Gryphon™ I GM4100
General Purpose Handheld
Linear Imager Barcode Reader
Quick Reference Guide
Datalogic Scanning, Inc.
959 Terry Street
Eugene, Oregon 97402
Telephone: (541) 683-5700
Fax: (541) 345-7140
An Unpublished Work - All rights reserved. No part of the contents of this documentation or the procedures described therein
may be reproduced or transmitted in any form or by any means
without prior written permission of Datalogic Scanning, Inc. or
its subsidiaries or affiliates ("Datalogic" or “Datalogic Scanning”).
Owners of Datalogic products are hereby granted a non-exclusive, revocable license to reproduce and transmit this documentation for the purchaser's own internal business purposes.
Purchaser shall not remove or alter any proprietary notices,
including copyright notices, contained in this documentation
and shall ensure that all notices appear on any reproductions of
the documentation.
Should future revisions of this manual be published, you can
acquire printed versions by contacting your Datalogic representative. Electronic versions may either be downloadable from the
Datalogic website (www.scanning.datalogic.com) or provided
on appropriate media. If you visit our website and would like to
make comments or suggestions about this or other Datalogic
publications, please let us know via the "Contact Datalogic"
page.
Disclaimer
Datalogic has taken reasonable measures to provide information in this manual that is complete and accurate, however, Datalogic reserves the right to change any specification at any time
without prior notice.
Datalogic and the Datalogic logo are registered trademarks of
Datalogic S.p.A. in many countries, including the U.S.A. and the
E.U. All other brand and product names may be trademarks of
their respective owners.
Patents
Design Pat.: EP 870,787.
US Pat.: 5,144,118; 5,311,000; 5,481,098; 5,493,108; 5,929,421;
5,992,740; 6,098,883; 6,260,764; 6,443,360 B1; 6,517,003 B2;
6,631,846 B2; 6,808,114 B1; 6,817,525 B2; 6,997,385 B2; 7,075,663
B2; 7,387,246 B2.
European Pat.: 789,315 B1; 926,620 B1; 962,880 B1; 997,760 B1;
1,128,314 B1; 1,128,315 B1; 1,164,536 B1; 1,396,811 B1.
Additional patents pending.
Table of Contents
Statement of Agency Compliance ..........................................................1
FCC Class B Compliance Statement ............................................. 1
FCC RF Radiation Exposure Statement............................ 1
Canadian Notice ..................................................................................2
Software Product Policy .............................................................................. 6
Customers Under Software Support ........................................... 6
Setting Up the Reader ................................................................................. 7
Battery Safety ....................................................................................... 7
Install the Batteries ..........................................................................10
Configuring the Base Station .................................................................12
Changing the Base Station Position ..........................................12
Connecting the Base Station ........................................................14
Linking the Reader to a Base Station ....................................................17
System and Network Layouts .................................................................17
Using the BC40xx™ Radio Base ...............................................................19
Programming ................................................................................................20
Interface Selection ......................................................................................22
Keyboard Interface .....................................................................................27
Country Mode ...............................................................................................27
Caps Lock State ............................................................................................32
Numlock ..........................................................................................................33
Technical Specifications ............................................................................34
LED and Beeper Indications .....................................................................37
Error Codes ....................................................................................................39
Base Station Indications ............................................................................40
Ergonomic Recommendations ...............................................................41
Regulatory Information .............................................................................41
Warranty .........................................................................................................44
Securing the DC Power Cord (Optional) ....................... 14
RF Devices ...........................................................................................17
Stand Alone Layouts .......................................................................17
Base LEDs .............................................................................................19
Display ..................................................................................................20
Using the Programming Barcodes .............................................20
Select the Interface Type ...............................................................21
Configure Other Settings.................................................... 21
Resetting Standard Product Defaults............................. 21
Configuring the Interface ..............................................................22
Standard Factory Settings .............................................................27
Scancode Tables ...............................................................................27
Power Supply .....................................................................................41
Imager Labeling ................................................................................42
WEEE Statement ...............................................................................43
NOTES
Gryphon™ I GM4100
Quick Reference Guide
Statement of Agency Compliance
This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
FCC Class B Compliance Statement
The user is cautioned that changes or modifications not expressly
approved by the part responsible for compliance could void the
user’s authority to operate the equipment.
This equipment has been tested and found to comply with the
limits for a Class B digital device pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio or television
technician for help.
FCC RF Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits under Specific Absorption Rate (SAR) tests for portable devices operating closer than 20 cm to nearby persons, set forth in an
uncontrolled environment. The Gryphon M4100 cordless imaging reader has been demonstrated to meet these RF emissions
safety limits.
Quick Reference Guide 1
Statement of Agency Compliance
Canadian Notice
This equipment does not exceed the Class B limits for radio noise
emissions as described in the Radio Interference Regulations of
the Canadian Department of Communications.
Le present appareil numerique n’emet pas de bruits radioelectriques depassant les limites applicables aux appareils numeriques
de la classe B prescrites dans le Reglement sur le brouillage radioelectrique edicte par le ministere des Communications du Canada.
Do not attempt to open or otherwise service any components in the optics cavity. Opening or servicing any part
of the optics cavity by unauthorized personnel may vio-
CAUTION
late laser safety regulations.
2 Gryphon™ I GM4100
Statement of Agency Compliance
Datalogic Scanning, Inc.
GRYPHON™ PRODUCT SERIES
END USER LICENSE AGREEMENT
Notice to End User: The Datalogic Product you have acquired contains embedded Software, which is integral to the product's operation. This Software is
being provided to you under license, subject to the terms and conditions of this
Agreement. If you use the Datalogic Product, you will be deemed to have
accepted the terms and conditions of this Agreement. If you do not intend to be
bound to the terms of this Agreement, Datalogic is not will ing to license the
Software to you, you may not use the Datalogic Product or the Software, and
you must contact the party from whom you acquired the Datalogic Product for
instructions.
This End User Software License Agreement ("Agreement") is a legally binding agreement governing the licensing of the Software and Documentation by Datalogic Scanning, Inc. and its Affiliates ("Datalogic") to the entity or person who has purchased or
otherwise acquired a Datalogic Product ("End User"). For purposes of this Agreement,
any software that is associated with a separate end-user license agreement is licensed
to you under the terms of that license agreement. Datalogic and End User hereby
agree as follows:
1. Definitions.
1.1 "Affiliate" means a business entity currently existing or later acquired that controls,
is controlled by, or is under common control w ith Datalogic S.p.A.
1.2 "Documentation" means materials such as user's guides, program reference
guides, quick reference guides, manuals, or similar materials associated with or
related to the Datalogic Product, whether in printed, "online", or other form.
1.3 "Proprietary Information" means: (a) source code, object code, software, documentation, and any related internal design, system design, data base design,
algorithms, technology, technical data or information, implementation techniques, and trade secrets related to the Software, (b) any other trade secrets
marked appropriately or identified as proprietary or confidential, and (c) any
information that End User, under the circumstances, should recognize as confidential. Proprietary Information does not include any information that the
receiving party can establish was (1) in the public domain, (2) already in the
receiving party's possession or rightfully known prior to receipt, (3) rightfully
learned from a third party not in violation of any other's proprietary rights, or
(4) independently developed without access to Proprietary Information.
1.4 "Datalogic Product" means the Datalogic® Gryphon™ series scanner product,
including all embedded Software in and all Documentation related to such
product, which has been purchased or otherwise acquired by End User,
whether obtained directly or indirectly from Datalogic.
1.5 "Software" means any software or computer programs of Datalogic or its third
party licensors in machine readable form which is embedded in the Datalogic
Product, whether obtained directly or indirectly from Datalogic, including any
replacement, update, upgrade, enhancement or modification.
2. Scope Of License Granted.
2.1 Datalogic grants to End User a non-exclusive, non-transferable, perpetual license
to use the Software, solely on the Datalogic Product in which it is embedded
("designated Datalogic Product"), in machine-readable form only, solely for
End User's internal business purposes. This Agreement does not convey ownership of the Software to End User. Title to the Software shall be and remain
with Datalogic or the third party from whom Datalogic has obtained a licensed
right. As used in this Agreement, the term "purchase" or its equivalents when
applied to the Software shall mean "acquire under license." End User is not
entitled to receipt or use of the source code to any Software.
2.2 End User shall not copy, modify, decompile, disassemble, reverse engineer, or
otherwise reproduce or remanufacture the Software, whether modified or
unmodified, nor sell, assign, sublicense, distribute, lend, rent, give, or otherwise transfer the Software to any other person or organization, for purposes
other than as expressly provided in this Agreement, without Datalogic's prior
written consent.
3. Transfers, Support.
3.1 Any copying, installing, reproduction, remanufacture, reverse engineering,
electronic transfer, or other use of the Software on other than the designated
Datalogic Product will be a material breach of this Agreement. However, Data-
Quick Reference Guide 3
Statement of Agency Compliance
logic may elect not to terminate this Agreement or the granted licenses, but
instead may elect to notify End User that End User is deemed to have ordered
and accepted a license for each breaching use. End User shall pay Datalogic
the applicable list price for such licenses as of the date of such breach.
3.2 End User shall not sell, assign, sublicense, distribute, lend, rent, give, or otherwise transfer the Datalogic Product to any third party unless such third party
agrees with Datalogic in writing to be bound by the terms and conditions of
this Agreement. Any such transfer of the Datalogic Product absent such agreement shall be null and void.
3.3 End User may obtain support for Software from Datalogic at Datalogic's standard support fees and under Datalogic's standard support terms and conditions in effect at the time the support is requested.
4. Intellectual Property.
End User acknowledges that the Software constitutes valuable trade secrets of Datalogic or Datalogic's third party licensors and that the Software is protected by intellectual property laws and treaties. The license set forth in this Agreement does not transfer
to End User any ownership of Datalogic's or its third party licensors' copyrights, patents,
trademarks, service marks, trade secrets, or other intellectual property rights and End
User shall have no right to commence any legal actions to obtain such rights. End User
shall not remove, modify, or take any other action that would obscure any copyright,
trademark, patent marking, or other intellectual property notices contained in or on the
Datalogic Product.
5. Proprietary Information.
5.1 End User acknowledges that Proprietary Information is the confidential, proprietary, and trade secret property of Datalogic and Datalogic's third party
licensors and End User acquires no right or interest in any Proprietary Information.
5.2 End User shall not disclose, provide, or otherwise make available the Proprietary Information of Datalogic or its third party licensors to any person other
than End User's authorized employees or agents who are under confidentiality
agreement, and End User shall not use the Proprietary Information other than
in conjunction with use of the Datalogic Product exclusively for End User's
internal business purposes. End User shall take steps to protect the Proprietary
Information no less securely than if it were End User's own intellectual property.
5.3 The provisions of this Proprietary Information Section shall survive and continue for five (5) years after the termination of this Agreement.
6. Limited Warranty.
6.1 Datalogic warrants that, under normal use and operation, the Datalogic Product will conform substantially to the applicable Documentation for the period
specified in the Documentation. During this period, for all reproducible nonconformities for which Datalogic has been given written notice, Datalogic will
use commercially reasonable efforts to remedy nonconformities verified by
Datalogic. End User agrees to supply Datalogic with all reasonably requested
information and assistance necessary to help Datalogic in remedying such
nonconformities. For all defects reported to Datalogic within the warranty
period, Datalogic's liability is limited to providing End User with one copy of
corrections or responding to End User's problem reports according to Datalogic's standard assistance practices. Datalogic does not warrant that the product will meet End User's requirements or that use of the product will be
uninterrupted or error free, or that Datalogic's remedial efforts will correct any
nonconformance. This limited warranty does not cover any product that have
been subjected to damage or abuse, whether intentionally, accidentally, or by
neglect, or to unauthorized repair or unauthorized installation, and shall be
void if End User modifies the product, uses the product in any manner other
than as established in the Documentation, or if End User breaches any of the
provisions of this Agreement.
6.2 EXCEPT AS PROVIDED IN THIS AGREEMENT, THE DATALOGIC PRODUCT IS PROVIDED "AS IS" AND DATALOGIC MAKES NO WARRANTIES OF ANY KIND,
EXPRESS OR IMPLIED, WRITTEN OR ORAL, WITH RESPECT TO THE PRODUCT,
AND SPECIFICALLY DISCLAIMS THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
7. Infringement.
7.1 Datalogic will defend End User against any claim in a lawsuit that th e Datalogic
Product furnished hereunder infringe a United States patent or copyright of a
third party and Datalogic will pay any damages finally awarded against End
User by a court of competent jurisdiction that are attributable to such claim or
will pay End User's part of any settlement that is attributable to such claim,
4 Gryphon™ I GM4100
Statement of Agency Compliance
provided, that 1) End User notifies Datalogic promptly in writing of the claim,
2) Datalogic controls the defense or settlement of the claim, and 3) End User
cooperates fully with Datalogic in such defense or settlement. All notices of a
claim should be sent to Datalogic Scanning, Inc., Legal Department, 959 Terry
Street, Eugene, OR 97402.
7.2 In the defense or settlement of any such claim, Datalogic may, at its option, 1)
procure for End User the right to continue using the Datalogic Product, 2)
modify the Datalogic Product so that it becomes non-infringing, 3) replace the
Datalogic Product with an equivalent product not subject to such claim, or 4)
provide End User an opportunity to return the Datalogic Product and receive a
refund of the purchase price paid, less a reasonable allowance for use.
7.3 Datalogic shall have no liability to End User for claims of infringement based
upon 1) the use of any Datalogic Product in combination with any product
which Datalogic has not either furnished or authorized for use with such Datalogic Product 2) the use of any Datalogic Product designed, manufactured, or
modified to the specifications of End User, or 3) End User's modification of the
Datalogic Product without written authorization from Datalogic.
7.4 THE FOREGOING STATES DATALOGIC'S COMPLETE AND ENTIRE OBLIGATION
CONCERNING CLAIMS OF PATENT, COPYRIGHT, OR OTHER INTELLECTUAL
PROPERTY INFRINGEMENT, CANCELS AND SUPERCEDES ANY PRIOR AGREEMENTS, WHETHER ORAL OR WRITTEN, BETWEEN THE PARTIES CONCERNING
SUCH CLAIMS, AND WILL NOT BE MODIFIED OR AMENDED BY ANY PAST, CONTEMPORANEOUS, OR FUTURE AGREEMENTS OR DEALINGS BETWEEN THE PARTIES, WHETHER ORAL OR WRITTEN, EXCEPT AS SET FORTH IN A FUTURE
WRITING SIGNED BY BOTH PARTIES.
8. Limitation Of Liability.
EXCEPT AS PROVIDED IN SECTION 7, DATALOGIC SHALL NOT BE LIABLE FOR ANY CLAIMS
AGAINST END USER BY ANY OTHER PARTY. IN NO EVENT SHALL DATALOGIC'S LIABILITY
FOR DAMAGES, IF ANY, WHETHER BASED UPON CONTRACT, TORT (INCLUDING NEGLIGENCE), PRODUCT LIABILITY, STRICT LIABILITY, WARRANTY, OR ANY OTHER BASIS,
EXCEED THE PRICE OR FEE PAID BY END USER FOR THE DATALOGIC PRODUCT. UNDER NO
CIRCUMSTANCES SHALL DATALOGIC BE LIABLE TO END USER OR ANY THIRD PARTY FOR
LOST PROFITS, LOST DATA, INTERRUPTION OF BUSINESS OR SERVICE, OR FOR ANY OTHER
SPECIAL, CONSEQUENTIAL, CONTINGENT, INDIRECT, INCIDENTAL, PUNITIVE, EXEMPLARY,
OR OTHER SIMILAR DAMAGES, EVEN IF DATALOGIC HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
9. Government Restricted Rights; International Use.
9.1 Use, duplication, or disclosure of the Software by the U.S. Government is subject to the restrictions for computer software developed at private expense as
set forth in the U.S. Federal Acquisition Regulations at FAR 52.227-14(g), or
52.227-19 or in the Rights in Technical Data and Computer Software clause at
DFARS 252.227-7013(c)(1)(ii), whichever is applicable.
9.2 If End User is using the Datalogic Product outside of the United States, End
User must comply with the applicable local laws of the country in which the
Datalogic Product is used, with U.S. export control laws, and with the English
language version of this Agreement. The provisions of the "United Nations
Convention on International Sale of Goods" shall not apply to this Agreement.
10. Termination.
10.1 Either party may terminate this Agreement or any license granted under this
Agreement at any time upon written notice if the other party breaches any
provision of this Agreement.
10.2 Upon termination of this Agreement, End User immediately shall cease using
any nonembedded software and shall return to Datalogic or destroy all nonembedded software covered by this Agreement, and shall furnish Datalogic
with a certificate of compliance with this provision signed by an officer or
authorized representative of End User. For embedded software, End User
agrees to sign a waiver prepared by Datalogic concerning further use of the
embedded Software. End User's resumed or continued use of the embedded
Software after termination shall constitute End User's agreement to be bound
by the terms and conditions of this Agreement for such use.
11. General Provisions.
11.1 Entire Agreement; Amendment. This document contains the entire agreement
between the parties relating to the licensing of the Software and supersedes
all prior or contemporaneous agreements, written or oral, between the parties
concerning the licensing of the Software. This Agreement may not be
changed, amended, or modified except by written document signed by Datalogic.
11.2 Notice. All notices required or authorized under this Agreement shall be given in
Quick Reference Guide 5
Software Product Policy
writing, and shall be effective when received, with evidence of receipt. Notices
to Datalogic shall be sent to the attention of Contract Administration, Datalogic Scanning, Inc., 959 Terry Street, Eugene, OR 97402, or such other address
as may be specified by Datalogic in writing.
11.3 Waiver. A party's failure to enforce any of the terms and conditions of this Agreement shall not prevent the party's later enforcement of such terms and conditions.
11.4 Governing Law; Venue: This Agreement and the rights of the parties hereunder
shall be governed by and construed in accordance with the laws of the State of
Oregon U.S.A, without regard to the rules governing conflicts of law. The state
or federal courts of the State of Oregon located in either Multnomah or Lane
counties shall have exclusive jurisdiction over all matters regarding this Agreement, except that Datalogic shall have the right, at its absolute discretion, to
initiate proceedings in the courts of any other state, country, or territory in
which End User resides, or in which any of End User's assets are located.
11.5 Attorneys' Fees. In the event an action is brought to enforce the terms and conditions of this Agreement, the prevailing party shall be entitled to reasonable
attorneys' fees, both at trial and on appeal.
- END -
Software Product Policy
Datalogic reserves the right to ship its products with the latest
version of software/firmware available. This provides our customers with the very latest in Datalogic software technology.
The only exception to this policy is when the buyer has a signed
contract with Datalogic that clearly defines the terms and conditions for making software/firmware changes in products shipped
to the buyer.
Customers Under Software Support
Customers that elect to subscribe to Datalogic Software Maintenance and Support Agreement will receive 30 days advance notification of: (1) the release of a new software version; and/or (2)
discontinuation of any prior software version that will no longer
be supported. Datalogic will provide maintenance for a fee that
will assist customers in transitioning to the next software version.
If a customer is currently using the software version being discontinued, the customer may elect to transition to any one of the
newer versions, depending on the hardware in use.
To arrange for a Software Maintenance and Support Agreement
please contact your Datalogic sales person.
6 Gryphon™ I GM4100
Setting Up the Reader
Setting Up the Reader
Follow the steps below to connect and get your reader up and
communicating with its host.
1. Install the Batteries
2. Connecting the Base Station
3. Select the Interface Type
4. Configure Other Settings (if not using factory settings for
that interface)
Battery Safety
To install, charge and/or do any other action on the battery, follow the instructions in this manual.
Before installing the Battery, read “Battery Safety” on
the following pages. Datalogic recommends annual
replacement of rechargeable battery packs to ensure
NOTE
maximum performance.
Quick Reference Guide 7
Setting Up the Reader
Do not discharge the battery using any device except
for the scanner. When the battery is used in devices
other than the designated product, it may damage the
WARNING
battery or reduce its life expectancy. If the device
causes an abnormal current to flow, it may cause the
battery to become hot, explode or ignite and cause
serious injury.
Lithium-ion battery packs may get hot, explode or
ignite and cause serious injury if exposed to abusive
conditions. Be sure to follow the safety warnings
listed below:
In the event the battery pack leaks and the fluid gets
into your eye, do not rub the eye. Rinse well with
water and immediately seek medical care. If left
untreated, the battery fluid could cause damage to
the eye.
• Do not place the battery pack in fire or heat.
• Do not connect the positive terminal and negative terminal of the battery pack to each other
with any metal object (such as wire).
• Do not carry or store the batter y pack together
with metal objects.
• Do not pierce the battery pack with nails, strike
it with a hammer, step on it or otherwise subject it to strong impacts or shocks.
• Do not solder directly onto the batter y pack.
• Do not expose the battery pack to liq uids, or
allow the battery to get wet.
• Do not apply voltages to the battery pack contacts.
8 Gryphon™ I GM4100
Setting Up the Reader
Always charge the battery at 32° – 104°F (0° - 40°C) temperature range.
Use only the authorized power supplies, battery pack,
chargers, and docks supplied by your Datalogic reseller.
CAUTION
The use of any other power supplies can damage the
device and void your warranty.
Do not disassemble or modify the battery. The battery
contains safety and protection devices, which, if damaged, may cause the battery to generate heat, explode
or ignite.
Do not place the battery in or near fire, on stoves or
other high temperature locations.
Do not place the battery in direct sunlight, or use or
store the battery inside cars in hot weather. Doing so
may cause the battery to generate heat, explode or
ignite. Using the battery in this manner may also result
in a loss of performance and a shortened life expectancy.
Do not place the battery in microwave ovens, high-pressure containers or on induction cookware.
Immediately discontinue use of the battery if, while
using, charging or storing the battery, the battery emits
an unusual smell, feels hot, changes color or shape, or
appears abnormal in any other way.
Do not replace the battery pack when the device is
turned on.
Do not remove or damage the battery pack’s label.
Do not use the battery pack if it is damaged in any part.
Battery pack usage by children should be su pervised.
As with other types of batteries, Lithium-Ion (LI) batteries will lose capacity
over time. Capacity deterioration is noticeable after one year of service
whether the battery is in use or not. It is difficult to precisely predict the
finite life of a LI battery, but cell manufacturers rate them at 500 charge
cycles. In other words, the batteries should be expected to take 500 full discharge / charge cycles before needing replacement. This number is higher if
partial discharging / recharging is adhered to rather than full / deep discharging,
The typical manufacturer advertised useful life of LI batteries is one to three
years, depending on usage and number of charges, etc., after which they
should be removed from service, espe cially in mission critical applic ations. Do
not continue to use a battery that is showing excessive loss of capacity, it
should be properly recycled / disposed of and replaced. For most applications,
batteries should be replaced after one year of service to maintain customer
satisfaction and minimize safety concerns.
Collect and recycle waste batteries separately from the device in comply with
European Directive 2006/66/EC, 2002/95/EC, 2002/96/EC and subsequent
modifications, US and China regulatory and others laws and regulations
about the environment.
Quick Reference Guide 9
Setting Up the Reader
Connector
Screw
Screw
Screw
Install the Batteries
Before installing the Battery, read “Battery Safety” on
the preceding pages. Datalogic recommends annual
replacement of rechargeable battery packs to ensure
NOTE
To install or change the battery of your reader, you must:
1. With a screwdriver, unscrew the battery cover screw.
2. Unplug the three screws securing the battery holder, and
maximum performance.
unplug the white connector.
10 Gryphon™ I GM4100
Setting Up the Reader
Pass-t hrough
hole
3. Carefully lift out the gold contacts circuit, and remove
the battery holder while letting the white connector pass
through the hole in the battery holder (as shown in the
picture below).
4. Remove the old battery from its place (if present), and
insert the new battery in the same position.
5. Replace the battery holder, plug in the connector and
return the contacts circuit to its previous location.
When inserting the new battery into the handle, take
care to position the battery and the connector as
shown.
NOTE
6. Insert the cover in the handle and screw it back into
place.
Quick Reference Guide 11
Configuring the Base Station
Standing
Horizontal
Standing,
Horizontal
Horizontal
or Vertical
Only
Configuring the Base Station
The base charger/station may be configured in desk application to
hold the reader in two different positions, either a horizontal or
standing position, in order to provide the most comfortable use
depending on needs.
Changing the Base Station Position
The base station is configured by installing one of two sets of mechanical parts that come with the cordless kit. The default mounts
(shown below) provide three options: vertical (wall) mounting,
standing (45°), or horizontal mounting with a higher mechanical
retention of the scanner. Use the other mounts only for horizontal
mounting, with lower retention of the scanner. The different
parts may be interchanged to customize retention preferences.
A tool such as a rigid pen or a flat screwdriver can be used
to change the mounts. Do not allow it to touch the contacts.
1. Insert the appropriate parts for the desired base station
position, as shown below.
12 Gryphon™ I GM4100
Configuring the Base Station
Tab
Tab
Horizontal
Standing
2. Using your thumbs, push open the plastic tabs on the
bottom of the base to free the wing holders.
3. The stand can now be repositioned in either horizontal
or standing position.
Quick Reference Guide 13
Configuring the Base Station
Base
Station
I/F Cable
AC/DC
Adapter
DC Power
Cord
Wall plug
Connector
Connecting the Base Station
Figure 1 shows how to connect the Base Station to a terminal, PC
or other host device. Turn off the host before connection and consult the manual for that equipment (if necessary) before proceeding. Connect the interface cable before applying power to the Base
Station.
Gryphon Mobile can also be Powered by the Terminal. The
external power supply is recommended but not necessary.
When powered by the Terminal, the battery charger is
automatically set as Slow charge.
NOTE
Base Station Connection and Routing:
Fully insert the Power Cable and Interface (I/F) Cable connectors into their respective ports
in the underside of the Base Station (see Figure 1). Then connect
to an AC Adapter, and plug the AC power cord into the (wall)
outlet.
Figure 1. Connecting the Base Station
Securing the DC Power Cord (Optional)
The DC power cord for the adapter can be secured to the bottom
of the base in order to maximize the mechanical retention of the
cable itself. The routing of the power cord can be changed to accommodate the base station positioning: horizontal, stand or wall
mounting. The cables can be looped around to the front of the
Base Station, or fed directly out the back of the Base Station, as
shown in Figure 2 on page 15.
14 Gryphon™ I GM4100
Configuring the Base Station
Figure 2. Options for routing the DC cord
Please refer to the arrows depicted on the bottom of the base when
placing the cables, detailed in Figure 3.
Figure 3. Arrows showing routing
Host Connection:
Verify before connection that the reader’s cable
type is compatible with your host equipment. Most connections
pl ug di rect ly in to th e hos t de vice a s sh own i n Fig ure 4 on pa ge 16 .
Keyboard Wedge interface cables have a ‘Y’ connection where its
female end mates with the male end of the cable from the keyboard and the remaining end at the keyboard port on the terminal/PC.
Quick Reference Guide 15
Configuring the Base Station
U
S
B
I
B
M
K
e
y
b
o
a
r
d
W
e
d
g
e
W
a
n
d
or...
or...
or...
Insert
Paper Clip
Figure 4. Connecting to the Host
Power Connection :
Plug the AC Adapter in to an approved AC
wall socket with the cable facing downwards (as shown in Figure
1) to prevent undue strain on the socket.
Gryphon Mobile can also be Powered by the Terminal. The
external power supply is recommended but not necessary.
When powered by the Terminal, the battery charger is automatically set as Slow charge.
NOTE
Disconnecting the Cable:
To detach the cable, insert a paper clip
or similar object into the hole on the base, as shown in Figure 5.
Figure 5. Disconnecting the Cable
16 Gryphon™ I GM4100
Linking the Reader to a Base Station
Unlink
Linking the Reader to a Base Station
RF Devices
For RF devices, before configuring the interface it is necessary to
link the handheld with the base.
To link the handheld and the base, press the trigger to wake it and
place it on the base. If the reader was previously linked to another
base, you must first scan the Unlink action command before relinking to the new base.
System and Network Layouts
Stand Alone Layouts
Figure 6. Single Reader Layout
Quick Reference Guide 17
System and Network Layouts
Figure 7. Multiple Reader Layout
In stand alone systems, each cradle is connected to a single Host.
Figure 8. Multiple Stand Alone Layouts
Many stand alone connections can operate in the same physical
area without interference, provided all readers and cradles in the
system have different addresses.
18 Gryphon™ I GM4100
Using the BC40xx™ Radio Base
YELLOW LED
RED LED —
GREEN LED
BUTTON
Using the BC40xx™ Radio Base
Base LEDs
LEDs on the Gryphon I Base provide information about the
Base’s status, as shown in Figure 9.
Figure 9. Gryphon I Base LEDs
The following table describes the significance of each LED:
LED STATUS
Yellow On = Base is powered
Power o n / Data
Yellow Blinking = Base receives data and
commands from the Host or the Reader.
Charging Red On = the Battery is in progress.
Charge completed Green On = the Battery is completely charged.
Charging +
Charge completed
A button is available to force device connection via the Datalogic
Aladdin Software tool, and for paging the scanner when bidirectional connection is activated. Refer to the Gryphon I Product
Reference Guide (PRG) for a more detailed explanation.
Red and Green Blinking together = the Reader
is not correctly placed onto the Base.
Quick Reference Guide 19
Programming
Display
The Gryphon I is also available with an optional Display. The
FSTN Display with white LED backlight provides additional information.
Figure 10. Gryphon™ I Display
Programming
The reader is factory-configured with a set of standard default features. After scanning the interface barcode from the Interfaces section, you can select other options and customize your reader
through use of the instructions and programming barcodes available in the Gryphon™ I GD4100/GM4100 Product Reference
Guide (PRG). Check the corresponding features section for your
interface, and also the Data Editing and Symbologies chapters of
the PRG.
Using the Programming Barcodes
This manual contains barcodes which allow you to reconfigure
your reader. Some programming barcode labels, like the Standard
Product Default Settings on page 21, require only the scan of that
single label to enact the change.
Other barcodes require the reader to be placed in Programming
Mode prior to scanning them. Scan an ENTER/EXIT barcode
once to enter Programming Mode, scan the desired parameter settings, then scan the ENTER/EXIT barcode a second time to accept your changes, exit Programming Mode and return the reader
to normal operation.
20 Gryphon™ I GM4100
Programming
Standard Product Default Settings
Select the Interface Type
Upon completing the physical connection between the reader and
its host, proceed directly to Interface Selection on page 22 for information and programming for the interface type the reader is
connected to (for example: RS-232, Keyboard Wedge, USB, etc.)
and scan the appropriate barcode to select your system’s correct
interface type.
Configure Other Settings
Additional programming barcodes are available in the
Gryphon™ I GD4100/GM4100 PRG to allow for customizing
programming features. If your installation requires different programming than the standard factory default settings, refer to the
PRG.
Resetting Standard Product Defaults
If you aren’t sure what programming options are in your reader,
or you’ve changed some options and want the factory settings restored, scan the Standard Product Default Settings barcode below
to copy the factory configuration for the currently active interface
to the current configuration.
Factory defaults are based on the interface type. Configure the reader for the correct interface before scanning this label.
NOTE
Quick Reference Guide 21
Interface Selection
Interface Selection
Each reader model will support one of the following sets of host
interfaces:
General Purpose Models:
board Wedge
Retail Point of Sale Models :
46XX
Configuring the Interface
Scan the programming barcode which selects the appropriate interface type matching the system the reader will be connected to.
Next, proceed to the corresponding chapter in the Gryphon™ I
GD4100/GM4100 PRG to customize any settings and features
associated with that interface.
Unlike some other programming features and options,
interface selections require that you scan only one
programming barcode label. DO NOT scan an ENTER/
EXIT barcode prior to scanning an interface selection
barcode.
Some interfaces require the sc anner to start in the dis-
NOTE
abled state when powered up. If additional scanner
configuration is desired while in this state, pull the
trigger and hold for 5 seconds. The scanner will change
to a state that allows programming with barcodes.
RS-232, RS-232 OPOS, USB, Key-
RS-232, RS-232 OPOS, USB, IBM
RS-232
RS-232 standard interface
Select RS232-STD
RS-232 Wincor-Nixdorf
Select RS232-WN
22 Gryphon™ I GM4100
RS-232 (continued)
RS-232 for use with OPOS/UPOS/JavaPOS
Select RS-232 OPOS
USB Com to simulate RS-232 sta ndard interface
Interface Selection
Select USB-COM-STD
a
IBM
IBM-46xx Port 5B reader inter face
Select IBM-P5B
IBM-46xx Port 9B reader inter face
Select IBM-P9B
USB-OEM
USB-OEM
(can be used for OPOS/UPOS/JavaPOS)
Select USB-OEM
a. Download the correct USB Com driver from www.datalogic.com
Quick Reference Guide 23
Interface Selection
KEYBOARD
AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80 , 90 & 95 w/
Keyboard Wedge for IBM AT PS2 with standard key encoding but without ex ternal
AT, PS/2 25-286, 30-286, 50, 50Z, 60 , 70, 80, 90 & 95
Keyboard Wedge for IBM AT PS2 with alternate key encoding but without exter-
Standard Key Encoding
Select KBD-AT
keyboard
Select KBD-AT-NK
w/Alternate Key
Select KBD-AT-ALT
nal keyboard
Select KBD-AT-ALT-NK
24 Gryphon™ I GM4100
Interface Selection
KEYBOARD (continued)
PC/XT w/Standard Key Encoding
Select KBD-XT
Keyboard Wedge for IBM Terminal 3153
Select KBD-IBM-3153
Keyboard Wedge for IBM Terminals 31xx , 32xx, 34xx, 37xx make only keyboard
Select KBD-IBM-M
Keyboard Wedge for IBM Terminals 31xx, 32xx, 34xx, 37xx make break keyboard
Select KBD-IB M-MB
Quick Reference Guide 25
Interface Selection
KEYBOARD (continued)
Keyboard Wedge for DIGITAL Terminals
USB Keyb oard with st andard key enc oding
USB Keyboard with alternate key encoding
Select USB Alternate Keyboard
USB Keyboard for Apple computers
VT2xx, VT3xx, VT4xx
Select KBD-DIG-VT
Select USB Keyboard
Select USB-KBD-APPLE
WAND EMULATION
Wand Emul atio n
Select WAND
26 Gryphon™ I GM4100
Keyboard Interface
Keyboard Interface
Use the programming barcodes to select options for USB Keyboard and Wedge Interfaces.
Standard Factory Settings
Reference the Gryphon™ I GD4100/GM4100 Product Reference Guide (PRG) for a listing of standard factory settings.
Scancode Tables
Reference the Gryphon™ I GD4100/GM4100 PRG for information about control character emulation which applies to keyboard interfaces.
Country Mode
This feature specifies the country/language supported by the keyboard. Only the following interfaces support ALL Country
Modes.
• USB Keyboard (without alternate key encoding)
• AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80, 90 & 95
w/Std Key Encoding
• Keyboard Wedge for IBM AT PS2 with standard key
encoding but without external keyboard
• AT, PS/2 25-286, 30-286, 50, 50Z, 60, 70, 80, 90 & 95
without Alternate Key
• Keyboard Wedge for IBM AT PS2 without alternate key
encoding but without external keyboard
All other interfaces support ONLY the following Country Modes:
U.S., Belgium, Britain, France, Germany, Italy, Spain, Sweden.
Quick Reference Guide 27
Country Mode
COUNTRY MODE
ENTER/EXIT PROGRAMMING MODE
Country Mode = U.S.
Country Mode = Belgium
Country Mode = Britain
Country Mode = Croatia*
*Supports only the interfaces listed in the Country Mode feature
description
28 Gryphon™ I GM4100
COUNTRY MODE (continued)
Country Mode = Czechoslovakia*
Country Mode = Denmark*
Country Mode = France
Country Mode
Country Mode = Germany
Country Mode = Hungary*
Country Mode = Italy
*Supports only the interfaces listed in the Country Mode feature
description
Quick Reference Guide 29
Country Mode
COUNTRY MODE (continued)
Country Mode = Japanese 106-key*
Country Mode = Norway*
Country Mode = Poland*
Country Mode = Portugal*
Country Mode = Romania*
Country Mode = Slovakia*
*Supports only the interfaces listed in the Country Mode feature
description
30 Gryphon™ I GM4100
Country Mode
COUNTRY MODE (continued)
Country Mode = Spain
Country Mode = Sweden
Country Mode = Switzerland*
*Supports only the interfaces listed in the Country Mode feature
description
Quick Reference Guide 31
Caps Lock State
Caps Lock State
This option specifies the format in which the reader sends character data. This applies to keyboard wedge interfaces. This does not
apply when an alternate key encoding keyboard is selected.
ENTER/EXIT PROGRAMMING MODE
Caps Lock St ate = Caps Lock OFF
Caps Lock St ate = Caps Lock ON
Caps Lock State = AUTO Caps Lock Enable
32 Gryphon™ I GM4100
Numlock
Numlock
This option specifies the setting of the Numbers Lock (Numlock)
key while in keyboard wedge interface. This only applies to alternate key encoding interfaces. It does not apply to USB keyboard.
ENTER/EXIT PROGRAMMING MODE
Numlock = Numlock key unchanged
Numlock = Numlock key toggled
Quick Reference Guide 33
Technical Specifications
Technical Specifications
The following table contains Physical and Performance Characteristics, User Environment and Regulatory information.
Item Description
Physical Characteristics
Color
Dimensions
Weight (without cable)
Electrical Characteristics
Battery Type Li-Ion battery pack
Charge time for full charge
from full discharge
Operating autonomy
(continuous reading)
Cradle consumption
and DC input supply range
Performance Characteristics
White/Gray
Black/Gray
Height 7.1”/181 mm
Length 3.9”/100 mm
Width 2.8”/71 mm
Approximately
8.7 ounces/246 g (reader with display)
8.7 ounces/246 g (base charger)
4 hours with external power supply adapter
max 22h hours with Host power
(in this case no supply adapter is needed)
a
50,000 reads
(typical)
b
Volt 4.75-14 VDC; Power <8W
;
Imax 500mA when in host/bus powered mode
a
b
.
Light Source LEDs
Roll (Tilt) Tolerance ± 35° from normal
Pitch Tolerance ± 65°
Skew (Yaw) Tolerance ± 65°
Field of View 10” (25.4cm) wide at 12.5” (31.8cm) from the reader
3 mil – 2.9” to 4.7” (7.5cm to 12cm)
c
d
– 1.2” to 23.6” (3cm to 60cm)
Depth of Field (Typical)
13 mil
20 mil – 1.2” to 31.5” (3cm to 80cm)
Minimum Element Width 3 mil
34 Gryphon™ I GM4100
Item Description
Print Contrast Minimum 15% minimum reflectance
UPC/EAN/JAN, P2 /P5 add-ons; Code 39; Italian
Pharmacode 39; Code 128; C128 ISBT; Code 128 add-
Decode Capability
ons; I 2 of 5; Standard 2 of 5; Code 11;Codabar; EAN
128; Code 93; MSI; GS1 DataBar™ Omnidirectional,
GS1 DataBar™ Limited, GS1 DataBar™ Expanded;
Code4, Code5.
RS-232 Std, RS-232 Wincor-Nixdorf, RS-232 OPOS,
IBM 46xx (ports5B and 9B), USB Com Std., USB Keyboard, USB Alternate Keyboard, USB OEM, Keyboard
Wedge (AT with or w/o Alternate Key, IBM AT PS2
d
Interfaces Suppor ted
with or w/o Alternate Key, PC-XT, IBM 3153, IBM Terminals 31xx, 32xx,34xx, 37xx make only and make
break keyboard, Digital Terminals VT2x, VT3xx ,
VT4xx, and Apple) and Wand Emulation.
User Envir onment
Operating Temperature 32° to 122° F (0° to 50° C)
Charging Temperature 32° to 104° F (0° to 40° C)
Storage Temperature -4° to 158° F (-20° to 70° C)
Technical Specifications
Humidity
Drop Specifications
Operating: 5% to 90% relative humidity,
non-condensing
Scanner withstands 18 drops from 1.8 meters
(5.9 feet) to concrete
Ambient Light Immunity Up to 100,000 Lux
Contaminants Spray/rain
Dust/particulates
IEC 529-IP52 (scanner only)
ESD Level 16 KV
a. Charge Times are much lower when battery is within daily typical operat-
ing condition.
b. Typical input current measured under factory default configuration.
c. 13 mils DOF based on EAN. All others are Code 39. All labels grade A, typi-
cal environmental light, 20°C, label inclination 10°
d. See Interface Selection on page 22 for a listing of available interface sets
by model type.
Quick Reference Guide 35
Technical Specifications
Item Description
Regulatory
Electrical S afety UL 60950, CSA C22.2 No. 60950, IEC 60950
EMI/RFI
433 MHz model
Europe - CE, Russia – Gost;
Australia – Ctick;
China – SRRC;
Singapore – IDA,
910 MHz model
USA/Canada – FCC/IC;
Pendi ng:
Mexico – NOM + Cofetel
Pendi ng:
Brasile – Anatel
LED class safety IEC Class 1
Radio Features
433MHz model 910MHz model
Working Center Frequency 433.920 MHz 910.000 MHz
Range (in open air) 30 m 15 m
System Configuration
433MHz model 910MHz model
Max. number of devices per
base station
16 16
36 Gryphon™ I GM4100
LED and Beeper Indications
LED and Beeper Indications
The reader’s beeper sounds and its LED illuminates to indicate
various functions or errors on the reader. An optional “Green
Spot” also performs useful functions. The following tables list
these indications. One exception to the behaviors listed in the tables is that the reader’s functions are programmable, and may or
may not be turned on. For example, certain indications such as
the power-up beep can be disabled using programming barcode
labels.
INDICATION DESCRIPTION LED BEEPER
Reader beeps
four times at
highest frequency and volume upon
power-up.
Power-up Beep
The reader is in
the process of
powering-up.
LED behavior
for this indica-
A label has been
Good Read Beep
ROM Failure
Limited Scanning Label Read
Reader Active
Mode
Quick Reference Guide 37
successfully
scanned by the
reader.
There is an error
in the reader's
softwa re/programming
Indicates that a
host connection
is not established
when the IBM or
USB interface is
enabled.
The reader is
active and ready
to scan.
tion is configurable via the
feature “Good
Read: When to
Indicate”
(see the PRG for
information.)
Flashes
N/A
The LED is lit
steadily
a
The reader will
beep once at current frequency,
volume, mono/
bi-tonal setting
and duration
upon a successful label scan.
Reader sounds
one error beep at
highest volume.
Reader 'chirps'
six times at the
highest frequency and current volume.
N/A
LED and Beeper Indications
INDICATION DESCRIPTION LED BEEPER
Reader
Disabled
The reader has
been disabled by
the host.
The LED blinks
continuously
N/A
While in Stand
Mode or Trigger
Green Spot is on
continuously
Stand Mode the
green spot shall
be on while in
N/A N/A
stand watch
state.
Upon successful
read of a label,
Green Spot
flashes momentarily
turn the green
spot on for the
time specified by
N/A N/A
the software shall
a
the configured
value.
Programming Mode - The following indications ONLY occur when the reader is
in Programming Mode.
Label Programming Mode
Entry
Label Programming Mode
Rejection of
Label
A valid programming label has
been scanned.
A label has been
rejected.
LED blinks con-
tinuously
N/A
Reader sounds
four low fre-
quency beeps.
Reader sounds
three times at
lowest frequency and current volu me.
In cases where
multiple labels
Label Programming Mode
Acceptance of
Part ial Labe l
must be scanned
to program one
feature, this indication acknowledges each
portion as it is
N/A
Reader sounds
one short beep at
highest fre-
quency and cur-
rent volu me.
successfully
scanned.
38 Gryphon™ I GM4100
Error Codes
INDICATION DESCRIPTION LED BEEPER
Configuration
Label Programming Mode
Acceptan ce of
Programming
option(s) have
been successfully
programmed via
labels and the
reader h as exited
Programming
Mode.
N/A
Reader sounds
one high frequency beep and
4 low frequency
beeps followed
by reset beeps.
Label Programming Mode Cancel Item Entr y
a. Except when in sleep mode or when a Good Read LED Duration other than 00
is selected
Cancel label has
been scanned.
N/A
Reader sounds
two times at low
frequency and
current volume.
Error Codes
Upon startup, if the reader sounds a long tone, this means the
reader has not passed its automatic Selftest and has entered FRU
(Field Replaceable Unit) isolation mode. If the reader is reset, the
sequence will be repeated. The following table describes the LED
flashes/beep codes associated with an error found.
NUMBER OF
LED
FLASHES/
BEEPS
1 Configuration
2Interface PCB
4 Reader Module
5
6Digital PCB
ERROR CORRECTIVE ACTION
Laser Pointer (if so
equipped)
Contact Helpdesk for
assistance
14 CPLD/Code Mismatch
Quick Reference Guide 39
Base Station Indications
Base Station Indications
INDICATION LEDS
Power- up Comple te Yellow L ED on
Reader Disabled by the HOST or the communication with HOST is not established
Data/labels are transmitted to the HOST
Programming Mode Yellow LED blinks quickly
Configuration alignment with the HH is in
progress
Battery charger in progress Red LED on
Battery charger complete Green LED on
Battery charger error
No HH is placed on the cradle Red and Green LEDs off
Yel low LED bl ink ing ~1H z
Yellow LEDs turned off for
100mSec
Red LED blinks quickly
Green LED and Red LEDs blink
alternatively ~1Hz
40 Gryphon™ I GM4100
Ergonomic Recommendations
Ergonomic Recommendations
In order to avoid or minimize the potential risk of ergonomic injury follow the recommendations below. Consult
CAUTION
• Reduce or eliminate repetitive motion
• Maintain a natural position
• Reduce or eliminate excessive force
• Keep objects that are used frequently within easy reach
• Perform tasks at correct heights
• Reduce or eliminate vibration
• Reduce or eliminate direct pressure
• Provide adjustable workstations
•Provide adequate clearance
• Provide a suitable working environment
• Improve work procedures.
with your local Health & Safety Manager to ensure that
you are adhering to your company’s safety programs to
prevent employee injury.
Regulatory Information
All models are designed to be compliant with rules and regulations in locations they are sold and will be labeled as required.
Any changes or modifications to equipment, not expressly approved by Datalogic could void the user's authority to operate the
equipment.
Power Supply
This device is intended to be connected to a UL Listed/CSA Certified computer which supplies power directly to the reader or else
be supplied by UL Listed/CSA Certified Power Unit marked
“Class 2” or LPS power source rated 5-14V minimum 900mA,
which supplies power directly to the Base/Charger via the power
connector of the Base itself.
Quick Reference Guide 41
Regulatory Information
R
CUS
239045
10
DATALOGICSCANNING INC.
EUGENE ,OREGON
USA
SEEP
ACK
AGEFOR
PATENTLISTING
CLAS S 1LEDPRODUCT
N263
Scanner Regulatory Label
Base Station Label
Imager Labeling
Labels are shown here to illustrate their location only. Please view
the labels on your product for actual details.
42 Gryphon™ I GM4100
Regulatory Information
WEEE Statement
Waste Electrical and Electronic Equipment
(WEEE) Statement
English
For information about the disposal of Waste El ectrical and Electronic Equipment (WEEE),
please refer to the website at www.scanning.datalogic.com.
Italian
Per informazioni sullo smaltimento delle apparecchiature elettriche ed elettroniche
consultare il sito Web www.scanning.datalogic.com.
French
Pour toute information relative à l’élimination des déchets électroniques (WEEE),
veuillez consulter le site internet www.scanning.datalogic.com.
German
Informationen zur Entsorgung von Elektro- und Elektronik- Altgeräten (WEEE) erhalten
Sie auf der Webseite www.scanning.datalogic.com.
Spanish
Si desea información acerca de los procedimientos para el desecho de los residuos del
equipo eléctrico y electrónico (WEEE), visite la página Web
www.scanning.datalogic.com.
Portu guese
Para informações sobre a disposição de Sucatagem de Equipamentos Elétricos e
Eletrônicos (WEEE -Waste Electrical and Electronic Equipment), consultar o site web
www.scanning.datalogic.com.
Chinese
有关处理废弃电气电子设备 (WEEE) 的信息， 请参考 Datalogic
公司的网站： http://www.scanning.datalogic.com/。
Japanese
廃電気電子機器 (ＷＥＥＥ) の処理についての関連事項は
Datalogic のサイト www.scanning.datalogic.com をご参照下さ
い。
Quick Reference Guide 43
Warranty
Warranty
Datalogic warrants to Customer that Datalogic's products will be free from defects in
materials and workmanship for a period of 3 years from product shipment. This warranty does not extend to batteries and cables. As consumable items batteries and
cables carry a 90 day warranty from time of purchase for DOA (dead on arrival)
defects. In order to obtain service under this Warranty, Customer must notify Datalogic of the claimed defect before the expiration of the Warranty period and obtain
from Datalogic a return authorization number for return of the product to designated
Datalogic service center. If Datalogic determines Customer’s claim is valid, Datalogic
will repair or replace product without additional charge for parts and labor. Customer
shall be responsible for packaging and shipping the product to the designated Datalogic service center, with shipping charges prepaid. Datalogic shall pay for the return
of the product to Customer if the shipment is to a location within the country in wh ich
the Datalogic service center is located. Customer shall be responsible for paying all
shipping charges, duties, taxes, and any other charges for products returned to any
other locations.
Warranty is subject to the limitations and exclusions set forth in the paragraphs that
follow.
WARRANTY SET FORTH ABOVE IS IN LIEU OF ANY OTHER WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING MERCHANTABILITY AND FITNESS.
Exclusions
Warranty coverage shall not apply to any claimed defect, failure or damage whic h
Datalogic determines was caused by: improper use of product; failure to provide
product maintenance, including but not limited to cleaning of the upper window in
accordance with product manual; installation or service of product by other than Datalogic representatives; use of product with any other instrument, equipment or apparatus; modification or alteration of product. External cables and replacement of upper
window/cartridge due to scratchi ng, stains or other degradation will not be covered
under the Warranty. External power supplies returned for service must be accompanied by the original product for performance of service.
Limitation of Liability
Datalogic's REPAIR OR REPLACEMENT OF DEFECTIVE PRODUCT AS SET FORTH ABOVE
IS THE CUSTOMER’S SOLE AND EXCLUSIVE REMEDY ON ACCOUNT OF CLAIMS OF
BREACH OF WARRANTY OR PRODUCT DEFECT. UNDER NO CIRCUMSTANCES WILL Datalogic BE LIABLE TO CUSTOMER OR ANY THIRD PARTY FOR ANY LOST PROFITS, OR
ANY INCIDENTAL, CONSEQUENTIAL IN-DIRECT, SPECIAL OR CONTINGENT DAMAGES
REGARDLESS OF WHETHER Datalogic HAD ADVANCE NOTICE OF THE POSSIBILITY OF
SUCH DAMAGES.
Assignment
Customer may not assign or otherwise transfer its rights or obligations under Warranty except to a purchaser or transferee of product. No attempted assignment or
transfer in violation of this provision shall be valid or binding upon Datalogic.
Risk of Loss
Customer shall bear risk of loss or damage for product in transit to Datalogic. Datalogic shall assume risk of loss or damage for product in Datalogic's possession or
product being returned to Customer by Datalogic, except such loss or damage as may
be caused by the negligence of Customer, its agents or employees. In the absence of
specific written instructions for the return of product to Customer, Datalogic will
select the carrier, but Datalogic shall not thereby assume any liability in connection
with the return shipment.
44 Gryphon™ I GM4100
NOTES
Warranty
Quick Reference Guide 45
Warranty
NOTES
46 Gryphon™ I GM4100
09
EC-056
Rev.: 0
Pag.: 1 d i 1
DECLARATION OF CONFORMITY
Datalogic Scanning Group Srl
Via S. Vitali no, 13
Lippo di Calderara di Reno (BO)
40012 Italy
dichiara che
declares that the
déclare que le
bescheinigt, daß das Gerät
declare que el
Gryphon GM 41xx ; Cordless Barcode Reader
Gryphon BC 40xx ; Cordless Base Station /Charger
Gryphon CHR-GM40 ; Charger Only Base
e tutti i suoi modelli
and all its models
et tous ses modèles
und seine Modelle
y todos sus modelos
sono conformi alle Direttive del Consiglio Europeo sottoelencate:
are in conformity with the requirements of the European Council Directives listed below:
sont conformes aux spécifications des Directives de l'Union Européenne ci-dessous:
den nachstehenden angefüh rten Direktiven des Europäischen Rats:
cumple con los requisitos de las Directivas del Consejo Europeo, según la lista siguiente:
1999/5/EEC R&TTE
Questa dichiarazione è basata sulla conformità dei prodotti alle norme seguenti:
This declaration is based upon compliance of the products to the following standards:
Cette déclaration repose sur la conformité des produits aux normes suivantes:
Diese Erklärung basiert darauf, daß das Produkt den folgenden Normen entspricht:
Esta declaración se basa en el cumplimiento de los productos con las siguientes normas:
ETSI EN 301 489-3 v1.4.1, August 2002 : E
ETSI EN 300 220-3 v1.1.1, September 2000 : E
EN 60950-1, December 2001 : I
Lippo di Calderara, February 24th , 2009 Ruggero Cacioppo
LECTROMAGNETIC COMPATIBILITY AND RADIO SPECTRUM
MATTERS (ERM); ELECTROMAGNETIC COMPATIBILITY (EMC)
STANDARD FOR RADIO EQUIPMENT AND SERVICES; PART 3:
PECIFIC CONDITIONS FOR SHORT-RANGE DEVICES (SRD)
S
OPERATING ON FREQUENCIES BETWEEN 9KHZ AND 40GHZ
LECTROMAGNETIC COMPATIBILITY AND RADIO SPECTRUM
MATTERS (ERM); SHORT RANGE DEVICES (SRD); RADI O
TO BE USED IN THE 25MHZ TO 1000MHZ
EQUIPMENT
FREQUENCY
RANG E WITH POWER LEVELS RANGI NG UP TO
500MW; PART 3: HARMONIZED EN COV ERING ESSENTIAL
REQUIREMENTS
UNDER ARTICLE 3.2 OF THE R&TTE DIRECTIVE
NFORMATION TECHNOL OGY EQUIPMENT - SAFETY -
P
ART 1 : GENERAL REQUIREMENTS
Quality Assurance Manager
Australia
Datalogic Scanning Pty Ltd
Telephone: [61] (2) 9870 3200
australia.scanning@datalogic.com
France and Benelux
Datalogic Scanning SAS
Telephone: [33].01.64.86.71.00
france.scanning@datalogic.com
Germany
Datalogic Scanning GmbH
Telephone: 49 (0) 61 51/93 58-0
germany.scanning@datalogic.com
India
Datalogic Scanning India
Telephone: 91- 22 - 64504739
india.scanning@datalogic.com
Italy
Datalogic Scanning SpA
Telephone: [39] (0) 39/62903.1
italy.scanning@datalogic.com
Japan
Datalogic Scanning KK
Telephone: 81 (0)3 3491 6761
japan.scanning@datalogic.com
Latin America
Datalogic Scanning, Inc
Telephone: (305) 591-3222
latinamerica.scanning@datalogic.com
Singapore
Datalogic Scanning Singapore PTE LTD
Telephone: (65) 6435-1311
singapore.scanning@datalogic.com
Iberia
Datalogic Scanning SAS Sucursal en
España
Telephone: 34 91 746 28 60
spain.scanning@datalogic.com
United Kingdom
Datalogic Scanning LTD
Telephone: 44 (0) 1582 464900
uk.scanning@datalogic.com
www.scanning.datalogic.com
Datalogic Scanning, Inc.
959 Terry Street
Eugene, OR 97402
USA
Telephone: (541) 683-5700
Fax: (541) 345-7140
©2009 Datalogic Scanning, Inc. 820002384 (Rev. D) 9/09
Loading...
