CS4205

CrystalClear Audio Codec ’97 for Portable Computing

Features

l Integrated Asynchronous I

(ZV Port)

l Integrated High-Performance Microphone

Pre-Amplifier

l Integrated Digital Effects Processing for Bass

and Treble Response

l Digital Docking Including an I

Synchronous I2S Inputs

l Performance Oriented Digital Mixer l SRS



3D Stereo Enhancement

l On-chip PLL for use with External Clock

Sources

l Dedicated Microphone Analog-to-Digital

Converter

l Sample Rate Converters l S/PDIF Digital Audio Output l AC ’97 2.1 Compliant l PC Beep Bypass l 20-bit Stereo Digital-to-Analog Converters l 18-bit Stereo Analog-to-Digital Converters

S Input Port

S Output, 3

l Three Analog Line-level Stereo Inputs for

LINE IN, VIDEO, and AUX

l High Quality Pseudo-Differential CD Input l Extensive Power Management Support l Meets or Exceeds the Microsoft



PC 99 and

PC 2001 Audio Performance Requirements

Description

The CS4205 is an AC ’97 2.1 compliant stereo audio co- dec designed for PC multimedia systems. It uses industry leading CrystalClear signal technology. The CS405 is the first Cirrus AC ’97 audio codec to feature digital centric mixing and digital effects. This advanced technology and these features are designed to help enable the design of PC 99 and PC 2001 compliant high-quality audio systems for desktop, portable, and entertainment PCs.

Coupling the CS4205 with a PCI audio accelerator or core logic supporting the AC ’97 interface, implements a cost effective, superior quality audio solution. The CS4205 surpasses PC 99, PC 2001, and AC ’97 2.1 audio quality standards.

ORDERING INFO

CS4205-KQ 48-pin TQFP 9x9x1.4 mm



delta-sigma and mixed

AC-LINK AND AC ’97

REGISTERS

SYNC

BIT_CLK

SDATA_OUT

SDATA_IN

RESET#

ID0#

ID1#

GPIO0/LRCLK

GPIO1/SDOUT

EAPD/SCLK

SPDO/SDO2

GPIO[2:4]/SDI[1:3]

ZSCLK,ZSDATA,ZLRCLK

TEST

AC-

LINK

PROCESSING

SERIAL DATA PORT

Preliminary Product Information

P.O. Box 17847, Austin, Texas 78760 (512) 445 7222 FAX: (512) 445 7581 http://www.cirrus.com

ANALOG INPUT MUX AND OUTPUT MIXER

18 bit

ADC

(2ch)

18 bit

ADC

(1ch)

20 bit DAC (2ch)

INPUT

MUX

INPUT MIXER

OUTPUT

MIXER

SIGNAL

ENGINE

GPIO

S/PDIF

ZV PORT

PWR MGT

REG

SRC

AC ’97

SRC

GAIN / MUTE CONTROLS

MIXER / MUX SELECTS

SRC

PCM_DATA

MIC_PCM_DATA

PCM_DATA

This document contains information for a new product. Cirrus Logic reserves the right to modify this product without notice.

LINE

AUX

VIDEO

MIC1

MIC2

PHONE

PC_BEEP

LINE_OUT

MONO_OUT

APR ‘01

DS489PP2

TABLE OF CONTENTS

1. CHARACTERISTICS AND SPECIFICATIONS ..................................................................7

Analog Characteristics ........................................................................................................7

Absolute Maximum Ratings ................................................................................................8

Recommended Operating Conditions.................................................................................8

AC ’97 Serial Port Timing..................................................................................................10

2. GENERAL DESCRIPTION ...............................................................................................13

2.1 AC-Link ......................................................................................................................13

2.2 Control Registers .......................................................................................................14

2.3 Sample Rate Converters ...........................................................................................14

2.4 Mixers ........................................................................................................................14

2.5 Input Mux ...................................................................................................................14

2.6 Volume Control ..........................................................................................................14

2.7 Dedicated Mic Record Path .......................................................................................14

3. DIGITAL SIGNAL PATHS ................................................................................................16

3.1 Analog Centric Mode .................................................................................................16

3.2 Digital Centric Mode ..................................................................................................17

3.3 Host Processing Mode ..............................................................................................17

3.4 Multi-Channel Mode ..................................................................................................17

4. AC-LINK FRAME DEFINITION ........................................................................................19

4.1 AC-Link Serial Data Output Frame ............................................................................20

4.1.1 Serial Data Output Slot Tags (Slot 0) ...........................................................20

4.1.2 Command Address Port (Slot 1) ..................................................................20

4.1.3 Command Data Port (Slot 2) ........................................................................21

4.1.4 PCM Playback Data (Slots 3-11) .................................................................21

4.1.5 GPIO Pin Control (Slot12) ............................................................................21

4.2 AC-Link Serial Data Input Frame ..............................................................................22

4.2.1 Serial Data Input Slot Tag Bits (Slot 0) ......................................................22

4.2.2 Status Address Port (Slot 1) .........................................................................22

4.2.3 Status Data Port (Slot 2) ..............................................................................23

4.2.4 PCM Capture Data (Slot 3-8) .......................................................................23

4.2.5 GPIO Pin Status (Slot 12) ...........................................................................23

4.3 AC-Link Protocol Violation - Loss of SYNC ...............................................................24

5. REGISTER INTERFACE .............................................................................................25

5.1 Reset Register (Index 00h) ......................................................................................27

5.2 Master Volume Register (Index 02h) .......................................................................27

CS4205

Contacting Cirrus Logic Support

For a complete listing of Direct Sales, Distributor, and Sales Representative contacts, visit the Cirrus Logic web site at:

http://www.cirrus.com/corporate/contacts/sales.cfm

Microsoft is a registered trademark of Microsoft Corporation in the United States and/or other countries. Intel is a registered trademark of Intel Corporation. CrystalClear is a registered trademark of Cirrus Logic.

Preliminary product information describes products which are in production, but for which full characterization data is not yet available. Advance product information describes products which are in development and subject to development changes. Cirrus Logic, Inc. has made best efforts to ensure that the information contained in this document is accurate and reliable. However, the information is subject to change without notice and is provided “AS IS” without warranty of any kind (express or implied). No responsibility is assumed by Cirrus Logic, Inc. for the use of this information, nor for infringements of patents or other rights of third parties. This document is the property of Cirrus Logic, Inc. and implies no license under patents, copyrights, trademarks, or trade secrets. No part of this publication may be copied, reproduced, stored in a retrieval system, or transmitted, in any form or by any means (electronic, mechanical, photographic, or otherwise) without the prior written consent of Cirrus Logic, Inc. Items from any Cirrus Logic website or disk may be printed for use by the user. However, no part of the printout or electronic files may be copied, reproduced, stored in a retrieval system, or transmitted, in any form or by any means (electronic, mechanical, photographic, or otherwise) without the prior written consent of Cirrus Logic, Inc.Furthermore, no part of this publication may be used as a basis for manufacture or sale of any items without the prior written consent of Cirrus Logic, Inc. The names of products of Cirrus Logic, Inc. or other vendors and suppliers appearing in this document may be trademarks or service marks of their respective owners which may be registered in some jurisdictions. A list of Cirrus Logic, Inc. trademarks and service marks can be found at http://www.cirrus.com.

2 DS489PP2

5.3 Mono Volume Register (Index 06h) .......................................................................... 28

5.4 Master Tone Control Register (Index 08h) ............................................................... 28

5.5 PC_BEEP Volume Register (Index 0Ah) .................................................................. 29

5.6 Phone Volume Register (Index 0Ch) ........................................................................ 29

5.7 Microphone Volume Register (Index 0Eh) ................................................................30

5.8 Analog Mixer Input Gain Registers (Index 10h - 18h) .............................................. 31

5.9 Input Mux Select Register (Index 1Ah) ..................................................................... 32

5.10 Record Gain Register (Index 1Ch) ......................................................................... 33

5.11 Record Gain Mic Register (Index 1Eh) ................................................................... 33

5.12 General Purpose Register (Index 20h) ................................................................. 34

5.13 3D Control Register (Index 22h) ............................................................................. 34

5.14 Powerdown Control/Status Register (Index 26h) ...................................................35

5.15 Extended Audio ID Register (Index 28h) ................................................................ 36

5.16 Extended Audio Status/Control Register (Index 2Ah) ............................................ 36

5.17 Audio Sample Rate Control Registers (Index 2Ch - 34h) ....................................... 37

5.18 Extended Modem ID Register (Index 3Ch) ............................................................38

5.19 Extended Modem Status/Control Register (Index 3Eh) ......................................... 38

5.20 GPIO Pin Configuration Register (Index 4Ch) ........................................................ 38

5.21 GPIO Pin Polarity/Type Configuration Register (Index 4Eh) .................................. 39

5.22 GPIO Pin Sticky Register (Index 50h) .................................................................... 39

5.23 GPIO Pin Wakeup Mask Register (Index 52h) ...................................................... 40

5.24 GPIO Pin Status Register (Index 54h) ................................................................... 40

5.25 AC Mode Control Register (Index 5Eh) .................................................................. 41

5.26 Misc. Crystal Control Register (Index 60h) ............................................................. 43

5.27 S/PDIF Control Register (Index 68h) ...................................................................... 44

5.28 Serial Port Control Register (Index 6Ah) ................................................................ 45

5.29 Special Feature Address Register (Index 6Ch) ...................................................... 46

5.30 Special Feature Data Register (Index 6Eh) ........................................................... 46

5.31 Digital Mixer Input Volume Registers (Index 6Eh, Address 00h - 05h) .................. 46

5.32 Serial Data Port Volume Control Registers (Index 6Eh, Address 06h - 07h) .........47

5.33 Signal Processing Engine Control Register (Index 6Eh, Address 08h) ..................48

5.34 Internal Error Condition Control/Status Registers (Index 6Eh, Address 09h - 0Bh) 49

5.35 BIOS-Driver Interface Control Registers (Index 6Eh, Address 0Ch - 0Dh) ............50

5.36 ZV Port Control/Status Registers (Index 6Eh, Address 0Eh - 0Fh) ........................ 50

5.37 BIOS-Driver Interface Status Register (Index 7Ah) ................................................ 51

5.38 Vendor ID1 Register (Index 7Ch) ........................................................................... 52

5.39 Vendor ID2 Register (Index 7Eh) ...........................................................................52

6. SERIAL DATA PORTS ..................................................................................................... 53

6.1 Overview ................................................................................................................... 53

6.2 Multi-Channel Expansion .......................................................................................... 53

6.3 Digital Docking ..........................................................................................................54

6.4 Serial Data Formats .................................................................................................. 54

7. ZV PORT ........................................................................................................................... 56

8. SONY/PHILIPS DIGITAL INTERFACE (S/PDIF) ............................................................. 57

9. EXCLUSIVE FUNCTIONS ................................................................................................ 58

10. POWER MANAGEMENT ............................................................................................... 59

10.1AC ’97 Reset Modes ................................................................................................. 59

10.1.1 Cold Reset ................................................................................................. 59

10.1.2 Warm Reset ............................................................................................... 59

10.1.3 New Warm Reset ....................................................................................... 59

10.1.4 Register Reset ........................................................................................... 59

10.2Powerdown Controls ................................................................................................60

CS4205

DS489PP2 3

11. CLOCKING .....................................................................................................................62

11.1PLL Operation (External Clock) ................................................................................62

11.224.576 MHz Crystal Operation ..................................................................................62

11.3Secondary Codec Operation .....................................................................................62

12. ANALOG HARDWARE DESCRIPTION .........................................................................64

12.1Analog Inputs ............................................................................................................64

12.1.1 Line Inputs ..................................................................................................64

12.1.2 CD Input .....................................................................................................64

12.1.3 Microphone Inputs ......................................................................................65

12.1.4 PC Beep Input ............................................................................................65

12.1.5 Phone Input ................................................................................................65

12.2Analog Outputs .........................................................................................................65

12.2.1 Stereo Output .............................................................................................66

12.2.2 Mono Output ..............................................................................................66

12.3Miscellaneous Analog Signals ..................................................................................66

12.4Power Supplies .........................................................................................................66

12.5Reference Design .....................................................................................................66

13. GROUNDING AND LAYOUT ........................................................................................67

14. PIN DESCRIPTIONS ..................................................................................................69

Audio I/O Pins .................................................................................................................70

Analog Reference, Filter, and Configuration Pins ...........................................................71

AC-Link Pins ...................................................................................................................72

Clock and Configuration Pins ..........................................................................................72

Misc. Digital Interface Pins ..............................................................................................73

Power Supply Pins ..........................................................................................................74

15. PARAMETER AND TERM DEFINITIONS ......................................................................75

16. REFERENCE DESIGN ..................................................................................................77

17. REFERENCES ................................................................................................................78

18. PACKAGE DIMENSIONS ...............................................................................................79

CS4205

4 DS489PP2

LIST OF FIGURES

Figure 1. Power Up Timing ............................................................................................... 11

Figure 2. Codec Ready from Start-up or Fault Condition ................................................. 11

Figure 3. Clocks................................................................................................................11

Figure 4. Data Setup and Hold ......................................................................................... 12

Figure 5. PR4 Powerdown and Warm Reset.................................................................... 12

Figure 6. Test Mode .........................................................................................................12

Figure 7. AC-link Connections.......................................................................................... 13

Figure 8. CS4205 Mixer Diagram ..................................................................................... 15

Figure 9. Digital Signal Path Overview ............................................................................. 16

Figure 10. Analog Centric Mode....................................................................................... 18

Figure 11. Digital Centric Mode ........................................................................................ 18

Figure 12. Host Processing Mode .................................................................................... 18

Figure 13. Multi-Channel Mode ........................................................................................ 18

Figure 14. AC-link Input and Output Framing ................................................................... 19

Figure 15. Serial Data Port: Six Channel Circuit ..............................................................53

Figure 16. Digital Docking Connection Diagram...............................................................54

Figure 17. Serial Data Format 0 (I2S) ..............................................................................55

Figure 18. Serial Data Format 1 (Left Justified)................................................................55

Figure 19. Serial Data Format 2 (Right Justified, 20-bit data) .......................................... 55

Figure 20. Serial Data Format 3 (Right Justified, 16-bit data) .......................................... 55

Figure 21. ZV Port Format (I2S, 16-bit data) ....................................................................56

Figure 22. S/PDIF Output ................................................................................................. 57

Figure 23. PLL External Loop Filter .................................................................................. 62

Figure 24. External Crystal ............................................................................................... 62

Figure 25. Line Input (Replicate for Video and AUX) ....................................................... 64

Figure 26. Differential 2 VRMS CD Input.......................................................................... 64

Figure 27. Differential 1 VRMS CD Input.......................................................................... 64

Figure 28. Microphone Input............................................................................................. 65

Figure 29. PC_BEEP Input............................................................................................... 65

Figure 30. Modem Connection ......................................................................................... 65

Figure 31. Stereo Output .................................................................................................. 66

Figure 32. +5V Analog Voltage Regulator ........................................................................66

Figure 33. Conceptual Layout for the CS4205 when in XTAL or OSC Clocking Modes ..68

Figure 34. Pin Locations for the CS4205.......................................................................... 69

Figure 35. CS4205 Reference Design.............................................................................. 77

CS4205

DS489PP2 5

LIST OF TABLES

Table 1. AC Mode Control Configurations ........................................................................17

Table 2. Register Overview for the CS4205 .....................................................................25

Table 3. Indirectly Addressed Register Overview .............................................................26

Table 4. Analog Mixer Output Attenuation ........................................................................27

Table 5. Tone Control Values ...........................................................................................28

Table 6. Microphone Input Gain Values............................................................................30

Table 7. Analog Mixer Input Gain Values .........................................................................31

Table 8. Analog Mixer Input Gain Register Index .............................................................31

Table 9. Input Mux Selection ............................................................................................32

Table 10. Record Gain Values..........................................................................................33

Table 11. Audio Sample Rate Control Register Index ......................................................37

Table 12. Directly Supported SRC Sample Rates for the CS4205 ...................................37

Table 13. GPIO Input/Output Configurations ....................................................................39

Table 14. Slot Mapping for the CS4205...........................................................................42

Table 15. Digital Signal Source Selects............................................................................42

Table 16. Serial Data Format Selection ............................................................................45

Table 17. Digital Mixer Input Volume Register Index ........................................................46

Table 18. Serial Port Volume Control Register Index .......................................................47

Table 19. Volume Change Modes and EQ Filter Selects .................................................48

Table 20. Internal Error Sources and Correction Methods ...............................................49

Table 21. ZV Port Control/Status Register Index..............................................................50

Table 22. Device ID with Corresponding Part Number .....................................................52

Table 23. Serial Data Formats and Compatible DACs/ADC’s for the CS4205 ................55

Table 24. Powerdown PR Bit Functions ...........................................................................60

Table 25. Powerdown PR Function Matrix for the CS4205 ..............................................61

Table 26. Power Consumption by Powerdown Mode for the CS4205..............................61

Table 27. Clocking Configurations for the CS4205...........................................................63

CS4205

6 DS489PP2

1. CHARACTERISTICS AND SPECIFICATIONS

CS4205

ANALOG CHARACTERISTICS (Standard test conditions unless otherwise noted: T

AVdd = 5.0 V ±5%, DVdd = 3.3 V ±5%; 1 kHz Input Sine wave; Sample Frequency, Fs = 48 kHz; Z 1000 pF load for Mono and Line Outputs; C

= 18 pF load (Note 1); Measurement bandwidth is 20 Hz - 20 kHz,

ambient

=100 kΩ/

= 25° C,

18-bit linear coding for ADC functions, 20-bit linear coding for DAC functions; Mixer registers set for unity gain.

Parameter

(Note 2)

Symbol Path

(Note 3)

Min Typ Max

CS4205-KQ

Unit

Full Scale Input Voltage Line Inputs Mic Inputs (10dB = 0, 20dB = 0) Mic Inputs (10dB = 1, 20dB = 0) Mic Inputs (10dB = 0, 20dB = 1) Mic Inputs (10dB = 1, 20dB = 1)

A-D A-D A-D A-D A-D

0.91

0.283

0.091

0.0283

1.00

0.315

0.10

0.0315

V V V V V

RMS

Full Scale Output Voltage Line and Mono Outputs D-A 0.91 1.0 1.13 V

Frequency Response (Note 4) Analog Ac = ± 0.5 dB DAC Ac = ± 0.5 dB ADC Ac = ± 0.5 dB

Dynamic Range Stereo Analog Inputs to LINE_OUT Mono Analog Input to LINE_OUT DAC Dynamic Range ADC Dynamic Range

DAC SNR (-20 dB FS input w/ CCIR-RMS filter on output)

Total Harmonic Distortion + Noise

SNR

THD+N

A-A D-A A-D

A-A A-A D-A A-D

20 20 20

90 85 85 85

95 90 90 90

20,000 20,000 20,000

D-A - 70 - dB

RMS

Hz Hz Hz

dB FS A dB FS A dB FS A dB FS A

(-3 dB FS input signal): Line Output DAC ADC (all inputs)

A-A D-A A-D

-90

-87

-84

-80

dB FS dB FS dB FS

Power Supply Rejection Ratio (1 kHz, 0.5 V

w/ 5 V DC offset) (Note 4) 40 60 - dB

RMS

Interchannel Isolation 70 87 - dB Spurious Tone (Note 4) - -100 - dB FS Input Impedance (Note 4) 10 - - kΩ

Notes: 1. Z

refers to the analog output pin loading and CDL refers to the digital output pin loading.

2. Parameter definitions are given in Section 15, Parameter and Term Definitions.

3. Path refers to the signal path used to generate this data. These paths are defined in Section 15, Parameter and Term Definitions.

4. This specification is guaranteed by silicon characterization; it is not production tested.

DS489PP2 7

ANALOG CHARACTERISTICS (Continued)

CS4205

Parameter

(Note 2)

External Load Impedance Line Output, Mono Output 10 - - kΩ

Output Impedance Line Output, Mono Output (Note 4) - 730 - Ω

Input Capacitance (Note 4) - 5 - pF Vrefout 2.3 2.4 2.5 V

Symbol Path

(Note 3)

Min Typ Max

CS4205-KQ

Unit

MIXER CHARACTERISTICS

Parameter Min Typ Max Unit

Mixer Gain Range Span PC Beep Line In, Aux, CD, Video, Mic1, Mic2, Phone Mono Out, Line Out ADC Gain

Step Size All volume controls except PC Beep PC Beep

45.0

46.5

22.5

1.5

3.0

dB dB dB dB

dB dB

ABSOLUTE MAXIMUM RATINGS (AVss1 = AVss2 = DVss1 = DVss2 = 0 V)

Parameter Min Typ Max Unit

Power Supplies +3.3 V Digital

+5 V Digital

Analog Total Power Dissipation (Supplies, Inputs, Outputs) - - 1.25 W Input Current per Pin (Except Supply Pins) -10 - 10 mA Output Current per Pin (Except Supply Pins) -15 - 15 mA Analog Input voltage -0.3 - AVdd+

Digital Input voltage -0.3 - DVdd +

Ambient Temperature (Power Applied) -55 - 110 °C Storage Temperature -65 - 150 °C

-0.3

6.0

0.3

RECOMMENDED OPERATING CONDITIONS (AVss1 = AVss2 = DVss1 = DVss2 = 0 V)

Parameter Symbol Min Typ Max Unit

Power Supplies +3.3 V Digital

+5 V Digital

Analog

Operating Ambient Temperature 0 - 70 °C

DVdd1, DVdd2 DVdd1, DVdd2

AVdd1, AVdd2

3.135

4.75

3.3 5 5

3.465

5.25

V V V

8 DS489PP2

CS4205

DIGITAL CHARACTERISTICS (AVss = DVss = 0 V)

Parameter Symbol Min Typ Max Unit

DVdd = 3.3V

Low level input voltage V High level input voltage V High level output voltage V Low level output voltage V

Input Leakage Current (AC-link inputs) -10 - 10 µA Output Leakage Current (Tri-stated AC-link outputs) -10 - 10 µA Output buffer drive current

BIT_CLK, SPDO/SDO2 SDATA_IN, EAPD/SCLK GPIO0/LRCLK, GPIO1/SDOUT GPIO2/SDI1, GPIO3/SDI2, GPIO4/SDI3 (Note 4)

DVdd = 5.0 V

Low level input voltage V High level input voltage V High level output voltage V Low level output voltage V

Input Leakage Current (AC-link inputs) -10 - 10 µA Output Leakage Current (Tri-stated AC-link outputs) -10 - 10 µA Output buffer drive current

BIT_CLK, SPDO/SDO2 SDATA_IN, EAPD/SCLK GPIO0/LRCLK, GPIO1/SDOUT GPIO2/SDI1, GPIO3/SDI2, GPIO4/SDI3 (Note 4)

- - 0.80 V

2.15 - - V

3.00 3.25 - V

- 0.03 0.35 V

4 4 4

mA mA mA mA

- - 0.80 V

3.25 - - V

4.50 4.95 - V

- 0.03 0.35 V

4 4 4

mA mA mA mA

DS489PP2 9

CS4205

AC ’97 SERIAL PORT TIMING Standard test conditions unless otherwise noted: T

AVdd = 5.0 V, DVdd = 3.3 V; C

= 55 pF load.

ambient

= 25° C,

Parameter Symbol Min Typ Max Unit

RESET Timing

RESET# active low pulse width T RESET# inactive to BIT_CLK start-up delay (XTL mode)

(OSC mode)

(PLL mode) 1st SYNC active to CODEC READY ‘set’ T Vdd stable to RESET# inactive T

rst_low

rst2clk

sync2crd

vdd2rst#

1.0 - - µs

4.0

2.5

- 62.5 - µs

100 - - µs

Clocks

BIT_CLK frequency F BIT_CLK period T

clk_period

clk

- 12.288 - MHz

- 81.4 - ns BIT_CLK output jitter (depends on XTL_IN source) - - 750 ps BIT_CLK high pulse width T BIT_CLK low pulse width T SYNC frequency F SYNC period T SYNC high pulse width T SYNC low pulse width T

sync_period

sync_high

sync_low

clk_high

clk_low

sync

36 40.7 45 ns 36 40.7 45 ns

-48-kHz

- 20.8 - µs

-1.3-µs

- 19.5 - µs

Data Setup and Hold

Output propagation delay from rising edge of BIT_CLK T Input setup time from falling edge of BIT_CLK T Input hold time from falling edge of BIT_CLK T Input signal rise time T Input signal fall time T Output signal rise time (Note 4) T Output signal fall time (Note 4) T

isetup

ihold

irise

ifall

orise

ofall

81012ns

10 - - ns

0--ns 2-6ns 2-6ns 246ns 246ns

Misc. Timing Parameters

End of Slot 2 to BIT_CLK, SDATA_IN low (PR4) T SYNC pulse width (PR4) Warm Reset T SYNC inactive (PR4) to BIT_CLK start-up delay T Setup to trailing edge of RESET# (ATE test mode) (Note 4) T

s2_pdown

sync_pr4

sync2clk

setup2rst

Rising edge of RESET# to Hi-Z delay (Note 4) T

off

-0.21.0µs

1.0 - - µs

162.8 285 - ns 15 - - ns

- - 25 ns

µs µs

10 DS489PP2

BIT_CLK

RESET#

Vdd

BIT_CLK

rst_low

vdd2rst#

Figure 1. Power Up Timing

rst2clk

CS4205

SYNC

CODEC_READY

Figure 2. Codec Ready from Start-up or Fault Condition

BIT_CLK

orise

SYNC

irise

clk_highTclk_low

sync_high

sync2crd

ifall

sync_period

clk_period

sync_low

ifall

Figure 3. Clocks

DS489PP2 11

BIT_CLK

SDATA_IN

SDATA_OUT, SYNC

Slot 1 Slot 2

isetup

Figure 4. Data Setup and Hold

CS4205

ihold

SDATA_OUT

SDATA_IN

SYNC

Write to 0x20 Data PR4 Don’t Care

s2_pdown

Figure 5. PR4 Powerdown and Warm Reset

RESET#

setup2rst

SDATA_OUT, SYNC

off

sync_pr4

sync2clk

SDATA_IN,

BIT_CLK

Hi-Z

Figure 6. Test Mode

12 DS489PP2

CS4205

2. GENERAL DESCRIPTION

The CS4205 is a mixed-signal serial audio codec compliant with the Intel® Audio Codec ’97 Specifi-

cation, revision 2.1 [6] (referred to as AC ’97). It is designed to be paired with a digital controller, typically located on the PCI bus or integrated within the system core logic chip set. The controller is responsible for all communications between the CS4205 and the remainder of the system. The CS4205 contains two distinct functional sections: digital and analog. The digital section includes the AC-link interface, S/PDIF interface, serial data port, GPIO, signal processing engine, ZV Port, power management support, and Sample Rate Converters (SRCs). The analog section includes the analog input multiplexer (mux), stereo input mixer, stereo output mixer, mono output mixer, stereo Analog-to-Digital Converters (ADCs), stereo Digital-to-Analog Converters (DACs), dedicated mono microphone ADC, and their associated volume controls.

2.1 AC-Link

All communication with the CS4205 is established with a 5-wire digital interface to the controller called the AC-link. This interface is shown in Figure 7. All clocking for the serial communication is synchronous to the BIT_CLK signal. BIT_CLK is generated by the primary audio codec and is used to clock the controller and any secondary audio codecs. Both input and output AC-link audio frames are organized as a sequence of 256 serial bits forming 13 groups referred to as ‘slots’. During each audio frame, data is passed bi-directionally between the CS4205 and the controller. The input frame is driven from the CS4205 on the SDATA_IN line. The output frame is driven from the controller on the SDATA_OUT line. The controller is also responsible for issuing reset commands via the RESET# signal. Following a Cold Reset, the CS4205 is responsible for notifying the controller that it is ready for operation after synchronizing its internal functions. The CS4205 AC-link signals must use the same digital supply voltage as the controller, either +5 V or +3.3 V. See Section 4, AC-Link Frame Definition, for detailed AC-link information.

Digital AC’97

Controller

Figure 7. AC-link Connections

DS489PP2 13

SYNC

BIT_CLK

SDATA_OUT

SDATA_IN

RESET#

AC’97

CODEC

CS4205

2.2 Control Registers

The CS4205 contains a set of AC ’97 compliant control registers, and a set of Cirrus Logic defined control registers. These registers control the basic functions and features of the CS4205. Read accesses of the control registers by the AC ’97 controller are accomplished with the requested register index in Slot 1 of a SDATA_OUT frame. The following SDATA_IN frame will contain the read data in its Slot 2. Write operations are similar, with the register index in Slot 1 and the write data in Slot 2 of a SDATA_OUT frame. The function of each input and output frame is detailed in Section 4, AC-Link Frame Definition. Individual register descriptions are found in Section 5, Register Interface.

2.3 Sample Rate Converters

The sample rate converters (SRC) provide high accuracy digital filters supporting sample frequencies other than 48 kHz to be captured from the CS4205 or played from the controller. AC ’97 requires support for two audio rates (44.1 and 48 kHz) and four modem rates (8, 9.6, 13.714, and 16 kHz). In addition, the Intel® I/O Controller Hub (ICHx) specification [9] requires support for five more audio rates (8, 11.025, 16, 22.05, and 32 kHz) and specifies two optional modem rates (24, 48kHz). The CS4205 supports all these rates, as shown in Table 12 on page 37.

2.4 Mixers

The CS4205 input and output mixers are illustrated in Figure 8. The stereo input mixer sums together the analog inputs to the CS4205 according to the settings in the volume control registers. The stereo output mixer sums the output of the stereo input

mixer with the PC_BEEP and PHONE signals. The stereo output mix is then sent to the LINE_OUT pins of the CS4205. The mono output mixer generates a monophonic sum of the left and right audio channels from the stereo input mixer. The mono output mix is then sent to the MONO_OUT pin on the CS4205.

2.5 Input Mux

The input multiplexer controls which analog input is sent to the ADCs. The output of the input mux is converted to stereo 18-bit digital PCM data and transmitted to the controller by means of the AC-link SDATA_IN signal.

2.6 Volume Control

The CS4205 volume registers control analog input levels to the input mixer and analog output levels, including the master volume level. The PC_BEEP volume control uses 3 dB steps with a range of 0 dB to -45 dB attenuation. All other analog volume controls use 1.5 dB steps. The analog inputs have a mixing range of +12 dB signal gain to -34.5 dB signal attenuation. The analog output volume controls have from 0 dB to -46.5 dB attenuation for LINE_OUT and MONO_OUT.

2.7 Dedicated Mic Record Path

The CS4205 includes a dedicated microphone ADC that supports advanced functions such as speech recognition and internet telephony. The dedicated ADC allows recording of a microphone input independent of the input mux settings. This enables simultaneous capture of microphone and independent stereo sources.

14 DS489PP2

CS4205

PC_BEEP

PHONE

PCM_OUT

MIC1

MIC2

LINE

VIDEO

AUX

MIC

SELECT

Front D/A

CONVERTERS

DAC

BOOST

MUTE

PC BEEP BYPASS

ANALOG STEREO

INPUT MIXER

MONO MIX

SELECT

STEREO TO

MONO MIXER

ANALOG STEREO

OUTPUT MIXER

STEREO TO

MONO MIXER

1/2

DAC DIRECT

MODE

MONO OUT

SELECT

ADC

INPUT

MUX

MASTER VOLUME

VOL

MONO

VOLUME

VOL

L/R ADC

GAIN

VOL

MUTE

OUTPUT BUFFER

L/R A/D

CONVERTERS

ADCMUTE

LINE OUT

MONO OUT

PCM_IN

VOL

VOL VOL

VOL VOL VOL

MIC ADC

GAIN

VOL

MIC A/D

CONVERTER

ADCMUTE

MIC_PCM_IN

Figure 8. CS4205 Mixer Diagram

DS489PP2 15

CS4205

3. DIGITAL SIGNAL PATHS

The CS4205 includes a number of internal digital signal path options. Figure 9 shows the principal signal flow options through one channel of the device. Four commonly used signal flow modes are detailed in the following sections. The signal flow modes are controlled through the bits in the AC Mode Control Register (Index 5Eh). The bit configuration for each detailed mode is listed in Table 1 on page 17.

front

surr

c+lfe

SRC

DAC LINE_OUT

DACS

3.1 Analog Centric Mode

Analog centric mode is detailed in Figure 10 on page 18. In this mode, all the digital sources are pre-mixed in the digital mixer and sent to the DACs. The DAC outputs are mixed with the analog sources in the analog mixer. The ADCs send captured data directly to the host. The ADC mux is used to select a single source or the output of the input mixer for capture. In the analog centric mode, effects processing is only available on digital sources.

LINE

MIXER

mux out

ADC ½ ADC

VIDEO

mic out

AUX

MIC

mix out

DDM

MONO_OUT

L/R cap

mic cap

SRC

½ SRC

AC-Link

IN1

IN2

IN3

CAPS

MICS

I²S

ZV ASRC VOL

VOL

Figure 9. Digital Signal Path Overview

VOL VOL

Signal Processing Engine

DIG

EFX

SDOS

SPDS

VOL

I²S

OUT1

I²S

OUT2

S/PDIF

OUT

16 DS489PP2

CS4205

3.2 Digital Centric Mode

Digital centric mode is detailed in Figure 11. In this mode, the analog sources are first mixed in the analog mixer and sent to the ADCs. The ADC outputs are then mixed with the digital sources in the digital mixer. This allows effects processing on all sources and supports a “what you hear is what you record” model. The processed digital signal is sent to the DACs, bypassing the analog mixer using DAC direct mode. The ADC mux must be set to stereo mix to support this model. Consequently, only the mix can be captured by the host, rather than the individual sources.

3.3 Host Processing Mode

Host processing mode is detailed in Figure 12. This mode is similar to digital centric mode, except the

output of the digital mixer is captured by the host. Any mixing with host sources and effects processing is done on the host. The processed signal is sent to the DACs, bypassing the analog mixer using DAC direct mode. In host processing mode, the playback and capture paths are completely separate inside the CS4205.

3.4 Multi-Channel Mode

Multi-channel mode is detailed in Figure 13. This mode is an extension of any of the other three modes, with the distinguishing feature that one or two additional slot pairs are routed to the serial data output ports. This allows for a complete multi-channel solution with a single AC ’97 audio codec and external DACs.

AC Mode

Control Bits

DACS 1 1 0 0 or 1

CAPS[1:0] 00 10 10 00,10 or 11

MICS 0 or 1 0 or 1 0 or 1 0 or 1

DDM 0 1 1 0 or 1

SDOS[1:0] 10 or 11 11 - 00

SPDS[1:0] 00, 01, 10 or 11 00, 01, 10 or 11 00 or 01 N/A

Analog Centric

Mode

Table 1. AC Mode Control Configurations

Digital Centric

Mode

Host Processing

Mode

Multi-Channel

Mode

DS489PP2 17

CS4205

Signal Processing Engine

AC-Link

SRC

DAC MIXER LINE_OUT

LINE

VIDEO

AUX

MIC

MONO_OUT

ADC ½ ADC

SRC

½ SRC

I²S IN1

I²S IN2

I²S IN3

ZV ASRC VOL

VOL

DIG EFX

I²S

OUT1

S/PDIF

OUT

mux out

mix out

mic out

VOL

front

L/R cap

mic cap

surr

c+lfe

MICS

SDOS

SPDS

Signal Processing Engine

SRC

DAC LINE_OUT

MONO_OUT

ADC ½ ADC

SRC

½ SRC

I²S IN1

I²S IN2

I²S IN3

ZV ASRC VOL

VOL

DIG EFX

I²S

OUT1

S/PDIF

OUT

VOL

VOL VOL

MICS

SPDS

AC-Link

front

L/R

cap

mic

cap

surr

c+lfe

MIXER

LINE

VIDEO

AUX

MIC

mux out

mix out

mic out

Figure 11. Digital Centric Mode

front

SRC

surr

c+lfe

L/R

SRC

cap

mic

½ SRC

cap

AC-Link

Figure 10. Analog Centric Mode

front

surr

c+lfe

L/R

cap

mic

cap

AC-Link

18 DS489PP2

I²S

IN1

I²S

IN2

I²S

IN3

ZV ASRC VOL

Figure 12. Host Processing Mode

SRC

½ SRC

I²S

IN1

I²S

IN2

I²S

IN3

ZV ASRC VOL

Figure 13. Multi-Channel Mode

DAC LINE_OUT

MICS

VOL

DAC LINE_OUT

DACS

CAPS

MICS

VOL

AUX

LINE

VIDEO

MIXER

mux out

mic out

ADC ½ ADC

VOL

Signal Processing Engine

AUX

LINE

VIDEO

MIXER

mux out

mic out

ADC ½ ADC

VOL VOL

Signal Processing Engine

DIG EFX

MIC

mix out

MONO_OUT

SPDS

MIC

mix out

DDM

MONO_OUT

VOL

S/PDIF

OUT

I²S

OUT1

I²S

OUT2

CS4205

4. AC-LINK FRAME DEFINITION

The AC-link is a bi-directional serial port with data organized into frames consisting of one 16-bit and twelve 20-bit time-division multiplexed slots. Slot 0 is a special reserved time slot containing 16-bits which are used for AC-link protocol infrastructure. Slots 1 through 12 contain audio or control/status data. Both the serial data output and input frames are defined from the controller perspective, not from the CS4205 perspective.

The controller synchronizes the beginning of a frame with the assertion of the SYNC signal. Figure 14 shows the position of each bit location

Tag Phase Data Phase

within the frame. The first bit position in a new serial data frame is F0 and the last bit position in the serial data frame is F255. When SYNC goes active (high) and is sampled active by the CS4205 (on the falling edge of BIT_CLK), both devices are synchronized to a new serial data frame. The data on the SDATA_OUT pin at this clock edge is the final bit of the previous frame’s serial data. On the next rising edge of BIT_CLK, the first bit of Slot 0 is driven by the controller on the SDATA_OUT pin. On the next falling edge of BIT_CLK, the CS4205 latches this data in as the first bit of the frame.

20.8 µs

(48 kHz)

SYNC

BIT_CLK

Bit Frame Position:

SDATA_OUT

Bit Frame Position:

SDATA_IN

12.288 MHz

81.4 ns

F0 F1 F2 F16F15F14F13F12

F255

Valid

Frame

F0 F1 F2 F16F15F14F13F12 F35 F56 F76F255

Codec Ready

Slot 1 Valid

Slot 1

Valid

GPIO

INT

Slot 2

Valid

Slot 2 Valid

Slot 12

Valid

Slot 12

Valid

Slot 0 Slot 1 Slot 2 Slot 3 Slot 4 Slots 5-12

Codec

ID1

R/W 0 WD15

ID0

0000

Figure 14. AC-link Input and Output Framing

F36 F57

F35

F36

F56

D19 D18 D19

F57

D19 D18 D19RD15

F76

F96

D19

F96

D19

F255

GPIO

INT

DS489PP2 19

CS4205

4.1 AC-Link Serial Data Output Frame

In the serial data output frame, data is passed on the SDATA_OUT pin to the CS4205 from the AC ’97 controller. Figure 14 illustrates the serial port timing.

The PCM playback data being passed to the CS4205 is shifted out MSB first in the most significant bits of each slot. Any PCM data from the AC ’97 controller that is not 20 bits wide should be left justified in its corresponding slot and dithered or zero-padded in the unused bit positions.

Bits that are reserved should always be ‘cleared’ by the AC ’97 controller.

4.1.1 Serial Data Output Slot Tags (Slot 0)

Bit 1514131211109876543 210

Vali d

Slot 1

Frame

Vali d

Valid Frame The Valid Frame bit determines if any of the following slots contain either valid playback data

Slot 2

Valid

Slot 3

Valid

Slot 4

Valid

Slot 5

Valid

Slot 6

Valid

Slot 7

Valid

Slot 8

Valid

Slot 9

Val id

Slot 10

Val id

Slot 11

Val id

Slot 12

Valid

Res

Codec

ID1

Codec

ID0

for the CS4205 or data for read/write operations. When ‘set’, at least one of the other AC-link slots contains valid data. If this bit is ‘clear’, the remainder of the frame is ignored.

Slot 1 Valid The Slot 1 Valid bit indicates a valid register read/write address for a primary codec.

Slot 2 Valid The Slot 2 Valid bit indicates valid register write data for a primary codec.

Slot [3:11] Valid The Slot [3:11] Valid bits indicate the validity of data in their corresponding serial data output

slots. If a bit is ‘set’, the corresponding output slot contains valid data. If a bit is ‘cleared’, the corresponding slot will be ignored.

Slot 12 Valid The Slot 12 Valid bit indicates if output Slot 12 contains valid GPIO control data.

Codec ID[1:0] The Codec ID[1:0] bits determine which codec is being accessed during the current AC-link

frame. Codec ID[1:0] = 00 indicates the primary codec is being accessed. Codec ID[1:0] = 01, 10, or 11 indicates one of three possible secondary codecs is being accessed. A Codec ID value of 01, 10, or 11 also indicates a valid read/write address and/or valid register write data for a secondary codec.

4.1.2 Command Address Port (Slot 1)

Bit 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

R/W

R/W Read/Write. When this bit is ‘set’, a read of the AC ’97 register specified by the register index

RI6 RI5 RI4 RI3 RI2 RI1 RI0 Reserved

bits will occur in the AC ’97 2.x audio codec. When the bit is ‘cleared’, a write will occur. For any read or write access to occur, the Valid Frame bit (F0) must be ‘set’ and the Codec ID[1:0] bits (F[14:15]) must match the Codec ID of the AC ’97 2.x audio codec being accessed. Additionally, for a primary codec, the Slot 1 Valid bit (F1) must be ‘set’ for a read access and both the Slot 1 Valid bit (F1) and the Slot 2 Valid bit (F2) must be ‘set’ for a write access. For a secondary codec, both the Slot 1 Valid bit (F1) and the Slot 2 Valid bit (F2) must be ‘cleared’ for read and write accesses. See Figure 14 for bit frame positions.

RI[6:0] Register Index. The RI[6:0] bits contain the 7-bit register index to the AC ’97 registers in the

CS4205. All registers are defined at word addressable boundaries. The RI0 bit must be ‘clear’ to access CS4205 registers.

20 DS489PP2

CS4205

4.1.3 Command Data Port (Slot 2)

Bit 191817161514131211109876543210

WD15 WD14 WD13 WD12 WD11 WD10 WD9 WD8 WD7 WD6 WD5 WD4 WD3 WD2 WD1 WD0 Reserved

WD[15:0] Write Data. The WD[15:0] bits contain the 16-bit value to be written to the register. If an ac-

cess is a read, this slot is ignored.

NOTE: For any write to an AC ’97 register, the write is defined to be an ‘atomic’ access. This means

that when the Slot 1 Valid bit in output Slot 0 is ‘set’, the Slot 2 Valid bit in output Slot 0 should always be ‘set’ during the same audio frame. No write access may be split across 2 frames.

4.1.4 PCM Playback Data (Slots 3-11)

Bit 191817161514131211109876543210

PD19 PD18 PD17 PD16 PD15 PD14 PD13 PD12 PD11 PD10 PD9 PD8 PD7 PD6 PD5 PD4 PD3 PD2 PD1 PD0

PD[19:0] Playback Data. The PD[19:0] bits contain the 20-bit PCM (2’s complement) playback data for

the left and right DACs, serial data ports, and/or the S/PDIF transmitter. Table 14 on page 42 lists a cross reference for each function and its respective slot. The mapping of a given slot to the DAC, serial data port, or S/PDIF transmitter is determined by the state of the ID[1:0] bits in the Extended Audio ID Register (Index 28h) and by the SM[1:0] and AMAP bits in the AC Mode Control Register (Index 5Eh).

4.1.5 GPIO Pin Control (Slot12)

Bit 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

Not Implemented GPIO4 GPIO3 GPIO2 GPIO1 GPIO0 Reserved

GPIO[4:0] GPIO Pin Control. The GPIO[4:0] bits control the CS4205 GPIO pins configured as outputs.

Write accesses using GPIO pin control bits configured at outputs will be reflected on the GPIO pin output on the next AC-link frame. Write accesses using GPIO pin control bits configured as inputs will have no effect and are ignored. If the GPOC bit in the Misc. Crystal Control Reg- ister (Index 60h) is ‘set’, the bits in output Slot 12 are ignored and GPIO pins configured as outputs are controlled through the GPIO Pin Status Register (Index 54h).

DS489PP2 21

CS4205

4.2 AC-Link Serial Data Input Frame

In the serial data input frame, data is passed on the SDATA_IN pin from the CS4205 to the AC ’97 con- troller. The data format for the input frame is very similar to the output frame. Figure 14 on page 19 illustrates the serial port timing.

The PCM capture data from the CS4205 is shifted out MSB first in the most significant 18 bits of each slot. The least significant 2 bits in each slot will be ‘cleared’. If the host requests PCM data from the AC ’97 Controller that is less than 18 bits wide, the controller should dither and round or just round (but not truncate) to the desired bit depth.

Bits that are reserved or not implemented in the CS4205 will always be returned ‘cleared’.

4.2.1 Serial Data Input Slot Tag Bits (Slot 0)

Bit 1514131211109876543210

Codec Ready

Codec Ready Codec Ready. The Codec Ready bit indicates the readiness of the CS4205 AC-link. Immedi-

Slot 1

Vali d

Slot 2

Valid

Slot 3

ately after a Cold Reset this bit will be ‘clear’. Once the CS4205 clocks and voltages are stable, this bit will be ‘set’. Until the Codec Ready bit is ‘set’, no AC-link transactions should be attempted by the controller. The Codec Ready bit does not indicate readiness of the DACs, ADCs, Vref, or any other analog function. Those must be checked in the Powerdown Con- trol/Status Register (Index 26h) by the controller before any access is made to the mixer registers. Any accesses to the CS4205 while Codec Ready is ‘clear’ are ignored.

Valid

Slot 4

Vali d

Slot 5

Valid

Slot 6

Valid

Slot 7

Vali d

Slot 8

Valid

Slot 11

Valid

Slot 12

Valid

Reserved

Slot 1 Valid The Slot 1 Valid bit indicates Slot 1 contains a valid read back address.

Slot 2 Valid The Slot 2 Valid bit indicates Slot 2 contains valid register read data.

Slot [3:8,11] Valid The Slot [3:8,11] Valid bits indicate Slot [3:8,11] contains valid capture data from the CS4205

ADCs. If a bit is ‘set’, the corresponding input slot contains valid data. If a bit is ‘cleared’, the corresponding slot will be ignored.

Slot 12 Valid The Slot 12 Valid bit indicates Slot 12 contains valid GPIO status data.

4.2.2 Status Address Port (Slot 1)

Bit 191817161514131211109876543210

Res RI6 RI5 RI4 RI3 RI2 RI1 RI0 SR3 SR4 SR5 SR6 SR7 SR8 SR9 0 SR11 0 Reserved

RI[6:0] Register Index. The RI[6:0] bits echo the AC ’97 register address when a register read has

been requested in the previous frame. The CS4205 will only echo the register index for a read access. Write accesses will not return valid data in Slot 1.

SR[3:9,11] Slot Request. If SRx is ‘set’, this indicates the CS4205 SRC does not need a new sample on

the next AC-link frame for that particular slot. If SRx is ‘clear’, the SRC indicates a new sample is needed on the following frame. If the VRA bit in the Extended Audio Status/Control Register

(Index 2Ah)

and the SR[3:9,11] bits are used to request data.

is ‘clear’, the SR[3:9,11] bits are always 0. When VRA is ‘set’, the SRC is enabled

22 DS489PP2

CS4205

4.2.3 Status Data Port (Slot 2)

Bit 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

RD15 RD14 RD13 RD12 RD11 RD10 RD9 RD8 RD7 RD6 RD5 RD4 RD3 RD2 RD1 RD0 Reserved

RD[15:0] Read Data. The RD[15:0] bits contain the register data requested by the controller from the

previous read request. All read requests will return the read address in the input Slot 1 and the register data in the input Slot 2 on the following serial data frame.

4.2.4 PCM Capture Data (Slot 3-8)

Bit 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0

CD17 CD16 CD15 CD14 CD13 CD12 CD11 CD10 CD9 CD8 CD7 CD6 CD5 CD4 CD3 CD2 CD1 CD0 0 0

CD[17:0] Capture Data. The CD [17:0] bits contain 18-bit PCM (2’s complement) capture data. The

data will only be valid when the respective slot valid bit is ‘set’ in input Slot 0. The mapping of a given slot to an ADC is determined by the state of the ID[1:0] bits in the Extended Audio ID

Register (Index 28h) and the SM[1:0] and AMAP bits in the AC Mode Control Register (Index 5Eh). The definition of each slot can be found in Table 14 on page 42.

4.2.5 GPIO Pin Status (Slot 12)

Bit 191817161514131211109876543210

0 0000000000GPIO4GPIO3GPIO2GPIO1GPIO0ResBDIIEC

GPIO[4:0] GPIO Pin Status. The GPIO[4:0] bits reflect the status of the CS4205 GPIO pins configured

as inputs. The pin status of GPIO pins configured as outputs will be reflected back on the GPIO[4:0] bits of input Slot 12 in the next frame. The output GPIO pins are controlled by the GPIO[4:0] pin control bits in output Slot 12.

BDI BIOS-Driver Interface. The BDI bit indicates that a BIOS event has occurred. This bit is a logic

OR of all bits in the BDI Status Register (Index 7Ah) ANDed with their corresponding bit in the BDI Config Register (Index 6Eh, Address 0Ch).

IEC Internal Error Condition. The IEC bit indicates that an internal error, such as an ADC over-

range or a digital data overflow has occurred. This bit is a logic OR of all bits in the IEC Status Register (Index 6Eh, Address 0Bh).

GPIO_INT GPIO Interrupt. The GPIO_INT bit indicates that a GPIO, BDI, or IEC interrupt event has oc-

curred. The occurrence of a GPIO interrupt is determined by the GPIO interrupt requirements as outlined in the GPIO Pin Wakeup Mask Register (Index 52h) description. In this case, the GPIO_INT bit is cleared by writing a ‘0’ to the bit in the GPIO Pin Status Register (Index 54h) corresponding to the GPIO pin which generated the interrupt.

The occurrence of a BDI interrupt is determined by the BDI interrupt requirements as outlined

in the BIOS-Driver Interface Control Registers (Index 6Eh, Address 0C-0Dh). In this case, the GPIO_INT bit is cleared by writing a ‘0’ to the bit in the BDI Status Register (Index 7Ah) that generated the interrupt.

GPIO

_INT

The occurrence of an IEC interrupt is determined by the IEC interrupt requirements as out-

lined in the Internal Error Condition Control/Status Registers (Index 6Eh, Address 09h - 0Bh). In this case, the GPIO_INT bit is cleared by writing a ‘0’ to the bit in the IEC Status Register (Index 6Eh, Address 0Bh) corresponding to the IEC source which generated the interrupt.

DS489PP2 23

CS4205

4.3 AC-Link Protocol Violation - Loss of SYNC

The CS4205 is designed to handle SYNC protocol violations. The following are situations where the SYNC protocol has been violated:

• The SYNC signal is not sampled high for exact-

ly 16 BIT_CLK clock cycles at the start of an audio frame.

• The SYNC signal is not sampled high on the

256th BIT_CLK clock period after the previous SYNC assertion.

• The SYNC signal goes active high before the 256th BIT_CLK clock period after the previous SYNC assertion.

Upon loss of synchronization with the controller, the CS4205 will ‘clear’ the Codec Ready bit in the serial data input frame until two valid frames are detected. During this detection period, the CS4205 will ignore all register reads and writes and will discontinue the transmission of PCM capture data. In addition, if the LOSM bit in the Misc. Crystal Control Register (Index 60h) is ‘set’ (default), the CS4205 will mute all analog outputs. If the LOSM bit is ‘clear’, the analog outputs will not be muted.

24 DS489PP2

CS4205

5. REGISTER INTERFACE

Reg Register Name D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0 Default

Reset 0 SE4 SE3 SE2 SE1 SE0 0 ID8 ID7 0 ID5 0 ID3 ID2 0 ID0

00h

Master Volume Mute 0 ML5 ML4 ML3 ML2 ML1 ML0 0 0 MR5 MR4 MR3 MR2 MR1 MR0

02h

Mono Volume Mute 0 0 0 0 0 0 0 0 0 MM5 MM4 MM3 MM2 MM1 MM0

06h

Master Tone Control 0 0 0 0 BA3 BA2 BA1 BA0 0 0 0 0 TR3 TR2 TR1 TR0

08h

PC_BEEP Volume Mute 0 0 0 0 0 0 0 0 0 0 PV3 PV2 PV1 PV0 0

0Ah

Phone Volume Mute 0 0 0 0 0 0 0 0 0 0 GN4 GN3 GN2 GN1 GN0

0Ch

Mic Volume Mute 0 0 0 0 0 0 0 0 20dB 0 GN4 GN3 GN2 GN1 GN0

0Eh

Line In Volume Mute 0 0 GL4 GL3 GL2 GL1 GL0 0 0 0 GR4 GR3 GR2 GR1 GR0

10h

CD Volume Mute 0 0 GL4 GL3 GL2 GL1 GL0 0 0 0 GR4 GR3 GR2 GR1 GR0

12h

Video Volume Mute 0 0 GL4 GL3 GL2 GL1 GL0 0 0 0 GR4 GR3 GR2 GR1 GR0

14h

Aux Volume Mute 0 0 GL4 GL3 GL2 GL1 GL0 0 0 0 GR4 GR3 GR2 GR1 GR0

16h

PCM Out Volume Mute 0 0 GL4 GL3 GL2 GL1 GL0 0 0 0 GR4 GR3 GR2 GR1 GR0

18h

Record Select 0 0 0 0 0 SL2 SL1 SL0 0 0 0 0 0 SR2 SR1 SR0

1Ah

Record Gain Mute 0 0 0 GL3 GL2 GL1 GL0 0 0 0 0 GR3 GR2 GR1 GR0

1Ch

Record Gain Mic Mute 0 0 0 0 0 0 0 0 0 0 0 GM3 GM2 GM1 GM0

1Eh

General Purpose POP ST 3D LD 0 0 MIX MS LPBK 00 0 0 0 0 0

20h

3D Control 0 0 0 0 CR3 CR2 CR1 CR0 0 0 0 0 DP3 DP2 DP1 DP0

Powerdown Ctrl/Stat EAPD 0 PR5 PR4 PR3 PR2 PR1 PR0 0 0 0 0 REF ANL DAC ADC

26h

Ext’d Audio ID ID1 ID0 0 0 0 0 AMAP 00 0 0 0VRM0 0VRA

28h

Ext’d Audio Stat/Ctrl 0 PRL 0 0 0 0 MADC 00 0 0 0VRM0 0VRA

2Ah

PCM Front DAC Rate SR15 SR14 SR13 SR12 SR11 SR10 SR9 SR8 SR7 SR6 SR5 SR4 SR3 SR2 SR1 SR0

2Ch

PCM L/R ADC Rate SR15 SR14 SR13 SR12 SR11 SR10 SR9 SR8 SR7 SR6 SR5 SR4 SR3 SR2 SR1 SR0

32h

Mic ADC Rate SR15 SR14 SR13 SR12 SR11 SR10 SR9 SR8 SR7 SR6 SR5 SR4 SR3 SR2 SR1 SR0

34h

Ext’d Modem ID ID1 ID0 0 0 0 0 0 0 0 0 0 0 0 0 0 0

3Ch

Ext’d Modem Stat/Ctrl 0 0 0 0 0 0 0 PRA 0 0 0 0 0 0 0 GPIO

3Eh

GPIO Pin Config. 0 0 0 0 0 0 0 0 0 0 0 GC4 GC3 GC2 GC1 GC0

4Ch

GPIO Pin Polarity/Type 1 1 1 1 1 1 1 1 1 1 1 GP4 GP3 GP2 GP1 GP0

4Eh

GPIO Pin Sticky 0 0 0 0 0 0 0 0 0 0 0 GS4 GS3 GS2 GS1 GS0

50h

GPIO Pin Wakeup Mask 0 0 0 0 0 0 0 0 0 0 0 GW4 GW3 GW2 GW1 GW0

52h

GPIO Pin Status 0 0 0 0 0 0 0 0 0 0 0 GI4 GI3 GI2 GI1 GI0

54h

Cirrus Logic Defined Registers:

AC Mode Control

5Eh

Misc. Crystal Control 0 0 Res DPC 0 0 Reserved 10dB

60h

S/PDIF Control

68h

Serial Port Control

6Ah

Special Feature Addr 0 0 0 0 0 0 0 0 0 0 0 0 A3 A2 A1 A0

6Ch

Special Feature Data D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

6Eh

BDI Status E15 E14 E13 E12 E11 E10 E9 E8 E7 E6 E5 E4 E3 E2 E1 E0

7Ah

Vendor ID1 F7F6F5F4F3F2F1F0S7S6S5S4S3S2 S1S0

7Ch

Vendor ID2 T7 T6 T5 T4 T3 T2 T1 T0 0 DID2 DID1 DID0 1 REV2 REV1 REV0

7Eh

DACS CAPS1 CAPS0

SPEN

Val 0 Fs L CC6 CC5 CC4 CC3 CC2 CC1 CC0 Emph Copy /Audio Pro

SDEN

0 0 0 0 0 0 0 0 SDI3 SDI2 SDI1 SDO2 SDSC SDF1 SDF0

MICS 0 0 TMM DDM

AMAP

0SM1SM0

CRST

SDOS1 SDOS0 SPDS1 SPDS0

Reserved GPOC Reserved LOSM

Table 2. Register Overview for the CS4205

25ADh

8000h

0F0Fh

0000h

8008h

8808h

0000h

8000h

0000h

000Fh

x209h

4000h

BB80h

x000h

0100h

001Fh

FFFFh

0000h

0080h

0002h

0000h

8000h

0000h

4352h

5959h

DS489PP2 25

CS4205

Reg Register Name D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0 Default

PCM Input Volume Mute 0 GL5 GL4 GL3 GL2 GL1 GL0 0 0 GR5 GR4 GR3 GR2 GR1 GR0

00h

ADC Input Volume Mute 0 GL5 GL4 GL3 GL2 GL1 GL0 0 0 GR5 GR4 GR3 GR2 GR1 GR0

01h

SDI1 Volume Mute 0 GL5 GL4 GL3 GL2 GL1 GL0 0 0 GR5 GR4 GR3 GR2 GR1 GR0

02h

SDI2 Volume Mute 0 GL5 GL4 GL3 GL2 GL1 GL0 0 0 GR5 GR4 GR3 GR2 GR1 GR0

03h

SDI3 Volume Mute 0 GL5 GL4 GL3 GL2 GL1 GL0 0 0 GR5 GR4 GR3 GR2 GR1 GR0

04h

ZV Volume Mute 0 GL5 GL4 GL3 GL2 GL1 GL0 0 0 GR5 GR4 GR3 GR2 GR1 GR0

05h

SDOUT Volume Mute 0 GL5 GL4 GL3 GL2 GL1 GL0 0 0 GR5 GR4 GR3 GR2 GR1 GR0

06h

SDO2 Volume Mute 0 GL5 GL4 GL3 GL2 GL1 GL0 0 0 GR5 GR4 GR3 GR2 GR1 GR0

07h

SP Engine Control Res SDI1M SRZC1 SRZC0 LPFS1 LPFS0 HPFS1 HPFS0 GL3 GL2 GL1 GL0 GR3 GR2 GR1 GR0

08h

IEC Config EROF ELOF MROF MLOF 0 AMOR AROR ALOR 0 0 0 0 0 0 0 0

09h

IEC Wakeup EROF ELOF MROF MLOF 0 AMOR AROR ALOR 0 0 0 0 0 0 0 0

0Ah

IEC Status EROF ELOF MROF MLOF 0 AMOR AROR ALOR 0 0 0 0 0 0 0 0

0Bh

BDI Config E15 E14 E13 E12 E11 E10 E9 E8 E7 E6 E5 E4 E3 E2 E1 E0

0Ch

BDI Wakeup E15 E14 E13 E12 E11 E10 E9 E8 E7 E6 E5 E4 E3 E2 E1 E0

0Dh

ZV Port Ctrl/Stat 1 ZVEN LOCK 0 Ph24 Ph23 Ph22 Ph21 Ph20 Ph19 Ph18 Ph17 Ph16 Ph15 Ph14 Ph13 Ph12

0Eh

ZV Port Ctrl/Stat 2 Reserved Ph11 Ph10 Ph9 Ph8 Ph7 Ph6 Ph5 Ph4 Ph3 Ph2 Ph1 Ph0

0Fh

Table 3. Indirectly Addressed Register Overview

8000h

1800h

0000h

26 DS489PP2

CS4205

5.1 Reset Register (Index 00h)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

0 SE4 SE3 SE2 SE1 SE0 0 ID8 ID7 0 ID5 0 ID3 ID2 0 ID0

SE[4:0] SRS 3D Stereo Enhancement. SE[4:0] = 01001, indicating this feature is present.

ID8 18-bit ADC Resolution. The ID8 bit is ‘set’, indicating this feature is present.

ID7 20-bit DAC resolution. The ID7 bit is ‘set’, indicating this feature is present.

ID5 Loudness. The ID5 bit is ‘set’, indicating this feature is present.

ID3 Simulated Stereo. The ID3 bit is ‘set’, indicating this feature is present.

ID2 Bass & Treble. The ID2 bit is ‘set’, indicating this feature is present.

ID0 Dedicated Mic PCM in Channel. The ID0 bit is ‘set’, indicating this feature is present.

Default

Any write to this register causes a Register Reset of the audio control (Index 00h - 3Ah) and Cirrus Logic defined (Index 5Ah - 7Ah) registers. A read from this register returns configuration information about the CS4205.

Table 12 on page 37h. The data in this register is read-only data.

5.2 Master Volume Register (Index 02h)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

Mute 0 ML5

Mute Master Mute. Setting this bit mutes the LINE_OUT_L/R output signals.

ML[5:0] Master Volume Left. These bits control the left master output volume. Each step corresponds

MR[5:0] Master Volume Right. These bits control the right master output volume. Each step corre-

Default 8000h. This value corresponds to 0 dB attenuation and Mute ‘set’.

ML4 ML3 ML2 ML1 ML0 0 0 MR5 MR4MR3MR2MR1MR0

to 1.5 dB gain adjustment, with a total available range from 0 dB to -46.5 dB attenuation. Setting the ML5 ML[5:0] will read back 011111 when ML5

sponds to 1.5 dB gain adjustment, with a total available range from 0 dB to -46.5 dB attenuation. Setting the MR5 a ‘1’ state. MR[5:0] will read back 011111 when MR5 details.

bit sets the left channel attenuation to -46.5 dB by forcing ML[4:0] to a ‘1’ state.

has been ‘set’. See Table 4 for further details.

bit sets the right channel attenuation to -46.5 dB by forcing MR[4:0] to

has been ‘set’. See Table 4 for further

Mx5..Mx0

Write

000000 000000 0 dB

000001 000001 -1.5 dB

……...

011111 011111 -46.5 dB

100000 011111 -46.5 dB

... ... ...

111111 0 11111 - 46 . 5 d B

Mx5..Mx0

Read

Gain

Level

Table 4. Analog Mixer Output Attenuation

DS489PP2 27

CS4205

5.3 Mono Volume Register (Index 06h)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

Mute000000000MM5

Mute Mono Mute. Setting this bit mutes the MONO_OUT output signal.

MM[5:0] Mono Volume Control. The MM[5:0] bits control the mono output volume. Each step corre-

sponds to 1.5 dB gain adjustment, with a total available range from 0 dB to -46.5 dB attenuation. Setting the MM5 state. MM[5:0] will read back 011111 when MM5 further attenuation levels.

Default 8000h. This value corresponds to 0 dB attenuation and Mute ‘set’.

bit sets the mono attenuation to -46.5 dB by forcing MM[4:0] to a ‘1’

has been ‘set’. See Table 4 on page 27 for

5.4 Master Tone Control Register (Index 08h)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

0 0 0 0 BA3 BA2 BA1 BA0 0 0 0 0 TR3 TR2 TR1 TR0

MM4 MM3 MM2 MM1 MM0

BA[3:0] Bass Control. The BA[3:0] bits are used to control the bass gain in the effects engine. Each

step corresponds to 1.5 dB gain adjustment, with a total available range from +10.5 dB to

-10.5 dB gain. See Table 5 for further details. The center frequency from which the gain is measured defaults to 100 Hz for bass, and may be changed using the LPFS[1:0] bits in the Signal Processing Engine Control Register (Index 6Eh, Address 08h).

TR[3:0] Treble Control. The TR[3:0] bits are used to control the treble gain in the effects engine. Each

step corresponds to 1.5 dB gain adjustment, with a total available range from +10.5 dB to

-10.5 dB gain. See Table 5 for further details. The center frequency from which the gain is measured defaults to 10 kHz for treble, and may be changed using the HPFS[1:0] bits in the Signal Processing Engine Control Register (Index 6Eh, Address 08h).

Default 0F0Fh. This value corresponds to bypass of bass and treble gain.

TR3..TR0

BA3..BA0

0000 +10.5 dB

0001 +9 dB

… ...

0110 +1.5 dB

0111 0 d B

1000 -1.5 dB

... ...

1101 -9 dB

1110 -10.5 dB

1111 bypass

Gain

Level

Table 5. Tone Control Values

28 DS489PP2

CS4205

5.5 PC_BEEP Volume Register (Index 0Ah)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

Mute 0 0 0 0 0 0 0 0 0 0 PV3 PV2 PV1 PV0 0

Mute PC_BEEP Mute. Setting this bit mutes the PC_BEEP input signal.

PV[3:0] PC_BEEP Volume Control. The PV[3:0] bits control the gain levels of the PC_BEEP input

source to the Input Mixer. Each step corresponds to 3 dB gain adjustment, with 0000 = 0 dB. The total range is 0 dB to -45 dB attenuation.

Default 0000h. This value corresponds to 0 dB attenuation and Mute ‘clear’.

This register has no effect on the PC_BEEP volume during RESET#.

5.6 Phone Volume Register (Index 0Ch)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

Mute0000000000GN4GN3GN2GN1GN0

Mute Phone Mute. Setting this bit mutes the Phone input signal.

GN[5:0] Phone Volume Control. The GN[4:0] bits control the gain level of the Phone input source to

the Input Mixer. Each step corresponds to 1.5 dB gain adjustment, with 01000 = 0 dB. The total range is +12 dB to -34.5 dB attenuation. See Table 7 on page 31 for further attenuation levels.

Default 8008h. This value corresponds to 0 dB attenuation and Mute ‘set’.

DS489PP2 29

CS4205

5.7 Microphone Volume Register (Index 0Eh)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

Mute0000000020dB0GN4GN3GN2GN1GN0

Mute Microphone Mute. Setting this bit mutes the MIC1 or MIC2 signal. The selection of the MIC1

or MIC2 input pin is controlled by the MS bit in the General Purpose Register (Index 20h).

20dB Microphone 20 dB Boost. When ‘set’, the 20dB bit enables the +20 dB microphone boost

block. In combination with the 10dB boost bit in the Misc. Crystal Control Register (Index 60h) this bit allows for variable boost from 0 dB to +30 dB in steps of 10 dB. Table 6 summarizes this behavior.

GN[4:0] Microphone Volume Control. The GN[4:0] bits are used to control the gain level of the Micro-

phone input source to the Input Mixer. Each step corresponds to 1.5 dB gain adjustment, with 01000 = 0 dB. The total range is +12 dB to -34.5 dB gain. See Table 6 for further details.

Default 8008h. This value corresponds to 0 dB gain and Mute ‘set’.

Gain Level

GN4 - GN0

00000 +12.0 dB +22.0 dB +32.0 dB +42.0 dB

00001 +10.5 dB +20.5 dB +30.5 dB +40.5 dB

……... ... ...

00111 +1.5 dB +11.5 dB +21.5 dB +31.5 dB

01000 0.0 dB +10.0 dB +20.0 dB +30.0 dB

01001 -1.5 dB +8.5 dB +18.5 dB +28.5 dB

……... ... ...

11111 -34.5 dB - 2 4 .5 d B -14.5 dB -4 .5 d B

10dB = 0,

20dB = 0

10dB = 1,

20dB = 0

10dB = 0,

20dB = 1

10dB = 1,

20dB = 1

Table 6. Microphone Input Gain Values

30 DS489PP2

CS4205

5.8 Analog Mixer Input Gain Registers (Index 10h - 18h)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

Mute 0 0 GL4 GL3 GL2 GL1 GL0 0 0 0 GR4 GR3 GR2 GR1 GR0

Mute Stereo Input Mute. Setting this bit mutes the respective input signal, both right and left inputs.

GL[4:0] Left Volume Control. The GL[4:0] bits are used to control the gain level of the left analog input

source to the Input Mixer. Each step corresponds to 1.5 dB gain adjustment, with 01000 = 0 dB. The total range is +12 dB to -34.5 dB gain. See Table 7 for further details.

GR[4:0] Right Volume Control. The GR[4:0] bits are used to control the gain level of the right analog

input source to the Input Mixer. Each step corresponds to 1.5 dB gain adjustment, with 01000 = 0 dB. The total range is +12 dB to -34.5 dB gain. See Table 7 for further details.

Default 8808h. This value corresponds to 0 dB gain and Mute ‘set’.

The Analog Mixer Input Gain Registers are listed in Table 8.

Gx4 - Gx0 Gain Level

00000 +12.0 dB

00001 +10.5 dB

……

00111 +1.5 dB

01000 0.0 dB

01001 -1.5 dB

……

11111 -34.5 dB

Table 7. Analog Mixer Input Gain Values

10h Line In Volume

12h CD Volume

14h Video Volume

16h Aux Volume

18h PCM Out Volume

Table 8. Analog Mixer Input Gain Register Index

DS489PP2 31

CS4205

5.9 Input Mux Select Register (Index 1Ah)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

00000SL2SL1SL000000SR2SR1SR0

SL[2:0] Left Channel Source. The SL[2:0] bits select the left channel source to pass to the ADCs for

recording. See Table 9 for possible values.

SR[2:0] Right Channel Source. The SR[2:0] bits select the right channel source to pass to the ADCs

for recording. See Table 9 for possible values.

Default 0000h. This value selects the Mic input for both channels.

Sx2 - Sx0 Record Source

000 Mic

001 CD Input

010 Video Input

011 Aux Input

100 Line Input

101 Stereo Mix

110 Mono Mix

111 Phone Input

Table 9. Input Mux Selection

32 DS489PP2

CS4205

5.10 Record Gain Register (Index 1Ch)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

Mute 0 0 0 GL3 GL2 GL1 GL0 0 0 0 0 GR3 GR2 GR1 GR0

Mute Record Gain Mute. Setting this bit mutes the input to the L/R ADCs.

GL[3:0] Left ADC Gain. The GL[3:0] bits control the input gain on the left channel of the analog

source, applied after the input mux and before the ADCs. Each step corresponds to 1.5 dB gain adjustment, with 0000 = 0 dB. The total range is 0 dB to +22.5 dB gain. See Table 10 for further details.

GR[3:0] Right ADC Gain. The GR[3:0] bits control the input gain on the right channel of the analog

source, applied after the input mux and before the ADCs. Each step corresponds to 1.5 dB gain adjustment, with 0000 = 0 dB. The total range is 0 dB to +22.5 dB gain.See Table 10 for further details.

Default 8000h. This value corresponds to 0 dB gain and Mute ‘set’.

Gx4 - Gx0 Gain Level

1111 +22.5 dB

……

0001 +1.5 dB

0000 0 dB

Table 10. Record Gain Values

5.11 Record Gain Mic Register (Index 1Eh)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

Mute00000000000GM3GM2GM1GM0

Mute Mic Record Gain Mute. When ‘set’, mutes the input to the microphone ADC.

GM[3:0] Mic ADC gain. The GM[3:0] bits control the input gain on the microphone source. The gain is

applied after the input mux and before the ADC. Each step corresponds to 1.5 dB gain adjustment, with 0000 = 0 dB. The total range is 0 dB to +22.5 dB gain. See Table 10 for further details.

Default 8000h. This value corresponds to 0 dB gain and Mute ‘set’.

DS489PP2 33

CS4205

5.12 General Purpose Register (Index 20h)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

POPST3DLD00MIXMSLPBK0000000

POP PCM Out Path. When ‘clear’, the PCM out path is mixed pre 3D. When ‘set’, the PCM out path

is mixed post 3D.

ST Stereo Enhancement Enable. When ‘set’, the ST bit enables the simulated stereo enhance-

ment via the SRS Mono algorithm.

3D 3D Enable. When ‘set’, the 3D bit enables the 3D stereo enhancement via the SRS Stereo

algorithm.

LD Loudness Enable. When ‘set’, the LD bit enables the loudness or “bass boost” via the equal-

izer algorithm.

MIX Mono Output Path. This bit controls the source of the mono output driver. When ‘clear’, the

output of the stereo-to-mono mixer is sent to the mono output. When ‘set’, the output of the microphone boost stage is sent to the mono output. The source of the stereo-to-mono mixer is controlled by the TMM bit in the AC Mode Control Register (Index 5Eh). The source of the microphone boost stage is controlled by the MS bit in the General Purpose Register (Index 20h).

MS Microphone Select. The MS bit determines which of the two Mic inputs are passed to the mix-

er. When ‘set’, the MIC2 input is selected. When ‘clear’, the MIC1 input is selected.

LPBK Loopback Enable. When ‘set’, the LPBK bit enables the ADC/DAC Loopback Mode. This bit

routes the output of the ADCs to the input of the DACs without involving the AC-link.

Default 0000h

5.13 3D Control Register (Index 22h)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

0 0 0 0 CR3 CR2 CR1 CR0 0 0 0 0 DP3 DP2 DP1 DP0

CR[3:0] Center Control. The CR[3:0] bits control the amount of the sum signal, (L+R), that is added

to the final left and right digital signals.

DP[3:0] Depth Control. The DP[3:0] bits control the amount of processed difference signal, (L-R)

that is added to the final left and right digital signals.

Default 0000h. This value corresponds to -22.5 dB center and depth attenuation.

This register is used to control the center and depth of the SRS stereo enhancement function in the effects engine. Each step corresponds to 1.5 dB gain adjustment, with a total available range from 0 dB to -22.5 dB attenuation. The recommended starting point for listening is -12 dB center attenuation and -4.5 dB depth attenuation, a register value of 070Ch.

34 DS489PP2

CS4205

5.14 Powerdown Control/Status Register (Index 26h)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

EAPD 0 PR5 PR4 PR3 PR2 PR1 PR0 0 0 0 0 REF ANL DAC ADC

EAPD External Amplifier Power Down. The EAPD pin follows this bit and is generally used to power

down external amplifiers. The EAPD bit is mutually exclusive with the SDSC bit in the Serial

Port Control Register (Index 6Ah). The SDSC bit must be ‘clear’ before the EAPD bit may be ‘set’.

If the SDSC bit is ‘set’, EAPD is a read-only bit and always returns ‘0’.

PR5 Internal Clock Disable. When ‘set’, the internal master clock is disabled (BIT_CLK running).

The only way to recover from setting this bit is through a Cold Reset (driving the RESET# signal active).

PR4 AC-link Powerdown. When ‘set’, the AC-link is powered down (BIT_CLK off). The AC-link can

be restarted through a Warm Reset using the SYNC signal, or a Cold Reset using the RESET# signal (primary audio codec only).

PR3 Analog Mixer Powerdown (Vref off). When ‘set’, the analog mixer and voltage reference are

powered down. When clearing this bit, the ANL, ADC, and DAC bits should be checked before writing any mixer registers.

PR2 Analog Mixer Powerdown (Vref on). When ‘set’, the analog mixer is powered down (the volt-

age reference is still active). When clearing this bit, the ANL bit should be checked before writing any mixer registers.

PR1 Front DACs Powerdown. When ‘set’, the DACs are powered down. When clearing this bit, the

DAC bit should be checked before sending any data to the DACs.

PR0 L/R ADCs and Input Mux Powerdown. When ‘set’, the ADCs and the ADC input muxes are

powered down. When clearing this bit, no valid data will be sent down the AC-link until the ADC bit goes high.

REF Voltage Reference Ready Status. When ‘set’, the REF bit indicates the voltage reference is

at a nominal level.

ANL Analog Ready Status. When ‘set’, the analog output mixer, input multiplexer, and volume con-

trols are ready. When ‘clear’, no volume control registers should be written.

DAC Front DAC Ready Status. When ‘set’, the DACs are ready to receive data across the AC-link.

When ‘clear’, the DACs will not accept any valid data.

ADC L/R ADCs Ready Status. When ‘set’, the ADCs are ready to send data across the AC-link.

When ‘clear’, no data will be sent to the controller.

Default 0000h. This value indicates all blocks are powered on. The lower four bits will change as the

CS4205 finishes an initialization and calibration sequence.

The PR[5:0] and the EAPD bits are powerdown control for different sections of the CS4205 as well as external amplifiers. The REF, ANL, DAC, and ADC bits are read-only status bits which, when ‘set’, indicate that a particular section of the CS4205 is ready. After the controller receives the Codec Ready bit in input Slot 0, these status bits must be checked before writing to any mixer registers. See Section 10, Power Management, for more information on the powerdown functions.

DS489PP2 35

CS4205

5.15 Extended Audio ID Register (Index 28h)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

ID1ID00000AMAP00000VRM00VRA

ID[1:0] Codec Configuration ID. These bits indicate the current codec configuration. When

ID[1:0] = 00, the CS4205 is the primary audio codec. When ID[1:0] = 01, 10, or 11, the CS4205 is a secondary audio codec. The state of the ID[1:0] bits is determined at power-up from the ID[1:0]# pins and the current clocking scheme, see Table 27 on page 63.

AMAP Audio Slot Mapping. The AMAP bit indicates whether the optional AC ’97 2.1 compliant

AC-link slot to audio DAC mapping is supported. This bit is a shadow of the AMAP bit in the AC Mode Control Register (Index 5Eh). The PCM playback and capture slots are mapped according to Table 14 on page 42.

VRM Variable Rate Mic Audio. The VRM bit indicates whether variable rate Mic audio is supported.

This bit always returns ‘1’, indicating that variable rate mic audio is available.

VRA Variable Rate PCM Audio. The VRA bit indicates whether variable rate PCM audio is support-

ed. This bit always returns ‘1’, indicating that variable rate PCM audio is available.

Default x209h. The Extended Audio ID Register (Index 28h) is a read-only register.

5.16 Extended Audio Status/Control Register (Index 2Ah)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

0 PRL 0 0 0 0 MADC 0 0 0 0 0 VRM 0 0 VRA

PRL Mic ADC Powerdown. When ‘set’, the PRL bit powers down the dedicated Mic ADC and cor-

responding input gain stage. To use the dedicated Mic ADC, clear the PRL bit first.

MADC Mic ADC Ready Status. When ‘set’, the MADC bit indicates the dedicated Mic ADC is ready

to transmit data.

VRM Enable Variable Rate Mic Audio. When ‘set’, the VRM bit allows access to the Mic ADC Rate

Register (Index 34h). This bit must be ‘set’ in order to use variable mic capture rates. The VRM bit also serves as a powerdown for the Mic ADC SRC block. Clearing VRM will reset the Mic ADC Rate Register (Index 34h) to its default value and the SRC data path is flushed.

VRA Enable Variable Rate Audio. When ‘set’, the VRA bit allows access to the PCM Front DAC

Rate Register (Index 2Ch) and the PCM L/R ADC Rate Register (Index 32h). This bit must

be ‘set’ in order to use variable PCM playback or capture rates. The VRA bit also serves as a powerdown for the DAC and ADC SRC blocks. Clearing VRA will reset the PCM Front DAC Rate Register (Index 2Ch) and the PCM L/R ADC Rate Register (Index 32h) to their default values. The SRC data path is flushed and the Slot Request bits for the currently active DAC slots will be fixed at ‘0’.

Default 4000h

36 DS489PP2

CS4205

5.17 Audio Sample Rate Control Registers (Index 2Ch - 34h)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

SR15 SR14 SR13 SR12 SR11 SR10 SR9 SR8 SR7 SR6 SR5 SR4 SR3 SR2 SR1 SR0

SR[15:0] Sample Rate Select. The Audio Sample Rate Control Registers (Index 2Ch - 34h) control

playback and capture sample rates. The PCM Front DAC Rate Register (Index 2Ch) controls the Front Left and Front Right DAC sample rates. The PCM L/R ADC Rate Register

(Index 32h) controls the Left and Right ADC sample rates. The Mic ADC Rate Register (Index 34h) controls the Microphone ADC sample rate.There are ten sample rates directly supported

by this register, shown in Table 12. Any value written to this register not contained inTable 12 is not directly supported and will be decoded according to the ranges indicated in the table. The range boundaries have been chosen so that only bits SR[15:11] of each register will have to be considered. All register read transactions will reflect the actual value stored (column 2 in Table 12) and not the one attempted to be written.

Default BB80h. This value corresponds to 48 kHz sample rate.

Writes to the PCM Front DAC Rate Register (Index 2Ch) and the PCM L/R ADC Rate Register (Index 32h) are only available in Variable Rate PCM Audio mode when the VRA bit in the Extended Audio Status/Control Register (Index 2Ah) is ‘set’. If VRA = 0, writes to the register are ignored and the register will always read BB80h. Writes to the Mic ADC Rate Register (Index 34h) are only available in Variable Rate Mic Audio mode when the VRM bit in the Extended Audio Status/Control Register (Index 2Ah) is ‘set’. If VRM = 0, writes to the register are ignored and the register will always read BB80h. Table 11 lists the SRC registers and their corresponding SRC enable bit.

Index

2Ch PCM Front DAC Rate VRA

32h PCM L/R ADC Rate VRA

34h Mic ADC Rate VRM

Table 11. Audio Sample Rate Control Register Index

Sample Rate

(Hz)

8,000 1F40 0000 - 1FFF 00000 - 00011

9,600 2580 2000 - 27FF 00100 - 00100

11,025 2B11 2800 - 2FFF 00101 - 00101

13,714 3592 3000 - 37FF 00110 - 00110

16,000 3E80 3800 - 47FF 00111 - 01000

22,050 5622 4800 - 57FF 01001 - 01010

24,000 5DC0 5800 - 6FFF 01011 - 01101

32,000 7D00 7000 - 8FFF 01110 - 10001

44,100 AC44 9000 - AFFF 10010 - 10101

48,000 BB80 B000 - FFFF 10110 - 11111

SR[15:0], register

content (hex value)

SRC

SR[15:0], decode

range (hex value)

SRC Enable Bit

(Index 2Ah)

SR[15:11], decode

range (bin value)

Table 12. Directly Supported SRC Sample Rates for the CS4205

DS489PP2 37

CS4205

5.18 Extended Modem ID Register (Index 3Ch)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

ID1ID000000000000000

ID[1:0] Codec Configuration ID. Primary is 00; Secondary is 01,10,or 11. This is a reflection of the

ID[1:0]# configuration pins. The state of the ID[1:0] bits is determined at power-up from the Codec ID[1:0]# pins and the current clocking scheme, see Table 27 on page 63.

Default x000h. This value indicates no supported modem functions.

The Extended Modem ID Register (Index 3Ch) is a read/write register that identifies the CS4205 modem capabilities. Writing any value to this location issues a reset to modem registers (Index 3Ch-54h), including GPIO registers (Index 4Ch - 54h). Audio registers are not reset by a write to this location.

5.19 Extended Modem Status/Control Register (Index 3Eh)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

0000000PRA0000000GPIO

PRA GPIO Powerdown. When ‘set’, the PRA bit powers down the GPIO subsystem. When the

GPIO section is powered down, all outputs must be tri-stated and input Slot 12 should be marked invalid when the AC-link is active. To use any GPIO functionality, including Internal Error Signaling, PRA must be cleared first.

GPIO GPIO. When ‘set’, the GPIO bit indicates the GPIO subsystem is ready for use. When ‘set’,

input Slot 12 will also be marked valid.

Default 0100h

5.20 GPIO Pin Configuration Register (Index 4Ch)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

00000000000GC4GC3GC2GC1GC0

GC[4:0] GPIO Pin Configuration. When ‘set’, the GC[4:0] bits define the corresponding GPIO pin as

an input. When ‘clear’, the corresponding GPIO pin is defined as an output. When the SDEN bit in the Serial Port Control Register (Index 6Ah) is ‘set’, the GC[1:0] bits are read-only bits and always return ‘0’. When SDEN is ‘clear’, the GC[1:0] bits function normally. Likewise, GC2 depends on SDI1, GC3 depends on SDI2, and GC4 depends on SDI3. The SDI[1:3] bits are located in the Serial Port Control Register (Index 6Ah).

Default 001Fh. This value corresponds to all GPIO pins configured as inputs.

After a Cold Reset or a modem Register Reset (see Extended Modem ID Register (Index 3Ch)), all GPIO pins are configured as inputs. The upper 11 bits of this register always return ‘0’.

38 DS489PP2

CS4205

5.21 GPIO Pin Polarity/Type Configuration Register (Index 4Eh)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

11111111111GP4GP3GP2GP1GP0

GP[4:0] GPIO Pin Configuration. This register defines the GPIO input polarity (0 = Active Low,

1 = Active High) when a GPIO pin is configured as an input. The GP[4:0] bits define the GPIO output type (0 = CMOS, 1 = OPEN-DRAIN) when a GPIO pin is configured as an output. The GC[4:0] bits in the GPIO Pin Configuration Register (Index 4Ch) define the GPIO pins as inputs or outputs. See Table 13 for the various GPIO configurations.

Default FFFFh

After a Cold Reset or a modem Register Reset this register defaults to all 1’s. The upper 11 bits of this register always return ‘1’.

GCx GPx Function Configuration

0 0 Output CMOS Drive

0 1 Output Open Drain

1 0 Input Active Low

1 1 Input Active High (default)

Table 13. GPIO Input/Output Configurations

5.22 GPIO Pin Sticky Register (Index 50h)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

00000000000GS4GS3GS2GS1GS0

GS[4:0] GPIO Pin Sticky. This register defines the GPIO input type (0 = not sticky, 1 = sticky) when a

GPIO pin is configured as an input. The GPIO pin status of an input configured as “sticky” is ‘cleared’ by writing a ‘0’ to the corresponding bit of the GPIO Pin Status Register (Index 54h), and by reset.

Default 0000h

After a Cold Reset or a modem Register Reset this register defaults to all 0’s, specifying “non-sticky”. “Sticky” is defined as edge sensitive, “non-sticky” as level sensitive. The upper 11 bits of this register always return ‘0’.

DS489PP2 39

CS4205

5.23 GPIO Pin Wakeup Mask Register (Index 52h)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

00000000000GW4GW3GW2GW1GW0

GW[4:0] GPIO Pin Wakeup. This register provides a mask for determining if an input GPIO change will

generate a wakeup event (0 = No, 1 = yes). When the AC-link is powered up, a wakeup event will be communicated through the assertion of GPIO_INT = 1 in input Slot 12. When the AC-link is powered down (Powerdown Control/Status Register (Index 26h) bit PR4 = 1 for primary codecs), a wakeup event will be communicated through a ‘0’ to ‘1’ transition on SDATA_IN.

Default 0000h

GPIO bits which have been programmed as inputs, “sticky”, and “wakeup”, upon transition either (high-to-low) or (low-to-high) depending on pin polarity, will cause an AC-link wakeup if and only if the AC-link was powered down. Once the controller has re-established communication with the CS4205 following a Warm Reset, it will continue to signal the wakeup event through the GPIO_INT bit of input Slot 12 until the AC ’97 controller clears the interrupt-causing bit in the GPIO Pin Status Register (Index 54h); or the “wakeup”, config, or “sticky” status of that GPIO pin changes.

After a Cold Reset or a modem Register Reset (see Extended Modem ID Register (Index 3Ch)) this register defaults to all 0’s, specifying no wakeup event. The upper 11 bits of this register always return ‘0’.

5.24 GPIO Pin Status Register (Index 54h)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

00000000000GI4GI3GI2GI1GI0

GI[4:0] GPIO Pin Status. This register reflects the state of all GPIO pin inputs and outputs. These

values are also reflected in Slot 12 of every SDATA_IN frame. GPIO inputs configured as “sticky” are ‘cleared’ by writing a ‘0’ to the corresponding bit of this register. The GPIO_INT bit in input Slot 12 is ‘cleared’ by clearing all interrupt-causing bits in this register.

Default 0000h

GPIO pins which have been programmed as inputs and “sticky”, upon transition either high-to-low or low-to-high depending on pin polarity, will cause the individual GI bit to be ‘set’, and remain ‘set’ until ‘cleared’. GPIO pins which have been programmed as outputs are controlled either through output Slot 12 or through this register, depending on the state of the GPOC bit in the Misc. Crystal Control Register (Index 60h). If the GPOC bit is ‘cleared’, the GI bits in this register are read-only and reflect the status of the corresponding GPIO output pin ‘set’ through output slot 12. If the GPOC bit is ‘set’, the GI bits in this register are read/write bits and control the corresponding GPIO output pins.

The default value is always the state of the GPIO pin. The upper 11 bits of this register should be forced to zero in this register and input Slot 12.

40 DS489PP2

CS4205

5.25 AC Mode Control Register (Index 5Eh)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

DACS CAPS1 CAPS0 MICS 0 0 TMM DDM AMAP 0 SM1

DACS DAC Source Select. The DACS bit controls the source of data routed to the DACs. If this bit

is ‘clear’, the DACs will receive data from the DAC slots, see Table 14 for actual slots used. If this bit is ‘set’, the DACs will receive data from the CS4205 digital effects engine.

CAPS[1:0] L/R Capture Source Select. The CAPS[1:0] bits control the source of data routed to the L/R

ADC slots, see Table 14 for actual slots used. Table 15 lists the available capture options. If a reserved source is selected, the capture slot data will be fixed to ‘0’.

MICS Microphone Capture Source Select. The MICS bit selects the source of data routed to the Mic

ADC slot. If this bit is ‘clear’, the Mic capture slot will receive data from the Mic ADC. If this bit is ‘set’, the Mic capture slot will receive the left channel data from the first serial data input port.

TMM True Mono Mode. The TMM bit controls the source of the stereo-to-mono mixer that feeds

into the mono out select mux. If this bit is ‘clear’, the output of the stereo input mixer is sent to the stereo-to-mono mixer. If this bit is ‘set’, the output of the DAC direct mode mux is sent to the stereo-to-mono mixer. This allows a true mono mix that includes the PC Beep and Phone inputs and also works during DAC direct mode.

SDOS1 SDOS0 SPDS1 SPDS0

SM0

DDM DAC Direct Mode. The DDM bit controls the source of the line output drivers. When this bit is

‘clear’, the CS4205 stereo output mixer drives the line output. When this bit is ‘set’, the CS4205 audio DACs (DAC1 and DAC2) directly drive the line output.

AMAP Audio Slot Mapping. The AMAP bit controls whether the CS4205 responds to the Codec ID

based slot mapping as outlined in the AC ’97 2.1 Specification. This bit is shadowed in the Extended Audio ID Register (Index 28h). Refer to Table 14 for the slot mapping configurations.

SM[1:0] Slot Map. The SM[1:0] bits define the Slot Mapping for the CS4205 when the AMAP bit is

‘cleared’. Refer to Table 14 for the slot mapping configurations.

SDOS[1:0] Serial Data Output Source Select. The SDOS[1:0] bits control the source of data routed to the

CS4205 first serial data output port. Table 15 on page 42 lists the available source options. If a reserved source is selected, the serial output data will be fixed to ‘0’.

SPDS[1:0] S/PDIF Transmitter Source Select. The SPDS[1:0] bits control the source of data routed to

the S/PDIF transmitter. Table 15 on page 42 lists the available source options.

Default 0080h

See Section 3, Digital Signal Paths, for more information on using the bits in this register to create various digital signal path options.

DS489PP2 41

CS4205

Codec ID Slot Map

Slot

Assignment

Mode

AMAP Mode 000XX 1 347869346

AMAP Mode 101XX 1 347869346

AMAP Mode 210XX 1 78691011786

AMAP Mode 311XX 1 69781011786

Slot Map Mode 0XX00 0 347869346

Slot Map Mode 1XX01 0 78691011786

Slot Map Mode 2XX10 0 69781011786

Slot Map Mode 3XX11 0 51178695116

ID1 ID0 SM1 SM0

Table 14. Slot Mapping for the CS4205

CAPS[1:0], SDOS[1:0],

SPDS[1:0]

00 L/R ADCs SDOUT slots DAC slots

01 reserved reserved SDO2 slots

10 Digital Mixer Digital Mixer Digital Mixer

11 Digital Effects Digital Effects Digital Effects

AMAP

L/R Capture

Source

(CAPS[1:0])

DAC

SPDIF for

SPDS = 00

LRLRLRLRM

Serial Data

Output Source

(SDOS[1:0])

Slot Assignments

SDOUT

Transmitter

(SPDS[1:0])

SPDIF for

SPDS = 01

S/PDIF

Source

SDO2

ADC

Table 15. Digital Signal Source Selects

42 DS489PP2

CS4205

5.26 Misc. Crystal Control Register (Index 60h)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

0 0 0 DPC 0 0 Reserved 10dB CRST Reserved GPOC Reserved LOSM

DPC DAC Phase Control. This bit controls the phase of the PCM stream sent to the DACs (after

SRC). When ‘cleared’ the phase of the signal will remain unchanged. When this bit is ‘set’, each PCM sample will be inverted before being sent to the DACs.

10dB Microphone 10 dB Boost. When ‘set’, the 10dB bit enables an additional boost of 10 dB on

the selected microphone input. In combination with the 20dB boost bit in the Microphone Vol- ume Register (Index 0Eh) this bit allows for variable boost from 0 dB to +30 dB in steps of 10 dB.

CRST Force Cold Reset. The CRST bit is used as an override to the New Warm Reset behavior

defined during PR4 powerdown. If this bit is ‘set’, an active RESET# signal will force a Cold Reset to the CS4205 during a PR4 powerdown.

GPOC General Purpose Output Control. The GPOC bit specifies the mechanism by which the status

of a General Purpose Output pin can be controlled. If this bit is ‘cleared’, the GPO status is controlled through the standard AC ’97 method of setting the appropriate bits in output Slot 12. If this bit is ‘set’, the GPO status is controlled through the GPIO Pin Status Register (Index 54h).

LOSM Loss of SYNC Mute Enable. The LOSM bit controls the loss of SYNC mute function. If this bit

is ‘set’, the CS4205 will mute all analog outputs for the duration of loss of SYNC. If this bit is ‘cleared’, the mixer will continue to function normally during loss of SYNC. The CS4205 expects to sample SYNC ‘high’ for 16 consecutive BIT_CLK periods and then ‘low’ for 240 consecutive BIT_CLK periods, otherwise loss of SYNC becomes true.

Default 0002h

DS489PP2 43

CS4205

5.27 S/PDIF Control Register (Index 68h)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

SPEN Val 0 Fs L CC6 CC5 CC4 CC3 CC2 CC1 CC0 Emph Copy /Audio Pro

SPEN S/PDIF Enable. The SPEN bit enables S/PDIF data transmission on the SPDO/SDO2 pin.

The SPEN bit routes the left and right channel data from the AC ’97 controller, the digital mixer, or the digital effects engine to the S/PDIF transmitter block. The actual data routed to the S/PDIF block is controlled through the SPDS[1:0]/AMAP/SM[1:0] configuration in the AC

Mode Control Register (Index 5Eh). This bit can only be ‘set’ if the SDO2 bit in the Serial Port Control Register (Index 6Ah) is ‘0’. If the SDO2 bit is ‘set’, SPEN is a read-only bit and always

returns ‘0’.

Val Validity. The Val bit is mapped to the V bit (bit 28) of every sub-frame. If this bit is ‘clear’, the

signal is suitable for conversion or processing.

Fs Sample Rate. The Fs bit indicates the sampling rate for the S/PDIF data. The inverse of this

bit is mapped to bit 25 of the channel status block. When the Fs bit is ‘clear’, the sampling frequency is 48 kHz. When ‘set’, the sampling frequency is 44.1 kHz. The actual rate at which S/PDIF data are being transmitted solely depends on the master clock frequency of the CS4205. The Fs bit is merely an indicator to the S/PDIF receiver.

L Generation Status. The L bit is mapped to bit 15 of the channel status block. For category

codes 001xxxx, 0111xxx and 100xxxx, a value of ‘0’ indicates original material and a value of ‘1’ indicates a copy of original material. For all other category codes the definition of the L bit is reversed.

CC[6:0] Category Code. The CC[6:0] bits are mapped to bits 8-14 of the channel status block.

Emph Data Emphasis. The Emph bit is mapped to bit 3 of the channel status block. When ‘set’,

50/15us filter pre-emphasis is indicated. When is ‘clear’, no pre-emphasis is indicated.

Copy Copyright. The Copy bit is mapped to bit 2 of the channel status block. If the Copy bit is ‘set’

/Audio Audio / Non-Audio. The /Audio bit is mapped to bit 1 of the channel status block. If the /Audio

bit is ‘clear’, the data transmitted over S/PDIF is assumed to be digital audio. If the /Audio bit is ‘set’, non-audio data is assumed.

Pro Professional/Consumer. The Pro bit is mapped to bit 0 of the channel status block. If the Pro

bit is ‘clear’, consumer use of the audio control block is indicated. If the bit is ‘set’, professional use is indicated.

Default 0000h

For a further discussion of the proper use of the channel status bits see application note AN22: Overview of Digital Audio Interface Data Structures [3].

44 DS489PP2

CS4205

5.28 Serial Port Control Register (Index 6Ah)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

SDEN 0 0 0 0 0 0 0 0 SDI3 SDI2 SDI1 SDO2 SDSC SDF1 SDF0

SDEN Serial Data Output Enable. The SDEN bit enables transmission of serial data on the SDOUT

pin. The SDEN bit routes the left and right channel data from the AC ’97 controller, the digital mixer, or the digital effects engine to the serial data port. The actual data routed to the serial data port is controlled through the SDOS[1:0]/AMAP/SM[1:0] configuration in the AC Mode Control Register (Index 5Eh). SDEN also functions as a master control for the serial data input ports, the second serial data output port and the serial clock. Setting this bit also disables the GPIO[1:0] pins and clears the GC[1:0] bits in the GPIO Pin Configuration Register (Index 4Ch). Clearing this bit re-enables the GPIO[1:0] pins and sets the GC[1:0] bits.

SDI[3:1] Serial Data Input Enable. The SDI[3:1] bits individually enable the reception of serial data on

the SDI[3:1] pins. Each of these bits routes the left and right channel data from the corresponding serial data input port to its associated volume control. These bits can only be set if the SDEN bit is ‘1’ and will be cleared automatically if SDEN returns to ‘0’. If the SDEN bit is ‘0’, SDI[3:1] are read-only bits and always return ‘0’. If allowed, setting one of these bits also disables the corresponding GPIO pin and clears the associated GC bit for this pin in the GPIO Pin Configuration Register (Index 4Ch). Clearing one of these bits re-enables the corresponding GPIO pin and sets the associated GC bit.

SDO2 Serial Data Output 2 Enable. The SDO2 bit enables transmission of serial data on the

SPDO/SDO2 pin. The SDO2 bit routes the left and right channel data from the AC ’97 controller to the second serial data port. The actual slots routed to the second serial data port are controlled through the AMAP/SM[1:0] configuration in the AC Mode Control Register (Index 5Eh). This bit can only be ‘set’ if the SDEN bit is ‘1’ and will be ‘cleared’ automatically if SDEN returns to ‘0’. Furthermore, the SDO2 bit can only be ‘set’ if the SPEN bit in the S/PDIF Control Register (Index 68h) is ‘0’. If the SDEN bit is ‘0’ or the SPEN bit is ‘1’, SDO2 is a read-only bit and always returns ‘0’.

SDSC Serial Clock Enable. The SDSC bit enables transmission of a serial clock on the EAPD/SCLK

pin. Serial data can be routed to DACs that support internal SCLK mode without transmitting a serial clock. For DACs that only support external SCLK mode, transmission of a serial clock is required and this bit must be set to ‘1’. This bit can only be set if the SDEN bit is ‘1’ and will be cleared automatically if SDEN returns to ‘0’. Furthermore, the SDSC bit can only be ‘set’ if the EAPD bit in the Powerdown Control/Status Register (Index 26h) is ‘0’. If the SDEN bit is ‘0’ or the EAPD bit is ‘1’, SDSC is a read-only bit and always returns ‘0’.

SDF[1:0] Serial Data Format. The SDF[1:0] bits control the format of the serial data transmitted on the

two output ports and the three input ports. All ports will use the same format. See Table 16 for available formats.

Default 0000h

SDF1 SDF0 Serial Data Format

00 I

0 1 Left Justified

1 0 Right Justified, 20-bit data

1 1 Right Justified, 16-bit data

Table 16. Serial Data Format Selection

DS489PP2 45

CS4205

5.29 Special Feature Address Register (Index 6Ch)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

000000000000A3A2A1A0

A[3:0] Special Feature Address. This register functions as an index register to select the desired

functionality of the Special Feature Data Register (Index 6Eh). Before using any of these indexed registers, the correct index value must be written to bits A[3:0].

Default 0000h

5.30 Special Feature Data Register (Index 6Eh)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

D[15:0] Special Feature Data. This register is an indexed data port for the special feature registers

(Index 6E, Address 00h - 0Fh) which control advanced subsystems of the CS4205, such as digital mixer settings, effects engine parameters, ZV Port control, and internal error condition signaling. Before using any of these functions, the correct index value must be written to the Special Feature Address Register (Index 6Ch).

Default 8000h

5.31 Digital Mixer Input Volume Registers (Index 6Eh, Address 00h - 05h)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

Mute 0 GL5 GL4 GL3 GL2 GL1 GL0 0 0 GR5 GR4 GR3 GR2 GR1 GR0

Mute Digital Mixer Mute. Setting this bit mutes the respective input signal, both left and right inputs.

GL[5:0] Left Volume Control. The GL[5:0] bits are used to control the digital mixer left channel input

volume. Each step corresponds to 1 dB gain adjustment. The total range is 0 dB to -63 dB gain.

GR[5:0] Right Volume Control. The GR[4:0] bits are used to control the digital mixer right channel in-

put volume. Each step corresponds to 1 dB gain adjustment. The total range is 0 dB to -63 dB gain.

Default 8000h. This value corresponds to 0 dB gain and Mute ‘set’.

If the digital mixer signals an overflow condition by setting the MLOF or MROF bit in the IEC Status Register (Index 6Eh, Address 0Bh), the controller should correct the error by reducing the digital mixer input volumes in these registers. The Digital Mixer Input Volume Registers are listed in Table 17.

00h PCM Input Volume

01h ADC Input Volume

02h SDI1 Volume

03h SDI2 Volume

04h SDI3 Volume

05h ZV Volume

Table 17. Digital Mixer Input Volume Register Index

46 DS489PP2

CS4205

5.32 Serial Data Port Volume Control Registers (Index 6Eh, Address 06h - 07h)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

Mute 0 GL5 GL4 GL3 GL2 GL1 GL0 0 0 GR5 GR4 GR3 GR2 GR1 GR0

Mute Serial Data Port Mute. Setting this bit mutes the respective input signal, both left and right

inputs.

GL[5:0] Left Volume Control. The GL[5:0] bits are used to control the serial data port left channel out-

put volume. Each step corresponds to 1 dB gain adjustment. The total range is 0 dB to -63 dB gain.

GR[5:0] Right Volume Control. The GR[5:0] bits are used to control the serial data port right channel

output volume. Each step corresponds to 1 dB gain adjustment. The total range is 0 dB to

-63 dB gain.

Default 8000h. This value corresponds to 0 dB gain and Mute ‘set’.

The Serial Data Port Volume Control Registers are listed in Table 18.

06h SDOUT Volume

07h SDO2 Volume

Table 18. Serial Port Volume Control Register Index

DS489PP2 47

CS4205

5.33 Signal Processing Engine Control Register (Index 6Eh, Address 08h)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

Res SDI1M SRZC1 SRZC0 LPFS1 LPFS0 HPFS1 HPFS0 GL3 GL2 GL1 GL0 GR3 GR2 GR1 GR0

SDI1M Serial Data Input 1 Mode. The SDI1M bit controls the flow of data from the first serial data

input into the signal processing engine. If this bit is ‘0’, the two channels of the SDI1 port are routed to their respective channels of the SDI1 volume control. If this bit is ‘1’, the left channel of the SDI1 port is routed to both, the left and right channels of the SDI1 volume control.

SRZC[1:0] Soft Ramp and Zero Cross Control. The SRZC bits control when changes take effect on the

digital volume controls. Table 19 lists the available settings.

LPFS[1:0] Low Pass Filter Select. The LPFS[1:0] bits select the center frequency of the low pass filter

for the EQ algorithm. Table 19 lists the available settings.

HPFS[1:0] High Pass Filter Select. The HPFS[1:0] bits select the center frequency of the high pass filter

for the EQ algorithm. Table 19 lists the available settings.

GL[3:0] Effects Engine Left Output Volume. The GL[3:0] bits are used to control the effects engine

left channel output volume. Each step corresponds to 1 dB gain adjustment, with 0000 = 0 dB attenuation. The total range is 0 dB to -15 dB attenuation.

GR[3:0] Effects Engine Right Output Volume. The GR[3:0] bits are used to control the effects engine

right channel output volume. Each step corresponds to 1 dB gain adjustment, with 0000 = 0 dB attenuation. The total range is 0 dB to -15 dB attenuation.

Default 1800h

If the digital effects engine signals an overflow condition by setting the ELOF or EROF bit in the IEC Status Register (Index 6Eh, Address 0B), the controller should correct the error by reducing the effects engine output volume in this register.

SRZC[1:0]

LPFS[1:0]

HPFS[1:0]

00 immediately 20 Hz 10 kHz

01 on zero crossings 50 Hz 15 kHz

10 soft ramp (1/8 dB step per frame) 100 Hz 20 kHz

11 1/8 dB step per zero crossing reserved reserved

Table 19. Volume Change Modes and EQ Filter Selects

Volume Change Mode

Low Pass

Filter

High Pass

Filter

48 DS489PP2

CS4205

5.34 Internal Error Condition Control/Status Registers (Index 6Eh, Address 09h - 0Bh)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

EROFELOFMROFMLOF0AMORARORALOR00000000

EROF Effects Engine Right Channel Overflow

ELOF Effects Engine Left Channel Overflow

MROF Digital Mixer Right Channel Overflow

MLOF Digital Mixer Left Channel Overflow

AMOR Mic ADC Overrange

AROR L/R ADC Right Channel Overrange

ALOR L/R ADC Left Channel Overrange

Default 0000h

The IEC Config Register (Index 6Eh, Address 09h) enables error signaling for each potential error source. If a bit is

‘clear’, the corresponding source will not be monitored for errors. If a bit is ‘set’, the corresponding source will be monitored and is able to signal an error condition. If an error occurs, the corresponding bit in the IEC Status Register (Index 6Eh, Address 0Bh) will be ‘set’ and remains ‘set’ until the error is cleared, even if the error condition is no longer present. This behavior is equivalent to “sticky” (edge sensitive) GPIO input pins.

The IEC Wakeup Register (Index 6Eh, Address 0Ah)

up or GPIO_INT. If a bit is ‘0’, the corresponding error condition will not generate an interrupt. If a bit is ‘set’, the corresponding error condition will generate an interrupt. For details about wakeup interrupts refer to the GPIO Pin Wakeup Mask Register (Index 52h).

The IEC Status Register (Index 6Eh, Address 0Bh)

the corresponding source has not encountered an error condition or is not being monitored for errors. If a bit is ‘set’, the corresponding source has encountered an error condition. The IEC bit in input slot 12 is a logic OR of all bits in this register. An error condition is cleared by writing a ‘0’ to the corresponding bit of this register. Before clearing an error condition, the controller should correct the error to prevent repeated error signaling. Table 20 lists all the internal error sources and corrective measures for each source.

IEC Bit Error Source Correction Method

ALOR L/R ADC left channel overrange GL[3:0] bits in reg 1Ch

AROR L/R ADC right channel overrange GR[3:0] bits in reg 1Ch

AMOR Mic ADC overrange GM[3:0] bits in reg 1Eh

MLOF Digital mixer left channel overflow GL[5:0] bits in reg 6Eh, addr 00h-05h

MROF Digital mixer right channel overflow GR[5:0] bits in reg 6Eh, addr 00h-05h

ELOF Effects engine left channel overflow GL[3:0] bits in reg 6Eh, addr 08h

EROF Effects engine right channel overflow GR[3:0] bits in reg 6Eh, addr 08h

provides a mask for determining if an IEC will generate a wake-

reflects the state of all internal error conditions. If a bit is ‘clear’,

Table 20. Internal Error Sources and Correction Methods

DS489PP2 49

CS4205

5.35 BIOS-Driver Interface Control Registers (Index 6Eh, Address 0Ch - 0Dh)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

E15 E14 E13 E12 E11 E10 E9 E8 E7 E6 E5 E4 E3 E2 E1 E0

E[15:0] Event Configuration. The E[15:0] bits control the BIOS-Driver Interface mechanism.

Default 0000h

The BDI Config Register (Index 6Eh, Address 0Ch)

a bit is ‘0’, the corresponding event will not be communicated. If a bit is ‘1’, the corresponding event will be communicated by asserting the BDI bit in input slot 12. If an event occurs, the BIOS will ‘set’ the corresponding bit in the BDI Status Register (Index 7Ah). This bit remains ‘set’ until it is cleared by the driver, acknowledging the event has been handled. This behavior is equivalent to “non-sticky” (level sensitive) GPIO input pins.

The BDI Wakeup Register (Index 6Eh, Address 0Dh)

a wakeup or GPIO_INT. If a bit is ‘0’, the corresponding event will not generate an interrupt. If a bit is ‘1’, the corresponding event will generate an interrupt. Refer to the GPIO Pin Wakeup Mask Register (Index 52h) for details about wakeup interrupts.

enables BIOS-Driver communication for each possible event. If

provides a mask for determining if a BDI event will generate

5.36 ZV Port Control/Status Registers (Index 6Eh, Address 0Eh - 0Fh)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

ZVEN LOCK 0 Ph24 Ph23 Ph22 Ph21 Ph20 Ph19 Ph18 Ph17 Ph16 Ph15 Ph14 Ph13 Ph12

Reserved Ph11 Ph10 Ph9 Ph8 Ph7 Ph6 Ph5 Ph4 Ph3 Ph2 Ph1 Ph0

ZVEN ZV Port Input Enable. The ZVEN bit enables the reception of asynchronous serial data on the

ZLRCLK, ZSDATA, and ZSCLK pins. The ZVEN bit routes the left and right channel data from the ZV Port to the asynchronous SRC (ASRC) and on to the ZV volume control. This bit also functions as a powerdown control for the ASRC. When this bit is ‘cleared’, the ASRC is pow- ered down. To use the ZV Port and the ASRC, this bit must be ‘set’.

LOCK ZV Port Locked. When ‘set’, the LOCK read-only bit indicates the ZV Port is receiving valid

data and the receiver has locked on to the data stream. If this bit is ‘cleared’, no valid data are received on the ZV Port and the ZV input to the digital mixer will be muted.

Ph[24:0] Phase Increment. The Ph[24:0] bits contain the current Phase Increment used by the ASRC.

The current sample rate can be determined by Fsin = Fs Fs

is 48 kHz. For more information on how to use these bits see Section 7, ZV Port.

out

Default 0000h

0Eh ZV Port Control/Stat 1

0Fh ZV Port Control/Stat 2

Table 21. ZV Port Control/Status Register Index

50 DS489PP2

*Ph/16,777,216, where

out

CS4205

5.37 BIOS-Driver Interface Status Register (Index 7Ah)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

E15 E14 E13 E12 E11 E10 E9 E8 E7 E6 E5 E4 E3 E2 E1 E0

E[15:0] Event Status. This register, in conjunction with the BIOS-Driver Interface Control Registers

(Index 6Eh, Address 0Ch - 0Dh), controls the BIOS-Driver Interface mechanism.

Default 0000h

The BDI Status Register (Index 7Ah) reflects the state of all possible events. If a bit is ‘0’, the corresponding event

has not occurred or has already been handled by the driver. If a bit is ‘1’, the corresponding event has occurred and has not been handled by the driver yet. The BDI bit in input slot 12 is a logic OR of all bits in this register ANDed with their corresponding bit in the BDI Config Register (Index 6Eh, Address 0Ch). After handling an event, the driver should clear it by writing a ‘0’ to the corresponding bit of this register.

DS489PP2 51

CS4205

5.38 Vendor ID1 Register (Index 7Ch)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

F7 F6 F5 F4 F3 F2 F1 F0 S7 S6 S5 S4 S3 S2 S1 S0

F[7:0] First Character of Vendor ID. With a value of F[7:0] = 43h, these bits define the ASCII ‘C’ char-

acter.

S[7:0] Second Character of Vendor ID. With a value of S[7:0] = 52h, these bits define the ASCII ‘R’

character.

Default 4352h. This register contains read-only data.

5.39 Vendor ID2 Register (Index 7Eh)

D15 D14 D13 D12 D11 D10 D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

T7 T6 T5 T4 T3 T2 T1 T0 0 DID2 DID1 DID0 1 REV2 REV1 REV0

T[7:0] Third Character of Vendor ID. With a value of T[7:0] = 59h, these bits define the ASCII ‘Y’

character.

DID[2:0] Device ID. With a value of DID[2:0] = 101, these bits specify the audio codec is a CS4205.

REV[2:0] Revision. With a value of REV[2:0] = 001, these bits specify the audio codec revision is ‘A’.

Default 595xh. This register contains read-only data.

The two Vendor ID registers provide a means to determine the manufacturer of the AC ’97 audio codec. The first three bytes of the Vendor ID registers contain the ASCII code for the first three letters of Crystal (CRY). The final byte of the Vendor ID registers is divided into a Device ID field and a Revision field. Table 22 lists the currently defined Device ID’s.

DID2-DID0 Part Name

000 CS4297

001 CS4297A

010 CS4294/CS4298

011 CS4299

100 CS4201

101 CS4205

110 CS4291

Table 22. Device ID with Corresponding Part Number

52 DS489PP2

CS4205

6. SERIAL DATA PORTS

6.1 Overview

The CS4205 implements two serial data output ports and three serial data input ports that can be used for digital docking or multi-channel expansion. Each serial port consists of 4 signals: MCLK, SCLK, LRCLK, and SDATA. The existing 256 Fs BIT_CLK will be used as MCLK. The clock pins are shared between all the serial ports with only the SDATA pins being separate; SDOUT for the first output port, SDO2 for the second output port, and SDI[3:1] for the three input ports. Serial data is received and transmitted on these ports every AC-link frame.

The serial data port is controlled by the SDEN, SDSC, SDI[3:1], and SDO2 bits in the Serial Port Control Register (Index 6Ah). All the serial data port pins are multiplexed with other functions and cannot be used unless the other function is disabled or powered down; see Section 9, Exclusive Func- tions. Some audio DACs can run in an internal SCLK mode where SCLK is internally derived from MCLK and LRCLK. In this case, SCLK generation in the CS4205 is optional.

A feature has been designed into the CS4205 that allows the phase of the internal DACs to be re-

versed. This DAC phase reversal is controlled by the DPC bit in the Misc. Crystal Control Register (Index 60h). This feature is necessary since the phase response for external DACs is unknown and the phase response of the internal DACs can vary depending on the path determined by the DDM bit in the AC Mode Control Register (Index 5Eh). This feature guarantees that all DACs in a system have the same phase response, maintaining the accuracy of spatial cues.

In the CS4205, the volume of the serial port data is controlled with the Serial Data Port Volume Con- trol Registers (Index 6Eh, Address 06h - 07h). However, there is no SRC available on this data, so it is the responsibility of the controller or host software to provide this functionality if desired.

6.2 Multi-Channel Expansion

For multi-channel expansion, the two serial data output ports are used to send AC-link data to one or two external stereo DACs to support up to a total of six channels. The first serial port takes the digital audio data from the SDOUT slots. The second serial port takes the digital audio data from the SDO2 slots. See Table 14 on page 42 for the actual slots used depending on configuration. Figure 15 shows a six channel application using the CS4205.

LINE_OUT_L

LINE_OUT_R

GPIO1/SDOUT

EAPD/SCLK

GPIO0/LRCLK

BIT_CLK

SPDO/SDO2

10uF

1000pF

10uF

ELEC

10uF

ELEC

10uF

ELEC

10uF

ELEC

10uF

ELEC

47K 47K

AGNDAGND

47K 47K

220K 220K

AGND

560

2700pF 2700pF

560

2700pF 2700pF

1000pF

CS4334

44 47 43 6 48

SDATA

DEM#/SCLK

LRCK

MCLK

SDATA

DEM#/SCLK

LRCK MCLK

AOUTL

AOUTR

CS4334

AOUTL

AOUTR

AGND

270K 270K

AGND AGND

Left Front

Right Front

Left Surround

Right Surround

AGND

Center

LFE

AGND

Figure 15. Serial Data Port: Six Channel Circuit

DS489PP2 53

CS4205

6.3 Digital Docking

The CS4205 features three serial data input ports used to receive data from three stereo ADCs inside a docking station. One serial data output port is used to transmit data to a stereo DAC inside the docking station. To fully utilize digital docking, the CS4205 should be configured for digital centric mode; see Section 3.2, Digital Centric Mode. This will allow the docking sources to be mixed with the analog sources from the notebook. The resulting mix is available for listening on both the notebook and the docking station and for capturing on the host. Figure 16 shows a block diagram for digital docking applications of the CS4205.

Note the BIT_CLK output should be buffered before sending it as MCLK to the docking station converters. The capacitance loading of the docking station connector, the relatively long trace, and the multiple loads on this signal may exceed the load-

ing restrictions on BIT_CLK. Buffering of SCLK and LRCLK should also be considered.

6.4 Serial Data Formats

In order to support a wide variety of serial audio DACs and ADCs, the CS4205 can transmit and receive serial data in four different formats. The desired format is selected through the SDF[1:0] bits in the Serial Port Control Register (Index 6Ah). All serial ports use the same serial data format when enabled. In all cases, LRCLK will be synchronous with Fs, and SCLK will be 64 Fs (BIT_CLK/4). Serial data is transitioned by the CS4205 on the falling edge of SCLK and latched by the DACs on the next rising edge. Serial data is shifted out MSB first in all supported formats, but LRCLK polarity as well as data justification, alignment, and resolution vary. Table 23 shows the principal characteristics of each serial format.

SCLK LRCLK

CS4205

SYNC

RESET#

DC ’97

Controller

Notebook Side Docking Station Side

SDOUT

SDI1 SDI2 SDI3

MCLK

BIT_CLK

SDATA_IN

SDATA_OUT

Figure 16. Digital Docking Connection Diagram

Stereo DAC

Stereo ADC

Line Out L

Line Out R

Mic In L

Mic In R

Line In L

Line In R

CD In L

CD In R

54 DS489PP2

CS4205

SDF[1:0]

LRCLK

Polarity

Data

Justification

0 0 negative left justified 1 SCLK delayed 20-bit Figure 17 CS4334/CS5331A 0 1 positive left justified not delayed 20-bit Figure 18 CS4335/CS5330A 1 0 positive right justified not delayed 20-bit Figure 19 CS4337/none 1 1 positive right justified not delayed 16-bit Figure 20 CS4338/none

Table 23. Serial Data Formats and Compatible DACs/ADC’s for the CS4205

LRCK

SCLK

SDATA +3 +2 +1 LSB+5 +4

LRCK

SCLK

MSB-1-2-3-4-5

Left Channel

Data Alignment

(MSB vs. LRCLK)

Data

Resolution

MSB-1-2-3-4

Figure 17. Serial Data Format 0 (I2S)

Timing

Diagram

Right Channel

Recommended

DAC/ADC

+3 +2 +1 LSB+5 +4

SDATA +3 +2 +1 LSB+5 +4

LRCK

SCLK

SDATA

MSB-1 -2 -3 -4 -5

Left Channel

17 16 17 1619 18 19 18

15 14 13 12 11 10

Figure 19. Serial Data Format 2 (Right Justified, 20-bit data)

LRCK

SCLK

SDATA

Left Channel

15 14 13 12 11 10

Figure 20. Serial Data Format 3 (Right Justified, 16-bit data)

MSB-1 -2 -3 -4

Figure 18. Serial Data Format 1 (Left Justified)

6543210987

15 14 13 12 11 10

+3 +2 +1 LSB+5 +4

Right Channel

6543210987

Right Channel

6543210987

DS489PP2 55

CS4205

7. ZV PORT

The CS4205 implements an asynchronous serial data input port that conforms to the Zoomed Video Port (ZV Port) specification. ZV Port data is asynchronous I2S data in PCM format with 16 bits of resolution. The ZV Port interface consists of four signals: MCLK, SCLK, LRCLK, and SDATA. However, the CS4205 does not require a connection to the asynchronous MCLK. The other three signals are respectively received on ZSCLK, ZLRCLK, and ZSDATA. Although the ZV Port specification calls for SCLK running at 32 Fs, the CS4205 supports any SCLK from 32 Fs up to 128 Fs. In all cases, only the first 16 bits of each channel will be recovered from the incoming serial data stream. Figure 21 shows the ZV Port format. The ZV Port is controlled by the ZVEN, LOCK, and Ph[24:0] bits in the ZV Port Control/Status Registers (Index 6Eh, Address 0Eh - 0Fh).

Since the data received on the ZV Port is asynchronous and at varying sample rates, it must be sample rate converted before being sent to the digital mixer. The asynchronous SRC is similar in function to

the synchronous DAC SRC, but differs in the way samples are received and how the sample rate is determined. While the synchronous SRC is being programmed to the desired sample rate by the host and requests samples from the host at the programmed rate, the asynchronous SRC receives data from a push source at an unknown rate. Therefore, the asynchronous SRC must determine the rate of incoming data and calculate the necessary parameters. The current sample rate can be determined from the Ph[24:0] bits in the ZV Port Control/Sta- tus Registers (Index 6Eh, Address 0Eh - 0Fh) by

=Fs

*Ph/16,777,216, where Fs

out

is 48 kHz. Once the rate estimator has settled, the LOCK bit will be asserted. If the incoming clock rate changes, LOCK will be de-asserted until the rate estimator has settled again. Settling may take up to 400 ms. As long as the receiver is unlocked, the ZV input to the digital mixer will be muted, regardless of the state of the ZV mute bit in the Dig-

ital Mixer Input Volume Register (Index 6E, Address 00h - 05h).

ZLRCK

ZSCLK

ZSDATA

56 DS489PP2

Left Channel

98 7151413 12 11 10 6543

654 32

Figure 21. ZV Port Format (I2S, 16-bit data)

Right Channel

98715 14 131211 10

21 0

CS4205

8. SONY/PHILIPS DIGITAL INTERFACE (S/PDIF)

The S/PDIF digital output is used to interface the CS4205 to consumer audio equipment external to the PC. This output provides an interface for storing digital audio data or playing digital audio data to digital speakers. Figure 22 illustrates the circuits

SPDO/SDO2

DVdd

3.3V

247.5

107.6

S/PDIF_OUT

375

Ω Ω

Ω

93.75

DGND

Ω

necessary for implementing the IEC-958 optical or consumer interface. For further information on S/PDIF operation see application note AN22: Over- view of Digital Audio Interface Data Structures [3]. For further information on S/PDIF recommended transformers see application note AN134: AES and S/PDIF Recommended Transformers [4].

+5V_PCI

0.1µF

SPDO/SDO2

8.2 k

DGND

Ω

TOTX-173

DGND

Figure 22. S/PDIF Output

DS489PP2 57

CS4205

9. EXCLUSIVE FUNCTIONS

Some of the digital pins on the CS4205 have multiplexed functionality. These functions are mutually exclusive and cannot be requested at the same time. The following pairs of functions are mutually exclusive:

• GPIO and Serial Data Port (GPIO0 pin is shared with LRCLK pin, GPIO1 pin is shared with SDOUT pin, and GPIO[4:2] pins are shared with SDI[3:1] pins)

• EAPD and Serial Data Port Serial Clock (EAPD pin is shared with SCLK pin)

• S/PDIF and Second Serial Data Port (SPDO pin is shared with SDO2 pin)

Use of the GPIO0/LRCLK, GPIO1/SDOUT, and GPIO[4:2]/SDI[3:1] pins for serial data port has

priority over their GPIO functionality. There is no priority assigned to the other two exclusive functions. A function currently in use must be disabled or powered down before the corresponding exclusive function can be enabled. The following control bits for these functions will behave differently than normal bits: the EAPD bit in the Powerdown Con- trol/Status Register (Index 26h), the GC[4:0] bits in the GPIO Pin Config Register (Index 4Ch), the SPEN bit in the S/PDIF Control Register (Index 68h), and the SDI[3:1], SDO2, and SDSC bits in the Serial Port Control Register (Index 6Ah). These bits can become read-only bits if they control a feature that is currently unavailable because the corresponding exclusive feature is already in use, or the corresponding master control for this feature is not set.

58 DS489PP2

CS4205

10. POWER MANAGEMENT

10.1 AC ’97 Reset Modes

The CS4205 supports four reset methods, as defined in the AC ’97 Specification: Cold Reset, Warm Reset, New Warm Reset, and Register Reset. A Cold Reset results in all AC ’97 logic (registers included) initialized to its default state. A Warm Reset or New Warm Reset leaves the contents of the AC ’97 register set unaltered. A Register Reset initializes only the AC ’97 registers to their default states.

10.1.1 Cold Reset

A Cold Reset is achieved by asserting RESET# for a minimum of 1 µs after the power supply rails have stabilized. This is done in accordance with the minimum timing specifications in the AC ’97 Seri- al Port Timing section on page 10. Once de-asserted, all of the CS4205 registers will be reset to their default power-on states and the BIT_CLK and SDATA_IN signals will be reactivated.

10.1.2 Warm Reset

A Warm Reset allows the AC-link to be reactivated without losing information in the CS4205 registers. A Warm Reset is required to resume from a D3 state where the AC-link had been halted yet full power had been maintained. A primary codec Warm Reset is initiated when the SYNC signal is driven high for at least 1 µs and then driven low in the absence of the BIT_CLK clock signal. The BIT_CLK clock will not restart until at least 2 nor-

hot

mal BIT_CLK clock periods (162.8 ns) after the SYNC signal is de-asserted. A Warm Reset of the secondary codec is recognized when the primary codec on the AC-link resumes BIT_CLK generation. The CS4205 will wait for BIT_CLK to be stable to restore SDATA_IN activity, S/PDIF and/or serial data port transmission on the following frame.

10.1.3 New Warm Reset

The New Warm Reset also allows the AC-link to be reactivated without losing information in the registers. A New Warm Reset is required to resume from a D3

state where AC-link power has been

cold

removed. New Warm Reset is recognized by the low-high transition of RESET# after the AC-link has been programmed into PR4 powerdown. The New Warm Reset functionality can be disabled by setting the CRST bit in the Misc. Crystal Control Register (Index 60h).

10.1.4 Register Reset

The last reset mode provides a Register Reset to the CS4205. This is available only when the CS4205 AC-link is active and the Codec Ready bit is ‘set’. The audio (including extended audio) control registers (Index 00h - 3Ah) and the vendor specific registers (Index 5Ah - 7Ah) are reset to their default states by a write of any value to the Reset Register (Index 00h). The modem (including GPIO) registers (Index 3Ch - 56h) are reset to their default states by a write of any value to the Extended Mo- dem ID Register (Index 3Ch).

DS489PP2 59

CS4205

10.2 Powerdown Controls

The Powerdown Control/Status Register (Index 26h) controls the power management func-

tions. The PR[5:0] bits in this register control the internal powerdown states of the CS4205. Powerdown control is available for individual subsections of the CS4205 by asserting any PRx bit or any combination of PRx bits. All powerdown states except PR4 and PR5 can be resumed by clearing the corresponding PRx bit. Table 24 shows the mapping of the power control bits to the functions they manage.

When PR0 is ‘set’, the L/R ADCs and the Input Mux are shut down and the ADC bit in the Power- down Control/Status Register (Index 26h) is ‘cleared’ indicating the ADCs are no longer in a ready state. The same is true for PR1 and the DACs, PR2 and the analog mixer, and PR3 and the voltage reference (Vrefout). When one of these bits is ‘cleared’, the corresponding subsystem will begin a power-on process, and the associated status bit will be ‘set’ when the hardware is ready.

In a primary codec the PR4 bit powers down the AC-link, but all other analog and digital sub-

systems continue to function. The required resume

sequence from a PR4 state is either a Warm Reset

or a New Warm Reset, depending on whether a

or D3

hot

state has been entered.

cold

The PR5 bit disables all internal clocks and powers

down the DACs and the ADCs, but maintains oper-

ation of the BIT_CLK and the analog mixer. A

Cold Reset is the only way to restore operation to

the CS4205 after asserting PR5. To achieve a com-

plete digital powerdown, PR4 and PR5 must be as-

serted within a single AC output frame. This will

also drive BIT_CLK ‘low’.

The CS4205 does not automatically mute any input

or output when the powerdown bits are ‘set’. The

software driver controlling the AC ’97 device must

manage muting the input and output analog signals

before putting the part into any power management

state. The definition of each PRx bit may affect a

single subsection or a combination of subsections

within the CS4205. Table 25 contains the matrix of

subsections affected by the respective PRx func-

tion. Table 26 shows the different operating power

consumptions levels for different powerdown func-

tions.

PR Bit Function

PR0 L/R ADCs and Input Mux Powerdown

PR1 Front DACs Powerdown

PR2 Analog Mixer Powerdown (Vref on)

PR3 Analog Mixer Powerdown (Vref off)

PR4 AC-link Powerdown (BIT_CLK off)*

PR5 Internal Clock Disable

* Applies only to primary codec

Table 24. Powerdown PR Bit Functions

60 DS489PP2

CS4205

PR Bit ADCs DACs Mixer

PR0

•

Analog

ReferenceACLink

Internal

Clock Off

Mic ADC

PR1 • PR2 ••• • PR3 ••• • • PR4 • PR5 •• •

•

PRL •

Table 25. Powerdown PR Function Matrix for the CS4205

Power State

(mA)

DVdd1

[DVdd=3.3 V]

(mA)

DVdd1

[DVdd=5 V]

AVdd1

(mA)

Full Power + SRC’s TBD TBD TBD

Full Power + S/PDIF

TBD TBD TBD

Full Power TBD TBD TBD

ADCs off (PR0) TBD TBD TBD

DACs off (PR1) TBD TBD TBD

Audio off (PR2) TBD TBD TBD

Vref off (PR3) TBD TBD TBD

AC-Link off (PR4) TBD TBD TBD

Internal Clocks off (PR5) TBD TBD TBD

Digital off (PR4+PR5) TBD TBD TBD

PR3+PR4+PR5 TBD TBD TBD

RESET TBD TBD TBD

Table 26. Power Consumption by Powerdown Mode for the CS4205

Assuming standard resistive load for transformer coupled coaxial S/PDIF output (Rload = 292 Ohm, DVdd = 3.3 V) (Rload = 415 Ohm, DVdd = 5 V). General: I

S/PDIF

= I

+ DVdd/Rload/2

DVdd

DS489PP2 61

CS4205

11. CLOCKING

The CS4205 may be operated as a primary or secondary codec. As a primary codec, the system clock for the AC-link may be generated from an external 24.576 MHz clock source, a 24.576 MHz crystal, or use the internal Phase Locked Loop (PLL). The PLL allows the CS4205 to accept external clock frequencies other than 24.576 MHz. The CS4205 uses the presence or absence of a valid clock on the XTL_IN pin in conjunction with the ID[1:0]# pins to determine the clocking configuration.

11.1 PLL Operation (External Clock)

The PLL mode is activated if a valid clock is present on XTL_IN during the rising edge of RESET#. Once PLL mode is entered, the XTL_OUT pin is redefined as the PLL loop filter, as shown in Figure 23. The ID[1:0]# inputs determine the configuration of the internal divider ratios required to generate the 12.288 MHz BIT_CLK output; see Table 27 on page 63 for additional details. In PLL mode, the CS4205 is configured as a primary codec independent of the state of the ID[1:0]# pins. If 24.576 MHz is chosen as the external clock input (ID[1:0]# inputs both pulled high or left floating), the PLL is disabled and the clock is used directly. The loop filter is not required and XTL_OUT is left unconnected. For all other clock input choices, the loop filter is required. The ID[1:0] bits of the Extended Audio ID Register

(Index 28h) and the Extended Modem ID Register (Index 3Ch) will always report 0 in PLL mode.

11.2 24.576 MHz Crystal Operation

11.3 Secondary Codec Operation

If a valid clock is not present on XTL_IN and either ID[1:0]# input is pulled low during the rising edge of RESET#, the device is determined to be a secondary codec. The BIT_CLK pin is configured as an input and the CS4205 is driven from the

12.288 MHz BIT_CLK of the primary codec. The ID[1:0] bits of the Extended Audio ID Register

(Index 28h) and the Extended Modem ID Register (Index 3Ch) will report the state of the ID[1:0]#

inputs.

Clock Source

XTL_IN

XTL_OUT

2.2 k

220 pF

DGND

Figure 23. PLL External Loop Filter

24.576 MHz

22 pF 22 pF

Ω

0.022 uF

XTL_IN

XTL_OUT

If a valid clock is not present on XTL_IN during the rising edge of RESET#, the device disables the

DGND

PLL input and latches the state of the ID[1:0]# inputs. If the ID[1:0]# inputs are both pulled high or

Figure 24. External Crystal

left floating, the device is configured as a primary codec. An external 24.576 MHz crystal is used as the system clock as shown in Figure 24.

62 DS489PP2

CS4205

External

Clock on

ID1# ID0#

XTL_IN

Yes 1 1 Primary 0 External 24.576 No clock generator driving XTL_IN Yes 1 0 Primary 0 External 14.31818 Yes Yes 0 1 Primary 0 External 27.000 Yes Yes 0 0 Primary 0 External 48.000 Yes

No 1 1 Primary 0 XTAL 24.576 No crystal connected to XTL_IN, XTL_OUT No 1 0 Secondary 1 BIT_CLK 12.288 No No 0 1 Secondary 2 BIT_CLK 12.288 No No 0 0 Secondary 3 BIT_CLK 12.288 No

AC-Link

Timing

Mode

Codec IDClock

Source

Clock

Rate

(MHz)

PLL

Active

Application Notes

external clock source driving XTL_IN loop filter connected to XTL_OUT

BIT_CLK from primary codec driving BIT_CLK on all secondary codecs

Table 27. Clocking Configurations for the CS4205

DS489PP2 63

CS4205

12. ANALOG HARDWARE DESCRIPTION

The analog input section consists of four stereo line-level inputs (LINE_L/R, CD_L/GND/R, VIDEO_L/R, and AUX_L/R), two selectable mono microphone inputs (MIC1 and MIC2), and two mono inputs (PC_BEEP and PHONE). The analog output section consists of a mono output (MONO_OUT) and a stereo line-level output (LINE_OUT_L/R). This section describes the analog hardware needed to interface with these pins. The designs presented in this section are compliant with Chapter 17 of Microsoft’s PC 99 System De- sign Guide [7] (referred to as PC 99) and Chapter 11 of Microsoft’s PC 2001 System Design Guide [8] (referred to as PC 2001). For information on EMI reduction techniques refer to the application note AN165: CS4297A/CS4299 EMI Reduction Techniques [5].

common-mode noise out of the CD inputs when connected to the CD analog source ground. Following the reference designs in Figure 26 and

Figure 27 provides extra attenuation of common mode noise coming from the CD-ROM drive,

thereby producing a higher quality signal. One percent resistors are recommended since closely

matched resistor values provide better common-mode attenuation of unwanted signals. The circuit shown in Figure 26 can be used to attenuate

a 2 V shown in Figure 27 can be used for a 1 V

CD input signal by 6 dB. The circuit

RMS

CD in-

put signal.

AGND

6.8 k

Ω

6.8 k

Ω

1.0µF

6.8 k

1.0µF

Ω

LINE_IN_R

LINE_IN_L

12.1 Analog Inputs

All analog inputs to the CS4205, including CD_GND, should be capacitively coupled to the input pins. Unused analog inputs should be tied together and connected through a capacitor to analog ground or tied to the Vrefout pin directly. The maximum allowed voltage for analog inputs, except the microphone input, is 1 V

. The maximum al-

RMS

lowed voltage for the microphone input depends on the selected boost setting.

12.1.1 Line Inputs

Figure 25 shows circuitry for a line-level stereo input. Replicate this circuit for the Line, Video and Aux inputs. This design attenuates the input by 6 dB, bringing the signal from the PC 99 specified 2V

, to the CS4205 maximum allowed 1 V

RMS

12.1.2 CD Input

AGND

Figure 25. Line Input (Replicate for Video and AUX)

6.8 k

47 k

Ω

AGND

Ω

1.0 µF

3.4 k

1.0 µF

47 k

1.0 µF

Ω

RMS

1.0 µF

Ω

CD Input

6.8 k

CD_R

CD_L

CD_COM

(All resistors 1%)

6.8 k

3.4 k

Ω

6.8 k

Ω

Figure 26. Differential 2 V

100

CD_R

CD_L

CD_COM

100

Ω

47 k

Ω

2.2 µF

CD_R

CD_L

CD_GND

CD_R

CD_L

CD_GND

The CD line-level input has an extra pin, CD_GND, providing a pseudo-differential input

Figure 27. Differential 1 V

AGND

CD Input

RMS

for both CD_L and CD_R. This pin takes the

64 DS489PP2

CS4205

Figure 28. Microphone Input

12.1.3 Microphone Inputs

Figure 28 illustrates an input circuit suitable for dynamic and electret microphones. Electret, also known as phantom-powered, microphones use the right channel (ring) of the jack for power. The design also supports the recommended advanced frequency response for voice recognition as specified in PC 99 and PC 2001. The microphone input of the CS4205 has an integrated pre-amplifier. Using combinations of the 10dB bit in the Misc. Crystal

Control Register (Index 60) and the 20dB bit in the Mic Volume Register (Index 0Eh) the pre-amplifier

gain can be set to 0 dB, 10 dB, 20 dB, or 30 dB.

12.1.4 PC Beep Input

The PC_BEEP input is useful for mixing the output of the “beeper” (timer chip), provided in most PCs, with the other audio signals. When the CS4205 is held in reset, PC_BEEP is passed directly to the line output. This allows the system sounds or “beeps” to be available before the AC ’97 interface has been activated. Figure 29 illustrates a typical input circuit for the PC_BEEP input. If PC_BEEP is driven from a CMOS gate, the 4.7 kΩ resistor should be tied to analog ground instead of +5VA. Although this input is described for a low-quality “beeper”, it is of the same high-quality as all other analog inputs and may be used for other purposes.

device so that modem dialing signals and protocol negotiations may be monitored through the audio system. Figure 30 shows a design for a modem connection where the output is fed from the CS4205 MONO_OUT pin through a divider. The divider ratio shown does not attenuate the signal, providing an output voltage of 1 V

. If a lower

RMS

output voltage is desired, the resistors can be replaced with appropriate values, as long as the total load on the output is kept greater than 10 kΩ. The PHONE input is divided by 6 dB to accommodate a line-level source of 2 V

RMS

12.2 Analog Outputs

The analog output section provides a stereo and a mono output. The MONO_OUT, LINE_OUT_L, and LINE_OUT_R pins require 680 pF to 1000 pF NPO dielectric capacitors between the corresponding pin and analog ground. Each analog output is DC-biased up to the Vrefout voltage signal reference, nominally 2.4 V. This requires the outputs be AC-coupled to external circuitry (AC loads must be greater than 10 kΩ for the line output).

+5VA (Low Noise) or

AGND if CMOS Source

4.7 k

1.0 µF

6.8 k

1.0 µF

Ω

PC_BEE P

0.1 µF

X7R

PHONE

MONO_OUT

1000 pF

12.1.5 Phone Input

One application of the PHONE input is to interface to the output of a modem analog front end (AFE)

+5VA

1.5 k

Ω

10 µF

Ω

2.2 k

AGND

ELEC

100

AGND

0.1 µF

X7R

MIC1/MIC2

Ω

AGND

PC-BEEP-BUS

PHONE

MONO_OUT

Ω

47 k

2.7 nF

X7R

AGND

Figure 29. PC_BEEP Input

6.8 k

Ω

0 Ω

47 k

Ω

AGND AGND

Figure 30. Modem Connection

DS489PP2 65

CS4205

LINE_OUT_R

LINE_OUT_L

10 µF ELEC

ELEC

220 k

Ω

220 k

Ω

AGND

1000 pF1000 pF

AGND

Line Out

Figure 31. Stereo Output

12.2.1 Stereo Output

See Figure 31 for a stereo line-level output reference design.

12.2.2 Mono Output

The mono output, MONO_OUT, can be either a sum of the left and right output channels, attenuated by 6 dB to prevent clipping at full scale, or the selected Mic signal. The mono out channel can drive the PC internal mono speaker using an appropriate buffer circuit

12.3 Miscellaneous Analog Signals

The AFLT1, AFLT2, and AFLT3 pins must have a 1000 pF NPO capacitor to analog ground. These capacitors provide a single-pole low-pass filter at the inputs to the ADCs. This makes low-pass filters at each analog input pin unnecessary.

The REFFLT pin must have a short, wide trace to a

2.2 µF and a 0.1 µF capacitor connected to analog

ground (see Figure 33 in Section 13, Grounding and Layout, for an example). The 2.2 µF capacitor must not be replaced by any other value and must be ceramic with low leakage current. Electrolytic capacitors should not be used. No other connection should be made, as any coupling onto this pin will degrade the analog performance of the CS4205. Likewise, digital signals should be kept away from REFFLT for similar reasons.

the analog section which could degrade analog performance. The +5 VA supply should be generated from a voltage regulator (7805 type) connected to a +12 VD supply. This helps isolate the analog circuitry from noise typically found on +5 VD supplies which power many digital circuits in a PC environment. A typical voltage regulator circuit for analog power using an MC78M05CDT is shown in Figure 32. The AVdd1/AVss1 analog power/ground pin pair on the CS4205 supplies power to all the analog circuitry and should be connected to +5 VA/AGND. The AVdd2 and AVss2 pins are not used on the CS4205 and may be left floating or tied to +5 VA/AGND for backwards compatibility.

The DVdd2/DVss2 digital power/ground pin pair on the CS4205 should be connected to the same digital supply as the controller AC-link interface. Since the digital interface on the CS4205 may operate at either +3.3 VD or +5 VD, proper connection of these pins will depend on the digital power supply of the controller. The DVdd1/DVss1 pair supplies power to the clocking circuitry and needs to be connected to the +5 VA/AGND power supply when the CS4205 is in PLL clocking mode. In XTAL or OSC clocking modes these pins may be connected to either +5 VA/AGND or use the same power supply used for DVdd2/DVss2

12.5 Reference Design

12.4 Power Supplies

See Section 16 for a CS4205 reference design.

The power supplies providing analog power should be as clean as possible to minimize coupling into

+12VD

MC78M05CDT

IN OUT

DGND

10 µF ELEC

0.1 µF Y5V

66 DS489PP2

Figure 32. +5V Analog Voltage Regulator

GND

0.1 µF Y5V

+5VA

AGND

10 µF ELEC

CS4205

13. GROUNDING AND LAYOUT

Figure 33 on page 68 shows the conceptual layout for the CS4205 in XTAL or OSC clocking modes. The decoupling capacitors should be located physically as close to the pins as possible. Also, note the connection of the REFFLT decoupling capacitors to the ground return trace connected directly to the ground return pin, AVss1.

It is strongly recommended that separate analog and digital ground planes be used. Separate ground planes keep digital noise and return currents from modulating the CS4205 ground potential and degrading performance. The digital ground pins should be connected to the digital ground plane and kept separate from the analog ground connections of the CS4205 and any other external analog circuitry. All analog components and traces should be located over the analog ground plane and all digital components and traces should be located over the digital ground plane.

tion traces should be routed such that the digital ground plane lies underneath these signals (on the internal ground layer). This applies along the entire length of these traces from the AC ’97 controller to the CS4205.

Refer to the Application Note AN18: Layout and

Design Rules for Data Converters and Other Mixed Signal Devices [2] for more information on

layout and design rules.

The common connection point between the two ground planes (required to maintain a common ground voltage potential) should be located under the CS4205. The AC-link digital interface connec-

DS489PP2 67

CS4205

Via to +5VA

0.1 µF

Y5V

AVss2

AVdd2

Via to Analog Ground

Digital

Ground

Vrefout

1000 pF NPO

AFLT3

AFLT2

Via to Digital Ground

to via

AFLT1

REFFLT

2.2

AVss1

Via to Analog Ground

Analog

Ground

µF

Via to +5VA

0.1 µF Y5V

AVdd1

Pin 1

DVdd1

Via to +5VD or +3.3VD

0.1 µF Y5V

DVss1

DVss2

0.1 µF Y5V

DVdd2

Via to +5VD or +3.3VD

Figure 33. Conceptual Layout for the CS4205 when in XTAL or OSC Clocking Modes

68 DS489PP2

14. PIN DESCRIPTIONS

CS4205

DVdd1

XTL_IN

XTL_OUT

DVss1

SDATA_OUT

BIT_CLK

DVss2

SDATA_IN

DVdd2

SYNC

RESET#

ID0#

ID1#

EAPD/SCLK

SPDO/SDO2

48 47 46 45 44 43 42 41 40 39 38 37

GPIO1/SDOUT

CS4205

AVss2

GPIO0/LRCLK

GPIO3/SDI2

GPIO4/SDI3

AVdd2

GPIO2/SDI1

MONO_OUT

LINE_OUT_R

LINE_OUT_L

ZSCLK

ZSDATA

ZLRCLK

AFLT3

AFLT2

AFLT1

Vrefout

REFFLT

AVss1

PC_BEEP

13 14 15 16 17 18 19 20 21 22 23 24

MIC2

AUX_L

PHONE

AUX_R

VIDEO_L

CD_L

VIDEO_R

CD_GND

MIC1

CD_R

LINE_IN_L

LINE_IN_R

AVdd1

Figure 34. Pin Locations for the CS4205

DS489PP2 69

Audio I/O Pins

PC_BEEP - Analog Mono Source, Input, Pin 12

The PC_BEEP input is intended to allow the PC system POST (Power On Self-Test) tones to pass through to the audio subsystem. The PC_BEEP input has two connections: the first connection is to the analog output mixer, the second connection is directly to the LINE_OUT stereo outputs. While the RESET# pin is actively being asserted to the CS4205, the PC_BEEP bypass path to the LINE_OUT outputs is enabled. While the CS4205 is in normal operation mode with RESET# de-asserted, PC_BEEP is a monophonic source to the analog output mixer. The maximum allowable input is 1 V (sinusoidal). This input is internally biased at the Vrefout voltage reference and requires AC-coupling to external circuitry. If this input is not used, it should be connected to the Vrefout pin or AC-coupled to analog ground.

PHONE - Analog Mono Source, Input, Pin 13

This analog input is a monophonic source to the output mixer. It is intended to be used as a modem subsystem input to the audio subsystem. The maximum allowable input is 1 V input is internally biased at the Vrefout voltage reference and requires AC-coupling to external circuitry. If this input is not used, it should be connected to the Vrefout pin or AC-coupled to analog ground.

MIC1 - Analog Mono Source, Input, Pin 21

This analog input is a monophonic source to the analog output mixer. It is intended to be used as a desktop microphone connection to the audio subsystem. The CS4205 internal mixer’s microphone input is MUX selectable with either MIC1 or MIC2 as the input. The maximum allowable input is 1 V (sinusoidal). This input is internally biased at the Vrefout voltage reference and requires AC-coupling to external circuitry. If this input is not used, it should be connected to the Vrefout pin or AC-coupled to analog ground.

CS4205

(sinusoidal). This

RMS

MIC2 - Analog Mono Source, Input, Pin 22

This analog input is a monophonic source to the analog output mixer. It is intended to be used as an alternate microphone connection to the audio subsystem. The CS4205 internal mixer’s microphone input is MUX selectable with either MIC1 or MIC2 as the input. The maximum allowable input is 1 V (sinusoidal). This input is internally biased at the Vrefout voltage reference and requires AC-coupling to external circuitry. If this input is not used, it should be connected to the Vrefout pin or AC-coupled to analog ground.

LINE_IN_L, LINE_IN_R - Analog Line Source, Inputs, Pins 23 and 24

These inputs form a stereo input pair to the CS4205. The maximum allowable input is 1 V (sinusoidal). These inputs are internally biased at the Vrefout voltage reference and require AC-coupling to external circuitry. If these inputs are not used, they should both be connected to the Vrefout pin or AC-coupled to analog ground.

CD_L, CD_R - Analog CD Source, Inputs, Pins 18 and 20

These inputs form a stereo input pair to the CS4205. It is intended to be used for the Red Book CD audio connection to the audio subsystem. The maximum allowable input is 1 V inputs are internally biased at the Vrefout voltage reference and require AC-coupling to external circuitry. If these inputs are not used, they should both be connected to the Vrefout pin or AC-coupled to analog ground.

CD_GND - Analog CD Common Source, Input, Pin 19

This analog input is used to remove common mode noise from Red Book CD audio signals. The impedance on the input signal path should be one half the impedance on the CD_L and CD_R input paths. This pin requires AC-coupling to external circuitry. If this input is not used, it should be connected to the Vrefout pin or AC-coupled to analog ground.

(sinusoidal). These

RMS

70 DS489PP2

VIDEO_L, VIDEO_R - Analog Video Audio Source, Inputs, Pins 16 and 17

These inputs form a stereo input pair to the CS4205. It is intended to be used for the audio signal output of a video device. The maximum allowable input is 1 V internally biased at the Vrefout voltage reference and require AC-coupling to external circuitry. If these inputs are not used, they should both be connected to the Vrefout pin or AC-coupled to analog ground.

AUX_L, AUX_R - Analog Auxiliary Source, Inputs, Pins 14 and 15

CS4205

(sinusoidal). These inputs are

RMS

LINE_OUT_L, LINE_OUT_R - Analog Line-Level, Outputs, Pins 35 and 36

These signals are analog outputs from the stereo output mixer. The full-scale output voltage for each output is nominally 1 V

(sinusoidal). These outputs are internally biased at the Vrefout voltage

RMS

reference and require either AC-coupling to external circuitry or DC-coupling to a buffer op-amp biased at the Vrefout voltage. These pins need a 680-1000 pF NPO capacitor attached to analog ground.

MONO_OUT - Analog Mono Line-Level, Output, Pin 37

This signal is an analog output from the stereo-to-mono mixer. The full-scale output voltage for this output is nominally 1 V

(sinusoidal). This output is internally biased at the Vrefout voltage reference

RMS

and requires either AC-coupling to external circuitry or DC-coupling to a buffer op-amp biased at the Vrefout voltage. This pin needs a 680-1000 pF NPO capacitor attached to analog ground.

Analog Reference, Filter, and Configuration Pins

REFFLT - Internal Reference Voltage, Input, Pin 27

RMS

This signal is the voltage reference used internal to the CS4205. A 0.1 µF and a 2.2 µF ceramic capacitor with short, wide traces must be connected to this pin. No other connections should be made to this pin. Do not use an electrolytic 2.2 µF capacitor, use a type Z5U or Y5V ceramic capacitor.

Vrefout - Voltage Reference, Output, Pin 28

All analog inputs and outputs are centered around Vrefout, nominally 2.4 Volts. This pin may be used to bias external amplifiers. It can also drive up to 5 mA of DC which can be used for microphone bias.

AFLT1 - Left ADC Channel Antialiasing Filter, Input, Pin 29

This pin needs a 1000 pF NPO capacitor connected to analog ground.

AFLT2 - Right ADC Channel Antialiasing Filter, Input, Pin 30

This pin needs a 1000 pF NPO capacitor connected to analog ground.

AFLT3 - Mic ADC Channel Antialiasing Filter, Input, Pin 31

This pin needs a 1000 pF NPO capacitor connected to analog ground.

DS489PP2 71

AC-Link Pins

RESET# - AC ’97 Chip Reset, Input, Pin 11

This active low signal is the asynchronous Cold Reset input to the CS4205. The CS4205 must be reset before it can enter normal operating mode.

SYNC - AC-Link Serial Port Sync pulse, Input, Pin 10

SYNC is the serial port timing signal for the AC-link. Its period is the reciprocal of the maximum sample rate, 48 kHz. The signal is generated by the controller and is synchronous to BIT_CLK. SYNC is an asynchronous input when the CS4205 is configured as a primary codec and is in a PR4 powerdown state. A series terminating resistor of 47 Ω should be connected on this signal close to the controller.

BIT_CLK - AC-Link Serial Port Master Clock, Input/Output, Pin 6

This input/output signal controls the master clock timing for the AC-link. In primary mode, this signal is a

12.288 MHz output clock derived from either a 24.576 MHz crystal or from the internal PLL based on the XTL_IN input clock. When the CS4205 is in secondary mode, this signal is an input which controls the AC-link serial interface and generates all internal clocking including the AC-link serial interface timing and the analog sampling clocks. A series terminating resistor of 47 Ω should be connected on this signal close to the CS4205 in primary mode or close to the BIT_CLK source in secondary mode.

SDATA_OUT - AC-Link Serial Data Input Stream to AC ’97, Input, Pin 5

CS4205

This input signal receives the control information and digital audio output streams. The data is clocked into the CS4205 on the falling edge of BIT_CLK. A series terminating resistor of 47 Ω should be connected on this signal close to the controller.

SDATA_IN - AC-Link Serial Data Output Stream from AC ’97, Output, Pin 8

This output signal transmits the status information and digital audio input streams from the ADCs. The data is clocked out of the CS4205 on the rising edge of BIT_CLK. A series terminating resistor of 47 Ω should be connected on this signal close to the CS4205.

Clock and Configuration Pins

XTL_IN - Crystal Input/Clock Input, Pin 2

This pin requires either a 24.576 MHz crystal, with the other pin attached to XTL_OUT, or an external CMOS clock. XTL_IN must have a crystal or clock source attached for proper operation except when operating in secondary codec mode. The crystal frequency must be 24.576 MHz and designed for fundamental mode, parallel resonance operation. If an external CMOS clock is used to drive this pin, it must run at one of these acceptable frequencies: 14.31818. 24.576, 27, or 48 MHz. When configured as a secondary codec, all timing is derived from the BIT_CLK input signal and this pin should be left floating. See Section 11, Clocking, for additional details.

XTL_OUT - Crystal Output/ PLL Loop Filter, Pin 3

This pin is used for a crystal placed between this pin and XLT_IN. If an external 24.576 MHz clock is used on XTL_IN, this pin must be left floating with no traces or components connected to it. If one of the other acceptable clocks is used on XTL_IN, this pin must be connected to a loop filter circuit. See Section 11, Clocking, for additional details.

ID1#, ID0# - Codec ID, Inputs, Pins 45 and 46

These pins select the Codec ID for the CS4205, as well as determine the rate of the incoming clock in PLL mode. They are only sampled after the rising edge of RESET#. These pins are internally pulled up to the digital supply voltage and should be left floating for logic ‘0’ or tied to digital ground for logic ‘1’.

72 DS489PP2

Misc. Digital Interface Pins

SPDO/SDO2 - Sony/Philips Digital Interface / Serial Data Output 2,Output, Pin 48

This pin generates the S/PDIF digital output from the CS4205 when the SPEN bit in the S/PDIF Control Register (Index 68h) is ‘set’. This output may be used to directly drive a resistive divider and coupling

transformer to an RCA-type connector for use with consumer audio equipment. This pin also provides the serial data for the second serial data port when the SDO2 bit in the Serial Port Control Register (Index 6Ah) is ‘set’. These two functions are mutually exclusive. When neither function is being used this output is driven to a logic ‘0’.

EAPD/SCLK - External Amplifier Powerdown / Serial Clock, Output, Pin 47

This pin is used to control the powerdown state of an audio amplifier external to the CS4205. The output is controlled by the EAPD bit in the Powerdown Ctrl/Stat Register (Index 26h). It is driven as a normal CMOS output and defaults low (‘0’) upon power-up. This pin also provides the serial clock for all serial data ports when the SDSC bit in the Serial Port Control Register (Index 6Ah) is ‘set’.

GPIO0/LRCLK - General Purpose I/O / Left-Right Clock, Input/Output, Pin 43

This pin is a general purpose I/O pin that can be used to interface with various external circuitry. When configured as an input, it functions as a Schmitt triggered input with 350 mV hysteresis at 5 V and 220 mV hysteresis at 3.3 V. When configured as an output, it can function as a normal CMOS output (4 mA drive) or as an open drain output. This pin also provides the L/R clock for all serial data ports when the SDEN bit in the Serial Port Control Register (Index 6Ah) is ‘set’. This bit powers up in the high impedance state for backward compatibility.

CS4205

GPIO1/SDOUT - General Purpose I/O / Serial Data Ouput, Input/Output, Pin 44

This pin is a general purpose I/O pin that can be used to interface with various external circuitry. When configured as an input, it functions as a Schmitt triggered input with 350 mV hysteresis at 5 V and 220 mV hysteresis at 3.3 V. When configured as an output, it can function as a normal CMOS output (4 mA drive) or as an open drain output. This pin also provides the serial data for the first serial data port when the SDEN bit in the Serial Port Control Register (Index 6Ah) is ‘set’. This bit powers up in the high impedance state for backward compatibility.

GPIO2/SDI1 - General Purpose I/O / Serial Data Input 1, Input/Output, Pin 39

This pin is a general purpose I/O pin that can be used to interface with various external circuitry. When configured as an input, it functions as a Schmitt triggered input with 350 mV hysteresis at 5 V and 220 mV hysteresis at 3.3 V. When configured as an output, it can function as a normal CMOS output (4 mA drive) or as an open drain output. This pin also receives the serial data for the first serial input port when the SDI1 bit in the Serial Port Control Register (Index 6Ah) is ‘set’. This bit powers up in the high impedance state for backward compatibility.

GPIO3/SDI2 - General Purpose I/O / Serial Data Input 2, Input/Output, Pin 40

This pin is a general purpose I/O pin that can be used to interface with various external circuitry. When configured as an input, it functions as a Schmitt triggered input with 350 mV hysteresis at 5 V and 220 mV hysteresis at 3.3 V. When configured as an output, it can function as a normal CMOS output (4 mA drive) or as an open drain output. This pin also receives the serial data for the second serial input port when the SDI2 bit in the Serial Port Control Register (Index 6Ah) is ‘set’. This bit powers up in the high impedance state for backward compatibility.

DS489PP2 73

GPIO4/SDI3 - General Purpose I/O / Serial Data Input 3, Input/Output, Pin 41

This pin is a general purpose I/O pin that can be used to interface with various external circuitry. When configured as an input, it functions as a Schmitt triggered input with 350 mV hysteresis at 5 V and 220 mV hysteresis at 3.3 V. When configured as an output, it can function as a normal CMOS output (4 mA drive) or as an open drain output. This pin also receives the serial data for the third serial input port when the SDI3 bit in the Serial Port Control Register (Index 6Ah) is ‘set’. This bit powers up in the high impedance state for backward compatibility.

ZLRCLK - ZV Port Left-Right Clock, Input, Pin 32

This pin receives the Left/Right clock for the Zoomed Video Port. The L/R clock determines which channel is currently being inputted on the ZSDATA pin. The signal must conform to the ZV Port Specification.

ZSDATA - ZV Port Serial Data, Input, Pin 33

This pin receives two’s complement MSB-first serial audio data for the Zoomed Video Port. The data is clocked into the CS4205 by the ZSCLK, and the channel is determined by ZLRCLK. The signal must conform to the ZV Port Specification.

ZSCLK - ZV Port Serial Clock, Input, Pin 34

CS4205

This pin receives the serial clock for the Zoomed Video port. The serial clock is used to clock data on the ZSDATA pin into the CS4205. The signal must conform to the ZV Port Specification.

Power Supply Pins

DVdd1, DVss1 - Digital Supply Voltage 1 / Digital Ground 1, Pins 1 and 4

These pins provide the supply voltage and ground for the clocking section of the CS4205. In XTAL or OSC clocking modes DVdd1 should be tied to +5 VD or to +3.3 VD, with DVss1 tied to DGND. In PLL clocking mode, DVdd1 must be tied to +5 VA and DVss1 must be tied to AGND. If connecting these pins to +5 VD or to +3.3 VD and DGND, the CS4205 and controller AC-link should share a common digital supply.

DVdd2, DVss2 - Digital Supply Voltage 2 / Digital Ground 2, Pins 9 and 7

These pins provide the digital supply voltage and digital ground for the AC-link section of the CS4205. In all clocking modes DVdd2 should be tied to +5 VD or to +3.3 VD, with DVss2 tied to DGND. The CS4205 and controller AC-link should share a common digital supply. DVss2 should be isolated from analog ground currents.

AVdd1, AVss1 - Analog Supply Voltage 1 / Analog Ground 1, Pins 25 and 26

These pins provide the analog supply voltage and analog ground for the analog and mixed signal sections of the CS4205. AVdd1 must be tied to the +5 VA power supply, with AVss1 connected to AGND. It is strongly recommended the +5 VA power supply be generated from a voltage regulator to ensure proper supply currents and noise immunity from the rest of the system. AVss2 should be isolated from digital ground currents

AVdd2, AVss2 - Analog Supply Voltage 2 / Analog Ground 2, Pins 38 and 42

The AVdd2 and AVss2 pins are not used on the CS4205 and may be left floating or tied to +5 VA and AGND for backwards compatibility

74 DS489PP2

15. PARAMETER AND TERM DEFINITIONS

AC ’97 Specification

Refers to the Audio Codec ’97 Component Specification Ver 2.1 published by the Intel

AC ’97 Controller or Controller

Refers to the control chip which interfaces to the audio codec AC-link. This has been also called DC ’97 for Digital Controller ’97 [6].

AC ’97 Registers or Codec Registers

Refers to the 64-field register map defined in the AC ’97 Specification.

ADC

Refers to a single Analog-to-Digital converter in the CS4205. “ADCs” refers to the stereo pair of Analog-to-Digital converters. The CS4205 ADCs have 18-bit resolution.

Codec

Refers to the chip containing the ADCs, DACs, and analog mixer. In this data sheet, the codec is the CS4205.

DAC

CS4205

Corporation [6].

Refers to a single Digital-to-Analog converter in the CS4205. “DACs” refers to the stereo pair of Digital-to-Analog converters. The CS4205 DACs have 20-bit resolution.

dB FS A

dB FS is defined as dB relative to full-scale. The “A” indicates an A weighting filter was used.

Differential Nonlinearity

The worst case deviation from the ideal code width. Units in LSB.

Dynamic Range (DR)

DR is the ratio of the RMS full-scale signal level divided by the RMS sum of the noise floor, in the presence of a signal, available at any instant in time (no change in gain settings between measurements). Measured over a 20 Hz to 20 kHz bandwidth with units in dB FS A.

FFT

Fast Fourier Transform.

Frequency Response (FR)

FR is the deviation in signal level verses frequency. The 0 dB reference point is 1 kHz. The amplitude corner, Ac, lists the maximum deviation in amplitude above and below the 1 kHz reference point. The listed minimum and maximum frequencies are guaranteed to be within the Ac from minimum frequency to maximum frequency inclusive.

Sampling Frequency.

Interchannel Gain Mismatch

For the ADCs, the difference in input voltage to get an equal code on both channels. For the DACs, the difference in output voltages for each channel when both channels are fed the same code. Units are in dB.

DS489PP2 75

Interchannel Isolation

The amount of 1 kHz signal present on the output of the grounded AC-coupled line input channel with 1 kHz, 0 dB, signal present on the other line input channel. Units are in dB.

Line-level

Refers to a consumer equipment compatible, voltage driven interface. The term implies a low driver impedance and a minimum 10 kΩ load impedance.

PATHS

A-D: Analog in, through the ADCs, onto the serial link.

D-A: Serial interface inputs through the DACs to the analog output.

A-A: Analog in to Analog out (analog mixer).

PC 99

CS4205

Refers to the PC 99 System Design Guide published by the Microsoft

PC 2001

Refers to the PC 2001 System Design Guide published by the Microsoft

PLL

Phase Lock Loop. Circuitry for generating a desired clock from an external clock source.

Resolution

The number of bits in the output words to the DACs, and in the input words to the ADCs.

Signal to Noise Ratio (SNR)

SNR, similar to DR, is the ratio of an arbitrary sinusoidal input signal to the RMS sum of the noise floor, in the presence of a signal. It is measured over a 20 Hz to 20 kHz bandwidth with units in dB.

S/PDIF

Sony/Phillips Digital Interface. This interface was established as a means of digitally interconnecting consumer audio equipment. The documentation for S/PDIF has been superseded by the IEC-958 consumer digital interface document.

Corporation [7].

Corporation [8].

SRC

Sample Rate Converter. Converts data derived at one sample rate to a differing sample rate. The CS4205 operates at a fixed sample frequency of 48 kHz. The internal sample rate converters are used to convert digital audio streams playing back at other frequencies to 48 kHz.

Total Harmonic Distortion plus Noise (THD+N)

THD+N is the ratio of the RMS sum of all non-fundamental frequency components, divided by the RMS full-scale signal level. It is tested using a -3 dB FS input signal and is measured over a 20 Hz to 20 kHz bandwidth with units in dB FS.

76 DS489PP2

16. REFERENCE DESIGN

C11

0.1uF

X7R

C10

0.1uF

X7R

+5VA+12V

U1 MC78M05ACDT

10uF

ELEC

0.1uF

X7R

+3.3VD

OUT

GND

0.1uF

10uF

AGND

X7R

ELEC

0.1uF

X7R

0.1uF

X7R

AC LINK

AVdd2

AVdd1

AVss2

AVss1

DVdd1

DVdd2

CS4205

C17 10uF

PHONO-1/8

S/PDIF

OUT

R13

220k

AGND

R11

220k

ELEC

C35

1000pF

NPO

AGND

C34

1000pF

NPO

MONO_OUT

ID1#46ID0#

EAPD/SCLK

GPIO0/LRCLK

SPDO/SDO2

GPIO2/SDI1

GPIO4/SDI3

GPIO3/SDI2

GPIO1/SDOUT

XTL_OUT

XTL_IN

43521

LINE OUT

JACK

ASYNC

ARST#

ABITCLK

ASDOUT

ASDIN

PCI Audio Controller

or ICH Controller

AGND

R7 47

R8 47

SYNC

RESET#

BIT_CLK

SDATA_IN

SDATA_OUT

ELEC

C15 10uF

ZSCLK

ZSDATA33ZLRCLK

LINE_OUT_R

LINE_OUT_L

CS4205

DVss1

DVss2

PC_BEEP

AUX_L14AUX_R

CD_L18CD_GND19CD_R20MIC121MIC222LINE_IN_L23LINE_IN_R

DGND

PHONE

VIDEO_L16VIDEO_R

REFFLT27Vrefout28AFLT129AFLT2

AFLT3

TOTX-173

12345

DGND

R18

8.2k

C26

0.1uF

X7R

DGND

+5VD

60 mil trace

GND_TIE

DGND AGND

Tie at one point

only under the codec

C33

22pF

C25

1000pF

NPO

AGND

C24

1000pF

NPO

C23

NPO

1000pF

C22

0.1uF

X7R

NPO

DGND

(50 PPM)

24.576 MHz

C32

22pF

NPO

DGND

Figure 35. CS4205 Reference Design

C21

2.2uF

Z5U

MIC IN -3 dB roll-off

frequencies at 60 Hz.

and 16 KHz in

X7R

C1 0.1uF

2700pF

R1 47k

PC SPEAKER

X7R

AGND

LINE IN

ELEC

C19 10uF

R14 6.8kJ5

43521

ELEC

C20 10uF

R15 6.8k

R17 6.8k

R16 6.8k

AGND

PHONO-1/8

+5VA

R21 1.5kR19 2.2k

43521

MIC IN

C28 0.1uF

R20 100

X7R

4.7k

2X1HDR-SN/PB

ELEC

C7 10uF

AGND

R3 6.8k

DGND

AUX IN

ELEC

C12 10uF

R4 6.8k

R6 6.8k

R5 6.8k

123

4X1HDR-AU

ELEC

C13 10uF

C14 10uF

R9 100k

AGND

CD IN

ELEC

C16 10uF

R10 100k

R12 100k

123

4X1HDR-AU

accordance with PC-99

C29

0.1uF

X7R

AGND

C30

10uF

ELEC

AGNDAG ND

PHONO-1/8

DS489PP2 77

17. REFERENCES

1) Cirrus Logic, Audio Quality Measurement Specification, Version 1.0, 1997

http://www.cirrus.com/products/papers/meas/meas.html

CS4205

2) Cirrus Logic, AN18: Layout and Design Rules for Data Converters and Other Mixed Signal Devices Version 6.0, February 1998

3) Cirrus Logic, AN22: Overview of Digital Audio Interface Data Structures

, Version 2.0, February 1998

4) Cirrus Logic, AN134: AES and S/PDIF Recommended Transformers, Version 2, April 1999

5) Cirrus Logic, AN165: CS4297A/CS4299 EMI Reduction Techniques

6) Intel

, Audio Codec ’97 Component Specification, Revision 2.1, May 1998

, Version 1.0, September 1999

http://developer.intel.com/ial/scalableplatforms/audio/index.htm

7) Microsoft®, PC 99 System Design Guide, Version 1.0, July 1999

http://www.microsoft.com/hwdev/desguid/

8) Microsoft

, PC 2001 System Design Guide, Version 0.9, August 2000

http://www.pcdesguide.org/pc2001/default.htm

9) Intel® 82801AA (ICH) and 82801AB (ICH0) I/O Controller Hub, June 1999

http://developer.intel.com/design/chipsets/datashts/290655.htm4

78 DS489PP2

18. PACKAGE DIMENSIONS

48L LQFP PACKAGE DRAWING

CS4205

∝

INCHES MILLIMETERS

DIM MIN NOM MAX MIN NOM MAX

A --- 0.055 0.063 --- 1.40 1.60

A1 0.002 0.004 0.006 0.05 0.10 0.15

B 0.007 0.009 0.011 0.17 0.22 0.27

D 0.343 0.354 0.366 8.70 9.0 BSC 9.30

D1 0.272 0.28 0.280 6.90 7.0 BSC 7.10

E 0.343 0.354 0.366 8.70 9.0 BSC 9.30

E1 0.272 0.28 0.280 6.90 7.0 BSC 7.10

e* 0.016 0.020 0.024 0.40 0.50 BSC 0.60

L 0.018 0.24 0.030 0.45 0.60 0.75

∝

* Nominal pin pitch is 0.50 mm

0.000° 4° 7.000° 0.00° 4° 7.00°

Controlling dimension is mm. JEDEC Designation: MS022

DS489PP2 79

Cirrus Logic CS4205-KQ Datasheet

Specifications and Main Features

Frequently Asked Questions

User Manual

Features

Description

ANALOG CHARACTERISTICS (Standard test conditions unless otherwise noted: T

ABSOLUTE MAXIMUM RATINGS (AVss1 = AVss2 = DVss1 = DVss2 = 0 V)

RECOMMENDED OPERATING CONDITIONS (AVss1 = AVss2 = DVss1 = DVss2 = 0 V)

Figure 1. Power Up Timing

Figure 2. Codec Ready from Start-up or Fault Condition

Figure 3. Clocks

Figure 4. Data Setup and Hold

Figure 5. PR4 Powerdown and Warm Reset

Figure 6. Test Mode

2.1 AC-Link

Figure 7. AC-link Connections

2.2 Control Registers

2.3 Sample Rate Converters

2.4 Mixers

2.5 Input Mux

2.6 Volume Control

2.7 Dedicated Mic Record Path

Figure 8. CS4205 Mixer Diagram

3.1 Analog Centric Mode

Figure 9. Digital Signal Path Overview

3.2 Digital Centric Mode

3.3 Host Processing Mode

3.4 Multi-Channel Mode

Figure 11. Digital Centric Mode

Figure 10. Analog Centric Mode

Figure 12. Host Processing Mode

Figure 13. Multi-Channel Mode

Figure 14. AC-link Input and Output Framing

4.1 AC-Link Serial Data Output Frame

4.2 AC-Link Serial Data Input Frame

4.3 AC-Link Protocol Violation - Loss of SYNC

6.1 Overview

6.2 Multi-Channel Expansion

Figure 15. Serial Data Port: Six Channel Circuit

6.3 Digital Docking

6.4 Serial Data Formats

Figure 16. Digital Docking Connection Diagram

Figure 17. Serial Data Format 0 (I2S)

Figure 19. Serial Data Format 2 (Right Justified, 20-bit data)

Figure 20. Serial Data Format 3 (Right Justified, 16-bit data)

Figure 18. Serial Data Format 1 (Left Justified)

Figure 21. ZV Port Format (I2S, 16-bit data)

Figure 22. S/PDIF Output

10.1.1 Cold Reset

10.1.2 Warm Reset

10.1.3 New Warm Reset

10.1.4 Register Reset

10.2 Powerdown Controls

11.1 PLL Operation (External Clock)

11.2 24.576 MHz Crystal Operation

11.3 Secondary Codec Operation

Figure 23. PLL External Loop Filter

Figure 24. External Crystal

12.1 Analog Inputs

12.1.1 Line Inputs

12.1.2 CD Input

Figure 25. Line Input (Replicate for Video and AUX)

Figure 28. Microphone Input

12.1.3 Microphone Inputs

12.1.4 PC Beep Input

12.2 Analog Outputs

12.1.5 Phone Input

Figure 29. PC_BEEP Input

Figure 30. Modem Connection

Figure 31. Stereo Output

12.2.1 Stereo Output

12.2.2 Mono Output

12.3 Miscellaneous Analog Signals

12.5 Reference Design

12.4 Power Supplies

Figure 32. +5V Analog Voltage Regulator

Figure 33. Conceptual Layout for the CS4205 when in XTAL or OSC Clocking Modes

Figure 34. Pin Locations for the CS4205

Figure 35. CS4205 Reference Design
