Cuisinart EM-350 User Manual

INSTRUCTION/RECIPE
BOOKLET

Buona Tazza™ Single Serve Espresso,
Caffe Latte and Cappuccino Machine

For your safety and continued enjoyment of this product, always read the instruction book carefully before using.

EM-350 SERIES

IMPORTANT
SAFEGUARDS

We at Cuisinart are very safety conscious. We
design and manufacture consumer products
with the safety of you, our valued customer,
foremost in mind. In addition we ask that you
exercise a degree of care when using electrical
appliances and adhere to the following
precautions.

When using electrical appliances, basic safety
precautions should always be followed,
including the following:

1. CAREFULLY READ ALL INSTRUCTIONS

BEFORE OPERATING APPLIANCE, AND
SAVE THIS MANUAL FOR FUTURE
REFERENCE.

2. Unplug appliance from outlet when not

in use and before cleaning. Allow to cool
before putting on or taking off parts, and
before cleaning.

3. To protect against fire, electric shock and
injury to persons do not immerse the
appliance, cord or plug in water or any
other liquid.

4. This appliance is for household use only.

5. Do not operate the unit with the brewing
head open.

6. Do not use this appliance for anything other
than its intended use.

7. This appliance should not be used by or
near children or individuals with certain
disabilities.

8. Do not leave the appliance unattended
when in use.

9. Do not touch hot surfaces. Use handles
or knobs.

10. Always use the appliance on a dry,
level surface.

11. To disconnect, turn all controls off, then
remove plug from power outlet.

12. Do not place this appliance on or near a
hot gas or electric burner, or where it could
touch a heated oven.

13. Do not let the cord hang over the edge of a
table or counter or touch hot surfaces or
become knotted.

14. The use of accessory attachments not
recommended by Cuisinart may cause a
risk of injury to persons, fire or electrical
shock.

15. Strictly follow cleaning and care instructions.

16. Do not use this appliance for anything other
than its intended use. Do not use in moving
vehicles or boats.

17. Do not use outdoors.

18. Always switch the appliance off and then
remove plug from the power outlet when
the appliance is not being used and before
cleaning.

19. An extension cord is not recommended.
However, if one is needed, the extension
cord should be a grounded type and its
electrical rating must be the same or higher
wattage as the appliance. Regularly inspect
the supply cord, plug and actual appliance
for any damage. If found damaged in any
way, immediately cease use of the
appliance and call Cuisinart Customer
Service at 1-800-726-0190.

20. For any maintenance other than cleaning,
call Cuisinart Customer Service at 1-800­726-0190.

21. Refer servicing to qualified personnel.

22. Do not operate any appliance with a
damaged cord or plug or after the
appliance malfunctions, or has been
damaged in any manner. Return appliance
to the nearest authorized service facility for
examination, repair or adjustment.

23. Do not operate your appliance in an
appliance garage or under a wall cabinet.

When storing in an appliance garage
always unplug the unit from the
electrical outlet. Not doing so could

create a risk of fire, especially if the
appliance touches the walls of the garage
or the door touches the unit as it closes.

24. Scalding may occur if the brewing head is
opened during brewing cycle.

2

SAVE THESE
INSTRUCTIONS

NOTE: For safety reasons it is recommended
you plug your Cuisinart appliance directly into
the power outlet. Use in conjunction with a
power strip or extension cord is not
recommended.

FOR HOUSEHOLD USE
ONLY

WARNING: RISK OF FIRE OR
ELECTRIC SHOCK

The lightning flash with arrowhead
symbol within an equilateral
triangle is intended to alert the
user to the presence of
uninsulated dangerous voltage
within the product’s enclosure
that may be of sufficient
magnitude to constitute a risk of
fire or electric shock to persons.
The exclamation point within an
equilateral triangle is intended to
alert the user to the presence of
important operating and
maintenance (servicing)
instructions in the literature
accompanying the appliance.

WARNING

RISK OF FI RE OR ELEC TRIC SHOCK

DO NOT OPEN

WARNIN G: TO REDUCE THE R ISK OF FIRE OR ELE CTRIC SHOCK ,

DO NOT RE MOVE CO VER (OR BA CK)

NO USER-SERVICEABLE PARTS INSIDE

REPAIR SHOULD BE DONE BY AUTHORIZED SERVICE PERSONNEL ONLY

SPECIAL CORD SET
INSTRUCTIONS

A short power-supply cord is provided to
reduce the risks resulting from becoming
entangled in or tripping over a longer cord.

Longer extension cords are available and may
be used if care is exercised in their use.

If an extension cord is used, the marked
electrical rating of the extension cord must be
at least as great as the electrical rating of the
appliance. The extension cord should be a
grounding-type 3-wire cord, and the longer
cord should be arranged so that it will not
drape over the countertop or tabletop where
it can be pulled on by children or tripped over.

A.

NOTICE

If you have a
die-cast metal unit,
for your protection
it is equipped with
a 3-conductor cord
set that has
a molded 3-prong
grounding-type
plug, and should
be used in combi­nation with a
properly connected
grounding-type
outlet as shown
in Figure A.

Circuit Grounding
Conductor
Connected
Properly

Grounding
Prong

Adapter

Grounding Lug

Cover
Mounting
Screw

Cover of
Grounded
Outlet Box

B.

C.

SPECIAL SAFETY
INSTRUCTIONS

1. Use only cold water in the water reservoir.
Do not use any other liquid.

2. Never use the machine without water in it.

If a grounding-type outlet is not available, an
adapter, as shown in Figure B, may be
obtained so that a 2-slot wall outlet can be
used with a 3-prong plug. As shown in Figure
C, the adapter must be grounded by

3

attaching its grounding lug under the screw of
the outlet cover plate. NOTE: Do not remove

the grounding prong.

CAUTION: Before using an adapter, it must
be determined that the outlet cover plate
screw is properly grounded. If in doubt,
consult a licensed electrician. Never use
an adapter unless you are sure it is
properly grounded.

Note: Use of an adapter is not permitted in
Canada.

CONTENTS

Important Safeguards.....................................2

Unpacking Instructions .................................. 4

Introduction ....................................................4

Features and Benefits ....................................5

Preparing Your Espresso Machine ................. 6

Using Your Espresso Machine ....................... 6

Programming .................................................. 7

Using the Steam Wand ..................................7

Temperature Controls ..................................... 8

Cleaning and Maintenance ............................ 8

Troubleshooting .............................................. 9

Recipes ......................................................... 10

Steaming/Frothing Instructions .................... 10

Warranty .......................................................17

IMPORTANT UNPACKING
INSTRUCTIONS

1. Place the box on a large, sturdy, flat surface.

2. Remove the instruction book and any
other literature.

3. Remove the sample pack of illy®
iperEspresso® capsules.

4. Turn the box so that the backside of the
machine is down, and slide the espresso
maker from the box.

5. After the espresso maker has been removed,
place the box and the side pulp-molded
inserts out of the way.

6. Remove all packing materials, tape, etc.

We suggest you save all packing materials in
the event that future shipping of the machine
is needed. Keep all plastic bags away from
children.

INTRODUCTION

Cuisinart and illy are proud to introduce the
Buona Tazza™ Single Serve Espresso,
Cappuccino and Latte Machine powered by
Cuisinart and featuring the proprietary illy®
iperEspresso
Cuisinart’s excellence in coffeemakers and illy’s
legendary coffee heritage to bring the pleasure
of savoring the rich, smooth taste of illy® to the
comfort of your own home.

®

capsule system. This combines

4

FEATURES AND BENEFITS

1. Water Reservoir Lid

2.

Removable 34-ounce Water Reservoir

3.

Cup-Warming Plate

Convenient place to warm cups.

4.

19 Bar Pump (not shown)

5.

Brew Head Lever

Use the die-cast metal lever to open and
close the brew head.

6. Brew Head

7.

Brewing Spout

Strategically positioned for optimal results.

8.

Used Capsule Container

(Also contains some residual liquid left after
brewing.)

9.

Espresso Cup Tray

Folds up when taller mugs need to be used.

10.

Drip Tray Grate

11.

Removable Drip Tray

12. Travel Mug Tray

13.

Power Switch

14.

Short Espresso Button

15.

Long Espresso Button

16.

Manual/Adjustable Strength Control/
Programmable Button

17. Steam Button

Used to make cappuccinos and lattes.

Will flash until ready for use.

5

14

15

16

17

26

21

22

6

7

18. Stainless Steel Frothing Pitcher

Used for steaming milk for cappuccinos and

lattes.

19. Frothing Wand and Removable Sleeve

Used to steam milk for Cappuccinos and Lattes.

20. Steam/Hot Water Control Dial

Used to activate steam or hot water.

21. Hot Setting Button

Select if less-hot coffee temperature is
desired.

22. Hotter Setting Button

Default coffee temperature setting.

23. Energy Saver Mode (not shown)

Saves 50% of power after 30 min. non-use.

24. Auto Off Mode (not shown)

Shuts off after 60 min. non-use.

25. Power Cord (not shown)

26.

Cleaning Pin

Use the black cleaning pin to clean any excess
milk that gets stuck inside the steam wand.

27. BPA Free (not shown)

All materials that come in contact with liquid
are BPA free.

28. 14-Capsule Pack (not shown)

Choose from 100% Arabica varieties!

3

20

1

2

8

10

11

9

12

19

13

18

5

PREPARING YOUR
ESPRESSO MACHINE

1.

Put the espresso machine on a dry, stable
countertop or other flat, sturdy surface
where you will be using the machine.

IMPORTANT: For first-time use or if the

machine has not been used for some time,
it is important that it is rinsed as follows:

2. Remove the lid of the water reservoir. Using
the handle, lift the water reservoir off the
base and fill with fresh, cold drinking water.
Replace the water reservoir on the base,
and cover with the lid. Using the tracks as
a guide, slide the water reservoir back into
position and push down firmly to engage.

Important: The unit will not function unless

the water reservoir is properly in place.

3. Insert the plug into a power outlet. Press
the power button once to turn the espresso
machine on. All of the controls on the front
of the machine will flash while it’s pre­heating. Lights will turn steady when the
unit is in ready mode (approximately
1 minute).

4. Make sure the drip tray and grate are in
place.

5. Place a mug on the drip tray.

6. Press the Manual
water to run through for approximately 5 to
10 seconds. Press once more to stop.

7.

Position espresso cups on the warming plate.

8. The machine is now in preheat/ready mode
and ready to use.

NOTE: If the water reservoir is empty or not
properly positioned, the unit will not function.
The Short , Long , Manual and Steam

LEDs will flash. Turn off the machine, fill the

water reservoir, and turn the machine back on.

button and allow the

USING YOUR
ESPRESSO MACHINE

Always make sure you have water in the
reservoir, a capsule in the brew head, and
that the appropriate tray is being used.
NOTE: This machine is designed

exclusively for use with illy
capsules. No other type of capsule, pod,
or coffee can be used.

Short or Long Pre-Programmed Espresso

1. Using the lever, open the brew head, insert
a capsule, and close the brew head.

2. With an espresso cup on the espresso cup
tray, select either a SHORT
or LONG
selected function and Hotter Temperature
setting LEDs remain on, while all the other
LEDs are off. Once all LEDs are on again,
the machine is ready for the next cycle.)

For optimal results, we recommend using the
Long
iperEspresso capsule. The Long
provides an Americano single espresso. Using
this setting with other iperEspresso
will alter the taste.

NOTE: As part of illy-patented technology in the
iperEspresso
completely self-contained in the capsule and
does not get into the brew head. So there is no
need to rinse in between cycles as there will be
no transfer of flavor.

CAUTION: Scalding may occur if the brewing
head is opened during brewing cycle.

Manual/Adjustable Strength Control
Programming

1. Using the lever, open the brew head, insert

button with the blue "Lungo"

a capsule, and close the brew head.

(3 ounces) espresso. (The

®

capsule, the brewing process is

®

iperEspresso®

(1.2 ounces)

button

®

varieties

6
