Datasheet 2SD2492, 2SD2491 Datasheet (HIT)

2SD2491, 2SD2492

Silicon NPN Epitaxial

Application

Low frequency high voltage amplifier

Features

• Isolated package

TO-126FM

Outline

TO-126FM

1. Emitter

2. Collector

1

2

3

3. Base

2SD2491, 2SD2492

Absolute Maximum Ratings (Ta = 25°C)

Ratings

Item Symbol 2SD2491 2SD2492 Unit

Collector to base voltage V
Collector to emitter voltage V
Emitter to base voltage V
Collector current I
Collector power dissipation P
Collector power dissipation PC*

CBO

CEO

EBO

C

C

1

Junction temperature Tj 150 150 °C
Storage temperature Tstg –55 to +150 –55 to +150 °C

Note: 1. Value at TC = 25°C

Electrical Characteristics (Ta = 25°C)

2SD2491 2SD2492

Item Symbol Min Typ Max Min Typ Max Unit Test conditions

Collector to base
breakdown voltage

Collector to emitter
breakdown voltage

Emitter to base
breakdown voltage

Collector cutoff current I

DC current transfer ratio h
DC current transfer ratio h
Base to emitter voltage V
Collector to emitter

saturation voltage
Gain bandwidth product f
Collector output

capacitance
Note: 1. The 2SD2491 and 2SD2492 are grouped by h

V

(BR)CBO

V

(BR)CEO

V

(BR)EBO

CBO

160 — — 200 — — V IC = 10 µA, IE = 0

160 — — 200 — — V IC = 1 mA, RBE = ∞

5——5——VIE = 10 µA, IC = 0

——10———µAVCB = 140 V, IE = 0
—————10µAVCB = 160 V, IE = 0

1

*

60 — 320 60 — 320 VCE = 5 V, IC = 10 mA
30 — — 30 — — VCE = 5 V, IC = 1 mA
— — 1.5 — — 1.5 V VCE = 5 V, IC = 10 mA
——2 ——2 V IC = 30 mA, IB = 3 mA

— 140 — — 140 — MHz VCE = 5 V, IC = 10 mA

V

FE1

FE2

BE

CE(sat)

T

Cob — 3.8 — — 3.8 — pF VCB = 10 V, IE = 0

160 200 V
160 200 V
55V
100 100 mA

1.35 1.35 W
88W

f = 1 MHz

and its specification is as follows.

FE1

BCD

60 to 120 100 to 200 160 to 320

2

See characteristic curves of 2SD1609, 2SD1610.

Maximum Collector Dissipation Curve

8

6

4

2

1.35W

Collector Power Dissipation Pc (W)

0

50 100 150 200

Case Temperature Tc (°C)

Ambient Temperature Ta (°C)

2SD2491, 2SD2492

Tc

Ta

3

Unit: mm

1.0

11.0 ± 0.515.6 ± 0.5

0.65

2.29 ± 0.5

8.0 ± 0.4

6.0

φ

3.1

1.9 Max 3.5

1.4

0.7

2.29 ± 0.5

+0.15
–0.1

3.2 ± 0.4

Hitachi Code
JEDEC
EIAJ
Weight

1.7

(reference value)

TO-126FM
—
—

0.87 g
