Page 1
Service Manual
CHASSIS : CP-005
MODEL :14C3 / 14C4/T
14C5T / 20C4/T
20C5T / 21C6/T
Page 2
Video
Audio
Page 3
Electrical Parts List
LOC PART CODE PART NAME PART DESCRIPTION
R
ZZ100 48B3740A01
ZZ110 PTACPWA627 ACCESSORY AS DTP-14C5TF
100 4850Q00910 BATTERY R03/NN
M821 4858213800 BAG INSTRUCTION L.D.P.E T0.05X250X400
ZZ120 PTBCSHA627 COVER BACK AS DTP-14C5TF
R
M211 4852151401 COVER BACK HIPS BK
M541 4855415800 SPEC PLATE 150ART P/E FILM (C/TV)
ZZ130 PTPKCPA627 PACKING AS DTP-14C5TF
M801 4858038700 BOX CARTON SW-2 DTQ-1463FW
M811 4858189600 PAD EPS 14V5
M821 4858210600 BAG P.E
ZZ131 48519A4710 CRT GROUND NET 1401S-1015-1P
ZZ132 58G0000084 COIL DEGAUSSING DC-1450
ZZ140 PTCACAA627 CABINET AS DTP-14C5TF
R
CRT1 PTRTPWA605 CRT AS PAL 14" ITC CRT AS
V01 58D0000082 COIL DY ODY-M1489
V02 48A96R004- RUBBER WEDGE HMR 28 SR (|0X54)
V03 4850PM001- MAGNET CP NY-225 (MINI NECK)
V04 2TC26019BE TAPE CLOTH 19X30 BEIGE
V05 2224050026 BOND SILICON RTV 122 CARTRIDGE
V06 2233030001 PAINT LOCK 3B-1401B
V901 48A96414P4 CRT BARE A34JLL90X(K)
M193 4851937902 BUTTON CTRL 4942102+5537501
R
M321 4853214800 BRKT FR HIPS BK
R
M491B 4854942103 BUTTON ABS BK
M561 4855621401 MARK BRAND ABS BK
M681 4856812001 TIE CABLE NYLON66 DA100
SP01A 7178301011 SCREW TAPPTITE TT2 WAS 3X10 MFZN
R
ZZ200 PTFMSJA627 MASK FRONT AS DTP-14C5TF
M201 4852069901 MASK FRONT HIPS BK
ZZ210 PTSPPWA627 SPEAKER AS DTP-14C5TF
P601A 4850703S50 CONNECTOR
R
SP01 4858314010 SPEAKER SP-5070F01 3W 8 OHM
R
ZZ290 PTMPMSA627
C101 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C102 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C103 CEXF1C222V C ELECTRO
C301 CEXF1V471C C ELECTRO
C302 CCXB3A471K C CERA 1KV B 470PF K (T)
C303 CEXF1E102C C ELECTRO
C304 CEXF1H220V C ELECTRO 50V RSS 22MF (5X11) TP
C305 CMXE2A473J C MYLAR 100V PU 0.047MF J
C306 CEXF1V101C C ELECTRO
C307 CMXB1H224J C MYLAR 50V EU 0.22MF J (TP)
C313 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C401 CMYE2D364J C MYLAR 200V PU 0.36MF J
C402 CEXF2C109V C ELECTRO 160V RSS 1MF (6.3X11) TP
C404 CMYH3C692J C MYLAR 1.6KV BUP 6900PF J
C406 CCXB2H102K C CERA
TRANSMITTER
REMOCON
PCB MAIN MANUAL
AS
R-40A01
L.D.P.E
T0.03X1000X900
YH02503+35098+ULW=200
DTP-14C5TF
16V RSS 2200MF
(13X25) TP
35V RUS 470MF
(10X20) TP
25V RUS 1000MF
(13X20) TP
35V RUS 100MF
(8X11.5) TP
500V B 1000PF K
(TAPPING)
is a recommendable part for stock.
®
is safety component, so it must be used the same component.
LOC PART CODE PART NAME PART DESCRIPTION
C410 CMXM2A104J C MYLAR 100V 0.1MF J (TP)
C411 CMYN1J105K C MYLAR (MKT) 63V 1MF K (7.5MM)
C420 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
C421 CEXF2E330V C ELECTRO 250V RSS 33MF (13X25) TP
C501 CEXF1H478V C ELECTRO 50V RSS 0.47MF (5X11) TP
C502 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C503 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
C504 CEXD1H229F C ELECTRO 50V RND 2.2MF (5X11) TP
C506 CEXD1H229F C ELECTRO 50V RND 2.2MF (5X11) TP
C507 CEXF1C101V C ELECTRO
16V RSS 100MF
(6.3X11) TP
C511 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
C512 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C513~7 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C520 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
C522 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
C523 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C524 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C601 CEXF1C101V C ELECTRO
16V RSS 100MF
(6.3X11) TP
C602 CEXF1H108A C ELECTRO 50V RSM 0.1MF 4X7
C606 CEXF1C101V C ELECTRO
16V RSS 100MF
(6.3X11) TP
C611 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
C620 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C702 CEXF1H109V C ELECTRO 50V RSS 1MF (5X11) TP
C703 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
C704 CEXF1C102V C ELECTRO
16V RSS 1000MF
(10X20) TP
C706 CEXF1H478V C ELECTRO 50V RSS 0.47MF (5X11) TP
C801 CL1JB3474K C LINE ACROSS
AC250V 0.47MF U/C/
SNDF/SV
C803 CCXF3A472Z C CERA 1KV F 4700PF Z (T)
C804 CCXF3A472Z C CERA 1KV F 4700PF Z (T)
C805 CEYN2G181P C ELECTRO 400V LHS 180MF (25X35)
C807 CMYU3C222J C MYLAR 1.6KV BCP 2200PF J
C809 CH1HFE102M C CERA AC 4.0KV 1000PF E DG
C812 CH1HFE102M C CERA AC 4.0KV 1000PF E DG
C814 CCYR3A471K C CERA
C815 CEXF2C101V C ELECTRO
1KV R 470PF K 125
DE0705
160V RSS 100MF
(16X25) TP
C816 CCXB3A471K C CERA 1KV B 470PF K (T)
C818 CEXF2C101C C ELECTRO
C819 CEXF2A100V C ELECTRO
C820 CEXF1E102V C ELECTRO
C822 CEXF1C101V C ELECTRO
160V RUS 100MF
(16X25) TP
100V RSS 10MF
(6.3X11) TP
25V RSS 1000MF
(13X20) TP
16V RSS 100MF
(6.3X11) TP
C823 CCXB3A471K C CERA 1KV B 470PF K (T)
C824 CCXB3A471K C CERA 1KV B 470PF K (T)
C825 CEXF1H220V C ELECTRO 50V RSS 22MF (5X11) TP
C826 CEXF1H479V C ELECTRO 50V RSS 4.7MF (5X11) TP
C827 CEXF1C222V C ELECTRO
16V RSS 2200MF
(13X25) TP
LOC PART CODE PART NAME PART DESCRIPTION
C828 CEXF1C101V C ELECTRO
C829 CEXF1H100V C ELECTRO 50V RSS 10MF (5X11) TP
C830 CEXF1C471V C ELECTRO
C841 CCXF1H103Z C CERA 50V F 0.01MF Z (TAPPING)
C842 CCXB3A102K C CERA 1KV B 1000PF K (TAPPING)
C850 CEXF1C470V C ELECTRO 16V RSS 47MF (5X11) TP
C902 CMXL2E104K C MYLAR 250V MEU 0.1MF K
C905 CMXL2E104K C MYLAR 250V MEU 0.1MF K
C906 CBXB3D102K C CERA SEMI 2KV BL(N) 1000PF K (T)
CC102 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC103 HCQK101JCA C CHIP CERA 50V CH 100PF J 2012
CC104 HCQK101JCA C CHIP CERA 50V CH 100PF J 2012
CC105 HCQK102JCA C CHIP CERA 50V CH 1000PF J 2012
CC108 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC109 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC118 HCBK104KCA C CHIP CERA 50V X7R 0.1MF K 2012
CC412 HCQK160JCA C CHIP CERA 50V CH 16PF J 2012
CC501 HCQK101JCA C CHIP CERA 50V CH 100PF J 2012
CC502 HCFK103ZCA C CHIP CERA 50V Y5V 0.01MF Z 2012
CC504 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC505 HCBK222KCA C CHIP CERA 50V X7R 2200PF K 2012
CC506 HCQK102JCA C CHIP CERA 50V CH 1000PF J 2012
CC508 HCBK472KCA C CHIP CERA 50V X7R 4700PF K 2012
CC509~12 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC515~7 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC518 HCBK222KCA C CHIP CERA 50V X7R 2200PF K 2012
CC519 HCFK334ZCA C CHIP CERA 50V Y5V 0.33MF Z 2012
CC520 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC521 HCBK472KCA C CHIP CERA 50V X7R 4700PF K 2012
CC522~4 HCQK102JCA C CHIP CERA 50V CH 1000PF J 2012
CC526 HCBK223KCA C CHIP CERA 50V X7R 0.022MF K 2012
CC533 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC534 HCQK300JCA C CHIP CERA 50V CH 30PF J 2012
CC535 HCQK300JCA C CHIP CERA 50V CH 30PF J 2012
CC536 HCQK300JCA C CHIP CERA 50V CH 30PF J 2012
CC602~4 HCQK102JCA C CHIP CERA 50V CH 1000PF J 2012
CC605 HCQK471JCA C CHIP CERA 50V CH 470PF J 2012
CC606 HCQK471JCA C CHIP CERA 50V CH 470PF J 2012
CC610 HCQK181JCA C CHIP CERA 50V CH 180PF J 2012
CC612 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC613 HCFK103ZCA C CHIP CERA 50V Y5V 0.01MF Z 2012
CC701 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC702 HCQK820JCA C CHIP CERA 50V CH 82PF J 2012
CC705 HCBK472KCA C CHIP CERA 50V X7R 4700PF K 2012
CC707 HCQK820JCA C CHIP CERA 50V CH 82PF J 2012
CC708 HCBK472KCA C CHIP CERA 50V X7R 4700PF K 2012
CC709 HCQK220JCA C CHIP CERA 50V CH 22PF J 2012
CC713 HCBK222KCA C CHIP CERA 50V X7R 2200PF K 2012
CC722 HCQK102JCA C CHIP CERA 50V CH 1000PF J 2012
CC723 HCQK220JCA C CHIP CERA 50V CH 22PF J 2012
CC801 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
CC830 HCFK104ZCA C CHIP CERA 50V Y5V 0.1MF Z 2012
D101 D1N4148--- DIODE 1N4148 (TAPPING)
D103 D1SS85TA-- DIODE 1SS85TA
D105 DUZ33B---- DIODE ZENER UZ-33B
D106 D1N4148--- DIODE 1N4148 (TAPPING)
16V RSS 100MF
(6.3X11) TP
16V RSS 470MF
(10X12.5)TP
LOC PART CODE PART NAME PART DESCRIPTION
D107 DUZ5R1B--- DIODE ZENER UZ-5.1B UNIZON
D301,3 D1N4937G-- DIODE 1N4937G (TAPPING)
D402~3 D1N4937G-- DIODE 1N4937G (TAPPING)
D404 DDG3------ DIODE DG3
D410 DUZ5R1B--- DIODE ZENER UZ-5.1B UNIZON
D450 D1N4148--- DIODE 1N4148 (TAPPING)
D452 D1N4148--- DIODE 1N4148 (TAPPING)
D501~7 DUZ5R6BM-- DIODE ZENER UZ-5.6BM(TAPPING)
D508 D1N4148--- DIODE 1N4148 (TAPPING)
D509 D1N4148--- DIODE 1N4148 (TAPPING)
D510 DUZ5R1B--- DIODE ZENER UZ-5.1B UNIZON
D512~4 D1N4148--- DIODE 1N4148 (TAPPING)
D602 DUZ5R6BM-- DIODE ZENER UZ-5.6BM(TAPPING)
D610 D1N4148--- DIODE 1N4148 (TAPPING)
D620 D1N4148--- DIODE 1N4148 (TAPPING)
D701 DUZ3R9B--- DIODE ZENER UZ-3.9B
D704 85801065GY WIRE COPPER
AWG22 1/0.65 TIN
COATING
D706 DLH2PR---- LED BLOCK LH-2P-R
D720 D1N4148--- DIODE 1N4148 (TAPPING)
D806 DRGP30J--- DIODE RGP30J
D808,10,
D1N4936GP- DIODE 1N4936GP (TAPPING)
12
D816 DUZ3R9B--- DIODE ZENER UZ-3.9B
D820 D1N4148--- DIODE 1N4148 (TAPPING)
D835 DR2M------ DIODE ZENER R2M
D837~40 DLT2A05G-- DIODE LT2A05G (TP)
F801 5FSCB4022R FUSE CERA
SEMKO F4AH 4A 250V
MF51
F801A 4857415001 CLIP FUSE PFC5000-0702
F801B 4857415001 CLIP FUSE PFC5000-0702
I301 PTA2SW7104 HEAT SINK ASS`Y 1TDA1771-- + 7174301011
I301 1TDA1771-- IC VERTICAL TDA1771
R
I301A 4857027104 HEAT SINK SPCC T1.0+SN
I301B 7174301011 SCREW TAPPTITE TT2 RND 3X10 MFZN
R
I501 1STV2238DQ IC CHIP VIDEO STV2238D
R
I601 1TDA7267A- IC AMP TDA7267A
R
I701 1DW195DE1Q IC MICOM DW92195B7T-DE1(ERP)
R
I702 1AT24C16PC IC AT24C16-10PC
R
I703 1KA7805--- IC REGULATOR KA7805
I704 1KRT30---- IC PREAMP KRT30
R
R
I802 4850M04710 MODULE POWER DPM001T1A
I805 PTA2SW6904 HEAT SINK ASS`Y 1STV8131-- + 7174301011
I805 1STV8131-- IC REGULATOR STV8131
R
I805A 4857026904 HEAT SINK AL EX
I805B 7174301011 SCREW TAPPTITE TT2 RND 3X10 MFZN
I901 PTB3SW1100 HEAT SINK ASS`Y 1TDA6103Q- + 7174301011
R
I901 1TDA6103Q- IC VIDEO TDA6103Q
I901A 4857031100 HEAT SINK A1050P-H24 T2.0
I901B 7174301011 SCREW TAPPTITE TT2 RND 3X10 MFZN
J046 RD-4Z101J- R CARBON FILM 1/4 100 OHM J
JC001~6 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC008~9 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC011~20 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC022 HRFT000-CA R CHIP 1/10 0 OHM 2012
JC024~5 HRFT000-CA R CHIP 1/10 0 OHM 2012
JS02 4859109950 JACK PIN BOARD PH-JB-9710A
L101 58N0000044 COIL VCO TRF-V010
L301 5CPZ100K04 COIL PEAKING 10UH 10.5MM K (LAL04TB)
L511 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM)
L601 5CPZ109M02 COIL PEAKING 1UH M (AXIAL 3.5MM)
L602 5CPZ109M02 COIL PEAKING 1UH M (AXIAL 3.5MM)
LOC PART CODE PART NAME PART DESCRIPTION
L603 85801065GY WIRE COPPER
AWG22 1/0.65 TIN
COATING
L604 5CPZ109M02 COIL PEAKING 1UH M (AXIAL 3.5MM)
L606 85801065GY WIRE COPPER
AWG22 1/0.65 TIN
COATING
L701 5CPZ100K02 COIL PEAKING 10UH K (AXIAL 3.5MM)
L702 5CPZ569K02 COIL PEAKING 5.6UH K (AXIAL 3.5MM)
L800 58Q0000093 COIL DELAY LINE RS208
L801 5PLF24A3-- FILTER LINE LF-24A3
L802 5MC0000100 COIL BEAD HC-3550
L803 5MC0000100 COIL BEAD HC-3550
L805 58C4500079 COIL CHOKE L-45
L806 5CPZ390K04 COIL PEAKING 39UH 10.5MM K (LAL04TB)
M681 4856812001 TIE CABLE NYLON66 DA100
M721 4857235402 SHIELD CASE SPTH-C T0.25
P401 4859240020 CONN WAFER YFW500-05
P601 485923162S CONN WAFER YW025-03 (STICK)
P801 4859287320 CONN WAFER MKS2822-6-10-202
P802 4859242220 CONN WAFER YFW800-02
P901 4850709N02 CONNECTOR
PA801 4859906210 CORD POWER AS 6-L0+H03VVH2=2200
R
YBNH250-
09YBNT025+ULW=300
Q105 TKTC3198Y- TR KTC3198Y
Q401 TKTC3207-- TR KTC3207 (TP)
R
Q402 T2SD2499-- TR 2SD2499
Q501 TKTC3198Y- TR KTC3198Y
Q502 TKTC3198Y- TR KTC3198Y
Q503 TKTA1266Y- TR KTA1266Y (TP)
Q505 TKTA1266Y- TR KTA1266Y (TP)
Q506 TKTC3198Y- TR KTC3198Y
Q601 TKTC3198Y- TR KTC3198Y
Q620 TKTA1266Y- TR KTA1266Y (TP)
Q701 TKTA1266Y- TR KTA1266Y (TP)
Q702 TKTC3198Y- TR KTC3198Y
Q703 TKTC3198Y- TR KTC3198Y
Q704 TKTC3198Y- TR KTC3198Y
Q705 TKTC3198Y- TR KTC3198Y
Q710 TKTC3198Y- TR KTC3198Y
Q801 PTR2SW4500 HEAT SINK ASS`Y T2SK2671-- + 7174300811
R
Q801 T2SK2671-- FET 2SK2671
Q801A 4857024500 HEAT SINK AL EX B/K
Q801B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
R
Q802 TKSA1013Y- TR KSA1013Y (TP)
R101 RD-4Z242J- R CARBON FILM 1/4 2.4K OHM J
R109 RD-4Z183J- R CARBON FILM 1/4 18K OHM J
R110 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
R111 RD-4Z101J- R CARBON FILM 1/4 100 OHM J
R120 RD-4Z101J- R CARBON FILM 1/4 100 OHM J
R301 RD-2Z249J- R CARBON FILM 1/2 2.4 OHM J
R302 RN02B229JS R METAL FILM 2W 2.2 OHM J SMALL
R303 RN02B271JS R METAL FILM 2W 270 OHM J SMALL
R307 RN02B181JS R METAL FILM 2W 180 OHM J SMALL
R308 RN02B181JS R METAL FILM 2W 180 OHM J SMALL
R309 RN02B181JS R METAL FILM 2W 180 OHM J SMALL
R310 RN02B181JS R METAL FILM 2W 180 OHM J SMALL
R402 RS02Z103JS R M-OXIDE FILM 2W 10K OHM J SMALL
R403 RS01Z439J- R M-OXIDE FILM 1W 4.3 OHM J
R406 RD-2Z472J- R CARBON FILM 1/2 4.7K OHM J
R407 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
R408 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
R409 RD-4Z561J- R CARBON FILM 1/4 560 OHM J
R410 RN01B132JS R METAL FILM 1W 1.3K OHM J SMALL
LOC PART CODE PART NAME PART DESCRIPTION
R501 RD-4Z101J- R CARBON FILM 1/4 100 OHM J
R502 RD-4Z101J- R CARBON FILM 1/4 100 OHM J
R503 RN01B300JS R METAL FILM 1W 30 OHM J SMALL
R512 RD-4Z750J- R CARBON FILM 1/4 75 OHM J
R521 RD-4Z101J- R CARBON FILM 1/4 100 OHM J
R525 RD-4Z104J- R CARBON FILM 1/4 100K OHM J
R526 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
R532 RD-4Z101J- R CARBON FILM 1/4 100 OHM J
R601 RD-2Z102J- R CARBON FILM 1/2 1K OHM J
R602 RD-4Z511J- R CARBON FILM 1/4 510 OHM J
R611 RD-4Z362J- R CARBON FILM 1/4 3.6K OHM J
R715 RD-4Z102J- R CARBON FILM 1/4 1K OHM J
R723 RD-4Z332J- R CARBON FILM 1/4 3.3K OHM J
R735 RD-4Z103J- R CARBON FILM 1/4 10K OHM J
R736 RD-4Z224J- R CARBON FILM 1/4 220K OHM J
R753 RD-4Z473J- R CARBON FILM 1/4 47K OHM J
R801 DEC140M290 POSISTOR ECPCC140M290
R802 RX07C339JF R CEMENT 7W 3.3 OHM J 15MM 4P
R803 RD-4Z514J- R CARBON FILM 1/4 510K OHM J
R804 RD-4Z514J- R CARBON FILM 1/4 510K OHM J
R805 85801065GY WIRE COPPER
AWG22 1/0.65 TIN
COATING
R806 RD-4Z363J- R CARBON FILM 1/4 36K OHM J
R808 RS02Z828JS R M-OXIDE FILM 2W 0.82 OHM J SMALL
R809 RD-4Z103J- R CARBON FILM 1/4 10K OHM J
R810 RD-4Z333J- R CARBON FILM 1/4 33K OHM J
R812 RC-2Z825KP R CARBON COMP 1/2 8.2M OHM K
R819 RS02Z278JS R M-OXIDE FILM 2W 0.27 OHM J SMALL
R823 RD-4Z101J- R CARBON FILM 1/4 100 OHM J
R824 RD-4Z101J- R CARBON FILM 1/4 100 OHM J
R834 RD-4Z392J- R CARBON FILM 1/4 3.9K OHM J
R850 RN02B180JS R METAL FILM 2W 18 OHM J SMALL
R890 RC-2Z335KP R CARBON COMP 1/2 3.3M OHM K
R901~3 RN01B124JS R METAL FILM 1W 120K OHM J SMALL
R910~2 RD-2Z152J- R CARBON FILM 1/2 1.5K OHM J
RC106 HRFT682JCA R CHIP 1/10 6.8K OHM J 2012
RC107 HRFT473JCA R CHIP 1/10 47K OHM J 2012
RC111 HRFT511JCA R CHIP 1/10 510 OHM J 2012
RC114 HRFT432JCA R CHIP 1/10 4.3K OHM J 2012
RC115 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC301 HRFT361JCA R CHIP 1/10 360 OHM J 2012
RC302 HRFT202JCA R CHIP 1/10 2K OHM J 2012
RC303 HRFT562JCA R CHIP 1/10 5.6K OHM J 2012
RC304 HRFT272JCA R CHIP 1/10 2.7K OHM J 2012
RC306 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RC307 HRFT562JCA R CHIP 1/10 5.6K OHM J 2012
RC308 HRFT332JCA R CHIP 1/10 3.3K OHM J 2012
RC309 HRFT154JCA R CHIP 1/10 150K OHM J 2012
RC310 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC313 HRFT224JCA R CHIP 1/10 220K OHM J 2012
RC404 HRFT561JCA R CHIP 1/10 560 OHM J 2012
RC405 HRFT362JCA R CHIP 1/10 3.6K OHM J 2012
RC408 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC419 HRFT152JCA R CHIP 1/10 1.5K OHM J 2012
RC420 HRFT394JCA R CHIP 1/10 390K OHM J 2012
RC501 HRFT750JCA R CHIP 1/10 75 OHM J 2012
RC503~5 HRFT750JCA R CHIP 1/10 75 OHM J 2012
RC506 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC507 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC508 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC509 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC510 HRFT102JCA R CHIP 1/10 1K OHM J 2012
Page 4
LOC PART CODE PART NAME PART DESCRIPTION
RC511 HRFT470JCA R CHIP 1/10 47 OHM J 2012
RC512 HRFT223JCA R CHIP 1/10 22K OHM J 2012
RC513 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC514 HRFT151JCA R CHIP 1/10 150 OHM J 2012
RC515 HRFT000-CA R CHIP 1/10 0 OHM 2012
RC516 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC517 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC518 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC519 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC520 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC521 HRFT363JCA R CHIP 1/10 36K OHM J 2012
RC522 HRFT222JCA R CHIP 1/10 2.2K OHM J 2012
RC523 HRFT822JCA R CHIP 1/10 8.2K OHM J 2012
RC524 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC525 HRFT153JCA R CHIP 1/10 15K OHM J 2012
RC526 HRFT273JCA R CHIP 1/10 27K OHM J 2012
RC527 HRFT473JCA R CHIP 1/10 47K OHM J 2012
RC528 HRFT221JCA R CHIP 1/10 220 OHM J 2012
RC529~31 HRFT271JCA R CHIP 1/10 270 OHM J 2012
RC532 HRFT273JCA R CHIP 1/10 27K OHM J 2012
RC534 HRFT334JCA R CHIP 1/10 330K OHM J 2012
RC535 HRFT184JCA R CHIP 1/10 180K OHM J 2012
RC537 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC538 HRFT223JCA R CHIP 1/10 22K OHM J 2012
RC539 HRFT122JCA R CHIP 1/10 1.2K OHM J 2012
RC541~3 HRFT222JCA R CHIP 1/10 2.2K OHM J 2012
RC553 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC555 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC560 HRFT472JCA R CHIP 1/10 4.7K OHM J 2012
RC605 HRFT153JCA R CHIP 1/10 15K OHM J 2012
RC606 HRFT153JCA R CHIP 1/10 15K OHM J 2012
RC610 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC611 HRFT152JCA R CHIP 1/10 1.5K OHM J 2012
RC620 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC621 HRFT104JCA R CHIP 1/10 100K OHM J 2012
RC623 HRFT512JCA R CHIP 1/10 5.1K OHM J 2012
RC630 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC702 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC703 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC704 HRFT562JCA R CHIP 1/10 5.6K OHM J 2012
RC705 HRFT153JCA R CHIP 1/10 15K OHM J 2012
RC706 HRFT562JCA R CHIP 1/10 5.6K OHM J 2012
RC707 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC708 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC709 HRFT222JCA R CHIP 1/10 2.2K OHM J 2012
RC710 HRFT222JCA R CHIP 1/10 2.2K OHM J 2012
RC711 HRFT222JCA R CHIP 1/10 2.2K OHM J 2012
RC712 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC713 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC714 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC715 HRFT152JCA R CHIP 1/10 1.5K OHM J 2012
RC716 HRFT392JCA R CHIP 1/10 3.9K OHM J 2012
RC717 HRFT153JCA R CHIP 1/10 15K OHM J 2012
RC719 HRFT332JCA R CHIP 1/10 3.3K OHM J 2012
RC720 HRFT271JCA R CHIP 1/10 270 OHM J 2012
RC721 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC722 HRFT332JCA R CHIP 1/10 3.3K OHM J 2012
RC723 HRFT624JCA R CHIP 1/10 620K OHM J 2012
RC725 HRFT471JCA R CHIP 1/10 470 OHM J 2012
LOC PART CODE PART NAME PART DESCRIPTION
RC726 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC727 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC729 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC730 HRFT332JCA R CHIP 1/10 3.3K OHM J 2012
RC731 HRFT100JCA R CHIP 1/10 10 OHM J 2012
RC732 HRFT000-CA R CHIP 1/10 0 OHM 2012
RC733 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC736 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC738 HRFT101JCA R CHIP 1/10 100 OHM J 2012
RC751 HRFT103JCA R CHIP 1/10 10K OHM J 2012
RC752 HRFT682JCA R CHIP 1/10 6.8K OHM J 2012
RC754 HRFT333JCA R CHIP 1/10 33K OHM J 2012
RC755 HRFT473JCA R CHIP 1/10 47K OHM J 2012
RC822 HRFT134JCA R CHIP 1/10 130K OHM J 2012
RC828 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC829 HRFT102JCA R CHIP 1/10 1K OHM J 2012
RC901 HRFT272JCA R CHIP 1/10 2.7K OHM J 2012
RC902 HRFT302JCA R CHIP 1/10 3K OHM J 2012
RC903 HRFT302JCA R CHIP 1/10 3K OHM J 2012
RC904 HRFT302JCA R CHIP 1/10 3K OHM J 2012
RC905~7 HRFT272JCA R CHIP 1/10 2.7K OHM J 2012
RLY1 5SC0101338 SW RELAY DQ5D1-O(M)/GJ-SS-105LM
SCT1 4859303430 SOCKET CRT PCS633A
SF101 5PG3962M-- FILTER SAW G 3962-M
SF102 5PK9650M-- FILTER SAW K9650M
SJ01 4859200401 SOCKET RGB YRS21-R1
SW701 5S50101090 SW TACT SKHV17910A
SW702 5S50101090 SW TACT SKHV17910A
SW703 5S50101090 SW TACT SKHV17910A
SW704 5S50101090 SW TACT SKHV17910A
SW705 5S50101090 SW TACT SKHV17910A
R
SW801 5S40101146 SW POWER PUSH SS-160-7-B
T401 50D10A3--- TRANS DRIVE TD-10A3
R
T402 50H0000202 FBT FUY20C001
T801 50M4042A5- TRANS SMPS TSM-4042A5
R
U101 4859719930 TUNER VARACTOR DT5-BF18D
W101 4851900130
X501 5XEX4R433B CRYSTAL QUARTZ
X502 5XEX3R579B CRYSTAL QUARTZ
GROUND TUNER
AS
DS-W1015-S
HC-49U 4.43361M 15PPM
TP
HC-49U 3.57954M 15PPM
TP
X701 5XEX4R000C CRYSTAL QUARTZ HC-49U 4.0000MHZ (TP)
Loading...
