ClearOne StreamNet Integration User Manual

Telephone [phone]

1.801.974.3760

Tech Sales 1.800.705.2103

FAX [phone]

E-mail [e-mail]

[e-mail]
[e-mail]

On the Web www.clearone.com
www.netstreams.com
www.streamnetpartners.com

St r e a m Ne t

IN t e g r a t I o N & Pr o g r a m m e r ’S gu I d e

CLEARONE PART NO. 800-000-017 APRIL 16, 2011 (REV. 1.0)

© 2011 ClearOne and NetStreams - All rights reserved. No part of this document may be reproduced
in any form or by any means without written permission from ClearOne and NetStreams. Printed in the
United States of America. ClearOne and NetStreams reserves specific privileges.

Information in this document is subject to change without notice.

U.S. PATENTS: 7,643,894 & 7,711,126

INTERNATIONAL PATENTS: 2003-241405 (AU), 10-0966415, 10-2004-7017970 (KO)

OTHER PATENTS PENDING:

US 11/467,340
US 11/960,401
US 12/015,385
US 12/418,267
US 12/472,976
US 12/727,925
US 12/761,506
US 12/900,666
US 12/917,765
US 12/917,773
European 03731139.6
European 06251345.2
Canadian 2,485,104
Canadian 2,539,458
Australia 2008-207498

Table of Contents

CHAPTER 1: INTRODUCTION

DOCUMENT PURPOSE .................................................................................................................. 1

DOCUMENT ORGANIZATION ........................................................................................................ 1

CHAPTER 2: CONTROLLING A STREAMNET SYSTEM

CONNECTING TO THE STREAMNET SYSTEM ............................................................................. 3

St r e a m Ne t tCP Po r t a l .............................................................................................................................. 3

TCP Control ......................................................................................................................................................4

TCP Monitoring .................................................................................................................................................4

St r e a m Ne t udP Po r t a l ............................................................................................................................. 4

Unicast UDP Control ........................................................................................................................................4

Multicast UDP Control ......................................................................................................................................4

Unicast UDP Monitoring ................................................................................................................................... 4

Multicast UDP Monitoring .................................................................................................................................4

St r e a m Ne t Co m P a t I b l e S .............................................................................................................................. 4

STREAMNET CONCEPTS .............................................................................................................. 5

Se r v I C e S ..................................................................................................................................................... 5

STREAMNET ADDRESSING .......................................................................................................... 5

gr o u P ad d r e S S e S ....................................................................................................................................... 5

Co N t r o l l I N g le g a C y av de v I C e S ................................................................................................................. 6

Driver Pass Through (Serial or IP) ....................................................................................................................6

St r e a m Ne t So f t ad a P t e r S (SSa) ............................................................................................................... 6

So u r C e ad a P t e r S (dr I v e r S ) ........................................................................................................................ 6

dI S P l a y ad a P t e r S (dr I v e r S ) ......................................................................................................................... 6

Co N t r o l ad a P t e r S (gPIo dr I v e r S ) ............................................................................................................. 6

Adapter (computing) – Wikipedia .....................................................................................................................6

SUBSCRIPTION .............................................................................................................................. 7

re C e I v I N g Sy S t e m St a t u S ............................................................................................................................. 7

REGISTRATION .............................................................................................................................. 8

STREAMNET MULTICAST ADDRESSES ....................................................................................... 8

IP ADDRESS ASSIGNMENT .......................................................................................................... 8

IP Po r t Nu m b e r ta b l e ................................................................................................................................ 8

CHAPTER 3: ASCII OVERVIEW

ASCII MESSAGE SYNTAX .............................................................................................................. 9

@t o ad d r e S S .............................................................................................................................................. 9

No d e .......................................................................................................................................................... 9

Su b N o d e ................................................................................................................................................... 10

St r e a m Ne t Su b N o d e ad d r e S S e S : ............................................................................................................... 10

:fromAddress .................................................................................................................................................. 10

%modifier ........................................................................................................................................................10

#keyword (ASCII Command) .........................................................................................................................10

arg1, arg2, ..., arg# ........................................................................................................................................ 10

/0 (null byte) .................................................................................................................................................... 11

uN I q u e Id (uId) ........................................................................................................................................ 11

Su m m a r y ................................................................................................................................................... 11

aSCII me S S a g e ty P e S ............................................................................................................................... 12

Imperatives .....................................................................................................................................................12

Table of Contents

Interrogatives .................................................................................................................................................. 12

Declaratives .................................................................................................................................................... 12

Menus ............................................................................................................................................................. 12

me N u Na v I g at I o N ....................................................................................................................................... 14

#REPORT MESSAGES ................................................................................................................ 15

uN S o lI C I t e d #rePort ............................................................................................................................ 16

ASCII ADDRESSING AND ROUTING FOR TCP CONTROL ........................................................ 16

ASCII CHARACTER ESCAPE SEQUENCES ............................................................................... 17

STREAMNET MACROS ................................................................................................................ 17

CHAPTER 4: OVERVIEW OF SERVICES

COMMUNICATING WITH THE STREAMNET SYSTEM ............................................................... 19

SERVICES ..................................................................................................................................... 19

Se r v I C e Na m e S .......................................................................................................................................... 19

Se r v I C e ty P e S ........................................................................................................................................... 19

Co m m o N Se r v I C e S b y de v I C e ...................................................................................................................... 20

Se r v I C e Co N f I g u r a t I o N .............................................................................................................................. 20

Amplifier / Player Device ................................................................................................................................. 20

Audio / Video Encoder Device........................................................................................................................20

Touch Panel ....................................................................................................................................................20

Legacy Controller Device ...............................................................................................................................20

CHAPTER 5: SERVICES DESCRIBED

AUDIO/VIDEO RENDERER SERVICE .......................................................................................... 21

ov e r v I e w .................................................................................................................................................. 21

av mu l t I -Zo N e oP e r a t I o N ........................................................................................................................ 21

ex a m P l e S .................................................................................................................................................. 22

au d I o /vI d e o re N d e r e r Co m m a N d de t a I l S ................................................................................................... 22

Command: #ACTIVE OFF .............................................................................................................................22

Command: #ACTIVE ON ............................................................................................................................... 22

Command: #AMP OFF .................................................................................................................................. 22

Command: #AMP ON ....................................................................................................................................23

Levels ..............................................................................................................................................................23

Command: #EQ_PRESET .............................................................................................................................23

Command: #LEVEL_DN BALANCE ..............................................................................................................23

Command: #LEVEL_DN BAND_x .................................................................................................................23

Command: #LEVEL_DN BASS ...................................................................................................................... 23

Command: #LEVEL_DN TREB ...................................................................................................................... 23

Command: #LEVEL_DN VOL ........................................................................................................................23

Command: #LEVEL_SET BALANCE, x .........................................................................................................24

Command: #LEVEL_SET BAND_x, y ............................................................................................................24

Command: #LEVEL_SET BASS, x ................................................................................................................. 24

Command: #LEVEL_SET TREB, x ................................................................................................................. 24

Command: #LEVEL_SET VOL, x ...................................................................................................................24

Command: #LEVEL_UP BALANCE ...............................................................................................................25

Command: #LEVEL_UP BAND_x ..................................................................................................................25

Command: #LEVEL_UP BASS ......................................................................................................................25

Command: #LEVEL_UP TREB ...................................................................................................................... 25

Command: #LEVEL_UP VOL ........................................................................................................................25

Table of Contents

Command: #MENU_LIST m, n, sources .......................................................................................................26

Responses Received ......................................................................................................................................26

Command: #MENU_SEL {{path}} ............................................................................................................... 27

Command: #MULTIAUDIO ............................................................................................................................27

Command: #MULTIAUDIO JOIN {{sessionName}} ....................................................................................27

Command: #MULTIAUDIO LEAVE ................................................................................................................27

Command: #MUTE OFF ................................................................................................................................ 28

Command: #MUTE ON ................................................................................................................................. 28

Command: #MUTE TOGGLE ........................................................................................................................28

Command: #QUERY renderer ....................................................................................................................... 28

Parsing Reports .............................................................................................................................................. 28

Command: #QUERY CURRENT_SOURCE...................................................................................................28

Command: #SET ...........................................................................................................................................28

Command: #SLEEP ....................................................................................................................................... 29

Command: #SRC_SEL .................................................................................................................................. 29

Command: #SRC_SEL {{source ID}} .......................................................................................................... 29

Command: #TEMPSRC {{sourceName}} [,timeOut value] ......................................................................... 29

Command: #TEMPSRC {{sourceName}}, OFF ..........................................................................................29

Command: #TEMPSRC OFF ......................................................................................................................... 29

AUDIO/VIDEO SOURCE AND SOURCE PROXY SERVICE ......................................................... 30

ov e r v I e w .................................................................................................................................................. 30

ex a m P l e S .................................................................................................................................................. 30

Command: #MENU_LIST m, n, {{path}} .....................................................................................................30

Responses Received ......................................................................................................................................30

Summary ........................................................................................................................................................31

Command: #MENU_LIST m, n, {{path}} .....................................................................................................32

Responses Received ......................................................................................................................................32

Summary ........................................................................................................................................................32

Command: #QUERY SOURCE .....................................................................................................................33

USER INTERFACE (UI) SERVICE ................................................................................................ 34

ov e r v I e w .................................................................................................................................................. 34

INTERCOM SERVICE ................................................................................................................... 34

ov e r v I e w .................................................................................................................................................. 34

St a t I o N t o St a t I o N .................................................................................................................................... 34

IN t e r C o m mo N I t o r Se S S I o N ........................................................................................................................ 35

IN t e r C o m eN t r y Se S S I o N S .......................................................................................................................... 35

St a t u S re P o r t w I t h a Cu r r e N t IN t e r C o m Se S S I o N ...................................................................................... 36

St a t u S re P o r t w I t h No Cu r r e N t IN t e r C o m Se S S I o N S .................................................................................. 36

ov e r v I e w .................................................................................................................................................. 37

ROOT SERVICE ............................................................................................................................ 37

ov e r v I e w .................................................................................................................................................. 37

APPENDIX: SPEAKERLINX

SPEAKERLINX AUDIO RENDERER COMMANDS ......................................................................A-1

INDEX ............................................................................................................................................ I-1

GLOSSARY OF TERMS .............................................................................................................. G-1

Table of Contents

Chapter 1: Introduction

DOCUMENT PURPOSE

The intent of the StreamNet Integration & Programmer’s Guide is to define the StreamNet software command
structures necessary for Integrators to build interfaces. The interfaces can then be used by StreamNet System
Controllers to control StreamNet Ready devices.

DOCUMENT ORGANIZATION

The StreamNet Integration & Programmer’s Guide is designed to provide the Integrator with detailed
descriptions of the relevent commands for each of the StreamNet device sets (SpeakerLinX, MediaLinX,
TouchLinX, ViewLinX, etc.) Each set of commands is organized based on the specific sources available and
are listed through-out in alphabetical order.

This document begins with a detailed overview of the StreamNet ASCII Command Protocol which is the basic
mechanism for control and status reporting of the StreamNet services.

Chapter 2 provides detailed information needed for controlling a StreamNet System from connection to
addressing. Information on controlling legacy AV devices, StreamNet Soft Adapters (SSA), Source Adapters
as well as Display and Control Adapters is also covered. The chapter also covers Streamnet Subscription and
Registration topics.

Chapter 3 gives an overview of StreamNet ASCII commands, with an explanation of syntax structure, Subnode
addressing and related information. Chapter 3 provides details on ASCII message types and provides exam­ples as necessary. The chapter finishes with sections on Menu Navigation, Report Messages, ASCII Character
Escape Sequences and Streamnet macros.

Chapter 4 provides the reader with details of the services which may be found on a StreamNet device. Sections
include a brief description on communicating with the StreamNet system, a description of what a service is
and the types of services available. A chart of common services by device is provided and some examples of
zone configurations are presented.

Chapter 5 describes how services are implemented and examples of commands available per service type
with details of the parameters available for each listed command. Each service section of Chapter 5 provides
a detailed overview of the service type.

Chapter 5 is followed by an Index that can be useful as a reference source.

The document concludes with a Glossary of Terms.

Chapter 1: Introduction 1

2 Technical Sales: 1.800.705.2103

Chapter 2: Controlling A StreamNet System

StreamNet is designed such that a very large number of networked devices behave as a single coordinated
system. The integrator does not need to know about the underlying network complexity; StreamNet completely
handles it all. With StreamNet you get all of the advantages of an IP based system without the complexity. The
third party control device only needs to know a single IP address and through this one address can control
an unlimited number of StreamNet devices. Instead of IP addresses (which may change) the controller can
address commands to friendly, human readable names such as “Bedroom TV” or “DVD Player”. Control
messages using these friendly names may be sent to any StreamNet device or broadcast to all of them;
StreamNet will make sure that the correct device(s) and only the correct device(s) receive the message.

NOTE f : This document will describe a large number of alternative ways to control a StreamNet
system. This is a testament to the incredible flexibility of StreamNet; but, it may give the
impression that controlling StreamNet is complex – nothing could be further from the truth.
The integrator does not need to use all of the methods, only the most convenient one(s).

A StreamNet system remains remarkably uncomplicated even when scaled to huge proportions. Network
technology makes this scalability possible and StreamNet makes it simple.

Touchpanel user interface devices are available for controlling StreamNet without requiring any central
controller; but, this by no means the only way a StreamNet system can be controlled. In fact, StreamNet was
explicitly designed to simplify control by third party control devices such as AMX or Crestron Controllers.

Advanced users may be interested in StreamNet’s Auto-Discovery or Time Sync mechanisms, but the integrator
may mostly ignore how StreamNet does what it does and just take advantage of the simplicity it offers.

StreamNet devices handle the routing of AV content from one location to another as well as all aspects of
controlling the source and display devices. Most devices can learn and reproduce IR codes for controlling
non-StreamNet devices such as TVs, DVD players, etc. Serial and IP control of non-StreamNet devices are
also supported. StreamNet can even route IR signals transparently across the network to be reproduced at
other locations to control remote devices.

CONNECTING TO THE STREAMNET SYSTEM

Control messages may be sent to the StreamNet system in a variety of ways. Messages may be sent through
a TCP connection to a single device or through multiple TCP connections. Also, messages may be sent
using UDP, either unicast or multicast. It is even possible to send the commands using an IR or RS232 serial
interface. The integrator may choose the most convenient method or any combination of these methods.

StreamNet TCP Portal

The most common way for a controller to connect to the StreamNet system is through a single TCP connection
to one of the StreamNet devices. This single TCP connection can be made to any StreamNet device which
supports the “TCP Control Portal”. If lots of control message traffic is expected then it is recommended
that a ControLinX be dedicated to providing this TCP connection. The commands are sent and responses
and unsolicited status messages are conveyed over the TCP connection. The TCP connection should be
maintained continually if system status is desired. Typically, each StreamNet device supports a maximum of 4
TCP clients at a time.

Obviously to make the TCP connection the controller must know the IP address of the device to which it is
connecting. So at least one device in the StreamNet system must have a fixed IP address. This is another good
reason to dedicate a ControLinX device as the portal to the StreamNet system. The portal ControLinX can be
assigned a static IP address but all of the other StreamNet devices can be allowed to find their own address.

NOTE f : If there is no traffic on the TCP connection after 60 seconds it will be closed. To
keep the connection alive the client can send a dummy ASCII command every 30 seconds.
#HEARTBEAT is often used for this purpose. But if the client has registered for status the
#REGISTER commands will keep the connection alive.

Chapter 2: Controlling A StreamNet System 3

tCP Co N t r o l

Any StreamNet ASCII control message may be sent using TCP to the IP address of any StreamNet device at
port number 15000. Responses from the StreamNet system will be returned on the TCP connection which
initiated the request. See chapter on ASCII Protocol.

tCP mo N I t o r I N g

Unsolicited status messages may be received by the third party controller using TCP through the StreamNet
mechanism of Registration. See section on Registration.

StreamNet UDP Portal

A third party controller may perform all StreamNet control and monitoring functions using UDP.

Control Messages may be sent to the StreamNet system either multicast or unicast; monitoring or status
messages may be received either multicast or unicast. Any or all of these methods may be used simultaneously
in any desired combination.

uN I C a S t udP Co N t r o l

Any StreamNet ASCII control message may be sent using UDP to the IP address of any StreamNet device at
port number 15000. Responses from the StreamNet system will be addressed and routed according to the
ASCII “From Address” of the original message. See chapter on ASCII Protocol.

mu l t I C a S t udP Co N t r o l

Any StreamNet ASCII control message may be sent using UDP to the StreamNet System Multicast Address
at port number 15000. Responses from the StreamNet system will be addressed and routed according to the
ASCII “From Address” of the original message. See chapter on ASCII Protocol.

uN I C a S t udP mo N I t o r I N g

Unsolicited status messages may be received by the third party controller using unicast UDP through either of
two StreamNet mechanisms, Subscription or Registration.

mu l t I C a S t udP mo N I t o r I N g

Unsolicited status messages may be received by the third party controller using unicast UDP through the
StreamNet mechanism of Subscription. It is not recommended for the controller to monitor the multicast status
of the services directly. This mechanism is not intended for this use and may change without notice.

StreamNet Compatibles

Some devices support only a subset of the StreamNet protocols and functionality; these devices are
sometimes referred to as StreamNet Compatible devices. These devices currently include the iDock and the
Anthology Media Server. These devices work seamlessly within a StreamNet system but do not provide all of
the StreamNet functionality described in this document.

4 Technical Sales: 1.800.705.2103

STREAMNET CONCEPTS

There are few concepts that must be understood to properly understand StreamNet.

Services

A StreamNet service is an abstraction. It is a functional software module but it can be thought of as a virtual
device. A service performs a single function such as capturing analog audio and streaming that audio onto
the network. Another service may perform the function of converting the network audio stream to analog and
amplifying it. Still another service may provide an interface to a third party lighting system. A single physical
device may support many services of various types.

The service concept greatly simplifies controlling the StreamNet system. For example, control messages can
be addressed to the name of an AV zone (a service) instead of to “Device 1 at IP address, 10.15.65.113, output
number 7”. The controller does not need to know which physical device is providing the function or what the
physical configuration of that device is – just the service name. The control messages are simply addressed
to “Zone 1” and StreamNet ensures the correct AV zone reacts. Details about the types of services and the
functions performed are described in later sections of this document.

STREAMNET ADDRESSING

StreamNet ASCII messages may be sent, using any of various unicast methods, which include UDP (Unicast)
and TCP, to any StreamNet device. If addressed correctly, the message will be routed to the desired service(s).
Also, the messages may be sent to the StreamNet System multicast address. In this case, all StreamNet
devices receive the message simultaneously, but only the addressed services accept the message and react
to it. Messages may be addressed to a Service, a Group or a Room.

It is not necessary to know the IP addresses of the individual StreamNet devices to communicate with them. All
messages are addressed to service names associated with the devices during the configuration process.

If the 3rd Party Controller or software has the ability to send Multicast UDP messages, then all ASCII messages
may be sent to the default system Multicast Address and the destination device or group of destination devices
will receive it. Responses and status may be received by unicast/multicast UDP. If the 3rd Party Controller or
software does not have multicast capability, the messages may be sent Unicast UDP to any StreamNet device
and it will be forwarded.

If the 3rd Party Controller is also listening to its own (i.e., different) multicast address for responses, the
controller and the StreamNet system do not have to be in the same subnet.

The StreamNet system multicast address should not be used for responses. 3rd Party Controllers should
subscribe to use a separate unicast address or an unused multicast address to receive responses (see the
section on Subscription below).

Unsolicited status messages may be received by the 3rd Party Controller.

Group Addresses

Services can be members of named “groups”. A group address, or “group name”, is just a way of addressing
multiple services simultaneously with a single control message. A service may be a permanent member of a
particular group or it may join and/or leave the group. There may be special group names which are used for
specific purposes; for example, the group name “ALL” includes all services in the StreamNet system.

Chapter 2: Controlling A StreamNet System 5

Controlling Legacy AV Devices

dr I v e r Pa S S th r o u g h (Se r I a l o r IP)

Generally, when controlling an AV source device such as a media server or Sirius tuner the integrator will
want to use the drivers which already exist for their third party controller. StreamNet makes this simple and
convenient. The serial ports on any StreamNet device can be configured to transparently pass serial traffic to/
from any controller. In this way the existing driver can be used and no additional hardware is required to add
a serial port. And of course if the driver uses Internet Protocol (IP) to control the device this can be done just
as easily.

StreamNet Soft Adapters (SSA)

Another StreamNet feature which greatly simplifies control is the StreamNet Soft Adapter. Adapters are
small pieces of software written in the LUA programming language and executed on devices throughout the
StreamNet system. Soft adapters convert proprietary protocols of third party devices into standard StreamNet
protocol. This eliminates the complexity caused by multiple protocols from multiple vendors. Since the Soft
Adapters are executed by an “interpreter”, different Adapters may be selected by the integrator during system
configuration from a large number of standard adapters or the integrator may write a custom adapter to
perform any desired function.

Source Adapters (Drivers)

Source Adapters are software translators (drivers) which standardize the control of third party AV source
devices. Source Adapters take the myriad of device control interfaces and translate them to the common
language of StreamNet.

For example, media servers from different vendors may have very different and complex proprietary interface
protocols; but, Source Adapters can make them all operate exactly the same from the controller’s point of
view. Source Adapters may use IR, Serial, of Internet Protocol (IP) to control the AV source device.

The integrator may choose from a number of standard Source Adapters or the integrator may elect to write a
custom driver. If the integrator prefers to take advantage of existing drivers on third party controllers, StreamNet
devices can transparently pass serial communications to/from the AV device or learned IR codes can be
triggered by command.

Source Adapters run on devices with AV source services or Stream Proxy Services, such as a MediaLinX or
SpeakerLinX.

Display Adapters (Drivers)

Some StreamNet devices also support Display Adapters to translate controls for the video display device.

Control Adapters (GPIO Drivers)

Some Adapters can provide an interface to lighting systems or HVAC systems, or the Adapter may have
multiple unrelated functions. A custom Soft Adapter may perform multiple functions simultaneously. These
types of Adapters are called Control Adapters or GPIO drivers. GPIO Adapters can run on any StreamNet
device that has a GPIO service which supports Adapters; a ControLinx is a typical example. Control Adapters
can be custom written to perform nearly any conceivable control task.

The control messages themselves will be described in later chapters as the StreamNet ASCII Protocol.

Ad A p t e r (c o m p u t i n g ) – Wi k i pe d i A

“In computing, an adapter is a hardware device or software component that converts
transmitted data from one presentation form to another. The data presentation can be, for
example, a message sent between objects in an application or a packet sent through a
network.”

6 Technical Sales: 1.800.705.2103

SUBSCRIPTION

Receiving System Status

StreamNet Subscription allows third party controllers to receive unsolicited status messages from StreamNet
services. During configuration, the Integrator may subscribe to a StreamNet Service’s status message by
entering the controller’s IP address and the port to which the status messages are to be sent.

If a subscription exists, the StreamNet service will send status messages over UDP protocol to the specified
IP address and port number.

A static subscription is configured using the StreamNet Dealer Setup Program and is automatically in
effect as soon as the device powers up and remains in effect indefinitely. The user should use the StreamNet
Dealer Setup Program to specify an IP address and port number to which status reports are to be sent.
This IP Address is typically the static IP address of the 3rd Party Controller device. If the device receiving the
status messages is capable of receiving multicast UDP messages, then an unused multicast address may be
specified for the subscription. Using a multicast address eliminates the need for the controller to have a static
IP Address and also eliminates any subnet related issues.

During configuration, the integrator may enter “subscriptions” to a StreamNet service’s status messages
by entering the IP address and port to where the status messages are to be sent. If a subscription exists
the StreamNet service will send status messages over UDP protocol to the specified IP address and port
number.

The StreamNet system multicast address should not be used by the controller to receive responses or status.
When Controllers “Subscribe” either the controller’s unicast address or an unused multicast address should
be used.

Chapter 2: Controlling A StreamNet System 7

REGISTRATION

When controlling the system through a TCP connection the TCP client may “register” to receive status from
individual services. Registration is performed by sending a “#REGISTER” ASCII command to the StreamNet
device acting as the TCP server. This registration will time out after 30 seconds unless it is renewed by sending
another “#REGISTER” command.

A TCP client of a StreamNet device may “register” to receive status from a specific service. When a TCP
client such as a Flash application sends the “#REGISTER serviceName” command to the root service of the
device to which it is connected that device will start forwarding the status of the specified service to the TCP
client. This function is useful for controllers which cannot use multicast UDP. Adobe Flash can only make TCP
connections.

STREAMNET MULTICAST ADDRESSES

For each StreamNet system there is a single multicast address used by all of the devices for device discovery,
ASCII message routing, time synchronization, and other system level tasks; this multicast address is called the
“StreamNet System Multicast Address” and is configured into the device by the StreamNet set up program.
All other multicast addresses are assigned dynamically at run time by the StreamNet system master device.
The assigned addresses are chosen from a range of addresses configured into the device by the StreamNet
set up program.

These dynamically assigned multicast addresses would not normally be needed by any third party controllers
or other non-StreamNet devices; however, the addresses may sometimes be available through #QUERY
requests or other status reports.

IP ADDRESS ASSIGNMENT

Each StreamNet device must have an IP address. The device may obtain this address in any of several ways:
Static IP, Auto IP or DHCP. The installer may choose a preferred method of IP address assignment but if the
preferred method fails, the device may try other methods until an address is obtained. By default the devices
will initially try to obtain an address from a DHCP server. If after several minutes an address is not received
from a DHCP server, the device will attempt to obtain an address through the Auto-IP method. With the Static
IP method, the device will assume that the assigned address is valid.

NOTE: f If the device is configured for DHCP and no DHCP server is present on the system,
the device will remain unresponsive for several minutes until the Auto IP address is resolved.

IP Port Number Table

Multicast UDP ASCII Messaging Port 15000

Unicast UDP ASCII Messaging Port 15000

TCP ASCII Messaging Port 15000

Discovery Port 8000

Time Sync Port 5001

8 Technical Sales: 1.800.705.2103

Chapter 3: ASCII Overview

The basic mechanism for control and status reporting of the services in StreamNet is the ASCII protocol.
This protocol consists of various command messages and their parameters represented by strings of ASCII
characters. Messages also have associated routing and administrative information which informs recipients of
the destination and origin of the messages or provides other supplemental information.

ASCII MESSAGE SYNTAX

ASCII messages have the following syntax:

#@toAddress:fromAddress%modifier%modifier#keyword arg1, arg2, ... argN /0

A # symbol is required at the beginning of all messages.•

ASCII messages must not exceed 1000 characters in length.•

The various fields must be in the order shown above.•

The fields after the first # are the administrative fields, addresses and other control functions. The •
fields after the second # are the actual command.

@toAddress

Specifies the name of the Service, Group, or Room to which the message is sent. The @ symbol precedes all
toAddress fields. The address field may consist of two parts: the Node Address and the Subnode Address.

The Node Address specifies the Service, Group, or Room the message is addressed to. The Subnode Address
can be used to address a subordinate module within the destination service or to invoke other special routing
functions. The Subnode Address follows the Node Address and is separated by a tilde (~).

Example: @nodeAddress~subnodeAddress

NOTE f : When no service address is provided, the address defaults to the Root Service of that
device.

The device reacts only if the command is a valid Root Service command.

Messages without a toAddress will be ignored if they are sent multicast or broadcast.

Node

A Node Address is the main part of an ASCII command address and can be part of the TO or FROM address.
A node address is either a Service Name, a Service Unique ID (UID), a Room Name or a Group Name.

Chapter 3: ASCII Overview 9

Subnode

A subnode address is part of the ASCII command address. It can be part of the TO or FROM address. A
subnode address is a special address modifier which instructs the node where to forward the command once
it is received. Sometimes the subnode address indicates that the service should forward the command to a
non-StreamNet device.

Examples:

~IRMOD• : forwards the command to the device which is providing the IR I/O functions to the StreamNet
service.

~UDP192.168.5.3_5000• : forwards the command using UDP to the specified IP address and port

5000. The subnode address may refer to a StreamNet device with an address unknown to the
sender.

StreamNet Subnode Addresses:

• ~CURSRC Route to renderers current audio source

• ~IRMOD Route to IR module on MediaLinX

• ~SERIAL_X Route to serial port number X

• ~KEYPAD Route to KeyLinX module

• ~ROOT Route to root service on device

• ~STATUS Not used to route to, but rather to indicate a status message

• ~SUBSCRIBER indicates the route to subscribers

:fromAddress

:fromAddress indicates which entity sent the message. This is used by the recipient to address any response

that may be generated by the message. If a response is expected, then the fromAddress should specify the
address the response should be sent to. The : symbol must precede all fromAddress fields. The fromAddress
may have a subnode address.

For 3rd Party Controllers using UDP, it is recommended that the fromAddress resemble the following format:

~UDP192.168.5.3_5000

This includes the IP address and port to which any response should be sent.

%modifier

Optional field. May be used for various context specific purposes. If the recipient does not support the particular
modifier, the field may be ignored. There may be any number of %modifier fields in a message. The % symbol
precedes all modifier fields.

NOTE f : This field is reserved for future use in StreamNet.

#keyword (aSCII Co m m a N d )

Required field. This is the keyword that specifies the action to be executed. The # symbol precedes all keyword
fields (no intervening spaces). The keyword is one word and contains no spaces, commas, or other special
characters except the underscore “_”.

arg1, arg2, ..., arg#

Optional field (some keywords may require arguments). The keyword may be followed by arguments. There
are one or more spaces between the keyword and the first argument and a comma between each additional
argument. Arguments are separated by commas and any extra white space should be ignored.

10 Technical Sales: 1.800.705.2103

Arguments have the following formats:

• Meaningful Strings – These are labels which represent some value, case, or function. Examples of

meaningful strings are ON and OFF. Meaningful strings are not enclosed in quotation marks and must
begin with an alphabetic character – not a numeral.

• Character Literals – These character strings do not need any special delimiters if they contain

no blanks, spaces, commas, or other special characters. (A special character is other than alpha/
numeric).

NOTE f : If an argument contains any special characters or spaces, it must be enclosed

between double braces {{......}}. When in doubt, use the double braces.

• Numeric Scalars – These must be a decimal number.

• XML or other Special Formats - These arguments are enclosed in double braces {{...}} and can

take any form depending on context.

/0 (N u l l b y t e )

All ASCII messages must end with a 0x00 byte (null).

UniqueID (UID)

The UID of a service is an unchangeable identifier for the service. It is based upon the device’s serial number.
The UID will be the service name if none has been specified during configuration. It will also be used as the
service’s room name if none has been specified. Normally, there is no reason for an integrator to use the UID.
All services should be assigned names and all of the user’s commands should be addressed to those service
names (or room/group names).

The structure of the UID is serialNumber_index where serialNumber is the Serial Number of the device and
index is an integer that identifies the specific Service on the device.

Example: #@MLA10105151001161008019_4

serialNumber index

Summary

The 3rd Party Controller sends an ASCII message UDP to the IP address of any StreamNet device.

In the ASCII message, you should have the:

#@toAddress• - name of the service you are addressing.

:• fromAddress - your own IP Address with a Port number to receive responses.

The • :fromAddress - your IP Address/Port and all responses will be sent to this address.

#ASCII• command with appropriate arguments required by that command.

Chapter 3: ASCII Overview 11

ASCII Message Types

There are three types of ASCII messages - Imperative, Interrogative and Declarative.

Im P e r a t I v e S

Some messages are commands which initiate an action or directly cause a change of state. For example,
commands that change volume level, select an audio source, or send an IR code.

Example: #@CD PLAYER:~UDP192.168.5.3_5000#PLAY

The message will be routed to the StreamNet Service named CD PLAYER. This service may transmit an IR
code for PLAY to the actual CD player being controlled.

NOTE f : This command could be received by any StreamNet device in the system and it would
be routed to the correct device.

Generally, imperative StreamNet commands do not receive responses.

IN t e r r o g a t I v e S

Some messages are used to request information. If an interrogative message is sent, a response is
expected.

NOTE f : An Imperative may cause a change of state which then generates a report of the
change. This is different from the question/answer of the Interrogatives.

de C l a r a t I v e S

Some messages only report information. They may be unsolicited status reports (periodic or caused by a
change of state) or they may be a response to an interrogative message. The most common StreamNet
declarative is the #REPORT message.

me N u S

StreamNet has a special set of messages which make use of all three types, interrogative, declarative, and
imperative. These messages are the menu messages: #MENU_LIST, #MENU_RESP, and #MENU_SEL
These three messages combine to provide a general means to present menus and allow menu selections
without knowing the content of the menu in advance.

The controller sends a #MENU_LIST message to a StreamNet service to request the menu. The StreamNet
service responds with a series of #MENU_RESP messages (one for each item in the menu). After a selection
has been made, the controller sends a #MENU_SEL message indicating the user’s selection. In addition to
user readable menus selection mechanism, the #MENU_LIST can be used to provide information to third
party control programs.

Menus are organized in a branching tree structure. At the top level of the menu will be a list of items. Selecting
one of these items may lead to a second tier menu; selecting a second tier item may lead to a third tier menu,
etc. This may continue for an arbitrary number of menu tiers. At any level of the menu, there may be some of
the items which do NOT lead to a lower tier. These are called “terminal” items and generally selecting (use
#MENU_SEL) a terminal item will initiate some action in the system.

The syntax of the three menu messages are:

#MENU_LIST StartingItemNumber, EndingItemNumber, {{MenuPath}}

Where:

StartingItemNumber is the item number of the first item to be returned in the menu response

EndingItemNumber is the last item to be returned

{{MenuPath}} is the navigation path for the current menu tier

12 Technical Sales: 1.800.705.2103

#MENU_RESP {{<MenuName id=”itemId” children=”0” itemnum=”1” idpath=”tier1>tier2>etc”
disppath=”TierName” display=”Item ID” otherData=”123456” moreData=”xyz” />}}

The StreamNet service will respond to a #MENULIST message with a series of menu response messages,
one for each menu item requested. The payload of the menu response message is XML-like, items may or may
not be present and the order of the listed items may change.

The following are some of the items that will always be present:

id This is the identifier for this item.

display

children

itemnum

idpath

disppath This is a more readable version of the idpath to be used on user interfaces.

MenuName Generally, this may be ignored.

In addition to the required items there may be any number of context specific items. These items provide
additional information but are only defined for that specific menu.

#MENU_SEL {{MenuPath}}

Where {{MenuPath}} is the navigation path of the item being selected. The MenuPath is created by
concatenating the idpath with the itemId as in: {{idpath>itemId}}.

This is the text shown in the menu for this item. This should be a more readable
version of the “id”.

This is how many items are in the next tier menu below this item. 0 indicates that this
is a terminal item, and there is no menu tier below this item.

This indicates the item number within the menu list. Receiving itemnum=”-n” (any
negative integer) indicates that there are no more items at this tier of the menu.

This is the menu navigation path taken to arrive at this menu tier. The path is specified
by a list of “id” fields separated by the greater-than sign, “>”.

NOTE f : Do not use the #MENU_SEL outside of the context of menu navigation. Menus can
and will change.

Chapter 3: ASCII Overview 13

Menu Navigation

The menu navigation process begins with the controller or user interface device requesting the top level of a
menu. Menus can be very long so it is recommended that requests specify a small range of menu items to be
returned. The controller must then repeat the #MENU_LIST command changing the specified range until it
has all of the menu items desired.

The requestor must request the menu by name:

#MENU_LIST 1,6, {{MenuName}}

In response the requested items are returned, one #MENU_RESP for each item requested plus one if the end
of the list is reached.

#MENU_RESP {{<MenuName id=”itemId” children=”0” itemnum=”1” idpath=”MenuName”
disppath=”Menu Name” display=”Item ID” otherData=”123456” moreData=”xyz” />}}

Menus can be very long so it is recommended that requests specify a small range of menu items to be returned.
The controller must then repeat the #MENU_LIST command changing the specified range until it has all of
the menu items desired. When all of the items in the menu tier have been sent a separate #MENU_RESP
message will be sent with itemnum=”-n”.

Note that if exactly the maximum number of items are requested then an additional and final f
#MENU_RESP will be returned with itemnum=”-n”.

The user interface should display a list of the items’ “display” fields.

Next the user selects an item from the menu.

If the item is a terminal item the UI device sends a #MENU_SEL command specifying the “path” of the item
selected to indicate that an action has been requested.

#MENU_SEL {{MenuName>tier1ItemId}}

If the item is not terminal then the UI device will send a #MENU_LIST message to request the next tier of the
menu:

#MENU_LIST StartingItemNumber, EndingItemNumber, {{MenuName>tier1ItemId}}

The StreamNet service then returns the next tier of the menu. There can be an arbitrary number of menu
tiers.

Path names can be of arbitrary length. Some example path names are:

{{ media}}

{{ media>rock}}

{{ media>rock>artists}}

{{ media>rock>artists>beatles}}

{{ media>rock>artists>beatles>white album}}

{{ media>rock>artists>beatles>white album>helter skelter}}

{{sources>dvd1}}

14 Technical Sales: 1.800.705.2103

#REPORT MESSAGES

The primary mechanism for a StreamNet service to convey its current state and status is by sending #REPORT
ASCII messages. #REPORT messages may be sent in response to a #QUERY command or they may be
sent unsolicited.

A #REPORT sent in response to a #QUERY will be routed as an ordinary ASCII message. However, an
unsolicited #REPORT will not be routed as an ASCII command.

The “FromAddress” of the #REPORT message will indicate which service sent the #REPORT. Usually, the
FromAddress will have the subnode address, “~STATUS” attached to it.

The payload of a #REPORT message is XML-like, populated with label/value pairs of the form,

<LABEL=”value”>.

#@ToAddress:FromAddress~STATUS#REPORT {{<reportType LABEL1=”VALUE”
LABEL2=”VALUE” LABEL3=”VALUE”/>}}

The reportType field should not be used for any purpose. Only the FromAddress and the label/value pairs are
significant. The label/value pairs may be in any order. A particular #REPORT may omit some label/value pairs
or new label/value pairs may be added at any time. Any unrecognized label/value pairs should be ignored.

Some special characters in the #REPORT message will be “escaped”, using HTML style escape sequences.
For example, the VALUE field cannot contain a quotation mark, so every quotation mark that is part of the
VALUE field will be replaced with " or "

Example:

<ReportType Title=”He Said,"YES!"”> or <ReportType Title=”He Said,"YES!"”>
(See Character Escape Sequences section for more information).

Label/value pairs will differ from device type to device type or service type to service type (See the documentation
for each device/service for specific label/value pairs supported.

#QUERY/#REPORT Messages

Upon receiving a #QUERY message, a StreamNet service will send a #REPORT message with the requested
information. The solicited #REPORT message will addressed to the “FromAddress” of #QUERY message.
The the response may be split into multiple #REPORT messages. No message may exceed the 1000 char­acter limit.

---------------------------------------------------------------------------------------

#QUERY/#REPORT Example

The “Touchpanel” service sends:

#@Kitchen Player:Touchpanel#QUERY current_source

The “Kitchen Player” service responds with:

#@Touchpanel:Kitchen Player#REPORT {{<report type=”state” currentSource=”myXM”
currentSourceIP=”10.15.96.149” permId=”MLA10105151001161008019_1” />}}

---------------------------------------------------------------------------------------

Chapter 3: ASCII Overview 15

Unsolicited #REPORT

Unsolicited #REPORT messages are sent periodically and when the status of the service changes. The
unsolicited #REPORT messages are sent through any of several mechanisms.

Most commonly the unsolicited #REPORT message is sent using UDP on the multicast IP address which has
been assigned to the service for that purpose. This multicast address is referred to as the service’s “Status
Multicast Address” (See Multicast Addresses section).

Another common method of receiving unsolicited #REPORT messages is through “registration”. A TCP client
may register to receive unsolicited #REPORT messages by sending a #REGISTER message to the root
service of the device to which it is connected (See TCP Client section).

During device configuration a UDP address and port number may be designated to receive all unsolicited
#REPORT messages. This is called “subscribing to the status of a service” or “subscription”.

For a central controller type system topology, “subscription” is the recommended method of receiving status.

ASCII ADDRESSING AND ROUTING FOR TCP CONTROL

A common way for third parties to control a StreamNet system is through a TCP connection. The Controller
device makes a TCP connection (Port 15000) to any StreamNet device. The third party controller is the TCP
client and the StreamNet device acts as the TCP server. Typically each StreamNet device supports a maximum
of 4 TCP clients.

If a whole system is to be controlled through this connection, it is recommended that a dedicated StreamNet
device such as a ControLinX be used for this purpose. Once a TCP connection is made the controller may
send commands and receive responses to #QUERY messages. Any messages sent by the controller should
use the proper “ToAddress” but should completely leave off the “FromAddress”. The StreamNet router will
add the appropriate “FromAddress” which will be of the form “rootServiceName~TCPn.n.n.n_pppp”, where
n.n.n.n is the IP address of the TCP client and pppp is the port number of the TCP connection.

An example of how to address a command sent through the TCP portal:

#@ToWhom#COMMAND

To receive unsolicited status reports the device must send #REGISTER messages to the root service of the
device to which it is connected. A #REGISTER message is required for every service that the controller
wishes to monitor. The #REGISTER command times out after 30 seconds, so the #REGISTER commands
must be repeated for as long as the controller desires to receive status reports. The repeating #REGISTER
commands can be used as a heart beat to keep the TCP connection open.

An example of a typical #REGISTER command:

#REGISTER {{ServiceName}}

Notice that there is no ToAddress and no FromAddress. Leaving off the ToAddress causes the message to be
sent to the local root service and the FromAddress will be filled in by the StreamNet routing function.

16 Technical Sales: 1.800.705.2103

ASCII CHARACTER ESCAPE SEQUENCES

Sometimes characters which have a special meaning in an ASCII-based protocol will occur within text strings;
therefore, there must be a way to indicate that the character in a particular instance does NOT convey its
special meaning. This situation arises for StreamNet menu responses and status reports which have an XML
style format. The double quotation mark cannot occur within a string of characters without being confused with
the double quotation marks meant to enclose the string.

World Wide Web protocols use several methods for escaping characters and unfortunately all of these methods
have been used by StreamNet drivers in the past. Henceforth, the StreamNet ASCII protocol shall use only the
HTML style “&#nnnn;” format for escaping characters within literal strings (nnnn represents a decimal number
of multiple digits). There should not be a need to escape any characters besides the double quotation mark
but parsers should be prepared for any character to be escaped.

For historical purposes the various methods previously used for escaping the double quotation mark (“) are
listed here.

The double quotation mark, “, has been represented variously as:

"

"

"

%22

\”

STREAMNET MACROS

During configuration of the StreamNet system the integrator may define a quantity of “macros”. Macros are
a list of StreamNet commands that when invoked get executed in order. Variable time delays maybe added
between the execution of the commands. It is usually a StreamNet Root service which executes a macro.

When a macro is defined the integrator must give the macro a unique name. This name is later used to invoke
execution of the macro. Macros are very simple. Once a macro is invoked it continues until completion. There
are no conditional commands.

Macros can be invoked by third party controllers using the ASCII command, #MACRO.

Some system events may have macros attached to them. For example, the integrator may define a macro
to be executed when a GPIO input detects a contact closure. Another macro may be defined for when the
contact closure ends.

Chapter 3: ASCII Overview 17

18 Technical Sales: 1.800.705.2103

Chapter 4: Overview of Services

The scope of this manual is to provide details on how to integrate a 3rd Party Controllers with a StreamNet IP­Based Media Distribution system.

It is assumed that the user understands User Datagram Protocol (UDP), TCP and Unicast and Multicast
addressing.

It is also assumed that the user has used the StreamNet Dealer Setup tool to configure the StreamNet
system.

This chapter and the subsequent information in this document explain how to communicate with the StreamNet
system and integrate a 3rd Party Controller with a StreamNet system.

COMMUNICATING WITH THE STREAMNET SYSTEM

The StreamNet protocol uses ASCII messages to communicate with services associated with the devices in
the StreamNet system. These messages are either control or status messages.

SERVICES

In the StreamNet system, system/device functions are grouped together into logical constructs called Services.
A single StreamNet device may host multiple services. All communication with StreamNet is addressed to one
or more of these services hosted by the individual devices.

ASCII messages are not addressed to devices but to these virtual services which reside on each device. This
scheme alleviates the need to know the IP addresses of every StreamNet device.

Service Names

Every service must have a unique name which can be used to address ASCII messages. Every service may
have a room name associated with it. Services may also be assigned to multiple group names. Service names,
room names and group names may all be used to address ASCII messages. If a room name is used as an
address, all services assigned to that room will react. If a group name is used, all services assigned to that
group will react. There is a special group name (All) to which all services will react.

Service Types

The following is a list of service types supported, although not all physical StreamNet devices support all the
listed services.

• Audio Renderer

Audio/Video Renderer•

• Audio Source

Audio/Video Source•

• Audio-only Stream Proxy

User Interface (• UI)

• Intercom

General Purpose IO (• GPIO)

• Root

Chapter 4: Overview of Services 19

Common Services by Device

The following is not a comprehensive list of services available. To determine the services available for a specific
StreamNet application, consult the appropriate device documentation.

am P l If I e r / Pl a y e r de v I C e

(ie.: SpeakerLinX SL220, SL250, SL251, SL254,
SL9250-CS)

• Audio Renderer

• Audio Source

• Audio-only Stream Proxy

User Interface (• UI)

• Intercom

• Root

au d I o / vI d e o eN C o d e r de v I C e

(ie.: MediaLinX MLA100, MLA101, MLAV300,
MLA4000, MLA9101-CS, MLAV9300-CS)

Audio/Video Source•

• Audio-only Stream Proxy (MLA100 & MLA101

only)

• Root

to u C h Pa N e l

(ie.: TouchLinX TL430, TL700)

User Interface (• UI)

• Intercom

• Root

le g a C y Co N t r o l l e r de v I C e

(ie.: ControlLinX CL100, CL9100-CS)

General Purpose IO (• GPIO)

• Root

Service Configuration

Each physical StreamNet device may be configured to have some or all of its specific services enabled.

The Root Service is the only service that is always active on all devices.

A Media Server in Room X may have:

An Audio Renderer Service•

An Audio/Video Renderer Service•

An Intercom Service•

An Audio Source Service•

An Audio/Video Source Service•

Audio-only Local Source Service•

An Audio-only Stream Proxy Service•

A Root Service•

An Encoder in Room Y may have:

An Audio Source Service•

An Audio/Video Source Service•

An Audio-only Local Source Service•

An Audio-only Stream Proxy Service•

A Root Service•

An Amplifier in Room Z may have:

An Audio Renderer Service•

A Root Service•

20 Technical Sales: 1.800.705.2103

Chapter 5: Services Described

AUDIO/VIDEO RENDERER SERVICE

Overview

A Renderer Service (Audio/Video) is responsible for playing audio and/or video from network sources. It is also
responsible for controlling any attached amplifier or display device.

Renderers may support various combinations of the possible media stream types. Some of the media streams
currently supported are:

Stereo Audio (44.1KHz, 16bit, stereo, linear PCM) 1.

S/PDIF Digital Audio (transparent pass-through of S/PDIF bit stream)2.

Uncompressed Video (1 Gbps uncompressed video stream of various resolutions)3.

Compressed Video (less than 100Mbps video stream of various resolutions)4.

New stream types or variations of these stream types may be added at any time.

A Renderer may create S/PDIF, line level, or amplified audio outputs. Renderers which support video may
output HDMI/DVI, component, composite, or S-video.

The Renderer service may provide controls for the output of the media being rendered, such as volume, bass,
treble, and Display On/Off.

AV Multi-Zone Operation

Audio and video renderers may be joined together into a “super zone” or “party mode” where they all play the
same source. This is called Multi-zone operation. The #MULTIAUDIO command is used to control this mode.
Renderer services may be forced to “JOIN” or “LEAVE” a multi-zone session. Each multi-zone session has a
name specified when it is created. A renderer may only be a member of one multi-zone session.

If one renderer in a multi-zone session changes its source then all renderers in the session will follow. This will
continue as long as the renderer service is part of the session. The renderer will drop out of the session if it
receives a #MULTIAUDIO LEAVE or #ACTIVE OFF.

The source selection is the only attribute which will track throughout the multi-zone session. In this way volume
and other tone controls may be adjusted for each zone individually.

Commands may be addressed to the SessionName. If volume commands are sent addressed to the session, it
is recommended to use #LEVEL_SET commands instead of #LEVEL_UP and #LEVEL_DOWN commands.
The current volume levels may be different from zone to zone. The #LEVEL_SET will put all of the zones at
the same level.

If Do Not Disturb (DND) is enabled then the JOIN command will be ignored.

If Multiaudio is disabled during configuration then the JOIN will be ignored.

After creating the multi-zone session it is recommended to send #ACTIVE ON, #MUTE OFF and maybe
#LEVEL_SET VOLUME DEFAULT. The controller may also send a source select command to force the
session to have the same audio source as the current room. In this way it doesn’t matter whether the source
was selected before or after the session was established. All of these commands would be addressed to the
sessionName.

Chapter 5: Services Described 21

Examples

Audio/Video Renderer Command Details

The following pages detail the functions of many StreamNet ASCII commands.

The format of the text is as follows:

A brief description of what the command does.•

Command name and format.•

An example of the ASCII • message syntax for the command.

Notes specific to the command and explanation of possible responses generated.•

Co m m a N d : #aCtIve off

Sets the Active Audio Renderer Service to OFF (InActive).

Example: #@Room 1 Player:~UDP10.15.0.11_5000#ACTIVE OFF

Command a renderer service to enter the OFF state.

The Audio Renderer service Room 1 Player is set to the OFF state.

NOTE f : In this state, the renderer service will not listen to the audio source. It will also stop all
audio output. In effect, if there was an audio source being rendered, the rendering will stop
(that is, no music will be heard).

Co m m a N d : #aCtIve oN

Sets the Active Audio Renderer Service to ON (Active).

Example: #@Room 1 Player:~UDP10.15.0.11_5000#ACTIVE ON

The audio renderer service Room 1 Player is set to the ON state.

NOTE f : When the renderer service enters the ON state, it will maintain the last settings for
the Audio Source, Treble, Bass, Equalizer and Balance. However, Volume will be reset to the
default level set during configuration. Mute will be OFF and any multi-zone audio sessions
will be dropped.

Co m m a N d : #amP off

Commands a Renderer Service to turn its Amplifier OFF.

Example: #@Room 1 Player:~UDP10.15.0.11_5000#AMP OFF

The amplifier associated with the Audio Renderer service Room 1 Player is set to the OFF state.

NOTE f : Although the amplifier is turned off, if the renderer service is active, it will still be
listening to the audio source. Commands can still be issued to the renderer service to change
the audio sources and settings.

22 Technical Sales: 1.800.705.2103

Co m m a N d : #amP oN

Commands a Renderer Service to turn an Amplifier ON.

Example: #@Room 1 Player:~UDP10.15.0.11_5000#AMP ON

The amplifier associated with the Audio Renderer service Room 1 Player is set to the ON state.

NOTE f : #AMP OFF and #AMP ON have no effect on the renderer settings.

le v e l S

To control, report, and display analog (i.e., continuous) quantities such as Volume, Balance, Brightness, and
so on, the level construct was established. A level is a variable which may have any value between 0% and
100%, inclusive. This percentage is mapped to the actual analog value based on context and this mapping
need not be linear.

Example:

A volume of 0% might be an attenuation of infinity, 50% is -25dB, 75% is -15dB, and 100% is 0dB.

For Audio Balance 0% is all left channel, 50% is equal for both channels, and 100% is all right channel.

Co m m a N d : #eq_PreSet

Co m m a N d : #level_dN balaNCe

Commands a Renderer Service to Shift the Balance Level to the Left Channel.

Example: #@Room 1 Player:~UDP10.15.0.11_5000#LEVEL_DN BALANCE

Shifts the Balance level of the Audio Renderer service Room 1 Player towards the Left Channel (by Decreas­ing the Right Channel).

Co m m a N d : #level_dN baNd_x

Decreases the Band Level.

x is the Band number indicator (1 through 5).•

Example: #@Room 1 Player:~UDP10.15.0.11_5000#LEVEL_DN BAND_1

Commands a Renderer Service to Decrease the specified Band Level. In the above example, Band Level,
Indicator 1 is decreased for the Audio Renderer service on the device Room 1 Player.

Co m m a N d : #level_dN baSS

Commands a Renderer Service to Decrease the Bass Level.

Example: #@Room 1 Player:~UDP10.15.0.11_5000#LEVEL_DN BASS

Decrease the Bass Level of Audio Renderer service Room 1 Player.

Co m m a N d : #level_dN treb

Commands a Renderer Service to Decrease the Treble Level.

Example: #@Room 1 Player:~UDP10.15.0.11_5000#LEVEL_DN TREB

Decrease the Trebel Level of Audio Renderer service Room 1 Player.

Co m m a N d : #level_dN vol

Commands a Renderer Service to Decrease the Volume Level.

Example: #@Room 1 Player:~UDP10.15.0.11_5000#LEVEL_DN VOL

Decrease the Volume Level of Audio Renderer service Room 1 Player.

Chapter 5: Services Described 23

Co m m a N d : #level_Set balaNCe, x

Commands a Renderer Service to Set the Balance Level.

Example: #@Room 1 Player:~UDP10.15.0.11_5000#LEVEL_SET BALANCE, x

Set the Balance Level of Audio Renderer service Room 1 Player based on the value x.

x is a number between 0 – 100.•

x = 50 will set the balance to equal for both channels.•

x < 50 will shift the balance toward the left channel (by decreasing the right channel).•

x > 50 will shift the balance toward the right channel (by decreasing the left channel).•

Co m m a N d : #level_Set baNd_x, y

Sets the Band Level to a specific value.

x is the band indicator (1 through 5).•

y is a number between 0 – 100.•

y = 50 will set the BAND_1 to nominal.•

y < 50 will decrease the BAND_1 level from nominal.•

y > 50 will increase the BAND_1 level from nominal.•

Example: #@Room 1 Player:~UDP10.15.0.11_5000#LEVEL_SET BAND_1, y

Commands a Renderer Service to set the BAND_1 Level.

Set the Band_1 Level of Audio Renderer service Room 1 Player based on the value of y.

Co m m a N d : #level_Set baSS, x

Commands a Renderer Service to Set the Bass Level.

Example: #@Room 1 Player:~UDP10.15.0.11_5000#LEVEL_SET BASS, x

Set the Bass Level of the Audio Renderer service Room 1 Player based on the value x.

x is a number between 0 – 100.•

x = 50 will set the bass to nominal.•

x < 50 will decrease the bass from nominal.•

x > 50 will increase the bass from nominal.•

Co m m a N d : #level_Set treb, x

Commands a Renderer Service to Set the Treble Level.

Example: #@Room 1 Player:~UDP10.15.0.11_5000#LEVEL_SET TREB, x

Set the Trebel Level of the Audio Renderer service Room 1 Player based on the value x.

x is a number between 0 – 100. •

x = 50 will set the treble to nominal. •

x < 50 will decrease the treble level from nominal.•

x > 50 will increase the treble level from nominal.•

Co m m a N d : #level_Set vol, x

Commands a Renderer Service to Set the Volume Level.

Example: #@Room 1 Player:~UDP10.15.0.11_5000#LEVEL_SET VOL, x

Set the Volume Level of the Audio Renderer service Room 1 Player based on the value x.

x is a number between 0 – 100. •

x = 0 will set the volume to the minimum level. •

x =100 will set the volume to the maximum level.•

24 Technical Sales: 1.800.705.2103

Co m m a N d : #level_uP balaNCe

Commands a Renderer Service to Shift the Balance Level to the Right Channel.

Example: #@Room 1 Player:~UDP10.15.0.11_5000#LEVEL_UP BALANCE

Shifts the Balance Level of the Audio Renderer service Room 1 Player towards the Right Channel (by de­creasing the Left Channel.)

Co m m a N d : #level_uP baNd_x

Increases the device Equalizer Band Level.

x is the band indicator (1 through 5).•

Example: #@Room 1 Player:~UDP10.15.0.11_5000#LEVEL_UP BAND_1

Commands a Renderer Service to Increase the BAND_1 Level.

Increases the Band Level, Indicator 1 for the Audio Renderer service Room 1 Player.

Co m m a N d : #level_uP baSS

Commands a Renderer Service to Increase the Bass Level.

Example: #@Room 1 Player:~UDP10.15.0.11_5000#LEVEL_UP BASS

Increases the Bass Level of the Audio Renderer service Room 1 Player.

Co m m a N d : #level_uP treb

Commands a Renderer Service to Increase the Treble Level.

Example: #@Room 1 Player:~UDP10.15.0.11_5000#LEVEL_UP TREB

Increases the Trebel Level of the Audio Renderer service Room 1 Player.

Co m m a N d : #level_uP vol

Commands a Renderer Service to Increase the Volume Level.

Example: #@Room 1 Player:~UDP10.15.0.11_5000#LEVEL_UP VOL

Increases the Volume level of the Audio Renderer service Room 1 Player.

Chapter 5: Services Described 25

Co m m a N d : #meNu_lISt m, n, sources

Gets a List of Audio Sources available to the specified Renderer Service.

Example: #@Room 2 Player:~UDP10.15.0.11_5000#MENU_LIST 1,6,SOURCES

NOTE f : m,n specifies the range of items to be listed from the list of sources. m = item number
of the first item on the menu list to be listed, through n = the last item in the range.

Example: m=1 and n=6, will show the first through the sixth item, or m=3 and n=5 will show the third
through the fifth items in the menu list.

NOTE f : The command is requesting a list of six audio sources associated with this Service.
The response can come in a series of messages depending on the numbers of audio sources
associated with the Room 2 Player.

re S P o N S e S re C e I v e d
fI r S t re S P o N S e

#@TL3800538001161007532_1~UDP10.15.0.11_2141:Room 2 Player#MENU_RESP
{{<source id=”myXM” children=”0” itemnum=”1” idpath=”sources” disppath=”sources”
display=”myXM” type=”audio/source” />}}

id• = “myXM”

“• myXM”: Service name of the audio sources. Any commands issued to this audio source must be
addressed to its Service name “myXM”.

children• = ”0”: indicates a terminal node (no more lists under this audio source).

itemnum• = ”1”: indicates the item number on this menu. 1 indicates this is the first item on the

menu. If this is a positive number, then there are more audio sources in the list. A negative number
indicates the end of the list.

idpath• = “sources”: If there are further list(s) under this MENU, then the IDPath concatenated with
the Source ID defines the path for the next item on the menu.

dispath• = “sources”: This string can be used to display the current menu path, if desired.

display• = “myXM”: This string can be used to display this menu item. (based on itemnum).

type• = “audio/source”: only audio/source serviceType commands may be issued to this service.

The remaining responses show four more audio sources and can be parsed similarly:

Se C o N d re S P o N S e

#@TL3800538001161007532_1~UDP10.15.0.11_2141:Room 2 Player#MENU_RESP
{{<source id=”Stream 3” children=”0” itemnum=”2” idpath=”sources” disppath=”sources”
display=”Stream 3” type=”audio/source” />}}

th I r d re S P o N S e

#@TL3800538001161007532_1~UDP10.15.0.11_2141:Room 2 Player#MENU_RESP
{{<source id=”Local Source 2” children=”0” itemnum=”3” idpath=”sources” disppath=”sources”
display=”Local Source 2” type=”audio/localsource” />}}

fo u r t h re S P o N S e

#@TL3800538001161007532_1~UDP10.15.0.11_2141:Room 2 Player#MENU_RESP
{{<source id=”Stream 1” children=”0” itemnum=”4” idpath=”sources” disppath=”sources”
display=”Stream 1” type=”audio/source” />}}

fI f t h re S P o N e

#@TL3800538001161007532_1~UDP10.15.0.11_2141:Room 2 Player#MENU_RESP
{{<source id=”Stream 2” children=”0” itemnum=”5” idpath=”sources” disppath=”sources”
display=”Stream 2” type=”audio/source” />}}

26 Technical Sales: 1.800.705.2103

SI x t h re S P o N S e

#@TL3800538001161007532_1~UDP10.15.0.11_2141:Room 2 Player#MENU_RESP
{{<sources idpath=”sources” itemnum=”-1” />}}

NOTE f : itemnum=”-1”. The “-“ sign indicates that there are no more audio sources.

If itemnum = a positive number, then there are more audio sources assigned to this Service
and the command needs to be re-issued until itemnum=”-x” is received.

Example: #@Room 2 Player:~UDP10.15.0.11_5000#MENU_LIST 7,9,SOURCES will get a response
detailing the seventh through ninth items from the MENU_LIST.

NOTE f : If there are only five items in the menu (as in this case), then a command requesting
a list of ten sources, like:

#@Room 2 Player:~UDP10.15.0.11_5000#MENU_LIST 1,10,SOURCES

will still generate the exact same response as above, with the sixth response showing
“itemnum=-1”.

Co m m a N d : #meNu_Sel {{path}}

Selects the Audio Sources from a list available to the Renderer Service.

Example: #@Room 2 Player:~UDP10.15.0.11_5000#MENU_SEL {{sources>Stream 2}}

This command selects Stream 2 as the source to be rendered.

NOTE f : The menu path for this list is established by concatenating the item’s idpath and source id
separated by the “>” symbol.

Example: {{sources>Stream 2}} becomes the menu path to select the fifth (itemnum=5) audio source
based on the responses received from the MENU_LIST example above.

NOTE f : Alternatively, in this specific case, an #SRC_SEL command (see below) may be
used.

Co m m a N d : #multIaudIo

This command causes the renderer service to join an AV super-zone referred to as a “multi-zone session”.
(see section: AV Multi-Zone Operation)

Co m m a N d : #multIaudIo JoIN {{S e S S I o N Na m e }}

sessionName is the name of the multi-zone session. This name may be any string which would be a valid
StreamNet group address name; but it should not be an existing group name because a new group will be
formed using this name. Using an existing group name would have the effect of making the existing group
members part of the multi-zone session and vice versa.

When the addressed renderers receive a JOIN command they will automatically leave any currently active
session to join the new session. Also if the renderer is in the active=”0” state then it will change to the ac­tive=”1” state before joining the session.

Co m m a N d : #multIaudIo leave

When the addressed renderers receive a LEAVE command they will immediately leave any currently active
session.

Chapter 5: Services Described 27

Co m m a N d : #mute off

Commands a Renderer Service to set Mute to the OFF state.

Example: #@Room 1 Player:~UDP10.15.0.11_5000#MUTE OFF

Co m m a N d : #mute oN

Commands a Renderer Service to set Mute to the ON state.

Example: #@Room 1 Player:~UDP10.15.0.11_5000#MUTE ON

Co m m a N d : #mute toggle

Commands a Renderer Service to Toggle the state of Mute.

Example: #@Room 1 Player:~UDP10.15.0.11_5000#MUTE TOGGLE

Co m m a N d : #query renderer

Query the settings for current Audio Source being Rendered.

Example: #@Room 1 Player:~UDP10.15.0.11_5000#QUERY renderer

NOTE f : A #QUERY command is interrogative and gets a declarative response #REPORT.

The #QUERY RENDERER gets a report indicating the current settings for the Audio Source
being rendered.

Sample response:

#@SL22004280001161000057_4~UDP10.15.0.11_4881:Room 1 Player#REPORT {{<report type=”state”
vol=”29” balance=”50” bass=”50” treb=”50” loud=”0” mute=”0” audioSession=”All Rooms Multiroom”
audioSessionActive=”1” ampOn=”1” />}}

Pa r S I N g re P o r t S

NOTE f : Even though the format looks like XML, it isn’t. The report will always be flat (i.e., no
nested <> brackets).

The order of the attributes may change. Some may be added or omitted in any given #REPORT message.
Parsing of the message should key off the attribute name. For example, for “balance”, a suggested parsing
method would be to scan for “=”. The attribute name is to the left of “=” and the value is to the right. The
fromAddress (i.e., Room 1 Player) should be used to qualify the report before accepting the other data attri­butes (i.e., Room 1 Player). Validate the origin of the message before storing or using the reported status.

NOTE f : The data may be distributed among multiple #REPORT messages even if the
report(s) is the result of a single #QUERY message.

Co m m a N d : #query CurreNt_SourCe

Queries the current Audio Sources being Rendered.

Example: #@Room 2 Player:~UDP10.15.0.11_5000#QUERY CURRENT_SOURCE

Response Received:

#@TL3800538001161007532_1~UDP10.15.0.11_2230:Room 2 Player#REPORT {{<report type=”state”
currentSource=”myXM” currentSourceIP=”10.15.96.149” permId=”MLA10105151001161008019_1” />}}

NOTE f : Room 2 Player is currently rendering an Audio Source called “myXM”.

Co m m a N d : #Set

28 Technical Sales: 1.800.705.2103

Co m m a N d : #SleeP

Commands a Renderer Service to set a specific device to the Sleep state.

Example: #@Room 1 Player:~UDP10.15.0.11_5000#SLEEP

Sets the Room 1 Player device to Sleep.

Co m m a N d : #SrC_Sel

De-selects all Audio Sources from Renderer.

Example: #@Room 2 Player:~UDP10.15.0.11_5000#SRC_SEL “ “

NOTE f : If no Audio Source is specified between the “ “, the current Audio Source will be
deselected resulting in no Audio Source being rendered by the service: Room 2 Player.

Co m m a N d : #SrC_Sel {{source Id}}

Selects a specific Audio Source to be played.

Example: #@Room 2 Player:~UDP10.15.0.11_5000#SRC_SEL {{Stream 3}}

Selects Stream 3 to be rendered by service Room 2 Player.

NOTE f : The source name is case sensitive and must be bound by the double curly brackets,
as in {{Stream 3}}. The double curly brackets are required since the Service name has a
space (non alpha-numeric character)

Co m m a N d : #temPSrC {{S o u r C e Na m e }} [,t I m e ou t v a l u e ]

Forces the renderer service to temporarily select the specified source to be played. The time out value (in
seconds) is optional. When the #TEMPSRC command is canceled or times out the renderer returns to the
original source. If a new #TEMPSRC command comes in while another is still active the new command takes
effect. Nested #TEMPSRC commands are not supported; the first #TEMPSRC is canceled by the second.
And when the second #TEMPSRC is canceled, the renderer will return to the original source.

Example: #TEMPSRC {{camera1}}, 60

Will switch renderer to “camera1” for 60 seconds and then switch back to whatever source it was rendering
before.

Co m m a N d : #temPSrC {{S o u r C e Na m e }}, off

If there is an active #TEMPSRC command and the temporary source has the specified name then the
#TEMPSRC command will be canceled and the renderer service will return to the original source. If the

source name does not match the command will have no effect. In this way a #TEMPSRC command may
be cancelled without fear of interfering with a different #TEMPSRC command which may have subsequently
overridden it.

Co m m a N d : #temPSrC off

Will unconditionally cancel any active #TEMPSRC command.

Chapter 5: Services Described 29

AUDIO/VIDEO SOURCE AND SOURCE PROXY SERVICE

Overview

An Audio/Video Source service is responsible for taking in audio and video from some source and encoding
them into IP-based data packets and transmitting these packets over the network. The Source service may
also provide some control over the source device.

All current StreamNet AV Source services are controlled in more less the the same way. Typically all control
functionality is defined by the StreamNet Soft Adapter (SSA) which gets installed when the device is configured.
Some source services may provide IR control of the attached AV device. Some source services may provide
serial control of the attached AV device with the appropriate SSA. IP control of the AV device resides entirely
with the SSA. Or control of the attached AV device may be provided directly by a third party controller.

The primary difference between an AV Proxy service and other AV Source services is that the Proxy service
gets the audio and/or video over IP (possibly from the internet); and the other source services capture the
audio/video on physical connections such as S/PDIF or HDMI.

The Audio/Video Source Proxy Service represents (or proxies) network media sources which do not conform
to the StreamNet protocol (non-StreamNet devices). For example, an Audio/Video Proxy Service will convert
the content and control commands of a 3rd Party media server to be compatible with the menus and other
commands of the StreamNet ASCII protocol.

An Audio/Video Proxy Service must have a StreamNet Source Adapter installed to browse the source content
and to initiate the media stream. The Source Adapter translates various media servers’ protocol or internet
radio services’ protocol into standard StreamNet protocol.

The Audio/Video Source service may also provide controls (such as IR or RS-232) for management of the
legacy AV source device.

Examples

Co m m a N d : #meNu_lISt m, n, {{path}}

Requests a List of Media associated with a Media Server.

Example: #@Stream 1:~UDP10.15.0.11_5000#menu_list 1,10,media

NOTE f : This message is addressed to Stream 1. The command is requesting menu items 1
to 10 of the media associated with this service. Media is the default path name for the first
menu list.

re S P o N S e S re C e I v e d
fI r S t re S P o N S e

#@SL22004285001161000172_4~TCP10.15.0.11_4750:Stream 1 #MENU_RESP {{<item idpath=”media”
disppath=”media” itemnum=”1” id=”All Songs” display=”All Songs” children=”1078” />}}

Example: {{media>All Songs}} becomes the next menu path.

itemnum = “1”• A non-zero number indicates this is the first item on this menu list.

display = “All Songs”• is the display name for this list.

children = ”1078”• indicates that this is not a terminal node (i.e., there is another menu list below

this level).

30 Technical Sales: 1.800.705.2103

Se C o N d re S P o N S e

#@SL22004285001161000172_4~TCP10.15.0.11_4750:Stream 1#MENU_RESP {{<item idpath=”media”
disppath=”media” itemnum=”2” id=”Artists” display=”Artists” children=”63” />}}

The next level menu path for this list is established by concatenating the item’s idpath and ID separated by
the “>” symbol.

Example: {{media>Artists}} becomes the next menu path.

itemnum = “2”• indicates this is the second item on this menu list.

display = “Artists• ” is the display name for this list.

children = ”63”• indicates that this is not a terminal node. ie: there is another menu list below this

level.

re S P o N S e S 3 t h r o u g h 5

These responses can be similarly parsed.

#@SL22004285001161000172_4~TCP10.15.0.11_4750:Stream 1 #MENU_RESP {{<item •
idpath=”media” disppath=”media” itemnum=”3” id=”Albums” display=”Albums” children=”116”
/>}}

#@SL22004285001161000172_4~TCP10.15.0.11_4750:Stream 1 #MENU_RESP {{<item •
idpath=”media” disppath=”media” itemnum=”4” id=”Genres” display=”Genres” children=”12”
/>}}

#@SL22004285001161000172_4~TCP10.15.0.11_4750:Stream 1 #MENU_RESP {{<item •
idpath=”media” disppath=”media” itemnum=”5” id=”Playlists” display=”Playlists” children=”3”
/>}}

SI x t h re S P o N S e

#@SL22004285001161000172_4~TCP10.15.0.11_4750:Stream 1 #MENU_RESP {{<item idpath=”media”
disppath=”media” itemnum=”-1” />}}

itemnum = “-1”. The negative value indicates there are no more items on this list.

Su m m a r y

The service Stream 1 menu has five items which are displayed as:

• All Songs

• Artists

Albums•

• Genre

Playlists•

Each of these branches has children (another menu list) under them.

Chapter 5: Services Described 31

Co m m a N d : #meNu_lISt m, n, {{path}}

This command allows the user to traverse down a Menu List.

As explained above, the next level menu path is established by concatenating the item’s idpath and its id
separated by a “>” character.

Example: {{media>All Songs}} becomes the next menu path:

#@Stream 1:~UDP10.15.0.11_5000#menu_list 1,5,{{media>All Songs}}

The command is requesting menu items 1 to 5 of the menu list below the list All Songs, which was the first
item on the previous menu list.

re S P o N S e S re C e I v e d
fI r S t re S P o N S e

#@SL22004285001161000172_4~TCP10.15.0.11_4781:Stream 1 #MENU_RESP {{<song
idpath=”media>All Songs” disppath=”media>All Songs” itemnum=”1” id=”1481” display=”Brown,
Crane, Ker, Finesilver” children=”0” />}}

The next level menu path for this list is established by concatenating the item’s idpath and id separated by a
“>”. Example: {{media>All Songs>1481}} becomes the next menu path for Borwn, Crane, Ker, Finesilver

itemnum=“1”• indicates this is the first item on this menu list.

display=“Brown, Crane, Ker, Finesilver”• for this item.

children = ”0”• , indicates that this may be a terminal node (i.e., there are no items below this level).

Therefore, a further #MENU_LIST command would neither get a response nor a reaction. Instead, as
explained below, a #MENU_SEL command must be issued.

re S P o N S e S 2 t h r o u g h 5

These responses can be similarly parsed.

#@SL22004285001161000172_4~TCP10.15.0.11_4781:Stream 1 #MENU_RESP •
{{<song idpath=”media>All Songs” disppath=”media>All Songs” itemnum=”2” id=”1648”
display=”(Da Le) Yaleo” children=”0” />}}

#@SL22004285001161000172_4~TCP10.15.0.11_4781:Stream 1 #MENU_RESP •
{{<song idpath=”media>All Songs” disppath=”media>All Songs” itemnum=”3” id=”1606”
display=”(Hidden Track)” children=”0” />}}

#@SL22004285001161000172_4~TCP10.15.0.11_4781:Stream 1 #MENU_RESP •
{{<song idpath=”media>All Songs” disppath=”media>All Songs” itemnum=”4” id=”1974”
display=”11 O'Clock Tick Tock” children=”0” />}}

#@SL22004285001161000172_4~TCP10.15.0.11_4781:Stream 1 #MENU_RESP •
{{<song idpath=”media>All Songs” disppath=”media>All Songs” itemnum=”5” id=”1605”
display=”2000 Miles” children=”0” />}}

itemnum• = “5”. The positive value indicates there are more items on this list.

children• = “0”, in each of these items indicates that there are no more items under these items.

Su m m a r y

“All Songs” (the first item on the menu) has a list of items 1 to 5 which are displayed as:

Brown, Crane, Ker, Finesilver1.

(Da Le) Yaleo2.

(Hidden Track)3.

11 OClock Tick Tock4.

2000 Miles5.

32 Technical Sales: 1.800.705.2103

The “All Songs” menu had shown it had 1078 children of which the command #menu_list 1,5,{{media>All
Songs}} requested a list of items 1-5.

Similarly, if the integrator wanted to see the list under the second item, “Artists”, the command syntax would
be:

#@Stream 1:~UDP10.15.0.11_5000#menu_list 1,5,{{media>Artists}}

Co m m a N d : #query SOURCE

Gets details on the current Media being played.

Example: #@Stream 1:~UDP10.15.0.11_5000#QUERY source

re S P o N S e re C e I v e d

#@SL22004285001161000172_4~UDP 10.15.0.11_4028:Stream 1#REPORT {{<report type=”source”
artwork=”http://10.15.100.116/7.0.5/Database/Music/Covers/s4/s3/Nails-Corpus Christi”
display=”song/artist/album/genre” song=”14 Dreams” album=”Corpus Christi” artist=”Nails”
genre=”Rock” time=”376” percent=”59” sngPlIndex=”79” sngPlTotal=”11169” source=”Stream 1”
elapsed=”223744”
next=”14 Years” active=”2” controlState=”PAUSE” shuffle=”0” />}}

This command gives a report of the current song in “Stream 1”•

The display attribute gives a suggestion of which items to display and with what priority.•

In this example, the audio source “Stream 1” is suggesting that the song title is the most important •
item to display, followed by the artist’s name, the album name and finally the genre.

The UI device is not bound by the suggestion.•

NOTE f : #REPORT responses shall in no case exceed 1000 characters, but data may be
distributed among multiple #REPORT messages.

Chapter 5: Services Described 33

USER INTERFACE (UI) SERVICE

Overview

A UI service handles all of the configuration and control for a particular user interface. Some common
functionality provided by UI services are:

Converting key press commands to other ASCII commands.1.

Converting IR codes to key press commands or other ASCII commands.2.

Forwarding commands to a subordinate UI component such as a keypad or Flash GUI.3.

Unlike most other service types, UI services tend to have differing functionality from device to device.

INTERCOM SERVICE

Overview

Behind the scenes, the operation of the intercom service is very complex; but for basic intercom operation only
a few commands are required.

An Intercom session is like a conference call between two or more intercom zones. More than one simultaneous
session may exist for any zone. For simplicity, the StreamNet Intercom service completely manages multiple
Intercom sessions; the controller need not worry about the possibility of multiple sessions. It is possible for the
controller to take complete control of the Intercom sessions but that will not be covered here.

Currently there are three kinds of Intercom Sessions:

A. Station to Station(s) Session

This session type allows two-way communication between two or more intercom stations. When a user
presses the Push-to-Talk button their voice is transmitted to the other stations in the session. Communication
is half-duplex (Only one station may Transmit at a time.) This session will time out after a configurable time if
there is no activity.

B. Room Monitoring Session

This session type allows stations in one or more rooms to listen to (monitor) another room. This not very
different from a Station to Station session except that in the room being monitored the microphone is on by
default. Stations can talk to the room being monitored by pressing their Push-to-Talk buttons. This session will
stay active until terminated.

C. Door Answering Session

This type of session is initiated when the DoorBell button of a DoorLinX is pressed. This session is very
similar to the Room Monitoring session. The Door station is room being monitored. The DoorLinX will play an
announcement MP3 file at the beginning of the session. This session will time out after after a configurable
time if there is no activity.

Station to Station

To start a Station to Station Session send the following command to the zone which is initiating the call:

#INTERCOM CREATE, “ID”, “audience”

This message is sent by a user interface or third party controller to an intercom service causing the intercom
service to create an intercom session between itself and the specified audience.

“ID” is the name of the session. It may be any string but should usually be the same as the “audience”. This
is the name of the session that should be displayed on the User Interface.

“audience” is the service, room or group whose participation is desired. The “audience” is an ASCII protocol
“ToAddress” which is used internally by the IC service to send out commands to start the session.

34 Technical Sales: 1.800.705.2103

To turn on the microphone for a particular zone send the following command addressed to the zone:

#INTERCOM PTT

This command will turn on the microphone and keep it on for 300ms. This command must be repeated at
100ms intervals to keep the microphone on.

When the user is done speaking the following command should be sent:

#INTERCOM PTT OFF

This will immediately turn off the microphone. This is better than waiting for the time out. It is possible to direct
a PTT command to any specific CURRENT session by adding the sessionTag.

A PTT command without any qualifier always transmits to the RECENT session. If there are no CURRENT
sessions then an unqualified PTT will create a new default session.

Normally, it is best to let the Station to Station session time out on its own; however, if desired, the session may
be terminated by sending the command:

#INTERCOM LEAVE [, tagNumber]

Where tagNumber is a unique identification number for an Intercom session. The tag number is assigned
automatically by the system when the session is created. The tag numbers of all sessions are available in the
status report of the intercom service.

If the tag number is omitted all of the sessions will be dropped by the service(s) addressed, station-to-station,
monitor and door sessions. Leave commands will almost always be addressed to a room name.

NOTE: f It is not required to send a leave command for station-to-station or door sessions.
The session will quickly time out if there is no activity. The Leave command is usually sent in
response to a user action to cancel current sessions.

The command will terminate all Intercom sessions in that zone.

Intercom Monitor Session

A room monitoring session allows a user to listen to a remote room from one or more other rooms. To start a
Room Monitoring Session send the following command addressed to the zone to be monitored:

#INTERCOM MONITOR, “roomName”, “audience”

“roomName” is the name of the room which is to be monitored.

“audience” is a service, room, or group which will monitor the specified room.

Note that if there is an existing session monitoring the room then this command ADDS the new audience to
the existing session.

To terminate a room monitoring session in any zone(s) send the following command addressed to the
zone(s):

#INTERCOM LEAVE [,MONITOR]

This message can be sent addressed to a single room to stop that one zone from monitoring or addressed to
the room being monitored to terminate the entire session.

Intercom Entry Sessions

Normally a Entry [answering] Session is initiated automatically by a DoorLinX device when a guest presses the
doorbell button. The “audience” of this Entry session is configurable using the system set-up tool.

The DoorLinX initiates an Entry session with all of the rooms [services] in its “audience”. It begins by playing
a stored MP3 file which typically is a chime but could be any MP3 file. After the first room speaks to the door
station all of the other rooms in the audience are dropped from the session. The microphone at the door is left
open so that the guest may answer.

Chapter 5: Services Described 35

An intercom room may be forced out of a Door Session by sending a Leave command:

#INTERCOM LEAVE [, ENTRY]

#INTERCOM LEAVE [, tag]

If “ENTRY” or “tag” is left off the LEAVE command, all intercom sessions in the addressed room will be
terminated.

Status Report with a Current Intercom Session

The following is a typical status report for a station-to-station intercom session:

#@~STATUS:Room1 Intercom SL#REPORT {{<report type=”intercom” myServiceName=”Ryan’s
Room Intercom SL” serviceType=”intercom” myRoomName=”Ryan’s Room” sessions=”1” active=”1”
recentSessionID=”INTERCOM” recentSessionTag=”00000088” icVol=”84” privacy=”0” DND=”0”
kind=”conversation” monitor=”0” entry=”1” initiator=”Connor’s Room” />}}

Status Report with No Current Intercom Sessions

#@~STATUS:Ryan’s Room Intercom SL#REPORT {{<report type=”intercom” myServiceName=”Ryan’s
Room Intercom SL” serviceType=”intercom” myRoomName=”Ryan’s Room” sessions=”0” active=”0”
recentSessionID=”None” recentSessionTag=”FFFFFFFF” icVol=”84” privacy=”0” DND=”0” kind=”none”
monitor=”0” entry=”1” initiator=”” />}}

36 Technical Sales: 1.800.705.2103

GENERAL PURPOSE IO (GPIO) SERVICE

Overview

The General Purpose IO (GPIO) service can be thought of as a “Miscellaneous Function” or a catch-all type
Service. Services that don’t neatly fit into any of the other services described may often be found under this
umbrella service type. Some of the common I/O types associated with GPIO services are IR, RS232 serial, and
relay contact closures.

Many GPIO services have LUA interpreters associated with them. This allows custom drivers to be written to
perform any functionality desired. See Appendix for commands to control specific devices.

ROOT SERVICE

Overview

Every device has exactly one root service. The root services manage common and miscellaneous housekeeping
functions for each device. The root service is always active, even when all of the other services on the device
have been disabled.

Chapter 5: Services Described 37

38 Technical Sales: 1.800.705.2103

Appendix: SpeakerLinX

The following SpeakerLinX devices will respond only to the specified commands as outlined below.

Commands must be issued to the appropriate serviceType specifying the serviceName in the :toAddress field.

SPEAKERLINX AUDIO RENDERER COMMANDS

SP e a k e r lI N x au d I o re N d e r e r Se r v I C e Co m m a N d S

Device

ASCII STRING COMMENTS

SL220

SL250

SL251

SL254

SL9250-CS

SN1001

#ACTIVE OFF

#ACTIVE ON

#AMP OFF

#AMP ON

#LEVEL_DN BALANCE

#LEVEL_DN BAND_x

#LEVEL_DN BASS

#LEVEL_DN TREB

#LEVEL_DN VOL

#LEVEL_SET BALANCE, x

#LEVEL_SET BAND_x, y

#LEVEL_SET BASS, x

#LEVEL_SET TREB, x

#LEVEL_SET VOL, x

#LEVEL_UP BALANCE

#LEVEL_UP BAND_x

#LEVEL_UP BASS

#LEVEL_UP TREB

#LEVEL_UP VOL

#MENU_LIST m, n, sources

#MENU_SEL {{path}}

#MULTIAUDIO

#MUTE OFF

#MUTE ON

#MUTE TOGGLE

#QUERY CURRENT_SOURCE

#QUERY RENDERER

#SET

#SLEEP

#SRC_SEL

Enter the INACTIVE state

Enter the ACTIVE state

Turn OFF the amplifier

Turn ON the amplifier

Shift balance to the Left

Decrease band level to a specific value

Turn down bass level

Turn down treble level

Turn down volume level

Set the balance level, 0 = Full Left / 100 = Full Right

Set the Equalizer Band to a specific level (0-100%)

Set the bass to specific level, (0-100%)

Set the treble to specific level, (0-100%)

Set the volume to specific level, (0-100%)

Bump balance to the Right

Bump the equalizer band setting up

Bump up bass level

Bump up treble level

Bump up volume level

List of sources available to the renderer service

Make a Menu Selection

Force the Renderer into a Multizone audio session

Set MUTE=OFF

Set MUTE=ON

Toggle the Mute setting

Query which source is being rendered

Query for the current renderer settings

Command renderer service to stop listening to any source

ü ü ü ü ü ü

ü ü ü ü ü ü

ü ü ü ü ü ü

ü ü ü ü ü ü

ü ü ü ü ü ü

ü ü ü ü ü ü

ü ü ü ü ü ü

ü ü ü ü ü ü

ü ü ü ü ü ü

ü ü ü ü ü ü

ü ü ü ü ü ü

ü ü ü ü ü ü

ü ü ü ü ü ü

ü ü ü ü ü ü

ü ü ü ü ü ü

ü ü ü ü ü ü

ü ü ü ü ü ü

ü ü ü ü ü ü

ü ü ü ü ü ü

ü ü ü ü ü ü

ü ü ü ü ü ü

ü ü ü ü ü ü

ü ü ü ü ü ü

ü ü ü ü ü ü

ü ü ü ü ü ü

ü ü ü ü ü ü

ü ü ü ü ü ü

ü ü ü ü ü ü

ü ü ü ü ü ü

ü ü ü ü ü ü

Appendix: SpeakerLinX A-1

SP e a k e r lI N x au d I o re N d e r e r Se r v I C e Co m m a N d S

ASCII STRING COMMENTS

SL220

Device

SL250

SL251

SL254

SL9250-CS

SN1001

#SRC_SEL {{source id}}

#SRC_SEL NEXT

#TEMPSRC

Select a specific source to be rendered

Choose next available source to be rendered

ü ü ü ü ü ü

ü ü ü ü ü ü

ü ü ü ü ü ü

A-2 Technical Support: 800-283-5936

INDEX

Symbols

/0 (null byte)............................................................. 11

3rd Party

IP Address .............................................................. 7

@toAddress .............................................................. 9

A

ACTIVE OFF ..................................................... 22, A-1

ACTIVE ON ....................................................... 22, A-1

Address

Node ....................................................................... 9

Albums .................................................................... 31

All Songs ................................................................. 31

AMP OFF .......................................................... 22, A-1

AMP ON ..................................................... 23, 27, A-1

Arguments ......................................................... 10, 11

Character Literals ................................................. 11

Meaningful Strings ................................................ 11

Numeric Scalars ................................................... 11

XML or other Special Formats .............................. 11

Artists ....................................................................... 31

ASCII

Characters .............................................................. 5

Command Address ................................................ 9

Commands ........................................................... 12

Message Syntax ................................................ 22

Messages ............................................................. 12

Message Syntax ..................................................... 9

Message Types ..................................................... 12

Overview ................................................................. 9

Protocol .................................................................. 9

Audio

Renderer ......................................................... 19, 20

Source ............................................................ 19, 20

Stream Proxy .................................................. 19, 20

Audio Renderer ................................................. 19, 20

Audio Source ..................................................... 19, 20

Commands

SRC_SEL ..................................................... 28, 29

Deselect All

SRC_SEL ........................................................... 29

Get List

MENU_LIST m,n,SOURCES .............................. 26

Query Current Audio Source

QUERY CURRENT_SOURCE ............................ 28

Query Settings

QUERY RENDERER .......................................... 28

Select from List

MENU_SEL {{path}} ........................................ 27

Select Specific

SRC_SEL {{source id}} .............................. 28, 29

Audio Stream Proxy ........................................... 19, 20

B

Balance

Setting

LEVEL_SET BALANCE, x ............................ 24, A-1

Shifting

LEVEL_DN BALANCE ................................. 23, A-1

LEVEL_UP BALANCE ................................. 25, A-1

Band

Setting

LEVEL_DN BAND_X ................................... 23, A-1

LEVEL_SET BAND_X ........................................ A-1

LEVEL_SET BAND_X, Y ..................................... 24

LEVEL_UP BAND_X .................................... 25, A-1

Bass

Setting

LEVEL_DN BASS ........................................ 23, A-1

LEVEL_SET BASS, x ................................... 24, A-1

LEVEL_UP BASS ........................................ 25, A-1

D

DigiLinX Dealer Setup ............................................... 7

F

fromAddress ...................................................... 10, 11

G

Genre ....................................................................... 31

GPIO .................................................................. 19, 20

Group Name

All .......................................................................... 19

I

Intercom ............................................................ 19, 20

IP

Address .......................................................... 10, 11

Static Address ........................................................ 7

K

Keyword .................................................................. 10

L

LEVEL_DN BALANCE ...................................... 23, A-1

LEVEL_DN BAND_x ......................................... 23, A-1

LEVEL_DN BASS ............................................. 23, A-1

LEVEL_DN TREB .............................................. 23, A-1

LEVEL_DN VOL ................................................ 23, A-1

LEVEL_SET BALANCE, x ................................. 24, A-1

LEVEL_SET BAND_x, y .................................... 24, A-1

LEVEL_SET BASS, x ........................................ 24, A-1

LEVEL_SET TREB, x ......................................... 24, A-1

Index I-1

LEVEL_SET VOL, x ........................................... 24, A-1

LEVEL_UP BALANCE ....................................... 25, A-1

LEVEL_UP BAND_x .......................................... 25, A-1

LEVEL_UP BASS .............................................. 25, A-1

LEVEL_UP TREB .............................................. 25, A-1

LEVEL_UP VOL .......................................... 23, 25, A-1

M

Menu

Commands

MENU_LIST m,n,{{path}} ................................. 30

MENU_LIST m,n,SOURCES .............................. 26

MENU_SEL ........................................................ 27

MENU_LIST m,n,{{path}} ...................................... 30

MENU_LIST m,n,SOURCES ................................... 26

MENU_SEL ........................................................ 12, 27

Messages

Unsolicited .............................................................. 5

Multicast .......................................................... 7, 9, 19

MUTE OFF ............................................................. A-1

MUTE ON ............................................................... A-1

MUTE TOGGLE ...................................................... A-1

Q

QUERY CURRENT_SOURCE ................................. 28

QUERY RENDERER ................................................ 28

QUERY SOURCE .................................................... 33

R

Reports

Parsing .................................................................. 28

S

serviceName .......................................................... A-1

Services ............................................................... 9, 19

Address .................................................................. 9

By Device .............................................................. 20

Name .................................................................... 11

Names .................................................................. 19

Types ..................................................................... 19

serviceType ............................................................. A-1

Service Types

Audio Renderer............................................... 19, 20

Audio Source .................................................. 19, 20

Audio Stream Proxy ........................................ 19, 20

Device

ControlLinX

GPIO ................................................................ 20

Root ................................................................. 20

MediaLinX

Audio Stream Proxy ........................................ 20

Root ................................................................. 20

SpeakerLinX

Audio Renderer ............................................... 20

Audio Source................................................... 20

Audio Stream Proxy ........................................ 20

Intercom .......................................................... 20

Root ................................................................. 20

UI ..................................................................... 20

TouchLinX

Intercom .......................................................... 20

Root ................................................................. 20

UI ..................................................................... 20

GPIO ............................................................... 19, 20

Intercom .......................................................... 19, 20

Root ................................................................ 19, 20

UI .................................................................... 19, 20

Software

Third Party ............................................................... 5

SpeakerLinX

Services

Audio Renderer .................................................. 20

Audio Source ..................................................... 20

Audio Stream Proxy ........................................... 20

SpeakerLinX Audio Renderer Commands

ACTIVE OFF ......................................................... 22

ACTIVE ON ........................................................... 22

AMP OFF .............................................................. 22

AMP ON .......................................................... 23, 27

LEVEL_DN BALANCE ........................................... 23

LEVEL_DN BAND_x .............................................. 23

LEVEL_DN BASS .................................................. 23

LEVEL_DN TREB .................................................. 23

LEVEL_DN VOL .................................................... 23

Levels.................................................................... 23

LEVEL_SET BALANCE, x ...................................... 24

LEVEL_SET BAND_x, y......................................... 24

LEVEL_SET BASS, x ............................................. 24

LEVEL_SET TREB, x ............................................. 24

LEVEL_SET VOL, x ............................................... 24

LEVEL_UP BALANCE ........................................... 25

LEVEL_UP BAND_x .............................................. 25

LEVEL_UP BASS .................................................. 25

LEVEL_UP TREB .................................................. 25

LEVEL_UP VOL ............................................... 23, 25

MENU_LIST m,n,SOURCES ................................. 26

MENU_SEL {{path}} ........................................... 27

MUTE OFF ............................................................ 28

MUTE ON ............................................................. 28

MUTE TOGGLE .................................................... 28

QUERY CURRENT_SOURCE ............................... 28

QUERY RENDERER ............................................. 28

SRC_SEL .............................................................. 29

SRC_SEL {{source id}} ................................. 28, 29

SpeakerLinX Media Server Commands

QUERY SOURCE.................................................. 33

SRC_SEL .................................................... 28, 29, A-1

SRC_SEL NEXT ...................................................... A-2

SRC_SEL {{source id}} ........................................ A-2

StreamNet ............................................................... 19

I-2 Technical Support: 800-283-5936

Addressing ............................................................. 5

ASCII Command ................................................... 22

ASCII Messages ..................................................... 5

Devices ................................................................... 5

Status Messages .................................................... 7

Subscribing ............................................................ 7

Subnode

Address ................................................................ 10

~CURSRC ............................................................ 10

~IRMOD ............................................................... 10

~KEYPAD ............................................................. 10

~ROOT ................................................................. 10

~SERIAL_X .......................................................... 10

~STATUS ............................................................. 10

~SUBSCRIBER .................................................... 10

Subscription .............................................................. 7

Static ....................................................................... 7

T

toAddress ............................................................... A-1

TouchLinX

Services

Intercom ............................................................. 20

Root ................................................................... 20

UI ........................................................................ 20

Treble

Setting

LEVEL_DN TREB ........................................ 23, A-1

LEVEL_SET TREB, x ................................... 24, A-1

LEVEL_UP TREB ......................................... 25, A-1

U

UDP ................................................................... 11, 19

UI ....................................................................... 19, 20

UID

Index ..................................................................... 11

serialNumber ........................................................ 11

Unicast .................................................................... 19

V

Volume

Setting

LEVEL_DN VOL .......................................... 23, A-1

LEVEL_SET VOL, x ..................................... 24, A-1

LEVEL_UP VOL ..................................... 23, 25, A-1

Index I-3

I-4 Technical Support: 800-283-5936

GLOSSARY OF TERMS

A

Argument - Most often an optional fields that proceed keywords. When used, there are one or

more spaces between the keyword and the first argument and a comma is used to separate each
successive argument. Arguments can be in the format of Meaningful Strings, Character Literals,
Numeric Scalars or XML or other Special Formats.

ASCII Protocol - The basic control and status reporting mechanism of the services in StreamNet.
It consists of various audio and video messages and the respective parameters represented in
strings of ASCII characters. These messages also contain the associated routing and administrative
information used to inform recipients of the destination and origin of the messages or provides
various supplemental information.

Audio/Video Renderer Service - One of several Services associated with devices in the StreamNet
system. The Audio/Video Renderer service

Audio/Video Source Service - One of several Services associated with devices in the StreamNet
system. The Audio/Video Source service is responsible for taking an analog or digital audio and/
or the corresponding video signal from a legacy device (CD or DVD Changer), encoding them into
IP-based data packets and transmitting them over the network.

B

C

Case Sensitivity - Case Sensitivity is a term used to describe the actions of a parsing scheme that

is sensitive to the use of uppercase and lowercase characters and interprets a string of characters
differently based on the case of the characters in the string.

Case Sensitivity comes into play in a StreamNet system when, for instance, the Source or
Renderer service name is used as an argument in a command line: Service name: Room 2
Player

Correct Command Line - the Service name is used as an argument and is correctly
entered:

#@Room 2:~UDP10.15.0.11_5000#query service {{Room 2 Player}}

Incorrect Command Line - the Service name is used as an argument but is incorrectly
entered:

#@Room 2:~UDP10.15.0.11_5000#query service {{room 2 player}}

When the source or renderer service name is not used as the toAddress, it is not case
sensitive:

#@room 2 player:~UDP10.15.0.11_5000#query renderer

Character Literals - Argument labels that are comprised of character strings which do not need

any special delimiters and contain no blanks, spaces, commas or other special, non-alphanumeric
characters. Arguments that do contain special characters must be enclosed within double brackets
“{{...}}”.

Command - A string of ASCII characters that form a valid StreamNet statement which is sent to a
device or service to perform a requested action or generate an appropriate response.

Glossary G-1

D

Declarative - A StreamNet ASCII message command used to report information requested from

an unsolicited status report (periodic or caused by a change in a device’s state) or via a response to
an interrogative message. The most common StreamNet declarative is the #REPORT message.

E

F

Flash - A storage method/device for digital media.

fromAddress - Indicates which entity sent the message and is used to address any response that

may be generated by the message. If a response is expected, then the fromAddress should specify
the address the response should be sent to. The colon symbol “:” must precede all fromAddress
fields.

G

General Purpose IO (GPIO) Service - The General Purpose IO service is responsible for sending

IR or RS-232 commands to devices connected to a ControLinX. The GPIO service can be thought
of as a “Miscellaneous Function” or catch-all type service category for services that don’t fit neatly
into any of the other services described.

H

I

IP Address - A network IP Address is the network address assigned to each device in a StreamNet

system and is required for sending or receiving StreamNet ASCII commands for device operation
as well as device status inquiry.

Imperative - A type of ASCII message command that initiates an action or directly causes a change
in state of a specific device.

INTERCOM Service - An Intercom Service provides one-way (Unicast) or two way (Multicast)
voice communication with other Intercom Services.

Interrogative - An ASCII message command used to request information from a particular
device.

IR - A method of remotely controlling a device without having to be physically connected to it by
sending specific commands using wireless Infrared (IR) technology.

J

G-2 Technical Support: 800-283-5936

K

KEY - A UI/Keypad/IR service command used to identify the specific function key that was pressed

in order to initiate an action based on the depressed key.

Keyword - The keyword is a required field in all ASCII command statements and specifies the
action to be executed. The keyword field must be preceded by the ”#“ symbol with no intervening
spaces. The keyword is one word and contains no spaces, commas or other special characters
except the underline ”_“ character.

L

M

MENU - A set of StreamNet ASCII messages which makes use of all three ASCII message

types: Interrogative, Declarative and Imperative. The MENU ASCII messages are #MENU_LIST,
#MENU_RESP and #MENU_SEL.

Multicast - A One-to-Many communication technique where all parties can communicate with
each other over an IP network infrastructure, often in real-time.

Multiplexer - A device used to combine and send a stream of data over a communication line. The
multiplexer will also separate a received data stream into component packets.

N

Numeric Scalars - An argument format style in which the argument must be in the format of a

decimal number.

O

P

Point-To-Point - A method of communication between one sender and one receiver over a network

- similar to Unicast.

Push To Talk (PTT) - An Intercom Service parameter for the INTERCOM command used to create
and start a PTT session, stop a PTT session, monitor a PTT session, enter a PTT session or simply
create without starting a PTT session. A PTT session is an Intercom session where the microphone
is off unless the user manually pushes the microphone button to talk.

Q

QUERY - Multi-service ASCII command that requests information from a device or service and

generates a report based on the feedback received.

R

Root Service - One of several services associated with devices in the StreamNet system. The Root

service is the only service that is always active on all devices.

Glossary G-3

S

serviceName - A unique name assigned to each service in a StreamNet system. The serviceName

is then used to address ASCII messages. Each physical StreamNet device may be configured to
have some or all of its specific services enabled.

StreamNet - A technology that provides elegant solutions for streaming media & control applications
such as digital signage, distribution of HD video and audio, LAN Cloud Matrix Switching™, and
audio paging over data networks.

SubNode - A Subnode address is a part of the ASCII command address and can be a part of the
TO or FROM address. A subnode address is a special address modifier which instructs the node
where to forward the command once it is received. Typically, the subnode address indicates that
the service should forward the command to a non-StreamNet device.

T

tag - A 32-bit Intercom service session number that will be used to identify the session in the header

of the Intercom audio data and to reference it in other commands.

talkIpAdr - The IP Address to which a device should send replies to - may be Multicast or
Unicast.

talkPort - The port to which the device should send replies to.

toAddress - Specifies the name of the service, group or room to which the message is sent. The

toAddress must be immediately preceded by the “@” symbol. The Address field consists of two
parts: the node address and the subnode address.

U

UniqueID (UID) - The UID of a service is the unchangeable identifier for the service. The UID is

based on the combination of the device’s serial number and an integer that identifies the specific
service on the device. In general, there is no reason to use the UID as all services should be
assigned names and all of the user’s commands should be addressed to those service names (or
room/group names).

Unicast - A method of communication between one sender and one receiver over a network - see
Point-To-Point.

User Data Protocol (UDP) - The methods and standards used to send StreamNet ASCII messages
over the Internet to any StreamNet and StreamNet-compatible device. If addressed correctly, the
message will be routed to the desired service(s).

User Interface (UI) Service - A UI Service provides services for User Interfaces. There are
currently two types of UI services: UI/GUI and UI/Keypad. A TouchLinX hosts a UI/GUI service and
a SpeakerLinX hosts a UI/Keypad service.

V

W

G-4 Technical Support: 800-283-5936

X

Y

Z

Glossary G-5
