Compaq iPaq MP2810
Roughly the size of a day planner, the iPAQ MP2810 weighs just 3
pounds and stands as one of the world's smallest projectors at 118
cubic inches. Featuring the distinct tower design found on all
Compaq microportable projectors, the MP2810 goes beyond size to
deliver stunning, multi-media presentations in even the most
space-constrained environments. Utilizing the latest in Texas
Instruments Digital Light Processing (DLP) and Pixelworks
technologies, the MP2810 autosynchs with any PC, features
plug-and-present ease of use, offers an onscreen menu for easy
adjustments and displays 1024x768 XGA resolution at a brightness
of 1100 lumens. A true multimedia device, the Compaq MP2810 is
compatible with VCR, DVD and HDTV equipment, features a manual
zoom lens, standard 8-watt Premier · Sound Speaker system and
multi-function remote control.
www.dooyoo.co.uk :: Video :: Projector :: Compaq iPaq MP2810
General
Device Type DLP Projector - portable
Width 6.9 cm
Depth 22.1 cm
Height 18.1 cm
Weight 1.4 kg
Localisation Europe
Copyright © 2006 dooyoo AG www.dooyoo.co.uk
Projector / Panel
Image Brightness 1100 ANSI lumens
Image Contrast Ratio 500:1
Image Aspect Ratio 2.40:1
Image Size 0.6 m - 6.2 m
Projection Distance 1.1 m - 10 m
Uniformity 70 %
Digital Zoom Factor 32x
Max Resolution 1024 x 768 (native) / 1280 x 1024 (compressed)
Colour support 24-bit (16.7 million colours)
Max Sync Rate (V x H) 85 Hz x 80 kHz
Factory Preset Resolution Modes 640 x 350 / 70 Hz ¦ 640 x 350 / 85 Hz ¦ 640 x 480 / 60 Hz
¦ 640 x 480 / 72 Hz ¦ 640 x 480 / 75 Hz ¦ 640 x 480 / 85
Hz ¦ 720 x 400 / 70 Hz ¦ 720 x 400 / 85 Hz ¦ 800 x 600 /
56 Hz ¦ 800 x 600 / 60 Hz ¦ 800 x 600 / 72 Hz ¦ 800 x 600
/ 75 Hz ¦ 800 x 600 / 85 Hz ¦ 832 x 624 / 75 Hz ¦ 1152 x
870 / 75 Hz ¦ 1024 x 768 / 43.4 Hz ¦ 1024 x 768 / 60 Hz ¦
1024 x 768 / 70 Hz ¦ 1024 x 768 / 75 Hz ¦ 1024 x 768 / 85
Hz ¦ 1280 x 1024 / 60 Hz ¦ 1280 x 1024 / 75 Hz ¦ 1280 x
720 / 60 Hz ¦ 1920 x 1080 / 30 Hz
Bulb type 130 Watt
Bulb life cycle 1500 hour(s)
Controls / Adjustments Brightness, contrast, H/V position, input select, colour t
emperature, keystone correction, zoom
OSD Languages English, German, French, Italian, Spanish, Dutch,
Japanese, Chinese
Compliant Standards UL, TUV, FCC-B, CE, CISPR22 Class A, VDE Class B
Projector Lens System
Zoom Factor 1.2x
Video Input
Analogue Video Format NTSC, PAL
Analogue video Signal RGB, S-Video, composite video
Digital Video Format HDTV
Copyright © 2006 dooyoo AG www.dooyoo.co.uk
Audio Output
Type Speaker(s) - external
Sound Output Mode Mono
Audio Amplifier Integrated
Output Power / Channel 8 Watt
Speaker(s) 1 x mixed channel
Input Device
Type Remote control - external - wireless
Expansion / Connectivity
Connections 1 x display / video - VGA - 15 pin HD D-Sub (HD-15) - 1 ¦
1 x display / video - DVI-Digital - 24 pin digital DVI - 1
¦ 1 x display / video - S-video output - 4 PIN mini-DIN 1 ¦ 1 x display / video - composite video output - RCA 1 ¦ 1 x serial - 0 ¦ 1 x serial - RS-232 - 9 pin D-Sub
(DB-9) - 1 ¦ 1 x USB - 4 PIN USB Type A - 1 ¦ 1 x audio line-In - mini-phone stereo 3.5 mm - 1
Miscellaneous
Included Accessories Carrying case
Cables Included 1 x serial adapter
Compliant Standards Plug and Play
Power
Power Device Power supply - integrated
Voltage Required AC 110/220 V ± 16% ( 50/60 Hz )
Power Consumption Operational 185 Watt
Compliant Standards EPA Energy Star
Software / System Requirements
Software Included Drivers & Utilities
Manufacturer Warranty
Service & Support 2 years warranty
Service & Support Details Limited warranty - replacement - 2 years - carry-in - resp
onse time: 2 days
Copyright © 2006 dooyoo AG www.dooyoo.co.uk
Environmental Parameters
Min Operating Temperature 10 °C
Max Operating Temperature 40 °C
Humidity Range Operating 20 - 80%
Copyright © 2006 dooyoo AG www.dooyoo.co.uk
