XC74UL08AA
ETR1305_002
CMOS Logic
■GENERAL DESCRIPTION
The XC74UL08AA is a 2-input CMOS AND Gate, manufactured using silicon gate CMOS fabrication.
CMOS low power circuit operation makes high speed LS-TTL operation achievable.
With a wave forming buffer connected internally, stabilized output can be achieved as the circuit offers high noise immunity.
As the XC74UL08AA is integrated into mini molded, SSOT-25 and SON-6 package, high density mounting is possible.
■APPLICATIONS
●Palmtops
●Digital equipment
■PIN CONFIGURATION
■ABSOLUTE MAXIMUM RATINGS
SSOT-25
(TOP VIEW)
XC74UL08AAN
B
GND
Vcc
(TOP VIEW)
XC74UL08AAR
Y
SON-6
PARAME T E R SYMBOL RATINGS UNITS
Supply Voltage VCC -0.5~+6.0 V
Input Voltage VIN -0.5~+6.0 V
Output Voltage VOUT -0.5~VCC+0.5 V
Input Diode Current IIK -20 mA
Output Diode Current IOK ±20 mA
Output Current IOUT ±25 mA
VCC,GND Current ICC,IGND ±50 mA
1
*
150
2
*
Pd
Power Dissipation
SSOT-25
SON-6
Storage Temperature Range Tstg -65~+150 ℃
■FEATURES
High Speed Operation : tpd = 2.6ns (TYP.)
Operating Voltage Range : 2V ~ 5.5V
Low Power Consumption : 1μA ( MAX.)
CMOS 2-Input AND Gate
Ultra Small Packages : SSOT-25, SON-6*
* Under Development
■FUNCTIONS
INPUT
A B Y
L L L
L H L
H L L
H H H
H=High level
L=Low level
Ta =- 40 ℃~85℃
200
OUTPUT
mW
Voltage is all ground standardized.
*1)Ta =5 5℃
*2)Ta =2 5℃
1/4
