User Manual
Table of Contents
TABLE OF CONTENTS
1.Before You Begin ........................................................................ 1
What Is Included ........................................................................................... 1
Unpacking Instructions.................................................................................. 1
Text Conventions .......................................................................................... 1
Symbols ........................................................................................................ 1
Disclaimer ..................................................................................................... 1
Product at a Glance ...................................................................................... 2
Safety Notes.................................................................................................. 2
2.Introduction ................................................................................. 3
Product Overview.......................................................................................... 3
Product Dimensions ...................................................................................... 4
3.Setup ............................................................................................ 5
AC Power...................................................................................................... 5
Resetting the Breaker ................................................................................... 5
4.Operation ..................................................................................... 6
Control Priority .............................................................................................. 6
DMX Linking.................................................................................................. 7
Starting Address............................................................................................ 7
5.Maintenance and Storage........................................................... 8
Hazer Maintenance....................................................................................... 8
Storage.......................................................................................................... 8
6.Technical Specifications ............................................................ 9
Returns............................................................................................ 10
Contact Us ...................................................................................... 11
Cumulus User Manual Rev. 4
BEFORE YOU BEGIN
1. BEFORE YOU BEGIN
What Is Included
• Cumulus
• Overflow Tubing
• Hose and Square Holder
Unpacking Instructions
Carefully unpack the product immediately and check the container to make sure all the parts are in the
package and are in good condition.
Claims
If the box or the contents (the product and included accessories) appear damaged from shipping, or show
signs of mishandling, notify the carrier immediately, not Chauvet. Failure to report damage to the carrier
immediately may invalidate your claim. In addition, keep the box and contents for inspection.
For other issues, such as missing components or parts, damage not related to shipping, or concealed
damage, file a claim with Chauvet within 7 days of delivery.
Text Conventions
CONVENTION MEANING
1–512 A range of values
50/60 A set of values of which only one can be chosen
Settings A menu option not to be modified
<ENTER> A key to be pressed on the product’s control panel
ON A value to be entered or selected
• Power Cord
• Warranty Card
• Quick Reference Guide
Symbols
SYMBOL MEANING
Electrical warning. Not following these instructions may cause electrical damage to
the product, accessories, or the user.
Critical installation, configuration, or operation information. Not following these
instructions may make the product not work, cause damage to the product, or cause
harm to the operator.
Important installation or configuration information. The product may not function
correctly if this information is not used.
Useful information.
Disclaimer
Chauvet believes that the information contained in this manual is accurate in all respects. However,
Chauvet assumes no responsibility and specifically disclaims any and all liability to any party for any loss,
damage or disruption caused by any errors or omissions in this document, whether such errors or
omissions result from negligence, accident or any other cause. Chauvet reserves the right to revise the
content of this document without any obligation to notify any person or company of such revision, however,
Chauvet has no obligation to make, and does not commit to make, any such revisions. Download the latest
version from www.chauvetdj.com
The works of authorship contained in this manual, including, but not limited to, all design, text and images
are owned by Chauvet.
© Copyright 2018 Chauvet & Sons, LLC. All rights reserved.
Electronically published by Chauvet in the United States of America.
CHAUVET, the Chauvet logo, and Cumulus are registered trademarks or trademarks of Chauvet & Sons
LLC (d/b/a Chauvet and Chauvet Lighting) in the United States and other countries. Other company and
product names and logos referred to herein may be trademarks of their respective companies.
.
Cumulus User Manual Rev. 4
Page 1 of 11
Product at a Glance
BEFORE YOU BEGIN
Use on Dimmer
Outdoor Use
Sound-Active
DMX
Master/Slave
Safety Notes
• Not intended for permanent installations.
• Always connect the product to a grounded circuit to avoid the risk of electrocution.
• Make sure the power cord is not crimped or damaged.
• Never disconnect the power cord by pulling or tugging on the cord.
• Make sure there are no flammable materials close to the unit while operating
• Do not touch the output nozzle on this product. It is very hot during operation and it may
remain hot for several hours after turning the unit off.
• Do not drink the haze fluid. If you do, call your local emergency service (911 in the US) for
help.
• Do not add perfume, alcohol, gasoline, or any other flammables to the haze fluid.
• Depending on the amount of haze generated, all haze machines may set off smoke
detectors.
• Do not use for space heating purposes.
• Use only CHAUVET DJ water-based haze fluid.
• Drain the tank before transporting the product.
• Condensation may form on the bottom of the product, creating damp or wet conditions
under and around the Cumulus. Use caution! Surfaces around the product may become
slippery.
Auto Programs
Auto-ranging Power Supply
Breaker
User-Serviceable
• Always make sure that the voltage of the outlet to which you are connecting the product is
within the range stated in the decal or rear panel of the product.
• This product is for indoor use only! To prevent risk of fire or shock, do not expose this
product to rain or moisture.
• Always install this product in a location with adequate ventilation, at least 20 in (50 cm) from
adjacent surfaces.
• Be sure that no ventilation slots on the unit’s housing are blocked.
• Never connect this product to a dimmer or rheostat.
• Never carry the product from the power cord or any moving part. Always use the hanging/
mounting bracket.
• The maximum ambient temperature (Ta) is 104 °F (40 °C). Do not operate this product at
higher temperatures.
• In the event of a serious operating problem, stop using the product immediately.
• Never try to repair this product. Repairs carried out by unskilled people can lead to damage
or malfunction. Please contact the nearest authorized technical assistance center.
• To eliminate unnecessary wear and improve its lifespan, during periods of non-use
completely disconnect the product from power via breaker or by unplugging it.
Keep this User Manual for future use. If you sell the product, be sure that the purchaser
receives this document.
Page 2 of 11
Cumulus User Manual Rev. 4
INTRODUCTION
DMX IN
DMX OUT
DMX OUT
DMX IN
BREAKER
POWER SWITCH
POWER IN:
120V 60HZ
DMX In/Out
(3- and 5-pin)
Fluid Tank
Fixed Power
Cable
Power Switch
LED Display
Breaker
Drainage
Valves
Water Tank
Fans
Nozzle
Overflow
Hole
Fog Fluid Level
Indicator
2. INTRODUCTION
Product Overview
Cumulus User Manual Rev. 4
Page 3 of 11
Product Dimensions
18 in
457 mm
16 in
406 mm
25 in
635 mm
INTRODUCTION
Page 4 of 11
Cumulus User Manual Rev. 4
SETUP
3. SETUP
AC Power
The Cumulus has a fixed voltage power supply and it can work with an input voltage of either 120 VAC, 60
Hz or 230 VAC, 50 Hz, depending on the specific model.
To eliminate wear and improve its lifespan, during periods of non-use completely
disconnect the product from power via breaker or by unplugging it.
While operating the Cumulus, make sure there is adequate haze fluid in the machine
to prevent pump and heater damage. When the haze fluid level becomes low, simply
add more haze fluid to continue using the Cumulus.
This product may NOT be tilted. This product should be level when on a surface.
Resetting the Breaker
This product is equipped with a resettable circuit breaker. If the breaker trips, all sections of this product will
lose power.
1. Remove the power cord from mains power.
2. Allow unit to cool for 15 minutes.
3. After 15 minutes, you may attempt to reset the breaker by pressing the button with your finger.
4. Plug the product’s power cord into the power outlet and continue using as recommended.
Cumulus User Manual Rev. 4
Page 5 of 11
OPERATION
4. OPERATION
Control Priority
The Cumulus operates according to the following priority control levels:
Control Panel Operation
To access the control panel functions, use the four buttons located underneath the display, and the two
manual control knobs located to the right of the display. Please refer to the Product Overview to see the
button and knob locations on the control panel.
Control Panel Description
BUTTON/KNOB FUNCTION
<MENU> Exits from the current menu or function
<UP/TIMER>
<DOWN/
VOLUME>
<ENTER/
STOP>
Programming
Refer to the Menu Map to understand the menu options. The menu map shows the main level and a
variable number of programming levels for each option.
• To go to the desired main level, press <FUNCTION> repeatedly until the option shows on the
display. This will take you to the first programming level for that option.
• To select an option or value within the current programming level, press <UP> or <DOWN> until the
option shows on the display. If there is another programming level, you will see that first option, or
you will see the selected value.
•Press <FUNCTION> repeatedly to exit to the previous main level.
Operation
1. Place the machine on a level surface. Plug the power cord into the wall.
2. Remove the top lid.
3. Fill the water tank with distilled water to the maximum fill line located on the inside of the tank. The
container can hold up to 2 gal or (7.6 l).
4. Fill the fluid tank with CHAUVET haze or fog fluid to the maximum fill line located on the outside of
the tank. The container can hold up to 1 gal (3.8 l).
5. Turn the product on using the power switch on the back panel. Make sure the fans are operating
properly.
6. Using the control panel, set the product to the desired operating mode.
UP navigates upwards through the menu list and increases the numeric value when in
a function.
TIMER starts the timer controlled operation
DOWN navigates downwards through the menu list and decreases the numeric value
when in a function.
VOLUME triggers the pump to modify the output volume
ENTER enables the currently displayed menu or sets the currently selected value into
the selected function.
STOP turns the fog output off.
• Due to water evaporation, you may need to refill the Cumulus with water to
continue triggering the machine.
• The Cumulus is fitted with a safety shutoff feature, which prevents the unit’s
heaters from turning on when the water level is too low. If this safety shutoff
feature has been engaged, simply add more water to continue using the
Cumulus.
Page 6 of 11
The Cumulus can operate with the top lid on or off.
Cumulus User Manual Rev. 4
OPERATION
Menu Map
MODE PROGRAMMING LEVELS DESCRIPTION
Interval Set 5–200 Sets the interval between fog output
Duration Set 5–200 Sets the duration of the fog output
Timer Out 1-100% Sets the output volume in timer mode
Volume Out 1–100% Fog volume 1–100%
Fan Speed 1–100% Fan Speed (slow to fast)
Fluid Sensor ON/OFF Turns the fluid sensor ON or OFF
DMX 512 1–512 Selects the DMX starting address
Direct Timer ON/OFF Enables/disables the timer
If the product is turned off while in timer mode, the product will still be in timer mode
when the product is turned back on.
Ensure both valves are closed before filling the product with fluids.
Condensation may form on the bottom of the product, creating damp or wet
conditions under and around the Cumulus. Use caution! Surfaces around the
product may become slippery.
DMX Linking
The Cumulus can work with a DMX controller. Instructions for connecting and configuring this product for
DMX operation are in the User Manual. If you are not familiar with DMX, download the DMX Primer from
www.chauvetdj.com.
Starting Address
To ensure full access to all channels available in DMX mode, the highest recommended DMX address is
511.
Allow the Cumulus three minutes to heat up before continuing.
DMX Values
2-CH
CHANNEL FUNCTION VALUE PERCENT/SETTING
000
1 Fan Speed
2 Fog Output
010 No function
011
512 1–100%
000
010 No function
011
512 1–100%
Cumulus User Manual Rev. 4
Page 7 of 11
MAINTENANCE AND STORAGE
5. MAINTENANCE AND STORAGE
Hazer Maintenance
Do not allow the fogger to become clogged. After every 40 hours of continuous operation, use CHAUVET
Fog Cleaner Quart (FCQ) through the system to prevent the accumulation of particulate matter in the
heating element.
The recommended cleaning procedure is as follows.
1. Unplug the product from power.
2. Empty all fog fluid from the machine.
3. Add cleaning solution to the tank.
4. Connect the product to power and allow it to warm up.
5. Run the unit in a well-ventilated area until the tank is almost empty. Do not allow the pump to run
dry.
6. Refill with fog fluid to continue using the fogger. Run the machine briefly to clear any remaining
cleaning solution from the pump and heater.
Never operate the machine without fluid.
Fog Cleaner Quart (FCQ) was specifically developed by Chauvet to clean your
Cumulus. Make sure you use FCQ regularly, no longer than 90 days between
cleanings, to increase the life of your product.
Test-run your Cumulus on a monthly basis to achieve the best performance.
Storage
Before storing the fogger, run FCQ through the system as described in the cleaning procedure above;
however, only follow steps 1 through 5. Do not refill the tank with fog fluid if storing the fogger.
Cleaning the system prior to storage will help prevent any particles from condensing inside the pump or
heater while not in use.
Page 8 of 11
Cumulus User Manual Rev. 4
TECHNICAL
6. TECHNICAL SPECIFICATIONS
Dimensions and Weight
LENGTH WIDTH HEIGHT WEIGHT
25 in (635 mm) 16 in (406 mm) 18 in (457 mm) 58.8 lb (26.7 kg)
Note: Dimensions in inches rounded to the nearest decimal digit.
Power
POWER SUPPLY TYPE RANGE VOLTAGE SELECTION
Fixed
PARAMETER 120 V, 60 HZ 230 V, 50 HZ
Consumption 970 W 970 W
Operating Current 8 A 4 A
Breaker F 8 A, 250 V F 8 A, 250 V
POWER I/O U.S./WORLDWIDE UK/EUROPE
Power input connector IEC IEC
Power Cord plug Edison (U.S.) Local Plug
Operation
HEAT-UP TIME FLUID TANK CAPACITY WATER TANK CAPACITY
3 min 1 gal (3.8 l) 2 gal (7.6 l)
3 min Consumption: 80ml/min Consumption: 930 ml/min
120 VAC, 60 Hz, or 230 VAC, 50 Hz
Fixed
Thermal
MAXIMUM EXTERNAL TEMPERATURE COOLING SYSTEM
104 °F (40 °C) Convection
DMX
I/O CONNECTOR CHANNEL RANGE
3-pin or 5-pin XLR 2
Ordering
PRODUCT NAME ITEM CODE UPC NUMBER
Cumulus (120 V) 05071416 781462217648
Cumulus (230 V) 05071420 781462217686
Cumulus User Manual Rev. 4
Page 9 of 11
RETURNS
RETURNS
In case you need to get support or return a product:
• If you are located in the U.S., contact Chauvet World Headquarters.
• If you are located in the UK or Ireland, contact Chauvet Europe Ltd.
• If you are located in Mexico, contact Chauvet Mexico.
• If you are located in Benelux, contact Chauvet Europe BVBA.
• If you are located in any other country, DO NOT contact Chauvet. Instead, contact your local
distributor. See www.chauvetdj.com
Benelux.
If you are located outside the U.S., UK, Ireland, Mexico, or Benelux, contact your
distributor of record and follow their instructions on how to return Chauvet products to
them. Visit our website www.chauvetdj.com
Call the corresponding Chauvet Technical Support office and request a Return Merchandise Authorization
(RMA) number before shipping the product. Be prepared to provide the model number, serial number, and
a brief description of the cause for the return.
Send the merchandise prepaid, in its original box, and with its original packing and accessories. Chauvet
will not issue call tags.
Clearly label the package with the RMA number. Chauvet will refuse any product returned without an RMA
number.
Write the RMA number on a properly affixed label. DO NOT write the RMA number
directly on the box.
for distributors outside the U.S., UK, Ireland, Mexico, or
for contact details.
Before sending the product, clearly write the following information on a piece of paper and place it inside
the box:
• Your name
• Your address
• Your phone number
•RMA number
• A brief description of the problem
Be sure to pack the product properly. Any shipping damage resulting from inadequate packaging will be
your responsibility. FedEx packing or double-boxing are recommended.
Chauvet reserves the right to use its own discretion to repair or replace returned
product(s).
Page 10 of 11
Cumulus User Manual Rev. 4
CONTACT US
CONTACT US
World Headquarters
EUROPE
MEXICO
Address: Av. de las Partidas, 34-3B, Zona
Industrial Lerma (Entrance by Calle 2)
Lerma, Edo. de Mexico C.P. 52000
General Information Technical Support
Address: 5200 NW 108th Ave. Voice: (844) 393-7575
Sunrise, FL 33351 Fax: (954) 756-8015
Voice: (954) 577-4455 Email: chauvetcs@chauvetlighting.com
Fax: (954) 929-5560
Toll Free: (800) 762-1084 www.chauvetdj.com
Website
General Information Technical Support
Address: Stokstraat 18 Email: eutech@chauvetlighting.eu
9770 Kruishoutem
Belgium www.chauvetdj.eu
Voice: +32 9 388 93 97
Website
General Information Technical Support
Address: Unit 1C Email: uktech@chauvetlighting.com
Brookhill Road Industrial Estate
Pinxton, Nottingham, UK
NG16 6NT www.chauvetdj.eu
Voice: + 44 (0) 17 73 511115
Fax : +44 (0) 1773 511110
Website
General Information Technical Support
Email: servicio@chauvet.com.mx
Website
Voice: +52 (728) 690-2010 www.chauvetdj.mx
Visit the applicable website above to verify our contact details and instructions to request support.Outside
the U.S., United Kingdom, Ireland, Mexico or Benelux, contact the dealer of record.
Cumulus User Manual Rev. 4
Page 11 of 11
Loading...
