CDM-700
High Speed Satellite Modem
Installation and Operation Manual
IMPORTANT NOTE: The information contained in this document supersedes all previously published information regarding this product. Product specifications are subject to change without prior notice.
CDM-700
High-Speed Satellite Modem
Installation and Operation Manual
Part Number MN/CDM700.IOM
Revision 5
December 12, 2008
Copyright © 2008 Comtech EF Data. All rights reserved. Printed in the USA.
Comtech EF Data, 2114 West 7th Street, Tempe, Arizona 85281 USA, 480.333.2200, FAX: 480.333.2161

Table of Contents

PREFACE .................................................................................................................................. XV
Customer Support ..................................................................................................................................... xv
About this Manual ................................................................................................................................... xvi
Reporting Comments or Suggestions Concerning this Manual ............................................................. xvi
Conventions and References ................................................................................................................... xvi
Metric Conversion ................................................................................................................................. xvi
Cautions and Warnings .......................................................................................................................... xvi
Recommended Standard Designations ................................................................................................... xvi
Electrical Safety ...................................................................................................................................... xvii
Fuses ..................................................................................................................................................... xvii
Environmental ....................................................................................................................................... xvii
Installation............................................................................................................................................. xvii
Telecommunications Terminal Equipment Directive ......................................................................... xviii
CE Mark ................................................................................................................................................. xviii
RoHS Compliancy .................................................................................................................................. xviii
EMC (Electromagnetic Compatibility) ................................................................................................ xviii
Warranty Policy ........................................................................................................................................ xx
Limitations of Warranty .......................................................................................................................... xx
Exclusive Remedies ............................................................................................................................... xxi
CHAPTER 1.INTRODUCTION ............................................................................................. 1–1
1.1 Overview ...................................................................................................................................... 1–1
1.2 Standard Features ....................................................................................................................... 1–2
1.2.1 Software – Flash Upgrading ................................................................................................. 1–2
1.2.2 Turbo Product Coding (TPC) ................................................................................................ 1–3
1.3 Major Assemblies ........................................................................................................................ 1–3
1.4 Allowable Data Interface Combinations ................................................................................... 1–3
1.5 FAST and Hardware Options .................................................................................................... 1–5
iii
CDM-700 High-Speed Satellite Modem Revision 5 Table of Contents MN/CDM700.IOM
1.6 New in This Release .................................................................................................................... 1–6
CHAPTER 2.INSTALLATION .............................................................................................. 2–1
2.1 Unpacking and Inspection .......................................................................................................... 2–1
2.2 Mounting ...................................................................................................................................... 2–2
2.2.1 Method A: Optional Rear-Mounting Support Brackets ........................................................ 2–2
2.2.2 Method B: Optional Installation of Side-Railings ................................................................ 2–4
CHAPTER 3.FUNCTIONAL DESCRIPTION ........................................................................ 3–1
3.1 Description ................................................................................................................................... 3–1
3.2 Interfaces Modules ...................................................................................................................... 3–3
3.2.1 Data Interfaces And Data Transfer Across The Link ............................................................ 3–4
3.2.2 Simplex and Asymmetric Operation ..................................................................................... 3–4
3.3 Allowable Data Interfaces In Slot 1 and Slot 2 ......................................................................... 3–5
CHAPTER 4.PHYSICAL DESCRIPTION ............................................................................. 4–1
4.1 Introduction ................................................................................................................................. 4–1
4.2 Front Panel .................................................................................................................................. 4–2
4.3 Rear Panel .................................................................................................................................... 4–3
4.3.1 External Cables ..................................................................................................................... 4–3
4.3.2 IEC Line Input Connector ..................................................................................................... 4–3
4.3.3 Rx and Tx IF Connectors (J1 and J3) ................................................................................... 4–4
4.3.4 10/100 Ethernet Remote Port Connector (J4) ....................................................................... 4–4
4.3.5 SerDes (Private Communications Link) (J6) ........................................................................ 4–4
4.3.6 External Reference Connector (J7) ....................................................................................... 4–4
4.3.7 Alarm Form C Connector (P1) .............................................................................................. 4–4
4.3.8 Remote Control Connector (RS-232/RS-485), P2 ................................................................ 4–4
4.3.9 Data Interface Connector ...................................................................................................... 4–4
4.4 Dimensional Envelope ................................................................................................................ 4–5
CHAPTER 5.CONNECTOR PINOUTS ................................................................................. 5–1
5.1 External Connections .................................................................................................................. 5–1
5.1.1 Tx / Rx Connector Pinout – J1 / J3 ....................................................................................... 5–3
5.1.2 10/100 Ethernet Management Port Connector Pinout – J4 ................................................... 5–3
5.1.3 SerDes Port Connector – J6 (Earlier Chassis Only) .............................................................. 5–3
5.1.4 ASYNC Connector Pinout – J6 (Rev. A and Later Chassis) ................................................ 5–4
5.1.5 External Reference Input (Main Chassis) – J7 ...................................................................... 5–4
5.1.6 Alarm Connector Pinout – P1 ............................................................................................... 5–5
iv
CDM-700 High-Speed Satellite Modem Revision 5 Table of Contents MN/CDM700.IOM
5.1.7 RS-232/485 Remote Port Connector Pinout – P2 ................................................................. 5–7
5.2 Data Interfaces ............................................................................................................................ 5–7
CHAPTER 6.FRONT PANEL OPERATION ......................................................................... 6–1
6.1 Introduction ................................................................................................................................. 6–1
6.1.1 Front Panel LED Indicators .................................................................................................. 6–2
6.1.2 Front Panel Keypad ............................................................................................................... 6–3
6.1.3 Front Panel Vacuum Flourescent Display (VFD) ................................................................. 6–4
6.1.4 Menu Matrix ......................................................................................................................... 6–5
6.2 Opening Screen ........................................................................................................................... 6–6
6.3 SELECT: (Main) Menu .............................................................................................................. 6–6
6.3.1 (SELECT:) CONFIG ............................................................................................................ 6–7
6.3.1.1(CONFIG:) Remote ........................................................................................................... 6–8
Remote Control: Æ Local ............................................................................................................. 6–8
Remote Control: Æ Serial ............................................................................................................. 6–8
Remote Control: Æ Ethernet ........................................................................................................ 6–9
6.3.1.2(CONFIG:) Tx ................................................................................................................ 6–12
Tx: Æ Mod.................................................................................................................................. 6–12
Tx: Æ Code ................................................................................................................................. 6–13
Tx: Æ Freq .................................................................................................................................. 6–14
Tx: Æ Data.................................................................................................................................. 6–14
Tx: Æ Sym .................................................................................................................................. 6–15
Tx: Æ
Pwr ................................................................................................................................... 6–15
Tx: Æ Scram ............................................................................................................................... 6–16
6.3.1.3(CONFIG:) Rx ................................................................................................................ 6–17
Rx: Æ Dem (Demod) .................................................................................................................. 6–17
Rx: Æ Code ................................................................................................................................ 6–19
Rx: Æ Freq.................................................................................................................................. 6–19
Rx: Æ Data ................................................................................................................................. 6–19
Rx: Æ Sym.................................................................................................................................. 6–20
Rx: Æ Descrm ............................................................................................................................ 6–20
Rx: Æ Eb/No .............................................................................................................................. 6–20
6.3.1.4(CONFIG): Intfc1 ........................................................................................................... 6–22
Intfc1 (CDI-10 Dual G.703 Interface) ........................................................................................ 6–23
Intfc1: Æ Alarm .......................................................................................................................... 6–23
Intfc1: Æ Port1 ........................................................................................................................... 6–23
Intfc1: Æ Port2 ........................................................................................................................... 6–30
Intfc1: Æ Ext-Clk ....................................................................................................................... 6–30
6.3.1.4.1(CONFIG:) Intfc2 (CDI-10 Dual G.703 Interface) ................................................... 6–30
6.3.1.5(CONFIG:) Intfc1 (CDI-50 OC-3 Interface) ................................................................... 6–31
Intfc1 OC-3: Æ Tx ...................................................................................................................... 6–31
Intfc1 OC-3: Æ Rx ..................................................................................................................... 6–32
6.3.1.6(CONFIG:) Intfc1 (CDI-60 HSSI Interface) ................................................................... 6–34
Intfc1 HSSI: Æ Tx ...................................................................................................................... 6–34
Intfc1 HSSI: Æ Rx ...................................................................................................................... 6–35
v
CDM-700 High-Speed Satellite Modem Revision 5 Table of Contents MN/CDM700.IOM
Intfc1 HSSI: Æ CTS/RTS ........................................................................................................... 6–37
Intfc1 HSSI: Æ Alarm ................................................................................................................ 6–38
6.3.1.6.1(CONFIG:) Intfc2 (CDI-60 HSSI Interface) ............................................................. 6–38
6.3.1.7(CONFIG:) Intfc1 (CDI-70 Gigabit Ethernet Interface) ................................................. 6–38
Intfc1 Gigabit Ethernet: Æ Tx .................................................................................................... 6–39
Intfc1 Gigabit Ethernet: Æ Rx .................................................................................................... 6–40
Intfc1 Gigabit Ethernet: Æ Man ................................................................................................. 6–41
Intfc1 Gigabit Ethernet: Æ Stats ................................................................................................. 6–41
Intfc1 Gigabit Ethernet: Æ SWOP (Switch Operation) .............................................................. 6–44
Intfc1 Gigabit Ethernet: Æ Negotiation ...................................................................................... 6–49
Manual Negotiation .................................................................................................................... 6–49
Master/Slave Options .................................................................................................................. 6–49
Speed Options ............................................................................................................................. 6–50
Duplex Options ........................................................................................................................... 6–50
Automatic Negotiation ................................................................................................................ 6–50
View Negotiation ........................................................................................................................ 6–51
6.3.1.7.1(CONFIG:) Intfc2 (CDI-70 Gigabit Ethernet Interface) ........................................... 6–51
6.3.1.8(CONFIG:) Ref ............................................................................................................... 6–51
6.3.1.9(CONFIG:) Aux .............................................................................................................. 6–51
6.3.2 (SELECT:) Monitor ............................................................................................................ 6–52
Monitor: Æ Alarms ..................................................................................................................... 6–52
Monitor: Æ Rx-Params ............................................................................................................... 6–56
Monitor: Æ Event-Log ............................................................................................................... 6–57
6.3.3 (SELECT:) Test ................................................................................................................ .. 6–58
6.3.4 (SELECT:) Info .................................................................................................................. 6–61
INFO: Æ Rem ............................................................................................................................. 6–61
INFO: Æ Tx ................................................................................................................................ 6–61
INFO: Æ Rx................................................................................................................................ 6–62
INFO: Æ 1:1 ............................................................................................................................... 6–62
INFO: Æ Intfc1 / Intfc2 .............................................................................................................. 6–63
6.3.5 (SELECT:) Save/Load ........................................................................................................ 6–64
Save/Load Configuration: ÆSave .............................................................................................. 6–64
Save/Load Configuration: ÆLoad .............................................................................................. 6–65
6.3.6 (SELECT:) Util ................................................................................................................... 6–66
UTIL: Æ Rt-Clk .......................................................................................................................... 6–66
UTIL: Æ Ref ............................................................................................................................... 6–66
UTIL: Æ ID ................................................................................................................................ 6–66
UTIL: Æ Display ........................................................................................................................ 6–67
UTIL: Æ Firmware ..................................................................................................................... 6–67
UTIL: Æ FAST ........................................................................................................................... 6–69
CHAPTER 7.FORWARD ERROR CORRECTION OPTIONS ............................................. 7–1
7.1 Introduction ................................................................................................................................. 7–1
7.2 Turbo Product Codec ................................................................................................................. 7–1
7.2.1 Range of Data Rates .............................................................................................................. 7–2
7.2.2 Eb/No, Spectral Efficiency and Occupied Bandwidth .......................................................... 7–2
vi
CDM-700 High-Speed Satellite Modem Revision 5 Table of Contents MN/CDM700.IOM
7.3 End-to-End Processing Delay (Latency) ................................................................................... 7–3
CHAPTER 8.CLOCK MODES ............................................................................................. 8–1
8.1 Introduction ................................................................................................................................. 8–1
8.2 CDI-10 Dual G.703 Interface ..................................................................................................... 8–3
8.2.1 CDI-10 Dual G.703 Interface Transmit Clocking ................................................................. 8–3
8.2.2 CDI-10 Dual G.703 Interface Receive Clocking .................................................................. 8–3
8.3 CDI-50 OC-3 / STM-1 (Optical / Coaxial) 155.52 Mbps Interface ......................................... 8–4
8.3.1 CDI-50 OC-3 / STM-1 Interface Transmit Clocking ............................................................ 8–4
8.3.2 CDI-50 OC-3 / STM-1 Interface Receive Clocking ............................................................. 8–4
8.4 CDI-60 HSSI Interface ............................................................................................................... 8–5
8.4.1 CDI-60 HSSI Interface Transmit Clocking ........................................................................... 8–5
8.4.2 CDI-60 HSSI Interface Receive Clocking ............................................................................ 8–5
8.5 CDI-70 10/100/1000 Gigabit Ethernet Interface ...................................................................... 8–6
CHAPTER 9.FLASH UPGRADING ...................................................................................... 9–1
9.1 Introduction ................................................................................................................................. 9–1
9.2 Base Modem FTP upload procedure: ....................................................................................... 9–2
CHAPTER 10.SUMMARY OF SPECIFICATIONS ............................................................. 10–1
10.1Summary of Specifications ....................................................................................................... 10–1
10.2Data Rate Range ....................................................................................................................... 10–3
10.370/ 140 MHz Modulator ........................................................................................................... 10–4
10.4L-Band Modulator .................................................................................................................... 10–4
10.570 / 140 MHz Demodulator ...................................................................................................... 10–5
10.6
L-Band Demodulator ................................................................................................................ 10–5
10.7BER Performance ..................................................................................................................... 10–7
10.7.1 Adjacent Channel ................................................................................................................ 10–7
10.8Data Interface (Optional) ......................................................................................................... 10–8
10.9Environmental and Physical .................................................................................................... 10–8
CHAPTER 11.REMOTE CONTROL ................................................................................... 11–1
vii
CDM-700 High-Speed Satellite Modem Revision 5 Table of Contents MN/CDM700.IOM
11.1Introduction ............................................................................................................................... 11–1
11.2RS-485 ........................................................................................................................................ 11–1
11.3RS-232 ........................................................................................................................................ 11–2
11.4Basic Protocol ............................................................................................................................ 11–2
11.5Packet Structure ........................................................................................................................ 11–3
11.5.1 Start Of Packet .................................................................................................................... 11–3
11.5.2 Address ............................................................................................................................... 11–3
11.5.3 Instruction Code .................................................................................................................. 11–4
11.5.4 Instruction Code Qualifier .................................................................................................. 11–4
11.5.5 Message Arguments ............................................................................................................ 11–5
11.5.6 End Of Packet ..................................................................................................................... 11–5
11.6Remote Commands and Queries ............................................................................................. 11–6
CHAPTER 12. SNMP INTERFACE ..................................................................................... 12–1
12.1SNMP Interface ......................................................................................................................... 12–1
12.2CDM-700 Management Information Base (MIB) Files ......................................................... 12–2
12.3SNMP Community Strings ....................................................................................................... 12–3
12.4CDM-700 Common Private MIB ............................................................................................. 12–3
12.5System Information Group ...................................................................................................... 12–3
12.5.1 Remote Ethernet Group ...................................................................................................... 12–3
12.5.2 Ethernet SNMP Group ........................................................................................................ 12–3
12.5.3 Interface FAST OPTIONS Group ....................................................................................... 12–3
12.5.4 Modem Reference Group .................................................................................................... 12–4
12.5.5 Monitor Group .................................................................................................................... 12–4
12.5.6 Test Group .......................................................................................................................... 12–4
12.5.7 Save/Load Group ................................................................................................................ 12–4
12.5.8 Firmware Group .................................................................................................................. 12–4
12.5.9 System Log Group ............................................................................................................. 12–4
12.6Modulator Group ...................................................................................................................... 12–4
12.7Demodulator Modulator Group .............................................................................................. 12–4
12.8Interface Group ......................................................................................................................... 12–4
12.8.1 E3T3STS1 Group ................................................................................................................ 12–5
12.8.2 OC3 Group .......................................................................................................................... 12–5
12.8.3 HSSI Group ......................................................................................................................... 12–5
12.8.4 Gigabit Ethernet Group ....................................................................................................... 12–5
12.9CDM Monitor Objects .............................................................................................................. 12–5
viii
CDM-700 High-Speed Satellite Modem Revision 5 Table of Contents MN/CDM700.IOM
12.10 CDM Redundancy Objects .................................................................................................. 12–5
12.11 SNMP Traps .......................................................................................................................... 12–5
12.12 MIB-II .................................................................................................................................... 12–6
CHAPTER 13.TELNET INTERFACE ................................................................................. 13–1
13.1Telnet Interface ......................................................................................................................... 13–1
13.2Caution Using Windows Telnet Client .................................................................................... 13–3
13.3Using Telnet ............................................................................................................................... 13–4
13.3.1 Telnet Example ................................................................................................................... 13–4
CHAPTER 14. ETHERNET NETWORK CONFIGURATIONS ........................................... 14–1
14.1Introduction ............................................................................................................................... 14–1
14.2Ethernet Routers and Switches ................................................................................................ 14–1
14.3Ethernet Configuration Examples ........................................................................................... 14–2
14.3.1 Ethernet Network Overview ............................................................................................... 14–2
14.3.2 Ethernet Redundancy with CRS-300 .................................................................................. 14–3
14.3.2.1 Wired-thru Connection ............................................................................................... 14–3
14.3.2.2 Wired-around Connection ........................................................................................... 14–3
14.3.3 Hub-to-Hub with Standard Traffic using Switches ............................................................. 14–4
14.3.4 Hub-to-Hub with Standard Traffic using Routers ............................................................... 14–6
14.3.5 Hub-to-Remotes with Standard Traffic using Routers or Switches .................................... 14–8
14.3.6 Hub-to-Remotes, Split-path Traffic using Routers (Point-to-Multipoint) ........................ 14–10
14.3.7 Hub-to-Remotes, Split-path Traffic using Switches (Point-to-Multipoint) ...................... 14–12
CHAPTER 15.WEB SERVER PAGES ............................................................................... 15–1
15.1Overview .................................................................................................................................... 15–1
15.2Web Server Usage ..................................................................................................................... 15–1
15.2.1 Web Server Menu Tree ....................................................................................................... 15–2
15.3Home Pages ................................................................................................................................ 15–3
15.3.1 Home Page .......................................................................................................................... 15–3
15.3.2 Home: Contact Page............................................................................................................ 15–4
15.3.3 Home: Support Page ........................................................................................................... 15–5
15.4Admin Pages .............................................................................................................................. 15–6
15.4.1 Admin: Access Page ........................................................................................................... 15–6
15.4.2 Admin: Remote Page .......................................................................................................... 15–7
15.5Config Mdm (Modem Configuration) Pages .......................................................................... 15–8
ix
CDM-700 High-Speed Satellite Modem Revision 5 Table of Contents MN/CDM700.IOM
15.5.1 Config Mdm: Modem Page ................................................................................................. 15–8
15.5.2 Config Mdm: Modem Utilities Page ................................................................................... 15–9
15.5.3 Config Mdm: INTF1 (Interface 1) Page ........................................................................... 15–10
15.5.3.1 Config Mdm: INTF1 – E3/T3/STS1 Page ................................................................ 15–11
15.5.3.2 Config Mdm: INTF1 – OC3 (Optical) Page ............................................................. 15–12
15.5.3.3 Config Mdm: INTF1 – HSSI Page............................................................................ 15–13
15.5.4 Config Mdm: INTF2 (Interface 2) Page ........................................................................... 15–14
15.5.4.1 Config Mdm: INTF2 – GBEI (Gigabit Ethernet) Main Page ................................... 15–15
15.5.4.1.1GBEI: Statistics Page ............................................................................................ 15–16
15.5.4.1.2GBEI: VLAN Feature Page .................................................................................. 15–17
15.6Stats (Statistics) Pages ............................................................................................................ 15–18
15.6.1 Stats: Modem Status Page ................................................................................................. 15–18
15.6.2 Stats: Modem Logs Page ................................................................................................... 15–19
15.7Maint (Maintenance) Page: Unit Information ..................................................................... 15–20
APPENDIX A. FAST ACTIVATION PROCEDURE .............................................................. A–1
A.1 Introduction ................................................................................................................................ A–1
A.2 Activation Procedure ................................................................................................................. A–2
A.2.1 Serial Number ...................................................................................................................... A–2
A.2.2 View currently installed features ......................................................................................... A–2
A.2.3 Enter Access Codes .............................................................................................................. A–2
APPENDIX B.DUAL E3 / T3 / STS-1 INTERFACE (CDI-10) .............................................. B–1
B.1 Introduction ................................................................................................................................ B–1
B.2 Summary of Specifications .....................................................................................................
... B–3
B.3 Connector Pinouts ...................................................................................................................... B–4
APPENDIX C.OC-3 / STM-1 INTERFACE (CDI-50) ............................................................ C–1
C.1 Introduction ................................................................................................................................ C–1
C.2 General Specifications ............................................................................................................... C–3
C.3 Connector Pinout ....................................................................................................................... C–4
APPENDIX D. HSSI INTERFACE (CDI-60) ......................................................................... D–1
D.1 Introduction ................................................................................................................................ D–1
D.2 Physical Description ................................................................................................................... D–3
D.3 General Specifications ............................................................................................................... D–4
x
CDM-700 High-Speed Satellite Modem Revision 5 Table of Contents MN/CDM700.IOM
D.4 Environmental And Physical .................................................................................................... D–5
D.5 Connector Pinout ....................................................................................................................... D–6
APPENDIX E. 10/100/1000 BASE-T INTERFACE (GBEI) (CDI-70) .................................... E–1
E.1 Introduction ................................................................................................................................ E–1
E.2 Physical Description ................................................................................................................... E–2
E.3 General Specifications ............................................................................................................... E–2
E.4 Connector Pinout ....................................................................................................................... E–3
E.5 GBEI Software Upload Procedure ........................................................................................... E–4
E.5.1 Upgrading the Gigabit Ethernet Interface Card Firmware .................................................... E–5
1. Download the Files ....................................................................................................................... E–5
2. Connect the PC to the Interface .................................................................................................... E–5
3. Reflash the Unit ............................................................................................................................ E–5
E.6 GBEI Operational Setups .......................................................................................................... E–7
APPENDIX F. E
MEASUREMENT .................................................................................. F–1
B/N0
Tables
Table 1-1. Major Assemblies..................................................................................................................... 1–3
Table 1-2. FAST and Hardware Options ................................................................................................... 1–5
Table 6-1. Front Panel LED Indicators ...................................................................................................... 6–2
Table 7-1. Eb/No, Spectral Efficiency and Occupied Bandwidth .............................................................. 7–3
Table 10-1. Summary of Specifications ................................................................................................. 10–1
Table 10-2. Definition of Points For Spectral Mask ............................................................................... 10–2
Table 15-1 Web Server Menu Tree ........................................................................................................ 15–2
Table D-1. Interface Specifications ......................................................................................................... D–4
Table D-2. Connector Pinout .................................................................................................................. D–6
Table E-1. Interface Specifications .......................................................................................................... E–2
Table E-2. Connector Pinout .................................................................................................................... E–3
xi
CDM-700 High-Speed Satellite Modem Revision 5 Table of Contents MN/CDM700.IOM
Figures
Figure 1-1. CDM-700 High Speed Satellite Modem ................................................................................. 1–1
Figure 2-1. Installation of Optional Rear-Mounting Support Brackets (Kit KT/6228-2) ............................ 2–3
Figure 2-2. Installation of Optional Side-Railings (FP/SL0006) ............................................................... 2–4
Figure 3-1. CDM-700 Modem Block Diagram .......................................................................................... 3–3
Figure 3-2. Rear Panel View .................................................................................................................... 3–5
Figure 4-1. CDM-700 Satellite Modem .................................................................................................... 4–1
Figure 4-2. CDM-700 Rear Panel ................................................................................................ ............. 4–3
Figure 4-3. CDM-700 Dimensional Envelope (70/140 MHz) .................................................................... 4–5
Figure 5-1. CDM-700 Chassis – Rear Panel ........................................................................................... 5–1
Figure 6-1. Front Panel View .................................................................................................................... 6–1
Figure 6-2. Keypad .................................................................................................................................... 6–3
Figure 6-3. Traffic Flow Loopback Block Diagrams ................................................................................ 6–59
Figure 7-1. CDM-700 Gigabit Ethernet Latency with Modem in IF Loopback .......................................... 7–4
Figure 7-2. CDM-700 HSSI Latency with Modem in IF Loopback ............................................................ 7–4
Figure 7-3. Rate 3/4 TPC QPSK, 8-PSK, 16-QAM, 64-QAM ................................................................... 7–5
Figure 7-4. Rate 7/8 TPC QPSK, 8-PSK, 16-QAM, 64-QAM ................................................................... 7–6
Figure 8-1. Typical Data Interface (Features Vary By Interface) ............................................................. 8–2
Figure 8-2. CDI-10 G.703 Dual G.703 Interface ....................................................................................... 8–3
Figure 8-3. CDI-50 OC-3 / STM-1 Interface .............................................................................................. 8–4
Figure 8-4. CDI-60 HSSI Data Interface ................................................................................................... 8–5
Figure 9-1. Flash Update via Internet ....................................................................................................... 9–1
Figure 10-1. Spectral Mask .................................................................................................................... 10–2
Figure 10-2. 70/140 MHz and L-Band Carrier Input Level versus Symbol Rate ................................... 10–6
Figure 14-1. Networking Loop with Switches .......................................................................................... 14–2
Figure 14-2. Networking Loop Example .................................................................................................. 14–4
Figure 14-3. Networking Loop Example (Simplified) .............................................................................. 14–4
Figure 14-4. Hub-to-Hub with Standard Traffic using Routers .................................................................. 14–6
Figure 14-5. Wired-thru for Hub-to-Hub with Standard Traffic using Routers ........................................ 14–7
Figure 14-6. Wired-around for Hub-to-Hub with Standard Traffic using Routers ................................... 14–7
Figure 14-7. Hub-to-Remotes with Standard Traffic using Routers or Switches .................................... 14–8
Figure 14-8. Wired-thru for Hub-to-Remotes with Standard Traffic using Routers or Switches ....................... 14–9
Figure 14-9. Wired-around for Hub-to-Remotes with Standard Traffic using Routers or Switches .................. 14–9
Figure 14-10. Point-to-Multipoint using Routers ................................................................................... 14–10
Figure 14-11. Wired-thru for Point-to-Multipoint with Routers .............................................................. 14–11
Figure 14-12. Wired-around for Point-to-Multipoint with Routers ......................................................... 14–11
Figure 14-13. Point-to-Multipoint using Switches ................................................................................. 14–12
Figure 14-14. Wired-thru, Hub-to-Remotes, Split-path Traffic using Switches (Point-to-Multipoint) .... 14–13
Figure 14-15. Wired-around, Hub-to-Remotes, Split-path Traffic using Switches (Point-to-Multipoint) 14–13
Figure 15-1. CDM-700 Home Page ........................................................................................................ 15–3
Figure 15-2. Home: Contact Information Page ....................................................................................... 15–4
Figure 15-3. Home: Customer Support Page ......................................................................................... 15–5
Figure 15-4. Admin: Access Page .......................................................................................................... 15–6
Figure 15-5. Admin: Remote Page ......................................................................................................... 15–7
Figure 15-6. Config Mdm: Modem Page ................................................................................................. 15–8
Figure 15-7. Config Mdm: Modem Utilities Page .................................................................................... 15–9
Figure 15-8. Config Mdm: INTF1 Page (Default – no module installed) ............................................... 15–10
Figure 15-9. Config Mdm: INTF1 – E3/T3/STS1 (Dual G.703) Page ................................................... 15–11
Figure 15-10. Config Mdm: INTF1 – OC3 Page ................................................................................... 15–12
Figure 15-11. Config Mdm: INTF1 – HSSI Page .................................................................................. 15–13
Figure 15-12. Config Mdm: INTF2 page (Default – no module installed) ............................................. 15–14
Figure 15-13. Config Mdm: INTF2 – GBEI Main Page ......................................................................... 15–15
xii
CDM-700 High-Speed Satellite Modem Revision 5 Table of Contents MN/CDM700.IOM
Figure 15-14. Config Mdm: INTF2 Æ GBEI Statistics Page ................................................................. 15–16
Figure 15-15. Config Mdm: INTF2 Æ GBEI VLAN Feature Page ......................................................... 15–17
Figure 15-16. Statistics: (Main) Modem Status Page ........................................................................... 15–18
Figure 15-17. Statistics: Modem Logs Page ......................................................................................... 15–19
Figure 15-18. Maintenance: (Main) Unit Information Page ................................................................... 15–20
Figure B-1. Block Diagram of Dual E3/T3/STS-1 Data Interface Module ................................................ B–2
Figure B-2. Dual E3/T3/STS-1 Data Interface Module (CDI-10) ............................................................... B–2
Figure C-1. Optical / Coaxial Interface Block Diagram ............................................................................ C–2
Figure C-2. CDI-50 Rear Panel ............................................................................................................... C–2
Figure D-1. HSSI Interface Block Diagram ............................................................................................ D–2
Figure D-2. HSSI Interface ...................................................................................................................... D–2
Figure D-3. Continuous and Gap Clock at TT ......................................................................................... D–4
Figure E-1. CDI-70 1000 Base-T Gigabit Ethernet Interface (GBEI) ....................................................... E–1
Figure E-2. GBEI Interface Option Board – Phase 1 ............................................................................... E–3
Figure E-4. Example of GBEI Interface Bridging a Remote Host on a Common LAN over the Sate llite
.......................................................................................................................................................... E–8
Figure E-5. Example of M&C Port Assigned an IP Address NOT on a Common LAN ........................... E–8
xiii
CDM-700 High-Speed Satellite Modem Revision 5 Table of Contents MN/CDM700.IOM
Notes:
xiv
Customer Support
Contact the Comtech EF Data Customer Support Department for:
• Product support or training
• Reporting comments or suggestions concerning manuals
A Customer Support representative may be reached at:
To return a Comtech EF Data product (in-warranty and out-of-warranty) for repair or replaceme nt:
For Online Customer Support:
An RMA number request can be requested electronically by contacting the Customer Support Department through the online support page at
For information regarding this product’s warranty policy, refer to the
• Information on upgrading or returning a product
Comtech EF Data Attention: Customer Support Department 2114 West 7th Street Tempe, Arizona 85281 USA
480.333.2200 (Main Comtech EF Data number)
480.333.4357 (Customer Support Desk)
480.333.2161 FAX
• Contact the Comtech EF Data Customer Support Department. Be prepared to supply
the Customer Support representative with the model number, serial number, and a description of the problem.
• Request a Return Material Authorization (RMA) number from the Comtech EF Data
Customer Support representative.
• Pack the product in its original shipping carton/packaging to ensure that the product is
not damaged during shipping.
• Ship the product back to Comtech EF Data. (Shipping charges should be prepaid.)
• Click on “Return Material Authorization” for detailed instructions on our return
procedures.
• Click on the “RMA Request Form” hyperlink, then fill out the form completely before
sending.
• Send e-mail to the Customer Support Department at service@comtechefdata.com.

Preface

www.comtechefdata.com/support.asp:
Warranty Policy, p. xx.
xv
CDM-700 High Speed Satellite Modem Revision 5 Preface MN/CDM700.IOM
About this Manual
This manual provides installation and operation information for the Comtech EF Data CDM-700 High Speed Satellite Modem. This is a technical document intended for earth station engineers, technicians, and operators responsible for the operation and maintenance of the CDM-700.
Reporting Comments or Suggestions Concerning this Manual
Comments and suggestions regarding the content and design of this manual will be appreciated. To submit comments, please contact the Comtech EF Data Technical Publications Department:
TechnicalPublications@comtechefdata.com
.
Conventions and References
Metric Conversion
Metric conversion information is located on the inside back cover of this manual. This information is provided to assist the operator in cross-referencing non-metric to metric conversions.
Cautions and Warnings
CAUTION indicates a hazardous situation that, if not avoided, may result in minor or moderate injury. CAUTION may also be used to
CAUTION
indicate other unsafe practices or risks of property damage.
WARNING indicates a potentially hazardous situation that, if not
WARNING
IMPORTANT
avoided, could result in death or serious injury.
Indicates information critical for proper equipment function.
Recommended Standard Designations
Recommended Standard (RS) Designations have been superseded by the new designation of the Electronic Industries Association (EIA). References to the old designations are shown only when depicting actual text displayed on the screen of the unit (RS-232, RS-485, etc.). All other references in the manual will be shown with the EIA designations.
xvi
CDM-700 High Speed Satellite Modem Revision 5 Preface MN/CDM700.IOM
Electrical Safety
The CDM-700 Modem has been shown to comply with the EN 60950 Safety of Information Technology Equipment, including electrical business machines safety standard.
The equipment is rated for operation over the range 100 - 240 volts AC. It has a maximum power consumption of 75 watts, and draws a maximum of 0.75 mA.
The user should observe the following instructions:
IMPORTANT
Fuses
The CDM-700 is fitted with two fuses - one each for line and neutral connections. These are contained within the body of the IEC power inlet connector, behind a small plastic flap.
Note: Refer to Physical Description section for fuse data.
CAUTION
Environmental
The CDM-700 must not be operated in an environment where the unit is exposed to extremes of temperature outside the ambient range 0 to 50°C (32° to 122°F), precipitation, condensation, or humid atmospheres above 95% RH, altitudes (un-pressurized) greater than 2000 meters, excessive dust or vibration, flammable gases, corrosive or explosive atmospheres.
Operation in vehicles or other transportable installations that are equipped to provide a stable environment is permitted. If such vehicles do not provide a stable environment, safety of the equipment to EN60950 may not be guaranteed.
Installation
The installation and connection to the line supply must be made in compliance to local or national wiring codes and regulations.
The CDM-700 is designed for connection to a power system that has separate ground, line and neutral conductors. The equipment is not designed for connection to power system that has no direct connection to ground.
The CDM-700 is shipped with a line inlet cable suitable for use in the country of operation. If it is necessary to replace this cable, ensure the replacement has an equivalent specification. Examples of acceptable ratings for the cable include HAR, BASEC and HOXXX-X. Examples of acceptable
FOR CONTINUED OPERATOR SAFETY, ALWAYS REPLACE THE FUSES WITH THE CORRECT TYPE AND RATING.
xvii
CDM-700 High Speed Satellite Modem Revision 5 Preface MN/CDM700.IOM
connector ratings include VDE, NF-USE, UL, CSA, OVE, CEBEC, NEMKO, DEMKO, BS1636A, BSI, SETI, IMQ, KEMA-KEUR and SEV.
International Symbols
Symbol Definition Symbol Definition
~
Alternating Current
Fuse
Protective Earth
Chassis Ground
Telecommunications Terminal Equipment Directive
In accordance with the Telecommunications Terminal Equipment Directive 91/263/EEC, this equipment should not be directly connected to the Public Telecommunications Network.
CE Mark
Comtech EF Data declares that the CDM-700 Modem meets the necessary requirements for the CE Mark.
RoHS Compliancy
This unit satisfies (with exemptions) the re quirements specified in the European Union D irective on the Restriction of Hazardous Substances, Directive 2002/95/EC, (EU RoHS).
EMC (Electromagnetic Compatibility)
In accordance with European Directive 89/336/EEC, and European Directive 1999/5/EC (Radio Equipment and Telecommunications Equipment) the CDM-700 Modem has been shown, by independent testing, to comply with the following standards:
• EN 301 489-1 V1.4.1 (2002): Electromagnetic compatibility and Radio spectrum
Matters (ERM); ElectroMagnetic Compatibility (EMC) standard for radio equipment and services; Part 1: Common technical requirements
• Emissions: EN 55022 Class A - Limits and methods of measurement of radio
interference characteristics of Information Technology Equipment.
(Also tested to FCC Part 15 Class B)
• Immunity: EN 50082 Part 1 - Generic immunity standard, Part 1: Domestic,
commercial and light industrial environment.
xviii
CDM-700 High Speed Satellite Modem Revision 5 Preface MN/CDM700.IOM
Additionally, the CDM-700 has been shown to comply with the following standards:
EN 61000-3-2 Harmonic Currents Emission EN 61000-3-3 Voltage Fluctuations and Flicker EN 61000-4-2 ESD Immunity EN 61000-4-4 EFT Burst Immunity EN 61000-4-5 Surge Immunity EN 61000-4-6 RF Conducted Immunity EN 61000-4-8 Power Frequency Magnetic Field Immunity EN 61000-4-9 Pulse Magnetic Field Immunity EN 61000-4-11 Voltage Dips, Interruptions, and Variations Immunity EN 61000-4-13 Immunity to Harmonics
To ensure that the Modem continues to comply with these standards, observe the following instructions:
IMPORTANT
• Connections to the transmit and receive IF ports (‘N’ type female connectors) should
be made using a good quality coaxial cable - for example, RG213/U.
• All 'D' type connectors attached to the rear panel must have back-shells that provide
continuous metallic shielding. Cable with a continuous outer shield (either foil or braid, or both) must be used, and the shield must be bonded to the back-shell.
• The equipment must be operated with its cover on at all times. If it becomes
necessary to remove the cover, the user should ensure that the cover is correctly re­fitted before normal operation commences.
xix
CDM-700 High Speed Satellite Modem Revision 5 Preface MN/CDM700.IOM
Warrant y Policy
Comtech EF Data products are warranted against defects in material and workmanship for a period of two years from the date of shipment. During the warranty period, Comtech EF Data will, at its option, repair or replace products that prove to be defective.
For equipment under warranty, the owner is responsible for freight to Comtech EF Data and all related customs, taxes, tariffs, insurance, etc. Comtech EF Data is responsible for the freight charges only for return of the equipment from the factory to the owner. Comtech EF Data will return the equipment by the same method (i.e., Air, Express, Surface) as the equipment was sent to Comtech EF Data.
All equipment returned for warranty repair must have a valid RMA number issued prior to return and be marked clearly on the return packaging. Comtech EF Data strongly recommends all equipment be returned in its original packaging.
Comtech EF Data Corporation’s obligations under this warranty are limited to repair or replacement of failed parts, and the return shipment to the buyer of the repaired or replaced parts.
Limitations of Warranty
The warranty does not apply to any part of a product that has been installed, altered, repaired, or misused in any way that, in the opinion of Comtech EF Data Corporation, would affect the reliability or detracts from the performance of any part of the product, or is damaged as the result of use in a way or with equipment that had not been previously approved by Comtech EF Data Corporation.
The warranty does not apply to any produ ct or pa rts thereof where th e serial number or the serial number of any of its parts has been altered, defaced, or removed.
The warranty does not cover damage or loss incurred in transportation of the product.
The warranty does not cover replacement or repair necessitated by loss or damage from any cause beyond the control of Comtech EF Data Corporation, such as lightning or other natural and weather related events or wartime environments.
The warranty does not cover any labor involved in the removal and or reinstallation of warranted equipment or parts on site, or any labor required to diagnose the necessity for repair or replacement.
The warranty excludes any responsibility by Comtech EF Data Corporation for incidental or consequential damages arising from the use of the equipment or products, or for any inability to use them either separate from or in combination with any other equipment or products.
xx
CDM-700 High Speed Satellite Modem Revision 5 Preface MN/CDM700.IOM
A fixed charge established for each product will be imposed for all equipment returned for warranty repair where Comtech EF Data Corporation cannot identify the cause of the reported failure.
Exclusive Remedies
Comtech EF Data Corporation’s warranty, as stated is in lieu of all other warranties, expressed, implied, or statutory, including those of merchantability and fitness for a particular purpose. The buyer shall pass on to any purchaser, lessee, or other user of Comtech EF Data Corporation’s products, the aforementioned warra nty, and sh all indemnif y and hold harmless Comtech EF Data Corporation from any claims or liability of such purchaser, lessee, or user based upon allegations that the buyer, its agents, or employees have m ade additional warranties or representations as to product preference or use.
The remedies provided herein are the buyer’s sole and exclusive remedies. Comtech EF Data shall not be liable for any direct, indirect, special, incidental, or consequential damages, whether based on contract, tort, or any other legal theory.
xxi
CDM-700 High Speed Satellite Modem Revision 5 Preface MN/CDM700.IOM
Notes:
xxii
1.1 Overview
The Comtech EF Data CDM-700 High Speed Satellite Modem (Figure 1-1) – hereinafter referred to as “the modem” – is intended for simplex or duplex operations with a range of multi-port data interfaces. The modem operates in broadcast, circuit restoration, point-to-point and point-to-multipoint applications.
Chassis – Initially released version
Chapter 1. INTRODUCTION
Chassis –Rev. A or later version
Item Rev A or Later Version Initially released Version
1:1 and 1:N Redundancy Supports 1:1 and 1:N Redundancy
Front Panel Protruding Round Button + Arrow Keys Diamond Shape Flat Membrane Keys
Figure 1-1. CDM-700 High Speed Satellite Modem
1–1
Single Thread Only. Not Field Upgradable.
CDM-700 High Speed Satellite Modem Revision 5 Introduction MN/CDM700.IOM
1.2 Standard Features
The CDM-700 is a high data-rate satellite modem, intended for simplex or duplex operation. The following features are available in the modem:
• Compact: 1 RU, 22 inches (56 cm) deep with low power consumption
• (Optional) 52 to 88 and 104 to 176 MHz frequency range
• (Optional) 950 to 1950 MHz frequencies
• Combines multiple data streams into a single carrier (2.5% overhead).
• Data rate range: 155.52 Mbps within 1 to 64 Msps
• QPSK, 8-PSK, 16-QAM, 64-QAM
• Turbo Product Coding (TPC)
• Two data interface slots
• Data interfaces include: ♦ CDI-10: Dual G.703 (E3/T3/STS-1), 2 independent channels ♦ CDI-50: OC-3 Interface ♦ CDI-60: HSSI Interface ♦ CDI-70: 10/100/1000Base-T (GbE) Ethernet Interface
o VLAN supported in one of Slot 1 or Slot 2
• Adaptive Equalizer
• Unit Management/ M&C, Standard Features ♦ Front panel keypad and vacuum florescent display ♦ Ethernet 10/100 BaseT for firmware upgrades plus Telnet and SNMP device
management
♦ RS-232 or RS-485 ♦ USB1.1 Port for firmware upgrades
• Asymmetric data rates
• Standard 1.5 ppm internal reference or external reference
Notes:
1. Rev. A or later chassis is required for support of 1:1 or 1:N operation.
2. Initially released (prior to Rev. A) chassis are not field upgradeable to support 1:1 or 1:N operation.
1.2.1 Software – Flash Upgrading
The internal software is powerful and flexible, permitting storage an d retrieval of up to 10 different modem configurations. The modem uses ‘flash memory’ technology internally , and new firmware can be uploaded to the unit from an external PC. Th is simplifies software upgrading, and updates can now be sent via the Internet, e-mail, or on disk. The upgrade can be performed without opening the unit by simply connecting either to the modem Ethernet port or the USB1.1 port
1–2
CDM-700 High Speed Satellite Modem Revision 5 Introduction MN/CDM700.IOM
1.2.2 Turbo Product Coding (TPC)
The modem has Turbo Product Coding (TPC) available. TPC simultaneously offers increased coding gain and lowers decoding delay. The TPC rates are:
Rate 3/4
Rate 7/8
QPSK, 8-PSK, 16-QAM, 64-QAM
QPSK, 8-PSK, 16-QAM, 64-QAM
1.3 Major Assemblies
Later Unit Part Number
PL/12000-1 PL/10012-1 Framing Card
PL/10002-1 PL/10002-1 70 / 140 MHz Modulator Card
PL/10003-1 PL/10003-1
PL/10003-2 PL/10003-2
PL/12113-1 PL/11230-1
PL/11571-1 PL/11571-1
PL/10004-1 PL/10004-1 Generation 3 Turbo FEC Card
Data Interface Modules
PL/10008-1 CDI-10 – Dual E3 / T3 / STS-1 G.703 Data Interface Module
PL/11043-1 CDI-50-1 – Single Mode OC-3 (Optical) / STM-1 (Copper) Interface Module
PL/11043-2 (Note 2) CDI-50-2 – Multiple Mode OC-3 (Optical) / STM-1 (Copper) Interface Module
PL/11582-1 (Note 3) CDI-60 – HSSI Interface Module
PL/11509-1 (Initially released units)
PL/11509-3 (Rev. A and later units)
KT/12139-1 Blank Interface Panel
Early Unit Part Number
Table 1-1. Major Assemblies
Item (See Note 1)
70 / 140 Demodulator Card, 75 Ω 70 / 140 Demodulator Card, 50 Ω L-Band Modulator Card, 50 Ω L-Band Demodulator Card, 50 Ω
CDI-70 – Gigabit Ethernet Interface Module with RJ-45 female connector
CDI-70 – Gigabit Ethernet Interface Module with RJ-45 female connector
Notes:
1. Rev. A and later units required for 1:1 and 1:N Redundancy. Initially released units are not field upgradeable.
2. Check with factory for availability.
3. The PL/11509-1 is upgradeable to PL/11509-3 (functionality with a reflash of PL/11509-1 module via the Gigabit Ethernet port.)
1.4 Allowable Data Interface Combinations
Data interfaces are plugged into Slot 1 and Slot 2 of the CDM-700. The allowable combination of data interfaces and the data interfaces that are supported for redundancy are listed below. The
1–3
CDM-700 High Speed Satellite Modem Revision 5 Introduction MN/CDM700.IOM
CRS-170A and CRS-180 support 1:1 redundancy for the L-Band and 70/140 MHz, respectively. the CRS-300 provides support for 1:N redundancy:
1:1 Redundancy with the CRS-170A (70/140 MHz) and CRS-180 (L-Band):
CDM-700 Modem Configuration
column of the table below shows the data interface combinations
The Allowable
of the CDM-700 that are supported by the CRS-170A and CRS-180. First, the 1:1 switch is selected depending upon the operating frequency, and then a data interface kit for Slot 1 and Slot 2 is chosen. More information on these kits is provided in the datasheet and manual for CRS-170A or CRS-180 1:1 Redundancy Switches.
1:N Redundancy with the CRS-300: The CRS-300 was originally designed for operation with the CDM-600 and subsequently adapted to a number of other modems. It is capable of supporting interfaces up to the point where there are no more paths left to route traffic. This is the reason why the CRS-300 supports a limited set of the interface combinations supported by the CDM-700.
Allowable CDM-700 Combinations 1:N CRS-300 Configurations
Slot 1 Slot 2 TMI Module
Dual G.703 (CDI-10)
OC3 Optical (CDI-50-1)
Single Mode
OC3 Copper (CDI-50-1)
None CRS-345 CRS-306
Dual G.703 (CDI-10) CRS-345 CRS-306
HSSI (CDI-60) Not Supported Not Supported
GigE (CDI-70) CRS-345, Wired-Around Only CRS-306, Wired-Around Only
None Not Supported Not Supported
None CRS-325 CRS-306
GigE (CDI-70) (Allowed
in Standby unit only)
None CRS-336 CRS-306
CRS-325 CRS-306
Notes 1,3
RMI Module
Notes 2,4
HSSI (CDI-60)
GigE (CDI-70)
HSSI (CDI-60 Not Supported Not Supported
None
GigE (CDI-70)
None CRS-336 CRS-306
GigE (CDI-70)
Dual G.703 (CDI-10) CRS-345 CRS-306
HSSI (CDI-60) CRS-336 CRS-306
GigE (CDI-70) CRS-336 CRS-306
Note 5
CRS-336, CDI-70 is
Wired-Around Only
CRS-336, One CDI-70 is
Wired-Through and the other
is Wired-Around
CRS-306, CDI-70 is
Wired-Around Only
CRS-306, One CDI-70 is
Wired-Through and the other
is Wired-Around
Refer to the CRS-300 1:10 Redundancy Switch Installation and Operation Manual for additional details and operational information.
Notes:
1. A TMI (Traffic Modem Interface) Module is used with each Primary Traffic Modem.
2. An RMI (Redundant Modem Interface) Module is used with the Standby Modem.
3. As of April 2007, GigE or HSSI TMI requires a CRS-336. The CRS-336 fully replaces or
spares a CRS-335.
4. As of April 2007, the CRS-306 supersedes the CRS-305.
5. One Slot with a CDI-70 will support the maximum data rate. The 2
nd
slot is needed only
for the Standby Modem
1–4
CDM-700 High Speed Satellite Modem Revision 5 Introduction MN/CDM700.IOM
1.5 FAST and Hardware Options
The CDM-700 is extremely flexible and powerful, and incorporates a large number of optional features. Comtech EF Data provides Fully Accessible System Topology (FAST), which permits the purchase and installation of options through special authorization codes, entered remotely, or through the front panel. A customer can order features today and upgrade later to meet needs.
Table 1-2 lists the standard, hardware and FAST (software) options that are available.
Table 1-2. FAST and Hardware Options
How Installed Description
Standard (Note 1)
FAST (Note 1)
Hardware
Hardware (Note 2)
Notes:
1. Data rates are rounded. See Chapter 10. SUMMARY OF SPECIFICATIONS for the full
range.
2. See Chapter 3 for allowable Data Interface configurations for Slot 1 and Slot 2.
Tier 1, Turbo Coding, QPSK, 8-PSK to 15 Msymbol/s
(38.176 Mbps @ 7/8)
Tier 2, Turbo Coding, QPSK, 8-PSK to 22.5 Msymbol/s
(57.264 Mbps @ 7/8)
Tier 3, Turbo Coding, QPSK, 8-PSK to 30 Msymbol/s
(76.352 Mbps @ 7/8)
Tier 4, Turbo Coding, QPSK, 8-PSK to 37.5 Msymbol/s
(95.440 Mbps @ 7/8)
Tier 5, Turbo Coding, QPSK, 8-PSK to 45 Msymbol/s
(114.528 Mbps @ 7/8) (Fits in 54 MHz Transponder)
Tier 6, Turbo Coding, QPSK, 8-PSK to 64 Msymbol/s
(155.520 Mbps @ 7/8) (Fits in 72 MHz Transponder)
Tier 7, Turbo Coding, 16-QAM with Equalizer to 15 Msymbol/s
(50.901 Mbps @ 7/8)
Tier 8, Turbo Coding, 16-QAM with Equalizer to 22.5 Msymbol/s
(76.352 Mbps @ 7/8)
Tier 9, Turbo Coding, 16-QAM with Equalizer to 30 Msymbol/s
(101.803 Mbps @ 7/8) (Fits in 36 MHz Transponder)
Tier 10, Turbo Coding, 16-QAM with Equalizer to 37.5 Msymbol/s
(127.253 Mbps @ 7/8)
Tier 11, Turbo Coding, 16-QAM with Equalizer to 45 Msymbol/s
(152.704 Mbps @ 7/8)
Tier 12, Turbo Coding, 16-QAM with Equalizer to 64 Msymbol/s
(155.52 Mbps @ 7/8), (Fits in 54 MHz Transponder)
Tier 13, Turbo Coding, 64-QAM with Equalizer to 64 Msymbol/s
(155.520 Mbps @ 7/8) (Fits in 36 MHz Transponder) Tx 70/140 MHz IF With BNC 50Ω or 75Ω Impedance
Tx L-Band IF with Type N Female Rx 70/140 MHz IF With BNC 50Ωor 75Ω Impedance
Rx L-Band with Type N Female
CDI-10 Dual E3 / T3 / STS-1 G.703 Data Interface Module
CDI-50 Single Mode OC-3 (Optical) and STM-1 (Copper) Interface Module
CDI-60 HSSI Interface Module
CDI-70 1000 Base-T (GbE) Ethernet Interface
1–5
CDM-700 High Speed Satellite Modem Revision 5 Introduction MN/CDM700.IOM
1.6 New in This Release
Revision 5:
• Chapter 6
added, Monitor Rx-Params updated with GBEI Frame Rate (FER1 or 2)
• Chapter 10
• Chapter 11
Negotiation (GNG) commands
• Chapter 15
• Appendix E
Gigabit Ethernet Interface Card Firmware
: Incorporated GBEI Statistics Summary, Intfc1 GBEI Negotiation
: Incorporated Power Consumption specification change : Added Frame Error Rate (FER) and Gigabit Interface
: Updated GBEI Web Server pages
: Incorporated GBEI Statistics Summary and Upgrading the
1–6
Chapter 2. INSTALLATION
T
2.1 Unpacking and Inspection
The CDM-700 modem and its Installation and Operation Manual are packaged and shipped in a pre-formed, reusable cardboard carton containing foam spacing for maximum shipping protection.
CAUTION
IMPORTAN
Unpack and inspect the CDM-700 as follows:
Do not use any cutting tool that will extend more than 1” into the container and cause damage to the unit.
Be sure to keep all shipping materials for the carrier's inspection.
Step Procedure
Inspect shipping containers for damage. If shipping containers are
1
2 Remove the packing list from the outside of the shipping carton. 3
4
5
6
7 Refer to the following sections for further installation instructions.
damaged, keep them until the contents of the shipment have been carefully inspected and checked for normal operation.
Open the carton by cutting the tape at the top of the carton (indicated
OPEN THIS END).
by Remove the cardboard/foam space covering the modem. Remove the
modem, manual and power cord from the carton. Check the contents against the packing list to verify completeness of
the shipment. Inspect the equipment for any possible damage incurred during
shipment. If damage is evident, contact the carrier and Comtech EF Data immediately and submit a damage report.
2–1
CDM-700 High Speed Satellite Modem Revision 5 Installation MN/CDM700.IOM
2.2 Mounting
If the CDM-700 is to be mounted in a rack, ensure that there is adequate clearance for ventilation, particularly at the sides. In rack systems where there is high heat dissipation, forced air-cooling must be provided by top or bottom mounted fans or blowers. Under no circumstance should the highest internal rack temperature be allowed to exceed 50°C (122°F).
The CDM-700 has short rear support brackets mounted to the side of the
IMPORTANT
chassis - two cooling fans are mounted on the right-hand side of the unit.
2.2.1 Method A: Optional Rear-Mounting Support Brackets
Install the optional rear-mounting support brackets (Figure 2-1) using mounting kit KT/6228-2:
Mounting Kit KT/6228-2 (Optional)
Quantity Part Number Description
2 HW/10-32SHLDR Screw, #10 Shoulder 4 HW/10-32FLT Washer, #10 Flat 2 HW/10-32SPLIT Washer, #10 Split 2 HW/10-32HEXNUT Nut, #10 Hex 2 FP/6138-1 Bracket, Rear Support 4 HW/10-32x1/2RK Bolt, #10 Rack Bracket
The tools required for this installation are a medium Phillips™ screwdriver and a 5/32-inch SAE Allen™ Wrench.
The CDM-700 is assembled into the equipment rack as follows:
Step Procedure
Secure the #10 shoulder screws to the unit chassis through the rear
1
2
3
right and left side mounting slots, using the #10 flat wa shers, #10 split washers, and #10 hex nuts as shown.
Install the rear support brackets onto the equipment rack threaded rear mounting rails, using the #10 rack bracket bolts.
Mount the unit into the equipment rack, ensuring that the shoulders of the #10 shoulder screws properly engage into the rear support bracket slots.
2–2
CDM-700 High Speed Satellite Modem Revision 5 Installation MN/CDM700.IOM
Equipment Rack Rear Mounting Rail
#10 Shoulder Screw
Support Bracket
#10 Bracket Bolt
#10 Flat Washer
#10 Flat Washer #10 Split Washer
#10 Hex Nut
Back of unit
Figure 2-1. Installation of Optional Rear-Mounting Support Brackets (Kit KT/6228-2)
2–3
CDM-700 High Speed Satellite Modem Revision 5 Installation MN/CDM700.IOM
2.2.2 Method B: Optional Installation of Side-Railings
Figure 2-2 depicts installation , of the optional side-railings (FP/SL0006), using standard shop tooling and customer-furnished standard shop hardware:
Side-railings FP/SL0006 (Optional)
Quantity Part Number Description
2 FP/SL0006 Side-Railings
Figure 2-2. Installation of Optional Side-Railings (FP/SL0006)
2–4
3.1 Description
The CDM-700 has two fundamentally different types of interfaces - IF and data.
• The IF interface provides interface with the satellite via the uplink and downlink
equipment and will operate in full duplex or simplex modes.
• The data interface connects with the customer’s equipment (assumed to be the Data
Terminal Equipment [DTE]) and the modem (assumed to be the Data Communications Equipment [DCE]). The data interface is usually full duplex but the modem also operates in simplex Tx only and Rx only applications. (Note – the current version supports duplex and Rx only operation.)
Tx data is accepted by the terrestrial interface where line receivers convert the clock and data signals for further processing. A small First-In-First Out (FIFO) follows the terrestrial interface to facilitate various clocking selections. Th e clock and data are passed to the Framer card, wher e the data from all enabled aligned into a frame structure and sent to the Forward Error Correction (FEC) encoder.
In the FEC encoder, the data is differentially encoded, scrambled, and then encoded.
Following the encoder, the data is fed to the modulator where Tx digital filters perform spectral shaping on the data signals. The resultant in-phase (I) and quadrature (Q) signals are then fed to the remainder of the modulator for QPSK/8-PSK/16-QAM/64-QAM modulation. The carrier is generated by a frequency synthesizer, and the I and Q signals directly modulate this carrier to produce an IF output signal.
The Rx IF signal is digitally IF sampled, converted, demodulated and split into an I and a Q component. An Automatic Gain Control (AGC) circuit maintains the desired signal level constant over a broad range.
Chapter 3. FUNCTIONAL
DESCRIPTION
1
ports on the data interface are combined together in a Multiplexer (Mux) and
1
On all interfaces each port is enabled or disabled. An enabled port operates at the data rate programmed
for that port. A disabled port is not included or zero data rate.
3–1
CDM-700 High Speed Satellite Modem Revision 5 Functional Description MN/CDM700.IOM
After the IF sampling, the processing is all digital, including demodulator, phase lock loops, Nyquist filters and adaptive equalizer. The resultant demodulated signal is fed, in soft decision form, to the selected FEC decoder.
After decoding, the recovered clock and data pass to the Framer card, where the error corrected data stream is Demultiplexed (Demux) and directed to the individual data ports of each data interface. Depending upon the type of data interface, the data passes to the Plesiochronous/ Doppler buffer, which has a programmable size, or alternatively bypasses the buffer. From here, the receive clock and data signals are routed to the terrestrial interface, and are passed to the externally connected DTE equipment.
Physically, the CDM-700 modem comprises several main card assemblies. Refer to Figure 3-1 for a functional block diagram.
• Data Interface: There are two slots at the rear of the modem that where accept the available data interfaces are plugged into the modem. The data interfaces are single port and multi-port type:
♦ A single port interface provides a duplex path. Most are capable of simplex Tx and
Rx operation as well as full duplex operation
♦ A multi-port interface has more than one data interface. For example, the Dual
G.703 (CDI-10) interface has two ports and each Tx/Rx port is independently programmed for E3, T3, or STS-1 operation.
• The Framer card is part of the base modem and includes the Mux/Demux and microcontroller. It also provides the remote and Ethernet ports plus the alarm interface. The keypad and display are also controlled from the framer card.
• FEC: There are two expansion slots for error correction. Currently, one is used. These slots are within the modem and require removal of the cover to access. They look similar to SIM memory modules and are located near the front of the chassis on the Framer card.
• The Modulator card (70/140 MHz or L-Band) is a plug-in board that sits atop the Framer card.
• The Demodulator card (70/140 MHz or L-Band) also plugs into the Framer card.
3–2
CDM-700 High Speed Satellite Modem Revision 5 Functional Description MN/CDM700.IOM
3.2 Interfaces Modules
The two interface slots and multi-port interfaces provide a simple way to use standard telecom interfaces and to fill the gap in standard data rates between 52 and 155 Mbps by multiplexing data streams together. The standard telecom interfaces are G.703, E3, T3, STS-1 and HSSI at the lower end, and STM-1 or OC-3 at the top end, with a large unserved range between the two ends.
Module Description Mbps
CDI-10 Dual E3 / T3 / STS-1 G.703 Data Interface 34.368 / 44.736 / 55.184 CDI-50-1 OC-3 / STM-1 Single Mode and G.703 Coaxial Interface 155.52 (Fixed) CDI-60 HSSI Interface 1.5 to 70 CDI-70 1000 Base-T Gigabit Ethernet Interface (GbEI) 1.5 to 155.52
Figure 3-1. CDM-700 Modem Block Diagram
Operating with multiple interfaces allows greater efficiency:
• The transponder operates with less backoff and at higher efficiency with a single-carrier
and this translates into higher throughput.
• Operating with a single carrier requires fewer modems than operating with multiple
carriers. The impact of one versus multiple modems in many applications is less of an impact than the monthly transponder expense, but it is part of the overall ease of operation.
For additional information see the applicable section in the manual for each interface.
3–3
CDM-700 High Speed Satellite Modem Revision 5 Functional Description MN/CDM700.IOM
3.2.1 Data Interfaces And Data Transfer Across The Link
Data into a port (a port is a Tx / Rx pair) at one end of the link is transferred to the same port at the other end. If HSSI is plugged into Slot 1 then a HSSI module is plugged into Slot 1 at the other end of the link for proper data transfer. Transfer of data between the Gigabit Ethernet module in Slot 1at the near end to the HSSI module in Slot 1 at the distant end is not allowed.
When considering 1:N redundancy refer to the CRS-300 manual to see how it is possible to mix some data interfaces within the same switch for a cost effective solution.
3.2.2 Simplex and Asymmetric Operation
The CDM-700 is available in a full duplex or Rx only configuration, and mixing of 70/140 MHz and L-Band in the same chassis is not allowed. Most of the interfaces allow turning off the Tx or Rx side of the data interface, and this configures the disabled port to 0 Mbps. The composite data rate must lie within range of the allowable range for the chosen modulation and code rate.
Asymmetric operation is allowed on most interfaces. The OC-3 / STM-1 is an exception, and it operates only at 155.52 Mbps. Asymmetric operation of the G.703 is also possible, although seldom used. Here is an example of Tx (E3) and Rx (DS3):
CDM-700 At Near End CDM-700 At Distant End
Slot 1 Slot 1
Port 1 Port 2 Port 1 Port 2
Tx Rx Tx Rx Tx Rx Tx Rx E3 Disable Disable DS3 Disable E3 DS3 Disable
Notice the in this example data is transferred across the link to the same port and the same slot.
Asymmetric operation of the Gigabit Ethernet and HSSI interfaces is also allowed and simpler to configure.
3–4
CDM-700 High Speed Satellite Modem Revision 5 Functional Description MN/CDM700.IOM
3.3 Allowable Data Interfaces In Slot 1 and Slot 2
Interfaces are allowed in Slot 1 and Slot 2 as follows:
Slot 1 Slot 2
CDI-10 Dual G.703 CDI-10 Dual G.703 CDI-10 Dual G.703 CDI-10 Dual G.703
CDI-50 OC3 (Optical Single Mode or Copper) None CDI-60 HSSI
CDI-60 HSSI CDI-60 HSSI
CDI-70 Gigabit CDI-70 Gigabit
None
Chassis – Initially released version
None CDI-10 (Dual G.703) CDI-60 (HSSI) CDI-70 (Gigabit)
None CDI-60 (HSSI) CDI-70 (Gigabit)
None, CDI-70 (Gigabit)
CDI-10 (Dual G.703) CDI-60 (HSSI) CDI-70 (Gigabit)
Slot 1
Slot 2
Chassis – Rev. A and later versions
Figure 3-2. Rear Panel View
3–5
CDM-700 High Speed Satellite Modem Revision 5 Functional Description MN/CDM700.IOM
Notes:
3–6
4.1 Introduction
The CDM-700 is constructed as a 1RU high rack-mounting chassis, which can be freestanding, if desired. Rack handles at the front facilitate removal from and placement into a rack. Figure 4-1 shows the front panel of the modem.
Chassis – Initially released version
Chassis –Rev. A and later versions
Chapter 4. PHYSICAL
DESCRIPTION
Figure 4-1. CDM-700 Satellite Modem
4–1
CDM-700 High Speed Satellite Modem Revision 5 Physical Description MN/CDM700.IOM
4.2 Front Panel
The CDM-700 front panel features a Vacuum Fluorescent Display (VFD), a keypad, eight Light- Emitting Diode (LED) indicators, and a Universal Serial Bus (USB) port. The user enters data via
the keypad, and messages are displayed on the VFD. The LEDs indicate, in a summary fashion, the status of the unit.
Vacuum Fluorescent Display (VFD)
Initially Released Chassis Keypad
The VFD is an active display showing two lines with 24 characters per line. It produces a blue light, the brightness of which can be controlled by the user. It has greatly superior viewing characteristics compared to a Liquid Crystal Display (LCD), and does not suffer problems of viewing angle or contrast.
The keypad for the initially released chassis features six individual keyswitches mounted directly behind a fully sealed membrane overlay. They have a positive‘click’ action that provide the user with tactile feedback.
These six switches are identified as [↑], [↓], [→], [←] arrows, ENT (Enter) and CLR (Clear). The functions of these keys are described in Chapter 6. FRONT PANEL OPERATION.
The keypad for the Rev. A and later chassis features six individual protruding black buttons. They have a positive‘click’ action that provide the user with tactile feedback.The later keypad function is the same as the earlier keypad.
Rev. A and Later Chassis Keypad
LED Indicators
There are eight LEDs on the front panel. The behavior of these LEDs is described in Chapter 6. FRONT PANEL OPERATION.
4–2
CDM-700 High Speed Satellite Modem Revision 5
–
Physical Description MN/CDM700.IOM
4.3 Rear Panel
Chassis – Initially released version
Slot 1
Slot 2
Chassis
Rev. A and later versions
Figure 4-2. CDM-700 Rear Panel
4.3.1 External Cables
External cables are attached to connectors on the rear panel of the CDM-700. These comprise:
• IEC Line Input connector
• Tx and Rx IF Connectors (depends upon 70/140 MHz or L-Band)
• Data Interface connectors (depends upon installed interface)
• External Reference connector
• Ethernet
• Alarm Form C connector
• Remote Control connector (EIA-232/EIA-485)
• SerDes (private communications link)
• Form C Alarm connector
• Remote Control connector
4.3.2 IEC Line Input Connector
It also is fitted with two fuses - one each for line and neutral connections (or L1, L2, where appropriate). These are contained within the body of the connector, behind a small plastic flap.
For continued operator safety, always replace the fuses with the correct
IMPORTANT
type and rating. Use T1.75A (slow-blow) 20mm fuses.
4–3
CDM-700 High Speed Satellite Modem Revision 5 Physical Description MN/CDM700.IOM
4.3.3 Rx and Tx IF Connectors (J1 and J3)
These connectors depend upon whether 70/140 or L-Band operation is chosen. Refer to Chapter 5.
4.3.4 10/100 Ethernet Remote Port Connector (J4)
The Ethernet connector is a RJ45 type female.
4.3.5 SerDes (Private Communications Link) (J6)
The SerDes connector is a type RJ45 type female. This connector is a private communications link and NOT for customer use.
4.3.6 External Reference Connector (J7)
The Ext Ref (External Reference) input is a female SMA connector used to supply a master reference to the entire chassis. The clocks on the Framer Card and the Modulator and Demodulator Synthesizers are locked to this input, when it is used.
4.3.7 Alarm Form C Connector (P1)
The Alarms connector is a 15-pin 'D' type male (DB15-M). This provides the user with access to the Form-C relay contacts, which indicate the fault status of the unit. These are typically connected to an external fault monitoring system, often found in satellite earth stations.
In addition, the receive I and Q demodulator samples are provided on this connector. Connecting these signals to an oscilloscope in X,Y mode will provide the receive signal constellation diagram, which is a useful diagnostic aid.
A pin is also provided which can mute the transmit carrier. This requires that the pin be shorted to ground, or a TTL ‘low’. The Renduancy feature must be disabled when using alarm connector to view I and Q samples.
As an aid to antenna pointing or for driving step-track equipment, an analog AGC signal is provided on Pin 2 of this connector.
4.3.8 Remote Control Connector (RS-232/RS-485), P2
The Remote Control connector is a 9-pin 'D' type male (DB9-M). Access is provided to remote control ports of the modem, both RS-232 and RS-485.
4.3.9 Data Interface Connector
Refer to Chapter 5 and the Appendicies for applicable interfaces.
4–4
CDM-700 High Speed Satellite Modem Revision 5 Physical Description MN/CDM700.IOM
4.4 Dimensional Envelope
Figure 4-3. CDM-700 Dimensional Envelope (70/140 MHz)
4–5
CDM-700 High Speed Satellite Modem Revision 5 Physical Description MN/CDM700.IOM
Notes:
4–6
Chapter 5. CONNECTOR PINOUTS
5.1 External Connections
External cables are attached to connectors on the rear panel of the CDM-700. Figure 5-1 shows the CDM-700 rear panel – both current and original chassis configurations – with typical data interfaces installed in Slot 1 and Slot 2.
Chassis – Initially Released Version (70/140 MHz shown)
Chassis – Rev. A or Later Versions (70/140 MHz shown
)
Slot 1
Slot 2
Figure 5-1. CDM-700 Chassis – Rear Panel
Refer to the applicable appendix in this manual for specific Data Interface pinout information.
The initially released chassis differs from the Rev. A chassis as follows:
Chassis – Initially Released Version Chassis – Rev. A and Later Production Version J6: RJ-45, SerDes
J7: SMA-F, External Input
J6: 9 Pin D-F, Async Channel J7: BNC-F, External Input
For support of 1:1 and 1:N operation, a Rev. A or later chassis is required.
5–1
CDM-700 High Speed Satellite Modem Revision 5 Connector Pinouts MN/CDM700.IOM
Modem Rear Panel Connectors Table for Initially Released Chassis Version:
Name
Tx IF Output J1
Rx IF Input J3 10/100 Ethernet J4 RJ-45 Female Ethernet Management
SerDes J6 RJ-45 Female Private communications link Ext Ref J7 SMA Female External reference input Alarm P1 15-pin ‘D’ Male Alarm connector and Form C contacts RS232/485 P2 9-pin ‘D’ Male Remote Port AC INPUT NONE IEC 320 Prime Power Input GROUND NONE 10-32 Stud Grounding
Ref.
Des.
Connector Type Function
BNC Female 70/140 MHz IF Output Type N Female L-Band IF Output BNC Female 70/140 MHz IF Input Type N Female L-Band IF Input
Note: The initially-released chassis does not support 1:1 or 1:N operation and is not upgradeable.
Modem Rear Panel Connectors Table for L-Band, Rev. A and Later Chassis Versions
:
Name
Tx IF Output J1
Ref.
Des.
Connector Type Function
BNC Female 70/140 MHz IF Output Type N Female L-Band IF Output BNC Female 70/140 MHz IF Input
Rx IF Input J3
10/100 Ethernet J4 RJ-45 Female Ethernet Management Async Channel J6 9-pin D Female Async Engineering Channe l Ext Ref J7 BNC Female External reference input Alarm P1 15-pin ‘D’ male Alarm connector and Form C contacts RS232/485 P2 9-pin ‘D’ male Remote Port AC INPUT NONE IEC 320 Prime Power Input GROUND NONE 10-32 Stud Grounding
Type N Female L-Band IF Input
Note: This chassis is required for 1:1 or 1:N operation
The European EMC Directive (EN55022, EN50082-1) requires using properly shielded cables for DATA I/O. These cables are double-shielded from end-to-end, ensuring a continuous ground shield.
5–2
CDM-700 High Speed Satellite Modem Revision 5 Connector Pinouts MN/CDM700.IOM
5.1.1 Tx / Rx Connector Pinout – J1 / J3
The J1 (Tx) and J3 (Rx) IF interfaces are as follows:
Ref.
Des.
Description
70/140 MHz
Connector Type
L-Band
Connector Type
J1 Tx-IF Output
BNC Female Type N Female
J3 Rx-IF Input
BNC Female Type N Female
5.1.2 10/100 Ethernet Management Port Connector Pinout – J4
The J4 Ethernet management port interface is a RJ-45 female connector.
Pin # Description Direction
1 Tx+ Out 2 TX- Out 3 Rx+ In 4 N/A 5 N/A 6 Rx- In 7 N/A 8 N/A
5.1.3 SerDes Port Connector – J6 (Earlier Chassis Only)
The J6 private communications link is a type RJ-45 female connector – it is not
available for customer use.
5–3
CDM-700 High Speed Satellite Modem Revision 5 Connector Pinouts MN/CDM700.IOM
5.1.4 ASYNC Connector Pinout – J6 (Rev. A and Later Chassis)
The J6 ASYNC Channel interface is a 9-pin, Type D female connector.
Pin # Description Direction
1 Ground 2 RS-232 Transmit Data Out 3 RS-232 Receive Data In 4 Not Used 5 Not Used
RS-485 Receive Data B *
6
RS-485 Receive Data A *
7 8 RS-485 Transmit Data B Out 9 RS-485 Transmit Data A Out
* Use for 2-wire RS-485 operation.
In In
5.1.5 External Reference Input (Main Chassis) – J7
The J7 Ext Ref (External Reference) input is used to supply a master reference to the entire chassis. The clocks on the Framer Card and the Modulator and Demodulator Synthesizers are locked to this input, when it is used:
• Female SMA connector (on the initially released chassis)
• BNC female connector (on the Rev A or later chassis)
Some data interfaces have an Ext-Clk input for synchronizing the data sources. Refer to the individual data interface card on the Data Interfaces appendix for details.
5–4
CDM-700 High Speed Satellite Modem Revision 5 Connector Pinouts MN/CDM700.IOM
5.1.6 Alarm Connector Pinout – P1
The P1 Alarm interface is a 15-Pin type ‘D’ male connector with threaded jack nuts. The pinout depends upon whether the unit is in Normal mode, or in Redundancy mode for use with the CRS-170A (L-Band), CRS-180 (70/140 MHz), CRS-300, or CRS-700 redundancy switches.
The unit is put into 1:1 mode (available only in the Rev. A or later chassis) under the
AUX Æ 1:1 Mask Æ Ena/Dis
menu by selecting Enable.
Initially released modems (chassis versions prior to Rev. A) do not support 1:1 redundancy. There is no upgrade program to support redundancy for these chassis.
Alarm Connector Pinout P1 – Normal Mode
Pin # Description Name Direction
8 Rx Traffic (De-energized, Faulted) Rx-NC I/O
15 Rx Traffic (Energized, No Fault) Rx-NO I/O
Config:
7 Rx Traffic Rx-COM I/O
14 Tx Traffic (De-energized, Faulted) Tx-NC I/O
6 Tx Traffic (Energized, No Fault) Tx-NO I/O
13 Tx Traffic Tx-COM I/O
5 Unit Fault (De-energized, Faulted) Unit-NC I/O
12 Unit Fault (Energized, No Fault) Unit-NO I/O
4 Unit Fault Unit-Com I/O
11 Rx I Channel (Constellation Monitor) Rx-I O
3 Rx Q Channel (Constellation Monitor) Rx-Q O
10 No Connection NC NC
2 AGC Voltage (Rx signal level, 0-10 volts) AGC O 9 Ext Carrier Off EXT-OFF I 1 Ground GND Gnd
5–5
CDM-700 High Speed Satellite Modem Revision 5 Connector Pinouts MN/CDM700.IOM
The pinout table for the P1 connector in Redundancy mode is as follows:
Alarm Connector Pinout P1 – Redundancy Mode
[ 1:1 (CRS-170A, CRS-180) and 1:N (CRS-300/700) ]
Pin # Description Name Direction
8 Program Relay NC PR-NC I/O
15 Program Relay NO PR-NO I/O
7 Program Relay COM PR-COM I/O
14 Clock Detect Clk Det I
6 Aux Tx Enable Red_Out_4 O
13 No Connection NC NC
5 Fused –12 VDC Output (160 mA max) -12VDC O
12 Fused +12 VDC Output (160 mA max) +12VDC O
4 Online Red_In_2 I
11 Serial Clock Red_Out_1 O
3 Serial Data Red_Out_2 O
10 Receive Serial Data – auxiliary channel Red_In_3 I
2 Transmit Serial Data – auxiliary channel Red_Out_3 O 9 Ext Carrier Off Red_In_1 I 1 Ground GND Gnd
Note : For both the Normal Mode and the CRS-170A/180 and CRS300/700 and Redundancy Modes of operation:
• Prior to October 2007, the relays have low voltage contacts with transient
suppressors across each pin to ground. The maximum working voltage = 18VDC or 13VAC. The maximum current rating is 1 Amp DC or 0.5 Amp AC. The Summary Relay combines Tx, Rx, and Unit Faults into a single relay.
•
The suppressors were removed, as of October 2007, with Framer Card S/N
071539628. The Summary Relay combines Tx, Rx, and Unit Faults into a single relay.
5–6
CDM-700 High Speed Satellite Modem Revision 5 Connector Pinouts MN/CDM700.IOM
5.1.7 RS-232/485 Remote Port Connector Pinout – P2
The P2 Remote interface is a 9-Pin type ‘D’ male connector with threaded jack nuts.
Pin # Description Direction
1 Ground 2 RS-232 Transmit Data Out 3 RS-232 Receive Data In 4 Not Used 5 Not Used
RS-485 Receive Data B
6
See Note RS-485 Receive Data A
7
See Note 8 RS-485 Transmit Data B Out 9 RS-485 Transmit Data A Out
In
In
RS-232/485 Remote Port P2 is used for 2-wire RS-485 operation.
IMPORTANT
5.2 Data Interfaces
Refer to the applicable appendix in this manual for specific Data Interface pinout information:
• Appendix B. Dual E3/T3/STS-1 (G.703) Interface (CDI-10)
• Appendix C. OC3 Interface (CDI-50)
• Appendix D. HSSI Interface (CDI-60)
• Appendix E. Gigabit Ethernet Interface (GbEI) (CDI-70)
5–7
CDM-700 High Speed Satellite Modem Revision 5 Connector Pinouts MN/CDM700.IOM
Notes:
5–8
Chapter 6. FRONT PANEL
6.1 Introduction
LED Vacuum Fluorescent Indicators Keypad Display (VFD)
Operators can fully control and monitor the operation of the CDM-700 from the front panel using the keypad and display. Nested menus display all available options, prompting operators to carry out a required action.
Figure 6-1 identifies the key features of the front panel, which are explained in greater detail in this section.
OPERATION
Figure 6-1. Front Panel View
6–1
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
6.1.1 Front Panel LED Indicators
The behavior of the eight front panel LEDs adjacent to the keypad indicate the operational status of the CDM-700, and are described below in Table 6-1.
Table 6-1. Front Panel LED Indicators
LED Color Condition
Green No Unit Faults or Alarms exists
Unit Status
Tx Status
Rx Status
On line
Stored Event
Transmitter On
Remote/EDMAC
Test Mode
Orange No Unit Faults, but a Traffic fault exists
Red A Unit Fault exists
Green No Tx Traffic Faults or Alarms exists
Orange A Tx Traffic Alarm exists
Red A Traffic Fault exists
Off Unit not configured for Modulator or Interface Tx is not enabled.
Green No Rx Traffic Faults or Alarms exists
Orange A Rx Traffic Alarm exists
Red A Rx Fault exists
Off Unit not configured for Demodulator
Green The Unit is On Line, and carrying traffic
Off
Orange
Off There are no Stored Events
Green
Off Transmitter is currently OFF.
Green
Off The Unit is in Local Mode – remote monitoring is possible, but no remote control
Green A Test Mode is selected (Example: IF Loopback)
Off There is no Test Mode currently selected.
The Unit is Off Line (standby) – forced by externally connected 1:1 or 1:N redundancy system
There is a Stored Event in the log, which can be viewed from the front panel, or retrieved via the remote control interface
Transmitter is currently on. This indicator reflects the actual condition of the transmitter, as opposed to the programmed condition.
The Unit is in Remote Communication Mode. Local monitoring is possible, but no local control
In general, the Alarm relay state will reflect the state of the Front Panel LEDs. For instance, if the Unit Status LED is red, the Unit Alarm relay will be active, etc. The one exception is the Transmit Traffic relay. This will only be activated if a Transmit
IMPORTANT
Traffic Fault exists – it does not reflect the state of the Tx carrier.
6–2
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
6.1.2 Front Panel Keypad
The front panel keypad, with its physical variations, is shown in Figure 6-2:
Diamond Keypad:
Initially Released Chassis
Button Keypad:
Rev. A or Later Chassis
Figure 6-2. Keypad
The keypad features six individual key switches with a positive ‘click’ action – this provides tactile feedback. The function of these keys are as follows:
ENTER
[ENT]
CLEAR
[CLR]
Left, Right
W X
(←) (→)
Up, Down
S T (↑) (↓)
This key is used to select a displayed function or to execute a modem configuration change.
This key is used to back out of a selection or to cancel a configuration change,
which has not been executed using ENTER [ENT]. Pressing CLEAR [CLR]
generally returns the display to the previous selection.
These arrows are used to move to the next selection or to move the cursor functions. At times, they may also used to move from one section to another.
These arrows are used primarily to change configuration data (numbers). At times, they may also be used to move from one section to another.
The keypad has an auto-repeat feature. If a key is held down for more than 1 second, the key action will repeat, automatically, at the rate of 15 keystrokes per second. This is particularly useful when editing
IMPORTANT
numeric fields, with many digits, such as frequency or data rate.
6–3
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
6.1.3 Front Panel Vacuum Flourescent Display (VFD)
The CDM-700 features a Vacuum Fluorescent Display (VFD). The VFD is an active display
showing two lines of 24 characters each. It produces a blue light, the brightness of which
can be adjusted. Compared to a Liquid Crystal Display (LCD), it has greatly superior viewing characteristics and does not suffer problems of viewing angle or contrast.
As shown above, the ‘welcome screen’ is displayed whenever power is first applied to the unit. The top line identifies the unit model (i.e., CDM-700); the bottom line displays the CDM-700’s installed Firmware Version (version number varies).
Pressing any key navigates to the top-level Select menu. On most menu screens, a flashing, solid­block cursor blinks at a once-per-second rate. This cursor indicates the currently selected item, digit, or field:
CONFIG: Remote Tx Rx Intfc1 Intfc2 Ref Aux
Where this solid block cursor would obscure the item being edited (for example, a numeric field), the cursor will automatically change to an underline cursor:
Tx IF Freq: 0140.0000 MHz (◄ ► ▲ ▼ ENT)
To prevent the display from becoming burnt by a constant image, the unit employs a screen saver feature, which activates after one hour and constantly scrolls and wraps a message across the screen. The top line of the display will show the Circuit ID (which can be entered by the user) and the bottom line will show the circuit Eb/No value (if the demod is locked) followed by ‘Press
any key…’ as shown:
Circuit ID: ------------- not locked. Press any key..
Press any key to restore the previously active screen.
6–4
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
6.1.4 Menu Matrix
Para Title Selectable Params
6.2 Opening Screen
6.3 SELECT: (Main) Menu Config; Monitor; Test; Info, Save/Load; Util
6.3.1 (SELECT:) Config [Configuration] Remote; Tx; Rx; Intfc1; Intfc2; Ref, AUX
6.3.1.1 CONFIG: Remote [Control] Local; Serial; Ethernet
6.3.1.2 CONFIG: Tx Mod; Code; Freq: Data; Sym; Pwr; Scram
6.3.1.3 CONFIG: Rx Dem; Code; Freq: Data; Sym; Descram; EbNo; Mask
6.3.1.4 CONFIG: Intfc1 (CDI-10 Dual G.703) Alarm, Port 1, Port 2, Ext-Clk
6.3.1.4.1 CONFIG: Intfc2 (CDI-10 Dual G.703)
6.3.1.5 CONFIG: Intfc1 (CDI-50 OC-3) Tx, Rx, Mode
6.3.1.6 CONFIG: Intfc1 (CDI-60 HSSI) Tx, Rx, CTS/RTS
6.3.1.6.1 CONFIG: Intfc2 (CDI-60 HSSI)
6.3.1.7
6.3.1.7.1
CONFIG: Intfc1 (CDI-70 Gigabit Ethernet)
CONFIG: Intfc2 (CDI-70 Gigabit Ethernet)
Tx, Rx, Man, Stats, SWOP, NEG
6.3.1.9 CONFIG: Ref Frequency Reference
6.3.1.10 CONFIG: Aux Ena/Dis Force (1:1)
6.3.2 (SELECT:) Monitor Alarms; Rx-Params; Event-Log
6.3.3 (SELECT:) Test Norm; IF; Dig; I/O; RF; Tx-Cw; Tx-1,0
6.3.4 (SELECT:) Info [Information] Rem; Tx; Rx; 1:1; Intfc1; Intfc2
6.3.5 (SELECT:) Save/Load Save; Load
6.3.6 (SELECT:) Util [Utility] RT-CLK; Ref; ID; Display; Firmware; FAST
6–5
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
6.2 Opening Screen
The opening ‘welcome screen’ shown here is representative of what displays whenever power is first applied to the unit (the Firmware Version may differ). Pressing any key displays the top-level Select menu.
6.3 SELECT: (Main) Menu
The following menus are presented using CDI-10 G.703, CDI-60 HSSI, and CDI-70 GbE Interfaces. The CDI-10 G.703 Interface is used to present all
IMPORTANT
menus. The difference is noted in (SELECT:) Config Æ Intfc1, where each
interface is specifically referenced.
SELECT: Config Monitor Test Info Save/Load Util
Move the cursor to the desired choice using the ◄ ► arrow keys, then press following table describes the function of each menu branch:
Selection
Config
Monitor
Test
Info
Save/Load
Util
Menu Branch Description
[Configuration] Provides selections for the desired Interface, Transmit,
and Receive operations
Permits the user to monitor the alarm status of the unit, to view the log of stored events, and to display the Receive Parameters screen.
Permits the user to configure the modem into one of several Test modes, example: CW and Loopback
[Information] Provides a summary/display of the Interface, Transmit,
Receive, and M&C configurations.
Permits the user to save and retrieve up to 10 different modem configurations.
[Utility] Permits the user to perform miscellaneous functions, such as
setting the Real-Time Clock, adjusting the display brightness, etc.
ENTER. The
6–6
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
6.3.1 (SELECT:) CONFIG
CONFIG: Remote Tx Rx Intfc1 Intfc2 Ref Aux
The submenus available are:
Selection Submenu Description
Remote
Tx
Rx
Intfc1
or
Intfc2
Ref
Aux
IMPORTANT
[Remote Control] - used to define whether the unit is controlled locally or
remotely. (See Important Note.)
[Transmit] - used to define, on a parameter-by-parameter basis, the Tx
configuration of the unit. These submenu branches would be used to change, for example, just the Tx Frequency.
[Receive] - used to define, on a parameter-by-parameter basis, the Rx
configuration of the unit. These submenu branches would be used to change, for example, just the Rx Frequency.
[Interface] - used to configure Interfaces plugged into Slot 1 or Slot 2 on
the back of the unit. The menus change depending on the type of interface – as of this manual revision, Dual E3/T3/STS-1, Dual G.703, OC3, HSSI, and Gigabit Ethernet (GbE) are available.
[Reference] - used to configure the source of the modem reference
frequency.
[Auxiliary] - used to enable Redundancy. In 1:1 operation, allows the
online unit to force switchover.
The modem may be monitored over the remote control bus at any time. When in Local mode, however, configuration parameters may only be changed through the front panel. Conversely, when in Remote mode, the unit may be monitored from the front panel, but configuration parameters may only be changed via the remote control bus.
6–7
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
6.3.1.1 (CONFIG:) Remote
Remote Control: Local Serial Ethernet
Select Local, Serial or Ethernet by using the ◄ ► arrow keys, then press ENTER.
Selection Action Local Serial
Ethernet
Remote control is disabled. Remote monitoring is still possible.
RS232, RS485-2W, and RS485-4W menus are accessed.
Additional submenus will be displayed.
Remote Control: Æ Local
When Local is selected, remote control is disabled and local control enabled once ENTER is pressed; the CONFIG: menu returns. When Remote is selected,
IMPORTANT
menu operations associated with local control are disabled, and the following message appears when menu or command access associated with Local control is attempted:
THIS UNIT IS CURRENTLY IN REMOTE MODE!!
Remote Control: Æ Serial
Serial Config: Interface Baudrate (E)
Select Interface or Baudrate using the ◄ ► arrow keys, then press
ENTER.
If Serial Config: Æ Interface is selected:
M&C Bus Interface: RS232 RS485-2W RS485-4W (E)
Select RS232 or RS485-2W (2-wire) or RS485-4W (4-wire) using the ◄ ► arrow keys, then press
ENTER.
Note: At this point, a prompt requests entry of the bus address.
6–8
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
If M&C Bus Interface Æ RS232 is selected:
In RS232 Mode the Bus Address is fixed at 0000
If M&C Bus Interface Æ RS485-2W or RS485-4W is selected, further prompting occurs:
RS485 Bus Address: 0001 (E)
Edit the RS485 bus address of the modem by selecting the digit to be edited, using the ◄ ► arrow keys. The value of the digit is then changed using the ▲ ▼ arrow keys. The valid range of addresses is from 1 to 9999. Press
If Serial Config: Æ Baudrate is selected:
ENTER.
Local M&C Bus Baud Rate: 9600 Baud ( E )
Edit the Baud rate of the remote control bus, connected locally to the M&C computer. Values of 1200, 2400, 4800, 9600, 19200, 38400, and 57600 baud are possible. The value is changed using the ◄ ► arrow keys. Press
Note: The Asynchronous character format is FIXED at 8 data bits, No parity, and 1 stop bit (8-N-
1).
ENTER.
Remote Control: Æ Ethernet
Ethernet Config: Gateway Address MAC SNMP ( E)
Select Gateway, Address, MAC, or SNMP using the ◄ ► arrow keys, then press
If Ethernet Config: Æ Gateway is selected:
Ethernet IP Gateway:
063.168.001.127 ( E )
The IP Gateway address is the default address that the modem will send all IP responses when the message originated from a source outside the modems local attached network.
Edit the IP Gateway address by selecting the digit to be edited, using the ◄ ► arrow keys. The value of the digit is then changed using the ▲ ▼ arrow keys. Press
ENTER.
ENTER.
6–9
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
If Ethernet Config: Æ Address is selected:
Ethernet IP Address/Range:
010.006.030.139/16 ()
The operator uses this menu to set the modem’s management IP address and subnet mask (range). This is the address used by external applications to access and control the modem using the SNMP, HTTP or Telnet interfaces. This also is the address used to upgrade the device firmware using FTP.
Edit the IP Address/Range address by selecting the digit to be edited, using the ◄ ► arrow keys. The value of the digit is then changed using the ▲ ▼ arrow keys. Press
ENTER.
If Ethernet Config: Æ MAC is selected:
M&C Port MAC Address: 00-06-B0-00-47-12
This is a ‘read only’ status window that displays the factory program MAC address for the Ethernet management interface. Press
ENTER or CLEAR to return to the previous menu.
Note: The preceding address is representative of a typical MAC address.
If Ethernet Config: Æ SNMP is selected:
SNMP: Community Traps ( E )
This is a ‘read only’ status window . Submenus enable setting of the destination IP address for SNMP traps. Select Community or Traps using the ◄ ► arrow keys, then press
ENTER.
If SNMP Æ Community is selected:
SNMP Community: Read ( E )
This menu is the entry point into setting the Read, Write, and Trap community strings used for SNMP. Use the to drop into the next level menu.
▲ ▼ arrow keys to toggle between Read, Write, and Trap, then press ENTER
6–10
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
If Community ÆRead is selected:
Read Community: ( E ) public
Edit the Read Community string using the ◄ ► ▲ ▼ arrow keys. Only the bottom line (0 to 20 characters) is available. Select the cursor position on the bottom line using the ◄ ► arrow keys, then edit the selected character using the
▲ ▼ arrow keys.
The following characters are available:
<Space> A-Z a-z {|}!”#$%&’()*+,-./ 0123456789 :;<>?@ []^_`.
If Community ÆWrite is selected:
Write Community: ( E ) private
Edit the Write Community string using the ◄ ► ▲ ▼ arrow keys. Only the bottom line (0 to 20 characters) is available. Select the cursor position on the bottom line using the ◄ ► arrow keys, then edit the selected character using the
▲ ▼ arrow keys.
The following characters are available:
<Space> A-Z a-z {|}!”#$%&’()*+,-./ 0123456789 :;<>?@ []^_`.
If SNMP Æ Traps is selected:
SNMP Trap IP Address: 1 2 (E )
Select 1 or 2 to access/modify the Trap/IP Address #1 or #2 using the ◄ ► arrow keys, then press
ENTER.
If SNMP Trap IP Address: Æ 1 or 2 is selected:
SNMP Trap IP Address #X:
000.000.000.000 ()
Edit the SNMP Trip IP#1 or IP#2 Address by selecting the digit to be edited, using the ◄ ► arrow keys. The value of the digit is then changed using the ▲ ▼ arrow keys. Press
6–11
ENTER.
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
6.3.1.2 (CONFIG:) Tx
Tx: Mod Code Freq Data Sym Pwr Scram (E)
The modem symbol rate is a function of the modulation type, code rate, and data rate. If a change to one of these parameters produces a value outside the allowable symbol rate range, the invalid symbol rate is not programmed into the modem.
For example: If the data rate is increased at one of the interfaces and the symbol rate exceeds the limit it is possible that changing the modulation type or code rate will bring the symbol rate within range.
All possible choices are presented at all times, If an option is not installed (either Hardware or FAST) or valid, the ◄►arrow keys will force the cursor to
IMPORTANT
skip past the unavailable choice.
Tx: Æ Mod
Tx Modulation: Type Inv α (E)
Select Type, Inv, or α using the ◄ ► arrow keys. Press
If Tx Modulation Æ Type is selected:
Tx Mod: Q 8P 16Q 64Q (E)
Select the Transmit Modulation Type by using the ◄ ► arrow keys. Press are as follows:
Modulation Type (Symbol Rate) Selection Description Q (QPSK) 8P (8-PSK)
ENTER.
Valid for all FEC types
Valid for all FEC types
ENTER. The choices
16Q (16-QAM) 64Q (64-QAM)
Valid for all FEC types
Valid for all FEC types
6–12
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
If Tx Modulation Æ Inv is selected:
Tx Spectrum: Normal Inverted (E)
When Normal is selected the spectral sense of the carrier has the default transition to I and Q constellation points. Selecting Inverted causes the I and Q transition points to move in the opposite sense. The selection of the Inverted also can correct for spectral inversion in the uplink or downlink.
Select Normal or Invert using the ◄ ► arrow keys. Press
ENTER.
If Tx Modulation Æ α is selected:
Tx (α) Rolloff %: 25 35 (E)
The Rolloff, or α, dictates how fast the spectral edges of the carrier are attenuated beyond the 3dB bandwidth. The default setting is 25%; with 25% rolloff, the edge falls off more quickly than with the 35% setting.
Select the Rolloff (α) setting using the ◄ ► arrow keys. Whenever the Mode is changed, (α) reverts to 25%, but (α) can be modified to 35% from this menu. Press
ENTER.
Tx: Æ Code
Tx Code Rate: 3/4 7/8 (E)
Refer to data rate menu for valid code rates.
• All possible choices are presented at all times.
• If an option is not installed (either Hardware or FAST) or is not valid, or if a
IMPORTANT
Select the code rate by using the ◄ ► arrow keys. Press ENTER.
Tx Code Rate Selection Description 3/4 7/8
code rate is not available for the Mode selected, the ◄ ► arrow keys will force the cursor to skip past the unavailable choice.
Valid for all Modulation Types
Valid for all Modulation Types (actual 20/23)
6–13
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
Tx: Æ Freq
Tx Freq: 0140.0000 MHz (E)
Edit the Tx IF Frequency by selecting the digit to be edited, using the ◄ ► arrow keys. The value of the digit is then changed using the ▲ ▼ arrow keys. Press
ENTER.
70/140 MHz
L-Band
The ranges of frequencies are from 52 to 88 MHz and from 104 to 176 MHz with a resolution of 100 Hz.
The range of frequency is from 950 to 1950 MHz with 100 Hz resolution.
Tx: Æ Data
Tx Comp Data Rate(Mbps)
000.000000 (E)
This is a ‘read only’ status window that displays the Composite Data Rate, the sum of data rates for all enabled Tx ports on Intfc1 and Intfc2 as measured at the data input connector (customer interface). Referring to the next menu, the Symbol Rate is the rate transmitted at the Tx IF connector and corresponds to the Composite Data Rate plus overhead (2.5%), and includes the effects of coding and modulation.
Composite Data Rate = ∑ Port-Data Rates, where:
Ports = all enabled ports for Intfc1 and Intfc2 and depends upon the interfaces installed in Slot 1 and Slot 2.
Symbol Rate = 1.025 *Composite Data Rate /(m *CR), where:
m = the modulation index (2 for QPSK, 2 for 8-PSK, 4 for 16-QAM, 5 for
32-QAM, 6 for 64-QAM),
and
CR = Code Rate (3/4, etc)
Programming of this modem is not the same as conventional modems because the architecture differs. The incorporation of an internal statistical multiplexer/demultiplexer, and the multi-port interfaces makes the configuration more consistent if the user sets the data rate for each port on the interface. The data rate for each port is programmed under the CONFIG: Intfc1 and CONFIG: Intfc2 menus.
Press
ENTER or CLEAR to return to the previous menu.
6–14
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
Tx: Æ Sym
Tx Sym Rate:
34.368000 Msps (E)
This is a ‘read only’ status window that displays the Symbol Rate. Refer to the detailed explanation provided under (CONFIG:) Tx Æ Data.
The symbol rate shown in this example is for a composite data rate of 34.368 Mbps (E3) when the modulation is QPSK and the code rate is 3/4.
ENTER or CLEAR to return to the previous menu.
Press
Tx: Æ Pwr
Tx Power: Level On/Off Imped (E)
Select Level, On/Off, or Imped using the ◄ ► arrow keys. Press
ENTER.
The Imped(ance) selection is only available/displayed when the 70/140 MHz
IMPORTANT
Modulator card is installed.
If Tx Power Æ Level is selected:
Tx Output Power Level:
-24.9 dBm ( E)
Edit the TX Power Level by selecting the digit to be edited, using the ◄ ► arrow keys. The value of the digit is then changed using the
▲ ▼ arrow keys. Press ENTER. The valid ranges are
as follows:
70/140 MHz L-Band
0 to -20 dBm
-5 to -25 dBm
If Tx Power Æ On/Off is selected:
Tx Output State: Off On Rx­Tx_Inhibit ( E)
Select Off, On, or Rx-Tx_Inhibit using the ◄ ► arrow keys. Press
ENTER.
6–15
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
If Tx Output State Æ Rx-Tx_Inhibit is selected:
Prevents the Tx carrier from being transmitted, until the demodulator is locked.
Rx–Tx Inhibit (RTI)
IMPORTANT
To avoid the Tx Carrier from being turned Off when the demodulator loses lock for a very short period of time, the demodulator must be unlocked continuously for period of 10 seconds before the Tx carrier is inhibited. This time interval is fixed.
With this feature enabled it will not affect the internal IF Loopback feature. HOWEVER – if an external IF Loopback is attempted (connecting an external cable from the Tx IF output to the Rx IF input),
then this feature will not function (the Tx carrier cannot turn On until
the demodulator is locked, and the demodulator cannot lock because the Tx output is Off). The result is that the demodulator will not lock, and the Tx carrier will not turn On.
USE THE RTI FEATURE WITH EXTREME CARE.
If Tx Power Æ Imped is selected:
The Imped(ance) selection is only available when the 70/140 MHz
IMPORTANT
Modulator card is installed.
Tx Impedance (Ohms): 50 75 ( E)
This menu is displayed only when the 70/140 MHz modulator is installed.
70/140 MHz
L-Band
Select 50 or 75Ω, using the
Not Applicable.
◄ ► arrow keys. Press ENTER.
Tx: Æ Scram
Tx Scrambling: Default-On Off (E)
Options are:
Default-On Off
The options are displayed all of the time, but the ◄ ► arrow keys will force the cursor to skip past an unavailable choice. Press
The proprietary scrambler is selected.
No Scrambling.
ENTER.
6–16
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
6.3.1.3 (CONFIG:) Rx
Rx: Dem Code Freq Data Sym Descrm EbNo Mask (E)
The modem symbol rate is a function of the modulation type, code rate, and data rate. If a change to one of these parameters produces a value outside the allowable symbol rate range, the invalid symbol rate is not programmed into the modem.
For example: If the data rate is increased at one of the interfaces and the symbol rate exceeds the limit changing the modulation type or code rate may bring the symbol rate within range.
All possible choices are presented at all times, If an option is not installed (either Hardware or FAST) or valid, the ◄►arrow keys will force the cursor to
IMPORTANT
skip past the unavailable choice.
Rx: Æ Dem (Demod)
Rx Dem: Type Inv Acq α Adap-Eq (E)
Select Type, Inv, Acq, α, or Adap-Eq using the ◄ ► arrow keys. Press
If Rx Dem: Æ Type is selected:
Rx Type: Q 8P 16Q 64Q (E)
Select the Receive Demodulation Type by using the ◄ ► arrow keys. Press ENTER. The choices are as follows:
Demodulation Type (Symbol Rate) Selection
Q (QPSK) 8P (8-PSK) 16Q (16-QAM)
Description
Valid for all FEC types
Valid for all FEC types
Valid for all FEC types
ENTER.
64Q (64-QAM)
Valid for all FEC types
6–17
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
If Rx Dem: Æ Inv is selected:
Rx Spectrum: Normal Inverted (E)
Select Normal or Inverted using the ◄ ► arrow keys. Press ENTER.
When Normal is selected, the spectral sense of the carrier has the default transition to I and Q constellation points.
Selecting Inverted causes the I and Q transition points to move in the opposite sense. Selecting Inverted also can correct for spectral inversion in the uplink or downlink.
If Rx Dem: Æ Acq is selected:
Demod Acquisition Range: +/- 099 kHz (cbE)
The value entered here determines the amount of frequency uncertainty the demodulator will search over in order to find and lock to an incoming carrier.
Edit the demodulator acquisition search range value by selecting the digit to be edited, using the ◄ ► arrow keys. The value of the digit is then changed using the ▲ ▼ arrow keys. The range varies from ±001 kHz to ±100 kHz. Press
If Rx Demod: Æ
α is selected:
ENTER.
RX (α) Rolloff %: 25 35 (E)
The Rolloff, or α, dictates how fast the spectral edges of the carrier are attenuated beyond the 3dB bandwidth. The default setting is 25%; with 25% rolloff, the edge falls off more quickly than with the 35% setting.
Select the Rolloff (α) setting using the ◄ ► arrow keys. Whenever the Mode is changed, (α) reverts to 25%, but (α) can be modified to 35% from this menu. Press
If Rx Demod: Æ Adap-Eq is selected:
ENTER.
Rx Adaptive Equalizer: Off On (E)
The adaptive equalizer helps correct for linear distortion in the rest of the link. Linear distortion includes amplitude and phase that would occur due to imperfect filtering effects, but it does not include distortion due to non linear amplifiers.
Select Off or On using the ◄ ► arrow keys. Press
6–18
ENTER.
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
Rx: Æ Code
Code Rate: 3/4 7/8 ( E)
• All possible choices are presented at all times.
• If an option is not installed (either Hardware or FAST) or is not valid, or if a
IMPORTANT
Select the code rate by using the ◄ ► arrow keys. Press ENTER.
Rx Code Rate Selection Description
code rate is not available for the Mode selected, the ◄ ► arrow keys will force the cursor to skip past the unavailable choice.
3/4 7/8
Valid for all Modulation Types
Valid for all Modulation Types (actual 20/23)
Rx: Æ Freq
Rx IF Freq: 0140.0000 MHz (E)
Edit the Rx IF Frequency by selecting the digit to be edited, using the ◄ ► arrow keys. The value of the digit is then changed using the ▲ ▼ arrow keys. Press
70/140 MHz
L-Band
The ranges of frequencies are from 52 to 88 MHz and from 104 to 176 MHz with a resolution of 100 Hz.
The range of frequency is from 950 to 1950 MHz with 100 Hz resolution.
ENTER.
Rx: Æ Data
Rx Comp Data Rate(Mbps)
000.000000 (E)
This is a ‘read only’ status window that displays the Composite Data Rate, the sum of data rates for all enabled Tx ports on Intfc1 and Intfc2 as measured at the data input connector (customer interface). Referring to the next menu, the Symbol Rate is the rate transmitted at the Tx IF connector and corresponds to the Composite Data Rate plus overhead (2.5%), and includes the effects of coding and modulation.
6–19
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
Composite Data Rate = ∑ Port-Data Rates, where:
Ports = all enabled ports for Intfc1 and Intfc2 and depends upon the interfaces installed in Slot 1 and Slot 2.
Symbol Rate = 1.025 *Composite Data Rate /(m *CR), where:
m = the modulation index (2 for QPSK, 2 for 8-PSK, 4 for 16-QAM, 5 for
32-QAM, 6 for 64-QAM),
and
CR = Code Rate (3/4, etc)
Press
Rx: Æ Sym
This is a ‘read only’ status window that displays the Symbol Rate. Refer to the detailed explanation provided under (CONFIG:) Rx Æ Data.
The symbol rate shown in this example is for a composite data rate of 34.368 Mbps (E3) when the modulation is QPSK and the code rate is 3/4.
Press
Rx: Æ Descrm
Options are:
ENTER or CLEAR to return to the previous menu.
Rx Sym Rate:
34.368000 Msps (E)
ENTER or CLEAR to return to the previous menu.
Descrambling: Default-On Off (E)
Default-On
The proprietary descrambler is selected.
Off
No Descrambling.
The options are displayed all of the time, but the ◄ ► arrow keys will force the cursor to skip past an unavailable choice. Press
ENTER.
Rx: Æ Eb/No
Eb/No Alarm: Threshold Alarm/Fault (E)
Select Threshold or Alarm/Fault using the ◄ ► arrow keys. Press ENTER.
6–20
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
If Eb/No Alarm: Æ Threshold is selected:
Eb/No Alarm Threshold:
2.0 dB (▲ ▼ E)
Select a value here, and if the Eb/No falls below this value, a receive traffic fault will be generated.
Edit the Eb/No alarm point by selecting the digit to be edited, using the value of the digit is then changed using the
16.0 dB. Press
If Eb/No Alarm: Æ Alarm/Fault is selected:
ENTER.
▲ ▼ arrow keys. The range of values is from 0.1 to
◄ ► arrow keys. The
Eb/No Alarm: Alarm Fault Mask (E)
Select Alarm, Fault, or Mask using the Eb/No Alarm as an Alarm, as a Fault, or to completely Mask the alarm. This choice affects operation in 1:1 redundancy only. Press
If Eb/No Alarm: Æ Alarm/Fault Æ Mask is selected:
◄ ► arrow keys. The available choices define the
ENTER.
Rx Alarm Mask: AGC BER All-Rx-Flts (E)
Select AGC, BER, or All-Rx-Flts using the
If Rx Alarm Mask: Æ AGC is selected:
◄ ► arrow keys. Press ENTER.
AGC Alarm: Active Mask (E)
This choice effects operation in 1:1 redundancy only. Select Active to activate the AGC Alarm or Mask to mask the AGC Alarm using the
If Rx Alarm Mask: Æ BER is selected:
◄ ► arrow keys. Press ENTER.
BER Alarm: Active Mask (E)
This choice effects operation in 1:1 redundancy only. Select Active to activate the BER Alarm or Mask to mask the BER Alarm using the
6–21
◄ ► arrow keys. Press ENTER.
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
If Rx Alarm Mask: Æ All-Rx-Flts is selected:
Mask All Rx Faults? No Yes (E)
The default value is No. If Yes is selected, all Rx Faults will be masked, and the Rx Status LED
on the front panel will be off.
Select No or Yes using the
◄ ► arrow keys. Press ENTER.
Note: All-Rx-Flts is used when operating the modem in a Tx only mode.
6.3.1.4 (CONFIG): Intfc1
1. INFORMATION RE: ALLOWABLE INTERFACE COMBINATIONS/CONFIGURATIONS:
The combination of installed data interfaces in CDM-700 Chassis Slot 1 (Intfc1) and
IMPORTANT
Slot 2 (Intfc2) drive the appearance/selection of the CONFIG: Intfc1 and CONFIG: Intfc2 menus. Refer to Chapter 3.3 Allowable Data Interfaces In Slot 1 and Slot 2
for a table of the available data interface combinations.
2. INFORMATION RE: MENU DOCUMENTATION FOR INTFC1/INTFC2:
The Config: Intfc1 menu content depicted in this section is dependent on the installed data interface. While the Config: Intfc2 menu content is very similar to that of CONFIG: Intfc1, the data interface menus in this manual are presented in an order
that may or may not be representative of the actual configured unit.
Additional data interfaces will be added to this section as they are introduced. If an interface is not recognized, then
UNKNOWN is displayed. In this case, a later version of
firmware may be required to operate with the data interface.
3. INFORMATION RE: AVAILABLE DATA RATE RANGES:
(a) The composite data rate range depends on the FAST option ordered with the CDM-700. The options are arranged in ascending tiers by symbol rate and modulation type along with the corresponding data rate range.
(b) The Data Rate Range Table in the Chapt er 10. SUMMARY OF SPECIFI CATIONS
summarizes the composite data range by tiers. It also shows how the composite data rate is constructed from the individual data ports on the data interface modules.
(c) The data rate of each individual data port depends on the particular CDI-xx data interface installed in the CDM-700. Additional information about the data rate range for each individual port is provided in the menus below and in the chapter for each
data interface module.
6–22
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
Intfc1 (CDI-10 Dual G.703 Interface)
Interface Slot 1 Slot 2
CDI-10 Dual G.703 (E3/T3/STS1) Installed CDI-10 Dual G.703 or None
Intfc1 E3/T3/STS1: Alarm Port1 Port2 Ext-Clk
Select Alarm, Port1, Port2 or Ext-Clk using the
There are two independent Tx/Rx port pairs on an CDI-10 G.703 Interface. There is common reference, which may be used as a Rx Buffer reference clock for either port.
◄ ► arrow keys. Press ENTER.
Intfc1: Æ Alarm
Intfc1 Alarm/Fault: Ext-Clk
To configure the loss of External Clock as either an Alarm or a Fault, Press
If Intfc1 Alarm/Fault: Æ Ext-Clk is selected:
ENTER.
Intfc# Ext-Clk Alarm/Fault: Alarm Fault Mask (E)
This selection will effect the reporting status if the event of loss of External Clock – and subsequently, the switching logic – when the modem is in a 1:1 redundancy configuration.
Select Alarm, Fault, or Mask using the
◄ ► arrow keys. Press ENTER.
Intfc1: Æ Port1
Intfc1 Port1 E3/T3/STS1: Type Line-Code Tx Rx (E)
Select Type, Line-Code, Tx, or Rx using the
If Intfc1 Port1 E3/T3/STS1: Æ Type is selected:
◄ ► arrow keys. Press ENTER.
Intfc1 Port1 Type: E3 T3 STS1 34.368 Mbps (E)
This menu allows port type selection for the interface. Select E3, T3, or STS1 using the ◄ ► arrow keys. Press
6–23
ENTER.
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
Upon entering the menu, the cursor blinks below the currently active interface and its data rate is shown:
Port Type Selection Data Rate E3 T3 STS1
34.368 Mbps
44. 768 Mbps
51.85 Mbps
If Intfc1 Port1 E3/T3/STS1: Æ Line-Code is selected:
Intfc1 Port1 E3CODE (HDB3S): On Off (E)
This display indicates which port type was selected for Port 1 under Intfc1 Port1 E3/T3/STS1: Æ Type and allows enabling or disabling of the line code specific to that selected port type.
The appearance of the Line-Code menu display depends upon the selected port type. For each display, the port type is shown first; the applicable line code appears in parentheses; and the On or Off selections that follow enable or disable line coding.
Selected Port Type (as displayed) Line Code (as displayed) E3 CODE (HDB3) T3 CODE (B3ZS) STS1 CODE (B3ZS)
By selecting Off, the modem treats the data stream as alternate-mark-inversion (AMI) – that is, no line coding. Press
ENTER.
If Intfc1 Port1 E3/T3/STS1: Æ Tx is selected:
Intfc1 Port1 Tx: Alarms Inv Data Ena/Dia (E)
Select Alarms, Inv, Data or Ena/Dis, using the ◄ ► arrow keys. Press ENTER.
If Intfc1 Port1 Tx: Æ Alarms is selected:
Intfc1 Port1 Tx Alarms: Tx-Data Tx-AIS (E)
Select Tx-Data or Tx-AIS, using the ◄ ► arrow keys, to configure each as an Alarm or Fault condition. Press
If Intfc1 Port1 Tx Alarms: Æ Tx-Data is selected:
ENTER.
6–24
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
Tx Data Alarm: Alarm Fault Mask (E)
This selection affects the event reporting status upon detection of loss of Tx Cable, and subsequently the switching logic, when the modem is in a 1:1 redundancy configuration.
Select Alarm, Fault, or Mask using the If Intfc1 Port1 Tx Alarms: Æ Tx-AIS is selected:
◄ ► arrow keys. Press ENTER.
Tx-AIS Alarm: Alarm Fault Mask (E)
This selection affects the event reporting status upon detection of a Tx AIS condition, and subsequently the switching logic, when the modem is in a 1:1 redundancy configuration.
Select Alarm, Fault, or Mask using the
If Intfc1 Port1 Tx: Æ Inv is selected:
◄ ► arrow keys. Press ENTER.
Intfc1 Port 1 Tx Data: Normal Inverted (E)
This feature has been added for compatibility with certain older equipment. Select Normal or
Inverted using the
If Intfc1 Port1 Tx: Æ Data is selected:
◄ ► arrow keys. Press ENTER.
Intfc1 Port 1 Data Rate Tx: 34.368000 (E)
Intfc1 Port 1 Data Rate Tx: Disabled (E)
This is a ‘read only’ status window to display the data selected via the Intfc1 Port1: Æ Type menu. When Port1 Tx is enabled or disabled via Intfc1 Port1 Tx: Æ Ena/Dis (see next section), that status is reflected in this display:
• When Port1 Tx is enabled, the data rate associated with Port 1 is displayed, as shown in
the top example.
• When Port1 Tx is disabled, that status is reflected in this display, as shown in the bottom
example.
Press
ENTER to reveal the the following status menu:
6–25
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
Comp Tx Data/Sym Rate:
034.36800/23.484800 (E)
This display shows the Composite Tx Data Rate (Mbps) that is the sum of all enabled terrestrial ports. The Symbol Rate (Msps) is the IF Symbol Rate based on the Composite Data Rate, Overhead, Modulation, and Coding.
Press
ENTER or CLEAR to return to the previous menu.
If Intfc1 Port1 Tx: Æ Ena/Dis is selected:
Intfc1 Port1 Status Enable Disable (E)
This selection activates or deactivates the transmit (Tx) side of Port1. Disabling the Tx port
deactivates the port and changes the data rate to 0.
Select Enable or Disable using the
If Intfc1 Port1 E3/T3/STS1: Æ Rx is selected:
◄ ► arrow keys. Press ENTER.
Intfc1 Port 1 Rx: Alarms Inv Data Buf Clk Ena/Dis (E)
Select Alarms, Inv, Data, Buf, Clk or Ena/Dis using the
If Intfc1 Port1 Rx: Æ Alarms is selected:
◄ ► arrow keys. Press ENTER.
Intfc1 Port1 Rx Alarms: Rx-AIS Buffer-Slip (E)
Select Rx-AIS or Buffer-Slip, using the Fault condition. Press
If Intfc1 Port1 Rx Alarms: Æ Rx-AIS is selected:
ENTER.
◄ ► arrow keys, to configure either as an Alarm or
Rx-AIS Alarm: Alarm Fault Mask (E)
This selection will affect the event reporting status upon detection of a Rx AIS condition, and subsequently the switching logic, when the modem is in a 1:1 redundancy configuration.
Select Alarm, Fault, or Mask using the
◄ ► arrow keys. Press ENTER.
If Intfc1 Port1 Rx Alarms: Æ Buffer-Slip is selected:
6–26
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
Buffer Slip Alarm: Alarm Fault Mask (E)
This selection will affect the event reporting status upon detection of a Buffer Slip condition, and subsequently the switching logic, when the modem is in a 1:1 redundancy configuration.
Select Alarm, Fault, or Mask using the If Intfc1 Port1 Rx: Æ Inv is selected:
◄ ► arrow keys. Press ENTER.
Intfc1 Port 1 Rx Data: Normal Inverted (E)
This feature has been added for compatibility with certain older equipment. Select Normal or
Inverted, using the
If Intfc1 Port1 Rx: Æ Data is selected:
◄ ► arrow keys, to control data inversion. Press ENTER.
Intfc1 Port 1 Data Rate Rx: 34.368000 (E)
Intfc1 Port 1 Data Rate Rx: Disabled (E)
This is a ‘read only’ status window to display the data selected via the Intfc1 Port1: Æ Type menu. When Port1 Rx is enabled or disabled via Intfc1 Port1 Rx: Æ Ena/Dis (see next section), that status is reflected in this display:
• When Port1 Rx is enabled, the data rate associated with Port 1 is displayed, as shown in
the top example.
• When Port1 Rx is disabled, that status is reflected in this display, as shown in the bottom
example.
Press
ENTER to reveal the the following status menu:
Comp Rx Data/Sym Rate:
034.36800/23.484800 (E)
This display shows the Composite Rx Data Rate (Mbps) that is the sum of all enabled terrestrial ports. The Symbol Rate (Msps) is the IF Symbol Rate based on the Composite Data Rate, Overhead, Modulation, and Coding.
Press ENTER or CLEAR to return to the previous menu.
6–27
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
If Intfc1 Port1 Rx: Æ Buf is selected:
Intfc1 Port1 Rx Buffer: Frame-Type Size ReCenter
Select Frame-Type, Size, or Recenter using the ◄ ► arrow keys. Press ENTER.
If Intfc1 Port1 Rx Buffer: Æ Frame-Type is selected:
Intfc1 Port1 Rx Frame: G.751 (1536 Bits) ( E)
Select Frame-Type, Size, or Recenter using the ◄ ► arrow keys. Press ENTER.
The Frame Type and the number of bits in the frame displayed are dependent on the choice selected under Intfc1 Port1: Æ Type. In the above example, G.751 (1536 Bits) shows the frame when the Port Type is E3. The available Frame Type / (Bits) are as follows:
Selected Port Type (as displayed)
E3
T3
STS1
Frame Type (Frame Size, in bits, as displayed)
None - default G.751 (1536 Bits)
G.753 (2148 Bits)
None - default
G.752 (4760 Bits)
None - default STS-1 (6480 Bits)
The minimum buffer size is determined by the the number of bits in the frame and the maximum buffer size is based upon the integral number of frames that can fit in the buffer memory.
If Intfc1 Port1 Rx Buffer: Æ Size is selected:
Intfc1 Port1 Rx Buffer:
10.0 mSec (0344.064 Bits)( E)
Edit the Rx Buffer Size by selecting the digit to be edited, using the ◄ ► arrow keys. The value of the digit is then changed using the
▲ ▼ arrow keys. Press ENTER.
The Rx Buffer is programmed in 0.5 ms steps rounded to the increment closest to an integral number of bits based upon the Frame Type. The maximum buffer size is:
G.751 61 ms
G.752 44 ms
G.753 61 ms
STS-1 40 ms
The Rx buffer has a minimum value of 0.5 ms (default). Selecting the minimum value and programming Rx-CLK for Rx-SAT disables the buffer and sets it to minimum.
6–28
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
If Intfc1 Port1 Rx Buffer: Æ ReCenter is selected:
Intfc1 Port1 Rx Buffer: (65%) Re-Center (E)
The percentage (65%) indicates the current buffer fill status. Select Re-Center, using the arrow keys, to reset the buffer to the midpoint (50%). Press
ENTER.
◄ ►
If Intfc1 Port1 Rx Buffer: Æ Clk is selected:
Intfc1 Port1 Rx Clk: Rx-Sat Tx-Terr Ext-Clk
This selection determines which source clocks the output of the Rx Buffer for delivering data to the Rx port at the user interface.
Select Rx-Sat, Tx-Terr or Ext-Clk using the
◄ ► arrow keys. Press ENTER. The selections
are as follows:
Selection Description
Effectively disables the Rx Buffer because the input and output
Rx-Sat (default)
Tx-Terr
Ext-Clk
clocks are the same. Normally, the Rx Buffer is set for minimum when Rx-Sat is selected.
Uses the clock from the Tx input to clock out the Rx Buffer.
Derives a clock from a signal input to the Ext-Clk connector on the E3/T3/STS-1 Interface Card.
If Intfc1 Port1 Rx: Æ Ena/Dis is selected:
Intfc1 Port1 Rx Status Enable Disable (E)
This selection activates or deactivates the receive side of Port1. Disabling the Rx port deactivates
the port and changes the data rate to 0.
Select Enable or Disable using the
◄ ► arrow keys. Press ENTER.
6–29
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
Intfc1: Æ Port2
Intfc1 Port2 E3/T3/STS1: Type Line-Code Tx Rx (E)
Functionality for all submenus under (CONFIG:) Intfc1 Æ Port2 is identical to what has been outlined previously under (CONFIG:) Intfc1 Æ Port1. For a full explanation of all submenus under (CONFIG:) Intfc1 Æ Port2, refer to these previous sections.
Intfc1: Æ Ext-Clk
Intfc1 Ext-Clk Freq:
1.000 Mbps ( E)
Set the input frequency for the Ext-Clk connector on the E3/T3/STS-1 Interface Card by using the
▲ ▼ arrow keys. The Ext-Clk Frequency source selections are: 0 (None), 1, 2, 5, 10, 2.048,
34.368, 44.736, and 51.84 MHz. The input level ranges from 0.5 to 5.0 volts peak-to-peak.
Once the Ext-Clk input frequency has been edited, Press
ENTER.
6.3.1.4.1 (CONFIG:) Intfc2 (CDI-10 Dual G.703 Interface)
The CDM-700 can be configured with a second CDI-10 Dual G.703 Interface board plugged into interface Slot2 (Intfc2). The menus are identical to what is presented in 6.3.1.4 (CONFIG:) Intfc1 (CDI-10 Dual G.703 Interface) except that Intfc2, rather than Intfc1, is displayed in all menus.
6–30
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
6.3.1.5 (CONFIG:) Intfc1 (CDI-50 OC-3 Interface)
The menus depicted in this section pertain to the CDI-50 OC-3 Optical and STM-1 Copper Interface.
Intfc1 OC-3: Tx Rx Mode ( E)
Select Tx, Rx or Mode using the ◄ ► arrow keys. Press ENTER.
Intfc1 OC-3: Æ Tx
Intfc1 OC-3 Tx: Data Ena/Dis ( E)
Select Data or Ena/Dis using the ◄ ► arrow keys. Press ENTER.
If Intfc1 OC-3 Tx: Æ Data is selected:
Intfc1 Tx Data Rate:
155.520000 Mbps (E)
Intfc1 Tx Data Rate: Disabled (E)
This is a ‘read only’ status window to display the data rate of the interface. When the Tx side of this interface is enabled or disabled via Intfc1 OC-3 Tx: Æ Ena/Dis (see next section), that status is reflected in this display:
• When Tx is enabled, the data rate of the interface is displayed, as shown in the top
example.
• When Tx is disabled, that status is reflected in this display, as shown in the bottom
example.
Press
ENTER or CLEAR to return to the previous menu.
If Intfc1 OC-3 Tx: Æ Ena/Dis is selected:
Intfc1 Tx Status: Enable Disable (E)
This selection activates or deactivates the transmit (Tx) side of this interface. Disabling the Tx
side deactivates it and changes the data rate to 0.
Select Enable or Disable using the Note: Disabling the Tx side will also turn off the output power.
6–31
◄ ► arrow keys. Press ENTER.
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
Intfc1 OC-3: Æ Rx
Intfc1 OC-3 Rx: Data Buf Clk Ena/Dis ( E)
Select Data, Buf, Clk, or Ena/Dis using the
If Intfc1 OC-3 Rx: Æ Data is selected:
Intfc1 Rx Data Rate:
155.520000 Mbps (E)
Intfc1 Rx Data Rate: Disabled (E)
This is a ‘read only’ status window to display the data rate of the interface. When the Rx side of this interface is enabled or disabled via Intfc1 OC-3 Rx: Æ Ena/Dis (see section on pg. 6-3x), that status is reflected in this display:
◄ ► arrow keys. Press ENTER.
• When Rx is enabled, the data rate of the interface is displayed, as shown in the top
example.
• When Rx is disabled, that status is reflected in this display, as shown in the bottom
example.
Press
ENTER or CLEAR to return to the previous menu.
If Intfc1 OC-3 Rx: Æ Buf is selected:
Intfc1 Rx Buffer: Size ReCenter (E)
Select Size or ReCenter using the
If Intfc1 Rx Buffer: Æ Size is selected:
◄ ► arrow keys. Press ENTER.
Intfc1 Rx Buffer Size:
10.0 mSec (1555.200 Bits) (E)
Edit the Rx Buffer Size by selecting the digit to be edited, using the of the digit is then changed using the mSec. Press
ENTER.
▲ ▼ arrow keys. The range of values is from 00.0 to 26.0
◄ ► arrow keys. The value
6–32
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
If Intfc1 Rx Buffer: Æ ReCenter is selected:
Intfc1 Buffer Fill: (046%) ReCenter (E)
The percentage (046%) indicates the current buffer fill status. Select Re-Center, using the arrow keys, to reset the buffer to the midpoint (50%). Press
ENTER.
◄ ►
If Intfc1 OC-3 Rx: Æ Clk is selected:
Intfc1 Rx Clock: Rx-Sat Tx-Terr Internal (E)
This selection determines which source clocks the output of the Rx Buffer for delivering data to the Rx port at the user interface.
Select Rx-Sat, Tx-Terr or Internal using the are as follows:
◄ ► arrow keys. Press ENTER. The selections
Selection Description
Effectively disables the Rx Buffer because the input and output
Rx-Sat (default)
Tx-Terr
Internal
clocks are the same. Normally, the Rx Buffer is set for minimum when Rx-Sat is selected.
Uses the clock from the Tx input to clock out the Rx Buffer.
The Internal Clock comes from the modem. It is derived from either the Ext Ref (J7) or Int Ref oscillator (10 MHz) in the main part of the
modem, not from the data interface.
If Intfc1 OC-3 Rx: Æ Ena/Dis is selected:
Intfc1 Rx Status: Enable Disable (E)
This selection activates or deactivates the receive (Rx) side of this interface. Disabling the Rx
side deactivates it and changes the data rate to 0.
Select Enable or Disable using the
If Intfc1 OC-3 Rx: Æ Mode is selected:
◄ ► arrow keys. Press ENTER.
Intfc1 Line Mode: Optical Coax (E)
Select Optical or Coax using the ◄ ► arrow keys. Press ENTER.
6–33
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
6.3.1.6 (CONFIG:) Intfc1 (CDI-60 HSSI Interface)
The menus depicted in this section pertain to theCDI-60 HSSI Interface installed in Slot1. The CDM-700 supports either a single HSSI Interface (Intfc1) or Dual HSSI interfaces (Intfc1 and Intfc2). The menus for Intfc2 are identical to what is presented in this section, except that Intfc2, rather than Intfc1, is displayed in all menus.
Intfc1 HSSI: Tx Rx CTS/RTS Alarm (E)
There is a single port on an CDI-60 HSSI Interface. Select Tx, Rx, CTS/RTS, or Alarm using the
◄ ► arrow keys. Press ENTER.
Intfc1 HSSI: Æ Tx
Intfc1 Tx: Data Clock Enable ( E)
Select Data, Clock, or Enable using the ◄ ► arrow keys. Press ENTER.
If Intfc1 Tx: Æ Data is selected:
Intfc1 Tx Data: Datarate Invert ( E)
Select Datarate or Invert using the ◄ ► arrow keys. Press ENTER.
If Intfc1 Tx Data: Æ Datarate is selected:
Intfc1 Data Rate: Tx:032.000000 Mbps (▲ ▼ E)
Edit the Tx Data Rate by selecting the digit to be edited, using the ◄ ► arrow keys. The value of the digit is then changed using the Mbps. Note that the modem Symbol Rate limits of 1.0 to 64.0 Msps makes some choices of Modulation Type, FEC Coding and Data Rate selection invalid. Once the Tx Data Rate is edited, Press
ENTER.
If Intfc1 Tx Data: Æ Invert is selected:
▲ ▼ arrow keys. The range of values is from 1.0 to 70.0
Intfc1 Tx Data: Normal Inverted ( E)
This feature has been added for compatibility with certain older equipment. Select Normal or
Inverted, using the
6–34
◄ ► arrow keys, to control data inversion. Press ENTER.
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
If Intfc1 Tx: Æ Clock is selected:
Intfc1 Tx Clock: Normal Inverted ( E)
This feature has been added for compatibility with certain older equipment. Select Normal or
Inverted, using the
If Intfc1 Tx: Æ Enable is selected:
◄ ► arrow keys, to control clock inversion. Press ENTER.
Intfc1 Tx Enable: Enable Disable ( E)
This selection activates or deactivates the transmit (Tx) side of this interface. Disabling the Tx
side deactivates it and changes the data rate to 0.
Select Enable or Disable using the
◄ ► arrow keys. Press ENTER.
Intfc1 HSSI: Æ Rx
Intfc1 Rx: Data Buffer Clock Enable
Select Data, Buffer, Clock, or Enable using the
If Intfc1 Rx: Æ Data is selected:
Intfc1 Tx Data: Datarate Invert ( E)
Select Datarate or Invert using the
If Intfc1 Rx Data: Æ Datarate is selected:
◄ ► arrow keys. Press ENTER.
Intfc1 Data Rate: Rx:032.000000 Mbps
Edit the Rx Data Rate by selecting the digit to be edited, using the of the digit is then changed using the Mbps. Note that the modem Symbol Rate limits of 1.0 to 64.0 Msps makes some choices of Modulation Type, FEC Coding and Data Rate selection invalid.
Once the Rx Data Rate is edited, Press
▲ ▼ arrow keys. The range of values is from 1.0 to 70.0
ENTER.
◄ ► arrow keys. Press ENTER.
◄ ► arrow keys. The value
6–35
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
If Intfc1 Rx Data: Æ Invert is selected:
Intfc1 Rx Data Invert: Normal Inverted ( E)
This feature has been added for compatibility with certain older equipment. Select Normal or
Inverted, using the
If Intfc1 Rx: Æ Buffer is selected:
◄ ► arrow keys, to control data inversion. Press ENTER.
Intfc1 Rx Buffer: Size ReCenter (E)
Select Size or ReCenter using the
If Intfc1 Rx Buffer: Æ Size is selected:
◄ ► arrow keys. Press ENTER.
Intfc1 Rx Buffer Size:
10.0 mSec (0343.680 Bits)
Edit the Rx Buffer Size by selecting the digit to be edited, using the ◄ ► arrow keys. The value of the digit is then changed using the mSecs in 0.1 mSec increments. Press
If Intfc1 Rx Buffer: Æ ReCenter is selected:
▲ ▼ arrow keys. The range of values is from 5.0 to 32.0
ENTER.
Intfc1 Buffer Fill: (046%) ReCenter (E)
The percentage (046%) indicates the current buffer fill status. Select ReCenter, using the ◄ ► arrow keys, to reset the buffer to the midpoint (50%). Press
If Intfc1 Rx: Æ Clock is selected:
ENTER.
Intfc1 Rx Clock: Source Invert (E)
Select Source or Invert using the ◄ ► arrow keys. Press ENTER. The selections are as follows:
6–36
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
If Intfc1 Rx Clock: Æ Source is selected:
Intfc1 Rx Clock: Rx-Sat Tx-Terr Internal
This selection determines which source clocks the output of the Rx Buffer for delivering data to the Rx port at the user interface.
Select Rx-Sat, Tx-Terr or Internal using the are as follows:
Selection Description
Effectively disables the Rx Buffer because the input and output
Rx-Sat (default)
Tx-Terr Internal
If Intfc1 Rx Clock: Æ Invert is selected:
clocks are the same. Normally, the Rx Buffer is set for minimum when Rx-Sat is selected.
Uses the clock from the Tx input (TT) to clock out the Rx Buffer.
Derives a clock from the internal 10 Mhz reference clock.
◄ ► arrow keys. Press ENTER. The selections
Intfc1 Rx Data Invert: Normal Inverted ( E)
This feature has been added for compatibility with certain older equipment. Select Normal or
Inverted, using the
If Intfc1 Rx: Æ Enable is selected:
◄ ► arrow keys, to control clock inversion. Press ENTER.
Intfc1 Rx Enable: Enable Disable (E)
This selection activates or deactivates the receive (Rx) side of this interface. Disabling the Rx
side deactivates it and changes the data rate to 0.
Select Enable or Disable using the
◄ ► arrow keys. Press ENTER.
Intfc1 HSSI: Æ CTS/RTS
Intfc1 CTS/RTS: Normal Fault (E)
Select Normal or Fault using the
6–37
◄ ► arrow keys. Press ENTER.
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
RTS is the same as TA, and CTS is the same as CA. The selections operate as follows:
Selection Description
Normal
Fault
CTS = RTS
CTS = RTS when no fault is present. CTS is not asserted when a fault is present
Intfc1 HSSI: Æ Alarm
Intfc1 Ext-Clock Alarm: Alarm Fault Mask ( E)
Ext-Clock Alarm is the alarm generated for the HSSI Tx Clock .Alarm when the HSSI Cable is disconnected or faulty.
Select Alarm, Fault, or Mask using the
◄ ► arrow keys. Press ENTER.
6.3.1.6.1 (CONFIG:) Intfc2 (CDI-60 HSSI Interface)
The CDM-700 can be configured with a second CDI-60 HSSI interface board plugged into interface Slot2 (Intfc2). The menus are identical to what is presented in 6.3.1.6 (CONFIG:) Intfc1 (CDI-60 HSSI Interface) except that Intfc2, rather than Intfc1, is displayed in all menus.
6.3.1.7 (CONFIG:) Intfc1 (CDI-70 Gigabit Ethernet Interface)
There is a single RJ-45 port on the CDI-70 Gigabit Ethernet Interface.
The menus depicted in this section pertain to the CDI-70 Gigabit Ethernet Interface installed in Slot1. The CDM-700 supports either a single Gigabit Ethernet Interface (Intfc1) or Dual Gigabit Ethernet interfaces (Intfc1 and Intfc2). The menus for Intfc2 are identical to what is presented in this section except that Intfc2, rather than Intfc1, is displayed in all menus.
Intfc1 Gigabit Ethernet: Tx Rx Man Stats SWOP NEG(E)
Select Tx, Rx, Man, Stats, SWOP (Swith Operation), or NEG (Negotiation) using the ◄ ► arrow keys. Press
6–38
ENTER.
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
Intfc1 Gigabit Ethernet: Æ Tx
Intfc1 Tx: Data Enable Alarm (E)
Select Data, Enable, or Alarm using the ◄ ► arrow keys. Press ENTER.
If Intfc1 Tx: Æ Data is selected:
Intfc1 Data Rate: Tx:075.000000 Mbps (E)
Intfc1 Data Rate: Tx: Disabled (E)
Edit the Tx Data Rate by selecting the digit to be edited, using the ◄ ► arrow keys. The value of the digit is then changed using the Mbps.
▲ ▼ arrow keys. The range of values is from 1.0 to 155.0
Note that the modem Symbol Rate limits of 1.0 to 64.0 Msps makes some choices of Modulation Type, FEC Coding and Data Rate selection invalid. Once the Tx Data Rate is edited, Press
ENTER.
If Tx: Disabled is displayed, the port is turned Off (0 Mbps).
If Intfc1 Tx: Æ Enable is selected:
Intfc1 Tx Enable: Enable Disable (E)
This selection activates or deactivates the transmit (Tx) side of this interface. Disabling the Tx
side deactivates it and changes the data rate to 0.
Select Enable or Disable using the
If Intfc1 Tx: Æ Alarm is selected:
◄ ► arrow keys. Press ENTER.
GBEI Tx Cable Alarm: Alarm Fault Mask (E)
This selection will affect the event reporting status upon detection of loss of GBEI Cable.
Select Alarm, Fault, or Mask using the
◄ ► arrow keys. Press ENTER.
6–39
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
Intfc1 Gigabit Ethernet: Æ Rx
Intfc1 Rx: Data Enable ( E)
Select Data or Enable using the
If Intfc1 Rx: Æ Data is selected:
Intfc1 Data Rate: Rx:075.000000 Mbps (E)
Intfc1 Data Rate: Rx:Disabled (E)
Edit the Rx Data Rate by selecting the digit to be edited, using the of the digit is then changed using the Mbps. Note that the modem Symbol Rate limits of 1.0 to 64.0 Msps makes some choices of Modulation Type, FEC Coding and Data Rate selection invalid. Once the Rx Data Rate is edited, Press
ENTER.
If Rx: Disabled is displayed, the port is turned Off (0 Mbps).
◄ ► arrow keys. Press ENTER.
◄ ► arrow keys. The value
▲ ▼ arrow keys. The range of values is from 1.0 to 155.0
If Intfc1 Rx: Æ Enable is selected:
Intfc1 Rx Enable: Enable Disable (E)
This selection activates or deactivates the receive (Rx) side of this interface. Disabling the Rx
side deactivates it and changes the data rate to 0.
Select Enable or Disable using the ◄ ► arrow keys. Press
ENTER.
6–40
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
Intfc1 Gigabit Ethernet: Æ Man
Intfc1 Management IP:
192.168.001.001/30 (▲ ▼ E)
Edit the Gigabit Ethernet Interface Management IP Address and Mask Range by selecting the digit to be edited, using the ◄ ► arrow keys. The value of the digit is then changed using the ▲ ▼ arrow keys.
This is the IP address that can be used for 1 of 2 purposes:
• First, PING can be used with this IP address as a diagnostic tool to ensure the
interface is active and the external cabling in properly connected.
• Second, this is the IP address that will be used in the event that new firmware is
provided by CEFD for the CDI-70 Gigabit Ethernet interface.
Once the Gigabit Ethernet Interface Management IP Address and Mask Range are edited, Press
ENTER.
Intfc1 Gigabit Ethernet: Æ Stats
Intfc1 Statistics: View Clear (E)
Select View or Clear using the ◄ ► arrow keys. Press ENTER.
If Intfc1 Statistics: Æ View is selected:
FPGA Link Errors 00000000000000000000 (▲ ▼ E)
Use the ▲ ▼ arrow keys to scroll through the available statistics and counters.
6–41
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
The statistics for the Gigabit Ethernet Interface are shown in the following table:
GBEI Statistics Summary
Category Message Description
1000Base-T Link Statistics
FPGA Statistics
1000Base-T Link Statistics (cont)
LAN Statistics
FPGA Link Errors Indicates the number of HDLC link errors that have occurred on
the Rx WAN interface. This error would most likely occur if there are errors in the received signal from the satellite resulting in corrupted frames.
FPGA Overrun Errors Indicates the number of times that a GBEI buffer overrun has
occurred in the Rx direction (WAN to the LAN). This error would most likely occur if there are errors in the received signal from the satellite resulting in a corrupted framing structure.
FPGA Rx Packet Count Indicates the number of Ethernet packets received from the WAN FPGA Overflow Errors
v3.1.0 and earlier
FPGA Overflow Errors v3.1.1 and later
FPGA Tx Packet Count Indicates the number of Ethernet frames transmitted to the WAN LAN Good Octets (In) The sum of lengths of all good Ethernet frames received from the
LAN Bad Octets (In) The sum of lengths of all bad Ethernet frames received from the LAN
LAN Unicast (In)
LAN Broadcast (In)
LAN Multicast (In)
LAN Pause (In) The number of good flow control frames received from the LAN
LAN Collisions (In) The sum of collisions detected on the LAN
LAN Undersize (In) Removed, V1.3.1 and later
LAN Fragments (In)
LAN Oversize (In)
LAN Discards (In)
LAN Jabber (In) Removed, V1.3.1 and later
LAN Rx Err (In)
LAN FCS Err (In)
LAN Octets (Out) The sum of the lengths of all Ethernet frames transmitted to the LAN
LAN Unicast (Out)
LAN Broadcast (Out)
LAN Multicast (Out)
Indicates the number of times this error is likely to occur if the LAN traffic to the modem exceeds that which can be HDLC encapsulated per the configured modem data rate.
For debug only
LAN
The sum of good frames received from the LAN that have a unicast destination MAC address
The sum of good frames received from the LAN that have a broadcast destination MAC address
The sum of good frames received from the LAN that have a multicast destination MAC address
Total frames received from the LAN with a length of less than 64 octets and an invalid FCS
Total frames received form the LAN with a length greater than the maximum size of octets but with a valid FCS
A count of the number of incoming packets from the LAN to GBEI card that are overflowing the Tx Buffer and discarded
Total frames received from the LAN for which an error was detected at the PHY
Total frames received from the LAN with a CRC error which was not counted in the Fragments or Rx Err totals
The sum of frames transmitted to the LAN that have a unicast destination MAC address
The sum of frames transmitted to the LAN that have a broadcast destination MAC address
The sum of frames transmitted to the LAN that have a multicast destination MAC address
6–42
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
GBEI Statistics Summary
Category Message Description
1000Base-T Link Statistics (cont)
WAN Port Statistics
WAN Good Octets (In) The sum of lengths of all good Ethernet received from the WAN
WAN Bad Octets (In) The sum of lengths of all bad Ethernet received from the WAN
WAN Unicast (In)
WAN Broadcast (In)
WAN Multicast (In)
WAN Pause (In) The number of good flow control frames received from the WAN
WAN Undersize (In) Removed, V1.3.1 and later
WAN Collisions (In) The sum of collisions detected on the WAN
WAN Fragments (In)
WAN Oversize (In)
WAN Discards (In)
WAN Jabber (In) Removed, V1.3.1 and later
WAN Rx Error (In)
WAN FCS Error (In)
WAN Octets (Out)
WAN Unicast (Out)
WAN Broadcast (Out)
WAN Multicast (Out)
The sum of good frames received from the WAN that have a unicast destination MAC address
The sum of good frames received from the WAN that have a broadcast destination MAC address
The sum of good frames received from the WAN that have a multicast destination MAC address
Total frames received from the WAN with a length of less than 64 octets and an invalid FCS
Total frames received form the WAN with a length greater than the maximum size of octets but with a valid FCS
The number of packets from the WAN that have been discarded due to GBEI switch congestion
Total frames received from the WAN for which an error was detected at the PHY
Total frames received from the WAN with a CRC error which was not counted in the Fragments or Rx Err totals
The sum of the lengths of all Ethernet frames which are forwarded for transmission to the WAN
The number of good frames with unicast destination MAC addresses which are for transmission to the WAN
The number of good frames with broadcast destination MAC addresses which are forwarded for transmission to the WAN
The number of good frames with multicast destination MAC addresses which are forwarded for transmission to the WAN
WAN Good Octets (IN) The sum of lengths of all good Ethernet received from the WAN
WAN Unicast (IN)
WAN Broadcast (IN)
WAN Multicast (IN)
1000Base-T Link Statistics (cont)
Mng (Management) Statistics
6–43
Mng Good Octets (In)
Mng Bad Octets (In)
Mng Unicast (In)
Mng Broadcast (In)
Mng Multicast (In)
Mng Pause (In)
The sum of good frames received from the WAN that have a unicast destination MAC address
The sum of good frames received from the WAN that have a broadcast destination MAC address
The sum of good frames received from the WAN that have a multicast destination MAC address
The sum of lengths of all good Ethernet frames received from the local GBEI management processor
The sum of lengths of all bad Ethernet frames received from local GBEI management processor
The sum of good frames received from the local GBEI management processor that have a unicast destination MAC address
The sum of good frames received from the local GBEI management processor that have a broadcast destination MAC address
The sum of good frames received from the local GBEI management processor that have a multicast destination MAC address
The number of good flow control frames received from local GBEI management processor
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
GBEI Statistics Summary
Category Message Description
Mng Undersize (In) Removed, V1.3.1 and later
Mng Collisions (In) The sum of collisions detected on the WAN
Mng Fragments (In)
Mng Oversize (In)
Mng Jabber (In) Removed, V1.3.1 and later
Mng Discards (In)
Mng Rx Err (In)
Mng FCS Err (In)
Mng Octets (Out)
Mng Unicast (Out)
Mng Broadcast (Out)
Mng Multicast (Out)
Total frames received from the local GBEI management processor with a length of less than 64 octets and an invalid FCS
Total frames received form the local GBEI management processor with a length greater than the maximum size of octets but with a valid FCS
The number of management processor packets that have been discarded due to GBEI switch congestion
Total frames received from the local GBEI management processor for which an error was detected by its physical interface
Total frames received from the local GBEI management processor with a CRC error which was not counted in the Fragments or Rx Err totals
The sum of the lengths of all Ethernet frames transmitted to the local GBEI management processor
The sum of frames transmitted to the local GBEI management processor that have a unicast destination MAC address
The sum of frames transmitted to the local GBEI management processor that have a broadcast destination MAC address
The sum of frames transmitted to the local GBEI management processor that have a multicast destination MAC address
Intfc1 Gigabit Ethernet: Æ SWOP (Switch Operat ion)
Intfc1 SWOP: AutoCx Learning Mode (efE)
This section describes the menu selections for setting up VLAN operation when SWOP (Sw
eration) is selected from the (CONFIG:) Intfc1 Gigabit Ethernet: menu.
Op
Select AutoCx, Learning, or Mode using the
If Intfc1 SWOP: Æ AutoCx is selected:
Intfc1 Auto Crossover: Enable Disable (E)
If enabled, the Gigabit Ethernet Interface automatically detects the type of connection and configures the interface appropriately as straight-through (MDI) or crossover (MDIX).
If disabled, the Gigabit Ethernet port is configured as straight-through (MDI).
Select Enable or Disable using the ◄ ► arrow keys. Press
◄ ► arrow keys. Press ENTER.
ENTER.
itch
6–44
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
If Intfc1 SWOP: Æ Learning is selected:
Intfc1 Learning: Enable Disable (E)
IMPORTANT
Unit power must be cycled whenever Learning mode is enabled or disabled.
Learning is an Ethernet switch function that allows the LAN (user) side of the Gigabit Ethernet port to learn the MAC addresses of the equipment connected to the Gigabit port.
Learning applies only to the LAN (user) side of the port. There is no learning on the WAN (modem) side of the Gigabit Ethernet port.
If enabled, the interface is in LAN-to-WAN learning mode, and the GBEI learns connections based on
source MAC addresses and ingress ports. The hub thinks the remote site network nodes are local to the hub site network and does not send the traffic over the outbound carrier to the remote site.
If disabled, the GBEI passes all packets from the LAN to the WAN.
Select Enable or Disable using the ◄ ► arrow keys. Press
If Intfc1 SWOP: Æ Mode is selected:
ENTER, then cycle the unit power.
Intfc1 Switch Mode: Normal VLAN (E)
The unit supports two mode of operation: Normal and VLAN. Select Normal or VLAN using the ◄ ► arrow keys. Press
ENTER.
If Normal is selected, all packets pass unchanged, including VLAN tagged packets [Simple Bridge]. Once
ENTER is pressed, the previous menu returns.
If Intfc1 Switch Mode:Æ VLAN is selected:
VLANID Attribute 0001 NATIVE Add
VLANs can be configured on the unit. The user may add 32 VLANs with IDs from 1 to 4094.
6–45
CDM-700 High Speed Satellite Modem Revision 5 Front Panel Operation MN/CDM700.IOM
The following attributes are supported for association with each VLAN:
VLAN Tag Direction Comment
Only one per port. Only applies to packets from the
1… 4094 N - Native Lan Æ WAN
LAN. Management traffic is specified by the Management Port PVID.
END Æ LAN
1… 4094 M - Management
1…4094 T - Tagged
1… 4094 U - Untagged WAN Æ LAN
To scroll active VLANs on the front panel, use the bc arrow keys. Information is displayed per the following table:
VLAN Attribute Remarks
0001 Native Add
0001 Management Add
VLAN ID = n Tagged/Untagged Delete
END Æ WAN LAN Æ END WAN Æ END
WAN Æ LAN LAN Æ WAN
Only one per table. Defaults to 1 and can be changed to any valid entry. Will strip all packets going to the Endstation and will add the appropriate tag entry for all packets leaving the Endstation.
If the VLAN of the packet arriving from the WAN or LAN matches the VLAN tag, the packet passes unchanged.
Configuring a VLAN with this attribute will identify the LAN port as a member of the VLAN. The LAN frame will be removed and the packet will go out untagged.
To Edit the VLAN ID of NATIVE VLANs:
VLANID Attribute 0001 NATIVE Add
• Use the bc arrow keys to toggle between MNGMENT and NATIVE;
• Press ENTER;
• Use the bc arrow keys to change the NATIVE VLAN ID (on the bottom left of the display).
6–46
