INSTRUCTION MANUAL
PLEASE READ ALL THE INSTRUCTIONS
COMPLETELY BEFORE USE
AND SAVE THIS MANUAL
FOR FUTURE REFERENCE.
Pocket Radio
Before Use
Please read IMPORTANT SAFETY
INSTRUCTIONS on pages 23-25
before
use. It is important to read and understand all instructions. Keep these precautions and instructions where all who use
this radio will read them.
WARNING: TO PREVENT FIRE OR ELEC-
TRIC SHOCK HAZARD, DO NOT EXPOSE
THIS PRODUCT TO RAIN OR MOISTURE.
THE LIGHTNING FLASH AND ARROWHEAD WITHIN THE TRIANGLE IS A
WARNING SIGN ALERTING YOU OF
“DANGEROUS VOLTAGE” INSIDE THE
RADIO.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE RADIO
BACK. NO USER SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
THE EXCLAMATION POINT WITHIN
THE TRIANGLE IS A WARNING SIGN
ALERTING YOU OF IMPORTANT
INSTRUCTIONS ACCOMPANYING
THIS RADIO.
CAUTION
RISK OF ELECTRIC
SHOCK DO NOT OPEN
CCRadio-SWP Page 3
For your future reference:
Serial No.
(found inside battery compartment)
Date of Purchase
Name & Address of Dealer
The box should contain the CCRadio-SWP,
earbuds, carry pouch and this manual. If anything is missing or damaged, please contact
your dealer immediately. We recommend you
keep the box in the unlikely event your radio
needs to be serviced.
Unpacking
Copyright ©2007 by
C. Crane Company, Inc.
1001 Main St, Fortuna, CA 95540
Phone: 1-800-522-8863 Web: ccrane.com
All rights reserved. No part of this booklet may
be reproduced, in any form or means whatsoever, without permission in writing from
C. Crane Company, Inc.
Page 4 CCRadio-SWP
Quick Start
1.
Slide
K
(pg. 10) “SENSITIVITY”
switch to “DX” position.
2.
Install two AA batteries in the
g
battery compartment, paying
close attention to orientation of the
batteries’ + and – ends.
3.
Turn on the radio by pressing the
Q
POWER button.
4.
Adjust
I
“VOLUME”
5.
Select band by pressing the
{
BAND button
6.
Use the
W
“TUNING” knob to
locate a station or by directly
entering a frequency:
a) First, select the
{
BAND you
want
b) press the
}
“FREQ” UENCY”
button
c) Enter the frequency on the
q
keyboard.
CCRadio-SWP Page 5
Table of Contents
Unpacking ............................................... 3
Quick Start ............................................... 4
Radio Identification ........................... 6-11
Features and Operation Explained
Introduction ............................ 12
Power Sleep Button ............... 12
Tuning Knob ............................ 13
Light ........................................ 14
Setting Clock Time ................ 14
Saving Stations to Memory ... 14
Display Button ..................... 15
Setting the Alarm .................. 16
Favorites ................................ 16
Up and Down Buttons ........... 17
Band Button .......................... 17
Frequency Button .................. 18
0-9 Keys ................................. 18
Performance Tips ........................... 19-20
Troubleshooting Guide .......................... 21
Specifications ......................................... 22
Power Adapter ...................................... 22
Safety Instructions ........................... 23-25
Shortwave Tips ................................. 26-27
Station Log ........................................ 28-31
Page 6 CCRadio-SWP
Radio Identification — Front View
Q
W
E
R
T
Y
U
I
O
P
{
}
q
w
CCRadio-SWP Page 7
O
UP , Frequency, Time,
Memory Tune
P
DOWN , Frequency, Time,
Memory Tune
{
BAND, Change Bands,
•
9-10 kHz steps
} “
FREQ” UENCY, Press to enter
Frequency
q
0-9 KEYS, Direct Frequency
and Memory access
w
LCD Display
Q
POWER and SLEEP Timer
W
TUNING Knob
E
LIGHT Button
R
MEMORY, TIME SET Button
T
DISPLAY, Time, Frequency,
Alarm, AM Step, 12/24 Hour
Y
ALARM, (De)Activate Alarm,
Set Alarm Time
U
FAVORITES, Tune
Memories only
I
VOLUME, Up and Down
<
>
Page 8 CCRadio-SWP
Radio Identification — LCD Display
e r t y u
i o p [
]G
D AS
F
J
H
CCRadio-SWP Page 9
]
kHz indicates Kilohertz while in AM
and SW bands only
A
MHz indicates Megahertz in FM band
S
Time or Frequency display
D
AM/PM show while in 12 hour
time format
F
SWI or SWII, indicates Shortwave I
or Shortwave II
G
MW indicates “AM” in U.S.
(medium wave)
H F
M indicates radio is in FM band
J
BATTERY flashing indicates batteries
are low
e
FM STEREO indicator, displays
only when headphones are used
r
TUNE indicator means a
station or noise is high
t
SLEEP FUNCTION indicator
y
AL means alarm is active
u
AUTO, Radio alarm or goes to
Buzzer, if radio is already “on”
i
BUZZER indicates buzzer
type
alarm
o
LOCK switch is “on”
p
M.SCAN (FAVORITES), tunes
memorized stations only
[
Indicates memory channel num-
ber 00-199 for Memory Stations
Page 10 CCRadio-SWP
Radio Identification — Sides
K
DX - LOCAL switches Sensitivity of
SW and FM bands
L
EARPHONE jack
:
DC Power Jack, 3 Volts, Tip Negative
a
TUNING KNOB adjusts Frequency,
Time, Presets
s
BASS - NORMAL Switch, select for
best sound
d
LOCK, press to lock, hold for
1 second to unlock
K
L
:
a
s
d
CCRadio-SWP Page 11
Radio Identification — Back
f WHIP
ANTENNA used for FM and
SW bands
g
BATTERY COMPARTMENT
LOCATION, insert 2 “AA” batteries
h
RESET HOLE for resetting radio
(located on bottom of radio)
f
g
h
Page 12 CCRadio-SWP
Features and Operation Explained
Introduction
The CCRadio-SWP is the perfect size for
packing around. It is unusually good at picking up stations. Audio is clear for its size,
while taking as long as 70 hours to wear
down a set of two AA batteries. Using the
Tuning knob can be wearisome as it is with
any small radio. The SWP has a novel way
to zip around the bands to your favorite stations. “FAVORITES” (Memory Scan) can be
used to quickly access all of your AM/FM
and SW stations rapidly and across bands
without pressing buttons. We encourage
you to learn how to memorize a station
(page 14). You can then use the
“FAVORITES” button and the Tuning Knob
to quickly scan your memory presets.
POWER • SLEEP Button
When you press and release the “POWER”
button the first time, you will see “on” displayed for about two seconds. Press the
“POWER” button again to turn the radio off.
To change to a “SLEEP” setting, press
“POWER” again during the short time the
“on” is displayed. It will first show “90” min-
utes and then decrease by five minutes for
Q
CCRadio-SWP Page 13
Features and Operation Explained
each successive press. You have a choice
of “on”, and from 90 minutes down to 5 minutes by 5-minute steps. Stop on the setting
you desire and it will be remembered for
your convenience each time you turn the
radio “on” again. If you select any one of
the sleep settings, except “on”, the SLEEP
symbol will be displayed while the
radio is “on”. When “on” is selected, the
radio will simply turn on and off each time
the power button is pushed.
Pressing the “POWER • SLEEP” button
while the radio is operating on any of the
SLEEP settings will turn the radio off.
TUNING KNOB
Turn the Tuning Knob while the radio is on
to tune to a different frequency.
When setting the clock or alarm, it is also a
good way to change the time, rather then
using the up and down buttons.
The Tuning Knob also works when you
have your favorite stations in memory. You
can press “FAVORITES” and use the tuning
knob to quickly access your memorized station. See page 16 for
U
“FAVORITES”.
W
Page 14 CCRadio-SWP
LIGHT
Pressing the “LIGHT” button will give you
about eight seconds of light on the display.
SETTING CLOCK TIME /SAVING A
STATION TO MEMORY
The Memory/Time SET key works in two
ways:
1. When the radio is “off” press and hold
for one second until “Hour” flashes. You
have eight seconds to set the hour. Use
either the Tuning Knob or “UP” and
“DOWN” buttons. Press again to set the
minutes. Press a third time to confirm
when done. You can change from 12
hour to 24 hour clock format by holding
the “DISPLAY” button for five seconds.
2. When the radio is “on” the key is used
to store a station into memory. First, tune
to a station or frequency you want. Press
“MEM T.SET and will blink in the
upper right corner of the LCD display.
Rotate the Tuning Knob to the memory
channel where you want to store the station. The memory channels are numbered from “00” to “199”. Press “MEM
T.SET” again to finalize the memorized
Features and Operation Explained
E
R
CCRadio-SWP Page 15
station. There is a log in the back of this
manual on pages 28-31 to help you
organize your stations. Your memories
will not be lost when batteries go dead or
if you reset the radio.
DISPLAY button
The DISPLAY button works in two ways:
1. When the radio is “on” the LCD display
normally shows the frequency. Pressing
the “DISPLAY” button will toggle the display through “ALARM TIME”, “TIME” of
day, and “SLEEP” timer status. It will
show the minutes left on the “SLEEP”
timer or “on” if the sleep timer is not
being used.
2. When the radio is “off” the LCD display
normally shows the time of day. Pressing
the “DISPLAY” button will toggle the display through “ALARM TIME”, tuning
steps for AM, and your choice of 12 or
24 hour clock format. While the radio is
“off”, you can change from 12 hour to 24
hour clock format by holding the “DISPLAY” button for five seconds. Change it
back using the same method. See
{
“BAND” button on page 17 to change
tuning steps for AM.
Features and Operation Explained
T
Page 16 CCRadio-SWP
Features and Operation Explained
SETTING THE ALARM
You can activate or deactivate the alarm if
the radio is “on” or “off”. Pushing the
“ALARM” button once sets the alarm to
and the “radio” alarm. (The radio will
alarm on the last station listened to.) A second push of the “ALARM” button sets the
alarm to “buzzer” . A third press of the
“ALARM” button turns off both icons and
the radio will not alarm. Press the “Power”
button to stop the alarms when they come
on.
The alarm will not work if head-
phones are plugged in.
Set the alarm time
with the radio “off”.
Press and hold the “ALARM” button for two
seconds. Use the Tuning Knob to set the
hours, press the “ALARM” button again and
set the minutes. You must press the
“ALARM” button again when done to confirm the “ALARM” time.
If the alarm is set to “AUTO” and you happen to have the radio “on” at the alarm
time, then the buzzer will automatically
come on, too.
FAVORITES
Pressing the “FAVORITES” key allows you to
Y
U
CCRadio-SWP Page 17
UP and DOWN Buttons
These buttons can be used to tune the
radio one step at a time or “press and hold”
to scan for the next strong station.
The buttons can also be used when setting
the time or to scroll through memorized stations while in
U
FAVORITES (Memory
Scan) mode.
BAND button
Pressing the “BAND” button with the radio
“on” changes bands in order: FM, AM, SW1,
and SW2.
With the radio “off”, the “BAND” button can
be pressed and held for five seconds to
Features and Operation Explained
<
<
O
{
P
tune the stations you have installed in mem-
ory exclusively. You can use the Tuning
Knob, “Up” and “Down” buttons, or 0-9 Keys
to change memory channels. This can save
you much time if you are familiar with the
stations in your area. There is no other
function to this button. Press “FAVORITES”
again to go back to regular tuning.
VOLUME
This is easy, up + and down -.
I
Page 18 CCRadio-SWP
change the AM tuning steps from 10 to 9
kHz. The U.S. uses 10 kHz. Most of the rest
of the world uses 9 kHz steps. It could be
important to change the AM step rate if you
use the “Up” and “Down” button to scan for
stations and you happen to be in a foreign
country.
“FREQ”UENCY Button
This is used to directly enter a frequency.
You must be in the radio band of your
choice before you enter a frequency. AM
and SW is straightforward. Press “FREQ”
and enter the AM or SW frequency using
the numbered keys. For FM you must enter
a last digit. To enter 100.3 FM you must
press “FREQ” and then press 1-0-0-3.
0-9 KEYS
These are used to directly enter a frequen-
cy or memory channel. See
}
“FREQ”-
UENCY button for direct entry.
While in
U
FAVORITES (Memory Scan)
mode you can also enter the channel number of a station you memorized. There is a
programming quirk, however. Because there
are 200 channels, you must key in 3 digits
for each number. Channel “00” through “9”
Features and Operation Explained
q
}
CCRadio-SWP Page 19
Performance Tips
While excellent for fine tuning, the Tuning
Knob moves in only 1 kHz steps. Using the
FAVORITES (Memory Scan) to dial right to
your stations is a fast and easy method
(page 16). You also have the ability to
directly enter a frequency. See Shortwave
Tips on page 26.
For best AM reception, rotate the radio for
the clearest audio. If radio noise is present,
try moving the radio to a better location so
the noise decreases. Many times this is
only a few inches or feet away. In a hotel
room, try putting it in a window sill.
For FM, the telescopic antenna “up full”
Features and Operation Explained
LCD DISPLAY
Learning the features and the correspon-
ding display icons can make your radio easier to use.
w
must be entered with a “00” in front of the
channel number. Channel numbers 10
through 19 must have a “0” entered in front
of the channel number. Example: Channel
“1” must be entered as 0-0-1.
Page 20 CCRadio-SWP
Performance Tips
usually gives best reception. The antenna
can also be rotated and shortened until the
best signal is received.
Always fully extend the telescopic antenna
for the best Shortwave reception. SW
reception can easily be improved with the
addition of a very simple antenna. A
portable SW antenna available from C.
Crane works well for travel.
Also, any insulated small diameter wire can
be wound around the whip antenna and
extended out 20' to 60'. The wire can be
mounted on the inside of an outside wall or
out a window and along the top of a nonmetal fence. Simple experimentation with
the antenna wire location is the best way.
Most of the time, leave the DX-LOCAL
switch set on DX, unless you are receiving
an overly strong station. This can keep the
strong station from overdriving the radio and
also help in listening to a weaker station
that is next to a strong station.
The buttons can be somewhat hard to
press. Check the LCD display to confirm
that you have pressed it hard enough to
register.
CCRadio-SWP Page 21
Troubleshooting Guide
This radio has a microprocessor. If the dis-
play disappears or has odd characters, try
resetting the radio. Use a toothpick or
paperclip to momentarily stick in the “reset”
hole gently. It is located on the bottom of
the radio. The radio can be “on” or “off”
when this is done. There must be power to
the radio either by AC Adapter or batteries.
NO AUDIO: Be sure the volume is up and
headphone jack does not have something
in it. The alarm will not work if headphones
are plugged in.
RADIO WILL NOT COME ON: Be sure the
“LOCK” switch is off. Press and hold for one
second to turn “LOCK” off.
BATTERIES: Do not mix old batteries with
new batteries. The battery icon flashes
when the batteries are low. You have 15
seconds to change a set of batteries or you
may have to set the clock time again.
AC ADAPTER: Make sure it is fully plugged
into the radio.
SENSITIVITY: Be sure DX-LOCAL switch is
on “DX”. DX is an abbreviation for “dis-
tance”. Be sure the antenna is up fully for
FM and SW.
Page 22 CCRadio-SWP
Specifications
1. Frequency Coverage:
FM 70.0 ~ 108.0MHz
AM (MW) 522 ~ 1628kHz (9k step)
520 ~ 1710kHz (10k step)
SW1 2300 ~ 7500kHz
SW2 9200 ~ 22000kHz
2. S/N (Signal to Noise) Sensitivity:
FM > 10uV
AM > 1mv/m (this is extraordinary)
SW > 30uV
3. AM Selectivity: > 25dB
4. Number of Memories: 200
5. Power Source:
2 (AA Size) or LR2
DC IN: 3V 150mA, Tip (-) 3.5mm x 1.3mm
6. Built-in Speaker: 25ohm 0.5W
7. Earphone Socket: 3.5mm 32ohm
8. Dimensions: 4.75" W x 3" H x 1.2" D
If you have purchased an optional AC-DC
adapter, be sure it is the correct voltage. It
should have an output of three Volts DC with
the center negative, and not less than 150
MAh. Use only the recommended adapter.
Otherwise it may damage the radio or cause a
fire or electric shock.
Power Adapter
CCRadio-SWP Page 23
Safety Instructions
To prevent damage to your radio or possi-
ble injury to you or others, read these safety precautions and instructions entirely
before applying power to your radio. Keep
these precautions and instructions where all
who use this radio will read them.
1)
COMMON CARE
Check the radio, AC adapter, batteries
and any accessories regularly. Do not
use the radio if there is any sign of damage. Only operate in accordance with
the instructions in this manual. Only use
attachments or accessories specified by
the manufacturer.
2)
PROPER BATTERY HANDLING
Never mix different type of batteries or
use old batteries with new. We recommend you remove batteries from the
radio if you are not going to use the
radio for one month or more.
3) DISCONNECT THE RADIO
IN CASE OF MALFUNCTION
If you smell or notice smoke, disconnect
READ BEFORE
OPERATING EQUIPMENT
SAVE THESE INSTRUCTIONS
Page 24 CCRadio-SWP
Safety Instructions
the AC Adapter and remove the batteries
immediately, taking care to avoid burns.
Contact C. Crane Company or their representative for inspection and service
before any future operation. Only use
the AC-DC Adapter recommended with
the unit and replace it if wires become
frayed or exposed. It should have an
output of three Volts DC with the center
negative, and not less than 150 MAh.
Use only the recommended adapter.
Otherwise it may damage the radio or
cause a fire or electric shock.
4)
KEEP OUT OF REACH
OF CHILDREN
Dropping the radio can cause damage or
injury. Keep the AC Adapter cord in a
position so someone cannot trip and
cause the radio to fall.
5)
KEEP AWAY FROM WATER
AND MOISTURE
Keep the radio dry. Liquids and moisture
can damage the radio. If a liquid leaks
into the radio do not operate and seek a
qualified service shop. To clean the
radio, remove the power and use a
damp cloth on the exterior only.
CCRadio-SWP Page 25
Safety Instructions
6) KEEP AWAY FROM
EXTREME TEMPERATURES
Extreme temperatures can damage the
radio. Do not leave or use the radio
where it can be subjected to high or very
cold temperatures.
7)
DO NOT ATTEMPT TO
SERVICE RADIO
Refer all service work to a qualified
service shop when the radio does not
appear to operate normally, exhibits a
change in performance or the radio has
received damage. Never open the radio
as this may expose you to dangerous
voltages and this will void all warranties.
8)
OUTSIDE ANTENNAS
OR CABLES
Outside antennas or cables that create a
potential hazard should not be used with
this radio unless installed by qualified
personnel.
Page 26 CCRadio-SWP
Shortwave Tips
The CCRadio-SWP covers all of the impor-
tant international broadcast bands. A “
*
”
symbol signifies where you most likely find
the best listening. They are listed by frequency and then the (meter band). There
are exceptions to every rule in Shortwave.
Reception will vary when you are in a foreign country.
The CCRadio-SWP has plenty of memory. If
you install active frequencies into memory,
you can recall them easily. When you are
trying to find a station, it is best to switch to
manual tuning, using the tuning knob.
SWI
2300~2495 kHz (120m) –
mostly tropical regions
3200~3400 kHz (90m) –
mostly tropical regions
3900~4050 kHz (75m) –
mostly Europe
4400~5100 kHz (60m) –
night, mostly tropical
5800~6300 kHz (49m) –
all year-round, night
7100~7600 kHz (41m) –
best at night
CCRadio-SWP Page 27
Shortwave Tips
SWII
9250~9995 kHz (31m) –
all year, night/winter
*
11.50~12.16 MHz (25m) –
summer; near sunset
13.57~13.87 MHz (22m) –
day and summer
15.00~15.825 MHz (19m) –
day and summer
*
17.48~17.90 MHz (16m) –
day and summer
18.90~19.02 MHz (15m) –
day, not much
21.45~21.85 MHz (13m) –
day, not much
Shortwave broadcasters use Universal Time
Coordinated (UTC) time to coordinate their
shows. You can normally find a UTC time
signal at 5,000, 10,000 or 15,000 kHz.
Station Log
Page 28 CCRadio-SWP
000
001
002
003
004
005
006
007
008
009
010
011
012
013
014
015
016
017
018
019
020
021
022
023
024
Log Pages may be copied for your use. C. Crane
025
026
027
028
029
030
031
032
033
034
035
036
037
038
039
040
041
042
043
044
045
046
047
048
049
Station Log
CCRadio-SWP Page 29
Log Pages may be copied for your use. C. Crane
050
051
052
053
054
055
056
057
058
059
060
061
062
063
064
065
066
067
068
069
070
071
072
073
074
075
076
077
078
079
080
081
082
083
084
085
086
087
088
089
090
091
092
093
094
095
096
097
098
099
Page 30 CCRadio-SWP
Station Log
Log Pages may be copied for your use. C. Crane
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
Station Log
CCRadio-SWP Page 31
Log Pages may be copied for your use. C. Crane
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
Model: CCRadio-SWP
ANSI C63.4: 2003
THIS DEVICE COMPLIES WITH PART 15 OF THE
FCC RULES. OPERATION IS SUBJECT TO THE
FOLLOWING TWO CONDITIONS.
1) THIS DEVICE MAY NOT CAUSE HARMFUL
INTERFERENCE, AND
2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE
THAT MAY CAUSE UNDESIRED OPERATION.
Notice: Any changes or modifications not express-
ly approved by the party responsible for
compliance could void the user’s authority
to operate the equipment.
Loading...
