Navigate with Style
MULTIMEDIA
Microphone
Graphical User Interface
Only three buttons on the front panel —
the rest is handled by the intuitive graphical
interface that displays a variety of functions
from navigation to entertainment.
NX700
DVD MULTIMEDIA STATION
WITH BUILT-IN NAVIGATION
& 7-INCH TOUCH PANEL
CONTROL
CEA 2006 Power Ratings
20W×4 RMS [4@14.4V1% THD+N]
S/N 84dB (Ref:1W into 4)
Source
Volume --
Hands-free
Microphone
included
Volume +
Built-in Bluetooth® for
Hands-free Calling
Wirelessly connect your Bluetooth capable cell phone
to listen to calls through your vehicle’s audio system.
HFP is supported.
NX700
NZ500
NX500
04 www.clarion.com
USB(Audio)
or CCA723 / 748(Video)
USB(Audio)
or CCA723 / 748(Video)
USB(Audio)
or CCA723 / 748(Video)
Superior iPod® and iPhone™
Connectivity
*For compatibility details, please visit the Clarion website.
Playback of iPod Video requires the optional cable CCA723/748.
CLA-SC1
—
THD400
(With iTunes®
Tagging)
THD400
(With iTunes
Tagging)
+
SC-C1
—
—
—
Built-in Navigation System
Count on GPS accuracy and an efficient mapping
engine to guide you to your destination. Internal flash
memory provides fast access to data, while 3D
rendered graphics give you a realistic view of the
route you’re on.
CNP2000UC
+ CNPCLA1
———
———
—
Rear Inclu ded
Optional
Rear
(RCB199)
Optional
Rear
(RCB199)
Flash Memory
for
Map Storage
Flash Memory
for
Map Storage
Flash Memory
for
Map Storage
Navigate and Communicate with Intuitive Ease
NZ500
DVD MULTIMEDIA STATION
WITH BUILT-IN NAVIGATION
& 7-INCH TOUCH PANEL
CONTROL
CEA 2006 Power Ratings
16W×4 RMS [4@14.4V 1% THD+N]
S/N 82dB (Ref:1W into 4)
Easy-view Sub Display
In addition to its main LCD screen, when the
NZ500 is in the "closed" position, the
informative 12-character blue LCD offers
maximum visibility in a space-saving
package.
NX500
2-DIN DVD MULTIMEDIA STATION
WITH BUILT-IN NAVIGATION
& 6.5-INCH TOUCH PANEL
CONTROL
CEA 2006 Power Ratings
16W×4 RMS [4@14.4V 1% THD+N]
S/N 81dB (Ref:1W into 4)
MULTIMEDIA
Built-in Navigation System
Efficient guidance to your destination, with 12 million
POIs (Points Of Interest) pre-stored in the internal
flash memory.
12 Million
12 Million
12 Million
18FM /
12AM
36FM /
12AM
36FM /
12AM
Microphone
—
—
Built-in Bluetooth® Interface
Wireless connection of mobile phones and other
devices to the main unit. Supports HFP/OPP for handsfree calling, and A2DP/AVRCP for audio streaming.
———
———
—
—
—
Superior iPod® and iPhone™
Connectivity
*For compatibility details, please visit the Clarion website.
Playback of iPod Video requires the optional cable CCA723/748.
1 AV (Rear) 7-inch
1 Front AV/
1 Rear AV
1 Front AV/
1 Rear AV
7-i nch
6.5-inch
www.clarion.com 05
Premium Multimedia with A Simple Touch
VX400
2-DIN DVD MULTIMEDIA
STATION WITH 6.5-INCH
TOUCH PANEL CONTROL
MULTIMEDIA
*VX400 Screen Image Showing
Optional Navigation Function with
Navigation Module NP400 Connected*
CEA 2006 Power Ratings
15W×4 RMS [4Ω@14.4V ≤1% THD+N]
S/N 77dB (Ref:1W into 4Ω)
VZ400
DVD MULTIMEDIA
STATION WITH 7-INCH
TOUCH PANEL CONTROL
CEA 2006 Power Ratings
15W×4 RMS [4Ω@14.4V ≤1% THD+N]
S/N 75dB (Ref:1W into 4Ω)
Navigation System Example
Touch Panel Controlled GUI
Only 4 physical buttons (VZ400) and 3 physical buttons (VX400) on the front
panel — the rest is handled by the touch panel graphical interface. Operation
is beautifully enhanced by the high-resolution on-screen display.
VZ400
VX400
HD Radio™ Ready with
iTunes
Enjoy high quality digital broadcasts, and if
you hear a song you like, tag it to download
later from the iTunes Store.
®
Tagging
Direct Navigation
Control
Microphone
Microphone
NP400
Built-in Bluetooth®
Interface
Bluetooth Profile :
Hands-free Profile (HFP), Object Push Profile (OPP),
Advanced Audio Distribution Profile (A2DP),
Audio Video Remote Control Profile (AVRCP)
Optional External Hands-free Microphone available. (RCB-199)
VZ400
VX400
VZ300
●●●
●●●
●●
06 www.clarion.com
USB (Audio) or CCA723 / 748 (Video
—
USB (Audio) or CCA723 / 748 (Video
—
(Audio / Video)
—
●
CCUIPOD3
)
Built-in
)
Built-in
—
THD400
(With iTunes
Tagging)
THD400
(With iTunes
Tagging)
THD300
●
●
—
—
—
CNP2000UC
+CCUXM1
●
●
●
Rear NP400 36 FM/12 AM
Rear NP400 36 FM/12 AM
Front
—
Easily Add Navigation to Your System
Designed especially to work with Clarion multimedia stations (VX400 & VZ400),
simply adding the NP400 option will transform your in-car entertainment system
into a reliable navigator.
NP400
FLASH MEMORY NAVIGATION SYSTEM
Compatible with VZ400/VX400
•
Touch Screen Operation (VZ400/VX400)
•
12 Million Built-in POIs
•
Map Coverage: US 50 States and Canada
•
Audible Voice Commands in 3 Different
•
Languages (English / French / Spanish)
NAND Flash Memory (Map Data Pre-loaded)
•
USB port for updates
•
SiRF GPS lll Module with 20-channel
•
GPS Receiver
Automatic Route Recalculation
•
Turn by Turn Voice Prompts and TTS
•
for Street Announcements
3 Display Mode: 3D/2D Split Mode
•
USB Port for Updates
Navigation map updates can be
imported into the system through
the USB connector.
Multiple Viewing Options for Added Realism
and Driving Accuracy
3D Map View
Navigation Menu Split Screen
Dashboard Display Night Mode
2D Map View
Satisfy Your Need for
Entertainment
VZ300
DVD MULTIMEDIA STATION
WITH 3.5-INCH LCD MONITOR
CEA 2006 Power Ratings
16W×4 RMS [4Ω@14.4V ≤1% THD+N]
S/N 81dB (Ref:1W into 4Ω)
iPod® Playback
Just connect your iPod using the optional
CCUIPOD3 cable for music and video
playback on the VZ300.
MULTIMEDIA
Front USB Input
USB Connector supports playback of
WMA/MP3 files.
18 FM/12 AM
●●●●●●●
●●●●●●●
Front / Rear 7-inch
Front / Rear 6.5-inch
●●●●●●●
Front
—
—
—
3.5-inch
●
●
—
—
—
●
www.clarion.com 07
●
●
—
HD Radio Modules for Your Drive
THD400
HD RADIO MODULE
iTunes® Tagging Ready
•
Compatible with
NX500 / NZ500 / VX400 / VZ400
THD300
HD RADIO MODULE
iTunes® Tagging Ready
•
MULTIMEDIA
TechnoPhile: iTunes® Tagging
iTunes® Tagging allows listeners to “tag” songs heard on their HD Radio Receiver.
Tagging saves the song’s title and metadata to a connected iPod. When the iPod is
synced to iTunes, a playlist is generated with links to the iTunes Store where the song
can be purchased and downloaded.
WH204 / WH104H / WH204H /
WH105H / WH114H
WIRELESS HEADPHONE SYSTEMS
• WH204: IR Wireless Headphones (Dual Channel Input)
• WH104H: Replacement and/or Additional Headphone for WH104
• WH204H: Replacement and/or Additional Headphone for WH204
• WH105H: Replacement and/or Additional Headphone for WH105
• WH114H: Replacement and/or Additional Headphone for WH114
CCA723 / CCA748
CONNECTION CABLE
for iPod VIDEO
for For NX700/NX500/NZ500/
VX400/VZ400/FZ709/
FZ409/CMV1
HD Radio Station
CCUIPOD2
CONNECTION
CABLE
for iPod VIDEO
for CMS1
Compatible with
VZ300 / CZ500 / CZ300
* iTunes Tagging is not available for VZ300
Tagged Data
iTunes Store
OPTIONAL ACCESSORIES REAR VISION CAMERA
CCUIPOD3
CONNECTION
CABLE
for iPod VIDEO
for VZ300
VA700
VIDEO DISTRIBUTION
AMPLIFIER
• 1 RCA Composite Video Input
• 7 Buffered 75-Ohm RCA
Composite Video Outputs
• Stable Video Signal for up to
7 LCD Monitors
RCB199
External
Bluetooth
Microphone
for NX500/
NZ500/VX400/
VZ400
RCB204
External
Bluetooth
Microphone
for FZ709/
CX609/CZ500
SH1575 /
SH1075
SHROUD
for VT1510B/VT1010B/
VT1500B/
VT1000B&T/
CK625E
REAR VISION CAMERA KIT
Includes :
CC2011E (Camera) / CAA185
(Power Box) / MF23RM (23'cable)
08 www.clarion.com
Home Theater Enjoyment for Your In-Car Audience
Clarion’s overhead monitors bring the comforts of a home theatre system into the
vehicle, where your back seat passengers can enjoy a front row seat. DVDs and
video files play directly in the overhead unit, freeing up the in-dash system for
other tasks.
VT1510B
WXGA Resolution for VT1510B
•
Roof Mounting Application
•
NTSC and PAL Compatible
•
Adjustable Color/Contrast/Brightness/Tint
•
White LED Dome Lights
•
Built-in IR Transmitter for Wireless Headphones
•
Headphone Quantity Included,
•
2 (VT1510B/VT1010B) / 1 (VT810B)
IR Remote Control
•
On Screen Display
•
3.5mm AUX Input Connection
•
2 x AV Inputs (Back side)
•
1 x AV Output (Back side)
•
Slot-in DVD mechanism/USB/SD/MMC (VT1510B/VT1010B)
•
Slot-in DVD mechanism/USB (VT810B)
•
Capability to read: DVD Format/DVD±R/DVD±RW/CD-DA/CD-R/
•
CD-RW/MPEG(1/2/4)/MP3/WMA/VCD/SVCD
15.4-INCH WIDE SCREEN LCD OVERHEAD COLOR
MONITOR WITH DVD PLAYER
USB and SD/MMC slots support playback
of MPEG(1/2/4) and MP3/WMA files.
MULTIMEDIA
VT1010B
10.2-INCH WIDE SCREEN LCD OVERHEAD
COLOR MONITOR WITH DVD PLAYER
Turn Your Back Seat into a First Class Experience
Display video playback or games from a connected source with a high-quality 7” screen.
Show a movie or play a game and upgrade your passengers to First Class.
VM700B
7-INCH HEADREST/
STAND-ALONE LCD WIDE
MONITOR
Front USB and SD/MMC slots support playback of MPEG(1/2/4) and
MP3/WMA files.
VT810B
8-INCH WIDE SCREEN LCD OVERHEAD
COLOR MONITOR WITH DVD PLAYER
Equipped with AV input, plus USB
slots that support playback of
MPEG(1/2/4) and MP3/WMA files.
7” TFT Color Monitor
•
16:9/4:3 Adjustable Screen Format
•
On-screen Display
•
Front Panel 3.5mm Headphone Mini Jack
•
Built-in Dual IR Output for Headphone
•
(Optional WH204H)
Easy-fit Universal Mounting Bracket Included
•
Supports NTSC and PAL
•
Dimensions: 7.5” (W) × 5.12” (H) × 1.38” (D)
•
www.clarion.com 09
