Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

Inc.; and Access Registrar, Aironet, Catalyst, CCDA, CCDP, CCIE, CCIP, CCNA, CCNP, CCSP, Cisco, the Cisco Certified Internetwork Expert logo, Cisco IOS,

Press, Cisco Systems, Cisco Systems Capital, the Cisco Systems logo, Cisco Unity, Enterprise/Solver, EtherChannel, EtherFast, EtherSwitch, Fast Step, Follow Me

New and Changed Information v

Preface vii

Audience vii

Organization vii

Conventions viii

New and Changed Information

The Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide applies to the SFS 7024 Release

3.1 or later.

Table 1 lists the new and changed features available with each supported SFS 7024 release.

Ta b l e 1 Documented Features for the Cisco SFS 7024 InfiniBand Server Switch Hardware

Users Guide

Feature Description

Initial release of the Cisco SFS 7024

InfiniBand Server Switch Hardware

Users Guide

Redundant Management

Double Data Rate (DDR) capabilities

Added redundant management information.

Added DDR information

Changed in Release

3.3 Installing the Spine

3.4 Product Overview,

Where Documented

and Leaf Modules, page 1-17

Updating Management Spine IP Addresses in a Redundant Management Configuration, page 1-27

page 1-1

OL-8794-05

Port Statistics Field Descriptions, page 2-36

CLI command ismPortSetSpeed in

the section

IbSwitchInfo, page B-55 of

Appendix B: Command Line Interface.

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

Table 1 Documented Features for the Cisco SFS 7024 InfiniBand Server Switch Hardware

Users Guide (continued)

Changed in

Feature Description

User authentication via command line

User login and password required to

access the SFS 7024 interface (CLI), serial console and Chassis Viewer GUI

Release Where Documented

4.1.1.1.11 LDAP Configuration,

page 2-20

HTTP/CLI Session Configuration, page 2-21

Accessing the CLI, page B-3

Added the following CLI commands:

• userAdd

• userAdd allows multiple user

accounts to be created.

• userRem allows user accounts to be

removed.

4.1.1.1.11 Refer to the CLI command group

General, page B-4

• userRem

• userListShow

• userListShow allows the list of

user accounts to be displayed.

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

Preface

This preface describes the audience, organization, and conventions of the Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide . It also provides information on how to obtain related documentation.

Audience

The intended audience for this document are network administrators responsible for configuring and operating network equipment. It assumes a basic working knowledge of:

• Local Area Networks (LANs)

• Ethernet concepts

• Simple Network Management Protocol (SNMP)

• InfiniBand

Organization

OL-8794-05

This guide is organized as follows:

Chapter Title Description

Chapter 1 Installation Task-oriented information for installing the SFS 7024

Chapter 2 Operations and

Administration

Appendix A Technical

Specifications

Appendix B Command Line

Interface

Appendix C Troubleshooting Troubleshooting symptoms and resolutions for the SFS 7024

Task-oriented information for configuring and monitoring the SFS 7024

SFS 7024 technical specifications

Reference information for the SFS 7024 command line interface (CLI)

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

vii

Conventions

This document uses the following conventions for notes, cautions, and safety warnings.

Notes and Cautions contain important information that you should be aware of.

Note Means reader take note. Notes contain helpful suggestions or references to material not

covered in the publication.

Caution Means reader be careful. You are capable of doing something that might result in equipment damage or

loss of data.

Safety warnings appear throughout this publication in procedures that, if performed incorrectly, may harm you. A warning symbol precedes each warning statement.

Warning

This warning symbol means danger. You are in a situation that could cause bodily injury. Before you work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar with standard practices for preventing accidents. To see translations of the warnings that appear in this publication, refer to the Regulatory Compliance and Safety Information document that accompanied this device.

Obtaining Documentation, Obtaining Support, and Security Guidelines

viii

For information on obtaining documentation, obtaining support, providing documentation feedback, security guidelines, and also recommended aliases and general Cisco

What’s

New in Cisco Product Documentation, which also lists all new and revised Cisco technical

documentation, at:

http://www.cisco.com/en/US/docs/general/whatsnew/whatsnew.html

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

documents, see the monthly

OL-8794-05

CHAPTER

Installation

This chapter describes how to install the Cisco SFS 7024 and its components, and it includes the following information:

• Planning the Installation, page 1-7

• Installation Tasks, page 1-12

• Hot Swapping Components, page 1-32

Note Before you install, operate, or service the system, read the Regulatory Compliance and Safety

Information for the Cisco Server Fabric Switches: 7000P, 7000D, 7008P, 7012, 7024, and 3012R for important safety information.

OL-8794-05

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

1-1

Warning

IMPORTANT SAFETY INSTRUCTIONS

This warning symbol means danger. You are in a situation that could cause bodily injury. Before you work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar with standard practices for preventing accidents. Use the statement number provided at the end of each warning to locate its translation in the translated safety warnings that accompanied this device.

Statement 1071

SAVE THESE INSTRUCTIONS

Warning

This unit is intended for installation in restricted access areas. A restricted access area can be accessed only through the use of a special tool, lock and key, or other means of security.

Statement 1017

Warning

Only trained and qualified personnel should be allowed to install, replace, or service this equipment.

Statement 1030

Warning

A readily accessible two-poled disconnect device must be incorporated in the fixed wiring.

1022

Statement 1019—Main Disconnecting Device

Warning

Waarschuwing

The plug-socket combination must be accessible at all times, because it serves as the main disconnecting device.

Statement 1019

De combinatie van de stekker en het elektrisch contactpunt moet te allen tijde toegankelijk zijn omdat deze het hoofdmechanisme vormt voor verbreking van de aansluiting.

Statement

1-2

Varoitus

Attention

Pistoke/liitinkohta toimii pääkatkaisumekanismina. Pääsy siihen on pidettävä aina esteettömänä.

La combinaison de prise de courant doit être accessible à tout moment parce qu'elle fait office de système principal de déconnexion.

Warnung

Der Netzkabelanschluß am Gerät muß jederzeit zugänglich sein, weil er als primäre Ausschaltvorrichtung dient.

Avvertenza

Il gruppo spina-presa deve essere sempre accessibile, poiché viene utilizzato come dispositivo di scollegamento principale.

Advarsel

Kombinasjonen støpsel/uttak må alltid være tilgjengelig ettersom den fungerer som hovedfrakoplingsenhet.

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

Aviso

¡Advertencia!

Varning!

A combinação ficha-tomada deverá ser sempre acessível, porque funciona como interruptor principal.

El conjunto de clavija y toma ha de encontrarse siempre accesible ya que hace las veces de dispositivo de desconexión principal.

Man måste alltid kunna komma åt stickproppen i uttaget, eftersom denna koppling utgör den huvudsakliga frånkopplingsanordningen.

Statement 1045—Short-circuit Protection

Warning

Waarschuwing

Varoitus

Attention

Warnung

Avvertenza

This product requires short-circuit (overcurrent) protection, to be provided as part of the building installation. Install only in accordance with national and local wiring regulations.

Voor dit product moet kortsluitbeveiliging (overstroombeveiliging) deel uitmaken van de installatie in het gebouw. De installatie moet voldoen aan de nationale en lokale bedradingvoorschriften.

Tämä tuote vaatii suojauksen oikosulkuja (ylivirtaa) vastaan osana asennusta rakennukseen. Asenna ainoastaan kansallisten ja paikallisten johdotussäännösten mukaisesti.

La protection de ce produit contre les courts-circuits (surtensions) doit être assurée par la configuration électrique du bâtiment. Vérifiez que l'installation a lieu uniquement en conformité avec les normes de câblage en vigueur au niveau national et local.

Für dieses Produkt ist eine Kurzschlußsicherung (Überstromsicherung) erforderlich, die als Teil der Gebäudeinstallation zur Verfügung gestellt wird. Die Installation sollte nur in Übereinstimmung mit den nationalen und regionalen Vorschriften zur Verkabelung erfolgen.

Questo prodotto richiede una protezione contro i cortocircuiti, da fornirsi come parte integrante delle dotazioni presenti nell’edificio. Effettuare l’installazione rispettando le Norme CEI pertinenti.

OL-8794-05

Advarsel

Dette produktet krever beskyttelse mot kortslutninger (overspenninger) som en del av installasjonen. Bare installer utstyret i henhold til nasjonale og lokale krav til ledningsnett.

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

1-3

Aviso

Este produto requer proteção contra curto-circuitos (sobreintensidade de corrente), que deve estar instalada nos edifícios. Instale apenas de acordo com as normas de instalação elétrica nacionais

locais.

Advertencia

Varning!

Este producto necesita estar conectado a la protección frente a cortacircuitos (sobretensiones) que exista en el edificio. Instálelo únicamente en conformidad con las regulaciones sobre cableado, tanto locales como nacionales, a las que se tenga que atener.

Denna produkt kräver att kortslutningsskydd (överström) tillhandahålles som en del av byggnadsinstallationen. Installera bara i enlighet med nationella och lokala kabeldragningsbestämmelser.

Aviso

Advarsel

Este produto requer uma proteção contra curto-circuito (sobrecorrente) que deve fazer parte da instalação do edifício. Faça a instalação somente de acordo com as regulamentações de cabeamento nacionais e locais.

Dette produkt kræver beskyttelse mod kortslutning (overstrøm). Dette skal være en del elinstallationen i bygningen. Installation skal ske i overensstemmelse med nationale og lokale ledningsregler.

1-4

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

Statement 1074—Comply with Local and National Electrical Codes

Warning

Waarschuwing

Varoitus

Attention

Warnung

Avvertenza

Advarsel

Aviso

¡Advertencia!

Installation of the equipment must comply with local and national electrical codes.

Bij installatie van de apparatuur moet worden voldaan aan de lokale en nationale elektriciteitsvoorschriften.

Laitteisto tulee asentaa paikallisten ja kansallisten sähkömääräysten mukaisesti.

L'équipement doit être installé conformément aux normes électriques nationales et locales.

Die Installation der Geräte muss den Sicherheitsstandards entsprechen.

L'installazione dell'impianto deve essere conforme ai codici elettrici locali e nazionali.

Installasjon av utstyret må samsvare med lokale og nasjonale elektrisitetsforskrifter.

A instalação do equipamento tem de estar em conformidade com os códigos eléctricos locais e nacionais.

La instalación del equipo debe cumplir con las normativas de electricidad locales y nacionales.

Statement 1074

OL-8794-05

Varning!

Installation av utrustningen måste ske i enlighet med gällande elinstallationsföreskrifter.

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

1-5

Statement 1075—Hazardous Voltage or Energy Present on DC Power Terminals

Warning

Waarschuwing

Varoitus

Attention

Warnung

Avvertenza

Advarsel

Hazardous voltage or energy may be present on DC power terminals. Always replace cover when terminals are not in service. Be sure uninsulated conductors are not accessible when cover is in

Statement 1075

place.

Op DC-aansluitingspunten kunnen zich gevaarlijke voltages of energieën voordoen. Plaats altijd de afsluiting wanneer de aansluitingspunten niet worden gebruikt Zorg ervoor dat blootliggende contactpunten niet toegankelijk zijn wanneer de afsluiting is geplaatst.

Tasavirtaliittimissä saattaa olla huomattava jännite tai teho. Sulje suojus aina, kun liittimet eivät ole käytössä. Suojuksen ollessa suljettuna varmista, että kohde on suojattu eristämättömiltä johtimilta.

Le voltage ou l'énergie électrique des terminaux à courant continu peuvent être dangereux. Veillez à toujours replacer le couvercle lors les terminaux ne sont pas en service. Assurez-vous que les conducteurs non isolés ne sont pas accessibles lorsque le couvercle est en place.

In mit Gleichstrom betriebenen Terminals kann es zu gefählicher Spannung kommen. Die Terminals müssen abgedeckt werden, wenn sie nicht in Betrieb sind. Stellen Sie bei Benutzung der Abdeckung sicher, dass alle nicht isolierten, stromführenden Kabel abgedeckt sind.

I terminali di alimentazione DC potrebbero contenere voltaggio o energia pericolosi. Accertarsi di sostituire il coperchio ogni qualvolta i terminali non sono operativi. Accertarsi che i conduttori scoperti non siano accessibili quando il coperchio è inserito.

Det kan forekomme farlig spenning eller energi i likestrømsterminaler. Sett alltid dekselet på plass når terminalene ikke er i bruk. Kontroller at uisolerte ledere ikke er tilgjengelige når dekselet er på plass.

1-6

Aviso

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

Os terminais de corrente contínua podem fornecer tensão ou energia perigosa. Volte a colocar a tampa, sempre que os terminais não estiverem a ser utilizados. Certifique-se de que os condutores sem isolamento não estão acessíveis, quando a tampa estiver colocada.

OL-8794-05

¡Advertencia!

Varning!

Puede haber energía o voltaje peligrosos en los terminales eléctricos de CC. Reemplace siempre la cubierta cuando no estén utilizándose los terminales. Asegúrese de que no haya acceso a conductores descubiertos cuando la cubierta esté colocada.

Farlig spänning eller skadlig energi kan finnas i likströmsterminalerna. Sätt alltid tillbaka höljet när terminalerna inte används. Försäkra att inga oisolerade ledare kan nås när höljet sitter på plats.

Planning the Installation

Rack Specifications and Recommendations

The SFS 7024 switch is designed to be installed in an existing 19-inch equipment rack or server rack.

Note The SFS 7024 switch is designed for a four-post server cabinet. It is not designed for a two-post telco

cabinet.

Racks should conform to conventional standards. In the United States, use American National Standards Institute (ANSI)/Electronic Industries Association (EIA) standard ANSI/EIA-310-D-92, and International Electrotechnical Commission (IEC) 297

• Racks should meet the following mechanical recommendations:

–

Four-post, 19" rack to facilitate easy maintenance

–

Universal mounting rail hole pattern identified in IEC Standard 297

–

Mounting holes flush with the rails to accommodate the switch

• Use a rack grounding kit and a ground conductor that is carried back to earth or to another suitable

building ground. Ground the equipment rack to earth ground.

• Provide enough room to work on the equipment. Clear the work site of any unnecessary materials.

Make sure the equipment will have enough clearance for front and rear access.

OL-8794-05

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

1-7

Cable Requirements

Cable Distances

When planning the location of the switches, consider the distance limitations for signaling, EMI, and connector compatibility. It is recommended that the user does not exceed specified transmission rate and distance limits.

Note Building and electrical codes vary depending on the location. Comply with all code specifications when

planning the site and installing cable.

When running cables to the equipment, consider the following:

• Do not run cables where they can be stepped on or rolled over.

• Be sure cables are intact with no cuts, bends, or nicks.

• If the user is making a cable, ensure that the cable is properly crimped.

• Provide proper strain relief for standard IB cables.

• Support cable using a cable manager mounted above connectors to avoid unnecessary weight on the

• Bundle cable using velcro straps to avoid injuring cables.

• Keep all ports and connectors free of dust.

• Untwisted Pair (UTP) cables can build up Electrostatic Discharge (ESD) charges when being pulled

cable bundles.

into a new installation. Before installing category 5 UTP cables, discharge ESD from the cable by plugging it into a port on a system that is not powered on.

• When required for safety and fire rating requirements, plenum-rated cable can be used. Check the

local building codes to determine when it is appropriate to use plenum-rated cable, or refer to IEC standard 850.

Uninterruptible Power Supply

Consider the following when selecting Uninterruptible Power Supply (UPS) equipment:

• The minimum amperage requirements for a UPS:

–

Calculate VA (Volt-Amps): Locate the voltage and amperage requirements for each piece of equipment (usually located on a sticker on the back or bottom of the equipment). Multiply the numbers together to get VA.

–

Add the VA from each piece of equipment together to find the total VA requirement. Then add 30% to determine the minimum amperage requirements for the UPS.

• Transition time (the time necessary for the UPS to transfer from utility power to full-load battery

power).

• The longest potential time period the UPS might be required to supply backup power.

• Whether or not the UPS unit also provides online protection.

1-8

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

Installation Tasks Checklist

To perform the actual switch installation, the site implementation engineer must perform the following tasks, which are detailed in this section.

Caution Be sure to review the Safety Information on page 1-9 before starting the installation and during the

installation process. Check the installation site to verify the installation of cabinet power feeds, rails, and grounding.

Step 1 Unpack the equipment and inspect for any shipping damage. Any shipping damage should be reported

to the shipping company.

Step 2 Verify that the equipment shipped matches the packing list.

Step 3 Mark the rack and install the mounting rails.

Step 4 Physically install the switch in the rack.

Safety Information

The following safety guidelines are provided to ensure both personal safety for the user and to protect the system from potential damage. These precautions cover the following categories:

• Precautions for Rack-Mountable Products

• Protecting Against Electrostatic Discharge

• Electrical Safety Precautions

Precautions fit into one of three categories:

Note A textual callout designed to emphasize:

–

Tasks of particular importance.

–

Tips and reminders to maximize the use of the equipment.

Caution Potential for damage to system equipment. Damage to the system caused by the user may have potential

warranty implications.

Warning

Potential for personal injury.

Precautions for Rack-Mountable Products

OL-8794-05

Warning

Installing system components in a rack without the front and side stabilizers installed could cause the rack to tip over. Therefore, always install the stabilizers before installing components in the rack.

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

1-9

Warning

After installing system components in a rack never pull more than one component at one time out of the rack on its slide assemblies. The weight of more than one extended component could cause the rack to tip over.

Warning

Do not step on or stand on any component when servicing other components in a rack.

The chassis, when fully populated with leaf modules, spine modules, power and fan supplies, is very heavy (approximately 175 lbs.). It is recommended that a lifting device be used to handle a fully loaded chassis.

Caution Always load the rack from the bottom up, loading the heaviest item first.

Caution Make sure the rack is level and stable before extending any component from the rack.

Note Ensure that proper airflow is provided to components of the rack.

Protecting Against Electrostatic Discharge

Caution Use a grounded wrist strap designed to prevent static discharge.

Caution Static electricity can harm delicate components inside the system. To prevent ESD damage, users need

discharge any static electricity from their bodies before touching any electronic components. Touching an unpainted metal surface will discharge static electricity.

Caution When transporting an ESD sensitive component, first place it in an antistatic container or packaging.

Electrical Safety Precautions

Warning

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

Do not work alone when working with high voltage components.

This unit may have more than one power cord. To reduce the risk of electrical shock, disconnect both cords before servicing the unit.

1-10

OL-8794-05

Warning

Caution Do not overload the power supply branch circuit providing power to the rack. The total rack load should

To avoid potential electrical shock, operate this unit only when the cover is in place.

To avoid potential electrical shock, use only a grounded (three wire) electrical outlet.

Keep objects that might damage this unit and liquids that might spill clear from this unit. Liquids and foreign objects that come into contact with voltage points could create the risk of fire or electrical shock.

not exceed 80 percent of the branch circuit rating.

Caution Keep power cord and connection cables clear of obstructions that might cause damage.

Caution Do not attempt to service the unit yourself. The first course of action is to contact Technical Support.

Note Unplug this unit from the electrical outlet and refer servicing to a qualified service center if any of the

following conditions occur:

–

The power cord is damaged or frayed.

–

The unit has been dropped or the case has been damaged.

–

The unit has been exposed to any liquids.

–

The unit does not operate normally when all operating instructions have been followed.

–

The unit exhibits a distinct change in performance, indicating a need for service.

Tools, Equipment and Personnel Required

• An ESD wrist strap

• A #2 Phillips screwdriver

• Pen (felt-tip) to mark the mounting holes\

• Three people to complete the installation (highly recommended). The SFS 7024 switch chassis

weighs up to 180 pounds fully loaded.

Check the Installation Site

The SFS 7024 switch is designed to be installed in an existing server cabinet (not a telco cabinet), where it can be mounted in a standard equipment rack. Mounting brackets are integrated with the switch.

OL-8794-05

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

1-11

Be sure of the following:

• The cabinet has a full earth ground to provide reliable grounding.

• There is enough room to work on the equipment.

• The equipment will have enough clearance for front and rear access.

• The IB cables can be accessed easily.

• Water or moisture cannot enter the switch.

• The ambient temperature stays between 50° - 113°F (5° - 45° C).

• Cabinet doors do not interfere with front-to-back air flow.

The cabinet should have its own power distribution (with switch). If the switch has two power supplies, it is suggested that a cabinet with dual power distribution units is used.

It is recommended that cabinet anti-tip devices are used. This is especially true if installing or removing an SFS 7024 switch in the upper half of the cabinet when the lower half is empty.

Unpack the Equipment

Warning

Step 1 Carefully open the box and unpack the SFS 7024 switch. The SFS 7024 is shipped fully populated and

Read all installation instructions before connecting the system to its power source.

should contain.

–

SFS 7024 Chassis

–

Leaf modules (up to 24)

–

Leaf module blanks (up to 23). These blanks populate unused leaf module slots to help maintain the thermal integrity of the chassis.

–

Spine modules (up to 6)

–

Spine module blanks (up to 4). These blanks populate unused spine module slots to help maintain the thermal integrity of the chassis.

–

Power Supplies: up to twelve (12)

–

Power supply blanks (up to 6). These blanks populate unused power supply slots to help maintain the thermal integrity of the chassis.

–

Fans (8)

–

Mounting hardware kits

Step 2 Inspect the equipment for any shipping damage and report any problems to the shipping company.

Step 3 Verify that the equipment serial numbers match those on the packing slip.

Step 4 Resolve any issues with incorrect serial numbers or missing/incorrect parts before installing the

equipment.

Installation Tasks

The following is an overview of the installation tasks detailed in this section:

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

1-12

OL-8794-05

Step 1 If applicable, remove the doors of the rack.

Step 2 Mark the rack, allowing 14 U (24.50 inches) of vertical space to install the SFS 7024 switch.

Step 3 Install the support rails.

Step 4 Rack mount the switch.

Step 5 If applicable, replace the doors of the rack.

Mounting Kit

The mounting kit hardware contains all of the necessary parts for installing and mounting the SFS 7024 switch into a rack. These kits are intended for use in cabinets with a depth ranging from 28 - 34 inches.

Note If the rack is less than 28”, or more than 34” deep, instead of using the rails, a support shelf able to

support 175 lbs is required.

Mounting Hardware Kit Contents:

• Kit Mounting Rails containing:

–

One pair (left and right) of bottom support rail assemblies

–

One pair of top support rail assemblies

–

One pair of lower rear mounting brackets

–

Four heyclips

• Kit Mounting Hardware 3/8” Square Hole containing:

–

Twenty-four 10/32” x 0.375” pan-head Phillips screws

–

Twenty caged nut adapters for square-holed racks

Mark the Rack

Allow 14U (24.50 inches) of vertical space to install the SFS 7024 switch in the rack.

Step 1 Determine the location on the rack of the bottom of the switch.

Step 2 Mark the upper and lower mounting positions on the vertical rails on the front of the rack.

Step 3 Mark the upper and lower mounting positions on the vertical rails on the back of the rack.

Install the Rails in the Rack

OL-8794-05

Note The front flange (chassis fan side) of the rail has 3 holes. The back flange of the rail (chassis leaf module

side) has two holes, which correspond to the bottom two holes on the front flange.

Step 1 Install the caged nuts into the 2 back holes (chassis leaf module side) and the top and bottom holes

(chassis fan side) in the front of the rack.

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

1-13

Note The 2 front holes should match up with the top and bottom holes of the rail front flange.

All holes should correspond to the rail mounting positions (i.e., the holes marked with pen or tape).

Step 2 Fasten the rail back flange (chassis leaf module side) to the rack by installing two screws into the rail

and rack.

Figure 1 Rail Back Flange

Install 2 screws to

top and bottom holes

Step 3 Fasten the rail front flange (chassis fan side) to the rack by installing one screw into the top hole of each

rail.

Figure 2 Rail Front Flange

Install the second rail on the other side of the rack by repeating steps 1 through 3.

Rack-Mount the Switch

Caution Because of its size and weight, it is recommended that either a lifting device or three (3) people install

the SFS 7024.

To install the switch into the rack, perform the following steps:

Step 1 Clear the area of any unnecessary materials.

Step 2 Attach the clip of the ESD wristband (strap) to bare metal on the cabinet. Put the wristband around one

wrist with the metal button against the skin.

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

1-14

Install 2 screws to

p and bottom holes

OL-8794-05

Step 3 Lift the switch and from the front of the cabinet, slide it onto the rails. The fans and power supplies are

on the front of the chassis; leaf modules are to the rear.

Caution Never lift the switch with the handles on the spine modules, leaf modules, power supplies, and fan trays.

These handles are not designed to support the weight of the SFS 7024.

Step 4 Tighten the screw on the bottom of each side of the chassis into the corresponding bottom hole of the

front flange of each rail.

Figure 3 Secure Chassis to Rail

Install 1 screw into

bottom hole on each rail

Step 5 On each side of the chassis, install a screw and caged nut into the three holes in the chassis sheet metal.

Figure 4 Secure Chassis to Rack

Install 1 screw and

caged nut into each

hole in the chassis

sheet metal

OL-8794-05

Step 6 Attach the top support rails to the chassis rear side as shown in Figure 5:

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

1-15

Figure 5 Top Rail Assembly

Install 1 screw into

each hole in the

chassis sheet metal

Connect the top rail to rack with 1 screw and caged nut

into each hole

Install the

heyclip

here

a. When complete, the top rail assembly should look like Figure 6:

Figure 6 Completed Top Rail Assembly

Step 7 Using two screws, install the lower mounting bracket to the rail assembly and chassis as shown in

Figure 7.

1-16

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

Figure 7 Install the Lower Mounting Bracket and Heyclip

Install the lower rear

mounting bracket to the rail

assembly and chassis

Install the

heyclip here

Step 8 Install the heyclip to the rail assembly.

Step 9 If applicable, reinstall the chassis fascia(s).

Installing the Switch Face Plate

To install the switch face plate(s):

Step 1 On the switch fan side, insert the notches on the top of the fascia into the two slots on the chassis frame.

Snap the bottom of the faceplate in place.

Installing the Spine and Leaf Modules

Note The purchased configuration for the SFS 7024 is shipped fully populated. Follow these steps when it

becomes necessary to install or replace spine modules and leaf modules.

Step 1 Remove the necessary spine modules, spine module blanks, leaf modules, and leaf module blanks. For

detailed instructions, please refer to the section

Note If the user is only adding additional modules, remove only the blank(s) for the slot(s) to be populated.

These will not be replaced.

Removing a Module or Blank, page 1-19.

OL-8794-05

Step 1 When placing the spine modules and leaf modules into chassis slots, the following recommendations

apply:

a. Spine Modules — It is recommended that the spine module(s) be installed into:

–

Lower Hemisphere: Slot 1 for managed. For redundant management, populate slots 1 and 2 with management-capable spines. Use slot 3 for unmanaged.

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

1-17

–

Upper Hemisphere: Slot 5 for managed. For redundant management, populate slots 5 and 6 with management-capable spines. Use slot 4 for unmanaged.

Refer to Figure 1-8 below:

Figure 1-8 SFS 7024 Chassis — Spine Module Slot Numbering

Upper

Hemisphere

PS9PS8PS

Spine 6 (Managed)

Spine 5 (Managed)

Spine 2 (Managed)

Spine 1 (Managed)

Fan

Lower

Hemisphere

PS12PS11PS

Fan

Spine 4 (Unmanaged)

Spine 3 (Unmanaged)

PS6PS5PS4PS3PS2PS

b. Leaf Modules— Leaf modules should be populated beginning with slot 1, then slot 2, then slots 3

through 24 respectively. Refer to

Figure 1-9:

1-18

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

Figure 1-9 SFS 7024 Chassis — Leaf Module Slot Numbering

Leaf 23

Leaf 21

Leaf 19

Leaf 17

Leaf 15

Leaf 13

Leaf 11

Leaf 9

Leaf 7

Leaf 5

Leaf 3

Leaf 1

Step 2 To install a module or filler, hold it so that the ejector handles are on the bottom.

Step 3 Pull the handles out to extend them. Slide the module into the appropriate slot of the chassis until it

makes contact with the backplane. As the module seats in the chassis, the handles will begin to close.

Leaf 24

Leaf 22

Leaf 20

Leaf 18

Leaf 16

Leaf 14

Leaf 12

Leaf 10

Leaf 8

Leaf 6

Leaf 4

Leaf 2

Step 4 Push the handles in to fully close.

Note Be sure that all cards are fully inserted in their respective chassis slots, and that the handles are in the

locked position. This prevents accidental removal, provides proper grounding for the system, and helps to seat the bus connectors in the backplane receptacles.

Removing a Module or Blank

The handles are self-locking. To unlock, push up on the handles to disengage from the lock notch. Then gently pull the handles out and slide the module out of the slot.

Note If removing, but not replacing a module, remember to replace with a module blank. All slots must be

either populated with a module or have blanks for EMI and thermal integrity.

OL-8794-05

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

1-19

Connect Equipment to the Ports and Power On the System

Note Before performing the tasks in this section, take a few minutes to review Figure 1-10 and Figure 1-11

below. It is important to understand the slot numbering for the leaf modules and spine modules (and the corresponding spine RJ-45 ports). It is also important to understand the slot numbering for the fans and power supplies (and the corresponding AC power inlets for the power supplies).

Figure 1-10 SFS 7024 Chassis Front View

Upper

Hemisphere

Lower

Hemisphere

Fan

PS12PS11PS

Spine 6 (Managed)

Spine 5 (Managed)

Spine 4 (Unmanaged)

Spine 3 (Unmanaged)

Spine 2 (Managed)

Spine 1 (Managed)

PS6PS5PS

PS9PS8PS

Fan

PS3PS2PS

Fan

1-20

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

Figure 1-11 SFS 7024 Chassis Back View

RJ-45 for Spine 5 RJ-45 for Spine 6

AC power inlet for power

supplies 7 to 9

Leaf 23

Leaf 21

Leaf 19

Leaf 17

Leaf 15

Leaf 13

Leaf 11

Leaf 9

Leaf 7

Leaf 5

Leaf 3

Leaf 1

AC power inlet for power

supplies 10 to 12

Leaf 24

Leaf 22

Leaf 20

Leaf 18

Leaf 16

Leaf 14

Leaf 12

Leaf 10

Leaf 8

Leaf 6

Leaf 4

Leaf 2

AC power inlet for power

supplies 1 to 3

RJ-45 for Spine 1 RJ-45 for Spine 2

Step 1 Connect a Category 5 or 6 (Cat 5/6) Ethernet cable to one of the RJ-45 connectors on the SFS 7024.

Connect the other end of the Cat 5/6 to the OOB LAN workstation. Refer to connector(s) to use:

Step 2 Connect the switch to IB-enabled hosts using 4X-to-4X IB cables.

Note Make sure all cables latch securely into the corresponding port connectors. If the IB cable connector is

not properly oriented to fit onto the port receptacle (i.e., while attempting to insert the cable in the port), do not twist the connector to achieve the correct orientation. Instead, reach back a few feet on the cable, and twist the bulk cable to allow the connector to rotate to the proper orientation. Doing this prevents all of the rotational forces from acting right at the connector terminations.

Caution It is important to provide strain relief for the IB cable connector.

AC power inlet for power

supplies 4 to 6

Figure 1-11 for which RJ-45

OL-8794-05

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

1-21

Note When handling IB connectors, make certain to remove the connectors by pulling on the center of the

Connecting Power

lanyard only as shown in

Figure 1-12 below. Pulling abruptly on the lanyard, or pulling on only one side

of the lanyard will prevent the latch/unlatch operation from occurring, and could damage or break the lanyard.

Figure 1-12 4X IB Cable Connector

Step 1 Provide strain relief for the power cable(s) by feeding them into the heyclips on the support rails.

Note Be certain that the power cords are firmly seated into the SFS 7024 AC power inlets. Depending upon

the purchased configuration, refer to Figure 1-11 to determine the correct AC power inlet to use.

Step 2 If necessary, replace the faceplates over the switch fans.

Step 3 Connect the power cables to an AC power outlet.

Step 4 When the SFS 7024 switch is plugged into an AC power outlet:

a. The system powers up.

b. The fans start.

c. The system performs a power-on self test (POST).

Step 5 The switch, power supply, and fan LEDs light up.

Bringing Up the System For the First Time

Start-up Procedures

Step 1 Power up the SFS 7024.

Step 2 From its flash image on the CMU spine module, the switch begins its boot process.

1-22

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

Note If the spine module RS-232 port is connected to a terminal emulation program, the user will be able to

view the switch boot process. Be certain to use a null-modem/crossover serial cable for the console port. The settings for the terminal emulation device should be:

–

8 data bits

–

no parity bits

–

1 stop bit

–

57600 baud

–

Use VT100 emulation.

–

Flow control = XON/XOFF

Figure 1-13 SFS 7024 RS-232 Connector

Spine 3 (Unmanaged)

Fan

Spine 2 (Managed)

Spine 1 (Managed)

Fan

PS5PS

Step 3 The system prompts for a user name. In order to change the IP address and default gateway, the user

must be logged in as the administrator. At the prompt enter:

super

Step 4 The system prompts for a password. At the prompt enter:

super

The system responds with:

Welcome to the SFS 7024 CLI. Type 'list' for the list of commands.

Step 5 Verify the IP address with the command line interface (CLI) command showChassisIpAddr

command. The system returns the information similar to the following:

Chassis IP Address: 192.168.100.9 Net mask: 0xffffff00

PS3PS2PS

Changing the IP Address and Default Gateway

There are 3 methods to change the IP address and default gateway of the chassis:

• Using the serial port.

• Logging into the CLI over Ethernet from a system that can reach the chassis using the default IP

address (192.168.100.9).

OL-8794-05

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

1-23

• Use the Chassis Viewer GUI from a system that can reach the chassis using the default IP address

Note One of the following procedures need to be performed on each hemisphere of the 7024.

Using the RS232 Serial Port

Step 1 Connect null-modem/crossover serial cables to the RS-232 port of lower hemisphere spine 1 (upper

hemisphere spine 6). If using a terminal emulation device, the settings should be:

Step 2 Power up the switch.

Step 3 The system prompts for a user name. In order to change the IP address and default gateway, the user

must be logged in as the administrator. At the prompt enter:

Step 4 The system prompts for a password. At the prompt enter:

The system responds with:

Step 5 To change the SFS 7024 default IP address enter:

where -h ipaddress is the new IP address in dotted decimal (i.e., xxx.xxx.xxx.xxx) format, and -m netMask is the new subnet mask in dotted decimal (i.e., xxx.xxx.xxx.xxx) format.

Step 6 To change the SFS 7024 default gateway IP address enter:

where -h ipaddress is the new default gateway IP address in dotted decimal (i.e., xxx.xxx.xxx.xxx) format.

(192.168.100.9).

–

8 data bits

–

no parity bits

–

1 stop bit

–

57.6K baud

–

Use VT100 emulation.

–

Flow control = XON/XOFF

super

Welcome to the SFS 7024 CLI. Type 'list' for the list of commands.

setChassisIpAddr -h ipaddress -m netMask

setDefaultRoute -h ipaddress

Step 7 To to exit the CLI enter:

Using Telnet or SSH

Step 1 Power up the switch.

Step 2 Connect a Category 5 or 6 (Cat 5/6) Ethernet cable to the RJ-45 connector on lower hemisphere spine 1

Step 3 Access the lower hemisphere of the switch with the following command:

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

1-24

logout

or upper hemisphere spine 6. Connect the other end of the Cat 5/6 to an OOB LAN Ethernet hub or Ethernet switch where a work station can access the 7024. A work station can be connected directly to the Ethernet port of spine 1 of the lower hemisphere (spine 6 of the upper hemisphere) if using a crossover Ethernet cable. Power up the switch.

telnet 192.168.100.9

OL-8794-05

Note Access the upper hemisphere with telnet 192.168.100.10

Step 4 The system prompts for a user name. In order to change the IP address and default gateway, the user

must be logged in as the administrator. At the prompt enter:

super

Step 5 The system prompts for a password. At the prompt enter:

super

The system responds with:

Welcome to the SFS 7024 CLI. Type 'list' for the list of commands.

Step 6 To change the SFS 7024 default IP address enter:

setChassisIpAddr -h ipaddress -m netMask

where -h ipaddress is the new IP address in dotted decimal (i.e., xxx.xxx.xxx.xxx) format, and -m netMask is the new subnet mask in dotted decimal (i.e., xxx.xxx.xxx.xxx) format.

Note After changing the IP address the chassis TELNET/SSH session is terminated and must be

reopened using the new IP address.

Step 7 To change the SFS 7024 default gateway IP address enter:

where -h ipaddress is the new default gateway IP address in dotted decimal (i.e., xxx.xxx.xxx.xxx) format.

Step 8 To to exit the CLI enter:

Using the Chassis Viewer GUI

Step 1 Power up the switch.

Step 2 Connect a Category 5 or 6 (Cat 5/6) Ethernet cable to the RJ-45 connector on lower hemisphere spine 1

or upper hemisphere spine 6. Connect the other end of the Cat 5/6 to an OOB LAN Ethernet hub or Ethernet switch where a work station can access the 7024. A work station can also be connected directly to the Ethernet port of spine 1 of the lower hemisphere (spine 6 of the upper hemisphere). Power up the switch.

Step 3 To start Chassis Viewer, open a web browser and enter the default IP of the switch (i.e., 192.168.100.9).

Note The browser must be on a workstation connected to the same Ethernet LAN, and on the same

setDefaultRoute -h ipaddress

logout

TCP/IP subnet as the OOB LAN port of spine 1 (lower hemisphere) or spine 6 (upper hemisphere).

OL-8794-05

Note Chassis Viewer supports the following browsers: Microsoft Internet Explorer 6.0+ (Windows)

and Mozilla FireFox version 1.5.0.4 or later (Linux).

Note If the user is leaving their workstation for a period of time, be sure to close the browser window.

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

1-25

Step 4 If web authentication is enabled, the following screen will be displayed:

Note If web authentication is not enabled, skip to Step 5.

Figure 14 SFS 7024 Web Authentication

Enter the user name super and password super.

Step 5 From the chassis OOB LAN IP submenu, click Set OOB LAN IP. The Set OOB LAN IP is displayed:

Step 6 Click in the OOB IP Address field.

Figure 15 Set OOB LAN IP Window

1-26

Step 7 Enter the new switch IP address.

Step 8 Click in the Net Mask field.

Step 9 Enter the new net mask.

Step 10 Click Apply. The following screen is displayed:

Figure 16 OOB LAN IP Confirmation Window

When the user clicks OK the Chassis Viewer refreshes and uses the new IP address.

Step 11 To change the switch default gateway, from the main menu select OOB LAN IP then Set Default

Gateway IP. The following screen is displayed:

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

Figure 17 Set Default Gateway IP Window

Step 12 Click in the Gateway address field.

Step 13 Enter the new switch default gateway IP address.

Step 14 Click Apply.

Note A reboot is required to activate the new gateway IP address.

Updating Management Spine IP Addresses in a Redundant Management Configuration

Note This procedure should be performed the first time the SFS 7024 is powered on.

Each managed spine must have a unique IP address that is different than the chassis IP address of the SFS 7024. Therefore, a redundantly-managed SFS 7024 will have six (6) unique IP addresses; three (3) for each hemisphere. The current default IP addresses are:

Lower Hemisphere

–

Chassis: 192.168.100.9

–

Spine 1: 192.168.100.11

–

Spine 2: 192.168.100.12

Upper Hemisphere

–

Chassis: 192.168.100.10

–

Spine 5: 192.168.100.13

–

Spine 6: 192.168.100.14

It is necessary for each managed spine to have a unique IP address for the following reasons:

• Unique IP addresses are used when sending syslog messages from a managed spine to a syslog

server.

• Gives the user the ability to ping each management spine separately.

• If the IP addresses are not unique, collisions will occur, causing IP operations to fail.

To update the IP address on managed spine, do the following:

Step 1 Ensure that the spine module is connected to a COM port on a serial terminal device via the RS-232 port.

Step 2 Get to a [boot]: prompt by following Step a or b.

OL-8794-05

a. If the managed spine is running, enter the following command at the console:

reboot

Then press Enter.

b. If the managed spine is not running, power on the switch.

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

1-27

Step 3 After selecting image1 or image2, press the Spacebar to interrupt the auto load sequence before the

counter expires (within 5 seconds).

Step 4 At the [boot]: prompt enter the new spine IP address with the following syntax:

spineip <NEW IP ADDRESS>

Then press Enter.

Step 5 At the [boot]: prompt, enter reboot, and press Enter. Upon reboot the managed spine will display

information similar to the following:

Unified Boot Manager For The T3 Platform. Image Date: Jan 19 2006, 15:03:31 Checking L2 functionality... BCM1125 L2 caches initialized and invalidated CPU0 caches initialized Initialized SMBUS Channels SPD Checksum ok. MEM_SEL = 0x00000007 CPU_REV = 0x00000001_112421FF CPU speed = 400 MHz IO Bridge 0,1 speed = 133, 200 MHz Memory size = 128 MB MC1 Configured for 128M SODIMM, CAS=2, 100 MHz Configured Memory Size = 0x08000000 Channel Interleave Bit = 0 Number of Mem Channels = 1 Testing memory Memory tests pass CPU0 flushing caches L2 flush complete Start type = 0xBFC006A0 Jumping to romStart Initializing HyperTransport bus HyperTransport initialization completed rintf MBOX connect interrupt_source=28 vector=62 sta tus=0 Printf MBOX intEnable status=0 Found Intel Strata Flash 128 MBit (0x8918 ). Mounted raw file system on device /image1. (size=6291456 bytes) Mounted raw file system on device /image2. (size=6291456 bytes) Mounted raw file system on device /dump0. (size=1048576 bytes) Mounted flash file system on device /rfa1 . (size=2097152 bytes)

1-28

Unified Boot Manager [1] image1 [2] image2

CPU: Broadcom BCM1125 VxWorks Version: 5.4

[boot]:

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

Configured Memory Size = 0x08000000 Channel Interleave Bit = 0 Number of Mem Channels = 1 Testing memory Memory tests pass CPU0 flushing caches L2 flush complete Start type = 0xBFC006A0 Jumping to romStart Initializing HyperTransport bus HyperTransport initialization completed rintf MBOX connect interrupt_source=28 vector=62 sta tus=0 Printf MBOX intEnable status=0 Found Intel Strata Flash 128 MBit (0x8918 ). Mounted raw file system on device /image1. (size=6291456 bytes) Mounted raw file system on device /image2. (size=6291456 bytes) Mounted raw file system on device /dump0. (size=1048576 bytes) Mounted flash file system on device /rfa1 . (size=2097152 bytes)

Unified Boot Manager [1] image1 [2] image2

CPU: Broadcom BCM1125 VxWorks Version: 5.4

boot device : icspkg0 processor number : 0 host name : home file name : /image1 inet on ethernet (e) : <NEW IP ADDRESS> inet on backplane (b): host inet (h) : 192.168.100.1 gateway inet (g) : user (u) : ftp ftp password (pw) (blank = use rsh): ftp flags (f) : 0x0 target name (tn) : startup script (s) : other (o) : sbe

Loading package from flash device /image1 ... Boot System = 7024 Boot Image Information: Product = SFS7024 BSP = t3

Version = 4.1.1.1.11

Compressed Image Size = 3616523 bytes md5 = 46086777be1b5ba e45140a440425b915 vxWorks Image Type = loadable Computed md5 = 46086777be1b5bae45140a440425b915 md5 values match! 11088736 Starting at 0x80010000...

sysI REGS BOOT Initializing HyperTransport bus HyperTransport initialization completed Found Intel Strata Flash 128 MBit (0x8918 ). Mounted raw file system on device /image1. (size=6291456 bytes) Mounted raw file system on device /image2. (size=6291456 bytes) Mounted raw file system on device /dump0. (size=1048576 bytes) Mounted flash file system on device /rfa1 . (size=2097152 bytes) Network configuration requested. cliEnabled=1

OL-8794-05

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

1-29

sbe0 speed=100 fullDuplex=0 flowControl=0 sbe1 speed=100 fullDuplex=1 flowControl=0

Note The command spineip changes the IP address for image1 and image2,

SFS 7024 Component LEDs

Chassis Status LED

The chassis status LED (one per hemisphere) is Green when the system is functioning normally.

The chassis status LED is Amber when one of the following conditions exists:

• The system ambient temperature exceeds 52 C but remains less than 60 C.

• Any Fan Alarm is amber.

• Any power supply AC OK LED is off.

• Any power supply DC OK LED is off

• Any spine module Attention LED is on, or it has been determined that a spine is not functioning

(even if it is unable to light the LED).

• Any leaf module Attention LED is on, or it has been determined that a leaf is not functioning (even

if it is unable to light the LED).

The chassis status LED is Red when the system can no longer function properly and indicates one of the following conditions:

• The system ambient temperature exceeded 60 degrees C.

• No functional fan trays are present.

• No functional spines are present.

• No functional leaves are present.

The chassis status LED is off when:

• There are no functional power supplies present.

• There are no management cards in the system

• AC power has been removed from the system.

Subnet Manager Agent (SMA) LED

There is a single SMA LED associated with the system. This LED is Blue if any external InfiniBand links have been established. If no external IB links have been established, the LED if off.

RJ45 LEDs

The SFS 7024 RJ45 connector has two LEDs, Act and 100. The 100 LED is Green when a 100Mbps link is connected. The Act LED is Green when an Ethernet link has been established, and blinking when the link is active.

Fan LEDs

Fan LEDs indicate the following status(es):

1-30

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

Power Supply LEDs

• Green indicates that the fan is functioning properly.

• Amber indicates that the following warning condition exists:

–

A single fan rotation failure at less than 4000 RPM or greater than 10950 RPM.

• Red indicates a possible problem, including:

–

The fan tray is not responding to commands for configuration and temperature-related operations.

–

A fan is not responding to commands for temperature and speed related operations.

–

The fan speed has fallen below the minimum allowed RPM for a fan.

Each SFS 7024 power supply has two LEDs: DC OK and AC OK. Following are the statuses for each.

DC OK

–

Green indicates that DC power is normal.

–

Off indicates a DC power failure or no DC power is present.

AC O K

–

Green indicates that AC power is normal.

–

Off indicates a AC power failure or no AC power is present.

SFS 7024 Leaf and Spine Module LEDs

Leaf Module IB Port LEDs

Each SFS 7024 leaf module port has a Blue IB link status LED that provide the following indications:

• On - the logical link is up (port is in the Active state).

• Off - the physical link is down (port is in the Down state).

Spine and Leaf Module Status LED

The status LED indicates one of the following conditions:

• Steady Green - the module is operating normally.

• Blinking Green - LED test state.

• Off - module is in the removable state.

Spine and Leaf Module Attention LED

The Attention LED indicates one of the following conditions:

OL-8794-05

• Off - the system functioning normally.

• Steady Amber - the system requires some attention, which could indicate one of the following

conditions:

–

The switch temperature is at a warning level on the module.

–

The switch silicon temperature is at a warning level (approximately 90 degrees C).

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

1-31

–

DC voltages on the board are slightly out of tolerance (12V Bulk, 5V, 3.3V, 1.8V, VBIO are all monitored).

–

The module can no longer function properly. The system will take the appropriate actions to ensure that no damage is done to its components.

• Blinking Amber (once every four seconds) - LED test state.

Spine Module Management LEDs

Each SFS 7024 spine module has three management LEDs:

• Capable:

–

Green indicates that the spine slot supports management.

–

Off indicates that the spine slot does not support management.

• Stat:

–

Green indicates that a management board is present.

–

Off indicates that no management board is present.

• Act:

–

Green indicates that management board is in the active mode. In a redundantly-managed

system, this would indicate the master spine.

–

Off indicates that the management board is in the standby mode (if the STAT LED is Green). In a redundantly-managed system, if the Capable LED is also Green, this would indicate the slave spine.

• DDR:

–

Green indicates that the switch is capable of running at DDR speeds.

–

Off indicates that the switch is not capable of running at DDR speeds (i.e., SDR only).

Shutdown Procedures

In order to shutdown the SFS 7024:

Step 1 Power down the switch by removing the power cords from the AC power inlets.

Hot Swapping Components

Hot Swapping Spine and Leaf Modules

Note Following are the general guidelines for hot swapping leaf and spine modules:

Caution Be certain that the managed spine to be hot swapped is a that same firmware level as all other

components in the SFS 7024. A hot swap of a managed spine with another firmware level will cause a disruptive reboot (i.e., I/O traffic is interrupted).

1-32

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

• Hot swap one module at a time, allowing the chassis to completely update it before hot-swapping

the next module. The module update is complete when it becomes visible within the Chassis Viewer GUI. Listed below are the approximate times to fully update each module type:

–

Spines modules: up to 4 minutes

–

Leaf modules: up to 2 minutes

• When a management spine is hot swapped, the rest of the chassis will continue to move packets

without interruption.

• There is no need to reboot the chassis when replacing either a spine or leaf module.

Step 1 Remove the module by pushing up on the handles to disengage from the lock notch. Once the handles

are disengaged, gently pull the handles out and slide the module out of the slot.

Step 2 To install a module, hold it so that the ejector handles are on the bottom.

Step 3 Pull the handles out to extend them. Slide the module into the appropriate slot of the chassis until it

makes contact with the backplane. As the module seats in the chassis, the handles will begin to close.

Step 4 Push the handles in to fully close.

Hot Swapping the Fan Unit

Step 1 Loosen the captive panel screw.

Step 2 Pull the panel screw down to partially disengage the unit.

Step 3 Slowly pull the unit. The unit will disengage from the connector.

Step 4 Carefully slide the fan out until it is completely removed from its slot.

To install a fan unit:

Step 1 Place the unit into the slot. Slowly slide the fan unit in until it engages into the connector.

Step 2 Using the panel screw, push up to re-engage the unit.

Step 3 Tighten the captive panel screw.

Hot Swapping Power Supplies

The SFS 7024 switch requires a minimum of six power supplies for normal operation. Power supplies can be hot swapped without powering down the switch. To replace a power supply:

Step 1 Loosen the captive panel screw.

Step 2 Pull the panel screw down to partially disengage the unit.

OL-8794-05

Step 3 Slowly pull the unit. The unit will disengage from the connector.

Step 4 Carefully slide the power supply out until it is completely removed from its slot.

Step 5 To install a power supply:

Step 6 Place the unit into the slot. Slowly slide the power supply in until it engages into the connector.

Step 7 Using the panel screw, push up to re-engage the unit.

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

1-33

Step 8 Tighten the captive panel screw.

1-34

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

CHAPTER

Operations and Administration

This chapter describes how to administer and configure the Cisco SFS 7024 and its components. It includes the following information:

• Logging, page 2-14

• Maintenance, page 2-19

• SNMP, page 2-22

• Configuration File Administration, page 2-27

• Chassis Traps, page 2-32

• SFS 7024 Port Statistics, page 2-35

• Time Service, page 2-41

• Configuring the Chassis OOB IP Address, page 2-43

Chassis Viewer

The Chassis Viewer is Cisco's browser-based management software. The Chassis Viewer provides the primary management interface for each hemisphere of the SFS 7024 switch (one Chassis Viewer for each hemisphere), allowing the user to perform management, configuration, and monitoring tasks related to InfiniBand networks.

• The Chassis Viewer runs on the Chassis Management Unit (CMU) of the SFS 7024 managed spine

modules.

• The browser must be on a workstation which has connectivity to the RJ-45 OOB LAN port on the

switch.

• Management Workstation Requirements

–

• To access the Chassis Viewer, point a browser to the IP address of the SFS 7024.

• If user authentication is enabled, the following screen is displayed:

Browser Level: Internet Explorer 6.0 (Windows) or Mozilla Firefox 1.5.0.4+ (Linux)

OL-8794-05

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

2-1

Figure 1 SFS 7024 Web Authentication

• Enter the default user name and password:

–

Administrator-level user name: super

–

Administrator-level password: super

–

Operator-level user name: admin

–

Operator-level password: admin

• The Chassis Viewer home page is displayed.

The Chassis Viewer Manages

For each hemisphere (lower or upper):

• The SFS 7024 hemisphere.

• Each SFS 7024 leaf module.

• Each SFS 7024 spine module.

• Logging and monitoring functionality.

2-2

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

Home Page

Figure 2-2 Chassis Viewer Home Page (7024 Lower Hemisphere)

The Chassis Viewer home page provides a high-level overview of a hemisphere of the SFS 7024 switch and individual leaf and spine modules. This area is the starting point to more detailed information for the SFS 7024 chassis and components (fans and power supplies), leaf modules and spine modules. The selected component provides hyperlinks to related menus and information where the user can perform configuration and monitoring tasks.

? (Help) Button

Support Button

Figure 2-3 Help Button

The ? (HELP) button displays online help. Each help screen gives the user a high-level, topic-specific description.

Figure 2-4 Support Button

The Support button displays key contact information for support, displayed in the following window:

OL-8794-05

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

2-3

Figure 2-5 Support Contact Screen

Displaying the Leaf and Spine Module Views

Leaf Module View

To display the leaf module view for the SFS 7024:

Step 1 Mouse over the leaf module to display. The edges of the leaf module are highlighted green as shown in

Figure 2-6 below:

Figure 2-6 Leaf Module Mouseover

Left click the mouse. The leaf module view will be displayed.

2-4

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

Figure 2-7 Leaf Module View

Spine Module View

To display the spine module view for the SFS 7024:

Step 1 Mouse over the spine module to display. The edges of the spine module are highlighted green as shown

Figure 2-8 below:

Figure 2-8 Spine Module Mouseover

Left click the mouse. The spine module view will be displayed.

Figure 2-9 Spine Module View

OL-8794-05

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

2-5

Leaf and Spine Module Component Details Area

The Component Details Area contains three areas.

• Details Header

• Information area.

• Menu

Figure 2-10 Leaf and Spine Component Details Area

Leaf and Spine Details Header

The leaf and spine Details Header allows the user to execute the most common tasks for the SFS 7024 switch:

• Display the applicable hemisphere Home page

• View field-replaceable unit (FRU) information.

• Access online help

Figure 2-11 Leaf and Spine Details Header

Leaf and Spine Information Area

The Leaf and Spine Information Area allows the user to view high-level information for each specific leaf or spine module. The information area contains two different fields:

• The white fields allow the user to add or modify applicable general and system information which

is specific to their environment.

• The gray fields are tied to live data from the selected hardware component as well as live system

information.

Additionally, the Component Information Area has Apply and Refresh buttons, which perform the following functionality:

Apply:

Saves any user edits within the white fields to flash memory.

Refresh:

Refreshes all fields in the information areas.

2-6

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

Displaying the Chassis View

There are two ways to display the chassis view for the SFS 7024:

Step 1 Mouse over the outer region of the leaf module view. The edges of the chassis are highlighted green as

shown in

Figure 2-12 Leaf Module Chassis Mouseover

Figure 2-12 below:

Left click the mouse. The chassis view will be displayed.

Step 2 The second way is to mouse over the outer region of the spine module view. The edges of the chassis are

highlighted green as shown in

Figure 2-13 Spine Module Chassis Mouseover

Figure 2-13 below:

Left click the mouse. The chassis view will be displayed.

OL-8794-05

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

2-7

Figure 2-14 Chassis Viewer Component Details Area

Chassis View Component Details Area

The Component Details Area contains three areas.

• Details Header

• Information area.

• Menu

Chassis Details Header

The Chassis Details Header allows the user to execute the most common tasks for the SFS 7024 switch:

• Display the applicable hemisphere Home page

• View Log

Figure 2-15 Chassis Details Header

Rebooting Components from Chassis Viewer

Step 1 From the Chassis Details header, click Reboot. A screen similar to the following is displayed.

2-8

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

Figure 2-16 Reboot Window

Step 2 Select the radio button of the spine to be rebooted, or select the radio button to reboot the entire

hemisphere.

Step 3 Click Reboot.

Chassis View Component Information Area

Figure 2-17 Component Information Area

The Chassis View Component Information Area allows the user to monitor important information for each specific hardware component, as well as important system information. The information area is comprised of two different fields:

• The white fields allow the user to add or modify applicable general and system information which

is specific to their environment.

• The gray fields are tied to live data from the selected hardware component as well as live system

information.

Additionally, the Component Information Area has Apply and Refresh buttons, which perform the following functionality:

Apply:

Saves any user edits within the white fields to flash memory.

Refresh:

Refreshes all fields in the information areas.

Chassis View Component Information Area Tabs

The tabs along the top of the information area present information about the following components:

• LED and sensor information

• Overall system information

OL-8794-05

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

2-9

LEDs and Sensors Tab

• Switch Field Replaceable Unit (FRU) Information

• Power supply information

• Fan information

• Switch backplane information

The LEDs and Sensors tab displays for the applicable hemisphere:

• Switch component LED information for chassis status, chassis SMA, fan and power supplies.

• Slot-based temperature and AC-power sensor data for the internal switching complex.

Figure 2-18 LEDs and Sensors Tab

System Tab

Note For a detailed explanation of physical LEDs on the hardware components, please refer to the section SFS

7024 Component LEDs, page 1-30.

The System tab displays the overall system information for the applicable hemisphere of the SFS 7024. This information includes the following items:

Out of Band LAN IP

The IP address for the applicable hemisphere of the switch.

Netmask

The current net mask settings for the Chassis.

System Description

A read-only textual description of the system.

IB Node Description

Assigned by the administrator, the IB node description is an IB fabric-applicable name that will be displayed within a subnet manager GUI. Note that changes to this field will be visible to the outside systems only after the chassis is rebooted. To reset this field to the default setting, click the Field Default button.

2-10

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

Note If the IB Node Description field has been changed since the last reboot of either spine, the next

reboot will be treated as disruptive.

System Uptime

The elapsed time since the last time the applicable hemisphere was re-initialized.

System Contact

The textual identification of the contact person and their contact information for this system, assigned by the administrator.

System Name

The name for the system, assigned by an administrator. One convention is to use the system's fully qualified domain name as the System Name.

System Location

The location of the system, assigned by an administrator.

Apply Button

Chassis FRU Tab

Saves any changes made by the user in the System tab to memory.

Refresh Button

Refreshes all fields in the System tab.

The Chassis FRU tab displays switch Field Replaceable Unit (FRU) information. This information includes the following items:

Type

The type of component.

Description

A description of the component, assigned by an administrator.

Alias Name

Name of the component, assigned by an administrator.

Serial Num

Component serial number

Detail

A button for each row that displays additional detail about the component. Additional details include: Part Number, Model, Version, Manufacturer Name, Product Name, Manufacturer Identification, and Manufactured Date.

OL-8794-05

Apply Button

Saves any changes made by the user in the Chassis FRU tab to memory.

Refresh Button

Refreshes all fields in the Chassis FRU tab.

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

2-11

Power Tab

Fan Tab

The Power tab displays switch power supply information. This information includes the following items:

Description

A description of the component, assigned by an administrator.

Status

Displays the status of the component.

Part Num

Displays the part number of the component.

Detail

A button for each row that displays additional detail about the component. Additional details include: Model, Version, Manufacturer Name, Product Name, Manufacturer Id, Manufactured Date

Apply Button

Saves any changes made by the user in the Power tab to memory.

Refresh Button

Refreshes all fields in the Power tab.

The Fan tab displays switch fan information. For descriptions of the fields, see the Power Tab.

Backplane Tab

The Backplane tab displays switch backplane information. For descriptions of the fields, see the Power Tab.

Additionally, the user can modify the Description field, adding information specific to their network environment.

Modifying Switch Component Information

Following is the procedure for modifying the fields for switch components:

Step 1 Select the applicable tab; System, Chassis FRU, Power, Fan, or Backplane.

Step 2 Click on the row to be modified.

Step 3 In the text boxes, enter information which is applicable to the existing network environment.

Step 4 To save, click the Apply button at the bottom of the screen.

2-12

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

Figure 2-19 System Information Area

OL-8794-05

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

2-13

Configuration and Monitoring Features

The following section provides detailed, task-oriented descriptions for configuring and monitoring the SFS 7024 switch and its feature functionality.

Chassis View Menu

Figure 2-20 Chassis View Menu

The Chassis View Menu allows the user to execute all configuration and operation tasks available for the SFS 7024 switch.

Logging

Set Level

The Logging submenu allows the user to set and reset levels for the message log file.

Figure 2-21 Logging Submenu

Figure 2-22 Set Level Button

The Set Level button allows the user to set log level configuration parameters for all software modules on the SFS 7024.

2-14

To set log levels:

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

Step 1 From the menu, select Logging.

Step 2 From Logging, select Set Level. The Log System Configurator (Device Tab) window is displayed:

Figure 2-23 Log System Configurator (Device Tab)

The Device tab presents current log level configuration settings for the following software modules:

–

RAM = The circular log buffer contained in memory. To access the contents of this buffer, use the Chassis Viewer View Log button

–

Syslog = Messages that are sent to a syslog host specified on the Syslog tab.

From this screen, the user can change any of the log level settings for a specific software module by clicking on the Configure hyperlink, which displays a configuration screen:

Figure 2-24 Device Tab: Software Module Configurator

To change any Log Level settings:

Step 1 Click the On-Off checkbox to the right of the setting.

Step 2 Click the Submit button to save any changes.

The following list describes each of the Log Level configuration parameters.

–

DUMP – Dump: Indicates that a problem has caused the system to produce a system dump file. In most circumstances, it is recommended that the user retrieve the dump that was produced. Support engineers may require the information contained in the dump file to diagnose the cause of the problem.

OL-8794-05

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

2-15

–

FATAL – Indicates that a non-recoverable system problem has occurred. The user should reboot the system or component and verify that the subsystem is fully functional to determine whether the fault has been corrected. If the problem persists, the user should contact the supplier.

–

ERROR – Indicates that a serious system error has occurred which might be recoverable. If the system exhibits any instability, the user should reboot the system or component. If errors persist, the user should immediately contact the supplier's technical support.

–

ALARM - Indicates that a serious problem has occurred which degrades capacity or service. If the error is recoverable, the user should correct the failure. If the alarm/failure persists, the user should reboot the system at a convenient time. If the problem is still not cleared, the user should contact the supplier.

–

WA RN I NG - Indicates that a recoverable problem has occurred. The user does not need to take action.

–

PART IAL - When more information is available, Partial causes additional message-related details to be displayed.

–

CONFIGURATION: An informational message indicating changes that a user has made to the system configuration. The user does not need to take any action.

–

INFO: Informational messages that occur during a system or component boot. The user does not need to take any action.

–

PERIODIC: An informational message containing periodic statistics. The user does not need to take action.

Debug message levels 1 through 5: Debug messages are for supplier and/or Cisco engineering use and are not necessarily indicative of actions that an end user may need to take.

Preset Tab

–

DEBUG1 – Messages that describe the states of connections and links.

–

DEBUG2 – Messages that describe major configuration changes or operations.

–

DEBUG3 – Messages that describe the I/O flow.

–

DEBUG4 – Messages that contain the packet dumps within an I/O flow. I/O flows contain multiple packets.

–

DEBUG5 – Messages that contain the packet dumps within an I/O flow. I/O flows contain multiple packets.

Note When configuring the log levels to display debug messages, care should be taken to ensure that system

performance issues are weighed against troubleshooting requirements. Generally, the higher the debug number the more information is written to the log. Specifically, debug levels 3-5 have the most effect on system performance.

The Preset tab allows the user to quickly change log level settings for all software modules on the switch.

2-16

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

Figure 2-25 Log System Configurator: Preset Tab

To change the log level settings:

Step 1 Click the On-Off checkbox to the right of the setting(s).

Step 2 Click the Submit button to save any changes.

Syslog Tab

Figure 2-26 Log System Configurator: Syslog Host Tab

The Syslog tab allows the user to configure logging messages to be sent to a syslog host. If the Host IP address is 0.0.0.0, no syslog host is configured, otherwise log messages are sent to the syslog server at a specified IP address and port.

To setup the syslog host:

Step 1 In the Host IP dialog box, enter the IP address of the syslog host where the log files are to be saved.

Step 2 Click the Apply button to save the IP address.

Configure Syslog on a Linux Server

OL-8794-05

Step 1 Edit the /etc/sysconfig/syslog file and ensure that the -r is included in the

SYSLOGD_OPTIONS. This allows logging from a remote system. For example:

SYSLOGD_OPTIONS="-r -m 0"

Step 2 Type /etc/init.d/syslog restart, and press Enter.

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

2-17

Note To centralize logging for all switches in an IB fabric, the user can configure each switch to point to the

Reset Log Levels

Step 1 From the menu, select Logging.

Step 2 Click Logging.

Step 3 Click Reset Levels. The Reset Levels window is displayed:

same syslog server that has the syslog daemon (syslogd) running. When messages are sent to a syslog server, they will appear in the log as being sent from the IP address of the master spine.

The Reset Levels button resets the logging levels to their factory default values.

Figure 2-27 Reset Levels Button

To reset the logging levels:

Figure 2-28 Reset Log Levels Window

Step 4 To reset the logging levels, click OK.

2-18

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

Maintenance

Note For rebooting information, see Rebooting Components from Chassis Viewer, page 2-8

Figure 2-29 Maintenance Menu

Firmware Update

Step 1 From the menu, select Maintenance.

Step 2 Click Firmware Update. The Firmware Update screen is displayed.

Figure 2-30 Firmware Update Button

The Firmware Update button allows the user to select an alternate firmware file for the SFS 7024. These alternate files are reflected in the drop-down lists in the Firmware Update screen.

To dow nl o a d fi r m w a r e :

Figure 2-31 Firmware Update Screen

OL-8794-05

Step 3 In the Select Target Slot Column, select the hardware component to change its firmware.

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

2-19

Note If there are multiple spine modules, the user can select all applicable slots.

Step 4 From the Image to Overwrite drop-down list, choose a firmware image to overwrite.

Step 5 In the Firmware Update Package: text box, enter the path to the alternate firmware file. If the path is

not known, the user can use the Browse... button to locate it.

Step 6 To have the new image become active after the next reboot, check the box in the Boot? Column.

Step 7 Click the Update Firmware button.

Note Before using the Browse... button, make certain that the browser can connect to the server where the

firmware files reside.

LDAP Configuration

Figure 2-32 LDAP Configuration Button

The lightweight directory access protocol (LDAP) configuration feature allows the user to set and configure authentications for the switch. The LDAP service resides on a server that has access to a user code and password database.

On a SFS 7024 with LDAP enabled, when a user attempts to login to either Chassis Viewer or the CLI, the LDAP client intercepts the login attempt and rather than authenticating internally, encrypts and packages the information in an LDAP packet and sends it to a pre-configured LDAP server over TCP/IP (i.e., the out of band LAN). The LDAP server receives the request, passes it on to the authentication services, and responds to the client with a yes or no, either allowing or denying the user access to the box.

When LDAP is disabled internal authentication becomes the default.

To setup LDAP authentication:

Step 1 From the menu, select Maintenance.

Step 2 Click LDAP Configuration. The LDAP Authentication screen is displayed.

Figure 2-33 LDAP Authentication Screen

Step 3 In the LDAP Server IP Address box, enter the address of the applicable LDAP server.

Step 4 In the LDAP Server Port box, enter the applicable server port number (the default is 389).

2-20

Step 5 When finished, click the Apply button.

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

HTTP/CLI Session Configuration

Figure 2-34 HTTP/CLI Session Configuration Button

The hyper text transfer protocol (HTTP) and command line interface (CLI) session configuration feature allows the user to set HTTP and CLI session timeout parameters, as well as set security requirements for the switch.

The session timeout duration is the length of time that a session remains active if there is no GUI activity. If a session is inactive for a time exceeding the timeout duration, the user will be logged out.

To modify the HTTP and CLI configurations:

Step 1 From the menu, select Maintenance.

Step 2 Click HTTP/CLI Session Config. The HTTP/CLI Session Configuration screen is displayed.

Figure 2-35 HTTP/CLI Session Configuration Screen

Step 3 To modify the session timeout duration (in seconds), click on the existing configuration. The row

changes to orange.

Step 4 In the HTTP Timeout Duration field, enter the new timeout duration (in seconds). The default is 0

seconds (i.e., no timeout).

Note If the user is leaving their workstation for a period of time, be sure to close the browser window.

Step 5 In the CLI Timeout Duration field, enter the new timeout duration (in seconds). The default is 600

seconds.

Step 6 To change the User Authentication parameter, click on the dropdown list. The following is displayed:

Figure 2-36 User Authentication Dropdown List

Step 7 Select the preferred user authentication method. These are:

• LDAP - use an LDAP server. If the user name/password validation fails to complete successfully,

check in the database of the local switch.

• Login Enabled - User Name and Password must be entered, and must match what is in the database

of the local switch.

OL-8794-05

• UserOnly Required - According to the local switch database, a valid user name must be entered. A

password is not required.

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

2-21

• Login Disabled - Does not require username or password.

Step 8 When finished, click the Apply button.

SNMP

The SNMP submenu allows the user to configure and filter SNMP trap information.

Figure 2-37 SNMP Submenu

Target Configuration

The Target Configuration button displays the SNMP Target Configuration Window, allowing the user to view and edit existing SNMP trap destinations.

Figure 2-38 Target MIB Configuration Button

2-22

To display the Target Configuration window:

Step 1 From the menu, select SNMP.

Step 2 Select Target Configuration.

Step 3 The SNMP Target Configuration window is displayed:

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

Figure 2-39 SNMP Target Configuration Window

The top section of the window, SNMP Target Addresses, allows the user to determine what type of SNMP traps are sent, and where they are sent. The rows provide an area for specifying multiple trap destinations. The bottom section of the window, SNMP Target Parameters, allows the user to configure each trap destination with version, optional security information, and filtering mechanisms.

The Apply button applies the current settings to either the SNMP Target Addresses or SNMP Target Parameters section.

Note The Target Configuration window is used for viewing and modifying existing SNMP target

entries. It is not used for creating new target entries.

To create a new target entry, use the following CLI command:

snmpTargetAddr add -n name -a addr [-p port] [-t timeout] [-r retry_count] [-l tag_list] [-v parameters] [-s storage_type]

For example:

To add a trap target with the IP address 192.168.0.123 that accepts SNMP v2c style traps:

snmpTargetAddr add -n traphost1 -a 192.168.0.123 -v "v2 params"

Or, to add the same target except using SNMP v1traps:

snmpTargetAddr add -n traphost1 -a 192.168.0.123 -v "v1 params"

Target Configuration Window Field Descriptions

The following are descriptions for each field in the Target MIB Configuration window:

SNMP Target Addresses:

• Address Name

Specifies a unique, administrator-defined name the system uses to identify a row.

• Transport Domain

Specifies the transport type of the address contained in the snmpTargetAddrTAddress object (e.g.,

1.3.6.1.6.1.1 = udp, 1.3.6.1.4.1.1977.200.1 = tcp).

OL-8794-05

• Transport Address

Specifies the IP address in dotted decimal format.

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

2-23

Note The combination of the Transport Domain and the Transport Address determines the trap destination.

• Port

Specifies the TCP or UDP port that the SNMP trap is sent.

• Timeout

Specifies the time (in milliseconds) that the trap sender waits on a response before re-sending the trap.

• Retry Count

Specifies the number of attempts to be made to send the trap after a timeout condition occurs.

Note Timeout and Retry Count are SNMP v2.c and above. Not applicable for v1 traps.

• Tag List

Specifies which traps should be sent to a particular destination.

Note RFC2233 specifies the link up/down traps. Including RFC2233 in the Tag List specifies that the trap

receiver will get link up/down traps.

• Parameters

Specifies a mapping to an entry in the SNMP Target Parameters table, determining the version of SNMP to use.

• Storage Type

This field determines whether or not the entry is saved for each reboot of the SFS 7024.

–

Nonvolatile means that the value is saved, and remains with each subsequent reboot.

–

Volatile or Other indicates it will not be saved.

• Status

Indicates the current status of the row. The row may be in one of three states:

–

Active

–

Not in service

–

Not Ready

Note A status of not in service indicates that the current row will not be used in the event a trap is generated

by the system. Toggling a trap to not in service, which temporarily suspends trap forwarding, may be useful to keep values intact.

SNMP Target Parameters:

• Parameter Name

Specifies a mapping to an entry in the SNMP Target Parameters table, determining the version of SNMP to use.

• MP Model

2-24

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

The Message Processing Model to be used when generating SNMP messages for entry. Values for this field are 0 for SNMP v1, 1 for SNMP v2 and 3 for SNMP v3.

• Security Model

The Security Model to be used when generating SNMP messages using this entry. Values for this field are 1 for SNMP v1, 2 for SNMP v2, or 3 for SNMP v3.

• Security Name

Security name identifies the entity for whom SNMP messages will be generated.

Note This is equivalent to the community string in an SNMP get.

• Security Level

One of three options:

–

NoAuthNoPriv: No Authentication, no privacy.

–

AuthNoPriv: Authentication, no privacy.

–

AuthPriv: Authentication and privacy

Filter Status

• Storage Type

This field determines whether or not the entry is saved for each reboot of the SFS 7024.

–

Nonvolatile means that the value is saved, and remains with each subsequent reboot.

–

Volatile or Other indicates it will not be saved.

• Status

Indicates the current status of the row. The row may be in one of three states:

–

Active

–

Not in service

–

Not Ready

Note A status of not in service indicates that the current row will not be used in the event a trap is generated

by the system. Toggling a trap to not in service, which temporarily suspends trap forwarding, may be useful to keep values intact.

The SNMP Filter Status screen allows the user to view parameters for rfc2273 (SNMP-NOTIFICATION-MIB).

OL-8794-05

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

2-25

Figure 2-40 Filter Status Button

To view the SNMP filter status:

Step 1 From the menu, select SNMP

Step 2 Click Filter Status. The SNMP Filter Status screen is displayed.

Figure 2-41 Filter Status Screen

Setting Community Strings

The Set Community Stings screen allows the user to set two SNMP community names:

• Read Only Community Name

• Read/Write Community Name

Figure 2-42 Set Community Strings Button

To set the Community Strings:

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

2-26

OL-8794-05

Step 1 Click SNMP

Step 2 Click Set Community Strings. The Set Community Strings screen is displayed.

Figure 2-43 Set Community Strings Window

The first field, "Read Only Comm. Name," is the community string that when specified in an SNMP client, allows read-only access to SNMP fields exported by the SNMP server.

The second field, "Read/Write Comm. Name," is the community string that when specified in an SNMP client, allows read and write access to SNMP fields exported by the SNMP server.

Step 3 In each field, enter a meaningful name (such as public and private shown above), and click Apply.

Configuration File Administration

The Configuration File Administration menu allows the user to perform various administrative tasks related to the configuration files for each line card populating the switch.

Figure 2-44 Configuration File Administration Menu

Administer

The Administer screen allows the user to set backup and restore scenarios for the configuration file of each line card.

OL-8794-05

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

2-27

Figure 2-45 Configuration File Administration - Administer

Step 1 Click the chassis view.

Step 2 Click Config File Admin.

Step 3 Click Administer. The Configuration File Administration screen is displayed:

Figure 2-46 Configuration File Administration Screen

Step 4 Click on the line card to be modified. The row changes to orange.

Step 5 In the Mode column, click the drop-down and select the configuration file administration mode for a line

card.

Figure 2-47 Configuration File Administration - Mode Drop-down

Following is a description of each mode option:

• Disabled

Following an Auto Restore of a configuration file to a line card, the system sets the card mode to Disabled. This allows the user to verify that the configuration file is correct, before returning the card to Auto Backup mode. In the Disabled mode, use the Backup and Restore buttons to either back up or restore a configuration file.

• Auto Backup

All configuration changes to a line card are automatically backed up to the CMU.·

• Auto Restore

The most recent configuration file is restored to a line card inserted into a specific Chassis slot. This is useful as a prerequisite to hot swapping a card.

2-28

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

Step 6 To save, click on Apply.

Note The Clear button deletes the configuration file from the CMU on the switch.

Host Upload/Download

The Host Up/Download screens allows the user to:

• Upload configuration files from a server to the CMU.

• Download saved configuration files from the CMU to a server.

Figure 2-48 Configuration File Administration - Host Up/Download

Step 1 Click the chassis view.

Step 2 Click Config File Admin.

Step 3 Click Host Up/Download. The Configuration File Upload/Download screen is displayed:

Figure 2-49 Configuration File Upload/Download Screen

To upload a configuration file from a server to the CMU:

Step 1 For a selected module, click the Upload button. The following screen is displayed:

Figure 2-50 Upload Screen

OL-8794-05

Step 2 Type the path to the desired server location, or click Browse to locate the correct path.

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

2-29

Step 3 Click Submit.

To download a configuration file from the CMU to a server:

Step 1 For a selected module, click the Download button. The File Download screen is displayed.

Step 2 Click Save.

Step 3 In the Save As window, locate the correct path to the desired server location, and click Save.

2-30

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

Trap Control

Step 1 Click the chassis view.

Step 2 Click Config File Admin.

Step 3 Click Trap Contro l. The Trap Contro l screen is displayed:

The Trap Control screen allows the user to set default trap scenarios related to configuration files.

Figure 2-51 Trap Control

Figure 2-52 Configuration File Trap Control Screen

Step 4 Select or deselect the desired trap(s).

Note To generate an immediate trap, click the applicable Gen Trap button.

Step 5 To save settings, click on Apply.

Note If the checkbox is not checked the Gen Trap button will not generate a trap.

Following are definitions for each configuration file trap:

• CfgSrvBackupFailed

The server was instructed to backup a file for a particular slot, which failed.

• CfgSrvSyncError

OL-8794-05

Synchronization to the slave CMU failed. The problem should be resolved and attempted manually.

• CfgSrvGenError

A general error has occurred.

• CfgSrvFileRestored

The configuration files have been restored to a particular slot.

• CfgSrvFileBackedup

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

2-31

Note The default settings for this screen are as shown above. The user should not change the defaults unless

Chassis Traps

Step 1 Click Chassis.

The configuration files have been successfully backed up for a particular slot.

• CfgSrvModeDisabled

An event has occurred that has caused the slot mode to be set to disabled. The user should resolve the error and reset the mode to the proper value for the affected slot.

instructed by Technical Support.

The Chassis Trap Control screen allows the user to set default trap scenarios related to SFS 7024.

Figure 2-53 Chassis Trap Control

Step 2 Click Chassis Traps

Step 3 Click Trap Control. The Chassis Trap Control screen is displayed.

Figure 2-54 Chassis Trap Control Screen

Step 4 Select or deselect the desired trap(s).

Note To generate an immediate trap, click the applicable Gen Trap button.

Step 5 To save settings, click on Apply.

2-32

Following are definitions for each chassis trap:

Chassis Group

icsChassisTrapSystemSelfTestFailure

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

This trap indicates that the chassis failed one or more of its self-test(s).

icsChassisTrapSystemReboot

This trap indicates that the chassis is in the process of rebooting.

icsChassisTrapSystemMgmtSrvcStarted

This trap indicates that the internal service used to support the management of the chassis is operational.

icsChassisTrapSystemMgmtSrvcAborted

This trap indicates that the internal service used to support the management of the chassis has terminated abnormally.

icsChassisTrapSystemSwitchFailover

This trap indicates that there was a fail over from one switch in the chassis to the other.

Slot Group

icsChassisTrapModuleNotResponding

This trap indicates that a module is not responding to HEARTBEAT poll requests, that are issued by the internal chassis management service.

icsChassisTrapModuleInserted

This trap indicates that a module was inserted into the chassis.

IcsChassisTrapModuleRemoved

This trap indicates that a module was removed from the chassis.

icsChassisTrapModuleFailed

This trap indicates that a module has failed and is not operational.

icsChassisTrapModuleSelfTestFailure

This trap indicates, that the module failed one or more of its self-test.

icsChassisTrapModuleEEPROMReadFailure

This trap indicates, that an error condition was encountered when reading the EEPROM of the module.

icsChassisTrapModuleFPGAReadFailure

This trap indicates, that an error condition was encountered when reading the Field-Programmable Gate Array (FPGA) of the module.

icsChassisTrapModuleBulkPowerFailure

This trap indicates, that the bulk power used by a module has failed within the chassis.

icsChassisTrapModuleReboot

This trap indicates that the chassis is in the process of rebooting.

Power Group

OL-8794-05

icsChassisTrapPowerSupplyNotResponding

This trap indicates that a power supply is not responding to HEARTBEAT poll requests, that are issued by the internal chassis management service.

icsChassisTrapPowerSupplyInserted

This trap indicates that a power supply was inserted into the chassis.

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

2-33

icsChassisTrapPowerSupplyRemoved

This trap indicates that a power supply was removed from the chassis.

icsChassisTrapPowerSupplyFailed

This trap indicates that a power supply has failed and is not operational.

icsChassisTrapPowerSupplyEEPROMReadFailure

This trap indicates, that an error condition was encountered when reading the EEPROM of the power supply.

icsChassisTrapPowerSupplyFanFailed

This trap indicates that a power supply fan has failed and is not operational.

Fan Group

icsChassisTrapFanNotResponding

This trap indicates that a fan is not responding to HEARTBEAT poll requests, that are issued by the internal chassis management service.

icsChassisTrapFanTrayInserted

This trap indicates that a fan was inserted into the chassis.

icsChassisTrapFanTrayRemoved

This trap indicates that a fan was removed from the chassis.

icsChassisTrapFanFailed

This trap indicates that a fan has failed and is not operational.

icsChassisTrapFanTrayEEPROMReadFailure

This trap indicates, that an error condition was encountered when reading the EEPROM of the fan tray.

2-34

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

SFS 7024 Port Statistics

The Chassis View Port Statistics area provides IB port information for all of the external and internal ports of the SFS 7024.

Figure 2-55 IB Port Statistics

To view port statistical information, do the following:

Step 1 From the Chassis View Port Statistics submenu, select IB Port Stats. The IB Port Statistics window is

displayed:

Figure 2-56 IB Port Statistics

Understanding Port Naming Conventions

Following is an explanation of the conventions used in the Port Name column.

Leaf modules/ports:

L = Leaf module number

P = Leaf module port number

Example: L13P01 is leaf module 13 port number 1.

Interswitch Link (ISL) Ports:

S = Spine module number

L = Leaf leaf module number

A = Spine module switch chip A

B = Spine module switch chip B

Example: S4AL24 is the ISL between spine module 4, switch chip A and leaf module 24.

OL-8794-05

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

2-35

Note Spine chips are referenced by the spine number and the switch chip identifier. Each spine module

contains two switch chips (Switch chip A and B).

Port Statistics Field Descriptions

Port Name/Port Number:

Corresponds to external leaf module number/port number, spine module number/port number, and all interswtich links.

Link State:

Indicates whether the InfiniBand link associated with the physical port is up or down. Possible values are no state change, down, init, armed, active, and unknown.

Physical State:

Indicates whether the internal connection to the InfiniBand port is up or down. Possible values are

No State Change, Sleep, Polling, Disabled, Training, Up, and Error Recovery.

Link Down Default:

Indicates the default down state as set by the subnet manager. Possible values are No State Change, Sleep, Polling, and Unknown.

Active Link Width:

Indicates the number of full duplex serial links that are currently being used on a port. The current bandwidth capability of a port is determined by multiplying this value by the Active Link Speed of this port. For instance a 4X DDR link has a bandwidth capability of 20Gb/s.

Note Values of 1X are possible in this field with 4X IB cables if poor cable connections or defective

4X IB cables are used.

Link Width Enabled:

Link Width Enabled is the allowed link width(s) that a port can arbitrate to. Normally, this defaults to the Link Width Supported value, but can be overridden by the subnet manager.

Link Width Supported:

Indicates the link width in terms of multipliers of 2.5 Gbit/sec full duplex serial links supported by the port.

Active Link Speed:

Indicates the speed of the full duplex serial link. This is either 2.5Gbps (single data rate, or SDR), or 5.0Gbps (double data rate, or DDR).

Link Speed enabled:

Link Speed Enabled is the allowed link speed(s) that a port can arbitrate to. Normally this defaults to the Link Speed Supported value, but can be overridden by the subnet manager.

Link Speed supported:

The supported link speed of the port. This could be 2.5Gbps (SDR), 5.0Gbps (DDR) or both.

2-36

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

InfiniBand Statistics:

Transmit 32 Bit Words:

The number of 32-bit data words transmitted by the port, not including flow control and VCRC data.

Receive 32 Bit Words:

The number of 32-bit data words received by the port, not including flow control and VCRC data.

Transmit P a c ke ts :

The number of data packets transmitted by the port, not including flow control packets.

Receive Packets:

The number of data packets received by the port, not including flow control packets.

Symbol Errors:

The number of times a 8B10B encoding violation, or a disparity violation was detected. If multiple errors are detected simultaneously (in more than one lane), the counter only increments by one. The value of the counter is not incremented past 65535. The Performance Manager may reset and/or consolidate the results of this counter.

Link Error Recovery:

Indicates the number of times the link error recovery process happened successfully. The value of the counter does not increment past 255. The Performance Manager may reset and/or consolidate the results of this counter.

Link Downed:

The number of times the link error recovery process failed. The value of the counter does not increment past 65535. The Performance Manager may reset and/or consolidate the results of this counter.

Receive Errors:

Number of errors received on the port.

Remote Physical Error Received:

Indicates bit errors on a link other than the physically attached link.

Transmit Discards:

Number of port transmit discards.

Local Link Integrity Errors:

An error caused by a marginal link. Depending upon the number of code violations, physical switch problems are detected at the physical layer. These errors are based on a count of local physical errors.

Excessive Buffer Overrun:

This error is detected when the OverrunErrors threshold is exceeded by the number of consecutive flow control update periods with at least one overrun error in each period given in the PortInfo attribute.

OL-8794-05

Pkey Violations Inbound:

Indicates the number of times an invalid partition key (PKey) was received. PKeys support an advanced InfiniBand feature for logically partitioning a physical subnet into logical access domains.

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

2-37

Pkey Violations Outbound:

Indicates the number of times an invalid PKey was sent. PKeys support an advanced InfiniBand feature for logically partitioning a physical subnet into logical access domains.

Raw Violations Inbound:

Number of times a raw inbound packet discarded.

Raw Violations Outbound:

Number of times a raw outbound packet was discarded.

Leaf and Spine Module IB Port Statistics

To access IB port statistics for a specific leaf or spine module, perform the following steps.

Leaf Modules

Step 1 Select a leaf module. The leaf module view is displayed.

1. From the Leaf Port Stats menu, select IB Port Stats.

Figure 2-57 Leaf Port Stats Menu

Spine Modules

The leaf port statistics window is displayed:

Figure 2-58 Leaf Port Statistics Window

For information on the each IB port statistic field, refer to the section Port Statistics Field Descriptions,

page 2-36

2-38

Step 1 Select a spine module. The spine module view is displayed.

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

Step 2 From the Spine Port Stats menu, select IB Port Stats.

Figure 2-59 Spine Port Stats Menu

The spine port statistics window is displayed:

Figure 2-60 Spine Port Statistics Window

For information on the each IB port statistic field, refer to the section Port Statistics Field Descriptions,

page 2-36

Set Field Thresholds

The Set Field Thresholds screen allows the user to set, for a specific parameter(s), an error message threshold for cable ports on the SFS 7024.

Figure 2-61 Set Field Thresholds

To change error reporting thresholds, do the following:

Step 1 Click on Port Stats.

Step 2 Click on Set Field Thresholds. The Set Field Thresholds screen is displayed:

OL-8794-05

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

2-39

Figure 2-62 Set Error Reporting Thresholds Screen

Step 3 To change a threshold value for any field:

a. Click in the Threshold field.

b. Enter a new threshold value.

Note For those fields with a “Percent of Max” time unit, the user may enter a number from 0 to

100. For those fields with a “1 Second” time unit, the user may enter a number from 1 to 65,535.

c. Click Apply.

Note Any port which exceeds the configured thresholds will be displayed as red on the home page.

The following are descriptions for each field in the Set Field Thresholds area:

Note The thresholds for the following four fields are set as a percentage of maximum; that is the percentage

of maximum port capacity, which depending upon the IB fabric configuration can be:

- 4X (10 Gbps)

- 1X (2.5 Gbps)

portXmitDataThresh

The threshold for the number of 32-bit data words transmitted by the port.

portRecvDataThresh

The threshold for the number of 32-bit data words received by the port.

portXmitPktsThresh

The threshold for the number of data packets transmitted by the port.

portRecvPktsThresh

The threshold for the number of data packets received by the port.

Note The thresholds for the following fields are set based upon the number of error message which can occur

in one second. The value can be from 1 to 65,535.

2-40

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

portSymbolErrThresh

The threshold for the number of times a 8B10B encoding violation, or a disparity violation was detected on the port.

portLinkErrRecvThresh

The threshold for the number of times the link error recovery process happened successfully on the port.

portLinkDownedThresh

The threshold for the number of times the link error recovery process failed on the port.

portRecvErrThresh

The threshold for the number of errors received on the port.

portRecvRemPhysErrThresh

The threshold for the number of remote physical errors received on the port.

portXmitDiscardThresh

The threshold for the number of transmit discards received on the port.

portPKeyViolInThresh

The threshold for the number of times PKey inbound was invalid on the port.

Time Service

portPKeyViolOutThresh

The threshold for the number of times PKey outbound was invalid on the port.

portRawViolInThresh

The threshold for the number of times a raw inbound packet was discarded by the port.

portRawViolOutThresh

The threshold for the number of times a raw outbound packet was discarded by the port.

portLocalLinkIntegThresh

The threshold for the number of local link integrity errors on the port.

portExcBufferOverrunThresh

The threshold for the number of excessive buffer overrun errors on the port.

The System Time Information screen allows the user to set the system time using either network time protocol (NTP) or manual overrides.

Figure 2-63 Switch Time Service

OL-8794-05

To set the system time:

Step 1 From the menu, click Time Service.

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

2-41

Step 2 Click Set System Time. The System Time Information screen is displayed:

Figure 2-64 System Time Information Screen

To use NTP:

Step 1 Click the Use Network Time Protocol? checkbox.

Step 2 Enter the IP address for the NTP server.

Step 3 To save, click on Apply.

Figure 2-65 Time Service - NTP Setup

To manually set the system time:

Step 1 Make sure the Use Network Time Protocol? checkbox is unchecked.

Step 2 Set the current date and time using the drop-downs for Month, Day, and Ye ar as well as Hour, Minute,

Seconds, and AM/PM.

2-42

Step 3 To save, click on Apply.

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

Figure 2-66 Time Service - Manual Setup

To set time zone and daylight saving time (DST) settings:

Step 1 In the Time Zone drop-down, select the correct time zone based upon Greenwich Mean Time (GMT).

Step 2 Using the Which, Day, in Month drop-downs, set the start and end dates for daylight saving time.

Step 3 To save, click on Apply.

Figure 2-67 Time Service - Time Zone/Daylight Saving Time Setup

Time Zone Tips:

In the U.S. the following time zones are in effect:

–

Eastern Standard Time = GMT –5

–

Central Standard Time = GMT –6

–

Mountain Standard Time = GMT –7

–

Pacific Standard Time = GMT -8

Daylight Saving Time Tips:

For most of the United States, Daylight Saving Time in the United States begins at 2 a.m. on the second Sunday of March, and ends at 2 a.m. on the first Sunday in November.

Additionally, for those US regions that do not observe DST, the start and end dates in the Which, Day, in Month settings, should be set to the exact same date.

Configuring the Chassis OOB IP Address

To configure the chassis IP address:

Step 1 From the OOB LAN IP submenu, click Set OOB LAN IP.

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

2-43

Figure 2-68 Set Switch OOB IP Address Button

Step 2 Click in the OOB IP Address field.

Figure 2-69 Set OOB LAN IP Window

Step 3 Enter the correct switch IP address.

Step 4 Enter the correct net mask.

Step 5 Click Apply. The following screen is displayed:

Figure 70 OOB LAN IP Confirmation Window

When the user clicks OK the Chassis Viewer refreshes and uses the new IP address.

Configuring the Switch Default Gateway IP Address

The Set Default Gateway IP address Window allows the user to configure the IP address for the default gateway to route packets from the OOB management port to an external network.

To configure the Switch default gateway IP address:

Step 1 From the OOB LAN IP submenu, click Set Default Gateway IP.

Figure 2-71 Set Switch Default Gateway IP Address Button

Step 2 Click in the Gateway Address field.

2-44

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

Figure 2-72 Set Default Gateway IP Window

Step 3 Type in the correct switch default gateway IP address.

Step 4 Click Apply.

Note A reboot is required to activate the new gateway IP address.

OL-8794-05

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

2-45

Spine View Menu

Figure 2-73 Spine View Menu

Note For information on IB port statistics refer to the section SFS 7024 Port Statistics, page 2-35.

Logging

Viewing the Log

The Logging submenu allows the user to view, set levels, reset levels, and purge the message log file.

Figure 2-74 Logging Submenu

The View Log button allows the user to view the message log.

Figure 2-75 View Log Button

To view the message log:

2-46

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

Step 1 From the menu, select Logging.

Step 2 Click View Log. The log message window is displayed:

Figure 2-76 Sample Message Log

To save a log message for further analysis, perform the following steps:

Step 1 From the Messages window, select Edit, Select All (or CTRL + A).

Step 2 Select Edit, Copy (or CTRL + C).

Step 3 Open a text editing package, such as Notepad.

Step 4 Select Edit, Paste (or CTRL + V).

Step 5 Save as a plain text (.txt) file.

Purging the Log

Step 1 From the menu, click Logging.

Step 2 Click Purge Log. The Purge Log confirmation window is displayed:

The Purge Log button purges the RAM, clearing the log file(s).

Figure 2-77 Purge Log Button

To purge the log:

OL-8794-05

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

2-47

Step 3 Click OK.

Step 4 The message log file is now purged.

Maintenance

Select Boot Image

Figure 2-78 Purge Log Confirmation Window

The Select Boot Image button allows the user to choose an alternative boot image for the SFS 7024. To select a boot image:

Figure 2-79 Select Boot Image Button

Step 1 From the menu, select Maintenance.

Step 2 Click Select Boot Image. The Boot Image Selection screen is displayed:

Figure 2-80 Boot Image Selection Screen

To choose a new boot image:

Step 1 Click on the radio button of the new boot image.

Step 2 Click Apply.

2-48

Note The image preceded with => is the image that is currently running.

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

License Keys; Key Administration

The License Key submenu allows the user to activate and deactivate feature functionality that is sold as an add-on to the SFS 7024.

Adding a New License Key

Step 1 Click License Keys. The Key Administration button is displayed:

Figure 2-81 License Key Submenu

Step 2 Click Key Administration. The Key Management window is displayed:

Figure 2-82 Key Management Window

Step 3 To add a new license key, click the Add Key button. The License Key Management Information

window is displayed:

Figure 2-83 License Key Management Information Window

Step 4 Enter the license key information in the New Key text box, and click Apply.

Note The license key number should be part of the paperwork shipped with the product. If the feature

functionality is purchased at a later date, the license key number will be provided via e-mail.

Deleting a License Key

Step 1 Click on the License Keys submenu.

Figure 2-84 License Key Submenu

OL-8794-05

Step 2 Click on Key Administration. The Key Management window is displayed.

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

2-49

Step 3 To delete a license key, click the Delete button. The system prompts with the following:

Figure 2-85 License Key Delete Prompt

Step 4 Click OK to delete.

2-50

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

Technical Specifications

Ta b l e A- 1 SFS 7024 Technical Specifications

APPENDIX

Switch Physical Dimensions

Weight • 175 lb. (80 kg.) (including power supplies)

Cooling • Air cooled with 8 hot plug fan trays

Environmental • Operating temperature: 50° - 104°F (5° - 40°C) at sea

• 14U high (24.5”)

• 19" rack mount (17.32" wide)

• 25 3/4" deep (without cables)

• Hot plug with two axial, brushless, 12V fans per Fan Tray

• Chassis: Front-to-back airflow

• Power Supply: Power supplies intake air from a pressurized chamber inside a chassis and exhaust to the front of a chassis.

• Temperatures of all major heat producing components are continuously monitored by system management modules. Fan speed is monitored and automatically adjusted by system management modules to maintain appropriate temperatures of major heat producing components. Monitoring is performed via a two wire I2C interface to each Fan Tray.

level, altitude derating 2°F (1°C) per 300m to 2,000m

• Non-operating temperature: -35°C to 65°C

• Relative humidity (non-condensing): operating 5% – 85%; non-operating 5% – 90%

• Self-contained thermal management

OL-8794-05

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

A-1

Table A-1 SFS 7024 Technical Specifications

Power Supply • Up to twelve redundant, hot plug supplies

• 90/264 VAC operation

• 350W max power per supply

• Input:

• 90–264 VAC, 50-60Hz, 1 Phase, 4.0A max current at 115VAC

• Inrush Current:

• 15A @ 115VAC (25°C cold start) 30A @ 230VAC (25°C cold start)

• Power Factor 0.95

• Two IEC320-C14 connectors for independent AC inputs

Certification Marks • UL, CSA, CE, VCCI, GS, FCC Class B, IC Class B,

ICES - 003

A-2

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

Overview

APPENDIX

Command Line Interface

This appendix includes the following information:

• Commands and Functional Groups, page B-2

• Accessing the CLI, page B-3

• Groups and Commands, page B-4

This section details the usage of the Command Line Interface (CLI) feature for the Cisco SFS 7024. The CLI allows the user to perform remote configuration and management tasks, which in many respects mirrors the functionality of the Chassis Viewer GUI.

The CLI is accessed via a terminal attached to the SFS 7024 spine module(s) RS232 port(s) or via the OOB management port using Telnet and secure shell (SSH). For a standalone SFS 7024, the user would Telnet to the unit's IP address(es). Once connected, the CLI works as any telnet session does.

To access the CLI, a login and password is required. There are two user modes, operator and administrator with the following access privileges:

Operator:

–

Read only access.

Administrator:

–

Read and write Access.

–

Reboot access.

–

Can change operator and administrator passwords.

–

Can disable user login and passwords. This would allow all users administrator-level access without the need for a user name or password.

–

Can view all current user sessions

–

Can access all of the commands executed from any open operator session.

–

Can log out any open user sessions

Can send messages to the open user sessions

The CLI allows multiple users to be logged in simultaneously. However, some commands will be locked to a user(s) if another user is executing the same command.

OL-8794-05

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

B-1

The CLI is also accessible through the RS232 serial port of the SFS 7024. Providing access through the serial port means that users will always have access to the SFS 7024, even if Telnet and SSH are not functioning.

Commands and Functional Groups

The list of available commands can be accessed by typing list. To keep the list short, the commands are grouped into functional groups, which are:

General:

General administrative commands

Deprecated:

Commands that have been deprecated.

Note The Deprecated group contains CLI commands that been replaced or are to be removed. Please

use the new command where appropriate.

Chassis:

Provides commands for configuring and managing chassis-level functionality. This includes commands for changing the SFS 7024 IP address, and displaying fan tray, power supply, and FRU information.

Network:

General network commands.

Firmware:

Provides commands for updating the firmware via a File Transfer Protocol (FTP) server or Secure Copy Protocol (SCP) (if using SSH to access the SFS 7024). The SFS 7024 has the ability to store the location of the firmware files for future upgrades. Additionally, the Firmware functional group includes commands for viewing the current firmware revisions and for changing the boot image.

SubnetManagement:

InfiniBand subnet manager configuration and management.

Log:

Provides commands for viewing log files as well as configuring logging parameters. This includes commands for changing the SFS 7024 IP address, and displaying fan tray, power supply, and FRU information.

KeyManagement:

Provides commands for adding, removing and displaying license keys on the SFS 7024.

IbSwitchInfo:

Provides commands for displaying InfiniBand (IB) statistics for all IB ports on the SFS 7024.

TimeManagement:

Provides commands for retrieving and setting the current system time, as well as commands for setting the time zone and daylight saving time parameters.

Snmp:

B-2

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

Online Help

Provides commands for configuring SNMP trap destinations and security parameters required to access the SFS 7024 from an SNMP manager.

Capture:

Provides commands for capturing switch-specific information for the purposes of analysis and debugging.

To list commands within a functional group, simply type in the functional group name. For example, to list all of the firmware commands, type Firmware. The system would display the following:

-> Firmware fwUpdateSlot Update units firmware fwUpdateChassis Update units firmware fwListFiles List the contents of the firmware ramdisk fwShowUpdateParams Display firmware default update parameters fwSetUpdateParams Configure firmware default update parameters showCapability Display the capabilities/features fwVersion Display Firmware revisions bootQuery Query boot image information bootSelect Change boot selection

The online help for the CLI provides, for each command, all necessary information to successfully execute the command. For example, typing help fwShowUpdateParams displays the following information:

NAME fwShowUpdateParams SYNOPSIS fwShowUpdateParams DESCRIPTION Display the default update firmware settings. OPTIONS None.

Keyboard Shortcuts

• The CLI keeps a history of recently executed commands. This history is available via the Up and

Down arrow keys.

• Users may edit the current command with the Left and Right arrow keys.

• Tab completion: pressing the Ta b key after typing at least one character either completes a command

or lists all the available commands that begin with the characters already typed.

Accessing the CLI

OL-8794-05

Note The CLI can be accessed via Telnet, SSH, or through the SFS 7024 RS232 serial port. The following

instructions use Telnet.

Step 1 Telnet to the IP address of the SFS 7024 (the default IP address is 192.168.100.9) with the following

command:

telnet <IP ADDRESS>

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

B-3

Step 2 The system prompts for a username. The CLI has the following default user names:

–

Operator access: admin

–

Administrator access: super

Type the appropriate username and press Enter.

Step 3 The system prompts for a password. The CLI has the following default passwords:

–

Operator access: admin

–

Administrator access: super

Type the appropriate password and press Enter. The system responds with:

Welcome to the SFS 7024 CLI. Type 'list' for the list of commands.

Groups and Commands

The following section lists the CLI’s functional groups along with the commands for each group. For more specific information for each functional group, the user would execute the help <GROUP NAME> command. For more specific command information, the user would execute the help <COMMAND NAME> command.

General

help

Displays help information for a specific command.

Syntax:

help [command]

Options:

[command]

The command to display help for.

Sample Output:

-> help list

NAME list

SYNOPSIS list [group] [-noprompt]

DESCRIPTION List available commands.

OPTIONS group - List the commands in that particular group

-noprompt - Just list the command groups.

B-4

Cisco SFS 7024 InfiniBand Server Switch Hardware Users Guide

OL-8794-05

Cisco SFS 7024 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

New and Changed Information

Preface

Audience

Organization

Conventions

Related Documentation

Obtaining Documentation, Obtaining Support, and Security Guidelines

Installation

Planning the Installation

Rack Specifications and Recommendations

Cable Requirements

Uninterruptible Power Supply

Installation Tasks Checklist

Safety Information

Tools, Equipment and Personnel Required

Check the Installation Site

Unpack the Equipment

Installation Tasks

Mounting Kit

Mark the Rack

Install the Rails in the Rack

Rack-Mount the Switch

Installing the Switch Face Plate

Installing the Spine and Leaf Modules

Removing a Module or Blank

Connect Equipment to the Ports and Power On the System

Bringing Up the System For the First Time

Changing the IP Address and Default Gateway

Updating Management Spine IP Addresses in a Redundant Management Configuration

SFS 7024 Component LEDs

SFS 7024 Leaf and Spine Module LEDs

Shutdown Procedures

Hot Swapping Components

Hot Swapping Spine and Leaf Modules

Hot Swapping the Fan Unit

Hot Swapping Power Supplies

Operations and Administration

Chassis Viewer

The Chassis Viewer Manages

Home Page

? (Help) Button

Support Button

Displaying the Leaf and Spine Module Views

Leaf Module View

Spine Module View

Leaf and Spine Module Component Details Area

Leaf and Spine Details Header

Leaf and Spine Information Area

Displaying the Chassis View

Chassis View Component Details Area

Chassis Details Header

Rebooting Components from Chassis Viewer

Chassis View Component Information Area

Chassis View Component Information Area Tabs

Modifying Switch Component Information

Configuration and Monitoring Features

Chassis View Menu

Logging

Set Level

Reset Log Levels

Maintenance

Firmware Update

LDAP Configuration

HTTP/CLI Session Configuration

SNMP

Target Configuration

Filter Status

Setting Community Strings

Configuration File Administration

Administer

Host Upload/Download

Trap Control

Chassis Traps

SFS 7024 Port Statistics

Port Statistics Field Descriptions

Leaf and Spine Module IB Port Statistics
