Dell 6YCRT Product Data Sheet

OptiPlex 3040

Essential business-class computing

OptiPlex 3040 simplifies business computing with best-in-class security and
manageability in new, smaller energy-ecient designs-Mini Tower, Small Form
Factor and Micro Form Factor.

Available with up to 6th Gen Intel® Core™ i5 Processors, Intel® Integrated graphics,
and Dell Client Command Suite tools for time-saving systems management,
OptiPlex 3040 provides excellent value at an entry-level price.

Enhance these features with purpose-built Dell accessories such as award winning
monitors, custom-designed cable covers, and a variety of Micro mounts for a
complete computing experience; all backed by outstanding 24x7 ProSupport Plus.

For more information visit:

www.dell.com

Feature 3040 MT/SFF/Micro Technical Specifications

Processors

Chipset Intel® H110 Chipset

1

Intel® 6th generation Core™ i5 Quad Core (65W for MT & SFF, 35W for micro), Core™ i3 Dual Core, Pentium® Dual
Core and Celeron® Dual Core (65W for MT & SFF, 35W for Micro)

Operating System Microsoft® Windows 10 Home 64 - bit, Microsoft® Windows 10 Pro 64 - bit

Microsoft® Windows 8.1 Standard 64-bit, Microsoft® Windows 8.1 Pro 64-bit
Microsoft® Windows 7® Professional SP1 (32/64 bit)

®

Ubuntu
Neokylin® (China only)

Graphics Options

2

Integrated Intel® HD Graphics 530
Supports optional discrete graphics (MT/SFF only): AMD Radeon™ R7 350X, AMD Radeon™ R5 340X

Memory

3

2 Long DIMM slots; Non-ECC dual-channel 1600MHz DDR3L SDRAM, supports up to 16GB (MT/SFF);
2 SO- DIMM slots (MFF)

Networking MT/SFF: Integrated Realtek® RTL8111HSD Ethernet LAN 10/100/1000; Optional wireless: 802.11ac+ Bluetooth

4.1 card
Micro: Integrated Realtek® RTL8111HSD Ethernet LAN 10/100/1000; Optional wireless M.2 802.11ac +
Bluetooth 4.1 card

I/O Ports MT/SFF: 8 External USB: 4 x 3.0 (2 front/2 rear) and 4 x 2.0 (2 front/2 rear); 1 RJ-45; 1 Serial (optional); 1 Display Port

1.2; 1 HDMI 1.4; 2 PS/2 (optional); 1 UAJ, 1 Line-out; 1 VGA (optional)

MFF: 6 External USB: 4 x 3.0 (2 front/2 rear) and 2 x 2.0 (2 rear); 1 RJ-45; 1 HDMI 1.4; 1 Display Port 1.2; 1 UAJ (front);
1 Line-out (front); 1 Serial (optional); 1 VGA (optional); Serial+PS2 (optional)

Removable Media Options Supports optional optical disc drives and media card reader (MT/SFF only)

Hard Drive4 Options
(internal)

Hard Disk Drives: up to 1TB
Supports Solid State Drives,
Hybrid and Hybrid Opal SED FIPS
No Hard Drive – Supports Dell Cloud Desktop diskless

Chassis Minitower (MT) Small Form Factor (SFF) Micro (MFF)

Dimensions (H x W x D)
Inches/(cm)

13.8 x 6.1 x 10.8 (inches) 11.4 x 3.6 x 11.5 (inches) 7.2 x 1.4 x 7 (inches)

35 x 15.4 x 27.4 (cm) 29 x 9.2 x 29.2 (cm) 18.2 x 3.6 x 17.8 (cm)

Weights (lbs./kg) 17.49 / 7.93 13.45 / 6.1 2.82 / 1.28

Number of Bays 1 internal 3.5” 2 internal 2.5”

1 external 5.25”

Expansion Slots 1 full height PCIe x16

3 full height PCIe x1

Power Supply
Unit (PSU)

Standard 240W PSU
Active PFC

11

1 internal 3.5”
1 internal 2.5”

1 half height PCIe x16
1 half height PCIe x1

Standard 180W PSU Active
PFC

1 internal 2.5”

1 M.2 (22x30mm) (Wireless
only)

65W external adapter,
87% minimum average

eciency
180W typical 85% Ecient
PSU (80 PLUS Bronze)
ENERGY STAR compliant,
Active PFC

180W typical 92% Ecient
PSU (80 PLUS Platinum);
ENERGY STAR compliant,
Active PFC

Recommended
Accessories

240W up to 85% Ecient
PSU (80 PLUS Bronze)
ENERGY STAR compliant,
Active PFC

240W up to 92% Ecient
PSU (80 PLUS Platinum);
ENERGY STAR compliant,
Active PFC

Monitors - qualified with Dell commercial monitors including
Dell E series monitor 17” – 27”, Touch monitor in 20” screen size
Dell Professional series monitors available from 19”-27”, Touch monitor in 23” screen size

Micro Mounting Options: Vertical Stand, VESA Mount, Dual VESA Mount, All in One Mount, Console with DVD-RW,
All in One Mount for E Series Displays

Keyboards: Dell wired Keyboard with Multimedia functionality, Dell Smart Card Keyboard, Dell Wireless KB/Mouse,
Logitech Wireless KB/Mouse

Mouse: Dell wired Mouse, Dell wireless mouse, Dell Laser Mouse.

Audio Speakers: Internal Dell Business audio speaker, Dell stereo speaker systems available; Dell sound bar for
select Flat-panel displays. Dell Wireless Speaker System available.

Security Options Trusted Platform Module10 (TPM) 2.0 Dell Data Protection| Security Tools, Dell Data Protection| Encryption, Chassis

lock slot support, Chassis Intrusion Switch, Setup/BIOS Password, I/O Interface Security, optional Smart Card
keyboards, Intel® Trusted Execution Technology, Intel® Identity Protection Technology, Intel®Anti-Theft Technology,
KACE Security, Dell Secure Works, BIOS support for optional Computrace⁵

Systems Management

Dell Client Command Suite; In-Band Systems Management

Options
