English
This appliance contains a laser system
and is classied as a “CLASS 1 LASER
PRODUCT“. To use this model properly, read
this Owner’s Manual carefully and keep this
manual for your future reference. In case of
any trouble with this player, please contact
your nearest “AUTHORIZED service station”.
To prevent direct exposure to the laser beam,
do not try to open the enclosure.
OBS!
Apparaten innehåller laserkomponenten som
avger laserstrålning överstigande gränsen för
laserklass 1.
VAROITUS
Suojakoteloa si saa avata. Laite sisältää
laserdiodin, joka lähettää näkymätöntä
silmille vaarallista lasersäteilyä.
!CAUTION
USE OF CONTROLS OR ADJUSTMENTS
OR PERFORMANCE OF PROCEDURES
OTHER THAN THOSE SPECIFIED IN THE
OWNER’S MANUAL MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.
ADVARSEL.
Denne mærking er anbragt udvendigt på
apparatet og indikerer, at apparatet arbejder
med laserstråler af klasse 1, hvilket betyder,
at der anvendes laserstråler af svageste
klasse, og at man ikke på apparatets
yderside kan blive udsat for utilladelig kraftig
stråling.
APPARATET BØR KUN ÅBNES AF
FAGFOLK MED SÆRLIGT KENDSKAB TIL
APPARATER MED LASERSTRÅLER!
Indvendigt i apparatet er anbragt den her
gengivne advarselsmækning, som advarer
imod at foretage sådanne indgreb i apparatet,
at man kan komme til at udsaætte sig for
laserstråling.
531-1602kHzMW
FM
87.5-108MHz
LW 153-279kHz
This product includes technology owned by Microsoft Corporation and
cannot be used or distributed without a license from MSLGP.
03 2120
CHINA
PN:127070006821TX-1073E-A
1
Contents
Thank you for purchasing this Clarion product.
• Please fully read this owner’s manual before operating this equipment.
• Check the contents of the enclosed warranty card and store it in a safe place with this manual.
1. FEATURES ........................................................................................................................3
2. PRECAUTIONS .................................................................................................................4
Front Panel / Generalities .................................................................................................. 4
Remove the DCP ..............................................................................................................5
Attach the DCP .................................................................................................................. 5
Storing the DCP in the DCP Case ..................................................................................... 5
3. CONTROLS .......................................................................................................................6
Operational Panel .............................................................................................................. 6
Names of Buttons .............................................................................................................. 6
4. CAUTIONS ON HANDLING ..............................................................................................7
Handling Discs ..................................................................................................................7
5. OPERATIONS ....................................................................................................................8
Basic Operations ...............................................................................................................8
System Setup ....................................................................................................................9
Audio Setup ....................................................................................................................... 9
Radio Operations ............................................................................................................10
Radio Data System Operations ....................................................................................... 11
CD/MP3/WMA Operations ..............................................................................................12
AUX Operations ..............................................................................................................14
6. TROUBLE SHOOTING ....................................................................................................15
7. ERROR DISPLAYS..........................................................................................................16
8. SPECIFICATIONS ...........................................................................................................17
9. INSTALLATION / WIRE CONNECTION GUIDE .............................................................18
English
2
English
1. FEATURES
MP3/WMA compatible with ID3-TAG display
Front-panel auxiliary input & 2ch RCA output
"BEAT-EQ" with 3 Band Parametric Equalizer & "MAGNA BASS EX" dynamic bass
enhancement
Expanding Systems
Expanding audio features
2 Channel Amplier
Note:
The items listed outside of the frames are
the commercial products generally sold.
3
Portable Player
(Connect by AUX IN Jack)
2. PRECAUTIONS
WARNING
For your safety, the driver should not operate the controls while driving.
Also, while driving, keep the volume to a level at which external sounds can be heard.
English
1. When the inside of the car is very
cold and the player is used soon after
switching on the heater, moisture may
form on the disc or the optical parts of the
player and proper playback may not be
possible. If moisture forms on the disc,
wipe it off with a soft cloth. If moisture
forms on the optical parts of the player,
do not use the player for about one hour.
The condensation will disappear naturally
allowing normal operation.
2. Driving on extremely bumpy roads which
cause severe vibration may cause the
sound to skip.
3. This unit uses a precision mechanism.
Even in the event that trouble arises,
never open the case, disassemble the
unit, or lubricate the rotating parts.
Front Panel / Generalities
For a longer service life, be sure to read the
following cautions.
• Do not allow any liquids on the set from
drinks, umbrellas, etc. Doing so may
damage the internal circuitry.
• Do not disassemble or modify the set in
any way. Doing so may result in damage.
• Do not let cigarettes burn the display.
Doing so may damage or deform the
body.
• If a problem should occur, have the set
inspected at your store of purchase.
Cleaning the body
• Use a soft, dry cloth and gently wipe off
the dirt.
• For tough dirt, apply some neutral
detergent diluted in water to a soft cloth,
wipe off the dirt gently, then wipe again
with a dry cloth.
• Do not use benzene, thinner, car cleaner,
etc., as these substances may damage
the body or cause the paint to peel. Also,
leaving rubber or plastic products in
contact with the body for long periods of
time may cause stains.
4
Remove the DCP
English
The control panel can be detached to prevent
theft. When detaching the control panel, store
it in the DCP (DETACHABLE CONTROL
PANEL) case to prevent scratches.
We recommend taking the DCP with you
when leaving the car.
1. Press the [SRC / ] button (1 sec.) to turn
off the power.
2. Deeply push in [OPEN] button to unlock
the DCP.
3. Hold the side popped out, remove the
DCP.
Attach the DCP
1. Hold the DCP and ensure that the panel
faces towards you. Set the right side of the
DCP into the DCP bracket.
2. Press the left side of the DCP until it locks.
Storing the DCP in the DCP Case
Hold the DCP, as shown in the gure below,
and put it into the supplied DCP case.
DCP
DCP case
Note:
If the DCP is dirty, wipe off the dirt with a soft,
dry cloth only.
5
CAUTION
• The DCP can easily be da maged by
shocks. After removing it, be carefully not
to drop it or subject it to strong shocks.
• Once the [OPEN] button is pressed and
DCP is unlocked, car vibrations can cause
the DCP to fall
• The connector for the main unit and
DCP is extremely important. Be careful
not to damage it by pressing on it with
ngernails, screwdrivers, etc.
3. CONTROLS
Operational Panel
English
[PS/AS]
[VOLUME] [1~6] AUX Jack[BAND]
[SOUND]
[ , ]
[MENU] Disc Slot [ ]
[OPEN]
[SRC/ ]
Names of Buttons
[SRC / ] Button
• Power / Toggle the audio source
[BAND] Button
• Select tuner band
[MENU] Button
• MP3/WMA mode – Search function.
• CD mode – No function.
• RADIO mode – PTY select
• AUX mode – No function.
[ ] Button
• Press to eject disc.
[ , ] Buttons
• Previous / next track
• Search (Long press)
[Open] Button
• Unlock the front panel.
TA
[TA]
[D]
[VOLUME] Knob
• Adjust volume level / Conrm (press)
[TA] Button
• Trafc announcement
[1~6] Buttons
• [1] Button: Scan play / Preset station 1.
• [2] Button: Repeat play / Preset station 2.
• [3] Button: Random play / Preset station 3.
• [4] Button: Play / Pause / Top play (long
press) / Preset station 4.
• [5] Button: Previous folder / Preset station 5.
10 tracks down (long press)
• [6] Button: Next folder / Preset station 6.
10 tracks up (long press)
[D] Button
• Display switch
• System setup (long press)
E
[PS / AS] Button
• Scan play / Preset scan
• Auto memory store (long press)
[SOUND] Button
• Sound effect setting
6
English
4. CAUTIONS ON HANDLING
Handling Discs
Handling
• New discs may have some roughness
around the edges. If such discs are used,
the player may not work or the sound may
skip. Use a ball-point pen or the like to
remove any roughness from the edge of
the disc.
Ball-point pen
Roughness
• Never stick labels on the surface of the disc
or mark the surface with a pencil or pen.
• Never play a disc with any cellophane tape
or other glue on it or with peeling off marks.
If you try to play such a disc, you may not
be able to get it back out of the player or it
may damage the player.
• Do not use discs that have large
scratches, are misshapen, cracked, etc.
Use of such discs may cause
misoperation or damage.
• To remove a disc from its storage case,
press down on the center of the case and
lift the disc out, holding it carefully by the
edges.
• Do not use commercially available disc
protection sheets or discs equipped with
stabilizers, etc. These may damage the
disc or cause breakdown of the internal
mechanism.
Storage
• Do not expose discs to direct sunlight or
any heat source.
• Do not expose discs to excess humidity or
dust.
• Do not expose discs to direct heat from
heaters.
Cleaning
• To remove ngermarks and dust, use a soft
cloth and wipe in a straight line from the
center of the disc to the circumference.
• Do not use any solvents, such as
commercially available cleaners, anti-static
spray, or thinner to clean discs.
• After using special disc cleaner, let the disc
dry off well before playing it.
On Discs
• Never turn off the power and remove the
unit from the car with a disc loaded.
CAUTION
For your safety, the driver should not insert
or eject a disc while driving.
7
5. OPERATIONS
Basic Operations
English
Note:
• Refer to the diagrams in “3. CONTROLS”
when reading this chapter.
CAUTION
When the unit is turned on, starting and
stopping the engine with its volume
raised to the maximum level may harm
your hearings.
Be careful about adjusting the volume.
Power on / off
Notes:
• Start the engine before using this unit.
• Be careful about using this unit for a long
time without running the engine. If you
drain the car’s battery too far, you may not
be able to start the engine and this can
reduce the service life of the battery.
1. Start the engine. The power button / knob
illumination on the unit will light up.
Engine ON
2. Press the [SRC /
panel to turn on the power under standby
mode. The unit goes back to the last
status after power on.
3. Press and hold the [SRC / ] button on
the front panel to turn off the power.
position
] button on the front
Volume adjustment
Turn the [VOLUME] knob on the front panel.
The adjustable range of volume is 0 to 40.
CAUTION
While driving, keep the volume level at
which external sounds can be heard.
Playing source selection
Press [SRC / ] button on the front panel
repeatedly to choose desired playing source.
Notes:
• Playing source selection means selecting
work mode, such as DISC mode, RADIO
mode and AUX mode.
Display system time
Press the [D] button on the front panel to
switch the display information between RDS
information, system time and playing source.
RESET
Note:
* When the [RESET] button is pressed,
frequencies of radio stations, titles, etc.
stored in memory are cleared.
CT (Clock Time) display
• The displayed clock data is based on the
CT (clock time) data in the RDS signal.
RESET
8
System Setup
English
At all mode, press and hold [D] button to
enter system setup. Press [ , ] buttons
to select options, rotate the [VOLUME] knob
to adjust.
AF: ON/OFF
Rotate the [VOLUME] knob to choose AF ON
or OFF.
REG: ON/OFF
Rotate the [VOLUME] knob to choose REG
ON or OFF.
DX/LO (RADIO mode)
Rotate the [VOLUME] knob to choose radio
local or distant at RADIO mode.
• LO: Only stations with strong signal can
be received.
• DX: Stations with strong and weak signals
can be received.
AUX SENS (AUX mode)
Rotate the [VOLUME] knob to choose AUX
Input sensitivity LOW, MID or HIGH at AUX
mode.
SCRN SVR: ON/OFF
Rotate the [VOLUME] knob to choose SCRN
SVR (screen saver) ON or OFF.
SCROLL: ON/OFF
For track information that is longer than the
display panel:
When SCROLL is ON, the LCD will display
ID3 TAG information cyclely, e.g: TRACK> F O L DE R->FI L E - >A LBUM - > T I TL E>ARTIST->TRACK->...
When SCROLL is OFF, the LCD will display
one of the ID3 TAG information, the default
is TRACK, but user can adjust it to other ID3
TAG information by press [BAND] button.
DIMMER: ON/OFF
Rotat e the [VOLUME] knob to choos e
DIMMER ON or OFF.
• ON: LCD dimmer is active when small light
of vehicle is turned ON.
• OFF: LCD always maximum brightness
regardless of the vehicle small light.
REAR/S-W
Rotate the [VOLUME] knob to choose REAR
or S-WOOFER (SUB-WOOFER).
TEL-SW
Rotate the [VOLUME] knob to choose MUTE,
ON or OFF.
• MUTE:
The sound from this unit is muted during
telephone calls.
• OFF:
This unit continues normal operation even
when the cellular phone is used.
• ON:
You can listen to your telephone calls from
the speakers connected to this unit.
*When listening to your calls on your car
speakers, you can adjust the volume by
turning the [VOLUME] knob.
BEEP: ON/OFF
Rotate the [VOLUME] knob to choose button
beep sound ON or OFF.
Audio Setup
Press the [SOUND] button to enter sound
effect setting mode. First press shows current
EQ. Rotate the [VOLUME] knob to changes
BEAT EQ in this order:
OFF -> B-BOOST -> IMPACT -> EXCITE ->
CUSTOM
Rotate the [VOLUME] knob to changes
CUSTOM, and press the [VOLUME] knob,
the press [
9
] or [ ] button to select
it including: BAS-G -> BAS-F -> BAS-Q
-> MID-G -> MID-F -> MID-Q -> TRE-G ->
TRE-F, rotate the [VOLUME] knob to select a
value.
BAS-G / MID-G / TRE-G: (-7)- (+7)
BAS-F: 60 / 80 / 100 / 200
BAS-Q: 1.0 / 1.25 / 1.5 / 2.0
MID-F: 500 / 1K / 1.5K / 2.5K
MID-Q: 0.5 / 0.75 / 1.00 / 1.25
TRE-F: 10.0K / 12.5K / 15.0K / 17.5K
Audio Setup
Press the [SOUND] button, then press [
] buttons to select USER preset including:
BALANCE -> FADER -> M-B EX -> LPF(low
pass lter) -> S-W VOL (Subwoofer Volume),
rotate the [VOLUME] knob to select a value.
Radio Operations
,
BALANCE:LEFT 1-7->CENTER->RIGHT 1-7
FADER:FRONT 1-7->CENTER->REAR 1-7
M-BEX: ON/OFF
LPF: THROUGH/80/120/160
SUBW VOL: (-6)-(+6)
English
Select tuner as playing source
Press [SRC / ] button once or more to
enter RADIO mode.
Select one radio band
Press the [BAND] button on the panel to
select one radio band among FM1, FM2,
FM3, MW and LW.
Manual tuning
During manual tuning, the frequency will be
changed in steps.
Press the [ ] / [ ] buttons on the
panel to tune in a higher / lower station.
Auto tuning
Press and hold the [ ] / [ ] buttons
on the panel to seek a higher / lower station.
To stop searching, repeat the operation
above or press other buttons having radio
functions.
Note:
When a station is received, searching stops
and the station is played.
Preset scan
Preset scan receives the stations stored
in preset memory in order. This function is
useful when searching for a desired station in
memory.
1. Press the [PS/AS] button.
2. When a desired station is tuned in, press
the [PS/AS] button again to continue
receiving that station.
Note:
• Be care fu l not to pre ss and hold the
[PS/AS] button for 1 second or longer,
otherwise the auto store function will begin
and the unit starts storing stations.
Auto store
Only stations with sufcient signal strength
will be detected and stored in the memory.
Press and hold the [PS/AS] button (1 sec.) to
start automatic station search.
To stop auto store, press other buttons
having radio functions.
Notes:
1. After auto store, the previous stored
stations will be overwritten.
2. The unit has 5 bands, such as FM1,
FM2, FM3, MW, LW. FM3 and MW, LW
can store by AS function. Each bands
can store 6 stations, CZ101E/CZ101ER/
CZ101EG can store 30 stations in total.
Manual store
When one expected radio station has been
detected, press and hold number button 1-6
to store it in the memory.
Recall the stored stations
Press one numeric button among 1 to 6 on
the panel to select the corresponding stored
station.
Local seeking
When LOCAL seeking is on, only those radio
stations with strong radio signal could be
received.
To open or close LOCAL function, press and
hold the [D] button on the front panel, then
press [ ] button repeatedly until LO or
DX displays on the screen, and rotate the
[VOLUME] knob to select Local or Distant
mode.
Note:
The number of radio stations that can be
received will decrease after the local seeking
mode is on.
10
Radio Data System Operations
English
Radio Data System
This unit has a built-in “Radio Data System”
decoder system that supports broadcast
stations transmitting “Radio Data System”
data.
Whe n usi ng the “ Rad io Da ta Sys tem ”
function, always set the radio to FM mode.
AF function
The AF function switches to a dif fe rent
frequency on the same network in order to
maintain optimum reception.
* The factory default setting is ON.
1. Set to system setup by long pressing [D]
button.
2. Press the [ ] or [ ] button to select
“AF”.
3. Rotate the [VOLUME] knob to select ON
or OFF.
• AF ON:
“AF” indicator appears in the display and
AF function turns on.
• AF OFF:
“AF” indicator disappears in the display
and AF function turns off.
REG (Regional programme)
function
When the REG function is ON, the optimum
regional station can be received. When this
function is OFF, if the regional station area
switches as you drive, a regional station for
that region is received.
* The factory default setting is ON.
Notes:
• This function is disabled when a national
station such as BBC R2 is being received.
• The REG function ON/OFF setting is valid
when the AF function is ON.
1. Set to system setup by long pressing [D]
button.
2. Press the [ ] or [ ] button to select
“REG”.
3. Rotate the [VOLUME] knob to select ON
or OFF.
Manually tuning a regional station
in the same network
This function is valid when the AF function is
ON and the REG function is OFF.
Note:
This function can be used when a regional
broadcast of the same network is received.
TA (Trafc Announcement)
In the TA standby mode, when a trafc
announcement broadcast starts, the trafc
announcement broadcast is received as top
priority regardless of the function mode so
you can listen to it. Trafc programme (TP)
automatic tuning is also available.
* This function can only be used when
“TP” appears in the display. When “TP”
appears, this means that the “Radio Data
System” broadcast station being received
has trafc announcement programmes.
Setting the TA standby mode
If you press the [TA] button, “TA” lights in
the display and the unit is set into the TA
standby mode until a traffic announcement
is broadcast. When a traffic announcement
broadcast starts, “TRAF INF” appears in the
display. If you press the [TA] button while
a traffic announcement broadcast is being
received, the trafc announcement broadcast
reception is cancelled and the unit goes into
the TA standby mode.
Cancelling the TA standby mode
As “TA” lits in the display, press the [TA]
button. The “TA” in the display goes off and
the TA standby mode is cancelled.
PTY (Programme Type)
This function enabl es you to listen to a
broadcast of the selected programme type
even if the unit is on a function mode other
than radio.
* Some countries do not yet have PTY
broadcast.
* In the TA standby mode, a TP station has
priority over a PTY broadcast station.
Selecting PTY
Press [MENU] but ton , the n rotate the
[VOLUME] k nob to s elect PTY typ e,
press the [VOLUME] knob, the unit begin
searching.
11
CD/MP3/WMA Operations
English
This unit can play back MP3/WMA
les
Notes:
• If you play a WMA file with active DRM
(Digital Rights Management), no audio is
output.
To disable DRM
(Digital Rights Management)
When using Windows Media Player 9/10/11,
click on Tool -> Options -> Copy music tab,
then under Copy settings, unclick the Check
box for Copy protect music. Then, reconstruct
les.
Personally constructed WMA files are used
at your own responsibility.
Precautions when creating MP3/
WMA le
Usable sampling rates and bit rates
1. MP3: Sampling rate 8 kHz-48 kHz, Bit rate
8 kbps-320 kbps / VBR
2. WMA: Bit rate 8 kbps-320 kbps
File extensions
1. Alwa ys add a file exten sion “.MP 3”,
“.WMA” to MP3, WMA le by using single
byte letters. If you add a file extension
other than specified or forget to add the
le extension, the le cannot be played.
2. Files without MP3/WMA data will not play.
The les will be played soundlessly if you
attempt to play files without MP3/WMA
data.
* When VBR les are played, the play time
display may differ the play location.
* When MP3/WMA les are played, a little
no sound part is caused between tunes.
byte alphabetical letters and numerals
(including an extension).
3. Do not afx a name to a le inside a folder
having the same name.
Folder structure
A disc with a folder having more than 8
hierarchical levels will be impossible.
Number of les or folders
1. Up to 999 files can be recognized per
folder.
Up to 999 les can be played.
2. Tracks are played in the order that they
were recorded onto a disc . (Tr ack s
may not always be played in the order
displayed on the PC.)
3. Some noise may occur depending on
the type of encoder software used while
recording.
Eject function
Just pressing the [ ] button, ejects the disc.
Notes:
• If yo u force a CD int o befor e auto
reloading, this can damage the CD.
• If a CD (12 cm) is left ejected for 15
seconds, the CD is automatically reloaded
(Auto reload).
Listening to a disc already loa
ded in the unit
Press the [SRC / ] button to select the CD/
MP3/WMA mode.
When the unit enters the CD/MP3/WMA
mode, play starts automatically.
Logical format (File system)
1. When writing MP3/WMA file on a CD-R
dis c or C D-R W disc, pl ease selec t
“ISO9660 level 1, 2 or Joliet or Romeo” or
Apple ISO as the writing software format.
Normal play may not be possible if the
disc is recorded on another format.
2. The folder name and file name can be
displayed as the title during MP3/WMA
play but the title must be within 32 single
Loading a CD
In ser t a CD into the center of the CD
SLOT with label facing up. The CD plays
automatically after loading.
Notes:
• Never insert foreign objects into the CD
SLOT.
• If the CD is not inserted easily, there may
be another CD in the mechanism or the
unit may require service.
12
CD/MP3/WMA Operations
English
• Discs without the or
CD-ROMs cannot be played by this unit.
• Some CD-R/CD-RW discs may not be
usable.
mark and
TEXT
Pausing play
1. Press the [ 4 ] button to pause play.
“PAUSE” appears in the display.
2. To resume CD play, press the [ 4 ] button
again.
Displaying CD titles
This unit can display title data for MP3/WMA
disc.
When SCROLL is OFF, each time you press
the [BAND] button to change the title display.
MP3/WMA disc
Track -> Folder -> File title -> Album -> Title
-> Artist -> Track ...
Notes:
• If MP3/WMA disc is not input TAG, “NO
TITLE” appears in the display.
• Only ASCII characters can be displayed in
Tags.
Selecting a track
Track-up
1. Press the [ ] button to move ahead to
the beginning of the next track.
2. Each time you press the [
track advances ahead to the beginning of
the next track.
3. For MP3/WMA disc, press and hold the
[6] button (1 sec.) to move ahead to +10
tracks.
Track-down
1. Press the [
the beginning of the current track.
2. Press the [
to the beginning of the previous track.
3. For MP3/WMA disc, press and hold the [5]
button (1 sec.) to move back to -10 tracks.
] button to move back to
] button twice to move back
] button, the
Fast-forward/Fast-reverse
Fast-forward
Press and hold the [ ] button .
Fast-reverse
Press and hold the [ ] button .
* For MP3/WMA discs, it takes some time
until the start of searching and between
tracks. In addition, some error may occur in
the play time.
Folder Select
This function allows you to select a folder
containing MP3/WMA les and start playing
from the rst track in the folder.
1. Press the [ 5 ] or [ 6 ] button.
Press the [ 6 ] button to move the next
folder. Press the [ 5 ] button to move the
previous folder.
2. To select a track, press the [ ] or [ ]
button.
Search Function
1. Press the [MENU] button to enter FOLD
SCH mode. Press the [VOLUME] button
to enter the folder list search mode.
2. Turn the [VOLUME] knob to select a folder.
3. Press the [VOLUME] button to enter the
file list search mode. And then the track
list appears in the display.
4. Turn the [VOLUME] knob to select a track.
5. Press the [VOLUME] knob to play.
* When play back MP3 / MWA file, this
function is performed in the current folder.
Top function
The top function resets the CD player to the
rst track of the disc. Press and hold the [ 4 ]
button (1 sec.) to play the rst track (track No.
1) on the disc.
* In case of MP3/WMA, the rst track of the
current folder will be played.
13
CD/MP3/WMA Operations
English
Other various play functions
Scan play
This function allows you to locate and play
the rst 10 seconds of all the tracks recorded
on a disc.
Press the [ 1 ] button to perform scan play.
Repeat play
This function allows you to play the current
track repeatedly or play a track currently
bei ng play ed in the MP 3 /WM A folde r
repeatedly.
CD:
1. Press the [ 2 ] button once or more until
“RPT ON” appears on the LCD to perform
repeat play.
2. Press [ 2 ] button repeatedly until “RPT
OFF” appears on the LCD to cancel repeat
playback.
AUX Operations
Press [SRC /
“AUX”.
AUX is just for audio content with 3.5mm
Jack connector plugged into audio-in socket
on the front panel.
] button on the panel to select
MP3/WMA:
1. Press the [ 2 ] button once or more until
“TRACK RPT” appears on the display to
perform repeat play, and “RPT” segment
lights on.
2. For MP3/WM A files, press [ 2 ] button
repeatedly until “FOLDER RPT” appears
on the display for folder repeat play.
3. Press [ 2 ] button repeatedly until “ RPT
OFF” appears on the display to cancel
repeat playback, and “RPT” segment goes
o.
Random play
This function allows you to play all tracks
recorded on a disc in a random order.
Press the [ 3 ] button to perform random play.
AUX Input sensitivity setting
1. Press and hold the [D] button (1 sec.).
2. Turn the [VOLUME] knob to select “AUX
SENS”.
3. If the output level of connected external
audio player is “HIGH”, rotate [VOLUME]
knob and choose “LOW”. And if the output
level is “LOW”, choose “HIGH”.
14
English
6. TROUBLE SHOOTING
GENERAL
Problem Cause Measure
Unit can not
power on.
Unit can not
power on.
Nothing happens
when buttons are
pressed.
Display is not
accurate.
No/low audio
output.
Poor sound
quality or
distortion.
Tel-Mute
malfunction.
Unit resets itself
when engine
is o.
Unit fuse blown. Replace with new fuse of correct rating.
Car battery fuse blown. Replace with new fuse of correct rating.
The microprocessor has
malfunctioned due to noise, etc.
Improper audio output
connection.
Volume set too low. Increase volume level.
Speakers damaged. Replace speakers.
Heavily biased volume balance.
Speaker wiring is in contact with
metal part of car.
Non-standard disc used. Use a standard disc.
Speaker power rating does not
match unit.
Wrong connections. Check wiring and correct.
Speaker is shorted. Check wiring and correct.
MUTE wire is grounded. Check the MUTE wiring and correct.
Incorrect connection between
ACC and Battery.
Turn o the power and remove the DCP.
Press the [RESET] button with a thin rod.
Note:
When the [RESET] button is pressed, turn
o the ACC power.*
* When the [RESET] button is pressed,
frequencies of radio stations, titles, etc.
stored in memory are cleared.
Check wiring and correct.
Adjust the channel balance to center
position.
Insulate all speaker wiring connections.
Replace speakers.
Check wiring and correct.
15
DISC Player
Problem Cause Measure
Eject the disc before loading the new
one.
Remove the object inside the unit.
Replace with a compact disc with no
scratches.
Disc cannot be
loaded.
Sound skips or is
noisy.
Another disc is already loaded.
There is an object install inside
the unit.
Compact disc is dirty. Clean the compact disc with a soft cloth.
Compact disc is heavily scratched
or warped.
English
Sound is bad
when power is rst
turned on.
Condensation may form on the
internal lens when the car is
parked in a humid place.
Let dry for about 1 hour with power on.
7. ERROR DISPLAYS
If an error occurs, one of the following displays is displayed.
Take the measures described below to solve the problem.
Display Cause Measure
ERROR 3
ERROR 5 This is a failure of deck’s mechanism. Consult your store of purchase.
If an error display other than the ones described above appears, press the [RESET] button. If
the problem persists, turn off the power and consult your store of purchase.
* When the [RESET] button is pressed, frequencies of radio stations, titles, etc. stored in
memory are cleared.
Disc is inserted incorrectly. Eject the disc then reload it properly.
The disc format is not supported. Try another disc.
16
English
8. SPECIFICATIONS
FM Tuner
Frequency range: 87.5-108.0MHz
Usable sensitivity: 8dBμ
Frequency response: 30Hz-15kHz
Stereo separation: 30dB(1kHz)
Signal/noise ratio: >55dB
MW Tuner
Frequency range: 531-1602kHz
Usable sensitivity (S/N=20dB): 30dBμ
LW Tuner
Frequency range: 153-279kHz
Usable sensitivity (S/N=20dB): 30dBμ
CD Player
System: Disc digital audio system
Frequency response: 20Hz-20kHz
Signal/noise ratio: >94dB
Total harmonic distortion: Less than 0.1% (1kHz)
Channel separation: >60dB
MP3/WMA mode
MP3 sampling rate: 8 kHz to 48 kHz
MP3 bit rate: 8 kbps to 320 kbps / VBR
WMA bit rate: 8 kbps to 320 kbps
Logical format: ISO9660 level 1,2
Joliet or Romeo le system
General
Power supply voltage:
14.4VDC (10.8 to 15.6V allowable),
negative ground
Pre-Amp output voltage:
2.0V (CD play mode: 1kHz, 0dB, 10k load)
Fuse: 15A
Dimensions of the Main Unit:
188mm Width × 58mm Height × 190mm Depth
Weight of the Main Unit: 1.30kg
Notes:
• Specifications and design are subject
to change with out not ice for furthe r
improvement.
Audio Amplier
Maximum power output:
180W (45W x 4)
Speaker impedance: 4 (4 to 8 allowable)
Input
Audio input sensitivity:
High: 320mV (at 1V output)
Mid: 650mV (at 1V output)
Low: 1.3V (at 1V output)
(input impedance 10 k or greater)
Aux-in level: ≤2V
17
9. INSTALLATION / WIRE
CONNECTION GUIDE
CONTENTS
1) Before Starting ......................................................................18
2) Package Contents ................................................................. 18
3) General Cautions ..................................................................18
4) Cautions on Installation ......................................................... 19
5) Installing the Source Unit ......................................................19
6) Removing the Source Unit ....................................................21
7) Wiring and Connections ........................................................22
8) Connecting the Accessories .................................................. 23
1) Before Starting
1. This set is exclusively for use in cars with a
negative ground 12 V power supply.
2. Read these instructions carefully.
3. Be sure to disconnect the battery “terminal”
before starting. This is to prevent short circuits
during installation. (Figure 1)
Figure 1
2) Package Contents
English
Car battery
Source unit ..........................................1
Front panel ..........................................1
Trim ring ..............................................1
Mounting bracket ................................. 1
Special screw (M4x42) ........................1
Screws M5x6 mm ................................ 4
Rubber cap .......................................... 1
3) General Cautions
1. Do not open the case. There are no
user serviceable parts inside. If you
drop anything into the unit during
installation, consult your dealer or an
authorized Clarion service center.
L-key .................................................... 2
Wire connector ....................................1
DCP case ............................................1
Owner’s manual................................... 1
Warranty card ...................................... 1
Special screw (Front panel lock) .........1
2. Use a soft, dry cloth to clean the case.
Never use a rough cloth, thinner,
benzine, or alcohol etc. For tough dirt,
apply a little cold or warm water to a
soft cloth and wipe off the dirt gently.
18
4) Cautions on Installation
English
1. Prepare all articles necessary for
installing the source unit before
starting.
2. Install the unit within 30° of the
horizontal plane. (Figure 2)
3. If you have to do any work on the car
your car dealer beforehand.
4. Use the enclosed screws for
installation.
Using other screws can cause
damage.
(Figure 3)
body, such as drilling holes, consult
Chassis Chassis
Damage
Max 30
˚
Max. 6 mm (M5 screw)
Figure 2 Figure 3
5) Installing the Source Unit
1. Place the mounting bracket into the instrument panel, use a screwdriver to bend
each stopper of the mounting bracket inward, then secure the stopper.
2. Wire as shown in Section 7) .
3. Insert the source unit into the mounting bracket until it locks.
4. Take care of the top and bottom of the trim ring and mount it so that all the hooks
are locked.
Notes:
1. Some car models require special mounting kits for proper installation.
Consult your Clarion dealer for details.
2. Fasten the front stopper securely to prevent the source unit from coming loose.
• Console opening dimensions
(182 mm)
Hole
19
53 mm
Notes of installation
1. Before installation, please make sure
proper connections are conducted and
the unit operates normally. Improper
connection may result in damage to the
unit.
2. Use only accessories designed and
manufactured for this unit and other
unauthorized accessories may result in
damage to the unit.
3. Before installation, please fasten all power
cables.
4. DO NOT install the unit in the place where
close to hot area to prevent damage to
electrical components such as the laser
head.
5. Install the unit horizontally. Installing the
unit more than 30 degree vertically may
result in worse performance.
6. To prevent electric spark, connect the
positive pole rst and then the negative
pole.
7. DO NOT block the cooling fan exit to
ensure sufcient heating dissipation of this
unit, or it may result in damage to this unit.
Unit Installation
Method A
1. Insert mounting bracket into dash board,
choose appropriate mounting tab according
to the gap width, bending the mounting
tab outwards with a screwdriver to x the
mounting bracket in place.
2. Screw in 1 piece of M4×42 to the hole of
the unit back and put on a rubber cap over
the screw. (see picture below)
3. Slide the unit into the bracket until you hear
a click sound.
English
Dashboard
Mounting Bracket
Screwdriver
Rubber Cap
Special Screw
20
Method B
English
6) Removing the Source Unit
Disassemble trim ring
1. Push the trim ring to right and pull out the
right part.
M5x6
2. Push the trim ring to left and pull out the
left part.
Mounting Frame
Dashboard
1. Insert this unit directly to the opening of
the dashboard.
2. Place M5×6 cylindrical screw through the
holes of the mounting frame located inside
the opening to holes of the unit and fasten
the screws to left & right.
Trim Ring Installation
Attach the trim ring around the front panel.
Disassemble the unit
1. Switch off the power.
2. Remove the panel.
3. Remove the trim ring.
4. Insert the removal keys straight back until
they lock, then pull the unit out.
5. Disconnect all the wires.
21
7) Wiring and Connections
Black
Black
White
Rear audio output (Left) /
Subwoofer output 1
Red
Rear audio output (Right) /
Subwoofer output 2
English
Steering wheel
control terminal
(Black)
Black
Antenna
Black
SWC
C
2 Channel Amplier
Fuse 15A
Refer to next page
B
1
A
2
3
1
4
2
5
3
6
4
7
5
8
6
7
8
22
English
A
1
16
14
12
10
8
6
4
2
Rear right -
Front right -
Front left +
Rear left +
AMP Remote
ACC +
Ground
3
5
7
2
4
6
8
C
Rear right +
15
13
Front right +
11
Front left -
9
Rear left -
7
Illumination
5
Phone Mute
3
1
Battery +
B
1
3
5
7
2
4
6
8
Location
Connector A Connector B
Phone Mute / Brown Rear right (+) / Purple
Battery 12V(+) / Yellow
Remote On / Blue with white stripe
Illumination / Orange with white stripe Front left (-) / White with black stripe
ACC+ / Red Rear left (+) / Green
Ground / Black Rear left (-) / Green with black stripe
Red Red
Function
Rear right (-) / Purple with black stripe
Front right (+) / Gray
Front right (-) / Gray with black stripe
Front left (+) / White
YellowYellow
For VW and Audi: Change wiring like above.
8) Connecting the Accessories
• Connecting to the external amplier
External ampliers can be connected to the 2 channel RCA output connections.
Ensure that the connectors are not grounded or shorted to prevent damage to the
unit.
23
English:
Declaration of conformity
We Clarion declares that this model CZ101E is
following the provision of Directive 1999/5/EC with
the essential requirements and the other relevant
regulations.
Français:
Déclaration de conformité
Nous, Clarion, déclarons que ce modèle CZ101E
est conforme aux exigences essentielles et aux
autres dispositions pertinentes de la directive
1999/5/CE.
Deutsch:
Konformitätserklärung
Wir, Clarion, erklären, dass dieses Modell CZ101E
den Bestimmungen der Richtlinie 1999/5/EG im
Hinblick auf die grundlegenden Anforderungen und
andere relevante Bestimmungen entspricht.
Italiano:
Dichiarazione di conformità
Clarion dichiara che il presente modello CZ101E
è conforme ai requisiti essenziali e alle altre
disposizioni pertinenti stabiliti dalla direttiva 1999/5/
CE.
Nederlands:
Conformiteitsverklaring
Clarion verklaart dat het model CZ101E in
overeenstemming is met de essentiële eisen en
andere relevante voorschriften van de bepalingen
van Richtlijn 1999/5/EC.
Español:
Declaración de conformidad
Clarion declara que este modelo CZ101E cumple
con los requisitos esenciales y otras disposiciones
aplicables descritos en la Directiva 1999/5/CE.
Svenska:
Intyg om överensstämmelse
Härmed intygar Clarion att denna modell CZ101E
uppfyller kraven i direktiv 1999/5/EG gällande
väsentliga egenskaper och övriga relevanta
bestämmelser.
Polski:
Deklaracja zgodności
Fir ma Clar ion n ini ejszym oświ adc za, ż e model
CZ101E jest zgodny z istotnymi wymogami oraz
innymi odpowiednimi postanowieniami Dyrektywy
1999/5/WE
Ελληνικά:
Δήλωση συμμόρφωσης
Εμείς στην Clarion δηλώνουμε ότι αυτό το μοντέλο
CZ101E τηρεί τις διατάξεις της Οδηγίας 1999/5/ΕΚ
σχετικά με τις ουσιώδεις απαιτήσεις και τους άλλους
σχετικούς κανονισμούς.
Italy
Dichiarazione di conformità:
Io mandatario nell’ UE: Clarion Europe S.A.S.
Z.I. du Pré à Varois, Route de Pompey, 54670
Custines, Francia Dichiaro che il prodotto
CZ101E è conforme al DM 28-08-1995
ottemperando alle prescrizioni dei DM
25-06-1985 e DM 27-08-1987.
Ministerial authorization FI DM 27-08-1987 nº of
protocol: 0053639 date 13/07/2010
Clarion Europe S.A.S.
Z.I. du Pré à Varois, Route de Pompey, 54670 Custines, FRANCE (Γαλλία)
Clarion Co., Ltd.
All Rights Reserved. Copyright © 2010: Clarion Co., Ltd.
Printed in China / Imprimé en Chine / Gedruckt in China
Stampato in Cina / Gedrukt in China / Impreso en China
Tryckt i Kina / Wydrukowano w Chinach / Εκtυpώθηκe stην Κίνa
PN: 127075002837
Loading...
