CHA PT ER
1
Module Overview and Specifications
This chapter provides an overview of the features of the Catalyst 4500 series supervisor engines and switching modules. The information is presented in the following major sections:
• Catalyst 4000 Series Switches, page 1-1
• Catalyst 4500 Series Switches, page 1-2
• Supervisor Engines, page 1-2
• Ethernet and Fast Ethernet Switching Modules, page 1-12
• Gigabit Ethernet Switching Modules, page 1-29
• Other Switching Modules, page 1-42
• Switching Module LEDs, page 1-43
• Hot-Swapping Feature, page 1-45

Catalyst 4000 Series Switches

The Catalyst 4000 series switches consist of the Catalyst 4003 switch and the Catalyst 4006 switch. The switches are designed for high-performance, high-density wiring closet applications. A detailed overview of these switches is in the Catalyst 4000 Series Installation Guide.
Catalyst 4500 Series Module Installation Guide
78-13267-06
1-1

Catalyst 4500 Series Switches

Catalyst 4500 Series Switches
The Catalyst 4500 series switches consist of the Catalyst 4503 switch, the Catalyst 4506 switch, the Catalyst 4507R switch, and the Catalyst 4510R switch. The switches are designed for high-performance, high-density wiring closet applications. A detailed overview of these switches is in the Catalyst 4500 Series
Installation Guide.

Supervisor Engines

These sections describe the supervisor engines available for the Catalyst 4500 series switches:
• Supervisor Engine I (WS-X4012), which is used in the Catalyst 4003 switch
(Figure 1-1)
• Supervisor Engine II (WS-X4013, which is used in the Catalyst 4006, 4503,
and 4506 switches (Figure 1-2)
• Supervisor Engine II-Plus (WS-X4013+), which is used in the Catalyst 4006,
4503, 4506, and 4507R switches (Figure 1-3)
• Supervisor Engine II-Plus TS (WS-X4013+TS), which is used in Catalyst
4503 switches only (Figure 1-4)
Chapter 1 Module Overview and Specifications
1-2
• Supervisor Engine II-Plus 10GE (WS-X4013+10GE), which is used in
Catalyst 4503, 4506, and 4507R switches (Figure 1-5)
• Supervisor Engine III (WS-X4014), which is used in the Catalyst 4006, 4503,
and 4506 switches (Figure 1-6)
• Supervisor Engine IV (WS-X4515), which is used in the Catalyst 4006, 4503,
4506, and 4507R switches (Figure 1-7 )
• Supervisor Engine V (WS-X4516), which is used in the Catalyst 4006, 4503,
4506, 4507R, and 4510R switches (Figure 1-8)
• Supervisor Engine V-10GE (WS-X4516-10GE), which is used in the
Catalyst 4503, 4506, 4507R, and 4510R switches (Figure 1-9)
On the Catalyst 4006, 4503, and 4506 switches, you can install the Supervisor Engine in slot 1 only. On the Catalyst 4507R or 4510R switch, you install the primary supervisor engine in slot 1, and you can install an optional redundant supervisor engine in slot 2.
Catalyst 4500 Series Module Installation Guide
78-13267-06
Chapter 1 Module Overview and Specifications
The supervisor engines have the following features:
• Data path and control for all network interfaces
• Management functions:
–
Interface monitoring
–
Environmental status
–
SNMP and console/Telnet interface
• Hot-swapping
Note Packets are not forwarded while the module is removed. A system
reboot occurs when a supervisor engine is reinserted.
• The Supervisor Engine II-Plus TS provides 12 nonblocking
10/100/1000BASE-T (RJ-45) ports and 8 1000BASE-X (SFP) ports.
• The Supervisor Engine II-Plus 10GE and Supervisor Engine V-10GE provide
2 nonblocking 10GBASE uplink ports.
• The Supervisor Engine II-Plus 10GE and Supervisor Engine V-10GE provide
4 1000BASE-X (SFP) ports.
Supervisor Engines
78-13267-06
• The Supervisor Engine IV and V support the Catalyst 4500 series NetFlow
Services Card (WS-F4531). NetFlow is integral to the Supervisor Engine V-10 GE.
To install a supervisor engine, follow the procedure in the “Installing the
Modules” section on page 3-2.
The supervisor engines used in Catalyst 4000 and Catalyst 4500 switches are shown in Figure 1-1 to Figure 1-8.
Catalyst 4500 Series Module Installation Guide
1-3
Supervisor Engines
Figure 1-1 Supervisor Engine I (WS-X4012)
Chapter 1 Module Overview and Specifications
STATUS LED
0%
Switch load
100%
indicators
Ethernet
management
port
Figure 1-2 Supervisor Engine II (WS-X4013)
STATUS LED
U
P
LIN
KU
P
L
IN
S
T
A
T
U
S
Gigabit uplink
K
1
2
U
P
L
IN
K
S
E
N
A
B
LE
D
1%
ports
Switch load
indicators
Console
Reset button
Console port
Reset button
10/100
CONSOLE
BASE-TX
RESET
100%
Ethernet management port
port
16671
28844
1-4
Catalyst 4500 Series Module Installation Guide
78-13267-06
Chapter 1 Module Overview and Specifications
Figure 1-3 Supervisor Engine II-Plus (WS-X4013+)
Supervisor Engines
10/100 MGT
EJECT
LINK
Reset button
FLASH
RESET
STATUS LED
W
S
-X
4515 S
U
P
E
R
VIS
O
R
E
N
G
INE
IV
U P
LIN
K 1UP
S
TA
TU
S
LIN
E
A
C
TIV
E
L
IN
Gigabit uplink
LIN
K 2
E
A
C
TIV
E
A
C
TIV
E
CONSOLE
UTILIZATION
1%
100%
ports
Switch load
indicators
CompactFlash port Ethernet management port
Console port
(RJ-45)
Figure 1-4 Supervisor Engine II-Plus TS (WS-X4013+TS)
RESET button
STATUS LED
PoE status
Switch load
LED
indicators
Compact Flash port
Ethernet management port
CONSOLE
port
78480
113860
78-13267-06
Catalyst 4500 Series Module Installation Guide
1-5
Supervisor Engines
Figure 1-5 Supervisor Engine II-Plus 10GE (WS-X4013+10GE)
CONSOLE port
Ethernet
STATUS LED
Compact
Flash
port
RESET
button
Switch load
indicators
Figure 1-6 Supervisor Engine III (WS-X4014)
management port
10 GE uplink
ports
Gigabit SFP
ports
Chapter 1 Module Overview and Specifications
120474
STATUS LED
W
S
-X
4
0
14
U
P
LIN
K
1
U
P
LIN
K
S
U
P
E
R
V
IS
O
R
III E
N
G
IN
E
S
T
A
T
U
S
2
LIN
K
A
C
TIV
E
LIN
K
A
C
TIVE
Gigabit uplink ports
Catalyst 4500 Series Module Installation Guide
1-6
U T
IL
IZ
1 %
Switch load indicators
CONSOLE port
(RJ-45)
CONSOLE 10/100 MGT
A
T
IO
N
100
%
E J
E
C T
Management port
RESET button
F
L
A
S
H
R
E
S E
T
CompactFlash port
78479
78-13267-06
Chapter 1 Module Overview and Specifications
Figure 1-7 Supervisor Engine IV (WS-X4515)
Supervisor Engines
STATUS LED
W
S
-X
4515 S
U
P
E
R
VIS
O
R
E
N
G
INE
IV
U
P
LIN
K 1UP
LIN
S
TA
TU
S
Gigabit uplink
K 2
LIN
E
A
C
TIV
E
L
IN
E
A
C
TIV
E
A
C
TIV
E
10/100
CONSOLE
MGT
UTILIZATION
1%
100%
EJECT
LINK
ports
Switch load
indicators
Ethernet management port
Console port
(RJ-45)
Figure 1-8 Supervisor Engine V (WS-X4516)
STATUS LED
W
S
-X
45
15 S
U
P
E
R
V
IS
O
R
E
N
G
IN
E
IV
U
P
L
IN
K 1UP
L
IN
K
S
T
A
T
U
S
Gigabit uplink
2
LIN
E
A
C
T
IV
E
LIN
E
A
C
T IV
E
A
C
T
IV
E
10/100
CONSOLE
MGT
UTILIZATION
1%
100%
EJECT
LINK
ports
Switch load
indicators
Ethernet management port
Console port
(RJ-45)
Reset button
FLASH
RESET
CompactFlash port
Reset button
FLASH
RESET
CompactFlash port
78480
78480
78-13267-06
Catalyst 4500 Series Module Installation Guide
1-7
Supervisor Engines
Figure 1-9 Supervisor Engine V-10GE (WS-X4516-10GE)
CONSOLE port
Ethernet
STATUS LED
Compact
Flash
port
Switch load
RESET
button
indicators
management port
10 GE uplink
ports
Gigabit SFP
ports

Front-Panel Components

The following connectors, LEDs, and buttons are located on the front panel of the supervisor engine:
• The STATUS LED, which indicates the operating state of the module
Chapter 1 Module Overview and Specifications
120474
1-8
• Two Gigabit uplink ports (WS-X4013, WS-X4013+, WS-X4014, and
WS-X4515 supervisor engines only)
• Four SFP Gigabit uplinks ports and 2 10-Gigabit uplink ports on
WS-X4013+10GE and WS-X4016-10GE.
• Eight unmarked switch load indicator LEDs, which provide an approximation
of the current traffic across the backplane
• A console port (DB-25 for the WS-X4012; RJ-45 for the WS-X4013,
WS-X4013+, WS-X4013+ TS, WS-X4013+10GE, WS-X4014, WS-X4515, WS-X4516, and WS-X4516-10GE supervisor engines)
• An Ethernet management port (RJ-45)
• A link status LED, which provides status for the management port
(10BASE-T on the WS-X4012 and 10/100BASE-T on the WS-X4013, WS-X4013+, WS-X4013+ TS, WS-X4013+10GE, WS-X4014, WS-X4515, WS-X4516, and WS-X4516-10GE supervisor engines)
Catalyst 4500 Series Module Installation Guide
78-13267-06
Chapter 1 Module Overview and Specifications
• The Reset button (recessed), which allows you to reset the system
• The CompactFlash port and eject button (WS-X4013+, WS-X4013+ TS,
WS-X4013+10GE, WS-4014, WS-X4515, WS-X4516, and WS-X4516-10GE supervisor engines only) (refer to Using the Compact
Flash on the Catalyst 4000 Family Supervisor Engine III and IV.)
Table 1-1 describes the supervisor engine LEDs.
Table 1-1 Supervisor Engine LEDs
LED Color/State Description
STATUS Indicates the results of a series of self-tests.
UTILIZATION Green 1–100% If the switch is operational, this display
LINK Indicates the status of the 10/100BASE-T
ACTIVE Indicates whether the uplink port is active
Supervisor Engines
Green All diagnostic tests passed.
Red A test failed.
Orange System boot or diagnostic test is in
progress.
Off Module is disabled.
indicates the current traffic load over the backplane (as an approximate percentage).
Ethernet management port or uplink ports.
Green The link is operational.
Orange The link is disabled by user.
Flashing orange The power-on self-test indicates a faulty
port.
Off No signal is detected or there is a link
configuration failure.
or not.
Green The port is active.
Off The port is not active.
78-13267-06
Catalyst 4500 Series Module Installation Guide
1-9
Supervisor Engines

Ethernet Management Port

The WS-X4012 supervisor engine has a 10BASE-T Ethernet management port. The WS-X4516-10GE and WS-X4013+10GE supervisor engine modules have a 10/100/1000BASE-T Ethernet management port.The other supervisor engine modules have a 10/100BASE-T Ethernet management port. Supervisor engines use an RJ-45 connector on the front panel with a link status LED. For the location of the port, see Figure 1-1 (WS-X4012), Figure 1-2 (WS-X4013), Figure 1-3 (WS-X4013+), Figure 1-4 (WS-X4013+TS), Figure 1-5 (WS-X4013+10GE),
Figure 1-6 (WS-X4014), Figure 1-7 (WS-X4515), Figure 1-8 (WS-X4516), or Figure 1-9 (WS-X4516-10GE).
TCP/IP-based management services available through inband access also are provided through this port (Telnet and SNMP). This management port also supports image download.
Note The 10BASE-T and 10/100BASE-T Ethernet management ports are for network
management only. These ports do not support network switching.
Chapter 1 Module Overview and Specifications

Console Port

Note EIA/TIA-232 was known as recommended standard RS-232 before its acceptance
Catalyst 4500 Series Module Installation Guide
1-10
The console port allows you to perform the following functions:
• Configure the switch from the CLI
• Monitor network statistics and errors
• Configure SNMP agent parameters
• Download software updates to the switch or distribute software images
residing in Flash memory to attached devices
The Catalyst 4003 console port is a DCE DB-25 receptacle, which supports a DCE EIA/TIA-232 interface. The console port is an RJ-45 receptacle on the Catalyst 4006, 4503, 4506, and 4507.
as a standard by the Electronic Industries Association (EIA) and Telecommunications Industry Association (TIA).
78-13267-06
Chapter 1 Module Overview and Specifications

Supervisor Memory

Table 1-2 lists the memory and processor specifications for the Supervisor
engines.
Table 1-2 Supervisor Memory
Supervisor Engine
Supervisor Engine II+ 256 MB SODIMM SDRAM
Supervisor Engine II+TS 256 MB SODIMM SDRAM
Supervisor Engine II+10GE 256 MB SODIMM SDRAM
Supervisor Engine III 256 MB DIMM SDRAM
Supervisor Engine IV 512 MB SODIMM SDRAM
Supervisor Engine V 512 MB SODIMM SDRAM
Supervisor Engine V-10GE 512 MB SODIMM SDRAM
Supervisor Engines
32 MB Flash memory
32 MB Flash memory
(upgradeable to 512 MB) 64 MB Flash memory
64 MB Flash memory 512 KB NVRAM
64 MB Flash memory 512 KB NVRAM
64 MB Flash memory 512 KB NVRAM
64 MB Flash memory 512 KB NVRAM
78-13267-06
Catalyst 4500 Series Module Installation Guide
1-11
Chapter 1 Module Overview and Specifications

Ethernet and Fast Ethernet Switching Modules

Ethernet and Fast Ethernet Switching Modules
This section describes the Catalyst 4500 series Ethernet and Fast Ethernet switching modules and includes the following sections:
• WS-X4124-RJ45, page 1-12
• WS-X4124-FX-MT, page 1-14
• WS-X4148-FX-MT, page 1-15
• WS-X4148-RJ, page 1-15
• WS-X4148-FE-BD-LC, page 1-16
• WS-X4148-FE-LX-MT, page 1-17
• WS-X4148-RJ21, page 1-18
• WS-X4148-RJ45V, page 1-18
• WS-X4248-FE-SFP, page 1-20
• WS-X4224-RJ45V, page 1-20
• WS-X4248-RJ21V, page 1-22
• WS-X4248-RJ45V, page 1-23
• WS-X4232-GB-RJ, page 1-24
• WS-X4232-L3, page 1-25
• WS-X4232-RJ-XX, page 1-27

WS-X4124-RJ45

The WS-X4124-RJ45 24-port Fast Ethernet switching module (see Figure 1-10) has the following specifications:
Specification Description
Module type 10/100BASE-TX Fast Ethernet switching module
Port duplex mode Half or full duplex mode
Port speed 10 or 100 Mbps
Catalyst 4500 Series Module Installation Guide
1-12
–
WS-U4504-FX-MT Uplink Module, page 1-28
78-13267-06
Chapter 1 Module Overview and Specifications
Ethernet and Fast Ethernet Switching Modules
Specification Description
Number of ports 24
Connector type RJ-45 (See Figure 2-1 on page 2-2.)
Cable type UTP
1. UTP = unshielded twisted-pair
Figure 1-10 WS-X4124-RJ45 24-Port 10/100BASE-TX Fast Ethernet Switching Module
1
or FTP
113135
78-13267-06
Catalyst 4500 Series Module Installation Guide
1-13
Chapter 1 Module Overview and Specifications
Ethernet and Fast Ethernet Switching Modules

WS-X4124-FX-MT

The WS-X4124-FX-MT 24-port Fast Ethernet switching module (see
Figure 1-11) has the following specifications:
Specification Description
Module type 100BASE-FX Fast Ethernet switching module
Port duplex mode Half or full duplex mode
Port speed 100 Mbps
Number of ports 24
Connector type MT-RJ fiber-optic (See Figure 2-4 on page 2-4.)
Cable type MMF
Figure 1-11 WS-X4124-FX-MT 24-Port 100BASE-FX Fast Ethernet Switching Module
W
S
-X 4 1
2
4
-F X
2
4 P
O
R
T
S
W
IT
C
H
1-14
-M T
1
0 0
B
A
S
E
-F X
IN
G
M
O
D
U
L E
STATUS
1
2
3
4
5
6
7
8
9
1
0
1 1
1
2
1
3
1
4
1 5
1
6
1 7
1
8
1
9
2
0
2
1
2
2
2
3
2
4
29216
Note Catalyst 4000 WS-X4124-FX-MT modules with hardware revisions 1.5 and
earlier are supported with the Supervisor Engines I (WS-X4012) and II (WS-X4013) only. Contact your technical support representative for a replacement if you need to use this module with another supervisor.
Catalyst 4500 Series Module Installation Guide
78-13267-06
Chapter 1 Module Overview and Specifications
Ethernet and Fast Ethernet Switching Modules

WS-X4148-FX-MT

The WS-X4148-FX-MT 48-port 100BASE-FX Fast Ethernet switching module (see Figure 1-12) has the following specifications:
Specification Description
Module type 100BASE-FX Fast Ethernet switching module
Port duplex mode Half or full duplex mode
Port speed 100 Mbps
Number of ports 48
Connector type MT-RJ fiber-optic (See Figure 2-4 on page 2-4.)
Cable type MMF
Figure 1-12 WS-X4148-FX-MT 48-Port 100BASE-FX Fast Ethernet Switching Module
1
WS-X4188-FX-MT
48 PORT 100BASE-FX SWITCHING MODULE
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
45
STATUS
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
47
42
44
46
48
49434

WS-X4148-RJ

78-13267-06
The WS-X4148-RJ 48-port Fast Ethernet switching module (see Figure 1-13) has the following specifications:
Specification Description
Module type 10/100BASE-TX Fast Ethernet switching module
Port duplex mode Half or full duplex mode
Port speed 10 or 100 Mbps
Number of ports 48
Catalyst 4500 Series Module Installation Guide
1-15
Chapter 1 Module Overview and Specifications
Ethernet and Fast Ethernet Switching Modules
Specification Description
Connector type RJ-45 (See Figure 2-1 on page 2-2.)
Cable type UTP
1. UTP = unshielded twisted-pair
Figure 1-13 WS-X4148-RJ 48-Port 10/100BASE-TX Fast Ethernet Switching Module
1
3
WS-X4148-RJ
5
7
2
9
4
11
6
8
S
T A
T
U
S
2
3
4
5
6
7
8
13
10
9
10
15
12
11
12
17
19
14
21
16
23
18
20
4 PO
RT
10
/100 B
aseT
13
14
15
16
17
18
19
25
22
20
21
27
24
22
24
23
29
31
26
33
28
35
30
32
34
36
25
27
26
28
ET
H
EN
E
T
S
W
ITC
H
IN
G
M
O D
U
LE
25
26
27
28
29
30
31
32
5
33
34
36
3
25
26
27
1
or FTP
29
31
33
35
30
32
34
36
28
29
30
31
32
33
34
36
35

WS-X4148-FE-BD-LC

The WS-X4148-FE-BD-LC 48-port 100BASE-BX10-D Fast Ethernet switching module (see Figure 1-14) has the following specifications:
17408
Specification Description
Module type 100BASE-BX10-D Fast Ethernet switching module
Port duplex mode Full duplex mode
Port speed 100 Mbps
Number of ports 48
Connector type Single LC (See Figure 1-15.)
Cable type SMF
Figure 1-14 WS-X4148-FE-BD-LC 48-Port Fast Ethernet Switching Module
WS-4448-GB-LX
STATUS
1 3 5 7
2 4 6 8
2 4 6 8
9 11 13 15
10 12 14 16
10 12 14 16
17 19 21 23
18 20 22 24
18 20 22 24
25 27 29 31
26 28 30 32
26 28 30 32
Catalyst 4500 Series Module Installation Guide
33 35 37 39
34 36 38 40
34 36 38 40
41 43 45 47
42 44 46 48
42 44 46 48
1-16
55780
78-13267-06
Chapter 1 Module Overview and Specifications
Figure 1-15 Single LC Connector

WS-X4148-FE-LX-MT

The WS-X4148-FE-LX-MT 48-port 100BASE-LX10 Fast Ethernet switching module (see Figure 1-16) has the following specifications:
Specification Description
Module type 100BASE-LX10 Fast Ethernet switching module
Port duplex mode Half or full duplex mode
Port speed 100 Mbps
Number of ports 48
Connector type MT-RJ fiber-optic (See Figure 2-4 on page 2-4.)
Cable type SMF
Ethernet and Fast Ethernet Switching Modules
105887
Figure 1-16 WS-X4148-FE-LX-MT 48-Port 100BASE-LX-MT Fast Ethernet Switching Module
1
WS-X4188-FX-MT
48 PORT 100BASE-FX SWITCHING MODULE
3
STATUS
2
4
78-13267-06
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
41
43
45
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
47
42
44
46
48
85381
Catalyst 4500 Series Module Installation Guide
1-17
Chapter 1 Module Overview and Specifications
Ethernet and Fast Ethernet Switching Modules

WS-X4148-RJ21

The WS-X4148-RJ21 48-port Fast Ethernet switching module (see Figure 1-17) has the following specifications:
Specification Description
Module type 10/100BASE-TX Fast Ethernet switching module
Port duplex mode Half or full duplex mode
Port speed 10 or 100 Mbps
Number of ports 48
Connector type RJ-21 (See Figure 2-5 on page 2-5 or Figure 2-6 on
page 2-5.)
Cable type Category 5 UTP
Figure 1-17 WS-X4148-RJ21 48-Port 10/100-Mbps Fast Ethernet Switching Module
W
S
-X 4 1
4
8
-R J 2
1
1
0 /1
0
0
F
A
S
T
E
T
H
E R
N
E
T
STATUS
1
2
3
45
6
7
8
9
10
11 12
13
14 15
16
17 18 19 20

WS-X4148-RJ45V

The WS-X4148-RJ45V 48-port Cisco pre-standard Power over Ethernet (PoE) 10/100BASE-TX switching module (see Figure 1-18) has the following specifications:
Specification Description
Module type 10/100BASE-TX Fast Ethernet switching module
Port duplex mode Half or full duplex mode
Port speed 10 or 100 Mbps
Catalyst 4500 Series Module Installation Guide
1-18
21 22
23 24
25
26
27 28
29
30
31
32
33 34
35 36
37 38
39
40 41
42 43
44 45
46
47
48
29217
with Cisco pre-standard PoE
78-13267-06
Chapter 1 Module Overview and Specifications
Ethernet and Fast Ethernet Switching Modules
Specification Description
Number of ports 48
Connector type RJ-45 (See Figure 2-1 on page 2-2.)
Cable type UTP
Power over Ethernet 6.3 W per-powered device on a port, on all 48 ports
Figure 1-18 WS-X4148-RJ45V 48-Port PoE 10/100BASE-TX Switching Module
1
3
WS-X4648-PWR
5
7
2
9
4
11
6
DC IN-LINE
STATUS
8
2
3
4
5
6
7
8
13
10
9
10
15
12
11
12
17
19
14
21
16
23
18
20
48 PO
R
T
IN
_ LIN
E P
O
W
E
R
13
14
15
16
17
18
19
25
22
20
21
27
24
22
24
23
29
31
26
33
28
35
30
32
34
36
25
27
29
31
26
33
28
35
30
32
34
36
10/100B
A
S E-TX
ETH
ER
N ET
25
26
27
9
S W
28
2
IT
C H
IN
30
G
31
32
6
5
33
34
3
3
M
O
D
U
LE
25
26
27
28
P
H
O
N
29
E
30
31
32
33
34
36
35
To provide PoE with the 48-port PoE 10/100BASE-TX switching module in a Catalyst 4006 switch, you must have a power entry module (PEM) and a power shelf installed. For more information about installing the PEM or the external power shelf, refer to the Catalyst 4000 Series Installation Guide, Catalyst 4500
Series Installation Guide, Installation and Configuration Note for the Catalyst 4500 Series AC Power Shelf, or the Catalyst 4500 Series Power Entry Module and External Power Shelf Installation Note.
To provide PoE with the 48-port PoE 10/100BASE-TX switching module in a Catalyst 4500 series switch, you must have a PoE-enabled power supply. All power supplies support PoE except the 1000 W and 1400 W AC power supplies.
41854
78-13267-06
Note Auto MDIX is not supported on PoE enabled switching modules.
Catalyst 4500 Series Module Installation Guide
1-19
Chapter 1 Module Overview and Specifications
Ethernet and Fast Ethernet Switching Modules

WS-X4248-FE-SFP

The WS-X4248-FE-SFP 48-port 100BASE-X Fast Ethernet switching module (see Figure 1-19) has the following specifications:
Specification Description
Module type 100BASE-X Fast Ethernet switching module
Port duplex mode Half or full duplex mode
Port speed 100 Mbps
Number of ports 48
Connector type LC type (See Figure 2-9 on page 2-6.)
Cable type MMF or SMF
SFP type FX, LX10, BX-D and BX-U
Figure 1-19 WS-X4248-FE-SFP 48-Port 100BASE-X Fast Ethernet Switching Module
WS-4448-GB-LX
STATUS
1 3 5 7
2 4 6 8
2 4 6 8
9 11 13 15
10 12 14 16
10 12 14 16
17 19 21 23
18 20 22 24
18 20 22 24

WS-X4224-RJ45V

The WS-X4224-RJ45V 24-port IEEE 802.3af-compliant PoE 10/100BASE-TX switching module (see Figure 1-20) has the following specifications:
Specification Description
Module type 10/100BASE-TX Fast Ethernet switching module
Port duplex mode Half or full duplex mode
Port speed 10 or 100 Mbps
Number of ports 24
Catalyst 4500 Series Module Installation Guide
1-20
25 27 29 31
26 28 30 32
26 28 30 32
33 35 37 39
34 36 38 40
34 36 38 40
41 43 45 47
42 44 46 48
42 44 46 48
with IEEE 802.3af PoE
55780
78-13267-06
Chapter 1 Module Overview and Specifications
Ethernet and Fast Ethernet Switching Modules
Specification Description
Connector type RJ-45 (See Figure 2-1 on page 2-2.)
Cable type UTP
Power over Ethernet Up to 15.4 W per powered device on all 24 ports
(to a 312 W total on the Catalyst 4006)
Power regulation Internal on the switching module
Figure 1-20 WS-X4224-RJ45V 24-Port IEEE 802.3af-Compliant PoE 10/100BASE-TX Switching Module
113136
To provide PoE with the 24-port PoE 10/100BASE-TX switching module in a Catalyst 4006 switch, you must have a power entry module (PEM) and a power shelf installed. The Catalyst 4006 switch can provide 312 W per PoE module to powered devices. If the powered devices are using the maximum 15.4 W per port, there is only enough power for 18 powered devices. If the powered devices are using less than 15.4 W per port, more powered devices can be powered, up to the 312 W maximum. For more information about installing the PEM or the external power shelf, refer to the Catalyst 4000 Series Installation Guide, Catalyst 4500
Series Installation Guide, Installation and Configuration Note for the Catalyst 4500 Series AC Power Shelf, or the Catalyst 4500 Series Power Entry Module and External Power Shelf Installation Note.
To provide PoE with the 24-port PoE 10/100BASE-TX switching module in a Catalyst 4500 series switch, you must have a PoE-enabled power supply. All power supplies support PoE except the 1000 W and 1400 W AC power supplies.
78-13267-06
Note Auto MDIX is not supported on PoE enabled switching modules.
Catalyst 4500 Series Module Installation Guide
1-21
Ethernet and Fast Ethernet Switching Modules

WS-X4248-RJ21V

The WS-X4248-RJ21V 48-port IEEE 802.3af-compliant PoE 10/100BASE-TX RJ-21 switching module (see Figure 1-21) has the following specifications:
Specification Description
Module type 10/100BASE-TX Fast Ethernet switching module
Port duplex mode Half or full duplex mode
Port speed 10 or 100 Mbps
Number of ports 48
Connector type RJ-21 (See Figure 2-5 on page 2-5 or Figure 2-6 on
Cable type Category 5 UTP
Power over Ethernet Up to 15.4 W per powered device on all 48 ports
Power regulation Internal on the switching module
Chapter 1 Module Overview and Specifications
with IEEE 802.3af PoE
page 2-5.)
(to a 312 W total on the Catalyst 4006)
Figure 1-21 WS-X4248-RJ21V IEEE 802.3af-Compliant PoE 48-Port 10/100-Mbps Switching Module
W
S
-X 4 1
4
8
-R J 2
1
1
0 /1
0
0
F
A
S
T
E
T
H
E R
N
E
T
STATUS
1
2
3
45
6
7
8
9
10
11 12
13
14 15
16
17 18 19 20
21 22
23 24
25
26
27 28
29
30
31
32
33 34
35 36
37 38
39
40 41
42 43
44 45
46
47
48
29217
To provide PoE with the 48-port PoE 10/100BASE-TX switching module in a Catalyst 4006 switch, you must have a power entry module (PEM) and power shelf installed. The Catalyst 4006 switch can provide 312 W per PoE module to powered devices. If the powered devices are using the maximum 15.4 W per port, there is only enough power for 18 powered devices. If the powered devices are using less than 15.4 W per port, more powered devices can be powered, up to the 312 W maximum. For more information about installing the PEM or the external power shelf, refer to the Catalyst 4000 Series Installation Guide, Catalyst 4500
Catalyst 4500 Series Module Installation Guide
1-22
78-13267-06
Chapter 1 Module Overview and Specifications
Series Installation Guide, Installation and Configuration Note for the Catalyst 4500 Series AC Power Shelf, or the Catalyst 4500 Series Power Entry Module and External Power Shelf Installation Note.
To provide PoE with the 48-port PoE 10/100BASE-TX switching module in a Catalyst 4500 series switch, you must have a PoE-enabled power supply. All power supplies support PoE except the 1000 W and 1400 W AC power supplies.
Note Auto MDIX is not supported on PoE enabled switching modules.

WS-X4248-RJ45V

The WS-X4248-RJ45V 48-port IEEE 802.3af-compliant PoE 10/100BASE-TX switching module (see Figure 1-22) has the following specifications:
Specification Description
Module type 10/100BASE-TX Fast Ethernet switching module
Port duplex mode Half or full duplex mode
Port speed 10 or 100 Mbps
Number of ports 48
Connector type RJ-45 (See Figure 2-1 on page 2-2.)
Cable type UTP
Power over Ethernet Up to 15.4 W per powered device on all 48 ports
Power regulation Internal on the switching module
Ethernet and Fast Ethernet Switching Modules
with IEEE 802.3af PoE
(to a 312 W total on the Catalyst 4006)
Figure 1-22 WS-X4248-RJ45V 48-Port IEEE 802.3af-Compliant PoE 10/100BASE-TX Switching Module
1
3
WS-X4648-PWR
5
7
2
9
4
11
6
DC IN-LINE
STATUS
2
3
4
78-13267-06
8
5
6
7
8
13
10
9
10
15
12
11
12
17
19
14
21
16
23
18
20
48 P
O
R
T
IN
_L
IN
E
P
O
W
E
R
13
14
15
16
17
18
19
25
22
20
21
27
24
22
24
23
29
31
26
33
28
35
30
32
34
36
25
27
29
31
26
33
28
35
30
32
34
36
10
/100B
A
S E
-TX
E
TH
E
R
N E
T
25
26
27
28
S W
IT
C
H
IN
29
30
G
31
32
33
34
36
35
M
O
D
U
L E
25
26
27
28
P
H
O
N
29
E
30
31
32
33
34
36
35
85382
Catalyst 4500 Series Module Installation Guide
1-23
Ethernet and Fast Ethernet Switching Modules
To provide PoE with the 48-port PoE 10/100BASE-TX switching module in a Catalyst 4006 switch, you must have a power entry module (PEM) and a power shelf installed. The Catalyst 4006 switch can provide 312 W per PoE module to powered devices. If the powered devices are using the maximum 15.4 W per port, there is only enough power for 18 powered devices. If the powered devices are using less than 15.4 W per port, more powered devices can be powered, up to the 312 Watt maximum. For more information about installing the PEM or the external power shelf, refer to the Catalyst 4000 Series Installation Guide,
Catalyst 4500 Series Installation Guide, Installation and Configuration Note for the Catalyst 4500 Series AC Power Shelf, or the Catalyst 4500 Series Power Entry Module and External Power Shelf Installation Note.
To provide PoE with the 48-port PoE 10/100BASE-TX switching module in a Catalyst 4500 series switch, you must have a PoE-enabled power supply. All power supplies support PoE except the 1000 W and 1400 W AC power supplies.
Note Auto MDIX is not supported on PoE enabled switching modules.
Chapter 1 Module Overview and Specifications

WS-X4232-GB-RJ

The WS-X4232-GB-RJ 34-port Ethernet switching module (see Figure 1-23) has the following specifications:
Specification Description
Module type 10/100BASE-TX Ethernet plus 1000BASE-X Gigabit
Port duplex mode Half or full duplex mode on the 10/100BASE-TX
Port speed 10, 100, and 1000 Mbps
Number of ports 32 10/100BASE-TX ports
Catalyst 4500 Series Module Installation Guide
1-24
Ethernet switching module
ports Full duplex mode on the 1000BASE-X ports
2 1000BASE-X
1
ports
78-13267-06
Chapter 1 Module Overview and Specifications
Ethernet and Fast Ethernet Switching Modules
Specification Description
Connector type RJ-45 10/100BASE-TX ports (See Figure 2-1 on
page 2-2.)
SC-type 1000BASE-X ports
page 2-18.)
Cable type Category 5 UTP (10/100BASE-TX)
MMF or SMF (1000BASE-X)
1. See the “Installing, Removing, and Maintaining GBICs” section on page 2-8 for GBIC support information.
Figure 1-23 WS-X4232-GB-RJ 2-Port Gigabit and 32-Port 10/100BASE-T Ethernet Switching Module
1
(See Figure 2-16 on

WS-X4232-L3

1
13
1
13
16672
The WS-X4232-L3 Layer 3 services module (see Figure 1-24) has the following specifications:
Specification Description
Module type Layer 3 services module
Port duplex mode Half or full duplex mode on the 10/100BASE-TX
ports Full duplex mode on the 1000BASE-X Layer 3 ports
Port speed 10, 100, and 1000 Mbps
Number of ports 32 10/100BASE-TX ports
2 1000BASE-X ports 1 console port 1 10BASE-T uplink port
78-13267-06
Catalyst 4500 Series Module Installation Guide
1-25
Ethernet and Fast Ethernet Switching Modules
Specification Description
Connector type RJ-45 10/100BASE-TX ports (See Figure 2-1 on
page 2-2.)
SC-type 1000BASE-X ports
page 2-18.)
RJ-45 (console and 10BASE-T ports) (See Figure 2-1
on page 2-2.)
Cable type Category 5 UTP (10/100BASE-TX)
MMF or SMF (1000BASE-X) Category 3 or Category 5 UTP (console and 10BASE-T ports)
1. See the “Installing, Removing, and Maintaining GBICs” section on page 2-8 for GBIC support information.
For more information, refer to the Installation and Configuration Note for the
Catalyst 4000 Layer 3 Services Module.
Figure 1-24 WS-X4232-L3 Layer 3 Services Module
Chapter 1 Module Overview and Specifications
1
(See Figure 2-16 on
W
S
-X 4 2
3
2
-L 3
1
0/1
0
0 B
A
S
E
X
L3
R
O
U TIN
G
M
1-26
C
O
N S
O
LE
1
0B
A
S
E
-M G
T
3
L
IN
K
U P
L
IN
-T X
O
D
U
LE S
T
A
T
U
S
K
1
4
2
3
4
5
6
7
8
9
10
17
19
18
11
20
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
33
34
27
28
29
30
31
32
33
34
29219
Catalyst 4500 Series Module Installation Guide
78-13267-06
Chapter 1 Module Overview and Specifications

WS-X4232-RJ-XX

The WS-X4232-RJ-XX 32-port Ethernet switching module (see Figure 1-25) has the following specifications:
Specification Description
Module type 10/100BASE-TX plus 100BASE-FX Ethernet
Port duplex mode Half or full duplex mode on both the
Port speed 10 and 100 Mbps
Number of ports 32 10/100BASE-TX ports
Connector type RJ-45 32 10/100BASE-TX ports (See Figure 2-1 on
Cable type Category 5 UTP (10/100BASE-TX)
Ethernet and Fast Ethernet Switching Modules
switching module
10/100BASE-TX and the 100BASE-FX ports
4 optional 100BASE-FX ports on an optional uplink module (WS-U4504-FX-MT)
page 2-2.)
MT-RJ for the 4 optional ports 100BASE-FX (See
Figure 2-4 on page 2-4.)
MMF or SMF (100BASE-FX)
Figure 1-25 WS-X4232-RJ-XX 32-port Ethernet Switching Module
W
S
-X 4
2
3
2
-R J
-X X
1
0
/1
0
0
F
E
STATUS
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
W
S
-U 4
5
0
4
-F X
-M T
N+1
N+2
N+3
28
29
30
31
32
N+4
U
P
L
IN
K
S
T A
T
U
S
Note The WS-X4232-RJ-XX Ethernet switching module can operate with or without
the WS-U4504-FX-MT uplink module installed.
Catalyst 4500 Series Module Installation Guide
78-13267-06
28472
1-27
Ethernet and Fast Ethernet Switching Modules

WS-U4504-FX-MT Uplink Module

The WS-U4504-FX-MT uplink module (see Figure 1-26) has the following specifications:
Specification Description
Module type 100BASE-FX uplink module
Port duplex mode Half or full duplex mode
Port speed 100 Mbps
Number of ports 4
Connector type MT-RJ (See Figure 2-4 on page 2-4.)
Cable type MMF cable
Figure 1-26 WS-U4504-FX-MT Uplink Module
WS-U4504-FX-MT
Chapter 1 Module Overview and Specifications
N+1
1-28
N+2
N+3
N+4
The WS-U4504-FX-MT uplink module is installed onto a switching module to provide optional port configurations.
Each port has a port link status LED below it, which is labeled N+x. The N indicates the last number of the port that is used on the Ethernet switching module (WS-X4232-RJ-XX).
For the far left port on the WS-U4504-FX-MT uplink module, add 1 to that number; for the second port, add 2; for the third port, add 3; for the last port, add 4.
Catalyst 4500 Series Module Installation Guide
23837
78-13267-06
Chapter 1 Module Overview and Specifications

Gigabit Ethernet Switching Modules

This section describes the Catalyst 4500 series Gigabit Ethernet switching modules and includes the following sections:
• WS-X4302-GB, page 1-29
• WS-X4306-GB, page 1-30
• WS-X4506-GB-T, page 1-31
• WS-X4412-2GB-T, page 1-33
• WS-X4418-GB, page 1-34
• WS-X4424-GB-RJ45, page 1-35
• WS-X4448-GB-LX, page 1-36
• WS-X4448-GB-RJ45, page 1-37
• WS-X4524-GB-RJ45V, page 1-38
• WS-X4548-GB-RJ45, page 1-39
• WS-X4448-GB-SFP, page 1-40
Gigabit Ethernet Switching Modules

WS-X4302-GB

78-13267-06
• WS-X4548-GB-RJ45V, page 1-41
• WS-X4019, page 1-42
• Access Gateway Module (WS-X4604-GWY), page 1-43
The WS-X4302-GB 2-port Gigabit Ethernet switching module (see Figure 1-27) has the following specifications:
Specification Description
Module type 1000BASE-X Gigabit Ethernet switching module
Port duplex mode Full duplex mode
Port speed 1000 Mbps
Number of ports 2
Catalyst 4500 Series Module Installation Guide
1-29
Chapter 1 Module Overview and Specifications
Gigabit Ethernet Switching Modules
Specification Description
Connector type SC type
Cable type MMF or SMF
1. See the “Installing, Removing, and Maintaining GBICs” section on page 2-8 for GBIC support information.
Figure 1-27 WS-X4302-GB 2-Port Gigabit Ethernet Switching Module
1
(See Figure 2-16 on page 2-18.)

WS-X4306-GB

1
2
94138
The WS-X4306-GB 6-port Gigabit Ethernet switching module (see Figure 1-28) has the following specifications:
Specification Description
Module type 1000BASE-X Gigabit Ethernet switching module
Port duplex mode Full duplex mode
Port speed 1000 Mbps
Number of ports 6
Connector type SC type
1
(See Figure 2-16 on page 2-18.)
Cable type MMF or SMF
1. See the “Installing, Removing, and Maintaining GBICs” section on page 2-8 for GBIC support information.
1-30
Catalyst 4500 Series Module Installation Guide
78-13267-06
Chapter 1 Module Overview and Specifications
Figure 1-28 WS-X4306-GB 6-Port Gigabit Ethernet Switching Module

WS-X4506-GB-T

The WS-X4506-GB-T 6-port Gigabit Ethernet switching module (see
Figure 1-28) has the following specifications:
Specification Description
Module type 10/100/1000BASE-T Fast Ethernet with IEEE802.3af
PoE or 1000BASE-X SFP Gigabit Ethernet switching module
Port duplex mode Half or full duplex mode
Port speed 10, 100, or 1000 Mbps
Number of ports 6 total
Connector type RJ-45 (See Figure 2-1 on page 2-2.)
LC type (See Figure 2-9 on page 2-6.)
Cable type Category 5 UTP (1000BASE-T)
MMF or SMF (1000BASE-X, LX fiber-optic cable only)
Power over Ethernet Up to 15.4 W per powered device on all 6 ports
Gigabit Ethernet Switching Modules
16673
78-13267-06
Note There are six10/100/1000BASE-T and six 1000BASE-X SFP Gigabit Ethernet
connectors present. Use the select media sfp | rj45 command to set whether a specific port number uses the SFP or RJ-45 connector. SFP is the default.
Catalyst 4500 Series Module Installation Guide
1-31
Chapter 1 Module Overview and Specifications
Gigabit Ethernet Switching Modules
Figure 1-29 WS-X4506-GB-T 6-Port Gigabit Ethernet Switching Module
To provide PoE with the 6-port Gigabit Ethernet switching module in a Catalyst 4006 switch, you must have a power entry module (PEM) and power shelf installed. For more information about installing the PEM or the external power shelf, refer to the Catalyst 4000 Series Installation Guide, Catalyst 4500 Series
Installation Guide, Installation and Configuration Note for the Catalyst 4500 Series AC Power Shelf, or the Catalyst 4500 Series Power Entry Module and External Power Shelf Installation Note.
To provide PoE with the 6-port Gigabit Ethernet switching module in a Catalyst 4500 series switch, you must have a PoE-enabled power supply.
Note Auto MDIX is not supported on PoE enabled switching modules.
113137
1-32
Catalyst 4500 Series Module Installation Guide
78-13267-06
Chapter 1 Module Overview and Specifications

WS-X4412-2GB-T

The WS-X4412-2GB-T 14-port Gigabit Ethernet switching module (see
Figure 1-30) has the following specifications:
Specification Description
Module type 1000BASE-T plus 1000BASE-X Gigabit Ethernet
Port duplex mode Full duplex mode
Port speed 1000 Mbps
Number of ports 12 1000BASE-T ports
Connector type RJ-45 for the 12 1000BASE-T ports (See Figure 2-1
Cable type Category 5 UTP (1000BASE-T)
1. See the “Installing, Removing, and Maintaining GBICs” section on page 2-8 for GBIC support information.
Gigabit Ethernet Switching Modules
switching module
2 optional 1000BASE-X
on page 2-2.)
SC-type for the 2 1000BASE-X ports
Figure 2-16 on page 2-18.)
MMF or SMF (1000BASE-X)
1
uplink ports
1
(See
Figure 1-30 WS-X4412-2GB-T 14-Port Gigabit Ethernet Switching Module
W
S
-X 4 4
1
2
-2 G
B
-T X
100
0
B
A S
E
-TX G
IG
A
B
IT E
TH
E R
N
E T
S
W
ITC
H
IN
G
M
O
D
U
LE
S
T
A
T
U
S
1
2
3
4
5
6
7
8
9
10
11
12
17
18
Some Gigabit Ethernet ports on the WS-X4412-2GB-T switching module are oversubscribed. For additional information on these ports, see the “Configuring
Gigabit Ethernet Ports” section on page 3-9.
Note You must use Category 5 cables when connecting to the 1000BASE-T ports on
this switching module.
Catalyst 4500 Series Module Installation Guide
78-13267-06
29319
1-33
Gigabit Ethernet Switching Modules
The two Gigabit Ethernet ports can be configured with any combination of shortwave (SX), longwave/long-haul (LX/LH), and long-range (ZX) GBICs. For a description of GBICs, see the “Installing, Removing, and Maintaining GBICs”
section on page 2-8.

WS-X4418-GB

The WS-X4418-GB 18-port Gigabit Ethernet switching module (see Figure 1-31) has the following specifications:
Chapter 1 Module Overview and Specifications
Specification Description
Module type 1000BASE-X Gigabit Ethernet switching module
Port duplex mode Full duplex mode
Port speed 1000 Mbps
Number of ports 18
Connector type SC type
Cable type MMF or SMF
1. See the “Installing, Removing, and Maintaining GBICs” section on page 2-8 for GBIC support information.
1
(See Figure 2-16 on page 2-18.)
Figure 1-31 WS-X4418-GB 18-Port Gigabit Ethernet Switching Module
Some ports on this switching module are oversubscribed. For further information on these ports, see the “Configuring Gigabit Ethernet Ports” section on page 3-9.
Note WS-X4418-GB does not support WS-G5483, which is the 1000BASE-T GBIC.
Catalyst 4500 Series Module Installation Guide
1-34
18147
78-13267-06
Chapter 1 Module Overview and Specifications
The ports on this switching module can be configured with any combination of shortwave (SX), longwave/long-haul (LX/LH), and long-range (ZX) GBICs. For a description of GBICs, see the “Installing, Removing, and Maintaining GBICs”
section on page 2-8.

WS-X4424-GB-RJ45

The WS-X4424-GB-RJ45 24-port 10/100/1000BASE-T Gigabit Ethernet switching module (see Figure 1-32) has the following specifications:
Specification Description
Module type 10/100/1000 Fast or Gigabit Ethernet switching
Port duplex mode Half or full duplex mode at 10 and 100 Mbps; full
Port speed 10, 100, or 1000 Mbps
Number of ports 24
Connector type RJ-45 (See Figure 2-1 on page 2-2.)
Cable type UTP
Gigabit Ethernet Switching Modules
module
duplex mode only at 1000 Mbps
Note You must use Category 5 cables when connecting to the 1000BASE-T ports on
this switching module.
Figure 1-32 WS-X4424-GB-RJ45 24-Port 10/100/1000BASE-T Gigabit Ethernet Switching Module
WS-X4424-GB-RJ45
STATUS
1 1
2
3
4
5
24 PORT
10/1000/BASE-T
6
7
8
9
10
11
12
MULIT-SPEED
GIGABIT ETHERNET SWITCHING
MODULE
13
14
15
16
17
18
19
20
21
22
23
24
49435
Ports on this switching module may be oversubscribed, depending on utilization. For further information on these ports, see the “Configuring Gigabit Ethernet
Ports” section on page 3-9.
Catalyst 4500 Series Module Installation Guide
78-13267-06
1-35
Chapter 1 Module Overview and Specifications
Gigabit Ethernet Switching Modules

WS-X4448-GB-LX

The WS-X4448-GB-LX 48-port Gigabit Ethernet switching module (see
Figure 1-33) has the following specifications:
Specification Description
Module type 1000BASE-X Gigabit Ethernet switching module
Port duplex mode Full duplex mode
Port speed 1000 Mbps
Number of ports 48
Connector type LC type (See Figure 2-9 on page 2-6.)
Cable type MMF or SMF (LX fiber-optic cable only)
Figure 1-33 WS-X4448-GB-LX 48-Port Gigabit Ethernet Switching Module
WS-4448-GB-LX
STATUS
1 3 5 7
2 4 6 8
2 4 6 8
9 11 13 15
10 12 14 16
10 12 14 16
17 19 21 23
18 20 22 24
18 20 22 24
25 27 29 31
26 28 30 32
26 28 30 32
33 35 37 39
34 36 38 40
34 36 38 40
41 43 45 47
42 44 46 48
42 44 46 48
55780
1-36
Ports on this switching module may be oversubscribed, depending on utilization. For further information on these ports, see the “Configuring Gigabit Ethernet
Ports” section on page 3-9.
The 48 ports can be configured with any combination of small, form-factor pluggable (SFP) modules. For a description of SFP modules, see the “Installing
SFP Modules” section on page 2-22.
Problem Insertion of unsupported SFPs (small form-factor pluggable optics) into
a WS-X4448-GB-LX module can cause undetected communication failures between the supervisor engine and the corresponding module. Subsequent insertion or removal of SFPs from the module is not recognized by the system. This activity can be observed on a Catalyst 4500 series switch using Release
12.1(12c)EW1 or later releases.
Solution Reset the module with the hw-module module reset command.
(CSCee05078)
Catalyst 4500 Series Module Installation Guide
78-13267-06
Chapter 1 Module Overview and Specifications

WS-X4448-GB-RJ45

The WS-X4448-GB-RJ45 48-port 10/100/1000BASE-T Gigabit Ethernet switching module (see Figure 1-34) has the following specifications:
Specification Description
Module type 10/100/1000 Fast or Gigabit Ethernet switching
Port duplex mode Half or full duplex mode at 10 and 100 Mbps; full
Port speed 10, 100, or 1000 Mbps
Number of ports 48
Connector type RJ-45 (See Figure 2-1 on page 2-2.)
Cable type UTP
Gigabit Ethernet Switching Modules
module
duplex mode only at 1000 Mbps
Note You must use Category 5 cables when connecting to the 1000BASE-T ports on
this switching module.
Figure 1-34 WS-X4448-GB-RJ45 48-Port 10/100/1000BASE-T Gigabit Ethernet Switching Module
WS-X4448-GB-RJ45
STATUS
1
2
3
4
5
6
7
8
1 0
/1
0
0 B
9
A
S E
-T
10
X
11
12
13
E T
H
E
R N
E
14
T
15
16
17
18
19
20
21
22
23
24
M
U L
T
I-S
P
E E
D G IG
25
A
26
B
IT E
T H
27
E
R
N
E T
28
29
30
S
31
W
IT
C H
IN
32
G
M
O
D
U
L
E
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
63419
Ports on this switching module may be oversubscribed, depending on utilization. For further information on these ports, see the “Configuring Gigabit Ethernet
Ports” section on page 3-9.
Catalyst 4500 Series Module Installation Guide
78-13267-06
1-37
Gigabit Ethernet Switching Modules

WS-X4524-GB-RJ45V

The WS-X4524-GB-RJ45V 24-port IEEE 802.3af-compliant PoE 10/100/1000BASE-T RJ-45 switching module (see Figure 1-35) has the following specifications:
Specification Description
Module type 10/100/1000BASE-T Fast Ethernet switching module
Port duplex mode Half or full duplex mode
Port speed 10, 100, or 1000 Mbps
Number of ports 24
Connector type RJ-45 (See Figure 2-1 on page 2-2.)
Cable type UTP
Power over Ethernet Up to 15.4 W per powered device on all 24 ports
Chapter 1 Module Overview and Specifications
with IEEE802.3af PoE
(to a 312 W total on the Catalyst 4006)
Figure 1-35 WS-X4524-GB-RJ45V 24-Port IEEE-Compliant PoE 10/100/1000BASE-T Switching Module
113138
To provide PoE with the 24-port PoE 10/100BASE-TX switching module in a Catalyst 4006 switch, you must have a power entry module (PEM) and a power shelf installed. The Catalyst 4006 switch can provide 312 W per PoE module to powered devices. If the powered devices are using the maximum 15.4 W per port, there is only enough power for 18 powered devices. If the powered devices are using less than 15.4 W per port, more powered devices can be powered, up to the 312 Watt maximum. For more information about installing the PEM or the external power shelf, refer to the Catalyst 4000 Series Installation Guide,
Catalyst 4500 Series Installation Guide, Installation and Configuration Note for the Catalyst 4500 Series AC Power Shelf, or the Catalyst 4500 Series Power Entry Module and External Power Shelf Installation Note.
Catalyst 4500 Series Module Installation Guide
1-38
78-13267-06
Chapter 1 Module Overview and Specifications
To provide PoE with the 24-port PoE 10/100/1000BASE-T switching module in a Catalyst 4500 series switch, you must have an PoE-enabled power supply. All power supplies support PoE except the 1000 W and 1400 W AC power supplies.
Note Auto MDIX is not supported on PoE enabled switching modules.

WS-X4548-GB-RJ45

The WS-X4548-GB-RJ45 48-port 10/100/1000BASE-T Gigabit Ethernet switching module (see Figure 1-36) has the following specifications:
Specification Description
Module type 10/100/1000 Fast or Gigabit Ethernet switching
Port duplex mode Half or full duplex mode at 10 and 100 Mbps; full
Port speed 10, 100, or 1000 Mbps
Number of ports 48
Connector type RJ-45 (See Figure 2-1 on page 2-2.)
Cable type UTP
Gigabit Ethernet Switching Modules
module
duplex mode only at 1000 Mbps
Note You must use Category 5 cables when connecting to the 1000BASE-T ports on
this switching module.
Figure 1-36 WS-X4548-GB-RJ45 48-Port 10/100/1000BASE-T Gigabit Ethernet Switching Module
WS-X4448-GB-RJ45
STATUS
1
2
3
4
5
6
78-13267-06
7
8
1 0
/1
0
0 B
9
A
S E
-T
10
X
11
12
13
E T
H
E
R N
E
14
T
15
16
17
18
19
20
21
22
23
24
M
U L
T
I-S
P
E E
D G IG
25
A
26
B
IT E
T H
27
E
R
N
E T
28
29
30
S
31
W
IT
C H
IN
32
G
M
O
D
U
L
E
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
63419
Catalyst 4500 Series Module Installation Guide
1-39
Gigabit Ethernet Switching Modules
Ports on this switching module may be oversubscribed, depending on utilization. For further information on these ports, see the “Configuring Gigabit Ethernet
Ports” section on page 3-9.

WS-X4448-GB-SFP

The WS-X4448-GB-SFP 48-port Gigabit Ethernet switching module (see
Figure 1-37) has the following specifications:
Specification Description
Module type 1000BASE-X Gigabit Ethernet switching module
Port duplex mode Full duplex mode
Port speed 1000 Mbps
Number of ports 48
Connector type LC type (See Figure 2-9 on page 2-6.)
Cable type MMF or SMF
SFP type SX, LX, Copper 1000BASE-T, BX10-D and BX10-U
Chapter 1 Module Overview and Specifications
Figure 1-37 WS-X4448-GB-SFP 48-Port Gigabit Ethernet Switching Module
WS-4448-GB-LX
STATUS
1 3 5 7
2 4 6 8
2 4 6 8
9 11 13 15
10 12 14 16
10 12 14 16
17 19 21 23
18 20 22 24
18 20 22 24
25 27 29 31
26 28 30 32
26 28 30 32
33 35 37 39
34 36 38 40
34 36 38 40
41 43 45 47
42 44 46 48
42 44 46 48
Ports on this switching module may be oversubscribed, depending on utilization. For further information on these ports, see the “Configuring Gigabit Ethernet
Ports” section on page 3-9.
For a description of SFP modules, see the “Installing SFP Modules” section on
page 2-22.
Problem Insertion of unsupported SFPs (small form-factor pluggable optics) into
a WS-X4448-GB-SFP module can cause undetected communication failures between the supervisor engine and the corresponding module. Subsequent
Catalyst 4500 Series Module Installation Guide
1-40
55780
78-13267-06
Chapter 1 Module Overview and Specifications
insertion or removal of SFPs from the module is not recognized by the system. This activity can be observed on a Catalyst 4500 series switch using Release
12.1(12c)EW1 or later releases.
Solution Reset the module with the hw-module module reset command.
(CSCee05078)

WS-X4548-GB-RJ45V

The WS-X4548-GB-RJ45V 48-port IEEE 802.3af-compliant PoE 10/100/1000BASE-T RJ-45 switching module (see Figure 1-38) has the following specifications:
Specification Description
Module type 10/100/1000BASE-T Fast Ethernet switching module
Port duplex mode Half or full duplex mode
Port speed 10, 100, or 1000 Mbps
Number of ports 48
Connector type RJ-45 (See Figure 2-1 on page 2-2.)
Cable type UTP
Power over Ethernet Up to 15.4 W per powered device on all 48 ports
Gigabit Ethernet Switching Modules
with IEEE802.3af PoE
(to a 312 W total on the Catalyst 4006)
Figure 1-38 WS-X4548-GB-RJ45V 48-Port IEEE-Compliant PoE 10/100/1000BASE-T Switching Module
WS-X4448-GB-RJ45
STATUS
1
2
3
4
5
6
7
8
1 0
/1
0
0 B
9
A
S E
-T
10
X
11
12
13
E T
H
E
R N
E
14
T
15
16
17
18
19
20
21
22
23
24
M
U L
T
I-S
P
E E
D G IG
25
A
26
B
IT E
T H
27
E
R
N
E T
28
29
30
S
31
W
IT
C H
IN
32
G
M
O
D
U
L
E
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
63419
To provide PoE with the 48-port PoE 10/100BASE-TX switching module in a Catalyst 4006 switch, you must have a power entry module (PEM) and a power shelf installed. The Catalyst 4006 switch can provide 312 W per PoE module to powered devices. If the powered devices are using the maximum 15.4 W per port,
Catalyst 4500 Series Module Installation Guide
78-13267-06
1-41

Other Switching Modules

there is only enough power for 18 powered devices. If the powered devices are using less than 15.4 W per port, more powered devices can be powered, up to the 312 W maximum. For more information about installing the PEM or the external power shelf, refer to the Catalyst 4000 Series Installation Guide, Catalyst 4500
Series Installation Guide, Installation and Configuration Note for the Catalyst 4500 Series AC Power Shelf, or the Catalyst 4500 Series Power Entry Module and External Power Shelf Installation Note.
To provide PoE with the 48-port PoE 10/100/1000BASE-T switching module in a Catalyst 4500 series switch, you must have an PoE-enabled power supply. All power supplies support PoE except the 1000 W and 1400 W AC power supplies.
Note Auto MDIX is not supported on PoE enabled switching modules.
Other Switching Modules
This section describes other Catalyst 4500 series switching modules and includes the following sections:
• WS-X4019, page 1-42
• Access Gateway Module (WS-X4604-GWY), page 1-43
Chapter 1 Module Overview and Specifications

WS-X4019

Catalyst 4500 Series Module Installation Guide
1-42
The WS-X4019 backplane channel module (see Figure 1-39) has the following specifications:
Specification Description
Module type Backplane channel module
Port duplex mode –
Port speed –
Number of ports 0
78-13267-06
Chapter 1 Module Overview and Specifications
Specification Description
Connector type –
Cable type –
Figure 1-39 WS-X4019 Backplane Channel Module

Switching Module LEDs

STATUS
Note The backplane channel module is supported by only the WS-X4013 supervisor
engine in the Catalyst 4006, 4503, or 4506 switches using the Catalyst Operating System.

Access Gateway Module (WS-X4604-GWY)

The Access Gateway Module is described in the Catalyst 4000 Access Gateway
Module Installation and Configuration Note (DOC-7810818).
Switching Module LEDs
Each switching module has one LED labeled STATUS that provides information about the module and one numbered LED labeled LINK for each port on the module. Figure 1-40 shows the Gigabit Ethernet port and status LEDs.
Figure 1-41 shows the 10/100BASE-T port LEDs. Ta bl e 1- 3 describes the
switching module LEDs.
38301
78-13267-06
Catalyst 4500 Series Module Installation Guide
1-43
Switching Module LEDs
Chapter 1 Module Overview and Specifications
Figure 1-40 Gigabit Ethernet Port and Status LEDs
WS-X4306-GB GIGABIT ETHERNET
STATUS
1000BASE-X SWITCHING MODULE
1
Figure 1-41 10/100BASE-T Port LEDs
7
5
3
WS-X4148-RJ
1
4
2
8
6
2 3
9
11
12
10
26854
1-44
STATUS
5
4
Table 1-3 Switching Module LEDs
LED Color/State Description
STATUS Indicates the results of a series of self-tests and
Green All the tests pass.
Red A test other than an individual port test failed.
Orange System boot, self-test diagnostics running, or the
1
LINK
Green The port is operational (a signal is detected).
Orange The link has been disabled by software.
Flashing orange
Off No signal is detected.
Catalyst 4500 Series Module Installation Guide
4 PORT
7
6
8
9
10
10/100 B
11
12
17407
diagnostic tests performed by the switch.
module is disabled.
Indicates the status of the 10BASE-T port.
The link has been disabled due to a hardware failure.
78-13267-06
Chapter 1 Module Overview and Specifications
Table 1-3 Switching Module LEDs (continued)
LED Color/State Description
Port
2
Status
Green The port is operational (a signal is detected).
Orange The link has been disabled by software.
Flashing orange
Off No signal is detected.
1. Used on the WS-X4232-L3 Ethernet routing module.
2. LEDs labeled 1 through the number of ports on the switching module are the individual port link LEDs.

Hot-Swapping Feature

Hot-Swapping Feature
Indicates individual port status.
The link has been disabled due to a hardware failure.
78-13267-06
Catalyst 4500 series switches allow you to remove and replace switching modules without powering down the switch. This feature is known as hot swapping.
When you remove or insert a switching module while the switch is operating, the system does the following:
1. Scans the backplane for configuration changes.
2. Initializes all newly inserted switching modules, notes any removed modules,
and places them in the administratively shutdown state.
3. Places any previously configured interfaces on the switching module back to
the state they were in when they were removed. Any newly inserted interfaces are put in the administratively shutdown state, as if they were present (but unconfigured) at boot time. If you insert a similar switching-module type into a slot, its ports are configured and brought online up to the port count of the original switching module.
The system runs diagnostic tests on any new interfaces. If the test passes, the system is operating normally. If the new switching module is faulty, the system resumes normal operation but places the new module in the “faulty” state.
If the diagnostic test fails, the system crashes, which usually indicates that the new switching module has a problem and should be removed.
Catalyst 4500 Series Module Installation Guide
1-45
Hot-Swapping Feature
Caution To avoid erroneous failure messages, allow at least 15 seconds for the system to
Chapter 1 Module Overview and Specifications
reinitialize, and note the current configuration of all interfaces before you remove or insert another switching module.
When you hot swap switching modules, the system displays status messages on the console screen. The following sample display shows the messages logged by the system when a switching module is removed from slot 2:
Console> (enable) 2001 Sep 09 12:23:26 %SYS-5-MOD_REMOVE:Module 3 has been removed Console> (enable) 2001 Sep 09 12:23:44 %SYS-5-MOD_INSERT:Module 3 has been inserted Console> (enable) 2001 Sep 09 12:23:47 %SYS-5-MOD_OK:Module 3 is online Console> (enable)
If you use the show port command to query the module before reinstalling a module to replace the removed one, the system responds, “Module 3 is not installed.” When the module is reinserted, the system recognizes the module as ready again.
1-46
Catalyst 4500 Series Module Installation Guide
78-13267-06
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
