Millennia
Use and Care Manual
™
Wall and Island Range Hoods
For Use With Models:
DHW301, DHW361, DHW421, DHW482,
DHI361, DHI421, DHI482, DHI542, DHI602
Part No. 101741 Rev. B
Style varies
Model DHW482 shown
Ta b l e o f Co n T e n T s
Im p o r T a n T sa f e T y In s T r u C T I o n s ............................................. 1-2
pa r T s o f T h e ra n g e ho o d ...................................................... 3
op e r a T I n g In s T r u C T I o n s ......................................................... 4
l e a n I n g a n d ma I n T e n a n C e ................................................ 5-6
C
be f o r e yo u Ca l l f o r se r v I C e ................................................... 7
Wa r r a n T y & se r v I C e ............................................................. 8
a r r a n T y Ca r d ......................................................ba C k Co v e r
W
To Our Valued Customer:
Congratulations on your purchase of the very latest in Dacor
®
products! Our unique combination of features, style and
performance make us The Life of the Kitchen
™
, and a great addition to your home.
In order to familiarize yourself with the controls, functions, and full potential of your new Distinctive Appliance, we
suggest that you thoroughly read this use and care manual, beginning with the Important Safety Instructions
section.
All Dacor appliances are designed and manufactured with quality and pride, while working within the framework of our
company value. Should you ever experience a problem with your product, please first check the Before You Call for
Service section of this manual for guidance. It provides useful suggestions and remedies prior to calling for service.
Valuable customer input helps us to continuously improve our products and services, so please feel free to contact
our Customer Service Team for assistance with any of your product support needs.
Dacor Customer Service Team
1440 Bridge Gate Drive
Diamond Bar, CA 91765
Telephone: (800) 793-0093
Fax: (626) 403-3130
Hours of Operation: Monday through Friday
6:00 A.M. to 5:00 P.M. Pacific Time
Web Site: www.Dacor.com
Thank you for choosing Dacor for your home. We are a company built by families for families and we are dedicated
to serving yours. We are confident that your new Dacor product will deliver a high level of performance and
enjoyment for many years to come.
Sincerely,
Cheryl Crowe
Director, Customer Satisfaction
© 2008 Dacor, all rights reserved
Important Safety Instructions
INSTALLER: PLEASE LEAVE MANUAL WITH THE
APPLIANCE.
CUSTOMER: READ THIS USE & CARE MANUAL
COMPLETELY BEFORE USING YOUR APPLIANCE.
KEEP IT FOR FUTURE REFERENCE. KEEP THIS
MANUAL AND THE SALES RECEIPT OR THE
CANCELED CHECK IN A SAFE PLACE. PROOF OF
ORIGINAL PURCHASE DATE IS REQUIRED FOR
WARRANTY SERVICE.
If you have any questions, call:
Dacor Customer Service Team
(800) 793-0093 (U.S.A. and Canada)
Monday — Friday 6:00
Web site: www.Dacor.com
Have the model and serial number for your range hood
available. Remove the filters to access the model and serial
number labels. They are located on the left side (as you
face the control panel). Record these numbers below for
easy access.
Model Number ___________________________________
Serial Number ___________________________________
a.m. to 5:00 p.m. Pacific Time
What You Need to Know About Safety
Instructions
Important Safety Instructions and warnings in this guide
cover all possible situations. Use common sense, caution
and care when installing, maintaining or operating any
appliance.
Safety Symbols and Labels
DANGER
DANGER – Immediate hazards that WILL result in
severe personal injury or death.
WARNING
WARNING – Hazards or unsafe practices that COULD
result in severe personal injury or death.
CAUTION
CAUTION – Hazards or unsafe practices that COULD
result in minor personal injury or property damage.
Date of Purchase_________________________________
For warranty and service information, see page 8.
Because Dacor continously improves its products we may
need to make changes to this product without changing this
manual.
DANGER
To avoid the possibility of explosion or fire, do not store or use combustible, flammable or explosive vapors and liquids
(such as gasoline) inside or in the vicinity of this or any other appliance. Also keep items that could explode, such as
aerosol cans away from cooktop burners, ovens and range hoods. Do not store flammable or explosive materials in
adjacent cabinets or areas.
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING:
a) Use this unit only in the manner intended by the manufacturer. If you have questions, contact the manufacturer.
b) Before servicing or cleaning unit, switch power off at service panel and lock the service disconnecting means to
prevent power from being switched on accidentally. When the service disconnecting means cannot be locked,
security fasten a prominent warning device, such as a tag, to the service panel.
READ AND SAVE THESE INSTRUCTIONS
1
3
Important Safety Instructions
To reduce the risk of fire, electric shock, serious injury or death when using your range hood, follow basic safety
precautions, including the following:
WARNING
If you receive a damaged product, immediately contact your dealer or builder. 1. Do not install or use a damaged hood.
Make sure that the range hood has been properly installed and grounded by a qualified installer according to the 2.
accompanying installation instructions. Have the installer show you the location of the fuse or junction box so that
you know where and how to turn the power off.
Do not install, repair or replace any part of the range hood unless specifically recommended in the literature 3.
accompanying it. A qualified service technician should perform all other service.
To avoid the risk of electric shock, before cleaning the range hood, turn off the main power switch.4.
Use the range hood only for its intended purpose as outlined in this manual. 5. DO NOT use this range hood to vent
hazardous or explosive materials or vapors. If you have questions, contact the manufacturer.
Do not tamper with the controls.6.
Never allow the filters to become blocked or clogged. Do not allow foreign objects, such as cigarettes or napkins, to 7.
be sucked into the hood.
Clean the filter(s) and all grease-laden surfaces often to prevent grease fires and maintain performance.8.
Clean this appliance only in the manner specified in this manual. Use only the cleaners specified.9.
If the cooktop and range hood are near a window, use an appropriate window treatment. Avoid long drapes or other 10.
window coverings that could blow over the cooktop and hood, resulting in a fire hazard.
Always run the blower(s) whenever the cooktop is operating.11.
Never leave the range or cooktop unattended when a burner (or element) is in use. Boil-overs and greasy spills may 12.
smoke and/or ignite.
Do not leave children alone or unattended in the area where the cooktop and range hood are in use. Never allow 13.
children to sit or stand on an appliance. Do not let children play with a range, cooktop or range hood. Do not store
items of interest to children above or around the cooktop, range or range hood.
The minimum vertical distance between the cooktop surface and the exterior part of the hood must be no less 14.
than 30” (762 mm). The vertical distance may be longer for the range or cooktop being used. Consult the range or
cooktop installation instructions for the minimum vertical distance from the appliance being used.
TO REDUCE THE RISK OF INJURY TO PERSONS IN THE EVENT OF A RANGE TOP GREASE FIRE: 15.
SMOTHER FLAMES with a close-fitting lid, cookie sheet or metal tray, then turn off the burner. BE CAREFUL a.
TO PREVENT BURNS. If the flames do not go out immediately, EVACUATE AND CALL THE FIRE
DEPARTMENT.
NEVER PICK UP A FLAMING PAN - you may be burned.b.
DO NOT USE WATER, including wet dish clothes or towels - a violent steam explosion may result.c.
Use a fire extinguisher ONLY if:d.
You have a Class ABC extinguisher, and you already know how to operate it.•
The fire is small and contained in the area where it started.•
The fire department is being called.•
You can fight the fire with your back to an exit.•
2
Parts of the Range Hood
B
F D F D
A HOOD - The hood directs heat and smoke into the
blower system located inside the unit. The blower system
forces heat and smoke into the duct inside the chimney B
which vents to the outside. The filter, the lights and main
power switch are located on the bottom of the hood. The
blower system on some models, consists of more than one
blower. See the table below.
C CONTROL PANEL - Use the keys on the control panel
to control your hood’s various features.
E
C
D FILTER - Prevents grease and grime from getting into
the blower(s). The number of filters depends on the model.
See the table below.
E MAIN POWER SWITCH - Located behind the filter, on
the bottom of the hood, on the opposite side of the control
panel. Controls power to the control panel, lights and
blower(s).
F LIGHTS - 20W halogen lights. The number of lights and
location depends on the model. See the table below.
A
HOOD FEATURES
MODEL HOOD TYPE HOOD SIZE BLOWERS FILTERS LIGHTS
DHW301 WALL MOUNT 30” 1 1 2
DHW361 WALL MOUNT 36” 1 1 2
DHW421 WALL MOUNT 42” 1 1 3
DHW482 WALL MOUNT 48” 2 2 4
DHI361 ISLAND 36” 1 1 4
DHI421 ISLAND 42” 1 1 4
DHI482 ISLAND 48” 2 2 4
DHI542 ISLAND 54” 2 2 6
DHI602 ISLAND 60” 2 3 6
3
5
Operating Instructions
WARNING
Never operate the range hood without the filter(s) in
place. Also, do not operate the hood with grimy or
grease-laden filters. Personal injury or damage to the
range hood could result.
IMPORTANT OPERATING TIPS
Always use the blower when using the cooktop or •
range.
Turn the blower on a few minutes before starting to •
cook to establish an airflow pattern in the room.
Adjust the fan speed according to the volume and •
weight of the food you are cooking.
Shut nearby windows and doors, turn off ceiling fans •
and close nearby heating and air conditioning outlets to
reduce air currents around the hood.
Place your largest pots and pans on the back burners •
when possible.
In the interest of safety, heat oils and fats slowly.•
OPERATION
Main Power Switch
The main power switch is located behind the filter, on the
bottom of the hood, on the opposite side of the control
panel. See page 3 for the location.
Remove the filters and push in on the switch to turn •
power on or off. The control panel is lit when the main
power switch is on.
Turning on the Lights
Touch the light key • A to turn on the lights.
Touch the light key again to turn them off.•
Touch and release the • “-” key B on the control panel
to decrease the speed.
Touch and hold the • “-” key to turn the blower
completely off.
OFF LOW HIGHMEDIUM
BLOWER SPEED INDICATOR
NOTE: To conserve energy, the blower system
automatically turns itself off if it is left on for four hours
continuously.
Timer Key (Filter System)
After 30 hours of blower operation, the control panel will
flash. This signal means it is time to clean the filter system
(see page 5).
To reset the timer, touch the timer reset key • E .
ENERGY SAVING TIPS
Do not operate the blower • system at a speed higher
than necessary to remove heat and smoke. Running
at too high a speed will draw in air from outside the
house, increasing heating and cooling costs.
Keep the• filter system and hood surfaces free of grease
and grime to improve efficiency.
Turn the blower • off as soon as all smoke and odors
have been cleared.
Select cookware of the proper size, material and •
construction for the cooking task. Always use lids on
cookware to retain heat and moisture.
Minimize the amount of liquid used to cook food.•
A B D EC
CONTROL PANEL
Turning on the Blower System
The blower system has four speed settings. The speed is
indicated by the number of lights that glow on the blower
speed indicator C .
Touch the • “+” key D to turn on the blower system.
To increase the speed, touch and release the • “+” key
until the blower system is at the desired setting.
4
Cleaning and Maintenance
Cleaning
WARNING
To prevent electric shock or damage to the blower(s), •
thoroughly dry the filter(s) immediately after cleaning.
To prevent electric shock turn off the power at the •
circuit breaker or fuse box before cleaning the range
hood or filter(s).
Clean the hood only in the manner specified.•
To avoid dangerous fumes or damage to your hood’s •
surfaces, use only the types of cleaning solutions
specified in this manual.
To avoid personal injury, turn off the cooktop or range •
and make sure that the appliance and range hood are
cool before cleaning.
Always wipe stainless steel (silver colored) surfaces •
with the grain. To prevent scratching, do not use
abrasive cleaners or scrubbers on stainless steel or
glass surfaces.
To avoid damage to the blower, do not reinstall •
damaged filters (see page 6 for replacement part
numbers).
Proper cleaning is necessary to ensure safe operation
and maintain hood performance and appearance. The
frequency of cleaning should be adjusted according to the
type and amount of cooking. Best results will be achieved
by cleaning soiled components as soon as possible.
CLEANING STAINLESS STEEL SURFACES
Clean stainless steel surfaces with a mild solution of
detergent or dishwashing soap and warm water. Rinse and
dry with a soft, lint-free cloth.
You may also use Dacor Stainless Steel Cleaner. Use it
according to the directions on the package.
CLEANING THE LIGHT LENS
Use a mild glass cleaner to remove smudges on the light
fixture lens. You can also clean it with Dacor Cook Top
Cleaning Creme. Use it according to the directions on the
package.
To Remove the Filter(s):
The filter(s) A are located on the bottom of the hood,
directly above the cooking surface.
Hold the filter in place with one hand and pull on the 1.
release lever B with the other.
Lower the filter out of the hood. On hoods with more 2.
than one filter, remove and clean all of the filters.
A
B
To Clean the Filter(s):
Hand wash the filter(s) in hot water with a mild detergent
solution or dishwashing soap. Or you can place them in an
automatic dishwasher. Dry the filter(s) completely before
reinstalling.
To Reinstall the Filter(s):
Insert the end of the filter opposite the release lever 1.
into the slots toward the back of the hood above the
hood rim. The release lever must be facing down.
Pull on the release lever while sliding the free end of 2.
the filter into the filter opening.
Release the lever.3.
CLEANING THE FILTER(S)
Clean the filter a minimum of every two months.
To help remind you to clean the filter(s), the
control panel will flash after 30 hours of blower
operation. Touch the timer reset key to reset the timer.
5
7
Cleaning and Maintenance
Maintenance
LIGHT BULB REPLACEMENT
WARNING
To prevent electric shock turn off the main power •
switch.
To avoid personal injury, make sure the cooktop or •
range, the hood and the light bulb are cool before
changing the light bulb.
Light bulb replacement is considered to be a homeowner
maintenance operation. If all of the lights do not work,
before replacing any bulbs, check to make sure that the
main circuit breaker (or fuse) and the main power switch on
the hood are on.
Replace the light bulbs only with Dacor Part No. 101944,
available from any authorized Dacor parts dealer.
IMPORTANT:
Do not touch the replacement halogen light bulbs with •
your fingers. Halogen bulbs are sensitive to the oils
from your hand. The oils from your hand will stick to the
bulb and cause it to burn out faster than normal.
Do not pry out the entire light fixture • A , when replacing
the light bulb. It is difficult to reinstall. Pry out only the
the lens retaining ring B , which is the inner metal ring
attached to the light fixture.
Once the lens retaining ring and lens are removed, pull 3.
the old bulb C sideways, out of the socket.
Using a glove, insert the new bulb into the socket. Line 4.
up the prongs on the new light blub with the holes in
the light socket. Gently push in on the new bulb until it
stops.
A
C
D
B
A
B
Turn off the main power switch. See page 3 for the 1.
location.
Hold the lens retaining ring 2. B and lens in place with
one hand while prying the edge of the ring loose
with a small screwdriver or plastic knife. If you use
a screwdriver, cover the end with tape to prevent
scratching.
Center the lens 5. D on the lens retaining ring B and
snap it back into place on the light fixture A .
Turn on the main power switch. Touch the light key to 6.
make sure it is working.
REPLACEMENT PARTS
DACOR PART # DESCRIPTION
101944 Light bulb
101952 Filter
6
Before You Call For Service
Problem Solution Guide
PROBLEM MAY BE CAUSED BY WHAT TO DO
Nothing Works. Control panel is not lit.
Blower system does not work.
Lights do not work. Control panel is not
lit.
Light does not work. Control panel is lit. Loose light bulb. Check to make sure that both prongs
Blower system does not draw heat and
smoke properly.
Blower shuts off by itself after being left
on for a long time.
Blower system does not work. Control
panel not lit.
Blower system does not work. Control
panel lit.
Power to hood is off. Turn on power at junction or fuse box.
Check for tripped breaker or blown
fuse.
Hood main power switch is off. Make sure hood main power switch is
on (see page 3).
Power outage. Call electric company.
Hood not connected to electric power. Have qualified electrician connect
hood to electric power.
See Nothing Works above.
on the light bulb are inserted into the
holes on the light socket (see
page 6).
Light bulb burned out. Replace light bulb (see page 6).
Blower set to low setting. See Operating Instructions section.
Filter(s) clogged or dirty. Check filters. Make sure they are
completely clean and not blocked by
foreign objects.
Damper jammed shut or duct work
clogged.
Normal operation. To conserve energy, the blower
See Nothing Works above.
Blower system malfunction. Call for service.
Consult with a qualified installation
professional.*
automatically turns itself off if it is left
on for four hours continuously.
* The duct work connected from the range hood chimney to outside the house or building required to vent heat and
smoke is not manufactured, warranted or serviced by Dacor. The customer is responsible for having a qualified installer
install and maintain the duct work.
7
Warranty & Service
Product Maintenance
Do not perform any maintenance other than that instructed
in the Cleaning and Maintenance section of this manual.
A qualified service technician should perform all other
service.
ge T T I n g he l p
Before you obtain service, please review the Before You
Call for Service section of this manual starting on page 7.
If you have performed the checks in the Problem Solution
Guide and the problem has not yet been remedied, please
visit our web site or contact our Customer Service Team
for a listing of Dacor authorized service agents. Prior
to requesting service, it is helpful to be familiar with the
warranty terms and conditions on this page.
Contact us through our web site at:
www.Dacor.com
Dacor Customer Service Team:
Tel: (800) 793-0093
Fax: (626) 403-3130
Business Hours: 6:00
a.m. - 5:00 p.m. Pacific Time
You may also write us at:
Dacor Customer Service
1440 Bridge Gate Drive
Diamond Bar, CA 91765
At Dacor, we believe that our quality of service equals
that of our product. Should your experience with our
service network or product be different, please contact our
Customer Service Team and share your encounter with us.
We will do our utmost to resolve the situation for you and
deliver on our Dacor promise.
If you need anything clarified, just let us know.
Wh a T Is Co v e r e d
CERTIFICATE OF WARRANTIES: DACOR HOODS
WITHIN THE FIFTY STATES OF THE U.S.A., THE
DISTRICT OF COLUMBIA, AND CANADA*:
FULL ONE-YEAR WARRANTY
If your DACOR product fails to function within one year of
the original date of purchase, due to a defect in material or
workmanship, DACOR will remedy the defect without charge
to you or subsequent users. The owner must provide proof of
purchase upon request, and have the appliance accessible for
service.
Warranty is null and void if non-CSA approved product is
transported from the U.S.
OUTSIDE THE FIFTY STATES OF THE U.S.A., THE
DISTRICT OF COLUMBIA, AND CANADA:
LIMITED FIRST YEAR WARRANTY
If your DACOR product fails to function within one year of
the original date of purchase, due to a defect in material or
workmanship, DACOR will furnish a new part, F.O.B. factory,
to replace the defective part. All delivery, installation and labor
costs are the responsibility of the purchaser. The owner must
provide proof of purchase, upon request, and have the appliance
accessible for service.
Wh a T Is no T Co v e r e d
Service calls to educate the customer in the proper use and •
care of the product.
Failure of the product when used for commercial, business, •
rental or any application other than for residential consumer
use.
Replacement of house fuses or fuse boxes, or resetting of •
circuit breakers.
Light bulbs and filters.•
Routine maintenance and cleaning.•
Duct work external to the range hood.•
Breakage, discoloration or damage to glass, metal surfaces, •
plastic components, trim, paint or other cosmetic finish,
caused by improper usage or care, abuse or neglect.
Damage to the product caused by accident, fire, flood or •
other acts of God.
THE REMEDIES PROVIDED FOR IN THE ABOVE EXPRESS
WARRANTIES ARE THE SOLE AND EXCLUSIVE REMEDIES.
THEREFORE, NO OTHER EXPRESS WARRANTIES ARE
MADE, AND OUTSIDE THE FIFTY STATES OF THE UNITED
STATES, THE DISTRICT OF COLUMBIA, AND CANADA, ALL
IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED
TO, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR USE OR PURPOSE, ARE
LIMITED IN DURATION TO ONE YEAR FROM THE DATE OF
ORIGINAL PURCHASE. IN NO EVENT SHALL DACOR BE
LIABLE FOR INCIDENTAL EXPENSE OR CONSEQUENTIAL
DAMAGES. NO WARRANTIES, EXPRESS OR IMPLIED, ARE
MADE TO ANY BUYER FOR RESALE.
Some states do not allow limitations on how long an implied
warranty lasts, or do not allow the exclusion or limitation of
inconsequential damages, so the above limitations or exclusions
may not apply to you. This warranty gives you specific legal rights,
and you may also have other rights that vary from state to state.
8
NO POSTAGE
NECESSARY
IF MAILED
IN THE
UNITED STATES
DACOR INC.
ATTN: WARRANTY PROCESSING DEPT
1440 BRIDGE GATE DR STE 200
PO BOX 6532
DIAMOND BAR CA 91765-9861
BUSINESS REPLY MAIL
PERMIT NO. 4507
POSTAGE WILL BE PAID BY ADDRESSEE
FIRST-CLASS MAIL DIAMOND BAR CA
fold here
Web site: www.Dacor.com
Corporate phone: (800) 793-0093
WARRANTY INFORMATION
IMPORTANT:
Your warranty will not be activated until you activate it online or return this form to Dacor. If you have purchased more
than one Dacor product, please return all forms in one envelope or activate the warranty for each product online.
Please rest assured that under no conditions will Dacor sell your name or any of the information on this form for mailing list purposes. We
are very grateful that you have chosen Dacor products for your home and do not consider the sale of such information to be a proper way
of expressing our gratitude!
Place Serial Number Label Here
Your willingness to take a few seconds to fill in the section below will be sincerely appreciated. Thank you.
1. How were you first exposed to Dacor products? (Please check one only.)
A. T.V. Cooking Show F Builder
B. Magazine G. Architect/Designer
C. Appliance Dealer Showroom H. Another Dacor Owner
D. Kitchen Dealer Showroom I. Model Home
E. Home Show J. Other
2. Where did you buy your Dacor appliances?
A. Appliance Dealer D. Builder
B. Kitchen Dealer E. Other
C. Builder Supplier
3. For what purpose was the product purchased?
A. Replacement only C. New Home
B. Part of a Remodel D. Other
4. What is your household income?
A. Under $75,000 D. $150,000 – $200,000
B. $75,000 – $100,000 E. $200,000 – $250,000
C. $100,000 – $150,000 F. Over $250,000
5. What other brands of appliances do you have in your kitchen?
A. Cooktop C. Dishwasher
B. Oven D. Refrigerator
6. Would you buy or recommend another Dacor product?
Yes No
Comments:
Owner’s Name:
Street:
City: State: Zip:
Purchase Date: Email: Telephone:
Dealer:
City: State: Zip:
(Please Print or Type)
Last First Middle
cut here cut here
Please visit www.Dacor.com to activate your warranty online.
Thank you very much for your assistance. The information you have
provided will be extremely valuable in helping us plan for the future
and giving you the support you deserve.
Loading...
