USER GUIDE
Cisco Unified IP Phone 7975G for
Cisco Unified Communications Manager Express Version 7.1
1 Overview, page 2
2 Operating Your Phone, page 8
3 Phone Features Index, page 23
1 Overview
9
7
5
1716
8
6
4
3
2
1
This guide provides operating instructions and feature descriptions for the Cisco Unified IP Phone 7975G. The Cisco Unified IP
phone 7975G is a multiline touch screen phone.
Physical Description
Your Cisco Unified IP Phone 7975G provides touch-screen access, in addition to soft keys and dedicated buttons, allowing you
to place and receive phone calls, put calls on hold, transfer calls, make conference calls, and so on.
Name Description
Programmable or line buttons Depending on the configuration, programmable buttons provide access to:
1
• Phone lines and intercom lines (line buttons)
• Speed-dial numbers (speed-dial buttons, including the BLF speed-d ial feature)
• Web-based services (for example, a Personal Address Book button)
Footstand adjustment Allows you to adjust phone base angle.
2
2
• Call features (for example, a Privacy, Hold, or Transfer button)
Buttons light to indicate status:
Green, steady: Active call or two-way intercom call
Green, flashing: Held call
Amber, steady: Privacy in use, one-way intercom call, DnD active, or
logged into hunt group
Amber, flashing: Incoming call or reverted call
Red, steady: Remote line in use (shared line or BLF status)
Name (continued) Description (continued)
Display button Awakens the touch screen from sleep mode or disables it for cleaning.
3
No color: Ready for input
Green flashing: Disabled
Green steady: Sleep mode
Messages button Autodials your voice message service.
4
Directories button Provides access to phone directories.
5
Help button Activates Help menu (not supported).
6
Settings button Provides access to phone settings to change touch screen and ring settings.
7
Services button Provides access to phone services.
8
Volume button Increases or decreases handset, headset, ringer, or speakerphone volume.
9
Speaker button Toggles speaker on and off.
10
Mute button Toggles mute on and off.
11
Headset button Toggles headset on and off.
12
4-way navigation pad and select
13
(center) button
Keypad Functions like a traditional telephone keypad.
14
Soft keys buttons Engages the functions displayed on the corresponding LCD tabs.
15
Allows you to scroll through menus and highlight items, displays phone numbers
from your Placed Calls, when phone is on-hook. Use the Select button to select an
item that is highlighted on the screen.
Navigation button
• Scroll up and down to see menus and highlight items.
• Scroll left to open the Details view and see the directory numbers and features
assigned to each line button (when on call screen).
• Scroll right to close the Details view.
Select button- Scroll to select a line using the Navigation button, then:
• If the button is mapped to a directory number, and:
–
The line is idle, press to initiate a new call.
–
There is an on-hold call on the line, press to resume the call.
–
There is an active call on the line, the Select button has no effect.
• If the button is mapped to a feature, press to access the feature.
3
Name (continued) Description (continued)
Handset with indicator light Functions like a traditional handset and provides message waiting indicator light
16
and message-waiting (stutter) tone.
Touchscreen Shows phone’s touch screen features.
17
4
Connecting Your Phone
AUX
DC48V
10/100 SW 10/100 PC
+
113656
2
8
3
4
5
6
7
1
This section shows and describes the connectors on your Cisco Unified IP phone.
1
DC adapter port (DC48V) for phones not
provided with inline power
2
AC-to-DC power supply
3
AC power cord
4
Network port (10/100 SW) for connecting to the
network
5
Access port (10/100 PC) for connecting your
phone to your computer
6
Handset port
7
Headset port
8
Footstand button
5
Adjusting the Handset Rest
1 2 3
120521
When you connect your phone, you can adjust the handset rest so that the receiver does not slip out of the cradle. To adjust the
handset:
1. Set the handset aside and pull the square plastic tab from the handset rest.
2. Rotate the tab halfway.
3. Slide the tab back into the handset rest. An extension protrudes from the top of the rotated tab. Return the handset to the
handset rest.
Touch Screen Features
This is what your main touch screen might look like with active calls and some feature menus open.
Primary phone
1
line
Programmable
2
button
indicators
Soft key labels Each displays a soft key function. Soft key labels are touch-sensitive.
3
Status line Displays audio mode icons, status information, and prompts.
4
Call activity
5
area
Phone tab Indicates call activity. Press this tab to return to the call activity area, if needed.
6
Feature tabs Each indicates an open feature menu. Tabs are touch-sensitive.
7
Displays the phone number (directory number) for your primary phone line.
Programmable buttons can serve as phone line buttons, speed-dial buttons, phone service buttons or
phone feature buttons. Icons and labels indicate how these buttons are configured.
Displays current calls per line, including caller ID, call duration, and call state for the highlighted line
(standard view). Items in this area are touch-sensitive.
6
Choosing Touch Screen Items
To choose items on your phone’s touch screen:
• By touch, press (or tap) touch-sensitive items on the touch screen with your fingertip. Use only your fingertip to press the
touch screen because using any other objects could damage the display. Be aware that pressing a phone number can cause
the phone to dial the number.
• By item number , press the corresponding number on your keypad. For example, press 4 to choose the fourth item in a menu.
• By scrolling, press the Navigation button to highlight an item. Press a soft key to finish the action, or tap the item on the
touch screen with your fingertip.
Cleaning and Maintaining the Touch Screen
To disable the touch screen for cleaning, press and hold for more than one second. flashes. The screen remains
disabled for about a minute, unless you enable it.
To enable the touch screen (after disabling it), press (flashing) and hold for more than one second.
To wake the touch screen from sleep mode, press the touch screen or any button, or lift the handset. After a period of inactivity
(determined by your system administra tor), the touch sc reen enters sleep mode to save power. In this mode, the touch screen
appears blank and
Caution Use only a soft, dry cloth to wipe the touch screen. Do not use any liquids or powders on the phone because they
can contaminate phone components and cause failures.
remains lit.
Feature Buttons and Menus
To open or close a feature menu, press a feature button:
Messages
Services
Help
Directories
Settings
To scroll through a list or menu, press the Navigation button.
To go back one level in a feature menu, press Exit. Pressing Exit from the top level of a menu closes the menu.
To switch between open feature menus, press a feature tab on your touch screen. Each feature menu has a corresponding tab.
The tab is visible when the feature menu is open.
Line and Call Icons
The difference between lines and calls is as follows:
• Lines: Each corresponds to a directory number that others can use to call you. Your phone can support up to eight lines.
To see your phone lines, look at the right side of your touch screen. You have as many lines as you have directory numbers
and phone line icons:
• Calls: Each line can support two calls. Only one call can be active at any time; other calls are automatically placed on hold.
.
7
Your phone displays icons to indicate the line and call state.
Icon Line or Call State Description
On-hook line No call activity on this line.
Off-hook line You are dialing a number or an outgoing call is ringing.
Connected call You are connected to the other party.
Ringing call A call is ringing on one of your lines.
Call on hold You have put the call on hold.
Remote-in-use Another phone that shares your line has a connected call.
Authenticated call Verifies the identities of all phones participating in a call.
Encrypted call Identifies phones receiving an encrypted call (your audio) within the
Cisco Unified IP network.
Idle line (BLF) Indicates the line is idle when using the Busy Lamp Feature (BLF).
Busy line (BLF) Indicates the line is busy when using the Busy Lamp Feature (BLF).
2 Operating Your Phone
This section describes how to operate your Cisco Unified IP phone and includes information on soft keys and phone features.
Note Because of differences in phone and site configuration, not all features described here may apply to your phone. Consult
system administrator for more information.
Soft Key Descriptions
Your Cisco Unified IP phone is equipped with soft keys for call features and options. Soft keys are listed along the bottom of
the LCD screen and activated using the corresponding buttons. Soft keys can change acc ording to the state of the phone.
Following is a comprehensive list of soft keys offered on the Cisco Unified IP Phone 7975G. Functions depends on your system
configuration.
Soft Key Function
<<or >> Navigates to edit characters. Use the backspace soft key to erase digits that you entered
incorrectly.
Acct Account code, consult your system administrator on the use of this soft key.
Answer Answers an incoming call.
Callback Notifies callers that the called line is free.
Cancel Cancels the last selection.
cbarge Allows callers to join a shared-line call.
CFwdALL Forwards all calls.
Clear Clears the directory history.
Confrn Connects callers to a conference call.
Delete Deletes a selected number.
Dial Dials a displayed number.
8
Soft Key Function
DnD Enables the Do-Not-Disturb feature.
Down Decreases the LCD screen contrast.
EditDial Selects the number and activates the cursor for editing.
EndCall Ends the current call.
Exit Exits from the current selection.
Flash Provides hookflash functionality fo r three-way call ing and call wai ting services
provided by the PSTN or Centrex service.
GPickUp Selectively pick up calls coming into a phone number that is a member of a pickup
group.
Hold Places active call on hold. Resumes an on hold call.
Login Provides PIN-controlled access to restricted phone features. Contact your local system
administrator for additional information.
LiveRcd Enables the user to record a phone conversation.
MeetMe Starts a new MeetMe conferences
more Scrolls through additional soft key options (for example, use the more soft key to locate
the DnD soft key).
NewCall Opens a new line on a speakerphone to a place call.
Ok Confirms a selection.
Park Forwards calls to a location from which a call can be retrieved by anyone in the system.
PickUp Selectively picks up calls coming into another extension.
Play Plays ring sound samples.
Redial Redials the last number dialed.
Remove Removes a conference participant
RmLstC Removes the Last Participant from the Conference Call.
Resume Returns to the active call.
Save Saves the last change.
Search Initiates a search in the local directory.
Select Selects the highlighted op tion.
Trnsfer Transfers active calls to another extension.
TrnsfVM Transfers a call to voice mail.
Up Increases LCD screen contrast.
Update Updates content.
Basic—Place a Call
To place a call, use one of the following methods:
• Lift the handset and dial the number.
• Dial the number, and then lift the handset.
• Dial the number, and then press the Dial soft key.
• Press the line button for your extension, and then dial.
• Press the Speaker button, and then dial.
• Press the New Call soft key, and then dial.
9
• If you are using a headset, press the Headset button, and then dial. Or, if is lit, press New Call and enter a number.
• Dial the number, and then press the Headset button.
• If you have selected a number from a directory, press the Dial soft key.
• Press Redial to dial the last number, or press the Navigation button (with the phone idle) to see your Placed Calls.
• If you are placing a call while another call is active (using the same line), press Hold, and then press New Call and enter the
number.
• If you are dialing from the directory , choose Missed Calls, Received Calls, or Placed Calls. Press the listings on the
touch screen.
• If you are dialing on-hook, without a dial tone (predial), enter a number, then go off-hook by lifting the handset, pressing
the number on the touch screen, or pressing Dial,
• When you predial, your phone anticipates the nu mber yo u are dialing by displaying matching numbers (if avai lable) from
your Placed Calls log. This is called Auto Dial. To call a number displayed with Auto Dial, press the number, or scroll to it
and go off-hook.
Note Use the backspace (<<) soft key to erase digits that you enter incorrectly.
, or .
Additional Options—Place a Call
To place a call while another call is active (using a different line):
1. Press for a new line. The first call is automatically placed on hold.
2. Enter a number.
To dial from a Personal Address Book (PAB) entry:
1. Press > Personal Directory to log in.
2. Choose Personal Address Book and search for a listing.
Answer a Call
To answer a call, use one of the following methods:
• Press to answer with a headset, if unlit. Or, if is lit, press Answer or (flashing).
• Press , to answer with the speakerphone, press Answer, or (flashing).
• Press Answer to switch from a connected call to answer a new call, or, if the call is ringing on a different line, press
(flashing).
• Press Answer to answer a call using call waiting.
• Press iDivert to send a call to your voice messaging system.
End a Call
To end a call, use one of the following methods:
• Hang up the handset or press EndCall.
• If you are using a headset, press . Or, to keep headset mode active, press EndCall.
• If you are using the speakerphone, pre ss or EndCall.
• Press EndCall to hang up one call, and preserve another call on the same line. If necessary, remove the call from hold first.
Hold and Resume a Call
Engaging the Hold feature typically generates music or a beep. A call-on-hold is indicated by the icon.
To put a call on hold:
1. Make sure the call you want to put on hold is highlighted.
10
2. Press Hold.
To remove a call from hold on the current line:
1. Make sure the appropriate call is highlighted.
2. Press Resume.
T o remove a call from hold on a different line, press (flashing) for the appropriate line. If a single call is holding on this line,
the call automatically resumes. If multiple calls are holding, scroll to the appropriate call an d press Resume.
Mute a Call
With Mute enabled, you can hear other parties on a call and they cannot hear you. You can use Mute in conjunction with the
handset, speakerphone, or a headset.
Press to toggle Mute on.
Press to toggle Mute off.
Manage Call Waiting
If you are on a call when a second call comes in, you hear a call-w aiting tone or see a flashin g indicator light on the handset
rest, depending on the configuration of your phone.
To answer the new call on the same line:
1. Use the Navigation button to select the call.
2. Press the Answer soft key to answer the call. The call on the other line is automatically put on hold.
To return to the original call:
1. Use the Navigation button to reselect the call.
2. Press the Resume soft key to reconnect to the call.
For calls on a separate line:
• Press the Line button for the incoming call. The call on the other line is automatically put on hold.
To return to the original call:
• Press the Line button associated with the original call.
Retrieve Voice Messages
To retrieve voice messages:
1. Select an available Cisco Unified IP phone line by lifting the handset, pressing the speakerphone button, or pressing a line
button. Listen for the dial tone.
2. Press the Messages button, and follow the voice instructions.
Note When you have one or more new messages, the message-waiting indicator (MWI) light on your handset is lit. The MWI
works only if you have the MWI configured on your phone.
Note Your company determines the voice message service that your phone system uses. For the most accurate and detailed
information, see the documentation for your voice message service.
Adjust the Volume for the Current Call
To adjust the handset, speakerphone, or headset volume for the current call:
1. During a call, press the Up or Down Volume button.
2. Press the Save soft key to apply the new volume level to future calls.
11
Adjust the Ring Volume
• Press the Up or Down Volume button while the handset is in its cra dle.
Select the Ring Type
To change the ringer sound:
1. Press the Settings button.
2. Press 2 for Ring Type, or use the Navigation button to scroll to Ring Type and press the Select soft key.
3. Use the Navigation button to scroll through the list of ring types. Press the Play soft key to hear samples.
4. Highlight the ring you want, and then press the Select soft key.
5. Press the Ok soft key to select your setting.
6. Press the Save soft key to save the setting, or press Cancel to exit to the previous menu without chan ging the setting.
7. Press the Exit soft key to return to the main directory menu.
Adjust the Display Contrast
To adjust the contrast in your LCD display:
1. Press the Settings button.
2. Press 1 for Contrast, or use the Select soft key.
3. Use the Down or Up soft key to change the contrast.
4. Press the Ok soft key.
5. Press the Save or Exit soft key.
6. Press the Ok soft key to select your contrast setting.
7. Press the Save soft key to save the setting, or press Cancel to exit to the previous menu without chan ging the setting.
8. Press the Exit soft key to return to the main directory menu.
Note Press the backspace (<<) soft key to erase digits that you enter incorrectly.
Divert Incoming Calls
To forward any incoming call to the call-forward destination set on the Cisco Unified IP phone:
• Press the DnD soft key.
Note If the call-forward destination is not set, pressing the DnD soft key disables the ringer.
Whisper Intercom
The Whisper Intercom feature allows the user to make an intercom call to a busy extension. The recipient can hear the caller or
hear the whisper intercom, and the original caller on the receiving phone does not hear the whisper interco m. The phone
receiving a whisper intercom displays the extension and name of the party initiating the whisper intercom and a zipzip tone is
played before the called party hears the caller's voice. The receiving party needs to select the intercom line button on their phone
to speak to the caller.
Note For intercom users to know whether the intercom is using one-way or two-way audio, the lamps for both intercom
buttons are colored amber for one-way whisper intercom and green for two-way audio.
12
To place an intercom call:
• Dial the intercom directory number from your intercom line. The intercom recipient hears the intercom caller audio without
answering the call.
To answer an intercom call:
• Press the intercom button to talk to the intercom caller.
To end a whisper intercom call:
• Press Endcall.
Place a Priority (Precedence) Call
In some specialized environments, such as military or government offices, you might need to make and receive urgent or critical
calls. If you need this specialized call handling, your system administrator can add Multilevel Precedence and Preemption
(MLPP) to your phone.
Keep these terms in mind:
• Precedence indicates the priority associated with a call.
• Preemption is the process of ending an existing, lower priority call while accepting a higher priority call that is sent to your
phone.
Priority Level of an MLPP Call
To see the priority level of an MLPP call, look for an MLPP icon on your phone screen:
Priority Call
Medium priority (immediate) call
High priority (flash) call
Highest priority (flash override) or Executive Override call
Higher priority calls are displayed at the top of your call list. If you do not see an MLPP icon, the priority l evel of the call is
normal (routine).
Note Contact your system administrator for a list of corresponding precedence numbers for calls.
To Make a Priority (Precedence) Call:
Enter the MLPP access number (provided by your system administrator) followed by the Precedence level (0-4) and the phone
number.
Note If you enter an invalid MLPP access number, a verbal announcement alerts you of the error.
To Answer an MLPP Call:
End an active call (if necessary) and answer the MLPP call.
If the active call has lower precedence than the incoming call, then the active call is preempted.
Tips
–
When you are receiving a priority (precedence) call, an MLPP icon on your phone screen indicates the priority level of
the call.
–
When you make or receive an MLPP-enabled call, you hear special ring tones and call-waiting tones different from the
standard tones.
13
–
When you or the other party are receiving a call that must preempt the current call, disco nnect immediately to all ow
the higher priority call to ring through.
–
When you have more than 1 active call, the call with the lowest precedence is preempted. Similarly, for outgoing calls,
the call with lower precedence is preempted first.
Park a Call (SCCP)
Call park allows a user to place a call on hold at a designated parking slot from which the call can be retriev ed by anyone on
the system.
Note Contact your system administrator for your call park slot number.
To par k a call:
• Press the Park soft key.
The Cisco Unified Communications Manager Express system automatically selects an available call park slot an d displa ys
the number on the Cisco Unified IP phone screen.
To park a call to a specific call park slot:
• Press the Transfer soft key followed by the call park slot nu mber provided by your system administrator.
To retrieve a parked call:
• If your phone receives a call park notification, press the PickUp soft key followed by the asterisk (*).
• Press the PickUp soft key followed by the call park slot number.
Park a Call (SIP)
Call park allows a user to place a call on hold at a designated parking slot from which the call can be retriev ed by anyone on
the system.
Note Contact your system administrator for your call park slot number.
To par k a call:
• Press the Park soft key.
The Cisco Unified Communications Manager Express system automatically selects an available call park slot an d displa ys
the number on the Cisco Unified IP phone screen.
To retrieve a parked call:
• Dial the park slot extension.
To park a call to a directed call park slot:
• Press the Transfer soft key followed by the call park slot nu mber provided by your system administrator.
To retrieve a call parked at a directed call park slot:
• Dial the retrieval park-slot extension.
Pick Up Calls
To pick up a call that is on hold or a call that is ringing at another extension:
1. Press the PickUp soft key.
2. Dial the extension number of the Cisco Unified IP phone that you want to pick up. Control of the call is transferred to your
phone.
To selectively pick up a call ringing at a number that belongs to a pickup group:
14
• Press the GPickUp soft key. If only one pickup group is defined in the entire Cisco Unified
Communications Manager Express system, control of the call is transferred to your phone.
• If the ringing phone and your phone are in the same pickup group, press the asterisk (*) to transfer control of the call to
your phone.
• If the ringing phone and your phone are in different pickup groups, dial the pickup group number where the phone is ringing
to transfer control of the call to your phone.
Call-Blocking (Toll Bar) Override
Call blocking which prevents unauthorized use of phones is implemented by matching a pattern of specified di gits during a
specified time of day and day of week or date. The call-blocking override feature allows individual phone users to override the
call blocking that has been defined.
Note Contact your system administrator for your personal identification number (PIN).
To place calls when call-blocking is enabled:
1. Press the Login soft key on the Cisco Unified IP phone.
2. Enter the PIN that is associated with the phone.
View Multiple Calls
In standard viewing mode, your phone displays calls as follows for the highlighted line:
• Calls with the highest precedence and longest duration display at the top of the list.
• Calls of a similar type are grouped together. For example, calls that you have taken are grouped near the top, and calls on
hold are grouped last.
To view calls on another line, use the following method:
1. Press .
2. Immediately press the line button .
To switch to call overview mode, press for the highlighted line. The phone switches to call overview mode, displaying only
one call per line. The displayed call is either the active call or the held call with the longest duration.
To return to standard viewing mode, press , then immediately press the line button.
Transfer a Call
To transfer a selected call to another number, you can use blind transfer or consultative transfer:
Blind Transfer
Immediately redirects the call without allowing you to speak to the transfer recipient (the person to whom you are transferring
the call).
To make a blind transfer call:
1. During a call, press the Trnsfer soft key. The call is placed on hold.
2. Dial the number to which you want to transfer the call.
Consultative Transfer
Redirects the call after first allowing you to speak to the transfer recipient.
To make a consultative transfer:
1. During a call, press the Trnsfer soft key. The call is placed on hold.
2. Dial the number to which you want to transfer the call.
3. Wait for the call to be answered. Speak to the transfer recipient. Then press the Trnsfer button or hang up the handset.
15
4. If the transfer fails, press the Resume soft key to return to the original call.
Cancel Transfer
1. To cancel your consultative call-transfer attempt:
–
Press the EndCall soft key.
2. To reconnect to the original caller:
–
Press the Resume soft key.
Transfer to Voice Mail
To transfer a call to the recipient’s voice mail:
1. Press TrnsfVM.
2. Enter the recipient’s extension number and press TrnsfVM again.
Forward All Calls
To forward all incoming calls to another number:
1. Press the CFwdALL soft key. You hear a confirmation beep.
2. Dial the number to which you want to forward all your calls. Dial the numbe r exactl y as you wou ld if you we re plac ing a
call to that number. Remember to include locally required prefix numbers.
The phone display is updated to show that calls are to be forwarded.
3. Press the pound key (#) or the EndCall soft key.
Note To forward calls to voice mail, manually enter the voice-mail number, or use the soft key and button sequence of
CFwdALL soft key plus the Messages button, followed by the EndCall soft key.
T o forward calls to a speed-dial number, use the soft key and button sequence of the CFwdALL soft key plus a speed-dial
button, followed by the EndCall soft key.
To cancel call forwarding:
• Press the CFwdALL soft key.
Live Record a Call
Call initiators can use the LiveRcd soft key to record an active call, private line or conference call. To record a call:
1. Press the LiveRcd soft key. This puts the other party on-hold and initiates a call to the configured live record number.
2. Press the LiveRcd soft key again to stop the recording.
Join a Shared-Line Call (SCCP)
User can join a call on a shared line using the cBarge soft key.
To join the shared-line call:
1. Highlight the remote-in-use call that you want to join.
2. Press more to navigate to cBarge and press cBarge .
Join a Shared Line Call (SIP)
User can join a non-private call on a shared line call by using either Barge or cBarge soft keys.
• Barge allows you to add yourself to the call by hosting the conference on your phone and does not allow others to join the
conference.
16
• cBarge allows you to add yourself to the conference and allows others to join the conference.
To join a shared line call:
1. Highlight the remote-in-use call that you want to join.
2. Press Barge or cBarge to join the call.
Tips
–
When you Barge a call, other parties hear a beep announcing your presence. Y ou are disconnected from a call that you
have joined using Barge if the call is put on hold, transferred, or turned into a conference call by the Barg e initiato r.
–
If a phone that is using the shared line has Privacy enabled, call information and Barge/cBarge soft keys do not appear
on the other phones that share the line.
–
You are disconnected from a call that you joined using Barge if the call is put o n hold, transferred, or turned into a
conference call.
Hold a Shared-Line Call (SIP)
Users can put calls on a shared line on hold like calls on a nonshared line.
To place a call on hold while on a shared-line call:
• Highlight the call that you want to put on hold.
• Press the Hold soft key.
Resume a Shared Line Call (SIP)
Users can resume a nonprivate call placed on hold on a shared line call.
To resume a shared line call:
1. Highlight the call that you want to resume.
2. Press Resume to resume the call.
Tip
–
When a shared-line call is placed on hold, a flashing green shared line button notifies all the other phones with the
shared-line directory number that the call can be resumed.
Enable Privacy on Shared-Line (SIP)
Users can prevent others from viewing, barging or resuming a Shared-Line Call by enabling the phone’s privacy feature.
To prevent other from viewing or barging calls:
1. Press the privacy line button . The private icon next to an amber line button verifies that privacy is on.
2. Press privacy button again to disable privacy.
Tips
–
The privacy button is not displayed on the shared-line phone by default. Your system administrator should enable
privacy button on a per phone basis.
–
Privacy is enabled by default for shared-lines. Y our system administrator can change the default privacy setting globally
or on a per phone basis.
–
Calls placed on hold with privacy enabled have privacy disabled by default. Your system administrator can change the
default privacy on hold setting globally.
17
Place and Establish Conference Call
To place a conference call:
1. During a call, press the more soft key and then the Confrn soft key to open a new line and put the fi rst party on hold.
2. Place a call to another number.
3. When the call connects, press Confrn again to add the new party to the call.
To establish a conference call between two- and three-party calls to a Cisco Unified IP phone, one active and the other on hold:
• Press the Confrn soft key on the Cisco Unified IP phone.
To establish a conference call between two- and three-party c alls already present on a Cisco Unified IP phone, using separa te
line buttons, one active and the other on hold:
1. Press the Confrn soft key on the Cisco Unified IP phone.
2. Press the Line button of the call you want to add to the conference.
Note Your system administrator will have configured the system for three-party or eight-party ad-hoc conferences.
Place MeetMe Conference Call
To place a MeetMe conference call:
1. Obtain a MeetMe conference number from your system administrator.
2. Distribute the MeetMe conference number to all the participants.
3. Go offhook, press the MeetMe softkey, and dial the MeetMe conference number. All other participants join the meeting by
dialing into the MeetMe conference number.
• To end the MeetMe conference call, all participants must hang up the handset or press the EndCall soft key.
End a Conference Call
• To end the conference call:
1. Hang up the handset, or press the EndCall soft key.
Note Depending on configuration, when the conference call initiator disconnects, the conference call terminates.
Alternate Methods to End Conference Call
Call initiators may use one of the following methods (functionality will vary according to yo ur system configuration):
• To disconnect from the conference, hang up the handset. The other parties remain on the conference call.
Place Call from Your Local Directory
To access the local phone directory established by the system administrator:
1. Press the Directories button.
2. Press the Navigation Up or Down button or press 4 to select the Local Directory.
3. Press the Navigation Up or Down button to select the Last, First, or Number field search option.
4. Using the keypad, enter the last name or first name for the entry.
When entering letters, select the appropriate number key of the letter you want, and press that key a number of times that
equals the position of the target letter. For example, to enter a B, press the 2 key two times, and to enter a C, press the 2
key three times. Use the backspace (<<) soft key to make corrections while entering data .
5. Press the Search soft key to find your selection.
6. If your search results in mu ltiple listings, use the Navig ation Up or Down button to select the correct number.
18
7. Press the Dial soft key to dial the selected number.
Program Personal Speed-Dial Buttons
After an system administrator defines one or more speed-dial instances for a Cisco Unified IP phone, you can reprogram
numbers that are not locked or program numbers into an instance that has an empty dial string:
1. Select an available phone line by lifting the handset, by pressing the NewCall soft key, or by pressing a line button. Listen
for the dial tone.
2. Press the pound key (#).
3. Press the speed-dial button that you want to program. A short beep confirms that you are starting to program this button.
4. Enter the speed-dial number. The digits appear on the phone display. When you are entering speed-dial numbers, use the
backspace (<<) soft key to erase digits that you entered incorrectly.
• To remove a speed-dial number without replacing it with a new one.
1. Press the pound key (#).
2. Press the same speed-dial button a second time to indicate that you are done entering the speed-dial digits and to store the
new speed-dial number.
3. Hang up the handset, or press a new speed-dial button and repeat this procedure.
Place a Call from Your System Speed-Dial Directory
To place a call from your system speed-dial directory:
1. Select an available Cisco Unified IP phone line (off hook or NewCall) and get a dial tone.
2. Press the Directories button, or use the Navigation button to locate Directory and then press the Select soft key.
3. Use the Navigation button to scroll through the options. Use the Sele ct soft key to select speed-dial options.
–
Press 5 for the Local Speed Dial.
–
Press 6 for the Personal Speed Dial (func tionality var ies depending on your sy stem configuration).
4. Use the Navigation button to scroll through the speed-dial phone list.
5. To dial the selected phone number, either press the Select soft key or enter the number on the keypad.
6. Press the Exit soft key to go to the directory menu.
Place a Call Using Your Extension Mobility (EM) Profile
Extension Mobility (EM) allows the user to temporarily configure a Cisco Unified IP phone to function as user’s own phone.
Once the user is logged-in to EM, the phone adopts the user’s profile, including the line buttons, features, and established
services.
To log-in to Extension Mobility:
1. Press and select Extension Mobility.
2. Enter your User ID and Password.
3. Press Submit. The phone will temporarily configure user profile and settings.
Note Your system administrator must configure Extension Mobility for you.
Place a Call from Your Personal Speed-Dial
To place a call from your Personal Speed-Dial using My Phone Apps, use the following method:
1. Log-in to Extension Mobility.
2. Select My Phone Apps and scroll down to Personal Speed Dial.
3. Select Personal Speed Dial
19
4. Add a Label and Number
5. Go back to My Phone Apps and press Reset Phone. You Personal Speed-Dial number will appear on the phone display
screen.
Switching an In-Progress Call to Another Phone Using SNR
The Single Number Reach (SNR) feature allows you to switch an in-progress call on your desktop phone to your remote
destination phone, such as a mobile phone. You can pick up an in-progress call on the desktop phone or remote destination
phone without losing the call. All unanswered calls are forwarded to your voice mail.
Note Your system administrator must configure this feature for your IP Phone. Contact your system administrator for more
information.
Switch an in-progress Call from Your Desktop Phone to Your Remote Destination Phone
To switch an in-progress call on your desktop phone to your remote destination phone:
1. Press the Mobility soft key.
2. Select Send Call to Mobile Phone.
3. Answer the in-progress call on your remote destination phone.
The desktop phone line button turns red and handset icons and the calling party number appear on the phone display. You
cannot use same phone line for any other calls, but if your desk phone supports multiple lines, you can use another line to make
or receive calls.
Switch an in-progress Call from a Remote Destination Phone to Your Desktop Phone
1. Press Resume on your desk phone and start talking on your desk phone.
2. Hang up the call on your remote phone to disconnect the phone.
Change Your Remote Destination Phone Number
You can replace the existing remote destination phone number with a new phone number.
To change the existing remote destination phone number:
1. Press Services button and select My Phone Apps.
2. Select Single Number Reach.
3. Use << soft key to type your new remote destination phone number. Make sure you add the appropriate dialing prefix or
access code (if applicable) to your remote destination number.
4. Press Submit.
Enable or Disable Single Number Reach
You can enable or disable Single Number Reach (SNR) on your phone by using the M obility soft key.
• To disable SNR, press Mobility soft key and select Disable Mobile Connect.
• To enable SNR, press Mobility soft key and select Mobile Connect On.
View Call History
To view recent missed, received, or placed calls:
1. Press the Directories button.
2. Use the Navigation button to scroll and select the desired call list. Press the Select soft key, or
20
–
Press 1 on the keypad for Missed Calls.
–
Press 2 on the keypad for Received Calls.
–
Press 3 on the keypad for Placed Calls.
3. Press the Exit soft key to return to the previous directory menu.
Place a Call from Call History
To place a call to a number in the call history list:
1. Use the Navigation button to scroll through the call history list.
2. Use the Select soft key to select a phone number. The digits will appear on the phone display.
3. To dial the number as it appears on the phone display:
–
Press the Dial soft key.
To edit the number on the phone display before dialing:
1. Press the EditDial soft key to place the cursor at the beginning of the number on the phone display.
2. Use the keypad to edit the digits as needed. Use the backspace (<<) soft key to erase di gits that you enter inc orrectly.
3. Press the Dial soft key to place the call.
Clear Call History
To clear all numbers in the directory histories
• Press the Clear soft key.
Note The Clear soft key clears all call history lists. Selective clearing of call history lists is not supported.
Use the Intercom Feature
Cisco Unified Communications Manager Express supports intercom functionality for one-way and press-to-answer voice
connections using a dedicated pair of intercoms on two phones that speed-dial each other.
To use the intercom feature:
1. Press the Speaker button and get the dial tone.
2. Press the speed dial key or dial the directory number to start the intercom call.
Note The called Cisco Unified IP phone automatically answers the call in speakerphone mode with mute activated or
deactivated depending on configuration. The phone will beep to alert the recipient to the incoming call.
To respond to an intercom call:
• If Mute key is lighted, Press the Mute button, or lift the handset.
• If Mute key is not lighted, reply to caller handsfree.
Activate Do Not Disturb
For visual call alerting and information without audible ringing, use Do Not Disturb (DnD). Calls receive normal
call-forward-busy and no-answer treatment.
To activate the Do-Not-Disturb feature:
1. Press the more soft key to locate the DnD soft key.
2. Press the DnD soft key. A text message displays to indicate that the phone is in Do-Not-Disturb mode.
To deactivate the Do-Not-Disturb feature, repeat Steps 1 and 2 in idle state.
21
Customizing the Touch Screen
To change the touch screen brightness:
1. Choose > User Preference s > Brightn ess.
2. To make adjustments, press Up, Down or .
3. Press Save, or press Cancel.
To adjust the touch screen to accommodate your view ing angle:
1. Choose > User Preference s > Viewing Angle.
2. To make adjustments, press Up, Down or .
3. Press Save, or press Cancel.
To change the background image:
1. Choose > User Preference s > Backgroun d Images.
2. Scroll through available images and press Select to choose an image.
3. Press Preview to see a larger view of the background image.
4. Press Exit to return to the selection menu.
5. Press Save to accept the new image, or press Cancel.
To change the language on your touch screen:
1. Log in to your User Options web pages.
2. Access your user settings.
To change the line text label:
1. Log in to your User Options web pages.
2. Access your line label settings.
22
3 Phone Features Index
This section provides an alphabetical list of features for your Cisco Unified IP phone. Features supported in both SIP and SCCP
protocols are marked as “Supported” and features not supported in either one of the protocols are marked as “Not Supported”.
However, there are differences in how the feature works based on the call protocol.
Tab l e 1 Features (with page number references) supported in SIP and SCCP prot ocols.
Phone Features SIP SCCP
Activate Do Not Disturb 21 Supported Supported
Additional Options—Place a Call 10 Supported Supported
Adjust the Display Contrast 12 Supported Supported
Adjust the Ring Volume 12 Supported Supported
Adjust the Volume for the Current Call 11 Supported Supported
Answer a Call 10 Supported Supported
Basic—Place a Call 9 Supported Supported
Call-Blocking (Toll Bar) Override 15 Not Supported Supported
Cancel Transfer 16 Supported Supported
Clear Call History 20 Supported Supported
Divert Incoming Calls 12 Supported Supported
Enable Privacy on Shared-Line (SIP) 17 Supported Not Supported
End a Call 10 Supported Supported
End a Conference Call 18 Supported Supported
Forward All Calls 16 Supported Supported
Hold and Resume a Call 10 Supported Supported
Join a Shared Line Call (SIP) 16 Not Supported Supported
Join a Shared-Line Call (SCCP) 16 Not Supported Supported
Live Record a Call 16 Supported Supported
Manage Call Waiting 11 Supported Supported
Mute a Call 11 Supported Supported
Park a Call (SCCP) 14 Not Supported Supported
Park a Call (SIP) 14 Not Supported Supported
Pick Up Calls 14 Supported Supported
Place a Call from Call History 20 Not Supported Supported
Place a Call from Your Personal Speed-Dial 19 Supported Supported
Place a Call from Your System Speed-Dial Directory 19 Not Supported Supported
Place a Call Using Your Extension Mobility (EM) Profile 19 Supported Supported
Place a Priority (Precedence) Call 13 Supported Supported
Place and Establish Conference Call 18 Supported Supported
Place Call from Your Local Directory 18 Not Supported Supported
Place MeetMe Conference Call 18 Not Supported Supported
Program Personal Speed-Dial Buttons 19 Supported Supported
Resume a Shared Line Call (SIP) 17 Supported Supported
Retrieve Voice Messages 11 Supported Supported
23
Table 1 Features (with page number references) supported in SIP and SCCP protocols.
Phone Features SIP SCCP
Select the Ring Type 12 Supported Supported
Switching an In-Progress Call to Another Phone Using SNR 20 Not Supported Supported
Transfer a Call 15 Supported Supported
Transfer to Voice Mail 16 Not Supported Supported
Use the Intercom Feature 20 Supported Supported
View Call History 20 Supported Supported
View Multiple Calls 15 Supported Supported
Whisper Intercom 12 Not Supported Supported
24
Americas Headquarters
CCVP, the Cisco logo, and Welcome to the Human Network are trademarks of Cisco Systems, Inc.; Changing the Way We Work, Live, Play, and Learn is a service mark of Cisco Systems, Inc.; and Access Registrar,
Aironet, Catalyst, CCDA, CCDP, CCIE, CCIP, CCNA, CCNP, CCSP, Cisco, the Cisco Certified Internetwork Expert logo, Cisco IOS, Cisco Press, Cisco Systems, Cisco Systems Capital, the Cisco Systems logo,
Cisco Unity, Enterprise/Solver, EtherChannel, EtherFast, EtherSwitch, Fast Step, Follow Me Browsing, FormShare, GigaDrive, HomeLink, Internet Quotient, IOS, iPhone, IP/TV, iQ Expertise, the iQ logo, iQ Net
Readiness Scorecard, iQuick Study, LightStream, Linksys, MeetingPlace, MGX, Networkers, Networking Academy, Network Registrar, PIX, ProConnect, ScriptShare, SMARTnet, StackWise, The Fastest Way to
Increase Your Internet Quotient, and TransPath are registered trademarks of Cisco Systems, Inc. and/or its affiliates in the United States and certain other countries.
All other trademarks mentioned in this document or Website are the property of their respective owners. The use of the word partner does not imply a partnership relationship between Cisco and any other company.
(0711R)
Cisco Systems, Inc.
170 West Tasman Drive
San Jose, CA 95134-1706
USA
www.cisco.com
Tel: 408 526-4000
800 553-NETS (6387)
Fax: 408 527-0883
Asia Pacific Headquarters
Cisco Systems, Inc.
168 Robinson Road
#28-01 Capital Tower
Singapore 068912
www.cisco.com
Tel: +65 6317 7777
Fax: +65 6317 7799
Europe Headquarters
Cisco Systems International BV
Haarlerbergpark
Haarlerbergweg 13-19
1101 CH Amsterdam
The Netherlands
www-europe.cisco.com
Tel: 31 0 800 020 0791
Fax: 31 0 20 357 1100
Cisco has more than 200 offices worldwide. Addresses, phone numbers, and fax numbers are listed on the
Cisco Website at www.cisco.com/go/offices.
© 2009 Cisco Systems, Inc. All rights reserved.
OL-16472-01
26
Loading...
