Citizen REF CH-471B, REF CH-481C Instruction Manual

English

— Eng 1 —

IDENTIFICATION OF PARTS

P

O

W

E

R



S

T

A

R

T



SYSTOLIC

mmHg

mmHg

D

IA

S

T

O

L

IC



P

U

L

S

E



Systolic blood pressure display section

Start switch

Power switch

Battery
cover

Diastolic blood pressure
display section

Pulse display
section

Cuff Tube Air connector

INSTRUCTION MANUAL

FOR

DIGITAL BLOOD PRESSURE MONITOR

REF CH-471 B

TM

— Eng 2 —

CLEANING METHOD OF CUFF

After cleaning the cuff with a neutral detergent, lightly rinse it
with water and let it dry in the air. Hard rubbing or washing in a

washing machine will cause air leakage. Also, be careful not to
get water into the air hose.

GENERAL REMARKS

General Remarks on blood pressure measurement

• If the cuff is to be deflated quickly, depress “POWER” switch.

• The attached cuff is suited for an arm circumstance of 22cm
to 32cm.

• When attaching the cuff, rubber cuff hose should be placed
on the inside of your arm on top of the arterial.

• Self measurement is no therapy! In no case may y ou change
the dosage of medication prescribed by your physician.

• In operation for blood pressure measurement, you should
urinate and should remain relatively still for 10 to 15 min­utes prior to measurement.

• Exercise, eating and drinking, smoking, etc., prior to mea­surement may affect the results.

• The blood pressure varies constantly throughout the day.
Measurement should be made regularly at the same time
each day.

• Do NOT be impressed by the results of one measurement.
Keep a record of blood pressure variations. Many readings
tell a story.

• Emotional stress may tend to cause pressure to rise.

For proper measurement of blood pressure

• Take a deep breath five or six time and then relax before
measuring blood pressure. If you are tense when taking
the measurement, you will not get a valid reading.

SPECIFICATIONS

Measuring method: Oscillometric system
Indication: Digital display, Height: 14.5mm
Measuring range: Pressure; 0 ~ 280mmHg, Pulse; 40 ~ 180 beat/min.
Accuracy: Pressure; ±3mmHg, Pulse; ±5%
Inflation: Automatic inflation at suitable level by internal pump
Deflation: Electromagnetic valve
Memory function: 1 data
Power source: 4 “AA” (LR6) Alkaline batteries
Battery life: Approx. 700 times/LR6 (once a day, 170mmHg, room temp. 22°C)
Rated voltage: 6V DC
Working temp. & humidity: +10°C ~ +40°C, 30 to 85%RH
Storage temp. & humidity: –20°C ~ +60°C, 10 to 95%RH
Outside dimensions: 171mm(W) × 125mm(D) × 65mm(H)
Weight: 440g (Apparatus and batteries)
Electric shock protection: Type B equipment
Accessories: Preformed Cuff, 4 “AA” (LR6) batteries, Instruction manual

*Specifications and designs may be changed without notice in the event of improvements being made.

English

— Eng 3 —

• Blood pressure will be elevated when you are in a worri­some or irritated state, suffering from lack of sleep or con­stipation, or after exercise or a meal.

• Putting on the cuff is one of the most important tasks for
ensuring proper measurement of blood pressure.

Wind
the cuff around the arm and tighten it so that one
finger may be inserted between the cuff and arm.

• Do NOT measure blood pressure after bathing or drinking.

• When you feel like relieving yourself, you should do so be­fore measuring blood pressure.

• Measure blood pressure where the room temperature is

PRECAUTION FOR USE AND MAINTENANCE

• NEVER wipe the blood pressure monitor with thinner or
benzene, as they may damage it.

• When the monitor is very dirty, wipe it clean with a cloth
moistened with Sterilizing alcohol or a neutral detergent,
and then wipe it with a dry cloth. Do NOT use thinner or
benzene.

Nature and frequency of maintenance:

This products is designed for use over an extended period of
time; however, it is generally recommended that it be inspected
every two years to ensure proper function and performance.

Protect the nature environment:

Please help protect natural environment by respecting national
and/or local recycling regulations when disposing of the batter­ies and the products at the end of their useful lives.

Reference European standard:

This products complies with EC instructions 93/42/EEC (Medi­cal Device Directive) and with the f ollo wing standards: EN 1060­1: 1995 “Noninvasive Sphygmomanometers, Part 1 General
Requirements” and EN 1060-3: 1997 “Noninvasive Sphygmo­manometers, Part 3 Supplementary Requirements for Electro­mechanical Blood-Pressure Measuring Systems.

about 20°C. Do NOT measure blood pressure when it is
too cold (below 10°C) or too hot (above 40°C) in the room.

• Do NOT measure blood pressure immediately after drink­ing coffee or tea or smoking.

• Measure blood pressure with a relaxed and quiet posture.
Keep the center of the cuff at the level of your heart, and
do NOT move your arm or talk during measurement.

• Do NOT keep on measuring so many times, as your arm
will have built up congestion of b lood, and you will not get a
valid reading.

Precautions for use

• If you suffer from hear t disease, high blood pressure or
other circulatory disease, please consult your doctor first.

• If you feel abnormal pressure of the cuff during use or any
other irregularity, reduce the pressure by immediately
switching off the power or removing the batteries and con­sult the sales outlet where purchased.

• If you think the measured value is abnormal or if measur­ing makes you feel unw ell, discontinue use and consult your
doctor.

• Measurement of blood pressure may not be possible for
someone with a weak pulse or arrhythmia.

• Congestion, swelling, etc. may occur in some people.

• If blood pressure is measured repeatedly, an accurate
result will not be achieved. An interval of about 10 minutes
should be allowed.

• The memory is erased if the batteries are removed for re­placement, etc. and a record should be kept of any neces­sary data.

Precautions for maintenance

• Do NOT store the blood pressure monitor where it will be
exposed to direct sunlight, high temperature (over 60°C),
low temperature (below –20°C), high relative humidity (ov er
95%) or in a dusty place.

• Do NOT expose the blood pressure monitor to under force
or vibration, or drop it.

• Remove the battery/batteries when not in use for a long
period.

• Do NOT disassemble the apparatus.

• Do NOT bend the cuff or air hose unnecessarily.
