Clarion WH 105 User Manual
A
UTOMOTIVE
H
EADPHONE
O
WNER’S MANUAL
I
NSTALLATION
RF S
S
YSTEM
G
TEREO
UIDE
WARNING!
THE CLARION WH105 RF HEADPHONES ARE DESIGNED
FOR LISTENING TO VIDEO OR AUDIO SOURCES FOR REAR
SEAT PASSENGERS ONLY.
THIS PRODUCT IS NOT INTENDED FOR USE BY THE DRIVER
WHILE THE VEHICLE IS IN MOTION SINCE SUCH USE MAY
DISTRACT THE DRIVER OR INTERFERE WITH THE DRIVER'S
SAFE OPERATION OF THE VEHICLE AND MAY RESULT IN
SERIOUS INJURY OR DEATH. SUCH USE MAY ALSO VIOLATE STATE LAW.
CLARION DISCLAIMS ANY LIABILITY FOR ANY BODILY
INJURY, INCLUDING FATALITIES, OR PROPERTY DAMAGE
THAT MAY RESULT FROM ANY IMPROPER OR UNINTENDED
USES OF THIS PRODUCT.
ABOUT INSTALLATION
Installation of mobile audio and video components requires experience with a variety of mechanical and electrical procedures.
Even though this manual provides general installation and operation instructions for your new Clarion WH105 RF Headphones, it
does not show the exact installation methods for your particular
vehicle.
If you do not have the required knowledge and experience to successfully complete the installation, we strongly recommend consulting an authorized Clarion dealer about professional
installation options.
TABLE OF CONTENTS
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Description of Headphone Controls . . . . . . . . . . . . . . . . . .3
Description of RF Transmitter Box . . . . . . . . . . . . . . . . . . .4
RF Transmitter Box Specifications . . . . . . . . . . . . . . . . . . .4
Battery Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Operation Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Wiring Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Mounting the RF Transmitter Box . . . . . . . . . . . . . . . . . . . .7
Mounting the Antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Testing the Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
FCC Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
1
Introduction
The Clarion WH105 is a full-featured, high-tech Wireless
Automotive RF Stereo Headphone System specifically created for the mobile environment. The WH105 frees you
from the tangle of headphone wires and lets you enjoy
music or TV audio without the clutter of cables. To ensure
the best performance of your system, please read this
manual carefully.
Special Features
Automatic Level Control prevents
input signal over loading.
Uses RF transmission
Adjustable Headphone Band
Power Indicator LED
Auto ON/OFF Micro Switch
Independent Volume Controls
Additional Headphones
The Clarion WH105 allows users to take full advantage of
the benefits of RF audio transmission and its ability to
operate multiple headphones from one single transmitter.
There is no need for Y-adapters, complex installation, or
concerns over electrical overload. Additional headphones,
WH105H, are available through your local Clarion Audio
Dealer.
2
About The Manual And Warranty
To start enjoying your new Clarion WH105 system, please
read all remaining instructions listed in this manual. Keep
all instructions for future reference.
This product is covered by a limited warranty (see the
enclosed warranty card). Save the sales receipt to pro-
tect your purchase and aid in warranty service.
