Clarke COB 10CR, 4003615 User guide

RECHARGABLE LED WORKLIGHT

MODEL NO: COB10CR

PART NO: 4003615

USER INSTRUCTIONS

ORIGINAL INSTRUCTIONS GC1119 ISS 2

INTRODUCTION

Thank you for purchasing this CLARKE worklight. This work light with carry
handle and floor stand is suitable for indoor or outdoor use.

Before attempting to use this product, please read this manual thoroughly and
follow the instructions carefully. In doing so you will ensure the safety of yourself
and that of others around you, and you can look forward to your purchase
giving you long and satisfactory service.

ENVIRONMENTAL RECYCLING POLICY

Through purchase of this product, the customer is taking on the
obligation to deal with the WEEE in accordance with the WEEE
regulations in relation to the treatment, recycling & recovery and
environmentally sound disposal of the WEEE.

In effect, this means that this product must not be disposed of with general
household waste. It must be disposed of according to the laws governing
Waste Electrical and Electronic Equipment (WEEE) at a recognised disposal
facility.

GUARANTEE

This product is guaranteed against faulty manufacture for a period of 12
months from the date of purchase. Please keep your receipt which will be
required as proof of purchase.

This guarantee is invalid if the product is found to have been abused or
tampered with in any way, or not used for the purpose for which it was
intended.

Faulty goods should be returned to their place of purchase, no product can
be returned to us without prior permission.

This guarantee does not effect your statutory rights.

2

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

SAFETY PRECAUTIONS

1. This worklight must not be immersed in water. Don’t touch the lamp when
your hands are wet.

2. Do not look directly into the lamp when switched on as this can damage
the eyes.

3. Do not use this worklight if it has a broken lens or casing.

4. Do not attempt to disassemble or repair the worklight.

5. Never unplug the charger by holding the cable. Unplug by holding the
plug.

6. Do not leave the worklight unattended when switched on. Always unplug
the worklight when it is not in use.

7. Ensure the lamp is a safe distance from other objects in the working
environment.

ELECTRICAL CONNECTIONS

WARNING! READ THESE ELECTRICAL SAFETY INSTRUCTIONS
THOROUGHLY BEFORE CONNECTING THE CHARGER TO THE
MAINS POWER SUPPLY.

Before switching the product on to charge, make sure that the voltage of your
electricity supply is the same as that indicated on the charger. This product is
designed to operate on 230VAC 50Hz. Connecting it to any other power
source may cause damage.

This product incorporates a plug-in charger which cannot be re-wired. If lost or
damaged, it must be replaced from your Clarke dealer.

If in any doubt, consult a qualified electrician.

This symbol indicates that the charger/lead is an electrical Class II
product, and does not possess an earth connection.

This symbol indicates that the lamp assembly is an electrical Class III
product, and does not possess an earth connection.

3

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

CHARGING THE BATTERY

1. Charge the battery before using the worklight for the first time and after
every occasion of use if possible.

2. Charge thereafter, at least every 90 days or when needed.

3. Always avoid leaving your worklamp in a discharged state.

FOLLOW THE ABOVE POINTS TO ENSURE MAXIMUM LIFE FROM THE BATTERY.

Two means of charging the battery are provided:

1. Via a 230V mains electricity
supply, using the mains adaptor/
charger, shown.

2. Via a 12V supply using a vehicle
cigarette lighter adapter with
cable and plug provided.

NOTE: Using a 12V vehicle supply,

the battery will not charge to
maximum, but only to
approx. 50% of its capacity.

A 3 amp fuse is fitted into the cigarette lighter plug adaptor, accessed by
unscrewing the two halves of the adaptor. Take care not to loose the spring
when unscrewing this cap.

The worklight should operate for approx 2 hours when fully charged and it can
be used while on charge.

4

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

CARE & STORAGE

1. Always switch off when not in use.

2. This product should be stored in a secure, dry place, out of the reach of
children. DO NOT leave it exposed to the elements and avoid direct
sunlight, direct heat, rain/moisture etc.

3. Keep the external surfaces clean. Avoid impact damage & do not allow
this product to come into contact with abrasive or corrosive materials.

4. Do not use solvents, thinners or alcohol for cleaning, as these chemicals will
damage the finish. With the lamp unplugged from the power supply, use a
dry cloth to wipe over the lamp components.

5. The LED light source cannot be replaced but has a life expectancy of
approximately 20,000 hours.

6. Never use unauthorised accessories or attachments which may cause
personal injury or damage to the product.

Do not attempt to repair or modify this product or attempt any electrical
repair yourself. Consult the Clarke Service Department on 020 8988 7400.

5

Parts & Service: 020 8988 7400 / E-mail: [e-mail] or [e-mail]

ERP TECHNICAL INFORMATION

Model COB10CR

Part No 4003615

Model type LY9601H

Dimensions (L x W x H) 166 x 186 x 255 mm

Weight 1.3 kg

Light Source COB LED

Operating Temperature

-20 to + 50

o

C

Input power (consumption) 10 W

Light Output (luminous flux) 650 lumen

Power Supply 230V 50Hz

Insulation Class Class III (lamp only) Class II (charger only)

Ingress Protection Rating IP20

Energy Efficiency Class A+

Colour Temperature 6500 K

Weighted Energy Consumption 10 kWh/1000 h

Efficiency 65 Lm/W

Rechargable Battery output 2.2 Ah

LED Life expectancy 20,000 hours

LED replaceable No

Tilt angle adjustment

-90

o

to +90

o

6
