Compal LA-5912P, Aspire 5251, Aspire 5552, Aspire 5552G, eMachines E440 Schematic

A

1 1

B

C

D

E

Compal Confidential

2 2

NEWX5 / PEW56 M/B Schematics Document

AMD Danube Only UMA

AMD Champlain Processor with RS880M/SB820M

3 3

2010-06-17

LA5912P REV: 1.0

4 4

Security Classification

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

A

B

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

C

2009/10/06 2010/03/12

Compal Secret Data

Deciphered Date

Compal Electronics, Inc.

Title

Size Document Number Rev

B

Date: Sheet of

D

Date: Sheet of

Compal Electronics, Inc.

SCHEMATICS, MB A5912

401829

145Wednesday, June 30, 2010

E

C

A

B

C

D

E

Danube

Compal Confidential

Model Name : NEWX5 / PEW56 File Name : LA-5912P P/N : DA60000FZ10

1 1

LVDS

page 16

CRT

page 18

AMD S1G4 Processor

uPGA-638 Package Champlain

page 6,7,8,9

Hyper Transport Link 16 x 16

ATI RS880M

uFCBGA-528

page 12,13,14

Memory BUS(DDR3)

Dual Channel

1.5V DDRIII 1066~1333MHz

Thermal Sensor

ADM1032

page 28 page 16 page 28 page 27

204pin DDRIII-SO-DIMM X2

BANK 0, 1, 2, 3

Clock Generator

page 8 page 15

ICS9LPRS488

page 10,11

page 28

HDMI Conn.

page 17

2 2

MINI Card 1

WLAN

page 36

LAN(GbE)

Broadcom BCM57780

page 25

A link Express2

Gen1

ATI SB820M

uFCBGA-605

page 19,20,21,22,23

USB conn X 3

USB port 0,1,2

3.3V 48MHz

3.3V 24.576MHz/48Mhz

S-ATA

Gen2

CMOS Camera

USB port 5 USB port 12 USB port 8

Bluetooth Conn

USB

HD Audio

GPP0GPP1

RJ45

page 26

LED

3 3

page 30

RTC CKT.

page 19

LID SW / MEDIA/B

page 30

Fan Control

page 33

Extend Card/B

1. USB X2

2. Cardreader

Touch Pad

EC I/O Buffer

ENE KB926

page 30

LPC BUS

page 29

Int.KBD

BIOS

SATA HDD Conn.

port 0

page 30

page 24

SATA ODD Conn.

page 24

port 1

RTS5160

w/ 5IN1 Conn.

Power On/Off CKT.

page 33

w/ 2IN1 Conn.

DC/DC Interface CKT.

4 4

page 34

Mini card (WL)X1

HDA Codec ALC272X

page 31

Audio AMP

page 32

Phone Jack x2

page 32

PCB

ZZZ

LA-5912P REV1 M/B

LA-5912P REV1 M/B NEWX5@

NEWX5@

ZZZ1

LA-5912P REV1 M/B

LA-5912P REV1 M/B PEW56@

PEW56@

3G/GPS WWAN

Card Reader

USB port 9

USB port 6

NEWX5

LA-5912P MB Rev1: DA60000FZ10 LA-5912P MB DAZ0C600100

PEW56

LA-5912P MB Rev1: DA60000FZ10 LA-5912P MB DAZ0GJ00100

Power Circuit

page 35,36,37,38,39,40, 41,42,43

A

Security Classification

Issued Date

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL

THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D

AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS

DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

B

MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.

C

2009/10/06 2010/03/12

Compal Secret Data

Deciphered Date

Compal Electronics, Inc.

Title

Size Document Number Rev

B

Date: Sheet of

D

Date: Sheet of

Compal Electronics, Inc.

SCHEMATICS, MB A5912
