Danby DFF261 Owner's Manual

Owner’s Use and Care Guide

Guide d’utilisation et soin de Propriètaire

Manual de Instructions pare el Uso y el

Cuidado de su Unidad

Model • Modèle • Modelo

DFF261BSLDB, DFF261WDB

ALL REFRIGERATOR

Owner’s Use and Care Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6

• Important Safety Information

• Installation Instructions

• Features

• Operating Instructions

• Care and Maintenance

• Troubleshooting

• Warranty

TOUT RÉFRIGÉRATEUR

Guide d’utilisation et soin de Propriètaire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-12

• Consignes de Sécurité Important

• Instructions d’installation

• Caractéristiques

• Consignes d’operation

• Soins et entretien

• Dépannage

• Garantie

TODA REFRIGERADORA

Manual de Instructions pare el Uso y el Cuidado de su Unidad . . . . . . . . . . . . . . . . 13 - 19

• Instrucciones de Seguridad Importantes

• Instalación

• Caracteristicas

• Operación

• Cuidado y Mantenimiento

• Solución Sugerida

• Garantia

Danby Products Limited, Ontario, Canada N1H 6Z9

Danby Products Inc., Findlay, Ohio, USA 45840

V.2.09.09 JF

CAUTION:

Read and follow all safety rules and operating

instructions before first use of this product.

PRECAUTION:

Veuillez lire attentivement les consignes de sécurité et

les instructions d’utilisation avant l’utilisation initiale de

ce produit.

PRECACION:

Lea y observe todas las reglas de seguridad y las

instrucciones de operación antes de usar este producto

por primera vez.

IMPORTANT SAFETY INFORMATION

ELECTRICAL

REQUIREMENTS

This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electrical shock by providing an escape wire for the electrical current.

This appliance is equipped with a cord having a grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly installed and grounded.

IMPORTANT WARNING

An empty refrigerator can pose a threat to children. To render the unit harmless we strongly recommend removing the door prior to disposal.

WARNING - Improper use of the grounding plug can result in a risk of electric shock. Consult a qualified electrician or serviceman if the grounding instructions are not completely understood, or if doubt exists as to whether the appliance is properly grounded.

DO NOT USE AN EXTENSION CORD

Use an exclusive wall outlet. Do not connect your refrigerator to extension cords or together with any other appliance in the same wall outlet.

Remove exterior and interior packings, wipe the outside thoroughly with a soft dry cloth and the inside with a wet, lukewarm cloth. Avoid placing the unit in a narrow recess or near any heat source, direct sunlight, or moisture. Let air circulate freely around the unit. Keep the rear of the refrigerator 5 inches away from the wall.

Location

1) Select a place with a strong, level floor.

2) Allow 5 inches of space between the back of the

refrigerator and any adjacent wall.

3) Avoid direct sunlight and heat. Direct sunlight

may affect the acrylic coating. Heat sources nearby will cause higher electricity consumption.

The refrigerating system in this refrigerator is a “Frost Free” system. This type of system requires no user intervention (i.e. defrosting) other than selecting required cooling temperatures and the usual care and maintenance.

To avoid vibration, the unit must be set level. This is accomplished by adjusting the front leveling leg, located under the refrigerator.

NOTES:

• This appliance is intended for FREE-STANDING INSTALLATION ONLY, and is NOT intended to be built-in.

• Before connecting this appliance to electrical power supply, leave it to stand for approx. 24 hours, which will reduce the possibility of malfunction in the cooling system due to transport handling.

• This appliance is approved for INDOOR USE

ONLY and is NOT intended for outdoor operation.

IMPORTANT:

AMBIENT TEMPERATURES BELOW 50º F (10º C) WILL AFFECT THE OPERATION OF YOUR REFRIGERATOR. WHEN THE UNIT IS PLACED IN AN AREA WHERE THE TEMPERATURE DROPS LOWER THAN 50º F (10º C), SET THE TEMPERATURE CONTROL SELECTORS TO “MAX” IN BOTH THE REFRIGERATOR AND FREEZER SECTIONS.

NOTE:

IF THE UNIT IS UNPLUGGED, HAS LOST POWER, OR IS TURNED OFF, YOU MUST WAIT 3 TO 5 MINUTES BEFORE RESTARTING THE UNIT. IF YOU ATTEMPT TO RESTART BEFORE THIS TIME DELAY, THE REFRIGERATORFREEZER WILL NOT START.

INSTALLATION INSTRUCTIONS

INSTALLATION INSTRUCTIONS (cont’d)

DOOR REVERSAL

INSTRUCTIONS

Fig. 1

Fig. 2

Fig. 3

To avoid personal injury to yourself and/or property, we recommend someone assists you during the door reversal process.

1) To access the lower hinge assembly, tilt back the

refrigerator or lay the refrigerator on its back (Fig. 1).

2) Remove both leveling legs located at the front of the unit.

3) Remove the screws holding the lower hinge assembly to

the refrigerator (Fig. 1).

4) Remove the main door assembly from the unit (open door

and pull down).

5) Remove the screws from the middle hinge assembly.

Then remove the hinge and refrigerator door (open door and pull down) (Fig. 2).

6) Loosen top hinge screws. Remove top hinge from current

position and install with holes on other side of door. (Fig 3)

7) Remove the door plug and door bushing located on the top

and bottom of each door assembly (Fig. 2).

8) Interchange positions (ie. door plug right side, door

bushing left side).

9) Re-install refrigerator door assembly on unit.

10) Re-install the middle hinge assembly on the opposite side.

11) Make sure the door assembly is properly aligned on the

unit before tightening the hinge screws.

12) Re-install the main door assembly on the unit.

13) Re-install the lower hinge assembly on the opposite side,

making sure to change the bushing and screw on the opposite sides on the bottom of the unit.

14) Make sure the door assembly is properly aligned on the

unit before tightening lower hinge screws.

15) Re-install both leveling legs.

THE PROCESS IS NOW COMPLETE.

1) Interior Light

2) Refrigerator Temperature Control

3) Freezer Temperature Control

4) Removable Refrigerator Shelves

5) Glass Crisper Cover

6) Crisper with Tempered-Glass Shelf

7) Wire Freezer Shelf

8) Freezer Basket

9) Refrigerator Door Shelves (2)

10) CANSTOR

Door Liner: Holds 355ml cans of

pop, juice, or beer.

11) 2 Liter Bottle Storage

FEATURES

ICE CUBE TRAY

The Ice Cube Tray is flexible. Twist tray to remove the ice cubes. If the ice cube tray is frozen solid to the evaporator surface, run a little water over the tray. Never use a knife or other metal instruments to remove the ice cube tray, as this may damage the evaporator.

OPERATING INSTRUCTIONS

MED

MAX MIN

TEMPERATURE

CONTROLS

REFRIGERATOR

CONTROL

FREEZER

CONTROL

Your refrigerator has a separate control for regulating the temperature for each section independently. The temperature controls (Fig. A) are located at the rear of refrigerator section.

• The first time you turn the unit on, set the temperature control to “MAX” in refrigerator section and “MAX” in freezer section.

• The range of the temperature controls are from position “MIN” to “MAX” (MIN being the warmest and MAX being the coldest). We recommend starting at the mid-point for both the refrigerator and freezer, and after a period of 24 to 48 hours (to allow for cooling) adjust if necessary.

Fig. A

Fig. B

CARE AND MAINTENANCE

Cooling System

This refrigerator is inclusive of a “Frost Free” type cooling system, which means you never have to defrost the freezer compartment. Defrosting is done automatically by means of a defrost heating element and a defrost timer factory-programmed to operate (cycle) after approximately 3 hours of continuous compressor cycling. The defrost water is routed into a defrost pan located directly above the compressor, where it then evaporates.

Cleaning

Before cleaning the refrigerator or freezer, always disconnect the refrigerator from the power supply. To clean the inside, use a soft cloth and a solution of a tablespoon baking soda to one quart (4 cups) of water, or a mild soap suds solution or mild detergent. Wash ice cube tray, drip tray, and glide out shelves in a mild detergent solution, then wipe dry with a soft cloth. Clean the outside with a damp soft cloth and some mild detergent or appliance cleaner.

Setting the Thermostat

The thermostat setting can be adjusted from Minimum (warmest) setting through Maximum (coldest) setting in both the refrigerator and freezer. We recommend setting the thermostat at the medium (middle) setting indicated by “•”. However, if you find this setting inadequate for your cooling requirements, adjust as needed by rotating the thermostat knobs. To locate the thermostat control knobs, refer to Features on page 3.

For short vacation periods, leave the control knob at the usual setting. During longer absences;

a) remove all food.

b) disconnect from electrical outlet.

c) clean the refrigerator thoroughly, including

defrost pan.

d) leave the door open to avoid possible formations

of condensation, mold, or odors.

Power Failure

Most power failures are corrected within a couple of hours, and will not affect your refrigerator temperatures. However, you should minimize the number times you open the door while the power is off. During power failures of longer duration, take steps to protect your food, for example, by placing dry ice on top of packages.

If You Move

Remove, or securely fasten down, all loose items inside the refrigerator. To avoid damaging the leveling legs, turn them all the way into the base.

Some Important Rules for the Correct Use of the Refrigerator

• Never place hot foods in the refrigerator.

• Beverages should be stored in sealed containers.

• Foods to be stored for a long time should be wrapped in cellophane or polyethylene, or kept in glass containers. Never place spoiled food in the refrigerator.

• Don’t overload the refrigerator.

• Don’t open the door unless necessary.

• Should the refrigerator be stored without use for long periods, it is suggested, after careful cleaning, to leave the door ajar to allow the air to circulate inside the unit in order to avoid the possible formations of condensation, mold, or odors.

Food Storage Suggestions:

Fresh Food Compartment-

• Never cover food compartment shelves with aluminum foil or any other shelf covering material which may prevent air circulation.

• Always remove porous store wrapping paper from meats, poultry, and fish. Meats should be wrapped individually and placed in a dish for storage. Wrap fish and poultry in foil or heavy waxed paper. Most fish should be used the same day of purchase. Packaged meats such as ham, bacon, dried beef, or frankfurter, store best in their original packages.

• Allow warm foods to cool to room temperature

before placing them in the refrigerator.

• Always cover open dishes of food, especially leftovers. Use leftovers within 2 or 3 days.

Vegetable Crisper

The tray at the bottom of the refrigerator is covered to retain moisture. The crisper compartment will enable you to store vegetables and fruits which would otherwise dry out rapidly. The humidity level inside the crisper drawer can be controlled by adjusting the “damper” control (white slider) located on the front of the drawer.

TROUBLESHOOTING

Occasionally, a problem may arise that is minor in nature, and a service call may not be necessary. Use this troubleshooting guide for a possible solution. If the unit continues to operate improperly, call an authorized service depot or Danby’s Toll Free Number 1-800-263-2629 for assistance.

PROBLEM POSSIBLE CAUSE SOLUTION

1) Unit does not work.

• No power to unit.

• Power cord is unplugged.

• Wrong voltage is being used.

• Check connection of power cord at power source.

• Plug in unit.

• Use proper voltage.

2) Refrigerator running too frequently.

• Temperature control too high.

• Door not closed.

• Hot food inserted.

• Doors open too long/often.

• Close proximity to heat source or direct sunlight.

• Adjust settings as needed.

• Close the door securely.

• Cool food before inserting.

• Minimize door openings/duration.

• DO NOT place unit close to heat sources or in direct sunlight.

3) Internal Temperature too

cold.

• Temperature control too high.

• Adjust settings as needed.

4) Internal Temperature not

cold enough.

• No power to unit.

• Power cord is unplugged.

• Wrong voltage is being used.

• Temperature control too low.

• Hot food inserted.

• Doors open too long/often.

• Air flow obstruction.

• Close proximity to heat source or direct sunlight.

• Check connection of power cord at power source.

• Plug in unit.

• Use proper voltage.

• Check/adjust settings as needed.

• Cool food before inserting.

• Minimize door openings/duration.

• Allow room for air to circulate around the unit.

• DO NOT place unit close to heat sources or in direct sunlight.

5) Freezer not cold enough.

• Temperature control too low.

• Door not closed.

• Hot food inserted.

• Doors open too long/often.

• Wrong voltage is being used.

• Adjust settings as needed.

• Close door securely.

• Cool food before insterting.

• Minimize door openings/ duration.

• Use proper voltage.

6) Light will not work.

• No power to unit.

• Power cord is unplugged.

• Bulb is loose/needs replacing.

• Door switch is stuck.

• Check connection of power cord to power source.

• Plug in unit.

• Tighten or replace bulb.

• Check the switch for obstructions, clean if necessary.
