Cisco Catalyst Blade Switch 3020 for HP
Command Reference
Cisco IOS Release 12.2(25)SEF
June 2006
Text Part Number: OL-8916-01
THE SPECIFICATIONS AND INFORMATION REGARDING THE PRODUCTS IN THIS MANUAL ARE SUBJECT TO CHANGE WITHOUT NOTICE. ALL
STATEMENTS, INFORMATION, AND RECOMMENDATIONS IN THIS MANUAL ARE BELIEVED TO BE ACCURATE BUT ARE PRESENTED WITHOUT
WARRANTY OF ANY KIND, EXPRESS OR IMPLIED. USERS MUST TAKE FULL RESPONSIBILITY FOR THEIR APPLICATION OF ANY PRODUCTS.
THE SOFTWARE LICENSE AND LIMITED WARRANTY FOR THE ACCOMPANYING PRODUCT ARE SET FORTH IN THE INFORMATION PACKET THAT
SHIPPED WITH THE PRODUCT AND ARE INCORPORATED HEREIN BY THIS REFERENCE. IF YOU ARE UNABLE TO LOCATE THE SOFTWARE LICENSE
OR LIMITED WARRANTY, CONTACT YOUR CISCO REPRESENTATIVE FOR A COPY.
The Cisco implementation of TCP header compression is an adaptation of a program developed by the University of California, Berkeley (UCB) as part of UCB’s public
domain version of the UNIX operating system. All rights reserved. Copyright © 1981, Regents of the University of California.
NOTWITHSTANDING ANY OTHER WARRANTY HEREIN, ALL DOCUMENT FILES AND SOFTWARE OF THESE SUPPLIERS ARE PROVIDED “AS IS” WITH
ALL FAULTS. CISCO AND THE ABOVE-NAMED SUPPLIERS DISCLAIM ALL WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING, WITHOUT
LIMITATION, THOSE OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OR ARISING FROM A COURSE OF
DEALING, USAGE, OR TRADE PRACTICE.
IN NO EVENT SHALL CISCO OR ITS SUPPLIERS BE LIABLE FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, OR INCIDENTAL DAMAGES, INCLUDING,
WITHOUT LIMITATION, LOST PROFITS OR LOSS OR DAMAGE TO DATA ARISING OUT OF THE USE OR INABILITY TO USE THIS MANUAL, EVEN IF CISCO
OR ITS SUPPLIERS HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
CCSP, CCVP, the Cisco Square Bridge logo, Follow Me Browsing, and StackWise are trademarks of Cisco Systems, Inc.; Changing the Way We Work, Live, Play, and Learn,
and iQuick Study are service marks of Cisco Systems, Inc.; and Access Registrar, Aironet, BPX, Catalyst, CCDA, CCDP, CCIE, CCIP, CCNA, CCNP, Cisco, the Cisco
Certified Internetwork Expert logo, Cisco IOS, Cisco Press, Cisco Systems, Cisco Systems Capital, the Cisco Systems logo, Cisco Unity, Enterprise/Solver, EtherChannel,
EtherFast, EtherSwitch, Fast Step, FormShare, GigaDrive, GigaStack, HomeLink, Internet Quotient, IOS, IP/TV, iQ Expertise, the iQ logo, iQ Net Readiness Scorecard,
LightStream, Linksys, MeetingPlace, MGX, the Networkers logo, Networking Academy, Network Registrar, Packet, PIX, Post-Routing, Pre-Routing, ProConnect,
RateMUX, ScriptShare, SlideCast, SMARTnet, The Fastest Way to Increase Your Internet Quotient, and TransPath are registered trademarks of Cisco Systems, Inc. and/or
its affiliates in the United States and certain other countries.
All other trademarks mentioned in this document or Website are the property of their respective owners. The use of the word partner does not imply a partnership relationship
between Cisco and any other company. (0601R)
Any Internet Protocol (IP) addresses used in this document are not intended to be actual addresses. Any examples, command display output, and figures included in the
document are shown for illustrative purposes only. Any use of actual IP addresses in illustrative content is unintentional and coincidental.
Cisco Catalyst Blade Switch 3020 for HP Command Reference
© 2006 Cisco Systems, Inc. All rights reserved.
iii
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
CONTENTS
Preface xv
Audience xv
Purpose xv
Conventions xv
Related Publications xvi
Obtaining Documentation xvii
Cisco.com xvii
Product Documentation DVD xvii
Ordering Documentation xvii
Documentation Feedback xviii
Cisco Product Security Overview xviii
Reporting Security Problems in Cisco Products xviii
Obtaining Technical Assistance xix
Cisco Technical Support & Documentation Website xix
Submitting a Service Request xx
Definitions of Service Request Severity xx
Obtaining Additional Publications and Information xx
CHAPTER
1 Using the Command-Line Interface 1-1
CLI Command Modes 1-1
User EXEC Mode 1-3
Privileged EXEC Mode 1-3
Global Configuration Mode 1-3
Interface Configuration Mode 1-4
config-vlan Mode 1-4
VLAN Configuration Mode 1-5
Line Configuration Mode 1-5
CHAPTER
2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands 2-1
aaa accounting dot1x 2-1
aaa authentication dot1x 2-3
aaa authorization network 2-5
action 2-6
Contents
iv
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
archive download-sw 2-8
archive tar 2-11
archive upload-sw 2-14
auto qos voip 2-16
boot boothlpr 2-20
boot config-file 2-21
boot enable-break 2-22
boot helper 2-23
boot helper-config-file 2-24
boot manual 2-25
boot private-config-file 2-26
boot system 2-27
channel-group 2-28
channel-protocol 2-31
class 2-32
class-map 2-34
clear dot1x 2-36
clear eap sessions 2-37
clear lacp 2-38
clear mac address-table 2-39
clear mac address-table move update 2-41
clear pagp 2-42
clear port-security 2-43
clear spanning-tree counters 2-45
clear spanning-tree detected-protocols 2-46
clear vmps statistics 2-47
clear vtp counters 2-48
define interface-range 2-49
delete 2-51
deny (MAC access-list configuration) 2-52
dot1x 2-55
dot1x auth-fail max-attempts 2-57
dot1x auth-fail vlan 2-59
dot1x control-direction 2-61
dot1x critical (global configuration) 2-63
Contents
v
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
dot1x critical (interface configuration) 2-65
dot1x default 2-67
dot1x guest-vlan 2-68
dot1x host-mode 2-70
dot1x initialize 2-71
dot1x mac-auth-bypass 2-72
dot1x max-reauth-req 2-74
dot1x max-req 2-75
dot1x pae 2-76
dot1x port-control 2-77
dot1x re-authenticate 2-79
dot1x reauthentication 2-80
dot1x timeout 2-81
duplex 2-84
errdisable detect cause 2-86
errdisable recovery 2-88
exception crashinfo 2-90
flowcontrol 2-91
interface port-channel 2-93
interface range 2-95
interface vlan 2-97
ip access-group 2-98
ip address 2-100
ip dhcp snooping 2-102
ip dhcp snooping information option 2-103
ip dhcp snooping information option allow-untrusted 2-105
ip dhcp snooping information option format remote-id 2-107
ip dhcp snooping limit rate 2-109
ip dhcp snooping trust 2-110
ip dhcp snooping verify 2-111
ip dhcp snooping vlan 2-112
ip dhcp snooping vlan information option format-type circuit-id string 2-113
ip igmp filter 2-115
ip igmp max-groups 2-116
ip igmp profile 2-118
Contents
vi
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
ip igmp snooping 2-120
ip igmp snooping last-member-query-interval 2-122
ip igmp snooping querier 2-124
ip igmp snooping report-suppression 2-126
ip igmp snooping tcn 2-128
ip igmp snooping tcn flood 2-130
ip igmp snooping vlan immediate-leave 2-131
ip igmp snooping vlan mrouter 2-133
ip igmp snooping vlan static 2-135
ip ssh 2-137
lacp port-priority 2-139
lacp system-priority 2-141
link state group 2-143
link state track 2-145
logging event 2-146
logging file 2-147
mac access-group 2-149
mac access-list extended 2-151
mac address-table aging-time 2-153
mac address-table move update 2-154
mac address-table notification 2-156
mac address-table static 2-158
mac address-table static drop 2-159
macro apply 2-161
macro description 2-164
macro global 2-165
macro global description 2-168
macro name 2-169
match (access-map configuration) 2-171
match (class-map configuration) 2-173
mdix auto 2-175
media-type 2-177
mls qos 2-179
mls qos aggregate-policer 2-181
mls qos cos 2-183
Contents
vii
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
mls qos dscp-mutation 2-185
mls qos map 2-187
mls qos queue-set output buffers 2-191
mls qos queue-set output threshold 2-193
mls qos rewrite ip dscp 2-195
mls qos srr-queue input bandwidth 2-197
mls qos srr-queue input buffers 2-199
mls qos srr-queue input cos-map 2-201
mls qos srr-queue input dscp-map 2-203
mls qos srr-queue input priority-queue 2-205
mls qos srr-queue input threshold 2-207
mls qos srr-queue output cos-map 2-209
mls qos srr-queue output dscp-map 2-211
mls qos trust 2-213
mls qos vlan-based 2-215
monitor session 2-216
mvr (global configuration) 2-220
mvr (interface configuration) 2-223
pagp learn-method 2-226
pagp port-priority 2-228
permit (MAC access-list configuration) 2-230
police 2-233
police aggregate 2-235
policy-map 2-237
port-channel load-balance 2-240
priority-queue 2-242
queue-set 2-244
radius-server dead-criteria 2-245
radius-server host 2-247
remote-span 2-249
rmon collection stats 2-253
service password-recovery 2-254
service-policy 2-256
set 2-259
setup 2-261
Contents
viii
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
setup express 2-264
show access-lists 2-266
show archive status 2-269
show auto qos 2-270
show boot 2-273
show cable-diagnostics tdr 2-275
show class-map 2-277
show controllers cpu-interface 2-278
show controllers ethernet-controller 2-280
show controllers tcam 2-288
show controllers utilization 2-290
show dot1x 2-292
show dtp 2-296
show eap 2-298
show env 2-301
show errdisable detect 2-302
show errdisable flap-values 2-304
show errdisable recovery 2-306
show etherchannel 2-308
show flowcontrol 2-311
show interfaces 2-313
show interfaces counters 2-321
show inventory 2-323
show ip dhcp snooping 2-324
show ip dhcp snooping binding 2-325
show ip igmp profile 2-327
show ip igmp snooping 2-328
show ip igmp snooping groups 2-330
show ip igmp snooping mrouter 2-332
show ip igmp snooping querier 2-334
show lacp 2-336
show link state group 2-340
show mac access-group 2-342
show mac address-table 2-344
show mac address-table address 2-346
Contents
ix
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
show mac address-table aging-time 2-348
show mac address-table count 2-349
show mac address-table dynamic 2-351
show mac address-table interface 2-353
show mac address-table move update 2-355
show mac address-table notification 2-357
show mac address-table static 2-359
show mac address-table vlan 2-361
show mls qos 2-363
show mls qos aggregate-policer 2-364
show mls qos input-queue 2-365
show mls qos interface 2-367
show mls qos maps 2-371
show mls qos queue-set 2-374
show mls qos vlan 2-376
show monitor 2-377
show mvr 2-379
show mvr interface 2-381
show mvr members 2-383
show pagp 2-385
show parser macro 2-387
show policy-map 2-390
show port-security 2-392
show setup express 2-395
show spanning-tree 2-396
show storm-control 2-402
show system mtu 2-404
show udld 2-405
show version 2-408
show vlan 2-410
show vlan access-map 2-415
show vlan filter 2-416
show vmps 2-417
show vtp 2-420
shutdown 2-423
Contents
x
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
shutdown vlan 2-424
snmp-server enable traps 2-425
snmp-server host 2-428
snmp trap mac-notification 2-432
spanning-tree backbonefast 2-434
spanning-tree bpdufilter 2-435
spanning-tree bpduguard 2-437
spanning-tree cost 2-439
spanning-tree etherchannel guard misconfig 2-441
spanning-tree extend system-id 2-443
spanning-tree guard 2-445
spanning-tree link-type 2-447
spanning-tree loopguard default 2-449
spanning-tree mode 2-451
spanning-tree mst configuration 2-453
spanning-tree mst cost 2-455
spanning-tree mst forward-time 2-457
spanning-tree mst hello-time 2-458
spanning-tree mst max-age 2-459
spanning-tree mst max-hops 2-460
spanning-tree mst port-priority 2-462
spanning-tree mst pre-standard 2-464
spanning-tree mst priority 2-465
spanning-tree mst root 2-466
spanning-tree port-priority 2-468
spanning-tree portfast (global configuration) 2-470
spanning-tree portfast (interface configuration) 2-472
spanning-tree transmit hold-count 2-474
spanning-tree uplinkfast 2-475
spanning-tree vlan 2-477
speed 2-480
srr-queue bandwidth limit 2-482
srr-queue bandwidth shape 2-484
srr-queue bandwidth share 2-486
storm-control 2-488
Contents
xi
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
switchport access 2-491
switchport backup interface 2-493
switchport block 2-496
switchport host 2-497
switchport mode 2-498
switchport nonegotiate 2-500
switchport port-security 2-502
switchport port-security aging 2-507
switchport priority extend 2-509
switchport protected 2-511
switchport trunk 2-512
switchport voice vlan 2-515
system mtu 2-517
test cable-diagnostics tdr 2-519
traceroute mac 2-520
traceroute mac ip 2-523
trust 2-525
udld 2-527
udld port 2-529
udld reset 2-531
vlan (global configuration) 2-532
vlan (VLAN configuration) 2-537
vlan access-map 2-543
vlan database 2-545
vlan filter 2-548
vmps reconfirm (privileged EXEC) 2-550
vmps reconfirm (global configuration) 2-551
vmps retry 2-552
vmps server 2-553
vtp (global configuration) 2-555
vtp (VLAN configuration) 2-559
APPENDIX
A Cisco Catalyst Switch 3020 for HP Boot Loader Commands A-1
boot A-2
cat A-4
copy A-5
Contents
xii
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
delete A-6
dir A-7
flash_init A-9
format A-10
fsck A-11
help A-12
load_helper A-13
memory A-14
mkdir A-15
more A-16
rename A-17
reset A-18
rmdir A-19
set A-20
type A-23
unset A-24
version A-26
APPENDIX
B Cisco Catalyst Blade Switch 3020 for HP Debug Commands B-1
debug auto qos B-2
debug backup B-4
debug dot1x B-5
debug dtp B-7
debug eap B-8
debug etherchannel B-10
debug interface B-12
debug ip igmp filter B-14
debug ip igmp max-groups B-15
debug ip igmp snooping B-16
debug lacp B-17
debug mac-notification B-18
debug matm B-19
debug matm move update B-20
debug monitor B-21
debug mvrdbg B-22
debug nvram B-23
Contents
xiii
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
debug pagp B-24
debug platform acl B-25
debug platform backup interface B-26
debug platform cpu-queues B-27
debug platform dot1x B-29
debug platform etherchannel B-30
debug platform forw-tcam B-31
debug platform ip dhcp B-32
debug platform ip igmp snooping B-33
debug platform led B-35
debug platform matm B-36
debug platform messaging application B-38
debug platform phy B-39
debug platform pm B-41
debug platform port-asic B-43
debug platform port-security B-44
debug platform qos-acl-tcam B-45
debug platform remote-commands B-46
debug platform resource-manager B-47
debug platform snmp B-48
debug platform span B-49
debug platform supervisor-asic B-50
debug platform sw-bridge B-51
debug platform tcam B-52
debug platform udld B-54
debug platform vlan B-55
debug pm B-56
debug port-security B-58
debug qos-manager B-59
debug spanning-tree B-60
debug spanning-tree backbonefast B-62
debug spanning-tree bpdu B-63
debug spanning-tree bpdu-opt B-64
debug spanning-tree mstp B-65
debug spanning-tree switch B-67
Contents
xiv
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
debug spanning-tree uplinkfast B-69
debug sw-vlan B-70
debug sw-vlan ifs B-72
debug sw-vlan notification B-74
debug sw-vlan vtp B-76
debug udld B-78
debug vqpc B-80
APPENDIX
C Cisco Catalyst Blade Switch 3020 for HP Show Platform Commands C-1
show platform acl C-2
show platform backup interface C-3
show platform configuration C-4
show platform etherchannel C-5
show platform forward C-6
show platform ip igmp snooping C-8
show platform layer4op C-10
show platform mac-address-table C-11
show platform messaging C-12
show platform monitor C-13
show platform mvr table C-14
show platform pm C-15
show platform port-asic C-16
show platform port-security C-21
show platform qos C-22
show platform resource-manager C-23
show platform snmp counters C-25
show platform spanning-tree C-26
show platform stp-instance C-27
show platform tcam C-28
show platform vlan C-30
I
NDEX
xv
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Preface
Audience
This guide is for the networking professional using the Cisco IOS command-line interface (CLI) to
manage the Cisco Catalyst Blade Switch 3020 for HP, hereafter referred to as the switch. Before using
this guide, you should have experience working with the Cisco IOS commands and the switch software
features. Before using this guide, you should have experience working with the concepts and
terminology of Ethernet and local area networking.
Purpose
This guide provides the information that you need about the Layer 2 commands that have been created
or changed for use with the switch. For information about the standard Cisco IOS Release 12.2 commands,
see the Cisco IOS documentation set available from the Cisco.com home page by selecting Technical
Support & Documentation > Cisco IOS Software.
This guide does not provide procedures for configuring your switch. For detailed configuration
procedures, see the software configuration guide for this release.
This guide does not describe system messages you might encounter. For more information, see the
system message guide for this release.
For documentation updates, see the release notes for this release.
Conventions
This publication uses these conventions to convey instructions and information:
Command descriptions use these conventions:
• Commands and keywords are in boldface text.
• Arguments for which you supply values are in italic.
• Square brackets ([ ]) means optional elements.
• Braces ({}) group required choices, and vertical bars ( | ) separate the alternative elements.
• Braces and vertical bars within square brackets ([{ | }]) mean a required choice within an optional
element.
xvi
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Preface
Related Publications
Interactive examples use these conventions:
• Terminal sessions and system displays are in screen font.
• Information you enter is in boldface screen font.
• Nonprinting characters, such as passwords or tabs, are in angle brackets (< >).
Notes, cautions, and warnings use these conventions and symbols:
Note Means reader take note. Notes contain helpful suggestions or references to materials not contained in
this manual.
Caution Means reader be careful. In this situation, you might do something that could result in equipment
damage or loss of data.
Related Publications
These documents provide complete information about the switch and are available from this Cisco.com
site:
http://www.cisco.com/en/US/products/ps6748/tsd_products_support_series_home.html
Note Before installing, configuring, or upgrading the switch, see these documents:
• For initial configuration information, see the “Configuring the Switch Module” section in the getting
started guide or the “Configuring the Switch with the CLI-Based Setup Program” appendix in the
hardware installation guide.
• For device manager requirements, see the “System Requirements” section in the release notes (not
orderable but available on Cisco.com).
• For upgrade information, see the “Downloading Software” section in the release notes.
You can order printed copies of documents with a DOC-xxxxxx= number from the Cisco.com sites and
from the telephone numbers listed in the “Obtaining Documentation” section on page xvii.
• Release Notes for the Cisco Catalyst Blade Switch 3020 for HP (not orderable but available on
Cisco.com)
• Cisco Catalyst Blade Switch 3020 for HP System Message Guide (not orderable but available on
Cisco.com)
• Cisco Catalyst Blade Switch 3020 for HP Software Configuration Guide (not orderable but available
on Cisco.com)
• Cisco Catalyst Blade Switch 3020 for HP Command Reference (not orderable but available on
Cisco.com)
• Device manager online help (available on the switch)
• Cisco Catalyst Blade Switch 3020 for HP Hardware Installation Guide (not orderable but available
on Cisco.com)
• Cisco Catalyst Blade Switch 3020 for HP Getting Started Guide (order number DOC-7817364=)
xvii
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Preface
Obtaining Documentation
• Regulatory Compliance and Safety Information for the Cisco Catalyst Blade Switch 3020 for HP
(order number DOC-7817607=)
• Cisco Small Form-Factor Pluggable Modules Installation Notes (order number DOC-7815160=)
Obtaining Documentation
Cisco documentation and additional literature are available on Cisco.com. Cisco also provides several
ways to obtain technical assistance and other technical resources. These sections explain how to obtain
technical information from Cisco Systems.
Cisco.com
You can access the most current Cisco documentation at this URL:
http://www.cisco.com/techsupport
You can access the Cisco website at this URL:
http://www.cisco.com
You can access international Cisco websites at this URL:
http://www.cisco.com/public/countries_languages.shtml
Product Documentation DVD
The Product Documentation DVD is a comprehensive library of technical product documentation on a
portable medium. The DVD enables you to access multiple versions of installation, configuration, and
command guides for Cisco hardware and software products. With the DVD, you have access to the same
HTML documentation that is found on the Cisco website without being connected to the Internet.
Certain products also have .PDF versions of the documentation available.
The Product Documentation DVD is available as a single unit or as a subscription. Registered Cisco.com
users (Cisco direct customers) can order a Product Documentation DVD (product number
DOC-DOCDVD= or DOC-DOCDVD=SUB) from Cisco Marketplace at this URL:
http://www.cisco.com/go/marketplace/
Ordering Documentation
Registered Cisco.com users may order Cisco documentation at the Product Documentation Store in the
Cisco Marketplace at this URL:
http://www.cisco.com/go/marketplace/
Nonregistered Cisco.com users can order technical documentation from 8:00 a.m. to 5:00 p.m.
(0800 to 1700) PDT by calling 1 866 463-3487 in the United States and Canada, or elsewhere by
calling 011 408 519-5055. You can also order documentation by e-mail at
tech-doc-store-mkpl@external.cisco.com or by fax at 1 408 519-5001 in the United States and Canada,
or elsewhere at 011 408 519-5001.
xviii
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Preface
Documentation Feedback
Documentation Feedback
You can rate and provide feedback about Cisco technical documents by completing the online feedback
form that appears with the technical documents on Cisco.com.
You can submit comments about Cisco documentation by using the response card (if present) behind the
front cover of your document or by writing to the following address:
Cisco Systems
Attn: Customer Document Ordering
170 West Tasman Drive
San Jose, CA 95134-9883
We appreciate your comments.
Cisco Product Security Overview
Cisco provides a free online Security Vulnerability Policy portal at this URL:
http://www.cisco.com/en/US/products/products_security_vulnerability_policy.html
From this site, you will find information about how to:
• Report security vulnerabilities in Cisco products.
• Obtain assistance with security incidents that involve Cisco products.
• Register to receive security information from Cisco.
A current list of security advisories, security notices, and security responses for Cisco products is
available at this URL:
http://www.cisco.com/go/psirt
To see security advisories, security notices, and security responses as they are updated in real time, you
can subscribe to the Product Security Incident Response Team Really Simple Syndication (PSIRT RSS)
feed. Information about how to subscribe to the PSIRT RSS feed is found at this URL:
http://www.cisco.com/en/US/products/products_psirt_rss_feed.html
Reporting Security Problems in Cisco Products
Cisco is committed to delivering secure products. We test our products internally before we release them,
and we strive to correct all vulnerabilities quickly. If you think that you have identified a vulnerability
in a Cisco product, contact PSIRT:
• For Emergencies only— security-alert@cisco.com
An emergency is either a condition in which a system is under active attack or a condition for which
a severe and urgent security vulnerability should be reported. All other conditions are considered
nonemergencies.
• For Nonemergencies—psirt@cisco.com
In an emergency, you can also reach PSIRT by telephone:
• 1 877 228-7302
• 1 408 525-6532
xix
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Preface
Obtaining Technical Assistance
Tip We encourage you to use Pretty Good Privacy (PGP) or a compatible product (for example, GnuPG) to
encrypt any sensitive information that you send to Cisco. PSIRT can work with information that has been
encrypted with PGP versions 2.x through 9.x.
Never use a revoked or an expired encryption key. The correct public key to use in your correspondence
with PSIRT is the one linked in the Contact Summary section of the Security Vulnerability Policy page
at this URL:
http://www.cisco.com/en/US/products/products_security_vulnerability_policy.html
The link on this page has the current PGP key ID in use.
If you do not have or use PGP, contact PSIRT at the aforementioned e-mail addresses or phone numbers
before sending any sensitive material to find other means of encrypting the data.
Obtaining Technical Assistance
Cisco Technical Support provides 24-hour-a-day award-winning technical assistance. The Cisco
Technical Support & Documentation website on Cisco.com features extensive online support resources.
In addition, if you have a valid Cisco service contract, Cisco Technical Assistance Center (TAC)
engineers provide telephone support. If you do not have a valid Cisco service contract, contact your
reseller.
Cisco Technical Support & Documentation Website
The Cisco Technical Support & Documentation website provides online documents and tools for
troubleshooting and resolving technical issues with Cisco products and technologies. The website is
available 24 hours a day, at this URL:
http://www.cisco.com/techsupport
Access to all tools on the Cisco Technical Support & Documentation website requires a Cisco.com user
ID and password. If you have a valid service contract but do not have a user ID or password, you can
register at this URL:
http://tools.cisco.com/RPF/register/register.do
Note Use the Cisco Product Identification (CPI) tool to locate your product serial number before submitting
a web or phone request for service. You can access the CPI tool from the Cisco Technical Support &
Documentation website by clicking the Tools & Resources link under Documentation & Tools. Choose
Cisco Product Identification Tool from the Alphabetical Index drop-down list, or click the Cisco
Product Identification Tool link under Alerts & RMAs. The CPI tool offers three search options: by
product ID or model name; by tree view; or for certain products, by copying and pasting show command
output. Search results show an illustration of your product with the serial number label location
highlighted. Locate the serial number label on your product and record the information before placing a
service call.
xx
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Preface
Obtaining Additional Publications and Information
Submitting a Service Request
Using the online TAC Service Request Tool is the fastest way to open S3 and S4 service requests. (S3
and S4 service requests are those in which your network is minimally impaired or for which you require
product information.) After you describe your situation, the TAC Service Request Tool provides
recommended solutions. If your issue is not resolved using the recommended resources, your service
request is assigned to a Cisco engineer. The TAC Service Request Tool is located at this URL:
http://www.cisco.com/techsupport/servicerequest
For S1 or S2 service requests, or if you do not have Internet access, contact the Cisco TAC by telephone.
(S1 or S2 service requests are those in which your production network is down or severely degraded.)
Cisco engineers are assigned immediately to S1 and S2 service requests to help keep your business
operations running smoothly.
To open a service request by telephone, use one of the following numbers:
Asia-Pacific: +61 2 8446 7411 (Australia: 1 800 805 227)
EMEA: +32 2 704 55 55
USA: 1 800 553-2447
For a complete list of Cisco TAC contacts, go to this URL:
http://www.cisco.com/techsupport/contacts
Definitions of Service Request Severity
To ensure that all service requests are reported in a standard format, Cisco has established severity
definitions.
Severity 1 (S1)—An existing network is down, or there is a critical impact to your business operations.
You and Cisco will commit all necessary resources around the clock to resolve the situation.
Severity 2 (S2)—Operation of an existing network is severely degraded, or significant aspects of your
business operations are negatively affected by inadequate performance of Cisco products. You and Cisco
will commit full-time resources during normal business hours to resolve the situation.
Severity 3 (S3)—Operational performance of the network is impaired, while most business operations
remain functional. You and Cisco will commit resources during normal business hours to restore service
to satisfactory levels.
Severity 4 (S4)—You require information or assistance with Cisco product capabilities, installation, or
configuration. There is little or no effect on your business operations.
Obtaining Additional Publications and Information
Information about Cisco products, technologies, and network solutions is available from various online
and printed sources.
• The Cisco Product Quick Reference Guide is a handy, compact reference tool that includes brief
product overviews, key features, sample part numbers, and abbreviated technical specifications for
many Cisco products that are sold through channel partners. It is updated twice a year and includes
the latest Cisco offerings. To order and find out more about the Cisco Product Quick Reference
Guide, go to this URL:
http://www.cisco.com/go/guide
xxi
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Preface
Obtaining Additional Publications and Information
• Cisco Marketplace provides a variety of Cisco books, reference guides, documentation, and logo
merchandise. Visit Cisco Marketplace, the company store, at this URL:
http://www.cisco.com/go/marketplace/
• Cisco Press publishes a wide range of general networking, training and certification titles. Both new
and experienced users will benefit from these publications. For current Cisco Press titles and other
information, go to Cisco Press at this URL:
http://www.ciscopress.com
• Packet magazine is the Cisco Systems technical user magazine for maximizing Internet and
networking investments. Each quarter, Packet delivers coverage of the latest industry trends,
technology breakthroughs, and Cisco products and solutions, as well as network deployment and
troubleshooting tips, configuration examples, customer case studies, certification and training
information, and links to scores of in-depth online resources. You can access Packet magazine at
this URL:
http://www.cisco.com/packet
• iQ Magazine is the quarterly publication from Cisco Systems designed to help growing companies
learn how they can use technology to increase revenue, streamline their business, and expand
services. The publication identifies the challenges facing these companies and the technologies to
help solve them, using real-world case studies and business strategies to help readers make sound
technology investment decisions. You can access iQ Magazine at this URL:
http://www.cisco.com/go/iqmagazine
or view the digital edition at this URL:
http://ciscoiq.texterity.com/ciscoiq/sample/
• Internet Protocol Journal is a quarterly journal published by Cisco Systems for engineering
professionals involved in designing, developing, and operating public and private internets and
intranets. You can access the Internet Protocol Journal at this URL:
http://www.cisco.com/ipj
• Networking products offered by Cisco Systems, as well as customer support services, can be
obtained at this URL:
http://www.cisco.com/en/US/products/index.html
• Networking Professionals Connection is an interactive website for networking professionals to share
questions, suggestions, and information about networking products and technologies with Cisco
experts and other networking professionals. Join a discussion at this URL:
http://www.cisco.com/discuss/networking
• World-class networking training is available from Cisco. You can view current offerings at
this URL:
http://www.cisco.com/en/US/learning/index.html
xxii
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Preface
Obtaining Additional Publications and Information
CHAPTER
1-1
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
1
Using the Command-Line Interface
The switch is supported by Cisco IOS software. This chapter describes how to use the switch
command-line interface (CLI) to configure software features.
• For a complete description of the commands that support these features, see Chapter 2, “Cisco
Catalyst Blade Switch 3020 for HP Cisco IOS Commands.”
• For information on the boot loader commands, see Appendix A, “Cisco Catalyst Switch 3020 for
HP Boot Loader Commands.”
• For information on the debug commands, see Appendix B, “Cisco Catalyst Blade Switch 3020 for
HP Debug Commands.”
• For information on the show platform commands, see Appendix C, “Cisco Catalyst Blade Switch
3020 for HP Show Platform Commands.”
• For more information on Cisco IOS Release 12.2, see the Cisco IOS Release 12.2 Command
Summary.
• For task-oriented configuration steps, see the software configuration guide for this release.
In this document, IP refers to IP version 4 (IPv4).
CLI Command Modes
This section describes the CLI command mode structure. Command modes support specific Cisco IOS
commands. For example, the interface interface-id command only works when entered in global
configuration mode.
These are the main command modes for the switch:
• User EXEC
• Privileged EXEC
• Global configuration
• Interface configuration
• Config-vlan
• VLAN configuration
• Line configuration
1-2
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 1 Using the Command-Line Interface
CLI Command Modes
Table 1 - 1 lists the main command modes, how to access each mode, the prompt you see in that mode,
and how to exit that mode. The prompts listed use the default name Switch.
Table 1-1 Command Modes Summary
Command Mode Access Method Prompt Exit or Access Next Mode
User EXEC This is the first level of access.
(For the switch) Change terminal
settings, perform basic tasks, and
list system information.
Switch>
Enter the logout command.
To enter privileged EXEC mode, enter
the enable command.
Privileged EXEC From user EXEC mode, enter the
enable command.
Switch#
To exit to user EXEC mode, enter the
disable command.
To enter global configuration mode,
enter the configure command.
Global
configuration
From privileged EXEC mode,
enter the configure command.
Switch(config)#
To exit to privileged EXEC mode,
enter the exit or end command, or
press Ctrl-Z.
To enter interface configuration mode,
enter the interface configuration
command.
Interface
configuration
From global configuration mode,
specify an interface by entering
the interface command followed
by an interface identification.
Switch(config-if)#
To exit to privileged EXEC mode,
enter the end command, or press
Ctrl-Z.
To exit to global configuration mode,
enter the exit command.
Config-vlan In global configuration mode,
enter the vlan vlan-id command.
Switch(config-vlan)#
To exit to global configuration mode,
enter the exit command.
To return to privileged EXEC mode,
enter the end command, or press
Ctrl-Z.
VLAN
configuration
From privileged EXEC mode,
enter the vlan database
command.
Switch(vlan)#
To exit to privileged EXEC mode,
enter the exit command.
Line configuration From global configuration mode,
specify a line by entering the line
command.
Switch(config-line)#
To exit to global configuration mode,
enter the exit command.
To return to privileged EXEC mode,
enter the end command, or press
Ctrl-Z.
1-3
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 1 Using the Command-Line Interface
CLI Command Modes
User EXEC Mode
After you access the device, you are automatically in user EXEC command mode. The EXEC commands
available at the user level are a subset of those available at the privileged level. In general, use the user
EXEC commands to temporarily change terminal settings, perform basic tests, and list system
information.
The supported commands can vary depending on the version of software in use. To display a
comprehensive list of commands, enter a question mark (?) at the prompt.
Switch> ?
Privileged EXEC Mode
Because many of the privileged commands configure operating parameters, privileged access should be
password-protected to prevent unauthorized use. The privileged command set includes those commands
contained in user EXEC mode, as well as the configure privileged EXEC command through which you
access the remaining command modes.
If your system administrator has set a password, you are prompted to enter it before being granted access
to privileged EXEC mode. The password does not appear on the screen and is case sensitive.
The privileged EXEC mode prompt is the device name followed by the pound sign (
#).
Switch#
Enter the enable command to access privileged EXEC mode:
Switch> enable
Switch#
The supported commands can vary depending on the version of software in use. To display a
comprehensive list of commands, enter a question mark (?) at the prompt.
Switch# ?
To return to user EXEC mode, enter the disable privileged EXEC command.
Global Configuration Mode
Global configuration commands apply to features that affect the device as a whole. Use the configure
privileged EXEC command to enter global configuration mode. The default is to enter commands from
the management console.
When you enter the configure command, a message prompts you for the source of the configuration
commands:
Switch# configure
Configuring from terminal, memory, or network [terminal]?
You can specify either the terminal or NVRAM as the source of configuration commands.
This example shows you how to access global configuration mode:
Switch# configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
1-4
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 1 Using the Command-Line Interface
CLI Command Modes
The supported commands can vary depending on the version of software in use. To display a
comprehensive list of commands, enter a question mark (?) at the prompt.
Switch(config)# ?
To exit global configuration command mode and to return to privileged EXEC mode, enter the end or
exit command, or press Ctrl-Z.
Interface Configuration Mode
Interface configuration commands modify the operation of the interface. Interface configuration
commands always follow a global configuration command, which defines the interface type.
Use the interface interface-id command to access interface configuration mode. The new prompt means
interface configuration mode.
Switch(config-if)#
The supported commands can vary depending on the version of software in use. To display a
comprehensive list of commands, enter a question mark (?) at the prompt.
Switch(config-if)# ?
To exit interface configuration mode and to return to global configuration mode, enter the exit command.
To exit interface configuration mode and to return to privileged EXEC mode, enter the end command,
or press Ctrl-Z.
config-vlan Mode
Use this mode to configure normal-range VLANs (VLAN IDs 1 to 1005) or, when VTP mode is
transparent, to configure extended-range VLANs (VLAN IDs 1006 to 4094). When VTP mode is
transparent, the VLAN and VTP configuration is saved in the running configuration file, and you can
save it to the switch startup configuration file by using the copy running-config startup-config
privileged EXEC command. The configurations of VLAN IDs 1 to 1005 are saved in the VLAN database
if VTP is in transparent or server mode. The extended-range VLAN configurations are not saved in the
VLAN database.
Enter the vlan vlan-id global configuration command to access config-vlan mode:
Switch(config)# vlan 2000
Switch(config-vlan)#
The supported keywords can vary but are similar to the commands available in VLAN configuration
mode. To display a comprehensive list of commands, enter a question mark (?) at the prompt.
Switch(config-vlan)# ?
For extended-range VLANs, all characteristics except the MTU size must remain at the default setting.
To return to global configuration mode, enter exit; to return to privileged EXEC mode, enter end. All
the commands except shutdown take effect when you exit config-vlan mode.
1-5
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 1 Using the Command-Line Interface
CLI Command Modes
VLAN Configuration Mode
You can use the VLAN configuration commands to create or modify VLAN parameters for VLAN IDs
1 to 1005.
Enter the vlan database privileged EXEC command to access VLAN configuration mode:
Switch# vlan database
Switch(vlan)#
The supported commands can vary depending on the version of software in use. To display a
comprehensive list of commands, enter a question mark (?) at the prompt.
Switch(vlan)# ?
To return to privileged EXEC mode, enter the abort VLAN configuration command to abandon the
proposed database. Otherwise, enter exit to implement the proposed new VLAN database and to return
to privileged EXEC mode. When you enter exit or apply, the configuration is saved in the VLAN
database; configuration from VLAN configuration mode cannot be saved in the switch configuration file.
Line Configuration Mode
Line configuration commands modify the operation of a terminal line. Line configuration commands
always follow a line command, which defines a line number. Use these commands to change terminal
parameter settings line-by-line or for a range of lines.
Use the line vty line_number [ending_line_number] command to enter line configuration mode. The
new prompt means line configuration mode. The following example shows how to enter line
configuration mode for virtual terminal line 7:
Switch(config)# line vty 0 7
The supported commands can vary depending on the version of software in use. To display a
comprehensive list of commands, enter a question mark (?) at the prompt.
Switch(config-line)# ?
To exit line configuration mode and to return to global configuration mode, use the exit command. To
exit line configuration mode and to return to privileged EXEC mode, enter the end command, or press
Ctrl-Z.
1-6
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 1 Using the Command-Line Interface
CLI Command Modes
CHAPTER
2-1
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
2
Cisco Catalyst Blade Switch 3020 for HP Cisco
IOS Commands
aaa accounting dot1x
Use the aaa accounting dot1x global configuration command to enable authentication, authorization,
and accounting (AAA) accounting and to create method lists defining specific accounting methods on a
per-line or per-interface basis for IEEE 802.1x sessions. Use the no form of this command to disable
IEEE 802.1x accounting.
aaa accounting dot1x {name | default} start-stop {broadcast group {name | radius | tacacs+}
[group {name | radius | tacacs+} ... ] | group {name | radius | tacacs+} [group {name | radius
| tacacs+} ... ]}
no aaa accounting dot1x {name | default}
Syntax Description name Name of a server group. This is optional when you enter it after the
broadcast group and group keywords.
default Use the accounting methods that follow as the default list for accounting
services.
start-stop Send a start accounting notice at the beginning of a process and a stop
accounting notice at the end of a process. The start accounting record is sent
in the background. The requested-user process begins regardless of whether
or not the start accounting notice was received by the accounting server.
broadcast Enable accounting records to be sent to multiple AAA servers and send
accounting records to the first server in each group. If the first server is
unavailable, the switch uses the list of backup servers to identify the first
server.
group Specify the server group to be used for accounting services. These are valid
server group names:
• name—Name of a server group.
• radius—List of all RADIUS hosts.
• tacacs+—List of all TACACS+ hosts.
The group keyword is optional when you enter it after the broadcast group
and group keywords. You can enter more than optional group keyword.
2-2
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
aaa accounting dot1x
Defaults AAA accounting is disabled.
Command Modes Global configuration
Command History
Usage Guidelines This command requires access to a RADIUS server.
We recommend that you enter the dot1x reauthentication interface configuration command before
configuring IEEE 802.1x RADIUS accounting on an interface.
Examples This example shows how to configure IEEE 802.1x accounting:
Switch(config)# aaa new-model
Switch(config)# aaa accounting dot1x default start-stop group radius
Note The RADIUS authentication server must be properly configured to accept and log update or watchdog
packets from the AAA client.
Related Commands
radius (Optional) Enable RADIUS authorization.
tacacs+ (Optional) Enable TACACS+ accounting.
Release Modification
12.2(25)SEF This command was introduced.
Command Description
aaa authentication
dot1x
Specifies one or more AAA methods for use on interfaces running
IEEE 802.1x.
aaa new-model Enables the AAA access control model. For syntax information, see the
Cisco IOS Security Command Reference, Release 12.2 > Authentication,
Authorization, and Accounting > Authentication Commands.
dot1x reauthentication Enables or disables periodic reauthentication.
dot1x timeout
reauth-period
Sets the number of seconds between re-authentication attempts.
2-3
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
aaa authentication dot1x
aaa authentication dot1x
Use the aaa authentication dot1x global configuration command to specify the authentication,
authorization, and accounting (AAA) method to use on ports complying with the IEEE 802.1x
authentication. Use the no form of this command to disable authentication.
aaa authentication dot1x {default} method1
no aaa authentication dot1x {default}
Syntax Description
Note Though other keywords are visible in the command-line help strings, only the default and group radius
keywords are supported.
Defaults No authentication is performed.
Command Modes Global configuration
Command History
Usage Guidelines The method argument identifies the method that the authentication algorithm tries in the given sequence
to validate the password provided by the client. The only method that is truly IEEE 802.1x-compliant is
the group radius method, in which the client data is validated against a RADIUS authentication server.
If you specify group radius, you must configure the RADIUS server by entering the radius-server host
global configuration command.
Use the show running-config privileged EXEC command to display the configured lists of
authentication methods.
Examples This example shows how to enable AAA and how to create an IEEE 802.1x-compliant authentication
list. This authentication first tries to contact a RADIUS server. If this action returns an error, the user is
not allowed access to the network.
Switch(config)# aaa new-model
Switch(config)# aaa authentication dot1x default group radius
You can verify your settings by entering the show running-config privileged EXEC command.
default Use the listed authentication method that follows this argument as the default
method when a user logs in.
method1 Enter the group radius keywords to use the list of all RADIUS servers for
authentication.
Release Modification
12.2(25)SEF This command was introduced.
2-4
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
aaa authentication dot1x
Related Commands Command Description
aaa new-model Enables the AAA access control model. For syntax information, see the
Cisco IOS Security Command Reference, Release 12.2 > Authentication,
Authorization, and Accounting > Authentication Commands.
show running-config Displays the current operating configuration. For syntax information, select
Cisco IOS Configuration Fundamentals Command Reference, Release
12.2 > File Management Commands > Configuration File Management
Commands.
2-5
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
aaa authorization network
aaa authorization network
Use the aaa authorization network global configuration command to the configure the switch to use
user-RADIUS authorization for all network-related service requests, such as IEEE 802.1x per-user
access control lists (ACLs) or VLAN assignment. Use the no form of this command to disable RADIUS
user authorization.
aaa authorization network default group radius
no aaa authorization network default
Syntax Description
Defaults Authorization is disabled.
Command Modes Global configuration
Command History
Usage Guidelines Use the aaa authorization network default group radius global configuration command to allow the
switch to download IEEE 802.1x authorization parameters from the RADIUS servers in the default
authorization list. The authorization parameters are used by features such as per-user ACLs or VLAN
assignment to get parameters from the RADIUS servers.
Use the show running-config privileged EXEC command to display the configured lists of authorization
methods.
Examples This example shows how to configure the switch for user RADIUS authorization for all network-related
service requests:
Switch(config)# aaa authorization network default group radius
You can verify your settings by entering the show running-config privileged EXEC command.
Related Commands
default group
radius
Use the list of all RADIUS hosts in the server group as the default authorization
list.
Release Modification
12.2(25)SEF This command was introduced.
Command Description
show running-config Displays the current operating configuration. For syntax information, select
Cisco IOS Configuration Fundamentals Command Reference, Release
12.2 > File Management Commands > Configuration File Management
Commands.
2-6
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
action
action
Use the action access-map configuration command to set the action for the VLAN access map entry. Use
the no form of this command to return to the default setting.
action {drop | forward}
no action
Syntax Description
Defaults The default action is to forward packets.
Command Modes Access-map configuration
Command History
Usage Guidelines You enter access-map configuration mode by using the vlan access-map global configuration command.
If the action is drop, you should define the access map, including configuring any access control list
(ACL) names in match clauses, before applying the map to a VLAN, or all packets could be dropped.
In access-map configuration mode, use the match access-map configuration command to define the
match conditions for a VLAN map. Use the action command to set the action that occurs when a packet
matches the conditions.
The drop and forward parameters are not used in the no form of the command.
Examples This example shows how to identify and apply a VLAN access map vmap4 to VLANs 5 and 6 that causes
the VLAN to forward an IP packet if the packet matches the conditions defined in access list al2:
Switch(config)# vlan access-map vmap4
Switch(config-access-map)# match ip address al2
Switch(config-access-map)# action forward
Switch(config-access-map)# exit
Switch(config)# vlan filter vmap4 vlan-list 5-6
You can verify your settings by entering the show vlan access-map privileged EXEC command.
drop Drop the packet when the specified conditions are matched.
forward Forward the packet when the specified conditions are matched.
Release Modification
12.2(25)SEF This command was introduced.
2-7
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
action
Related Commands Command Description
access-list {deny | permit} Configures a standard numbered ACL. For syntax information, select
Cisco IOS IP Command Reference, Volume 1 of 3:Addressing
and Services, Release 12.2 > IP Services Commands.
ip access-list Creates a named access list. For syntax information, select Cisco
IOS IP Command Reference, Volume 1 of 3:Addressing and
Services, Release 12.2 > IP Services Commands.
mac access-list extended Creates a named MAC address access list.
match (class-map
configuration)
Defines the match conditions for a VLAN map.
show vlan access-map Displays the VLAN access maps created on the switch.
vlan access-map Creates a VLAN access map.
2-8
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
archive download-sw
archive download-sw
Use the archive download-sw privileged EXEC command to download a new image from a TFTP server
to the switch and to overwrite or keep the existing image.
archive download-sw {/force-reload | /imageonly | /leave-old-sw | /no-set-boot | /overwrite |
/reload | /safe} source-url
Syntax Description /force-reload Unconditionally force a system reload after successfully downloading the
software image.
/imageonly Download only the software image but not the HTML files associated with
the embedded device manager. The HTML files for the existing version are
deleted only if the existing version is being overwritten or removed.
/leave-old-sw Keep the old software version after a successful download.
/no-set-boot Do not alter the setting of the BOOT environment variable to point to the new
software image after it is successfully downloaded.
/overwrite Overwrite the software image in flash memory with the downloaded one.
/reload Reload the system after successfully downloading the image unless the
configuration has been changed and not been saved.
/safe Keep the current software image; do not delete it to make room for the new
software image before the new image is downloaded. The current image is
deleted after the download.
source-url The source URL alias for a local or network file system. These options are
supported:
• The syntax for the local flash file system:
flash:
• The syntax for the FTP:
ftp:[[//username[:password]@location]/directory]/image-name.tar
• The syntax for an HTTP server:
http://[[username:password]@]{hostname |
host-ip}[/directory]/image-name.tar
• The syntax for a secure HTTP server:
https://[[username:password]@]{hostname |
host-ip}[/directory]/image-name.tar
• The syntax for the Remote Copy Protocol (RCP):
rcp:[[//username@location]/directory]/image-name.tar
• The syntax for the TFTP:
tftp:[[//location]/directory]/image-name.tar
The image-name.tar is the software image to download and install on the
switch.
2-9
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
archive download-sw
Defaults The current software image is not overwritten with the downloaded image.
Both the software image and HTML files are downloaded.
The new image is downloaded to the flash: file system.
The BOOT environment variable is changed to point to the new software image on the flash: file system.
Image names are case sensitive; the image file is provided in tar format.
Command Modes Privileged EXEC
Command History
Usage Guidelines The /imageonly option removes the HTML files for the existing image if the existing image is being
removed or replaced. Only the Cisco IOS image (without the HTML files) is downloaded.
Using the /safe or /leave-old-sw option can cause the new image download to fail if there is insufficient
flash memory. If leaving the software in place prevents the new image from fitting in flash memory due
to space constraints, an error results.
If you used the /leave-old-sw option and did not overwrite the old image when you downloaded the new
one, you can remove the old image by using the delete privileged EXEC command. For more
information, see the “delete” section on page 2-51.
Use the /overwrite option to overwrite the image on the flash device with the downloaded one.
If you specify the command without the /overwrite option, the download algorithm verifies that the new
image is not the same as the one on the switch flash device. If the images are the same, the download
does not occur. If the images are different, the old image is deleted, and the new one is downloaded.
After downloading a new image, enter the reload privileged EXEC command to begin using the new
image, or specify the /reload or /force-reload option in the archive download-sw command.
Examples This example shows how to download a new image from a TFTP server at 172.20.129.10 and overwrite
the image on the switch:
Switch# archive download-sw /overwrite tftp://172.20.129.10/test-image.tar
This example shows how to download only the software image from a TFTP server at 172.20.129.10 to
the switch:
Switch# archive download-sw /imageonly tftp://172.20.129.10/test-image.tar
This example shows how to keep the old software version after a successful download:
Switch# archive download-sw /leave-old-sw tftp://172.20.129.10/test-image.tar
Release Modification
12.2(25)SEF This command was introduced.
2-10
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
archive download-sw
Related Commands Command Description
archive tar Creates a tar file, lists the files in a tar file, or extracts the files from a tar file.
archive upload-sw Uploads an existing image on the switch to a server.
delete Deletes a file or directory on the flash memory device.
2-11
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
archive tar
archive tar
Use the archive tar privileged EXEC command to create a tar file, list files in a tar file, or extract the
files from a tar file.
archive tar {/create destination-url flash:/file-url} | {/table source-url} | {/xtract source-url
flash:/file-url [dir/file...]}
Syntax Description /create destination-url
flash:/file-url
Create a new tar file on the local or network file system.
For destination-url, specify the destination URL alias for the local or
network file system and the name of the tar file to create. These options
are supported:
• The syntax for the local flash filesystem:
flash:
• The syntax for the FTP:
ftp:[[//username[:password]@location]/directory]/tar-filename.tar
• The syntax for an HTTP server:
http://[[username:password]@]{hostname |
host-ip}[/directory]/image-name.tar
• The syntax for a secure HTTP server:
https://[[username:password]@]{hostname |
host-ip}[/directory]/image-name.tar
• The syntax for the Remote Copy Protocol (RCP) is:
rcp:[[//username@location]/directory]/tar-filename.tar
• The syntax for the TFTP:
tftp:[[//location]/directory]/tar-filename.tar
The tar-filename.tar is the tar file to be created.
For flash:/file-url, specify the location on the local flash file system from
which the new tar file is created.
An optional list of files or directories within the source directory can be
specified to write to the new tar file. If none are specified, all files and
directories at this level are written to the newly created tar file.
2-12
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
archive tar
Defaults There is no default setting.
/table source-url Display the contents of an existing tar file to the screen.
For source-url, specify the source URL alias for the local or network file
system. These options are supported:
• The syntax for the local flash file system:
flash:
• The syntax for the FTP:
ftp:[[//username[:password]@location]/directory]/tar-filename.tar
• The syntax for an HTTP server:
http://[[username:password]@]{hostname |
host-ip}[/directory]/image-name.tar
• The syntax for a secure HTTP server:
https://[[username:password]@]{hostname |
host-ip}[/directory]/image-name.tar
• The syntax for the RCP:
rcp:[[//username@location]/directory]/tar-filename.tar
• The syntax for the TFTP:
tftp:[[//location]/directory]/tar-filename.tar
The tar-filename.tar is the tar file to display.
/xtract source-url
flash:/file-url [dir/file...]
Extract files from a tar file to the local file system.
For source-url, specify the source URL alias for the local file system.
These options are supported:
• The syntax for the local flash file system:
flash:
• The syntax for the FTP:
ftp:[[//username[:password]@location]/directory]/tar-filename.tar
• The syntax for an HTTP server:
http://[[username:password]@]{hostname |
host-ip}[/directory]/image-name.tar
• The syntax for a secure HTTP server:
https://[[username:password]@]{hostname |
host-ip}[/directory]/image-name.tar
• The syntax for the RCP:
rcp:[[//username@location]/directory]/tar-filename.tar
• The syntax for the TFTP:
tftp:[[//location]/directory]/tar-filename.tar
The tar-filename.tar is the tar file from which to extract.
For flash:/file-url [dir/file...], specify the location on the local flash file
system into which the tar file is extracted. Use the dir/file... option to
specify an optional list of files or directories within the tar file to be
extracted. If none are specified, all files and directories are extracted.
2-13
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
archive tar
Command Modes Privileged EXEC
Command History
Usage Guidelines Filenames and directory names are case sensitive.
Image names are case sensitive.
Examples This example shows how to create a tar file. The command writes the contents of the new-configs
directory on the local flash device to a file named saved.tar on the TFTP server at 172.20.10.30:
Switch# archive tar /create tftp:172.20.10.30/saved.tar flash:/new-configs
This example shows how to display the contents of the cbs30x0-lanbasek9-tar.122-25.SEF.tar file that
is in flash memory. The contents of the tar file appear on the screen:
Switch# archive tar /table flash:cbs30x0-lanbase-tar.122-25.SEF.tar
info (219 bytes)
cbs30x0
-lanbasek9-mz.122-25.SEF
/ (directory)
(610856 bytes)
/info (219 bytes)
info.ver (219 bytes)
This example shows how to display only the cbs30x0-lanbasek9-tar.122-25.SEF/html directory and its
contents:
Switch# archive tar /table flash:cbs30x0-lanbasek9-tar.122-25.SEF.tar
cbs30x0-lanbasek9-tar.122-25.SEF
cbs30x0
-lanbasek9-mz.122-25.SEF
/html/ (directory)
cbs30x0
-lanbasek9-mz.122-25.SEF
/html/const.htm (556 bytes)
cbs30x0
-lanbasek9-mz.122-25.SEF
/html/xhome.htm (9373 bytes)
cbs30x0
-lanbasek9-mz.122-25.SEF
/html/menu.css (1654 bytes)
<output truncated>
This example shows how to extract the contents of a tar file on the TFTP server at 172.20.10.30. This
command extracts just the new-configs directory into the root directory on the local flash file system.
The remaining files in the saved.tar file are ignored.
Switch# archive tar /xtract tftp:/172.20.10.30/saved.tar flash:/ new-configs
Related Commands
Release Modification
12.2(25)SEF This command was introduced.
Command Description
archive download-sw Downloads a new image from a TFTP server to the switch.
archive upload-sw Uploads an existing image on the switch to a server.
2-14
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
archive upload-sw
archive upload-sw
Use the archive upload-sw privileged EXEC command to upload an existing switch image to a server.
archive upload-sw [/version version_string] destination-url
Syntax Description
Defaults Uploads the currently running image from the flash: file system.
Command Modes Privileged EXEC
Command History
Usage Guidelines Use the upload feature only if the HTML files associated with the embedded device manager have been
installed with the existing image.
The files are uploaded in this sequence: the Cisco IOS image, the HTML files, and info. After these files
are uploaded, the software creates the tar file.
Image names are case sensitive.
/version version_string (Optional) Specify the specific version string of the image to be uploaded.
destination-url The destination URL alias for a local or network file system. These options
are supported:
• The syntax for the local flash file system:
flash:
• The syntax for the FTP:
ftp:[[//username[:password]@location]/directory]/image-name.tar
• The syntax for an HTTP server:
http://[[username:password]@]{hostname |
host-ip}[/directory]/image-name.tar
• The syntax for a secure HTTP server:
https://[[username:password]@]{hostname |
host-ip}[/directory]/image-name.tar
• The syntax for the Remote Copy Protocol (RCP):
rcp:[[//username@location]/directory]/image-name.tar
• The syntax for the TFTP:
tftp:[[//location]/directory]/image-name.tar
The image-name.tar is the name of software image to be stored on the
server.
Release Modification
12.2(25)SEF This command was introduced.
2-15
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
archive upload-sw
Examples This example shows how to upload the currently running image to a TFTP server at 172.20.140.2:
Switch# archive upload-sw tftp://172.20.140.2/test-image.tar
Related Commands Command Description
archive download-sw Downloads a new image to the switch.
archive tar Creates a tar file, lists the files in a tar file, or extracts the files from a tar file.
2-16
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
auto qos voip
auto qos voip
Use the auto qos voip interface configuration command to automatically configure quality of service
(QoS) for voice over IP (VoIP) within a QoS domain. Use the no form of this command to return to the
default setting.
auto qos voip {cisco-phone | cisco-softphone | trust}
no auto qos voip [cisco-phone | cisco-softphone | trust]
Syntax Description
Defaults Auto-QoS is disabled on the port.
When auto-QoS is enabled, it uses the ingress packet label to categorize traffic, to assign packet labels,
and to configure the ingress and egress queues as shown in Ta b le 2 - 1.
cisco-phone Identify this port as connected to a Cisco IP Phone, and automatically configure QoS
for VoIP. The QoS labels of incoming packets are trusted only when the telephone
is detected.
cisco-softphone Identify this port as connected to a device running the Cisco SoftPhone, and
automatically configure QoS for VoIP.
trust Identify this port as connected to a trusted switch or router, and automatically
configure QoS for VoIP. The QoS labels of incoming packets are trusted. For
nonrouted ports, the CoS value of the incoming packet is trusted.
Table 2-1 Traffic Types, Packet Labels, and Queues
VoIP Data
Traffic
VoIP Control
Traffic
Routing Protocol
Traffic
STP1 BPDU2
Traffic
1. STP = Spanning Tree Protocol
2. BPDU = bridge protocol data unit
Real-Time
Video Traffic All Other Traffic
DSCP
3
3. DSCP = Differentiated Services Code Point
46 24, 26 48 56 34 –
CoS
4
4. CoS = class of service
53 6 73–
CoS-to-Ingress
Queue Map
2, 3, 4, 5, 6, 7 (queue 2) 0, 1 (queue 1)
CoS-to-Egress
Queue Map
5 (queue 1) 3, 6, 7 (queue 2) 4 (queue 3) 2
(queue 3)
0, 1
(queue 4)
2-17
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
auto qos voip
Table 2 - 2 shows the generated auto-QoS configuration for the ingress queues.
Table 2 - 3 shows the generated auto-QoS configuration for the egress queues.
Command Modes Interface configuration
Command History
Usage Guidelines Use this command to configure the QoS appropriate for VoIP traffic within the QoS domain. The QoS
domain includes the switch, the interior of the network, and edge devices that can classify incoming
traffic for QoS.
Auto-QoS configures the switch for VoIP with Cisco IP Phones on switch and routed ports and for VoIP
with devices running the Cisco SoftPhone application. These releases support only Cisco IP SoftPhone
Version 1.3(3) or later. Connected devices must use Cisco Call Manager Version 4 or later.
To take advantage of the auto-QoS defaults, you should enable auto-QoS before you configure other QoS
commands. You can fine-tune the auto-QoS configuration after you enable auto-QoS.
Note The switch applies the auto-QoS-generated commands as if the commands were entered from the
command-line interface (CLI). An existing user configuration can cause the application of the generated
commands to fail or to be overridden by the generated commands. These actions occur without warning.
If all the generated commands are successfully applied, any user-entered configuration that was not
overridden remains in the running configuration. Any user-entered configuration that was overridden can
be retrieved by reloading the switch without saving the current configuration to memory. If the generated
commands fail to be applied, the previous running configuration is restored.
Table 2-2 Auto-QoS Configuration for the Ingress Queues
Ingress Queue Queue Number CoS-to-Queue Map
Queue Weight
(Bandwidth)
Queue (Buffer)
Size
SRR
1
shared
1. SRR = shaped round robin. Ingress queues support shared mode only.
1 0, 1 81 percent 67 percent
Priority 2 2, 3, 4, 5, 6, 7 19 percent 33 percent
Table 2-3 Auto-QoS Configuration for the Egress Queues
Egress Queue Queue Number CoS-to-Queue Map
Queue Weight
(Bandwidth)
Queue (Buffer) Size
for Gigabit-Capable
Ports
Queue (Buffer)
Size for 10/100
Ethernet Ports
Priority (shaped) 1 5 10 percent 16 percent 10 percent
SRR shared 2 3, 6, 7 10 percent 6 percent 10 percent
SRR shared 3 2, 4 60 percent 17 percent 26 percent
SRR shared 4 0, 1 20 percent 61 percent 54 percent
Release Modification
12.2(25)SEF This command was introduced.
2-18
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
auto qos voip
If this is the first port on which you have enabled auto-QoS, the auto-QoS-generated global configuration
commands are executed followed by the interface configuration commands. If you enable auto-QoS on
another port, only the auto-QoS-generated interface configuration commands for that port are executed.
When you enable the auto-QoS feature on the first port, these automatic actions occur:
• QoS is globally enabled (mls qos global configuration command), and other global configuration
commands are added.
• When you enter the auto qos voip cisco-phone interface configuration command on a port at the
edge of the network that is connected to a Cisco IP Phone, the switch enables the trusted boundary
feature. The switch uses the Cisco Discovery Protocol (CDP) to detect the presence or absence of a
Cisco IP Phone. When a Cisco IP Phone is detected, the ingress classification on the port is set to
trust the QoS label received in the packet. When a Cisco IP Phone is absent, the ingress classification
is set to not trust the QoS label in the packet. The switch configures ingress and egress queues on
the port according to the settings in Tab l e 2-2 and Ta b l e 2-3 .
• When you enter the auto qos voip cisco-softphone interface configuration command on a port at
the edge of the network that is connected to a device running the Cisco SoftPhone, the switch uses
policing to decide whether a packet is in or out of profile and to specify the action on the packet. If
the packet does not have a DSCP value of 24, 26, or 46 or is out of profile, the switch changes the
DSCP value to 0. The switch configures ingress and egress queues on the port according to the
settings in Tab le 2 -2 and Ta b le 2- 3 .
• When you enter the auto qos voip trust interface configuration command on a port connected to the
interior of the network, the switch trusts the CoS value for nonrouted ports in ingress packets (the
assumption is that traffic has already been classified by other edge devices). The switch configures
the ingress and egress queues on the port according to the settings in Tab le 2 -2 and Tab l e 2-3 .
You can enable auto-QoS on static, dynamic-access, and voice VLAN access, and trunk ports. When
enabling auto-QoS with a Cisco IP Phone on a routed port, you must assign a static IP address to the
IP phone.
Note When a device running Cisco SoftPhone is connected to a switch or routed port, the switch supports only
one Cisco SoftPhone application per port.
After auto-QoS is enabled, do not modify a policy map or aggregate policer that includes AutoQoS in its
name. If you need to modify the policy map or aggregate policer, make a copy of it, and change the
copied policy map or policer. To use the new policy map instead of the generated one, remove the
generated policy map from the interface, and apply the new policy map.
To display the QoS configuration that is automatically generated when auto-QoS is enabled, enable
debugging before you enable auto-QoS. Use the debug auto qos privileged EXEC command to enable
auto-QoS debugging. For more information, see the debug auto qos command.
To disable auto-QoS on a port, use the no auto qos voip interface configuration command. Only the
auto-QoS-generated interface configuration commands for this port are removed. If this is the last port
on which auto-QoS is enabled and you enter the no auto qos voip command, auto-QoS is considered
disabled even though the auto-QoS-generated global configuration commands remain (to avoid
disrupting traffic on other ports affected by the global configuration). You can use the no mls qos global
configuration command to disable the auto-QoS-generated global configuration commands. With QoS
disabled, there is no concept of trusted or untrusted ports because the packets are not modified (the CoS,
DSCP, and IP precedence values in the packet are not changed). Traffic is switched in pass-through mode
(packets are switched without any rewrites and classified as best effort without any policing).
2-19
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
auto qos voip
Examples This example shows how to enable auto-QoS and to trust the QoS labels received in incoming packets
when the switch or router connected to the port is a trusted device:
Switch(config)# interface gigabitethernet0/21
Switch(config-if)# auto qos voip trust
You can verify your settings by entering the show auto qos interface interface-id privileged EXEC
command.
Related Commands Command Description
debug auto qos Enables debugging of the auto-QoS feature.
mls qos cos Defines the default CoS value of a port or assigns the default
CoS to all incoming packets on the port.
mls qos map {cos-dscp dscp1 ... dscp8
| dscp-cos dscp-list to cos}
Defines the CoS-to-DSCP map or the DSCP-to-CoS map.
mls qos queue-set output buffers Allocates buffers to a queue-set.
mls qos srr-queue input bandwidth Assigns shaped round robin (SRR) weights to an ingress
queue.
mls qos srr-queue input buffers Allocates the buffers between the ingress queues.
mls qos srr-queue input cos-map Maps CoS values to an ingress queue or maps CoS values to
a queue and to a threshold ID.
mls qos srr-queue input dscp-map Maps DSCP values to an ingress queue or maps DSCP values
to a queue and to a threshold ID.
mls qos srr-queue input
priority-queue
Configures the ingress priority queue and guarantees
bandwidth.
mls qos srr-queue output cos-map Maps CoS values to an egress queue or maps CoS values to
a queue and to a threshold ID.
mls qos srr-queue output dscp-map Maps DSCP values to an egress queue or maps DSCP values
to a queue and to a threshold ID.
mls qos trust Configures the port trust state.
queue-set Maps a port to a queue-set.
show auto qos Displays auto-QoS information.
show mls qos interface Displays QoS information at the port level.
srr-queue bandwidth shape Assigns the shaped weights and enables bandwidth shaping
on the four egress queues mapped to a port.
srr-queue bandwidth share Assigns the shared weights and enables bandwidth sharing
on the four egress queues mapped to a port.
2-20
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
boot boothlpr
boot boothlpr
Use the boot boothlpr global configuration command to load a special Cisco IOS image, which when
loaded into memory, can load a second Cisco IOS image into memory and launch it. This variable is used
only for internal development and testing. Use the no form of this command to return to the default setting.
boot boothlpr filesystem:/file-url
no boot boothlpr
Syntax Description
Defaults No helper image is loaded.
Command Modes Global configuration
Command History
Usage Guidelines Filenames and directory names are case sensitive.
This command changes the setting of the BOOTHLPR environment variable. For more information, see
Appendix A, “Cisco Catalyst Switch 3020 for HP Boot Loader Commands.”
Related Commands
filesystem: Alias for a flash file system. Use flash: for the system board flash device.
/file-url The path (directory) and name of a bootable helper image.
Release Modification
12.2(25)SEF This command was introduced.
Command Description
show boot Displays the settings of the boot environment variables.
2-21
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
boot config-file
boot config-file
Use the boot config-file global configuration command to specify the filename that Cisco IOS uses to
read and write a nonvolatile copy of the system configuration. Use the no form of this command to return
to the default setting.
boot config-file flash:/file-url
no boot config-file
Syntax Description
Defaults The default configuration file is flash:config.text.
Command Modes Global configuration
Command History
Usage Guidelines Filenames and directory names are case sensitive.
This command changes the setting of the CONFIG_FILE environment variable. For more information,
see Appendix A, “Cisco Catalyst Switch 3020 for HP Boot Loader Commands.”
Related Commands
flash:/file-url The path (directory) and name of the configuration file.
Release Modification
12.2(25)SEF This command was introduced.
Command Description
show boot Displays the settings of the boot environment variables.
2-22
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
boot enable-break
boot enable-break
Use the boot enable-break global configuration command to enable interrupting the automatic boot
process. Use the no form of this command to return to the default setting.
boot enable-break
no boot enable-break
Syntax Description This command has no arguments or keywords.
Defaults Disabled. The automatic boot process cannot be interrupted by pressing the Break key on the console.
Command Modes Global configuration
Command History
Usage Guidelines When you enter this command, you can interrupt the automatic boot process by pressing the Break key
on the console after the flash file system is initialized.
Note Despite the setting of this command, you can interrupt the automatic boot process at any time by pressing
the MODE button on the switch front panel.
This command changes the setting of the ENABLE_BREAK environment variable. For more
information, see Appendix A, “Cisco Catalyst Switch 3020 for HP Boot Loader Commands.”
Related Commands
Release Modification
12.2(25)SEF This command was introduced.
Command Description
show boot Displays the settings of the boot environment variables.
2-23
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
boot helper
boot helper
Use the boot helper global configuration command to dynamically load files during boot loader
initialization to extend or patch the functionality of the boot loader. Use the no form of this command
to return to the default.
boot helper filesystem:/file-url ...
no boot helper
Syntax Description
Defaults No helper files are loaded.
Command Modes Global configuration
Command History
Usage Guidelines This variable is used only for internal development and testing.
Filenames and directory names are case sensitive.
This command changes the setting of the HELPER environment variable. For more information, see
Appendix A, “Cisco Catalyst Switch 3020 for HP Boot Loader Commands.”
Related Commands
filesystem: Alias for a flash file system. Use flash: for the system board flash device.
/file-url The path (directory) and a list of loadable files to dynamically load during
loader initialization. Separate each image name with a semicolon.
Release Modification
12.2(25)SEF This command was introduced.
Command Description
show boot Displays the settings of the boot environment variables.
2-24
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
boot helper-config-file
boot helper-config-file
Use the boot helper-config-file global configuration command to specify the name of the configuration
file to be used by the Cisco IOS helper image. If this is not set, the file specified by the CONFIG_FILE
environment variable is used by all versions of Cisco IOS that are loaded. Use the no form of this
command to return to the default setting.
boot helper-config-file filesystem:/file-url
no boot helper-config file
Syntax Description
Defaults No helper configuration file is specified.
Command Modes Global configuration
Command History
Usage Guidelines This variable is used only for internal development and testing.
Filenames and directory names are case sensitive.
This command changes the setting of the HELPER_CONFIG_FILE environment variable. For more
information, see Appendix A, “Cisco Catalyst Switch 3020 for HP Boot Loader Commands.”
Related Commands
filesystem: Alias for a flash file system. Use flash: for the system board flash
device.
/file-url The path (directory) and helper configuration file to load.
Release Modification
12.2(25)SEF This command was introduced.
Command Description
show boot Displays the settings of the boot environment variables.
2-25
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
boot manual
boot manual
Use the boot manual global configuration command to enable manually booting the switch during the
next boot cycle. Use the no form of this command to return to the default setting.
boot manual
no boot manual
Syntax Description This command has no arguments or keywords.
Defaults Manual booting is disabled.
Command Modes Global configuration
Command History
Usage Guidelines The next time you reboot the system, the switch is in boot loader mode, which is shown by the switch:
prompt. To boot the system, use the boot boot loader command, and specify the name of the bootable
image.
This command changes the setting of the MANUAL_BOOT environment variable. For more
information, see Appendix A, “Cisco Catalyst Switch 3020 for HP Boot Loader Commands.”
Related Commands
Release Modification
12.2(25)SEF This command was introduced.
Command Description
show boot Displays the settings of the boot environment variables.
2-26
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
boot private-config-file
boot private-config-file
Use the boot private-config-file global configuration command to specify the filename that Cisco IOS
uses to read and write a nonvolatile copy of the private configuration. Use the no form of this command
to return to the default setting.
boot private-config-file filename
no boot private-config-file
Syntax Description
Defaults The default configuration file is private-config.
Command Modes Global configuration
Command History
Usage Guidelines Filenames are case sensitive.
Examples This example shows how to specify the name of the private configuration file to be pconfig:
Switch(config)# boot private-config-file pconfig
Related Commands
filename The name of the private configuration file.
Release Modification
12.2(25)SEF This command was introduced.
Command Description
show boot Displays the settings of the boot environment variables.
2-27
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
boot system
boot system
Use the boot system global configuration command to specify the Cisco IOS image to load during the
next boot cycle. Use the no form of this command to return to the default setting.
boot system filesystem:/file-url ...
no boot system
Syntax Description
Defaults The switch attempts to automatically boot the system by using information in the BOOT environment
variable. If this variable is not set, the switch attempts to load and execute the first executable image it
can by performing a recursive, depth-first search throughout the flash file system. In a depth-first search
of a directory, each encountered subdirectory is completely searched before continuing the search in the
original directory.
Command Modes Global configuration
Command History
Usage Guidelines Filenames and directory names are case sensitive.
If you are using the archive download-sw privileged EXEC command to maintain system images, you
never need to use the boot system command. The boot system command is automatically manipulated
to load the downloaded image.
This command changes the setting of the BOOT environment variable. For more information, see
Appendix A, “Cisco Catalyst Switch 3020 for HP Boot Loader Commands.”
Related Commands
filesystem: Alias for a flash file system. Use flash: for the system board flash device.
/file-url The path (directory) and name of a bootable image. Separate image names
with a semicolon.
Release Modification
12.2(25)SEF This command was introduced.
Command Description
show boot Displays the settings of the boot environment variables.
2-28
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
channel-group
channel-group
Use the channel-group interface configuration command to assign an Ethernet port to an EtherChannel
group, to enable an EtherChannel mode, or both. Use the no form of this command to remove an Ethernet
port from an EtherChannel group.
channel-group channel-group-number mode {active | {auto [non-silent]} | {desirable
[non-silent]} | on | passive}
no channel-group
PAg P mo d es :
channel-group channel-group-number mode {{auto [non-silent]} | {desirable [non-silent}}
LACP modes:
channel-group channel-group-number mode {active | passive}
On mode:
channel-group channel-group-number mode on
Syntax Description channel-group-number Specify the channel group number. The range is 1 to 48.
mode Specify the EtherChannel mode.
active Unconditionally enable Link Aggregation Control Protocol (LACP).
Active mode places a port into a negotiating state in which the port initiates
negotiations with other ports by sending LACP packets. A channel is
formed with another port group in either the active or passive mode.
auto Enable the Port Aggregation Protocol (PAgP) only if a PAgP device is
detected.
Auto mode places a port into a passive negotiating state in which the port
responds to PAgP packets it receives but does not start PAgP packet
negotiation. A channel is formed only with another port group in desirable
mode. When auto is enabled, silent operation is the default.
desirable Unconditionally enable PAgP.
Desirable mode places a port into an active negotiating state in which the
port starts negotiations with other ports by sending PAgP packets. An
EtherChannel is formed with another port group that is in the desirable or
auto mode. When desirable is enabled, silent operation is the default.
non-silent (Optional) Use in PAgP mode with the auto or desirable keyword when
traffic is expected from the other device.
on Enable on mode.
In on mode, a usable EtherChannel exists only when both connected port
groups are in the on mode.
passive Enable LACP only if a LACP device is detected.
Passive mode places a port into a negotiating state in which the port
responds to received LACP packets but does not initiate LACP packet
negotiation. A channel is formed only with another port group in active
mode.
2-29
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
channel-group
Defaults No channel groups are assigned.
No mode is configured.
Command Modes Interface configuration
Command History
Usage Guidelines For Layer 2 EtherChannels, you do not have to create a port-channel interface first by using the interface
port-channel global configuration command before assigning a physical port to a channel group.
Instead, you can use the channel-group interface configuration command. It automatically creates the
port-channel interface when the channel group gets its first physical port if the logical interface is not
already created. If you create the port-channel interface first, the channel-group-number can be the same
as the port-channel-number, or you can use a new number. If you use a new number, the channel-group
command dynamically creates a new port channel.
After you configure an EtherChannel, configuration changes that you make on the port-channel interface
apply to all the physical ports assigned to the port-channel interface. Configuration changes applied to
the physical port affect only the port where you apply the configuration. To change the parameters of all
ports in an EtherChannel, apply configuration commands to the port-channel interface, for example,
spanning-tree commands or commands to configure a Layer 2 EtherChannel as a trunk.
If you do not specify non-silent with the auto or desirable mode, silent is assumed. The silent mode is
used when the switch is connected to a device that is not PAgP-capable and seldom, if ever, sends
packets. A example of a silent partner is a file server or a packet analyzer that is not generating traffic.
In this case, running PAgP on a physical port prevents that port from ever becoming operational.
However, it allows PAgP to operate, to attach the port to a channel group, and to use the port for
transmission. Both ends of the link cannot be set to silent.
In the on mode, an EtherChannel exists only when a port group in the on mode is connected to another
port group in the on mode.
Caution You should use care when using the on mode. This is a manual configuration, and ports on both ends of
the EtherChannel must have the same configuration. If the group is misconfigured, packet loss or
spanning-tree loops can occur.
Do not configure an EtherChannel in both the PAgP and LACP modes. EtherChannel groups running
PAgP and LACP can coexist on the same switch. Individual EtherChannel groups can run either PAgP
or LACP, but they cannot interoperate.
If you set the protocol by using the channel-protocol interface configuration command, the setting is
not overridden by the channel-group interface configuration command.
Do not configure a port that is an active or a not-yet-active member of an EtherChannel as an
IEEE 802.1x port. If you try to enable IEEE 802.1x authentication on an EtherChannel port, an error
message appears, and IEEE 802.1x authentication is not enabled.
Do not configure a secure port as part of an EtherChannel or an EtherChannel port as a secure port.
Release Modification
12.2(25)SEF This command was introduced.
2-30
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
channel-group
For a complete list of configuration guidelines, see the “Configuring EtherChannels” chapter in the
software configuration guide for this release.
Examples This example shows how to configure an EtherChannel. It assigns two static-access ports in VLAN 10
to channel 5 with the PAgP mode desirable:
Switch# configure terminal
Switch(config)# interface range gigabitethernet0/21 -22
Switch(config-if-range)# switchport mode access
Switch(config-if-range)# switchport access vlan 10
Switch(config-if-range)# channel-group 5 mode desirable
Switch(config-if-range)# end
This example shows how to configure an EtherChannel. It assigns two static-access ports in VLAN 10
to channel 5 with the LACP mode active:
Switch# configure terminal
Switch(config)# interface range gigabitethernet0/21 -22
Switch(config-if-range)# switchport mode access
Switch(config-if-range)# switchport access vlan 10
Switch(config-if-range)# channel-group 5 mode active
Switch(config-if-range)# end
You can verify your settings by entering the show running-config privileged EXEC command.
Related Commands Command Description
channel-protocol Restricts the protocol used on a port to manage channeling.
interface port-channel Accesses or creates the port channel.
show etherchannel Displays EtherChannel information for a channel.
show lacp Displays LACP channel-group information.
show pagp Displays PAgP channel-group information.
show running-config Displays the current operating configuration. For syntax
information, select Cisco IOS Configuration Fundamentals
Command Reference, Release 12.2 > File Management
Commands > Configuration File Management Commands.
2-31
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
channel-protocol
channel-protocol
Use the channel-protocol interface configuration command to restrict the protocol used on a port to
manage channeling. Use the no form of this command to return to the default setting.
channel-protocol {lacp | pagp}
no channel-protocol
Syntax Description
Defaults No protocol is assigned to the EtherChannel.
Command Modes Interface configuration
Command History
Usage Guidelines Use the channel-protocol command only to restrict a channel to LACP or PAgP. If you set the protocol
by using the channel-protocol command, the setting is not overridden by the channel-group interface
configuration command.
You must use the channel-group interface configuration command to configure the EtherChannel
parameters. The channel-group command also can set the mode for the EtherChannel.
You cannot enable both the PAgP and LACP modes on an EtherChannel group.
PAgP and LACP are not compatible; both ends of a channel must use the same protocol.
Examples This example shows how to specify LACP as the protocol that manages the EtherChannel:
Switch(config-if)# channel-protocol lacp
You can verify your settings by entering the show etherchannel [channel-group-number] protocol
privileged EXEC command.
Related Commands
lacp Configure an EtherChannel with the Link Aggregation Control Protocol (LACP).
pagp Configure an EtherChannel with the Port Aggregation Protocol (PAgP).
Release Modification
12.2(25)SEF This command was introduced.
Command Description
channel-group Assigns an Ethernet port to an EtherChannel group.
show etherchannel protocol Displays protocol information the EtherChannel.
2-32
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
class
class
Use the class policy-map configuration command to define a traffic classification match criteria (through
the police, set, and trust policy-map class configuration commands) for the specified class-map name.
Use the no form of this command to delete an existing class map.
class class-map-name
no class class-map-name
Syntax Description
Defaults No policy map class-maps are defined.
Command Modes Policy-map configuration
Command History
Usage Guidelines Before using the class command, you must use the policy-map global configuration command to
identify the policy map and to enter policy-map configuration mode. After specifying a policy map, you
can configure a policy for new classes or modify a policy for any existing classes in that policy map. You
attach the policy map to a port by using the service-policy interface configuration command.
After entering the class command, you enter policy-map class configuration mode, and these
configuration commands are available:
• exit: exits policy-map class configuration mode and returns to policy-map configuration mode.
• no: returns a command to its default setting.
• police: defines a policer or aggregate policer for the classified traffic. The policer specifies the
bandwidth limitations and the action to take when the limits are exceeded. For more information,
see the police and police aggregate policy-map class commands.
• set: specifies a value to be assigned to the classified traffic. For more information, see the set
command.
• trust: defines a trust state for traffic classified with the class or the class-map command. For more
information, see the trust command.
To return to policy-map configuration mode, use the exit command. To return to privileged EXEC mode,
use the end command.
The class command performs the same function as the class-map global configuration command. Use
the class command when a new classification, which is not shared with any other ports, is needed. Use
the class-map command when the map is shared among many ports.
class-map-name Name of the class map.
Release Modification
12.2(25)SEF This command was introduced.
2-33
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
class
Examples This example shows how to create a policy map called policy1. When attached to the ingress direction,
it matches all the incoming traffic defined in class1, sets the IP Differentiated Services Code Point
(DSCP) to 10, and polices the traffic at an average rate of 1 Mbps and bursts at 20 KB. Traffic exceeding
the profile is marked down to a DSCP value gotten from the policed-DSCP map and then sent.
Switch(config)# policy-map policy1
Switch(config-pmap)# class class1
Switch(config-pmap-c)# set dscp 10
Switch(config-pmap-c)# police 1000000 20000 exceed-action policed-dscp-transmit
Switch(config-pmap-c)# exit
You can verify your settings by entering the show policy-map privileged EXEC command.
Related Commands Command Description
class-map Creates a class map to be used for matching packets to the class whose name
you specify.
police Defines a policer for classified traffic.
policy-map Creates or modifies a policy map that can be attached to multiple ports to
specify a service policy.
set Classifies IP traffic by setting a DSCP or IP-precedence value in the packet.
show policy-map Displays quality of service (QoS) policy maps.
trust Defines a trust state for the traffic classified through the class policy-map
configuration command or the class-map global configuration command.
2-34
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
class-map
class-map
Use the class-map global configuration command to create a class map to be used for matching packets
to the class name you specify and to enter class-map configuration mode. Use the no form of this
command to delete an existing class map and to return to global configuration mode.
class-map [match-all | match-any] class-map-name
no class-map [match-all | match-any] class-map-name
Syntax Description
Defaults No class maps are defined.
If neither the match-all or match-any keyword is specified, the default is match-all.
Command Modes Global configuration
Command History
Usage Guidelines Use this command to specify the name of the class for which you want to create or modify class-map
match criteria and to enter class-map configuration mode.
The class-map command and its subcommands are used to define packet classification, marking, and
aggregate policing as part of a globally named service policy applied on a per-port basis.
After you are in quality of service (QoS) class-map configuration mode, these configuration commands
are available:
• description: describes the class map (up to 200 characters). The show class-map privileged EXEC
command displays the description and the name of the class-map.
• exit: exits from QoS class-map configuration mode.
• match: configures classification criteria. For more information, see the match (class-map
configuration) command.
• no: removes a match statement from a class map.
• rename: renames the current class map. If you rename a class map with a name that is already used,
the message
A class-map with this name already exists appears.
match-all (Optional) Perform a logical-AND of all matching statements under this class
map. All criteria in the class map must be matched.
match-any (Optional) Perform a logical-OR of the matching statements under this class
map. One or more criteria must be matched.
class-map-name Name of the class map.
Release Modification
12.2(25)SEF This command was introduced.
2-35
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
class-map
To define packet classification on a physical-port basis, only one match command per class map is
supported. In this situation, the match-all and match-any keywords are equivalent.
Only one access control list (ACL) can be configured in a class map. The ACL can have multiple access
control entries (ACEs).
Examples This example shows how to configure the class map called class1 with one match criterion, which is an
access list called 103:
Switch(config)# access-list 103 permit any any dscp 10
Switch(config)# class-map class1
Switch(config-cmap)# match access-group 103
Switch(config-cmap)# exit
This example shows how to delete the class map c
lass1
:
Switch(config)# no class-map class1
You can verify your settings by entering the show class-map privileged EXEC command.
Related Commands Command Description
class Defines a traffic classification match criteria (through the police,
set, and trust policy-map class configuration commands) for the
specified class-map name.
match (class-map
configuration)
Defines the match criteria to classify traffic.
policy-map Creates or modifies a policy map that can be attached to multiple
ports to specify a service policy.
show class-map Displays QoS class maps.
2-36
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
clear dot1x
clear dot1x
Use the clear dot1x privileged EXEC command to clear IEEE 802.1x information for the switch or for
the specified port.
clear dot1x {all | interface interface-id}
Syntax Description
Defaults No default is defined.
Command Modes Privileged EXEC
Command History
Usage Guidelines You can clear all the information by using the clear dot1x all command, or you can clear only the
information for the specified interface by using the clear dot1x interface interface-id command.
Examples This example shows how to clear all IEEE 8021.x information:
Switch# clear dot1x all
This example shows how to clear IEEE 8021.x information for the specified interface:
Switch# clear dot1x interface gigabithethernet0/21
You can verify that the information was deleted by entering the show dot1x privileged EXEC command.
Related Commands
all Clear all IEEE 802.1x information for the switch.
interface interface-id Clear IEEE 802.1x information for the specified interface.
Release Modification
12.2(25)SEE This command was introduced.
12.2(25)SEF This command was introduced.
Command Description
show dot1x Displays IEEE 802.1x statistics, administrative status, and operational
status for the switch or for the specified port.
2-37
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
clear eap sessions
clear eap sessions
Use the clear eap sessions privileged EXEC command to clear Extensible Authentication Protocol
(EAP) session information for the switch or for the specified port.
clear eap sessions [credentials name [interface interface-id] | interface interface-id | method
name | transport name] [credentials name | interface interface-id | transport name] ...
Syntax Description
Defaults No default is defined.
Command Modes Privileged EXEC
Command History
Usage Guidelines You can clear all counters by using the clear eap sessions command, or you can clear only the specific
information by using the keywords.
Examples This example shows how to clear all EAP information:
Switch# clear eap
This example shows how to clear EAP-session credential information for the specified profile:
Switch# clear eap sessions credential type1
You can verify that the information was deleted by entering the show dot1x privileged EXEC command.
Related Commands
credentials name Clear EAP credential information for the specified profile.
interface interface-id Clear EAP information for the specified interface.
method name Clear EAP information for the specified method.
transport name Clear EAP transport information for the specified lower level.
Release Modification
12.2(25)SEE This command was introduced.
Command Description
show eap Displays EAP registration and session information for the switch or for
the specified port
2-38
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
clear lacp
clear lacp
Use the clear lacp privileged EXEC command to clear Link Aggregation Control Protocol (LACP)
channel-group counters.
clear lacp {channel-group-number counters | counters}
Syntax Description
Defaults No default is defined.
Command Modes Privileged EXEC
Command History
Usage Guidelines You can clear all counters by using the clear lacp counters command, or you can clear only the counters
for the specified channel group by using the clear lacp channel-group-number counters command.
Examples This example shows how to clear all channel-group information:
Switch# clear lacp counters
This example shows how to clear LACP traffic counters for group 4:
Switch# clear lacp 4 counters
You can verify that the information was deleted by entering the show lacp counters or the show lacp 4
counters privileged EXEC command.
Related Commands
channel-group-number (Optional) Channel group number. The range is 1 to 48.
counters Clear traffic counters.
Release Modification
12.2(25)SEF This command was introduced.
Command Description
show lacp Displays LACP channel-group information.
2-39
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
clear mac address-table
clear mac address-table
Use the clear mac address-table privileged EXEC command to delete from the MAC address table a
specific dynamic address, all dynamic addresses on a particular interface, or all dynamic addresses on a
particular VLAN. This command also clears the MAC address notification global counters.
clear mac address-table {dynamic [address mac-addr | interface interface-id | vlan vlan-id] |
notification}
Syntax Description
Defaults No default is defined.
Command Modes Privileged EXEC
Command History
Examples This example shows how to remove a specific MAC address from the dynamic address table:
Switch# clear mac address-table dynamic address 0008.0070.0007
You can verify that the information was deleted by entering the show mac address-table privileged
EXEC command.
dynamic Delete all dynamic MAC addresses.
dynamic address
mac-addr
(Optional) Delete the specified dynamic MAC address.
dynamic interface
interface-id
(Optional) Delete all dynamic MAC addresses on the specified physical port
or port channel.
dynamic vlan vlan-id (Optional) Delete all dynamic MAC addresses for the specified VLAN. The
range is 1 to 4094.
notification Clear the notifications in the history table and reset the counters.
Release Modification
12.2(25)SEF This command was introduced.
2-40
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
clear mac address-table
Related Commands Command Description
mac address-table notification Enables the MAC address notification feature.
show mac address-table Displays the MAC address table static and dynamic entries.
show mac address-table notification Displays the MAC address notification settings for all
interfaces or the specified interface.
snmp trap mac-notification Enables the Simple Network Management Protocol (SNMP)
MAC address notification trap on a specific interface.
2-41
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
clear mac address-table move update
clear mac address-table move update
Use the clear mac address-table move update privileged EXEC command to clear the mac
address-table-move update-related counters.
clear mac address-table move update
Syntax Description This command has no arguments or keywords.
Defaults No default is defined.
Command Modes Privileged EXEC
Command History
Examples This example shows how to clear the mac address-table move update related counters.
Switch# clear mac address-table move update
You can verify that the information was cleared by entering the show mac address-table move update
privileged EXEC command.
Related Commands
Release Modification
12.2(25)SEF This command was introduced.
Command Description
mac address-table move update
{receive | transmit}
Configures MAC address-table move update on the switch.
show mac address-table move update Displays the MAC address-table move update information on
the switch.
2-42
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
clear pagp
clear pagp
Use the clear pagp privileged EXEC command to clear Port Aggregation Protocol (PAgP)
channel-group information.
clear pagp {channel-group-number counters | counters}
Syntax Description
Defaults No default is defined.
Command Modes Privileged EXEC
Command History
Usage Guidelines You can clear all counters by using the clear pagp counters command, or you can clear only the counters
for the specified channel group by using the clear pagp channel-group-number counters command.
Examples This example shows how to clear all channel-group information:
Switch# clear pagp counters
This example shows how to clear PAgP traffic counters for group 10:
Switch# clear pagp 10 counters
You can verify that information was deleted by entering the show pagp privileged EXEC command.
Related Commands
channel-group-number (Optional) Channel group number. The range is 1 to 48.
counters Clear traffic counters.
Release Modification
12.2(25)SEF This command was introduced.
Command Description
show pagp Displays PAgP channel-group information.
2-43
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
clear port-security
clear port-security
Use the clear port-security privileged EXEC command to delete from the MAC address table all secure
addresses or all secure addresses of a specific type (configured, dynamic, or sticky) on the switch or on
an interface.
clear port-security {all | configured | dynamic | sticky} [[address mac-addr | interface
interface-id] [vlan {vlan-id | {access | voice}}]]
Syntax Description
Defaults No default is defined.
Command Modes Privileged EXEC
Command History
Examples This example shows how to clear all secure addresses from the MAC address table:
Switch# clear port-security all
This example shows how to remove a specific configured secure address from the MAC address table:
Switch# clear port-security configured address 0008.0070.0007
all Delete all secure MAC addresses.
configured Delete configured secure MAC addresses.
dynamic Delete secure MAC addresses auto-learned by hardware.
sticky Delete secure MAC addresses, either auto-learned or configured.
address mac-addr (Optional) Delete the specified dynamic secure MAC address.
interface interface-id (Optional) Delete all the dynamic secure MAC addresses on the specified
physical port or VLAN.
vlan (Optional) Delete the specified secure MAC address from the specified
VLAN. Enter one of these options after you enter the vlan keyword:
• vlan-id—On a trunk port, specify the VLAN ID of the VLAN on which
this address should be cleared.
• access—On an access port, clear the specified secure MAC address on
the access VLAN.
• voice—On an access port, clear the specified secure MAC address on the
voice VLAN.
Note The voice keyword is available only if voice VLAN is configured on
a port and if that port is not the access VLAN.
Release Modification
12.2(25)SEF This command was introduced.
2-44
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
clear port-security
This example shows how to remove all the dynamic secure addresses learned on a specific interface:
Switch# clear port-security dynamic interface gigabitethernet0/21
This example shows how to remove all the dynamic secure addresses from the address table:
Switch# clear port-security dynamic
You can verify that the information was deleted by entering the show port-security privileged EXEC
command.
Related Commands Command Description
switchport port-security Enables port security on an interface.
switchport port-security
mac-address mac-address
Configures secure MAC addresses.
switchport port-security maximum
value
Configures a maximum number of secure MAC addresses on a
secure interface.
show port-security Displays the port security settings defined for an interface or for
the switch.
2-45
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
clear spanning-tree counters
clear spanning-tree counters
Use the clear spanning-tree counters privileged EXEC command to clear the spanning-tree counters.
clear spanning-tree counters [interface interface-id]
Syntax Description
Defaults No default is defined.
Command Modes Privileged EXEC
Command History
Usage Guidelines If the interface-id is not specified, spanning-tree counters are cleared for all interfaces.
Examples This example shows how to clear spanning-tree counters for all interfaces:
Switch# clear spanning-tree counters
Related Commands
interface interface-id (Optional) Clear all spanning-tree counters on the specified interface. Valid
interfaces include physical ports, VLANs, and port channels. The VLAN
range is 1 to 4094. The port-channel range is 1 to 48.
Release Modification
12.2(25)SEF This command was introduced.
Command Description
show spanning-tree Displays spanning-tree state information.
2-46
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
clear spanning-tree detected-protocols
clear spanning-tree detected-protocols
Use the clear spanning-tree detected-protocols privileged EXEC command to restart the protocol
migration process (force the renegotiation with neighboring switches) on all interfaces or on the
specified interface.
clear spanning-tree detected-protocols [interface interface-id]
Syntax Description
Defaults No default is defined.
Command Modes Privileged EXEC
Command History
Usage Guidelines A switch running the rapid per-VLAN spanning-tree plus (rapid-PVST+) protocol or the Multiple
Spanning Tree Protocol (MSTP) supports a built-in protocol migration mechanism that enables it to
interoperate with legacy IEEE 802.1D switches. If a rapid-PVST+ switch or an MSTP switch receives a
legacy IEEE 802.1D configuration bridge protocol data unit (BPDU) with the protocol version set to 0,
it sends only IEEE 802.1D BPDUs on that port. A multiple spanning-tree (MST) switch can also detect
that a port is at the boundary of a region when it receives a legacy BPDU, an MST BPDU (Version 3)
associated with a different region, or a rapid spanning-tree (RST) BPDU (Version 2).
However, the switch does not automatically revert to the rapid-PVST+ or the MSTP mode if it no longer
receives IEEE 802.1D BPDUs because it cannot learn whether the legacy switch has been removed from
the link unless the legacy switch is the designated switch. Use the clear spanning-tree
detected-protocols command in this situation.
Examples This example shows how to restart the protocol migration process on a port:
Switch# clear spanning-tree detected-protocols interface gigabitethernet0/1
Related Commands
interface interface-id (Optional) Restart the protocol migration process on the specified interface.
Valid interfaces include physical ports, VLANs, and port channels. The
VLAN range is 1 to 4094. The port-channel range is 1 to 48.
Release Modification
12.2(25)SEF This command was introduced.
Command Description
show spanning-tree Displays spanning-tree state information.
spanning-tree link-type Overrides the default link-type setting and enables rapid spanning-tree
changes to the forwarding state.
2-47
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
clear vmps statistics
clear vmps statistics
Use the clear vmps statistics privileged EXEC command to clear the statistics maintained by the VLAN
Query Protocol (VQP) client.
clear vmps statistics
Syntax Description This command has no arguments or keywords.
Defaults No default is defined.
Command Modes Privileged EXEC
Command History
Examples This example shows how to clear VLAN Membership Policy Server (VMPS) statistics:
Switch# clear vmps statistics
You can verify that information was deleted by entering the show vmps statistics privileged EXEC
command.
Related Commands
Release Modification
12.2(25)SEF This command was introduced.
Command Description
show vmps Displays the VQP version, reconfirmation interval, retry count, VMPS IP
addresses, and the current and primary servers.
2-48
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
clear vtp counters
clear vtp counters
Use the clear vtp counters privileged EXEC command to clear the VLAN Trunking Protocol (VTP) and
pruning counters.
clear vtp counters
Syntax Description This command has no arguments or keywords.
Defaults No default is defined.
Command Modes Privileged EXEC
Command History
Examples This example shows how to clear the VTP counters:
Switch# clear vtp counters
You can verify that information was deleted by entering the show vtp counters privileged EXEC
command.
Related Commands
Release Modification
12.2(25)SEF This command was introduced.
Command Description
show vtp Displays general information about the VTP management domain, status,
and counters.
2-49
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
define interface-range
define interface-range
Use the define interface-range global configuration command to create an interface-range macro. Use
the no form of this command to delete the defined macro.
define interface-range macro-name interface-range
no define interface-range macro-name interface-range
Syntax Description
Defaults This command has no default setting.
Command Modes Global configuration
Command History
Usage Guidelines The macro name is a 32-character maximum character string.
A macro can contain up to five ranges.
All interfaces in a range must be the same type; that is, all Gigabit Ethernet ports, all EtherChannel ports,
or all VLANs, but you can combine multiple interface types in a macro.
When entering the interface-range, use this format:
• type {first-interface} - {last-interface}
• You must add a space between the first interface number and the hyphen when entering an
interface-range. For example, gigabitethernet 0/1 - 2 is a valid range; gigabitethernet 0/1-2 is not
a valid range
Valid values for type and interface:
• vlan vlan-id , where the VLAN ID is 1 to 4094
VLAN interfaces must have been configured with the interface vlan command (the show
running-config privileged EXEC command displays the configured VLAN interfaces). VLAN
interfaces not displayed by the show running-config command cannot be used in interface-ranges.
• port-channel port-channel-number, where port-channel-number is from 1 to 48
• gigabitethernet module/{first port} - {last port}
For physical interfaces:
• module is always 0.
• the range is type 0/number - number (for example, gigabitethernet 0/1 - 2).
macro-name Name of the interface-range macro; up to 32 characters.
interface-range Interface range; for valid values for interface ranges, see “Usage Guidelines.”
Release Modification
12.2(25)SEF This command was introduced.
2-50
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
define interface-range
When you define a range, you must enter a space before the hyphen (-), for example:
gigabitethernet0/1 - 2
You can also enter multiple ranges. When you define multiple ranges, you must enter a space after the
first entry before the comma (,). The space after the comma is optional, for example:
gigabitethernet0/3, gigabitethernet 0/6 - 7
gigabitethernet0/3 -4, gigabitethernet 0/6 - 7
Examples This example shows how to create a multiple-interface macro:
Switch(config)# define interface-range macro1 gigabitethernet0/1 - 2
Related Commands Command Description
interface range Executes a command on multiple ports at the same time.
show running-config Displays the current operating configuration, including defined
macros. For syntax information, select Cisco IOS Configuration
Fundamentals Command Reference, Release 12.2 > File Management
Commands > Configuration File Management Commands.
2-51
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
delete
delete
Use the delete privileged EXEC command to delete a file or directory on the flash memory device.
delete [/force] [/recursive] filesystem:/file-url
Syntax Description
Command Modes Privileged EXEC
Command History
Usage Guidelines If you use the /force keyword, you are prompted once at the beginning of the deletion process to confirm
the deletion.
If you use the /recursive keyword without the /force keyword, you are prompted to confirm the deletion
of every file.
The prompting behavior depends on the setting of the file prompt global configuration command. By
default, the switch prompts for confirmation on destructive file operations. For more information about
this command, see the Cisco IOS Command Reference for Release 12.1.
Examples This example shows how to remove the directory that contains the old software image after a successful
download of a new image:
Switch# delete /force /recursive flash:/old-image
You can verify that the directory was removed by entering the dir filesystem: privileged EXEC
command.
Related Commands
/force (Optional) Suppress the prompt that confirms the deletion.
/recursive (Optional) Delete the named directory and all subdirectories and the files contained in
it.
filesystem: Alias for a flash file system.
The syntax for the local flash file system:
flash:
/file-url The path (directory) and filename to delete.
Release Modification
12.2(25)SEF This command was introduced.
Command Description
archive download-sw Downloads a new image to the switch and overwrites or keeps the existing
image.
2-52
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
deny (MAC access-list configuration)
deny (MAC access-list configuration)
Use the deny MAC access-list configuration command to prevent non-IP traffic from being forwarded
if the conditions are matched. Use the no form of this command to remove a deny condition from the
named MAC access list.
{deny | permit} {any | host src-MAC-addr | src-MAC-addr mask} {any | host dst-MAC-addr |
dst-MAC-addr mask} [type mask | aarp | amber | cos cos | dec-spanning | decnet-iv |
diagnostic | dsm | etype-6000 | etype-8042 | lat | lavc-sca | lsap lsap mask |mop-console |
mop-dump | msdos | mumps | netbios | vines-echo | vines-ip | xns-idp]
no {deny | permit} {any | host src-MAC-addr | src-MAC-addr mask} {
any | host dst-MAC-addr |
dst-MAC-addr mask} [type mask | aarp | amber | cos cos | dec-spanning | decnet-iv |
diagnostic | dsm | etype-6000 | etype-8042 | lat | lavc-sca | lsap lsap mask | mop-console |
mop-dump | msdos | mumps | netbios | vines-echo | vines-ip | xns-idp]
Syntax Description any Keyword to specify to deny any source or destination MAC address.
host src MAC-addr |
src-MAC-addr mask
Define a host MAC address and optional subnet mask. If the source
address for a packet matches the defined address, non-IP traffic from that
address is denied.
host dst-MAC-addr |
dst-MAC-addr mask
Define a destination MAC address and optional subnet mask. If the
destination address for a packet matches the defined address, non-IP
traffic to that address is denied.
type mask (Optional) Use the Ethertype number of a packet with Ethernet II or
SNAP encapsulation to identify the protocol of the packet.
The type is 0 to 65535, specified in hexadecimal.
The mask is a mask of don’t care bits applied to the Ethertype before
testing for a match.
aarp (Optional) Select Ethertype AppleTalk Address Resolution Protocol that
maps a data-link address to a network address.
amber (Optional) Select EtherType DEC-Amber.
cos
cos (Optional) Select a class of service (CoS) number from 0 to 7 to set
priority. Filtering on CoS can be performed only in hardware. A warning
message reminds the user if the cos option is configured.
dec-spanning (Optional) Select EtherType Digital Equipment Corporation (DEC)
spanning tree.
decnet-iv (Optional) Select EtherType DECnet Phase IV protocol.
diagnostic (Optional) Select EtherType DEC-Diagnostic.
dsm (Optional) Select EtherType DEC-DSM.
etype-6000 (Optional) Select EtherType 0x6000.
etype-8042 (Optional) Select EtherType 0x8042.
lat (Optional) Select EtherType DEC-LAT.
lavc-sca (Optional) Select EtherType DEC-LAVC-SCA.
2-53
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
deny (MAC access-list configuration)
Note Though visible in the command-line help strings, appletalk is not supported as a matching condition.
To filter IPX traffic, you use the type mask or lsap lsap mask keywords, depending on the type of IPX
encapsulation being used. Filter criteria for IPX encapsulation types as specified in Novell terminology
and Cisco IOS terminology are listed in Table 2- 4 .
Defaults This command has no defaults. However; the default action for a MAC-named ACL is to deny.
Command Modes MAC-access list configuration
Command History
lsap lsap-number mask (Optional) Use the LSAP number (0 to 65535) of a packet with 802.2
encapsulation to identify the protocol of the packet.
mask is a mask of don’t care bits applied to the LSAP number before
testing for a match.
mop-console (Optional) Select EtherType DEC-MOP Remote Console.
mop-dump (Optional) Select EtherType DEC-MOP Dump.
msdos (Optional) Select EtherType DEC-MSDOS.
mumps (Optional) Select EtherType DEC-MUMPS.
netbios (Optional) Select EtherType DEC- Network Basic Input/Output System
(NETBIOS).
vines-echo (Optional) Select EtherType Virtual Integrated Network Service (VINES)
Echo from Banyan Systems.
vines-ip (Optional) Select EtherType VINES IP.
xns-idp (Optional) Select EtherType Xerox Network Systems (XNS) protocol
suite (0 to 65535), an arbitrary Ethertype in decimal, hexadecimal, or
octal.
Table 2-4 IPX Filtering Criteria
IPX Encapsulation Type
Filter CriterionCisco IOS Name Novel Name
arpa Ethernet II Ethertype 0x8137
snap Ethernet-snap Ethertype 0x8137
sap Ethernet 802.2 LSAP 0xE0E0
novell-ether Ethernet 802.3 LSAP 0xFFFF
Release Modification
12.2(25)SEF This command was introduced.
2-54
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
deny (MAC access-list configuration)
Usage Guidelines You enter MAC-access list configuration mode by using the mac access-list extended global
configuration command.
If you use the host keyword, you cannot enter an address mask; if you do not use the host keyword, you
must enter an address mask.
When an access control entry (ACE) is added to an access control list, an implied deny-any-any
condition exists at the end of the list. That is, if there are no matches, the packets are denied. However,
before the first ACE is added, the list permits all packets.
For more information about named MAC extended access lists, see the software configuration guide for
this release.
Examples This example shows how to define the named MAC extended access list to deny NETBIOS traffic from
any source to MAC address 00c0.00a0.03fa. Traffic matching this list is denied.
Switch(config-ext-macl)# deny any host 00c0.00a0.03fa netbios.
This example shows how to remove the deny condition from the named MAC extended access list:
Switch(config-ext-macl)# no deny any 00c0.00a0.03fa 0000.0000.0000 netbios.
This example denies all packets with Ethertype 0x4321:
Switch(config-ext-macl)# deny any any 0x4321 0
You can verify your settings by entering the show access-lists privileged EXEC command.
Related Commands Command Description
mac access-list extended Creates an access list based on MAC addresses for non-IP traffic.
permit (MAC access-list
configuration)
Permits non-IP traffic to be forwarded if conditions are matched.
show access-lists Displays access control lists configured on a switch.
2-55
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
dot1x
dot1x
Use the dot1x global configuration command to globally enable IEEE 802.1x authentication. Use the no
form of this command to return to the default setting.
dot1x {critical {eapol | recovery delay milliseconds} | system-auth-control}
no dot1x {credentials | critical {eapol | recovery delay} | system-auth-control}
Note Though visible in the command-line help strings, the credentials name keywords are not supported.
Syntax Description
Defaults IEEE 802.1x authentication is disabled.
Command Modes Global configuration
Command History
Usage Guidelines You must enable authentication, authorization, and accounting (AAA) and specify the authentication
method list before globally enabling IEEE 802.1x authentication. A method list describes the sequence
and authentication methods to be used to authenticate a user.
Before globally enabling IEEE 802.1x authentication on a switch, remove the EtherChannel
configuration from the interfaces on which IEEE 802.1x authentication and EtherChannel are
configured.
If you are using a device running the Cisco Access Control Server (ACS) application for IEEE 802.1x
authentication with EAP-Transparent LAN Services (TLS) and with EAP-MD5, make sure that the
device is running ACS Version 3.2.1 or later.
Examples This example shows how to globally enable IEEE 802.1x authentication on a switch:
Switch(config)# dot1x system-auth-control
You can verify your settings by entering the show dot1x [interface interface-id] privileged EXEC
command.
critical {eapol |
recovery delay
milliseconds}
Configure the inaccessible authentication bypass parameters. For more
information, see the dot1x critical (global configuration) command.
system-auth-control Enable IEEE 802.1x authentication globally on the switch.
Release Modification
12.2(25)SEF This command was introduced.
2-56
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
dot1x
Related Commands Command Description
dot1x critical (global
configuration)
Configures the parameters for the inaccessible authentication bypass
feature on the switch.
dot1x guest-vlan Enables and specifies an active VLAN as an IEEE 802.1x guest VLAN.
dot1x port-control Enables manual control of the authorization state of the port.
show dot1x [interface
interface-id]
Displays IEEE 802.1x status for the specified port.
2-57
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
dot1x auth-fail max-attempts
dot1x auth-fail max-attempts
Use the dot1x auth-fail max-attempts interface configuration command to configure the maximum
allowable authentication attempts before a port is moved to the restricted VLAN. To return to the default
setting, use the no form of this command.
dot1x auth-fail max-attempts max-attempts
no dot1x auth-fail max-attempts
Syntax Description
Defaults The default value is 3 attempts.
Command Modes Interface configuration
Command History
Usage Guidelines If you reconfigure the maximum number of authentication attempts allowed by the VLAN, the change
takes effect after the re-authentication timer expires.
Examples This example shows how to set 2 as the maximum number of authentication attempts allowed before the
port is moved to the restricted VLAN on port 23:
Switch# configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
Switch(config)# interface gigabitethernet0/23
Switch(config-if)# dot1x auth-fail max-attempts 2
Switch(config-if)# end
Switch(config)# end
Switch#
You can verify your settings by entering the show dot1x [interface interface-id] privileged EXEC
command.
max-attempts Specify a maximum number of authentication attempts allowed before a port
is moved to the restricted VLAN. The range is 1 to 3, the default value is 3.
Release Modification
12.2(25)SEF This command was introduced.
2-58
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
dot1x auth-fail max-attempts
Related Commands Command Description
dot1x auth-fail vlan [vlan id] Enables the optional restricted VLAN feature.
dot1x max-reauth-req [count] Sets the maximum number of times that the switch restarts
the authentication process before a port changes to the
unauthorized state.
show dot1x [interface interface-id] Displays IEEE 802.1x status for the specified port.
2-59
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
dot1x auth-fail vlan
dot1x auth-fail vlan
Use the dot1x auth-fail vlan interface configuration command to enable the restricted VLAN on a port.
To return to the default setting, use the no form of this command.
dot1x auth-fail vlan vlan-id
no dot1x auth-fail vlan
Syntax Description
Defaults No restricted VLAN is configured.
Command Modes Interface configuration
Command History
Usage Guidelines You can configure a restricted VLAN on ports configured as follows:
• single-host (default) mode
• auto mode for authorization
You should enable re-authentication. The ports in restricted VLANs do not receive re-authentication
requests if it is disabled. To start the re-authentication process, the restricted VLAN must receive a
link-down event or an Extensible Authentication Protocol (EAP) logoff event from the port. If a host is
connected through a hub, the port might never receive a link-down event when that host is disconnected,
and, as a result, might not detect any new hosts until the next re-authentication attempt occurs.
If the supplicant fails authentication, the port is moved to a restricted VLAN, and an EAP success
message is sent to the supplicant. Because the supplicant is not notified of the actual authentication
failure, there might be confusion about this restricted network access. An EAP success message is sent
for these reasons:
• If the EAP success message is not sent, the supplicant tries to authenticate every 60 seconds (the
default) by sending an EAP-start message.
• Some hosts (for example, devices running Windows XP) cannot implement DHCP until they receive
an EAP success message.
A supplicant might cache an incorrect username and password combination after receiving an EAP
success message from the authenticator and re-use that information in every re-authentication. Until the
supplicant sends the correct username and password combination, the port remains in the restricted
VLAN.
Internal VLANs used for Layer 3 ports cannot be configured as restricted VLANs.
You cannot configure a VLAN to be both a restricted VLAN and a voice VLAN. If you do this, a syslog
message is generated.
vlan-id Specify a VLAN in the range of 1 to 4094.
Release Modification
12.2(25)SEF This command was introduced.
2-60
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
dot1x auth-fail vlan
When a restricted VLAN port is moved to an unauthorized state, the authentication process restarts. If
the supplicant fails the authentication process again, the authenticator waits in the held state. After the
supplicant has correctly re-authenticated, all IEEE 802.1x ports are reinitialized and treated as normal
IEEE 802.1x ports.
When you reconfigure a restricted VLAN as a different VLAN, any ports in the restricted VLAN are also
moved, and the ports stay in their currently authorized state.
When you shut down or remove a restricted VLAN from the VLAN database, any ports in the restricted
VLAN are immediately moved to an unauthorized state, and the authentication process restarts. The
authenticator does not wait in a held state because the restricted VLAN configuration still exists. While
the restricted VLAN is inactive, all authentication attempts are counted so that when the restricted
VLAN becomes active, the port is immediately placed in the restricted VLAN.
The restricted VLAN is supported only in single host mode (the default port mode). For this reason,
when a port is placed in a restricted VLAN, the supplicant’s MAC address is added to the MAC address
table, and any other MAC address that appears on the port is treated as a security violation.
Examples This example shows how to configure a restricted VLAN on port 21:
Switch# configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
Switch(config)# interface gigabitethernet0/21
Switch(config-if)# dot1x auth-fail vlan 40
Switch(config-if)# end
Switch#
You can verify your configuration by entering the show dot1x [interface interface-id] privileged EXEC
command.
Related Commands Command Description
dot1x auth-fail max-attempts
[max-attempts]
Configures the number of authentication attempts allowed
before assigning a supplicant to the restricted VLAN.
show dot1x [interface interface-id] Displays IEEE 802.1x status for the specified port.
2-61
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
dot1x control-direction
dot1x control-direction
Use the dot1x control-direction interface configuration command to enable the IEEE 802.1x
authentication with the wake-on-LAN (WoL) feature and to configure the port control as unidirectional
or bidirectional. Use the no form of this command to return to the default setting.
dot1x control-direction {both | in}
no dot1x control-direction
Syntax Description
Defaults The port is in bidirectional mode.
Command Modes Interface configuration
Command History
Usage Guidelines Use the both keyword or the no form of this command to return to the default setting, bidirectional
mode.
For more information about WoL, see the “Using IEEE 802.1x Authentication with Wake-on-LAN”
section in the “Configuring IEEE 802.1x Port-Based Authentication” chapter in the software
configuration guide.
Examples This example shows how to enable unidirectional control:
Switch(config-if)# dot1x control-direction in
This example shows how to enable bidirectional control:
Switch(config-if)# dot1x control-direction both
You can verify your settings by entering the show dot1x all privileged EXEC command.
The show dot1x all privileged EXEC command output is the same for all switches except for the port
names and the state of the port. If a host is attached to the port but is not yet authenticated, a display
similar to this appears:
Supplicant MAC 0002.b39a.9275
AuthSM State = CONNECTING
BendSM State = IDLE
PortStatus = UNAUTHORIZED
both Enable bidirectional control on port. The port cannot receive
packets from or send packets to the host.
in Enable unidirectional control on port. The port can send packets to
the host but cannot receive packets from the host.
Release Modification
12.2(25)SEF This command was introduced.
2-62
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
dot1x control-direction
If you enter the dot1x control-direction in interface configuration command to enable unidirectional
control, this appears in the show dot1x all command output:
ControlDirection = In
If you enter the dot1x control-direction in interface configuration command and the port cannot support
this mode due to a configuration conflict, this appears in the show dot1x all command output:
ControlDirection = In (Disabled due to port settings)
Related Commands Command Description
show dot1x [all | interface
interface-id]
Displays control-direction port setting status for the specified
interface.
2-63
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
dot1x critical (global configuration)
dot1x critical (global configuration)
Use the dot1x critical global configuration command on a standalone switch to configure the parameters
for the inaccessible authentication bypass feature, also referred to as critical authentication or the
authentication, authorization, and accounting (AAA) fail policy. To return to default settings, use the no
form of this command.
dot1x critical {eapol | recovery delay milliseconds}
no dot1x critical {eapol | recovery delay}
Syntax Description
Defaults The switch does not send an EAPOL-Success message to the host when the switch successfully
authenticates the critical port by putting the critical port in the critical-authentication state.
The recovery delay period is 1000 milliseconds (1 second).
Command Modes Global configuration
Command History
Usage Guidelines Use the eapol keyword to specify that the switch sends an EAPOL-Success message when the switch
puts the critical port in the critical-authentication state.
Use the recovery delay milliseconds keyword to set the recovery delay period during which the switch
waits to re-initialize a critical port when a RADIUS server that was unavailable becomes available. The
default recovery delay period is 1000 milliseconds. A port can be re-initialized every second.
To enable inaccessible authentication bypass on a port, use the dot1x critical interface configuration
command. To configure the access VLAN to which the switch assigns a critical port, use the dot1x
critical vlan vlan-id interface configuration command.
Examples This example shows how to set 200 as the recovery delay period on the switch:
Switch# dot1x critical recovery delay 200
You can verify your configuration by entering the show dot1x privileged EXEC command.
eapol Specify that the switch sends an EAPOL-Success message when the
switch puts the critical port in the critical-authentication state.
recovery delay milliseconds Set the recovery delay period in milliseconds. The range is from 1
to 10000 milliseconds.
Release Modification
12.2(25)SEE This command was introduced.
12.2(25)SEF This command was introduced.
2-64
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
dot1x critical (global configuration)
Related Commands Command Description
dot1x critical (interface
configuration)
Enables the inaccessible authentication bypass feature, and
configures the access VLAN for the feature.
show dot1x Displays IEEE 802.1x status for the specified port.
2-65
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
dot1x critical (interface configuration)
dot1x critical (interface configuration)
Use the dot1x critical interface configuration command on a standalone switch to enable the
inaccessible-authentication-bypass feature, also referred to as critical authentication or the
authentication, authorization, and accounting (AAA) fail policy. You can also configure the access
VLAN to which the switch assigns the critical port when the port is in the critical-authentication state.
To disable the feature or return to default, use the no form of this command.
dot1x critical [recovery action reinitialize | vlan vlan-id]
no dot1x critical [recovery | vlan]
Syntax Description
Defaults The inaccessible-authentication-bypass feature is disabled.
The recovery action is not configured.
The access VLAN is not configured.
Command Modes Interface configuration
Command History
Usage Guidelines To specify the access VLAN to which the switch assigns a critical port when the port is in the
critical-authentication state, use the vlan vlan-id keywords. The specified type of VLAN must match the
type of port, as follows:
• If the critical port is an access port, the VLAN must be an access VLAN.
• If the critical port is a private VLAN host port, the VLAN must be a secondary private VLAN.
• If the critical port is a routed port, you can specify a VLAN, but this is optional.
If the client is running Windows XP and the critical port to which the client is connected is in the
critical-authentication state, Windows XP might report that the interface is not authenticated.
If the Windows XP client is configured for DHCP and has an IP address from the DHCP server, receiving
an EAP-Success message on a critical port might not re-initiate the DHCP configuration process.
recovery action reinitialize Enable the inaccessible-authentication-bypass recovery feature, and
specify that the recovery action is to authenticate the port when an
authentication server is available.
vlan vlan-id Specify the access VLAN to which the switch can assign a critical
port. The range is from 1 to 4094.
Release Modification
12.2(25)SEF This command was introduced.
2-66
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
dot1x critical (interface configuration)
You can configure the inaccessible authentication bypass feature and the restricted VLAN on an
IEEE 802.1x port. If the switch tries to re-authenticate a critical port in a restricted VLAN and all the
RADIUS servers are unavailable, the switch changes the port state to the critical authentication state,
and it remains in the restricted VLAN.
You can configure the inaccessible bypass feature and port security on the same switch port.
Examples This example shows how to enable the inaccessible authentication bypass feature on port 21:
Switch# configure terminal
Enter configuration commands, one per line. End with CNTL/Z.
Switch(config)# interface gigabitethernet0/21
Switch(config-if)# dot1x critical
Switch(config-if)# end
Switch(config)# end
Switch#
You can verify your configuration by entering the show dot1x [interface interface-id] privileged EXEC
command.
Related Commands Command Description
dot1x critical (global configuration) Configures the parameters for the inaccessible authentication
bypass feature on the switch.
show dot1x [interface interface-id] Displays IEEE 802.1x status for the specified port.
2-67
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
dot1x default
dot1x default
Use the dot1x default interface configuration command to reset the IEEE 802.1x parameters to their
default values.
dot1x default
Syntax Description This command has no arguments or keywords.
Defaults These are the default values:
• The per-port IEEE 802.1x protocol enable state is disabled (force-authorized).
• The number of seconds between re-authentication attempts is 3600 seconds.
• The periodic re-authentication is disabled.
• The quiet period is 60 seconds.
• The retransmission time is 30 seconds.
• The maximum retransmission number is 2 times.
• The host mode is single host.
• The client timeout period is 30 seconds.
• The authentication server timeout period is 30 seconds.
Command Modes Interface configuration
Command History
Examples This example shows how to reset the IEEE 802.1x parameters on a port:
Switch(config-if)# dot1x default
You can verify your settings by entering the show dot1x [interface interface-id] privileged EXEC
command.
Related Commands
Release Modification
12.2(25)SEF This command was introduced.
Command Description
show dot1x [interface interface-id] Displays IEEE 802.1x status for the specified port.
2-68
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
dot1x guest-vlan
dot1x guest-vlan
Use the dot1x guest-vlan interface configuration command to specify an active VLAN as an
IEEE 802.1x guest VLAN. Use the no form of this command to return to the default setting.
dot1x guest-vlan vlan-id
no dot1x guest-vlan
Syntax Description
Defaults No guest VLAN is configured.
Command Modes Interface configuration
Command History
Usage Guidelines You can configure a guest VLAN on one of these switch ports:
• A static-access port that belongs to a nonprivate VLAN.
• A private-VLAN port that belongs to a secondary private VLAN. All the hosts connected to the
switch port are assigned to private VLANs, whether or not the posture validation was successful.
The switch determines the primary private VLAN by using the primary- and
secondary-private-VLAN associations on the switch.
For each IEEE 802.1x port on the switch, you can configure a guest VLAN to provide limited services
to clients (a device or workstation connected to the switch) not running IEEE 802.1x authentication.
These users might be upgrading their systems for IEEE 802.1x authentication, and some hosts, such as
Windows 98 systems, might not be IEEE 802.1x-capable.
When you enable a guest VLAN on an IEEE 802.1x port, the switch assigns clients to a guest VLAN
when it does not receive a response to its Extensible Authentication Protocol over LAN (EAPOL)
request/identity frame or when EAPOL packets are not sent by the client.
The switch maintains the EAPOL packet history. If another EAPOL packet is detected on the interface
during the lifetime of the link, the guest VLAN feature is disabled. If the port is already in the guest
VLAN state, the port returns to the unauthorized state, and authentication restarts. The EAPOL history
is reset upon loss of link.
Any number of non-IEEE 802.1x-capable clients are allowed access when the switch port is moved to
the guest VLAN. If an IEEE 802.1x-capable client joins the same port on which the guest VLAN is
configured, the port is put into the unauthorized state in the RADIUS-configured or user-configured
access VLAN, and authentication is restarted.
Guest VLANs are supported on IEEE 802.1x ports in single-host or multiple-hosts mode.
vlan-id Specify an active VLAN as an IEEE 802.1x guest VLAN. The range is 1
to 4094.
Release Modification
12.2(25)SEF This command was introduced.
2-69
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
dot1x guest-vlan
You can configure any active VLAN except an Remote Switched Port Analyzer (RSPAN) VLAN or a
voice VLAN as an IEEE 802.1x guest VLAN. The guest VLAN feature is not supported on trunk ports;
it is supported only on access ports.
After you configure a guest VLAN for an IEEE 802.1x port to which a DHCP client is connected, you
might need to get a host IP address from a DHCP server. You can change the settings for restarting the
IEEE 802.1x authentication process on the switch before the DHCP process on the client times out and
tries to get a host IP address from the DHCP server. Decrease the settings for the IEEE 802.1x
authentication process (dot1x timeout quiet-period and dot1x timeout tx-period interface
configuration commands). The amount to decrease the settings depends on the connected IEEE 802.1x
client type.
The switch supports MAC authentication bypass. When it is enabled on an IEEE 802.1x port, the switch
can authorize clients based on the client MAC address when IEEE 802.1x authentication times out while
waiting for an EAPOL message exchange. After detecting a client on an IEEE 802.1x port, the switch
waits for an Ethernet packet from the client. The switch sends the authentication server a
RADIUS-access/request frame with a username and password based on the MAC address. If
authorization succeeds, the switch grants the client access to the network. If authorization fails, the
switch assigns the port to the guest VLAN if one is specified. For more information, see the “Using IEEE
802.1x Authentication with MAC Authentication Bypass” section in the “Configuring IEEE 802.1x
Port-Based Authentication” chapter of the software configuration guide.
Examples This example shows how to specify VLAN 5 as an IEEE 802.1x guest VLAN:
Switch(config-if)# dot1x guest-vlan 5
This example shows how to set 3 as the quiet time on the switch, to set 15 as the number of seconds that
the switch waits for a response to an EAP-request/identity frame from the client before resending the
request, and to enable VLAN 2 as an IEEE 802.1x guest VLAN when an IEEE 802.1x port is connected
to a DHCP client:
Switch(config-if)# dot1x timeout quiet-period 3
Switch(config-if)# dot1x timeout tx-period 15
Switch(config-if)# dot1x guest-vlan 2
This example shows how to enable the optional guest VLAN behavior and to specify VLAN 5 as an
IEEE 802.1x guest VLAN:
Switch(config)# dot1x guest-vlan supplicant
Switch(config)# interface gigabitethernet0/21
Switch(config-if)# dot1x guest-vlan 5
You can verify your settings by entering the show dot1x [interface interface-id] privileged EXEC
command.
Related Commands Command Description
dot1x Enables the optional guest VLAN supplicant feature.
show dot1x [interface interface-id] Displays IEEE 802.1x status for the specified port.
2-70
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
dot1x host-mode
dot1x host-mode
Use the dot1x host-mode interface configuration command to allow a single host (client) or multiple
hosts on an IEEE 802.1x-authorized port that has the dot1x port-control interface configuration
command set to auto. Use the no form of this command to return to the default setting.
dot1x host-mode {multi-host | single-host}
no dot1x host-mode [multi-host | single-host]
Syntax Description
Defaults The default is single-host mode.
Command Modes Interface configuration
Command History
Usage Guidelines Use this command to limit an IEEE 802.1x-enabled port to a single client or to attach multiple clients to
an IEEE 802.1x-enabled port. In multiple-hosts mode, only one of the attached hosts needs to be
successfully authorized for all hosts to be granted network access. If the port becomes unauthorized
(re-authentication fails or an Extensible Authentication Protocol over LAN [EAPOL]-logoff message is
received), all attached clients are denied access to the network.
Before entering this command, make sure that the dot1x port-control interface configuration command
is set to auto for the specified port.
Examples This example shows how to enable IEEE 802.1x authentication globally, to enable IEEE 802.1x
authentication on a port, and to enable multiple-hosts mode:
Switch(config)# dot1x system-auth-control
Switch(config)# interface gigabitethernet0/21
Switch(config-if)# dot1x port-control auto
Switch(config-if)# dot1x host-mode multi-host
You can verify your settings by entering the show dot1x [interface interface-id] privileged EXEC
command.
Related Commands
multi-host Enable multiple-hosts mode on the switch.
single-host Enable single-host mode on the switch.
Release Modification
12.2(25)SEF This command was introduced.
Command Description
show dot1x [interface interface-id] Displays IEEE 802.1x status for the specified port.
2-71
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
dot1x initialize
dot1x initialize
Use the dot1x initialize privileged EXEC command to manually return the specified
IEEE 802.1x-enabled port to an unauthorized state before initiating a new authentication session on the
port.
dot1x initialize [interface interface-id]
Syntax Description
Defaults There is no default setting.
Command Modes Privileged EXEC
Command History
Usage Guidelines Use this command to initialize the IEEE 802.1x state machines and to set up a fresh environment for
authentication. After you enter this command, the port status becomes unauthorized.
There is not a no form of this command.
Examples This example shows how to manually initialize a port:
Switch# dot1x initialize interface gigabitethernet0/22
You can verify the unauthorized port status by entering the show dot1x [interface interface-id]
privileged EXEC command.
Related Commands
interface interface-id (Optional) Port to be initialized.
Release Modification
12.2(25)SEF This command was introduced.
Command Description
show dot1x [interface interface-id] Displays IEEE 802.1x status for the specified port.
2-72
Cisco Catalyst Blade Switch 3020 for HP Command Reference
OL-8916-01
Chapter 2 Cisco Catalyst Blade Switch 3020 for HP Cisco IOS Commands
dot1x mac-auth-bypass
dot1x mac-auth-bypass
Use the dot1x mac-auth-bypass interface configuration command to enable the MAC authentication
bypass feature. Use the no form of this command to disable MAC authentication bypass feature.
dot1x mac-auth-bypass [eap]
no dot1x mac-auth-bypass
Syntax Description
Defaults MAC authentication bypass is disabled.
Command Modes Interface configuration
Command History
Usage Guidelines Unless otherwise stated, the MAC authentication bypass usage guidelines are the same as the
IEEE 802.1x authentication guidelines.
If you disable MAC authentication bypass from a port after the port has been authenticated with its MAC
address, the port state is not affected.
If the port is in the unauthorized state and the client MAC address is not the authentication-server
database, the port remains in the unauthorized state. However, if the client MAC address is added to the
database, the switch can use MAC authentication bypass to re-authorize the port.
If the port is in the authorized state, the port remains in this state until re-authorization occurs.
If an EAPOL packet is detected on the interface during the lifetime of the link, the switch determines
that the device connected to that interface is an IEEE 802.1x-capable supplicant and uses IEEE 802.1x
authentication (not MAC authentication bypass) to authorize the interface.
Clients that were authorized with MAC authentication bypass can be re-authenticated.
For more information about how MAC authentication bypass and IEEE 802.lx authentication interact,
see the “Understanding IEEE 802.1x Authentication with MAC Authentication Bypass” section and the
“IEEE 802.1x Authentication Configuration Guidelines” section in the “Configuring IEEE 802.1x
Port-Based Authentication” chapter of the software configuration guide.
eap (Optional) Configure the switch to use Extensible Authentication Protocol
(EAP) for authentication.
Release Modification
12.2(25)SEE This command was introduced.
12.2(25)SEF This command was introduced.
