Clarion VMA1131 User Manual
VMA1131
11” LCD
COLOR MONITOR
OWNER’S MANUAL
INTRODUCTION
The Clarion VMA1131 is a full-featured 11.3" LCD Color Display Monitor. It
can be used as:
• A stand-alone TV when used with the optional TV Tuner, TTX001
• A monitor integrated into a mobile multimedia system using the auxiliary
A/V inputs
• A PC monitor with the VGA input
ABOUT THE MANUAL AND WARRANTY
To start enjoying your new Clarion VMA1131, please read the instructions
listed in this manual. Keep all instructions for future reference. Please fill out
and send in the enclosed warranty card to protect your purchase and aid in
warranty service. Also, save your original sales receipt as proof of
purchase.
* If using the VMA1131 with the optional TV Tu n e r, please refer to the owner’s manual
for the TTX001.
TABLE OF CONTENTS
Precautions • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •2
Package Contents • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •3
Button Locations • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •3
Installation and Wiring • • • • • • • • • • • • • • • • • • • • • • • • • • • • •5
Picture Adjustment • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •5
Auxiliary Video Inputs • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •6
Optional Remote Control Battery Installation • • • • • • • • • • • • • • •6
Optional Remote Control Operation • • • • • • • • • • • • • • • • • • • • •7
Optional TTX001 TV Tuner Installation • • • • • • • • • • • • • • • • • • •7
TV Tuning • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •8
Care and Maintenance • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •8
Troubleshooting • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •8
Product Specs • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •9
Notes • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • • •10
PRECAUTIONS
•
This set is for use in 12V, negative ground vehicles. Be sure to consult your
store of purchase before installing it on 24V vehicles.
•
Do not operate the set in ways other than described in this guide. Doing so
may damage it.
•
SAFETYFIRST! For rear seat use only. Do not install on dashboard or anywhere else that would permit monitor to be viewed by the driver. Monitor
must not be located in the motor vehicle at any point forward of the back of
the front seats. Monitor must never be used in any manner that will distract
driver or interfere with driver’s safe operation of the motor vehicle.
•
Be careful not to run down the car battery while using the set with the car
stopped.
2
•
For safety, install the set in a position at which the driver cannot see it.
•
Do not disassemble or modify the set. Doing so may damage it and voids
your warranty.
•
Keep drinks and drops from umbrellas away from the set. Water may damage the internal circuitry.
•
Do not let the set become hot. If temperature in the car is high or the set
has been exposed to direct sunlight and is hot, lower the temperature before
using it. (The liquid crystal panel will work properly within a temperature
range of 30 – 113 degrees F.)
•
In extremely cold temperatures, the movement of the picture may be slow
and the picture may be dark, but this is not a malfunction. The set will work
normally once the temperature increases.
•
Small black and shiny dots inside the liquid crystal panel are normal for liquid crystal products.
PACKAGE CONTENTS
The Clarion VMA1131 comes with the following items:
• Ribbon Cable for connection to the TTX001 TV Tuner
• A/V RCA Cable
• Power Cord
• Table Top Stand
BUTTON LOCATIONS
1 Volume Down Button
2 Volume Up Button
3 Picture Adjustment Button
4 Mode Selection Button
5 Power Button
6 IR Remote Sensor
3
7 DC Power Connector 8 Earphone Jack
9 AV2 Input Connectors
0 AV1 Input Connectors
q VGAInput Connector
w Channel Preset Button
e Channel Down Button
r Channel Up Button
4
t TV Tuner Ribbon Connector
y TTX001 TV Tuner (optional)
u Antenna Input Connector
