Data Sheet
Cisco Unified IP Conference Phone 8831
Product Overview
The Cisco® Unified IP Conference Phone 8831 enhances people-centric communications, combining superior
high-definition (HD) audio performance and 360-degree coverage for all sizes of conference rooms and executive
offices. It provides an audiophile sound experience with a full-duplex two-way wideband (G.722) audio hands-free
speaker.
The IP Conference Phone 8831 is a simple, scalable solution that meets the challenges of the most diverse rooms.
It provides flexible deployment options and expansion by using extension microphones that can be wired or
wireless (Digital Equipment Cordless Telephone [DECT]) with a daisy-chain configuration of two units.
The IP Conference Phone 8831 has an industrial design with enhanced ergonomics that puts the user first. It offers
a detached control panel so that the display may be easily viewed without having to move the entire unit. It also
provides easy view of device mute status from all sides.
Supported on Cisco Unified Communications Manager and Business Edition systems, the IP Conference Phone
8831 delivers a more productive, acoustically pleasing, and secure communications experience across sites and
participants.
Features and Benefits
The Cisco Unified IP Conference Phone 8831 offers many improvements over the existing Cisco Unified IP
Conference Station 7937G. New features include:
●
Superior wideband acoustics with the first two-element speaker in a conference phone; this feature allows
the phone to capture the full voice spectrum without having to compromise with a single-element speaker
●
Expanded room coverage with support for daisy chaining two units
●
Support for DECT wireless extension microphones
●
Session Initiation Protocol (SIP) signaling
●
Device authentication and signaling encryption using Transport Layer Security (TLS) with Advanced
Encryption Standard 128 (AES-128)
●
Media encryption using Secure Real-Time Transport Protocol (SRTP) with AES-128
© 2014 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 2 of 7
Feature
Specification
Features
Superior wideband acoustics
●
160 Hz to 20 kHz, +/-3 dB.
●
The latest in wideband codecs for maximum voice bandwidth.
●
Enhanced speech quality and speaker recognition.
Output
92-dB SPL peak output*
Expanded room coverage
●
160-degrees conical pattern provides even coverage of listening area.
●
Four Hemi-Cardioid microphones are perfectly spaced so that they combine to provide a 180-degree
pick-up pattern around the device. Speech is captured at the same level at all points around the Cisco
Unified IP Conference Phone 8831.
Wired microphones
These microphones extend the operational range of the Cisco Unified IP Conference Phone 8831 with even
coverage around the periphery of the device with 7 feet of additional reach.
Wireless microphones
DECT wireless microphones for the Cisco Unified IP Conference Phone 8831 provide additional coverage
with the added flexibility of 300 feet of range.
Wired control panel
The panel allows easy control of the unit and viewing of the display without having to move the entire unit.
Power Features
IEEE 802.3af line power
Local power supply is not required.
Cisco Power Cube 3
This power cube uses a standard Cisco Unified IP Phone Power Supply for non-Power over Ethernet (PoE)
deployments. It is required for daisy chaining two units together.
Call-Control Support
Cisco Unified Communications
Manager
The phone supports Cisco Unified Communications Manager (Cisco UCM) Releases 7.1(5), 8.5(1), 8.6(2),
9.0, and later.
Cisco Business Edition 3000
The phone is supported on the Cisco Business Edition 3000 Releases 8.6(1) and later.
Cisco Business Edition 6000
The phone is supported on the Cisco Business Edition 6000 Releases 8.6(5) and later.
Cisco Unified Communications
Manager Express
The phone is supported with CME 10.0 and above. On IOS 15.4(1)T and later with Fast Track Support.
Feature
Specification
Signaling protocol support
Session Initiation Protocol (SIP)
Codec support
G.711, G.729(a and ab), G.722, and Internet Low Bitrate Codec (iLBC)
Calling feature support
●
+ Dialing (E.164)
●
Adjustable ringing and volume levels
●
Adjustable display brightness
●
Application launch pad
●
Auto-answer
●
Auto-detection of headset
●
Barge
●
Call forward
Table 1 lists the features and benefits of the Cisco Unified IP Conference Phone 8831.
Table 1. Features and Benefits
*
Peak output measured in half-space environment.
Licensing
The Cisco Unified IP Conference Phone 8831 requires an Enhanced User Connect License (UCL) on Cisco UCM
Versions 9.0 and later. For supported Cisco UCM versions before 9.0, a public space license is required.
Product Specifications
Table 2 lists the features and specifications of the Cisco Unified IP Conference Phone 8831.
Table 2. Features and Specifications of Cisco Unified IP Conference Phone 8831
© 2014 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 3 of 7
Feature
Specification
●
Call history lists
●
Call timer
●
Call waiting
●
Caller ID
●
Corporate directory
●
Conference
●
Direct transfer
●
Fast-dial service
●
Hold
●
Immediate divert
●
Join
●
Message-waiting indicator
●
Music on hold
●
Mute
●
Network profiles (automatic)
●
On- and off-network distinctive ringing
●
Personal directory
●
Predialing before sending
●
Privacy
●
Ring tone per line appearance
●
Shared line
●
Survivable Remote Site Telephony (SRST)
●
Time and date display
●
Transfer
●
Voicemail
Directories
The Cisco Unified IP Conference Phone 8831 identifies incoming messages and categorizes them for users
on the screen. This feature allows you to quickly and effectively return calls using direct dial-back capability.
The corporate directory integrates with the Lightweight Directory Access Protocol Version 3 (LDAPv3)
standard directory.
Settings
The Settings feature key allows you to adjust display contrast, select background images (if available), and
select from a large number of unique ringer sounds through the User Preference menu. Network
configuration preferences also can be set up (usually by the system administrator). Configuration can be
either automatically or manually set up for Dynamic Host Control Protocol (DHCP), Trivial File Transfer
Protocol (TFTP), Cisco Unified Communications Manager, and backup Cisco Unified Communications
Manager instances.
Help
The online Help feature gives you information about the phone keys, buttons, and features. The pixel display
allows for more flexible feature navigation and significantly expands the information viewed when using
features such as Services, Information, Messages, and Directory. For example, the Directory button can
show local and server-based directory information.
Hold, Mute, and Redial keys
The Mute key is a fixed key. When it is active, the LED flashes on the Cisco Unified IP Conference Phone
8831 as well as on the optional wired and wireless microphone kits. Hold and Redial are provided as soft
keys associated with the screen, and are always at the same position for easy access.
Display
The conference station has a large high-resolution, graphical 3.5-inch backlit display (396 x 162 pixels).
Speakerphone
The Cisco Unified IP Conference Phone 8831 offers full-duplex high-quality wideband speakerphone
technology. Included are Automatic Gain Control, comfort-noise generation, silence suppression and voice
activity detection, Echo Suppression, and dynamic noise reduction, which reduces noise by up to 9 dB from
constant noise sources such as fans or heating, ventilation, and air conditioning (HVAC) systems.
A two-way high-fidelity loud speaker system provides superior speech clarity versus traditional conferencing
systems.
Volume control
The convenient Volume Control buttons on Cisco Unified IP Conference Phone 8831 provide for easy,
decibel-level adjustments for the speakerphone and ringer.
Quality-of-service (QoS) options
The Cisco Unified IP Conference Phone supports DHCP and 802.1Q/p standards. The conference station
can also be configured with an 801.1Q VLAN header containing the VLAN ID overrides configured by the
Admin VLAN ID.
Multiple ring tones
User-adjustable ring tones are available.
Security
The Cisco Unified IP Conference Phone 8831 supports device authentication through 802.1.x supplicant
(TLS) and SRTP.
© 2014 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 4 of 7
Feature
Specification
Language support
Arabic (Arabic Area)
Bulgarian (Bulgaria)
Catalan (Spain)
Chinese (China)
Chinese (Hong Kong)
Chinese (Taiwan)
Croatian (Croatia)
Czech (Czech Republic)
Danish (Denmark)
Dutch (Netherlands)
English (United Kingdom)
Estonian (Estonia)
French (France)
Finnish (Finland)
German (Germany)
Greek (Greece)
Hebrew (Israel)
Hungarian (Hungary)
Italian (Italy)
Japanese (Japan)
Latvian (Latvia)
Lithuanian (Lithuania)
Korean (Korea Republic)
Norwegian (Norway)
Polish (Poland)
Portuguese (Portugal)
Portuguese (Brazil)
Romanian (Romania)
Russian (Russian Federation)
Spanish (Columbia)
Spanish (Spain)
Slovak (Slovakia)
Swedish (Sweden)
Serbian (Republic of Serbia)
Serbian (Republic of Montenegro)
Slovenian (Slovenia)
Thai (Thailand)
Turkish (Turkey)
Configuration options
You can configure IP address assignment statically or through the DHCP client.
Category
Specification
Dimensions (H x W x D)
Base: 10.38 x 10.38 x 2.0 in. (15.05 x 26.35 x 5.08 cm)
Control panel: 5.75 x 5.0 x 1.0 in. (14.61 x 12.7 x 2.54 cm)
Microphones: 3.5 x 2.5 x 0.5 in. (8.89 x 6.35 x 1.27 cm)
Charger tray: 6.5 x 4.5 x 0.75 in. (16.51 x 11.43 x 1.90 cm)
Specifications
Table 3 gives specifications of the Cisco Unified IP Conference Phone 8831, Table 4 provides temperature ratings,
and Table 5 lists certifications for the conference station.
Table 3. System Specifications
© 2014 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 5 of 7
Category
Specification
Weight
Base 3.50 lbs. (1,587.0 grams)
DCU 0.56 lbs. (253.0 grams)
Wired Microphones 0.15 lbs. (66.8 grams)
Wireless Microphones 0.14 lbs. (64.7 grams)
Charger 0.42 lbs. (191.9 grams)
Display
3.25 x 1.5 in. (8.26 x 3.81 cm); 396 x 162 pixels
Phone casing composition
Polycarbonate acrylonitrile butadiene styrene (ABS) textured plastic
Power requirements
The Cisco Unified IP Conference Phone 8831 is an interoperable IEEE 802.3af PoE (Class 3 device);
48 VDC is required; it can be supplied locally at the desktop using an optional AC-to-DC power supply
(CP-PWR-CUBE-3=). Use of the power supply also requires the use of one of the corresponding AC country
cords listed in Table 7 later in this document.
Use of a power supply (CP-PWR-CUBE-3=) is required when using the Cisco Unified IP Conference Phone
8831 in a daisy-chain configuration.
Category
Range
Operational temperature
23~104°F (-5°C~40°C)
Nonoperational temperature
shock
-13~158 (-25~70°C)
Temperature altitude
(operational)
77°F (25°C) ambient condition to 9843 ft (3000m)
Temperature altitude
(nonoperational)
Ambient condition to 15,000 ft (4572m)
Temperature humidity
(nonoperational)
95% relative humidity
Specification
Description
Regulatory compliance
Products should comply with CE Marking per directives 2004/108/EC and 2006/95/EC
Safety
UL 60950-1 Second Edition Amd 1
CAN/CSA-C22.2 No. 60950-1 Second Edition Amd 1
EN 60950-1 Second Edition A11, A1, A12
IEC 60950-1 Second Edition Amd 1
AS/NZS 60950-1: 2011
GB4943 2011
EMC: Emissions
FCC Part 15 Subpart B Class B
AS/NZS 3548 CISPR22 Class B
EN55022 Class B
ICES-003 Class B
VCCI Class B
KN22 Class B
CNS13438 Class B
EMC: Immunity
EN55024
CISPR24
EN300386
KN24
Table 4. Temperature
Note that products with the CE marking in Table 5 indicate compliance with the 2006/95/EC and 2004/108/EC
directives, which include the safety and EMC standards listed.
Table 5. Regulatory Standards Compliance: Safety and EMC
© 2014 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 6 of 7
Specification
Description
EMC: Radio DECT
FCC Part 15 Subpart D
IC RSS-213
EN 301 406
Telecom
AUS AS/ACIF S004 - Hands-free Send Frequency Response
Product Name
Part Number
CP-8831-K9=
Cisco Unified IP Conference Phone 8831 base unit and control panel
CP-8831-J-K9=
Cisco Unified IP Conference Phone 8831 base unit and control panel - Japan DECT Frequency
CP-8831-DC-K9=
*
Optional Daisy Chain Kit extension for the Cisco Unified IP Conference Phone 8831.
●
Cisco Unified IP Conference Phone 8831 Base Unit
●
Daisy Chain Cable (25ft)
CP-8831-DC-K9=
*
Optional Daisy Chain Kit extension for the Cisco Unified IP Conference Phone 8831 - Japan DECT
Frequency.
●
Cisco Unified IP Conference Phone 8831 Base Unit
●
Daisy Chain Cable (25ft)
CP-8831-3PCC-K9=
Cisco Unified IP Conference Phone 8831 base unit and control panel for 3rd party sip based call control
CP-8831-MIC-WRLS=
*
Optional Wireless Microphone Kit for Cisco Unified IP Conference Phone 8831
●
2 DECT Wireless Microphones
●
Charging Station for Microphones
●
Power Supply
CP-MIC-WIRED-S=
*
Optional Wired Microphone Kit for Cisco Unified IP Conference Phone 8831
●
2 Wired microphones
CP-8831-DC-CBL=
*
Optional Daisy Chain Cable for the Cisco Unified IP Conference Phone 8831. For Daisy Chaining 2 Cisco
Unified IP Conference Phone 8831’s together (25ft)
*
Not required if purchasing the Daisy Chain Kit (CP-8831-DC-S-K9)
CP-PWR-CUBE-3
Cisco Power Cube 3
CP-PWR-CUBE-3
Cisco Power Cube 3
Product Name
Part Number
CP-PWR-CORD-AP=
Asia Pacific
CP-PWR-CORD-AR=
Argentina
CP-PWR-CORD-AU=
Australia
CP-PWR-CORD-CE=
European community
CP-PWR-CORD-CN=
China
CP-PWR-CORD-JP=
Japan
CP-PWR-CORD-NA=
North America
CP-PWR-CORD-SW=
Switzerland
CP-PWR-CORD-UK=
United Kingdom
Ordering Information
Tables 6, 7 and 8 give ordering information for the phone and power cord, respectively.
Table 6. Ordering Information
Table 7. Power Cords
© 2014 Cisco and/or its affiliates. All rights reserved. This document is Cisco Public Information. Page 7 of 7
Printed in USA C78-726887-05 06/14
Warranty
Cisco Unified IP Phones and Conference Stations are covered by a Cisco standard 1-year replacement warranty.
Cisco Unified Communications Services
Cisco and our certified partners can help you deploy a secure, resilient Cisco Unified Communications solution,
meeting aggressive deployment schedules and accelerating business advantage. Cisco's portfolio of services is
based on proven methodologies for unifying voice, video, data, and mobile applications on fixed and mobile
networks.
Cisco's unique lifecycle approach to services defines the requisite activities at each phase of the solution lifecycle.
Customized planning and design services focus on creating a solution that meets your business needs. Awardwinning technical support increases operational efficiency. Remote-management services simplify day-to-day
operations, and optimization services enhance solution performance as your business needs change.
More Information
For additional details on the Cisco Unified IP Conference Phone 8831, go to
http://www.cisco.com/go/ipphones/8800.
Loading...
