CS42428

114 dB, 192 kHz 8-Ch Codec with PLL

Features



Eight 24-bit D/A, two 24-bit A/D converters



114 dB DAC / 114 dB ADC dynamic range



-100 dB THD+N



System sampling rates up to 192 kHz



Integrated low-jitter PLL for increased system jitter tolerance



PLL clock or OMCK system clock selection



7 configurable general purpose outputs



ADC high pass filter for DC offset calibration



Expandable ADC channels and one-line mode support



Digital output volume control with soft ramp



Digital +/-15 dB input gain adjust for ADC



Differential analog architecture



Supports logic levels between 5 V and 1.8 V

Mute

DAC#1

DAC#2

DAC#3

DAC#4

DAC#5

DAC#6

DAC#7

DAC#8

REFGND

Internal Voltage

Dig ital Filte r

GPO1 GPO2 GPO3 GPO4 GPO5 GPO6 GPO7

MUTEC

AINL+ AINL-

AINR+ AINR-

AOUTA1+ AOUTA1-

AOUTB1+

AOUTB1-

AOUTA2+ AOUTA2-

AOUTB2+ AOUTB2-

AOUTA3+ AOUTA3-

AOUTB3+

AOUTB3-

AOUTA4+ AOUTA4-

AOUTB4+ AOUTB4-

VA AGND

GPO

ADC#1

ADC#2

Analog Filter

Reference

General Description

The CS42428 CODEC provides two analog-to-digital and eight digital-to-analog Delta-Sigma converters, as well as an integrated PLL, in a 64-pin LQFP package.

The CS42428 integrated PLL provides a low-jitter system clock. The internal stereo ADC is capable of independent channel gain control for single-ended or differential analog inputs. All eight channels of DAC provide digital volume control and differential analog outputs. The general purpose outputs may be driven high or low, or mapped to a variety of DAC mute controls or ADC overflow indicators.

The CS42428 is ideal for audio systems requiring wide dynamic range, negligible distortion and low noise, such as A/V receivers, DVD receivers, digital speaker and automotive audio systems.

ORDERING INFORMATION

CS42428-CQZ -10° to 70° C 64-pin LQFP CS42428-DQZ -40° to 85° C 64-pin LQFP CDB42428 Evaluation Board

FILT+

OMCK RMCK LPFLT

Gain & Clip

Digita l Filter

Volume Control

PLL

ADC Serial Audio

Port

Mult/Div

DAC Serial Audio Port

VLC

Control

Port

DGND

INT

RST

AD0/CS AD1/CDIN SDA/CDOUT SCL/CCLK

ADCIN1

ADCIN2 ADC_SDOUT

ADC_LRCK

Level Translator

Leve l Transla tor

ADC_SCLK

VLS

DAC_LRCK

DAC_SCLK

DAC_SDIN1

DAC_SDIN 2

DAC_SDIN 3

DAC_SDIN4

Advance Product Information

Cirrus Logic, Inc.

www.cirrus.com

This document contains information for a new product. Cirrus Logic reserves the right to modify this product without notice.

JUL ‘04

DS605A2

TABLE OF CONTENTS

1 PIN DESCRIPTIONS ................................................................................................................. 6

2 TYPICAL CONNECTION DIAGRAMS ..................................................................................... 8

3 APPLICATIONS ....................................................................................................................... 10

3.1 Overview .......................................................................................................................... 10

3.2 Analog Inputs ................................................................................................................... 10

3.2.1 Line Level Inputs ................................................................................................. 10

3.2.2 External Input Filter ............................................................................................. 11

3.2.3 High Pass Filter and DC Offset Calibration ......................................................... 11

3.3 Analog Outputs ................................................................................................................ 11

3.3.1 Line Level Outputs and Filtering .........................................................................11

3.3.2 Interpolation Filter ............................................................................................... 12

3.3.3 Digital Volume and Mute Control ........................................................................ 12

3.3.4 ATAPI Specification ............................................................................................13

3.4 Clock Generation ............................................................................................................. 14

3.4.1 PLL and Jitter Attenuation ................................................................................... 14

3.4.2 OMCK System Clock Mode ................................................................................ 15

3.4.3 Master Mode ....................................................................................................... 15

3.4.4 Slave Mode ......................................................................................................... 15

3.5 Digital Interfaces ..............................................................................................................16

3.5.1 Serial Audio Interface Signals .............................................................................16

3.5.2 Serial Audio Interface Formats ............................................................................18

3.5.3 ADCIN1/ADCIN2 Serial Data Format ..................................................................21

3.5.4 One Line Mode(OLM) Configurations ................................................................. 22

3.6 Control Port Description and Timing ................................................................................ 26

CS42428

Contacting Cirrus Logic Support

For all product questions and inquiries contact a Cirrus Logic Sales Representative. To find one nearest you go to www.cirrus.com/

IMPORTANT NOTICE

"Advance" product information describes products that are in development and subject to development changes. Cirrus Log ic, Inc. and its subsidiaries ("Cirrus") believe that the information contained in this document is accurate and reliable. However, the information is subject to change without notice and is provided "AS IS" without warranty of any kind (express or implied). Customers are advised to obtain the latest version of relevant information to verify, before placing orders, that information being relied on is current and complete. All produ cts are sold subject to the terms and conditions of sale supplied at the time of order acknowledgment, including those pertaining to warranty, patent infringement, and limitation of liability. No responsibility is assumed by Cirrus for the use of this information, including use of this information as the basis for manufacture or sale of any items, or for infringement of patents or other righ ts of third parties. This document is the pro perty of Cirrus and by furnishing this information, Cirrus grants no license, express or implied under any patents, mask work rights, copyrights, trademarks, trade secrets or other intellectual property rights. Cirrus owns the copyrights associated with the information contained herein and gives consent for copies to be made of the information only for use within your organization with respect to Cirrus integrated circuits or other parts of Cirrus. This consent does not extend to other copying such as copying for general distribution, advertising or promotional purposes, or for creating any work for resale.

An export permit needs to be obtained from the competent authorities of the Japanese Government if any of the products or technologies described in this material and controlled under the "Foreign Exchange and Foreign Trade Law" is to be exported or taken out of Japan. An export license and/or quota needs to be obtained from the competent authorities of the Chinese Government if any of the products or technologies described in this material is subject to the PRC Foreign Trade Law and is to be exported or taken out of the PRC.

CERTAIN APPLICATIONS USING SEMICONDUCTOR PRODUCTS MAY INVOLVE POTENTIAL RISKS OF DEATH, PERSONAL INJURY, OR SEVERE PROPERTY OR ENVIRONMENTAL DAMAGE ("CRITICAL APPLICATIONS"). CIRRUS PRODUCTS ARE NOT DESIGNED, AUTHORIZED OR WARRANTED FOR USE IN AIRCRAFT SYSTEMS, MILITARY APPLICATIONS, PRODUCTS SURGICALLY IMPLANTED INTO THE BODY, LIFE SUPPORT PRODUCTS OR OTHER CRITICAL APPLICATIONS (INCLUDING MEDICAL DEVICES, AIRCRAFT SYSTEMS OR COMPONENTS AND PERSONAL OR AUTOMOTIVE SAFETY OR SECURITY DEVICES). INCLUSION OF CIRRUS PRODUCTS IN SUCH APPLICATIONS IS UNDERSTOOD TO BE FULLY AT THE CUSTOMER'S RISK AND CIRRUS DISCLAIMS AND MAKES NO WARRANTY, EXPRESS, STATUTORY OR IMPLIED, INCLUDING THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR PARTICULAR PURPOSE, WITH REGARD TO ANY CIRRUS PRODUCT THAT IS USED IN SUCH A MANNER. IF THE CUSTOMER OR CUSTOMER'S CUSTOMER USES OR PERMITS THE USE OF CIRRUS PRODUCTS IN CRITICAL APPLICATIONS, CUSTOMER AGREES, BY SUCH USE, TO FULLY INDEMNIFY CIRRUS, ITS OFFICERS, DIRECTORS, EMPLOYEES, DISTRIBUTORS AND OTHER AGENTS FROM ANY AND ALL LIABILITY, INCLUDING ATTORNEYS' FEES AND COSTS, THAT MAY RESULT FROM OR ARISE IN CONNECTION WITH THESE USES.

Purchase of I2C components of Cirrus Logic, Inc., or one of its sublicensed Associated Companies conveys a license under the Phil lips I2C Patent Rights to use those components in a standard I

Cirrus Logic, Cirrus, and the Cirrus Logic logo designs are trademarks of Cirrus Logic, Inc. All other brand and product names in this document may be trademarks or service marks of their respective owners.

C system.

CS42428

3.6.1 SPI Mode ............................................................................................................ 26

3.6.2 I2C Mode ............................................................................................................ 27

3.7 Interrupts ......................................................................................................................... 28

3.8 Reset and Power-up ....................................................................................................... 29

3.9 Power Supply, Grounding, and PCB layout ..................................................................... 29

4 REGISTER QUICK REFERENCE ........................................................................................... 30

5 REGISTER DESCRIPTION ..................................................................................................... 32

5.1 Memory Address Pointer (MAP)....................................................................................... 32

5.2 Chip I.D. and Revision Register (address 01h) (Read Only) ............................................ 32

5.3 Power Control (address 02h)............................................................................................ 33

5.4 Functional Mode (address 03h) ........................................................................................ 33

5.5 Interface Formats (address 04h) ...................................................................................... 34

5.6 Misc Control (address 05h) .............................................................................................. 36

5.7 Clock Control (address 06h)............................................................................................. 37

5.8 OMCK/PLL_CLK Ratio (address 07h) (Read Only) ......................................................... 39

5.9 Clock Status (address 08h) (Read Only).......................................................................... 39

5.10 Volume Control (address 0Dh) ....................................................................................... 40

5.11 Channel Mute (address 0Eh).......................................................................................... 41

5.12 Volume Control (addresses 0Fh, 10h, 11h, 12h, 13h, 14h, 15h, 16h) ........................ 42

5.13 Channel Invert (address 17h) ......................................................................................... 42

5.14 Mixing Control Pair 1 (Channels A1 & B1)(address 18h) Mixing Control Pair 2 (Channels A2 & B2)(address 19h) Mixing Control Pair 3 (Channels A3 & B3)(address 1Ah)

Mixing Control Pair 4 (Channels A4 & B4)(address 1Bh) ............................................ 42

5.15 ADC Left Channel Gain (address 1Ch) .......................................................................... 45

5.16 ADC Right Channel Gain (address 1Dh)........................................................................ 45

5.17 Interrupt Control (address 1Eh) ...................................................................................... 45

5.18 Interrupt Status (address 20h) (Read Only) ................................................................... 46

5.19 Interrupt Mask (address 21h) ......................................................................................... 47

5.20 Interrupt Mode MSB (address 22h)

Interrupt Mode LSB (address 23h)................................................................................ 47

5.21 MuteC Pin Control (address 28h) ................................................................................... 47

5.22 General Purpose Pin Control (addresses 29h to 2Fh) ................................................... 48

6 CHARACTERISTICS AND SPECIFICATIONS ....................................................................... 50

SPECIFIED OPERATING CONDITIONS............................................................................... 50

ABSOLUTE MAXIMUM RATINGS ......................................................................................... 50

ANALOG INPUT CHARACTERISTICS.................................................................................. 51

A/D DIGITAL FILTER CHARACTERISTICS .......................................................................... 52

ANALOG OUTPUT CHARACTERISTICS.............................................................................. 55

D/A DIGITAL FILTER CHARACTERISTICS .......................................................................... 56

SWITCHING CHARACTERISTICS ........................................................................................ 61

SWITCHING CHARACTERISTICS - CONTROL PORT - I2C FORMAT ............................... 62

SWITCHING CHARACTERISTICS - CONTROL PORT - SPI FORMAT ............................... 63

DC ELECTRICAL CHARACTERISTICS ................................................................................ 64

DIGITAL INTERFACE CHARACTERISTICS ......................................................................... 64

7 PARAMETER DEFINITIONS ................................................................................................... 65

8 REFERENCES ......................................................................................................................... 66

9 PACKAGE DIMENSIONS .................................................................................................... 67

THERMAL CHARACTERISTICS ........................................................................................... 67

LIST OF FIGURES

Figure 1. Typical Connection Diagram............................................................................................8

Figure 2. Typical Connection Diagram using the PLL .....................................................................9

Figure 3. Full-Scale Analog Input .................................................................................................. 10

Figure 4. Full-Scale Output ........................................................................................................... 12

Figure 5. ATAPI Block Diagram (x = channel pair 1, 2, 3, 4)......................................................... 13

Figure 6. Clock Generation ........................................................................................................... 14

Figure 7. Right Justified Serial Audio Formats ..............................................................................18

Figure 8. I

Figure 9. Left Justified Serial Audio Formats ................................................................................ 19

Figure 10. One Line Mode #1 Serial Audio Format....................................................................... 20

Figure 11. One Line Mode #2 Serial Audio Format....................................................................... 20

Figure 12. ADCIN1/ADCIN2 Serial Audio Format.........................................................................21

Figure 13. OLM Configuration #1.................................................................................................. 22

Figure 14. OLM Configuration #2.................................................................................................. 23

Figure 15. OLM Configuration #3.................................................................................................. 24

Figure 16. OLM Configuration #4.................................................................................................. 25

Figure 17. Control Port Timing in SPI Mode.................................................................................. 26

Figure 18. Control Port Timing, I2C Slave Mode Write ................................................................. 27

Figure 19. Control Port Timing, I2C Slave Mode Read ................................................................. 27

Figure 20. Single Speed Mode Stopband Rejection ..................................................................... 53

Figure 21. Single Speed Mode Transition Band............................................................................ 53

Figure 22. Single Speed Mode Transition Band (Detail) ............................................................... 53

Figure 23. Single Speed Mode Passband Ripple.......................................................................... 53

Figure 24. Double Speed Mode Stopband Rejection .................................................................... 53

Figure 25. Double Speed Mode Transition Band .......................................................................... 53

Figure 26. Double Speed Mode Transition Band (Detail).............................................................. 54

Figure 27. Double Speed Mode Passband Ripple ........................................................................ 54

Figure 28. Quad Speed Mode Stopband Rejection....................................................................... 54

Figure 29. Quad Speed Mode Transition Band............................................................................. 54

Figure 30. Quad Speed Mode Transition Band (Detail) ................................................................ 54

Figure 31. Quad Speed Mode Passband Ripple........................................................................... 54

Figure 32. Single Speed (fast) Stopband Rejection ...................................................................... 57

Figure 33. Single Speed (fast) Transition Band ............................................................................ 57

Figure 34. Single Speed (fast) Transition Band (detail) ................................................................ 57

Figure 35. Single Speed (fast) Passband Ripple .......................................................................... 57

Figure 36. Single Speed (slow) Stopband Rejection..................................................................... 57

Figure 37. Single Speed (slow) Transition Band ........................................................................... 57

Figure 38. Single Speed (slow) Transition Band (detail) ............................................................... 58

Figure 39. Single Speed (slow) Passband Ripple......................................................................... 58

Figure 40. Double Speed (fast) Stopband Rejection..................................................................... 58

Figure 41. Double Speed (fast) Transition Band ........................................................................... 58

Figure 42. Double Speed (fast) Transition Band (detail) ............................................................... 58

Figure 43. Double Speed (fast) Passband Ripple......................................................................... 58

Figure 44. Double Speed (slow) Stopband Rejection ................................................................... 59

Figure 45. Double Speed (slow) Transition Band.......................................................................... 59

Figure 46. Double Speed (slow) Transition Band (detail).............................................................. 59

Figure 47. Double Speed (slow) Passband Ripple........................................................................ 59

Figure 48. Quad Speed (fast) Stopband Rejection ....................................................................... 59

Figure 49. Quad Speed (fast) Transition Band.............................................................................. 59

Figure 50. Quad Speed (fast) Transition Band (detail).................................................................. 60

Figure 51. Quad Speed (fast) Passband Ripple............................................................................ 60

S Serial Audio Formats................................................................................................ 19

CS42428

Figure 52. Quad Speed (slow) Stopband Rejection...................................................................... 60

Figure 53. Quad Speed (slow) Transition Band ............................................................................ 60

Figure 54. Quad Speed (slow) Transition Band (detail) ................................................................ 60

Figure 55. Quad Speed (slow) Passband Ripple.......................................................................... 60

Figure 56. Serial Audio Port Master Mode Timing ........................................................................ 61

Figure 57. Serial Audio Port Slave Mode Timing .......................................................................... 61

Figure 58. Control Port Timing - I2C Format................................................................................. 62

Figure 59. Control Port Timing - SPI Format................................................................................. 63

LIST OF TABLES

Table 1. PLL External Component Values .................................................................................... 15

Table 2. Common OMCK Clock Frequencies .............................................................................. 15

Table 3. Common PLL Output Clock Frequencies....................................................................... 16

Table 4. Slave Mode Clock Ratios ...............................................................................................16

Table 5. Serial Audio Port Channel Allocations ............................................................................ 17

Table 6. DAC De-Emphasis .......................................................................................................... 34

Table 7. Digital Interface Formats ................................................................................................. 35

Table 8. ADC One_Line Mode ......................................................................................................35

Table 9. DAC One_Line Mode ......................................................................................................35

Table 10. RMCK Divider Settings .................................................................................................37

Table 11. OMCK Frequency Settings ........................................................................................... 38

Table 12. Master Clock Source Select.......................................................................................... 38

Table 13. PLL Clock Frequency Detection.................................................................................... 39

Table 14. Example Digital Volume Settings.................................................................................. 42

Table 15. ATAPI Decode .............................................................................................................. 44

Table 16. Example ADC Input Gain Settings ................................................................................ 45

CS42428

1 PIN DESCRIPTIONS

CS42428

DGND

VLC

AD0/CS

INT

RST

AINR-

AINR+

AINL+

AINL-

DAC_SDIN1

DAC_SCLK

DAC_LRCK

SCL/CC LK

SDA/CDOUT

AD1/CDIN

Pin Name # Pin Description

DAC Serial Audio Data Input (

DAC_SDIN1 DAC_SDIN2 DAC_SDIN3 DAC_SDIN4

DAC_SCLK 2 DAC Serial Clock

DAC_LRCK 3 DAC Left Right Clock (

VD 451Digital Power (

1 64 63 62

the DAC serial audio data line.

Input

(Input/Output)

) - Positive power supply for the digital section.

DAC_SDIN2

64 63 6 2 6 1 60 59 58 57 56 5 5 54 53 52 51 50 49

ADCIN2

ADCIN1

OMCK

ADC_SDOUT

ADC_SCLK

ADC_LRCK

DAC_SDIN4

DAC_SDIN3

VLS

RMCK

DGND

CS42428

17 18 19 20 21 22 23 24 25 2 6 27 28 29 30 31 32

FILT+

REFGND

AOUTB4-

Input

- Serial clock for the DAC serial audio interface.

Input/Output

AOUTB4+

AGND

AOUTA4-

AOUTA4+

AOUTB3-

AOUTA3-

AOUTB3+

AOUTB2-

AOUTA3+

AOUTB2+

) - Input for two’s complement serial audio data.

) - Determines which channel, Left or Right, is currently active on

AOUTA2+

GPO1

GPO2

GPO3

GPO4

GPO5

GPO6

GPO7

AGND

LPFLT

MUTEC

AOUTA1-

AOUTA1+

AOUTB1+

AOUTB1-

AOUTA2-

Input

DGND 552Digital Ground (

VLC 6

Control Port Power (

) - Ground reference. Should be connected to digital ground.

Input

SCL/CCLK 7 Serial Control Port Clock (

resistor to the logic interface voltage in I

SDA/CDOUT 8 Serial Control Data (

Input/Output

resistor to the logic interface voltage, as shown in the Typical Connection Diagram. CDOUT is the output data line for the control port interface in SPI mode.

AD1/CDIN 9 Address Bit 1 (I

C)/Serial Control Data (SPI) (

the input data line for the control port interface in SPI mode.

AD0/CS

Address Bit 0 (I

C)/Control Port Chip Select (SPI)

is the chip select signal in SPI mode.

INT 11 Interrupt

(Output

) - The CS42428 will generate an interrupt condition as per the Interrupt Mask register.

See “Interrupts” on page 28 for more details.

) - Determines the required signal level for the control port.

Input

) - Serial clock for the serial control port. Requires an external pull-up

C mode as shown in the Typical Connection Diagram.

) - SDA is a data I/O line in I2C mode and requires an external pull-up

Input

) - AD1 is a chip address pin in I2C mode; CDIN is

(Input

) - AD0 is a chip address pin in I2C mode; CS

CS42428

RST 12 Reset (

AINRAINR+

AINL+ AINL-

VQ 17 Quiescent Voltage (

FILT+ 18 Positive Voltage Reference (

REFGND 19 Reference Ground (

AOUTA1 +,AOUTB1 +,AOUTA2 +,AOUTB2 +,AOUTA3 +,AOUTB3 +,AOUTA4 +,AOUTB4 +,-

VA 2441Analog Power (

AGND 2540Analog Ground (

MUTEC 38 Mute Control (

LPFLT 39 PLL Loop Filter (

GPO7 GPO6 GPO5 GPO4 GPO3 GPO2 GPO1

VLS 53 Serial Port Interface Power (

RMCK 55 Recovered Master Clock (

ADC_SDOUT

ADCIN1 ADCIN2

OMCK 59 External Reference Clock (

ADC_LRCK 60 ADC Left/Right Clock (

ADC_SCLK 61 ADC Serial Clock

1314Differential Right Channel Analog Input (

1516Differential Left Channel Analog Input (

36,37 35,34 32,33 31,30 28,29 27,26 22,23 21,20

42 43 44 45 46 47 48

56 ADC Serial Data Output (

5857External ADC Serial Input (

Input

) - The device enters a low power mode and all internal registers are reset to their default

settings when low.

modulators via the AINR+/- pins.

modulators via the AINL+/- pins.

Output

) - Filter connection for internal quiescent reference voltage.

Input

) - Ground reference for the internal sampling circuits.

Differential Analog Output ( Analog Characteristics specification table.

Input

) - Positive power supply for the analog section.

Input

) - Ground reference. Should be connected to analog ground.

Output

) - The Mute Control pin outputs high impedance following an initial power-on condition or whenever the PDN bit is set to a ‘1’, forcing the codec into power-down mode. The signal will remain in a high impedance state as long as the part is in power-down mode. The Mute Control pin goes to the selected “active” state during reset, muting, or if the master clock to left/right clock frequency ratio is incorrect. This pin is intended to be used as a control for external mute circuits to prevent the clicks and pops that can occur in any single supply system. The use of external mute circuits are not mandatory but may be desired for designs requiring the absolute minimum in extraneous clicks and pops.

Output

) - An RC network should be connected between this pin and ground.

General Purpose Output ( ADC overflow interrupt or Mute Control outputs according to the General Purpose Pin Control registers.

Output

(OMCK, pin 59) or the PLL which is locked to the incoming ADC_LRCK.

Output

of the internal and external ADCs.

converter inputs to provide a maximum of six channels on one serial data output line when the CS42428 is placed in One Line mode.

the register “OMCK Frequency (OMCK Freqx)” on page 38.

Input/Output

the ADC serial audio data line.

(Input/Output)

Input

) - Signals are presented differentially to the delta-sigma

Input

) - Signals are presented differentially to the delta-sigma

Output

) - Positive reference voltage for the internal sampling circuits.

Output

) - The full-scale differential analog output level is specified in the

) - These pins can be configured as general purpose output pins, an

Input

) - Determines the required signal level for the serial port interfaces.

) - Recovered master clock output from the External Clock Reference

) - Output for two’s complement serial audio PCM data from the output

Input

) - The CS42428 provides for up to two external stereo analog to digital

Input

) - External clock reference that must be within the ranges specified in

) - Determines which channel, Left or Right, is currently active on

- Serial clock for the ADC serial audio interface.

2 TYPICAL CONNECTION DIAGRAMS

CS42428

+3.3 V to +5 V

+2.5 V to +5 V

+1.8 V to +5 V

Note: Resistors are required for

C control port operation

10 µ F

CS5361

A/D Converter

CS5361

A/D Converter

Digital Audio

Processor

Micro-

Controller

See Note

0.1 µ F 0.01 µF

0.1 µ F

0.01 µF

0.1 µ F

OSC

2 kΩ

2 k Ω

0.1 µF

GPO1

GPO2

GPO3

GPO4

GPO5

GPO6

GPO7

VLS

OMCK

ADCIN1

ADCIN2

RMCK

CS42428

ADC_SDOUT

ADC_LRCK

ADC_SCLK

DAC_LRCK

DAC_ SCLK

DAC_SDIN1

DAC_SDIN2

DAC_SDIN3

DAC_SDIN4

INT

RST

SCL/CCLK

SDA/CDOUT

AD1/CDIN

AD0/CS

VLC

DGND

52 40

414

VAVD

AOUTA1+

AOUTA1-

AOUTB1+

AOUTB1-

AOUTA2+

AOUTA2-

AOUTB2+

AOUTB2-

AOUTA3+

AOUTA3-

AOUTB3+

AOUTB3-

AOUTA4+

AOUTA4-

AOUTB4+

AOUTB4-

MUTEC

AINL+

AINL-

AINR+

AINR-

FILT+

REFGND

LPFLT

AGNDAGND

0.01 µF

+VA

***

0.1 µF

RFILT**

CFILT**

0.1 µF

10 µF

0.1 µF

10 µF

Analog Conditioning

and Muting

Analog Conditioning

and Muting

Analog Conditioning

and Muting

Analog Conditioning

and Muting

Analog Conditioning

and Muting

Analog Conditioning

and Muting

Analog Conditioning

and Muting

Analog Conditioning

and Muting

Mute Drive

*** Pull up or down as required on startup

Analog 2700 pF*

Input

Buffer *

Analog 2700 pF*

Input

Buffer *

* See CDB42428 for a recommended filter.

0.1 µF

100 µF

** Refer to Table 1

for proper values

CRIP**

+5 V

Left Analog Input

Right Analog Input

4.7 µF

Connect DGND and AGND at single point near Codec

Figure 1. Typical Connection Diagram

CS42428

+1.8 V

to +5.0 V

+3.3 V to +5 V

27 MHz

0.1 µF 0.01 µF

10 µ F

0.1 µF

10 µ F

DVD

Processor

Ω

See

2 k

Note

Note: Resistors are required for

C control port operation

0.01 µF

0.1 µF

Ω

2 k

0.1 µF

GPO1

GPO2

GPO3

GPO4

GPO5

GPO6

GPO7

VLS

OMCK

ADCIN1

ADCIN2

CS42428

RMCK

ADC_SDOUT

ADC_L RCK

ADC_S CLK

DAC_L RCK

DAC_S CLK

DAC_S DIN1

DAC_S DIN2

DAC_S DIN3

DAC_S DIN4

INT

RST

SCL/ CCLK

SDA/ CDOUT

AD1/CDIN

AD0/CS

VLC

DGND

52 40

0.1 µF

+5 V

Left Analog I nput

Right Analog Input

4.7 µF

0.1 µF

0.01 µF

414

VAVD

AOUTA1+

AOUTA1-

AOUTB1+

AOUTB1-

AOUTA2+

AOUTA2-

AOUTB2+

AOUTB2-

AOUTA3+

AOUTA3-

AOUTB3+

AOUTB3-

AOUTA4+

AOUTA4-

AOUTB4+

AOUTB4-

MUTEC

AINL+

AINL -

AINR+

AI NR-

FILT+

REFGND

LPFL T

AGNDAGND

+VA

***

0.1 µF

CFI LT**

10 µF

0.1 µF

10 µF

Analog Conditioning

and Muting

Analog Conditioning

and Muting

Analog Conditioning

and Muting

Analog Conditioning

and Muting

Analog Conditioning

and Muting

Analog Conditioning

and Muting

Analog Conditioning

and Muting

Analog Conditioning

and Muting

Mute Dri ve

*** Pull up or down as required on start up

Analog

2700 pF*

Input

Buffer *

Analog 2700 pF*

Input

Buffer *

* See CDB42428 for a recommended filter.

100 µF

RFI LT**

** Refer to Table 1

for proper val ues

CRIP**

Connect DGND and AGND at single point near Codec

Figure 2. Typical Connection Diagram using the PLL

CS42428

3 APPLICATIONS

3.1 Overview

The CS42428 is a highly integrated mixed signal 24-bit audio codec comprised of 2 analog-to-digital converters (ADC), implemented using multi-bit delta-sigma techniques, and 8 digital-to-analog converters (DAC). Other functions integrated within the codec include independent digital volume controls for each DAC, digital de-emphasis filters for DAC, digital gain control for ADC channels, ADC high-pass filters, and an on-chip voltage reference. All serial data is transmitted through one configurable serial audio interface for the ADC with enhanced one line modes of operation allowing up to 6 channels of serial audio data on one data line. All functions are configured through a serial control port operable in SPI mode or in I2C mode. Figure 1 shows the recommended connections for the CS42428.

The CS42428 operates in one of three oversampling modes based on the input sample rate. Mode selection is determined by the FM bits in register “Functional Mode (address 03h)” on page 33. Single-Speed mode (SSM) supports input sample rates up to 50 kHz and uses a 128x oversampling ratio. Double-Speed mode (DSM) supports input sample rates up to 100 kHz and uses an oversampling ratio of 64x. Quad-Speed mode (QSM) supports input sample rates up to 192 kHz and uses an oversampling ratio of 32x.

Using the integrated PLL, a low jitter clock is recovered from the ADC LRCK input signal. The recovered clock or an externally supplied clock attached to the OMCK pin can be used as the System Clock.

3.2 Analog Inputs

3.2.1 Line Level Inputs

AINR+, AINR-, AINL+, and AINL- are the line level differential analog inputs. These pins are internally biased to the DC quiescent reference voltage, VQ, of approximately 2.7 V. The level of the signal can be adjusted for the left and right ADC independently through the ADC Left and Right Channel Gain Control Registers on page 45. The ADC output data is in 2’s complement binary format. For inputs above positive full scale or below negative full scale, the ADC will output 7FFFFFH or 800000H, respectively and cause the ADC Overflow bit in the register “Interrupt Status (address 20h) (Read Only)” on page 46 to be set to a ‘1’. The GPO pins may also be configured to indicate an overflow condition has occurred in the ADC. See “General Purpose Pin Control (addresses 29h to 2Fh)” on page 48 for proper configuration. Figure 3 shows the full-scale analog input levels.

4.1 V

2.7 V

1.3 V

4.1 V

2.7 V

1.3 V

AIN+

AIN-

Full-Scale Input Level= (AIN+) - (AIN-)= 5.6 Vpp

Figure 3. Full-Scale Analog Input

CS42428

3.2.2 External Input Filter

The analog modulator samples the input at 6.144 MHz (internal MCLK=12.288 MHz). The digital filter will reject signals within the stopband of the filter. However, there is no rejection for input signals which are (n × 6.144 MHz) the digital passband frequency, where n=0,1,2,... Refer to the CDB42418 for a recommended analog input buffer that will attenuate any noise energy at 6.144 MHz, in addition to providing the optimum source impedance for the modulators. The use of capacitors which have a large voltage coefficient (such as general purpose ceramics) must be avoided since these can degrade signal linearity.

3.2.3 High Pass Filter and DC Offset Calibration

The high pass filter continuously subtracts a measure of the DC offset from the output of the decimation filter. The high pass filter can be independently enabled and disabled. If the HPF_Freeze bit is set during normal operation, the current value of the DC offset for the corresponding channel is frozen and this DC offset will continue to be subtracted from the conversion result. This feature makes it possible to perform a system DC offset calibration by:

1) Running the CS42428 with the high pass filter enabled until the filter settles. See the Digital Filter Characteristics for filter settling time.

2) Disabling the high pass filter and freezing the stored DC offset.

The high pass filters are controlled using the HPF_FREEZE bit in the register “Misc Control (address 05h)” on page 36.

3.3 Analog Outputs

3.3.1 Line Level Outputs and Filtering

The CS42428 contains on-chip buffer amplifiers capable of producing line level differential outputs. These amplifiers are biased to a quiescent DC level of approximately VQ.

The delta-sigma conversion process produces high frequency noise beyond the audio passband, most of which is removed by the on-chip analog filters. The remaining out-of-band noise can be attenuated using an off-chip low pass filter. The recommended output filter configuration is shown in the CDB42418. This filter configuration accounts for the normally differing AC loads on the AOUT+ and AOUT- differential output pins. It also shows an AC coupling configuration which minimizes the number of required AC coupling capacitors.

CS42428

The CS42428 is a linear phase design and does not include phase or amplitude compensation for an external filter. Therefore, the DAC system phase and amplitude response will be dependent on the external analog circuitry. Figure 4 shows the full-scale analog output levels.

3.95 V

AOUT+

AOUT-

Full-Scale Output Level= (AIN+) - (AIN-)= 5 Vpp

Figure 4. Full-Scale Output

2.7 V

1.45 V

3.95 V

2.7 V

1.45 V

3.3.2 Interpolation Filter

To accommodate the increasingly complex requirements of digital audio systems, the CS42428 incorporates selectable interpolation filters for each mode of operation. A “fast” and a “slow” roll-off filter is available in each of Single, Double, and Quad Speed modes. These filters have been designed to accommodate a variety of musical tastes and styles. The FILT_SEL bit found in the register “Misc Control (address 05h)” on page 36 is used to select which filter is used. Filter response plots can be found in Figures 32 to 55.

3.3.3 Digital Volume and Mute Control

Each DAC’s output level is controlled via the Volume Control registers operating over the range of 0 to

-127 dB attenuation with 0.5 dB resolution. See “Volume Control (addresses 0Fh, 10h, 11h, 12h, 13h, 14h, 15h, 16h)” on page 42. Volume control changes are programmable to ramp in increments of 0.125 dB at the rate controlled by the SZC[1:0] bits in the Digital Volume Control register. See “Volume Control (address 0Dh)” on page 40.

Each output can be independently muted via mute control bits in the register “Channel Mute (address 0Eh)” on page 41. When enabled, each XX_MUTE bit attenuates the corresponding DAC to its maximum value (-127 dB). When the XX_MUTE bit is disabled, the corresponding DAC returns to the attenuation level set in the Volume Control register. The attenuation is ramped up and down at the rate specified by the SZC[1:0] bits.

The Mute Control pin, MUTEC, is typically connected to an external mute control circuit. The Mute Control pin is tri-stated during power up or in power down mode by setting the PDN bit in the register “Power Control (address 02h)” on page 33 to a ‘1’. Once out of power-down mode the pin can be controlled by the user via the control port, or automatically asserted high when zero data is present on all DAC inputs, or when serial port clock errors are present. To prevent large transients on the output, it is desirable to mute the DAC outputs before the Mute Control pin is asserted. Please see the MUTEC pin in the Pin Descriptions section for more information.

CS42428

Each of the GPO1-GPO7 can be programmed to provide a hardware MUTE signal to individual circuits. Each pin can be programmed as an output, with specific muting capabilities as defined by the function bits in the register “General Purpose Pin Control (addresses 29h to 2Fh)” on page 48.

3.3.4 ATAPI Specification

The CS42428 implements the channel mixing functions of the ATAPI CD-ROM specification. The ATAPI functions are applied per A-B pair. Refer to Table 15 on page 44 and Figure 5 for additional information.

DAC_SDINx

Left Channel

Audio Data

Right Channel

Audio Data

Figure 5. ATAPI Block Diagram (x = channel pair 1, 2, 3, 4)

A Channel

Volume

Control

MUTE

AOUTAx

ΣΣ

B Channel

Volume

Control

MUTE

AOUTBx

CS42428

3.4 Clock Generation

The clock generation for the CS42428 is shown in the figure below. The internal MCLK is derived from the output of the PLL or a master clock source attached to OMCK. The mux selection is controlled by the SW_CTRLx bits and can be configured to manual switch mode only, or automatically switch on loss of PLL lock to the other source input.

OMCK

ADC_LRCK

(slave mode)

PLL_LRCK

PLL (256Fs)

49.152 MHz

bit

8.192 -

Internal

MCLK

SW_CTRLx

(manual or auto

Auto D etect

Input Clock

1,1.5, 2, 4

switch)

bits

RMCK_DIVx

single speed

256

double

speed

128

quad

speed

single speed

double

speed

quad

speed

bits

DAC_FMx

ADC_FMx

bits

not O LM

128FS

OLM #1

256FS

OLM #2

bits

ADC_OLx

ADC_SP SELx

not O LM

128FS

OLM #1

256FS

OLM #2

DAC_OLx

ADC_OLx

RMCK

DAC_LRCK

bits

DAC_SCLK

ADC_LRCK

and

bits

ADC_SCLK

Figure 6. Clock Generation

3.4.1 PLL and Jitter Attenuation

The PLL can be configured to lock onto the incoming ADC_LRCK signal from the ADC Serial Port and generate the required internal master clock frequency. There are some applications where low jitter in the recovered clock, presented on the RMCK pin, is important. For this reason, the PLL has been designed to have good jitter attenuation characteristics. By setting the PLL_LRCK bit to a ‘1’ in the register “Clock Control (address 06h)” on page 37, the PLL will lock to the incoming ADC_LRCK and generate an output master clock (RMCK) of 256Fs. Table 3 below shows the output of the PLL with typical input Fs values for ADC_LRCK.

The PLL behavior is affected by the external filter component values. Figure 1 shows the required configuration of the external filter components. The set of component values required for 32 kHz to 192 kHz

CS42428

sample rate applications are shown in Table 1. The lock time is the worst case for an Fs transition from unlocked state to locking to 192 kHz.

Fs Range (kHz) RFILT (kΩ) CFILT (pF) CRIP (pF) Settling time

32 to 192 10 2700 680 11 ms

Table 1. PLL External Component Values

It is important to treat the LPFLT pin as a low level analog input. It is suggested that the ground end of the PLL filter be returned directly to the AGND pin independently of the digital ground plane.

3.4.2 OMCK System Clock Mode

A special clock switching mode is available that allows the clock that is input through the OMCK pin to be used as the internal master clock. This feature is controlled by the SW_CTRLx bits in register “Clock Control (address 06h)” on page 37. An advanced auto switching mode is also implemented to maintain master clock functionality. The clock auto switching mode allows the clock input through OMCK to be used as a clock in the system without any disruption when the PLL loses lock, for example, when the LRCK is removed from ADC_LRCK. This clock switching is done glitch free.

3.4.3 Master Mode

In master mode, the serial interface timings are derived from an external clock attached to OMCK or the output of the PLL with an input reference to the ADC_LRCK input from the ADC serial port. The DAC Serial Port and ADC Serial Port can both be masters only when OMCK is used as the clock source. When using the PLL output, the ADC Serial Port must be slave and the DAC Serial Port can operate in Master Mode. Master clock selection and operation is configured with the SW_CTRL1:0 and CLK_SEL bits in the Clock Control Register (See “Clock Control (address 06h)” on page 37).

The sample rate to OMCK ratios and OMCK frequency requirements for Master mode operation are shown in Table 2.

Sample

Rate

(kHz)

48 12.2880 18.4320 24.5760 -----96 - - - 12.2880 18.4320 24.5760 - - -

192 - - - - - - 12.2880 18.4320 24.5760

Single Speed

(4 to 50 kHz)

256x 384x 512x 128x 192x 256x 64x 96x 128x

Table 2. Common OMCK Clock Frequencies

OMCK (MHz)

Double Speed

(50 to 100 kHz)

Quad Speed

(100 to 192 kHz)

3.4.4 Slave Mode

In Slave mode, DAC_LRCK, DAC_SCLK and/or ADC_LRCK and ADC_SCLK operate as inputs. The Left/Right clock signal must be equal to the sample rate, Fs and must be synchronously derived from the supplied master clock, OMCK or must be synchronous to the supplied ADC_LRCK used as the input to

CS42428

the PLL. In this latter scenario the PLL output becomes the internal master clock. The supported PLL output frequencies are shown in Table 3 below.

Sample

Rate

(kHz)

32 8.1920 - -

44.1 11.2896 - 48 12.2880 - 64 - 16.3840 -

88.2 - 22.5792 96 - 24.5760 -

176.4 - - 45.1584 192 - - 49.1520

Single Speed

(4 to 50 kHz)

256x 256x 256x

Table 3. Common PLL Output Clock Frequencies

The serial bit clock, DAC_SCLK and/or ADC_SCLK, must be synchronous to the corresponding DAC_LRCK/ADC_LRCK and be equal to 128x, 64x, 48x or 32x Fs depending on the interface format selected and desired speed mode. One Line Mode #1 is supported in Slave Mode. One Line Mode #2 is not supported. Refer to Table 4 for required clock ratios.

Single Speed Double Speed Quad Speed One Line Mode #1

OMCK/LRCK Ratio 256x, 512x 128x, 256x 128x 256x

SCLK/LRCK Ratio 32x, 48x, 64x, 128x 32x, 64x 32x, 64x 128x

PLL Output (MHz)

Double Speed

(50 to 100 kHz)

Quad Speed

(100 to 192 kHz)

Table 4. Slave Mode Clock Ratios

3.5 Digital Interfaces

3.5.1 Serial Audio Interface Signals

The CS42428 interfaces to an external Digital Audio Processor via two independent serial ports, the DAC serial port, DAC_SP and the ADC serial port, ADC_SP. The digital output of the internal ADCs use the ADC_SDOUT pin and can be configured to use either the ADC or DAC serial port timings. These configuration bits and the selection of Single, Double or Quad Speed mode for DAC_SP and ADC_SP are found in register “Functional Mode (address 03h)” on page 33.

The serial interface clocks, ADC_SCLK for ADC_SP and DAC_SCLK for DAC_SP, are used for transmitting and receiving audio data. Either ADC_SCLK or DAC_SCLK can be generated by the CS42428 (master mode) or it can be input from an external source (slave mode). Master or Slave mode selection is made using bits DAC_SP M/S and ADC_SP M/S in register “Misc Control (address 05h)” on page 36.

The Left/Right clock (ADC_LRCK or DAC_LRCK) is used to indicate left and right data frames and the start of a new sample period. It may be an output of the CS42428 (master mode), or it may be generated by an external source (slave mode). As described in later sections, particular modes of operation do allow the sample rate, Fs, of the ADC_SP and the DAC_SP to be different, but must be multiples of each other.

The serial data interface format selection (left/right justified, I2S or one line mode) for the ADC serial port data out pin, ADC_SDOUT, and the DAC input pins, DAC_SDIN1:4, is configured using the appropriate

CS42428

bits in the register “Interface Formats (address 04h)” on page 34. The serial audio data is presented in 2's complement binary form with the MSB first in all formats.

DAC_SDIN1, DAC_SDIN2, DAC_SDIN3 and DAC_SDIN4 are the serial data input pins supplying the internal DAC. ADC_SDOUT, the ADC data output pin, carries data from the two internal 24-bit ADCs and, when configured for one-line mode, up to four additional ADC channels attached externally to the signals ADCIN1 and ADCIN2 (typically two CS5361 stereo ADCs). When operated in One Line Data Mode, 6 channels of DAC data are input on DAC_SDIN1, two additional DAC channels on DAC_SDIN4, and 6 channels of ADC data are output on ADC_SDOUT. Table 5 outlines the serial port channel allocations.

Serial Inputs / Outputs

DAC_SDIN1 left channel

right channel

one line mode

DAC_SDIN2 left channel

right channel

one line mode

DAC_SDIN3 left channel

right channel

one line mode

DAC_SDIN4 left channel

right channel

one line mode

ADC_SDOUT left channel

right channel

one line mode

ADCIN1 left channel

right channel

ADCIN2 left channel

right channel

DAC #1 DAC #2 DAC channels 1,2,3,4,5,6

DAC #3 DAC #4 not used

DAC #5 DAC #6 not used

DAC #7 DAC #8 DAC channels 7,8

ADC #1 ADC #2 ADC channels 1,2,3,4,5,6

External ADC #3 External ADC #4

External ADC #5 External ADC #6

Table 5. Serial Audio Port Channel Allocations

CS42428

3.5.2 Serial Audio Interface Formats

The DAC_SP and ADC_SP digital audio serial ports support 5 formats with varying bit depths from 16 to 24 as shown in Figure 7, Figure 8, Figure 9, Figure 10 and Figure 11. These formats are selected using the configuration bits in the registers, “Functional Mode (address 03h)” on page 33 and “Interface Formats (address 04h)” on page 34. For the diagrams below, single-speed mode is equivalent to Fs = 32, 44.1, 48kHz; double-speed mode is for Fs = 64, 88.2, 96 kHz; and quad-speed mode is for Fs = 176.4, 196 kHz.

DAC_LRC K ADC_LRCK

DAC_SCLK ADC_SCLK

DAC_SDINx

ADC_SDOUT

Left Channel

15 14 13 12 11 10

Right Justified Mode, Data Valid on Rising Edge of SCLK

Bits/Sample SCLK Rate(s) Notes

Master Slave

16 64 Fs 48, 64, 128 Fs single-speed mode

64 Fs 64 Fs double-speed mode

64 Fs 64 Fs quad-speed mode

24 64, 128, 256 Fs 64, 128 Fs single-speed mode

64 Fs 64 Fs double-speed mode

64 Fs 64 Fs quad-speed mode

Figure 7. Right Justified Serial Audio Formats

Right Channel

6543210987

15 14 13 12 11 10

6543210987

CS42428

DAC_LRCK ADC_LR CK

DAC_SCLK ADC_SCLK

DAC_SDINx

ADC_SDOUT

MSB MSBLSB LSB

-1 -2 -3 -4 -5

Left Channel

+3 +2 +1+5 +4

-1 -2 -3 -4

I2S Mode, Data Valid on Rising Edge of SCLK

Bits/Sample SCLK Rate(s) Notes

Master Slave

16 64 Fs 48, 64, 128 Fs single-speed mode

64 Fs 64 Fs double-speed mode

64 Fs 64 Fs quad-speed mode

18 to 24 64, 128, 256 Fs 48, 64, 128 Fs single-speed mode

64 Fs 64 Fs double-speed mode

64 Fs 64 Fs quad-speed mode

Figure 8. I2S Serial Audio Formats

DAC_LRCK ADC_LRCK

DAC_SCLK ADC_SCLK

Left Channel

Right Channel

+3 +2 +1+5 +4

Right Channel

DAC_SDINx

ADC_SDOUT

MSB LSB MSB LSB

-1 -2 -3 -4 -5

+3 +2 +1+5 +4

-1 -2 -3 -4

Left Justified Mode, Data Valid on Rising Edge of SCLK

Bits/Sample SCLK Rate(s) Notes

Master Slave

16 64 Fs 32, 48, 64, 128 Fs single-speed mode

64 Fs 32, 64 Fs double-speed mode

64 Fs 32, 64 Fs quad-speed mode

18 to 24 64, 128, 256 Fs 48, 64, 128 Fs single-speed mode

64 Fs 64 Fs double-speed mode

64 Fs 64 Fs quad-speed mode

Figure 9. Left Justified Serial Audio Formats

+3 +2 +1+5 +4

CS42428

DAC_LRCK ADC_LRCK

DAC_SCLK ADC_SCLK

DAC_SDIN1

DAC_SDIN4

ADC_SDOUT

LSBMSB

DAC1 DAC3 DAC5 DAC2 DAC4 DAC6

20 clks

DAC7 DAC8

20 clks

ADC1 ADC3 ADC5 ADC2 ADC4 ADC6

20 clks

64 clks 64 clks

Left Channel Right Channel

LSBMSB LSBMSB LS BMSB LSBMSB LSBMSB MSB

20 clks

20 clks 20 clks 20 clks 20 clks

20 clks

20 clks 20 clks 20 clks 20 clks

One Line Data Mode #1, Data Valid on Rising Edge of SCLK

Bits/Sample SCLK Rate(s) Notes

Master Slave

20 128 Fs 128 Fs single-speed mode

128 Fs 128Fs double-speed mode

Figure 10. One Line Mode #1 Serial Audio Format

DAC_LRCK ADC_LRCK

DAC_SCLK ADC_SCLK

DAC_SDIN1

DAC_SDIN4

ADC_SDOUT

LSBMSB

DAC1 DAC3 DAC5 DAC2 DAC4 DAC6

24 clks

DAC7 DAC8

24 clks

ADC1 ADC3 ADC5 ADC2 ADC4 ADC6

24 clks

128 clks

Left Channel Right Channel

LSBMSB LSBMSB LSBMSB LSBMSB LSBMSB MSB

24 clks

24 clks 24 clks 24 clks 24 clks

24 clks

24 clks 24 clks 24 clks 24 clks

One Line Data Mode #2, Data Valid on Rising Edge of SCLK

Bits/Sample SCLK Rate(s) Notes

Master Slave

24 256 Fs not supported single-speed mode

Figure 11. One Line Mode #2 Serial Audio Format

128 clks

CS42428

3.5.3 ADCIN1/ADCIN2 Serial Data Format

The two serial data lines which interface to the optional external ADCs, ADCIN1 and ADCIN2, support only left-justified, 24-bit samples at 64Fs or 128Fs. This interface is not affected by any of the serial port configuration register bit settings. These serial data lines are used when supporting One Line Mode of operation with external ADCs attached. If these signals are not being used, they should be tied together and wired to GND via a pull-down resistor.

DAC_LRCK ADC_LRCK

DAC_SCLK ADC_SCLK

ADCIN1/2

MSB LSB MSB LSB

-1 -2 -3 -4 -5

Left Justified Mode, Data Valid on Rising Edge of SCLK

Bits/Sample SCLK Rate(s) Notes

Left Channel

+3 +2 +1+5 +4

-1 -2 -3 -4

Right Channel

+3 +2 +1+5 +4

24 64, 128 Fs single-speed mode, Fs= 32, 44.1, 48 kHz

64 Fs double-speed mode, Fs= 64, 88.2, 96 kHz

not supported quad-speed mode, Fs= 176.4, 192 kHz

Figure 12. ADCIN1/ADCIN2 Serial Audio Format

For proper operation, the CS42428 must be configured to select which SCLK/LRCK is being used to clock the external ADCs. The EXT ADC SCLK bit in register “Misc Control (address 05h)” on page 36, must be set accordingly. Set this bit to ‘1’ if the external ADCs are wired using the DAC_SP clocks. If the ADCs are wired to use the ADC_SP clocks, set this bit to ‘0’.

CS42428

3.5.4 One Line Mode(OLM) Configurations

3.5.4.1 OLM Config #1

One Line Mode Configuration #1 can support up to 8 channels of DAC data, and 6 channels of ADC data. This is the only configuration which will support up to 24-bit samples at a sampling frequency of 48 kHz on all channels for both the DAC and ADC.

Functional Mode Register (addr = 03h)

Set DAC_FMx = ADC_FMx = 00,01,10

Set ADC_CLK_SEL = 0

Interface Format Register (addr = 04h)

Set DIFx bits to proper serial format

Set ADC_OLx bits = 00,01,10

Set DAC_OLx bits = 00,01,10

Misc. Control Register (addr = 05h)

Set DAC_SP M/S = 1

Set ADC_SP M/S = 1

Set EXT ADC SCLK = 0

DAC_LRCK must equal ADC_LRCK; sample rate conversion not supported

Configure ADC_SDOUT to be clocked from the DAC_SP clocks.

Select the digital interface format when not in one line mode

Select ADC operating mode, see table below for valid combinations

Select DAC operating mode, see table below for valid combinations

Configure DAC Serial Port to master mode.

Configure ADC Serial Port to master mode.

Identify external ADC clock source as ADC Serial Port.

ADC Mode

Not One Line Mode

One Line Mode #1

One Line Mode #2

DAC Mode

Not One Line Mode One Line Mode #1 One Line Mode #2

DAC_SCLK=64Fs DAC_LRCK=SSM/DSM/QSM

DAC_SCLK=128Fs DAC_LRCK=SSM/DSM

not valid ADC_SCLK=64Fs ADC_LRCK=DAC_LRCK

DAC_SCLK=128Fs DAC_LRCK=SSM/DSM ADC_SCLK=64Fs ADC_LRCK=DAC_LRCK

DAC_SCLK=256Fs DAC_LRCK=SSM ADC_SCLK=64Fs ADC_LRCK=DAC_LRCK

LRCK

SCLK

MCLK

SDOUT1

SDOUT2

CS5361

RMCK

ADCIN1

ADCIN2

CS42428

DAC_SCLK=128Fs DAC_LRCK=SSM/DSM ADC_SCLK=64Fs ADC_LRCK=DAC_LRCK

not valid

ADC_SCLK

ADC_LRCK

DAC_SCLK

DAC_LRC K

ADC_SDOUT

DAC_SDIN1 DAC_SDIN2

DAC_SDIN3

DAC_SDIN4

64Fs

64Fs,128Fs, 256Fs

ADC Data

not valid

DAC_SCLK=256Fs

DAC_LRCK=SSM

ADC_SCLK=64Fs

ADC_LRCK=DAC_LRCK

MCLK

SCLK_PORT1

LRCK_PORT1

SDIN_PORT1

SCLK_PORT2

LRCK_PORT2

SDOUT1_PORT2

SDOUT2_PORT2

SDOUT3_PORT2

SDOUT4_PORT2

DIGITAL A UDIO

PROCESSOR

Figure 13. OLM Configuration #1

CS42428

3.5.4.2 OLM Config #2

This configuration will support up to 8 channels of DAC data, 6 channels of ADC data and will handle up to 20-bit samples at a sampling frequency of 96 kHz on all channels for both the DAC and ADC. The output data stream of the internal and external ADCs is configured to use the ADC_SDOUT output and run at the DAC Serial Port sample frequency.

Functional Mode Register (addr = 03h)

Set DAC_FMx = 00,01,10

Set ADC_FMx = 00,01,10

Set ADC_CLK_SEL = 1

Interface Format Register (addr = 04h)

Set DIFx bits to proper serial format

Set ADC_OLx bits = 00,01,10

Set DAC_OLx bits = 00,01

Misc. Control Register (addr = 05h)

Set CODEC_SP M/S = 1

Set SAI_SP M/S = 1

Set EXT ADC SCLK = 1

DAC_LRCK can run at SSM, DSM or QSM independent of ADC_LRCK

ADC_LRCK can run at SSM, DSM or QSM independent of DAC_LRCK

Configure ADC_SDOUT to be clocked from the ADC_SP clocks.

Select the digital interface for mat when not in one line mode

Select ADC operating mode, see table below for valid combinations

Select DAC operating mode, see table below for valid combinations

Set CODEC Serial Port to master mode.

Set Serial Audio Interface Port to master mode.

Identify external ADC clock source as DAC Serial Port.

ADC Mode

Not One Line Mode

One Line Mode #1

One Line Mode #2

DAC Mode

Not One Line Mode One Line Mode #1 One Line Mode #2

DAC_SCLK=64Fs DAC_LRCK=SSM/DSM/QSM ADC_SCLK=64Fs ADC_LRCK=SSM/DSM/QSM

DAC_SCLK=64Fs DAC_LRCK=SSM/DSM ADC_SCLK=128Fs ADC_LRCK=CX_LRCK

DAC_SCLK=64Fs DAC_LRCK=SSM

DAC_SCLK=128Fs DAC_LRCK=SSM ADC_SCLK=64Fs ADC_LRCK=SSM/DSM/QSM

DAC_SCLK=128Fs DAC_LRCK=SSM ADC_SCLK=128Fs ADC_LRCK=CX_LRCK

not valid

ADC_SCLK=256Fs ADC_LRCK=CX_LRCK

MCLK

64Fs,128Fs,

256Fs

ADC Data

SCLK_PORT1

LRCK_PORT1

SDIN_PORT1

SCLK_PORT2

LRCK_PORT2

SDOUT1_PORT2

SDOUT2_PORT2

SDOUT3_PORT2

SDOUT4_PORT2

DIGITAL AUDIO

PROCESSOR

SDOUT1

SDOUT2

CS5361

LRCK

SCLK

MCLK

ADC_SCLK

RMCK

ADCIN1

ADCIN2

ADC_LRCK

ADC_SDOUT

DAC_SCLK

DAC_LRCK

DAC_SDIN1

DAC_SDIN2

DAC_SDIN3

DAC_SDIN4

CS42428

64Fs,128Fs

Figure 14. OLM Configuration #2

CS42428

3.5.4.3 OLM Config #3

This configuration will support up to 8 channels of DAC data, and 6 channels of ADC data. OLM Config #3 will handle up to 20-bit ADC samples at an Fs of 48 kHz and 24-bit DAC samples at an Fs of 48 kHz. Since the ADCs data stream is configured to use the ADC_SDOUT output and the internal and external ADCs are clocked from the ADC_SP, then the sample rate for the DAC Serial Port can be different from the sample rate of the ADC serial port.

Functional Mode Register (addr = 03h)

Set DAC_FMx = 00,01,10

Set ADC_FMx = 00,01,10

Set ADC_CLK_SEL = 1

Interface Format Register (addr = 04h)

Set DIFx bits to proper serial format

Set ADC_OLx bits = 00,01

Set DAC_OLx bits = 00,01,10

Misc. Control Register (addr = 05h)

Set DAC_SP M/S = 1

Set ADC_SP M/S = 0 or 1

Set EXT ADC SCLK = 0

DAC_LRCK can run at SSM, DSM, or QSM independent of ADC_LRCK

ADC_LRCK can run at SSM, DSM, or QSM independent of DAC_LRCK

Configure ADC_SDOUT to be clocked from the ADC_SP clocks.

Select the digital interface for mat when not in one line mode

Select ADC operating mode, see table below for valid combinations

Select DAC operating mode, see table below for valid combinations

Set DAC Serial Port to master mode.

Set ADC Serial Port to master mode or slave mode.

Identify external ADC clock source as ADC Serial Port.

ADC Mode

Not One Line Mode

One Line Mode #1

One Line Mode #2

DAC Mode

Not One Line Mode One Line Mode #1 One Line Mode #2

DAC_SCLK=64Fs DAC_LRCK=SSM/DSM/QSM ADC_SCLK=64Fs ADC_LRCK=SSM/DSM/QSM

DAC_SCLK=64Fs DAC_LRCK=SSM/DSM/QSM ADC_SCLK=128Fs ADC_LRCK=SSM

DAC_SCLK=128Fs DAC_LRCK=SSM/DSM ADC_SCLK=64Fs ADC_LRCK=SSM/DSM/QSM

DAC_SCLK=128Fs DAC_LRCK=SSM/DSM ADC_SCLK=128Fs ADC_LRCK=SSM

DAC_SCLK=256Fs DAC_LRCK=SSM ADC_SCLK=64Fs ADC_LRCK=SSM/DSM/QSM

DAC_SCLK=256Fs DAC_LRCK=SSM ADC_SCLK=128Fs ADC_LRCK=SSM

not valid not valid not valid

MCLK

64Fs,128Fs

SCLK_PORT1

LRCK_P ORT1

SDIN_PORT1

SCLK_PORT2

LRCK_P ORT2

SDOUT 1_PORT 2

SDOUT 2_PORT 2

SDOUT 3_PORT 2

SDOUT 4_PORT 2

DIGITAL AUDIO

PROCESSOR

SDOUT1

SDOUT2

CS53 61

CS5361

LRCK

SCLK

MCLK

ADC_SCLK

RMCK

ADCIN1

ADCIN2

ADC_LRCK

ADC_SDOUT

DAC_SCLK

DAC_LRCK

DAC_SDIN1

DAC_SDIN2

DAC_SDIN3

DAC_SDIN4

CS42428

64Fs,128Fs,256Fs

Figure 15. OLM Configuration #3

CS42428

3.5.4.4 OLM Config #4

This One-Line Mode configuration can support up to 8 channels of DAC data on 2 DAC_SDIN pins, and 2 channels of ADC data and will handle up to 24-bit samples at a sampling frequency of 48 kHz on all channels for both the DAC and ADC. The output data stream of the internal ADCs can be configured to run at the DAC_SP clock speeds or to run at the ADC_SP rate. The DAC_SP and ADC_SP can operate at different Fs rates.

Functional Mode Register (addr = 03h)

Set DAC_FMx = 00,01,10

Set ADC_FMx = 00,01,10

Set ADC_CLK_SEL = 0 or 1

Interface Format Register (addr = 04h)

Set DIFx bits to proper serial format

Set ADC_OLx bits = 00

Set DAC_OLx bits = 00,01,10

Misc. Control Register (addr = 05h)

Set DAC_SP M/S = 0 or 1

Set ADC_SP M/S = 0 or 1

Set EXT ADC SCLK = 0

DAC_LRCK can run at SSM, DSM, or QSM independent of ADC_LRCK

ADC_LRCK can run at SSM, DSM, or QSM independent of DAC_LRCK

Configure ADC_SDOUT to be clocked from the ADC_SP or DAC_SP

clocks.

Select the digital interface for mat when not in one line mode

Set ADC operating mode to Not One Line Mode since only 2 channels of

ADC are supported

Select DAC operating mode, see table below for valid combinations

Set DAC Serial Port to master mode or slave mode.

Set ADC Serial Port to master mode or slave mode.

External ADCs are not used. Leave bit in default state.

ADC Mode

Not One Line Mode

One Line Mode #1

One Line Mode #2

DAC Mode

Not One Line Mode One Line Mode #1 One Line Mode #2

DAC_SCLK=64Fs/128Fs DAC_LRCK=SSM/DSM/QSM ADC_SCLK=64Fs/128Fs ADC_LRCK=SSM/DSM/QSM

DAC_SCLK=128Fs DAC_LRCK=SSM/DSM ADC_SCLK=64Fs/128Fs ADC_LRCK=SSM/DSM/QSM

DAC_SCLK=256Fs DAC_LRCK=SSM ADC_SCLK=64Fs/128Fs ADC_LRCK=SSM/DSM/QSM

not valid not valid not valid

MCLK

ADC_SCLK

RMCK

ADCIN1

ADCIN2

ADC_LRCK

ADC_SDOUT

DAC_SCLK

DAC_LRCK

DAC_SDIN1

DAC_SDIN2

DAC_SDIN3

DAC_SDIN4

CS42428

64Fs,128Fs

64Fs,128Fs, 256Fs

SCLK_PORT1

LRCK_PORT1

SDIN_PO RT1

SDIN_PORT2

SCLK_PORT2

LRCK_PORT2

SDOUT1_PORT2

SDOUT2_PORT2

SDOUT3_PORT2

SDOUT4_PORT2

DIGITAL AUDIO

PROCESS OR

Figure 16. OLM Configuration #4

CS42428

3.6 Control Port Description and Timing

The control port is used to access the registers, allowing the CS42428 to be configured for the desired operational modes and formats. The operation of the control port may be completely asynchronous with respect to the audio sample rates. However, to avoid potential interference problems, the control port pins should remain static if no operation is required.

The control port has 2 modes: SPI and I2C, with the CS42428 acting as a slave device. SPI mode is selected if there is a high to low transition on the AD0/CS pin, after the RST pin has been brought high. I2C mode is selected by connecting the AD0/CS pin through a resistor to VLC or DGND, thereby permanently selecting the desired AD0 bit address state.

3.6.1 SPI Mode

In SPI mode, CS is the CS42428 chip select signal, CCLK is the control port bit clock (input into the CS42428 from the microcontroller), CDIN is the input data line from the microcontroller, CDOUT is the output data line to the microcontroller. Data is clocked in on the rising edge of CCLK and out on the falling edge.

Figure 17 shows the operation of the control port in SPI mode. To write to a register, bring CS low. The first seven bits on CDIN form the chip address and must be 1001111. The eighth bit is a read/write indicator (R/W), which should be low to write. The next eight bits form the Memory Address Pointer (MAP), which is set to the address of the register that is to be updated. The next eight bits are the data which will be placed into the register designated by the MAP. During writes, the CDOUT output stays in the Hi-Z state. It may be externally pulled high or low with a 47 kΩ resistor, if desired.

There is a MAP auto increment capability, enabled by the INCR bit in the MAP register. If INCR is a zero, the MAP will stay constant for successive read or writes. If INCR is set to a 1, the MAP will autoincrement after each byte is read or written, allowing block reads or writes of successive registers.

To read a register, the MAP has to be set to the correct address by executing a partial write cycle which finishes (CS high) immediately after the MAP byte. The MAP auto increment bit (INCR) may be set or

CCLK

CHIP

ADDRESS

1001111

R/W

MSB

LSB

MSB

LSB

CDIN

CDOUT

CHIP

ADDRESS

1001111

High Impedance

MAP = Memory Address Pointer, 8 bits, MSB first

R/W

MAP

Figure 17. Control Port Timing in SPI Mode

DATA

MSB

byte 1

LSB

byte n

CS42428

not, as desired. To begin a read, bring CS low, send out the chip address and set the read/write bit (R/W) high. The next falling edge of CCLK will clock out the MSB of the addressed register (CDOUT will leave the high impedance state). If the MAP auto increment bit is set to 1, the data for successive registers will appear consecutively.

3.6.2 I2C Mode

In I2C mode, SDA is a bidirectional data line. Data is clocked into and out of the part by the clock, SCL. There is no CS pin. Pins AD0 and AD1 form the two least significant bits of the chip address and should be connected through a resistor to VLC or DGND as desired. The state of the pins is sensed while the CS42428 is being reset.

The signal timings for a read and write cycle are shown in Figure 18 and Figure 19. A Start condition is defined as a falling transition of SDA while the clock is high. A Stop condition is a rising transition while the clock is high. All other transitions of SDA occur while the clock is low. The first byte sent to the CS42428 after a Start condition consists of a 7 bit chip address field and a R/W bit (high for a read, low for a write). The upper 5 bits of the 7-bit address field are fixed at 10011. To communicate with a CS42428, the chip address field, which is the first byte sent to the CS42428, should match 10011 followed by the settings of the AD1 and AD0. The eighth bit of the address is the R/W bit. If the operation is a write, the next byte is the Memory Address Pointer (MAP) which selects the register to be read or written. If the operation is a read, the contents of the register pointed to by the MAP will be output. Setting the auto increment bit in MAP allows successive reads or writes of consecutive registers. Each byte is separated by an acknowledge bit. The ACK bit is output from the CS42428 after each input byte is read, and is input to the CS42428 from the microcontroller after each transmitted byte.

SCL

SDA

0 1 2 3 8 9 12 16 17 18 1910 11 13 14 15 27 28

CHIP ADDRESS (WRITE) MAP BYTE DATA DATA +1

1 0 0 1 1 AD1 AD0 0

START

4 5 6 7 24 25

INCR 6 5 4 3 2 1 0 7 6 1 0 7 6 1 0 7 6 1 0

ACK

Figure 18. Control Port Timing, I2C Slave Mode Write

168 9 12 13 14 154 5 6 7 0 1 20 21 22 2 3 24 26 27 282 3 1 0 11 17 18 19 25

SCL

CHIP ADDRESS (WRITE)

SDA 1 0 0 1 1 AD1 AD0 1

1 0 0 1 1 AD1 AD0 0

ACK

START

MAP BYTE

INCR 6 5 4 3 2 1 0

STOP

ACK

CHIP ADDRESS (READ)

START

Figure 19. Control Port Timing, I2C Slave Mode Read

DATA +n

DATA

7 0 7 0 7 0

ACK

DATA +1

ACK

ACKACKACK

DATA + n

STOP

ACK

STOP

CS42428

Since the read operation can not set the MAP, an aborted write operation is used as a preamble. As shown in Figure 19, the write operation is aborted after the acknowledge for the MAP byte by sending a stop condition. The following pseudocode illustrates an aborted write operation followed by a read operation.

Send start condition.

Send 10011xx0 (chip address & write operation).

Receive acknowledge bit.

Send MAP byte, auto increment off.

Receive acknowledge bit.

Send stop condition, aborting write.

Send start condition.

Send 10011xx1(chip address & read operation).

Receive acknowledge bit.

Receive byte, contents of selected register.

Send acknowledge bit.

Send stop condition.

Setting the auto increment bit in the MAP allows successive reads or writes of consecutive registers. Each byte is separated by an acknowledge bit.

3.7 Interrupts

The CS42428 has a comprehensive interrupt capability. The INT output pin is intended to drive the interrupt input pin on the host microcontroller. The INT pin may be set to be active low, active high or active low with no active pull-up transistor. This last mode is used for active low, wired-OR hook-ups, with multiple peripherals connected to the microcontroller interrupt input pin.

Many conditions can cause an interrupt, as listed in the interrupt status register descriptions. See “Interrupt Status (address 20h) (Read Only)” on page 46. Each source may be masked off through mask register bits. In addition, each source may be set to rising edge, falling edge, or level sensitive. Combined with the option of level sensitive or edge sensitive modes within the microcontroller, many different configurations are possible, depending on the needs of the equipment designer.

CS42428

3.8

Reliable power-up can be accomplished by keeping the device in reset until the power supplies, clocks and configuration pins are stable. It is also recommended that reset be activated if the analog or digital supplies drop below the recommended operating condition to prevent power glitch related issues.

When RST is low, the CS42428 enters a low power mode and all internal states are reset, including the control port and registers, and the outputs are muted. When RST is high, the control port becomes operational and the desired settings should be loaded into the control registers. Writing a 0 to the PDN bit in the Power Control Register will then cause the part to leave the low power state and begin operation. If the internal PLL is selected as the clock source, the serial audio outputs will be enabled after the PLL has settled. See “Power Control (address 02h)” on page 33 for more details.

The delta-sigma modulators settle in a matter of microseconds after the analog section is powered, either through the application of power or by setting the RST pin high. However, the voltage reference will take much longer to reach a final value due to the presence of external capacitance on the FILT+ pin. A time delay of approximately 80ms is required after applying power to the device or after exiting a reset state. During this voltage reference ramp delay, all serial ports and DAC outputs will be automatically muted.

Reset and Power-up

3.9 Power Supply, Grounding, and PCB layout

As with any high resolution converter, the CS42428 requires careful attention to power supply and grounding arrangements if its potential performance is to be realized. Figure 1 shows the recommended power arrangements, with VA connected to clean supplies. VD, which powers the digital circuitry, may be run from the system logic supply. Alternatively, VD may be powered from the analog supply via a ferrite bead. In this case, no additional devices should be powered from VD.

For applications where the output of the PLL is required to be low jitter, use a separate, low noise analog +5 V supply for VA, decoupled to AGND. In addition, a separate region of analog ground plane around the FILT+, VQ, LPFLT, REFGND, AGND, and VA pins is recommended.

Extensive use of power and ground planes, ground plane fill in unused areas and surface mount decoupling capacitors are recommended. Decoupling capacitors should be as near to the pins of the CS42428 as possible. The low value ceramic capacitor should be the nearest to the pin and should be mounted on the same side of the board as the CS42428 to minimize inductance effects. All signals, especially clocks, should be kept away from the FILT+, VQ and LPFLT pins in order to avoid unwanted coupling into the modulators and PLL. The FILT+ and VQ decoupling capacitors, particularly the 0.1 µF, must be positioned to minimize the electrical path from FILT+ and REFGND. The CDB42418 evaluation board demonstrates the optimum layout and power supply arrangements.

CS42428

4 REGISTER QUICK REFERENCE

AddrFunction7654321 0

01h ID Chip_ID3 Chip_ID2 Chip_ID1 CHIP_ID0 Rev_ID3 Rev_ID2 Rev_ID1 Rev_ID0

default 1 1 1 0 0 0 1 1

02h Power Control Reserved PDN_PLL PDN_ADC PDN_DAC4 PDN_DAC3 PDN_DAC2 PDN_DAC1 PDN

default 0 0 0 0 0 0 0 1

03h Functional Mode DAC_FM1 DAC_FM0 ADC_FM1 ADC_FM0 Reserved ADC_CLK

SEL

default 0 0 0 0 0 0 0 0

04h Interface Formats DIF1 DIF0 ADC_OL1 ADC_OL0 DAC_OL1 DAC_OL0 Reserved CODEC_RJ16

default 0 1 0 0 0 0 0 0

05h Misc Control Ext ADC

SCLK

default 0 0 0 0 0 0 1 1

06h Clock Control RMCK_DIV1 RMCK_DIV0 OMCK

default 0 0 0 0 0 0 1 0

07h OMCK/PLL_CLK

Ratio

default X X X X X X X X

08h Clock Status Reserved Reserved Reserved Reserved Active_CLK PLL_CLK2 PLL_CLK1 PLL_CLK0

default X X X X X X X X

09h-

Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved

0Ch

default X X X X X X X X

0Dh Volume Control Reserved SNGVOL SZC1 SZC0 AMUTE Reserved RAMP_UP RAMP_DN

default 0 0 0 0 1 0 0 0

0Eh Channel Mute B4_MUTE A4_MUTE B3_MUTE A3_MUTE B2_MUTE A2_MUTE B1_MUTE A1_MUTE

default 0 0 0 0 0 0 0 0

0Fh Vol. Control A1 A1_VOL7 A1_VOL6 A1_VOL5 A1_VOL4 A1_VOL3 A1_VOL2 A1_VOL1 A1_VOL0

default 0 0 0 0 0 0 0 0

10h Vol. Control B1 B1_VOL7 B1_VOL6 B1_VOL5 B1_VOL4 B1_VOL3 B1_VOL2 B1_VOL1 B1_VOL0

default 0 0 0 0 0 0 0 0

11h Vol. Control A2 A2_VOL7 A2_VOL6 A2_VOL5 A2_VOL4 A2_VOL3 A2_VOL2 A2_VOL1 A2_VOL0

default 0 0 0 0 0 0 0 0

12h Vol. Control B2 B2_VOL7 B2_VOL6 B2_VOL5 B2_VOL4 B2_VOL3 B2_VOL2 B2_VOL1 B2_VOL0

default 0 0 0 0 0 0 0 0

13h Vol. Control A3 A3_VOL7 A3_VOL6 A3_VOL5 A3_VOL4 A3_VOL3 A3_VOL2 A3_VOL1 A3_VOL0

default 0 0 0 0 0 0 0 0

14h Vol. Control B3 B3_VOL7 B3_VOL6 B3_VOL5 B3_VOL4 B3_VOL3 B3_VOL2 B3_VOL1 B3_VOL0

default 0 0 0 0 0 0 0 0

15h Vol. Control A4 A4_VOL7 A4_VOL6 A4_VOL5 A4_VOL4 A4_VOL3 A4_VOL2 A4_VOL1 A4_VOL0

default 0 0 0 0 0 0 0 0

16h Vol. Control B4 B4_VOL7 B4_VOL6 B4_VOL5 B4_VOL4 B4_VOL3 B4_VOL2 B4_VOL1 B4_VOL0

default 0 0 0 0 0 0 0 0

17h Channel Invert INV_B4 INV_A4 INV_B3 INV_A3 INV_B2 INV_A2 INV_B1 INV_A1

default 0 0 0 0 0 0 0 0

18h Mixing Ctrl Pair 1 P1_A=B Reserved Reserved P1_ATAPI4 P1_ATAPI3 P1_ATAPI2 P1_ATAPI1 P1_ATAPI0

default 0 0 0 0 1 0 0 1

RATIO7 RATIO6 RATIO5 RATIO4 RATIO3 RATIO2 RATIO1 RATIO0

HiZ_RMCK Reserved FREEZE FILTSEL HPF_

FREEZE

Freq1

OMCK

Freq0

PLL_LRCK SW_CTRL1 SW_CTRL0 FRC_PLL_LK

DAC_DEM Reserved

DAC_SP

M/S

ADC_SP

M/S

CS42428

AddrFunction7654321 0

19h Mixing Ctrl Pair 2 P2_A=B Reserved Reserved P2_ATAPI4 P2_ATAPI3 P2_ATAPI2 P2_ATAPI1 P2_ATAPI0

default 0 0 0 0 1 0 0 1

1Ah Mixing Ctrl Pair 3 P3_A=B Reserved Reserved P3_ATAPI4 P3_ATAPI3 P3_ATAPI2 P3_ATAPI1 P3_ATAPI0

default 0 0 0 0 1 0 0 1

1Bh Mixing Ctrl Pair 4 P4_A=B Reserved Reserved P4_ATAPI4 P4_ATAPI3 P4_ATAPI2 P4_ATAPI1 P4_ATAPI0

default 0 0 0 0 1 0 0 1

1Ch ADC Left Ch.

Gain

default 0 0 0 0 0 0 0 0

1Dh ADC Right Ch.

Gain

default 0 0 0 0 0 0 0 0

1Eh Interrupt Control SP_SYNC Reserved DE-EMPH1 DE-EMPH0 INT1 INT0 Reserved Reserved

default 0 0 0 0 0 0 0 0

1Fh Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved

default 0 0 0 0 0 0 0 0

20h Interrupt Status UNLOCK Reserved Reserved Reserved Reserved Reserved OverFlow Reserved

default X X X X X X X X

21h Interrupt Mask UNLOCKM Reserved Reserved Reserved Reserved Reserved OverFlowM Reserved

default 0 0 0 0 0 0 0 0

22h Interrupt Mode

MSB

default 0 0 0 0 0 0 0 0

23h Interrupt Mode

LSB

default 0 0 0 0 0 0 0 0

24h-

Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved

27h

default 0 0 0 0 0 0 0 0

28h MUTEC Reserved Reserved MCPolarity M_AOUTA1 M_AOUTB1 M_AOUTA2

default 0 0 0 1 1 1 1 1

29h GPO7 Mode1 Mode0 Polarity Function4 Function3 Function2 Function1 Function0

default 0 0 0 0 0 0 0 0

2Ah GPO6 Mode1 Mode0 Polarity Function4 Function3 Function2 Function1 Function0

default 0 0 0 0 0 0 0 0

2Bh GPO5 Mode1 Mode0 Polarity Function4 Function3 Function2 Function1 Function0

default 0 0 0 0 0 0 0 0

2Ch GPO4 Mode1 Mode0 Polarity Function4 Function3 Function2 Function1 Function0

default 0 0 0 0 0 0 0 0

2Dh GPO3 Mode1 Mode0 Polarity Function4 Function3 Function2 Function1 Function0

default 0 0 0 0 0 0 0 0

2Eh GPO2 Mode1 Mode0 Polarity Function4 Function3 Function2 Function1 Function0

default 0 0 0 0 0 0 0 0

2Fh GPO1 Mode1 Mode0 Polarity Function4 Function3 Function2 Function1 Function0

default 0 0 0 0 0 0 0 0

Reserved Reserved LGAIN5 LGAIN4 LGAIN3 LGAIN2 LGAIN1 LGAIN0

Reserved Reserved RGAIN5 RGAIN4 RGAIN3 RGAIN2 RGAIN1 RGAIN0

UNLOCK1 Reserved Reserved Reserved Reserved Reserved OF1 Reserved

UNLOCK0 Reserved Reserved Reserved Reserved Reserved OF0 Reserved

M_AOUTB2

M_AOUTA3 M_AOUTB3

M_AOUTA4 M_AOUTB4

CS42428

5 REGISTER DESCRIPTION

All registers are read/write except for I.D. and Revision Register, OMCK/PLL_CLK Ratio Register, Clock Status and Interrupt Status Register which are read only. See the following bit definition tables for bit assignment information. The default state of each bit after a power-up sequence or reset is listed in each bit description.

5.1 Memory Address Pointer (MAP)

Not a register

76543210

INCR MAP6 MAP5 MAP4 MAP3 MAP2 MAP1 MAP0

5.1.1 INCREMENT(INCR)

Default = 1

Function:

Memory address pointer auto increment control 0 - MAP is not incremented automatically. 1 - Internal MAP is automatically incremented after each read or write.

5.1.2 MEMORY ADDRESS POINTER (MAPX)

Default = 0000001

Function:

Memory address pointer (MAP). Sets the register address that will be read or written by the control port.

5.2 Chip I.D. and Revision Register (address 01h) (Read Only)

76543210

Chip_ID3 Chip_ID2 Chip_ID1 CHIP_ID0 Rev_ID3 Rev_ID2 Rev_ID1 Rev_ID0

5.2.1 CHIP I.D. (CHIP_IDX)

Default = 1110

Function:

I.D. code for the CS42428. Permanently set to 1110.

5.2.2 CHIP REVISION (REV_IDX)

Default = 0001

Function:

CS42428 revision level. Revision C is coded as 0011.

CS42428

5.3 Power Control (address 02h)

76543210

Reserved PDN_PLL PDN_ADC PDN_DAC4 PDN_DAC3 PDN_DAC2 PDN_DAC1 PDN

5.3.1 POWER DOWN PLL (PDN_PLL)

Default = 0

Function:

When enabled, the PLL will remain in a reset state. It is advised that any change of this bit be made while the DACs are muted or the power down bit (PDN) is enabled to eliminate the possibility of audible artifacts.

5.3.2 POWER DOWN ADC (PDN_ADC)

Default = 0

Function:

When enabled the stereo analog to digital converter will remain in a reset state. It is advised that any change of this bit be made while the DACs are muted or the power down bit (PDN) is enabled to eliminate the possibility of audible artifacts.

5.3.3 POWER DOWN DAC PAIRS (PDN_DACX)

Default = 0

Function:

When enabled the respective DAC channel pair x (AOUTAx and AOUTBx) will remain in a reset state.

5.3.4 POWER DOWN (PDN)

Default = 1

Function:

The entire device will enter a low-power state when this function is enabled, and the contents of the control registers are retained in this mode. The power down bit defaults to ‘enabled’ on power-up and must be disabled before normal operation can occur.

5.4 Functional Mode (address 03h)

76543210

DAC_FM1 DAC_FM0 ADC_FM1 ADC_FM0 Reserved ADC_SP SEL DAC_DEM Reserved

5.4.1 DAC FUNCTIONAL MODE (DAC_FMX)

Default = 00

00 - Single-Speed Mode (4 to 50 kHz sample rates) 01 - Double-Speed Mode (50 to 100 kHz sample rates) 10 - Quad-Speed Mode (100 to 192 kHz sample rates) 11 - Reserved Function:

Selects the required range of sample rates for all converters clocked from the DAC serial port (DAC_SP). Bits must be set to the corresponding sample rate range when the DAC_SP is in Master or Slave mode.

5.4.2 ADC FUNCTIONAL MODE (ADC_FMX)

Default = 00

00 - Single-Speed Mode (4 to 50 kHz sample rates) 01 - Double-Speed Mode (50 to 100 kHz sample rates) 10 - Quad-Speed Mode (100 to 192 kHz sample rates) 11 - Reserved Function:

Selects the required range of sample rates for the ADC serial port(ADC_SP). These bits must be set to the corresponding sample rate range when the ADC_SP is in Master or Slave mode.

5.4.3 ADC CLOCK SOURCE SELECT (ADC_CLK SEL)

Default = 0

0 - ADC_SDOUT clocked from the DAC_SP. 1 - ADC_SDOUT clocked from the ADC_SP. Function:

Selects the desired clocks for the ADC serial output.

5.4.4 DAC DE-EMPHASIS CONTROL (DAC_DEM)

CS42428

Default = 0

Function:

Enables the digital filter to maintain the standard 15 µs/50 µs digital de-emphasis filter response at the auto-detected sample rate of either 32, 44.1, or 48 kHz. De-emphasis will not be enabled, regardless of this register setting, at any other sample rate. If the FRC_PLL_LK bit is set to a ‘1’b, then the auto-detect sample rate feature is disabled. To apply the correct de-emphasis filter, use the DEEMPH bits in the Interrupt Control (address 1Eh) register to set the appropriate sample rate.

DAC_DEM

reg03h[1]

0 X XX No De-Emphasis 1 0 XX Auto-Detect Fs 11 00

FRC_PLL_LK

reg06h[0]

Table 6. DAC De-Emphasis

DE-EMPH[1:0]

reg1Eh[5:4]

01 10

De-Emphasis

Mode

Reserved

32 kHz

44.1 kHz 48 kHz

5.5 Interface Formats (address 04h)

76543210

DIF1 DIF0 ADC_OL1 ADC_OL0 DAC_OL1 DAC_OL0 Reserved CODEC_RJ16

5.5.1 DIGITAL INTERFACE FORMAT (DIFX)

Default = 01

Function:

These bits select the digital interface format used for the ADC & DAC Serial Port when not in one_line mode. The required relationship between the Left/Right clock, serial clock and serial data is defined by the Digital Interface Format and the options are detailed in Figures 7 - 9.

DIF1 DIF0 Description Format Figure

00 01 10 11

Left Justified, up to 24-bit data I2S, up to 24-bit data Right Justified, 16-bit or 24-bit data reserved

09 18 27

Table 7. Digital Interface Formats

5.5.2 ADC ONE_LINE MODE (ADC_OLX)

Default = 00

Function:

These bits select which mode the ADC will use. By default one-line mode is disabled but can be selected using these bits. Please see Figures 10 and 11 to see the format of one-line mode 1 and one-line mode 2.

ADC_OL1 ADC_OL2 Description Format Figure

00 01 10

DIF: take the DIF setting from reg04h[7:6] One-Line #1 One-Line #2 reserved

Table 8. ADC One_Line Mode

-310 411

CS42428

5.5.3 DAC ONE_LINE MODE (DAC_OLX)

Default = 00

Function:

These bits select which mode the DAC will use. By default one-line mode is disabled but can be selected using these bits. Please see Figures 10 and 11 to see the format of one-line mode 1 and one-line mode 2.

DAC_OL1 DAC_OL2 Description Format Figure

00 01 10 11

DIF: take the DIF setting from reg04h[7:6] One-Line #1 One-Line #2 reserved

-310 411

Table 9. DAC One_Line Mode

5.5.4 CODEC RIGHT JUSTIFIED BITS (CODEC_RJ16)

Default = 0

Function:

This bit determines how many bits to use during right justified mode for the DAC and ADC. By default the DAC and ADC will be in RJ24 bits but can be set to RJ16 bits.

0 - 24 bit mode. 1 - 16 bit mode.

CS42428

5.6 Misc Control (address 05h)

76543210

Ext ADC SCLK HiZ_RMCK Reserved FREEZE FILT_SEL HPF_FREEZE DAC_SP

M/S

5.6.1 EXTERNAL ADC SCLK SELECT (EXT ADC SCLK)

Default = 0

Function:

This bit identifies the SCLK source for the external ADCs attached to the ADCIN1/2 ports when using one line mode of operation.

0 - ADC_SCLK is used as external ADC SCLK. 1 - DAC_SCLK is used as external ADC SCLK.

5.6.2 RMCK HIGH IMPEDANCE (HIZ_RMCK)

Default = 0

Function:

This bit is used to create a high impedance output on RMCK when the clock signal is not required.

ADC_SP

M/S

5.6.3 FREEZE CONTROLS (FREEZE)

Default = 0

Function:

This function will freeze the previous output of, and allow modifications to be made, to the Volume Control (address 0Fh-16h), Channel Invert (address 17h) and Mixing Control Pair (address 18h-1Bh) registers without the changes taking effect until the FREEZE is disabled. To make multiple changes in these control port registers take effect simultaneously, enable the FREEZE bit, make all register changes, then disable the FREEZE bit.

5.6.4 INTERPOLATION FILTER SELECT (FILT_SEL)

Default = 0

Function:

This feature allows the user to select whether the DAC interpolation filter has a fast or slow roll off. For filter characteristics please See “D/A Digital Filter Characteristics” on page 56.

0 - Fast roll off. 1 - Slow roll off.

5.6.5 HIGH PASS FILTER FREEZE (HPF_FREEZE)

Default = 0

Function:

When this bit is set, the internal high-pass filter for the selected channel will be disabled.The current DC offset value will be frozen and continue to be subtracted from the conversion result. See “A/D Digital Filter Characteristics” on page 52.

5.6.6 DAC SERIAL PORT MASTER/SLAVE SELECT (DAC_SP M/S)

Default = 1

Function:

In Master mode, DAC_SCLK and DAC_LRCK are outputs. Internal dividers will divide the master clock to generate the serial clock and left/right clock. In Slave mode, DAC_SCLK and DAC_LRCK become inputs.

5.6.7 ADC SERIAL PORT MASTER/SLAVE SELECT (ADC_SP M/S)

Default = 1

Function:

In Master mode, ADC_SCLK and ADC_LRCK are outputs. Internal dividers will divide the master clock to generate the serial clock and left/right clock. In Slave mode, ADC_SCLK and ADC_LRCK become inputs.

To use the PLL to lock to ADC_LRCK, the ADC_SP must be in slave mode. When using the PLL to lock to LRCK, if ADC_SDOUT is configured to be clocked by the ADC_SP, then both ADC_SCLK and ADC_LRCK must be present. If ADC_SDOUT is configured to be clocked by the DAC_SP, then only the ADC_LRCK signal must be applied.

5.7 Clock Control (address 06h)

CS42428

76543210

RMCK_DIV1 RMCK_DIV0 OMCK Freq1 OMCK Freq0 PLL_LRCK SW_CTRL1 SW_CTRL0 FRC_PLL_LK

5.7.1 RMCK DIVIDE (RMCK_DIVX)

Default = 00

Function:

Divides/multiplies the internal MCLK, either from the PLL or OMCK, by the selected factor.

RMCK_DIV1 RMCK_DIV0 Description

00 01 10 11

Table 10. RMCK Divider Settings

Divide by 1 Divide by 2 Divide by 4

Multiply by 2

5.7.2 OMCK FREQUENCY (OMCK FREQX)

Default = 00

Function:

Sets the appropriate frequency for the supplied OMCK.

OMCK Freq1 OMCK Freq0 Description

01 10 11

Table 11. OMCK Frequency Settings

11.2896 MHz or 12.2880 MHz

16.9344 MHz or 18.4320 MHz

22.5792 MHz or 24.5760 MHz Reserved

5.7.3 PLL LOCK TO LRCK (PLL_LRCK)

Default = 0 0 - Disabled 1 - Enabled

Function:

When enabled, the internal PLL of the CS42428 will lock to the LRCK of the ADC serial port (ADC_LRCK) while the ADC_SP is in slave mode.

CS42428

5.7.4 MASTER CLOCK SOURCE SELECT (SW_CTRLX)

Default = 01

Function:

These two bits, along with the UNLOCK bit in register “Interrupt Status (address 20h) (Read Only)” on page 46, determine the master clock source for the CS42428. When SW_CTRL1 and SW_CTRL0 are set to '00'b, selecting the output of the PLL as the internal clock source, and the PLL becomes unlocked, then RMCK will equal OMCK, but all internal and serial port timings are not valid.

SW_CTRL1 SW_CTRL0 UNLOCK Description

00X 01X

100

110

Table 12. Master Clock Source Select

Manual setting, MCLK sourced from PLL. Manual setting, MCLK sourced from OMCK. Hold, keep same MCLK source. Auto switch, MCLK sourced from OMCK. Auto switch, MCLK sourced from PLL. Auto switch, MCLK sourced from OMCK.

5.7.5 FORCE PLL LOCK (FRC_PLL_LK)

Default = 0

Function:

This bit is used to enable the PLL to lock to the ADC_LRCK with the absence of a clock signal on OMCK. When set to a ‘1’b, the auto-detect sample frequency feature will be disabled. The OMCK/PLL_CLK Ratio (address 07h) (Read Only) register contents are not valid and the PLL_CLK[2:0] bits will be set to ‘111’b. Use the DE-EMPH[1:0] bits to properly apply de-emphasis filtering.

CS42428

5.8 OMCK/PLL_CLK Ratio (address 07h) (Read Only)

76543210

RATIO7(21)RATIO6(20)RATIO5(2-1)RATIO4(2-2)RATIO3(2-3)RATIO2(2-4)RATIO1(2-5)RATIO0(2-6)

5.8.1 OMCK/PLL_CLK RATIO (RATIOX)

Default = sixth

Function:

This register allows the user to find the exact absolute frequency of the recovered MCLK coming from the PLL. This value is represented as an integer (RATIO7:6) and a fractional (RATIO5:0) part. For example, an OMCK/PLL_CLK ratio of 1.5 would be displayed as 60h.

5.9 Clock Status (address 08h) (Read Only)

76543210

Reserved Reserved Reserved Reserved Active_CLK PLL_CLK2 PLL_CLK1 PLL_CLK0

5.9.1 SYSTEM CLOCK SELECTION (ACTIVE_CLK)

Default = x 0 - Output of PLL 1 - OMCK

Function:

This bit identifies the source of the internal system clock (MCLK).

5.9.2 PLL CLOCK FREQUENCY (PLL_CLKX)

Default = xxxh

Function:

The CS42428 will auto-detect the ratio between the OMCK and the recovered clock from the PLL, which is displayed in register 07h. Based on this ratio, the absolute frequency of the PLL clock can be determined, and this information is displayed according to the following table. If the absolute frequency of the PLL clock does not match one of the given frequencies, this register will display the closest available value.

NOTE: These bits are set to ‘111’b when the FRC_PLL_LK bit is ‘1’b.

PLL_CLK2 PLL_CLK1 PLL_CLK0 Description

000 001 010 011 100 101

110 111

Table 13. PLL Clock Frequency Detection

8.1920 MHz

11.2896 MHz

12.288 MHz

16.3840 MHz

22.5792 MHz

24.5760 MHz

45.1584 MHz

49.1520 MHz

CS42428

5.10 Volume Control (address 0Dh)

76543210

Reserved SNGVOL SZC1 SZC0 AMUTE MUTE ADC_SP RAMP_UP RAMP_DN

5.10.1 SINGLE VOLUME CONTROL (SNGVOL)

Default = 0

Function:

The individual channel volume levels are independently controlled by their respective Volume Control registers when this function is disabled. When enabled, the volume on all channels is determined by the A1 Channel Volume Control register and the other Volume Control registers are ignored.

5.10.2 SOFT RAMP AND ZERO CROSS CONTROL (SZCX)

Default = 00

00 - Immediate Change 01 - Zero Cross 10 - Soft Ramp 11 - Soft Ramp on Zero Crossings Function:

Immediate Change

When Immediate Change is selected all level changes will take effect immediately in one step.

Zero Cross

Zero Cross Enable dictates that signal level changes, either by attenuation changes or muting, will occur on a signal zero crossing to minimize audible artifacts. The requested level change will occur after a timeout period between 512 and 1024 sample periods (10.7 ms to 21.3 ms at 48 kHz sample rate) if the signal does not encounter a zero crossing. The zero cross function is independently monitored and implemented for each channel.

Soft Ramp

Soft Ramp allows level changes, both muting and attenuation, to be implemented by incrementally ramping, in 1/8 dB steps, from the current level to the new level at a rate of 1 dB per 8 left/right clock periods.

Soft Ramp on Zero Crossing

Soft Ramp and Zero Cross Enable dictates that signal level changes, either by attenuation changes or muting, will occur in 1/8 dB steps and be implemented on a signal zero crossing. The 1/8 dB level change will occur after a timeout period between 512 and 1024 sample periods (10.7 ms to 21.3 ms at 48 kHz sample rate) if the signal does not encounter a zero crossing. The zero cross function is independently monitored and implemented for each channel.

5.10.3 AUTO-MUTE (AMUTE)

Default = 1

0 - Disabled 1 - Enabled Function:

The Digital-to-Analog converters of the CS42428 will mute the output following the reception of 8192 consecutive audio samples of static 0 or -1. A single sample of non-static data will release the mute. Detection and muting is done independently for each channel. The quiescent voltage on the output will be retained and the MUTEC pin will go active during the mute period. The muting function is affected, similar to volume control changes, by the Soft and Zero Cross bits (SZC[1:0]).

5.10.4 SOFT VOLUME RAMP-UP AFTER ERROR (RMP_UP)

Default = 0

0 - Disabled 1 - Enabled Function:

An un-mute will be performed after executing a filter mode change, after a MCLK/LRCK ratio change or error, and after changing the Functional Mode. When this feature is enabled, this un-mute is affected, similar to attenuation changes, by the Soft and Zero Cross bits (SZC[1:0]). When disabled, an immediate un-mute is performed in these instances.

Note: For best results, it is recommended that this bit be used in conjunction with the RMP_DN bit.

5.10.5 SOFT RAMP-DOWN BEFORE FILTER MODE CHANGE (RMP_DN)

Default = 0

0 - Disabled 1 - Enabled Function:

CS42428

A mute will be performed prior to executing a filter mode or de-emphasis mode change. When this feature is enabled, this mute is affected, similar to attenuation changes, by the Soft and Zero Cross bits (SZC[1:0]). When disabled, an immediate mute is performed prior to executing a filter mode or de-emphasis mode change.

Note: For best results, it is recommended that this bit be used in conjunction with the RMP_UP bit.

5.11 Channel Mute (address 0Eh)

76543210

B4_MUTE A4_MUTE B3_MUTE A3_MUTE B2_MUTE A2_MUTE B1_MUTE A1_MUTE

5.11.1 INDEPENDENT CHANNEL MUTE (XX_MUTE)

Default = 0

0 - Disabled 1 - Enabled Function:

The Digital-to-Analog converter outputs of the CS42428 will mute when enabled. The quiescent voltage on the outputs will be retained. The muting function is affected, similar to attenuation changes, by the Soft and Zero Cross bits (SZC[1:0]).

CS42428

5.12 Volume Control (addresses 0Fh, 10h, 11h, 12h, 13h, 14h, 15h, 16h)

76543210

xx_VOL7 xx_VOL6 xx_VOL5 xx_VOL4 xx_VOL3 xx_VOL2 xx_VOL1 xx_VOL0

5.12.1 VOLUME CONTROL (XX_VOL)

Default = 0

Function:

The Digital Volume Control registers allow independent control of the signal levels in 0.5 dB increments from 0 to -127 dB. Volume settings are decoded as shown in Table 14. The volume changes are implemented as dictated by the Soft and Zero Cross bits (SZC[1:0]). All volume settings less than

-127 dB are equivalent to enabling the MUTE bit for the given channel.

Binary Code Decimal Value Volume Setting

00000000 0 0 dB 00101000 40 -20 dB 01010000 80 -40 dB

01111000 120 -60 dB

10110100 180 -90 dB

Table 14. Example Digital Volume Settings

5.13 Channel Invert (address 17h)

76543210

INV_B4 INV_A4 INV_B3 INV_A3 INV_B2 INV_A2 INV_B1 INV_A1

5.13.1 INVERT SIGNAL POLARITY (INV_XX)

Default = 0

0 - Disabled 1 - Enabled Function:

When enabled, these bits will invert the signal polarity of their respective channels.

5.14 Mixing Control Pair 1 (Channels A1 & B1)(address 18h) Mixing Control Pair 2 (Channels A2 & B2)(address 19h) Mixing Control Pair 3 (Channels A3 & B3)(address 1Ah) Mixing Control Pair 4 (Channels A4 & B4)(address 1Bh)

76543210

Px_A=B Reserved Reserved Px_ATAPI4 Px_ATAPI3 Px_ATAPI2 Px_ATAPI1 Px_ATAPI0

5.14.1 CHANNEL A VOLUME = CHANNEL B VOLUME (PX_A=B)

Default = 0

0 - Disabled 1 - Enabled Function:

The AOUTAx and AOUTBx volume levels are independently controlled by the A and the B Channel Volume Control registers when this function is disabled. The volume on both AOUTAx and AOUTBx are determined by the A Channel Volume Control registers (per A-B pair), and the B Channel Volume Control registers are ignored when this function is enabled.

CS42428

5.14.2 ATAPI CHANNEL MIXING AND MUTING (PX_ATAPIX)

Default = 01001

Function:

The CS42428 implements the channel mixing functions of the ATAPI CD-ROM specification. The ATAPI functions are applied per A-B pair. Refer to Table 15 and Figure 5 for additional information.

ATAPI4 ATAPI3 ATAPI2 ATAPI1 ATAPI0 AOUTAx AOUTBx

00000 MUTE MUTE 00001 MUTE bR 00010 MUTE bL 00011 MUTE b[(L+R)/2] 00100 aR MUTE 00101 aR bR 00110 aR bL 00111 aR b[(L+R)/2] 01000 aL MUTE 01001 aL bR 01010 aL bL 01011 aL b[(L+R)/2] 01100 a[(L+R)/2] MUTE 01101 a[(L+R)/2] bR 01110 a[(L+R)/2] bL 0 1 1 1 1 a[(L+R)/2] b[(L+R)/2] 10000 MUTE MUTE 10001 MUTE bR 10010 MUTE bL 1 0 0 1 1 MUTE [(aL+bR)/2] 10100 aR MUTE 10101 aR bR 10110 aR bL 1 0 1 1 1 aR [(bL+aR)/2] 11000 aL MUTE 11001 aL bR 11010 aL bL 1 1 0 1 1 aL [(aL+bR)/2] 1 1 1 0 0 [(aL+bR)/2] MUTE 1 1 1 0 1 [(aL+bR)/2] bR 1 1 1 1 0 [(bL+aR)/2] bL 1 1 1 1 1 [(aL+bR)/2] [(aL+bR)/2]

CS42428

Table 15. ATAPI Decode

CS42428

5.15 ADC Left Channel Gain (address 1Ch)

76543210

Reserved Reserved LGAIN5 LGAIN4 LGAIN3 LGAIN2 LGAIN1 LGAIN0

5.15.1 ADC LEFT CHANNEL GAIN (LGAINX)

Default = 00h

Function:

The level of the left analog channel can be adjusted in 1 dB increments as dictated by the Soft and Zero Cross bits (SZC[1:0]) from +15 to -15 dB. Levels are decoded in two’s complement, as shown in Table 16.

5.16 ADC Right Channel Gain (address 1Dh)

76543210

Reserved Reserved RGAIN5 RGAIN4 RGAIN3 RGAIN2 RGAIN1 RGAIN0

5.16.1 ADC RIGHT CHANNEL GAIN (RGAINX)

Default = 00h

Function:

The level of the right analog channel can be adjusted in 1dB increments as dictated by the Soft and Zero Cross bits (SZC[1:0]) from +15 to -15dB. Levels are decoded in two’s complement, as shown in Table 16.

Binary Code Decimal Value Volume Setting

001111 +15 +15 d B 001010 +10 +10 dB 000101 +5 +5 dB 000000 0 0 dB

111011 -5 -5 dB

110110 -10 -10 dB 110001 -15 -15 dB

Table 16. Example ADC Input Gain Settings

5.17 Interrupt Control (address 1Eh)

76543210

SP_SYNC Reserved DE-EMPH1 DE-EMPH0 INT1 INT0 Reserved Reserved

5.17.1 SERIAL PORT SYNCHRONIZATION (SP_SYNC)

Default = 0 0 - DAC & ADC Serial Port timings not in phase 1 - DAC & ADC Serial Port timings are in phase

Function:

Forces the LRCK and SCLK from the DAC & ADC Serial Ports to align and operate in phase. This function will operate when both ports are running at the same sample rate or when operating at different sample rates.

5.17.2 DE-EMPHASIS SELECT BITS (DE-EMPHX)

Default = 00 00 - Reserved 01 - De-Emphasis for 32 kHz sample rate. 10 - De-Emphasis for 44.1 kHz sample rate. 11 - De-Emphasis for 48 kHz sample rate.

Function:

Used to specify which de-emphasis filter to apply when the FORCE PLL LOCK (FRC_PLL_LK) in reg06h is enabled.

5.17.3 INTERRUPT PIN CONTROL (INTX)

Default = 00 00 - Active high; high output indicates interrupt condition has occurred 01 - Active low, low output indicates an interrupt condition has occurred 10 - Open drain, active low. Requires an external pull-up resistor on the INT pin. 11 - Reserved

Function:

CS42428

Determines how the interrupt pin (INT) will indicate an interrupt condition.

5.18 Interrupt Status (address 20h) (Read Only)

76543210

UNLOCK Reserved Reserved Reserved Reserved Reserved OverFlow Reserved

For all bits in this register, a “1” means the associated interrupt condition has occurred at least once since the register was last read. A ”0” means the associated interrupt condition has NOT occurred since the last reading of the register. Reading the register resets all bits to 0. Status bits that are masked off in the associated mask register will always be “0” in this register.

5.18.1 PLL UNLOCK (UNLOCK)

Default = 0

Function:

PLL unlock status bit. This bit will go high if the PLL becomes unlocked.

5.18.2 ADC OVERFLOW (OVERFLOW)

Default = 0

Function:

Indicates that there is an over-range condition anywhere in the CS42428 ADC signal path.

CS42428

5.19 Interrupt Mask (address 21h)

76543210

UNLOCKM Reserved Reserved Reserved Reserved Reserved OverFlowM Reserved

Default = 00000000

Function:

The bits of this register serve as a mask for the interrupt sources found in the register “Interrupt Status (address 20h) (Read Only)” on page 46. If a mask bit is set to 1, the error is unmasked, meaning that its occurrence will affect the INT pin and the status register. If a mask bit is set to 0, the error is masked, meaning that its occurrence will not affect the INT pin or the status register. The bit positions align with the corresponding bits in the Interrupt Status register.

5.20 Interrupt Mode MSB (address 22h) Interrupt Mode LSB (address 23h)

76543210

UNLOCK1 Reserved Reserved Reserved Reserved Reserved OF1 Reserved UNLOCK0 Reserved Reserved Reserved Reserved Reserved OF0 Reserved

Default = 00000000

Function:

The two Interrupt Mode registers form a 2-bit code for each Interrupt Status register function. There are three ways to set the INT pin active in accordance with the interrupt condition. In the Rising edge active mode, the INT pin becomes active on the arrival of the interrupt condition. In the Falling edge active mode, the INT pin becomes active on the removal of the interrupt condition. In Level active mode, the INT interrupt pin becomes active during the interrupt condition. Be aware that the active level(Active High or Low) only depends on the INT(1:0) bits located in the register “Interrupt Control (address 1Eh)” on page 45.

00 - Rising edge active 01 - Falling edge active 10 - Level active 11 - Reserved

5.21 MuteC Pin Control (address 28h)

76543210

Reserved Reserved MCPolarity M_AOUTA1 M_AOUTB1 M_AOUTA2

M_AOUTB2

5.21.1 MUTEC POLARITY SELECT (MCPOLARITY)

Default = 0 0 - Active low 1 - Active high

Function:

M_AOUTA3 M_AOUTB3

M_AOUTA4 M_AOUTB4

Determines the polarity of the MUTEC pin.

CS42428

5.21.2 CHANNEL MUTES SELECT (M_AOUTXX)

Default = 11111 0 - Channel mute is not mapped to the MUTEC pin 1 - Channel mute is mapped to the MUTEC pin

Function:

Determines which channel mutes will be mapped to the MUTEC pin. If no channel mute bits are mapped, then the MUTEC pin is driven to the "active" state as defined by the POLARITY bit. These Channel Mute Select bits are "ANDed" together in order for the MUTEC pin to go active. This means that if multiple Channel Mutes are selected to be mapped to the MUTEC pin, then all corresponding channels must be muted before the MUTEC will go active.

5.22 General Purpose Pin Control (addresses 29h to 2Fh)

76543210

Mode1 Mode0 Polarity Function4 Function3 Function2 Function1 Function0

5.22.1 MODE CONTROL (MODEX)

Default = 00

00 - Reserved 01 - Mute Mode 10 - GPO/Overflow Mode 11 - GPO, Drive High Mode

Function:

Mute Mode Function bits.

GPO/Overflow Mode ADC overflow pin indicating an over-range condition anywhere in the ADC signal path for either the left or right channel. The Functionx bits determine the operation of the pin. When configured as a GPO with the output driven low, the driver is a CMOS driver. When configured to identify an ADC Overflow condition, the driver is an open drain driver requiring a pull-up resistor.

GPO, Drive High Mode

- The pin is configured as a dedicated mute pin. The muting function is controlled by the

- The pin is configured as a general purpose output driven low or as a dedicated

- The pin is configured as a general purpose output driven high.

5.22.2 POLARITY SELECT (POLARITY)

Default = 0

Function:

Mute Mode the polarity of the mapped pin according to the following

0 - Active low 1 - Active high

GPO/Overflow Mode - If the pin is configured as a GPO/Overflow Mode pin, the polarity bit is ignored. It is recommended that in this mode this bit be set to 0.

GPO, Drive High Mode bit is ignored. It is recommended that in this mode this bit be set to 0.

- If the pin is configured as a dedicated mute output pin, then the polarity bit determines

- If the pin is configured as a general purpose output driven high, the polarity

5.22.3 FUNCTIONAL CONTROL (FUNCTIONX)

Default = 00000

Function:

CS42428

Mute Mode

- If the pin is configured as a dedicated mute pin, then the functional bits determine which

channel mutes will be mapped to this pin according to the following table.

0 - Channel mute is not mapped to the GPOx pin 1 - Channel mute is mapped to the GPOx pin:

GPOx Reg Address Function4 Function3 Function2 Function1 Function0

GPO7

pin 42

GPO6

pin 43

GPO5

pin 44

GPO4

pin 45

GPO3

pin 46

GPO2

pin 47

GPO1

pin 48

29h

2Ah

2Bh

2Ch

2Dh

2Eh

2Fh

M_AOUTA1 M_AOUTB1 M_AOUTA2

M_AOUTA1 M_AOUTB1 M_AOUTA1 M_AOUTB1 M_AOUTA1 M_AOUTB1 M_AOUTA1 M_AOUTB1 M_AOUTA1 M_AOUTB1 M_AOUTA1 M_AOUTB1

M_AOUTA2 M_AOUTB2 M_AOUTA3

M_AOUTA2

M_AOUTB2

M_AOUTA2

M_AOUTB2

M_AOUTA2

M_AOUTB2

M_AOUTA2

M_AOUTB2

M_AOUTA3 M_AOUTB3 M_AOUTA4

M_AOUTA3 M_AOUTB3 M_AOUTA3 M_AOUTB3

M_AOUTA3 M_AOUTB3

M_AOUTB3

M_AOUTA4 M_AOUTB4

M_AOUTA4 M_AOUTB4 M_AOUTA4 M_AOUTB4

M_AOUTB4

GPO/Overflow Mode - If the pin is configured as a GPO/Overflow Mode pin, then the Function1 and Function0 bits determine how the output will behave according to the following table. It is recommended that in this mode the remaining functional bits be set to 0.

Function1 Function0 GPOx Driver Type

00 11

Drive Low CMOS

OVFL R or L Open Drain

GPO, Drive High Mode

- If the pin is configured as a general purpose output, then the functional bits are ignored and the pin is driven high. It is recommended that in this mode all the functional bits be set to 0.

CS42428

6 CHARACTERISTICS AND SPECIFICATIONS

(All Min/Max characteristics and specifications are guaranteed over the Specified Operating Conditions. Typical performance characteristics and specifications are derived from measurements taken at nominal supply voltages and T

= 25° C.)

SPECIFIED OPERATING CONDITIONS (T

to ground; OMCK=12.288 MHz; Master Mode)

Parameter Symbol Min Typ Max Units

DC Power Supply Analog power

Digital internal power

Serial data port interface power

Control port interface power

Ambient Operating Temperature (power applied) CS42428-CQ

CS42428-DQ

= 25° C; AGND=DGND=0, all voltages with respect

VD VLS VLC

4.75

3.13

1.8

-10

-40

5.0

3.3

5.0

5.25

+70 +85

V V V V

°C °C

ABSOLUTE MAXIMUM RATINGS (AGND = DGND = 0 V; all voltages with respect to ground.)

Parameters Symbol Min Max Units

DC Power Supply Analog power

Digital internal power

Serial data port interface power

Control port interface power Input Current (Note 1) I Analog Input Voltage (Note 2) V Digital Input Voltage Serial data port interface

(Note 2) Control port interface

Ambient Operating Temperature(power applied)

CS42428-CQ CS42428-DQ

Storage Temperature T

WARNING: Operation at or beyond these limits may result in permanent damage to the device. Normal operation is

not guaranteed at these extremes.

Notes: 1. Any pin except supplies. Transient currents of up to ±100 mA on the analog input pins will not cause SCR

latch-up.

2. The maximum over/under voltage is limited by the input current.

VD VLS VLC

IND-S

IND-C

T T

stg

-0.3

-±10mA

AGND-0.7 VA+0.7 V

-0.3

A A

-20

-50

-65 +150 °C

6.0

VLS+ 0.4

VLC+ 0.4

+85 +95

V V V V

V V

°C °C

CS42428

ANALOG INPUT CHARACTERISTICS (T

=AGND = 0 V; Logic "1" = VLS = VLC = 5 V; Measurement Bandwidth 10 Hz to 20 kHz unless otherwise specified. Full scale input sine wave, 997 Hz.; OMCK = 12.288 MHz; Single speed Mode DAC_SCLK = 3.072 MHz; Double Speed Mode DAC_SCLK = 6.144 MHz; Quad Speed Mode DAC_SCLK = 12.288 MHz.)

Parameter (Note 3) Symbol

Single Speed Mode (Fs=48 kHz)

Dynamic Range A-weighted

unweighted

Total Harmonic Distortion + Noise (Note 4) -1 dB

-20 dB

-60 dB

Double Speed Mode (Fs=96 kHz)

Dynamic Range A-weighted

unweighted

40 kHz bandwidth unweighted

Total Harmonic Distortion + Noise (Note 4) -1 dB

-20 dB

-60 dB

40kHz bandwidth -1 dB

Quad Speed Mode (Fs=192 kHz)

Dynamic Range A-weighted

unweighted

40 kHz bandwidth unweighted

Total Harmonic Distortion + Noise (Note 4) -1 dB

-20 dB

-60 dB

40 kHz bandwidth -1 dB

Dynamic Performance for All Modes

Interchannel Isolation - 110 - - 110 - dB Interchannel Phase Deviation - 0.0001 - - 0.0001 - Degree

DC Accuracy

Interchannel Gain Mismatch - 0.1 - - 0.1 - dB Gain Drift - +/-100 - - +/-100 - ppm/°C Offset Error HPF_FREEZE enabled

HPF_FREEZE disabled

Analog Input

Full-scale Differential Input Voltage 1.9 2.0 2.1 1.8 2.0 2.2 Vrms Input Impedance(differential) (Note 5) 37 - - 37 - - k Common Mode Rejection Ratio CMRR - 82 - - 82 - dB VQ Nominal Voltage

Output Impedance Maximum allowable DC current

THD+N

Min Typ Max

108 105

= 25° C; VA = 5 V, VD = 3.3 V, Logic "0" = DGND

CS42428-CQ

114 111

-100

-91

-51

114 111 108

-100

-91

-51

-97

114 111 108

-100

-91

-51

-97

100

2.7 50

0.01

-94

CS42428-DQ

Min Typ Max Unit

106 103

114 111

-100

-91

-51

114 111

108

-100

-91

-51

-97

114 111

108

-100

-91

-51

-97

100

2.7 50

0.01

-92

dB dB

dB dB dB

dB dB dB dB

dB dB dB

dB dB dB dB

LSB LSB

Ω

CS42428

FILT+ Nominal Voltage Output Impedance Maximum allowable DC current

5.0 35

0.01

5.0 35

0.01

Ω

k mA

Notes: 3. Typical performance numbers are taken at 25° C. Min/Max performance numbers are guaranteed across

the specified temperature range, T

4. Referred to the typical full-scale voltage.

5. Measured between AIN+ and AIN-

A/D DIGITAL FILTER CHARACTERISTICS

Parameter Symbol Min Typ Max Unit

Single Speed Mode (2 to 50 kHz sample rates)

Passband (-0.1 dB) (Note 6) 0 - 0.47 Fs

Passband Ripple - - ±0.035 dB

Stopband (Note 6) 0.58 - - Fs

Stopband Attenuation -95 - - dB

Total Group Delay (Fs = Output Sample Rate) t

Group Delay Variation vs. Frequency ∆t

Double Speed Mode (50 to 100 kHz sample rates)

Passband (-0.1 dB) (Note 6) 0 - 0.45 Fs

Passband Ripple - - ±0.035 dB

Stopband (Note 6) 0.68 - - Fs

Stopband Attenuation -92 - - dB

Total Group Delay (Fs = Output Sample Rate) t

Group Delay Variation vs. Frequency ∆t

Quad Speed Mode (100 to 192 kHz sample rates)

Passband (-0.1 dB) (Note 6) 0 - 0.24 Fs

Passband Ripple - - ±0.035 dB

Stopband (Note 6) 0.78 - - Fs

Stopband Attenuation -97 - - dB

Total Group Delay (Fs = Output Sample Rate) t

Group Delay Variation vs. Frequency ∆t

High Pass Filter Characteristics

Frequency Response -3.0 dB

-0.13 dB (Note 7)

Phase Deviation @ 20 Hz (Note 7) - 10 - Deg

Passband Ripple - - 0 dB

Filter Setting Time - 10

-12/Fs- s

--0.0µs

-9/Fs- s

--0.0µs

-5/Fs- s

--0.0µs

-120-

/Fs - s

Hz Hz

Notes: 6. The filter frequency response scales precisely with Fs.

7. Response shown is for Fs equal to 48 kHz. Filter characteristics scale with Fs.

-10

-20

-30

-40

-50

-60

-70

-80

Amplitude (dB)

-90

-100

-110

-120

-130

-140

0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0

Frequency (normalized to Fs)

Figure 20. Single Speed Mode Stopband Rejection Figure 21. Single Speed Mode Transition Band

-10

-20

-30

-40

-50

-60

-70

-80

Amplitud e (dB)

-90

-100

-110

-120

-130

-140

0.40 0.42 0.4 4 0.46 0.48 0.50 0.5 2 0.54 0.56 0.58 0. 60

Frequenc y (normalized t o Fs)

CS42428

-1

-2

-3

-4

-5

Amplitude (dB)

-6

-7

-8

-9

-10

0.45 0.46 0.47 0.48 0.49 0.50 0 .51 0.52 0.53 0.54 0. 55

Frequency (normali zed to Fs)

Figure 22. Single Speed Mode Transition Band (Detail)

-10

-20

-30

-40

-50

-60

-70

-80

Amplitude (dB)

-90

-100

-110

-120

-130

-140

0.00.10.20.30.40.50.60.70.80.91.0

Frequency (norma lized to Fs)

0.10

0.08

0.05

0.03

0.00

Amplitude (dB)

-0.03

-0.05

-0.08

-0.10

0.00 0.05 0.10 0.15 0.20 0.25 0.30 0.35 0.40 0.45 0.50

Frequen cy (normalize d to Fs)

Figure 23. Single Speed Mode Passband Ripple

-10

-20

-30

-40

-50

-60

-70

-80

Amplitude (dB)

-90

-100

-110

-120

-130

-140

0.40 0.43 0.45 0.48 0.50 0.5 3 0. 55 0.58 0.60 0.63 0.65 0.68 0.70

Frequ ency (norma lized to F s)

Figure 24. Double Speed Mode Stopband Rejection Figure 25. Double Speed Mode Transition Band

CS42428

-1

-2

-3

-4

-5

Amplitude (dB)

-6

-7

-8

-9

-10

0.40 0.43 0.45 0.48 0.50 0.53 0.55

Frequency (normalized to Fs)

0.10

0.08

0.05

0.03

0.00

Amplitude (dB)

-0.03

-0.05

-0.08

-0.10

0.00 0.05 0.1 0 0.15 0.20 0.25 0.3 0 0.35 0.40 0.45 0. 50

Frequency (normalized to Fs)

Figure 26. Double Speed Mode Transition Band (Detail) Figure 27. Double Speed Mode Passband Ripple

-10

-20

-30

-40

-50

-60

-70

Amplitude (dB)

-80

-90

-100

-110

-120

0.0 0.1 0 .2 0. 3 0.4 0.5 0.6 0.7 0. 8 0.9 1.0

Frequency (norma lized to Fs)

-10

-20

-30

-40

-50

-60

-70

Amplitude (dB)

-80

-90

-100

-110

-120

-130

0.2 0.2 5 0.3 0.35 0.4 0.45 0.5 0.55 0.6 0.65 0.7 0.75 0.8

Frequency (normalized to Fs)

Figure 28. Quad Speed Mode Stopband Rejection Figure 29. Quad Speed Mode Transition Band

-1

-2

-3

-4

-5

Amplitude (dB)

-6

-7

-8

-9

-10

0.1 0.15 0 .2 0.25 0 .3 0.35 0. 4 0.45 0.5 0. 55 0.6

Frequency ( normalized to F s)

0.10

0.08

0.06

0.04

0.02

0.00

Amplitude (dB)

-0.02

-0.04

-0.06

-0.08

-0.10

0.00 0.05 0. 10 0 .15 0.20 0.25

Frequenc y (normalized to Fs)

Figure 30. Quad Speed Mode Transition Band (Detail) Figure 31. Quad Speed Mode Passband Ripple

CS42428

ANALOG OUTPUT CHARACTERISTICS (T

=AGND = 0 V; Logic "1" = VLS = VLC = 5V; Measurement Bandwidth 10 Hz to 20 kHz unless otherwise specified.; Full scale output 997 Hz sine wave, Test load R DAC_SCLK = 3.072 MHz; Double Speed Mode, DAC_SCLK = 6.144 MHz; Quad Speed Mode, DAC_SCLK =

12.288 MHz.)

Parameter Symbol

= 3 kΩ, CL = 30 pF; OMCK = 12.288 MHz; Single speed Mode,

CS42428-CQ

Min Typ Max

= 25° C; VA = 5 V, VD = 3.3 V, Logic "0" = DGND

CS42428-DQ

Min Typ Max Unit

Dynamic performance for all modes

Dynamic Range(Note 8)

24-bit A-weighted

unweighted

16-bit A-Weighted

(Note 9) unweighted

Total Harmonic Distortion + Noise

24-bit 0 dB

-20 dB

-60 dB

16-bit 0 dB

(Note 9) -20 dB

-60 dB

Idle Channel Noise/Signal-to-noise ratio

Interchannel Isolation (1 kHz)

THD+N

108 105

- 114 - - 114 - dB

-90-- 90 -dB

114 111

97 94

-100

-91

-51

-94

-74

-34

-94

108 105

114 111

97 94

-100

-91

-51

-94

-74

-34

-94

dB dB dB dB

dB dB dB dB dB dB

Analog Output Characteristics for all modes

Full Scale Differential Output .88VA .92VA .94VA .88VA .92VA .94VA Vpp Interchannel Gain Mismatch - 0.1 - - 0.1 - dB Gain Drift - 100 - - 100 - ppm/°C Output Impedance Z AC-Load Resistance R Load Capacitance C

OUT

- 100 - - 100 - Ω

3- -3 - -kΩ

- - 30 - - 30 pF

Notes: 8. One-half LSB of triangular PDF dither is added to data.

9. Performance limited by 16-bit quantization noise.

CS42428

D/A DIGITAL FILTER CHARACTERISTICS

Fast Roll-Off Slow Roll-Off

Parameter

Combined Digital and On-chip Analog Filter Response - Single Speed Mode - 48 kHz

Passband (Note 10) to -0.01 dB corner

to -3 dB corner00 Frequency Response 10 Hz to 20 kHz -0.01 - +0.01 -0.01 - +0.01 dB StopBand 0.5465 - - 0.5834 - - Fs StopBand Attenuation (Note 11) 90 - - 64 - - dB Group Delay - 12/Fs - - 6.5/Fs - s Passband Group Delay Deviation 0 - 20 kHz - - ±0.41/Fs - ±0.14/Fs s De-emphasis Error (Note 12) Fs = 32 kHz (Relative to 1 kHz) Fs = 44.1 kHz

Fs = 48 kHz

0.4535

0.4998

±0.23 ±0.14 ±0.09

0 0

0.4166

0.4998FsFs

±0.23 ±0.14 ±0.09

Combined Digital and On-chip Analog Filter Response - Double Speed Mode - 96 kHz

Passband (Note 10) to -0.01 dB corner

to -3 dB corner00 Frequency Response 10 Hz to 20 kHz -0.01 - 0.01 -0.01 - 0.01 dB StopBand 0.5834 - - .7917 - - Fs StopBand Attenuation (Note 11) 80 - - 70 - - dB Group Delay - 4.6/Fs - - 3.9/Fs - s Passband Group Delay Deviation 0 - 20 kHz - - ±0.03/Fs - ±0.01/Fs s

0.4166

0.4998

0 0

0.2083

0.4998FsFs

Combined Digital and On-chip Analog Filter Response - Quad Speed Mode - 192 kHz

Passband (Note 10) to -0.01 dB corner

to -3 dB corner00 Frequency Response 10 Hz to 20 kHz -0.01 - 0.01 -0.01 - 0.01 dB StopBand 0.6355 - - 0.8683 - - Fs StopBand Attenuation (Note 11) 90 - - 75 - - dB Group Delay - 4.7/Fs - - 4.2/Fs - s Passband Group Delay Deviation 0 - 20 kHz - - ±0.01/Fs - ±0.01/Fs s

Notes: 10. Response is clock dependent and will scale with Fs. Note that the response plots (Figures 32 to 55) have

been normalized to Fs and can be de-normalized by multiplying the X-axis scale by Fs.

11. Single and Double Speed Mode Measurement Bandwidth is from stopband to 3 Fs. Quad Speed Mode Measurement Bandwidth is from stopband to 1.34 Fs.

12. De-emphasis is available only in Single Speed Mode.

0.1046

0.4897

0 0

0.1042

0.4813FsFs

UnitMin Typ Max Min Typ Max

dB dB dB

CS42428

Amplitude (dB)

100

120

0.4 0.5 0.6 0.7 0.8 0.9 1

Frequency(normalized to Fs)

Amplitude (dB)

100

120

0.4 0.42 0.44 0.46 0.48 0.5 0.52 0.54 0.56 0.58 0.6

Frequency(normalized to Fs)

Figure 32. Single Speed (fast) Stopband Rejection Figure 33. Single Speed (fast) Transition Band

Amplitude (dB)

0.45 0.46 0.47 0.48 0.49 0.5 0.51 0.52 0.53 0.54 0.55

Frequency(normalized to Fs)

0.02

0.015

0.01

0.005

Amplitude (dB)

0.005

0.01

0.015

0.02 0 0.05 0.1 0.15 0.2 0.25 0.3 0.35 0.4 0.45 0.5

Frequency(normalized to Fs)

Figure 34. Single Speed (fast) Transition Band (detail) Figure 35. Single Speed (fast) Passband Ripple

Amplitude (dB)

100

120

0.4 0.5 0.6 0.7 0.8 0.9 1

Frequency(normalized to Fs)

Amplitude (dB)

100

120

0.4 0.42 0.44 0.46 0.48 0.5 0.52 0.54 0.56 0.58 0.6

Frequency(normalized to Fs)

Figure 36. Single Speed (slow) Stopband Rejection Figure 37. Single Speed (slow) Transition Band

CS42428

Amplitude (dB)

0.45 0.46 0.47 0.48 0.49 0.5 0.51 0.52 0.53 0.54 0.55

Frequency(normalized to Fs)

0.02

0.015

0.01

0.005

Amplitude (dB)

0.005

0.01

0.015

0.02 0 0.05 0.1 0.15 0.2 0.25 0.3 0.35 0.4 0.45 0.5

Frequency(normalized to Fs)

Figure 38. Single Speed (slow) Transition Band (detail) Figure 39. Single Speed (slow) Passband Ripple

Amplitude (dB)

100

120

0.4 0.5 0.6 0.7 0.8 0.9 1

Frequency(normalized to Fs)

100

120

0.4 0.42 0.44 0.46 0.48 0.5 0.52 0.54 0.56 0.58 0.6

Frequency(normalized to Fs)

Figure 40. Double Speed (fast) Stopband Rejection Figure 41. Double Speed (fast) Transition Band

Amplitude (dB)

0.45 0.46 0.47 0.48 0.49 0.5 0.51 0.52 0.53 0.54 0.55

Frequency(normalized to Fs)

0.02

0.015

0.01

0.005

Amplitude (dB)

0.005

0.01

0.015

0.02 0 0.05 0.1 0.15 0.2 0.25 0.3 0.35 0.4 0.45 0.5

Frequency(normalized to Fs)

Figure 42. Double Speed (fast) Transition Band (detail) Figure 43. Double Speed (fast) Passband Ripple

CS42428

Amplitude (dB)

100

120

0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1

Frequency(normalized to Fs)

Amplitude (dB)

100

120

0.2 0.3 0.4 0.5 0.6 0.7 0.8

Frequency(normalized to Fs)

Figure 44. Double Speed (slow) Stopband Rejection Figure 45. Double Speed (slow) Transition Band

Amplitude (dB)

0.45 0.46 0.47 0.48 0.49 0.5 0.51 0.52 0.53 0.54 0.55

Frequency(normalized to Fs)

0.02

0.015

0.01

0.005

Amplitude (dB)

0.005

0.01

0.015

0.02 0 0.05 0.1 0.15 0.2 0.25 0.3 0.35

Frequency(normalized to Fs)

Figure 46. Double Speed (slow) Transition Band (detail) Figure 47. Double Speed (slow) Passband Ripple

Amplitude (dB)

100

120

0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1

Frequency(normalized to Fs)

Amplitude (dB)

100

120

0.2 0.3 0.4 0.5 0.6 0.7 0.8

Frequency(normalized to Fs)

Figure 48. Quad Speed (fast) Stopband Rejection Figure 49. Quad Speed (fast) Transition Band

CS42428

Amplitude (dB)

0.45 0.46 0.47 0.48 0.49 0.5 0.51 0.52 0.53 0.54 0.55

Frequency(normalized to Fs)

0.2

0.15

0.1

0.05

Amplitude (dB)

0.05

0.1

0.15

0.2 0 0.05 0.1 0.15 0.2 0.25

Frequency(normalized to Fs)

Figure 50. Quad Speed (fast) Transition Band (detail) Figure 51. Quad Speed (fast) Passband Ripple

Amplitude (dB)

100

120

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1

Frequency(normalized to Fs)

100

120

0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9

Frequency(normalized to Fs)

Figure 52. Quad Speed (slow) Stopband Rejection Figure 53. Quad Speed (slow) Transition Band

Amplitude (dB)

0.45 0.46 0.47 0.48 0.49 0.5 0.51 0.52 0.53 0.54 0.55

Frequency(normalized to Fs)

0.02

0.015

0.01

0.005

Amplitude (dB)

0.005

0.01

0.015

0.02 0 0.02 0.04 0.06 0.08 0.1 0.12

Frequency(normalized to Fs)

Figure 54. Quad Speed (slow) Transition Band (detail) Figure 55. Quad Speed (slow) Passband Ripple

CS42428

SWITCHING CHARACTERISTICS (For CQ, T

VA = 5 V, VD =VLC= 3.3 V, VLS = 1.8 V to 5.25 V; Inputs: Logic 0 = DGND, Logic 1 = VLS, C

= -10 to +70° C; For DQ, TA = -40 to +85° C;

= 30 pF)

Parameters Symbol Min Typ Max Units

pin Low Pulse Width (Note 13) 1 - - ms

RST

PLL Clock Recovery Sample Rate Range 30 - 200 kHz

RMCK output jitter (Note 15) - 200 - ps RMS

RMCK output duty cycle 45 50 55 %

OMCK Duty Cycle (Note 14) 40 50 60 %

DAC_SCLK, ADC_SCLK Duty Cycle 45 50 55 %

DAC_LRCK, ADC_LRCK Duty Cycle 45 50 55 %

Master Mode

RMCK to DAC_SCLK, ADC_SCLK active edge delay t

RMCK to DAC_LRCK, ADC_LRCK delay t

smd

lmd

0-10 ns

Slave Mode

DAC_SCLK, ADC_SCLK Falling Edge to

dpd

-50ns

ADC_SDOUT, ADC_SDOUT Output Valid

DAC_LRCK, ADC_LRCK Edge to MSB Valid t

DAC_SDIN Setup Time Before DAC_SCLK Rising

lrpd

-20ns

-10ns

Edge

DAC_SDIN Hold Time After DAC_SCLK Rising Edge t

DAC_SCLK, ADC_SCLK High Time t

DAC_SCLK, ADC_SCLK Low Time t

DAC_SCLK, ADC_SCLK rising to DAC_LRCK,

sckh

sckl

lrckd

20 - - ns

25 - - ns

-30ns

SAI_LRCK Edge

DAC_LRCK, ADC_LRCK Edge to DAC_SCLK,

lrcks

25 - - ns

ADC_SCLK Rising

Notes: 13. After powering up the CS42428, RST

should be held low after the power supplies and clocks are settled.

14. See Table 2 on page 15 for suggested OMCK frequencies

15. Limit the loading on RMCK to 1 CMOS load if operating above 24.576 MHz.

DAC_SCLK ADC_SCLK

(output)

DAC_LRCK ADC_LRCK

(output)

smd

lmd

RMCK

Figure 56. Serial Audio Port Master Mode Timing Figure 57. Serial Audio Port Slave Mode Timing

DAC_LR CK ADC_LR CK

(input)

DAC_SC LK ADC_SCLK

(input)

DAC_S DINx

ADC_SDOUT

lrckd

lrcks

lrpd

sckh

MSB

sckl

dpd

MSB-1

CS42428

SWITCHING CHARACTERISTICS - CONTROL PORT - I2C FORMAT (For CQ, T

= -10 to +70° C; For DQ, T 0 = DGND, Logic 1 = VLC, C

SCL Clock Frequency f

Rising Edge to Start t

RST

Bus Free Time Between Transmissions t

Start Condition Hold Time (prior to first clock pulse) t

Clock Low time t

Clock High Time t

Setup Time for Repeated Start Condition t

SDA Hold Time from SCL Falling (Note 16) t

SDA Setup time to SCL Rising t

Rise Time of SCL and SDA t

Fall Time SCL and SDA t

Setup Time for Stop Condition t

Acknowledge Delay from SCL Falling (Note 17) t

= -40 to +85° C; VA = 5 V, VD =VLS= 3.3 V; VLC = 1.8 V to 5.25 V; Inputs: Logic

=30pF)

Parameter Symbol Min Max Unit

scl

irs

buf

hdst

low

high

sust

hdd

sud

susp

ack

- 100 kHz

500 - ns

4.7 - µs

4.0 - µs

4.7 - µs

4.0 - µs

4.7 - µs

0-µs

250 - ns

-1µs

- 300 ns

4.7 - µs

- (Note 18) ns

Notes: 16. Data must be held for sufficient time to bridge the transition time, t

17. The acknowledge delay is based on MCLK and can limit the maximum transaction speed.

----------- ----------

18. for Single-Speed Mode, for Double-Speed Mode, for Quad-Speed Mode

256 Fs×

RST

irs

Stop St art

SDA

SCL

buf

hdst

low

high

hdd

------------- -------128 Fs×

sud

Repeated

ack

Figure 58. Control Port Timing - I2C Format

, of SCL.

Start

sust

------------ -----64 Fs×

hdst

Stop

sus

CS42428

SWITCHING CHARACTERISTICS - CONTROL PORT - SPI FORMAT

(For CQ, TA = -10 to +70° C; For DQ, TA = -40 to +85° C; VA = 5 V, VD =VLS= 3.3 V; VLC = 1.8 V to 5.25 V; Inputs: Logic 0 = DGND, Logic 1 = VLC, C

Parameter Symbol Min Typ Max Units

=30pF)

CCLK Clock Frequency (Note 19) f

High Time Between Transmissions t

Falling to CCLK Edge t

CCLK Low Time t

CCLK High Time t

CDIN to CCLK Rising Setup Time t

CCLK Rising to DATA Hold Time (Note 20) t

CCLK Falling to CDOUT Stable t

Rise Time of CDOUT t

Fall Time of CDOUT t

Rise Time of CCLK and CDIN (Note 21) t

Fall Time of CCLK and CDIN (Note 21) t

sck

csh

css

scl

sch

dsu

0-6.0MHz

1.0 - - µs

20 - - ns

66 - - ns

40 - - ns

15 - - ns

- - 50 ns

- - 25 ns

- - 100 ns

Notes: 19. If Fs is lower than 46.875 kHz, the maximum CCLK frequency should be less than 128 Fs. This is

dictated by the timing requirements necessary to access the Channel Status and User Bit buffer memory. Access to the control register file can be carried out at the full 6 MHz rate. The minimum allowable input sample rate is 8 kHz, so choosing CCLK to be less than or equal to 1.024 MHz should be safe for all possible conditions.

20. Data must be held for sufficient time to bridge the transition time of CCLK.

21. For f

<1 MHz.

sck

CCLK

CDIN

CDOUT

sch

dsu

scl

css

Figure 59. Control Port Timing - SPI Format

csh

CS42428

DC ELECTRICAL CHARACTERISTICS (T

= 25° C; AGND=DGND=0, all voltages with respect

to ground; OMCK=12.288 MHz; Master Mode)

Parameter Symbol Min Typ Max Units

Power Supply Current normal operation, VA=5 V (Note 22) VD=5 V

VD=3.3 V

Interface current, VLC=5V (Note 23)

VLS=5 V

power-down state (all supplies) (Note 24)

I I I

90 150 100 250 250 250

mA mA mA

µA µA µA

Power Consumption (Note 22) VA=5 V, VD=VLS=VLC=3.3 V normal operation

power-down (Note 24)

VA=5 V, VD=VLS=VLC=5 V normal operation

power-down (Note 24)

Power Supply Rejection Ratio (Note 25) (1 kHz)

(60 Hz)

PSRR -

780

1.25 950

1.25

60 40

850

1050

mW mW mW mW

dB dB

Notes: 22. Current consumption increases with increasing FS and increasing OMCK. Max values are based on

highest FS and highest OMCK. Variance between speed modes is negligible.

23. I

24. Power down mode is defined as RST

measured with no external loading on the SDA pin.

pin = Low with all clock and data lines held static.

25. Valid with the recommended capacitor values on FILT+ and VQ as shown in Figure .

DIGITAL INTERFACE CHARACTERISTICS (For CQ, T

= +25° C; For DQ, TA = -40 to +85° C)

Parameters (Note 26) Symbol Min Typ Max Units

High-Level Input Voltage Serial Port

Control Port

Low-Level Input Voltage Serial Port

Control Port

High-Level Output Voltage at I

=2 mA (Note 27)Serial Port

Control Port

MUTEC, GPOx

Low-Level Output Voltage at I

=2 mA (Note 27)

Serial Port, Control Port, MUTEC, GPOx Input Leakage Current I

0.7xVLS

0.7xVLC

VLS-1.0

VLC-1.0

VA-1.0

--0.4V

--±10µA

0.2xVLS

0.2xVLC

Input Capacitance - 8 - pF MUTEC Drive Current - 3 - mA

Notes: 26. Serial Port signals include: RMCK, OMCK, ADC_SCLK, ADC_LRCK, DAC_SCLK, DAC_LRCK,

A D C _ S D O U T , D A C _ S D I N 1 -4 A D C I N 1 / 2 Control Port signals include: SCL/CCLK, SDA/CDOUT, AD0/CS

, AD1/CDIN, INT, RST

27. When operating RMCK above 24.576 MHz, limit the loading on the signal to 1 CMOS load.

V V

V V V

7 PARAMETER DEFINITIONS

Dynamic Range

The ratio of the rms value of the signal to the rms sum of all other spectral components over the specified bandwidth. Dynamic Range is a signal-to-noise ratio measurement over the specified band width made with a -60 dBFS signal. 60 dB is added to resulting measurement to refer the measurement to full-scale. This technique ensures that the distortion components are below the noise level and do not effect the measurement. This measurement technique has been accepted by the Audio Engineering Society, AES17-1991, and the Electronic Industries Association of Japan, EIAJ CP-307. Expressed in decibels.

Total Harmonic Distortion + Noise

The ratio of the rms value of the signal to the rms sum of all other spectral components over the specified band width (typically 10 Hz to 20 kHz), including distortion components. Expressed in decibels. Measured at -1 and -20 dBFS as suggested in AES17-1991 Annex A.

Frequency Response

A measure of the amplitude response variation from 10 Hz to 20 kHz relative to the amplitude response at 1 kHz. Units in decibels.

Interchannel Isolation

A measure of crosstalk between the left and right channels. Measured for each channel at the converter's output with no signal to the input under test and a full-scale signal applied to the other channel. Units in decibels.

CS42428

Interchannel Gain Mismatch

The gain difference between left and right channels. Units in decibels.

Gain Error

The deviation from the nominal full-scale analog output for a full-scale digital input.

Gain Drift

The change in gain value with temperature. Units in ppm/°C.

Offset Error

The deviation of the mid-scale transition (111...111 to 000...000) from the ideal. Units in mV.

CS42428

8 REFERENCES

1) Cirrus Logic, Audio Quality Measurement Specification, Version 1.0, 1997.

http://www.cirrus.com/products/papers/meas/meas.html

2) Cirrus Logic, AN18: Layout and Design Rules for Data Converters and Other Mixed Signal Devices, Version 6.0, February 1998.

3) Cirrus Logic, Techniques to Measure and Maximize the Performance of a 120 dB, 96 kHz A/D Converter Integrated Circuit, by Steven Harris, Steven Green and Ka Leung. Presented at the 103rd Convention of the Audio Engineering Society, September 1997.

4) Cirrus Logic, A Stereo 16-bit Delta-Sigma A/D Converter for Digital Audio, by D.R. Welland, B.P. Del Signore, E.J. Swanson, T. Tanaka, K. Hamashita, S. Hara, K. Takasuka. Paper presented at the 85th Convention of the Audio Engineering Society, November 1988.

5) Cirrus Logic, The Effects of Sampling Clock Jitter on Nyquist Sampling Analog-to-Digital Converters, and on Oversampling Delta Sigma ADC's, by Steven Harris. Paper presented at the 87th Convention of the Audio Engineering Society, October 1989.

6) Cirrus Logic, An 18-Bit Dual-Channel Oversampling Delta-Sigma A/D Converter, with 19-Bit Mono Application Example, by Clif Sanchez. Paper presented at the 87th Convention of the Audio Engineering Society, October 1989.

7) Cirrus Logic, How to Achieve Optimum Performance from Delta-Sigma A/D and D/A Converters,by Steven Harris. Presented at the 93rd Convention of the Audio Engineering Society, October 1992.

8) Cirrus Logic, A Fifth-Order Delta-Sigma Modulator with 110 dB Audio Dynamic Range, by I. Fujimori, K. Hamashita and E.J. Swanson. Paper presented at the 93rd Convention of the Audio Engineering Society, October 1992.

9) Philips Semiconductor, The I2C-Bus Specification: Version 2.1, Jan. 2000. http://www.semiconduc-

tors.philips.com

9 PACKAGE DIMENSIONS

64L LQFP PACKAGE DRAWING

D1D

CS42428

∝

INCHES MILLIMETERS

DIM MIN NOM MAX MIN NOM MAX

A --- 0.55 0.063 --- 1.40 1.60

A1 0.002 0.004 0.006 0.05 0.10 0.15

B 0.007 0.008 0.011 0.17 0.20 0.27

D 0.461 0.472 BSC 0.484 11.70 12.0 BSC 12.30

D1 0.390 0.393 BSC 0.398 9.90 10.0 BSC 10.10

E 0.461 0.472 BSC 0.484 11.70 12.0 BSC 12.30

E1 0.390 0.393 BSC 0.398 9.90 10.0 BSC 10.10

e* 0.016 0.020 BSC 0.024 0.40 0.50 BSC 0.60

L 0.018 0.024 0.030 0.45 0.60 0.75

∝

0.000° 4° 7.000° 0.00° 4° 7.00°

* Nominal pin pitch is 0.50 mm

Controlling dimension is mm. JEDEC Designation: MS022

THERMAL CHARACTERISTICS

Parameter Symbol Min Typ Max Units

Allowable Junction Temperature - - +135 °C

Junction to Ambient Thermal Impedance θ

-48 -°C/Watt

CIRRUS LOGIC CS42428 Service Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Features

General Description

1 PIN DESCRIPTIONS

2 TYPICAL CONNECTION DIAGRAMS

Figure 1. Typical Connection Diagram

Figure 2. Typical Connection Diagram using the PLL

3 APPLICATIONS

3.1 Overview

3.2 Analog Inputs

3.2.1 Line Level Inputs

Figure 3. Full-Scale Analog Input

3.2.2 External Input Filter

3.2.3 High Pass Filter and DC Offset Calibration

3.3 Analog Outputs

3.3.1 Line Level Outputs and Filtering

Figure 4. Full-Scale Output

3.3.2 Interpolation Filter

3.3.3 Digital Volume and Mute Control

3.3.4 ATAPI Specification

Figure 5. ATAPI Block Diagram (x = channel pair 1, 2, 3, 4)

3.4 Clock Generation

Figure 6. Clock Generation

3.4.1 PLL and Jitter Attenuation

Table 1. PLL External Component Values

3.4.2 OMCK System Clock Mode

3.4.3 Master Mode

Table 2. Common OMCK Clock Frequencies

3.4.4 Slave Mode

Table 3. Common PLL Output Clock Frequencies

Table 4. Slave Mode Clock Ratios

3.5 Digital Interfaces

3.5.1 Serial Audio Interface Signals

Table 5. Serial Audio Port Channel Allocations

3.5.2 Serial Audio Interface Formats

Figure 7. Right Justified Serial Audio Formats

Figure 8. I2S Serial Audio Formats

Figure 9. Left Justified Serial Audio Formats

Figure 10. One Line Mode #1 Serial Audio Format

Figure 11. One Line Mode #2 Serial Audio Format

3.5.3 ADCIN1/ADCIN2 Serial Data Format

Figure 12. ADCIN1/ADCIN2 Serial Audio Format

3.5.4 One Line Mode(OLM) Configurations

Figure 13. OLM Configuration #1

Figure 14. OLM Configuration #2

Figure 15. OLM Configuration #3

Figure 16. OLM Configuration #4

3.6 Control Port Description and Timing

3.6.1 SPI Mode

Figure 17. Control Port Timing in SPI Mode

3.6.2 I2C Mode

Figure 18. Control Port Timing, I2C Slave Mode Write

Figure 19. Control Port Timing, I2C Slave Mode Read

3.7 Interrupts

Reset and Power-up

3.9 Power Supply, Grounding, and PCB layout

4 REGISTER QUICK REFERENCE

5 REGISTER DESCRIPTION

5.1 Memory Address Pointer (MAP)

5.2 Chip I.D. and Revision Register (address 01h) (Read Only)

5.3 Power Control (address 02h)

5.4 Functional Mode (address 03h)

Table 6. DAC De-Emphasis

5.5 Interface Formats (address 04h)

Table 7. Digital Interface Formats

Table 8. ADC One_Line Mode

Table 9. DAC One_Line Mode

5.6 Misc Control (address 05h)

5.7 Clock Control (address 06h)

Table 10. RMCK Divider Settings

Table 11. OMCK Frequency Settings

Table 12. Master Clock Source Select

5.8 OMCK/PLL_CLK Ratio (address 07h) (Read Only)

5.9 Clock Status (address 08h) (Read Only)

Table 13. PLL Clock Frequency Detection

5.10 Volume Control (address 0Dh)

5.11 Channel Mute (address 0Eh)
