Datalogic Memor™

User’s Manual

Datalogic Mobile S.r.l. Via S. Vitalino 13

40012 - Lippo di Calderara di Reno Bologna - Italy

Datalogic Memor™ - User's Manual

Software Version: 3.00

Ed.: 07/2008

Datalogic is a registered trademark of Datalogic S.p.A. in many countries and the Datalogic logo is a trademark of Datalogic S.p.A.. All other brand and product names mentioned herein are for identification purposes only and may be trademarks or registered trademarks of their respective owners.

Datalogic reserves the right to make modifications and improvements without prior notification.

Datalogic shall not be liable for technical or editorial errors or omissions contained herein, nor for incidental or consequential damages resulting from the use of this material.

	DATALOGIC END USER LICENSE AGREEMENT	............................v
	REFERENCES...................................................................................	vii
	Conventions .......................................................................................	vii
	Reference Documentation .................................................................	vii
	Services and Support.........................................................................	vii
	SAFETY REGULATIONS .................................................................	viii
	General Safety Rules ........................................................................	viii
	Bluetooth® Approval .........................................................................	viii
	Power Supply ....................................................................................	viii
	Laser Safety ........................................................................................	ix
	Radio Compliance.............................................................................	xiv
	FCC Compliance................................................................................	xv
	SAR Compliance................................................................................	xv
	Patents ...............................................................................................	xv
	WEEE Compliance............................................................................	xvi
	China RoHS Pollution Control Logos ..............................................	xviii
	GENERAL VIEW..............................................................................	xix
1	INTRODUCTION.................................................................................	1
1.1	Datalogic Memor™ Description ..........................................................	1
1.2	Model Description ...............................................................................	1
1.3	Package Contents...............................................................................	2
1.4	Inserting an SD Card...........................................................................	3
1.5	Accessories.........................................................................................	4
2	CONNECTIONS..................................................................................	5
2.1	USB Connection..................................................................................	5
2.2	RS232 Connection ..............................................................................	6
2.3	Ethernet Connection ...........................................................................	7
2.4	WLAN Connection...............................................................................	8
2.5	WPAN Connections ..........................................................................	10
2.6	Connection Cables............................................................................	11
3	USE AND FUNCTIONING ................................................................	12
3.1	Startup...............................................................................................	12
3.1.1	Using the Stylus ................................................................................	14
3.1.2	Using the Joystick .............................................................................	15
3.2	Data Capture.....................................................................................	16
3.2.1	Laser Data Capture...........................................................................	16
3.3	Description of the Keys .....................................................................	17
3.3.1	Resetting the Memor™ .....................................................................	19
3.4	Status Indicators ...............................................................................	21
3.4.1	LED Status ........................................................................................	21
3.4.2	Taskbar .............................................................................................	21
3.5	Data Capture Configuration...............................................................	23
3.5.1	Configure...........................................................................................	23
		iii

3.5.2	Capture..............................................................................................	28
3.6	Control Panel ....................................................................................	29
3.6.1	Buttons ..............................................................................................	29
3.6.2	Registry .............................................................................................	30
3.6.3	Files Admin .......................................................................................	31
3.6.4	Wireless Communications.................................................................	33
3.6.5	Ethernet Settings...............................................................................	34
3.6.6	Stylus Calibration ..............................................................................	35
3.7	Windows Connections.......................................................................	37
3.7.1	Microsoft® ActiveSync®....................................................................	37
3.7.2	Bluetooth® Manager Device Setup...................................................	39
3.7.3	FTP Server Setup..............................................................................	42
3.8	Backup Directory File Management ..................................................	43
3.9	Firmware Update...............................................................................	44
4	MAINTENANCE................................................................................	47
4.1	Connecting the Backup Battery.........................................................	47
4.2	Charging the Battery Pack ................................................................	49
4.3	Replacing the Battery Pack...............................................................	50
4.4	Cleaning the Mobile Computer..........................................................	53
5	TECHNICAL FEATURES .................................................................	54
5.1	Technical Data ..................................................................................	54
5.2	Reading Diagram ..............................................................................	56
6	TEST CODES ...................................................................................	57
	GLOSSARY ......................................................................................	60
	INDEX ...............................................................................................	62

DATALOGIC END USER LICENSE AGREEMENT

BY DOWNLOADING OR INSTALLING THE SOFTWARE, OR BY USING DATALOGIC EQUIPMENT THAT INCLUDES THIS SOFTWARE, YOU ARE CONSENTING TO BE BOUND BY THIS AGREEMENT. IF YOU DO NOT AGREE TO ALL OF THE TERMS OF THIS AGREEMENT, THEN DO NOT DOWNLOAD, INSTALL, USE THE SOFTWARE NOR DATALOGIC EQUIPMENT.

The following terms and conditions govern your use of the Software except to the extent that a particular program (a) is the subject of a separate written agreement with Datalogic or (b) includes a separate “clickon” license agreement as part of the installation and/or download process. Should a conflict arise between the provisions of the foregoing documents, the order of precedence shall be (1) the written agreement, (2) the click-on agreement, and (3) this agreement (“Agreement”).

1. License. Subject to the terms and conditions of and except as otherwise provided in this Agreement, Datalogic Mobile S.r.l. (“Datalogic”) and its suppliers grant to Customer (“Customer”) a nonexclusive and nontransferable license to use the specific program modules, feature set(s) or feature(s) in object code form only as well as associated media, printed materials and “online” or electronic documentation (the “Software”) for which Customer has paid, if required, the license fees. The Software is licensed not sold. The license shall be subject to each of the following limitations:

•Unless otherwise expressly provided in the documentation, Customer shall use the Software solely as embedded in, for execution on, or (where the applicable documentation permits installation on non-Datalogic equipment) for communication with Datalogic equipment owned or leased by Customer;

•Customer’s use of the Software shall be limited to use on a single hardware chassis, on a single central processing unit, as applicable, or use on such greater number of chassis or central processing units as Customer may have paid Datalogic the required license fee; and

•Customer’s use of the Software shall also be limited, as applicable and set forth in Customer’s purchase order or in Datalogic’s product catalog, user documentation, or web site, to a maximum number of (a) seats (i.e. users with access to the installed Software), (b) concurrent users, sessions, ports, and/or issued and outstanding IP addresses, and/or (c) central processing unit cycles or instructions per second. Customer’s use of the Software shall also be limited by any other restrictions set forth in Customer’s purchase order or in Datalogic’s product catalog, user documentation or web site for the Software.

2.General Limitations. Except as otherwise expressly provided under this Agreement, Customer shall have no right, and Customer specifically agrees not to (i) transfer, assign or sublicense its license rights to any other person, or use the Software on unauthorized or secondhand Datalogic equipment, and any such attempted transfer, assignment or sublicense shall be void; (ii) correct errors to or otherwise modify or adapt the Software or create derivative works based upon the Software, or to permit third parties to do the same; or (iii) decompile, decrypt, reverse engineer, disassemble or otherwise reduce the Software to human-readable form to gain access to trade secrets or confidential information in the Software. To the extent required by law, at Customer's request, Datalogic shall provide Customer with the interface information needed to achieve interoperability between the Software and another independently created program, upon payment of Datalogic's applicable fee. Customer shall observe strict obligations of confidentiality with respect to such information.

3.Upgrades and Additional Copies. For purposes of this Agreement, “Software” shall include (and the terms and conditions of this Agreement shall apply to) any upgrades, updates, bug fixes or modified versions (collectively, “Upgrades”) or backup copies of the Software licensed or provided to Customer by Datalogic or an authorized distributor for which Customer has paid the applicable license fees. Notwithstanding any other provision of this Agreement: (1) customer has no license or right to use any such additional copies or upgrades unless customer, at the time of acquiring such copy or upgrade, already holds a valid license to the original Software and has paid the applicable fee for the upgrade, if required; (2) use of upgrades is limited to Datalogic equipment for which customer is the original end user, purchaser or lessee or who otherwise holds a valid license to use the Software which is being upgraded; and (3) use of additional copies is limited to backup purposes only.

4.Proprietary Notices. Customer agrees to maintain and reproduce all copyright and other proprietary notices on all copies, in any form, of the Software in the same form and manner that such copyright and other proprietary notices are included on the Software. Except as expressly authorized in this Agreement, Customer shall not make any copies or duplicates or any Software without the prior written permission of Datalogic. Customer may make such backup copies of the Software as may be necessary for Customer’s lawful use, provided Customer affixes to such copies all copyright, confidentiality, and proprietary notices that appear on the original.

5.Protection of Information. Customer agrees that aspects of the Software and associated documentation, including the specific design and structure of individual programs, constitute trade secrets

and/or copyrighted material of Datalogic. Customer shall not disclose, provide, or otherwise make available such trade secrets or copyrighted material in any form to any third party without the prior written consent of Datalogic. Customer shall implement reasonable security measures to protect such trade secrets and copyrighted material. Software and documentation shall remain solely property of Datalogic.

6. Limited Warranty. If Customer obtained the Software directly from Datalogic, then Datalogic warrants that during the Warranty Period (as defined below): (i) the media on which the Software is furnished will be free of defects in materials and workmanship under normal use; and (ii) the Software will substantially conform to its published specifications. The “Warranty Period” means a period beginning on the date of Customer’s receipt of the Software and ending on the later of (a) ninety (90) days from the date of initial shipment of the Software by Datalogic, or (b) the end of the minimum period required by the law of the applicable jurisdiction. The limited warranties extend only to Customer as the original licensee. Customer's sole and exclusive remedy and the entire liability of Datalogic and its suppliers under these limited warranties will be, at Datalogic’s sole option, repair or replacement of the Software if reported (or, upon request, returned) to Datalogic. Except as expressly granted in this Agreement, the Software is provided AS IS and with all faults. Datalogic does not warrant that the Software is error free or that Customer will be able to operate the Software without problems or interruptions. In addition, due to the continual development of new techniques for intruding upon and attacking networks, Datalogic does not warrant that the Software or any equipment, system or network on which the Software is used will be free of vulnerability to intrusion or attack. This warranty does not apply if the Software

(a) is licensed for beta, evaluation, testing or demonstration purposes for which Datalogic does not receive a license fee, (b) has been altered, except by Datalogic, (c) has not been installed, operated, repaired, or maintained in accordance with instructions supplied by Datalogic, (d) has been subjected to abnormal physical or electrical stress, misuse, negligence, or accident, or (e) is used in ultra hazardous activities. If Customer obtained the Software from a Datalogic reseller, the terms of any warranty shall be as provided by such distributor, and Datalogic provides Customer no warranty with respect to such Software. The Software may contain support for programs written in Java. Java technology is not fault tolerant and is not designed, manufactured, or intended for use or resale as online control equipment in hazardous environments requiring fail-safe performance, such as in the operation of nuclear facilities, aircraft navigation or communication systems, air traffic control, direct life support machines, or weapons systems, in which the failure of Java technology could lead directly to death, personal injury, or severe physical or environmental damage. Microsoft Inc. has contractually obligated Datalogic to make this disclaimer.

7.Disclaimer of Warranties. Except as specified in this warranty, all expressed or implied conditions, representations, and warranties including, without limitation, any implied warranty or condition of merchantability, fitness for a particular purpose, non-infringement, satisfactory quality or arising from a course of dealing, usage, or trade practice, are hereby excluded to the extent allowed by applicable law. To the extent that an implied warranty cannot be excluded, such warranty is limited in duration to the warranty period.

8.Disclaimer of Liabilities. In no event will Datalogic or its suppliers be liable for any lost revenue, profit, or data, or for special, indirect, consequential, incidental, or punitive damages however caused and arising out of the use of or inability to use the Software even if Datalogic has been advised of the possibility of such damages. In no event shall Datalogic or its suppliers' liability to customer, whether in contract, tort (including negligence), or otherwise, exceed the price paid by customer. The foregoing limitations shall apply even if the above-stated warranty fails of its essential purpose.

9.Term and Termination. This Agreement is effective until terminated. Customer may terminate this Agreement at any time by destroying all copies of Software including any documentation. Customer’s license rights under this Agreement will terminate immediately without notice from Datalogic if Customer fails to comply with any provision of this Agreement. Upon termination, Customer must destroy all copies of Software in its possession or control.

10.Customer Records. Customer grants to Datalogic and its independent accountants the right to examine Customer’s books, records and accounts during Customer’s normal business hours to verify compliance with this Agreement. In the event such audit discloses non-compliance with this Agreement, Customer shall promptly pay to Datalogic the appropriate license fees.

11.General Provisions. This Agreement shall be governed by and construed in accordance with the laws of Italy. All disputes arising out of or in connection with this Agreement will be subject to the exclusive jurisdiction of the competent Court of the place where Datalogic has its registered office. If any portion hereof is found to be void or unenforceable, the remaining provisions of this Agreement shall remain in full force and effect. Except as expressly provided herein, this Agreement constitutes the entire agreement between the parties with respect to the license of the Software and supercedes any conflicting or additional terms contained in the purchase order.

REFERENCES

CONVENTIONS

This manual uses the following conventions:

“User” refers to anyone using a Datalogic Memor™ mobile computer.

“Mobile computer” and "Datalogic Memor™" refer to Datalogic Memor™ mobile computer.

“You” refers to the System Administrator or Technical Support person using this manual to install, configure, operate, maintain or troubleshoot a Datalogic Memor™ mobile computer.

“Single Cradle” refers to both Datalogic Memor™ Single Cradle and Datalogic Memor™ Single Ethernet Cradle.

REFERENCE DOCUMENTATION

For further information regarding Datalogic Memor™ refer to the SDK Help on-Line.

SERVICES AND SUPPORT

Datalogic provides several services as well as technical support through its website.

Log on to www.mobile.datalogic.com and click on the links indicated for further information including:

-PRODUCTS

Search through the links to arrive at your product page where you can download specific Manuals and Software & Utilities

-SERVICES & SUPPORT

-Datalogic Services Warranty Extensions and Maintenance Agreements

-Authorised Repair Centres

-CONTACT US

E-mail form and listing of Datalogic Subsidiaries

vii

SAFETY REGULATIONS

Read this manual carefully before performing any type of connection to the Datalogic Memor™ mobile computer.

The user is responsible for any damages caused by incorrect use of the equipment or by inobservance of the indication

NOTE supplied in this manual.

GENERAL SAFETY RULES

−Use only the components supplied by the manufacturer for the specific Datalogic Memor™ being used.

−Do not attempt to disassemble the Datalogic Memor™ mobile computer, as it does not contain parts that can be repaired by the user. Any tampering will invalidate the warranty.

−When replacing the battery pack or at the end of the operative life of the Datalogic Memor™ mobile computer, disposal must be performed in compliance with the laws in force. See also par. 4.3.

−Do not submerge the Datalogic Memor™ in liquid products.

BLUETOOTH® APPROVAL

This product is equipped with the following certified Bluetooth® module: Product Name: Pocket-Sized Mobile Computer

Bluetooth ID: B03720

Product ID: DL-Memor 001-904-416

POWER SUPPLY

This device is intended to be connected to a UL Listed/CSA Certified computer which supplies power directly to the reader or else be supplied by a UL Listed/CSA Certified Power Unit marked “Class 2” or LPS power source rated 5 V, minimum 3.0 A, which supplies power directly to the reader via the power connector of the cable.

The package includes three international plug adapters. The adapters must be plugged in the power supply before the power supply itself is plugged on the wall outlet.

viii

LASER SAFETY

The laser light is visible to the human eye and is emitted from the window indicated in the figure.

This information applies to both laser models and the Datalogic Memor™ Imager Aiming System.

Laser output window

AVOID EXPOSURE

LASER LIGHT

IS EMITTED FROM

THIS APERTURE

This product complies with 21 CFR Subchapter J

CAUTION-CLASS 2 LASER LIGHT WHEN OPEN - DO NOT STARE INTO BEAM

LASER LIGHT - DO NOT STARE INTO BEAM

CLASS 2 LASER PRODUCT

MAX. OUTPUT RADIATION 1.7 mW

EMITTED WAVELENGTH 630~680 nm

EN60825-1:2001

I	D	F	E

La luce laser è	Die Laserstrahlung	Le rayon laser est	La luz láser es
visibile all'occhio	ist für das	visible à l'oeil nu et il	visible al ojo
umano e viene	menschliche Auge	est émis par la	humano y es
emessa dalla	sichtbar und wird am	fenêtre désignée sur	emitida por la
finestra indicata	Strahlaustrittsfenster	l'illustration dans la	ventana indicada
nella figura.	ausgesendet (siehe	figure.	en la figura.
	Bild).
				ix
				ix

I	D	F	E

LUCE LASER	LASERSTRAHLUNG	RAYON LASER	RAYO LÁSER
NON FISSARE IL	NICHT IN DER STRAHL	EVITER DE	NO MIRAR FIJO EL
FASCIO	BLINKEN	REGARDER	RAYO
APPARECCHIO	PRODUKT DER	LE RAYON	APARATO LÁSER DE
LASER DI CLASSE 2	LASERKLASSE 2	APPAREIL LASER DE	CLASE 2
MINIMA POTENZA DI	MAXIMALE	CLASSE 2	MÁXIMA POTENCIA
USCITA:	AUSGANGLEISTUNG:	PUISSANCE DE	DE SALIDA:
LUNGHEZZA D'ONDA	WELLENLÄNGE:	SORTIE:	LONGITUD DE ONDA
EMESSA:	ENTSPR. EN 60825-1	LONGUER D'ONDE	EMITIDA:
CONFORME A EN	(2001)	EMISE:	CONFORME A EN
60825-1 (2001)		CONFORME A EN	60825-1
		60825-1 (2001)	(2001)

ENGLISH

The following information is provided to comply with the rules imposed by international authorities and refers to the correct use of your mobile computer.

STANDARD LASER SAFETY REGULATIONS

This product conforms to the applicable requirements of both CDRH 21 CFR 1040 and EN 60825-1 at the date of manufacture.

For installation, use and maintenance, it is not necessary to open the device.

Use of controls or adjustments or performance of procedures other than those specified herein may result in exposure to hazardous visible laser light.

CAUTION

The product utilizes a low-power laser diode. Although staring directly at the laser beam momentarily causes no known biological damage, avoid staring at the beam as one would with any very strong light source, such as the sun. Avoid that the laser beam hits the eye of an observer, even through reflective surfaces such as mirrors, etc.

ITALIANO

Le seguenti informazioni vengono fornite dietro direttive delle autorità internazionali e si riferiscono all’uso corretto del terminale.

NORMATIVE STANDARD PER LA SICUREZZA LASER

Questo prodotto risulta conforme alle normative vigenti sulla sicurezza laser alla data di produzione: CDRH 21 CFR 1040 e EN 60825-1.

Non si rende mai necessario aprire l’apparecchio per motivi di installazione, utilizzo o manutenzione.

L'utilizzo di procedure o regolazioni differenti da quelle descritte nella documentazione può provocare un'esposizione pericolosa a luce laser visibile.

ATTENZIONE

Il prodotto utilizza un diodo laser a bassa potenza. Sebbene non siano noti danni riportati dall’occhio umano in seguito ad una esposizione di breve durata, evitare di fissare il raggio laser così come si eviterebbe qualsiasi altra sorgente di luminosità intensa, ad esempio il sole. Evitare inoltre di dirigere il raggio laser negli occhi di un osservatore, anche attraverso superfici riflettenti come gli specchi.

DEUTSCH

Die folgenden Informationen stimmen mit den Sicherheitshinweisen überein, die von internationalen Behörden auferlegt wurden, und sie beziehen sich auf den korrekten Gebrauch vom Terminal.

NORM FÜR DIE LASERSICHERHEIT

Dies Produkt entspricht am Tag der Herstellung den gültigen EN 60825-1 und CDRH 21 CFR 1040 Normen für die Lasersicherheit.

Es ist nicht notwendig, das Gerät wegen Betrieb oder Installations-, und Wartungs-Arbeiten zu öffnen.

Jegliche Änderungen am Gerät sowie Vorgehensweisen, die nicht in dieser Betriebsanleitung beschrieben werden, können ein gefährliches Laserlicht verursachen.

ACHTUNG

Der Produkt benutzt eine Laserdiode. Obwohl zur Zeit keine Augenschäden von kurzen Einstrahlungen bekannt sind, sollten Sie es vermeiden für längere Zeit in den Laserstrahl zu schauen, genauso wenig wie in starke Lichtquellen (z.B. die Sonne). Vermeiden Sie es, den Laserstrahl weder gegen die Augen eines Beobachters, noch gegen reflektierende Oberflächen zu richten.

FRANÇAIS

Les informations suivantes sont fournies selon les règles fixées par les autorités internationales et se réfèrent à une correcte utilisation du terminal.

NORMES DE SECURITE LASER

Ce produit est conforme aux normes de sécurité laser en vigueur à sa date de fabrication: CDRH 21 CFR 1040 et EN 60825-1.

Il n’est pas nécessaire d’ouvrir l’appareil pour l’installation, l’utilisation ou l’entretien.

L'utilisation de procédures ou réglages différents de ceux donnés ici peut entraîner une dangereuse exposition à lumière laser visible.

ATTENTION

Le produit utilise une diode laser. Aucun dommage aux yeux humains n’a été constaté à la suite d’une exposition au rayon laser. Eviter de regarder fixement le rayon, comme toute autre source lumineuse intense telle que le soleil. Eviter aussi de diriger le rayon vers les yeux d’un observateur, même à travers des surfaces réfléchissantes (miroirs, par exemple).

ESPAÑOL

Las informaciones siguientes son presentadas en conformidad con las disposiciones de las autoridades internacionales y se refieren al uso correcto del terminal.

NORMATIVAS ESTÁNDAR PARA LA SEGURIDAD LÁSER

Este aparato resulta conforme a las normativas vigentes de seguridad láser a la fecha de producción: CDRH 21 CFR 1040 y EN 60825-1.

No es necesario abrir el aparato para la instalación, la utilización o la manutención.

xii

La utilización de procedimientos o regulaciones diferentes de aquellas describidas en la documentación puede causar una exposición peligrosa a la luz láser visible.

ATENCIÓN

El aparato utiliza un diodo láser a baja potencia. No son notorios daños a los ojos humanos a consecuencia de una exposición de corta duración. Eviten de mirar fijo el rayo láser así como evitarían cualquiera otra fuente de luminosidad intensa, por ejemplo el sol. Además, eviten de dirigir el rayo láser hacia los ojos de un observador, también a través de superficies reflectantes como los espejos.

xiii

RADIO COMPLIANCE

In radio systems configured with mobile computers and access points, the frequencies to be used must be allowed by the spectrum authorities of the specific country in which the installation takes place. Be absolutely sure that the system frequencies are correctly set to be compliant with the spectrum requirements of the country.

The following shows the correspondence between the Datalogic Memor™ models and the Radio components:

Datalogic Memor™ 6XX-XXX-XXX 802.11b/g radio Datalogic Memor™ 8XX-XXX-XXX 802.11b/g radio

Information for the User

ENGLISH

Contact the competent authority responsible for the management of radio frequency devices of your country to verify any possible restrictions or licenses required.

Refer to the web site http://europa.eu.int/comm/enterprise/rtte/spectr.htm for further information.

ITALIANO

Prendi contatto con l'autorità competente per la gestione degli apparati a radio frequenza del tuo paese, per verificare eventuali restrizioni o licenze. Ulteriori informazioni sono disponibili sul sito: http://europa.eu.int/comm/enterprise/rtte/spectr.htm.

FRANÇAIS

Contactez l'autorité compétente en la gestion des appareils à radio fréquence de votre pays pour vérifier d'éventuelles restrictions ou licences. Pour tout renseignement vous pouvez vous adresser au site web: http://europa.eu.int/comm/enterprise/rtte/spectr.htm.

DEUTSCH

Wenden Sie sich an die für Radiofrequenzgeräte zuständige Behörde Ihres Landes, um zu prüfen ob es Einschränkungen gibt, oder eine Lizenz erforderlich ist. Weitere Informationen finden Sie auf der Web Seite: http://europa.eu.int/comm/enterprise/rtte/spectr.htm.

ESPAÑOL

Contacta la autoridad competente para la gestión de los dispositivos de radio frecuencia de tu país, para verificar cualesquiera restricciones o licencias posibles requerida. Además se puede encontrar mas información en el sitio Web:

http://europa.eu.int/comm/enterprise/rtte/spectr.htm.

xiv

FCC COMPLIANCE

Modifications or changes to this equipment without the expressed written approval of Datalogic could void the authority to use the equipment.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

-Reorient or relocate the receiving antenna.

-Increase the separation between the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

-Consult the dealer or an experienced radio/TV technician for help.

FCC ID:

U4G0024 for 600-XXX-XXX 802.11 b/g models.

U4G0018 for 001-XXX-XXX Bluetooth® models.

U4G0025 for 800-XXX-XXX 802.11 b/g models.

SAR COMPLIANCE

This product has been tested and found to comply with the following standards:

- OET BULLETIN 65 SUPPLEMENT C: evaluating compliance with FCC guidelines for human exposure to radio frequency electromagnetic fields.

PATENTS

This product is covered by one or more of the following patents.

Design Pat. AU 310182 S; CN 658612; HK 0601962.6; KR 30-0466667; TW D118829.

US Pat. 5,992,740; European Pat. 789,315 B1. Additional patents pending.

WEEE COMPLIANCE

Informazione degli utenti ai sensi della Direttiva Europea 2002/96/EC

L’apparecchiatura che riporta il simbolo del bidone barrato deve essere smaltita, alla fine della sua vita utile, separatamente dai rifiuti urbani.

Smaltire l’apparecchiatura in conformità alla presente Direttiva consente di: evitare possibili conseguenze negative per l’ambiente e per la salute umana che potrebbero invece essere causati dall’errato smaltimento dello stesso;

recuperare materiali di cui è composto al fine di ottenere un importante risparmio di energia e di risorse.

Per maggiori dettagli sulle modalità di smaltimento, contattare il Fornitore dal quale è stata acquistata l’apparecchiatura o consultare la sezione dedicata sul sito www.mobile.datalogic.com.

Information for the user in accordance with the European Commission Directive 2002/96/EC

At the end of its useful life, the product marked with the crossed out wheeled wastebin must be disposed of separately from urban waste.

Disposing of the product according to this Directive:

avoids potentially negative consequences to the environment and human health which otherwise could be caused by incorrect disposal enables the recovery of materials to obtain a significant savings of energy and resources.

For more detailed information about disposal, contact the supplier that provided you with the product in question or consult the dedicated section at the website www.mobile.datalogic.com.

Information aux utilisateurs concernant la Directive Européenne 2002/96/EC

Au terme de sa vie utile, le produit qui porte le symbole d'un caisson à ordures barré ne doit pas être éliminé avec les déchets urbains.

Éliminer ce produit selon cette Directive permet de:

xvi

éviter les retombées négatives pour l'environnement et la santé dérivant d'une élimination incorrecte

récupérer les matériaux dans le but d'une économie importante en termes d'énergie et de ressources

Pour obtenir des informations complémentaires concernant l'élimination, veuillez contacter le fournisseur auprès duquel vous avez acheté le produit ou consulter la section consacrée au site Web www.mobile.datalogic.com.

Información para el usuario de accuerdo con la Directiva Europea 2002/96/CE

Al final de su vida útil, el producto marcado con un simbolo de contenedor de bassura móvil tachado no debe eliminarse junto a los desechos urbanos.

Eliminar este producto de accuerdo con la Directiva permite de:

evitar posibles consecuencias negativas para el medio ambiente y la salud derivadas de una eliminación inadecuada

recuperar los materiales obteniendo así un ahorro importante de energía y recursos

Para obtener una información más detallada sobre la eliminación, por favor, póngase en contacto con el proveedor donde lo compró o consultar la sección dedicada en el Web site www.mobile.datalogic.com.

Benutzerinformation bezüglich Richtlinie 2002/96/EC der europäischen Kommission

Am Ende des Gerätelebenszyklus darf das Produkt nicht über den städtischen Hausmüll entsorgt werden. Eine entsprechende Mülltrennung ist erforderlich.

Beseitigung des Produkts entsprechend der Richtlinie:

verhindert negative Auswirkungen für die Umwelt und die Gesundheit der Menschen

ermöglicht die Wiederverwendung der Materialien und spart somit Energie und Resourcen

Weitere Informationen zu dieser Richtlinie erhalten sie von ihrem Lieferanten über den sie das Produkt erworben haben, oder besuchen sie unsere Hompage unter www.mobile.datalogic.com.

xvii

CHINA ROHS POLLUTION CONTROL LOGOS

Part		Toxic or Hazardous Substances and Elements
name	Pb		Hg	Cd	Cr6+	PBB	PBDE
Upper	O		O	O	O	O	O
Case	O		O	O	O	O	O
Case
Lower	O		O	O	O	O	O
Case	O		O	O	O	O	O
Case
Touch	O		O	O	O	O	O
Panel	O		O	O	O	O	O
Panel
PCB	O		O	O	O	O	O
Board	O		O	O	O	O	O
Board
Laser	X		O	O	O	O	O
Engine	X		O	O	O	O	O
Engine
BT
Module	O		O	O	O	O	O
(Note 1)
WiFi
Module	O		O	O	O	O	O
(Note 2)
WiFi
Module	O		O	O	O	O	O
(Note 3)

O:Indicates that this is a toxic or hazardous substance contained in all of the homogenous materials for this part is below the limit requirement in SJ/T11363-2006.

X: Indicates that this is toxic or hazardous substance contained in at least one of the homogeneous materials used for this part is above the limit requirement in SJ/T11363-2006.

Note 1: It is only for DL-MEMOR 001-904-416 Model.

Note 2: It is only for DL-MEMOR 600-904-416 Model.

Note 3: It is only for DL-MEMOR 800-904-416 Model.

Note 4: 99% of the parts of this product adopt the nonpoisonous and harmless environmental protection material to make, the part with poisonous harmful substance or the element is all unable to realize the substitution of the poisonous harmful thing or the element because the global technological development level is limited.

xviii

GENERAL VIEW

G B K

A) Transflective 64K Color Display

G) Strap with Stylus Holder

B)Good Read or User Programmable LED

C)Charging Status LED

D)Scan Key

E)Keyboard

F)Radio Status LED

H)Laser Safety Label

I)Product Label (under battery)

J)Battery Pack

K)ON/OFF Power Key

M N 0

	L
L)	Data Capture/Laser Output	N) Communication/Charger Connector
	Window *	(through cradle)
M)	DC Charger Connector	O) Mini USB Communication/Charger
		Connector (through cable)

•Remove protective film cover before use

xix

INTRODUCTION	1

1 INTRODUCTION

1.1DATALOGIC MEMOR™ DESCRIPTION

The Datalogic Memor™ is a pocket-sized Windows powered mobile computer.

This extremely compact, lightweight, and versatile device, combines fully integrated automatic data capture (1D bar code) and wireless communication capabilities (Bluetooth® or 802.11 b/g), supporting nearly any application.

The Datalogic Memor™ system architecture is based on the blend of Intel X- Scale series processors coupled with the Windows CE operating system and it was developed to meet the most demanding customer needs.

A huge quantity of on-board memory is available and the possibility to expand it through an externally accessible SD card slot, enables the user to adapt the terminal for any specific need.

A customized layout keyboard and a sharp and brilliant touch screen display make the Datalogic Memor™ an easy-to-use tool for your daily work.

Thanks to its great ergonomics and the state of the art architecture, the Datalogic Memor™ is the right answer to enhance your business opportunities.

1.2MODEL DESCRIPTION

The brand new Datalogic Memor™ is available in different models depending on the options it is equipped with. All options are listed below:

•communication options: 802.11 b/g radio, Bluetooth®

•capture options: Laser

For further details about the Datalogic Memor™ models refer to the web site: http://www.mobile.datalogic.com.

1	DATALOGIC MEMOR™

1.3PACKAGE CONTENTS

The Datalogic Memor™ package contains:

−1 Datalogic Memor™ mobile computer

−1 AC/DC power supply

−1 EU plug adapter

−1 AUS. Plug Adapter

−1 UK Plug Adapter

−1 standard Mini USB cable

−1 CD-ROM Datalogic SDK

−1 extensible stylus

−1 user’s manual

−1 rechargeable standard 1000 mAh battery pack + cover

−1 hand-strap with stylus holder

Any other packages will contain the accessories necessary for the Datalogic Memor™ connection to the host computer and to the network: the cradle, one or more connection cables.

Remove all the components from their packaging; check their integrity and congruity with the packing documents.

Keep the original packaging for use when sending products to the technical assistance center. Damage caused by improper packaging is not covered under the warranty.

CAUTION

Rechargeable backup batteries and battery packs are not initially charged. Therefore the initial operation to perform is to charge them. See paragraphs 4.1 and 4.2.

NOTE

INTRODUCTION	1

1.4INSERTING AN SD CARD

Datalogic Memor™ provides the possibility to add an SD memory storage card. To access the SD card slot and to insert the card, proceed as follows:

1.Extract the SD card slot cover from side of the mobile computer. Then carefully pull it out till unlocking its base as shown in the picture below:

2.Insert the card with the written part upward and push it in, aided by the back of the stylus, until it clicks into place.

To remove the SD card, just push it toward the inside, aided by the back of the stylus, until it clicks; a spring system will return it out.

Follow proper ESD precautions to avoid damaging the SD. Proper ESD precautions include, but are not limited to, working on an ESD mat and ensuring that the operator is properly grounded.

CAUTION Do not force the card. If you feel resistance, remove the card, check the orientation, and reinsert it.

Do not use the SD card slot for any other accessories.

1	DATALOGIC MEMOR™

1.5ACCESSORIES

Cradles

94A151111 Datalogic Memor™ Single Cradle

94A151116 Datalogic Memor™ Single Ethernet Cradle

Batteries

94ACC1326 Datalogic Memor™ Standard Battery Pack (Li-Pol or Li-Ion battery pack 1000 mAh@3.7 V)

94ACC1325 Datalogic Memor™ Large Capacity Battery Pack (Li-Pol or LiIon battery pack 2000 mAh@3.7 V) + cover

94ACC1327 Adapter for 3 AAA Alkaline batteries + cover

Power Supply

94ACC1324 PG5-30P35 AC/DC Power Supply EU/USA Plug 94ACC1334 PG5-30P35 AUS. Plug Adapter (10pcs) 94ACC1335 PG5-30P35 UK Plug Adapter (10pcs) 94ACC1339 PG5-30P35 EU Plug Adapter (10pcs)

Cables

94A051016 CAB-421 Mini USB Straight Cable

94A051022 WIN-NET Serial Cable (HRS ST40X-18S-CV)

Various

94ACC1328 Datalogic Memor™ Stylus Pens (10 pcs)

Use only a Datalogic Mobile-approved power supply and cables. Use of an alternative power supply will invalidate any approval given to this device and may be dangerous.

NOTE

CONNECTIONS	2

2 CONNECTIONS

2.1USB CONNECTION

You can use any standard mini USB cable to directly connect the Datalogic Memor™ to a host computer to transfer data through the USB interface.

B C

Key:

A) Host Computer

C) Datalogic Memor™

B)Standard Mini USB cable

The Single Cradle can be connected to the Host by any standard mini USB cable to transfer data through the USB interface.

		C
	B
		D*
Key:
A) Host Computer	C)	Single Cradle
B) Standard Mini USB cable	D)	*Power Supply (only necessary
		for battery charging)

In this case the power supply is only necessary for battery charging. Insert the power supply plug into the power jack on the base of the cradle and attach the power supply to a power outlet.

If using the Datalogic Memor™ Single Ethernet Cradle, be sure that the switch is in the “USB” position.

During switch operation from USB position to Ethernet position

and vice versa the mobile computer must not be inserted in the NOTE cradle.

12	DATALOGIC MEMOR™

2.2RS232 CONNECTION

You can use a cable to directly connect the Datalogic Memor™ to a host computer to transfer data through the RS232 interface.

B C

Key:

A) Host Computer

C) Datalogic Memor™

B)94A051022 WIN-NET (HRS ST40X-18S-CV)

The Single Cradle can be connected to the Host by any standard 9-pin serial null-modem cable for RS232 communications.

Once the Host has been turned on, insert the Datalogic Memor™ mobile computer into the cradle.

Key:			D
Key:
A)	Host Computer	C)	Single Cradle
B)	94A051020 CAB-427	D)	*Power Supply (only necessary for
	Null-Modem		battery charging)

In this case the power supply is only necessary for battery charging. Insert the power supply plug into the power jack on the base of the cradle and attach the power supply to a power outlet.

If using the Datalogic Memor™ Single Ethernet Cradle, be sure that the switch is in the “USB” position.

During switch operation from USB position to Ethernet position

and vice versa the mobile computer must not be inserted in the NOTE cradle.

+ 59 hidden pages
