Page 1
Features
• Low forward voltage drop
• High frequency properties and switching speed
• Guard ring for over-voltage protection
FYP1045DN
FYP1045DN
Applications
• Switched mode power supply
• Freewheeling diodes
1 2 3
TO-220
1. Anode 2.Cathode 3. Anode
SCHOTTKY BARRIER RECTIFIER
Absolute Maximum Ratings T
Symbol Parameter Value Units
V
RRM
V
R
I
F(AV)
I
FSM
T
J, TSTG
Maximum Repetitive Reverse Voltage 45 V
Maximum DC Reverse Voltage 45 V
Average Rectified Forward Current @ TC = 130°C10 A
Non-repetitive Peak Surge Current (per diode)
60Hz Single Half-Sine Wave
Operating Junction and Storage Temperature -65 to +150 °C
Thermal Characteristics
Symbol Parameter Value Units
R
θJC
Maximum Thermal Resistance, Junction to Case (per diode) 3.0 °C/W
Electrical Characteristics
Symbol Parameter Value Units
V
FM
*
I
RM
*
* Pulse Test: Pulse Width=300µs, Duty Cycle=2%
Maximum Instantaneous Forward Voltage
Maximum Instantaneous Reverse Current
= 5A
I
F
I
= 5A
F
= 10A
I
F
= 10A
I
F
@ rated V
=25°°°°C unless otherwise noted
C
(per diode)
TC = 25 °C
R
T
= 25 °C
C
T
= 125 °C
C
= 25 °C
T
C
= 125 °C
T
C
= 125 °C
T
C
80 A
0.55
0.49
0.70
0.65
1
40
V
mA
©2002 Fairchild Semiconductor Corporation Rev. A, September 2002
Page 2
Typical Characteristics
FYP1045DN
10
[A]
F
1
TJ=125 oC
Forward C u rre nt, I
0.1
0.01
0.0 0.5 1.0 1.5
TJ=75 oC
TJ=25 oC
Forward Voltage Drop, VF[V]
Figure 1. Typical Forward Volta ge C haracteristics
(per diode)
700
600
500
400
[pF]
J
300
200
TJ=25 oC
100
10
[mA]
R
1
0.1
0.01
Reverse Current, I
1E-3
0 10203040
TJ=150 oC
TJ=125 oC
TJ=75 oC
TJ=25 oC
Reverse Voltage, VR[V]
Figure 2. Typical Reverse Current
vs. Reverse Voltage (p er diode)
10
C/W]
o
1
Juntion Capacitance, C
100
90
80
0 10203040
Reverse Voltage, VR[V]
Figure 3. Typical Junction Capacitance
(per diode)
12
[A]
10
F(AV)
8
6
4
2
Average Forward Current, I
0
0 20 40 60 80 100 120 140 160
Case Temperature, TC[oC]
DC
Figure 5. Forward Current Derating Curve
Transient Thermal Impedance [
100µ 1m 10m 100m 1 10
Pulse Duration [s]
Figure 4. Thermal Impedance Characte rist ics
(per diode)
100
[A]
80
FSM
60
40
20
Max. Forward Su rge Cu rren t, I
0
1 10 100
Number of Cycles @ 60Hz
Figure 6. Non-Repetitive Surge Current
(per diode)
©2002 Fairchild Semiconductor Corporation Rev. A, September 2002
Page 3
Package Dimensions
±0.10
(1.70)
1.30
±0.20
9.20
(1.46)
±0.20
(1.00)
1.27
13.08
±0.10
9.90
(8.70)
ø3.60
TO-220
±0.20
±0.10
(45°)
1.52
(3.70)(3.00)
±0.10
±0.10
2.80
±0.20
15.90
18.95MAX.
±0.30
10.08
4.50
1.30
±0.20
+0.10
–0.05
FYP1045DN
2.54TYP
[2.54
±0.20
]
10.00
±0.20
0.80
2.54TYP
[2.54
±0.10
±0.20
+0.10
0.50
–0.05
2.40
±0.20
]
Dimensions in Millimeters
©2002 Fairchild Semiconductor Corporation Rev. A, September 2002
