Dell 1610HD User Manual

Dell™ 1610HD Projector

User’s Guide

Notes, Notices, and Cautions

NOTE: A NOTE indicates important information that helps you

make better use of your projector.

NOTICE: A NOTICE indicates either potential damage to

hardware or loss of data and tells you how to avoid the problem.

CAUTION: A CAUTION indicates a potential for property

damage, personal injury, or death.

____________________

Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.

Trademarks used in this text: Dell and the DELL logo are trademarks of Dell Inc.; DLP and DLP logo are trademarks of T Microsoft and Windows are either trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries.

Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and trade names other than its own.

Model 1610HD

December 2009 Rev. A00

EXAS INSTRUMENTS INCORPORATED;

1 Your Dell Projector . . . . . . . . . . . . . . . . . . 6

2 Connecting Your Projector . . . . . . . . . . . . 9

Connecting to a Computer . . . . . . . . . . . . . . . . 10

About Your Projector . . . . . . . . . . . . . . . . . 7

Connecting a Computer Using a VGA Cable

Monitor Loop-Through Connection Using

VGA Cables . . . . . . . . . . . . . . . . . . . . . 11

Connecting a Computer Using an RS232 cable

. . . . 10

. . . 12

Connecting a DVD Player

Connecting a DVD Player Using an S-video Cable

Connecting a DVD Player Using a Composite

Video Cable . . . . . . . . . . . . . . . . . . . . . 14

Connecting a DVD Player Using a Component Video Cable

Connecting a DVD Player Using an HDMI Cable

Connecting to Local Area Network

To control the projector that is connected to a network through an RJ45 cable.

Connection With Commercial RS232 Control Box

. . . . . . . . . . . . . . . . 13

. 13

. . . . . . . . . . . . . . . . . . . . . 15

. . 16

. . . . . . . . . . . 17

. . . . . . . . . . 17

. 18

3 Using Your Projector . . . . . . . . . . . . . . . . 19

Turning Your Projector On . . . . . . . . . . . . . . . . 19

Contents 3

Turning Your Projector Off . . . . . . . . . . . . . . . . 19

Adjusting the Projected Image

Raising the Projector Height

Lowering the Projector Height

Adjusting the Projector Zoom and Focus

Adjusting Projection Image Size

. . . . . . . . . . . . . 20

. . . . . . . . . . . . 20

. . . . . . . . . . . 20

. . . . . . . . 21

. . . . . . . . . . . . 22

Using the Control Panel . . . . . . . . . . . . . . . . . 23

Using the Remote Control

Installing the Remote Control Batteries

. . . . . . . . . . . . . . . . 26

. . . . . . . . 29

Operating Range With Remote Control . . . . . . . . . 30

Using the On-Screen Display

Main Menu

. . . . . . . . . . . . . . . . . . . . . 31

. . . . . . . . . . . . . . 31

AUTO-ADJUST . . . . . . . . . . . . . . . . . . . 31

INPUT SELECT

PICTURE (in PC Mode)

. . . . . . . . . . . . . . . . . . . 32

. . . . . . . . . . . . . . . 33

PICTURE (in Video Mode) . . . . . . . . . . . . . 34

DISPLAY (in PC Mode)

DISPLAY (in Video Mode)

LAMP

. . . . . . . . . . . . . . . . . . . . . . . . 38

SET UP

. . . . . . . . . . . . . . . . . . . . . . . 38

INFORMATION

OTHERS

. . . . . . . . . . . . . . . . . . . . . . . 41

. . . . . . . . . . . . . . . 35

. . . . . . . . . . . . . 37

. . . . . . . . . . . . . . . . . . . 41

4 Contents

Managing the Projector From Web Management . . . 48

Configuring the Network Setting

. . . . . . . . . . 48

Accessing Web Management . . . . . . . . . . . 48

Managing Properties

. . . . . . . . . . . . . . . . 49

4 Troubleshooting Your Projector . . . . . . . . 61

Guiding Signals . . . . . . . . . . . . . . . . . . . . . 65

Changing the Lamp

. . . . . . . . . . . . . . . . . . . . 67

5 Specifications . . . . . . . . . . . . . . . . . . . . . 69

6 Contacting Dell . . . . . . . . . . . . . . . . . . . . 74

7 Appendix: Glossary . . . . . . . . . . . . . . . . . 75

Contents 5

Your Dell Projector

Your projector comes with all the items shown below. Ensure that you have all the items, and contact Dell™ if anything is missing.

Package Contents

Power cable 1.8m VGA cable (VGA to VGA)

Carrying case Remote control

CD User’s Guide & Documentation AAA Batteries (2)

6 Your Dell Projector

About Your Projector

Top View

Bottom View

1 Control panel 2 Zoom tab 3 Focus ring 4 Lens 5 Elevator button for height adjustments 6 IR receivers 7 Lens cap 8 Mounting holes for ceiling mount: Screw hole M3 x 6.5mm depth.

Recommended torque <8 kgf-cm

9 Mounting hole for tripod: Insert nut 1/4"*20 UNC 10 Lamp cover 11 Tilt adjustment wheel 12 Elevator foot

CAUTION: Safety Instructions

Do not use the projector near appliances that generate a lot of heat.

Do not use the projector in areas where there is an excessive amount of dust. The dust may cause the system to fail and the projector will automatically shutdown.

Ensure that the projector is mounted in a well-ventilated area.

Do not block the ventilation slots and openings on the projector.

Ensure the projector operates between ambient temperatures (5ºC to 35ºC).

Your Dell Projector 7

Do not try to touch the ventilation outlet as it can become very hot after the projector has been turned on or immediately after it is turned off.

Do not look into the lens while the projector is on as it may cause injury to your eyes.

Do not place any objects near or in front of the projector or cover its lens while the projector is on as the heat may cause the object to melt or burn.

NOTE:

• Do not attempt to ceiling mount the projector yourself. It should be installed by a qualified technician.

• Recommended Projector Ceiling Mount Kit (P/N: C3505). For more information, see the Dell Support website at

• For more information, see the

Safety Information

support.dell.com

that is shipped with your

projector.

8 Your Dell Projector

Connecting Your Projector

1 2

1 USB remote connector 9 Audio-A input connector 2 HDMI connector 10 Microphone connector 3 VGA-A output

(monitor loop-through)

4 VGA-A input (D-sub) connector 12 RJ45 connector 5 VGA-B input (D-sub) connector 13 Security cable slot 6 S-video connector 14 Audio output connector 7 Composite video connector 15 Audio-B left-channel input

8 Audio-B right-channel input

connector

3 4 5 6 7

9 10 11 12

15 14

11 RS232 connector

connector

16 Power cord connector

CAUTION: Before you begin any of the procedures in this section, follow the

Safety Instructions as described on page 7.

Connecting Your Projector 9

Connecting to a Computer

Connecting a Computer Using a VGA Cable

1 Power cord 2 VGA to VGA cable 3 USB-A to USB-B cable

NOTE: The USB cable is not provided with your projector.

NOTE: The USB cable must be connected if you want to use the Page Up and

Page Down features on the remote control.

10 Connecting Your Projector

Monitor Loop-Through Connection Using VGA Cables

1 Power cord 2 VGA to VGA cable

NOTE: Only one VGA cable is shipped with your projector. An additional VGA

cable can be purchased on the Dell website at dell.com.

Connecting Your Projector 11

Connecting a Computer Using an RS232 cable

1Power cord 2 RS232 cable

NOTE: The RS232 cable is not shipped with your projector. Consult a

professional installer for the cable and RS232 remote control software.

12 Connecting Your Projector

Connecting a DVD Player

Connecting a DVD Player Using an S-video Cable

1 Power cord 2 S-video cable

NOTE: The S-video cable is not shipped with your projector. You can purchase

the S-Video extension (50 ft/100 ft) cable on the Dell website at dell.com.

Connecting Your Projector 13

Connecting a DVD Player Using a Composite Video Cable

1 Power cord 2 Composite video cable

NOTE: The Composite Video cable is not shipped with your projector. You can

purchase the Composite Video Extension (50 ft/100 ft) cable on the Dell website at dell.com.

14 Connecting Your Projector

Connecting a DVD Player Using a Component Video Cable

1 Power cord 2 VGA to Component Video cable

NOTE: The VGA to Component Video cable is not shipped with your projector.

You can purchase the VGA to Component Video Extension (50 ft/100 ft) cable on the Dell website at dell.com.

Connecting Your Projector 15

Connecting a DVD Player Using an HDMI Cable

1 Power cord 2 HDMI cable

NOTE: The HDMI cable is not shipped with your projector.

16 Connecting Your Projector

Connecting to Local Area Network

To control the projector that is connected to a network through an RJ45 cable.

Local Area Network (LAN)

1 Power cord 2 RJ45 cable

NOTE: The RJ45 cable is not shipped with your projector.

Connecting Your Projector 17

Connection With Commercial RS232 Control Box

1 Power cord 2 RS232 cable 3 Commercial RS232 control box

NOTE: The RS232 cable is not shipped with your projector. Consult a

professional technician to obtain the cable.

18 Connecting Your Projector

Using Your Projector

Turning Your Projector On

NOTE: Turn on the projector before you turn on the source (computer, DVD

player, etc.). The Power button light blinks blue until pressed.

Remove the lens cap.

Connect the power cord and appropriate signal cables. For information about connecting the projector, see "Connecting Your Projector" on page 9.

Press the

Power

Turn on your source (computer, DVD player, etc.).

Connect your source to the projector using the appropriate cable. See "Connecting Your Projector" on page 9 for instructions to connect your source to the projector.

By default, the input source of projector is set to VGA-A. Change the input source of projector if necessary.

If you have multiple sources connected to the projector, press the on the remote control or control panel to select the desired source. See "Using the Control Panel" on page 23 and "Using the Remote Control" on page 26 to locate the

button).

Source

Power

button (see "Using the Control Panel" on page 23 to locate the

button.

Source

button

Turning Your Projector Off

NOTICE: Unplug the projector after properly shutting down as explained in the

following procedure.

Press the

Press the seconds.

Power

button.

NOTE: The "Press Power Button to Turn off Projector" message will appear

on the screen. The message disappears after 5 seconds or you can press the Menu button to clear it.

Power

button again. The cooling fans continue to operate for 120

Using Your Projector 19

To power off the projector quickly, press the

Power

button and hold for 1 second

while the projector’s cooling fans are still running.

NOTE: Before you turn on the projector again, wait for 60 seconds to allow the

internal temperature to stabilize.

Disconnect the power cord from the electrical outlet and the projector.

Adjusting the Projected Image

Raising the Projector Height

Press the

Raise the projector to the desired display angle, and then release the button to lock the elevator foot into position.

Use the tilt adjustment wheel to fine-tune the display angle.

Lowering the Projector Height

Press the

Lower the projector, and then release the button to lock the elevator foot into position.

Elevator

button.

1 Elevator button 2 Elevator foot (Angle of tilt: 0 to 8 degree) 3 Tilt adjustment wheel

20 Using Your Projector

Adjusting the Projector Zoom and Focus

CAUTION: To avoid damaging the projector, ensure that the zoom lens and

elevator foot are fully retracted before moving the projector or placing the projector in its carrying case.

Rotate the zoom tab to zoom in and out.

Rotate the focus ring until the image is clear. The projector focuses at distances ranging between 3.94 ft to 32.81 ft (1.2 m to 10 m).

1 Zoom tab 2 Focus ring

Using Your Projector 21

Adjusting Projection Image Size

302"

(767.08 cm)

272"

(690.88 cm)

212"

(538.48 cm)

362"(919.48 cm)

326"(828.04 cm)

254"(645.16 cm)

181"(459.74 cm)

Projector to screen distance

32.81'(10.0m)

29.53'(9.0m)

22 Using Your Projector

22.97'(7.0m)

151"

(383.54 cm)

16.40'(5.0m)

91"

(231.14 cm)

(92.20 cm)

9.84'(3.0m)

109"(276.86 cm)

44"(111.76 cm)

36.3"

3.94'(1.2m)

Max. 44"

Screen (Diagonal)

(111.76 cm)

Min. 36.3"

(92.20 cm)

Max.

37.01" X

(WxH)

23.23" (94 cm X 59

Min. (WxH)

cm)

30.71" X

19.29" (78 cm X

49 cm)

Screen Size

Max. 25.98"

Min.

(66 cm)

21.65"

(55 cm)

Distance

* This graph is for user reference only.

3.94' (1.2m) 9.8' (3.0m) 16.4' (5.0m) 23.0' (7.0m) 29.5' (9.0m) 32.81'

109" (276.86 cm)

91" (231.14 cm)

92.13" X

57.48" (234 cm X

146 cm)

76.77" X

48.03" (195 cm X

122 cm)

64.96" (165 cm)

53.94" (137 cm)

181" (459.74 cm)

151" (383.54 cm)

153.94" X

96.06" (391 cm X

244 cm)

128.35" X

79.92" (326 cm X

203 cm)

107.87" (274 cm)

90.16" (229 cm)

Using the Control Panel

1 3

254" (645.16 cm)

212" (538.48 cm)

215.35" X

134.65" (547 cm X

342 cm)

179.53" X

112.20" (456 cm X

285 cm)

151.18" (384 cm)

125.98" (320 cm)

326" (828.04 cm)

272" (690.88 cm)

276.77" X

172.83" (703 cm X

439 cm)

230.71" X

144.09" (586 cm X

366 cm)

194.49" (494 cm)

162.20" (412 cm)

362" (919.48 cm)

302" (767.08 cm)

307.48" X

192.13" (781 cm X

488 cm)

256.30" X

160.24" (651 cm X

407 cm)

216.14" (549 cm)

179.92" (457 cm)

(10.0m)

Using Your Projector 23

1 LAMP warning light If the LAMP amber indicator is on or blinking,

one of the following problems could be occurring:

• Lamp is reaching its end of usable life

• Lamp module is not properly installed

• Lamp driver failure

• Color wheel failure For more information, see "Troubleshooting Your

Projector" on page 61 and "Guiding Signals" on page 65.

2 TEMP warning light If the TEMP amber indicator is on or blinking,

one of the following problems could be occurring:

• Internal temperature of the projector is too high

• Color wheel failure

For more information, see "Troubleshooting Your Projector" on page 61 and "Guiding Signals" on page 65.

3 Power Turns the projector on or off. For more

information, see "Turning Your Projector On" on page 19 and "Turning Your Projector Off" on page 19.

4 Up / Keystone

adjustment

5 Right / Auto

Adjust~

Press to navigate through the On-Screen Display (OSD) Menu items.

Press to adjust image distortion caused by tilting the projector (+40/-35 degrees).

Press to navigate through the On-Screen Display (OSD) Menu items.

Press to synchronize the projector to the input source.

NOTE: Auto Adjust does not operate if the on-

screen display (OSD) is displayed.

6 IR Receiver Point the remote control towards the IR receiver

and press a button.

24 Using Your Projector

+ 56 hidden pages
