Cisco Systems 1760 User Manual

Quick Start Guide
Cisco 1760 Modular Access Router Cabling and Installation
INCLUDING LICENSE AND WARRANTY
1 Cisco One-Year Limited Hardware Warranty Terms
2 Overview
3 Parts List
4 Mounting the Router in a Rack
6 Connecting the Router to Your Local Network
7 Connect Power and Verify Installation
8 Connect a PC to the Router Console Port
9 Perform Initial Configuration
10 Use the CLI to Configure VoIP
11 Obtaining Documentation
12 Documentation Feedback
13 Cisco Product Security Overview
14 Obtaining Technical Assistance
15 Obtaining Additional Publications and Information

1 Cisco One-Year Limited Hardware Warranty Terms

There are special terms applicable to your hardware warranty and various services that you can use during the warranty period. Your formal Warranty Statement, including the warranties and license agreements applicable to Cisco software, is available on Cisco.com. Follow these steps to access and download the Cisco Information Packet and your warranty and license agreements from Cisco.com.
1. Launch your browser, and go to this URL:
http://www.cisco.com/univercd/cc/td/doc/es_inpck/cetrans.htm
The Warranties and License Agreements page appears.
2. To read the Cisco Information Packet, follow these steps:
a. Click the Information Packet Number field, and make sure that the part number 78-5235-03A0 is highlighted.
b. Select the language in which you would like to read the document.
c. Click Go.
The Cisco Limited Warranty and Software License page from the Information Packet appears.
d. Read the document online, or click the PDF icon to download and print the document in Adobe Portable Document
Format (PDF).
Note You must have Adobe Acrobat Reader to view and print PDF files. You can download the reader from Adobe’s
website: http://www.adobe.com
3. To read translated and localized warranty information about your product, follow these steps:
a. Enter this part number in the Warranty Document Number field:
78-10747-01C0
b. Select the language in which you would like to view the document.
c. Click Go.
The Cisco warranty page appears.
d. Read the document online, or click the PDF icon to download and print the document in Adobe Portable Document
Format (PDF).
You can also contact the Cisco service and support website for assistance:
http://www.cisco.com/public/Support_root.shtml.
Duration of Hardware Warranty
One (1) Year
Replacement, Repair, or Refund Policy for Hardware
Cisco or its service center will use commercially reasonable efforts to ship a replacement part within ten (10) working days after receipt of a Return Materials Authorization (RMA) request. Actual delivery times can vary, depending on the customer location.
Cisco reserves the right to refund the purchase price as its exclusive warranty remedy.
To Receive a Return Materials Authorization (RMA) Number
Contact the company from whom you purchased the product. If you purchased the product directly from Cisco, contact your Cisco Sales and Service Representative.
2
Complete the information below, and keep it for reference.
Company product purchased from
Company telephone number
Product model number
Product serial number
Maintenance contract number

2 Overview

This document describes the hardware installation and software configuration steps necessary to install your Cisco 1760 modular access router with its complement of WAN interface cards (WICs) and voice interface cards (VICs). Additional documentation can be found on Cisco.com.
Product Serial Number Location
The serial number label for Cisco 1760 router is located on the rear of the chassis, in the lower right-hand corner.

3 Parts List

Your router package should include the following items:
One Cisco 1760 modular access router
One blue RJ-45-to-DB-9 console cable
One DB-25-to-DB-9 adapter
One black power supply cord
Cable guide
Rack-mounting brackets
Product documentation

4 Mounting the Router in a Rack

Warning
This unit should be mounted at the bottom of the rack if it is the only unit in the rack.
When mounting this unit in a partially filled rack, load the rack from the bottom to the top with the heaviest component
at the bottom of the rack.
If the rack is provided with stabilizing devices, install the stabilizers before mounting or servicing the unit in the rack.
The rack-mounting brackets supplied with the router can be attached to a 19- or 24-inch rack. Figure 1 shows the bracket mounting points that attach to the rack.
To prevent bodily injury when mounting or servicing this unit in a rack, you must take special precautions to ensure that the system remains stable. The following guidelines are provided to ensure your safety.
3
Figure 1 Bracket Mounting Points
19" rack
mount point
19" rack
mount point
24" rack
mount point
38398
24" rack
mount point
To install the router in a 19-inch or a 24-inch standard rack, follow the instructions described in these procedures:
Attaching Brackets to the Router
Attaching Brackets to the Rack
Attaching the Optional Cable Guide

Attaching Brackets to the Router

The bracket orientation and the screws you use depend on whether you are attaching the brackets for a 19-inch or a 24-inch rack. Use two of the supplied screws to attach each bracket, according to the following guidelines:
For a 19-inch rack, use the supplied number-8 Phillips flat-head screws to attach the long side of the bracket to the router.
For a 24-inch rack, use the supplied number-8 Phillips truss-head screws to attach the short side of the bracket to the router.
Figure 2 shows how to attach brackets to the two sides of the router with the front panel forward.
Figure 2 Attaching Brackets for 19- and 24-Inch Racks
PW
R
OK
PVDM
0
PVDM 1
O
K
OK
19" Configuration
Phillips
flat-head
screws
M
OD
OK
SLOT 0
0
1
OK
SLOT 1
0
1
OK
60942
4
PW
R
O
K
PVDM
0
PVDM
1
MO
O
D
K
OK
O
SLO
K
T 0
0
1
OK
SLOT 1
0
1
O
24" Configuration
K
60943
Phillips
truss-head
screws

Attaching Brackets to the Rack

After the brackets are attached to the router, use the four supplied number-12 Phillips machine screws to securely attach the brackets to the rack, as shown in Figure 3.
Caution Make sure that the fans on the side of the chassis are not blocked.
Figure 3 Attaching Brackets to the Rack
C
ON
PWR
OK
PVDM 0
PVDM 1
MOD
OK
OK
SLOT 0
OK
0
1
OK
SLOT 1
0
1
OK
ACT
COL
SOLE
FDX
100
10/100 ETHERNET
LINK
A UX
SLOT 2
0
1
OK
SLOT 3
OK
Cisco 1700
Series
0
1
60941
Phillips machine screws

Attaching the Optional Cable Guide

Cisco recommends attaching the cable guide to prevent the cables from obscuring the front panel of the router and the other devices installed in the rack. If the router is in a 19-inch or 24-inch rack, use the supplied black screw, as shown in Figure 4, to attach the cable guide to the left or right bracket.
5
Figure 4 Attaching the Cable Guide to the Router
C
O
NS
O
L
PW
R
O
K
P VD
M 0
P VD
M
1
M
OD
OK
O
K
SLO
O
K
T 0
0
1
OK
S LO
T 1
0
1
O
K
AC
T
C
OL
E
F DX
100
1 0/1
LINK
0 0 E
T H
E R
N
E T
A U
X
S LO
T 2
10
O
SLO
K
T 3
O
K
Cisco 1700
S
e
rie
s
0
1
65286
Cable guide screw

5 Installing WIC/VIC Cards

The router has four card slots that hold Cisco WICs and VICs. Either one or two WICs may be installed, with the remaining slots holding VICs, as desired. If no WICs are present in the slots, up to four VICs may be installed. Each WIC has one or two WAN ports, and each VIC has two or more voice ports. This section describes the procedure for installing a WIC or a VIC in the router.
Note For details on specific WICs and VICs, on how to connect a WIC to the WAN line or a VIC to the telephone and fax
line, and on how to configure the interface with Cisco IOS software, refer to the Cisco WAN Interface Cards Hardware Installation Guide that came with the cards.

Safety Information

This section lists safety warnings that you should be aware of before installing WICs or VICs in the router. To see translated versions of these warnings, refer to the Regulatory Compliance and Safety Information for the Cisco 1700 Routers document that came with the router.
Warning
Warning
Warning
Before working on a system that has an on/off switch, turn off the power and unplug the power cord.
Only trained and qualified personnel should be allowed to install or replace this equipment.
Before working on equipment that is connected to power lines, remove jewelry (including rings, necklaces, and watches). Metal objects will heat up when connected to power and ground and can cause serious burns or weld the metal object to the terminals.
Warning
Warning
6
Before opening the chassis, disconnect the telephone-network cables (from the card) to avoid contact with the telephone-network voltages.
Do not work on the system or connect or disconnect cables during periods of lightning activity.
Caution Do not connect a WAN, telephone or fax cable to the card until you have completed the installation procedure.

Card Installation

Follow these steps to insert a card in the router:
Step 1 Make sure the router is turned off and is disconnected from AC power.
Caution Power must be removed from the system prior to installing or removing WICs or VICs to avoid damaging them.
When WICs or VICs are pushed into or pulled out of a router that is powered up, there is a very good chance that they could be damaged electrically and will no longer function.
Step 2 Loosen the thumbscrews on the WIC or VIC slot cover, as shown in Figure 5.
Figure 5 Removing a WIC or VIC Slot Cover
C
O
N
S
O
L
PWR
OK
PVDM 0
PVDM 1
MOD
OK
OK
SLOT 0
OK
0
1
OK
SLOT 1
0
1
OK
ACT
COL
FDX
E
100
1 0
/1
LINK
0 0
E
T H
E
R
N
E
T
A
U
X
SLOT 2
0
1
OK
SLOT 3
0
OK
Cisco 1700
Series
1
60950
You should be able to loosen the screws using your fingers; however, if the screws are very tight, you may need to use a Phillips screwdriver.
Step 3 Remove the metal plate that covers the card slot.
Step 4 Hold the card by the edges on either side of the card front panel, and line up the card edges with the guides inside the
card slot, as shown in Figure 6.
Figure 6 Inserting a WIC or VIC in the Router
1 2
C
O
N
S
O L
PWR
OK
PVDM 0
PVDM 1
MOD
OK
OK
SLOT 0
OK
0
1
OK
SLOT 1
0
1
OK
ACT
COL
FDX
E
100
1
0
/1
LINK
0
0 E
T
H E
R
N
E
T
A
U
X
SLOT 2
0
1
OK
SLOT 3
0
OK
Cisco 1700
Series
1
60949
1
Interface Card
2
Guides
Step 5 Insert the card in the slot, and gently push it into the router until the front panel of the card is flush with the router.
7
Note Slots 2 and 3 accept VICs only. These slots have a small metal tab on the right side that interferes with a similar
tab on WICs, preventing the insertion of WICs by mistake.
Step 6 Tighten the screws that are on the card.

Voice Port Verification

When the router is connected to a PC and you are running the command-line interface, as described in the “Connect a PC to the Router Console Port” section, you can enter the show voice port command to identify the port numbers of voice interfaces installed in your router:
Router# show voice port slot-number/port-number
As an example of voice port numbering, if you install VICs in both slot 1 and slot 2 of the router, the ports in each of these slots would be numbered as follows:
Slot 1—1/0 and 1/1
Slot 2—2/0 and 2/1
Figure 7 shows the Cisco 1760 router front panel and slot numbering.
Figure 7 Cisco 1760 Router Front Panel
1 2 3
PWR OK PVDM 0OKPVDM 1OKMOD
16 15 13
1
2
3
4
5
6
7
8
WIC/VIC Slot 0
WIC/VIC Slot 1
Console Port
VIC Slot 2
VIC Slot 3
Slot 3 LEDs
Slot 2 LEDs
Auxiliary Port
OK
ACT COL FDX 100 LINKSLOT 0OK0 1 SLOT 1OK0 1 SLOT 2OK0 1 SLOT 3OK0 1
10
4 5
10/100 ETHERNET
CONSOLE
AUX
THESE SLOTS ACCEPT ONLY VOICE INTERFACE CARDS
9 814 12 11 7 6
9
10
11
12
13
14
15
16
Ethernet Port
Ethernet LEDs
Slot 1 LEDs
Slot 0 LEDs
MOD OK LED
PVDM 0/1 OK LEDs
Router OK LED
Power LED
Cisco 1700 Series
60906

6 Connecting the Router to Your Local Network

The router is connected to your local Ethernet network through the yellow 10/100 Ethernet port. You must provide the following items for this connection:
A straight-through, RJ-45-to-RJ-45 Ethernet cable
A 10/100-Mbps Ethernet hub or switch
8
Warning
The ports labeled 10/100-Mbps Ethernet port and Console port are safety extra-low voltage (SELV) circuits. SELV circuits should only be connected to other SELV circuits. Because BRI circuits are treated like telephone-network voltage, avoid connecting the SELV circuits to the telephone network voltage (TNV) circuits. (To see translated versions of this warning, refer to the Regulatory Compliance and Safety Information for Cisco 1700 Routers document that came with the router.)
Caution Always connect the Ethernet cable to the yellow ports on the router. Do not connect the cable to an ISDN S/T or
U port on a WIC or to an NT1 that is connected to a WIC. Accidentally connecting the cable to the wrong port can damage your router.
Follow these steps to connect the router to your local network:
Step 1 Connect one end of the Ethernet cable to the yellow Ethernet port (labeled 10/100-Mbps Ethernet port), as shown in
Figure 8.
Figure 8 Connecting the Router to the Local Network
CON
PWR
OK
PVDM 0
PVDM 1
MOD
OK
OK
SLOT 0
OK
0
1
OK
SLOT 1
0
1
OK
ACT
COL
SOLE
C
FDX
100
10/100 ETHERNET
LINK
AU
X
SLOT 2
10
OK
SLOT 3
OK
isco 1700
S
e
rie
s
0
1
1
2
1X
2X
ETHERNET
3X
SPEED
LED
100BaseTX
1
SOLID
2
3
4
10BaseT
BLINK
5
6
7
8
3
1
2
10/100 Ethernet port
Ethernet hub or switch
4X
5X
6X
7X
8X
MDI MDI-X
3
Straight-through Ethernet cable
60945
Step 2 Connect the other end of the Ethernet cable to a network port on the hub or switch.

7 Connect Power and Verify Installation

Read the following warnings before connecting the power to the router.
Warning
The power supply is designed to work with TN power systems.
9
Warning
This product relies on the building’s installation for short-circuit (overcurrent) protection. Ensure that a fuse or circuit breaker no larger than 120VAC, 15A U.S. (240VAC, 16A international) is used on the phase conductors (all current-carrying conductors).
Warning
This equipment needs to be grounded. Use a green-and-yellow 14 AWG ground wire to connect the host to earth ground during normal use.
Warning
Warning
When installing the unit, always make the ground connection first and disconnect it last.
Never defeat the ground conductor or operate the equipment in the absence of a suitably installed ground conductor. Contact the appropriate electrical inspection authority or an electrician if you are uncertain that suitable grounding is available.
Follow these steps to connect power to the router and to turn the router on:
Step 1 Connect the separate power cord to the power socket on the rear panel, as shown in Figure 9.
Figure 9 Connecting the Power Supply
100-240V~
1.5 MAX/1.5A MAX
50-60 Hz
Step 2 Connect the other end of the separate power cord to a power outlet.
Step 3 Turn the power switch to on ( | ).
Step 4 Verify that you have correctly installed the router by checking the following LEDs:
PWR—On when power is being supplied to the router.
LINK—On when the router is correctly connected to the local Ethernet LAN through the 10/100-Mbps Ethernet
port.
ETH ACT—Blinking when there is network traffic on the local Ethernet LAN.
SLOT OK—On when a WIC is correctly installed in the slot.
PVDM 0/1 OK—On when a packet voice data module (PVDM) is correctly installed in its slot and is recognized
by the system.
60948
10
MOD OK—On when the virtual private network (VPN) module is correctly installed in its slot and is recognized
by the system.

8 Connect a PC to the Router Console Port

Connect a PC to the router’s console port and establish a console session to view startup messages and verify voice card installation. Follow these steps to connect the router to a terminal or PC:
Step 1 Connect the light blue console cable to the blue console port on the router, as shown in Figure 10.
Figure 10 Connecting the Console Cable to the Router
CON
PWR
OK
PVDM 0
PVDM 1
MOD
OK
OK
SLOT 0
OK
0
1
OK
SLOT 1
0
1
OK
ACT
COL
SOLE
C
FDX
100
10/100 ETH
LINK
ERNET
AUX
SLOT 2
10
OK
SLOT 3
OK
isco 1700
S
eries
0
1
1
3
1
2
Blue console port
To PC or terminal
2
3
Light blue console cable
60946
Step 2 Use the console adapter to connect the other end of the cable to the terminal or PC. If your terminal or PC has a console
port that does not fit the adapter included with the router, you must provide the correct adapter for that port.
Step 3 Start HyperTerminal or a similar terminal emulation program on your PC. Select the appropriate PC COM port. Set
the configurations to 9600 baud, 8 data bits, 1 stop bit, no flow control, and no parity.
Startup messages begin to appear in your terminal emulation program window.
Caution Do not press any keys on the keyboard until the messages stop. Any keys pressed during this time are interpreted
as the first command typed when the messages stop, which might cause the router to power off and start over. It will take a few minutes for the messages to stop.
If you see the following messages, the router has booted with a configuration file and is ready for initial configuration using the Cisco Router and Security Device Manager (SDM):
yourname con0 is now available
Press RETURN to get started.
See the “Initial Configuration Using Cisco Router and Security Device Manager” section on page 12 to learn how to configure your router using SDM or to learn how to obtain SDM and install it on your router.
If you see the following messages, the router has booted and is ready for initial configuration using the setup command facility or the command-line interface (CLI):
11
--- System Configuration Dialog --­At any point you may enter a question mark '?' for help. Use ctrl-c to abort configuration dialog at any prompt. Default settings are in square brackets '[]'.
Would you like to enter the initial configuration dialog? [yes/no]:
To learn how to use the CLI to configure the router, see the “Initial Configuration Using Cisco CLI—Manual Configuration” section on page 12.

9 Perform Initial Configuration

You can configure your router by using one of the following tools:
Security Device Manager—If your router was purchased with a VPN bundle, Security Device Manager is installed on the router. See “Initial Configuration Using Cisco Router and Security Device Manager” to determine if SDM is installed on the router. For instructions on configuring your router by using SDM, refer to the Cisco Security Device Manager (SDM) Quick Start Guide that shipped with your router. Voice over IP configuration must be done using the CLI, but you can use SDM to configure LAN and WAN connections, firewalls, VPNs, routing and other features.
Command-line interface (CLI)—If you prefer to use the Cisco IOS CLI, see the “Initial Configuration Using Cisco CLI—Manual Configuration” section on page 12 for instructions on how to use the CLI.

Initial Configuration Using Cisco Router and Security Device Manager

If the following messages appear at the end of the startup sequence, Cisco Router and Security Device Manager (SDM) is installed on your router:
yourname con0 is now available
Press RETURN to get started.
For instructions on configuring your router by using SDM, refer to the Cisco Router and Security Device Manager (SDM) Quick Start Guide that shipped with your router.
Tip If the messages above do not appear, SDM and the Cisco Router and Security Device Manager (SDM) Quick Start
Guide were not shipped with your router. If you want to use SDM, you can download the latest version of SDM and
instructions for installing it on your router from the following location:
http://www.cisco.com/pcgi-bin/tablebuild.pl/sdm
To obtain the SDM quick start guide, SDM release notes, and other SDM documentation, go to www.cisco.com/go/sdm and click the Technical Documentation link.
Initial Configuration Using Cisco CLI—Manual Configuration
This section shows how to display a command-line interface (CLI) prompt for configuration using the CLI, and it directs you to documentation for the CLI configuration.
You can use the CLI if the following messages appear at the end of the startup sequence:
--- System Configuration Dialog ---
At any point you may enter a question mark '?' for help. Use ctrl-c to abort configuration dialog at any prompt. Default settings are in square brackets '[]'.
Would you like to enter the initial configuration dialog? [yes/no]:
12
Loading...
+ 28 hidden pages
