Page 1
1
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Administrator guide
For Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40
Profile 42” Profile 52” Profile 52” Dual Profile 65”
Codec C60/C40
Software version TC4.2
JULY 2011
Page 2
2
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
TA - ToC - Hidden
text anchor
Thank you for choosing Cisco!
Your Cisco product has been designed to give you many years
of safe, reliable operation.
This part of the product documentation is aimed at
administrators working with the setup of the Codec C60/C40
and Profiles using Codec C60/C40.
Our main objective with this Administrator guide is to address
your goals and needs. Please let us know how well we
succeeded!
May we recommend that you visit the Cisco web site regularly
for updated versions of this guide.
The user documentation can be found on http://www.cisco.
com/go/telepresence/docs.
How to use this guide
The top menu bar and the entries in the Table of contents are
all hyperlinks. You can click on them to go to the topic.
Table of Contents
Introduction ........................................................................... 4
Intellectual property rights ..................................................... 5
User documentation .............................................................. 6
Software ............................................................................... 6
Cisco contacts ...................................................................... 6
What’s new in this version ....................................................... 7
Software release notes ......................................................... 7
Software download ............................................................... 7
New features and improvements .......................................... 7
Advanced configuration menu changes ................................ 8
Profile 42” using Codec C40 ataglance ................................ 9
Profile 52” at a glance ........................................................... 10
Profile 52” Dual at a glance ................................................... 11
Profile 65” at a glance ........................................................... 12
Codec C60 at a glance ......................................................... 13
Codec C40 at a glance ......................................................... 14
Web interface ...................................................................... 15
Connecting to the video conference system ......................... 16
The interactive menus ........................................................... 17
The system information page ................................................ 18
Log files ................................................................................. 19
XML files ................................................................................ 20
Making a snapshot................................................................. 21
Advanced configuration ......................................................... 22
Custom wallpaper .................................................................. 23
Sign in banner ....................................................................... 24
Making a call from the web interface ..................................... 25
Upgrading the system software ............................................. 26
Certificate management ........................................................ 27
The audit certificate list .......................................................... 28
User administration ................................................................ 29
Changing your password ....................................................... 31
Restarting the system ............................................................ 32
Advanced settings ............................................................... 33
The advanced settings .......................................................... 34
Overview of the advanced settings ..................................... 34
The Audio settings .............................................................. 38
The Cameras settings ......................................................... 42
The Conference settings ..................................................... 44
The GPIO settings ............................................................... 47
The H323 settings .............................................................. 47
The Network settings .......................................................... 49
The NetworkPort settings .................................................... 53
The NetworkServices settings ............................................ 53
The Phonebook settings ..................................................... 56
The Provisioning settings .................................................... 57
The RTP settings ................................................................. 58
The Security settings .......................................................... 58
The SerialPort settings ........................................................ 59
The SIP settings .................................................................. 60
The Standby settings .......................................................... 61
The SystemUnit settings ..................................................... 62
The Time settings ............................................................... 63
The Video settings .............................................................. 64
The Experimental settings ................................................... 71
Password protection ............................................................ 75
Password protection .............................................................. 76
Changing the system/codec password ............................... 76
Setting the Administrator settings menu password ............. 77
Setting a root password ...................................................... 77
Page 3
3
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Appendices ......................................................................... 78
Connecting the Cisco TelePresence Touch controller to
CodecCSeries ..................................................................... 79
About monitors when you have a Codec C60 ....................... 80
The main monitor ................................................................ 80
Connecting to HDMI 1 ...................................................... 80
Connecting to DVI-I 2 ....................................................... 80
Moving the OSD using the remote control ........................ 80
Moving the OSD using the web interface ......................... 80
Moving the OSD using API commands ............................. 80
Dual monitors ...................................................................... 80
Dual monitor configuration ................................................ 80
About monitors when you have a Codec C40 ....................... 81
The main monitor ................................................................ 81
Connecting to HDMI 1 ...................................................... 81
Connecting to DVI-I 2 ....................................................... 81
Moving the OSD using the remote control ........................ 81
Moving the OSD using the web interface ......................... 81
Moving the OSD using API commands ............................. 81
Dual monitors ...................................................................... 81
Dual monitor configuration ................................................ 81
TC console ............................................................................ 82
Video compositor ................................................................ 82
Audio console ..................................................................... 82
Optimal definition profiles ...................................................... 83
ClearPath — Packet loss resilience ......................................... 84
Requirements for speaker systems connected to a Cisco
TelePresence C Series codec ............................................... 85
DNAM for Profile 42”/52” ...................................................... 86
The DNAM Loudspeaker ..................................................... 86
The DNAM Amplifier............................................................ 86
DNAM for Profile 65” ............................................................. 87
The DNAM Loudspeaker ..................................................... 87
The DNAM Amplifier............................................................ 87
Technical specifications ......................................................... 88
Codec C60/C40 ................................................................. 88
Profile 52” using C60 .......................................................... 90
Profile 65” using C60 .......................................................... 91
Profile 42”/52” using C40 ................................................... 92
User documentation on the Cisco web site ........................... 93
Cisco contacts ..................................................................... 94
Page 4
4
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Chapter 1
Introduction
Page 5
5
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Intellectual property rights
THE SPECIFICATIONS AND INFORMATION REGARDING THE PRODUCTS IN THIS MANUAL ARE SUBJECT TO CHANGE
WITHOUT NOTICE. ALL STATEMENTS, INFORMATION, AND RECOMMENDATIONS IN THIS MANUAL ARE BELIEVED TO BE
ACCURATE BUT ARE PRESENTED WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED. USERS MUST TAKE FULL
RESPONSIBILITY FOR THEIR APPLICATION OF ANY PRODUCTS.
THE SOFTWARE LICENSE AND LIMITED WARRANTY FOR THE ACCOMPANYING PRODUCT ARE SET FORTH IN THE
INFORMATION PACKET THAT SHIPPED WITH THE PRODUCT AND ARE INCORPORATED HEREIN BY THIS REFERENCE. IF YOU
ARE UNABLE TO LOCATE THE SOFTWARE LICENSE OR LIMITED WARRANTY, CONTACT YOUR CISCO REPRESENTATIVE FOR
A COPY.
The Cisco implementation of TCP header compression is an adaptation of a program developed by the University of California,
Berkeley (UCB) as part of UCB’s public domain version of the UNIX operating system. All rights reserved. Copyright © 1981,
Regents of the University of California.
NOTWITHSTANDING ANY OTHER WARRANTY HEREIN, ALL DOCUMENT FILES AND SOFTWARE OF THESE SUPPLIERS ARE
PROVIDED “AS IS” WITH ALL FAULTS. CISCO AND THE ABOVE-NAMED SUPPLIERS DISCLAIM ALL WARRANTIES, EXPRESSED
OR IMPLIED, INCLUDING, WITHOUT LIMITATION, THOSE OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND
NONINFRINGEMENT OR ARISING FROM A COURSE OF DEALING, USAGE, OR TRADE PRACTICE.
IN NO EVENT SHALL CISCO OR ITS SUPPLIERS BE LIABLE FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, OR INCIDENTAL
DAMAGES, INCLUDING, WITHOUT LIMITATION, LOST PROFITS OR LOSS OR DAMAGE TO DATA ARISING OUT OF THE USE
OR INABILITY TO USE THIS MANUAL, EVEN IF CISCO OR ITS SUPPLIERS HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES.
Cisco and the Cisco Logo are trademarks of Cisco Systems, Inc. and/or its affiliates in the U.S. and other countries. A listing
of Cisco’s trademarks can be found at www.cisco.com/go/trademarks. Third party trademarks mentioned are the property of
their respective owners. The use of the word partner does not imply a partnership relationship between Cisco and any other
company. (1005R)
Any Internet Protocol (IP) addresses and phone numbers used in this document are not intended to be actual addresses
and phone numbers. Any examples, command display output, network topology diagrams, and other figures included in the
document are shown for illustrative purposes only. Any use of actual IP addresses or phone numbers in illustrative content is
unintentional and coincidental.
TANDBERG is now a part of Cisco. TANDBERG® is a registered trademark belonging to Tandberg ASA.
Page 6
6
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
This document provides you with the information
required to administrate your product at an advanced
level.
Products covered in this guide:
• Profile 52” / 52” Dual / 65” using C60
• Profile 42” / 52” using C40
• Codec C60
• Codec C40
User documentation
The user documentation for the Cisco TelePresence systems,
running the TC software, has several guides suitable for various
user groups.
• Video conference room primer
• Video conference room acoustics guidelines
• Installation guides for the TelePresence systems
• Software release notes for the TC software
• Getting started guide for the TelePresence systems
• User guide for the TelePresence systems
- with Touch controller
- with Remote Control
• Quick reference guides for the TelePresence systems
• Administrator guides for the TelePresence systems
• Camera user guide for the PrecisionHD cameras
• API reference guides for the Codec C Series
• TC Console user guide for the Codec C Series
• Physical interfaces guides for the Codec C Series
• Regulatory compliance and safety information guides
• Legal & license information for products using TC software
Downloading the user documentation
We recommend you visit the Cisco web site regularly for
updated versions of the user documentation.
Go to: http://www.cisco.com/go/telepresence/docs.
Guidelines how to find the documentation on the Cisco web
site are included in the User documentation on the Cisco
web site appendix.
Software
You can download the software for your product from the Cisco
web site, go to:
http://www.cisco.com/cisco/software/navigator.html
Cisco contacts
On our web site you will find an overview of the worldwide
Cisco contacts.
Go to: http://www.cisco.com/web/siteassets/contacts
Corporate Headquarters
Cisco Systems, Inc.
170 West Tasman Dr.
San Jose, CA 95134 USA
Page 7
7
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
What’s new in this version
This section provides an overview of the new and changed
advanced settings and new features in the TC4.2 software
version.
Software release notes
For a complete overview of the news and changes, we
recommend reading the Software Release Notes (TC4).
Go to: http://www.cisco.com/en/US/products/ps11422/
tsd_products_support_series_home.html
Software download
For software download go to: http://www.cisco.com/cisco/
software/navigator.html?a=a&i=rpm
New features and improvements
New software release for Cisco TelePresence PrecisionHD
Camera
With the TC4.2.0 release, the PrecisionHD 1080p camera
will automatically be upgraded to camera software release
ID40069. Included in this release is:
• Improvements to auto focus.
• Improvement to hot pixel correction.
• Improvements with the automatic white balance.
New features accessible from Touch panel
• Support for MultiWay conference.
• Support for restart of the codec.
• Support for factory defaulting the system.
• Support for camera presets for cameras with pan,
tilt and zoom functionality.
• Support for putting someone on hold.
• Support for call transfer.
• Support for standby.
New features accessible from menu on screen
Virtual keyboard for the remote control.
New web interface
• The web interface has been redesigned.
• Recommended browsers are IE8 and Firefox.
Support for CEC (Consumer Electronics Control)
The HDMI outputs now supports Consumer Electronics Control
(CEC). When set to On (default is Off), and the monitor
connected to the HDMI output is CEC compatible and CEC
is configured, the system will use CEC to set the monitor
in standby when the system enters standby. Likewise the
system will wake up the monitor when the system wakes
up from standby. Note that the different manufacturers uses
different marketing names for CEC: Anynet+ (Samsung);
Aquos Link (Sharp); BRAVIA Sync (Sony); HDMI-CEC (Hitachi);
Kuro Link (Pioneer); CE-Link and Regza Link (Toshiba); RIHD
(Remote Interactive over HDMI) (Onkyo); SimpLink (LG <http://
en.wikipedia.org/wiki/LG_Electronics> ); HDAVI Control,
EZ-Sync, VIERA Link (Panasonic); EasyLink (Philips); and
NetCommand for HDMI (Mitsubishi).
Support for always unmute when not in conference
The codec can be configured to allow muting of audio only
when the device is in a call. This is useful when an external
telephone service/audio system is connected via the codec
and you want it to be available when the codec is outside a
call. See the Audio Microphones Mute Enabled setting. When
set to InCallOnly this will prevent the audio-system from being
muted by accident. When set to True, muting of audio is always
available.
Support for VCS clustering
The system can now retrieve a list of SIP registrars and/
or H.323 gatekeepers by configuring the unit with the fully
qualified domain name of the registrar/gatekeeper. Both NAPTR
and SRV records are supported in addition to A-records
using DNS. This will allow the unit to retrieve a list of up to 20
registrars/gatekeepers and try to register to them in order. If the
first one is full, unavailable or does not answer the registration
request, the unit will try to register to the next one in the list
until a successful registration is made.
Page 8
8
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Advanced configuration menu changes
New settings
Audio Microphones Mute Enabled <True/InCallOnly>
Cameras Camera [1..7] DHCP <Off/On> (C40 only)
Experimental Conference ReceiverBasedDownspeeding <Off/On>
Experimental CapsetReduction <Auto/Reduced>
Experimental Audio EcReferenceDelay <0..300>
Experimental Audio Input Microphone [1..4] EchoControl
ResidualEchoMasking <Normal/Aggressive> (C60 only)
Experimental SystemUnit SoftwareUpgrade
RequireAuthentication <Off/On>
NetworkServices HTTPS OCSP URL <S: 0, 255>
NetworkServices HTTPS OCSP Mode <Off/On>
RTP Ports Range Start <1024..65502>
RTP Ports Range Stop <1056..65535>
Security Session ShowLastLogon <On/Off>
SIP Profile DisplayName <S: 0, 255>
SystemUnit Type <Personal/Shared>
Video OSD AutoSelectPresentationSource <Off/On>
Video Output HDMI [1] CEC Mode <Off/On>
Settings that are removed
Experimental SoftwareUpgrade Mode
Experimental SoftwareUpgrade ServerAddress
Settings that are modified
Audio Input Microphone [1..2] Equalizer ID (C40 only)
OLD: <1..14>
NEW: <1..16>
Audio Input Microphone [1..4] Equalizer ID (C60 only)
OLD: <1..14>
NEW: <1..16>
Network MTU
OLD: <400..1500>
NEW: <576..1500>
Network VLAN Voice Mode
OLD: <Untagged/Tagged>
NEW: <Manual/Off>
Network VLAN Voice VlanId
OLD: <0..4096>
NEW: <1..4094>
NetworkServices NTP Mode
OLD: <Auto/Manual>
NEW: <Off/Auto/Manual>
Provisioning Mode
OLD: <Off/TMS/VCS/CallWay>
NEW: <Off/TMS/VCS/CallWay/Auto>
SIP Profile Authentication LoginName
OLD: <S: 0, 50>
NEW: <S: 0, 128>
SIP Profile Authentication Password
OLD: <S: 0, 50>
NEW: <S: 0, 128>
SystemUnit MenuLanguage
Added menu languages: Czech and Hungarian
Video Output HDMI [1] Resolution
Added new resolutions: 1280_720_50 and 1920_1080_50
Video Output DVI [2] Resolution
Added new resolutions: 1280_720_50 and 1920_1080_50
Page 9
9
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Power cable
Mic cable
PC cable
Ethernet cable
Profile 42” using Codec C40
ataglance
See the installation sheet for the Profile 42” for instructions on
how to install the system.
Codec C40
• Full HD video.
• High resolution data sharing.
• Full HD Multisite.
• Rich I/O capabilities.
PrecisionHD 1080p camera
Full HD Camera designed for visual communication with:
• 12 × optical zoom.
• Fast and precise pan, tilt and zoom.
Monitor
42” Full HD LCD, 16:9, 1080 × 1920 resolution.
Audio module
Wide band audio module supporting:
• 20 kHz AAC-LD.
• Full echo canceling.
• Stereo.
Audio amplifier
Optimized DNAM for the Profile system, providing
crystal clear and natural audio.
Microphones
2 × Microphones.
Operating devices
Touch controller for C Series.
Remote control with AAA batteries.
Foot stand
Stand alone, wheelbase or wall mounting foot stand.
In the bottom module:
• Audio amplifier (DNAM)
• Codec C40
PrecisionHD 1080p camera
Monitor 42’’
Full HD LCD
Foot stand (stand alone,
wheelbase or wall mounting
foot module)
2 × Microphones with
cables
Remote control
with batteries
Touch controller
Page 10
10
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Power cable
Mic cable
PC cable
Ethernet cable
PrecisionHD 1080p camera
Monitor 52’’
Full HD LCD
In the bottom module:
• Audio amplifier (DNAM)
• Codec C60/C40
Profile 52” at a glance
See the installation sheet for the Profile 52” for instructions on
how to install the system.
Codec C60/C40
• Full HD video.
• High resolution data sharing.
• Full HD Multisite.
• Rich I/O capabilities.
PrecisionHD 1080p camera
Full HD Camera designed for visual communication with:
• 12 × optical zoom.
• Fast and precise pan, tilt and zoom.
Monitor
52” Full HD LCD, 16:9, 1080 × 1920 resolution.
Audio module
Wide band audio module supporting:
• 20 kHz AAC-LD.
• Full echo canceling.
• Stereo.
Audio amplifier
Optimized DNAM for the Profile system, providing
crystal clear and natural audio.
Microphones
3 × Microphones (with C60) / 2 × Microphones (with C40).
Operating devices
Touch controller for C Series.
Remote control with AAA batteries.
Foot stand
Stand alone, wheelbase or wall mounting foot stand.
3/2 × Microphones
with cables
Remote control
with batteries
Touch controller
Foot stand (stand alone,
wheelbase or wall mounting
foot module)
Page 11
11
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Power cable
Mic cable
PC cable
Ethernet cable
4 × Microphones with
cables
Profile 52” Dual at a glance
See the installation sheet for the Profile 52” Dual for instructions
on how to install the system.
Codec C60
• Full HD video.
• High resolution data sharing.
• Full HD Multisite.
• Rich I/O capabilities.
PrecisionHD 1080p camera
Full HD Camera designed for visual communication with:
• 12 × optical zoom.
• Fast and precise pan, tilt and zoom.
Dual monitor
Dual 52” Full HD LCD, 16:9, 1080 × 1920 resolution.
Audio module
Wide band audio module supporting:
• 20 kHz AAC-LD.
• Full echo canceling.
• Stereo.
Audio amplifier
Optimized DNAM for the Profile system, providing
crystal clear and natural audio.
Microphones
4 × Microphones.
Operating devices
Touch controller for C Series.
Remote control with AAA batteries.
Foot stand
Stand alone or wall mounting foot stand.
PrecisionHD 1080p camera
Dual 52’’ monitor Full
HD LCD
In the bottom module:
• Audio amplifier (DNAM)
• Codec C60
Foot stand (stand alone or
wall mounting foot module)
Remote control
with batteries
Touch controller
Page 12
12
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Power cable
Mic cables
PC cable
Ethernet cable
Profile 65” at a glance
See the Profile 65” Installation Sheet for instructions of how to
assemble the system.
Codec C60
• Full HD video.
• High resolution data sharing.
• Full HD Multisite.
• Rich I/O capabilities.
PrecisionHD 1080p camera
Full HD Camera designed for Visual communication with:
• 12 × optical zoom.
• Fast and precise pan, tilt and zoom.
Monitor 65”
65” Full HD LCD, 16:9, 1080 × 1920 resolution.
Audio module
Wide band audio module supporting:
• 20 kHz AAC-LD.
• Full echo canceling.
• Stereo.
Audio amplifier
Optimized DNAM for the Profile system, providing
crystal clear and natural audio.
Microphones
3 × Microphones.
Operating devices
Touch controller for C Series.
Remote control with AAA batteries.
Foot stand
Stand alone or wall mounting foot stand.
Foot stand (stand alone
or wall mounting foot
module)
PrecisionHD 1080p camera
Monitor 65” Full
HD LCD
In the bottom module:
• Audio amplifier (DNAM)
• Codec C60
3 × Microphones with
cables
Remote control
with batteries
Touch controller
Page 13
13
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Integrator package
The integrator package of the Codec C60 comes with the
PrecisionHD 1080p camera, microphone and cables.
Codec C60 at a glance
The Codec C60 is the 1080p HD video collaboration engine.
Based upon the same technology as the Codec C90, the C60
delivers Full HD video, HD collaboration and superior audio for
natural communication at its finest, delivering unrivaled value.
The C60 is a standards-compliant codec for integration into
team meeting rooms, boardrooms and industry projects.
• Full High Definition Video with up to 4 HD sources, and
collaboration with optimal definition for the best video quality
every time, regardless of environment.
• Highest Quality Audio with flexibility to add up to 4
microphones directly from the codec, and superior, full
duplex audio with high quality stereo sound.
• Full APIs.
• Ensure successful, streamlined integration projects with
standards-compliant professional connectors.
Page 14
14
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Integrator package
The integrator package of the Codec C40 comes with the
PrecisionHD 1080p camera, microphone and cables.
Codec C40 at a glance
The Codec C40 provides all the power required to transform any
conference room to a HD video collaboration room. Designed
for any standard HD integration project, the Codec C40 is the
ideal solution for everyday video conferencing and collaboration
solution. 1080p HD video, and Multisite™ features combine to
make the Codec C40 ideal for a variety of applications.
The Codec C40 is ideal for standard meeting rooms, executive
offices and team collaboration rooms.
• Full High Definition Video with up to 2 HD sources, and
collaboration with optimal definition for the best video quality
every time, regardless of environment.
• Highest Quality Audio with flexibility to add up to 2
microphones directly from the codec, and superior, full
duplex audio with high quality stereo sound.
• Full APIs.
• Ensure successful, streamlined integration projects with
standards-compliant professional connectors.
Page 15
15
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Chapter 2
Web interface
Page 16
16
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Connecting to the video
conference system
The web interface provides full configuration access to your
video conference system.
You can connect from a computer and administer the system
remotely.
This section describes the web interface functions and how
you can use them for system configuration and maintenance.
Starting to use web interface
1. Open a web browser and enter the IP address of the video
system in the address bar.
To find the IP address, open the System Information page
on the Touch controller. Tap the icons More > Settings,
select System Information and find the IPv4Address or
IPv6 Address.
2. Enter your user name and password and click Sign In.
The system is delivered with a default user named admin
with no password (i.e. leave the Password field blank when
signing in).
3. To sign out, click your user name and select Sign out from
the drop down menu.
About password protection
You sign in to the web interface with the same user name and
password as for the video conference system.
NOTE: We strongly recommend that you set a password for
the admin user to restrict access to system configuration.
Read more about password protection in the Password
protection chapter.
1. Connect
Enter the IP
address of the
video system.
2. Sign in
Enter the user
name and
password and
press Sign in.
3. Sign out
Click on your user
name and select
Sign out.
Change your password
Click on your user
name and select
Change password.
Page 17
17
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
The interactive menus
When you have signed in to the system the main menu
appears near the top of the page.
When you hover the mouse over a menu item, the names of
the related sub-menus appear. When you click a sub-menu
name the corresponding web page opens. These web pages
are described on the following pages.
Menu availability and user roles
A user account possesses one or more user roles. Three user
roles are defined: ADMIN, AUDIT and USER. Note that the
default admin user holds all three roles.
1
The table below shows which menus are available for users
holding the different roles.
ADMIN AUDIT USER
Diagnostics
System Information
Logs
XML Files
Snapshot
Configuration
Advanced Configuration
Wallpaper
Sign In Banner
Conference Control
Call
Maintenance
Upgrade Software
Certificate Management
Audit Certificate
User Administration
Change Password
Restart
When you hover the mouse over a main menu item, the related sub-menus are shown.
2
Main menu
The signed in user
• Diagnostics
• Configuration
• Conference
Control
• Maintenance
Click on your user name to
change your password or
sign out.
2
The illustration lists all the sub-menus. A user not possessing all user roles will only see the sub-set relevant for his type of user.
1
You can read more about user administration and user roles in the
User administration section.
Diagnostics
System Information
Logs
XML Files
Snapshot
Configuration
Advanced Configuration
Wallpaper
Sign In Banner
Conference Control
Call
Maintenance
Upgrade Software
Certificate Management
Audit Certificate
User Administration
Change Password
Restart
Page 18
18
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
The system information page
You can find an overview of your video system set-up on the
System Information page.
Security information Login information System information
Information about the
current security mode.
Information about recent
login attempts and
password expiry.
Information about
system name, product
type, software version,
IPaddress, etc.
Diagnostics
System Information
Logs
XML Files
Snapshot
Page 19
19
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Log files
The log files are Cisco specific debug files which may be
requested by the Cisco support organization if you need
technical support.
Current log files
The current log files are time stamped event log files.
Select Current log files, and click on a log file to view or save
the file (left or right click depending on your browser). Follow
the instructions in the dialog box to save or open the file.
Historical log files
These are time stamped historical log files.
Select Historical log files, and click on a log file to view or save
the file (left or right click depending on your browser). Follow
the instructions in the dialog box to save or open the file.
Diagnostics
System Information
Logs
XML Files
Snapshot
Page 20
20
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
XML files
The XML files are structured in a hierarchy building up a
database of information about the codec.
• Select Configuration to see an overview of the system
settings, which are controlled from the web interface or
from the API (Application Programmer Interface).
• The Status information is constantly updated by the
system to reflect system and process changes. The status
information is normally monitored from the API.
• Select Command to see an overview of the commands
available to instruct the system to perform an action. The
commands are issued from the API.
• Select Valuespace to see an overview of the value spaces.
Diagnostics
System Information
Logs
XML Files
Snapshot
Page 21
21
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Making a snapshot
When administering the video system from a remote location,
you can use the web interface snapshot feature to check the
view of the main video input source.
This feature is disabled by default. The feature can be enabled
only when you have direct access to the codec, i.e. from the
on screen menu or by using the command line interface via
the codec serial data port.
Using the on screen menu
From the Advanced configuration menu, navigate to Video >
AllowWebSnapshots and select On to enable the snapshot
feature.
Using the command line interface
Enter the following command to enable the snapshot feature:
xConfiguration Video AllowWebSnapshots <Off/On>.
Make a snapshot
Press Get snapshot. The
snapshot will be displayed on
the web interface.
Diagnostics
System Information
Logs
XML Files
Snapshot
Page 22
22
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Advanced configuration
The web interface allows for remote administration of the
system.
The system settings are structured in a hierarchy, and you can
navigate to each setting. Click a folder to open or close it, and
change a value as explained to the right.
Each system setting is further described in the Advanced
settings chapter.
Changing the system settings
Edit: To change a value, click on the
value to see the expanded view.
Value space: When you edit a value the
value space is specified either as a drop
down list or as text.
OK: Press the ok button to save the new
value.
Cancel: Select cancel to leave without
saving.
The search functionality
When searching for words such as
H323 or SIP, all settings beginning with
these words, and all settings below in
the hierarchy, will be shown in the list.
Search: Enter as many characters as
needed to get the desired result and
click the Search button to initiate the
search.
Clear: Click the Clear button to return to
the main view.
Configuration
Advanced Configuration
Wallpaper
Sign In Banner
Page 23
23
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Custom wallpaper
If you want the company logo or a custom picture to be
displayed on the main screen, you may use a custom
wallpaper.
If you use the Touch controller: The custom wall paper
applies to the main screen only and will not appear on
the Touch controller. When you choose a new predefined
wallpaper on the Touch controller, it will replace your custom
wall paper.
File format and picture size
The picture file format for the custom wallpaper is PNG. The
maximum size is 1920 × 1280 pixels.
Uploading the custom wallpaper file
1. Press Browse... and locate the wallpaper file (.PNG)
2. Press Upload to save the file to the codec.
Activating the new wallpaper
1. Go to the Configuration tab and open the the Advanced
Configuration page. Enter wallpaper in the search
field. From the drop down list, select Custom. The new
wallpaper will be displayed on screen.
Configuration
Advanced Configuration
Wallpaper
Sign In Banner
1. Upload the custom wallpaper file
2. Activate the new wallpaper
Page 24
24
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Sign in banner
If a system administrator wants to provide initial information to
all users, he can create a sign in banner. A sign in banner is a
message that is displayed to the user before signing in.
The message will be shown when the user signs in using
the menu system, the web interface or the command line
interface.
Adding a sign in banner
1. Enter the text message, which you want to present to the
user prior to signing in, in the Sign In Banner text area.
2. Press Submit Changes to activate the message.
Configuration
Advanced Configuration
Wallpaper
Sign In Banner
Page 25
25
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Making a call from the web
interface
Sometimes, e.g. when you are configuring the system from a
remote location, it is convenient to be able to make calls from
the video system to ensure everything works as expected.
Making a call
Input field: Enter one or more characters in the input field until
the name you want to call appears in the dynamic search list
or, enter the complete name or number.
Dial: Press Dial to initiate the call.
Disconnect all: Press Disconnect all to end all calls.
Options: Click Options to change the bit rate for this call.
Select the bit rate you want in the Call rate drop down list.
The call status page
You will find the following information on the call status page
when you are in a call:
• Remote number
• Call direction: Incoming/Outgoing
• Call protocol: H323/SIP
• Transmit and receive call rate
• Encryption
• Audio: Transmit and receive protocols
• Video: Transmit protocol and resolution, and receive
protocol and resolution
• Presentation: Transmit protocol and resolution, and receive
protocol and resolution
Conference Control
Call
Page 26
26
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Upgrading the system software
From the Upgrade Software page you can initiate software
upgrades and add a release key and option keys.
Software versions
This video conference system is using TC software.
NOTE: Contact your system administrator if you have
questions about the software version.
Software release notes and upgrade files
For a complete overview of the news and changes, we
recommend reading the Software Release Notes (TC4).
Go to: http://www.cisco.com/en/US/products/ps11422/
tsd_products_support_series_home.html
Downloading new software
For software download, go to: http://www.cisco.com/cisco/
software/navigator.html
Release key
The release key is required to be able to use the released
software.
Contact your Cisco representative to obtain the release key.
Option key
An option key is required to activate any optional functionality,
and you may have several option keys in your system. The
available options are:
• Premium resolution
• Multisite
• Dual display (only for Codec C40)
Contact your Cisco representative to obtain the option key(s).
1. Add the release and option keys
Contact your Cisco representative to obtain the required
key(s). If you will add both a release key and one or more
option keys, the correct procedure will be:
i. Enter the release key and press Add.
Key format: “1TC001-1-0C22E348” (each system
will have a unique key).
ii. Enter the option key and press Add.
Key format: “1N000-1-AA7A4A09” (each system will
have a unique key).
iii. If you have more than one option key, add the
remaining keys.
2. Upgrade the software on the codec
i. Before you can start the upgrade you must
download the software upgrade file. The file format:
“s52000tc4_0_0.pkg” (each software version has a
unique file name).
ii. Press Browse... and select the .PKG file.
iii. Press the Upgrade button to start the installation.
iv. Leave the system to allow the installation process
to complete. You can follow the progress on this
page. When the upgrade is successfully completed
a message will appear. The installation process may
take up to 30 minutes.
Maintenance
Upgrade Software
Certificate Management
Audit Certificate
User Administration
Change Password
Restart
Page 27
27
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Certificate management
The SSL certificate is a text file which verifies the authenticity
of your video conference system. The certificate may be
issued by a certificate authority (CA). Other parties can check
this certificate before setting up communication with you.
The list of trusted CA certificates is a list containing the SSL
certificates of all parties that you want your system to trust.
Uploading the SSL certificate
To install the SSL certificate, you will need the following:
• HTTPS certificate ( .PEM format)
• Private key ( .PEM format)
• Passphrase (optional)
Contact your system administrator to obtain the required files.
1. Press Browse... and locate the HTTPS certificate file (.PEM
format).
2. Press Browse... and locate the Private key file (.PEM
format).
3. Enter the Passphrase.
4. Press Upload to upload the certificate to your system.
Uploading the trusted CA certificates list
To install the trusted CA certificates list, you will need the
following:
• Trusted CA list file ( .PEM format).
Contact your system administrator to obtain the required file.
1. Press Browse... and locate the file with the Trusted CA list
(.PEM format).
2. Press Upload to upload the certificate list to your system.
Maintenance
Upgrade Software
Certificate Management
Audit Certificate
User Administration
Change Password
Restart
Page 28
28
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
The audit certificate list
If you want to use the ExternalSecure audit logging mode,
you must upload a list of trusted audit certificates to the video
conference system. This list covers all audit servers that your
system shall trust.
In the ExternalSecure audit logging mode audit logging
information will only be sent to entities holding a valid audit
certificate.
NOTE: You should always upload the audit certificate list
before enabling secure audit logging.
About audit logging
Audit logging records all login activity and configuration
changes on the system.
Audit logging is disabled by default. You can enable audit
logging using the on-screen menu or the web interface.
1. Upload the audit certificate list
To install the audit certificate, you will need:
• Audit list file ( .PEM format)
Contact your system administrator to obtain the required file.
i. Press Browse... and locate the file with the audit list file
(.PEM format).
ii. Press Upload to upload the certificate to your system.
2. Enable secure audit logging
When you have uploaded the audit certificate list you must
enable secure audit logging:
i. Navigate to Advanced Configuration > Security > Audit >
Server and enter the IP address and Port number of the
audit server.
ii. Navigate to Advanced Configuration > Security > Audit >
Logging > Mode and set it to ExternalSecure.
Maintenance
Upgrade Software
Certificate Management
Audit Certificate
User Administration
Change Password
Restart
Page 29
29
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
User administration
From this page you can manage the user accounts of your
video conference system. You can create a new user, edit the
details of an existing user, and delete a user.
The default user account
The system comes with a default administrator user account
with username admin and no password set. The admin user
has full access rights, and it is highly recommended to set a
password for this user.
Read more about passwords in the Password protection
chapter.
About user roles
A user account must possess one or a combination of several
user roles. Three user roles exist, representing different rights:
• ADMIN: A user with admin rights can create new users and
change all settings, except the security audit settings. This
user cannot upload audit certificates.
• USER: A user with user rights can make calls and search
the phonebook.
• AUDIT: A user with audit rights can change the security
audit configurations and upload audit certificates.
It is important to note that these roles have non-overlapping
rights.
An administrator user account with full access rights, like the
default admin user, must possess all the three roles.
Security mode
You can enable/disable the strong security mode from
this page. Strong security mode sets very strict password
requirements, and requires all users to change their password
on next sign in.
You can create as many
user accounts as you
like on your system.
Each user must have
one or more roles.
User name User role(s)
The system comes with
admin as default user
account. This user has
full access rights.
Default user account
Maintenance
Upgrade Software
Certificate Management
Audit Certificate
User Administration
Change Password
Restart
Page 30
30
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Creating a new user account
1. Press Create new user.
2. Fill in the Username, Password and PIN code, and select
the user role(s) for this user account.
As a default the user have to change the password and PIN
code when signing in for the first time.
Do not fill in the Distinguished Name (DN) Subject field
unless you want to use certificate login on https.
3. Set the Status to Active to activate the user.
4. Press Save to save the changes.
Editing user details
1. Select the name of an existing user to open the Editing
user window.
2. Edit the details.
3. Press Save to save the changes or Cancel to go back one
step without storing the information.
Deactivating a user account
1. Select the name of an existing user to open the Editing
user window.
2. Set the Status to Inactive.
3. Press Save to save the changes.
NOTE: Always keep at least one user with ADMIN rights Active.
Deleting a user account
1. Select the name of the user to open the Editing user
window.
2. Press Delete.
NOTE: Always keep at least one user with ADMIN rights.
Maintenance
Upgrade Software
Certificate Management
Audit Certificate
User Administration
Change Password
Restart
Page 31
31
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Changing your password
When you are signed in, you can change your password. In
the example to the right, the admin user is signed in.
Remember, it is highly recommended to set a password for all
users holding ADMIN rights.
The password is a string with 0–64 characters.
Changing your password
1. Enter your current password, your new password, and
repeat the new password in the input fields.
If no password is set, leave the current password input field
empty.
If you want to remove a password, leave the new password
input fields empty (not recommended for users with
ADMIN rights).
2. Click Change password to change the password.
The signed in userChanging your password
The signed in user can
change his own password.
Maintenance
Upgrade Software
Certificate Management
Audit Certificate
User Administration
Change Password
Restart
Page 32
32
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Restarting the system
To restart the system, press Restart now.
Restarting the system takes a few minutes.
Maintenance
Upgrade Software
Certificate Management
Audit Certificate
User Administration
Change Password
Restart
Page 33
33
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Chapter 3
Advanced settings
Page 34
34
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
The Audio settings
Audio Input HDMI [2] Level ....................................................................................................38
Audio Input HDMI [2] Mode ....................................................................................................38
Audio Input HDMI [2] VideoAssociation MuteOnInactiveVideo ...............................................38
Audio Input HDMI [2] VideoAssociation VideoInputSource .....................................................38
Audio Input Line [1..2] Channel..............................................................................................38
Audio Input Line [1..2] Equalizer ID ........................................................................................38
Audio Input Line [1..2] Equalizer Mode ..................................................................................38
Audio Input Line [1..2] Level ..................................................................................................39
Audio Input Line [1..2] LoopSuppression ...............................................................................39
Audio Input Line [1..2] Mode .................................................................................................39
Audio Input Line [1..2] VideoAssociation MuteOnInactiveVideo .............................................38
Audio Input Line [1..2] VideoAssociation VideoInputSource ..................................................38
Audio Input Microphone [1..2]/[1..4] EchoControl Mode ........................................................39
Audio Input Microphone [1..2]/[1..4] EchoControl NoiseReduction ........................................39
Audio Input Microphone [1..2]/[1..4] Equalizer ID ...................................................................39
Audio Input Microphone [1..2]/[1..4] Equalizer Mode .............................................................39
Audio Input Microphone [1..2]/[1..4] Level .............................................................................40
Audio Input Microphone [1..2]/[1..4] Mode ............................................................................40
Audio Input Microphone [1..2]/[1..4] Type .............................................................................40
Audio Input Microphone [1..2]/[1..4] VideoAssociation MuteOnInactiveVideo ........................40
Audio Input Microphone [1..2]/[1..4] VideoAssociation VideoInputSource .............................40
Audio Input Microphone [1..4] EchoControl Dereverberation .................................................39
Audio Microphones Mute Enabled .........................................................................................41
Audio Output HDMI [1] Level..................................................................................................40
Audio Output HDMI [1] Mode .................................................................................................40
Audio Output Line [1..2] Channel ...........................................................................................40
Audio Output Line [1..2] Equalizer ID .....................................................................................41
Audio Output Line [1..2] Equalizer Mode ...............................................................................41
Audio Output Line [1..2] Level ...............................................................................................41
Audio Output Line [1..2] Mode ...............................................................................................41
Audio Output Line [1] Type ....................................................................................................41
Audio Output Line [2] Type ....................................................................................................41
Audio SoundsAndAlerts KeyTones Mode...............................................................................41
Audio SoundsAndAlerts RingTone .........................................................................................42
Audio SoundsAndAlerts RingVolume .....................................................................................42
Audio Volume ........................................................................................................................42
The Cameras settings
Cameras Camera [1..7] Backlight ..........................................................................................42
Cameras Camera [1..7] Brightness Level ..............................................................................42
Cameras Camera [1..7] Brightness Mode ..............................................................................42
Cameras Camera [1..7] DHCP ...............................................................................................44
Cameras Camera [1..7] Flip ...................................................................................................43
Cameras Camera [1..7] Focus Mode .....................................................................................43
Cameras Camera [1..7] Gamma Level ...................................................................................43
Cameras Camera [1..7] Gamma Mode ..................................................................................43
Cameras Camera [1..7] IrSensor ...........................................................................................43
Cameras Camera [1..7] Mirror ...............................................................................................43
Cameras Camera [1..7] Whitebalance Level ..........................................................................44
Cameras Camera [1..7] Whitebalance Mode .........................................................................43
Cameras PowerLine Frequency .............................................................................................42
The Conference settings
Conference [1..1] AutoAnswer Delay.....................................................................................44
Conference [1..1] AutoAnswer Mode ....................................................................................44
Conference [1..1] AutoAnswer Mute .....................................................................................44
Conference [1..1] DefaultCall Protocol ..................................................................................45
Conference [1..1] DefaultCall Rate ........................................................................................45
Conference [1..1] DoNotDisturb Mode ..................................................................................45
Conference [1..1] Encryption Mode .......................................................................................45
Conference [1..1] FarEndControl Mode .................................................................................45
Conference [1..1] FarEndControl SignalCapability .................................................................45
Conference [1..1] IncomingMultisiteCall Mode ......................................................................44
Conference [1..1] MaxReceiveCallRate .................................................................................46
The advanced settings
In the following pages you will find a complete list of the system settings which are configured
from the Advanced configuration menu on screen or from the Advanced Configuration page on the
web interface. The examples show either the default value or an example of a value.
If you use the menu on screen, open the Home menu with the remote control and go to Settings >
Administrator settings > Advanced configuration.
If you use the web interface, open a web browser and enter the IP address of your system, sign in,
open the Configuration tab and select Advanced Configuration.
You will find the IP address on the System Information page, which you can access either using
the Touch controller (More > Settings > System Information) or using the remote control and on-
screen menu (Home > Settings > System Information).
Overview of the advanced settings
Page 35
35
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Conference [1..1] MaxTransmitCallRate.................................................................................45
Conference [1..1] MicUnmuteOnDisconnect .........................................................................45
Conference [1..1] PacketLossResilience Mode .....................................................................46
Conference [1..1] VideoBandwidth MainChannel Weight ......................................................46
Conference [1..1] VideoBandwidth Mode ..............................................................................46
Conference [1..1] VideoBandwidth PresentationChannel Weight ..........................................46
The GPIO settings
GPIO Pin [1..4] Mode .............................................................................................................47
The H323 settings
H323 NAT Address ................................................................................................................47
H323 NAT Mode ....................................................................................................................47
H323 Profile [1..1] Authentication LoginName .......................................................................48
H323 Profile [1..1] Authentication Mode ................................................................................47
H323 Profile [1..1] Authentication Password .........................................................................48
H323 Profile [1..1] CallSetup Mode .......................................................................................48
H323 Profile [1..1] Gatekeeper Address ................................................................................48
H323 Profile [1..1] Gatekeeper Discovery ..............................................................................48
H323 Profile [1..1] H323Alias E164 .......................................................................................48
H323 Profile [1..1] H323Alias ID ............................................................................................48
H323 Profile [1..1] PortAllocation ...........................................................................................49
The Network settings
Network [1..1] Assignment ....................................................................................................49
Network [1..1] DNS Domain Name ........................................................................................49
Network [1..1] DNS Server [1..5] Address .............................................................................49
Network [1..1] IEEE8021X AnonymousIdentity ......................................................................51
Network [1..1] IEEE8021X Eap Md5 ......................................................................................51
Network [1..1] IEEE8021X Eap Peap .....................................................................................52
Network [1..1] IEEE8021X Eap Ttls ........................................................................................52
Network [1..1] IEEE8021X Identity .........................................................................................51
Network [1..1] IEEE8021X Mode ...........................................................................................51
Network [1..1] IEEE8021X Password .....................................................................................51
Network [1..1] IPStack ...........................................................................................................49
Network [1..1] IPv4 Address ..................................................................................................50
Network [1..1] IPv4 Gateway .................................................................................................50
Network [1..1] IPv4 SubnetMask ...........................................................................................50
Network [1..1] IPv6 Address ..................................................................................................50
Network [1..1] IPv6 Assignment ............................................................................................50
Network [1..1] IPv6 DHCPOptions .........................................................................................50
Network [1..1] IPv6 Gateway .................................................................................................50
Network [1..1] MTU ...............................................................................................................52
Network [1..1] QoS Diffserv Audio .........................................................................................50
Network [1..1] QoS Diffserv Data ...........................................................................................51
Network [1..1] QoS Diffserv Signalling ...................................................................................51
Network [1..1] QoS Diffserv Video .........................................................................................51
Network [1..1] QoS Mode ......................................................................................................50
Network [1..1] RemoteAccess Allow......................................................................................52
Network [1..1] Speed ............................................................................................................52
Network [1..1] TrafficControl Mode ........................................................................................52
Network [1..1] VLAN Voice Mode ..........................................................................................52
Network [1..1] VLAN Voice Priority ........................................................................................52
Network [1..1] VLAN Voice VlanId..........................................................................................52
The NetworkPort settings
NetworkPort [2] Mode ...........................................................................................................53
The NetworkServices settings
NetworkServices H323 Mode................................................................................................53
NetworkServices HTTP Mode ................................................................................................54
NetworkServices HTTPS Mode .............................................................................................54
NetworkServices HTTPS OCSP Mode ...................................................................................54
NetworkServices HTTPS OCSP URL .....................................................................................54
NetworkServices HTTPS VerifyClientCertificate ....................................................................54
NetworkServices HTTPS VerifyServerCertificate ...................................................................54
NetworkServices Multiway Address .......................................................................................53
NetworkServices Multiway Protocol .......................................................................................53
NetworkServices NTP Address ..............................................................................................54
NetworkServices NTP Mode..................................................................................................54
NetworkServices SIP Mode ...................................................................................................55
NetworkServices SNMP CommunityName ............................................................................55
NetworkServices SNMP Host [1..3] Address .........................................................................55
NetworkServices SNMP Mode ..............................................................................................55
NetworkServices SNMP SystemContact ...............................................................................55
NetworkServices SNMP SystemLocation ..............................................................................55
NetworkServices SSH AllowPublicKey ...................................................................................56
NetworkServices SSH Mode .................................................................................................55
NetworkServices Telnet Mode ...............................................................................................56
The Phonebook settings
Phonebook Server [1..1] ID ...................................................................................................56
Phonebook Server [1..1] Type ...............................................................................................56
Phonebook Server [1..1] URL ................................................................................................56
Page 36
36
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
The Provisioning settings
Provisioning ExternalManager Address ..................................................................................57
Provisioning ExternalManager Domain ...................................................................................57
Provisioning ExternalManager Path ........................................................................................57
Provisioning ExternalManager Protocol ..................................................................................57
Provisioning HttpMethod ........................................................................................................57
Provisioning LoginName ........................................................................................................57
Provisioning Mode .................................................................................................................57
Provisioning Password ...........................................................................................................57
The RTP settings
RTP Ports Range Start ...........................................................................................................58
RTP Ports Range Stop ...........................................................................................................58
The Security settings
Security Audit Logging Mode ................................................................................................58
Security Audit OnError Action ................................................................................................58
Security Audit Server Address ...............................................................................................58
Security Audit Server Port .....................................................................................................58
Security Session InactivityTimeout ........................................................................................59
Security Session ShowLastLogon .........................................................................................59
The SerialPort settings
SerialPort BaudRate ...............................................................................................................59
SerialPort LoginRequired .......................................................................................................59
SerialPort Mode .....................................................................................................................59
The SIP settings
SIP Profile [1..1] Authentication [1..1] LoginName .................................................................60
SIP Profile [1..1] Authentication [1..1] Password ....................................................................60
SIP Profile [1..1] DefaultTransport ..........................................................................................60
SIP Profile [1..1] DisplayName ...............................................................................................60
SIP Profile [1..1] Outbound ....................................................................................................60
SIP Profile [1..1] Proxy [1..4] Address ....................................................................................60
SIP Profile [1..1] Proxy [1..4] Discovery .................................................................................61
SIP Profile [1..1] TlsVerify ......................................................................................................60
SIP Profile [1..1] Type ............................................................................................................61
SIP Profile [1..1] URI ..............................................................................................................60
The Standby settings
Standby BootAction ...............................................................................................................61
Standby Control .....................................................................................................................61
Standby Delay........................................................................................................................61
Standby StandbyAction .........................................................................................................61
Standby WakeupAction..........................................................................................................62
The SystemUnit settings
SystemUnit CallLogging Mode ...............................................................................................63
SystemUnit ContactInfo Type ................................................................................................62
SystemUnit IrSensor ..............................................................................................................63
SystemUnit MenuLanguage ...................................................................................................62
SystemUnit Name ..................................................................................................................62
SystemUnit Type ...................................................................................................................63
The Time settings
Time DateFormat ...................................................................................................................64
Time TimeFormat ...................................................................................................................64
Time Zone .............................................................................................................................63
The Video settings
Video AllowWebSnapshots ....................................................................................................69
Video DefaultPresentationSource ..........................................................................................66
Video Input DVI [3]/[2..3] Type ...............................................................................................66
Video Input Source [1..3] CameraControl CameraId ..............................................................65
Video Input Source [1..3] CameraControl Mode ....................................................................65
Video Input Source [1..3] Name ............................................................................................64
Video Input Source [1..3] OptimalDefinition Profile ................................................................65
Video Input Source [1..3] OptimalDefinition Threshold60fps..................................................65
Video Input Source [1..3] Quality ...........................................................................................66
Video Input Source [1..3] Type ..............................................................................................65
Video Input Source [1] Connector .........................................................................................64
Video Input Source [2] Connector .........................................................................................64
Video Input Source [3] Connector .........................................................................................64
Video Layout LocalLayoutFamily ............................................................................................67
Video Layout RemoteLayoutFamily ........................................................................................67
Video Layout ScaleToFrame ..................................................................................................67
Video Layout ScaleToFrameThreshold ...................................................................................67
Page 37
37
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Video Layout Scaling .............................................................................................................66
Video MainVideoSource ........................................................................................................67
Video Monitors ......................................................................................................................68
Video OSD AutoSelectPresentationSource ...........................................................................68
Video OSD InputMethod Cyrillic .............................................................................................69
Video OSD InputMethod InputLanguage ................................................................................68
Video OSD LoginRequired .....................................................................................................69
Video OSD Mode ...................................................................................................................68
Video OSD MyContactsExpanded .........................................................................................68
Video OSD Output .................................................................................................................68
Video OSD TodaysBookings ..................................................................................................68
Video Output Composite [3] MonitorRole ..............................................................................70
Video Output Composite [3] OverscanLevel ..........................................................................70
Video Output Composite [3] Resolution .................................................................................71
Video Output DVI [2] MonitorRole ..........................................................................................70
Video Output DVI [2] OverscanLevel ......................................................................................70
Video Output DVI [2] Resolution .............................................................................................70
Video Output HDMI [1] CEC Mode .........................................................................................69
Video Output HDMI [1] MonitorRole .......................................................................................69
Video Output HDMI [1] OverscanLevel ...................................................................................69
Video Output HDMI [1] Resolution .........................................................................................70
Video Selfview .......................................................................................................................71
Video SelfviewPosition ..........................................................................................................67
Video WallPaper ....................................................................................................................71
The Experimental settings
Experimental Audio EcReferenceDelay ..................................................................................71
Experimental Audio Input Microphone [1..2]/[1..4] Channel ...................................................72
Experimental Audio Input Microphone [1..2]/[1..4] EchoControl HighPassFilter .....................71
Experimental Audio Input Microphone [1..2]/[1..4] EchoControl ResidualEchoMasking .........71
Experimental Audio MicrophoneReinforcement AGC .............................................................72
Experimental Audio MicrophoneReinforcement Gain .............................................................72
Experimental Audio MicrophoneReinforcement Input Microphone [1..4] Mode .....................72
Experimental Audio MicrophoneReinforcement Output Line [1..2] Mode ..............................72
Experimental Audio Panning MaxAngle .................................................................................73
Experimental Audio Panning Mode ........................................................................................72
Experimental Audio Panning MonitorLeft ...............................................................................73
Experimental Audio Panning MonitorRight .............................................................................73
Experimental CapsetFilter ......................................................................................................73
Experimental CapsetReduction ..............................................................................................73
Experimental Conference [1..1] PacketLossResilience ForwardErrorCorrection ....................73
Experimental Conference [1..1] PacketLossResilience RateAdaption ....................................73
Experimental Conference [1..1] ReceiverBasedDownspeeding .............................................73
Experimental CustomSoftbuttons State [1..2] Softbutton [1..5] Type.....................................73
Experimental CustomSoftbuttons State [1..2] Softbutton [1..5] Value ....................................74
Experimental NetworkServices UPnP Mode ..........................................................................74
Experimental NetworkServices UPnP Timeout ......................................................................74
Experimental SystemUnit Controller Address ........................................................................74
Experimental SystemUnit MenuType .....................................................................................74
Experimental SystemUnit SoftwareUpgrade RequireAuthentication.......................................74
Page 38
38
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
The Audio settings
Audio Input HDMI [2] Mode
Determine if the audio channels on the HDMI input shall be enabled. The HDMI input 2 has two
audio channels.
Requires user role: ADMIN
Value space: <On/Off>
On: Enable the audio channels on the HDMI input.
Off: Disable the audio channels on the HDMI input.
Example: Audio Input HDMI 2 Mode: On
Audio Input HDMI [2] Level
Define the audio level of the HDMI input connector, in steps of 1 dB.
See the Audio Level tables in the Physical Interfaces Guide for the codec for a complete overview
of the menu values represented in dB.
Requires user role: ADMIN
Value space: <-24..0>
Range: Select a value from -24 to 0 dB.
Example: Audio Input HDMI 2 Level: 0
Audio Input HDMI [2] VideoAssociation MuteOnInactiveVideo
Enable association of a video source to an HDMI audio input.
Requires user role: ADMIN
Value space: <On/Off>
On: A video source is associated, and the audio will be muted if the associated video source is
not displayed.
Off: No video source is associated.
Example: Audio Input HDMI 2 VideoAssociation MuteOnInactiveVideo: Off
Audio Input HDMI [2] VideoAssociation VideoInputSource
Select the associated video input source.
Requires user role: ADMIN
Value space: <1/2/3>
Range: Select one of the video input sources.
Example: Audio Input HDMI 2 VideoAssociation VideoInputSource: 1
Audio Input Line [1..2] Equalizer ID
Select the audio input line equalizer ID.
Requires user role: ADMIN
Value space: <1..8>
Range: Select EqualizerID 1 to 8.
Example: Audio Input Line 1 Equalizer ID: 1
Audio Input Line [1..2] Equalizer Mode
Set the audio input line equalizer mode.
Requires user role: ADMIN
Value space: <On/Off>
On: Enable the equalizer for the audio input line.
Off: No equalizer.
Example: Audio Input Line 1 Equalizer Mode: Off
Audio Input Line [1..2] VideoAssociation MuteOnInactiveVideo
Enable association of a video source to a Line audio input.
Requires user role: ADMIN
Value space: <On/Off>
On: A video source is associated, and the audio will be muted if the associated video source is
not displayed.
Off: No video source is associated.
Example: Audio Input Line 1 VideoAssociation MuteOnInactiveVideo: Off
Audio Input Line [1..2] VideoAssociation VideoInputSource
Select the associated video input source.
Requires user role: ADMIN
Value space: <1/2/3>
Range: Select one of the video input sources.
Example: Audio Input Line 1 VideoAssociation VideoInputSource: 1
Audio Input Line [1..2] Channel
Define whether the Audio Line input is a mono signal or part of a multichannel signal.
Requires user role: ADMIN
Value space: <Left/Right/Mono>
Left: The Audio Line input signal is the left channel of a stereo signal.
Right: The Audio Line input signal is the right channel of a stereo signal.
Mono: The Audio Line input signal is a mono signal.
Example: Audio Input 1 Channel: Left
Page 39
39
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Audio Input Line [1..2] Level
Define the audio level of the Line input connector, in steps of 1 dB.
See the Audio Level tables in the Physical Interfaces Guide for the codec for a complete overview
of the menu values represented in dB.
Requires user role: ADMIN
Value space: <0..24>
Range: Select a value from 0 to 24 dB.
Example: Audio Input Line 1 Level: 10
Audio Input Line [1..2] LoopSuppression
NOTE: Codec C40/C60 does currently not support Loop Suppression, hence Loop Suppression
can be set to Off only.
Requires user role: ADMIN
Value space: <Off>
Off: Deactivate Loop Suppression.
Example: Audio Input Line 1 LoopSuppression: Off
Audio Input Line [1..2] Mode
Set the audio input line mode.
Requires user role: ADMIN
Value space: <On/Off>
On: Enable the Audio Line input.
Off: Disable the Audio Line input.
Example: Audio Input Line 1 Mode: On
Audio Input Microphone [1..2]/[1..4] EchoControl Mode
NOTE: Codec C40 has two microphone connectors. Codec C60 has four microphone connectors.
The echo canceller continuously adjusts itself to the audio characteristics of the room and
compensate for any changes it detects in the audio environment. If the changes in the audio
conditions are very significant the echo canceller may take a second or two to re-adjust.
Requires user role: ADMIN
Value space: <On/Off>
On: Echo Control is normally set to On to prevent the far end from hearing their own audio.
Once selected, echo cancellation is active at all times.
Off: Echo Control should be switched Off if external echo cancellation or playback equipment is
used.
Example: Audio Input Microphone 1 EchoControl Mode: On
Audio Input Microphone [1..2]/[1..4] EchoControl NoiseReduction
NOTE: Codec C40 has two microphone connectors. Codec C60 has four microphone connectors.
The system has a built-in noise reduction which reduces constant background noise (e.g.
noise from air-conditioning systems, cooling fans etc.). In addition, a high pass filter (Humfilter)
reduces very low frequency noise. NOTE: Requires the Echo Control Mode to be enabled for the
microphone.
Requires user role: ADMIN
Value space: <On/Off>
On: The Noise Reduction should be enabled in the presence of low frequency noise.
Off: Turn off the Noise Reduction.
Example: Audio Input Microphone 1 EchoControl NoiseReduction: On
Audio Input Microphone [1..4] EchoControl Dereverberation
The system has built-in signal processing to reduce the effect of room reverberation. NOTE:
Requires the Echo Control Mode to be enabled for the microphone.
Requires user role: ADMIN
Value space: <On/Off>
On: Turn on the dereverberation.
Off: Turn off the dereverberation.
Example: Audio Input Microphone 1 EchoControl Dereverberation: On
Audio Input Microphone [1..2]/[1..4] Equalizer ID
NOTE: Codec C40 has two microphone connectors. Codec C60 has four microphone connectors.
Select the audio input microphone equalizer ID.
Requires user role: ADMIN
Value space: <1..16>
Range: Select Equalizer ID 1 to 16.
Example: Audio Input Microphone 1 Equalizer ID: 1
Audio Input Microphone [1..2]/[1..4] Equalizer Mode
NOTE: Codec C40 has two microphone connectors. Codec C60 has four microphone connectors.
Set the audio input microphone equalizer mode.
Requires user role: ADMIN
Value space: <On/Off>
On: Enable the equalizer for the audio input microphone.
Off: No equalizer.
Example: Audio Input Microphone 1 Equalizer Mode: Off
Page 40
40
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Audio Input Microphone [1..2]/[1..4] VideoAssociation MuteOnInactiveVideo
NOTE: Codec C40 has two microphone connectors. Codec C60 has four microphone connectors.
Enable association of a video source to a microphone audio input.
Requires user role: ADMIN
Value space: <On/Off>
On: A video source is associated, and the audio will be muted if the associated video source is
not displayed.
Off: No video source is associated.
Example: Audio Input Microphone 1 VideoAssociation MuteOnInactiveVideo: On
Audio Input Microphone [1..2]/[1..4] VideoAssociation VideoInputSource
NOTE: Codec C40 has two microphone connectors. Codec C60 has four microphone connectors.
Select the associated video input source.
Requires user role: ADMIN
Value space: <1/2/3>
Range: Select one of the video input sources.
Example: Audio Input Microphone 1 VideoAssociation VideoInputSource: 1
Audio Input Microphone [1..2]/[1..4] Level
NOTE: Codec C40 has two microphone connectors. Codec C60 has four microphone connectors.
Define the audio level of the Microphone input connector, in steps of 1 dB.
See the Audio Level tables in the Physical Interfaces Guide for the codec for a complete overview
of the values represented in dB.
Requires user role: ADMIN
Value space: <0..24>
Range: Select a value from 0 to 24 dB.
Example: Audio Input Microphone 1 Level: 15
Audio Input Microphone [1..2]/[1..4] Mode
NOTE: Codec C40 has two microphone connectors. Codec C60 has four microphone connectors.
Set the audio input microphone mode.
Requires user role: ADMIN
Value space: <On/Off>
On: Enable the microphone connector.
Off: Disable the microphone connector.
Example: Audio Input Microphone 1 Mode: On
Audio Input Microphone [1..2]/[1..4] Type
NOTE: Codec C40 has two microphone connectors. Codec C60 has four microphone connectors.
The microphone connectors are intended for electret type microphones. The microphone
connector can be set to line or microphone mode.
Requires user role: ADMIN
Value space: <Microphone/Line>
Microphone: Select Microphone when you have 48 V Phantom voltage and the pre-amplification
is On.
Line: Select Line when you have a standard balanced line input. The phantom voltage and preamplification is Off.
Example: Audio Input Microphone 1 Type: Line
Audio Output HDMI [1] Level
Define the output level of the HDMI output connector, in steps of 1 dB.
See the Audio Level tables in the Physical Interfaces Guide for the codec for a complete overview
of the menu values represented in dB.
Requires user role: ADMIN
Value space: <-24..0>
Range: Select a value from -24 to 0dB.
Example: Audio Output HDMI 1 Level: 0
Audio Output HDMI [1] Mode
Determine if the audio channel on the HDMI output connector shall be enabled.
Requires user role: ADMIN
Value space: <On/Off>
On: Enable the audio channel on the HDMI output.
Off: Disable the audio channel on the HDMI output.
Example: Audio Output HDMI 1 Mode: On
Audio Output Line [1..2] Channel
Define whether the Audio Line output is a mono signal or part of a multichannel signal.
Requires user role: ADMIN
Value space: <Left/Right/Mono>
Left: The Audio Line output signal is the left channel of a stereo signal.
Right: The Audio Line output signal is the right channel of a stereo signal.
Mono: The Audio Line output signal is a mono signal.
Example: Audio Output Line 1 Channel: left
Page 41
41
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Audio Output Line [1..2] Equalizer ID
Select the audio output line equalizer ID.
Requires user role: ADMIN
Value space: <1..8>
Range: Select EqualizerID 1 to 8.
Example: Audio Output Line 1 Equalizer ID: 1
Audio Output Line [1..2] Equalizer Mode
Set the audio output line equalizer mode.
Requires user role: ADMIN
Value space: <On/Off>
On: Enable the equalizer for the audio output line.
Off: No equalizer.
Example: Audio Output Line 1 Equalizer Mode: Off
Audio Output Line [1..2] Level
Define the output level of the Audio Output Line connector, in steps of 1 dB.
See the Audio Level tables in the Physical Interfaces Guide for the codec for a complete overview
of the menu values represented in dB.
Requires user role: ADMIN
Value space: <-24..0>
Range: Select a value from -24 to 0 dB.
Example: Audio Output Line 1 Level: -10
Audio Output Line [1..2] Mode
Set the audio output line mode.
Requires user role: ADMIN
Value space: <On/Off>
On: Enable the Audio Line output.
Off: Disable the Audio Line output.
Example: Audio Output Line 1 Mode: On
Audio Output Line [1] Type
Determine if the Audio Line output will be analog or digital type output. The digital output on the
Cisco TelePresence Profile systems are identified as DNAM (Digital Natural Audio Module).
Requires user role: ADMIN
Value space: <Auto/SPDIF>
Auto: If a Digital NAM is detected then SPDIF mode will be selected, otherwise analog mode will
be selected.
SPDIF: Set to SPDIF when you want the line output to be in digital mode.
Example: Audio Output Line 1 Type: Auto
Audio Output Line [2] Type
Line output 2 is a dedicated analog output, hence type can be set to analog only.
Requires user role: ADMIN
Value space: <Analog>
Analog: Can be set to analog only.
Example: Audio Output Line 2 Type: Analog
Audio Microphones Mute Enabled
Determine whether audio-mute is allowed or not. The default value is True.
Requires user role: ADMIN
Value space: <True/InCallOnly>
True: Muting of audio is always available.
InCallOnly: Muting of audio is only available when the device is in a call. When Idle it is not
possible to mute the microphone. This is useful when an external telephone service/audio
system is connected via the codec and is to be available when the codec is not in a call. When
set to InCallOnly this will prevent the audio-system from being muted by mistake.
Example: Audio Microphones Mute Enabled: True
Audio SoundsAndAlerts KeyTones Mode
The system can produce a sound every time a key on the remote control is pressed.
Requires user role: USER
Value space: <On/Off>
On: There will be a sound indicator when pressing keys on the remote control.
Off: The remote control Key Tones is switched off.
Example: Audio SoundsAndAlerts KeyTones Mode: Off
Page 42
42
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Audio SoundsAndAlerts RingTone
Select the ring tone for incoming calls.
Requires user role: USER
Value space: <Marbles/IceCrystals/Polaris/Alert/Discreet/Fantasy/Jazz/
Nordic/Echo/Rhythmic>
Range: Select a tone from the list of ring tones.
Example: Audio SoundsAndAlerts RingTone: Jazz
Audio SoundsAndAlerts RingVolume
Sets the ring tone volume for an incoming call.
Requires user role: USER
Value space: <0..100>
Range: The value goes in steps of 5 from 0 to 100 (from -34.5 dB to 15 dB). Volume 0 = Off.
Example: Audio SoundsAndAlerts RingVolume: 50
Audio Volume
Set the volume on the loudspeaker.
Requires user role: USER
Value space: <0..100>
Range: The value goes in steps of 5 from 0 to 100 (from -34.5 dB to 15 dB). Value 0 = Off.
Example: Audio Volume: 70
The Cameras settings
Cameras PowerLine Frequency
Applies to cameras supporting PowerLine frequency anti-flickering, i.e PrecisionHD 1080p
cameras.
Requires user role: ADMIN
Value space: <Auto/50Hz/60Hz>
Auto: Set to Auto to enable power frequency auto detection in the camera.
50Hz: Set to 50 Hz.
60Hz: Set to 60 Hz.
Example: Cameras PowerLine Frequency: Auto
Cameras Camera [1..7] Backlight
The backlight functionality compensates for light shining directly at the camera (usually the sun
entering the window) to avoid a too dark image from the room.
Requires user role: ADMIN
Value space: <On/Off>
On: Turn on the camera backlight.
Off: Turn off the camera backlight.
Example: Cameras Camera 1 Backlight: Off
Cameras Camera [1..7] Brightness Mode
Set the camera brightness mode.
Requires user role: ADMIN
Value space: <Auto/Manual>
Auto: The camera brightness is automatically set by the system.
Manual: Enable manual control of the camera brightness, e.g. the level of the brightness level
setting will be used for the camera.
Example: Cameras Camera 1 Brightness Mode: Auto
Cameras Camera [1..7] Brightness Level
Set the brightness level. NOTE: Requires the Camera Brightness Mode to be set to Manual.
Requires user role: ADMIN
Value space: <1..31>
Range: Select a value from 1 to 31.
Example: Cameras Camera 1 Brightness Level: 1
Page 43
43
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Cameras Camera [1..7] Flip
With Flip mode (vertical flip) you can flip the image upside down.
Requires user role: ADMIN
Value space: <Auto/On/Off>
Auto: When the camera is placed upside down the image is automatically flipped upside down.
Use this setting with cameras that can be mounted upside down, and that can auto detect that
the camera is mounted upside down.
On: When enabled the video on screen is flipped. This setting is used with cameras that can be
mounted upside down, but cannot auto detect that the camera is mounted upside down.
Off: Display the video on screen the normal way.
Example: Cameras Camera 1 Flip: Off
Cameras Camera [1..7] Focus Mode
Set the camera focus mode.
Requires user role: ADMIN
Value space: <Auto/Manual>
Auto: When set to Auto the focus will be updated throughout the call. When moving the camera,
the system will use auto focus for a few seconds to set the right focus of the new camera
position. After a few seconds auto focus is turned off to prevent continuous focus adjustments
of the camera.
Manual: Turn the autofocus off and adjust the camera focus manually.
Example: Cameras Camera 1 Focus Mode: Auto
Cameras Camera [1..7] Gamma Mode
Applies to cameras which supports gamma mode. The Gamma Mode setting enables for gamma
corrections. Gamma describes the nonlinear relationship between image pixels and monitor
brightness. The Cisco TelePresence PrecisionHD 720p camera supports gamma mode. The
PrecisionHD 1080p camera does not support gamma mode.
Requires user role: ADMIN
Value space: <Auto/Manual>
Auto: Auto is the default and the recommended setting.
Manual: In severe light conditions, you may switch mode to manual and specify explicitly which
gamma table to use by setting the Gamma Level.
Example: Cameras Camera 1 Gamma Mode: Auto
Cameras Camera [1..7] Gamma Level
By setting the Gamma Level you can select which gamma correction table to use. This setting may
be useful in difficult lighting conditions, where changes to the brightness setting does not provide
satisfactory results. NOTE: Requires the Gamma Mode to be set to Manual.
Requires user role: ADMIN
Value space: <0..7>
Range: Select a value from 0 to 7.
Example: Cameras Camera 1 Gamma Level: 0
Cameras Camera [1..7] IrSensor
The IR sensor LED is located in the front of the camera and flickers when the IR sensor is activated
from the remote control. Both the Codec C Series and PrecisionHD camera have IR sensors, and
only one of them needs to be enabled at the time.
Requires user role: ADMIN
Value space: <On/Off>
On: Enable the IR sensor on the camera.
Off: Disable the IR sensor on the camera.
Example: Cameras Camera 1 IrSensor: On
Cameras Camera [1..7] Mirror
With Mirror mode (horizontal flip) you can mirror the image on screen.
Requires user role: ADMIN
Value space: <Auto/On/Off>
Auto: When the camera is placed upside down the image is automatically mirrored. Use this
setting with cameras that can be mounted upside down, and that can auto detect that the
camera is mounted upside down.
On: See the selfview in mirror mode, e.g. the selfview is reversed and the experience of
selfview is as seeing yourself in a mirror.
Off: See the selfview in normal mode, e.g. the experience of selfview is as seeing yourself as
other people see you.
Example: Cameras Camera 1 Mirror: Off
Cameras Camera [1..7] Whitebalance Mode
Set the camera whitebalance mode.
Requires user role: ADMIN
Value space: <Auto/Manual>
Auto: The camera will continuously adjust the whitebalance depending on the camera view.
Manual: Enables manual control of the camera whitebalance, e.g. the level of the whitebalance
level setting will be used for the camera.
Example: Cameras Camera 1 Whitebalance Mode: Auto
Page 44
44
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Cameras Camera [1..7] Whitebalance Level
Set the whitebalance level. NOTE: Requires the Camera Whitebalance Mode to be set to manual.
Requires user role: ADMIN
Value space: <1..16>
Range: Select a value from 1 to 16.
Example: Cameras Camera 1 Whitebalance Level: 1
Cameras Camera [1..7] DHCP
Applies to cameras which supports DHCP. The Cisco TelePresence PrecsisionHD 1080p camera
supports DHCP. The camera must be connected to a LAN. When set, the command enables
support for SW upgrade of daisy chained cameras. It will enable the camera's DHCP function and
force start of MAC and IP address retrieval. Remember to reset the DHCP when the camera is no
longer connected to a LAN.
Requires user role: ADMIN
Value space: <On/Off>
On: Enable DHCP in the camera. The camera is automatically re-booted. After re-boot the
DHCP is started and the IP address will be retrieved. Run the commnand "xStatus Camera" for
result.
Off: Disable DHCP in the camera. NOTE: This setting should be applied when the camera is not
connected to a LAN.
Example: Cameras Camera 1 DHCP: Off
The Conference settings
Conference [1..1] IncomingMultisiteCall Mode
Set the incoming Multisite call mode. The MultiSite feature allows participants from more than two
locations to join a meeting — by video and/or telephone.
Requires user role: ADMIN
Value space: <Allow/Deny>
Allow: Accept incoming calls to an already active call/conference. The incoming call will be
added to the MCU conference.
Deny: The system will not accept incoming calls when you are in a call. The calling side will
receive a busy signal.
Example: Conference 1 IncomingMultisiteCall Mode: Allow
Conference [1..1] AutoAnswer Mode
Set the AutoAnswer mode.
Requires user role: ADMIN
Value space: <On/Off>
On: Enable AutoAnswer to let the system automatically answer all incoming calls.
Off: The incoming calls must be answered manually by pressing the OK key or the green Call
key on the remote control.
Example: Conference 1 AutoAnswer Mode: Off
Conference [1..1] AutoAnswer Mute
Determine if the microphone shall be muted when an incoming call is automatically answered.
NOTE: Requires the AutoAnswer Mode to be enabled.
Requires user role: ADMIN
Value space: <On/Off>
On: The incoming call will be muted when automatically answered.
Off: The incoming call will not be muted.
Example: Conference 1 AutoAnswer Mute: Off
Conference [1..1] AutoAnswer Delay
Define how long (in seconds) an incoming call has to wait before it is answered automatically by
the system. NOTE: Requires the AutoAnswer Mode to be enabled.
Requires user role: ADMIN
Value space: <0..50>
Range: Select a value from 0 to 50 seconds.
Example: Conference 1 AutoAnswer Delay: 0
Page 45
45
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Conference [1..1] MicUnmuteOnDisconnect
Determine if the microphones shall be unmuted automatically when all calls are disconnected. In
a meeting room or other shared resources this could be done to prepare the system for the next
user.
Requires user role: ADMIN
Value space: <On/Off>
On: Un-mute the microphones after the call is disconnected.
Off: If muted, let the microphones remain muted after the call is disconnected.
Example: Conference 1 MicUnmuteOnDisconnect: On
Conference [1..1] DoNotDisturb Mode
Determine if there should be an alert on incoming calls.
Requires user role: USER
Value space: <On/Off>
On: All incoming calls will be rejected, with no alert. The calling side will receive a busy signal
when trying to call the codec. A message will display on screen, telling that Do not disturb is
turned on, together with an option to turn off the Do not disturb. When turning off the Do not
disturb mode you will see a list of the calls that have been rejected.
Off: The incoming calls will be alerted.
Example: DoNotDisturb Mode: Off
Conference [1..1] FarEndControl Mode
Lets you decide if the remote side (far end) should be allowed to select your video sources and
control your local camera (pan, tilt, zoom).
Requires user role: ADMIN
Value space: <On/Off>
On: Allows the far end to be able to select your video sources and control your local camera
(pan, tilt, zoom). You will still be able to control your camera and select your video sources as
normal.
Off: The far end is not allowed to select your video sources or to control your local camera (pan,
tilt, zoom).
Example: Conference 1 FarEndControl Mode: On
Conference [1..1] FarEndControl SignalCapability
Set the far end control (H.224) signal capability mode.
Requires user role: ADMIN
Value space: <On/Off>
On: Enable the far end control signal capability.
Off: Disable the far end control signal capability.
Example: Conference 1 FarEndControl SignalCapability: On
Conference [1..1] Encryption Mode
Set the conference encryption mode. A padlock with the text "Encryption On" or "Encryption Off"
displays on screen for a few seconds when the conference starts.
Requires user role: ADMIN
Value space: <BestEffort/On/Off>
BestEffort: The system will use encryption whenever possible.
> In Point to point calls: If the far end system supports encryption (AES-128), the call will be
encrypted. If not, the call will proceed without encryption.
> In MultiSite calls: In order to have encrypted MultiSite conferences, all sites must support
encryption. If not, the conference will be unencrypted.
On: The system will only allow calls that are encrypted.
Off: The system will not use encryption.
Example: Conference 1 Encryption Mode: BestEffort
Conference [1..1] DefaultCall Protocol
Set the Default Call Protocol to be used when placing calls from the system.
Requires user role: ADMIN
Value space: <H323/Sip>
H.323: Select H.323 to ensure that calls are set up as H.323 calls.
Sip: Select SIP to ensure that calls are set up as SIP calls.
Example: Conference 1 DefaultCall Protocol: H323
Conference [1..1] DefaultCall Rate
Set the Default Call Rate to be used when placing calls from the system.
Requires user role: ADMIN
Value space: <64..6000>
Range: Select a value between 64 and 6000 kbps
Example: Conference 1 DefaultCall Rate: 768
Conference [1..1] MaxTransmitCallRate
Specify the maximum transmit call rate to be used when placing or receiving calls.
Requires user role: ADMIN
Value space: <64..6000>
Range: Select a value between 64 and 6000 kbps.
Example: Conference 1 MaxTransmitCallRate: 6000
Page 46
46
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Conference [1..1] MaxReceiveCallRate
Specify the maximum receive call rate to be used when placing or receiving calls.
Requires user role: ADMIN
Value space: <64..6000>
Range: Select a value between 64 and 6000 kbps.
Example: Conference 1 MaxReceiveCallRate: 6000
Conference [1..1] VideoBandwidth Mode
Set the conference video bandwidth mode.
Requires user role: ADMIN
Value space: <Dynamic/Static>
Dynamic: The available transmit bandwidth for the video channels are distributed among the
currently active channels. If there is no presentation, the main video channels will use the
bandwidth of the presentation channel.
Static: The available transmit bandwidth is assigned to each video channel, even if it is not
active.
Example: Conference 1 VideoBandwidth Mode: Dynamic
Conference [1..1] VideoBandwidth MainChannel Weight
The available transmit video bandwidth is distributed on the main channel and presentation channel
according to "MainChannel Weight" and "PresentationChannel Weight". If the main channel
weight is 2 and the presentation channel weight is 1, then the main channel will use twice as much
bandwidth as the presentation channel.
Requires user role: ADMIN
Value space: <1..10>
Range: 1 to 10.
Example: Conference 1 VideoBandwidth MainChannel Weight: 5
Conference [1..1] VideoBandwidth PresentationChannel Weight
The available transmit video bandwidth is distributed on the main channel and presentation channel
according to "MainChannel Weight" and "PresentationChannel Weight". If the main channel
weight is 2 and the presentation channel weight is 1, then the main channel will use twice as much
bandwidth as the presentation channel.
Requires user role: ADMIN
Value space: <1..10>
Range: 1 to 10.
Example: Conference 1 VideoBandwidth PresentationChannel Weight: 5
Conference [1..1] PacketLossResilience Mode
Set the packetloss resilience mode. This configuration will only take effect for calls initiated after
the configuration is set.
Requires user role: ADMIN
Value space: <On/Off>
On: Enable the packetloss resilience.
Off: Disable the packetloss resilience.
Example: Conference 1 PacketLossResilience Mode: On
Page 47
47
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
The GPIO settings
GPIO Pin [1..4] Mode
NOTE: This command is not supported on Codec C40.
The four GPIO pins are configured individually. The state can be retrieved by "xStatus GPIO Pin
[1..4] State". The default pin state is High (+12 V). When activated as output, they are set to 0 V. To
activate them as input, they must be pulled down to 0 V.
Requires user role: ADMIN
Value space: <InputNoAction/OutputManualState/OutputInCall/
OutputMicrophonesMuted/OutputPresentationOn/OutputAllCallsEncrypted/
OutputStandbyActive/InputMuteMicrophones>
InputNoAction: The pin state can be set, but no operation is performed.
OutputManualState: The pin state can be set by "xCommand GPIO ManualState Set PinX:
<High/Low>" (to +12 V or 0 V, respectively).
OutputInCall: The pin is activated when in call, deactivated when not in call.
OutputMicrophonesMuted: The pin is activated when microphones are muted, deactivated when
not muted.
OutputPresentationOn: The pin is activated when presentation is active, deactivated when
presentation is not active.
OutputAllCallsEncrypted: The pin is activated when all calls are encrypted, deactivated when
one or more calls are not encrypted.
OutputStandbyActive: The pin is activated when the system is in standby mode, deactivated
when no longer in standby.
InputMuteMicrophones: When the pin is activated (0 V), the microphones will be muted. When
deactivated (+ 12 V), the microphones are unmuted.
Example: GPIO Pin 1 Mode: InputNoAction
The H323 settings
H323 NAT Mode
The firewall traversal technology creates a secure path through the firewall barrier, and enables
proper exchange of audio/video data when connected to an external video conferencing system
(when the IP traffic goes through a NAT router). NOTE: NAT does not work in conjunction with
gatekeepers.
Requires user role: ADMIN
Value space: <Auto/On/Off>
Auto: The system will determine if the "NAT Address" or the real IP-address should be used
within signalling. This is done to make it possible to place calls to endpoints on the LAN as well
as endpoints on the WAN.
On: The system will signal the configured "NAT Address" in place of its own IP-address within
Q.931 and H.245. The NAT Server Address will be shown in the startup-menu as: "My IP
Address: 10.0.2.1".
Off: The system will signal the real IP Address.
Example: H323 NAT Mode: Off
H323 NAT Address
Enter the external/global IP-address to the router with NAT support. Packets sent to the router will
then be routed to the system.
In the router, the following ports must be routed to the system's IP-address:
* Port 1720
* Port 5555-5574
* Port 2326-2485
Requires user role: ADMIN
Value space: <S: 0, 64>
Format: String with a maximum of 64 characters.
Example: H323 NAT Address: ""
H323 Profile [1..1] Authentication Mode
Set the authenticatin mode for the H.323 profile.
Requires user role: ADMIN
Value space: <On/Off>
On: If the H.323 Gatekeeper Authentication Mode is set to On and a H.323 Gatekeeper
indicates that it requires authentication, the system will try to authenticate itself to the
gatekeeper. NOTE: Requires the Authentication LoginName and Authentication Password to be
defined on both the codec and the Gatekeeper.
Off: If the H.323 Gatekeeper Authentication Mode is set to Off the system will not try to
authenticate itself to a H.323 Gatekeeper, but will still try a normal registration.
Example: H323 Profile 1 Authentication Mode: Off
Page 48
48
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
H323 Profile [1..1] Gatekeeper Discovery
Determine how the system shall register to a H.323 Gatekeeper.
Requires user role: ADMIN
Value space: <Manual/Auto>
Manual: The system will use a specific Gatekeeper identified by the Gatekeeper's IP-address.
Auto: The system will automatically try to register to any available Gatekeeper. If a Gatekeeper
responds to the request sent from the codec within 30 seconds this specific Gatekeeper will
be used. This requires that the Gatekeeper is in auto discovery mode as well. If no Gatekeeper
responds, the system will not use a Gatekeeper for making H.323 calls and hence an IPaddress must be specified manually.
Example: H323 Profile 1 Gatekeeper Discovery: Manual
H323 Profile [1..1] Gatekeeper Address
Enter the IP address of the Gatekeeper. NOTE: Requires the H.323 Call Setup Mode to be set to
Gatekeeper and the Gatekeeper Discovery to be set to Manual.
Requires user role: ADMIN
Value space: <S: 0, 255>
Format: Only the valid IP address format is accepted. An IP address that contains letters
(192.a.2.0) or unvalid IP addresses (192.0.1234.0) will be rejected.
Example: H323 Profile 1 Gatekeeper Address: "192.0.2.0"
H323 Profile [1..1] H323Alias E164
The H.323 Alias E.164 defines the address of the system, according to the numbering plan
implemented in the H.323 Gatekeeper. The E.164 alias is equivalent to a telephone number,
sometimes combined with access codes.
Requires user role: ADMIN
Value space: <S: 0, 30>
Format: Compact string with a maximum of 30 characters. Valid characters are 0-9, * and #.
Example: H323 Profile 1 H323Alias E164: "90550092"
H323 Profile [1..1] H323Alias ID
Lets you specify the H.323 Alias ID which is used to address the system on a H.323 Gatekeeper
and will be displayed in the call lists. Example: "firstname.surname@company.com", "My H.323
Alias ID"
Requires user role: ADMIN
Value space: <S: 0, 49>
Format: String with a maximum of 49 characters
Example: H323 Profile 1 H323Alias ID: "firstname.surname@company.com"
H323 Profile [1..1] Authentication LoginName
The system sends the Authentication Login Name and the Authentication Password to a H.323
Gatekeeper for authentication. The authentication is a one way authentication from the codec to
the H.323 Gatekeeper, i.e. the system is authenticated to the gatekeeper. If the H.323 Gatekeeper
indicates that no authentication is required, the system will still try to register. NOTE: Requires the
H.323 Gatekeeper Authentication Mode to be enabled.
Requires user role: ADMIN
Value space: <S: 0, 50>
Format: String with a maximum of 50 characters.
Example: H323 Profile 1 Authentication LoginName: ""
H323 Profile [1..1] Authentication Password
The system sends the Authentication Login Name and the Authentication Password to a H.323
Gatekeeper for authentication. The authentication is a one way authentication from the codec to
the H.323 Gatekeeper, i.e. the system is authenticated to the gatekeeper. If the H.323 Gatekeeper
indicates that no authentication is required, the system will still try to register. NOTE: Requires the
H.323 Gatekeeper Authentication Mode to be enabled.
Requires user role: ADMIN
Value space: <S: 0, 50>
Format: String with a maximum of 50 characters.
Example: H323 Profile 1 Authentication Password:
H323 Profile [1..1] CallSetup Mode
The H.323 Call Setup Mode defines whether to use a Gatekeeper or Direct calling when
establishing H323 calls.
NOTE: Direct H.323 calls can be made even though the H.323 Call Setup Mode is set to
Gatekeeper.
Requires user role: ADMIN
Value space: <Direct/Gatekeeper>
Direct: An IP-address must be used when dialling in order to make the H323 call.
Gatekeeper: The system will use a Gatekeeper to make a H.323 call. When selecting this option
the H323 Profile Gatekeeper Address and H323 Profile Gatekeeper Discovery settings must
also be configured.
Example: H323 Profile 1 CallSetup Mode: Gatekeeper
Page 49
49
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
H323 Profile [1..1] PortAllocation
The H.323 Port Allocation setting affects the H.245 port numbers used for H.323 call signalling.
Requires user role: ADMIN
Value space: <Dynamic/Static>
Dynamic: The system will allocate which ports to use when opening a TCP connection. The
reason for doing this is to avoid using the same ports for subsequent calls, as some firewalls
consider this as a sign of attack. When Dynamic is selected, the H.323 ports used are from
11000 to 20999. Once 20999 is reached they restart again at 11000. For RTP and RTCP
media data, the system is using UDP ports in the range 2326 to 2487. Each media channel
is using two adjacent ports, ie 2330 and 2331 for RTP and RTCP respectively. The ports are
automatically selected by the system within the given range. Firewall administrators should not
try to deduce which ports are used when, as the allocation schema within the mentioned range
may change without any further notice.
Static: When set to Static the ports are given within a static predefined range [5555-6555].
Example: H323 Profile 1 PortAllocation: Dynamic
The Network settings
Network [1..1] Assignment
Define whether to use DHCP or Static IPv4 assignment.
Requires user role: ADMIN
Value space: <Static/DHCP>
Static: Set the network assignment to Static and configure the static IPv4 settings (IP Address,
SubnetMask and Gateway).
DHCP: The system addresses are automatically assigned by the DHCP server.
Example: Network 1 Assignment: DHCP
Network [1..1] DNS Domain Name
DNS Domain Name is the default domain name suffix which is added to unqualified names.
Example: If the DNS Domain Name is "company.com" and the name to lookup is
"MyVideoSystem", this will result in the DNS lookup "MyVideoSystem.company.com".
Requires user role: ADMIN
Value space: <S: 0, 64>
Format: String with a maximum of 64 characters.
Example: Network 1 DNS Domain Name: ""
Network [1..1] DNS Server [1..5] Address
Define the network addresses for DNS servers. Up to 5 addresses may be specified. If the network
addresses are unknown, contact your administrator or Internet Service Provider.
Requires user role: ADMIN
Value space: <S: 0, 64>
Format: String with a maximum of 64 characters.
Example: Network 1 DNS Server 1 Address: ""
Network [1..1] IPStack
Select which internet protocols the system will support.
Requires user role: ADMIN
Value space: <IPv4/IPv6>
IPv4: IP version 4 is supported.
IPv6: IP version 6 is supported. The IPv4 settings (IP Address, IP Subnet Mask and Gateway)
will be disabled.
Example: Network 1 IPStack: IPv4
Page 50
50
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Network [1..1] IPv4 Address
Enter the static IPv4 network address for the system. Only applicable if the Network Assignment is
set to Static.
Requires user role: ADMIN
Value space: <S: 0, 64>
Format: Only the valid IP address format is accepted. An IP address that contains letters
(192.a.2.0) or unvalid IP addresses (192.0.1234.0) will be rejected.
Example: Network 1 IPv4 Address: "192.0.2.0"
Network [1..1] IPv4 Gateway
Define the IPv4 network gateway. Only applicable if the Network Assignment is set to Static.
Requires user role: ADMIN
Value space: <S: 0, 64>
Format: Compact string with a maximum of 64 characters.
Example: Network 1 IPv4 Gateway: "192.0.2.0"
Network [1..1] IPv4 SubnetMask
Define the IPv4 network subnet mask. Only applicable if the Network Assignment is set to Static.
Requires user role: ADMIN
Value space: <S: 0, 64>
Format: Compact string with a maximum of 64 characters.
Example: Network 1 IPv4 SubnetMask: "255.255.255.0"
Network [1..1] IPv6 Address
Enter the static IPv6 network address for the system. Only applicable if the Network IPv6
Assignment is set to Static.
Requires user role: ADMIN
Value space: <S: 0, 64>
Format: The IPv6 address of host name.
Example: Network 1 IPv6 Address: "ffff:ffff:ffff:ffff:ffff:ffff:ffff:ffff"
Network [1..1] IPv6 Gateway
Define the IPv6 network gateway address. Only applicable if the Network IPv6 Assignment is set to
Static.
Requires user role: ADMIN
Value space: <S: 0, 64>
Format: The IPv6 address of host name.
Example: Network 1 IPv6 Gateway: "ffff:ffff:ffff:ffff:ffff:ffff:ffff:ffff"
Network [1..1] IPv6 Assignment
Define whether to use Autoconf or Static IPv6 assignment.
Requires user role: ADMIN
Value space: <Static/Autoconf>
Static: Set the network assignment to Static and configure the static IPv6 settings (IP Address
and Gateway).
Autoconf: Enable IPv6 stateless autoconfiguration of the IPv6 network interface. See RFC4862
for a detailed description.
Example: Network 1 IPv6 Assignment: Autoconf
Network [1..1] IPv6 DHCPOptions
Retrieves a set of DHCP options from a DHCPv6 server.
Requires user role: ADMIN
Value space: <On/Off>
On: Enable the retrieval of a selected set of DHCP options from a DHCPv6 server.
Off: Set to Off when IPv6 Assignment is set to Static.
Example: Network 1 IPv6 Gateway: On
Network [1..1] QoS Mode
The QoS (Quality of Service) is a method which handles the priority of audio, video and data in
the network. The QoS settings must be supported by the infrastructure. Diffserv (Differentiated
Services) is a computer networking architecture that specifies a simple, scalable and coarsegrained mechanism for classifying, managing network traffic and providing QoS priorities on
modern IP networks.
Requires user role: ADMIN
Value space: <Off/Diffserv>
Off: No QoS method is used.
Diffserv: When you set the QoS Mode to Diffserv you must configure the Diffserv sub menu
settings (Audio, Data, Signalling and Video).
Example: Network 1 QoS Mode: diffserv
Network [1..1] QoS Diffserv Audio
The Diffserv Audio defines which priority Audio packets should have in an IP network. Enter a
priority, which ranges from 0 to 63 for the packets. The higher the number, the higher the priority.
These priorities might be overridden when packets are leaving the network controlled by the local
network administrator. NOTE: Requires the Network QoS Mode to be set to Diffserv.
Requires user role: ADMIN
Value space: <0..63>
Audio: A recommended value is Diffserv Code Point (DSCP) AF41, which equals the value 34. If
in doubt, contact your network administrator.
Range: Select a value from 0 to 63.
Example: Network 1 QoS Diffserv Audio: 0
Page 51
51
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Network [1..1] QoS Diffserv Data
The Diffserv Data defines which priority Data packets should have in an IP network. Enter a priority,
which ranges from 0 to 63 for the packets. The higher the number, the higher the priority. These
priorities might be overridden when packets are leaving the network controlled by the local network
administrator. NOTE: Requires the Network QoS Mode to be set to Diffserv.
Requires user role: ADMIN
Value space: <0..63>
Data: A recommended value is Diffserv Code Point (DSCP) AF23, which equals the value 22. If
in doubt, contact your network administrator.
Range: Select a value from 0 to 63.
Example: Network 1 QoS Diffserv Data: 0
Network [1..1] QoS Diffserv Signalling
The Diffserv Signalling defines which priority Signalling packets should have in an IP network. Enter
a priority, which ranges from 0 to 63 for the packets. The higher the number, the higher the priority.
These priorities might be overridden when packets are leaving the network controlled by the local
network administrator. NOTE: Requires the Network QoS Mode to be set to Diffserv.
Requires user role: ADMIN
Value space: <0..63>
Signalling: A recommended value is Diffserv Code Point (DSCP) AF31, which equals the value
26. If in doubt, contact your network administrator.
Range: Select a value from 0 to 63.
Example: Network 1 QoS Diffserv Signalling: 0
Network [1..1] QoS Diffserv Video
The Diffserv Video defines which priority Video packets should have in an IP network. Enter a
priority, which ranges from 0 to 63 for the packets. The higher the number, the higher the priority.
These priorities might be overridden when packets are leaving the network controlled by the local
network administrator. NOTE: Requires the Network QoS Mode to be set to Diffserv.
Requires user role: ADMIN
Value space: <0..63>
Video: A recommended value is Diffserv Code Point (DSCP) AF41, which equals the value 34. If
in doubt, contact your network administrator.
Range: Select a value from 0 to 63.
Example: Network 1 QoS Diffserv Video: 0
Network [1..1] IEEE8021X Mode
The system can be connected to an IEEE 802.1X LAN network, with a port-based network access
control that is used to provide authenticated network access for Ethernet networks.
Requires user role: ADMIN
Value space: <On/Off>
On: The 802.1X authentication is enabled.
Off: The 802.1X authentication is disabled (default).
Example: Network 1 IEEE8021X Mode: Off
Network [1..1] IEEE8021X Identity
The 802.1X Identity is the user name needed for 802.1X authentication.
Requires user role: ADMIN
Value space: <S: 0, 64>
Format: String with a maximum of 64 characters.
Example: Network 1 IEEE8021X Identity: ""
Network [1..1] IEEE8021X Password
The 802.1X Password is the password needed for 802.1X authentication.
Requires user role: ADMIN
Value space: <S: 0, 32>
Format: String with a maximum of 32 characters.
Example: Network 1 IEEE8021X Password: "***"
Network [1..1] IEEE8021X AnonymousIdentity
The 802.1X Anonymous ID string is to be used as unencrypted identity with EAP (Extensible
Authentication Protocol) types that support different tunneled identity, like EAP-PEAP and EAPTTLS. If set, the anonymous ID will be used for the initial (unencrypted) EAP Identity Request.
Requires user role: ADMIN
Value space: <S: 0, 64>
Format: String with a maximum of 64 characters.
Example: Network 1 IEEE8021X AnonymousIdentity: ""
Network [1..1] IEEE8021X Eap Md5
Set the Md5 (Message-Digest Algorithm 5) mode. This is a Challenge Handshake Authentication
Protocol that relies on a shared secret. Md5 is a Weak security.
Requires user role: ADMIN
Value space: <On/Off>
On: The EAP-MD5 protocol is enabled (default).
Off: The EAP-MD5 protocol is disabled.
Example: Network 1 IEEE8021X Eap Md5: On
Page 52
52
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Network [1..1] IEEE8021X Eap Peap
Set the Peap (Protected Extensible Authentication Protocol) mode. Authenticates LAN clients
without the need for client certificates. Developed by Microsoft, Cisco and RSA Security.
Requires user role: ADMIN
Value space: <On/Off>
On: The EAP-PEAP protocol is enabled (default).
Off: The EAP-PEAP protocol is disabled.
Example: Network 1 IEEE8021X Eap Peap: On
Network [1..1] IEEE8021X Eap Ttls
Set the TTLS (Tunneled Transport Layer Security) mode. Authenticates LAN clients without the
need for client certificates. Developed by Funk Software and Certicom. Usually supported by Agere
Systems, Proxim and Avaya.
Requires user role: ADMIN
Value space: <On/Off>
On: The EAP-TTLS protocol is enabled (default).
Off: The EAP-TTLS protocol is disabled.
Example: Network 1 IEEE8021X Eap Ttls: On
Network [1..1] MTU
Set the Ethernet MTU (Maximum Transmission Unit).
Requires user role: ADMIN
Value space: <576..1500>
Range: Select a value from 576 to 1500 bytes.
Example: Network 1 MTU: 1500
Network [1..1] Speed
Set the Ethernet link speed.
Requires user role: ADMIN
Value space: <Auto/10half/10full/100half/100full/1000full>
Auto: Autonegotiate link speed.
10half: Force link to 10 Mbps half-duplex.
10full: Force link to 10 Mbps full-duplex.
100half: Force link to 100 Mbps half-duplex.
100full: Force link to 100 Mbps full-duplex.
1000full: Force link to 1 Gbps full-duplex.
Example: Network 1 Speed: Auto
Network [1..1] TrafficControl Mode
Set the network traffic control mode to decide how to control the video packets transmission
speed.
Requires user role: ADMIN
Value space: <On/Off>
On: Transmit video packets at maximum 20 Mbps. Can be used to smooth out bursts in the
outgoing network traffic.
Off: Transmit video packets at link speed.
Example: Network 1 TrafficControl: On
Network [1..1] RemoteAccess Allow
Filter IP addresses for access to ssh/telnet/HTTP/HTTPS.
Requires user role: ADMIN
Value space: <S: 0, 255>
Format: String with a maximum of 255 characters, comma separated IP adresses or IP range.
Example: Network 1 RemoteAccess Allow: "192.168.1.231, 192.168.1.182"
Network [1..1] VLAN Voice Mode
Set the VLAN voice mode.
Requires user role: ADMIN
Value space: <Manual/Off>
Manual: The voice packets in the VLAN network are manually tagged with VlanId and Priority.
Off: The voice packets in the VLAN network are untagged.
Example: Network 1 VLAN Voice Mode: Off
Network [1..1] VLAN Voice VlanId
Set the VLAN voice ID.
Requires user role: ADMIN
Value space: <1..4094>
Range: Select a value from 1 to 4094.
Example: Network 1 VLAN Voice VlanId: 1
Network [1..1] VLAN Voice Priority
Set the VLAN voice priority.
Requires user role: ADMIN
Value space: <0..7>
Range: Select a value from 0 to 7.
Example: Network 1 VLAN Voice Priority: 0
Page 53
53
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
The NetworkPort settings
NetworkPort [2] Mode
Define if the network port 2 shall be enabled for direct pairing with the Cisco TelePresence Touch
for C Series.
Requires user role: ADMIN
Value space: <Inactive/DirectPairing>
Inactive: Set the NetworkPort 2 to Inactive when no device is connected.
DirectPairing: Set the NetworkPort 2 to DirectPairing when you have a Cisco TelePresence
Touch unit connected to the port. This will enable for direct pairing between the touch unit and
the codec.
Example: NetworkPort 2 Mode: Inactive
The NetworkServices settings
NetworkServices Multiway Address
The Multiway address must be equal to the Conference Factory Alias, as configured on the Video
Communication Server. The Multiway™ conferencing enables video endpoint users to introduce a
3rd party into an existing call.
Multiway™ can be used in the following situations:
1) When you want to add someone else in to your existing call.
2) When you are called by a 3rd party while already in a call and you want to include that person
in the call.
Requirements: The Codec C20 must be running TC3.0 (or later), Codec C90/C60/C40
must be running TC4.0 (or later), EX90/EX60/MX200 must be running TC4.2 (or later), Video
Communication Server (VCS) version X5 (or later) and Codian MCU version 3.1 (or later).
Endpoints invited to join the Multiway™ conference must support the H.323 routeToMC facility
message if in an H.323 call, or SIP REFER message if in a SIP call.
Requires user role: ADMIN
Value space: <S: 0, 255>
Format: String with a maximum of 255 characters.
Example: NetworkServices Multiway Address: "h323:multiway@company.com"
NetworkServices Multiway Protocol
Determine the protocol to be used for Multiway calls. NOTE: Requires a restart of the codec.
Requires user role: ADMIN
Value space: <Auto/H323/Sip>
Auto: The system will select the protocol for Multiway calls.
H323: The H323 protocol will be used for Multiway calls.
Sip: The SIP protocol will be used for Multiway calls.
Example: NetworkServices Multiway Protocol: Auto
NetworkServices H323 Mode
Determine whether the system should be able to place and receive H.323 calls or not. NOTE:
Requires a restart of the codec.
Requires user role: ADMIN
Value space: <On/Off>
On: Enable the possibility to place and receive H.323 calls (default).
Off: Disable the possibility to place and receive H.323 calls.
Example: NetworkServices H323 Mode: On
Page 54
54
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
NetworkServices HTTP Mode
Set the HTTP mode to enable/disable access to the system through a web browser. The web
interface is used for system management, call management such as call transfer, diagnostics and
software uploads.
Requires user role: ADMIN
Value space: <On/Off>
On: The HTTP protocol is enabled.
Off: The HTTP protocol is disabled.
Example: NetworkServices HTTP Mode: On
NetworkServices HTTPS Mode
HTTPS is a web protocol that encrypts and decrypts user page requests as well as the pages that
are returned by the web server.
Requires user role: ADMIN
Value space: <On/Off>
On: The HTTPS protocol is enabled.
Off: The HTTPS protocol is disabled.
Example: NetworkServices HTTPS Mode: On
NetworkServices HTTPS VerifyServerCertificate
When the system connects to an external HTTPS server (like a phonebook server or an external
manager), this server will present a certificate to the system to identify itself.
Requires user role: ADMIN
Value space: <On/Off>
On: Requires the system to verify that the server certificate is signed by a trusted Certificate
Authority (CA). This requires that a list of trusted CAs are uploaded to the system in advance.
Off: Do not verify server certificates.
Example: NetworkServices HTTPS VerifyServerCertificate: Off
NetworkServices HTTPS VerifyClientCertificate
When the system connects to a HTTPS client (like a web browser), the client can be asked to
present a certificate to the system to identify itself.
Requires user role: ADMIN
Value space: <On/Off>
On: Requires the client to present a certificate that is signed by a trusted Certificate Authority
(CA). This requires that a list of trusted CAs are uploaded to the system in advance.
Off: Do not verify client certificates.
Example: NetworkServices HTTPS VerifyClientCertificate: Off
NetworkServices HTTPS OCSP Mode
Define the support for OCSP (Online Certificate Status Protocol) responder services. The OCSP
feature allows users to enable OCSP instead of certificate revocation lists (CRLs) to check
certificate status.
Requires user role: ADMIN
Value space: <On/Off>
On: Enable OCSP support.
Off: Disable OCSP support.
Example: NetworkServices HTTPS OCSP Mode: Off
NetworkServices HTTPS OCSP URL
Specify the URL of an OCSP server.
Requires user role: ADMIN
Value space: <S: 0, 255>
Format: String with a maximum of 255 characters.
Example: NetworkServices HTTPS OCSP URL: "http://ocspserver.company.com:81"
NetworkServices NTP Mode
The Network Time Protocol (NTP) is used to synchronize the time of the system to a reference
time server. The time server will subsequently be queried every 24th hour for time updates.
The time will be displayed on the top of the screen. The system will use the time to timestamp
messages transmitted to Gatekeepers or Border Controllers requiring H.235 authentication. The
system will use the time to timestamp messages transmitted to Gatekeepers or Border Controllers
that requires H.235 authentication. It is also used for timestamping Placed Calls, Missed Calls and
Received Calls.
Requires user role: ADMIN
Value space: <Off/Auto/Manual>
Off: The system will not use an NTP server.
Auto: The system will use the NTP server, by which address is supplied from the DHCP server in
the network. If no DHCP server is used, or the DHCP server does not provide the system with a
NTP server address, the system will use the static defined NTP server address specified by the
user.
Manual: The system will always use the static defined NTP server address specified by the user.
Example: NetworkServices NTP Mode: Manual
NetworkServices NTP Address
Enter the NTP Address to define the network time protocol server address. This address will be
used if NTP Mode is set to Manual, or if set to Auto and no address is supplied by a DHCP server.
Requires user role: ADMIN
Value space: <S: 0, 64>
Format: String with a maximum of 64 characters.
Example: NetworkServices NTP Address: "1.ntp.tandberg.com"
Page 55
55
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
NetworkServices SIP Mode
Determine whether the system should be able to place and receive SIP calls or not. NOTE:
Requires a restart of the codec.
Requires user role: ADMIN
Value space: <On/Off>
On: Enable the possibility to place and receive SIP calls (default).
Off: Disable the possibility to place and receive SIP calls.
Example: NetworkServices SIP Mode: On
NetworkServices SNMP Mode
SNMP (Simple Network Management Protocol) is used in network management systems to monitor
network-attached devices (routers, servers, switches, projectors, etc) for conditions that warrant
administrative attention. SNMP exposes management data in the form of variables on the managed
systems, which describe the system configuration. These variables can then be queried (set to
ReadOnly) and sometimes set (set to ReadWrite) by managing applications.
Requires user role: ADMIN
Value space: <Off/ReadOnly/ReadWrite>
Off: Disable the SNMP network service.
ReadOnly: Enable the SNMP network service for queries only.
ReadWrite: Enable the SNMP network service for both queries and commands.
Example: NetworkServices SNMP Mode: ReadWrite
NetworkServices SNMP Host [1..3] Address
Enter the address of up to three SNMP Managers. All traps will then be sent to the hosts listed.
The system's SNMP Agent (in the codec) responds to requests from SNMP Managers (a PC
program etc.). SNMP Traps are generated by the SNMP Agent to inform the SNMP Manager about
important events. Can be used to send event created messages to the SNMP agent about different
events like: system reboot, system dialling, system disconnecting, MCU call, packet loss etc. Traps
can be sent to multiple SNMP Trap Hosts.
Requires user role: ADMIN
Value space: <S: 0, 64>
Format: String with a maximum of 64 characters.
Example: NetworkServices SNMP Host 1 Address: ""
NetworkServices SNMP CommunityName
Enter the name of the Network Services SNMP Community. SNMP Community names are used
to authenticate SNMP requests. SNMP requests must have a password (case sensitive) in order
to receive a response from the SNMP Agent in the codec. The default password is "public". If
you have the Cisco TelePresence Management Suite (TMS) you must make sure the same SNMP
Community is configured there too. NOTE: The SNMP Community password is case sensitive.
Requires user role: ADMIN
Value space: <S: 0, 50>
Format: String with a maximum of 50 characters.
Example: NetworkServices SNMP CommunityName: "public"
NetworkServices SNMP SystemContact
Enter the name of the Network Services SNMP System Contact.
Requires user role: ADMIN
Value space: <S: 0, 50>
Format: String with a maximum of 50 characters.
Example: NetworkServices SNMP SystemContact: ""
NetworkServices SNMP SystemLocation
Enter the name of the Network Services SNMP System Location.
Requires user role: ADMIN
Value space: <S: 0, 50>
Format: String with a maximum of 50 characters.
Example: NetworkServices SNMP SystemLocation: ""
NetworkServices SSH Mode
SSH (or Secure Shell) protocol can provide secure encrypted communication between the codec
and your local computer.
Requires user role: ADMIN
Value space: <On/Off>
On: The SSH protocol is enabled.
Off: The SSH protocol is disabled.
Example: NetworkServices SSH Mode: On
Page 56
56
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
NetworkServices SSH AllowPublicKey
Secure Shell (SSH) public key authentication can be used to access the codec.
Requires user role: ADMIN
Value space: <On/Off>
On: The SSH public key is allowed.
Off: The SSH public key is not allowed.
Example: NetworkServices SSH AllowPublicKey: On
NetworkServices Telnet Mode
Telnet is a network protocol used on the Internet or Local Area Network (LAN) connections.
Requires user role: ADMIN
Value space: <On/Off>
On: The Telnet protocol is enabled.
Off: The Telnet protocol is disabled. This is the factory setting.
Example: NetworkServices Telnet Mode: Off
The Phonebook settings
Phonebook Server [1..1] ID
Enter a name for the external phonebook.
Requires user role: ADMIN
Value space: <S: 0, 64>
Format: String with a maximum of 64 characters.
Example: Phonebook Server 1 ID: ""
Phonebook Server [1..1] Type
Select the phonebook server type.
Requires user role: ADMIN
Value space: <VCS/TMS/Callway>
VCS: Select VCS if the phonebook is located on the Cisco TelePresence Video Communication
Server.
TMS: Select TMS if the phonebook is located on the Cisco TelePresence Management Suite
server.
Callway: Select Callway if the phonebook is to be provided by the Callway subscription service.
Contact your Callway provider for more information.
Example: Phonebook Server 1 Type: TMS
Phonebook Server [1..1] URL
Enter the address (URL) to the external phonebook server.
Requires user role: ADMIN
Value space: <S: 0, 255>
Format: String with a maximum of 255 characters.
Example: Phonebook Server 1 URL: "http://tms.company.com/tms/public/
external/phonebook/phonebookservice.asmx"
Page 57
57
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
The Provisioning settings
Provisioning Mode
Provides the possibility of managing the codec (endpoint) by using an external manager/
management system.
Requires user role: ADMIN
Value space: <Off/TMS/VCS/CallWay/Auto>
Off: The system will not try to register to any management system.
TMS: If set to TMS (Cisco TelePresence Management System) the system will try to register
with a TMS server. Contact your Cisco representative for more information.
VCS: If set to VCS (Cisco TelePresence Video Communication Server) the system will try to
register with a VCS. Contact your Cisco representative for more information.
Callway: If set to Callway the system will try to register with the Callway subscription provider.
Contact your Callway provider for more information.
Auto: The provisioning server will automatically be selected by the system.
Example: Provisioning Mode: TMS
Provisioning LoginName
Enter the user id provided by the provisioning server. This is the user name part of the credentials
used to authenticate towards the HTTP server when using HTTP provisioning.
Requires user role: ADMIN
Value space: <S: 0, 80>
Format: String with a maximum of 80 characters.
Example: Provisioning LoginName: ""
Provisioning Password
Enter the password provided by the provisioning server. This is the password part of the credentials
used to authenticate towards the HTTP server when using HTTP provisioning.
Requires user role: ADMIN
Value space: <S: 0, 64>
Format: String with a maximum of 64 characters.
Example: Provisioning Password: ""
Provisioning HttpMethod
Select the HTTP method to be used for the provisioning.
Requires user role: ADMIN
Value space: <GET/POST>
GET: Select GET when the provisiong server supports GET.
POS T: Select POST when the provisiong server supports POST.
Example: Provisioning HttpMethod: POST
Provisioning ExternalManager Address
Enter the IP Address to the External Manager/Management system. If an External Manager address
and a path is configured, the system will post an HTTP message to this address when starting
up. When receiving this HTTP posting the External Manager (typically a management system)
can return configurations/commands to the unit as a result. If the DHCP Option 242 is returned in
the DHCP response from the DHCP server the system will interpret this as the External Manager
address to use.
Requires user role: ADMIN
Value space: <S: 0, 64>
Format: Only the valid IP address format is accepted. An IP address that contains letters
(192.a.2.0) or unvalid IP addresses (192.0.1234.0) will be rejected.
Example: Provisioning ExternalManager Address: ""
Provisioning ExternalManager Protocol
Determine whether or not to use secure management.
Requires user role: ADMIN
Value space: <HTTP/HTTPS>
HTTP: Set to HTTP to disable secure management. Requires HTTP to be enabled in the
xConfiguration NetworkServices HTTP Mode setting.
HTTPS: Set to HTTPS to enable secure management. Requires HTTPS to be enabled in the
xConfiguration NetworkServices HTTPS Mode setting.
Example: Provisioning ExternalManager Protocol: HTTP
Provisioning ExternalManager Path
Set the path to the External Manager/Management system. If an External Manager address and a
path is configured, the system will post an HTTP message to this address when starting up. When
receiving this HTTP posting the External Manager (typically a management system) can return
configurations/commands to the unit as a result. If the DHCP Option 242 is returned in the DHCP
response from the DHCP server the system will interpret this as the External Manager address to
use.
Requires user role: ADMIN
Value space: <S: 0, 255>
Format: String with a maximum of 255 characters.
Example: Provisioning ExternalManager Path: "tms/public/external/
management/SystemManagementService.asmx"
Provisioning ExternalManager Domain
Enter the SIP domain for the provisioning server.
Requires user role: ADMIN
Value space: <S: 0, 64>
Format: String with a maximum of 64 characters.
Example: Provisioning ExternalManager Domain: "any.domain.com"
Page 58
58
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
The RTP settings
RTP Ports Range Start
Specify the first port in the range of RTP ports. See also the "H323 Profile [1..1] PortAllocation"
command.
Requires user role: USER
Value space: <1024..65502>
Range: Select a value from 1024 to 65502.
Example: RTP Ports Range Start: 2326
RTP Ports Range Stop
Specify the last RTP port in the range. See also the "H323 Profile [1..1] PortAllocation" command.
Requires user role: USER
Value space: <1056..65535>
Range: Select a value from 1056 to 65535.
Example: RTP Ports Range Stop: 2486
The Security settings
Security Audit Server Address
Enter the external/global IP-address to the audit syslog server.
Requires user role: AUDIT
Value space: <S: 0, 64>
Format: String with a maximum of 64 characters.
Example: Security Audit Server Address: ""
Security Audit Server Port
Enter the port of the syslog server that the system shall send its audit logs to. A user with AUDIT
rights is required to change this setting.
Requires user role: AUDIT
Value space: <0..65535>
Range: Select a value from 0 to 65535.
Example: Security Audit Server Port: 514
Security Audit OnError Action
Describes what actions will be taken if connection to the syslog server is lost. A user with AUDIT
rights is required to change this setting.
Requires user role: AUDIT
Value space: <Halt/Ignore>
Halt: If the connection to the syslog server is lost for more than a few seconds, the system will
reboot and try to establish connection. If connection is restored, the audit logs are respooled to
the syslog server, and the system starts up again.
Ignore: The system will continue its normal operation, and rotate internal logs when full. When
connection is restored it will again send its audit logs to the syslog server.
Example: Security Audit OnError Action: Ignore
Security Audit Logging Mode
Describes where the audit logs are recorded or transmitted. A user with AUDIT rights is required to
change this setting.
Requires user role: AUDIT
Value space: <Off/Internal/External/ExternalSecure>
Off: No audit logging is performed.
Internal: The system records the audit logs to internal logs, and rotates logs when they are full.
External: The system sends the audit logs to an external audit server.
ExternalSecure: The system sends the audit logs to an external audit server that is verified by
the Audit CA list.
Example: Security Audit Logging Mode: Off
Page 59
59
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Security Session ShowLastLogon
When logging in to the system using SSH or Telnet you will see the UserId, time and date of the
last session that did a successful login.
Requires user role: ADMIN
Value space: <Off/On>
On: Set to On to enable the possibility to show information about the last session.
Off: Set to Off to disable the possibility to show information about the last session.
Example: Security Session ShowLastLogon: Off
Security Session InactivityTimeout
Determines how long the system will accept inactivity from the user before he is automatically
logged out.
Requires user role: ADMIN
Value space: <0..10000>
Range: Select a value from 0 to 10000 seconds. 0 means that inactivity will not enforce
automatically logout.
Example: Security Session InactivityTimeout: 0
The SerialPort settings
SerialPort Mode
Set the COM 1 serial port to be enabled/disabled.
Requires user role: ADMIN
Value space: <On/Off>
On: Enable the COM 1 serial port.
Off: Disable the COM 1 serial port.
Example: SerialPort Mode: On
SerialPort BaudRate
Specify the baud rate (data transmission rate, bits per second) for the COM 1 port on the codec.
The default value is 38400.
Connection parameters for the COM port: Data bits: 8; Parity: None; Stop bits: 1; Flow control:
None.
Requires user role: ADMIN
Value space: <9600/19200/38400/57600/115200>
Range: Select a baud rate from the baud rates listed (bps).
Example: SerialPort BaudRate: 38400
SerialPort LoginRequired
Determine if login shall be required when connecting to the COM 1 port at the codec.
Requires user role: ADMIN
Value space: <On/Off>
On: Login is required when connecting to the codec through COM 1 port.
Off: The user can access the codec through COM 1 port without any login.
Example: SerialPort LoginRequired: On
Page 60
60
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
The SIP settings
SIP Profile [1..1] URI
The SIP URI or number is used to address the system. This is the URI that is registered and used
by the SIP services to route inbound calls to the system. A Uniform Resource Identifier (URI) is a
compact string of characters used to identify or name a resource.
Requires user role: ADMIN
Value space: <S: 0, 255>
Format: Compact string with a maximum of 255 characters.
Example: SIP Profile 1 URI: "sip:firstname.lastname@company.com"
SIP Profile [1..1] DisplayName
When configured the incoming call will report the DisplayName instead of the SIP URI.
Requires user role: ADMIN
Value space: <S: 0, 255>
Format: String with a maximum of 255 characters.
Example: SIP Profile 1 DisplayName: ""
SIP Profile [1..1] Authentication [1..1] LoginName
This is the user name part of the credentials used to authenticate towards the SIP proxy.
Requires user role: ADMIN
Value space: <S: 0, 128>
Format: String with a maximum of 128 characters.
Example: SIP Profile 1 Authentication 1 LoginName: ""
SIP Profile [1..1] Authentication [1..1] Password
This is the password part of the credentials used to authenticate towards the SIP proxy.
Requires user role: ADMIN
Value space: <S: 0, 128>
Format: String with a maximum of 128 characters.
Example: SIP Profile 1 Authentication 1 Password:
SIP Profile [1..1] DefaultTransport
Select the transport protocol to be used over the LAN.
Requires user role: ADMIN
Value space: <UDP/TCP/Tls/Auto>
UDP: The system will always use UDP as the default transport method.
TCP: The system will always use TCP as the default transport method.
Tls: The system will always use TLS as the default transport method. For TLS connections a SIP
CA-list can be uploaded using the web interface. If no such CA-list is available on the system
then anonymous Diffie Hellman will be used.
Auto: The system will try to connect using transport protocols in the following order: TLS, TCP,
UDP.
Example: SIP Profile 1 DefaultTransport: Auto
SIP Profile [1..1] TlsVerify
For TLS connections a SIP CA-list can be uploaded using the web interface.
Requires user role: ADMIN
Value space: <On/Off>
On: Set to On to verify TLS connections. Only TLS connections to servers, whom x.509
certificate is validated against the CA-list, will be allowed.
Off: Set to Off to allow TLS connections without verifying them. The TLS connections are
allowed to be set up without verifying the x.509 certificate received from the server against the
local CA-list. This should typically be selected if no SIP CA-list has been uploaded.
Example: SIP Profile 1 TlsVerify: Off
SIP Profile [1..1] Outbound
The client initiated connections mechanism for firewall traversal, connection reuse and redundancy.
The current version supports http://tools.ietf.org/html/draft-ietf-sip-outbound-20.
Requires user role: ADMIN
Value space: <On/Off>
On: Set up multiple outbound connections to servers in the Proxy Address list.
Off: Connect to the single proxy configured first in Proxy Address list.
Example: SIP Profile 1 Outbound: Off
SIP Profile [1..1] Proxy [1..4] Address
The Proxy Address is the manually configured address for the outbound proxy. It is possible to
use a fully qualified domain name, or an IP address. The default port is 5060 for TCP and UDP but
another one can be provided. If Outbound is enabled, multiple proxies can be addressed.
Requires user role: ADMIN
Value space: <S: 0, 255>
Format: Compact string with a maximum of 255 characters. An IP address that contains letters
(192.a.2.0) or unvalid IP addresses (192.0.1234.0) will be rejected.
Example: SIP Profile 1 Proxy 1 Address: ""
Page 61
61
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
SIP Profile [1..1] Proxy [1..4] Discovery
Select if the SIP Proxy address is to be obtained manually or by using Dynamic Host Configuration
Protocol (DHCP).
Requires user role: ADMIN
Value space: <Auto/Manual>
Auto: When Auto is selected, the SIP Proxy address is obtained using Dynamic Host
Configuration Protocol (DHCP).
Manual: When Manual is selected, the manually configured SIP Proxy address will be used.
Example: SIP Profile 1 Proxy 1 Discovery: Manual
SIP Profile [1..1] Type
Enables SIP extensions and special behaviour for a vendor or provider.
Requires user role: ADMIN
Value space: <Standard/Alcatel/Avaya/Cisco/Microsoft/Nortel>
Standard: To be used when registering to standard SIP Proxy (tested with Cisco TelePresence
VCS and Broadsoft)
Alcatel: To be used when registering to Alcatel-Lucent OmniPCX Enterprise. NOTE: This mode
is not fully supported.
Avaya: To be used when registering to Avaya Communication Manager. NOTE: This mode is not
fully supported.
Cisco: To be used when registering to Cisco Unified Communication Manager.
Microsoft: To be used when registering to Microsoft LCS or OCS. NOTE: This mode is not fully
supported.
Nortel: To be used when registering to Nortel MCS 5100 or MCS 5200 PBX. NOTE: This mode
is not fully supported.
Example: SIP Profile 1 Type: Standard
The Standby settings
Standby Control
Determine whether the system should go into standby mode or not.
Requires user role: ADMIN
Value space: <On/Off>
On: Enter standby mode when the Standby Delay has timed out. NOTE: Requires the Standby
Delay to be set to an appropriate value.
Off: The system will not enter standby mode.
Example: Standby Control: On
Standby Delay
Define how long (in minutes) the system shall be in idle mode before it goes into standby mode.
NOTE: Requires the Standby Control to be enabled.
Requires user role: ADMIN
Value space: <1..480>
Range: Select a value from 1 to 480 minutes.
Example: Standby Delay: 10
Standby BootAction
Define the camera position after a restart of the codec.
Requires user role: ADMIN
Value space: <None/Preset1/Preset2/Preset3/Preset4/Preset5/Preset6/Preset7/
Preset8/Preset9/Preset10/Preset11/Preset12/Preset13/Preset14/Preset15/
RestoreCameraPosition/DefaultCameraPosition>
None: No action.
Preset1 to Preset15: After a reboot the camera position will be set to the position defined by
the selected preset.
RestoreCameraPosition: After a reboot the camera position will be set to the position it had
before the last boot.
DefaultCameraPosition: After a reboot the camera position will be set to the factory default
position.
Example: Standby BootAction: DefaultCameraPosition
Standby StandbyAction
Define the camera position when going into standby mode.
Requires user role: ADMIN
Value space: <None/PrivacyPosition>
None: No action.
PrivacyPosition: Turns the camera to a sideways position for privacy.
Example: Standby StandbyAction: PrivacyPosition
Page 62
62
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Standby WakeupAction
Define the camera position when leaving standby mode.
Requires user role: ADMIN
Value space: <None/Preset1/Preset2/Preset3/Preset4/Preset5/Preset6/Preset7/
Preset8/Preset9/Preset10/Preset11/Preset12/Preset13/Preset14/Preset15/
RestoreCameraPosition/DefaultCameraPosition>
None: No action.
Preset1 to Preset15: When leaving standby the camera position will be set to the position
defined by the selected preset.
RestoreCameraPosition: When leaving standby the camera position will be set to the position it
had before entering standby.
DefaultCameraPosition: When leaving standby the camera position will be set to the factory
default position.
Example: Standby WakeupAction: RestoreCameraPosition
The SystemUnit settings
SystemUnit Name
Enter a System Name to define a name of the system unit. If the H.323 Alias ID is configured
on the system then this ID will be used instead of the system name. The system name will be
displayed:
1) When the codec is acting as an SNMP Agent.
2) Towards a DHCP server.
Requires user role: ADMIN
Value space: <S: 0, 50>
Format: String with a maximum of 50 characters.
Example: SystemUnit Name: "Meeting Room"
SystemUnit MenuLanguage
Select the language to be used in the menus on screen.
Requires user role: USER
Value space: <English/ChineseSimplified/ChineseTraditional/Czech/Danish/
Dutch/Finnish/French/German/Hungarian/Italian/Japanese/Korean/Norwegian/
Polish/PortugueseBrazilian/Russian/Spanish/SpanishLatin/Swedish/Turkish>
Example: SystemUnit MenuLanguage: English
SystemUnit ContactInfo Type
Describes which parameter to put in the status field in the upper left corner on the screen display.
The information can also be read with the command xStatus SystemUnit ContactInfo.
Requires user role: ADMIN
Value space: <Auto/None/IPv4/IPv6/H323Id/E164Alias/SipUri/SystemName>
Auto: Shows the address which another system can dial to reach this system, depending on the
default call protocol and system registration.
None: Do not show any contact information.
IPv4: Shows the IPv4 address as the contact information.
IPv6: Shows the IPv6 address as the contact information.
H323Id: Shows the H323 ID as the contact information.
E164Alias: Shows the H323 E164 Alias as the contact information.
SipUri: Shows the SIP URI as the contact information.
SystemName: Shows the system name as the contact information.
Example: SystemUnit ContactInfo Type: Auto
Page 63
63
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
SystemUnit Type
Select whether the video system is for personal use or to be used in a multiuser environment. It is
highly recommended not to use the default setting.
Requires user role: ADMIN
Value space: <Personal/Shared>
Personal: Set to Personal when the system is for personal use.
Shared: Set to Shared when the system is used in a multiuser environment.
Example: SystemUnit Type: Shared
SystemUnit CallLogging Mode
Set the call logging mode for calls that are received or placed by the system. The call logs may
then be viewed via the web interface or using the xHistory command.
Requires user role: ADMIN
Value space: <On/Off>
On: Enable logging.
Off: Disable logging.
Example: SystemUnit CallLogging Mode: On
SystemUnit IrSensor
Both the Codec C Series and PrecisionHD camera have IR sensors, and only one of them needs to
be enabled at the time. The IR sensor LED is located on the front of the codec and the camera and
flickers when an IR signal is received from the remote control.
Requires user role: ADMIN
Value space: <On/Off/Auto>
On: Enable the IR sensor on the codec.
Off: Disable the IR sensor on the codec.
Auto: The system will automatically disable the IR sensor on the codec if the IR sensor at
camera is enabled. Otherwise, the IR sensor on the codec will be enabled.
Example: SystemUnit IrSensor: Auto
The Time settings
Time Zone
Set the time zone where the system is located, using Windows time zone description format.
Requires user role: USER
Value space: <GMT-12:00 (International Date Line West)/GMT-11:00 (Midway
Island, Samoa)/GMT-10:00 (Hawaii)/GMT-09:00 (Alaska)/GMT-08:00 (Pacific
Time (US & Canada); Tijuana)/GMT-07:00 (Arizona)/GMT-07:00 (Mountain Time
(US & Canada))/GMT-07:00 (Chihuahua, La Paz, Mazatlan)/GMT-06:00 (Central
America)/GMT-06:00 (Saskatchewan)/GMT-06:00 (Guadalajara, Mexico City,
Monterrey)/GMT-06:00 (Central Time (US & Canada))/GMT-05:00 (Indiana
(East))/GMT-05:00 (Bogota, Lima, Quito)/GMT-05:00 (Eastern Time (US &
Canada))/GMT-04:30 (Caracas)/GMT-04:00 (La Paz)/GMT-04:00 (Santiago)/
GMT-04:00 (Atlantic Time (Canada))/GMT-03:30 (Newfoundland)/GMT-03:00
(Buenos Aires, Georgetown)/GMT-03:00 (Greenland)/GMT-03:00 (Brasilia)/
GMT-02:00 (Mid-Atlantic)/GMT-01:00 (Cape Verde Is.)/GMT-01:00 (Azores)/
GMT (Casablanca, Monrovia)/GMT (Coordinated Universal Time)/GMT (Greenwich
Mean Time : Dublin, Edinburgh, Lisbon, London)/GMT+01:00 (West Central
Africa)/GMT+01:00 (Amsterdam, Berlin, Bern, Rome, Stockholm, Vienna)/
GMT+01:00 (Brussels, Copenhagen, Madrid, Paris)/GMT+01:00 (Sarajevo,
Skopje, Warsaw, Zagreb)/GMT+01:00 (Belgrade, Bratislava, Budapest,
Ljubljana, Prague)/GMT+02:00 (Harare, Pretoria)/GMT+02:00 (Jerusalem)/
GMT+02:00 (Athens, Istanbul, Minsk)/GMT+02:00 (Helsinki, Kyiv, Riga,
Sofia, Tallinn, Vilnius)/GMT+02:00 (Cairo)/GMT+02:00 (Bucharest)/
GMT+03:00 (Nairobi)/GMT+03:00 (Kuwait, Riyadh)/GMT+03:00 (Moscow, St.
Petersburg, Volgograd)/GMT+03:00 (Baghdad)/GMT+03:30 (Tehran)/GMT+04:00
(Abu Dhabi, Muscat)/GMT+04:00 (Baku, Tbilisi, Yerevan)/GMT+04:30 (Kabul)/
GMT+05:00 (Islamabad, Karachi, Tashkent)/GMT+05:00 (Ekaterinburg)/
GMT+05:30 (Chennai, Kolkata, Mumbai, New Delhi)/GMT+05:45 (Kathmandu)/
GMT+06:00 (Sri Jayawardenepura)/GMT+06:00 (Astana, Dhaka)/GMT+06:00
(Almaty, Novosibirsk)/GMT+06:30 (Rangoon)/GMT+07:00 (Bangkok, Hanoi,
Jakarta)/GMT+07:00 (Krasnoyarsk)/GMT+08:00 (Perth)/GMT+08:00 (Taipei)/
GMT+08:00 (Kuala Lumpur, Singapore)/GMT+08:00 (Beijing, Chongqing,
Hong Kong, Urumqi)/GMT+08:00 (Irkutsk, Ulaan Bataar)/GMT+09:00 (Osaka,
Sapporo, Tokyo)/GMT+09:00 (Seoul)/GMT+09:00 (Yakutsk)/GMT+09:30 (Darwin)/
GMT+09:30 (Adelaide)/GMT+10:00 (Guam, Port Moresby)/GMT+10:00 (Brisbane)/
GMT+10:00 (Vladivostok)/GMT+10:00 (Hobart)/GMT+10:00 (Canberra, Melbourne,
Sydney)/GMT+11:00 (Magadan, Solomon Is., New Caledonia)/GMT+12:00 (Fiji,
Kamchatka, Marshall Is.)/GMT+12:00 (Auckland, Wellington)/GMT+13:00 (Nuku
alofa)>
Range: Select a time zone from the list time zones. If using a command line interface; watch up
for typos.
Example: Time Zone: "GMT (Greenwich Mean Time : Dublin, Edinburgh, Lisbon,
London)"
Page 64
64
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Time TimeFormat
Set the time format.
Requires user role: USER
Value space: <24H/12H>
24H: Set the time format to 24 hours.
12H: Set the time format to 12 hours (AM/PM).
Example: Time TimeFormat: 24H
Time DateFormat
Set the date format.
Requires user role: USER
Value space: <DD_MM_YY/MM_DD_YY/YY_MM_DD>
DD_MM_YY: The date January 30th 2010 will be displayed: 30.01.10
MM_DD_YY: The date January 30th 2010 will be displayed: 01.30.10
YY_MM_DD: The date January 30th 2010 will be displayed: 10.01.30
Example: Time DateFormat: DD_MM_YY
The Video settings
Video Input Source [1..3] Name
Enter a name for the video input source.
Requires user role: ADMIN
Value space: <S: 0, 50>
Format: String with a maximum of 50 characters.
Example: Video Input Source 1 Name: ""
Video Input Source [1] Connector
Select which video input connector to be active on video input source 1.
Requires user role: ADMIN
Value space: <HDMI>
HDMI: Select HDMI when you want to use the HDMI 1 as input source 1.
Example: Video Input Source 1 Connector: HDMI
Video Input Source [2] Connector
NOTE: Codec C40 has one DVI input (DVI-I 3). Codec C60 has two DVI inputs (DVI-I 2 and 3).
Select which video input connector to be active on video input source 2.
Requires user role: ADMIN
Value space: <HDMI/DVI>
HDMI: Select HDMI when you want to use the HDMI 2 as input source 2.
DVI: Select DVI-I when you want to use the DVI-I 2 as input source 2.
Example: Video Input Source 2 Connector: HDMI
Video Input Source [3] Connector
NOTE: Codec C40 has one DVI input (DVI-I 3). Codec C60 has two DVI inputs (DVI-I 2 and 3).
Select which video input connector to be active on video input source 3.
Requires user role: ADMIN
Value space: <DVI/Composite/YC>
DVI: Select DVI-I when you want to use the DVI-I 3 as input source 3.
Composite: Select Composite when you want to use the Composite as input source 3.
YC: Select YC when you want to use the S-Video (YC) as input source 3. Connect to the two
connectors marked Y/Comp and C.
Example: Video Input Source 3 Connector: DVI
Page 65
65
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Video Input Source [1..3] Type
Set which type of input source is connected to the video input.
Requires user role: ADMIN
Value space: <other/camera/PC/DVD/document_camera>
Other: Select Other when some other type of equipment is connected to the selected video
input.
Camera: Select Camera when you have a camera connected to the selected video input.
PC: Select PC when you have a PC connected to the selected video input.
DVD: Select DVD when you have a DVD player connected to the selected video input.
Document_Camera: Select Document_Camera when you have a document camera connected
to the selected video input.
Example: Video Input Source 1 Type: PC
Video Input Source [1..3] CameraControl Mode
Set the camera control mode for the camera associated with the video source.
Requires user role: ADMIN
Value space: <On/Off>
On: Enable camera control.
Off: Disable camera control.
Example: Video Input Source 1 CameraControl Mode: On
Video Input Source [1..3] CameraControl CameraId
Select the ID of the camera in the Visca chain that is connected to this camera source. The
CameraId setting represents the camera's position in the Visca chain.
Requires user role: ADMIN
Value space: <1..5>
Range: Select the ID of the camera in the Visca chain.
Example: Video Input Source 1 CameraControl CameraId: 1
Video Input Source [1..3] OptimalDefinition Profile
Adjust how rapidly the system will increase the transmitted resolution when increasing the
bandwidth. NOTE: Requires that the Video Input Source Quality is set to Motion.
Normal: Use this setting for normal to poorly lit environment. If the source is a camera with
1920x1080p60, the system will transmit 1920x720p60 at about 2.2Mb/sec and above with this
setting set to normal.
Medium: Requires better than normal and consistent lighting and good quality video inputs. If the
source is a camera with 1920x1080p60, the system will transmit 1920x720p60 at about 1.4Mb/
sec and above with this setting set to medium.
High: Requires good lighting conditions for a good overall experience and good quality video
inputs. If the source is a camera with 1920x1080p60, the system will transmit 1920x720p60 at
about 1.1Mb/sec and above with this setting set to high.
Requires user role: ADMIN
Value space: <Normal/Medium/High>
Ref: Table 1 and Table 2.
Example: Video Input Source 1 OptimalDefinition Profile: Normal
.
Video Input Source [1..3] OptimalDefinition Threshold60fps
For each video input, this setting tells the system the lowest resolution where it should transmit
60fps. So for all resolutions lower than this, the maximum transmitted framerate would be 30fps,
while above this resolution 60fps would also be possible, if the available bandwidth is adequate.
Requires user role: ADMIN
Value space: <512_288/768_448/1024_576/1280_720/Never>
512_288: Set the threshold to 512x288.
768_448: Set the threshold to 768x448.
1024_576: Set the threshold to 1024x576.
1280_720: Set the threshold to 1280x720.
Never: Do not set a threshold for transmitting 60fps.
Example: Video Input Source 1 OptimalDefinition Threshold60fps: 1280_720
Table 1: Optimal definition for systems supporting 1080p
w288p30 w448p30 w576p30 720p30 1080p30
Normal 256 kbit/s 512 kbit/s 768 kbit/s 1152 kbit/s 2560 kbit/s
Medium 128 kbit/s 384 kbit/s 512 kbit/s 1152 kbit/s 1920 kbit/s
High 128 kbit/s 256 kbit/s 512 kbit/s 768 kbit/s 1472 kbit/s
Table 2: Optimal definition for systems supporting 720p60
w144p60 w288p60 w448p60 w576p60 720p60
Normal 128 kbit/s 512 kbit/s 1152 kbit/s 1472 kbit/s 2240 kbit/s
Medium 128 kbit/s 384 kbit/s 768 kbit/s 1152 kbit/s 1920 kbit/s
High 128 kbit/s 256 kbit/s 512 kbit/s 768 kbit/s 1152 kbit/s
Page 66
66
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Video Input Source [1..3] Quality
When encoding and transmitting video there will be a tradeoff between high resolution and high
framerate. For some video sources it is more important to transmit high framerate than high
resolution and vice versa. The Quality setting specifies whether to give priority to high frame rate or
to high resolution for a given source.
Requires user role: ADMIN
Value space: <Motion/Sharpness>
Motion: Gives the highest possible framerate. Used when there is a need for higher frame rates,
typically when a large number of participants are present or when there is a lot of motion in the
picture.
Sharpness: Gives the highest possible resolution. Used when you want the highest quality of
detailed images and graphics.
Example: Video Input Source 1 Quality: Motion
Video DefaultPresentationSource
Define which video input source shall be used as the default presentation source (when you
press the Presentation key on the remote control). The input source is configured to a video input
connector.
Requires user role: USER
Value space: <1..5>
Range: Select the video source to be used as the presentation source.
Example: Video DefaultPresentationSource: 3
Video Input DVI [3]/[2..3] Type
NOTE: Codec C40 has one DVI input (DVI-I 3). Codec C60 has two DVI inputs (DVI-I 2 and 3).
The official DVI standard supports both digital and analog signals. In most cases the default
AutoDetect setting can detect whether the signal is analog RGB or digital. However, in some rare
cases when DVI-I cables are used (these cables can carry both the analog and digital signals) the
auto detection fails. This setting makes it possible to override the AutoDetect and select the correct
DVI video input.
This setting should also be used if the video input is an analog component (YPbPr) type signal. This
is used by some cameras (Sony EVI-HD1) and DVD/Blu-ray players. Since it is not possible to auto
detect the difference between AnalogRGB and AnalogYPbPr, the AnalogYPbPr setting must be
selected.
Requires user role: ADMIN
Value space: <AutoDetect/Digital/AnalogRGB/AnalogYPbPr>
AutoDetect: Set to AutoDetect to automatically detect if the signal is analog RGB or digital.
Digital: Set to Digital to force the DVI video input to Digital when using DVI-I cables with both
analog and digital pins and AutoDetect fails.
AnalogRGB: Set to AnalogRGB to force the DVI video input to AnalogRGB when using DVI-I
cables with both analog and digital pins and AutoDetect fails.
AnalogYPbPr: Set to AnalogYPbPr to force the DVI video input to AnalogYPbPr, as the
component (YPbPr) signal cannot be auto detected.
Example: Video Input DVI 3 Type: AutoDetect
Video Layout Scaling
Define how the system shall adjust the aspect ratio for images or frames when there is a difference
between the image and the frame it is to be placed in.
Requires user role: ADMIN
Value space: <On/Off>
On: Let the system automatically adjust aspect ratio.
Off: No adjustment of the aspect ratio.
Example: Video Layout Scaling: On
Page 67
67
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Video Layout ScaleToFrame
Define what to do if the aspect ratio of a video input source doesn't match the aspect ratio of the
corresponding image frame in a composition. For example if you have a 4:3 input source (like XGA)
to be displayed on a 16:9 output (like HD720).
Requires user role: ADMIN
Value space: <Manual/MaintainAspectRatio/StretchToFit>
Manual: If the difference in aspect ratio between the video input source and the target image
frame is less than the ScaleToFrameThreshold configuration (in percent), the image is stretched
to fit. If not, the system will maintain the original aspect ratio.
MaintainAspectRatio: Will maintain the aspect ratio of the input source, and fill in black in the
rest of the frame (letter boxing or pillar boxing).
StretchToFit: Will stretch (horizontally or vertically) the input source to fit into the image frame.
NOTE: The general limitation is that you cannot upscale in one direction and at the same time
downscale in the other direction. In such situations the codec will apply letterboxing.
Example: Video Layout ScaleToFrame: MaintainAspectRatio
Video Layout ScaleToFrameThreshold
Only applicable if the ScaleToFrame configuration is set to manual. If the difference in
aspect ratio between the video input source and the target image frame is less than the
ScaleToFrameThreshold configuration (in percent), the image is stretched to fit. If not, the system
will maintain the original aspect ratio.
Requires user role: ADMIN
Value space: <0..100>
Range: Select a value from 0 to 100 percent.
Example: Video Layout ScaleToFrameThreshold: 5
Video SelfviewPosition
Select where the small selfview PiP (Picture-in-Picture) will appear on screen.
Requires user role: ADMIN
Value space: <UpperLeft/UpperRight/LowerLeft/LowerRight/CenterRight>
UpperLeft: The selfview PiP will appear in the upper left corner of the screen.
UpperRight: The selfview PiP will appear in the upper right corner of the screen.
LowerLeft: The selfview PiP will appear in the lower left corner of the screen.
LowerRight: The selfview PiP will appear in the lower right corner of the screen.
CenterRight: The selfview PiP will appear in to the right side of the screen, in center.
Example: Video SelfviewPosition: LowerRight
Video Layout LocalLayoutFamily
Select which video layout family to be used locally.
Requires user role: ADMIN
Value space: <Auto/FullScreen/Equal/PresentationSmallSpeaker/
PresentationLargeSpeaker>
Auto: The default layout family, as given by the layout database, will be used as the local layout.
For more information about the layout database, see the command: xCommand Video Layout
LoadDb.
FullScreen: The FullScreen layout family will be used as the local layout.
Equal: The Equal layout family will be used as the local layout.
PresentationSmallSpeaker: The PresentationSmallSpeaker layout family will be used as the local
layout.
PresentationLargeSpeaker: The PresentationLargeSpeaker layout family will be used as the local
layout.
Example: Video Layout LocalLayoutFamily: Auto
Video Layout RemoteLayoutFamily
Select which video layout family to be used for the remote participants.
Requires user role: ADMIN
Value space: <Auto/FullScreen/Equal/PresentationSmallSpeaker/
PresentationLargeSpeaker>
Auto: The default layout family, as given by the local layout database, will be used as the remote
layout. For more information about the layout database, see the command: xCommand Video
Layout LoadDb.
FullScreen: The FullScreen layout family will be used as the remote layout.
Equal: The Equal layout family will be used as the remote layout.
PresentationSmallSpeaker: The PresentationSmallSpeaker layout family will be used as the
remote layout.
PresentationLargeSpeaker: The PresentationLargeSpeaker layout family will be used as the
remote layout.
Example: Video Layout RemoteLayoutFamily: Auto
Video MainVideoSource
Define which video input source shall be used as the main video source.
Requires user role: USER
Value space: <1..3>
Range: Select the source to be used as the main video source.
Example: Video MainVideoSource: 1
Page 68
68
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Video Monitors
Set the monitor layout mode.
Requires user role: ADMIN
Value space: <Single/Dual/DualPresentationOnly>
Single: The same layout is shown on all monitors.
Dual: The layout is distributed on two monitors.
DualPresentationOnly: All participants in the call will be shown on the first monitor, while the
presentation (if any) will be shown on the second monitor.
Example: Video Monitors: Single
Video OSD Mode
The Video OSD (On Screen Display) Mode lets you define if information and icons should be
displayed on screen.
Requires user role: ADMIN
Value space: <On/Off>
On: Display the on screen menus, icons and indicators.
Off: Hide the on screen menus, icons and indicators.
Example: Video OSD Mode: On
Video OSD AutoSelectPresentationSource
Determine if the presentation source should be automatically selected.
Requires user role: ADMIN
Value space: <On/Off>
On: Enable automatic selection of the presentation source.
Off: Disable automatic selection of the presentation source.
Example: Video OSD AutoSelectPresentationSource: Off
Video OSD TodaysBookings
This setting can be used to display the systems bookings for today on the main OSD menu. This
requires that the system is bookable by an external booking system, like Cisco TelePresence
Management Suite (TMS).
Requires user role: ADMIN
Value space: <On/Off>
On: Displays information about this systems bookings on screen.
Off: Do not display todays bookings.
Example: Video OSD TodaysBookings: Off
Video OSD MyContactsExpanded
Set how the local contacts will be displayed in the phone book dialog in the OSD (On Screen
Display).
Requires user role: ADMIN
Value space: <On/Off>
On: The local contacts in the phone book will be shown in the top level of the phonebook dialog.
Off: The local contacts will be placed in a separate folder called MyContacts in the phonebook
dialog.
Example: Video OSD MyContactsExpanded: Off
Video OSD Output
The Video OSD (On Screen Display) Output lets you define which monitor should display the on
screen menus, information and icons. By default the OSD is sent to the monitor connected to the
Video OSD Output 1. If you cannot see the OSD on screen, then you must re-configure the OSD
Output. You can do this by entering a key sequence on the remote control, from the web interface,
or by a command line interface.
Using the remote control: Press the Disconnect key followed by: * # * # 0 x # (where x is output 1
to 2).
Using the web interface: Open a web browser and enter the IP address of the codec. Open the
Advanced Configuration menu and navigate to Video OSD Output and select the video output.
Using a command line interface: Open a command line interface and connect to the codec (if in
doubt of how to do this, see the API Guide for the codec). Enter the command: xConfiguration
Video OSD Output [1..2] (select the OSD Output)
Requires user role: ADMIN
Value space: <1..2>
Range: Select 1 for HDMI 1 output, or select 2 for DVI-I 2 output.
Example: Video OSD Output: 1
Video OSD InputMethod InputLanguage
The codec can be enabled for Cyrillic input characters in the menus on screen. NOTE: Requires
that xConfiguration Video OSD inputMethod Cyrillic is set to On.
Requires user role: ADMIN
Value space: <Latin/Cyrillic>
Latin: Latin characters can be entered when using the remote control (default).
Cyrillic: Cyrillic characters can be entered using the remote control. NOTE: Requires a Cisco
TelePresence Remote Control with Cyrillic fonts.
Example: Video OSD InputMethod InputLanguage: Latin
Page 69
69
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Video OSD InputMethod Cyrillic
Set the Cyrillic mode for the menu input language in the menus on screen.
Requires user role: ADMIN
Value space: <On/Off>
On: Cyrillic mode is available as a menu input language in the menus on screen. This will enable
the setting xConfiguration Video OSD InputMethod InputLanguage.
Off: Cyrillic mode is NOT available as a menu input language in the menus on screen.
Example: Video OSD InputMethod Cyrillic: Off
Video OSD LoginRequired
Determine if the system should require the user to login before accessing the On Screen Display
(OSD). If enabled, the user must enter his username and his PIN. After the user has logged in he
can only execute to the configurations changes and commands allowed by his Role.
Requires user role: ADMIN
Value space: <On/Off>
On: The user must log in to access the On Screen Display (OSD).
Off: No login to the OSD is required.
Example: Video OSD LoginRequired: Off
Video AllowWebSnapshots
Set if the system shall be allowed to generate a web snapshot of the video input main source.
To generate and view the snapshot you must open a web browser, enter the IP address of the
codec, login to the Web interface, select Snapshot from the left menu, and press the button "Get
snapshot".
NOTE: This is a local setting which is available only from the On Screen Display (OSD) and when
connected directly to the serial port (COM 1 port) on the codec.
Requires user role: ADMIN
Value space: <On/Off>
On: If set to on, a web snapshot can be generated and displayed on the web page under
"Snapshot".
Off: The generation of web snapshots is not allowed.
Example: Video AllowWebSnapshots: Off
Video Output HDMI [1] CEC Mode
The HDMI outputs support Consumer Electronics Control (CEC). When set to on (default is off),
and the monitor connected to the HDMI output is CEC compatible and CEC is configured, the
system will use CEC to set the monitor in standby when the system enters standby. Likewise the
system will wake up the monitor when the system wakes up from standby. Please note that the
different manufacturers uses different marketing names for CEC: Anynet+ (Samsung); Aquos Link
(Sharp); BRAVIA Sync (Sony); HDMI-CEC (Hitachi); Kuro Link (Pioneer); CE-Link and Regza Link
(Toshiba); RIHD (Onkyo); SimpLink (LG); HDAVI Control, EZ-Sync, VIERA Link (Panasonic); EasyLink
(Philips); and NetCommand for HDMI (Mitsubishi).
Requires user role: ADMIN
Value space: <On/Off>
On: Enable CEC control.
Off: Disable CEC control.
Example: Video Output HDMI 1 CEC Mode: Off
Video Output HDMI [1] MonitorRole
The HDMI monitor role describes what video stream will be shown on the monitor connected to the
video output HDMI connector. Applicable only if the "Video > Monitors" configuration is set to dual.
Requires user role: ADMIN
Value space: <First/Second/PresentationOnly>
First: Show main video stream.
Second: Show presentation video stream if active, or other participants.
PresentationOnly: Show presentation video stream if active, and nothing else.
Example: Video Output HDMI 1 MonitorRole: First
Video Output HDMI [1] OverscanLevel
Some TVs or other monitors may not display the whole image sent out on the systems video
output, but cuts the outer parts of the image. In this case this setting can be used to let the system
not use the outer parts of video resolution. Both the video and the OSD menu will be scaled in this
case.
Requires user role: ADMIN
Value space: <Medium/High/None>
Medium: The system will not use the outer 3% of the output resolution.
High: The system will not use the outer 6% of the output resolution
None: The system will use all of the output resolution.
Example: Video Output HDMI 1 OverscanLevel: None
Page 70
70
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Video Output HDMI [1] Resolution
Select the preferred resolution for the monitor connected to the video output HDMI connector. This
will force the resolution on the monitor.
Requires user role: ADMIN
Value space: <Auto/640_480_60/800_600_60/1024_768_60/1280_1024_60/1280_720_5
0/1280_720_60/1920_1080_50/1920_1080_60/1280_768_60/1360_768_60/1366_768_6
0/1600_1200_60/1920_1200_60>
Auto: The system will automatically try to set the optimal resolution based on negotiation with
the connected monitor.
Range: 640x480@60p, 800x600@60p, 1024x768@60p, 1280x1024@60p, 1280x720@50p,
1280x720@60p, 1920x1080@50p, 1920x1080@60p, 1280x768@60p, 1360x768@60p,
1366x768@60p, 1600x1200@60p, 1920x1200@60p
Example: Video Output HDMI 1 Resolution: 1920_1080_60
Video Output DVI [2] MonitorRole
The DVI monitor role describes what video stream will be shown on the monitor connected to the
video output DVI-I connector. Applicable only if the "Video > Monitors" configuration is set to dual.
Requires user role: ADMIN
Value space: <First/Second/PresentationOnly>
First: Show main video stream.
Second: Show presentation video stream if active, or other participants.
PresentationOnly: Show presentation video stream if active, and nothing else.
Example: Video Output DVI 2 MonitorRole: Second
Video Output DVI [2] OverscanLevel
Some TVs or other monitors may not display the whole image sent out on the systems video
output, but cuts the outer parts of the image. In this case this setting can be used to let the system
not use the outer parts of video resolution. Both the video and the OSD menu will be scaled in this
case.
Requires user role: ADMIN
Value space: <Medium/High/None>
Medium: The system will not use the outer 3% of the output resolution.
High: The system will not use the outer 6% of the output resolution
None: The system will use all of the output resolution.
Example: Video Output DVI 2 OverscanLevel: None
Video Output DVI [2] Resolution
Select the preferred resolution for the monitor connected to the video output DVI-I connector. This
will force the resolution on the monitor.
Requires user role: ADMIN
Value space: <Auto/640_480_60/800_600_60/1024_768_60/1280_1024_60/1280_720_5
0/1280_720_60/1920_1080_50/1920_1080_60/1280_768_60/1360_768_60/1366_768_6
0/1600_1200_60/1920_1200_60>
Auto: The system will automatically try to set the optimal resolution based on negotiation with
the connected monitor.
Range: 640x480@60p, 800x600@60p, 1024x768@60p, 1280x1024@60p, 1280x720@50p,
1280x720@60p, 1920x1080@50p, 1920x1080@60p, 1280x768@60p, 1360x768@60p,
1366x768@60p, 1600x1200@60p, 1920x1200@60p
Example: Video Output DVI 2 Resolution: 1024_768_60
Video Output Composite [3] MonitorRole
NOTE: This command is not supported on Codec C40.
The Composite monitor role describes what video stream will be shown on the monitor connected
to the video output Composite connector. Applicable only if the monitor configuration is set to dual.
Requires user role: ADMIN
Value space: <First/Second/PresentationOnly>
First: Show main video stream.
Second: Show presentation video stream if active, or other participants.
PresentationOnly: Show presentation video stream if active, and nothing else.
Example: Video Output Composite 3 MonitorRole: First
Video Output Composite [3] OverscanLevel
NOTE: This command is not supported on Codec C40.
Some TVs or other monitors may not display the whole image sent out on the systems video
output, but cuts the outer parts of the image. In this case this setting can be used to let the system
not use the outer parts of video resolution. Both the video and the OSD menu will be scaled in this
case.
Requires user role: ADMIN
Value space: <Medium/High/None>
Medium: The system will not use the outer 3% of the output resolution.
High: The system will not use the outer 6% of the output resolution
None: The system will use all of the output resolution.
Example: Video Output Composite 3 OverscanLevel: None
Page 71
71
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Video Output Composite [3] Resolution
NOTE: This command is not supported on Codec C40.
Select the preferred resolution for the monitor connected to the video output Composite
connector. This will force the resolution on the monitor.
Requires user role: ADMIN
Value space: <PAL/NTSC>
Range: PAL, NTSC
Example: Video Output Composite 3 Resolution: NTSC
Video Selfview
Determine if the main video source (selfview) shall be displayed on screen.
Requires user role: USER
Value space: <On/Off>
On: Display selfview on screen.
Off: Do not display selfview on screen.
Example: Video Selfview: On
Video WallPaper
Determine if a background picture should be displayed on screen when idle.
Requires user role: USER
Value space: <None/Growing/Summersky/Custom>
None: No wallpaper will be displayed on screen.
Summersky, Growing: Select one of the predefined wallpapers to be displayed on screen.
Custom: The custom wallpaper must be uploaded to the codec from the web interface before
selecting Custom. The maximum supported resolution is 1920x1280.
1) On the video system: Find the IP address of the codec. Open the menu on screen and go to
Home > Settings > System information to find the IP Address.
2) On your computer: Open a web browser and enter the IP address of the codec. Select
"Wallpaper" from the menu, browse for the file, and press the "Upload" button.
3) On the video system: Open the menu on screen and go to Home > Settings > Wallpaper >
Custom. Give it a few seconds to display the new picture. If the picture does not show, toggle
once between "None" and "Custom" wallpaper to make the change take effect.
Example: Video Wallpaper: Summersky
The Experimental settings
The Experimental settings are beta preview features and can be used 'as is'. They are not fully
documented.
NOTE: The Experimental settings are likely to change without further notice.
Experimental Audio EcReferenceDelay
NOTE: This Experimental command can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
Requires user role: ADMIN
Value space: <0..300>
Example: Experimental Audio EcReferenceDelay: 0
Experimental Audio Input Microphone [1..2]/[1..4] EchoControl HighPassFilter
NOTE: This Experimental command can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
NOTE: Codec C40 has two microphone connectors. Codec C60 has four microphone connectors.
Requires user role: ADMIN
Value space: <On/Off>
Example: Experimental Audio Input Microphone 1 EchoControl HighPassFilter:
Off
Experimental Audio Input Microphone [1..2]/[1..4] EchoControl ResidualEchoMasking
NOTE: This Experimental command can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
NOTE: Codec C40 has two microphone connectors. Codec C60 has four microphone connectors.
Requires user role: ADMIN
Value space: <Normal/Aggressive>
Example: Experimental Audio Input Microphone 1 EchoControl
ResidualEchoMasking: Normal
Page 72
72
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Experimental Audio Input Microphone [1..2]/[1..4] Channel
NOTE: This Experimental command can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
NOTE: Codec C40 has two microphone connectors. Codec C60 has four microphone connectors.
Defines whether the signal from the microphone is a mono signal or part of a multichannel signal.
Requires user role: ADMIN
Value space: <Left/Right/Mono>
Left: The microphone signal is the left channel of a stereo signal.
Right: The microphone signal is the right channel of a stereo signal.
Mono: The microphone signal is a mono signal.
Example: Experimental Audio Input Microphone 1 Channel: Mono
Experimental Audio MicrophoneReinforcement Gain
NOTE: This Experimental command can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
Microphone reinforcement is local amplification of one or several input connectors, directly to one
or several output connectors, with minimum delay.
For software version TC4.0: Microphone reinforcement should not be enabled on a codec that is
also configured using the Audio Console application.
This setting configures the gain of this path, from -53 dB to +15 dB. The value -54 corresponds to
mute.
Requires user role: ADMIN
Value space: <-54..15>
Example: Experimental Audio MicrophoneReinforcement Gain: -19
Experimental Audio MicrophoneReinforcement AGC
NOTE: This Experimental command can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
Microphone reinforcement is local amplification of one or several input connectors, directly to one
or several output connectors, with minimum delay.
For software version TC4.0: Microphone reinforcement should not be enabled on a codec that is
also configured using the Audio Console application.
This setting controls an AGC on the mix of all input connectors attached to the Microphone
reinforcement.
Requires user role: ADMIN
Value space: <On/Off>
Example: Experimental Audio MicrophoneReinforcement AGC: Off
Experimental Audio MicrophoneReinforcement Input Microphone [1..4] Mode
NOTE: This Experimental command can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
Microphone reinforcement is local amplification of one or several input connectors, directly to one
or several output connectors, with minimum delay.
For software version TC4.0: Microphone reinforcement should not be enabled on a codec that is
also configured using the Audio Console application.
Configuring this setting to On for a microphone, means to attach it to the microphone
reinforcement for local amplification. This is done in parallel to the microphone's existing
connections, and will not affect any of these.
Requires user role: ADMIN
Value space: <On/Off>
Example: Experimental Audio MicrophoneReinforcement Input Microphone 1
Mode: On
Experimental Audio MicrophoneReinforcement Output Line [1..2] Mode
NOTE: This Experimental command can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
Microphone reinforcement is local amplification of one or several input connectors, directly to one
or several output connectors, with minimum delay.
For software version TC4.0: Microphone reinforcement should not be enabled on a codec that is
also configured using the Audio Console application.
Configuring this setting to On for an output line, means to attach that output connector to the
microphone reinforcement for local amplification. If the output connector already is attached
to a Local Output, it will first be detached from that before being attached to the Microphone
reinforcement. When this setting is On, the output connector cannot be attached to any Local
Output.
Requires user role: ADMIN
Value space: <On/Off>
Example: Experimental Audio MicrophoneReinforcement Output Line 1 Mode: On
Experimental Audio Panning Mode
NOTE: This Experimental command can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
Requires user role: ADMIN
Value space: <Off/Auto>
Example: Experimental Audio Panning Mode: Off
Page 73
73
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Experimental Audio Panning MaxAngle
NOTE: This Experimental command can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
Requires user role: ADMIN
Value space: <0..90>
Example: Experimental Audio Panning MaxAngle: 0
Experimental Audio Panning MonitorLeft
NOTE: This Experimental command can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
Requires user role: ADMIN
Value space: <1/2/3/4/5>
Example: Experimental Audio Panning MonitorLeft: 1
Experimental Audio Panning MonitorRight
NOTE: This Experimental command can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
Requires user role: ADMIN
Value space: <1/2/3/4/5>
Example: Experimental Audio Panning MonitorRight: 1
Experimental CapsetFilter
NOTE: This Experimental command can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
Requires user role: ADMIN
Value space: <S: 0, 100>
Example: Experimental CapsetFilter: ""
Experimental CapsetReduction
NOTE: This Experimental command can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
Requires user role: ADMIN
Value space: <Auto/Reduced>
Example: Experimental CapsetReduction: Auto
Experimental Conference [1..1] PacketLossResilience ForwardErrorCorrection
NOTE: This Experimental command can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
Will enable ForwardErrorCorrection (RFC5109) mechanism as part of the PacketLossResilience
mechanism. Default value is On.
On: Forward error correction will be used as part of the PacketLossResilience mechanism.
Off: Forward error correction will NOT be used as part of the PacketLossResilience mechanism.
Requires user role: ADMIN
Value space: <On/Off>
Example: Experimental Conference 1 PacketLossResilience
ForwardErrorCorrection: On
Experimental Conference [1..1] PacketLossResilience RateAdaption
NOTE: This Experimental command can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
Will use the a RateAdaption algorithm adapted to the PacketLossResilience mechanism. Default
value is On.
On: RateAdaption will be used as part of the PacketLossResilience mechanism.
Off: RateAdaption will NOT be used as part of the PacketLossResilience mechanism.
Requires user role: ADMIN
Value space: <On/Off>
Example: Experimental Conference 1 PacketLossResilience RateAdaption: On
Experimental Conference [1..1] ReceiverBasedDownspeeding
NOTE: This Experimental command can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
Requires user role: ADMIN
Value space: <On/Off>
Example: Experimental Conference 1 ReceiverBasedDownspeeding: Off
Experimental CustomSoftbuttons State [1..2] Softbutton [1..5] Type
NOTE: This Experimental command can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
Requires user role: ADMIN
Value space: <NotSet/MainSource/PresentationSource/CameraPreset/Actions/
SpeedDial>
Example: Experimental CustomSoftbuttons State 1 Softbutton 1 Type: NotSet
Page 74
74
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Experimental CustomSoftbuttons State [1..2] Softbutton [1..5] Value
NOTE: This Experimental command can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
Requires user role: ADMIN
Value space: <S: 0, 255>
Example: Experimental CustomSoftbuttons State 1 Softbutton 1 Value: ""
Experimental NetworkServices UPnP Mode
NOTE: This Experimental command can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
Requires user role: ADMIN
Value space: <On/Off>
Example: Experimental NetworkServices UPnP Mode: Off
Experimental NetworkServices UPnP Timeout
NOTE: This Experimental command can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
Requires user role: ADMIN
Value space: <0..3600>
Example: Experimental NetworkServices UPnP Timeout: 0
Experimental SystemUnit Controller Address
NOTE: This Experimental command can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
Requires user role: ADMIN
Value space: <S: 0, 255>
Example: Experimental SystemUnit Controller Address: ""
Experimental SystemUnit MenuType
NOTE: This Experimental command can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
Requires user role: ADMIN
Value space: <Indicators/Full>
Example: Experimental SystemUnit MenuType: Full
Experimental SystemUnit SoftwareUpgrade RequireAuthentication
NOTE: This Experimental command can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
Requires user role: ADMIN
Value space: <On/Off>
Example: Experimental SystemUnit SoftwareUpgrade RequireAuthentication: Off
Page 75
75
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Chapter 4
Password protection
Page 76
76
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Changing the system/codec password
The system is delivered with a default user account with
username admin and no password set. This user has full
access rights to the system.
NOTE: We strongly recommend that you set a password for the
admin user to restrict access to system configuration.
Make sure to keep a copy of the password in a safe place.
You have to contact your Cisco representative if you have
forgotten the admin password.
A user can change his system/codec password using the web
interface or the command line interface.
Changing the password using the web interface
If a password is currently not set, use a blank Current
password; to remove a password, leave the New password
fields blank.
1. Sign in to the web interface with your username and current
password.
2. Go to the Maintenance tab and select Change Password.
3. Enter the Current password, the New password, and repeat
the new password in the appropriate input fields.
The password format is a string with 0–64 characters.
4. Click Change password.
Changing the password using the command line interface
If a password is currently not set, use a blank current password;
to remove a password, leave the new password entries blank.
1. Connect to the system/codec through the network or the
serial data port, using a command line interface (SSH or
Telnet).
2. Sign in to the codec with your username and current
password.
3. Run the following API command and when prompted enter
the current password, the new password, and confirm the
new password:
systemtools passwd
The password format is a string with 0–64 characters.
Changing another user’s password
If you have ADMIN rights, you can change all users’ passwords
by performing the following steps:
1. Sign in to the web interface with your username and
password.
2. Go to the Maintenance tab and select User administration.
3. Select the appropriate user from the list.
4. Enter a new password and PIN code.
5. Click Save.
You can read more about creating user accounts in the User
administration section.
Password protection
The system is password protected in the following ways:
• The System/Codec is password protected. You always need
to enter a username to sign in to the web and command line
interfaces.
You can also configure the system/codec to prompt for a
PIN-code before accessing all the on screen menus.
• The Administrator settings menu can be password protected
with a menu password.
• You can protect the File system of the codec by setting a
password for the root user. The root user is disabled by
default.
NOTE: We strongly recommend that you set the passwords to
protect your video conference system.
Page 77
77
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Setting the Administrator settings menu password
When starting up the system for the first time the
Administrator Settings menu password is not set.
NOTE: We strongly recommend that you define a password
to protect the Administrator Settings menu, since these
settings affect the behavior of the video conference system.
When you set a password for the Administrator settings
menu, all users must enter the password to get access to
this menu, either on screen when using the remote control,
or on the touch screen if you are using a Touch controller.
The menu password can be set from the on-screen menu,
using the remote control or from the command line interface;
you neither can use a Touch controller nor the web interface.
Setting the menu password using the remote control
1. In the on screen menu, go to Home > Settings >
Administrator settings> Set menu password.
The password format is a string with 0–255 characters.
To deactivate the password leave the password input field
empty.
2. Enter the menu password in the input field. The password
you enter is hidden; each character is replaced with a star
(*).
On the remote control, press the # key to toggle between
lower or upper case characters and numbers: abc/
ABC/123.
3. Select Save to save the changes, or Cancel to leave
without saving.
4. Press Home (
) to exit.
Setting the menu password from a command line interface
1. Connect to the system through the network or the serial
data port, using a command line interface (SSH or Telnet).
2. Type the following command:
xCommand SystemUnit MenuPassword Set
Password: <password>
The password format is a string with 0–255 characters.
To deactivate the password leave the password field
empty.
Setting a root password
If you sign in to the command line interface as root, you can
access the system/codec’s file system.
The root user is disabled by default.
Perform the following steps to activate the root user and set
a password:
1. Connect to the system/codec through the network or the
serial data port, using a command line interface (SSH or
Telnet).
2. Sign in to the system/codec with the username (admin)
and password. You need ADMIN rights.
3. Run the following API command:
systemtools rootsettings on <password>
NOTE: The root password is not the same as the
administrator password.
Page 78
78
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Chapter 5
Appendices
Page 79
79
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Connecting the Cisco TelePresence
Touch controller to CodecCSeries
A C Series codec running software version TC4.1 or later can be
controlled using the Cisco TelePresence Touch controller (instead
of using the remote control).
Connecting the Touch controller
The Touch controller can be connected to the codec in two
different ways:
1. Connect the Touch controller to the codec via LAN.
The process of associating the Touch controller to the codec
is called paring.
NOTE: The codec is signalling that it is available for pairing
for 30 minutes after it is switched on.
2. Connect the Touch controller directly to the codec’s second
Ethernet connector.
NOTE: To use this mode of operation set Direct connection
to On on the codec. Go to Administrator settings > Pairing
> Direct connection using the web interface or the remote
control.
Touch controller set-up
Once the Touch controller is connected to power, the set-up
procedure begins. Follow the instructions on screen.
If you have connected the unit to the codec via LAN, you
have to select which codec to pair with. If your codec is not
in the list of available codecs displayed on the Touch screen,
you can select a codec manually by entering its IP address.
If the Touch controller needs software upgrade, new software
will be downloaded from the codec and installed on the unit
automatically as part of the set-up procedure. The Touch
controller restarts after the upgrade.
You can verify that the Touch controller is successfully paired to
your codec by checking that the codec address is displayed in
the top banner.
If you want more details on Touch installation, please read the
Cisco TelePresence Touch for C Series Installation Guide, which
you will find on the Cisco web site.
Codec address
Page 80
80
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
The video outputs at Codec C60
About monitors when you have a
Codec C60
The main monitor
The monitor can be connected to any of the video outputs
HDMI1 (the default connector for the main monitor) or DVI-I 2.
Connecting to HDMI 1
The HDMI 1 output is, by default, defined as the main monitor
connector. When you connect the main monitor to this output
the menu and icons (OSD - on screen display) will show on this
monitor.
Connecting to DVI-I 2
When connecting the main monitor to the DVI–I 2 output, you
must move the OSD to this output.
If you cannot see any menu on screen you must run a key
sequence on the remote control. The menu on screen, icons
and other information (OSD - on screen display) will be moved
to the selected output. At the same time, the resolution will be
set to the default value, which is 1024x768@60Hz for DVI (and
1280x720@60Hz for HDMI).
Moving the OSD using the remote control
If the main monitor is connected to DVI-I 2 video output, and the
OSD is on HDMI 1 output, you must run the following shortcut or
key sequence on the remote control.
• Disconnect * # * # 0 x # x=1 (HDMI 1) x=2 (DVI–I 2)
Example: Set DVI-I 2 as the OSD output:
– * – # – * – # – 0 – 2 – #
Dual monitors
When you want to run a dual monitor setup, connect the second
monitor to video output DVI-I 2 video output on codec.
Dual monitor configuration
Go to Advanced configuration (menu on screen or web
interface) to set the monitor to dual:
1. Navigate to Video > Output > Monitor and set the Monitor to
Dual.
HDMI 1
(the default connector for
the main monitor)
DVI-I 2
Moving the OSD using the web interface
Go to the Advanced Configuration page and navigate to
Video > OSD > Output and select the video output connector for
the main mointor.
Moving the OSD using API commands
You can also set the resolution and the OSD output by setting
up a serial port connection and run API commands. See the API
Guide for the codec for information about API commands.
Page 81
81
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
The video outputs at Codec C40
About monitors when you have a
Codec C40
The main monitor
The monitor can be connected to any of the video outputs
HDMI1 (the default connector for the main monitor) or DVI-I 2.
Connecting to HDMI 1
The HDMI 1 output is, by default, defined as the main monitor
connector. When you connect the main monitor to this output
the menu and icons (OSD - on screen display) will show on this
monitor.
Connecting to DVI-I 2
When connecting the main monitor to the DVI–I 2 output, you
must move the OSD to this output.
If you cannot see any menu on screen you must run a key
sequence on the remote control. The menu on screen, icons
and other information (OSD - on screen display) will be moved
to the selected output. At the same time, the resolution will be
set to the default value, which is 1024x768@60Hz for DVI (and
1280x720@60Hz for HDMI).
Moving the OSD using the remote control
If the main monitor is connected to DVI-I 2 video output, and the
OSD is on HDMI 1 output, you must run the following shortcut or
key sequence on the remote control.
• Disconnect * # * # 0 x # x=1 (HDMI 1) x=2 (DVI–I 2)
Example: Set DVI-I 2 as the OSD output:
– * – # – * – # – 0 – 2 – #
Dual monitors
When you want to run a dual monitor setup, connect the second
monitor to video output DVI-I 2 video output on codec.
Dual monitor configuration
Go to Advanced configuration (menu on screen or web
interface) to set the monitor to dual:
1. Navigate to Video > Output > Monitor and set the Monitor to
Dual.
HDMI 1
(the default connector for
the main monitor)
DVI-I 2
Moving the OSD using the web interface
Go to the Advanced Configuration page and navigate to
Video > OSD > Output and select the video output connector for
the main mointor.
Moving the OSD using API commands
You can also set the resolution and the OSD output by setting
up a serial port connection and run API commands. See the API
Guide for the codec for information about API commands.
Page 82
82
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
TC console
The term ‘layouts’ can be used to describe the various ways
a video conversation appear on screen. Different types of
meetings would require different layouts.
The TC Console tool lets you customize different parts of the
Codecs C90, C60 and C40 by use of simple drag and drop
technique.
It will let you create setup profiles that can be applied to the
codec at a later time or you can configure the system in real
time without having to program the codec.
Read more about the TC Console functionality in the
TCConsole user guide.
The Video compositor allows you to modify the default video
compositing behavior of the codec without the need for any
programming.
You can add new layouts, change the automatically
selected layouts and control what will be shown to the
users depending on the state of the codec. A layout is a
composition of one or more frames, typically differing in size.
The Audio console helps you configure the audio system
of the codec. It will allow you to change the default mixing,
routing and equalization as well as allow you to set various
input and output connector properties.
Video compositor Audio console
Page 83
83
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Optimal definition profiles
Under ideal lighting conditions the bandwidth requirements can
be substantially reduced with the optimal definitions profiles.
Generally, we recommend the Optimal Definition set at Normal.
If lighting conditions are good we recommend that you test
the endpoint on the various Optimal Definition settings before
deciding on a profile.
Go to Advanced configuration (menu on screen or web
interface) to set the optimal definition profile:
• Navigate to Video > Input > Source [1..n] > OptimalDefinition
> Profile and select a profile.
You can set a resolution threshold below which the maximum
frame rate will be 30 fps.
Go to Advanced configuration (menu on screen or web
interface) to set the threshold:
• Navigate to Video > Input > Source [1..n] > OptimalDefinition
> Threshold60fps and select a threshold.
The video input quality settings must be set to Motion to ensure
the Optimal Definition to work. With the video input quality set
to Sharpness, the endpoint will transmit the highest resolution
possible, regardless of frame rate.
Go to Advanced configuration (menu on screen or web
interface) to set the input quality:
• Navigate to Video > Input > Source [1..n] > Quality and set
the video quality parameter.
You can read more about the video settings in the Advanced
settings chapter.
High (720p60)
Typically used in dedicated video
conferencing rooms. Requires good
lighting conditions for a good overall
experience.
Under ideal conditions the bandwidth
requirements can be reduced by up to
50%.
Medium (w576p60)
Typically used in rooms with better than
normal, and consistent lighting.
The bandwidth requirements can be
reduced by up to 25%.
Normal (w448p60)
This setting is typically used in office
environments where the environment is
normal to poorly lit.
Generally, we recommend the Optimal
Definition set at Normal.
Optimal definition profiles for systems supporting 1080p
w288p30 w448p30 w576p30 720p30 1080p30
Normal 256 kbit/s 512 kbit/s 768 kbit/s 1152 kbit/s 2560 kbit/s
Medium 128 kbit/s 384 kbit/s 512 kbit/s 1152 kbit/s 1920 kbit/s
High 128 kbit/s 256 kbit/s 512 kbit/s 768 kbit/s 1472 kbit/s
Optimal definition profiles for systems supporting 720p60
w144p60 w288p60 w448p60 w576p60 720p60
Normal 128 kbit/s 512 kbit/s 1152 kbit/s 1472 kbit/s 2240 kbit/s
Medium 128 kbit/s 384 kbit/s 768 kbit/s 1152 kbit/s 1920 kbit/s
High 128 kbit/s 256 kbit/s 512 kbit/s 768 kbit/s 1152 kbit/s
Page 84
84
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
ClearPath — Packet loss resilience
ClearPath introduces advanced packet loss resilience
mechanisms that increase the experienced quality when you
use your video system in an error prone environment.
We recommend that you enable ClearPath on your video
system.
Go to Advanced configuration (menu on screen or web
interface) to switch on ClearPath:
• Navigate to Conference 1 > PacketLossResilience > Mode
and select On.
Page 85
85
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Requirements for speaker systems
connected to a Cisco TelePresence
C Series codec
Cisco has put in a lot of effort to minimize the camera to screen
delay on our TelePresence endpoints.
New consumer TVs are usually equipped with “Motion Flow” or
similar technology to insert new video frames between standard
frames to create smoother images. This processing takes time
and to maintain lip synchronization, the TV will delay the audio
so that the audio and video arrives at the same time.
The echo canceller in the Cisco endpoints can handle such
delay up to 30 ms. Many consumer TVs are not made for real
time video communication and may introduce more than 30 ms
of delay.
If you use such a TV together with a C Series codec it is
recommended that you turn off “Motion Flow”, “Natural Motion”
or any other video processing that introduces additional delay.
Some consumer TVs also support advanced audio processing
like “Virtual Surround” effects and “Dynamic Compression” to
improve the TV experience. Such processing will make any
acoustic echo canceller malfunction and should hence be
switched off.
Some monitors are equipped with a setting called ‘Game Mode’.
This mode is specifically designed to help reduce the response
time and will usually help to reduce the delay.
Page 86
86
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
The DNAM Amplifier
• 3 × 50 W continuous average Center Output
Power (load specified by DNAM Center
Loudspeakers)
• 2 × 50 W continuous average Stereo Output
Power (load specified by DNAM Stereo
Loudspeakers)
• Full dynamic range for audio (20 Hz–20 kHz)
• Digital Signal Processing and Filtering on all
channels for best audio detail clarity
• Digital Crossover Filtering on center
channels
• In/out:
• Audio In - SPDIF (stereo) or Analog
(mono), using the same connector.
• Audio Loop Out - line out directly from
the input, always analog even with
SPDIF in.
• Audio Differential In - female XLR
pinout: 1 - GND, 2 – Signal (+), 3 –
Signal (-)
• Audio Stereo Out - male XLR, common
GND configuration
• Loudspeaker Out - female D-SUB 15p
• Fuse 2 A 250 V Slow, 5 × 20 mm, Littelfuse
type 215002. Push and twist anti-clockvice
to release.
DNAM for Profile 42”/52”
The DNAM – Digital Natural Audio Module – is
built on two specially designed and separate
modules, the amplifier and the loudspeaker
cabinet.
The DNAM Loudspeaker
• 3-way Center Loudspeaker system
• Frequency range 50 Hz - 20 kHz
• 2 × 100 mm low- and midrange
loudspeaker 8 Ohms nominal, excellent
quality (SEAS Prestige series)
• 1 × 25 mm dome tweeter, 6 ohms nominal,
excellent quality
• Active crossover filtered audio signals
received from DNAM amplifier
• Long time max power 70 Watt on all
loudspeakers
• Enclosed MDF loudspeaker cabinet
Integrated Left / Right Stereo Loudspeaker
Stereo Loudspeaker System, each side has:
• 1 × 90 mm fullrange loudspeaker, 8 Ohms
nominal, excellent quality
• Frequency range 70 Hz - 20 kHz
• Enclosed MDF Loudspeaker cabinet
Power socket
DNAM Amplifier
DNAM Loudspeaker
Fuse
Audio Stereo Out (XLR)
Audio Differential In (XLR)
Loudspeaker Out
(D-SUB)
Audio In
(RCA)
Audio Loop Out
(RCA)
Page 87
87
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
DNAM for Profile 65”
The DNAM (Digital Natural Audio Module) used
in Profile 65”, is built on two specially designed
and separate modules, which is the amplifier
and the loudspeaker cabinet.
The DNAM Loudspeaker
• 3-way Center Speaker system
• Frequency range 50 Hz - 20 kHz
• 2 × 100 mm low- and midrange
loudspeakers, 8 ohms nominal, reference
quality (SEAS Excel series)
• 1 × 25 mm dome tweeter, 6 ohms nominal,
excellent quality
• Crossover filtered audio signals received
from DNAM amplifier
• Long time max power 70 Watt on all
loudspeakers
• Enclosed MDF speaker cabinet
Integrated Stereo Speaker
2-way Stereo Speaker System, each side has:
• 1 × 100 mm low- and midrange
loudspeaker, 8 ohms nominal, reference
quality (SEAS Excel series)
• 1 × 25 mm dome tweeter, 6 ohms nominal,
excellent quality
• Passive crossover filter
• Frequency range 70 Hz - 20 kHz
• Long time max power 70 Watt
• Enclosed MDF speaker cabinet
Audio In (RCA)
Audio Loop Out (RCA)
Audio Differential In (XLR)
Audio Stereo Out (XLR)
Loudspeaker Out
(D-SUB)
Power socket
The DNAM Amplifier
• 3 × 50 W continuous average Center Output
Power (load specified by DNAM Center
Speakers)
• 2 × 50 W continuous average Stereo Output
Power (load specified by Loudspeaker
Stereo Kit)
• Full dynamic range for audio (high fidelity
range) or Integrated stereo speakers
• Digital Signal Processing and Filtering on all
channels for best audio detail clarity
• Digital Crossover Filtering on center
channels
• In/out:
• Audio In - SPDIF (stereo) or Analog
(mono), using the same connector
• Audio Loop Out - line out directly from
the input, always analog even with
SPDIF in
• Audio Differential In - female XLR
pinout: 1 - GND, 2 – Signal (+), 3 –
Signal (-)
• Audio Stereo Out - male XLR, common
GND configuration
• Loudspeaker Out - female D-SUB 15p
• Fuse 2 A 250 V Slow, 5 × 20 mm, Littelfuse
type 215002
DNAM Amplifier
DNAM Loudspeaker
Fuses
Page 88
88
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Codec C60/C40
UNIT DELIVERED COMPLETE WITH:
Video conferencing codec, wireless remote control,
rack mounting rails (C60), rack mounting ears (C40),
LAN cable, power cable
BANDWIDTH
H.323/SIP up to 6 Mbps point-to-point
H.323/SIP up to 10 Mbps total MultiSite bandwidth*
FIREWALL TRAVERSAL
Cisco TelePresence Expressway technology
H.460.18, H.460.19 Firewall Traversal
VIDEO STANDARDS
H.261, H.263, H.263+, H.264
VIDEO FEATURES
Native 16:9 Widescreen
Advanced Screen Layouts
Intelligent Video Management
Local Auto Layout
7 embedded individual video compositors — 1 for every
output and 1 for every encoder (C60 only) **
VIDE O INPUTS (5 I NPUTS (C60) / 4 I NPUTS (C40))
2 × HDMI inputs, supported formats:
1920 × 1080@60, 59.94 Hz (1080p60)
1920 × 1080@50 Hz (1080p50)
1920 × 1080@30, 29.97 Hz (1080p30)
1920 × 1080@25 Hz (1080p25)
1920 × 1080@24, 23.97 Hz (1080p24)
1280 × 720@60, 59.94 Hz (720p60)
1280 × 720@50 Hz (720p50)
720 × 480@60, 59.94 Hz (480p60)
640 × 480@60 Hz (480p60)
1600 × 1200@50, 60 Hz (UXGA)
1280 × 1024@60, 75 Hz (SXGA)
1024 × 768@60, 70, 75, 85 Hz (XGA)
800 × 600@56, 60, 72, 75, 85 Hz (SVGA)
1920 × 1200@50, 60 Hz (WUXGA)
1680 × 1050@60 Hz (WSXGA+)
1440 × 900@60 Hz (WXGA+)
1280 × 768@60 Hz (WXGA)
2 (C60), 1 (C40) × DVI-I input s, suppor ted
formats:
Analog (VGA):
1920 × 1080@60 Hz (1080p60)
1280 × 720@60 Hz (720p60)
1600 × 1200@60 Hz (UXGA)
1280 × 1024@60, 75 Hz (SXGA)
1280 × 960@60 Hz
1024 × 768@60, 70, 75, 85 Hz (XGA)
1920 × 1200@50 Hz (WUXGA)
1680 × 1050@60 Hz (WSXGA+)
1440 × 900@60 Hz (WXGA+)
1280 × 800@60 Hz (WXGA)
1280 × 768@60 Hz (WXGA)
Analog (YPbPr):
1920 × 1080@60 Hz (1080p60)
1920 × 1080@50 Hz (1080p50)
1920 × 1080@30 Hz (1080p30)
1920 × 1080@25 Hz (1080p25)
1280 × 720@60 Hz (720p60)
1280 × 720@50 Hz (720p50)
1280 × 720@30 Hz (720p30)
720 × 576@50 Hz (576p50)
720 × 480@60 Hz (480p60)
Digital (DVI-D):
Same as HDMI, ref. above.
1 × S-video/Composite input (BNC connector):
PAL/NTSC
Extended Display Identification Data (EDID)
VIDEO OUTPUTS (3 OUTPUTS (C60) /
2 OUTPUTS (C40))
1 × HDMI out put, 1 × DVI-I output, supported
formats:
1920 × 1080@60 Hz (1080p60)
1280 × 720@60 Hz (720p60)
1600 × 1200@60 Hz (UXGA)
1280 × 1024@60 Hz (SXGA)
1024 × 768@60 Hz (XGA)
800 × 600@60 Hz (SVGA)
640 × 480@60 Hz (VGA)
1920 × 1200@60Hz (WUXGA)
1360 × 768@60 Hz
1366 × 768@60 Hz
1280 × 768@60 Hz (WXGA)
1 × Composite output (BNC connector) (C60 only):
PAL/NTSC
VESA Monitor Power Management
Extended Display Identification Data (EDID)
LIVE VIDEO RESOLUTIONS (ENCODE/DECODE)
176 × 144@30 fps (QCIF)
352 × 288@30 fps (CIF)
512 × 288@30 fps (w288p)
576 × 448@30 fps (448p)
768 × 448@30 fps (w448p)
704 × 576@30 fps (4CIF)
1024 × 576@30 fps (w576p)
1280 × 720@30 fps (720p30)
1920 × 1080@30 fps (1080p30)*
640 × 480@30 fps (VGA)
800 × 600@30 fps (SVGA)
1024 × 768@30 fps (XGA)
1280 × 1024@30 fps (SXGA) (C60 only)
1280 × 768@30 fps (WXGA)
1440 × 900@30 fps (WXGA+)* (C60 only)
1680 × 1050@30 fps (WSXGA+)* (C60 only)
1600 × 1200@30 fps (UXGA)* (C60 only)
1920 × 1200@25fps (WUXGA)* (C60 only)
512 × 288@60 fps (w288p60)*
768 × 448@60 fps (w448p60)*
1024 × 576@60 fps (w576p60)*
1280 × 720@60 fps (720p60)*
720p30 from 768kbps
720p60 from 1152kbps*
1080p30 from 1472 kbps*
AUDIO STANDARDS
G.711, G.722, G.722.1, 64 kbps & 128 kbps MPEG4
AAC-LD, AAC-LD Stereo
AUDIO FEATURES
CD-Quality 20 KHz Mono and Stereo
Four (C60) / Two (C40) separate acoustic echo
cancellers
4-port (C60) / 2-port (C40) Audio mixer
Automatic Gain Control (AGC)
Automatic Noise Reduction
Active lip synchronization
AUDIO I NPUTS (7 INPU TS (C60), 5 INPUTS
(C40))
4 × microphone (C60) , 2 × microphone (C40) ,48 V
phantom powered, XLR connector each with separate
echo cancellers and noise reduction,all microphones
can be set for balanced line level
2 × RCA/Phono, Line Level: Stereo PC input,
configurable to 2 × RCA/Phono, Line Level: Mono
auxiliary/DVD input
1 × HDMI, digital: Stereo PC/DVD inputs
AUDIO OUTPUTS (3 OUTPUTS)
2 × RCA/Phono, line level, stereo main audio,
configurable to S/PDIF or 2 × RCA/Phono, line level,
mono to recording device
1 × HDMI, digital, stereo main audio
DUAL STREAM
H.239 (H.323) dual stream
BFCP (SIP) dual stream
Support for resolutions up to 1080p30/WUXGA
(C60)/ WXGAp30 (C40), independent of main stream
resolution
Technical specifications
Page 89
89
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Codec C60/C40, continued...
MULTISITE FEATURES*
4-way SIP/H.323 MultiSite. Resolution up to 720p30
(C60) / w576p30 (C40)
Full individual audio and video transcoding
Individual layouts in MultiSite CP (Takes out SelfView)
H.323/SIP/VoIP in the same conference
Support for Presentation (H.239/BFCP) from any
participant at resolutions up to WXGAp30 (C60) /
WXGAp15 (C40)
Best Impression (Automatic CP Layouts)
H.264, Encryption, Dual Stream from any site
IP Downspeeding
Dial in/Dial out
Additional telephone call (no license required)
Conference rates up to 10 Mbps
PROTOCOLS
H.323
SIP
EMBEDDED ENCRYPTION
H.323/SIP point-to-point
Standards-based: H.235 v2 & v3 and AES
Automatic key generation and exchange
Supported in Dual Stream
IP NET WORK FEATURES
DNS lookup for service configuration
Differentiated Services (QoS)
IP adaptive bandwidth management (including flow
control)
Auto gatekeeper discovery
Dynamic playout and lip-sync buffering
H.245 DTMF tones in H.323
Date and Time support via NTP
Packet Loss based Downspeeding
URI Dialing
TCP/IP
DHCP
802.1x Network authentication
ClearPath
IPV6 NETWORK SUPPORT
Single call stack support for both H323 and SIP
Dual-stack IPv4 and IPv6 for DHCP, SSH, HTTP,
HTTPS, DNS, DiffServ
Support for both Static and Autoconfig (stateless
address auto configuration)
SECURITY FEATURES
Management via HTTPS and SSH
IP Administration Password
Menu Administration Password
Disable IP services
Network Settings protection
NETWORK INTERFACES
1 × LAN/Ethernet (RJ-45) 10/100/1000 Mbit
1 × LAN/Ethernet (RJ-45) interface to be used for the
Cisco TelePresence Touch for C-series user interface
device only
OTHER INTERFACES
USB host for future usage (C60 only)
USB device for future usage
GPIO – General purpose Input/Output (C60 only)
PRECISIONHD 1080P CAMERA
1/3” CMOS
12 × zoom (C60)
12 × zoom / 4 × zoom (C40)
+15°/-25° tilt, +/- 90° pan
43.5° vertical field of view
72° horizontal field of view
Focus distance 0.3 m–infinity
1920 × 1080 pixels progressive @ 60fps
(12 × zoom version)
1920 × 1080 pixels progressive @ 30fps
(4 × zoom version)
Other formats supported (configurable through Dip-
switch):
1920 × 1080@60 Hz (HDMI only)***
1920 × 1080@50 Hz (HDMI only)***
1920 × 1080@30 Hz
1920 × 1080@25 Hz
1280 × 720@60 Hz***
1280 × 720@50 Hz ***
1280 × 720@30 Hz
1280 × 720@25 Hz
Automatic or manual focus/brightness/white balance
Far-end camera control
Daisy-chain support (Visca protocol camera)***
Dual HDMI and HD-SDI output
Upside-down mounting with automatic flipping of
SYSTEM MANAGEMENT
Support for the Cisco TelePresence Management Suite
Total management via embedded SNMP, Telnet, SSH,
XML, SOAP
Remote software upload: via web server, SCP, HTTP,
HTTPS
1 × RS-232 for local control and diagnostics
Remote control and on-screen menu system
DIRE CTORY S ERVI CES
Support for Local directories (My Contacts)
Corporate Directory
Unlimited entries using Server directory supporting
LDAP and H.350
Unlimited number for Corporate directory (through
Cisco TelePresence Management Suite)
Received Calls with Date and Time
Placed Calls with Date and Time
Missed Calls with Date and Time
POWER
Auto-sensing power supply
100-120/200-240 VAC, 60/50 Hz
175 watts max for codec and main camera
OPERATING TEMPERATURE AND HUMIDITY
0° C to 35° C (32° F to 95° F) ambient temperature
10% to 90% Relative Humidity (RH)
STOR AGE AND TRA NSPORT TEM PERATURE
-20° C to 60° C (-4° F to 140° F) at RH 10–90%
(non-condensing)
DIMENSIONS
Length: 17.4 in. / 44.2 cm
Height: 1.7 in. / 4.4 cm
Depth: 10.9 in. / 27.8 cm
Weight: 8.8 lbs / 4 kg
* Requires option
** Multiwindow compositing not supported on the dual stream
*** Not supported on 4 x zoom camera
APPROVALS
EU/EEC
Directive 2006/95/EC (Low Voltage Directive)
– Standard EN 60950-1
Directive 2004/108/EC (EMC Directive)
– Standard EN 55022, Class B
– Standard EN 55024
– Standard EN 61000-3-2/-3-3
USA
Approved according to UL 60950-1
Complies with FCC15B Class B
Canada
Approved according to CAN/CSA C22.2 No. 60950-1
This Class B digital apparatus complies with Canadian
ICES-003.
Cet appareil numérique de la classe B est conforme à
la norme NMB-003 du Canada.
MTBF PRODUCT RELIABILITY/MTBF
The predicted reliability is expressed in the expected
random Mean Time Between Failures (MTBF) for the
electronic components based on the Power On Hours:
Power On Hours (POH) > 69 000 hours
Useful Life Cycle > 6 years
ISO 9001 certificate is available upon request
All specifications are subject to change without notice, system specifics may vary.
All images in these materials are for representational purposes only, actual products may differ.
Cisco and the Cisco Logo are trademarks of Cisco Systems, Inc. and/or its affiliates in the U.S. and other
countries. A listing of Cisco’s trademarks can be found at www.cisco.com/go/trademarks. Third party trademarks
mentioned are the property of their respective owners. The use of the word partner does not imply a partnership
relationship between Cisco and any other company.
February 2011
Page 90
90
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Profile 52” using C60
UNIT DELIVERED COMPLETE WITH:
Full HD LCD display, Codec C60, Touch for C-series
user interface device, remote control, PrecisionHD
Camera (1080p), microphone (3x with single screen,
4x with dual screen), Digital Audio Module, integrated
speakers and integrated cabling.
Choice of installation configuration: floor stand, wheel
base or wall mount on pedestal.
Choice of screen size and configuration.
MONITOR available with:
52’’ Full HD LCD, 16:9, 1080 × 1920 resolution
42’’ Full HD LCD, 16:9, 1080 × 1920 resolution
BASE available with:
Floor standing foot plate
Wheel base (not available on 52” Dual)
Wall mount on pedestal
BANDWIDTH
The same as Codec C60
FIREWALL TRAVERSAL
The same as Codec C60
VIDEO STANDARDS
The same as Codec C60
VIDEO FEATURES
The same as Codec C60
VIDEO INPUTS (5 INPUTS)
The same as Codec C60
VIDEO OUTPUTS (3 OUTPUTS)
The same as Codec C60
LIVE VIDEO RESOLUTIONS (ENCODE/DECODE)
The same as Codec C60
AUDIO STANDARDS
The same as Codec C60
AUDIO FEATURES
The same as Codec C60
AUDIO I NPUTS (7 INPUT S)
The same as Codec C60
AUDIO OUTPUTS (3 OUTPUTS)
The same as Codec C60
DUAL STREAM
The same as Codec C60
MULTISITE FEATURES*
The same as Codec C60
PROTOCOLS
The same as Codec C60
EMBEDDED ENCRYPTION
The same as Codec C60
IP NET WORK FEATURES
The same as Codec C60
IPV6 NETWORK SUPPORT
The same as Codec C60
SECURITY FEATURES
The same as Codec C60
NETWORK INTERFACES
The same as Codec C60
OTHER INTERFACES
The same as Codec C60
PRECISIONHD 1080P CAMERA
The same as Codec C60
SYSTEM MANAGEMENT
The same as Codec C60, as well as
Cisco TelePresence Touch for C-series user interface
device
DIRE CTORY S ERVI CES
The same as Codec C60
POWER
Prole 52’’
Auto-sensing power supply
100-120/200-240 VAC, 60/50 Hz, 6 A max
175 W max for codec and main camera
Maximum power rating complete system, 526 W
Prole 52’’ Dual
Auto-sensing power supply
100-120/200-240 VAC, 60/50 Hz, 10/5 A max
175 W max for codec and main camera
Maximum power rating complete system, 870 W
OPERATING TEMPERATURE AND HUMIDITY
0° C to 35° C (32° F to 95° F) ambient temperature
10% to 90% Relative Humidity (RH)
STOR AGE AND TRA NSPORT TEM PERATURE
-20° C to 60° C (-4° F to 140° F) at RH 10–90%
(non-condensing)
DIMENSIONS
Prole 52’’
Height: 63.78 in. / 162 cm
Width: 47.25 in. / 120 cm
Depth: 6.7 in. / 17 cm
Weight: 253.5 lbs / 115 kg (with floor standing
footplate)
229.3 lbs / 104 kg (with wheel base)
Prole 52’’ Dual
Height: 63.5 in. / 161.3 cm
Width: 95 in. / 241.2 cm
Depth: 6.7 in. / 17 cm
Weight: 515.9 lbs / 234 kg (with floor standing
footplate)
* Requires option
APPROVALS
EU/EEC
Directive 2006/95/EC (Low Voltage Directive)
– Standard EN60950-1, 2nd ed.
Directive 2004/108/EC (EMC Directive)
– Standard EN55022, Class A
– Standard EN55024
– Standard EN61000-3-2/-3-3
Warning: This is a class A product. In a domestic
environment this product may cause radio interference
in which case the user may be required to take
adequate measures.
USA
Approved according to UL60950-1 2nd ed.
Complies with FCC15B Class A
Note: This equipment has been tested and found to
comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference when the equipment is
operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance
with the instruction manual, may cause harmful
interference to radio communications. Operation of
this equipment in a residential area is likely to cause
harmful interference in which case the user will
be required to correct the interference at his own
expense.
Canada
Approved according to CAN/ CSA-C22.2 No. 60950-1
This Class A digital apparatus complies with Canadian
ICES-003.
Cet appareil numérique de la classe A est conforme à
la norme NMB-003 du Canada.
MTBF PRODUCT RELIABILITY/MTBF
The predicted reliability is expressed in the expected
random Mean Time Between Failures (MTBF) for the
electronic components based on the Power On Hours:
Power On Hours (POH) > 69 000 hours
Useful Life Cycle > 6 years
ISO 9001 certificate is available upon request
All specifications are subject to change without notice, system specifics may vary.
All images in these materials are for representational purposes only, actual products may differ.
Cisco and the Cisco Logo are trademarks of Cisco Systems, Inc. and/or its affiliates in the U.S. and other
countries. A listing of Cisco’s trademarks can be found at www.cisco.com/go/trademarks. Third party trademarks
mentioned are the property of their respective owners. The use of the word partner does not imply a partnership
relationship between Cisco and any other company.
June 2011
Page 91
91
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Profile 65” using C60
UNIT DELIVERED COMPLETE WITH:
Full HD LCD display, Codec C60, Touch for C-series
user interface device, remote control, PrecisionHD
1080p Camera, microphones, Digital Audio Module,
integrated speakers and integrated cabling.
MONITOR available with:
65’’ Full HD LCD, 16:9, 1080 × 1920 resolution
BASE available with:
Floor standing footplate
Wall mount on pedestal
BANDWIDTH
The same as Codec C60
FIREWALL TRAVERSAL
The same as Codec C60
VIDEO STANDARDS
The same as Codec C60
VIDEO FEATURES
The same as Codec C60
VIDEO INPUTS (5 INPUTS)
The same as Codec C60
VIDEO OUTPUTS (3 OUTPUTS)
The same as Codec C60
LIVE VIDEO RESOLUTIONS (ENCODE/DECODE)
The same as Codec C60
AUDIO STANDARDS
The same as Codec C60
AUDIO FEATURES
The same as Codec C60
AUDIO I NPUTS (7 INPUT S)
The same as Codec C60
AUDIO OUTPUTS (3 OUTPUTS)
The same as Codec C60
DUAL STREAM
The same as Codec C60
MULTISITE FEATURES*
The same as Codec C60
PROTOCOLS
The same as Codec C60
EMBEDDED ENCRYPTION
The same as Codec C60
IP NET WORK FEATURES
The same as Codec C60
IPV6 NETWORK SUPPORT
The same as Codec C60
SECURITY FEATURES
The same as Codec C60
NETWORK INTERFACES
The same as Codec C60
OTHER INTERFACES
The same as Codec C60
PRECISIONHD 1080P CAMERA
The same as Codec C60
SYSTEM MANAGEMENT
The same as Codec C60, as well as
Cisco TelePresence Touch for C-series user interface
device
DIRE CTORY S ERVI CES
The same as Codec C60
POWER
Auto-sensing power supply
100-120/200-240 VAC, 60/50 Hz
175 W max for codec and main camera
Maximum power rating complete system, 650 W
OPERATING TEMPERATURE AND HUMIDITY
0° C to 35° C (32° F to 95° F) ambient temperature
10% to 90% Relative Humidity (RH)
STOR AGE AND TRA NSPORT TEM PERATURE
-20° C to 60° C (-4° F to 140° F) at RH 10–90%
(non-condensing)
DIMENSIONS
Height: 65 in. / 165 cm
Width: 59.1 in. / 150 cm
Depth: 5.9 in. / 15 cm
Weight: 330 lbs / 150 kg (with floor standing footplate)
* Requires option
APPROVALS
EU/EEC
Directive 2006/95/EC (Low Voltage Directive)
– Standard EN 60950-1
Directive 2004/108/EC (EMC Directive)
– Standard EN 55022, Class A
– Standard EN 55024
– Standard EN 61000-3-2/-3-3
Warning: This is a class A product. In a domestic
environment this product may cause radio interference
in which case the user may be required to take
adequate measures.
USA
Approved according to UL 60950-1
Complies with FCC15B Class A
Note: This equipment has been tested and found to
comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference when the equipment is
operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance
with the instruction manual, may cause harmful
interference to radio communications. Operation of
this equipment in a residential area is likely to cause
harmful interference in which case the user will
be required to correct the interference at his own
expense.
Canada
Approved according to CAN/ CSA-C22.2 No. 60950-1
This Class A digital apparatus complies with Canadian
ICES-003.
Cet appareil numérique de la classe A est conforme à
la norme NMB-003 du Canada.
MTBF PRODUCT RELIABILITY/MTBF
The predicted reliability is expressed in the expected
random Mean Time Between Failures (MTBF) for the
electronic components based on the Power On Hours:
Power On Hours (POH) > 69 000 hours
Useful Life Cycle > 6 years
ISO 9001 certificate is available upon request
All specifications are subject to change without notice, system specifics may vary.
All images in these materials are for representational purposes only, actual products may differ.
Cisco and the Cisco Logo are trademarks of Cisco Systems, Inc. and/or its affiliates in the U.S. and other
countries. A listing of Cisco’s trademarks can be found at www.cisco.com/go/trademarks. Third party trademarks
mentioned are the property of their respective owners. The use of the word partner does not imply a partnership
relationship between Cisco and any other company.
June 2011
Page 92
92
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
www.cisco.com
Profile 42”/52” using C40
UNIT DELIVERED COMPLETE WITH:
Full HD LCD display, Codec C40, Touch for C-series
user interface device, remote control, PrecisionHD
Camera (1080p), microphones (2x), Digital Audio
Module, integrated speakers and integrated cabling.
Choice of installation configuration: floor stand, wheel
base or wall mount on pedestal.
MONITOR available with:
52’’ Full HD LCD, 16:9, 1080 × 1920 resolution
42’’ Full HD LCD, 16:9, 1080 × 1920 resolution
BASE available with:
Floor standing footplate
Wheel base
Wall mount on pedestal
BANDWIDTH
The same as Codec C40
FIREWALL TRAVERSAL
The same as Codec C40
VIDEO STANDARDS
The same as Codec C40
VIDEO FEATURES
The same as Codec C40
VIDEO INPUTS (4 INPUTS)
The same as Codec C40
VIDEO OUTPUTS (2 OUTPUTS)
The same as Codec C40
LIVE VIDEO RESOLUTIONS (ENCODE/DECODE)
The same as Codec C40
AUDIO STANDARDS
The same as Codec C40
AUDIO FEATURES
The same as Codec C40
AUDIO I NPUTS (5 INPUT S)
The same as Codec C40
AUDIO OUTPUTS (3 OUTPUTS)
The same as Codec C40
DUAL STREAM
The same as Codec C40
MULTISITE FEATURES*
The same as Codec C40
PROTOCOLS
The same as Codec C40
EMBEDDED ENCRYPTION
The same as Codec C40
IP NET WORK FEATURES
The same as Codec C40
IPV6 NETWORK SUPPORT
The same as Codec C40
SECURITY FEATURES
The same as Codec C40
NETWORK INTERFACES
The same as Codec C40
OTHER INTERFACES
The same as Codec C40
PRECISIONHD 1080P CAMERA
The same as Codec C40 with 12 × zoom camera
SYSTEM MANAGEMENT
The same as Codec C40, as well as
Cisco TelePresence Touch for C-series user interface
device
DIRE CTORY S ERVI CES
The same as Codec C40
POWER
Prole 42’’
Auto-sensing power supply
100-120/200-240 VAC, 60/50 Hz, 6 A max
175 W max for codec and main camera
Maximum power rating complete system 365 W
Prole 52’’
Auto-sensing power supply
100-120/200-240 VAC, 60/50 Hz, 6 A max
175 W max for codec and main camera
Maximum power rating complete system 526 W
OPERATING TEMPERATURE AND HUMIDITY
0° C to 35° C (32° F to 95° F) ambient temperature
10% to 90% Relative Humidity (RH)
STOR AGE AND TRA NSPORT TEM PERATURE
-20° C to 60° C (-4° F to 140° F) at RH 10–90%
(non-condensing)
DIMENSIONS
Prole 42’’
Height: 63.78 in. / 162 cm
Width: 38.58 in. / 98 cm
Depth: 6.7 in. / 17 cm
Weight: 220.5 lbs / 100 kg (with floor standing
footplate)
200.6 lbs / 91 kg (with wheel base)
Prole 52’’
Height: 63.78 in. / 162 cm
Width: 47.25 in. / 120 cm
Depth: 6.7 in. / 17 cm
Weight: 253.5 lbs / 115 kg (with floor standing
footplate)
229.3 lbs / 104 kg (with wheel base)
* Requires option
APPROVALS
EU/EEC
Directive 2006/95/EC (Low Voltage Directive)
– Standard EN60950-1, 2nd ed.
Directive 2004/108/EC (EMC Directive)
– Standard EN55022, Class A
– Standard EN55024
– Standard EN61000-3-2/-3-3
Warning: This is a class A product. In a domestic
environment this product may cause radio interference
in which case the user may be required to take
adequate measures.
USA
Approved according to UL60950-1 2nd ed.
Complies with FCC15B Class A
Note: This equipment has been tested and found to
comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference when the equipment is
operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance
with the instruction manual, may cause harmful
interference to radio communications. Operation of
this equipment in a residential area is likely to cause
harmful interference in which case the user will
be required to correct the interference at his own
expense.
Canada
Approved according to CAN/ CSA-C22.2 No. 60950-1
This Class A digital apparatus complies with Canadian
ICES-003.
Cet appareil numérique de la classe A est conforme à
la norme NMB-003 du Canada.
MTBF PRODUCT RELIABILITY/MTBF
The predicted reliability is expressed in the expected
random Mean Time Between Failures (MTBF) for the
electronic components based on the Power On Hours:
Power On Hours (POH) > 69 000 hours
Useful Life Cycle > 6 years
ISO 9001 certificate is available upon request
All specifications are subject to change without notice, system specifics may vary.
All images in these materials are for representational purposes only, actual products may differ.
Cisco and the Cisco Logo are trademarks of Cisco Systems, Inc. and/or its affiliates in the U.S. and other
countries. A listing of Cisco’s trademarks can be found at www.cisco.com/go/trademarks. Third party trademarks
mentioned are the property of their respective owners. The use of the word partner does not imply a partnership
relationship between Cisco and any other company.
June 2011
Page 93
93
Cisco TelePresence System Codec C60/C40 and Profiles using C60/C40 Administrator guide
D14636.06 Profile C60-C40 and Codec C60-C40 Administrator Guide TC4.2, July 2011.
