLAN Ports in a Secondary VLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 849

Place the Secondary VLANs in a Primary VLAN . . . . . . . . . . . . . . . . . . . . . . . . . .850

Private VLAN show Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .850

41 Per-VLAN Spanning Tree Plus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 851

Protocol Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .851

Implementation Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 852

Configure Per-VLAN Spanning Tree Plus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .852

Related Configuration Tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .852

Enable PVST+ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 853

Disable PVST+ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 853

Influence PVST+ Root Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 853

Modify Global PVST+ Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .856

Modify Interface PVST+ Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 856

Configure an EdgePort . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 857

Configure a Root Guard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .859

Configure a Loop Guard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 860

PVST+ in Multi-vendor Networks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .861

PVST+ Extended System ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .861

Displaying STP Guard Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 862

PVST+ Sample Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .863

22 |

42 Quality of Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 865

Implementation Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 867

Port-based QoS Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 868

Set dot1p Priorities for Incoming Traffic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 868

Honor dot1p Priorities on Ingress Traffic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 869

Configure Port-based Rate Policing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .870

Configure Port-based Rate Limiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 871

Configure Port-based Rate Shaping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .872

Policy-based QoS Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 873

Classify Traffic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 873

Create a QoS Policy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 877

Create Policy Maps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 880

QoS Rate Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .885

Strict-priority Queueing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .886

Weighted Random Early Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .886

Create WRED Profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .887

Apply a WRED profile to traffic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 887

Configure WRED for Storm Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .887

Display Default and Configured WRED Profiles . . . . . . . . . . . . . . . . . . . . . . . . . . .888

Display WRED Drop Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .888

Allocating Bandwidth to Multicast Queues . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .889

Pre-calculating Available QoS CAM Space . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .890

Viewing QoS CAM Entries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 891

43 Routing Information Protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 893

Protocol Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .893

RIPv1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .893

RIPv2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .894

Implementation Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 894

Configuration Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .894

Configuration Task List for RIP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .895

RIP Configuration Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .902

44 Remote Monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 909

Implementation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 909

Fault Recovery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .910

45 Rapid Spanning Tree Protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 915

Protocol Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .915

Configuring Rapid Spanning Tree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .915

Related Configuration Tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .915

Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 916

Configure Interfaces for Layer 2 Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 916

Enable Rapid Spanning Tree Protocol Globally . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .917

Add and Remove Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 920

Modify Global Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 920

Modify Interface Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .922

Configure an EdgePort . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 922

Influence RSTP Root Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 924

| 23

SNMP Traps for Root Elections and Topology Changes . . . . . . . . . . . . . . . . . . . . . . .924

Fast Hellos for Link State Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .925

Configure a Root Guard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .926

Configure a Loop Guard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 927

Displaying STP Guard Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 928

46 Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 929

AAA Accounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 929

Configuration Task List for AAA Accounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .930

AAA Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 933

Configuration Task List for AAA Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . .933

www.dell.com | support.dell.com

AAA Authorization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .936

Privilege Levels Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 936

Configuration Task List for Privilege Levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 937

RADIUS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 941

RADIUS Authentication and Authorization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .942

Configuration Task List for RADIUS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 944

TACACS+ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 947

Configuration Task List for TACACS+ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .947

TACACS+ Remote Authentication and Authorization . . . . . . . . . . . . . . . . . . . . . . .949

Command Authorization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 951

Protection from TCP Tiny and Overlapping Fragment Attacks . . . . . . . . . . . . . . . . . . . 951

SCP and SSH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .951

Using SCP with SSH to copy a software image . . . . . . . . . . . . . . . . . . . . . . . . . . .953

Secure Shell Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 954

Troubleshooting SSH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 957

Telnet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 957

Trace Lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 958

Configuration Tasks for Trace Lists . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .958

VTY Line and Access-Class Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 964

VTY Line Local Authentication and Authorization . . . . . . . . . . . . . . . . . . . . . . . . . . 964

VTY Line Remote Authentication and Authorization . . . . . . . . . . . . . . . . . . . . . . . . 965

VTY MAC-SA Filter Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 965

24 |

47 Service Provider Bridging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 967

VLAN Stacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .967

Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .968

Configure VLAN Stacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .969

Create Access and Trunk Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .969

Enable VLAN-Stacking for a VLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 970

Configure the Protocol Type Value for the Outer VLAN Tag . . . . . . . . . . . . . . . . .970

FTOS Options for Trunk Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .971

VLAN Stacking in Multi-vendor Networks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .972

VLAN Stacking Packet Drop Precedence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .978

Enable Drop Eligibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .979

Honor the Incoming DEI Value . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 979

Mark Egress Packets with a DEI Value . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 980

Dynamic Mode CoS for VLAN Stacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .981

Layer 2 Protocol Tunneling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 983

Implementation Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 985

Enable Layer 2 Protocol Tunneling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 986

Specify a Destination MAC Address for BPDUs . . . . . . . . . . . . . . . . . . . . . . . . . . .986

Rate-limit BPDUs on the E-Series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .986

Rate-limit BPDUs on the C-Series and S-Series . . . . . . . . . . . . . . . . . . . . . . . . . .987

Debug Layer 2 Protocol Tunneling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 987

Provider Backbone Bridging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 987

48 sFlow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 989

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 989

Implementation Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 990

Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .990

Enable and Disable sFlow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 991

Enable and Disable on an Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 991

sFlow Show Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .992

Show sFlow Globally . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .992

Show sFlow on an Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .992

Show sFlow on a Line Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .993

Configure Collectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 994

Polling Intervals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .994

Sampling Rate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 995

Sub-sampling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .995

Back-off Mechanism . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 996

sFlow on LAG ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 996

Extended sFlow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 996

Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .998

49 Simple Network Management Protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 999

Protocol Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .999

Implementation Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 999

Configure Simple Network Management Protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 999

Related Configuration Tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1000

Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1000

Create a Community . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1000

Read Managed Object Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1001

Write Managed Object Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1002

Configure Contact and Location Information using SNMP . . . . . . . . . . . . . . . . . . . . . 1003

| 25

Subscribe to Managed Object Value Updates using SNMP . . . . . . . . . . . . . . . . . . . . 1004

Copy Configuration Files Using SNMP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1006

Manage VLANs using SNMP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1013

Create a VLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1013

Assign a VLAN Alias . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1013

Display the Ports in a VLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1013

Add Tagged and Untagged Ports to a VLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . .1015

Enable and Disable a Port using SNMP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1017

Fetch Dynamic MAC Entries using SNMP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1017

Deriving Interface Indices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1019

Monitor Port-channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1020

www.dell.com | support.dell.com

Troubleshooting SNMP Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1021

50 SONET/SDH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1023

Packet Over SONET (POS) Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1023

Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1023

Configuring POS Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1024

10GE WAN Physical Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1025

SONET Alarm Reporting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1026

SONET TRAP Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1029

SONET Syslog Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1029

Events that Bring Down a SONET Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1029

SONET Port Recovery Mechanism . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1030

SONET MIB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1031

SONET Traps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1031

26 |

51 Stacking S-Series Switches. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1035

S-Series Stacking Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1035

High Availability on S-Series Stacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1035

MAC Addressing on S-Series Stacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1037

Management Access on S-Series Stacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1041

Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1042

S-Series Stacking Installation Tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1042

Create an S-Series Stack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1042

Add a Unit to an S-Series Stack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1045

Remove a Unit from an S-Series Stack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1048

Merge Two S-Series Stacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1050

Split an S-Series Stack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1051

S-Series Stacking Configuration Tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1051

Assign Unit Numbers to Units in an S-Series Stack . . . . . . . . . . . . . . . . . . . . . . . 1051

Create a Virtual Stack Unit on an S-Series Stack . . . . . . . . . . . . . . . . . . . . . . . . . 1052

Display Information about an S-Series Stack . . . . . . . . . . . . . . . . . . . . . . . . . . 1052

Influence Management Unit Selection on an S-Series Stack . . . . . . . . . . . . . . . .1055

Manage Redundancy on an S-Series Stack . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1055

Reset a Unit on an S-Series Stack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1055

Monitor an S-Series Stack with SNMP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1056

Troubleshoot an S-Series Stack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1056

Recover from Stack Link Flaps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1056

Recover from a Card Problem State on an S-Series Stack . . . . . . . . . . . . . . . . .1057

Recover from a Card Mismatch State on an S-Series Stack . . . . . . . . . . . . . . . .1057

52 Broadcast Storm Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1059

Storm Control Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1059

Implementation Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1059

Broadcast Storm Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1060

Layer 3 Broadcast Storm Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1060

Layer 2 Broadcast Storm Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1061

Multicast Storm Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1061

53 Spanning Tree Protocol. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1063

Protocol Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1063

Configuring Spanning Tree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1063

Related Configuration Tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1064

Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1064

Configuring Interfaces for Layer 2 Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1065

Enabling Spanning Tree Protocol Globally . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1066

Adding an Interface to the Spanning Tree Group . . . . . . . . . . . . . . . . . . . . . . . . . . . .1068

Removing an Interface from the Spanning Tree Group . . . . . . . . . . . . . . . . . . . . . . . . 1068

Modifying Global Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1069

Modifying Interface STP Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1070

Enabling PortFast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1070

Preventing Network Disruptions with BPDU Guard . . . . . . . . . . . . . . . . . . . . . . . . . . .1071

STP Root Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1073

STP Root Guard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1074

Root Guard Scenario . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1074

Root Guard Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1077

SNMP Traps for Root Elections and Topology Changes . . . . . . . . . . . . . . . . . . . . . .1077

Configuring Spanning Trees as Hitless . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1078

STP Loop Guard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1078

Loop Guard Scenario . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1078

Loop Guard Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1081

Displaying STP Guard Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1082

54 System Time and Date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1083

Network Time Protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1083

| 27

Protocol Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1084

Implementation Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1085

Configuring Network Time Protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1085

Enable NTP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1086

Set the Hardware Clock with the Time Derived from NTP . . . . . . . . . . . . . . . . . . 1087

Configure NTP broadcasts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1087

Disable NTP on an interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1087

Configure a source IP address for NTP packets . . . . . . . . . . . . . . . . . . . . . . . . . .1088

Configure NTP authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1089

FTOS Time and Date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1091

Configuring time and date settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1091

www.dell.com | support.dell.com

Set daylight savings time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1094

55 Uplink Failure Detection (UFD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1099

Feature Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1099

How Uplink Failure Detection Works . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1100

UFD and NIC Teaming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1101

Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1102

Configuring Uplink Failure Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1103

Clearing a UFD-Disabled Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1104

Displaying Uplink Failure Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1106

Sample Configuration: Uplink Failure Detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1109

56 Upgrade Procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1111

Find the upgrade procedures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1111

Get Help with upgrades . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1111

57 VLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1113

Virtual LAN Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1113

Port-based VLANs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1114

VLAN Tagging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1115

Default VLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1116

Implementation Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1116

Configuring VLANs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1116

Related Configuration Tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1116

Related Protocols and Topics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1117

Create a VLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1117

Assign Interfaces to VLANs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1118

Enable Routing between VLANs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1119

Use a Native VLAN on Trunk Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1120

Change the Default VLAN ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1121

Set the Null VLAN as the Default VLAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1121

28 |

Enable VLAN Interface Counters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1122

58 Virtual Routing and Forwarding (VRF) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1123

VRF Configuration Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1124

CAM Profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1126

DHCP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1128

IP addressing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1128

VRF Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1128

Load the VRF CAM Profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1129

Enable VRF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1129

Assign an Interface to a VRF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1130

View VRF instance information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1131

Connect an OSPF process to a VRF instance . . . . . . . . . . . . . . . . . . . . . . . . . . .1132

Configure VRRP on a VRF Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1132

Sample VRF Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1132

59 Virtual Router Redundancy Protocol (VRRP) . . . . . . . . . . . . . . . . . . . . . . . . . . 1141

VRRP Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1141

VRRP Benefits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1143

VRRP Implementation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1143

VRRP version 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1144

VRRP Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1145

Create a Virtual Router . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1145

Assign Virtual IP addresses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1146

Set VRRP Group (Virtual Router) Priority . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1149

Configure VRRP Authentication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1150

Disable Preempt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1151

Change the Advertisement interval . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1152

Track an Interface or Object . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1153

VRRP on a VRF Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1156

Sample Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1158

VRRP for IPv4 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1158

VRRP for IPv6 Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1160

VRRP in VRF Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1163

60 FTOS XML Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1169

XML Functionality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1169

The Form of XML Requests and Responses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1170

The Configuration Request and Response . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1171

The “Show” Request and Response . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1172

Configuration Task List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1172

XML Error Conditions and Reporting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1176

| 29

Summary of XML Limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1176

Error Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1176

Examples of Error Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1177

Using display xml as a Pipe Option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1179

61 C-Series Debugging and Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1181

Switch Fabric overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1182

Switch Fabric link monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1182

Runtime hardware status monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1184

Inter-CPU timeouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1186

Bootup diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1187

www.dell.com | support.dell.com

Recognizing bootup failure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1187

Troubleshoot bootup failure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1187

Environmental monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1187

Recognize an overtemperature condition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1188

Troubleshoot an overtemperature condition . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1188

Recognize an under-voltage condition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1189

Troubleshoot an under-voltage condition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1189

Trace logs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1189

Automatic trace log updates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1190

Save a hardware log to a file on the flash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1190

Manual reload messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1191

CP software exceptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1192

Command history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1192

Advanced debugging commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1193

debug commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1193

show hardware commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1194

Monitoring hardware components with SNMP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1196

Hardware watchdog timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1197

Offline diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1198

Configuration task list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1198

Important points to remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1198

Take the line card offline . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1199

Run offline diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1199

View offline diagnostic test results . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1199

Bring the line card online . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1202

Buffer tuning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1203

When to tune buffers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1204

Buffer tuning commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1205

Sample configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1208

30 |

62 E-Series TeraScale Debugging and Diagnostics . . . . . . . . . . . . . . . . . . . . . . . 1211

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1212

System health checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1212

Runtime dataplane loopback check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1212

Disable RPM-SFM walk . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1214

RPM-SFM bring down . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1215

Manual loopback test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1215

Power the SFM on/off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1216

Reset the SFM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1218

SFM channel monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1218

Respond to PCDFO events . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1219

Inter-CPU timeouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1220

Debug commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1222

Hardware watchdog timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1222

Show hardware commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1223

Offline diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1223

Important points to remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1224

Offline configuration task list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1224

Parity error detection and correction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1225

Enable parity error correction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1225

Recognize a transient parity error . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1226

Recognize a non-recoverable parity error . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1227

Trace logs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1228

Buffer full condition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1228

Manual reload condition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1229

CP software exceptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1229

View trace buffer content . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1229

Write the contents of the trace buffer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1230

Clear the trace buffer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1230

Recognize a high CPU condition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1231

Configure an action upon a hardware error . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1231

Buffer traffic manager hardware errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1231

Flexible packet classifier hardware errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1232

Line card MAC hardware errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1232

Core dumps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1232

RPM core dumps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1232

Line card core dumps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1233

63 E-Series ExaScale Debugging and Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . 1235

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1236

System health checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1237

Line card loopback checks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1237

Manual loopback test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1240

Power On/Off the SFM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1241

Reset the SFM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1243

| 31

SFM channel monitoring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1243

Respond to PCDFO events . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1244

Inter-CPU timeouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1245

Software debugging commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1247

Hardware debugging commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1247

show control-traffic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1248

show ipc-traffic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1250

show hardware commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1252

Identify a suspect SFM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1256

Identify a suspect line card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1257

Last restart reason . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1257

www.dell.com | support.dell.com

Hardware watchdog timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1258

Information files and logs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1258

Trace logs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1259

Automatic trace log updates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1260

Save a trace log to a file on the flash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1260

Manual reload messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1260

CP/RP1/RP2 software exceptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1261

Recognize a high CPU condition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1261

Command history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1262

Software exception handling on line cards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1262

Crash logs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1263

Core dumps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1263

RPM core dumps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1263

Line card core dumps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1265

Console output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1268

32 |

64 S-Series Debugging and Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1271

Offline diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1271

Important Points to Remember . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1272

Running Offline Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1272

Trace logs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1275

Auto Save on Crash or Rollover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1276

Hardware watchdog timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1276

Buffer tuning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1276

Deciding to tune buffers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1278

Buffer tuning commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1279

Sample buffer profile configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1281

Troubleshooting packet loss . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1282

Displaying Drop Counters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1282

Dataplane Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1284

Displaying Stack Port Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1286

Displaying Stack Member Counters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1286

Application core dumps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1287

Mini core dumps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1287

65 Standards Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1289

IEEE Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1289

RFC and I-D Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1290

MIB Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1301

66 Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1303

| 33

www.dell.com | support.dell.com

34 |

About this Guide

Objectives

This guide describes the protocols and features supported by the Dell Force10 Operating System (FTOS) and provides configuration instructions and examples for implementing them. It supports the system platforms E-Series, C-Series, and S-Series.

The E-Series ExaScale platform is supported with FTOS version 8.1.1.0. and later.

Though this guide contains information on protocols, it is not intended to be a complete reference. This guide is a reference for configuring protocols on Dell Force10 systems. For complete information on protocols, refer to other documentation including IETF Requests for Comment (RFCs). The instructions in this guide cite relevant RFCs, and Appendix 65, Standards Compliance contains a complete list of the supported RFCs and Management Information Base files (MIBs).

Audience

This document is intended for system administrators who are responsible for configuring and maintaining networks and assumes you are knowledgeable in Layer 2 and Layer 3 networking technologies.

About this Guide | 35

Conventions

This document uses the following conventions to describe command syntax:

Convention Description

keyword

parameter

{X} Keywords and parameters within braces must be entered in the CLI. [X] Keywords and parameters within brackets are optional.

www.dell.com | support.dell.com

x | y Keywords and parameters separated by bar require you to choose one.

Keywords are in bold and should be entered in the CLI as listed. Parameters are in italics and require a number or word to be entered in the CLI.

Information Symbols

Table 1-1 describes symbols contained in this guide.

Table 1-1. Information Symbols

Symbol Warning Description

Note This symbol informs you of important operational information.

FTOS Behavior This symbol informs you of an FTOS behavior. These behaviors are

inherent to the Dell Force10 system or FTOS feature and are non-configurable.

ces

et e

Platform Specific Feature

E-Series Specific Feature/Command

Exception This symbol is a note associated with some other text on the page that is

Configuration Fundamentals

The FTOS Command Line Interface (CLI) is a text-based interface through which you can configure interfaces and protocols. The CLI is largely the same for the E-Series, C-Series, and S-Series with the exception of some commands and command outputs. The CLI is structured in modes for security and management purposes. Different sets of commands are available in each mode, and you can limit user access to modes using privilege levels.

In FTOS, after a command is enabled, it is entered into the running configuration file. You can view the current configuration for the whole system or for a particular CLI mode. To save the current configuration copy the running configuration to another location.

Note: Due to a differences in hardware architecture and the continued system development, features may occasionally differ between the platforms. These differences are identified by the information symbols shown on Table 1-1 on page 36.

Accessing the Command Line

Access the command line through a serial console port or a Telnet session (Figure 2-1). When the system successfully boots, you enter the command line in the EXEC mode.

Note: You must have a password configured on a virtual terminal line before you can Telnet into the system. Therefore, you must use a console connection when connecting to the system for the first time.

Figure 2-1. Logging into the System using Telnet

telnet 172.31.1.53 Trying 172.31.1.53... Connected to 172.31.1.53. Escape character is '^]'. Login: username

EXEC mode prompt

Configuration Fundamentals | 37

CLI Modes

Different sets of commands are available in each mode. A command found in one mode cannot be executed from another mode (with the exception of EXEC mode commands preceded by the command see The do Command on page 42). You can set user access rights to commands and command modes using privilege levels; for more information on privilege levels and security options, refer to Chapter 9, Security,

on page 627.

The FTOS CLI is divided into three major mode levels:

• EXEC mode is the default mode and has a privilege level of 1, which is the most restricted level. Only

a limited selection of commands is available, notably system information.

www.dell.com | support.dell.com

• EXEC Privilege mode has commands to view configurations, clear counters, manage configuration

files, run diagnostics, and enable or disable debug operations. The privilege level is 15, which is unrestricted. You can configure a password for this mode; see Configure the Enable Password on

page 52.

• CONFIGURATION mode enables you to configure security features, time settings, set logging and

SNMP functions, configure static ARP and MAC addresses, and set line cards on the system.

Beneath CONFIGURATION mode are sub-modes that apply to interfaces, protocols, and features.

Figure 2-2 illustrates this sub-mode command structure. Two sub-CONFIGURATION modes are

important when configuring the chassis for the first time:

do;

show commands, which allow you to view

• INTERFACE sub-mode is the mode in which you configure Layer 2 and Layer 3 protocols and IP

services specific to an interface. An interface can be physical (Management interface, 1-Gigabit Ethernet, or 10-Gigabit Ethernet, or SONET) or logical (Loopback, Null, port channel, or VLAN).

• LINE sub-mode is the mode in which you to configure the console and virtual terminal lines.

Note: At any time, entering a question mark (?) will display the available command options. For example, when you are in CONFIGURATION mode, entering the question mark first will list all available commands, including the possible sub-modes.

38 | Configuration Fundamentals

Figure 2-2. CLI Modes in FTOS

EXEC EXEC Privilege CONFIGURATION ARCHIVE AS-PATH ACL INTERFACE GIGABIT ETHERNET 10 GIGABIT ETHERNET INTERFACE RANGE LOOPBACK MANAGEMENT ETHERNET NULL PORT-CHANNEL SONET VLAN VRRP IP IPv6 IP COMMUNITY-LIST IP ACCESS-LIST STANDARD ACCESS-LIST EXTENDED ACCESS-LIST LINE AUXILIARY CONSOLE VIRTUAL TERMINAL MAC ACCESS-LIST MONITOR SESSION MULTIPLE SPANNING TREE Per-VLAN SPANNING TREE PREFIX-LIST RAPID SPANNING TREE REDIRECT ROUTE-MAP ROUTER BGP ROUTER ISIS ROUTER OSPF ROUTER RIP SPANNING TREE TRACE-LIST

Navigating CLI Modes

The FTOS prompt changes to indicate the CLI mode. Table 2-1 lists the CLI mode, its prompt, and information on how to access and exit this CLI mode. You must move linearly through the command modes, with the exception of the command moves you up one command mode level.

Note: Sub-CONFIGURATION modes all have the letters “conf” in the prompt with additional modifiers to identify the mode and slot/port information. These are shown in Table 2-1.

end command which takes you directly to EXEC Privilege mode; the exit

Configuration Fundamentals | 39

Table 2-1. FTOS Command Modes

CLI Command Mode Prompt

EXEC

EXEC Privilege

CONFIGURATION

www.dell.com | support.dell.com

Note: Access all of the following modes from CONFIGURATION mode.

ARCHIVE Force10(conf-archive) archive AS-PATH ACL Force10(config-as-path)# ip as-path access-list Gigabit Ethernet

Interface 10 Gigabit Ethernet

Interface Interface Range

Loopback Interface

Management Ethernet Interface

Access Command

Force10>

Access the router through the console or Telnet.

Force10# • From EXEC mode, enter the command enable.

• From any other mode, use the command end.

Force10(conf)# • From EXEC privilege mode, enter the command

configure.

• From every mode except EXEC and EXEC Privilege, enter the command

exit.

Force10(conf-if-gi-0/0)#

Force10(conf-if-te-0/0)#

Force10(conf-if-range)# Force10(conf-if-lo-0)#

Force10(conf-if-ma-0/0)#

interface

Null Interface Force10(conf-if-nu-0)#

INTERFACE modes

Port-channel Interface Force10(conf-if-po-0)# SONET Interface Force10(conf-if-so-0/0)# VLAN Interface Force10(conf-if-vl-0)# STANDARD ACCESS-

LIST EXTENDED ACCESS-

LIST

Force10(config-std-nacl)#

Force10(config-ext-nacl)#

ip access-list standard

ip access-list extended

IP ACCESS-LIST

IP COMMUNITY-LIST Force10(config-community-list)# ip community-list AUXILIARY Force10(config-line-aux)# CONSOLE Force10(config-line-console)#

LINE

VIRTUAL TERMINAL Force10(config-line-vty)#

line

40 | Configuration Fundamentals

Table 2-1. FTOS Command Modes

CLI Command Mode Prompt

STANDARD ACCESSLIST

EXTENDED ACCESSLIST

Force10(config-std-macl)# mac access-list standard

Force10(config-ext-macl)# mac access-list extended

MAC ACCESS-LIST

MULTIPLE SPANNING TREE

Per-VLAN SPANNING TREE Plus

PREFIX-LIST Force10(conf-nprefixl)# ip prefix-list RAPID SPANNING

TREE REDIRECT Force10(conf-redirect-list)# ip redirect-list ROUTE-MAP Force10(config-route-map)# route-map ROUTER BGP Force10(conf-router_bgp)# router bgp

Force10(config-mstp)#

Force10(config-pvst)#

Force10(config-rstp)#

Access Command

protocol spanning-tree mstp

protocol spanning-tree pvst

protocol spanning-tree rstp

ROUTER ISIS Force10(conf-router_isis)# router isis ROUTER OSPF Force10(conf-router_ospf)# router ospf ROUTER RIP

SPANNING TREE Force10(config-span)# protocol spanning-tree 0 TRACE-LIST Force10(conf-trace-acl)# ip trace-list

Force10(conf-router_rip)#

router rip

Figure 2-3 illustrates how to change the command mode from CONFIGURATION mode to PROTOCOL

SPANNING TREE.

Figure 2-3. Changing CLI Modes

Force10(conf)#protocol spanning-tree 0 Force10(config-span)#

New command prompt

Configuration Fundamentals | 41

The do Command

Enter an EXEC mode command from any CONFIGURATION mode (CONFIGURATION, INTERFACE, SPANNING TREE, etc.) without returning to EXEC mode by preceding the EXEC mode command with the command

Note: The following commands cannot be modified by the do command: enable, disable, exit, and

configure.

Figure 2-4. Using the do Command

Force10(conf)#do show linecard all

www.dell.com | support.dell.com

-- Line cards -Slot Status NxtBoot ReqTyp CurTyp Version Ports

-------------------------------------------------------------------------- 0 not present 1 not present 2 online online E48TB E48TB 1-1-463 48 3 not present 4 not present 5 online online E48VB E48VB 1-1-463 48

do. Figure 2-4 illustrates the do command.

“do” form of show command

Undoing Commands

When you enter a command, the command line is added to the running configuration file. Disable a command and remove it from the running-config by entering the original command preceded by the command

ip-address

Note: Use the help or ? command as discussed in Obtaining Help command to help you construct the “no” form of a command.

Figure 2-5. Undoing a command with the no Command

Force10(conf)#interface gigabitethernet 4/17 Force10(conf-if-gi-4/17)#ip address 192.168.10.1/24 Force10(conf-if-gi-4/17)#show config ! interface GigabitEthernet 4/17 ip address 192.168.10.1/24 no shutdown Force10(conf-if-gi-4/17)#no ip address Force10(conf-if-gi-4/17)#show config ! interface GigabitEthernet 4/17

Layer 2 protocols are disabled by default. Enable them using the no disable command. For example, in PROTOCOL SPANNING TREE mode, enter

no. For example, to delete an ip address configured on an interface, use the no ip address

command, as shown in Figure 2-5.

IP address removed

IP address assigned

“no” form of IP address command

no disable to enable Spanning Tree.

42 | Configuration Fundamentals

Obtaining Help

Obtain a list of keywords and a brief functional description of those keywords at any CLI mode using the ? or

help command:

• Enter

? at the prompt or after a keyword to list the keywords available in the current mode.

•

? after a prompt lists all of the available keywords. The output of this command is the same for the help command.

Figure 2-6. ? Command Example

Force10#? calendar Manage the hardware calendar cd Change current directory change Change subcommands clear Reset functions clock Manage the system clock configure Configuring from terminal copy Copy from one file to another debug Debug functions

--More--

“?” at prompt for list of commands

• ? after a partial keyword lists all of the keywords that begin with the specified letters.

Figure 2-7. Keyword? Command Example

Force10(conf)#cl? class-map clock Force10(conf)#cl

partial keyword plus “[space]?” for matching keywords

• A keyword followed by [space]? lists all of the keywords that can follow the specified keyword.

Figure 2-8. Keyword ? Command Example

Force10(conf)#clock ? summer-time Configure summer (daylight savings) time timezone Configure time zone Force10(conf)#clock

keyword plus “[space]?” for compatible keywords

Entering and Editing Commands

When entering commands:

• The CLI is not case sensitive.

• You can enter partial CLI keywords.

• You must enter the minimum number of letters to uniquely identify a command. For example, cannot be entered as a partial keyword because both the clock and class-map commands begin with the letters “cl.” begins with those three letters.

• The TAB key auto-completes keywords in commands. You must enter the minimum number of letters to uniquely identify a command.

clo, however, can be entered as a partial keyword because only one command

Configuration Fundamentals | 43

• The UP and DOWN arrow keys display previously entered commands (see Command History).

• The BACKSPACE and DELETE keys erase the previous letter.

• Key combinations are available to move quickly across the command line, as described in Table 2-2.

Table 2-2. Short-Cut Keys and their Actions

Key Combination Action

CNTL-A Moves the cursor to the beginning of the command line. CNTL-B Moves the cursor back one character. CNTL-D Deletes character at cursor. CNTL-E Moves the cursor to the end of the line. CNTL-F Moves the cursor forward one character.

www.dell.com | support.dell.com

CNTL-I Completes a keyword. CNTL-K Deletes all characters from the cursor to the end of the command line. CNTL-L Re-enters the previous command. CNTL-N Return to more recent commands in the history buffer after recalling commands with CTRL-P or the

UP arrow key. CNTL-P Recalls commands, beginning with the last command CNTL-R Re-enters the previous command. CNTL-U Deletes the line. CNTL-W Deletes the previous word. CNTL-X Deletes the line. CNTL-Z Ends continuous scrolling of command outputs. Esc B Moves the cursor back one word.

Esc F Moves the cursor forward one word. Esc D Deletes all characters from the cursor to the end of the word.

Command History

FTOS maintains a history of previously-entered commands for each mode. For example:

• When you are in EXEC mode, the UP and DOWN arrow keys display the previously-entered EXEC mode commands.

• When you are in CONFIGURATION mode, the UP or DOWN arrows keys recall the previously-entered CONFIGURATION mode commands.

44 | Configuration Fundamentals

Filtering show Command Outputs

Filter the output of a show command to display specific information by adding | [except | find | grep |

no-more | save

filtering and it IS case sensitive unless the

] specified_text after the command. The variable specified_text is the text for which you are

ignore-case sub-option is implemented.

Starting with FTOS 7.8.1.0, the

grep command accepts an ignore-case sub-option that forces the search to

case-insensitive. For example, the commands:

• show run | grep Ethernet returns a search result with instances containing a capitalized “Ethernet,” such as interface GigabitEthernet 0/0.

•

show run | grep ethernet would not return that search result because it only searches for instances

containing a non-capitalized “ethernet.”

Executing the command

show run | grep Ethernet ignore-case would return instances containing both

“Ethernet” and “ethernet.”

•

grep displays only the lines containing specified text. Figure 2-9 shows this command used in

combination with the command

show linecard all.

Figure 2-9. Filtering Command Outputs with the grep Command

Force10(conf)#do show linecard all | grep 0 0 not present

Note: FTOS accepts a space or no space before and after the pipe. To filter on a phrase with spaces, underscores, or ranges, enclose the phrase with double quotation marks.

• except displays text that does not match the specified text. Figure 2-10 shows this command used in combination with the command

show linecard all.

Figure 2-10. Filtering Command Outputs with the except Command

Force10#show linecard all | except 0

-- Line cards -Slot Status NxtBoot ReqTyp CurTyp Version Ports

-------------------------------------------------------------------------- 2 not present 3 not present 4 not present 5 not present 6 not present

Configuration Fundamentals | 45

• find displays the output of the show command beginning from the first occurrence of specified text

Figure 2-11 shows this command used in combination with the command

Figure 2-11. Filtering Command Outputs with the find Command

Force10(conf)#do show linecard all | find 0 0 not present 1 not present 2 online online E48TB E48TB 1-1-463 48 3 not present 4 not present 5 online online E48VB E48VB 1-1-463 48 6 not present 7 not present

show linecard all.

www.dell.com | support.dell.com

• display displays additional configuration information.

•

no-more displays the output all at once rather than one screen at a time. This is similar to the command terminal length except that the no-more option affects the output of the specified command only.

•

save copies the output to a file for future reference.

Note: You can filter a single command output multiple times. The save option should be the last option

entered. For example:

Force10# command | grep regular-expression | except

regular-expression | grep other-regular-expression | find regular-expression |

save

Multiple Users in Configuration mode

FTOS notifies all users in the event that there are multiple users logged into CONFIGURATION mode. A warning message indicates the username, type of connection (console or vty), and in the case of a vty connection, the IP address of the terminal on which the connection was established. For example:

• On the system that telnets into the switch, Message 1 appears:

Message 1 Multiple Users in Configuration mode Telnet Message

% Warning: The following users are currently configuring the system: User "<username>" on line console0

• On the system that is connected over the console, Message 2 appears:

Message 2 Multiple Users in Configuration mode Telnet Message

% Warning: User "<username>" on line vty0 "10.11.130.2" is in configuration mode

If either of these messages appears, Dell Force10 recommends that you coordinate with the users listed in the message so that you do not unintentionally overwrite each other’s configuration changes.

46 | Configuration Fundamentals

Getting Started

This chapter contains the following major sections:

• Default Configuration on page 48

• Configure a Host Name on page 49

• Access the System Remotely on page 49

• Configure the Enable Password on page 52

• Configuration File Management on page 52

• File System Management on page 57

When you power up the chassis, the system performs a Power-On Self Test (POST) during which Route Processor Module (RPM), Switch Fabric Module (SFM), and line card status LEDs blink green.The system then loads FTOS and boot messages scroll up the terminal window during this process. No user interaction is required if the boot process proceeds without interruption.

When the boot process is complete, the RPM and line card status LEDs remain online (green), and the console monitor displays the Force10 banner and EXEC mode prompt, as shown in Figure 3-1.

For details on using the Command Line Interface (CLI), see the Accessing the Command Line section in

Chapter 1, Configuration Fundamentals, on page 47.

Getting Started | 47

Figure 3-1. Completed Boot Process

.*************. .# #### #######. ######## ####### ######### ######## ######## .#. ###### ###########. ### ### ## ### ### #### ### .##. ## ### #### ###. ### ### ### ### ### ### ### *#. ### ### #* ### ### ## ### #### ### ######## *# -## ### #* ###### ### ## ######### ### ######## *# ### ## #* ### ### ## ### #### ### ### *# #### ### #* ### ### ### ### #### #### ### *#. #### ### ###* ### ### ### ### ### ##### ## ######## .#.##### #### #### . ### ##### ### ### ###### ######## .###### ############ . .# ######### . `************'

www.dell.com | support.dell.com

+ Force10 Networks, Inc. + CPU: DB-MV64460-BP/IBM750Fx (2.3) + Version: VxWorks5.5.1 + Memory Size: 1038876672 bytes. + BSP Version: 1.2/1.3.6 + Creation Date : Jan 2 2007

nvDrvInit: nvDrvErase passed

-> 00:00:10: %RPM0-U:CP %RAM-6-ELECTION_ROLE: RPM0 is transitioning to Primary RPM.

00:00:11: %RPM0-P:CP %CHMGR-2-FAN_BAD: Minor alarm: some fans in fan tray 0 are down 00:00:11: %RPM0-P:CP %CHMGR-5-CARDDETECTED: Line card 1 present

DSA Card Init 00:00:11: %RPM0-P:CP POEMGR-4-POE_POWER_USAGE_ABOVE_THRESHOLD: Inline power used is exceeded 90%

available inline power 00:00:12: %RPM0-P:CP %CHMGR-5-CARDDETECTED: Line card 2 present 00:00:12: %RPM0-P:CP %TSM-6-SFM_SWITCHFAB_STATE: Switch Fabric: UP 00:00:12: %RPM0-P:CP %TSM-6-SFM_FULL_PARTIAL_STATE: SW_FAB_UP_1 SFM in the system 00:00:13: %RPM0-P:CP %IFMGR-5-OSTATE_UP: Changed interface state to up: Ma 0/0

00:01:27: %RPM0-P:CP %CHMGR-5-CHECKIN: Checkin from line card 1 (type E48TB, 48 ports) 00:01:27: %RPM0-P:CP %CHMGR-5-CHECKIN: Checkin from line card 2 (type E48TB, 48 ports) 00:01:28: %RPM0-P:CP %CHMGR-5-LINECARDUP: Line card 1 is up 00:01:28: %RPM0-P:CP %CHMGR-5-LINECARDUP: Line card 2 is up 00:01:36: %RPM0-P:CP %RAM-5-RPM_STATE: RPM0 is in Active State. 00:01:36: %RPM0-P:CP %CHMGR-5-CHAS_READY: Chassis ready

00:01:37: %RPM0-P:CP %SEC-5-LOGIN_SUCCESS: Login successful for user on line console Force10>

Default Configuration

A version of FTOS is pre-loaded onto the chassis, however the system is not configured when you power up for the first time (except for the default hostname, which is Force10). You must configure the system using the CLI.

48 | Getting Started

Configure a Host Name

The host name appears in the prompt. The default host name is force10.

• Host names must start with a letter and end with a letter or digit.

• Characters within the string can be letters, digits, and hyphens.

To configure a host name:

Step Task Command Syntax Command Mode

1 Create a new host name.

Figure 3-2 illustrates the

Figure 3-2. Configuring a Hostname

Force10(conf)#hostname R1 R1(conf)#

New Hostname

hostname command.

Default Hostname

Access the System Remotely

You can configure the system to access it remotely by Telnet. The method for configuring the C-Series and E-Series for Telnet access is different from S-Series.

• The C-Series and E-Series have a dedicated management port and a management routing table that is separate from the IP routing table.

• The S-Series does not have a dedicated management port, but is managed from any port. It does not have a separate management routing table.

hostname name

CONFIGURATION

Access the C-Series and E-Series Remotely

Note: Use this process for the S60 system.

Configuring the system for Telnet is a three-step process:

1. Configure an IP address for the management port. See Configure the Management Port IP Address.

2. Configure a management route with a default gateway. See Configure a Management Route.

3. Configure a username and password. See Configure a Username and Password.

Getting Started | 49

Configure the Management Port IP Address

Assign IP addresses to the management ports in order to access the system remotely.

Note: Assign different IP addresses to each RPM’s management port.

To configure the management port IP address:

Step Task Command Syntax Command Mode

1 Enter INTERFACE mode for the

www.dell.com | support.dell.com

Management port.

Assign an IPv4 or IPv6 address to the interface.

Enable the interface.

Configure a Management Route

Define a path from the system to the network from which you are accessing the system remotely. Management routes are separate from IP routes and are only used to manage the system through the management port.

To configure a management route:

interface ManagementEthernet slot/port

• slot range: 0 to 1

• port range: 0

ip address {ipv4-address | ipv6-address}/mask

• ipv4-address: an address in dotted-decimal format (A.B.C.D).

• ipv6-address: an address in hexadecimal format (X:X:X:X::X).

• mask: a subnet mask in /prefix-length format (/ xx).

no shutdown

CONFIGURATION

INTERFACE

Step Task Command Syntax Command Mode

Configure an IPv4 or IPv6

management route to the network from which you are accessing the system.

Configure a Username and Password

Configure a system username and password to access the system remotely.

50 | Getting Started

management route {ipv4-address | ipv6-address}/

mask gateway

• ip-address: the network address in dotted-decimal format (A.B.C.D).

• mask: a subnet mask in /prefix-length format (/ xx).

• gateway: the next hop for network traffic originating from the management port.

CONFIGURATION

To configure a username and password:

Step Task Command Syntax Command Mode

Configure a username and

password to access the system remotely.

username username password [encryption-type] password encryption-type

specifies how you are inputting the

CONFIGURATION

password, is 0 by default, and is not required.

• 0 is for inputting the password in clear text.

• 7 is for inputting a password that is already encrypted using a Type 7 hash. Obtaining the encrypted password from the configuration of another Dell Force10 system.

Access the S-Series Remotely

The S-Series does not have a dedicated management port nor a separate management routing table. Configure any port on the S-Series to be the port through which you manage the system and configure an IP route to that gateway.

Note: The S60 system uses management ports and should be configured similar to the C-Series and E-Series systems. Refer to Access the C-Series and E-Series Remotely

Configuring the system for Telnet access is a three-step process:

1. Configure an IP address for the port through which you will manage the system using the command

address

from INTERFACE mode, as shown in Figure 3-3.

2. Configure a IP route with a default gateway using the command mode, as shown in Figure 3-3.

3. Configure a username and password using the command

username from CONFIGURATION mode, as

shown in Figure 3-3.

Figure 3-3. Configuring the S-Series for Remote Access

R5(conf)#int gig 0/48 R5(conf-if-gi-0/48)#ip address 10.11.131.240 R5(conf-if-gi-0/48)#show config ! interface GigabitEthernet 0/48 ip address 10.11.131.240/24 no shutdown R5(conf-if-gi-0/48)#exit R5(conf)#ip route 10.11.32.0/23 10.11.131.254 R5(conf)#username admin pass force10

ip route from CONFIGURATION

Getting Started | 51

Configure the Enable Password

The EXEC Privilege mode is accessed by the enable command. Configure a password as a basic security measure. When using a console connection, EXEC Privilege mode is unrestricted by default; it cannot be reached by a VTY connection if no password is configured. There are two types of

•

enable password stores the password in the running/startup configuration using a DES encryption

method.

•

enable secret is stored in the running/startup configuration in using a stronger, MD5 encryption

method.

enable passwords:

Dell Force10 recommends using the

www.dell.com | support.dell.com

enable secret password.

To configure an enable password:

Task Command Syntax Command Mode

Create a password to access EXEC Privilege mode.

enable [password | secret] [level level] [encryption-type]

password level

is the privilege level, is 15 by default, and is not required.

encryption-type specifies how you are inputting the password, is 0 by

default, and is not required.

• 0 is for inputting the password in clear text.

• 7 is for inputting a password that is already encrypted using a DES hash. Obtain the encrypted password from the configuration file of another Dell Force10 system.

• 5 is for inputting a password that is already encrypted using an MD5 hash. Obtain the encrypted password from the configuration file of another Dell Force10 system.

Configuration File Management

CONFIGURATION

Files can be stored on and accessed from various storage media. Rename, delete, and copy files on the system from the EXEC Privilege mode.

The E-Series EtherScale platform architecture uses MMC cards for both the internal and external Flash memory. MMC cards support a maximum of 100 files. The E-Series TeraScale and ExaScale platforms architecture use Compact Flash for the internal and external Flash memory. It has a space limitation but does not limit the number of files it can contain.

Note: Using flash memory cards in the system that have not been approved by Dell Force10 can cause unexpected system behavior, including a reboot.

52 | Getting Started

Copy Files to and from the System

The command syntax for copying files is similar to UNIX. The copy command uses the format copy

source-file-url destination-file-url.

Note: See the FTOS Command Reference for a detailed description of the copy command.

• To copy a local file to a remote system, combine the file-origin syntax for a local file location with the

file-destination syntax for a remote file location shown in Table 3-1.

• To copy a remote file to Dell Force10 system, combine the with the

Table 3-1. Forming a copy Command

Local File Location

Internal flash:

file-destination syntax for a local file location shown in Table 3-1.

source-file-url Syntax destination-file-url Syntax

file-origin syntax for a remote file location

primary RPM standby RPM copy rpm{0|1}flash://filename rpm{0|1}flash://filename

External flash:

primary RPM copy rpm{0|1}slot0://filename rpm{0|1}slot0://filename standby RPM copy rpm{0|1}slot0://filename rpm{0|1}slot0://filename

USB Drive (E-Series ExaScale only)

USB drive on RPM0 copy rpm0usbflash://filepath rpm0usbflash://filename External USB drive copy usbflash://filepath

Remote File Location Note: FTOS supports IPv4 and IPv6 addressing for FTP, TFTP, and SCP (in the hostip field).

FTP server copy ftp://username:password@{hostip |

TFTP server copy tftp://{hostip | hostname}/filepath/

SCP server copy scp://{hostip | hostname}/filepath/

copy flash://filename flash://filename

usbflash://filename

ftp://username:password

hostname

filename

}/filepath/filename

filepath/filename

tftp://{hostip | hostname}/filepath/filename

scp://{hostip | hostname}/filepath/filename

@{hostip | hostname}/

Important Points to Remember

• You may not copy a file from one remote system to another.

• You may not copy a file from one location to the same location.

• The internal flash memories on the RPMs are synchronized whenever there is a change, but only if both RPMs are running the same version of FTOS.

• When copying to a server, a hostname can only be used if a DNS server is configured.

Getting Started | 53

• The usbflash and rpm0usbflash commands are supported on E-Series ExaScale platform only. Refer to the FTOS Release Notes for a list of approved USB vendors.

Figure 3-4 shows an example of using the

Figure 3-4. Saving a file to a Remote System

Local Location

Force10#copy flash://FTOS-EF-8.2.1.0.bin ftp://myusername:mypassword@10.10.10.10//FTOS/FTOS-EF-8.2.1.0 !!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!

27952672 bytes successfully copied

www.dell.com | support.dell.com

Figure 3-5 shows an example of using the copy command to import a file to the Dell Force10 system from

an FTP server.

Figure 3-5. Saving a file to a Remote System

Remote Location

core1#$//copy ftp://myusername:mypassword@10.10.10.10//FTOS/FTOS-EF-8.2.1.0.bin flash:// Destination file name [FTOS-EF-8.2.1.0.bin.bin]: !!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!! 26292881 bytes successfully copied

copy command to save a file to an FTP server.

Remote Location

Local Location

Save the Running-configuration

The running-configuration contains the current system configuration. Dell Force10 recommends that you copy your running-configuration to the startup-configuration. The system uses the startup-configuration during boot-up to configure the system. The startup-configuration is stored in the internal flash on the primary RPM by default, but it can be saved onto an external flash (on an RPM) or a remote server.

To save the running-configuration:

Note: The commands in this section follow the same format as those in Copy Files to and from the

System on page 53 but use the filenames startup-configuration and running-configuration. These

commands assume that current directory is the internal flash, which is the system default.

54 | Getting Started

Task Command Syntax Command Mode

Save the running-configuration to:

the startup-configuration on the internal flash of the primary RPM

the internal flash on an RPM copy running-config rpm{0|1}flash://filename

Note: The internal flash memories on the RPMs are synchronized whenever there is a change, but only if the RPMs are running the same version of FTOS. Note: FTOS supports IPv4 and IPv6 addressing for FTP, TFTP, and SCP (in the

hostip field).

the external flash of an RPM copy running-config rpm{0|1}slot0://filename an FTP server

a TFTP server copy running-config tftp://{hostip | hostname}/

an SCP server copy running-config scp://{hostip | hostname}/

Note: When copying to a server, a hostname can only be used if a DNS server is configured.

Save the running-configuration to the startup-configuration on the internal flash of the primary RPM. Then copy the new startup-config file to the external flash of the primary RPM.

copy running-config startup-config

copy running-config ftp://

username:password filename

filepath/filename

copy running-config startup-config duplicate

@{hostip | hostname}/filepath/

EXEC Privilege

FTOS Behavior: If you create a startup-configuration on an RPM and then move the RPM to another

chassis, the startup-configuration is stored as a backup file (with the extension .bak), and a new,

empty startup-configuration file is created. To restore your original startup-configuration in this situation, overwrite the new startup-configuration with the original one using the command copy

startup-config.bak startup-config.

View Files

File information and content can only be viewed on local file systems.

Getting Started | 55

To view a list of files on the internal or external Flash:

Step Task Command Syntax Command Mode

1 View a list of files on:

the external flash of an RPM

The output of the command modification for each file, as shown in Figure 3-6.

Figure 3-6. Viewing a List of Files in the Internal Flash

www.dell.com | support.dell.com

Force10#dir Directory of flash:

1 drw- 32768 Jan 01 1980 00:00:00 . 2 drwx 512 Jul 23 2007 00:38:44 .. 3 drw- 8192 Mar 30 1919 10:31:04 TRACE_LOG_DIR 4 drw- 8192 Mar 30 1919 10:31:04 CRASH_LOG_DIR 5 drw- 8192 Mar 30 1919 10:31:04 NVTRACE_LOG_DIR 6 drw- 8192 Mar 30 1919 10:31:04 CORE_DUMP_DIR 7 d--- 8192 Mar 30 1919 10:31:04 ADMIN_DIR 8 -rw- 33059550 Jul 11 2007 17:49:46 FTOS-EF-7.4.2.0.bin 9 -rw- 27674906 Jul 06 2007 00:20:24 FTOS-EF-4.7.4.302.bin 10 -rw- 27674906 Jul 06 2007 19:54:52 boot-image-FILE 11 drw- 8192 Jan 01 1980 00:18:28 diag 12 -rw- 7276 Jul 20 2007 01:52:40 startup-config.bak 13 -rw- 7341 Jul 20 2007 15:34:46 startup-config 14 -rw- 27674906 Jul 06 2007 19:52:22 boot-image 15 -rw- 27674906 Jul 06 2007 02:23:22 boot-flash

--More--

dir flash:

dir slot:

dir also shows the read/write privileges, size (in bytes), and date of

EXEC Privilegethe internal flash of an RPM

To view the contents of a file:

Step Task Command Syntax Command Mode

1 View the:

View Configuration Files

Configuration files have three commented lines at the beginning of the file, as shown in Figure 3-7, to help you track the last time any user made a change to the file, which user made the changes, and when the file was last saved to the startup-configuration.

56 | Getting Started

contents of a file in the internal flash of an RPM

contents of a file in the external flash of an RPM

running-configuration startup-configuration

show file rpm{0|1}flash://filename

show file rpm{0|1}slot0://filename

show running-config

show startup-config

EXEC Privilege

In the running-configuration file, if there is a difference between the timestamp on the “Last configuration change,” and “Startup-config last updated,” then you have made changes that have not been saved and will not be preserved upon a system reboot.

Figure 3-7. Tracking Changes with Configuration Comments

Force10#show running-config Current Configuration ...

! Version 8.2.1.0 ! Last configuration change at Thu Apr 3 23:06:28 2008 by admin ! Startup-config last updated at Thu Apr 3 23:06:55 2008 by admin

! boot system rpm0 primary flash://FTOS-EF-8.2.1.0.bin boot system rpm0 secondary flash://FTOS-EF-7.8.1.0.bin boot system rpm0 default flash://FTOS-EF-7.7.1.1.bin boot system rpm1 primary flash://FTOS-EF-7.8.1.0.bin boot system gateway 10.10.10.100

--More--

File System Management

The Dell Force10 system can use the internal Flash, external Flash, or remote devices to store files. It stores files on the internal Flash by default but can be configured to store files elsewhere.

To view file system information:

Task Command Syntax Command Mode

View information about each file system.

The output of the command

show file-systems (Figure 3-8) shows the total capacity, amount of free

show file-systems

EXEC Privilege

memory, file structure, media type, read/write privileges for each storage device in use.

Figure 3-8. show file-systems Command Example

Force10#show file-systems Size(b) Free(b) Feature Type Flags Prefixes 520962048 213778432 dosFs2.0 USERFLASH rw flash: 127772672 21936128 dosFs2.0 USERFLASH rw slot0:

- - - network rw ftp:

- - - network rw tftp:

- - - network rw scp:

You can change the default file system so that file management commands apply to a particular device or memory.

To change the default storage location:

Task Command Syntax Command Mode

Change the default directory.

cd directory

EXEC Privilege

Getting Started | 57

In Figure 3-9, the default storage location is changed to the external Flash of the primary RPM. File management commands then apply to the external Flash rather than the internal Flash.

Figure 3-9. Alternative Storage Location

Force10#cd slot0: Force10#copy running-config test Force10#copy run test ! 7419 bytes successfully copied Force10#dir Directory of slot0:

1 drw- 32768 Jan 01 1980 00:00:00 . 2 drwx 512 Jul 23 2007 00:38:44 .. 3 ---- 0 Jan 01 1970 00:00:00 DCIM

www.dell.com | support.dell.com

4 -rw- 7419 Jul 23 2007 20:44:40 test 5 ---- 0 Jan 01 1970 00:00:00 BT 6 ---- 0 Jan 01 1970 00:00:00 200702~1VSN 7 ---- 0 Jan 01 1970 00:00:00 G 8 ---- 0 Jan 01 1970 00:00:00 F 9 ---- 0 Jan 01 1970 00:00:00 F

slot0: 127772672 bytes total (21927936 bytes free)

No File System Specified

File Saved to External Flash

View command history

The command-history trace feature captures all commands entered by all users of the system with a time stamp and writes these messages to a dedicated trace log buffer. The system generates a trace message for each executed command. No password information is saved to the file.

To view the command-history trace, use the

Figure 3-10. Command Example show command-history

Force10#show command-history [12/5 10:57:8]: CMD-(CLI):service password-encryption [12/5 10:57:12]: CMD-(CLI):hostname Force10 [12/5 10:57:12]: CMD-(CLI):ip telnet server enable [12/5 10:57:12]: CMD-(CLI):line console 0 [12/5 10:57:12]: CMD-(CLI):line vty 0 9 [12/5 10:57:13]: CMD-(CLI):boot system rpm0 primary flash://FTOS-CB-1.1.1.2E2.bin

show command-history command, as shown in Figure 487.

Upgrading and Downgrading FTOS

Note: To upgrade or downgrade FTOS, see the release notes for the version you want to load on the

system.

58 | Getting Started

System Management

System Management is supported on platforms: c e s

This chapter explains the different protocols or services used to manage the Dell Force10 system including:

• Configure Privilege Levels on page 59

• Configure Logging on page 63

• File Transfer Services on page 70

• Terminal Lines on page 71

• Lock CONFIGURATION mode on page 74

• Recovering from a Forgotten Password on page 76

• Recovering from a Forgotten Password on S-Series on page 78

• Recovering from a Failed Start on page 79

Configure Privilege Levels

Privilege levels restrict access to commands based on user or terminal line. There are 16 privilege levels, of which three are pre-defined. The default privilege level is 1.

• Level 0—Access to the system begins at EXEC mode, and EXEC mode commands are limited to

enable, disable, and exit.

• Level 1—Access to the system begins at EXEC mode, and all commands are available.

• Level 15—Access to the system begins at EXEC Privilege mode, and all commands are available.

Create a Custom Privilege Level

Custom privilege levels start with the default EXEC mode command set. You can then customize privilege levels 2-14 by:

• restricting access to an EXEC mode command

• moving commands from EXEC Privilege to EXEC mode

• restricting access

System Management | 59

A user can access all commands at his privilege level and below.

Removing a command from EXEC mode

Remove a command from the list of available commands in EXEC mode for a specific privilege level using the command

privilege exec from CONFIGURATION mode. In the command, specify a level greater

than the level given to a user or terminal line, followed by the first keyword of each command to be restricted.

Move a command from EXEC Privilege mode to EXEC mode

Move a command from EXEC Privilege to EXEC mode for a privilege level using the command privilege

www.dell.com | support.dell.com

from CONFIGURATION mode. In the command, specify the privilege level of the user or terminal

exec

line, and specify all keywords in the command to which you want to allow access.

Allow Access to CONFIGURATION mode commands

Allow access to CONFIGURATION mode using the command privilege exec level level configure from CONFIGURATION mode. A user that enters CONFIGURATION mode remains at his privilege level, and has access to only two commands, mode command to which you want to allow access using the command command, specify the privilege level of the user or terminal line, and specify all keywords in the command to which you want to allow access.

end and exit. You must individually specify each CONFIGURATION

privilege configure level level. In the

Allow Access to INTERFACE, LINE, ROUTE-MAP, and ROUTER mode

1. Similar to allowing access to CONFIGURATION mode, to allow access to INTERFACE, LINE, ROUTE-MAP, and ROUTER modes, you must first allow access to the command that enters you into the mode. For example, allow a user to enter INTERFACE mode using the command

configure level level interface

gigabitethernet

2. Then, individually identify the INTERFACE, LINE, ROUTE-MAP or ROUTER commands to which you want to allow access using the command

privilege {interface | line | route-map | router} level level.

In the command, specify the privilege level of the user or terminal line, and specify all keywords in the command to which you want to allow access.

The following table lists the configuration tasks you can use to customize a privilege level:

Task Command Syntax Command Mode

Remove a command from the list of available commands in EXEC mode.

Move a command from EXEC Privilege to EXEC mode. privilege exec level level

Allow access to CONFIGURATION mode. privilege exec level level

privilege exec level level

{command ||...|| command}

configure

privilege

CONFIGURATION

60 | System Management

Task Command Syntax Command Mode

Allow access to INTERFACE, LINE, ROUTE-MAP, and/or ROUTER mode. Specify all keywords in the command.

Allow access to a CONFIGURATION, INTERFACE, LINE, ROUTE-MAP, and/or ROUTER mode command.

The configuration in Figure 4-1 creates privilege level 3. This level:

• removes the

• moves the command

resequence command from EXEC mode by requiring a minimum of privilege level 4,

capture bgp-pdu max-buffer-size from EXEC Privilege to EXEC mode by,

requiring a minimum privilege level 3, which is the configured level for VTY 0,

• allows access to CONFIGURATION mode with the

• allows access to INTERFACE and LINE modes are allowed with no commands.

privilege configure level level

{interface | line | route-map |

router} {command-keyword ||...|| command-keyword}

privilege {configure |interface | line | route-map | router} level

level

{command ||...|| command}

banner command, and

CONFIGURATION

System Management | 61

Figure 4-1. Create a Custom Privilege Level

Force10(conf)#do show run priv ! privilege exec level 3 capture privilege exec level 3 configure privilege exec level 4 resequence privilege exec level 3 capture bgp-pdu privilege exec level 3 capture bgp-pdu max-buffer-size privilege configure level 3 line privilege configure level 3 interface Force10(conf)#do telnet 10.11.80.201 [telnet output omitted] Force10#show priv Current privilege level is 3. Force10#? capture Capture packet

www.dell.com | support.dell.com

configure Configuring from terminal disable Turn off privileged commands enable Turn on privileged commands exit Exit from the EXEC ip Global IP subcommands monitor Monitoring feature mtrace Trace reverse multicast path from destination to source ping Send echo messages quit Exit from the EXEC show Show running system information [output omitted] Force10#config [output omitted] Force10(conf)#do show priv Current privilege level is 3. Force10(conf)#? end Exit from configuration mode exit Exit from configuration mode interface Select an interface to configure line Configure a terminal line linecard Set line card type Force10(conf)#interface ? fastethernet Fast Ethernet interface gigabitethernet Gigabit Ethernet interface loopback Loopback interface managementethernet Management Ethernet interface null Null interface port-channel Port-channel interface range Configure interface range sonet SONET interface tengigabitethernet TenGigabit Ethernet interface vlan VLAN interface Force10(conf)#interface gigabitethernet 1/1 Force10(conf-if-gi-1/1)#? end Exit from configuration mode exit Exit from interface configuration mode Force10(conf-if-gi-1/1)#exit Force10(conf)#line ? aux Auxiliary line console Primary terminal line vty Virtual terminal Force10(conf)#line vty 0 Force10(config-line-vty)#? exit Exit from line configuration mode Force10(config-line-vty)#

62 | System Management

Apply a Privilege Level to a Username

To set a privilege level for a user:

Task Command Syntax Command Mode

Configure a privilege level for a user.

username username privilege level

CONFIGURATION

Apply a Privilege Level to a Terminal Line

To set a privilege level for a terminal line:

Task Command Syntax Command Mode

Configure a privilege level for a terminal line.

Note: When you assign a privilege level between 2 and 15, access to the system begins at EXEC mode,

but the prompt is hostname#, rather than hostname>.

privilege level level

LINE

Configure Logging

FTOS tracks changes in the system using event and error messages. By default, FTOS logs these messages on:

• the internal buffer

• console and terminal lines, and

• any configured syslog servers

Disable Logging

To disable logging:

Task Command Syntax Command Mode

Disable all logging except on the console.

Disable logging to the logging buffer.

Disable logging to terminal lines.

Disable console logging.

no logging on

no logging buffer

no logging monitor

no logging console

CONFIGURATION

System Management | 63

Log Messages in the Logging Buffer

All error messages, except those beginning with %BOOTUP (Message 1), are log in the internal buffer.

Message 1 BootUp Events

%BOOTUP:RPM0:CP %PORTPIPE-INIT-SUCCESS: Portpipe 0 enabled

Configuration Task List for System Log Management

The following list includes the configuration tasks for system log management:

www.dell.com | support.dell.com

• Disable System Logging on page 64

• Send System Messages to a Syslog Server on page 65

Disable System Logging

By default, logging is enabled and log messages are sent to the logging buffer, all terminal lines, console, and syslog servers.

Enable and disable system logging using the following commands:

Task Command Syntax Command Mode

Disable all logging except on the console.

Disable logging to the logging buffer.

Disable logging to terminal lines.

Disable console logging.

no logging on

no logging buffer

no logging monitor

no logging console

CONFIGURATION

64 | System Management

Send System Messages to a Syslog Server

Send system messages to a syslog server by specifying a server:

Task Command Syntax Command Mode

Specify the server to which you want to send system messages. You can configure up to eight syslog servers, which may be IPv4 and/or IPv6 addressed.

logging {ip-address | ipv6-address

| hostname}

Configure a Unix System as a Syslog Server

Configure a UNIX system as a syslog server by adding the following lines to /etc/syslog.conf on the Unix system and assigning write permissions to the file.

• on a 4.1 BSD UNIX system, add the line: local7.debugging /var/log/force10.log

• on a 5.7 SunOS UNIX system, add the line: local7.debugging /var/adm/force10.log

In the lines above, local7 is the logging facility level and debugging is the severity level.

Change System Logging Settings

You can change the default system logging settings (severity level and the storage location). The default is to log all messages up to debug level.

CONFIGURATION

Task Command Syntax Command Mode

Specify the minimum severity level for logging to the logging buffer.

Specify the minimum severity level for logging to the console.

Specify the minimum severity level for logging to terminal lines.

Specifying the minimum severity level for logging to a syslog server.

Specify the minimum severity level for logging to the syslog history table.

logging buffered level CONFIGURATION

logging console level

logging monitor level

logging trap level

logging history level

CONFIGURATION

System Management | 65

Task Command Syntax Command Mode

Specify the size of the logging buffer. Note: When you decrease the buffer size, FTOS deletes all messages stored in the buffer. Increasing the buffer size does not affect messages in the buffer.

Specify the number of messages that FTOS saves to its logging history table.

logging buffered size CONFIGURATION

logging history size size

CONFIGURATION

Display the logging buffer and configuration using the show logging command from EXEC Privilege mode, as shown in Figure 4-2.

www.dell.com | support.dell.com

Display the logging configuration using the

show running-config logging command from EXEC

Privilege mode, as shown in Figure 4-3.

Display the Logging Buffer and the Logging Configuration

Display the current contents of the logging buffer and the logging settings for the system using the show

logging

command from EXEC Privilege mode, as shown in Figure 4-2.

66 | System Management

Figure 4-2. show logging Command Example

Force10#show logging syslog logging: enabled Console logging: level Debugging Monitor logging: level Debugging Buffer logging: level Debugging, 40 Messages Logged, Size (40960 bytes) Trap logging: level Informational %IRC-6-IRC_COMMUP: Link to peer RPM is up %RAM-6-RAM_TASK: RPM1 is transitioning to Primary RPM. %RPM-2-MSG:CP1 %POLLMGR-2-MMC_STATE: External flash disk missing in 'slot0:' %CHMGR-5-CARDDETECTED: Line card 0 present %CHMGR-5-CARDDETECTED: Line card 2 present %CHMGR-5-CARDDETECTED: Line card 4 present %CHMGR-5-CARDDETECTED: Line card 5 present %CHMGR-5-CARDDETECTED: Line card 8 present %CHMGR-5-CARDDETECTED: Line card 10 present %CHMGR-5-CARDDETECTED: Line card 12 present %TSM-6-SFM_DISCOVERY: Found SFM 0 %TSM-6-SFM_DISCOVERY: Found SFM 1 %TSM-6-SFM_DISCOVERY: Found SFM 2 %TSM-6-SFM_DISCOVERY: Found SFM 3 %TSM-6-SFM_DISCOVERY: Found SFM 4 %TSM-6-SFM_DISCOVERY: Found SFM 5 %TSM-6-SFM_DISCOVERY: Found SFM 6 %TSM-6-SFM_DISCOVERY: Found SFM 7 %TSM-6-SFM_SWITCHFAB_STATE: Switch Fabric: UP %TSM-6-SFM_DISCOVERY: Found SFM 8 %TSM-6-SFM_DISCOVERY: Found 9 SFMs %CHMGR-5-CHECKIN: Checkin from line card 5 (type EX1YB, 1 ports) %TSM-6-PORT_CONFIG: Port link status for LC 5 => portpipe 0: OK portpipe 1: N/A %CHMGR-5-LINECARDUP: Line card 5 is up %CHMGR-5-CHECKIN: Checkin from line card 12 (type S12YC12, 12 ports) %TSM-6-PORT_CONFIG: Port link status for LC 12 => portpipe 0: OK portpipe 1: N/A %CHMGR-5-LINECARDUP: Line card 12 is up %IFMGR-5-CSTATE_UP: changed interface Physical state to up: So 12/8 %IFMGR-5-CSTATE_DN: changed interface Physical state to down: So 12/8

System Management | 67

Configure a UNIX Logging Facility Level

Facility is a message tag used to describe the application or process that submitted the log message. You can save system log messages with a UNIX system logging facility:

Command Syntax Command Mode Purpose

logging facility [facility-type] CONFIGURATION Specify one of the following parameters.

www.dell.com | support.dell.com

• auth (for authorization messages)

• cron (for system scheduler messages)

• daemon (for system daemons)

• kern (for kernel messages)

• local0 (for local use)

• local1 (for local use)

• local2 (for local use)

• local3 (for local use)

• local4 (for local use)

• local5 (for local use)

• local6 (for local use)

• local7 (for local use). This is the default.

• lpr (for line printer system messages)

• mail (for mail system messages)

• news (for USENET news messages)

• sys9 (system use)

• sys10 (system use)

• sys11 (system use)

• sys12 (system use)

• sys13 (system use)

• sys14 (system use)

• syslog (for syslog messages)

• user (for user programs)

• uucp (UNIX to UNIX copy protocol) The default is local7.

Display non-default settings using the shown in Figure 4-3.

Figure 4-3. show running-config logging Command Example

Force10#show running-config logging ! logging buffered 524288 debugging service timestamps log datetime msec service timestamps debug datetime msec ! logging trap debugging logging facility user logging source-interface Loopback 0 logging 10.10.10.4 Force10#

68 | System Management

show running-config logging command from EXEC mode, as

Synchronize Log Messages

You can configure a terminal line to hold all logs until all command inputs and outputs are complete so that log printing does not interfere when you are performing management tasks. Log synchronization also filters system messages for a specific line based on severity level and limits number of messages that are printed at once.

Step Task Command Syntax Command Mode

1 Enter the LINE mode. Configure the

following parameters for the virtual terminal lines:

• number range: zero (0) to 8.

• end-number range: 1 to 8. You can configure multiple virtual terminals at one time by entering a followed by an end-number.

Set a level and the maximum number of messages to be printed. The following parameters are optional:

• level severity-level range: 0 to 7. Default is 2. Use the all keyword to include all messages.

• limit range: 20 to 300. Default is 20.

Display the logging synchronous configuration using the

number

line {console 0 | vty number

[end-number] | aux 0}

logging synchronous [level

severity-level | all] [limit]

show config command from LINE mode.

Enable Timestamp on Syslog Messages

Syslog messages, by default, do not include a time/date stamp stating when the error or message was created. To have FTOS include a timestamp with the syslog message:

CONFIGURATION

LINE

Purpose Command Syntax Command Mode

Add timestamp to syslog messages. Specify the following optional parameters:

• datetime: You can add the keyword localtime to include the localtime, msec, and show-timezone. If you do not add the keyword localtime, the time is UTC.

• uptime. To view time since the last boot.

Display your configuration using the command

service timestamps [log | debug] [datetime

[

localtime] [msec] [show-timezone] |

uptime]

Default: uptime

show running-config logging from EXEC Privilege

CONFIGURATION

mode, as shown in Figure 4-3.

System Management | 69

File Transfer Services

You can configure the system to transfer files over the network using File Transfer Protocol (FTP).

Configuration Task List for File Transfer Services

The following list includes the configuration tasks for file transfer services:

• Enable FTP server on page 70

• Configure FTP server parameters on page 70

• Configure FTP client parameters on page 71

www.dell.com | support.dell.com

Enable FTP server

To make the system an FTP server:

Task Command Syntax Command Mode

Make the system an FTP server.

Display your FTP configuration using the command

ftp-server enable

show running-config ftp from EXEC Privilege mode,

CONFIGURATION

as shown in Figure 4-4.

Figure 4-4. show running-config ftp Command Example

Force10#show running ftp ! ftp-server enable ftp-server username nairobi password 0 zanzibar Force10#

Configure FTP server parameters

To configure FTP server parameters:

Task Command Syntax Command Mode

Specify the directory for users using FTP to reach the system. The default is the internal flash.

Specify a user name for all FTP users and configure either a plain text or encrypted password. Configure the following optional and required parameters:

• username: Enter a text string

• encryption-type: Enter 0 for plain text or 7 for encrypted text.

• password: Enter a text string.

ftp-server topdir dir CONFIGURATION

ftp-server username username password [encryption-type]

password

CONFIGURATION

70 | System Management

Note: You cannot use the change directory (cd) command until ftp-server topdir is configured.

Display your FTP configuration using the command show running-config ftp from EXEC Privilege mode, as shown in Figure 4-4.

Configure FTP client parameters

When the system will be an FTP client, configure FTP client parameters:

Task Command Syntax Command Mode

Specify a source interface. ip ftp source-interface interface CONFIGURATION Configure a password. Enter username to use on FTP client. ip ftp username name CONFIGURATION

Display the FTP configuration using the command

ip ftp password password

show running-config ftp from EXEC Privilege mode,

CONFIGURATION

Figure 4-4

Terminal Lines

You can access the system remotely and restrict access to the system by creating user profiles. The terminal lines on the system provide different means of accessing the system. The console line (console) connects you through the Console port in the RPMs. The virtual terminal lines (VTY) connect you through Telnet to the system. The auxiliary line (aux) connects secondary devices such as modems.

Deny and Permit Access to a Terminal Line

Force 10 recommends applying only standard ACLs to deny and permit access to VTY lines.

• Layer 3 ACL deny all traffic that is not explicitly permitted, but in the case of VTY lines, an ACL with no rules does not deny any traffic.

• You cannot use a VTY line.

show ip accounting access-list to display the contents of an ACL that is applied only to

To apply an IP ACL to a line:

Task Command Syntax Command Mode

Apply an ACL to a VTY line. ip access-class access-list LINE

To view the configuration, enter the

show config command in the LINE mode, as shown in Figure 4-5.

System Management | 71

Figure 4-5. Applying an Access List to a VTY Line

Force10(config-std-nacl)#show config ! ip access-list standard myvtyacl seq 5 permit host 10.11.0.1 Force10(config-std-nacl)#line vty 0 Force10(config-line-vty)#show config line vty 0 access-class myvtyacl

FTOS Behavior: Prior to FTOS version 7.4.2.0, in order to deny access on a VTY line, you must apply

an ACL and AAA authentication to the line. Then users are denied access only after they enter a

username and password. Beginning in FTOS version 7.4.2.0, only an ACL is required, and users are

denied access before they are prompted for a username and password.

www.dell.com | support.dell.com

Configure Login Authentication for Terminal Lines

You can use any combination of up to 6 authentication methods to authenticate a user on a terminal line. A combination of authentication methods is called a method list. If the user fails the first authentication method, FTOS prompts the next method until all methods are exhausted, at which point the connection is terminated. The available authentication methods are:

•

enable—Prompt for the enable password.

•

line—Prompt for the e password you assigned to the terminal line. You must configure a password for

the terminal line to which you assign a method list that contains the

line authentication method.

Configure a password using the command password from LINE mode.

•

local—Prompt for the the system username and password.

•

none—Do not authenticate the user.

•

radius—Prompt for a username and password and use a RADIUS server to authenticate.

•

tacacs+—Prompt for a username and password and use a TACACS+ server to authenticate.

To configure authentication for a terminal line:

Step Task Command Syntax Command Mode

1 Create an authentication method list.

You may use a mnemonic name or use the keyword default. The default authentication method for terminal lines is local, and the default method list is empty.

2 Apply the method list from Step 1 to

a terminal line.

aaa authentication login {method-list-name | default} [method-1] [method-2] [method-3]

[method-4] [method-5] [method-6]

CONFIGURATION

72 | System Management

Step Task Command Syntax Command Mode

3 If you used the line authentication

password

method in the method list you applied to the terminal line, configure a password for the terminal line.

In Figure 4-6 VTY lines 0-2 use a single authentication method, line.

Figure 4-6. Configuring Login Authentication on a Terminal Line

Force10(conf)#aaa authentication login myvtymethodlist line Force10(conf)#line vty 0 2 Force10(config-line-vty)#login authentication myvtymethodlist Force10(config-line-vty)#password myvtypassword Force10(config-line-vty)#show config line vty 0 password myvtypassword login authentication myvtymethodlist line vty 1 password myvtypassword login authentication myvtymethodlist line vty 2 password myvtypassword login authentication myvtymethodlist Force10(config-line-vty)#

LINE

Time out of EXEC Privilege Mode

EXEC timeout is a basic security feature that returns FTOS to the EXEC mode after a period of inactivity on terminal lines.

To change the timeout period or disable EXEC timeout.

Task Command Syntax Command Mode

Set the number of minutes and seconds. Default: 10 minutes on console, 30 minutes on VTY. Disable EXEC timeout by setting the timeout period to 0.

Return to the default timeout values.

View the configuration using the command

exec-timeout minutes [seconds]

no exec-timeout

show config from LINE mode.

LINE

System Management | 73

Figure 4-7. Configuring EXEC Timeout

Force10(conf)#line con 0 Force10(config-line-console)#exec-timeout 0 Force10(config-line-console)#show config line console 0 exec-timeout 0 0 Force10(config-line-console)#

Telnet to Another Network Device

To telnet to another device:

www.dell.com | support.dell.com

Task Command Syntax Command Mode

Telnet to the peer RPM. You do not need to configure the management port on the peer RPM to be able to telnet to it.

Telnet to a device with an IPv4 or IPv6 address. If you do not enter an IP address, FTOS enters a Telnet dialog that prompts you for one.

• Enter an IPv4 address in dotted decimal format (A.B.C.D).

• Enter an IPv6 address in the format 0000:0000:0000:0000:0000:0000:0000:0000. Elision of zeros is supported.

Note: Telnet to link-local addresses is not supported.

Figure 4-8. Telnet to Another Network Device

Force10# telnet 10.11.80.203 Trying 10.11.80.203... Connected to 10.11.80.203. Exit character is '^]'. Login: Login: admin Password: Force10>exit Force10#telnet 2200:2200:2200:2200:2200::2201 Trying 2200:2200:2200:2200:2200::2201... Connected to 2200:2200:2200:2200:2200::2201. Exit character is '^]'. FreeBSD/i386 (freebsd2.force10networks.com) (ttyp1) login: admin Force10#

telnet-peer-rpm

telnet [ipv4-address |

ipv6-address]

EXEC Privilege

Lock CONFIGURATION mode

FTOS allows multiple users to make configurations at the same time. You can lock CONFIGURATION mode so that only one user can be in CONFIGURATION mode at any time (Message 2).

74 | System Management

A two types of locks can be set: auto and manual.

• Set an auto-lock using the command

configuration mode exclusive auto from CONFIGURATION

mode. When you set an auto-lock, every time a user is in CONFIGURATION mode all other users are denied access. This means that you can exit to EXEC Privilege mode, and re-enter CONFIGURATION mode without having to set the lock again.

• Set a manual lock using the command

configure terminal lock from CONFIGURATION mode. When

you configure a manual lock, which is the default, you must enter this command time you want to enter CONFIGURATION mode and deny access to others.

Figure 4-9. Locking CONFIGURATION mode

R1(conf)#configuration mode exclusive auto BATMAN(conf)#exit 3d23h35m: %RPM0-P:CP %SYS-5-CONFIG_I: Configured from console by console

R1#config ! Locks configuration mode exclusively. R1(conf)#

If another user attempts to enter CONFIGURATION mode while a lock is in place, Message 1 appears on their terminal.

Message 1 CONFIGURATION mode Locked Error

% Error: User "" on line console0 is in exclusive configuration mode

If any user is already in CONFIGURATION mode when while a lock is in place, Message 2 appears on their terminal.

Message 2 Cannot Lock CONFIGURATION mode Error

% Error: Can't lock configuration mode exclusively since the following users are currently configuring the system: User "admin" on line vty1 ( 10.1.1.1 )

Note: The CONFIGURATION mode lock corresponds to a VTY session, not a user. Therefore, if you configure a lock and then exit CONFIGURATION mode, and another user enters CONFIGURATION

mode, when you attempt to re-enter CONFIGURATION mode, you are denied access even though you

are the one that configured the lock.

Note: If your session times out and you return to EXEC mode, the CONFIGURATION mode lock is unconfigured.

Viewing the Configuration Lock Status

If you attempt to enter CONFIGURATION mode when another user has locked it, you may view which user has control of CONFIGURATION mode using the command Privilege mode.

show configuration lock from EXEC

System Management | 75

You can then send any user a message using the send command from EXEC Privilege mode. Alternatively you can clear any line using the command

clear from EXEC Privilege mode. If you clear a console session,

the user is returned to EXEC mode.

Recovering from a Forgotten Password

If you configure authentication for the console and you exit out of EXEC mode or your console session times out, you are prompted for a password to re-enter.

If you forget your password:

www.dell.com | support.dell.com

Step Task Command Syntax Command Mode

1 Log onto the system via console. 2 Power-cycle the chassis by switching off all of the power modules and then switching them back on. 3 Abort bootup by sending the break

signal when prompted.

Figure 4-10. Entering BOOT_USER mode

Type "go 0x00040004" to enter the Force10 BLI shell You can use U-boot native networking facilities ============================================================

Hit any key to stop autoboot: 0 Starting F10 BLI Shell ...

BOOT_USER # enable admin Password : XXXXXXXXX RPM0-CP BOOT_ADMIN #

4 Enter BOOT_ADMIN mode using

the command

ncorerulz when prompted for a

enable admin. Enter

password.

Ctrl+Shift+6

enable admin BOOT_USER

Figure 4-11. Entering BOOT_ADMIN mode

***** Welcome to Force10 Boot Interface ***** Use "help" or "?" for more information. BOOT_USER # enable admin Password : XXXXXXXXX RPM0-CP BOOT_ADMIN #

5 Rename the startup-config so it does

not load on the next system reload.

6 Verify that startup-config is renamed. dir flash: BOOT_ADMIN

76 | System Management

rename :flash://startup-config flash:// startup-config.bak

BOOT_ADMIN

Step Task Command Syntax Command Mode

Figure 4-12. Renaming the startup-config

RPM0-CP BOOT_ADMIN # dir flash: Directory of flash: 1 -rwx 11407411 Jun 09 2004 09:38:40 FTOS-EE3-5.3.1.1.bin 2 -rwx 4977 Jun 09 2004 09:38:38 startup-config.bak

7 Reload the system. reload BOOT_ADMIN 8 Copy startup-config.bak to the

running config.

9 Remove all authentication statements

you might have for the console.

copy flash://startup-config.bak running-config

no authentication login no password

EXEC Privilege

LINE

10 Save the running-config. copy running-config startup-config EXEC Privilege

Recovering from a Forgotten Enable Password

If you forget the enable password:

Step Task Command Syntax Command Mode

1 Log onto the system via console. 2 Eject the secondary RPM if there is one. 3 Power-cycle the chassis by switching off all of the power modules and then switching them back on. 4 Abort bootup by sending the break

signal when prompted. See

Figure 4-10.

5 Configure the system to ignore the

enable password on bootup. Note: This command only bypasses the enable password once. You must repeat this procedure to bypass it again.

Ctrl+Shift+6

ignore enable-password BOOT_USER

Figure 4-13. Ignoring the Enable Password

***** Welcome to Force10 Boot Interface ***** Use "help" or "?" for more information. BOOT_USER # ignore enable-password

6 Reload the system. reload BOOT_USER 7 Configure a new enable password. enable {secret | password} CONFIGURATION 8 Insert the secondary RPM.

System Management | 77

Step Task Command Syntax Command Mode

9 Save the running-config to the

startup-config. The startup-config files on both RPMs will be synchronized.

Recovering from a Forgotten Password on S-Series

If you configure authentication for the console and you exit out of EXEC mode or your console session times out, you are prompted for a password to re-enter.

www.dell.com | support.dell.com

If you forget your password:

Step Task Command Syntax Command Mode

1 Log onto the system via console. 2 Power-cycle the chassis by unplugging the power cord. 3 Abort bootup by sending the break

signal when prompted.

Figure 4-14. Entering BOOT_USER mode

Type "go 0x00040004" to enter the Force10 BLI shell You can use U-boot native networking facilities ============================================================

copy running-config startup-config EXEC Privilege

(any key)

***** Welcome to Force10 Boot Interface ***** Use "help" or "?" for more information. BOOT_USER #

4 Configure the system to ignore the

ignore startup-config BOOT_USER

startup-config, which prevents the system from prompting you for a password to enter EXEC mode. Note: This command only bypasses the password once. You must repeat this procedure to bypass it again.

5 Remove all authentication statements

no authentication login CONFIGURATION

you might have for the console.

6 Reload the system. reload BOOT_USER

78 | System Management

Recovering from a Failed Start

A system that does not start correctly might be attempting to boot from a corrupted FTOS image or from a incorrect location. To resolve the problem, you can restart the system and interrupt the boot process to point the system to another boot location by using the details on the

boot change command, its supporting commands, and other commands that can help recover

from a failed start, refer to the BOOT_USER chapter in the FTOS Command Reference.

Step Task Command Syntax Command Mode

1 Power-cycle the chassis (pull the power cord and reinsert it).

boot change command, as described below. For

2 Abort bootup by sending the break

signal when prompted.

3 Tell the system where to access the

FTOS image used to boot the system:

• Enter primary to configure the boot parameters used in the first attempt to boot the system.

• Enter secondary for when the primary operating system boot selection is not available.

• Enter default to configure boot parameters used if the secondary operating system boot parameter selection is not available. The default location should always be the internal flash device (flash:), and a verified image should be stored there.

4 On S-Series systems only, assign a port

to be the Management Ethernet interface.

5 Assign an IP address to the

Management Ethernet interface.

6 (OPTIONAL) On C- and E-Series

systems only, configure speed, duplex, and negotiation settings for the management interface.

Ctrl-Shift 6 (Ctrl-^)—C-Series and E-Series (On the S-Series, hit any key)

boot change {primary | secondary | default} After entering the keywords and desired option, press Enter. The software prompts you to enter the following:

• boot device (ftp, tftp, flash, slot0) Note: S-Series can only use a TFTP location.

• image file name

• IP address of the server with the image

• username and password (only for FTP)

interface management ethernet port portID BOOT_USER

[no] interface management ethernet ip

address ip-address mask interface management port config

{half-duplex | full-duplex | 10m | 100m |

auto-negotiation | no auto-negotiation | show}

(during bootup)

BOOT_USER

7 Assign an IP address as the default

gateway for the system.

8 Reload the system. reload BOOT_USER

[no] default-gateway ip-address BOOT_USER

System Management | 79

Very similar to the options of the boot change command, the boot system command is available in

CONFIGURATION mode on the C-Series and E-Series to set the boot parameters that, when saved to the

startup configuration file, are stored in NVRAM and are then used routinely:

Task Command Syntax Command Mode

Configure the system to routinely boot from the designated location.

After entering rpm0 or rpm1, enter one of the three keywords and then the

file-url.

You can use the command for each of the combinations of RPM and option.

www.dell.com | support.dell.com

Also, because the C-Series and E-Series can boot from an external flash, you can recover from a failed boot image on the flash by simply fixing that source. For details on boot code and FTOS setup, see the FTOS Release Notes for the specific FTOS versions that you want to use.

The network boot facility has only become available on the S-Series with FTOS 7.8.1.0 and its accompanying boot code. In addition to installing FTOS 7.8.1.0, you must separately install that new boot code. For installation details, see the S-Series and FTOS Release Notes for Version 7.8.1.0.

boot system {rpm0 | rpm1} (default | primary | secondary} file-url

For file-url, to boot from a file:

• on the internal Flash, enter followed by the filename.

• on an FTP server, enter

flash://

ftp://

user:password@hostip/filepath

• on the external Flash, enter slot0:// followed by the filename.

• on a TFTP server, enter tftp://hostip/

filepath

CONFIGURATION

80 | System Management

802.1ag

802.1ag is available only on platform: s

Ethernet Operations, Administration, and Maintenance (OAM) is a set of tools used to install, monitor, troubleshoot and manage Ethernet infrastructure deployments. Ethernet OAM consists of three main areas:

1. Service Layer OAM: IEEE 802.1ag Connectivity Fault Management (CFM)

2. Link Layer OAM: IEEE 802.3ah OAM

3. Ethernet Local management Interface (MEF-16 E-LMI)

Ethernet CFM

Ethernet CFM is an end-to-end, per-service-instance Ethernet OAM scheme which enables: proactive connectivity monitoring, fault verification, and fault isolation.

The service-instance in the OAM for Metro/Carrier Ethernet context is a VLAN. This service is sold to an end-customer by a network service provider. Typically the service provider contracts with multiple network operators to provide end-to-end service between customers. For end-to-end service between customer switches, connectivity must be present across the service provider through multiple network operators.

Layer 2 Ethernet networks usually cannot be managed with IP tools such as ICMP Ping and IP Traceroute. Traditional IP tools often fail because:

• there are complex interactions between various Layer 2 and Layer 3 protocols such as STP, LAG, VRRP and ECMP configurations.

• Ping and traceroute are not designed to verify data connectivity in the network and within each node in the network (such as in the switching fabric and hardware forwarding tables).

• when networks are built from different operational domains, access controls impose restrictions that cannot be overcome at the IP level, resulting in poor fault visibility. There is a need for hierarchical domains that can be monitored and maintained independently by each provider or operator.

• routing protocols choose a subset of the total network topology for forwarding, making it hard to detect faults in links and nodes that are not included in the active routing topology. This is made more complex when using some form of Traffic Engineering (TE) based routing.

• network and element discovery and cataloging is not clearly defined using IP troubleshooting tools.

802.1ag | 81

There is a need for Layer 2 equivalents to manage and troubleshoot native Layer 2 Ethernet networks. With these tools, you can identify, isolate, and repair faults quickly and easily, which reduces operational cost of running the network. OAM also increases availability and reduces mean time to recovery, which allows for tighter service level agreements, resulting in increased revenue for the service provider.

In addition to providing end-to-end OAM in native Layer 2 Ethernet Service Provider/Metro networks, you can also use CFM to manage and troubleshoot any Layer 2 network including enterprise, datacenter, and cluster networks.

Maintenance Domains

www.dell.com | support.dell.com

Connectivity Fault Management (CFM) divides a network into hierarchical maintenance domains, as shown in Figure 5-1.

A CFM maintenance domain is a management space on a network that is owned and operated by a single management entity. The network administrator assigns a unique maintenance level (0 to 7) to each domain to define the hierarchical relationship between domains. Domains can touch or nest but cannot overlap or intersect as that would require management by multiple entities.

Figure 5-1. OAM Domains

Customer Network

Ethernet Access

Operator Domain (5)

Service Provider Network

MPLS Core MPLS Access

Customer Domain (7)

Provider Domain (6)

)

omain (

ain (5

Operator Dom

PLS D

erator Do

Customer Network

main (5)

Maintenance Points

Domains are comprised of logical entities called Maintenance Points. A maintenance point is an interface demarcation that confines CFM frames to a domain. There are two types of maintenance points:

• Maintenance End Points (MEPs): a logical entity that marks the end-point of a domain

• Maintenance Intermediate Points (MIPs): a logical entity configured at a port of a switch that is an intermediate point of a Maintenance Entity (ME). An ME is a point-to-point relationship between two MEPs within a single domain. MIPs are internal to a domain, not at the boundary, and respond to CFM only when triggered by linktrace and loopback messages. MIPs can be configured to snoop Continuity Check Messages (CCMs) to build a MIP CCM database.

82 | 802.1ag

These roles define the relationships between all devices so that each device can monitor the layers under its responsibility. Maintenance points drop all lower-level frames and forward all higher-level frames.

Figure 5-2. Maintenance Points

Customer Network

Service Provider Network

Customer Network

Ethernet Access

Operator Domain (5)

MEP

Maintenance End Points

A Maintenance End Point (MEP) is a logical entity that marks the end-point of a domain. There are two types of MEPs defined in 802.1ag for an 802.1 bridge:

• Up-MEP: monitors the forwarding path internal to an bridge on the customer or provider edge; on Dell Force10 systems the internal forwarding path is effectively the switch fabric and forwarding engine.

• Down-MEP: monitors the forwarding path external another bridge.

Configure Up- MEPs on ingress ports, ports that send traffic towards the bridge relay. Configure Down-MEPs on egress ports, ports that send traffic away from the bridge relay.

MPLS Core MPLS Access

Customer Domain (7)

Provider Domain (6)

ator Dom

per

MPLS Domain (4)

MIP

ain (5)

Operator Domain (5)

Figure 5-3. Up-MEP versus Down-MEP

Customer Network

towards relay

Up-MEP

Down-MEP

away from relay

Service Provider Ethernet Access

802.1ag | 83

Implementation Information

• Since the S-Series has a single MAC address for all physical/LAG interfaces, only one MEP is allowed per MA (per VLAN or per MD level).

Configure CFM

Configuring CFM is a five-step process:

1. Configure the ecfmacl CAM region using the

www.dell.com | support.dell.com

Sub-partitions.

2. Enable Ethernet CFM. See page 85.

3. Create a Maintenance Domain. See page 85.

4. Create a Maintenance Association. See page 86.

5. Create Maintenance Points. See page 86.

6. Use CFM tools: a Continuity Check Messages on page 89 b Loopback Message and Response on page 90 c Linktrace Message and Response on page 90

Related Configuration Tasks

• Enable CFM SNMP Traps. on page 92

• Display Ethernet CFM Statistics on page 93

cam-acl command. See Configure Ingress Layer 2 ACL

84 | 802.1ag

Enable Ethernet CFM

Task Command Syntax Command Mode

Spawn the CFM process. No CFM configuration is allowed until the CFM process is spawned.

Disable Ethernet CFM without stopping the CFM process.

ethernet cfm

disable

CONFIGURATION

ETHERNET CFM

Create a Maintenance Domain

Connectivity Fault Management (CFM) divides a network into hierarchical maintenance domains, as shown in Figure 5-1.

Step Task Command Syntax Command Mode

1 Create maintenance domain. domain name md-level number

Range: 0-7

2 Display maintenance domain information. show ethernet cfm domain [name |

brief]

Force10# show ethernet cfm domain

Domain Name: customer Level: 7 Total Service: 1 Services MA-Name VLAN CC-Int X-CHK Status

My_MA 200 10s enabled

Domain Name: praveen Level: 6 Total Service: 1 Services MA-Name VLAN CC-Int X-CHK Status

Your_MA 100 10s enabled

ETHERNET CFM

EXEC Privilege

802.1ag | 85

Create a Maintenance Association

A Maintenance Association MA is a subdivision of an MD that contains all managed entities corresponding to a single end-to-end service, typically a VLAN. An MA is associated with a VLAN ID.

Task Command Syntax Command Mode

Create maintenance association. service name vlan vlan-id ECFM DOMAIN

Create Maintenance Points

www.dell.com | support.dell.com

Domains are comprised of logical entities called Maintenance Points. A maintenance point is a interface demarcation that confines CFM frames to a domain. There are two types of maintenance points:

• Maintenance End Points (MEPs): a logical entity that marks the end-point of a domain

• Maintenance Intermediate Points (MIPs): a logical entity configured at a port of a switch that constitutes intermediate points of an Maintenance Entity (ME). An ME is a point-to-point relationship between two MEPs within a single domain.

These roles define the relationships between all devices so that each device can monitor the layers under its responsibility.

Create a Maintenance End Point

A Maintenance End Point (MEP) is a logical entity that marks the end-point of a domain. There are two types of MEPs defined in 802.1ag for an 802.1 bridge:

• Down-MEP: monitors the forwarding path external another bridge.

Configure Up- MEPs on ingress ports, ports that send traffic towards the bridge relay. Configure Down-MEPs on egress ports, ports that send traffic away from the bridge relay.

Task Command Syntax Command Mode

Create an MEP. ethernet cfm mep {up-mep | down-mep} domain {name |

level

} ma-name name mepid mep-id

Range: 1-8191

Display configured MEPs and MIPs.

show ethernet cfm maintenance-points local [mep | mip] EXEC Privilege

INTERFACE

86 | 802.1ag

Task Command Syntax Command Mode

Force10#show ethernet cfm maintenance-points local mep

------------------------------------------------------------------------------MPID Domain Name Level Type Port CCM-Status MA Name VLAN Dir MAC

-------------------------------------------------------------------------------

100 cfm0 7 MEP Gi 4/10 Enabled test0 10 DOWN 00:01:e8:59:23:45

200 cfm1 6 MEP Gi 4/10 Enabled test1 20 DOWN 00:01:e8:59:23:45

300 cfm2 5 MEP Gi 4/10 Enabled test2 30 DOWN 00:01:e8:59:23:45

Create a Maintenance Intermediate Point

Maintenance Intermediate Point (MIP) is a logical entity configured at a port of a switch that constitutes intermediate points of an Maintenance Entity (ME). An ME is a point-to-point relationship between two MEPs within a single domain. An MIP is not associated with any MA or service instance, and it belongs to the entire MD.

Task Command Syntax Command Mode

Create an MIP. ethernet cfm mip domain {name | level} ma-name name INTERFACE Display configured MEPs and

MIPs.

Force10#show ethernet cfm maintenance-points local mip

------------------------------------------------------------------------------MPID Domain Name Level Type Port CCM-Status MA Name VLAN Dir MAC

-------------------------------------------------------------------------------

0 service1 4 MIP Gi 0/5 Disabled My_MA 3333 DOWN 00:01:e8:0b:c6:36

0 service1 4 MIP Gi 0/5 Disabled Your_MA 3333 UP 00:01:e8:0b:c6:36

show ethernet cfm maintenance-points local [mep | mip] EXEC Privilege

MP Databases

CFM maintains two MP databases:

• MEP Database (MEP-DB): Every MEP must maintain a database of all other MEPs in the MA that have announced their presence via CCM.

802.1ag | 87

• MIP Database (MIP-DB): Every MIP must maintain a database of all other MEPs in the MA that have announced their presence via CCM

Task Command Syntax Command Mode

Display the MEP Database.

Force10#show ethernet cfm maintenance-points remote detail

MAC Address: 00:01:e8:58:68:78 Domain Name: cfm0 MA Name: test0 Level: 7

www.dell.com | support.dell.com

VLAN: 10 MP ID: 900 Sender Chassis ID: Force10 MEP Interface status: Up MEP Port status: Forwarding Receive RDI: FALSE MP Status: Active

Display the MIP Database.

MP Database Persistence

Task Command Syntax Command Mode

Set the amount of time that data from a missing MEP is kept in the Continuity Check Database.

show ethernet cfm maintenance-points remote detail [active

| domain {level | name} | expired | waiting]

show ethernet cfm mipdb

database hold-time minutes

Default: 100 minutes Range: 100-65535 minutes

EXEC Privilege

ECFM DOMAIN

88 | 802.1ag

Continuity Check Messages

Continuity Check Messages (CCM) are periodic hellos used to:

• discover MEPs and MIPs within a maintenance domain

• detect loss of connectivity between MEPs

• detect misconfiguration, such as VLAN ID mismatch between MEPs

• to detect unauthorized MEPs in a maintenance domain

Continuity Check Messages (CCM) are multicast Ethernet frames sent at regular intervals from each MEP. They have a destination address based on the MD level (01:80:C2:00:00:3X where X is the MD level of the transmitting MEP from 0 to 7). All MEPs must listen to these multicast MAC addresses and process these messages. MIPs may optionally processes the CCM messages originated by MEPs and construct a MIP CCM database.

MEPs and MIPs filter CCMs from higher and lower domain levels as described in Table 5-1.

Table 5-1. Continuity Check Message Processing

Frames at Frames from UP-MEP Action Down-MEP Action MIP Action

Less than my level Bridge-relay side or Wire side Drop Drop Drop My level Bridge-relay side Consume Drop Add to MIP-DB

Wire side Drop Consume

Greater than my level Bridge-relay side or Wire side Forward Forward Forward

and forward

All the remote MEPs in the maintenance domain are defined on each MEP. Each MEP then expects a periodic CCM from the configured list of MEPs. A connectivity failure is then defined as:

1. Loss of 3 consecutive CCMs from any of the remote MEP, which indicates a network failure

2. Reception of a CCM with an incorrect CCM transmission interval, which indicates a configuration error.

3. Reception of CCM with an incorrect MEP ID or MAID, which indicates a configuration or cross-connect error. This could happen when different VLANs are cross-connected due to a configuration error.

4. Reception of a CCM with an MD level lower than that of the receiving MEP, which indicates a configuration or cross-connect error.

5. Reception of a CCM containing a port status/interface status TLV, which indicates a failed bridge or aggregated port.

The Continuity Check protocol sends fault notifications (Syslogs, and SNMP traps if enabled) whenever any of the above errors are encountered.

802.1ag | 89

Enable CCM

Step Task Command Syntax Command Mode

1 Enable CCM.

2 Configure the transmit interval (mandatory).

The interval specified applies to all MEPs in the domain.

Enable Cross-checking

www.dell.com | support.dell.com

Task Command Syntax Command Mode

Enable cross-checking.

Start the cross-check operation for an MEP. Configure the amount of time the system waits for a

remote MEP to come up before the cross-check operation is started.

Loopback Message and Response

no ccm disable

Default: Disabled

ccm transmit-interval seconds

Default: 10 seconds

mep cross-check enable

Default: Disabled

mep cross-check mep-id

mep cross-check start-delay

number

ECFM DOMAIN

ETHERNET CFM

ETHERNET CFM ETHERNET CFM

Loopback Message and Response (LBM, LBR), also called Layer 2 Ping, is an administrative echo transmitted by MEPs to verify reachability to another MEP or MIP within the maintenance domain. LBM and LBR are unicast frames.

Task Command Syntax Command Mode

Send a Loopback message. ping ethernet domain name ma-name ma-name remote

{mep-id | mac-addr mac-address} source {mep-id | port

interface}

EXEC Privilege

Linktrace Message and Response

Linktrace Message and Response (LTM, LTR), also called Layer 2 Traceroute, is an administratively sent multicast frames transmitted by MEPs to track, hop-by-hop, the path to another MEP or MIP within the maintenance domain. All MEPs and MIPs in the same domain respond to an LTM with a unicast LTR. Intermediate MIPs forward the LTM toward the target MEP.

90 | 802.1ag

Figure 5-4. Linktrace Message and Response

MPLS Core

MEP

MIP MIP

MIP

Link trace messages carry a unicast target address (the MAC address of an MIP or MEP) inside a multicast frame. The destination group address is based on the MD level of the transmitting MEP (01:80:C2:00:00:3[8 to F]). The MPs on the path to the target MAC address reply to the LTM with an LTR, and relays the LTM towards the target MAC until the target MAC is reached or TTL equals 0.

Task Command Syntax Command Mode

Send a Linktrace message. Since the LTM is a Multicast message sent to the entire ME, there is no need to specify a destination.

traceroute ethernet domain

EXEC Privilege

Link Trace Cache

After a Link Trace command is executed, the trace information can be cached so that you can view it later without retracing.

Task Command Syntax Command Mode

Enable Link Trace caching. Set the amount of time a trace result is cached. traceroute cache hold-time minutes

Set the size of the Link Trace Cache. traceroute cache size entries

Display the Link Trace Cache.

traceroute cache

Default: 100 minutes Range: 10-65535 minutes

Default: 100 Range: 1 - 4095 entries

show ethernet cfm traceroute-cache

CONFIGURATION ETHERNET CFM

ETHERNET CFM

EXEC Privilege

802.1ag | 91

Task Command Syntax Command Mode

Force10#show ethernet cfm traceroute-cache

Traceroute to 00:01:e8:52:4a:f8 on Domain Customer2, Level 7, MA name Test2 with VLAN 2

----------------------------------------------------------------------------- Hops Host IngressMAC Ingr Action Relay Action Next Host Egress MAC Egress Action FWD Status

------------------------------------------------------------------------------

4 00:00:00:01:e8:53:4a:f8 00:01:e8:52:4a:f8 IngOK RlyHit 00:00:00:01:e8:52:4a:f8 Terminal MEP

www.dell.com | support.dell.com

Delete all Link Trace Cache entries.

Enable CFM SNMP Traps.

Task Command Syntax Command Mode

clear ethernet cfm traceroute-cache

EXEC Privilege

Enable SNMP trap messages for Ethernet CFM.

A Trap is sent only when one of the five highest priority defects occur, as shown in Table 5-2.

Table 5-2. ECFM SNMP Traps

%ECFM-5-ECFM_XCON_ALARM: Cross connect fault detected by MEP 1 in Domain customer1

Cross-connect defect Error-CCM defect MAC Status defect Remote CCM defect RDI defect

at Level 7 VLAN 1000 %ECFM-5-ECFM_ERROR_ALARM: Error CCM Defect detected by MEP 1 in Domain customer1

at Level 7 VLAN 1000 %ECFM-5-ECFM_MAC_STATUS_ALARM: MAC Status Defect detected by MEP 1 in Domain

provider at Level 4 VLAN 3000 %ECFM-5-ECFM_REMOTE_ALARM: Remote CCM Defect detected by MEP 3 in Domain customer1

at Level 7 VLAN 1000 %ECFM-5-ECFM_RDI_ALARM: RDI Defect detected by MEP 3 in Domain customer1 at Level

7 VLAN 1000

snmp-server enable traps ecfm

CONFIGURATION

92 | 802.1ag

Three values are given within the trap messages: MD Index, MA Index, and MPID. You can reference these values against the output of

local mep

Force10#show ethernet cfm maintenance-points local mep

------------------------------------------------------------------------------MPID Domain Name Level Type Port CCM-Status MA Name VLAN Dir MAC

-------------------------------------------------------------------------------

100 cfm0 7 MEP Gi 4/10 Enabled test0 10 DOWN 00:01:e8:59:23:45

Force10(conf-if-gi-0/6)#do show ethernet cfm domain

Domain Name: My_Name

MD Index: 1

Level: 0 Total Service: 1 Services

MA-Index MA-Name VLAN CC-Int X-CHK Status

1 test 0 1s enabled

Domain Name: Your_Name MD Index: 2 Level: 2 Total Service: 1 Services

MA-Index MA-Name VLAN CC-Int X-CHK Status

1 test 100 1s enabled

show ethernet cfm domain and show ethernet cfm maintenance-points

Display Ethernet CFM Statistics

Task Command Syntax Command Mode

Display MEP CCM statistics. show ethernet cfm statistics [domain {name | level}

vlan-id

vlan-id mpid mpid

Force10# show ethernet cfm statistics

Domain Name: Customer Domain Level: 7 MA Name: My_MA MPID: 300

CCMs: Transmitted: 1503 RcvdSeqErrors: 0 LTRs: Unexpected Rcvd: 0 LBRs: Received: 0 Rcvd Out Of Order: 0 Received Bad MSDU: 0 Transmitted: 0

EXEC Privilege

802.1ag | 93

Task Command Syntax Command Mode

Display CFM statistics by port. show ethernet cfm port-statistics [interface] EXEC Privilege

Force10#show ethernet cfm port-statistics interface gigabitethernet 0/5 Port statistics for port: Gi 0/5 ==================================

RX Statistics ============= Total CFM Pkts 75394 CCM Pkts 75394 LBM Pkts 0 LTM Pkts 0 LBR Pkts 0 LTR Pkts 0 Bad CFM Pkts 0 CFM Pkts Discarded 0

www.dell.com | support.dell.com

CFM Pkts forwarded 102417

TX Statistics ============= Total CFM Pkts 10303 CCM Pkts 0 LBM Pkts 0 LTM Pkts 3 LBR Pkts 0 LTR Pkts 0

94 | 802.1ag

802.3ah

802.3ah is available only on platform: s

A metropolitan area network (MAN) is a set of LANs, geographically separated but managed by a single entity. If the distance is large—across a city, for example—connectivity between LANs is managed by a service provider. While LANs use Ethernet, service providers networks use an array of protocols (PPP and ATM), and a variety access technologies. Implementing Ethernet from end to end, across the service provider network, simplifies design and management, increases scalability and bandwidth, and reduces costs.

Ethernet in a service provider environment introduces the concept of Carrier-class Ethernet and requires some basic management and diagnostic tools. Ethernet Operations, Administration, and Maintenance (OAM) is that toolset, which can be used to install, monitor, troubleshoot, and manage Ethernet infrastructure deployments. It consists of three main areas:

1. Service Layer OAM: IEEE 802.1ag, Connectivity Fault Management (CFM)

2. Link Layer OAM: IEEE 802.3ah, Ethernet in the First Mile (EFM) OAM

3. Ethernet Local management Interface (MEF-16 E-LMI)

Link Layer OAM Overview

Link Layer OAM introduces the toolset required to effectively monitor the link between the customer and service provider, which is called the first mile. Currently, service providers use a variety of access technologies including ISDN, DSL, and coax cable in the first mile. Implementing Ethernet here reduces the types of equipment in the subscriber access network, simplifying installation and management, and increasing bandwidth.

Link Layer OAM performs four primary operations for the purposes of link status, performance monitoring, and fault detection and isolation for Ethernet in the First Mile:

• OAM Discovery—detects whether the remote system is OAM capable, and negotiates OAM parameters.

• Link Event Monitoring—defines a set of events that may impact link operation, and monitors the link for those events.

802.3ah | 95

• Remote Loopback—directs the remote system to reflects back frames that the local system transmits so that an administrator can isolate a fault.

• Remote Failure Indication—notifies a peer of a critical link event.

Link Layer OAMPDUs

Link Layer OAM is conducted using OAMPDUs, shown in Figure 6-1. OAM is a slow protocol and by requirement may transmit no more than 10 frames per second, transmits to a multicast destination MAC, and uses an Ethernet subtype.

Figure 6-1. OAMPFU Frame Format

www.dell.com | support.dell.com

00: Information 01: Event Notification 02: Variable Request 03: Variable Response

04: Loopback Control 05-FD: Reserved FE: Organization Specific FF: Reserved

Destination MAC (01-80-c2-00-00-02)

Slow Protocol multicast address

Source MAC

Length/Type (0x8809)

Sub-type (0x03)

Slow Protocols use a subtype

0: Link Fault 1: Dying Gasp 2: Critical Event 3: Local Evaluating

Flags Code

Payload (TLVs)

4: Local Stable 5: Remote Evaluating 6: Remote Stable 7-15: Reserved

Padding

FCS

There are six OAMPDU types, identified by the Code field:

• Information—carries state information and Local Information and/or Remote Information TLVs. Information OAMPDUs are used in discovery, and as keepalives.

• Local Information TLVs—indicates support for variable retrieval, link performance events, and

remote loopback, unidirectional support, and OAM mode

• Remote Information TLVs—a copy of the peer’s Local Information TLV.

• Event Notification—carries TLVs for each concurrent link fault.

• Variable Request—carries MIB object descriptors for which the remote peer should return values.

• Variable Response—carries the requested MIB object values.

• Loopback Control—carries the loopback control command (enable and disable).

• Organization Specific—contains and OUI followed by data, the format and function of which is defined by the organization.

OAMPDU Flags

1-bit flags are used it indicate OAM state and link state. During discovery, flags 3-6 are used to indicate the state of peership establishment. Flags 0-2 are used to indicate a local critical link event to the remote peer.

96 | 802.3ah

Link Layer OAM Operational Modes

When participating in EFM OAM, system may operate in active or passive mode.

• Active mode—Active mode systems initiate discovery. Once the Discovery process completes, they can send any OAMPDU while connected to a peer in Active mode, and a subset of OAMPDUs if the peer is in Passive mode (see Table 6-1).

• Passive mode—Passive mode systems wait for an active mode system to initiate discovery, and do not send Variable Request or Loopback Control OAMPDUs.

Taken from IEEE 802.3ah, Table 6-1 summarizes the permitted actions in each role.

Table 6-1. Active Mode and Passive Mode Behaviors

Capability Active Passive

Initiates OAM Discovery process Yes No Reacts to OAM Discovery process initiation Yes Yes Required to send Information OAMPDUs Yes Yes Permitted to send Event Notification OAMPDUs Yes Yes Permitted to send Variable Request OAMPDUs Yes No Permitted to send Variable Response OAMPDUs (the peer must be in Active mode) Yes Yes Permitted to send Loopback Control OAMPDUs Yes No Reacts to Loopback Control OAMPDUs (the peer must be in Active mode) Yes Yes Permitted to send Organization Specific OAMPDUs Yes Yes

Link Layer OAM Discovery

OAM Discovery is the mechanism a Link Layer OAM-capable system uses to determine if the remote system on the link has OAM functionality enabled. OAM Discovery ascertains OAM parameters, such as maximum allowable OAMPDU size, and supported functions such as OAM remote loopback.

The discovery process is as follows:

1. If the link is not in Fault state, Active mode systems send Information OAMPDUs that contain (only) the Local Information TLV.

2. Once a system receives an Information OAMPDU, it responds with an Information OAMPDU that contains the Local and Remote Information TLV. Negotiation is complete when both systems have received their peer’s information and are satisfied with it; to be satisfied, both peers on the link must be have link performance event monitoring enabled.

3. When negotiation is complete, both peers may send any type of OAMPDU.

802.3ah | 97

Link Layer OAM Events

Link Layer OAM defines a set of events that may impact link operation, and monitors the link for those events. If an event occurs, the detecting system notifies its peer. There are two types of events:

• Critical Link Events—There are three critical events; each has an associated flag which can be set in the OAMPDU when the event occurs. Critical link events are communicated to the peer using Remote Failure Indication.

• Link Fault—A fault occurred in the receive direction of the local peer.

• Dying Gasp—An unrecoverable local failure condition occurred. Dying Gasp notification is not

supported on S-Series.

• Critical Event—An unspecified critical event occurred. Critical Event notification is not

www.dell.com | support.dell.com

• Link Performance Events—Link events are either symbol errors or frame errors, and are

supported on S-Series.

communicated using Link Event TLVs.

• Symbol Errors—a symbol is an (electrical or optical) pulse on the physical medium that

represents one or more bits. A symbol error occurs when a symbol degrades in transit so that the receiver is not able to decode it. Gigabit and 10-Gigabit Ethernet have and expect symbol rate, also called Baud.

• Frame Errors—frame errors are frames with a bad CRC.

Remote Loopback

An active-mode device can place a passive peer into loopback mode by sending a Loopback Control OAMPDU. When in loopback mode:

• the remote peer returns unaltered all non-OAMPDU frames sent by the local peer, and

• all outbound data frames are discarded (control frames are still forwarded).

Implementation Information

• Critical Link Events Dying Gasp and Critical Event are not supported.

• MIB retrieval is not supported.

• Both peers on a link must have Link Performance Monitoring Enabled, or else discovery does not complete.

• Control frames are still forwarded when an interface is in loopback mode.

98 | 802.3ah

Configure Link Layer OAM

Configuring Link Layer OAM is a two-step process:

1. Enable Link Layer OAM. See page 99.

2. Enable any or all of the following: a Link Performance Event Monitoring on page 101 b Remote Failure Indication on page 104 c Remote Loopback on page 105

Related Configuration Tasks

• Adjust the OAMPDU Transmission Parameters on page 101

• Display Link Layer OAM Configuration and Statistics on page 106

• Manage Link Layer OAM on page 108

Enable Link Layer OAM

Link Layer OAM is disabled by default. Enabling it places the system in Active mode and initiates OAM discovery.Both peers on the link must be have link performance event monitoring enabled for discovery to complete.

Task Command Syntax Command Mode

Enable Ethernet OAM.

Display the OAM discovery status. show ethernet oam discovery interface interface EXEC Privilege

ethernet oam

Default: Disabled

INTERFACE

802.3ah | 99

Task Command Syntax Command Mode

Force10# show ethernet oam discovery interface <interface-name> Output format: <interface name>

Local client __________ Administrative configurations: Mode:active Unidirection:not supported Link monitor:supported (on) Remote loopback:not supported MIB retrieval:not supported Mtu size:1500 Operational status:

www.dell.com | support.dell.com

Port status:operational Loopback status:no loopback PDU permission:any PDU revision:1

Remote client ___________ MAC address:0030.88fe.87de Vendor(OUI):0x00 0x00 0x0C

Administrative configurations: Mode:active Unidirection:not supported Link monitor:supported Remote loopback:not supported MIB retrieval:not supported Mtu size:1500

Display Link Layer OAM sessions.

Force10# show ethernet oam summary

Output format :

Symbols:* - Master Loopback State, # - Slave Loopback State Capability codes:L - Link Monitor, R - Remote Loopback U - Unidirection,V - Variable Retrieval

LocalRemote InterfaceMAC AddressOUIModeCapability Gi6/1/10023.84ac.b8000000DactiveL R

show ethernet oam summary

EXEC Privilege

100 | 802.3ah

Dell Force10 S25, Force10 S50 Configuration manual

Specifications and Main Features

Frequently Asked Questions

User Manual

About this Guide
