Craftsman 113.199250 User Manual

Save This Manual

For Future Reference

Sears

owners

manual

MODEL NO.

113.199200

SAW ONLY

113.199250

SAW WITH LEGS

Serial
Number

Model and serial
number may be found

at the front of the base.

You should record both
model and serial number

in a safe place for
future use.

CAUTION:

Read GENERAL
and ADDITIONAL

SAFETY
INSTRUCTIONS

carefully

CRRFTSMRN

IO-INCH

RADIAL SAW

• assembly

• operating

• repair parts

Sold by SEARS, ROEBUCK AND CO., Chicago, IL. 60684 U.S.A.

Part No. 63888 Printed in U.S.A.

FULL ONE YEAR WARRANTY ON CRAFTSMAN RADIAL SAW

If within one year from the date of purchase, this Craftsman Radial Saw fails due to a defect in material or

workmanship, Sears will repair it, free of charge.
WARRANTY SERVICE IS AVAILABLE BY SIMPLY CONTACTING THE NEAREST SEARS SERVICE

CENTER/DEPARTMENT THROUGHOUT THE UNITED STATES.

THIS WARRANTY APPLIES ONLY WHILE THIS PRODUCT IS IN USE IN THE UNITED STATES.

This warranty gives you specific legal rights, and you may have other rights which vary from state to state.

SEARS, ROEBUCK AND CO. DEPT., 698/731A Sears Tower, Chicago, IL 60684

general safety instructions for power tools

1. KNOW YOUR POWER TOOL

Read and understand the owner's manual and labels
affixed to the tool. Learn _ts applications and limitations
as welt as the specific potentiaI hazards peculiar to this

tool.

2. GROUND ALLTOOLS

lhis toot s equipped with an approved 3-conductor

cord and + 3-prong grounding type plug to fit the

proper grounding type receptacle. The green conductor

ill [he cord is the grounding wire. Never connect the

greerl wire ',o a live terminal,

3. KEEP GUARDS IN PLACE

hr workirrg order, and in proper adjustment and
alignment.

4. REMOVE ADJUSTING KEYS
AND WRENCHES

Form habt_ of checking lo see that keys and adjusting

wrerrches are removed from tool before turning it on,

5. KEEP WORK AREA CLEAN

Cluttered )reas arid benches invite accidents. Floor
must not b+_slippery due to wax ot sawdust

6. AVOID DANGEROUS ENVIRONMENT

Don't use power tools in damp or wet locations or

expose them to rain. Keep work area well lighted.

Provide adequate surrounding work space.

7. KEEP CHILDREN AWAY

Al! visitors should be kept a safe distance from work
area

8. MAKE WORKSHOP KID-PROOF

with padlocks, master switches, or by remowng

starter keyf

9. DON'T FORCE TOOL

It will do lhe job better and safer at the rate for which
it was designed

10. USE RIGHT TOOL

Don't forc_ tool or attachment to do a job it was not

designed for.

11. WEAR PROPER APPAREL

Do not wear loose clothing, gloves, neckties or jewelry
(rings, wrmt watches) to get caught in moving parts.

Nonslip footwear is recommended. Wear protective

hair covering to contain long hair. Roll long sleeves
above the _'lbow.

12. USE SAFETY GOGGLES (Head Protection}
Wear Safety goggles (must comply with ANSI Z87.1)

at all times. Everyday eyeglasses only have impact
resistant lenses, they are NOT safety glasses. Also, use
face or dust mask if cutting operation is dusty, and ear

protectors (plugs or muffs) during extended periods of

operation.

13. SECURE WORK

Use clamps or a vise to hold wo_k when practical. It's

safer than usingvour hand, frees both hands to operate
tool

14. DON'T OVERREACH

Keep proper footing and balance at all times.

15. MAINTAIN TOOLS WITH CARE

Keep tools sharp and clean for best and safest
performance. Follow instructions for lubricating and
changing accessorms.

16. DISCONNECT TOOLS

before servicing; when changing accessories such as
blades, bits, cutters, etc.

17. AVOID ACCIDENTAL STARTING

Make sure switch is in "OFF" position before plugging
in.

18. USE RECOMMENDED ACCESSORIES

Consult the owner's maoual for recommended
accessories. Follow the irrstructions that accompany

the accessories. The use of irrrproper accessories may
cause hazards.

19. NEVER STAND ON TOOL

Serious irrjury could occur if the tool is tipped or if the
cutting tool is accidentally contacted.

Do not store materials above or near the tool such that
it _snecessary to stand on the tool to reach them.

20. CHECK DAMAGED PARTS

Before further use of the tool, a guard or other part that
is damaged should be calefully checkecl to ensure that it

wi!l operate properly and perform its intended function
Check for alignment of moving parts, bindirlgof moving
parts, breakage of parts, mounting, and any other
conditions that may ,affect its operation. A guard or
other part that is damaged should be properly repaired

or replaced.

21. DIRECTION OF FEED

Feed work into a blade or cutter against the direction

of rotation of the blade or cutter only.

22. NEVER LEAVE TOOL RUNNING

UNATTENDED

Turn power off. Don't leave loci urrti+ ;t comes to a

complete stop.

additional safety instructions for radial saws

CAUTION: Always disconnect the power cord before Before starting work, verify that no play exists
removing the guard, changing the cutting tool, changing the between the cohJmn & column support, Or m the

set-up or making adjustments. Shut off motor before
performing layout work on the saw table.

WARNING: DO NOT CONNECT POWER CORD UNTIL
THE FOLLOWING STEPS HAVE BEEN
SATISFACTORI LY COMPLETED:

I. Assembly and alignment.
II. Examinatior and operating familiarity with ON-OFF

switch, elevation control, yoke index and lock bevel
index and lock, carriage lock, guard clamp screw,

spreader and ant!kickback device, and miter index and
lock.

Ill, Review and Jnderstanding of al! Safety Instructions and

Operating P_ocedures thru-out manual.

INSTALLATION

1. Set carriage lock before moving the saw.

2. Bolt the saw to the floor if it tends to slip, walk, or
slide during normal operation.

3. Mount the saw so the table is approximately 39" above
the froor.

4. Mount the saw so the arm slopes slightly" downward to

the rear so the carriage will not roll forward due to

gravity.

5. If you attach any kind of table extensions over 24"
wide to either end of the saw, make sure you either bolt

the saw to the bench or floor as appropriate, or support
the outer end of the extension from the bench or floor,
as appropriate.

MINIMIZE ACCIDENT POTENTIAL

Most accidents are caused by FAILURE TQ FOLLOW
setup and operahng instructions:

(A) GENERAL

-- Avoid awkward hand positions, where a sudden slip
could ca use a hand to move into a sawblade or other

cutting tool. Never reach in back of or around the
cutt=ng tool with either hand to hold down the

workpiece, or for any other reason DO NOT place

fingers or hands in the path of the sawblade

-- Never saw, dado, mold, or rabbet unless [he proper

guard (complete with all its parts) is installed and set

Lip as instructed

NOTE THE FOLLOWING DANGER LABELS WHICH
APPEAR ON THE FRONTOFTHEYOKEANDGUARD:

I _ _ _ UNDERS_A_ OWN[B S MAN AL _[ F _[ £ Pt R_{_ _%1 HIN l_JU RY O O
2 WLA_ _A_I_OG_L_S NOT F_D

KF_P _A_DS {11JTOFPAIH Of SAP/ 9L,_D[

6 _V_ K_A_H AROU_O IH{ SAW B[_O[

_ FOR YOUR OWN SAFETY: TO AVO$D

i_p[ ( _OPEaATIO_

t_6S RVICING

Ifany parl of this radial saw _s missu_g or should

break, b(,nd or fail m any way, or any electrical
component fail to perform properly shot off power

switch rib,move cord from power supply and replace

damaged missmg and/or failed parts before

resuminq operation

IF YOUR SAW MAKES AN UNFAMILIAR NOISE OR IF

IT VIBRATES EXCESSIVELY CEASE OPERATING

gVIMEDIATELY UNTIL THE SOURCE HAS BEEN

LOCATED AND THE PROBLEM CORRECTED

WARNING: ALWAYS KEEP ALERT. DO NOT
ALLOW FAMILIARITY (GAINED FROM

FREQUENT USE OF YOUR SAW) TO CAUSE A
CARELESS MISTAKE ALWAYS REMEMBER

THATA CARELESS FRACTION OFASECONDIS

SUFFICIENT TO INFLICT SEVERE INJURY

- I

7 DANGER i

can!age, and that arm, yoke, and bevel locks/clamps

are tight.

A large proportion of saw accidents is caused by use
of the w_ong type blade, dull, badly set, improperly
sharpened cutting tools, by gum or resh] adhering to
cutting tools, and by sawblade misalignment
out-of-parallel with the fence. Such conditions can
cause the material to stick, jam (stall the saw) or

"KICKBACK" at the operator, NEVER ATTEMPT
TO FREE A STALLED SAW BLADE WITHOUT

FIRST TURNING THE SAW "OFF". If the

sawblade [s stalled or jammed, shut saw "OFF".

remove workpiece, and check sawblade squareness to
table surface and to the fence, and check for heel.
Adjust as indicated.

-CAUTION: DO NOT cycle the motor switch "'ON"
and "OFF" rapidly, as this might cause the sawblade

to loosen. In the event this should ever occur, allow
the saw blade to come to a complete stop and
re-tighten the arbor nut normally, not excessively.

- Do not leave a long board unsupported so the spring

of the board causes it to shift on the table. Provide
proper support for the workpiece, based on ts size

and the type of operation to be performed. Hold the
work firmly against the fence.

Never use a length stop on the free end or edge of the
workpiece whether crosscutting or ripping. Neve_

hang onto or touch the free end of workpieee when
crosscutting, or a free piece that is cut off while
power is "ON" and/or the saw blade is rotating, tn
short, the cut-off piece m any "thru-sawing"

operation must never be confined it must be
allowed to move laterally.

- Make sure your fingers do not contact the terminals
when installing or removing the plug to or from a live

power source.
Never climb on the saw, or climb near the saw when

power is "ON". Never leave the saw with power
"ON", or before the cutting tool has come to a
complete stop. Lock the motor switch and put away
the key when leaving the saw.

-Do not use any blade or other cutting tool marked
for an operating speed lower than 3450 RPM. Never
use a cutting tool larger in diameter than the diameter

for which the saw was designed. For greatest safety
and efficiency when ripping, use the maximum
diameter blade for which tbe saw is designed, since

ur_der these conditions the spreader is nearest the
blade.

Never turn your saw "ON" before clearing the table
or work surface of all objects (tools, scraps of wood,
etc.) except the workpiece and reated feed or
support devices for the operation planned.

DO NOT perform layout, assembly, or setup work on
the table while the cutting tool is rotating.

Never perform any operation "FREE HAND". This
term means feeding the sawblade into the workpiece

or feeding the workpiece into the sawblade or other
cutting tool without using the fence or some other

device which prevents rotation or twisting of the
workpiece during the operation. Never "RIP" in the

crosscut position. Never make a miter cut with the

arm in the 90 ° crosscut position.

Never lower a revolving cutting tool into the table or

a workpiece w thout first locking the Carriagu Lock

Knob. Release the knob only after graspng the Yoke
Handle. Otherwise the cutting tool may grab the

workpiece and be propelled toward yo_

additional safety instructions for radial saws

--The sawblade, dado, or other cutting tool must be 12. DO NOT pull theworkpiecethroughthesawblade-
removed from the saw arbor before using the

accessory shaft (rear end of the saw motor). NEVER
operate the saw with cutting tools (including sanding

accessories) installed on both ends of the saw arbor.

-Do not use fences made of chipboard - use 3/4"
virgin lumber only, extending in one piece from end

to end of the saw table.

(B) RIPPING

Ripping is cutting with the grain or the long way of the
board - it is performed by pushing the workpiece

along the fence and thru the sawblade (sawblade

parallel to the fence).

1. Never apply the feed force to the section of the
workpiece that will become the cut-off (free) piece.

Feed force when ripping must always be applied

between the saw blade and the fence . . . use a
"PUSH STICK" (see pg. 26) for narrow or short

work.

2. Whenever possible, use the in-rip position - this
provides minimum obstruction for feeding by hand

or push stick as appropriate.

3. Do not release the workpiece before operation is
complete - -push the workpiece all the way past the

rear (outfeed or exit) of the sawblade.

4. Make sure by trial before starting the cut that the
antikickback pawls will stop a kickback once it has
started. Keep points of pawls SHARP!

5. Use a push stick when ripping short (under 12

inches) or narrow (under 6 inches wide) workpieces.

6. CAUTION: Never reposition the Guard or
antikickback with power "ON".

7. A "KICKBACK" occurs during a rip-type operation
when a part or al! of the workpiece is thrown back

violently toward the operator. It can occur when
the workpiece closes in on the rear (outfeed side) of

the sawblade (pinching), binds between the fence
and the sawblade (heel), or is grabbed by the

sawbtade teeth (wrong-way feed) at the outfeed
side. "PINCHING" is generally avoided by

utilization of the spreader, and a sharp sawblade of
the correct type for the workpiece being cut.

"HEEL" can be avoided by maintaining the
sawblade exactly parallel to the fence. Grabbing by

the sawblade teeth can be caused by heel or by

feeding from the wrong direction (see "DANGER"

warning on guard) -- it can be avoided by
maintaining parallelism of sawblade to fence,
feeding into the sawblade from the nose of the

guard only, by positioning the spreader and
antikickback properly, and keeping the workpiece

down on the table and against the fence.

8. Position the nose of the guard to just clear the

workp_ece, and position/adjust the antikickback
and spreader devices as instructed.

9. NEVER cut more than one piece at a time by
stacking workpieces vertically.

10. NEVER feed a workpiece thru the saw with another
piece (butting second piece against trailing edge of
piece being cut), even if of the same thickness. Feed
each workpiece individually thru the sawblade, and
completely beyond the sawblade, before ripping the

next workpiece. Use push stick if the rip cut is less

than 6" wide.

11. NEVER use another person as a substitute for a
table extension, or as additional support for a
workpiece that is longer or wider than the basic saw
table, or to assist in feeding or supporting or pulling

the workpiece.

position your body at the nose (in-feed) side of the
guard: start and complete the cut from that same
side This will require added table support for long
or wide workpieces that extend beyond the length

or width of the saw table.

13. Plastic and composition (like hardboard) materials
may be cut on your saw. However, since these are
usually quite hard and slippery, the antikickback

pawls may not stop a kickback.
Therefore, rip with the finished side down (next to

the table) and be especially attentive to following
proper set-up and cutting procedures. Do not stand,
or permit anyone else to stand, in line with a

potential kickback.

14. When sawing 1/4" or thinner materials, follow all

normal ripping procedures except set sawblade into
table top at least 1/8". DO NOT let go of or stop

feeding the workpiece between the blade and fence
until you have pushed it completely past the
antikickback pawls. Otherwise the workpiece could
get into the back of the sawblade and be thrown
violently from the saw in the direction opposite to

the feed direction. This is the same action that
would occur if the instructions of the DANGER

warning on the guard is aborted. Do not stand, or
permit anyone else to stand, in line with the path of

a workpiece that may be thrown from the saw in this
manner.

15. Position the saw so neither you, a helper, or a
casual observer is forced to stand in line with the

sawblade.

16, Use extra care when ripping wood that has a

twisted grain or is twisted or bowed -- it may rock
on the table and/or pinch the sawblade.

17. Shaping of wood with a dado head or a molding

head can be performed "top-side" (cutting tool
basically vertical and employing sawblade guard),
or "edge" (saw arbor vertical -- cutting tool

horizontal -- and employing the Accessory molding

head guard).
Ploughing

(Grooving with the grain),

Top side rabbeting,

Top side molding

(shaping) ......

resawing, gaining, coving, with the grain, are

examples of rip-type cuts. The same basic setup

procedures including rotation of the guard and

adjusting and positioning of the AKB/Spreader
device as for in-rip or out-rip cutting, apply.

However, since none of these operations involve

thru-sawing (sawing through the workpiece), there

is no kerf. Therefore the spreader and AKB pawls
can only be lowered to a position where the

spreader just clears the workpiece.
CAUTION: The AKB/Spreader" device will not

stop a kickback in this position, but will act as a
holddown and as a guard of the out-feed side of

the sawblade.

18.

For rip or rip-type cuts, the following end of a
workprece to which a push stick or push board is
applied must be square (perpindicular to the fence)

in order that feed pressure applied to theworkpiece
by the push stick or block does not cause the

workpiece to come away from the fence, and
possibly cause a kickback.

19.Duringripandriptypecuts,theworkpiecemustbe
helddownonthetableandagainstthefencewitha

push stick, push block, or featherboards. A
featherboard is made of solid lumber per sketch.

24"- - _l

5/'16" APART

(C) CROSSCUTTING

1. ALWAYS RETURN THE CARRIAGE TO THE
FULL REARWARD POSITION AT CONCLUSION
OF EACH CROSSCUT TYPE OPERATION. Never
remove your hand from the Yoke Handle unless the

carriage is in this position. Otherwise the cutting
tool ma_, climb up on the workpiece and be

propelled toward you.

2. Place guard in horizontal position and adjust
antikickback pawls to just clear the top of the fence
or workpiece, whichever is higher. This provides
additional guarding.

3. NEVER gang crosscut - lining up more than one
workpiece in froJ3t of the fence - stacked vertically,

or horizontally outward on the table - and then
pulling saw thru: the blade could pick up one or

more pieces and cause a binding or loss of controt
and possible iniury.

4. Do not position the Arm so the operation you are
performing permits the cutting too! to extend

beyond the edges of the Table.

5. Top-side dadoing or molding across the grain are

examples of crosscut-type cuts. The same basic
procedures including positioning of the
AKB/Spreader device as for crosscutting, apply.

(D) ACCESSORIES

1. Use only recommended accessories as listed qn page

34.

2. Never operate this saw when equipped 9vith a dado
head or molding head unless the mc)lding head

guard is installed see listing of recommended
accessories. The only exception is when "'tOP side"

dadoing or molding, when the sawblade guaid must
be used. See detaited instructions that.accompaey_ z

the dado head, molding head, and molding head
guard.

3. The use of grinding wheels, abrasive or cut-off

wheels, or wire wheels, can be dangerous and is not

recommended. (Abrasive or cut off wheels are used

to saw many different materials including metals,
stone, and gla_s.)

4. Drill Chuck: Do not install or use any twist drill
larger than 1/2-inch in dia., or longer than 7 inches
in length or ex.tending more than 6 inches beyond

the chuck jaws. Do not install or use any reduced
shank drill except of the spade type (1 inch dia. or
smaller). "Use for drilling WOOD and PLASTIC

only."
NOTE: Do not overtighten arbor nut. Use arbor wrenches
to just "snug" it.

WEAR YOUR

The operation of any power tool can result in foreign
objects being thrown into the eyes, which can result in

severe eye damage. Always wear safety goggles complying
with ANSI Z87.1 (shown on Package) before commencing
power tool operation. Safety Goggles are available at Sears

retail or catalog stores.

electrical connections

POWER SUPPLY

1. Motor Specifications
The A-C motor used in this saw is a capacitor start,

non-reversible type having the following specifications:

Voltage ............................. 120/240

Amperes .............................. 11/5.5

Hertz (cycles) ............................. 60

Phase ................................ Single

RPM ................................. 3450

Rotation as viewed from saw blade end .... Clockwise

CAUTION: Your saw is wired for 120V operation.
Connect to a 120V, 15-Amp. branch circuit and use a

15-Amp. time-delay fuse or circuit breaker. If the
motor is used for 240V operation, connect to a
15-Amp. branch circuit and use a 15-Amp. dual element

time-delay fuse or circuit breaker.
This machine must be grounded while in use to protect

the operator from electric shock.

IF YOU ARE NOT SURE THAT YOUR OUTLET IS
PROPERLY GROUNDED, HAVE IT CHECKED BY A

QUALI FlED ELECTRICIAN.

WARNING: DO NOT PERMIT FINGERS TO TOUCH

THE TERMINALS OF PLUGS WHEN INSTALLING

OR REMOVING THE PLUG TO OR FROM THE

OUTLET,
WARNING: IF NOT PROPERLY GROUNDED THIS

POWER TOOL CAN INCUR THE POTENTIAL

HAZARD OF ELECTRICAL SHOCK.
PARTICULARLY WHEN USED IN DAMP

LOCATIONS IN PROXIMITY TO PLUMBING. IF AN
ELECTRICAL SHOCK OCCURS THERE IS THE
POTENTIAL OF A SECONDARY HAZARD SUCH AS

YOUR HANDS CONTACTING THE SAWBLADE.
IF POWER CORD IS WORN OR CUT, OR DAMAGED

IN ANY WAY, HAVE IT REPLACED

IMMEDIATELY.

If your unit is for use on less than 150 volts it has a

plug that looks like below.

3 P_Oh_[_ piLJ(;

GROUNDING _ONG

P_OPE£L Y GROUt_D_D
3- PR©r_G CUlL ET

This power tool is equipped with a 3-conductor cord
and grounding type plug which has a grounding prong,

Listed by Underwriters' Laboratories. The ground
conductor has a green jacket and is attached to the tool
housing at one end and to the ground prong in the

attachment plug at the other end.

This plug requires a mating 3-conductor grounded type
outlet as shown.

If the outlet you are planning to use for this power tool

is of the two prong type DO NOT REMOVE OR

electrical connections

ALTER -FHE GROUNDING PRONG IN ANY
MANNER. Use an adapter as shown and always connect

the grounding lug to known ground.

It it recommended that you have a qualified electrician
replace the TWO prong outlet with a properly grounded
THREE prong outlet.

An adapter as shown below is available for connecting
plugs to 2 prong receptacles. The green grounding lug

extending from the adapter must be connected to a

permanent ground such as to a properly grounded

outlet box. ":_ROU_DI_G LtJ(_

I

A_APTE_ / r==_

\ t I: ll R,

3-PROb,h \1;_ 7 _ I ._ " I CON_ECT D TO A

PLLJG \ t'_'i/_'_+ _ II Yb40,'¢N GPOtlN)

/X'73:7":'-!I_'*: --"_'_ _ERON--

NOTE: The adapter illustrated is for use only if you
already have a properly grounded 2-prong receptacle.

ELECTRICAL CONNECTIONS

WARNING: CHANGES IN ELECTRICAL
CONNECTIONS SHOULD BE MADE BY A
QUALIFIED ELECTRICIAN.

1, Changing Motor Connections

a. Under normal home workshop usage, and if proper

{full) voltage is supplied to the motor, your saw will
operate efficiently on 120V, as connected at the
factory However, ifanyofthe following conditions
exists, pt will be advisable for you to reconnect the

motor for 240V operation - to obtain the
efficiency and performance for which your saw is
designed:

(1) Heavy-duty operations.

(2) Either an undersized or an overloaded branch

circuit serving the saw motor.

(3) Low voltage supplied by the power source,

which the power company cannot correct.

b. Motor 'wiring connections for 120V (as made at the

factory) are described below. Necessary

reconnections for 240V operation are also described

following. Whenever changing connections from

120V to 240V or vice-versa, make certain that all

necessary steps (including proper fusing of the

branch circuit) are completed.

,f i _".... x

/ ,i ,

/ , L _'\

/ \J

/ i __ _

(1) The orange-colored wire on number 6 terminal.
(2) The brown-colored w_re on number 5 terminal.

c Use the 120V power-cord plug furnished with your

saw.

/ : \

/' ["

Connections for 2407 A.C.
a. The wires inside the motor terminal box must be

connected as follows:

(1) The orange colored wire on number 8 terminal.
(2) The brown-colored wire on number 7 terminal,

b. Replace the 120V power-cord plug with a (3-blade)

240V plug, connecting the power-cord white and
black leads, respectively, to the two "hot" plug
blades -- and connecting the power-cord grounding
wire to the plug ground prong,

O_OUtqDING BLADE tq, I

LONGEST OF 3 BLADE5

240V PLUG & RECEPTACLE

GROdNDED

OUTLET BOX

NO ADAPTER IS

AVAILABLE _OR

fmlb TYPE PLUG

C.

Plug your saw into a 240V, 3-blade receptacle.

d.

Make certain the receptacle is connected to a 240V
A-C power supply through a 240V branch circuit
having at least a 15-amp. capacity, and protected by
a 15-amp. time-delay fuse or circuit breaker.

MOTOR SAFETY PROTECTION

NOTE: This motor should be blown out, or "'vacuumed",
frequently to prevent sawdust interference with normal

motor ventilation.

Your saw motor is equipped with a manual reset,
thermal-overload protector designed to open the power-line
circuit when the motor temperature exceeds a safe value.

, _ _ _ i 1

2. Connections for 1207 A.C.
a. Remove nameplate cover from motor to expose

terminal board.

b. The w_res inside of the motor must be connected as

shown

PROTECT_

1. If the pr(>tector opens the line and stops the saw motor,
_mmediately press the saw switch to the "'OFF"

position, and allow the motor to cool.

2 After cooling to a safe operating temperature, the

overload protector can be closed manually by pushing
in the red button on the top of the motor. I1 the red
button will not snap _nto place immediately, the motor

is still to,) hot and must be allowed to cool for a while
longer. In some cases this may take 20-30 minutes. {An

audible cick wil! indicate protector is closed.)

3. As soon as the red button will snap into running
position the saw may be started and operated
normally by pulling out the saw switch to the "ON"
position.

4. Frequent opening of fuses or circuit breakers may result

if motor is overloaded, or if the motor circuit is fused
differently from recommendations• Overloading can
occur if you feed to rapidly or if your saw is misaligned
so that [he blade heels. Do f_ot use a fuse of greater

capacity without consulting a qualified electrician.

5. Although the motor is designed for operation on the
voltage and frequency specified on motor nameplate,

normal loads will be handled safely on voltages not
more than 10_&-above or below the nameplate voltage.
Heavy loads, however, require that voltage at motor

terminals equals the voltage specified on nameplate.

LOCATION AND FUNCTION OF CONTROLS

#41TER SCALE

!I'4DICATO£

6. Most motor troubles may be tracedi to loose or
incorrect connections, overloading, reduced input
voltage (such as small size wires in the supply circuit) or
to an overly lung supply circuit. Always check the

connections, the load and the supply ciri:0itTwheneverl
the motor fails to perform satisfactorily. Check wire

sizes and lengths with the table following.

WIRE SIZES

The use of any extension cord will cause some loss of
power. To keep this to a minimum and to prevent

over heating and motor burn out, use the table below to
determine the minimum wire size (A.W.G.) extension cord.

Use only 3 wire extension cords which have 3 prong

grounding tvpe plugs and 3-pole receptacles which accept
the tools plug.

NOTE: For circuits of greater length, the wire size must be
increased proportionately in order to deliver ample voltage

to the saw motor.

Length of the

Conductor

Up to 100 feet

100 feet to 200 feet

200 feet to 400 feet

Wire Size Required

(American Wire Gauge Number)

240 Volt Lines 120 Volt Lines

No. 14 No. 12
No. 12 No. 8

No. 8 No. 6

PIVOT L ATCII

TABLE CLA_4P

q£M t OCK

]STNG "/HEEL

RIP ]CAt

I NDICArOR

CONTENTS

Guarantee .................................... 2

General Safety Instructions for Power Tools ......... 2

Additional Safety Instructions for Radial Saws ....... 3

Electrical Connections .......................... 5

Assembly and Alignment ........................ 8

Unpacking and Preassembly ..................... 8

Alignment Procudure ..................... ".... 12

Location and FunctioH of Controls ............... 20

Basic Saw Operations .......................... 23

Adjustments to Compensate fol Wear . ............. 28

Trouble Shooting ............................ 31

Maintenance and Lubrication ................ 34

Recommended Accessories ...................... 34

Repair Parts ................................. 35

assembly and alignment

TOOLS NEEDED

@_ ::::: :-_:_ Screwdriver 0xlectiu m)

7/16-inch wrench ,:#"2 Phillips Screwdriver [!i

9i16dnch wrench

15/16 -inch wrench _ _"

1/2-inch wrench d_.:__7__ I!!

E_ : am er :1

I,:_"!: __i-::::,._:. i ::_[!: ,

Framing square

Pliers

UNPACKING AND PREASSEMBLY

WARNING: DO NOT CONNECT THE POWER CORD TO
A SOURCE OF POWER. THIS CORD MUST REMAIN
UNPLUGGED WHENEVER YOU ARE WORKING ON

THE SAW.

Model 113.199200 Radial Saw is shipped complete in one

carton but DOES NOT INCLUDE Steel Legs.

Model 113.199250 Radial Saw is shipped complete in one

carton but INCLUDES Steel Legs.

1. Unpacking and Checking Contents
Separate all "loose" parts from packaging materials and

check each item with "Table of Loose Parts" to make
sure all items are accounted for, before discarding any

packing material.

If any parts are missing, do not attempt to assemble

radial saw, plug in the power cord, or turn the switch

on until the m_ssing parts are obtained and are installed
correctly.

2 3 4 5

Pencil

/

FRAMING SQUARE MUST BE TRUE

C_ ,_IING A_CU ACY Ci % _[' K[NC_ ACC[ R2,CY OF

PqSIDE OF _JAR5 DLISIDF Ct OUA_£

_A EDCE OF FRC:_JT I,_3L[

BOARDS , [t_*OV_ D)

DRA¢¢ LiC;H; LiNE Ohd \
TABLE ALONG THiS EDC_

SHOLII D _E NO GAP OR
OVERLAP HER[ _HEb,
SQb_RE IS FLIPPED OVE_
IN DOTTED POSITION

Key No. Table of Loose Parts

1

Basic Saw assembly .................... 1

2

Rear table ........................... 1

3

Table spacer .......................... 1

4

Rip fence .......................... 1

5

Front table ........................... 1

6

Channel, Table Mtg ..................... 2

7

"0woer's Manual" . .................... 1

k

--_- [ABLE ALONG THIS EDGE

SHOULD BE _40 GAP OR

O VE't LAP HER ¢,_H [ N

5_JAP, E 15 FLIPPE_ OVER
[N LIo[rED PO I OM

Loose Parts Bag Part Ne. _3895

(containing the following items):

Rip-Scale Indicator ................... 2

Twin Nut (for attaching rip scale indicator) . 2

Machine Screw, Pan Hd., 6-32 x 1/2". ..... 4

Hex "L"Wrench, 1/4 .................. 1

Hex '"L" Wrench, 3/16 ................ 1

Elevation Crank Assembly ............. !

Arbor Wrench ....................... 1

Shaft Wrench ........................ 1

Loose Parts Bag Part No. 63894

(containing the following; items):

Setscrew, cup pt. 1/4-20 × 3/8 ........... 1

Machine Screw, Pan Hd., 1/4-20 x 1" . .... 4

Washer, Steel (Flat), 1;'/64 x 5/8 x 1/32" .. 5

Nut, "Tee" . ......................... I

Screw, Pan Hd. 1/4-20 x 1-3/4" . ......... 1

Nut, Hex 1/4-20 ...................... 4

Lockwasher, 1/4 ..................... 4

Table Clamp ......................... 2

*Loose Parts Bag Part No. 63796

(containing the following items):

Hex "L" Wrench, 1/8" . ................ 1

Switch Key ......................... 1

Lockwasher, 5/16" . .................. 4

Washer, Flat11/32 x 7/8 x li16" . ....... 4

Set Screw, Cup Pt. 1/4-20 x 1"' . ......... 1

Nut, Lock 5/16 18 .................... 2

Bolt, Sq. Hd. 5/16-18x3/4" . ........... 4

Washer, 21/64 x 9/16 x 1/16" . .......... 2

Nat, He;<5/16-18 ..................... 4

Loose Parts Bag Part [1o. 63898

Cap, Arm ........................... 1

Trim, Arm Cap ....................... 1

Screw, Fiat Hd. Rec. Tvpe "T" 10 32 x 5/8 3
Screw, Pan Hd Rec. Type "T" 6-32 x 1/4 .. 2

/ _)?,A,'¢ IGHT LINE ION

J

Qty.

8 *This bag included in Loose Parts Bag No. 63895

ThefollowingpartsareincludedwithModel113.199250.

Key
No. Table of t.oose Parts Qty.

1 Leg ..................................... 4

2 Stiffener, L.H ............................. 4

3 Stiffener, R.H ............................. 4

Loose Parts Bag Part No. 63752

(containing the following items):

4 - Screw, Truss Hd. 1/4-20 x 5/8 .............. 40

5 - Lockwasher, 1/4 External ................. 40

5 - Loekwasher, 5/16 External ................ 4

6 - Nut, Hex 1/4-20 ......................... 40

6 - Nut, Hex Jam 5/t6-18 .................... 4

6 - Nut, Hex 1/2-13 ......................... 8

7 - Foot, Leveling .......................... 4

8 - Screw, Hex Hd. 5/16-18 x 5/8 .............. 4

9 - Washer, 11/32 x 11/16 × 1/16 .............. 8

/

/

/

2

J

4 5 6

8

3

.j '_%.

_-j-o

9

ASSEMBLING STEEL LEGS

NOTE: Steel Legs are furnished with Model 113.199250.
From among the loose parts, find the following Hardware:

40 Truss Head Screws, 1/4 20 x 5/'8
40 Lockwashers, 1/4-External
40 Hex Nuts, 1/4-20

8 Hex Nuts. 1/2-13
4 Leveling Feet

Assemble the Legs as shown.

1. Assemble Two (2) each of right and left hand Stiffeners
to the length shown using I/4-20 x 5/8" truss head

screws, Iockwashers and hex nuts.

2. Attach the four (4) legs to the Stiffeners using 1/4 20
screws, Iockwashers and nuts.

3. Install leveling feet as shown. To level steel legs, loosen

nut on inside of leg and turn nut on outside to raise or
Iowe_ feet. Adjust all four levelers if necessary, and then

tighten nuts on inside of leg.

NOTE: These levelers are

adjustment.

CAUTION: Leveling feet must be adjusted so the saw does

not rock AND so that the arm slopes slightly downward to
the rear so the carriage wilt not roll forward due to gravity.

not intended for height

17-3/4"

o o o

O O

STIFFENER

L.H.

Iooolo

O o O

STIFFENER

L.H.

3 2

0 O O 0

0 0 0 0

21-1/4"

/7

STIFFENER

R.H.

O O O O

O O O O

STIFFENER

R.H,

1

2

°n

°l

3

/

3

I./ 2

/

1

assembly and alignment

REMOVE SKIDS FROM BASE

MOUNTING SAW

1. From amonq the loose parts, find the following
hardware:

4 Hex Head Screws, 5/16-18 x 5/8
4 Lockwasher, 5/16 in. External Type

8 Washers, 1!/32 ID

4 Hex Jam Nuts, 5/16-18

2. Place saw orl legs so that holes in bottom of saw line up
with holes marked X in top of legs.

3. Install screws, washers and nuts as shown.

If you mount th,_ saw on any other Craftsman base or flat
bench, make sure Elevation Crank has proper clearance to
rotate. The saw must be boli:ed down. Position saw to slope

slightly rearward, so when the carriage is installed it will not

roll forward due to gravity,

LEG

o_o 0 0

x

R.H. S[IF ENER

l

L.F]. ' TI_-F [ hJ B! f(

,k 0 ooo

x

HE,: FdLT

ATTACH ELEVATION CRANK.
Install setscrew h_to crank. Install crank on elevation shaft.

Be sure setscrew is tightened on flat of shaft.

000

x

o oI

i

O ooo

x
,IL

"v

ELEVATE ARM TO ITS MAXIMUM HEIGHT.

Remove shipping block and discard.

ELEVATIOIN CRANK

TL!RN CLOCKWISE)

lo

BE positivu switch is "OFF" and power cord unplugged
thfu out entre p_ocedure.

REMOVE CARRIAGE STOP SCREW, LOCKWASHER
AND TAG. Read and understand warning tag before

discarding.

..............

LOCK ARM BEFORE PROCEEDING.

HOLDING CARRIAGE ASSEMBLY WITH BOTH
HANDS, CAREFULLY START AND SLIDE THE

CARRIAGE ONTO THE TRACKS. The assembly must be
held parallel with_the arm so that all four bearings slide
smoothly onto the arm, preventing any excessive strain on

bearings and track.
WARNING: REINSTALL CARRIAGE STOP SCREW TO

PREVENT CARRIAGE FROM ROLLING OFF ARM.

Check for looseness of carriage bearings. Refer to
"Adjusting Carriage Bearings" in "Adjustments to

Compensate for Wear" Section.

INSTALL ARM CAP AND ARM CAP TRIM

WARNING: Make certain power cord is unplugged.

1. Insert finger under end of switch lever and pull end out
to the "ON" position.

2. Place arm cap in position and install screws.

3. Attach arm cap trim using screws.

4. Push switch to "OFF" position.

REMOVE SHIPPING SCREWS FROM BOTTOM SIDE

OF MOTOR AND DISCARD.

Use of pliers may be necessary.

_ _"-- 'L' Wq.ENC_

-_._ _ \ SCREW

VIEW OF UNDERSIDE OF MOTOR SCREW

SHOWING LOCATION OF TWO

HEX

SUPPLIED

ARM CAP

SHIPPING SCREWS

V

REMOVE SAW BLADE.

1. Tighten carriage lock knob.

2. Loosen guard clamp screw, remove guard.

3. Motor shaft has left hand threads. Hold shaft wrench
and rotate arbor wrench down (clockwise).

4. Remove shaft nut, outer collar, saw blade, and inner

collar. Set aside and out of the way.

PULL DOWN

TO LOOSEN

BLADE

ROTATION

11

assembly and alignment

ALIGNMENT PROCEDURE

IMPORTANT:

IN ORDER TO OBTAIN MAXIMUM CUTTING

ACCURACY, THE FOLLOWING SIX STEPS

MUST BE CAREFULLY FOLLOWED.

BECOME THOROUGHLY FAMILIAR WITH

THESE STEPS SO THAT YOU CAN AL WA YS

MAINTAIN YOUR SAW IN PROPER
ALIGNMENT. THE ACCURACY OF EACH

ADJUSTMENT IS ALWAYS DEPENDENT

UPON THE ACCURAC Y OF THE PRECEDING

ADJUSTMENT.

After follovving the 6 step assembly and a/ignmer_t
procedure and the Basic Saw operation section refer to
Trouble Shooting section if any difficulty _s experienced
when performing any sawing operation.

STEP ONE

NOTE: The following adjustment, performed properly, will
result in the work table being parallel to the arm.

ATTACHING AND [.EVELING TABLE MOUNTING

SUPPORT CHANNELS.

1. Attach table mounting support channels with four
square head 5/16 18 x 3/4 screws, Iockwashers and flat

washers and luts. POStTION SCREWS IN CENTER OF
CHANNEL SLOTS, finger tight to permit channels to
"sip" against the base when leveling.

[ABLE _4OUNTI NG

SUPPORT CHANNEL

\

LOCKWABHER /

FLAT WASHER

FRO _'_T

MOUi_I" RAILS USING

THESE HOLES

U,_LOCK

2. Release bevel lock lever, move bevel index lever to the
left and rotate the motor to positido saw blade end of

shaft down. Lock bevel lock.

3. Unlock and hold arm control lever m index release
position as shown. Position arm against left stop

(approximately 50 ° miter). Looser] carriage Jock knob

and position carriage directly over left hand channel.

NOTE: For safety reasons in accordance with the UL

standard, stops have been provided to prevent 360 °

_otation of the radial arm.

4. Slide the arbor wrench handle between end of motor

shaft and mounting channel to act as a feeler gauge.
Carefully lower the motor with elevation crank until

the end of shaft is just touching the arbor wrench. The
wrench should slide back and forth with only slight

resistance. Ti _hten screw "A".
NOTE: Do not change this elevation setting until both

left and right hand table support channels have been
adjusted.

5. Move arm and carriage to screw "B" and tighten
support in the same manner.

6. Move arm and carriage to right hand support channel
and level in the same manner you adjusted the left hand

support channel.

7. Recheck both support channels to make sure that
tightening _,crews did not affect the accuracy of the

adjustment

8. Elevate saw and place motor in vertical posit_on to

provide clearance for installation of front (work) table.

ARBOR WRENCH

SCREW "_, "

12

tABLE MOUNTINC

SUPPORT CliANF4EL

(LEFT HAND)

SCRERV "B

SCREW '_,"

INSTALLATION OF FRONT (WORK) TABLE.

1. Place front table board upside down on a workbench of
on the floor. Drive T-nqt into the bole that is not

counterbored.

2. Align the counterbored holes with matching holes in
support channels. Install the five 17/64 inch flat

washers, and four _/_- 20 x 1 inch Pan-Head machine
screws. JList barely start the cup point set screw and the

one (1) _A 20 x 1-3/4 inch Pan Head machine screw in
table center holes.

3. Install one % Ioekwasher and Hex Nut on each of the
four (4) screws in the support channels and tighten.

FqONT TABLE

/_\\(IN dPSID£ DO,Vi_ POSITION)

HOL_ FOR IA_LE

,iOLD DOWN SCRE?¢S

r-b_UT (IYPIC_L)

T-NUT

BOTTOM SIDE

0 _ 1ABL_

\

4. Lay the rear table board on edge across the front table
to serve as a straightedge. Sight under this straightedge
to determine whether the front table board is high or

low at its center.

5. If the frorrt table is high at center, first tighten the
center (Y_ 20 x 1-3/4 inch) hold down screw until the

table is level then tighten the leveling screw until this
screw issrug.

If table is low at center, first tighter] the leveling screw

until the table is level then tighten the hold down
screw.

If table is not high o_ low, tighten leveling screw arrd

center hold down screw snug.

STEP TWO

ADJUSTING COLUMN TUBE IN COLUMN SUPPORT

NOTE: The following adjustment is very CRITICAL. All
future alignment procedures rely on this adjustment being

performed correctly. ALL LOOSENESS MUST BE

REMOVED.

1. Index and lock arm at 0 ° Miter.
While holding the arm with one hand, hold fingers of

other hand as shown, between column tube and column
support. Apply gentle side pressure to the arm m

opposing directions. Any side to side or rotational

rrrovemen[ (indicated by arrow) can be felt with finger.
If Ioose_ss exists the following adjustments are

r_rquired.

13

assembly and alignment

2. Loosen (2) v4 20 Gib set screws on the left side at the
rear of the column support.

3. Elevate, and then lower the Arm: {a} if the column

binds and elevation -is difficult loosen two 5/16 18

plated bolts on front side of the column support until
you achieve smooth but firm elevation. (b) If the
column moves side-to-side within the column support,

tighten the two 5/16 - 18 plated bolts until movement
disappears elevation should be smooth and firm.

4. Now tighten the 12} 'A 20 Gib set sclews until no
noticeable rotational play exists between Column Tube
and Column Support.

5. Recheck elevation and re adjust if necessary.

B IGHTPLATE0 /

i

J

I

I

STEP THREE

SQUARING CROSS CUT TRAVEL (CARRIAGE
TRAVELS IN A STRAIGHT LINE).

1 Index but do not lock arm at 0 ° miter.

2. Install saw blade as shown. Motor shaft has left hand
threads.

NOTE: Do not overtighten arbor nut. Use the arbor wrench
to just "snug" it.

I

BLADE

ROTATION

A_BORN JT-_ _NN_RCOtLAR

14
