IMI CORNELIUS INC.
www.cornelius.com
Nordic
Model CCU0150, 0220
Service Parts Manual
(Includes 50Hz. Units)
Publication Number: 631806055
Revision Date: September 1, 2007
Revision: C
Visit the IMI Cornelius web site at www.cornelius.com
CCU0150, 0220, 02202, 02205 Service Parts Manual Manual Number 631806055
for all your Literature needs.
Page 2
*
Page 3
CCU Undercounter Service Parts
This parts list contains the service parts available for the CCU Undercounter icemakers.
Check the model number on the data plate and refer to the correct listing for the specific component.
Check carefully that the correct part is identified and ordered.
Table of Contents Page 1
Bin and Exterior Components Page 2 - 3
Refrigeration System Page 4 - 5
Harvest Assist Assembly Page 6
Control Box Page 7
Evaporator Page 8
Water Pump Page 9
Wiring Diagram Page 10
E-Mail: tech.service@Cornelius.com
Website : www.cornelius.com
Telephone Number
800-238-3600 All Departments
The CCU Series Service Manual is available seperately, Part Number 631806061
Note: Model Number Suffix Indicates Machine Voltage As Follows:
1=115/60/1
2=208-230/60/1
3=208-230/60/3
5=230/50/1
