Coby Communications MID8048-8047 User Manual
DE
Coby® Kyros® Internet Tablet
Schnellstartanleitung .......................................... Seite2
Für Serie /
For series /
Pour la série
MID8048
Coby® Kyros® Internet Tablet
EN
FR
• Vor Gebrauch bitte sorgfältig lesen • Please read carefully before use
• Veuillez lire ce livret avant utilisation
Quick Start Guide .............................................. Page 43
Tablette Internet à Ecran Tactile
Guide de Démarrage Rapide ................................ Page 83
Â
Table of Contents
THANK YOU ...................................................44
Package Contents ..................................................... 44
Features....................................................................... 45
GETTING TO KNOW THE INTERNET TABLET ...46
About the Touchscreen .............................................49
Protective Film ......................................................49
Touchscreen Actions............................................49
About the Orientation Sensor ...................................51
Charging the Tablet ...................................................51
Inserting a Memory Card .........................................52
GETTING STARTED .........................................54
Turning the Tablet on and off .................................. 54
Turning the Screen On and Off (Standby) ...... 55
Unlocking the Screen ......................................... 55
About Applications ....................................................57
Preinstalled Applications .................................... 58
Installing Applications .........................................59
About Widgets ........................................................... 60
Adding Widgets to a Home Screen .................. 60
Removing Widgets .............................................. 60
About Notications .................................................... 60
CONNECTING TO THE INTERNET .................. 62
Requirements ..............................................................62
Connect to a Wi-Fi network ..................................... 63
BROWSING THE WEB .....................................65
Browser menu ..............................................................67
MANAGING APPLICATIONS ........................69
OPTIONAL CONNECTIONS ..........................72
Connecting to a Computer ......................................72
Connecting to a TV ....................................................73
Connecting Headphones (Optional) ......................74
Using the USB Full-Size Adapter (Optional) ............. 74
Connecting a Keyboard .....................................75
Connecting a Storage Device ...........................75
SETTING THE SYSTEM OPTIONS ....................76
SPECIFICATIONS ...........................................77
SUPPORT ........................................................78
SAFETY NOTICES ...........................................79
English
Page 43 Table Of Contents
Â
Thank You
Congratulations on your purchase of a Coby® Kyros®
Internet Tablet. This guide is provided to help you get
English
started quickly with your player; please read it carefully
and save it for future reference.
For detailed instructions, up-to-date information, and helpful
tips, please visit the Coby website at www.cobygermany.
de.
This manual is available for download from the
Coby website as a PDF le.
To view PDF documents, download and install
the free Adobe Acrobat reader from the Adobe
website at www.adobe.com.
Package Contents
Please make sure that the items shown below are
included in the package. Should an item be missing,
please contact the local retailer from which you purchased this product.
Coby
Protective pouch
USB cable
USB host/keyboard
®
Kyros® Internet
Tablet
adapter (Optional)
This package may contain plastic bags or other
materials that pose a hazard to children. Be
sure to safely dispose of all packing materials
after opening.
Professional stereo
Earphones (Optional)
Power adapter
Page 44 Thank You
Features
Browse the Web.
Visit your favorite websites
Check your e-mail
Keep in touch with friends and family
Watch YouTube™ videos
Browse the world’s most popular video-sharing com-
munity
Read your favorite books
Download thousands of books with the included
E-book reader *
Discover thousands of apps for Android™
Games, applications, and more with the installed
marketplace
HDMI™ output to your TV **
Enjoy videos, photos and more in the comfort of your
living room
Connect to the Internet wirelessly
High-speed Wi-Fi 802.11 b/g/n networking
microSDHC memory card reader
Increase your storage capacity (up to 32 GB supported)
Built-in camera
Convenient front-facing camera
Automatic orientation detection
Read any way you want; the display adjusts automatically!
* Reading books in the ePub format requires the included
E-book reader application.
Requires optional HDMI cable (Type A-to-Type C). 1080p
**
HD video playback requires a video le encoded at 1080p.
Streaming video quality will be affected by the source, and
the quality and condition of your network connection.
English
Enjoy your media library anywhere
Portable powerhouse plays popular music, video,
and photo formats
Page 45 Thank You
Â
Getting to Know the Internet Tablet
English
Unit at a Glance
Name Description
1 Camera Front - facing camera
Page 46 Getting To Know The Internet Tablet
Name Description
2 Power key Press to turn the unit on, or to turn the
screen on and o.
Press and hold to access the Power O
menu.
3 Volume +
key
4 Volume –
key
5 microSDHC
card slot
6 Speaker Speaker output is automatically muted
Press to increase the volume level.
Press to decrease the volume level.
Load external microSDHC memory
cards here.
when using headphone Jack.
English
6
6
5
Page 47 Getting To Know The Internet Tablet
7 Power jack
English
8 Headphone
9 USB 2.0 Hi-
Name Description
Charge and power the tablet with the
(DC input)
jack
speed port
included power adapter.
Audio output connection for headphones.
Note: Speaker output is automatically
disabled when headphones are connected to the player.
Connect to a computer to transfer data
(e.g., music, videos, photos, les).
MIC
DC IN 5V
7
8
10 HDMI jack
(mini Type C)
Connect to a TV or other display.
RESET
9
10
HDMI
Page 48 Getting To Know The Internet Tablet
About the Touchscreen
Your tablet comes equipped with an easy-to-use touchscreen.
Our capacitive multi-touchscreen requires gentle ngertip
touch on the glass screen to activate tablet’s functions.
Multiple ngers may be used to perform gestures (e.g.
2-nger picture zoom).
Please note: Your nger tips must not be covered. A
stylus may be used. Make sure it is for capacitive touchscreens.
To avoid damaging the screen, do not touch it
with excessive force or with any object other
than your nger. For best response, make sure
your hands are clean before using the touch-
screen controls.
Protective Film
A thin lm has been applied to the touchscreen to protect
it during shipping. The protective lm should be removed
before use. To remove it, simply take a corner of the lm
and peel it away from the screen.
Touchscreen Actions
You can control the functions of the tablet by using
the touchscreen in combination with the three touch
keys located on the bezel. To control the tablet with the
touchscreen, use your ngertip to manipulate icons,
buttons, menu items, the on-screen keyboard, and other
items displayed on the screen.
You can perform the following actions on the touchscreen
using your ngertip or appropriate stylus.
Touch: To activate an on-screen item (e.g.,
application icons, buttons, menu
items, and the letter/symbols of the
on-screen keyboard), simply touch
them with your ngertip.
Touch and
Hold:
Some on-screen items have an
alternate action if you touch and hold
it (e.g., opening an alternate menu, or
to activate the drag function). To touch
and hold an item, touch the item and
do not lift your ngertip until the action
occurs.
English
Page 49 Getting To Know The Internet Tablet
Drag: Drag an on-screen item to change its
position (e.g., an application icon on
the home screen).
English
To drag an item, touch and hold it for
a moment, then without lifting your
ngertip, move your ngertip on the
screen until the item reaches its target
destination.
Swipe: Swipe up/down on the screen to scroll
through a list. On some screens,
you may be able to swipe left/right to
change the view.
To swipe, touch the screen and then
quickly move your ngertip across the
screen without lifting your ngertip.
Do not pause on the screen with your
ngertip at the initial point of contact
or you may accidentally drag an item
instead.
Double-tap: Quickly tap the screen twice on a
webpage or other application screen
to zoom (the application must support
the double-tap/zoom function). Within
the browser, double-tapping a webpage section will cause the browser to
zoom and t that section to the width
of the screen.
Zooming in
and out:
Zoom In and Zoom out a photo on a
Web page or another application by
touching the screen with two ngers
and pull apart or you zoom by dragging two ngers together.
Page 50 Getting To Know The Internet Tablet
About the Orientation Sensor
The tablet contains a sensor that will automatically
change the orientation of most screens as you rotate the
tablet. The sensor works best when the tablet is rotated
perpendicular to the ground (i.e., when the tablet is held
upright and not fat on its back).
The orientation sensor can be turned on and off in the
Display settings menu.
Charging the Tablet
The tablet comes with a built-in rechargeable lithiumpolymer battery.
Before using the tablet, the battery should be charged
fully. Press lower right corner settings, next to battery
icon is charging percentage.
To charge the battery:
1. Plug one end of the included power adapter into an
AC 100-240V outlet.
2. Plug the other end of the included power adapter into
the Power jack on the tablet.
3. Disconnect the power adapter when the tablet is fully
charged.
The battery used in this device may present a
re or chemical burn if mistreated. Do not
disassemble, incinerate, or heat the device. Do
not leave the de-vice in a place subject to direct
sunlight, or in a car with its windows closed. Do
not connect the device to a power source other
than that which is indicated here or on the label
as this may result in the risk of re or electric
shock.
English
Page 51 Getting To Know The Internet Tablet
Inserting a Memory Card
The tablet accepts microSDHC memory cards. Insert a
memory card into the microSDHC card slot to:
English
Increase the memory capacity of your tablet
Play media les stored on the memory card (e.g.,
music, video, or photo les).
To release and remove a memory card:
1. UNMOUNT the memory card.
a. From the home screen, tap the Launcher Tab,
and then touch Settings to show the settings
menu.
b. Touch Storage to show the storage settings.
To insert a memory card:
1. Align the memory card with the card slot. The metal
contacts of the memory card should face down away
from the LCD screen.
2. Slide the card into the spring-loaded slot. Push the
card in until it clicks into place.
Do not attempt to insert objects other than a
microSDHC memory card into the card slot. A
compatible memory card should t easily into
the card slot; if you encounter resistance,
check the alignment of the card. Do not attempt
to force the card in.
Avoid touching the gold contacts of the
memory card.
Page 52 Getting To Know The Internet Tablet
c. Touch Unmount SD card to prepare the memory
card for safe removal.
2. Push the card further into the slot until you hear a
click. The card will spring out of the slot.
3. Grasp the card by its edge to remove it.
4. Remove the USB ash drive.
To avoid damage and data corruption, do not
remove a memory card while data is being
written to or read from the card. For example,
do not remove a card while playing a music le
stored on the card.
The available menu items are dependent on the
unit. All illustration is for reference only.
Resetting the Tablet
Reset the tablet if it should freeze and not respond or
otherwise malfunction.
1. Disconnect your tablet if it is connected to a compu ter.
2. Press and hold the POWER key for about 8 seconds
to turn off the tablet, and then press and hold the
POWER key until you see Coby logo.
Page 53 Getting To Know The Internet Tablet
English
Â
Getting Started
Turning the Tablet on and off
English
To turn the tablet on:
Press and hold the Power key until the LCD screen
turns on and you see Coby Logo, then wait until you
see the Unlock screen.
To turn the tablet off:
1. Press and hold the Power key until the conrmation
message appears.
2. Touch OK to turn off the tablet.
Page 54 Getting Started
Loading...
