USER’S MANUAL

CA-K20MT

CM Tech Co., Ltd.

THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE
HARMFUL INTERFERENCE, AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE
RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.

FCC RF INTERFERENCE STATEMENT

Note:
a Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation.

television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:

This equipment has been tested and found to comply with the limits for

If this equipment does cause harmful interference to radio or

--Reorient or relocate the receiving antenna.

--Increase the separation between the equipment and receiver.

--Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.

--Consult the dealer or an experienced radio/TV technician

for help.

■

Caution ( )

Do not change or modify the product without permission or authority of

manufacturer. It may cause undesirable operations, permanent damages or

harmful interferences.

◎

Notice ( )

·

Design and specification are subject to change without notice for product improvement

purposes.

◎

Functions

-

Multi Format Audio Player [MP3 / WMA]

-

FM Radio / FM Broadcasting Recording

-

Voice Recording

-

External Data Storage [Plug & Play]

-

TTS 2.0 [Text To Speech]

-

Song Title Display

◎

PC System Requirements

·

Processor: Pentium 233MHz or better

·

Windows98 / 98SE / ME / 2000PRO / XP

·

Hard Disc: 1GB or more available

·

Memory: 64MB DRAM or better

·

Monitor Resolution: 1024 x 768, 16Bit Color or better recommended

·

USB Port mounted

·

CD-ROM drive to install Software

◎

Description of Product Part

·

Front [fig-e01]

·

LCD Screen / Menu Button / Volume Control Button / Rewind Button / Fast Forward Button /

Play/Pause Button

·

Rear [fig-e02]

·

Earphone Jack / Microphone / Necklace Holder / Battery Cover / USB Jack / Hold Switch

◎

Direction of USB Cable Connection

[fig-03]

◎

Accessories

-

User’s Manual

-

Installation CD

-

USB Cable

-

Small-sized USB Adaptor

-

Earphone (FM Antenna Embedded)

-

Carrying Case / Battery 1 (1.5V AAA Type)

FM radio reception sensitivity could be lowered when other earphones than the provided one

are used.>

◎

USB Port Inspection

1. Before program installation, please inspect the USB port first.

2. Execution Order : 'My Computer

3. Check if there is ‘Universal Serial Bus Controllers’ in the device controller list.

4. It will be displayed as ‘General Serial Bus Controllers’ or ‘Universal Serial Bus

Controllers’ depending on the PC environment. [fig-e04]

5. USB port cannot be used if there is no 'Universal Serial Bus Controllers'. In such a case,

please ask the sales agent of your PC for its service before installation.

◎

Program Installation

→

View system information → Hardware → Device Manager'

·

Before installation, please disconnect other USB products connected to the USB port.

·

Do not connect the product to your PC until successfully installing the program. If you

have already connected the product to your PC, disconnect it before proceeding.

·

This manual is based on Windows XP. Appearance can be different depending on the version of

Windows you are using.

1. Insert the supplied CD-ROM into the CD-ROM drive of your PC. The dialog box shown below

should appear. If the installation program does not start automatically, double-click

‘Install.exe’ of the CD. [fig-e05]

2. Click the ‘Install’ button on the picture to begin installation. Select the ‘MP3

Driver+TTS’ button to use the TTS function. (Usually it takes about 5 minutes if TTS is

selected. The necessary time is somewhat different depending on the PC environment.)

→

3. Click "Next"

"Finish" to complete the installation and restart your PC. [fig-e06] [fig-

e07]

4. After your PC has restarted, you will see the 'Live Music_K Explorer' icon on your PC.

5. With the battery installed in the product, connect the product to the USB port on your PC,

and then press the '

▶/■

' button to turn on the product.

6. Execute 'Live Music_K Explorer' and a window will appear as shown below. [fig-e08]

◎

Program Deletion

1. If the product is already connected to your PC, disconnect it.

2. Execute “Control Panel”

3. Search the list for 'Live Music_K' and click on the “Change/Remove” button. A window will

appear as shown below. Select the "Remove" button, and then click "Next", "OK" and “Finish”

to complete the deletion. Restart your computer after deletion. [fig-e09] [fig-e10] [fig-e11]

[fig-e12]

→

“Add or Remove Programs” to see a list of the installed programs.

4. If the installation was not successful or if you need to reinstall the program for any

reason, follow the program deletion procedure and put the CD-ROM in for installation.

·

If you want to delete the TTS program, execute 'Controller' → 'Add or Remove Programs’.

Then search the list for 'TTSPad 2.0' and click “Change/Remove” to start deleting.

◎

Formatting (After installing the program)

1. Please execute formatting periodically for the efficient use of the memory.

2. Format the removable disc drive to delete all the files and initialize the drive.

3. With the battery removed from the product, connect the product to the USB port of your PC

and press the '

4. Execute “Start

The format window will appear as shown below. Click “Start” to start formatting. [fig-e13]

▶/■

' button to power up the product.

→

Programs → Live Music_K Audio Player → Live Music_K Format” on your PC.

5. When formatting is completed, press the 'Close' button to close the formatting window.

[fig-e14]

6. After formatting, disconnect the product from your PC and put the battery in it. Then

▶/■

press the '

use.

◎

Updating (After installing the program)

1. Update the firmware of the product.

2. With the battery removed from the product, connect the product to the USB port of your PC

and press the '

3. When the “Found New Hardware Wizard” appears as shown below, click "Next"

e15] [fig-e16]

' button and check if the power is on before you connect it to your PC again to

▶/■

' button for more than 10 seconds.

→

"Finish". [fig-

4. After installation is completed, check if there is 'Player Recovery Device Class' in the

device controller. (Device controller : My Computer

Device Manager) [fig-e17]

5. Click “Start”

window appears as shown, click “Next”

→

“Program”→ “Live Music_K Audio Player”→ “ Live Music_K Update”. When a

→

“Finish”. [fig-e18] [fig-e19]

→

View system information → Hardware →

6. The update window will appear as shown below. Then click “Start” to start updating. (In

case of Window98/98SE, you need to click “Start”

→

“Programs”→ “Live Music_K Audio Player”→

“Live Music_K Update” again to see the update window. [fig-e20]
