Cisco 1801, Cisco 1802, and Cisco 1803 Integrated Services Routers Cabling and Installation

INCLUDING LICENSE AND WARRANTY

1 Cisco One-Year Limited Hardware Warranty Terms

2 Overview

3 Unpacking the Box

4 Connecting the Router

5 Connecting Antennas to the Router RP-TNC Connectors

6 Configuring the Router Using Cisco Router and Security Device Manager

7 Connecting a PC to the Router Console Port

8 Verifying Your Installation

9 Obtaining Documentation

10 Cisco Product Security Overview

11 Obtaining Technical Assistance

12 Obtaining Additional Publications and Information

Note: For localized versions of these instructions, please see the following URL:

http://www.cisco.com/univercd/cc/td/doc/product/access/acs_mod/1800fix/qsgs/index.htm

1 Cisco One-Year Limited Hardware Warranty Terms

There are special terms applicable to your hardware warranty and various services that you can use during the warranty period. Your formal Warranty Statement, including the warranty applicable to Cisco software, is included on the CD that accompanies your Cisco product. Follow these steps to access and download the Cisco Information Packet and your warranty document from the CD or from Cisco.com.

1. Launch your browser, and go to this URL:

http://www.cisco.com/univercd/cc/td/doc/es_inpck/cetrans.htm

The Warranties and License Agreements page appears.

2. To re a d t h e Cisco Information Packet, follow these steps:

a. Click the Information Packet Number field, and make sure that the part number 78-5235-02F0 is highlighted.

b. Select the language in which you would like to read the document.

c. Click Go.

The Cisco Limited Warranty and Software License page from the Information Packet appears.

d. Read the document online, or click the PDF icon to download and print the document in Adobe Portable Document

Format (PDF).

Note You must have Adobe Acrobat Reader to view and print PDF files. You can download the reader from Adobe’s

website: http://www.adobe.com

3. To read translated and localized warranty information about your product, follow these steps:

a. Enter this part number in the Warranty Document Number field:

78-10747-01C0

b. Select the language in which you would like to view the document.

c. Click Go.

The Cisco warranty page appears.

d. Read the document online, or click the PDF icon to download and print the document in Adobe Portable Document

Format (PDF).

You can also contact the Cisco service and support website for assistance:

http://www.cisco.com/public/Support_root.shtml.

Duration of Hardware Warranty

One (1) Year

Replacement, Repair, or Refund Policy for Hardware

Cisco or its service center will use commercially reasonable efforts to ship a replacement part within ten (10) working days after receipt of a Return Materials Authorization (RMA) request. Actual delivery times can vary, depending on the customer location.

Cisco reserves the right to refund the purchase price as its exclusive warranty remedy.

To Receive a Return Materials Authorization (RMA) Number

Contact the company from whom you purchased the product. If you purchased the product directly from Cisco, contact your Cisco Sales and Service Representative.

Complete the information below, and keep it for reference.

Company product purchased from

Company telephone number

Product model number

Product serial number

Maintenance contract number

2 Overview

This document describes the steps for installing the Cisco 1801, Cisco 1802, and Cisco 1803 integrated services routers. The Cisco 1801, Cisco 1802, and Cisco 1803 routers are fixed-configuration routers. They each include an integrated 8-port 10/100-Mbps Ethernet switch, one onboard Fast Ethernet WAN port, and optional 802.11a/b/g wireless LAN support. The switch ports and the onboard 10/100-Mbps Ethernet ports support 802.1Q virtual LAN (VLAN) encapsulation and enable you to configure demilitarized zones (DMZs), using VLANs and Cisco IOS firewall features. The switch ports are also optionally upgradable to include inline power support for IP phones.

For WAN connectivity, the Cisco 1801 router has an ADSL over POTS port, the Cisco 1802 router has an ADSL over ISDN port, and the Cisco 1803 has a 4-wire G.SHDSL port. The Cisco 1801, Cisco 1802, and Cisco 1803 routers provide secure Internet connectivity and dial backup through an ISDN S/T port if your primary connection fails.

Additional information on these routers can be found on Cisco.com.

Product Serial Number Location

The serial number label for Cisco 1801, Cisco 1802, and Cisco 1803 routers is located on the rear of the chassis, to the right of the power switch. You need this serial number when calling Cisco for technical support. To see specifically where the serial label is on your router, go to the following link:

http://tools.cisco.com/Support/CPI/index.do

3 Unpacking the Box

When you unpack the box containing your Cisco 1801, Cisco 1802, or Cisco 1803 router, you should find the items shown in Figure 1.

Note The Cisco 1801, Cisco 1802, and Cisco 1803 routers have a wireless upgradable option. If this option is chosen, an

antenna kit should have been shipped with your router in addition to the items listed in Figure 1.

Figure 1 Items Included with the Cisco 1801, Cisco 1802, and Cisco 1803 Integrated Services Router

Quick Start Guide

CD-ROM

Documentation

Other

127941

1 Cisco 1801, Cisco 1802, or Cisco 1803 router 4 PoE power supply and cable (optional)

2 Power cable 5 DB-9 to DB-25 adapter

3 Console cable (light blue, RJ-45 to DB-9) 6 Product documentation

The shipment should include the following items:

• One Cisco 1801, Cisco 1802, or Cisco 1803 router

• One blue RJ-45-to-DB-9 console cable

• One DB-9-to-DB-25 adapter

• One black power supply cord

• One Power over Ethernet (PoE) power supply, if the router was purchased with the PoE option

• Product documentation

• One CD-ROM containing Cisco Router and Security Device Manager (SDM)

• One antenna kit (optional)

Items You Need to Provide

Depending on your network environment, you may need to provide some of the following items so that you can install the router:

• An ADSL or G.SHDSL cable to connect the router to the service provider

• Straight-through Ethernet cables (RJ-45-to-RJ-45) to connect the router to an Ethernet hub or switch, or to a computer with

a network interface card (NIC)

• Server or other computer with a NIC or other networked device (such as a hub or a switch) to connect to the integrated 8-port 10/100-Mbps Ethernet switch

4 Connecting the Router

Figure 2 shows a typical installation of the Cisco 1801, Cisco 1802, or Cisco 1803 router.

Figure 2 Typical Installation of a Cisco 1801, Cisco 1802, or Cisco 1803 Router

Internet Service

Provider

Ethernet Hub

Follow these steps to connect the router to the power supply, your local network, and your service provider network:

Step 1 Connect power to the router as shown in Figure 2:

a. Connect the separate power cord to the power socket on the back panel of the router.

b. Connect the other end of the separate power cord to a power outlet.

Note If you have a router with the PoE option, you must connect the PoE power supply to the PoE socket on the

back of the router, connect the female end of the PoE power cable to the PoE power supply, and connect the male end of the PoE power cable to a power outlet.

c. Turn on the router by pressing the power switch to the on ( | ) position.

d. Confirm that the router has power by checking that the SYS OK LED on the front panel is on.

Step 2 To connect the router to your network, connect one end of an Ethernet cable (RJ-45) to an Ethernet switch port

(FE 1–FE 8), and connect the other end of the cable to a port on a hub or switch, as shown in Figure 2.

Note The example in Figure 2 shows connectivity to a hub. The router Ethernet switch ports can be connected to

another networked device, such as a switch or computer with a network interface card (NIC). If you are connecting the switch port on the router to another switch, use a crossover cable. If you are connecting a computer to the switch port on the router, it will take about 30 seconds for connectivity to be established.

Power Supply

121547

Step 3 To connect the router to an xDSL line, connect either an ADSL cable to the ADSL port or a G.SHDSL cable to the

G.SHDSL port, and connect the other end of the cable to your xDSL line as shown in Figure 2.

See the “Connecting DSL WAN Interface Cards to a Network” chapter in the Cisco Interface Cards Hardware

Installation Guide for more information about cabling the xDSL port. This document is located at this URL:

http://www.cisco.com/univercd/cc/td/doc/product/access/acs_mod/cis2600/hw_inst/wic_inst/wic_doc/wandsl.htm

Step 4 To use Cisco Router and Security Device Manager (SDM) to configure your router, you must connect a PC to the first

Ethernet switch port. Connect one end of an Ethernet cable to one of the Ethernet switch ports (FE 1–FE 8), and connect the other end to the Ethernet port on your PC.

Caution Always connect the Ethernet cable to an Ethernet port on the router. Accidentally connecting the cable to the wrong

port can damage your router.

Step 5 (Optional) The Cisco 1801, Cisco 1802, and Cisco 1803 routers support a 144-kbps dialup connection to your service

provider network through their ISDN S/T port. These connections can serve as a backup to your service provider if your primary connection goes down. To make a backup connection to your service provider network, connect one end of a straight-through RJ-11 cable to the ISDN S/T port on the router, as shown in Figure 2, and connect the other end of the cable to your telephone wall jack.

Note To configure your router for a backup dialup connection, you must use the Cisco IOS command-line

interface (CLI). For more information, see the Cisco 1800 Series Integrated Services Routers (Fixed) Software Configuration Guide.

5 Connecting Antennas to the Router RP-TNC Connectors

If your router has the wireless LAN option, connect the antennas by screwing the antenna connectors in a clockwise direction onto the reverse-polarity threaded Neill-Concelman (RP-TNC) connectors on the back panel of the router. Figure 3 shows an example of how to connect the swivel-mount dipole antennas to the router.

Note The location and position of your router’s antennas are crucial to effective wireless connectivity. For more information

about the antennas compatible with the Cisco 1801, Cisco 1802, and Cisco 1803 routers, see the online documents located at the following URL:

http://www.cisco.com/univercd/cc/td/doc/product/access/acs_mod/1800fix/antennas/index.htm

Figure 3 Connecting Antennas to the Router

121942

For information about configuring the wireless LAN functionality of your router, see the Cisco Access Router Wireless Configuration Guide at the following URL:

http://www.cisco.com/univercd/cc/td/doc/product/access/acs_mod/1800fix/awg/index.htm
