Danby DCF072A2WDB1 User Manual [en, es, fr]

Danby Products Limited, Guelph, Ontario, Canada N1H 6Z9

Danby Products Inc., Findlay, Ohio, USA 45840

12.05.14

Model • Modèle • Modelo

• Owner’s Use and Care Guide

• Guide d’utilisation et soin de propriètaire

• Guía de utilización y cuidado para el

propietario

COMPACT CHEST FREEZER CONGÉLATEUR HORIZONTAL COMPACT CONGELADOR DE ARCÓN COMPACTO

DCF072A2WDB1

COMPACT CHEST FREEZER

Owner’s Use and Care Guide..........................................1-7

• Welcome

• Safety Instructions

• Installation

• Operation

• Care and Maintenance

• Troubleshooting

• Waranty

CONGÉLATEUR HORIZONTAL COMPACT

Guide d’utilisation et soin de propriètaire...................8-14

• Bienvenue

• Consignes de sécurité importantes

• Instructions d’installation

• Consignes d’utilisation

• Soins et entretien

• Dépannage

• Garantie

CONGELADOR DE ARCÓN COMPACTO

Guía de utilización y cuidado para el propietario......15-21

• Bienvenido

• Instrucciones de seguridad importantes

• Instrucciones de instalacón

• Instrucciones operadoras

• Limpieza y mantenimiento

• Solución sugerida

• Garantia

CONTENTS

TABLE DES MATIÈRES

ÍNDICE

CAUTION:

PRÉCAUTION :

PRECAUCIÓN:

Read and follow all safety rules and operating instructions before first use of this product.

Veuillez lire attentivement les consignes de sécurité et les instructions d’utilisation avant l’utilisation initiale de ce produit.

Lea y observe todas las reglas de seguridad y las instrucciones de operación antes de usar este producto por primera vez.

Model • Modèle • Modelo DCF072A2WDB1

Welcome

Welcome to the Danby family. We are proud of our quality products, and we believe in dependable service, like you will find in this Owner’s Use and Care Guide, and like you will receive from our friendly customer service department. Best of all, you will experience these values each and every time you use your Danby appliance. That is important, because your new appliance will be a part of your family for a long time.

Note the information below; you will need this information to obtain service under warranty. To receive service, you must provide the original receipt.

Model Number:

Serial Number:

Date of Purchase:

NEED HELP?

Before you call for service, here are a few things you can do to help us serve you better:

Read this Owner’s Use and Care Guide:

It contains instructions to help you use and maintain your appliance properly.

If you received a damaged appliance:

Immediately contact the retailer (or builder) that sold you the appliance.

Save time and money:

Check the Troubleshooting section at the end of the guide before calling. This section helps you solve common problems that may occur.

If you do need service, you can relax, knowing help is only a phone call away.

1-800-26-

(1-800-263-2629)

Important Safety Information

READ AND FOLLOW ALL SAFETY INSTRUCTIONS

ELECTRICAL REQUIREMENTS

This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electrical shock by providing an escape wire for the electrical current.

Due to possible variations in line voltage (caused by overloading of circuits), it is advisable to install a separate fuse circuit from the meter panel. This will help to eliminate current fluctuation which might cause motor trouble.

WARNING

ELECTRICAL RATING: The serial rating plate indicates the voltage and frequency the freezer is designed for.

GROUNDING INSTRUCTIONS

An empty freezer is a very dangerous attraction to children. Remove either the gasket or lid from unused appliances, or take some other action that will guarantee it harmless.

DANGER: Risk of child entrapment. Before you throw away your old freezer:

• Take off the doors.

• Leave the shelves in place so that children may not easily climb in.

DON’T WAIT! DO IT NOW!

IMPORTANT WARNING!

This appliance is equipped with a cord having a grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly installed and grounded.

WARNING - Improper use of the grounding plug can result in a risk of electric shock. Consult a qualified electrician or service agent if the grounding instructions are not completely understood, or if doubt exists as to whether the appliance is properly grounded.

DO NOT USE AN EXTENSION CORD

Use an exclusive 115V wall outlet. Do not connect your freezer to extension cords or together with any other appliance in the same wall outlet. Do not splice the cord.

SAVE THESE INSTRUCTIONS!

Please ensure that component parts shall be replaced with like components and that servicing shall be done by factory authorized service personnel, so as to minimize the risk of possible ignition due to incorrect parts or improper service.

Risk of fire or explosion due to puncturing of refrigerant tubing. Do not use sharp objects to aid in defrost. Please handle with care. Keep flammable materials and vapors such as gasoline away from the freezer. Use nonflammable cleaner.

Disposal of this unit should be in accordance with federal and local regulations.

WARNING! EXPLOSION HAZARD!

Installation Instructions

Remove exterior and interior packaging, wipe the outside thoroughly with a soft dry cloth and the inside with a wet, lukewarm cloth. Avoid placing the unit in a narrow recess or near any heat source, direct sunlight, or moisture. Let air circulate freely around the unit. Keep the rear of the freezer 5 inches away from the wall.

1) Locate the freezer in such a manner that extension cords are not necessary.

2) Due to lid and hinge arrangement, it is impossible to install your freezer directly against the wall. The spacing on the

back is essential for maintaining proper air circulation around the freezer.

3) Select a location with reasonable year round temperatures. We do not recommend operating the freezer when surrounding air temperature is below 0°C (32°F), though it will not harm the freezer to stand in any temperature below 0°C (32°F), provided the temperature control is set to avoid running the unit. In order to keep operating cost down, do not place freezer near a stove, furnace, heat register or in direct sunlight. If the place selected for your freezer is damp or moist, as in basements, place freezer on wooden blocks (two or three 2x4’s under entire length will ensure adequate support).

LOCATION

FEATURES

1) FRONT MOUNTED THERMOSTAT: Easy access control knob controls the desired temperature inside the freezer.

The proper food storage temperature is -18°C (0°F). The motor turns on as soon as the temperature rises above the desired level.

2) DEFROST DRAIN: For easy removal of melted ice during defrosting. It is recommended that you defrost your freezer once or twice a year.

3) RUST RESISTANT INTERIOR: Aluminum liner for long lasting durability (not pictured).

CAUTION:

The hinge of a chest freezer is under tension. You must excercise

EXTREME CAUTION when attempting to remove, replace, and/or adjust.

Operating Instructions

STARTING THE FREEZER

The freezer is ready to operate as received, when connected to the power supply. After connecting to power supply, close lid and allow freezer to operate. The unit will run from 1 to 2 hours (possibly longer, depending on conditions) before operating temperature is reached. It will then start and stop (cycle) at fairly regular intervals. It is recommended that food not be placed in the freezer until you are satisfied that it is operating (cycling) regularly and no final adjustments are necessary.

Once your freezer is starting and stopping (cycling) regularly, it is ready to freeze and store foods. The proper food storage temperature is -18°C (0°F). Do not operate freezer at temperatures below -19°C (-3°F), as this does not improve food preservation and only results in longer unit (cycle) running time. It is not advisable to freeze more than 25 kg (50 lbs.) of food in any 24 hour period. It will take 15 or more hours of unit running time to freeze this amount of food.

When adding fresh, unfrozen food packages, store them against the walls. The sensing bulb of the thermostat is fastened to the liner wall on the “insulation side” of the freezer. In view of the value of the contents of your freezer, it is advisable to inspect contents and check freezer operation regularly.

TEMPERATURE CONTROL

The temperature of the freezer compartment is controlled by adjusting / setting the thermostat control knob, located on the front of the freezer cabinet. To start the freezer and achieve maximum cooling quickly:

Turn the temperature control knob clockwise to the furthest (maximum) setting on the darker blue (wide) section of• the graduated control dial.

Allow the freezer to run at this setting for 3-4 hours.•

When maximum cooling is achieved, turn back the temperature control knob setting to the 2 o’clock position on the• graduated blue control dial. See Fig.1.

To turn off the freezer (no cooling), rotate the control knob to the “0” (off) position. See Fig.2.•

Fig. 2

Fig. 1

Care and Maintenance

DEFROSTING

Moisture will be introduced to the liner during lid openings and the addition of unfrozen food packages. The moisture will accumulate in the form of frost, mostly on the upper part of the liner walls. Accumulation of frost up to 6 mm (1/4") on the liner is not harmful. However, when it becomes heavier, it should be removed as it slows cooling, resulting in longer running (cycle) times. Under average conditions, defrosting will not be necessary more than once or twice a year. Besides frost, food particles and other foreign substances may accumulate and soil the liner.

For proper defrosting and cleaning, the following method is recommended:

a) Unplug freezer.

b) Quickly remove all frozen food and store in baskets, cartons or other suitable containers. Keep food well covered with

blankets to avoid excessive temperature rise.

c) With the help of a wooden spatula or a plastic defrosting scoop, remove the frost and ice off the liner walls as soon as it becomes loose (approximately 15 minutes from start) - do not use any sharp instruments as this may result in damage to the liner wall and/or sealed system, voiding any and/or all warranties which may be in effect. Using a piece of cloth soaked in hot water, the process can be considerably accelerated. As soon as the ice has fallen to the bottom, remove it. Do not let it melt in the freezer as this will increase defrosting and cleaning time.

CLEANING

Now the liner is ready to be cleaned. Sprinkle baking soda on the bottom and walls. This will help in cleaning and odor removal. In order to retain the finish of the freezer cabinet inside and outside, wash only with warm water and mild soap, then rinse and dry. Do not under any circumstances use a gritty soap or a kitchen scouring cleanser, as these tend to scratch the finish.

VACATION TIME

For short vacation periods, leave the control knob at its normal setting. During longer absences,

(a) remove all foods. (b) disconnect power cord from electrical outlet. (c) defrost and clean the freezer thoroughly.

(d) leave lid open to avoid possible formations of condensation, mold or odors.

ELECTRICAL AND MECHANICAL FAILURE

In the event of mechanical or electrical failure of the freezer, contact a service agent immediately and give complete information of your freezer, the model number and the serial number. These are shown on the serial plate located on the exterior (rear) cabinet wall.

POWER FAILURE

Most power failures are corrected within an hour or two and will not affect your freezer temperatures. However, you should minimize the number of lid openings while the power is off. During power failures of longer duration, take steps to protect your food.

IF YOU MOVE

Remove or securely fasten down all loose items inside the unit. To avoid damaging the leveling legs, turn them all the way into the base.

Care and Maintenance

SOME IMPORTANT RULES FOR THE CORRECT USE OF THE FREEZER

• Never place hot foods in the freezer.

• Never place spoiled foods in the unit.

• Don’t overload the unit.

• Don’t open the lid unless necessary.

• Should the freezer be stored without use for long periods, it is suggested, after a careful cleaning, to leave the lid open to allow the air to circulate inside the unit in order to avoid the possibility of condensation, mold or odors.

Troubleshooting

Occasionally, a minor problem may arise, and a service call may not be necessary- use this troubleshooting guide for a possible solution. If the unit continues to operate improperly, call an authorized service depot or Danby’s Toll Free

Number for assistance.

Tel: 1-800-26- (1-800-263-2629).

PROBLEM POSSIBLE CAUSE SOLUTION

1) Does not work.

• No power to unit.

• Power cord is unplugged.

• Wrong voltage is being used.

• Check connection of power cord to power source.

• Plug in unit.

• Use proper voltage.

2) Freezer runs continuously.

• Temperature set too low.

• Lid is not closed.

• Hot food inserted.

• Lid opened too long or too often.

• Close proximity to heat source or direct sunlight.

• Set temperature control to warmer setting

• Close lid securely.

• Be sure food is at room

temperature before inserting.

• Minimize lid openings/

duration.

• Do not place unit close to heat sources or direct sun light.

3) Internal temperature not cold enough.

• No power to unit.

• Power cord is unplugged.

• Temperature set too high.

• Lid is not closed.

• Hot food inserted.

• Lid opened too long or too often.

• Air flow obstruction.

• Wrong voltage is being used.

• Close proximity to heat source or direct sunlight.

• Check connection of power cord to power source.

• Plug in unit.

• Check setting and increase as needed.

• Close lid securely.

• Be sure that food is at room temperature.

• Minimize lid openings/

duration.

• Allow room for air to

circulate around unit.

• Use proper voltage.

• Do not place unit close to heat sources or direct sunlight.

PROBLEM

POSSIBLE CAUSE

POSSIBLE SOLUTION
