Owner’s Use and Care Guide

Guide d’utilisation et soin de Propriètaire

MICROWAVE OVEN FOUR À MICRO-ONDES

Model • Modèle • ModeloDMW7700BLDB / WDB

Danby Products Limited, Guelph, Ontario, Canada N1H 6Z9

Danby Products Inc., Findlay, Ohio, USA 45840

V2.01.11. DM

Contents

MICROWAVE OVEN



Owner’s Use and Care Guide .............................

1-15

• Welcome

• Important Safety Information

• Installation Guide

• Operation

• Care and Maintenance

• Troubleshooting

• Warranty

FOUR À MICRO-ONDES

Guide d’utilisation et soins de Propriètaire ......16-30

Bienvenue

Information de Sécurité Important

Guide d’Installation

Fonctionnement

Soins et Entretien

Depannage

Garantie

CAUTION:

Read and follow all safety rules and operating instructions before first use of this product.

PRECAUTION:

Veuillez lire attentivement les consignes de sécurité et les instructions d’utilisation avant l’utilisation initiale de ce produit.

Model • Modèle DMW7700BLDB / WDB

Welcome

Welcome to the Danby family. We’re proud of our quality products and we believe in dependable service. You’ll see it in this easy to use manual and you’ll hear it in the friendly voices of our consumer service department.

Best of all, you’ll experience these values each time you use your microwave. That’s important, because your new microwave will be part of your family for a long time.

Model No:

Serial No:

Date Purchased:

Need Help?

Before you call for service, there are a few things you can do to help us serve you better.

Read this Owner’s Use and Care Guide:

It contains instructions to help you use and maintain your appliance properly.

If you received a damaged appliance:

Immediately contact the builder (or dealer) that sold you the unit.

Save time and money:

Check the Trouble shooting section before calling. This section helps you solve common problems that may occur.

If you do need service, you can relax knowing help is only a phone call away.

Tel: 1-800-26-

(1-800-263-2629)

1

Important Safety Information

READ AND FOLLOW ALL SAFETY INSTRUCTIONS

FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT (U.S.A. ONLY)

This equipment generates and uses ISM frequencies and if not installed and used properly, that is in strict accordance with the manufacturer's instructions, may cause interference to radio and television reception. It has been type-tested and found to comply with limits for ISM Equipment pursuant to Part 18 of FCC Rules, which are designed to provide reasonable protection against such interference in a residential installation.

However, there is no guarantee that interference will not occur in particular installations. If this equipment does cause interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more ofthe following:

Reorient the receiving antenna of radio or television.

Relocate the microwave oven with respect to the receiver.

Move the microwave oven away from the receiver.

Plug the microwave into a different outlet so that microwave and receiver are on different branch circuits.

The Manufacturer is not responsible for any radio or TV interference caused by UNAUTHORIZED MODIFICATION to this microwave oven. It is the responsibility of the user to correct such interference.

PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO

EXCESSIVE MICROWAVE ENERGY

For your safety the information in this manual must be followed to minimize the risk of fire or explosion or to prevent property damage, personal injury or loss of life.

Do Not Attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks.

Do Not Place any object between the oven front face and the door or allow soil or cleaner residue to accumulate on sealing surfaces.

Do Not Operate the oven if it is damaged. It is particularly important that the oven door close properly and that there is no damage to the:

1.door (bent),

2.hinges and latches (broken or loosened),

3.door seals and sealing surfaces.

The Oven Should Not be adjusted or repaired by anyone except properly qualified service personnel.

SAVE THESE INSTRUCTIONS

2

Important Safety Information

READ AND FOLLOW ALL SAFETY INSTRUCTIONS

IMPORTANT WARNING

To reduce the risk of fire, electric shock, injury to persons or exposure of excessive microwave energy when using your appliance

SAFETY PRECAUTIONS

Read and follow the specific “Precautions to Avoid Possible Exposure to Excessive Microwave Energy” on page 2.

This appliance must be grounded. Connect only to a properly grounded outlet. See “Grounding Instructions” section on page 6.

Do not operate this appliance if it has a damaged power cord or plug, if it is not working properly, or if it

has been damaged or dropped.

Do not cover or block any openings on the appliance.

Use this appliance only for its intended use as

described in this manual. Do not use corrosive chemicals or vapors in this appliance.

This microwave oven is specifically designed to heat, dry or cook food, and is not intended for laboratory or industrial use.

Some products such as whole eggs and sealed containers for example, closed glass jarsmay explode and should not be heated in this oven.

Do not store this appliance outdoors.

Do not use this product near water - for example, near a kitchen sink, in a wet basement, near a swimming pool, or similar location.

Keep power cord away from heated surfaces.

Do not immerse power cord or plug in water.

See door surface cleaning instructions in the Care and Maintenance section(s) of this manual.

This appliance should be serviced only by qualified service personnel. Contact nearest authorized service facility for examination, repair or adjustment.

As with any appliance, close supervision is necessarry when used by children.

Install or locate this appliance only in accordance with the provided installation instructions.

Do not let cord hang over edge of table or counter.

Liquids such as water, coffee,or tee are able to be overheated beyond the boiling point without appearing to be boiling. Visible bubbling or boiling when the container is removed from the microwave oven is not always present. THIS COULD RESULT IN VERY HOT

LIQUID SUDDENLY BOILING OVER WHEN THE CONTAINER IS DISTURBED OR A SPOON OR OTHER UTENSIL IS INSERTED INTO THE LIQUID.

To reduce the risk of fire in the oven cavity:

Do not overcook food.

Carefully attend appliance if paper, plastic or other combustible materials are placed inside the oven while cooking.

Remove wire twist-ties and metal handles from paper or plastic containers before placing them in the oven.

Do not use the oven for storage purposes. Do not leave paper products, cooking utensils or food in the oven when not in use.

Do not use the microwave to dry newspapers.

If materials inside oven should ignite, keep the oven door closed, turn the oven off and disconnect the power at the fuse or circuit breaker panel. If the door is opened, the fire may spread.

SAVE THESE INSTRUCTIONS

3

Important Safety Information

SPECIAL NOTES ABOUT MICROWAVING

ARCING

FOODS

If you see arcing, press the “STOP/CANCEL” button and correct the problem. Arcing is the microwave term for sparks in the oven.

Arcing is caused by:

Metal or foil touching the side of the oven.

Foil not molded to food (upturned edges act like antennae).

Metal, such as twist-ties, poultry pins, or gold-rimmed dishes, in the microwave.

Recycled paper towels containing small metal pieces being used in the microwave.

Only cook popcorn in your microwave oven using a special microwave popcorn accessory dish, unless you use popcorn labeled for use in microwave ovens.

Some productssuch as whole eggs (with shell), sealed containers, and closed jars - will explode and should not be heated in this microwave oven. Heating these products in the microwave oven could result in injury.

Do not boil eggs in a microwave oven. Pressure will build up inside egg yolk and will cause it to burst, possibly resulting in injury.

Operating the microwave with no food inside may cause damage to the oven and could start a fire. It increases the heat around the magnetron and can shorten the life of the oven.

Foods with unbroken outer “skin” such as potatoes, hot dogs, sausages, tomatoes, apples, chicken livers and other giblets, and egg yolks should be pierced to allow steam to escape before cooking.

SAFETY FACT: SUPERHEATED WATER

Microwaved water and other liquids do not always bubble when they reach the boiling point; they can actually get superheated and not bubble at all. Superheated liquid can bubble up when it is moved or when something like a spoon or tea bag is put into it. To prevent this from happening and causing injury, do not heat any liquid for more than 2 minutes per cup. After heating, let the cup stand in the microwave for 30 seconds before moving it or putting anything into it.

• Avoid heating baby food in glass jars, even with the lid off. Make sure all infant food is thoroughly cooked. Stir food to distribute the heat evenly. Be careful to prevent scalding when warming formula. The container may feel cooler than the milk really is. Always test the milk before feeding the baby.

Spontaneous boilingUnder certain circumstances, liquids may start to boil during or shortly after removal from the microwave oven. To prevent burns from splashing liquid, we recommend the following:

Before removing the container from the oven, allow the container to stand in the the oven for 30 to 40 seconds. Containers such as soft drink bottles, wine flasks and especially narrow-necked coffee cups. Even if the container is opened, excessive steam can build up and cause it to burst or overflow.

Don’t defrost frozen beverages in narrow-necked bottles (especially carbonated beverages). Even if the container is opened, pressure can

build up.This can cause the container to burst, possibly resulting in injury.

Hot foods and steam can cause burns. Be careful when opening any containers of hot food, including popcorn bags, cooking pouches and boxes. To prevent possible injury, direct steam away from hands and face.

4

Important Safety Information

SPECIAL NOTES ABOUT MICROWAVING

SAFETY FACT: SUPERHEATED WATER (con’t)

MICROWAVE-SAFE COOKWARE

Do not overcook potatoes. They could dehydrate and catch fire, causing damage to your oven.

Cook meat and poultry thoroughlymeat to at least an INTERNAL temperature of 160°F (71.1°C), and poultry to at least an INTERNAL temperature of 180°F (82.2°C). Cooking to these temperatures usually protects against food borne illness.

Make sure all cookware used in your microwave oven is suitable for microwaving. Most glass casserole, cooking dishes, measuring cups, custard cups, pottery or china dinnerware which do not have metallic trim or glaze with a metallic sheen can be used. Some cookware will be labeled “suitable for microwaving”.

If you use a meat thermometer while cooking, make sure it is safe for use in microwave ovens.

Do not use recycled paper products. Recycled paper towels, napkins, and waxed paper can contain metal flecks which may cause arcing or ignite. Paper products containing nylon or nylon filament should be avoided, as they may also ignite.

Not all plastic wrap is suitable for use in microwave ovens. Check the package for proper use.

Some styrofoam trays (like those that meat is packaged on) have a thin strip of metal embedded in the bottom. When microwaved, the metal can burn the floor of the oven, or ignite a paper towel.

Cookware may become hot because of heat transferred from the heated food. Pot holders may be needed to handle the cookware.

“Boilable” cooking pouches and tightly closed plastic bags should be slit, pierced, or vented as directed by package. If they are not, plastic could burst during or immediately after cooking, possibly resulting in injury. Also, plastic storage containers should be at least partially uncovered

because they form a tight seal. When cooking with containers tightly covered with plastic wrap, remove covering carefully and direct steam away from hands and face.

Paper towels, waxed paper, and plastic wrap can be used to cover dishes in order to retain moisture and prevent splattering. Be sure to vent plastic wrap so steam can escape.

How to test for a microwave-safe dish:

1)Place in the oven both the dish you are testing and a glass measuring cup filled with1 cup of water.

2)Set the measuring cup either in or next to the dish.

3)Microwave 1 minute on high power.

If the dish heats, it should not be used for microwaving. If the dish remains cool and only the water in the cup heats, then the dish is microwave-safe.

Use foil only as directed in this manual. TV dinners may be microwaved in foil trays less than 3/4” high; remove the top foil cover and return the

tray to the box. When using foil in the microwave, keep the foil at least 1 inch away from the sides of the oven.

5

Important Safety Information

SPECIAL NOTES ABOUT MICROWAVING

MICROWAVE-SAFE

COOKWARE (con’t)

• Plastic cookware designed for microwave cooking is very useful, but should be used carefully. Even microwave-safe plastic may not be as tolerant of overcooking conditions as are glass and ceramic materials, and may soften or char if subjected to short periods of over-cooking. In longer exposure to over-cooking, the food and cookware could ignite.

Follow these guidelines:

1)Use Microwave-safe plastics only and use them in strict compliance with the cookware manufacturer’s recommendations.

2)Do not microwave empty containers.

3)Do not permit children to use plastic cookware without complete supervision.

GROUNDING

WARNING

INSTRUCTIONS



Improper use of the grounding plug can result in a risk of



electric shock.







This appliance must be grounded. In the event of an electrical short circuit,



grounding reduces the risk of electric shock by providing an escape wire



for the electric current. This appliance is equipped with a power cord hav-



ing a grounding wire with a grounding plug. The plug must be plugged into



an outlet that is properly installed and grounded.



Consult a qualified electrician or service technician if the grounding



instructions are not completely understood, or if doubt exists as to whether



the appliance is properly grounded.If the outlet is a standard 2-prong wall



outlet, it is your personal responsibility and obligation to have it replaced



with a properly grounded 3-prong wall outlet.



DO NOT under any circumstances cut or remove the third



(ground) prong from the power cord.



DO NOT use an adapter plug with this appliance.



DO NOT use an extension cord with this appliance.



If the power cord is too short, have a qualified electrician or service techni-



cian install an outlet near the appliance.



A. A short power supply cord is provided to reduce the risks resulting from



becoming entangled in or tripping over a longer cord.



B. Longer cord sets or extension cords are available and may be used if



care is exercised in their use



C. If long cord or extension cord is used:



(1) The marked electrical rating of the cord set or extension cord



should be at least as great as the electrical rating of the appliance.



(2) The extension cord must be a grounding-type 3-wire cord, and



(3) The longer cord should be arranged so that it will not drape over



the counter top or table top where it can be pulled on by children or



tripped over unintentionally.



For best operation, plug this appliance into its own electrical outlet to pre-



vent flickering of lights, blowing of fuse, or tripping of circuit breaker.

6

Danby DMW7700BLDB User Manual

Installation Guide

1)Make sure that all packing materials are removed from the inside of the microwave oven.

2)Check the microwave for any damage, such as misaligned or bent door, damaged door seals and sealing surface, broken or loose door hinges and latches, and dents inside the cavity or on the door. If there is any damage, do not operate the oven but contact a qualified service personnel.

3)This microwave oven must be placed on a flat, stable surface to hold its weight.

4)Do not place the microwave oven where heat, moisture, or high humidity are generated, or near combustible materials.

5)For correct operation, the microwave oven must have sufficient air flow. Allow 30 cm of space above the microwave oven,10 cm at back and 7.5 cm at both sides. Do not cover or block any openings on the appliance. Do not remove the feet on which the microwave oven stands.

6)Do not operate the oven without glass tray, roller support, and shafts in their proper positions.

7)Make sure that the power supply cord is undamaged and does not run under the microwave oven or over any hot or sharp surfaces.

8)The socket must be readily accessible so that it can be easily unplugged in an emergency.

SPECIAL CORD SET INSTRUCTIONS

DANGER

Electric Shock Hazard: Touching some of the internal components can cause serious personal injury or death. Do not disassemble this appliance

WARNING

Electric Shock Hazard: Improper grounding can result in electric shock. Do not plug into an outlet until appliance is properly installed and grounded.

Operating Instructions

FEATURES

2 6

1)Oven Window: Screen allows cooking to be viewed while keeping microwave energy

confined in oven.

2)

Turntable Shaft





3)

Roller Ring



5

4) Removable Glass Turntable: Turntable







and support must be in place when using







the oven. The turntable may be removed







for cleaning.





5)

Control Panel

3

4

1









6)

Electronic Display





7

Operating Instructions

CONTROLS

1)TIME COOK

2)TIME DEFROST

3)POWER

4)CLOCK

5)AUTO MENU: Popcorn,Potato,Pizza,Frozen vegetable,Beverage,Dinner plate

6)NUMBER BUTTONS

7)WEIGHT DEFROST

8)KITCHEN TIMER FUNCTION

9)STOP/CANCEL: clears all previous setting pressed before cooking starts. During cooking: press once to stop oven; twice to stop an clear all entries.

10)Memory Function

11)START/+30SEC.

1

2

3

4

5

6

9

10

POWER LEVELS

11 power levels are available:

Level

10

9

8

7

6

5

4

3

2

1

0

























Power

100%

90%

80%

70%

60%

50%

40%

30%

20%

10%

0%

























Display

PL10

PL9

PL8

PL7

PL6

PL5

PL4

PL3

PL2

PL1

PL0

























7

8

11

CLOCK SETTING

1)Press clock and “00:00” will display.

2)Press the number keys and enter the current time. For example, time is 10:12 now, please press "1,0,1,2" in turn.

3)Press " CLOCK " to finish clock setting. ":" will flash and the clock will be lighted.

4)If the numbers input are not within the range of 1:00-12:59, the setting will be invalid until valid numbers are entered.

NOTE:

1)In the process of clock setting, if the " STOP/CANCEL " button is pressed or if there is no operation within 1 minute, the oven will go back to the former setting automatically.

2)If the clock need to be reset, please repeat step 1 to step 3.

8

+ 23 hidden pages
