LKS250-E-2A

USER’S GUIDE

S250

Cove

Preparing a Power Supply Turning Power On or Off Connecting Headphones

(Sold Separately)

Selecting a Musical

Instrument Tone

Changing the Pitch in

Semitone Steps (Transpose)

Fine Tuning Pitch (Tuning) Using the SUSTAIN Button

Connecting a Pedal

(Sold Separately)

Saving and Loading

Instrument Settings

(MY SETUP)

Using a Dance Music Voice Playing with a Rhythm

Playing a Built-in Song Using a Lesson to Master

Backing

Song Play

Linking with a Smart Device

(APP Function)

Playing in the Dance Music

Mode

Configuring Function Settings

Included and Optional Accessories

• Any reproduction of the contents of this manual, either in part or its entirety, is prohibited. Except for your own, personal use, any other use of the contents of this manual without the consent of CASIO is prohibited under copyright laws.

• IN NO EVENT SHALL CASIO BE LIABLE FOR ANY DAMAGES WHATSOEVER (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF PROFITS, BUSINESS INTERRUPTION, LOSS OF INFORMATION) ARISING OUT OF THE USE OF OR INABILITY TO USE THIS MANUAL OR PRODUCT, EVEN IF CASIO HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

• The contents of this manual are subject to change without notice.

• The actual appearance of the product may be different from that shown in the illustrations in this User’s Guide.

• Company and product names used in this manual may be registered trademarks of others.

Use only accessories that are specified for use with this Digital Keyboard. Use of unauthorized accessories creates the risk of fire, electric shock, and personal injury.

• You can get information about accessories that are sold separately for this product from the CASIO catalog available from your retailer, and from the CASIO website at the URL or QR code below.

https://support.casio.com/global/en/emi/manual/LK-S250/

About Music Score data

You can download music score data as a PDF file from the CASIO website, which you can access using the URL or QR code below. You will then be able to view music scores on your smart device. You can jump from the PDF file table of contents directly to the music score you want, and you can print out scores as needed.

https://support.casio.com/global/en/emi/manual/LK-S250/

EN-1

General Guide EN-3

Getting Ready to Play EN-4

Preparing a Power Supply . . . . . . . . . . . . . . . . . . . EN-4

Preparing the Music Stand . . . . . . . . . . . . . . . . . . . EN-5

Connecting Headphones (Sold Separately) . . . . . . EN-6

Connecting a Pedal (Sold Separately) . . . . . . . . . . EN-6

Connecting a Microphone

(Commercially Available) . . . . . . . . . . . . . . . . . . . EN-6

Operations Common to All Modes EN-7

Display Screen Contents. . . . . . . . . . . . . . . . . . . . . EN-7

HOME Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EN-7

3 Buttons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EN-7

Dial Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . EN-7

Key Light Function . . . . . . . . . . . . . . . . . . . . . . . . . EN-8

Playing on the Keyboard EN-8

Turning Power On or Off. . . . . . . . . . . . . . . . . . . . . EN-8

Adjusting the Volume Level. . . . . . . . . . . . . . . . . . EN-10

Using the Metronome . . . . . . . . . . . . . . . . . . . . . . EN-10

Listening to Demo Play . . . . . . . . . . . . . . . . . . . . . EN-11

Controlling the Sound of a Performance EN-12

Selecting a Musical Instrument Tone . . . . . . . . . . EN-12

Changing Keyboard Response to Touch

Pressure (Touch Response) . . . . . . . . . . . . . . . EN-12

Using a Pedal . . . . . . . . . . . . . . . . . . . . . . . . . . . . EN-13

Using the SUSTAIN Button. . . . . . . . . . . . . . . . . . EN-13

Adding Reverb to Notes . . . . . . . . . . . . . . . . . . . . EN-13

Changing the Pitch in Semitone Steps

(Transpose) . . . . . . . . . . . . . . . . . . . . . . . . . . . . EN-14

Fine Tuning Pitch (Tuning) . . . . . . . . . . . . . . . . . . EN-14

Saving and Loading Instrument Settings

(MY SETUP) EN-15

Saving to MY SETUP . . . . . . . . . . . . . . . . . . . . . . EN-15

Recalling From MY SETUP. . . . . . . . . . . . . . . . . . EN-16

Playing a Built-in Song EN-17

Songs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EN-17

Selecting a Song to Play. . . . . . . . . . . . . . . . . . . . EN-17

Assigning the Song Tone to the Keyboard

(Tone Sync) . . . . . . . . . . . . . . . . . . . . . . . . . . . . EN-19

Practicing a Song Part . . . . . . . . . . . . . . . . . . . . . EN-19

Sounding a Count in Time with a Song. . . . . . . . . EN-20

Using a Lesson to Master Song Play EN-21

Lessons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . EN-21

Selecting a Song and Taking a Lesson. . . . . . . . . EN-21

Looping Part of a Song as a Lesson

(Loop Lesson) . . . . . . . . . . . . . . . . . . . . . . . . . . EN-23

Playing in the Dance Music Mode EN-24

Dance Music Mode. . . . . . . . . . . . . . . . . . . . . . . . .EN-24

Playing Dance Music . . . . . . . . . . . . . . . . . . . . . . .EN-25

Using the Recommended Tone . . . . . . . . . . . . . . .EN-27

Using a Dance Music Voice . . . . . . . . . . . . . . . . . .EN-27

Using Effects. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .EN-27

Building Performance Tension . . . . . . . . . . . . . . . .EN-28

Playing with a Rhythm Backing EN-28

Rhythm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .EN-28

Playing a Rhythm . . . . . . . . . . . . . . . . . . . . . . . . . .EN-28

Using Recommended Rhythm Settings . . . . . . . . .EN-30

Changing the Rhythm Pattern . . . . . . . . . . . . . . . .EN-30

Inserting a Fill-in Phrase . . . . . . . . . . . . . . . . . . . . .EN-31

Fingering a Chord to Play a Rhythm

Accompaniment. . . . . . . . . . . . . . . . . . . . . . . . . .EN-31

Inserting an Intro or an Ending . . . . . . . . . . . . . . . .EN-33

Connecting with External Devices EN-34

Linking with a Smart Device (APP Function) . . . . .EN-34

Connecting to a computer and Using MIDI. . . . . . .EN-35

Connecting with Audio Equipment . . . . . . . . . . . . .EN-36

Configuring Function Settings EN-37

Configuring Settings . . . . . . . . . . . . . . . . . . . . . . . .EN-37

Setting Item List . . . . . . . . . . . . . . . . . . . . . . . . . . .EN-38

Reference EN-41

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . .EN-41

Product Specifications . . . . . . . . . . . . . . . . . . . . . .EN-42

Tone List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .EN-45

Drum Assignment List. . . . . . . . . . . . . . . . . . . . . . .EN-48

Song List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .EN-49

Dance Music Mode List . . . . . . . . . . . . . . . . . . . . .EN-49

Rhythm List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .EN-50

Fingering Guide . . . . . . . . . . . . . . . . . . . . . . . . . . .EN-51

Chord Example List . . . . . . . . . . . . . . . . . . . . . . . .EN-52

MIDI Implementation Chart

EN-2

General Guide

P(Power) button ☞EN-8

VOLUME buttons ☞EN-10

3 buttons ☞EN-7

Dial ☞EN-7

HOME button ☞EN-7

a (Start/Stop) button ☞EN-10, 17, 28

TEMPO button ☞EN-10, 18, 26, 29

SUSTAIN button ☞EN-13

MY SETUP button ☞EN-15

FUNCTION button ☞EN-37

DC 9.5V terminal ☞EN-4

PHONES/OUTPUT jack ☞EN-6, 36

AUDIO IN jack ☞EN-37

PEDAL jack ☞EN-6

USB port ☞EN-35

MIC IN jack ☞EN-6

MIC VOLUME knob ☞EN-6

Dance Music tone

■ Front Panel

■ Back

• The numbers to the right of the ☞ symbol are reference page numbers.

EN-3

Getting Ready to Play

AC adaptor DC 9.5V terminal

Household power outlet

Tab

Using Batteries for Power

Preparing a Power Supply

Though either an AC adaptor or batteries can be used for power, use of AC adaptor power is normally recommended.

Using the AC Adaptor

Use only the AC adaptor (JEITA Standard with unified polarity plug) specified for this Digital Keyboard. Use of a different type of AC adaptor can cause malfunction.

AC Adaptor Type: AD-E95100L

(JEITA Standard plug)

• Be sure to turn off Digital Keyboard power before connecting or disconnecting the AC adaptor.

• The AC adaptor becomes warm to the touch after very long use. This is normal and does not indicate malfunction.

• To prevent breaking of the wire, take care to avoid putting any type of load on the power cord.

No twisting No pulling No wrapping

• Be sure to turn off power before loading batteries.

• Use commercially available AA-size alkaline batteries or AA-size rechargeable nickel metal hydride batteries.

• Low battery power can cause abnormal operation. If this happens, replace batteries with new ones. If you are using rechargeable batteries, charge them.

■ Batteries

Note the precautions below when using rechargeable batteries.

• Use Panasonic Group AA-size eneloop rechargeable batteries. Do not use any other type of batteries.

• Use only the specified charger to charge batteries.

• Rechargeable batteries must be removed from the product for charging.

• For information about using eneloop batteries or their specified charger, be sure to read the user documentation and precautions that come with each item, and use them only as directed.

Be sure to replace batteries at least once a year, even if there is no indication of low battery power. Dead rechargeable batteries (eneloop) in particular may deteriorate if they are left in the product. Remove rechargeable batteries from the product as soon as possible after they go dead.

Open the battery cover on the back of the Digital Keyboard.

• Never insert metal, pencils, or any other objects into the DC 9.5V terminal. Doing so creates the risk of accident.

EN-4

Load six AA-size batteries into the battery compartment.

Load batteries with their positive (+) and negative (–) ends facing correctly.

Insert the tabs of the battery cover into the holes, and close the cover.

• Configure the setting below to specify the type of batteries you loaded.

Getting Ready to Play

Battery icon (not flashing)

Battery icon (flashing)

Music stand

■ Configuring the Battery Type Setting

Press FUNCTION.

This displays the [FUNCTION] screen.

Use the U and I buttons to select “Battery”.

• To go back to the previous screen, press the EXIT button.

Rotate the dial to select “Alkaline” (alkaline batteries) or “Ni-MH” (rechargeable nickel metal hydride batteries).

• After you rotate the dial once to select an option, you also will be able to change the selection using the – and + buttons.

• To go back to the previous screen, press the BACK button.

■ Battery Level Indicator

A battery icon appears on the display as shown below to let you know when battery power is getting low.

Low Battery Power

Battery Replacement Required

• Low battery power may cause notes to become distorted, or other problems.

• You can conserve battery power by using headphones and by reducing the volume level.

Press FUNCTION to exit the setting screen.

Preparing the Music Stand

Insert the music stand into the handle of the Digital Keyboard.

EN-5

Getting Ready to Play

PHONES/OUTPUT jack

(3.5mm stereo mini jack)

Stereo mini plug

PEDAL jack (6.3mm standard jack)

Pedal (sold separately)

MIC VOLUME knob

MIC IN jack (6.3mm standard jack)

Connecting Headphones (Sold Separately)

Plugging in headphones cuts off output from the built-in speakers, which means you can practice playing even late at night without disturbing others.

• Be sure to turn down the Digital Keyboard volume level before connecting headphones.

• Headphones do not come with the Digital Keyboard.

• Use separately sold or commercially available headphones.

• Do not listen to output over headphones at very high volume levels for long periods. Doing so creates the risk of hearing damage.

• If the plug of the headphones does not match the PHONES/OUTPUT jack, use a commercially available adapter plug.

• If you are using headphones that require an adapter plug, make sure you do not leave the adapter plugged in when removing the headphones.

Connecting a Pedal (Sold Separately)

To use a pedal, connect it to the PEDAL jack.

Connecting a Microphone (Commercially Available)

Connect a commercially available dynamic microphone to the MIC IN jack.

• Before connecting, turn the MIC VOLUME knob to its lowest setting.

• Before connecting a microphone, make sure that the Digital Keyboard and microphone are turned off.

• It will take a few seconds for the microphone to become enabled after you turn on the Digital Keyboard.

EN-6

Operations Common to All

   

  



 (1

Modes

Display Screen Contents

Function name



Sustain



Battery icon



Tempo



Current setting



Status



3 button functions



Sub-function name



Setting item



Current setting



For information about how to adjust display contrast, see “Configuring Function Settings” (page EN-37).

3 Buttons

Operations assigned to the three buttons along the bottom of the display change according to the setting you are configuring. Operations currently assigned to the three buttons are indicated by labels above the buttons.

3 Button Examples

■ Home Screen (Tone Selection Screen)

■ Setting Screen

• Holding down the – or + button when selecting a number or value will scroll through settings at high speed.

• To return a number or value to its initial default or recommended setting, press the – and + buttons at the same time.

Dial Operations

Rotate the dial to change a number (tone number, etc.) or value (tempo value, etc.)

HOME Button

Pressing HOME will display the [TONE] screen, which you can use to select a tone. This is the home screen. You can use the home screen to select the instrument type and to configure various settings.

EN-7

Key Light Function

The Key Light function causes keyboard keys to light in accordance with the notes of your performance, built-in song playback, etc. You can disable the Key Light function if you want.

Press FUNCTION.

This displays the [FUNCTION] screen.

Use the U and I buttons to select “Key Light”.

• To go back to the previous screen, press the EXIT button.

Rotate the dial to the left to select “Off”.

• After you rotate the dial once to select an option, you also will be able to change the selection using the – and + buttons.

• To go back to the previous screen, press the BACK button.

Press FUNCTION to exit the setting screen.

Playing on the Keyboard

Turning Power On or Off

Press P (Power).

This turns on power.

• To turn off power, hold down P (Power) until the

display goes blank.

Play something on the keyboard.

• Turning off power normally causes the tone and rhythm number and other settings to return to their initial defaults. However, the settings below are remembered.

− Key Light

− MIDI Out Channel

− MIDI Out Octave Shift

− MIDI Out Velocity

− MIDI IN Navigate

− MIDI IN Navigate Right-hand Channel

− MIDI IN Navigate Left-hand Channel

− Startup volume level

− MY SETUP Startup

− Auto Power Off

− Power On Alert

− Battery type

− LCD contrast

EN-8

Auto Power Off Power-On Alert

While Auto Power Off is enabled, Digital Keyboard power will turn off automatically after about 30 minutes of non-operation.

Keyboard keys will light to remind you that power is on if you do not perform any operation for about six minutes.

Playing on the Keyboard

• Auto Power Off is disabled while a song is playing and while the APP function is being used.

■ Disabling Auto Power Off

You can disable Auto Power Off to ensure that power does not turn off automatically during a concert, etc.

Press FUNCTION.

This displays the [FUNCTION] screen.

Use the U and I buttons to select “Auto Power Off”.

• To go back to the previous screen, press the EXIT button.

Rotate the dial to the left to select “Off”.

• After you rotate the dial once to select an option, you also will be able to change the selection using the – and + buttons.

• To go back to the previous screen, press the BACK button.

• Power-On Alert is disabled while a song is playing and while the APP function is being used.

■ Disabling Power-On Alert

You can disable Power-On Alert to ensure that keyboard keys do not light during a concert, etc.

Press FUNCTION.

This displays the [FUNCTION] screen.

Use the U and I buttons to select “Power-On Alert”.

• To go back to the previous screen, press the EXIT button.

Rotate the dial to the left to select “Off”.

• After you rotate the dial once to select an option, you also will be able to change the selection using the – and + buttons.

• To go back to the previous screen, press the BACK button.

Press FUNCTION to exit the setting screen.

EN-9

Press FUNCTION to exit the setting screen.

Playing on the Keyboard

Adjusting the Volume Level

Use the VOLUME + and – buttons to adjust the volume level.

This will change the volume level and cause the current volume level value to appear momentarily on the display.

• The setting range is 0 to 10.

• Holding down either button scrolls the setting value.

Specifying the Power On Volume Level

You can use the procedure below to specify the volume level that is applied when the Digital Keyboard is turned on.

Press FUNCTION.

This displays the [FUNCTION] screen.

Use the U and I buttons to select “PowerOnVolume”.

• To go back to the previous screen, press the EXIT button.

Using the Metronome

The metronome lets you play and practice along with a steady beat to help keep you on tempo. You can also set a tempo that is suitable for your practice.

Start/Stop

Press HOME.

This displays the home screen.

Press a.

This starts the metronome.

Press a again to stop the metronome and return to the home screen.

Changing the Metronome Tempo

Use the procedure below to change the tempo of the metronome.

Start the metronome.

Rotate the dial to select the volume level.

• After you rotate the dial once to select an option, you also will be able to change the selection using the – and + buttons.

• To go back to the previous screen, press the BACK button.

Press FUNCTION to exit the setting screen.

Press TEMPO.

This displays the [TEMPO] screen.

Rotate the dial or use the – and + buttons to change the tempo value.

• You can specify a tempo value in the range of 20 to

255.

• To return the setting to its initial default, press the – and + buttons at the same time.

• To return to the [METRONOME] screen, press the EXIT button.

EN-10

Playing on the Keyboard

Specifying the Metronome Sound and Beats Per Measure

You can use the procedure below to configure a setting that sounds a chime on the first beat of each measure, and a click for the remaining beats.

• Available settings are Off, or a value of 1 to 16 beats.

Start the metronome.

Rotate the dial or use the – and + buttons to specify the number of beats per measure.

• Selecting “Off” disables the chime and sounds a click for all beats. Use this setting when you want to practice without worrying about the first beat of each measure.

• To return the setting to its initial default, press the – and + buttons at the same time.

• To display the metronome volume level setting screen, press VOLUME (3 buttons).

Changing the Metronome Sound Volume Level

Listening to Demo Play

You can use Demo Play to play built-in songs in sequence.

While holding down TEMPO, press a.

This displays the [DEMO] screen and starts song number “1”.

• The display shows the number and name of the current song.

• For a list of song titles, see the “Song List” (page

EN-49).

• To return to the home screen, press the EXIT button.

To change from the current song to another one, rotate the dial.

This starts Demo Play of the song you selected.

• After you rotate the dial once to select an option, you also will be able to change the selection using the – and + buttons.

• To go back to the previous screen, press the BACK button.

To exit Demo Play, press the EXIT button or a.

Start the metronome.

Press VOLUME (3 buttons).

This displays the metronome volume level setting screen.

Rotate the dial or use the – and + buttons to change the volume value.

• You can specify a volume value from 0 to 127.

• To return the setting to its initial default, press the – and + buttons at the same time.

• To display the beat setting screen, press the BEAT button.

EN-11

Controlling the Sound of a Performance

Selecting a Musical Instrument Tone

Your Digital Keyboard lets you select tones for a wide variety of musical instrument sounds, including violin, flute, orchestra, and more. Even the same song sounds different when the instrument type is changed.

Selecting an Instrument Tone for Keyboard Play

Press HOME.

This displays the home screen.

Rotate the dial to select a tone.

The selected tone number and instrument name will appear on the display.

• For tone information, see the “Tone List” (page

EN-45).

• After you rotate the dial once to select an option, you also will be able to change the selection using the – and + buttons.

• To return to the first tone in the tone list, press – and + at the same time.

• To go back to the previous screen, press the BACK button.

• Selecting a drum set tone causes various percussion instruments to be assigned to keyboard keys.

Changing Keyboard Response to Touch Pressure (Touch Response)

Touch Response alters tone volume in accordance with keyboard pressure (press velocity). This provides you some of the same expression capabilities you get on an acoustic piano.

Changing Touch Response Sensitivity

Press FUNCTION.

This displays the [FUNCTION] screen.

Use the U and I buttons to select “Touch Response”.

• To go back to the previous screen, press the EXIT button.

Rotate the dial to change the setting.

Touch Response settings are described in the table below.

Setting (Display Text)

Off (Off) Touch Response disabled. Sound

Light (Light) Strong sound even with light pressure.

Normal (Normal) Normal Touch Response.

• After you rotate the dial once to select an option, you also will be able to change the selection using the – and + buttons.

• To return the setting to its initial default, press the – and + buttons at the same time.

• To go back to the previous screen, press the BACK button.

Description

volume is fixed, regardless of key press velocity.

EN-12

Press FUNCTION to exit the setting screen.

Controlling the Sound of a Performance

Using a Pedal

A pedal can be used to change notes while playing. Under initial default settings, sustain is assigned to the pedal, so it can be used as a damper pedal.

• A pedal unit does not come with the Digital Keyboard. Purchase one separately from your retailer.

Selecting the Pedal Effect

Press FUNCTION.

This displays the [FUNCTION] screen.

Use the U and I buttons to select “Pedal”.

• To go back to the previous screen, press the EXIT button.

Rotate the dial to select a pedal effect type.

The following shows the available pedal effects.

Setting (Display Text)

Pedal Sustain (Pedal Sustain)

Sostenuto (Sostenuto)

Soft (Soft) Pressing the pedal and playing notes

Start/Stop (Start/Stop)

• After you rotate the dial once to select an option, you also will be able to change the selection using the – and + buttons.

• To return the setting to its initial default, press the – and + buttons at the same time.

• To go back to the previous screen, press the BACK button.

Description

Playing notes while the pedal is depressed causes the notes to be sustained, even if the keyboard keys are released.

Playing notes and then pressing the pedal before the keyboard keys are released causes the notes to be sustained.

causes the notes to be slightly softened.

The pedal has the same functions as the a button. It can be used to start and stop the metronome or rhythm play.

Using the SUSTAIN Button

While sustain is enabled, notes are sustained longer when keyboard keys are released.

Press SUSTAIN.

This momentarily displays “SUSTAIN ON”.

• “SUS” at the top of the display indicates that sustain is enabled.

To disable sustain, press SUSTAIN again.

Adding Reverb to Notes

You can use the procedure below to add reverb to the notes you play.

Press FUNCTION.

This displays the [FUNCTION] screen.

Use the U and I buttons to select “Reverb”.

• To go back to the previous screen, press the EXIT button.

Rotate the dial to select the reverb type.

Available reverb type settings are: Off, Room 1 to 4, Hall 1 to 4, and Stadium 1 and 2.

• After you rotate the dial once to select an option, you also will be able to change the selection using the – and + buttons.

• To return the setting to its initial default, press the – and + buttons at the same time.

• To go back to the previous screen, press the BACK button.

EN-13

Controlling the Sound of a Performance

Changing the Pitch in Semitone Steps (Transpose)

Transpose lets you raise or lower the overall pitch of the Digital Keyboard in semitone steps. You can use this feature to raise or lower the Digital Keyboard’s key to make it easier to play a piece written in a difficult key, or to adjust to a key that better matches a vocalist, another musical instrument, etc.

Press FUNCTION.

This displays the [FUNCTION] screen.

Use the U and I buttons to select “Transpose”.

• To go back to the previous screen, press the EXIT button.

Rotate the dial to change the transpose value.

• The setting range is one octave up (+12 semitones) and down (–12 semitones).

• After you rotate the dial once to select an option, you also will be able to change the selection using the – and + buttons.

• To return the setting to its initial default, press the – and + buttons at the same time.

• To go back to the previous screen, press the BACK button.

Fine Tuning Pitch (Tuning)

You can use the procedure below to adjust the overall pitch of the Digital Keyboard by changing the frequency of A4 in 0.1Hz units.

Press FUNCTION.

This displays the [FUNCTION] screen.

Use the U and I buttons to select “Tuning”.

• To go back to the previous screen, press the EXIT button.

Rotate the dial to fine tune the pitch.

• You can specify a frequency in the range of 415.5 to

465.9 Hz.

• After you rotate the dial once to select an option, you also will be able to change the selection using the – and + buttons.

• To return the setting to its initial default, press the – and + buttons at the same time.

• To go back to the previous screen, press the BACK button.

EN-14

Saving and Loading Instrument Settings (MY SETUP)

You can use MY SETUP to save the setup (tone, rhythm, and other settings) of the Digital Keyboard. You can recall a saved setup when you need it to perform a particular song, etc.

Saving to MY SETUP

Press MY SETUP.

This displays the [MY SETUP] screen.

Press the SAVE button.

This causes “Sure?” to appear on the display. The name of the main setting (TONE, RHYTHM, SONG, DANCE MUSIC, LESSON) also appears.

• To go back to the previous screen, press the BACK button.

Press the YES button.

This saves the current setup to MY SETUP.

When “Complete” appears on the display, press the OK button.

This completes the save operation.

Savable Settings

You can use MY SETUP to save the items below.

• The function you are using (Tone, Rhythm, Song, Dance Music, Lesson)

• Tempo

• Tone number

• Metronome beat

• Metronome volume level

•Sustain

• Rhythm number

• Patterns

• FILL-IN

•Accomp

• Song number

• Practice part

• Count

• Tone sync

• Lesson step

• Lesson part

• Loop Lesson

• Dance Music number

• Dance Music voice

• Transpose

• Reverb

• Pedal

•Intro/Ending

• Chord fingering mode

• Rhythm volume level

• Song volume level

• Lesson evaluation

• Simplified lesson accompaniment

• Dance Music volume level

• Tuning

• If tone sync is enabled when you save settings with MY SETUP, recalling from MY SETUP will apply the tone sync reverb setting, even if you changed the reverb setting to something else before saving to MY SETUP.

EN-15

Saving and Loading Instrument Settings (MY SETUP)

Recalling From MY SETUP

Press MY SETUP.

This displays the [MY SETUP] screen.

Press the LOAD button.

This causes “Sure?” to appear on the display. The name of the main setting (TONE, RHYTHM, SONG, DANCE MUSIC, LESSON) also appears.

• To go back to the previous screen, press the BACK button.

Press the YES button.

This recalls the saved settings.

When “Complete” appears on the display, press the OK button.

This completes the recall operation.

Enabling MY SETUP Power On

Use the procedure below to enable MY SETUP power on, which causes the MY SETUP settings to be applied whenever the Digital Keyboard is turned on.

Press FUNCTION.

This displays the [FUNCTION] screen.

Use the U and I buttons to select “PowerOnMySetup”.

• To go back to the previous screen, press the EXIT button.

Rotate the dial to the right to select “On”.

• After you rotate the dial once to select an option, you also will be able to change the selection using the – and + buttons.

• To go back to the previous screen, press the BACK button.

EN-16

Press FUNCTION to exit the setting screen.

Playing a Built-in Song

Songs

With this Digital Keyboard, the term “song” is used to refer to a musical piece. You can listen to the built-in songs for your own enjoyment, or you can play along with them for practice.

Selecting a Song to Play

Starting or Stopping Song Play

Press HOME.

This displays the home screen.

Press the SONG button.

This displays the currently selected song number and song title.

Rotate the dial to select a song.

• After you rotate the dial once to select an option, you also will be able to change the selection using the – and + buttons.

• To go back to the previous screen, press the BACK button.

Skip Forward and Skip Back

Use the operations in this section to perform skip forward and skip back operations.

■ Skip Forward

While a song is playing, press the FF button to skip forward.

• Pressing the FF button once skips forward one measure, while holding it down skips forward until it is released.

■ Skip Back

While a song is playing, press the REW button to skip back.

• Pressing the REW button once skips back one measure, while holding it down skips back until it is released.

Press a to start the song.

This causes the current measure number and beat number to appear on the display.

• If the song includes chord information, a chord will also appear on the display.

To stop the song, press a again.

• Displaying the [SONG] screen while the metronome is sounding or a rhythm or Dance Music is playing will cause the ongoing operation to stop.

EN-17

Playing a Built-in Song

Changing a Song’s Tempo (Speed) Adjusting the Song Volume Level

You can use the procedure below to change the tempo (speed) and slow down playback to practice difficult passages, etc.

While the [SONG] screen is displayed, select the song whose tempo you want to change and then press TEMPO.

This displays the [TEMPO] screen.

Rotate the dial to change the tempo setting.

• You can specify a tempo value in the range of 20 to

255.

• You can also use the – and + buttons to change the setting. Press the – button to make the tempo slower or the + button to make it faster. Holding down either button scrolls the setting value.

• To return to the recommended setting for the current song, press – and + at the same time.

• Changing the song number will also return the song to its recommended tempo.

• To go back to the previous screen, press the EXIT button.

Use the procedure below to adjust the balance between the volume levels of song play and what you play on the keyboard.

Press FUNCTION.

This displays the [FUNCTION] screen.

Use the U and I buttons to select “Song Volume”.

• To go back to the previous screen, press the EXIT button.

Rotate the dial to adjust the volume level.

• You can specify a volume value from 0 to 127.

• After you rotate the dial once to select an option, you also will be able to change the selection using the – and + buttons.

• To return the setting to its initial default, press the – and + buttons at the same time.

• To go back to the previous screen, press the BACK button.

EN-18

Press FUNCTION to exit the setting screen.

Playing a Built-in Song

Right-hand part off

Left-hand part off

Both parts muted

Both hand parts on

Changing the Keyboard Tone While a Song is Playing

While a song is playing, press HOME.

The selected tone number and instrument name will appear on the display.

Rotate the dial to select a tone.

• For tone information, see the “Tone List” (page

EN-45).

• After you rotate the dial once to select an option, you also will be able to change the selection using the – and + buttons.

• To return to the first tone in the tone list, press – and + at the same time.

• To go back to the previous screen, press the BACK button.

Assigning the Song Tone to the Keyboard (Tone Sync)

Practicing a Song Part

You can turn off the right-hand part or the left-hand part of a song you are playing and practice along with the remaining part. Use this when you feel that a song is initially too difficult for you to play with both hands at the same time.

While a song is playing or stopped, press the PART button.

Each press of the PART button cycles through the settings shown below.

Use the procedure below to assign the song tone to the keyboard so you can play along.

While a song is playing or stopped, long-press FUNCTION.

This momentarily displays “RECOMMENDED” and assigns the song tone to the keyboard.

Play along with the song.

• Tone sync also applies the song’s reverb setting to keyboard play.

• Changing the tone setting or to another song will automatically disable tone sync.

EN-19

Playing a Built-in Song

Sounding a Count in Time with a Song

You can configure count settings to sound a count in time with a song and to sound a pre-count before a song starts.

Sounding a Count

While the song stopped, press the COUNT button.

Press the button a number of times until “CNT” appears on the display.

Press a to start the song.

A count sounds as the song is played back.

• To turn off the count, stop the song and then press the COUNT button a number of times until “CNT” disappears from the display.

Sounding a Pre-count

While the song stopped, press the COUNT button.

Press the button a number of times until “PRE” appears on the display.

Press a to start the song.

This sounds a pre-count that helps you determine when to start playing along.

• To turn off the pre-count, stop the song and then press the COUNT button a number of times until “PRE” disappears from the display.

• While the pre-count is enabled, the beat is not displayed while a song is playing.

• While a count is sounding, the beat is not displayed while a song is playing.

EN-20

Using a Lesson to Master Song Play

Lessons

Your Digital Keyboard provides you with lessons that help make it easier to master the songs you want to play. You can select the right-hand part, left-hand part, or bothhand parts for practice. If playing with both hands is too difficult when you’re first getting started, you can practice each hand individually.

Selecting a Song and Taking a Lesson

Press HOME.

This displays the home screen.

Press the SONG button.

This displays the [SONG] screen.

Press the LESSON button.

This enables the Lesson Function and displays a song number and name.

Rotate the dial to select the song you want to use for the lesson.

• After you rotate the dial once to select an option, you also will be able to change the selection using the – and + buttons.

• To go back to the previous screen, press the BACK button.

Use the STEP button to select the lesson type you want.

• Each press of the STEP button cycles through the lesson types described in the table below.

Lesson Type Description

EASY Play on the keyboard by following the keys

that light. With this type of lesson, playback progresses even if you press the wrong keyboard key. If you do not press any keyboard key, playback stands by until you do.

LISTEN Listen to the example until you remember

WATCH Play while watching the keys that light.

REMEMBER Play without keyboard lighting.

the song. The Key Light function shows you the timing when you need to press keyboard keys.

The next key you will need to press flashes to guide you. If you do not play the correct note in time, accompaniment stands by until you do. While accompaniment is standing by, the key you need to press lights and a tone sounds to guide you.

If you do not play the correct note in time, accompaniment stands by until you do. If you do not press the correct keyboard key, the key you need to press lights and a tone sounds to guide you.

EN-21

Use the HAND button to select a lesson part.

• Each press of the HAND button cycles through the lesson parts described in the table below.

Setting (Display Text)

R Right-hand part lesson

L Left-hand part lesson

LR Right-hand part and left-hand part lesson

Press a.

This plays back the song and starts the lesson for the part that corresponds to the lesson type you selected.

The song continues to play until the end is

Description

reached, or until you press a again to stop the lesson.

• If the lesson type is WATCH or REMEMBER, a performance evaluation score will appear when the end of the song is reached.

• To return to the lesson screen from the performance evaluation screen, press the OK button.

Using a Lesson to Master Song Play

Skip Forward and Skip Back

■ Skip forward

While a lesson is in progress, press the FF button to skip forward.

• Pressing the FF button once skips forward one measure, while holding it down skips until it is released.

■ Skip back

While a lesson is in progress, press the REW button to skip back.

• Pressing the REW button once skips back one measure, while holding it down skips back until it is released.

• Performance evaluation may not be provided if you used skip back or skip forward.

EN-22

Using a Lesson to Master Song Play

Disabling Performance Evaluation

Use the procedure below to disable performance evaluation and score display for the WATCH and REMEMBER lesson types.

Press FUNCTION.

This displays the [FUNCTION] screen.

Use the U and I buttons to select “Lesson Eval”.

• To go back to the previous screen, press the EXIT button.

Rotate the dial to select “Off”.

• After you rotate the dial once to select an option, you also will be able to change the selection using the – and + buttons.

• To return to the function selection screen, press the BACK button.

Looping Part of a Song as a Lesson (Loop Lesson)

You can loop a specific section of a song for practice.

While a lesson is in progress, press the AB button to specify the starting measure of the Loop Lesson.

This will cause “A” to appear on the display, indicating that the beginning of the measure where you pressed the AB button is the start point of the loop.

When playback reaches the measure you want to specify as the end of the Loop Lesson, press the AB button again.

This will cause “AB” to appear on the display, indicating that the end of the measure where you pressed the AB button is the end point of the loop.

• The Loop Lesson will continue to play until you press

• To clear a loop, press the AB button.

Press FUNCTION to exit the setting screen.

Making Lesson Notes Easier to Hear

When using a song that includes chord information for a lesson, you can simplify the accompaniment to make it easier to hear lesson notes. For information about making lesson notes easier to hear, see “Configuring Function Settings” (page EN-37).

• Pressing the AB button while lesson playback is stopped when there is no loop present in the lesson song will cause the entire song to be repeated (looped) during lesson playback. If there is a loop in the lesson song, pressing the AB button while lesson playback is stopped will clear the loop.

• Changing the song being used for a lesson after creating a loop will cause the loop to be cleared.

• If the lesson type is WATCH or REMEMBER, a performance evaluation score will appear after you play the loop.

• To restart the lesson from the performance evaluation screen, press the OK button. To return to the lesson screen, press the FINISH button.

EN-23

Playing in the Dance Music Mode

Melody/voice keyboard

E4 (Middle E)

Switch keyboard

Drum

PITCH DOWN

PITCH UP

CHANGE

ROLL

FILTER

GATE

ENDING

DrumBDrumCBassABassBBassCSyn1ASyn1BSyn1CSyn2ASyn2BSyn2

FX1 FX2 FX3 FX4



Auto Tension Builder Switches

Drum part Bass part



Pattern Phrase Switches

Synth 1 parts Synth 2 parts



Effect Switches



Track Reset Switch



Pattern Phrase Switches

These keys switch the pattern phrase and turn pattern phrases on or off. There are four parts: Drum, Bass, Synth 1 and Synth 2, and three different pattern phrases can be assigned to each.



Effect Switches

While an Effect Switch key is depressed, the corresponding effect is applied to the entire song. (Using Effects, page

EN-27)



Track Reset Switch

Pressing this key while a song is playing returns to the beginning of the current phrase.



Auto Tension Builder Switches

These keyboard keys can be used to apply build-up effects that are characteristic of dance music. (Building

Performance Tension, page EN-28)

Dance Music Mode

In the Dance Music Mode, you can create dance music by combining and playing multiple types of pattern phrases, and by applying effects. Pattern phrases of each part can be combined, making it possible to enjoy dance music like a DJ.

Entering the Dance Music Mode (page EN-25) changes the functions of the keyboard keys as shown below.

Switch Keyboard Functions

The keys of the left-half switch keyboard have the functions below.

EN-24

Melody/Voice Keyboard Functions

C7F4



Shout Voice



Sing Voice

The right-side melody/voice keyboard can be used to play a melody along with pattern play, and, with the Voice Function, to sound voices. (Using a Dance Music Voice, page EN-27)

Shout Voice



Pressing a keyboard key while the Dance Music Voice setting is enabled sounds a voice that is characteristic of dance music.

Sing Voice



Pressing a keyboard key while the Dance Music Voice setting is enabled sounds a voice that resembles singing.

• Sing Voice continues to sound the voice until the keyboard key is released.

Playing Dance Music

Playing in the Dance Music Mode

Rotate the dial to select a song.

• After you rotate the dial once to select an option, you also will be able to change the selection using the – and + buttons.

• To return to the first Dance Music number, press the – and + buttons at the same time.

• To go back to the previous screen, press the BACK button.

• For a list of patterns, see the “Dance Music Mode List” (page EN-49).

• Changing the pattern normally changes the tempo to the setting assigned to each pattern.

Press a pattern phrase bass part key to start bass part play. Next, layer phrases in the following sequence: Drum Part, Synth 1 Part, Synth 2 Part.

This starts the Bass Part pattern followed by the other parts being sequentially added to create an exciting build-up.

Press HOME.

This displays the home screen.

Press the DANCE button.

This displays the currently selected Dance Music number and pattern name.

• Entering the Dance Music Mode while the metronome is sounding or while a rhythm is playing will cause the ongoing operation to stop.

• You can also start or stop pattern play by pressing a.

Play while trying out different combinations by changing phrases of parts, and by adding or removing parts.

• Use the Effect Switches and Auto Tension Builder Switches to change patterns.

• Pressing a keyboard key that corresponds to a pattern phrase that is currently sounding stops the phrase.

EN-25

Changing the Dance Music Tempo

You can use the tempo setting operation to change the tempo of pattern play.

In the Dance Music Mode, select the pattern whose tempo you want to change and then press TEMPO.

This displays the [TEMPO] screen.

Rotate the dial to change the tempo setting.

• You can specify a tempo value in the range of 20 to

255.

• To return to the recommended setting, press – and + at the same time.

• Changing the Dance Music number will also return the pattern to its recommended tempo.

• To go back to the previous screen, press the EXIT button.

Playing in the Dance Music Mode

Rotate the dial to adjust the Dance Music volume level.

• You can specify a volume value from 0 to 127.

• After you rotate the dial once to select an option, you also will be able to change the selection using the – and + buttons.

• To return the setting to its initial default, press the – and + buttons at the same time.

• To go back to the previous screen, press the BACK button.

Press FUNCTION to exit the setting screen.

Changing the Keyboard Tone While Dance Music is Playing

While Dance Music is playing, press HOME.

The selected tone number and instrument name will appear on the display.

Changing the Dance Music Volume Level

Press FUNCTION.

This displays the [FUNCTION] screen.

Use the U and I buttons to select “Dance Volume”.

• To go back to the previous screen, press the EXIT button.

Rotate the dial to select a tone.

• For tone information, see the “Tone List” (page

EN-45).

• After you rotate the dial once to select an option, you also will be able to change the selection using the – and + buttons.

• To return to the first tone in the tone list, press – and + at the same time.

• To go back to the previous screen, press the BACK button.

• If you change the tone setting while the Dance Music Voice setting (page EN-27) is enabled, the tone will not change until you disable the Dance Music Voice setting.

EN-26

Playing in the Dance Music Mode

Using the Recommended Tone

In the Dance Music Mode, long-press FUNCTION.

This momentarily displays “RECOMMENDED” and assigns the tone recommended for the currently selected pattern.

• If you change the tone setting while the Dance Music Voice setting is enabled, the tone will not change until you disable the Dance Music Voice setting.

Using a Dance Music Voice

In the Dance Music Mode, press the VOICE button.

This causes “VOICE” to appear, which indicates that the Melody/Voice Keyboard has been changed from Melody Tone to Voice Tone.

• To return to the Melody Tone, press the VOICE button again.

Using Effects

Pressing an Effect Switch key during pattern play applies one of the effects described below to the entire song.

Keyboard Key Function Effect, Description

FX1 MOD LPF*

FX2 MOD HPF*

FX3 FLANGER Applies an undulating surge

FX4 LO-FI Reduces the resolution of

*1 Modulation Low Pass Filter *2 Modulation High Pass Filter

• The display shows the applicable function name while an effect is being applied.

• An effect is applied as long as its keyboard key is depressed, and stops being applied when the key is released.

• The application manner of MOD LPF and MOD HPF changes with the tempo.

• Effects are applied to overall pattern play, and cannot be applied to individual parts.

Cuts the high-range frequencies of the sound.

Cuts the low-range frequencies of the sound.

effect to the sound.

the sound.

• Dance Music voices are not affected by Transpose and Sustain settings.

EN-27

Building Performance Tension

While pattern play is in progress, you can use the build-up function to apply dance music effects and build up tension.

Function Name

PITCH Each press of a keyboard key

CHANGE Instantly changes the pattern

ROLL Cuts out part of a song, repeats

FILTER Applies effects that make notes

GATE Applies an effect that finely

ENDING Ends the current song while

*1 Depending on the part, some pattern phrases are not

changed.

*2 How an effect is applied changes randomly with each

keyboard key press. Effects are applied for a fixed amount of time.

*3 While Dance Music Voice is enabled, automatically plays

back the effect along with the Voice Tone.

Description Remarks

changes the overall pitch of the song. Pressing the PITCH DOWN key lowers the pitch in semitone units, while PITCH UP raises the pitch in semitone units.

phrase of the current song.

it, and applies fine performance effects.

darker (by cutting high-range frequencies) or brighter (by cutting low-range frequencies).

chops a song.

applying various effects.

Playing with a Rhythm Backing

You can use the procedures in this section to select the rhythm you want, and then automatically play accompaniments to suit it simply by playing chords with your left hand. It’s like having a personal backup group along with you wherever you go.

• Auto Accompaniments are made up of the parts (instruments) below. – Rhythm (percussion) – Bass (bass instruments) – Harmony (other instruments) You can have only the rhythm part play, or you can have all three parts play at the same time.

Rhythm

The rhythm part is the foundation of each Auto Accompaniment. Your Digital Keyboard comes with a variety of built-in rhythms, including 8-beat and waltz. Use the procedure below to play the basic rhythm part.

Playing a Rhythm

Press HOME.

This displays the home screen.

Press the RHYTHM button.

This displays the [RHYTHM] screen, which shows the currently selected rhythm number and name.

• Build-up execution timing is the beat immediately after a keyboard key is pressed.

• Though effects and build-up functions can be used at the same time, the effect currently being executed may stop.

• The display shows the applicable function name while a build-up function is being used.

• If the ENDING effect is used, Dance Music play stops after the effect is complete.

• If the pattern phrase is changed while the ENDING effect is being applied, play of only the newly selected part continues without stopping after the effect is complete.

• Changing the rhythm while the metronome is sounding, or while song or Dance Music Mode play is in progress will cause the ongoing operation to stop.

Rotate the dial to select a rhythm.

This causes the category name to appear on the display.

• For information about rhythm types, see the “Rhythm

List” (page EN-50).

• After you rotate the dial once to select an option, you also will be able to change the selection using the – and + buttons.

• To go back to the previous screen, press the BACK button.

EN-28

Press a.

This starts the rhythm and displays the beat.

To stop the rhythm, press a again.

Changing the Tempo of a Rhythm

Use the procedure below to change tempo to a speed that suits you.

On the [RHYTHM] screen, select the name of the rhythm whose tempo you want to change and then press TEMPO.

This displays the [TEMPO] screen.

Rotate the dial to change the tempo setting.

• You can specify a tempo value in the range of 20 to

255.

• To return to the recommended setting, press – and + at the same time.

• To go back to the previous screen, press the EXIT button.

Playing with a Rhythm Backing

Changing the Volume Level of a Rhythm

Use the procedure below to adjust the balance between the volume levels of keyboard play and the rhythm.

Press FUNCTION.

This displays the [FUNCTION] screen.

Use the U and I buttons to select “Rhythm Volume”.

• To go back to the previous screen, press the EXIT button.

Rotate the dial to adjust the rhythm volume level.

• You can specify a volume value from 0 to 127.

• After you rotate the dial once to select an option, you also will be able to change the selection using the – and + buttons.

• To return the setting to its initial default, press the – and + buttons at the same time.

• To go back to the previous screen, press the BACK button.

EN-29

Press FUNCTION to exit the setting screen.

Playing with a Rhythm Backing

Changing the Keyboard Tone While a Rhythm is Playing

While a rhythm is playing, press HOME.

The selected tone number and instrument name will appear on the display.

Rotate the dial to select a tone.

• For tone information, see the “Tone List” (page

EN-45).

• After you rotate the dial once to select an option, you also will be able to change the selection using the – and + buttons.

• To return to the first tone in the tone list, press – and + at the same time.

• To go back to the previous screen, press the BACK button.

Using Recommended Rhythm Settings

Changing the Rhythm Pattern

You can use the procedure below to add liveliness to your rhythm pattern by playing intro and ending patterns, fill-in patterns, and variations of basic rhythm patterns. Each Auto Accompaniment pattern has a basic “normal pattern” as well as a “variation pattern”. This lets you play a pattern that is different from the Normal Pattern.

In the Rhythm Mode, press the PTRN button.

This causes “VAR2” to appear on the display.

• Press the PTRN button again to return to the “VAR1” screen.

Press a.

This starts the rhythm for the pattern you selected.

• If you press the PTRN button while a rhythm is playing, the pattern will change from the beginning of the following measure.

You can use the procedure below to use tone, and tempo settings that are most suitable for a particular rhythm pattern.

On the [RHYTHM] screen, select a rhythm name and then long-press FUNCTION.

This momentarily displays “RECOMMENDED” and configures the recommended rhythm settings.

EN-30

Playing with a Rhythm Backing

Accompaniment keyboard

Inserting a Fill-in Phrase Fingering a Chord to Play a

A “fill-in” is a short phrase played where you want to change the mood of a piece. A fill-in pattern can be used to create a link between two melodies or as an accent.

While a rhythm is playing, press the PTRN button and then select a pattern.

Press the FILL-IN button.

With some patterns, the fill-in continues until the end of the measure where it is inserted. FILL is displayed while a fill-in is playing.

• To continue the fill-in into the next measure, keep the FILL-IN button depressed.

• Pressing the FILL-IN button while a rhythm is stopped will insert the fill-in and cause it to be played as soon as rhythm play is started. In this case, pressing the FILL-IN button again before starting rhythm play will remove the fill-in.

Rhythm Accompaniment

Playing a chord with your left hand automatically adds bass and harmony accompaniment parts to the currently selected rhythm. It is just like having your own personal back up group on call.

In the Rhythm Mode, press the ACMP button.

This causes “AC” to appear on the display and enables chord fingering with the accompaniment (left-side) keyboard.

Press a to start the rhythm.

Play something on the accompaniment keyboard.

This will sound the bass, harmony, and other non-rhythm part instruments.

• Playing a chord while rhythm play is stopped will cause rhythm and accompaniment to start at the same time.

Play other chords with your left hand as you play the melody with your right hand.

Press the ACMP button again to stop the accompaniment.

EN-31

Playing with a Rhythm Backing

Accompaniment keyboard

DE F F

E#G

DE F

DE F F

E#G

DE F

Selecting a Chord Fingering Mode

You can select from among the six chord fingering modes below.

• CASIO CHORD

•FINGERED1

•FINGERED2

• FINGERED ON BASS

• FINGERED ASSIST

• FULL RANGE CHORD

Press FUNCTION.

This displays the [FUNCTION] screen.

Use the U and I buttons to select “Chord Mode”.

• To go back to the previous screen, press the EXIT button.

Rotate the dial to select a chord fingering mode.

• After you rotate the dial once to select an option, you also will be able to change the selection using the – and + buttons.

• To go back to the previous screen, press the BACK button.

■ CASIO CHORD

With CASIO CHORD, you can use simplified fingerings to play the four types of chords described below.

Chord Type Example

Major Chords

Letters above the accompaniment keyboard indicate the name of the chord assigned to each key. Accompaniment keyboard keys marked with the same chord name play exactly the same chord.

Minor Chords

Press the key that corresponds to the major chord, while also pressing one other accompaniment area key to the right.

Seventh Chords

Press the key that corresponds to the major chord, while also pressing two other accompaniment area keys to the right.

Minor Seventh Chords

Press the key that corresponds to the major chord, while also pressing three other accompaniment area keys to the right.

C (C Major)

E#G

DE F

DE F F

Cm (C Minor)

C7 (C Seventh)

Cm7 (C Minor Seventh)

E#G

DE F

DE F F

• When playing a minor, seventh, or minor seventh chord on the accompaniment keyboard, it makes no difference whether the additional keys you press are black or white.

EN-32

Playing with a Rhythm Backing

Accompaniment keyboard

Accompaniment Keyboard/Melody Keyboard

■ FINGERED

With this chord fingering mode, you play chords on the accompaniment keyboard using their normal chord fingerings. Note that some chords can also be formed using abbreviated fingerings of one or two keys. For information about the types of chords you can finger and their fingerings, see the “Fingering Guide” (page EN-51).

● FINGERED 1

Play the component notes of the chord on the keyboard.

● FINGERED 2

Unlike FINGERED 1, 6th input is not possible with this mode.

● FINGERED ON BASS

Play the component notes of the chord on the keyboard. This mode allows input of fraction chords with the lowest keyboard note as the base note.

● FINGERED ASSIST

In addition to FINGERED 1 input, you can also use the fingerings below to play the three chord types.

Minor Chords (Cm)

Seventh Chords (C7)

Minor Seventh Chords (Cm7)

One keyboard key for the base note and the nearest black key to the left.

One keyboard key for the base note and the nearest white key to the left.

One keyboard key for the base note and the nearest black key and white key to the left.

Inserting an Intro or an Ending

Use the procedure below to insert an intro or ending pattern of a few measures.

In the Rhythm Mode, long-press the ACMP button.

This momentarily displays “INTRO/ENDING ON” and then “INTRO>V1” as the current pattern.

• To disable INTRO/ENDING and display “INTRO/ ENDING OFF”, long-press the ACMP button again.

To change the pattern, press the PTRN button.

Each press of the PTRN button cycles the setting in the following sequence: “INTRO>V1”, “INTRO>V2”, “V1”, “V2”.

• “INTRO>V1” and “INTRO>V2” are patterns with intros.

• “V1” and “V2” are short for “VAR1” and “VAR2”.

■ FULL RANGE CHORD

With this chord fingering mode, you can use the full range of the keyboard to play chords and the melody.

EN-33

Press a to start rhythm play.

If you selected a pattern with an intro, play starts with the intro and then the pattern starts to sound after the intro is complete.

• Instead of pressing a to start rhythm play, you can also press the ACMP button to display the “AC” indicator. In this case, playing a chord will start the intro with the accompaniment.

• To stop an intro and switch to pattern play, press the PTRN button.

• Note that you cannot select “INTRO>V1” or “INTRO>V2” while rhythm play is in progress.

At the point where you want to sound the ending, press a.

This will cause “ENDING” to appear on the display. The ending will play and then the rhythm will stop.

■ Configuring [FUNCTION] Screen Settings

Press FUNCTION.

This displays the [FUNCTION] screen.

Use the U and I buttons to select “Intro/ Ending”.

• To go back to the previous screen, press the EXIT button.

Rotate the dial to select “On”.

• You can also use the – and + buttons to change the setting. Pressing the – button selects “Off”, while the + button selects “On”.

• To go back to the previous screen, press the BACK button.

Connecting with External Devices

Linking with a Smart Device (APP Function)

You can use the APP function to connect the Digital Keyboard with a phone, tablet or other smart device and perform the operations described below.

• Use the Digital Keyboard sound source to sound music data played using an app on the smart device.

• Use the lesson functions of an app on the smart device, playing notes on the Digital Keyboard keyboard.

• Configure the settings on your smart device (Airplane Mode, etc.) to disable data communication.

• When connecting a smart device to the Digital Keyboard, do not connect both a USB cable and an audio cable at the same time.

Press FUNCTION to exit the setting screen.

■ Downloading the Smart Device App

Download the Chordana Play from the CASIO website and install it on the smart device.

https://support.casio.com/global/en/emi/manual/LK-S250/

EN-34

Connecting with External Devices

Micro-B connector

Digital Keyboard USB port (Micro-B)

Smart Device

■ Linking the Digital Keyboard with a Smart Device

Referring to “Downloading the Smart Device

App” (page EN-34), install the app on the smart

device.

Use a commercially available USB cable to connect the smart device USB port to the Digital Keyboard USB port.

• After connecting the smart device to the Digital Keyboard, use the smart device app to perform operations. For details about operations, refer to the user documentation of the app.

Connecting to a computer and Using MIDI

You can connect the Digital Keyboard to a computer and exchange MIDI data between them. You can record Digital Keyboard play using computer music software, and use the Digital Keyboard to play data sent to it from the computer.

■ Minimum Computer System Requirements

The following shows the minimum computer system requirements for sending and receiving MIDI data. Be sure to check your computer system setup before trying to install the driver.

● Supported Operating Systems

Windows 7* Windows 8.1* Windows 10* macOS (OS X/Mac OS X) 10.7, 10.8, 10.9, 10.10, 10.11,

10.12, 10.13, 10.14

*1 Windows 7 (32-bit, 64-bit) *2 Windows 8.1 (32-bit, 64-bit) *3 Windows 10 (32-bit, 64-bit)

● USB Port

• Never connect the Digital Keyboard to a computer running an operating system that is not one of those above. Doing so can cause malfunction of the computer.

• For the latest news about supported operating systems, visit the website at the URL or QR code below.

https://support.casio.com/global/en/emi/manual/LK-S250/

EN-35

Connecting with External Devices

Digital Keyboard PHONES/OUTPUT jack (3.5mm stereo mini jack)

Stereo mini plug

Audio equipment, amplifier, etc.

■ Connecting to a Computer

• Incorrect connections can make data exchange impossible. Be sure to follow the steps of the procedure below.

Turn off the Digital Keyboard and then start up your computer.

• Do not start up the music software on your computer yet!

Use a commercially available USB cable to connect the Digital Keyboard to your computer.

• Use a USB 2.0 or 1.1 A-MicroB connector type USB cable that supports data communication.

Turn on the Digital Keyboard.

• If this is the first time you are connecting, the driver required to transfer data will automatically be installed on your computer.

Start up commercially available music software on your computer.

Use the settings of your computer’s commercially available music software to select “CASIO USB-MIDI” as the MIDI device.

• For information about how to select the MIDI device, refer to the user documentation that comes with the music software you are using.

• Be sure to turn on the Digital Keyboard before starting up your computer’s music software.

• Data send/receive cannot be performed while a song is playing (page EN-17).

■ Configuring MIDI Settings

For information about the MIDI settings below, refer to the “Setting Item List” (page EN-38).

• MIDI Out Channel

• MIDI Out Octave Shift

• MIDI Out Velocity

• MIDI IN Navigate

• MIDI IN Navigate Right-hand Channel

• MIDI IN Navigate Left-hand Channel

• Local Control

Connecting with Audio Equipment

You can connect the Digital Keyboard to a commercially available stereo system or amplifier, or to a recording device. You can also use the Digital Keyboard to sound output from a portable audio player or another device, and use that as backing for your keyboard play.

■ Sounding Digital Keyboard Output on an External Device

Connection requires commercially available connecting cords, supplied by you.

• The connecting cord should have a stereo mini plug on one end and a plug that matches the configuration of the input jack of the external device on the other end.

• Turn off the external device and the Digital Keyboard before connecting them. Before turning power on or off, turn down the volume level of the Digital Keyboard and external devices.

• After connecting, turn on the Digital Keyboard first and then the external device.

• If Digital Keyboard notes are distorted when they are sounded on an external audio device, lower the Digital Keyboard’s volume level.

• Once you are able to connect successfully, you can leave the USB cable connected when you turn off your computer and/or Digital Keyboard.

• For detailed specifications and connections that apply to MIDI data communication by this Digital Keyboard, see the latest support information provided on the website at the URL or QR code below.

https://support.casio.com/global/en/emi/manual/LK-S250/

EN-36

■ Sounding Input From an External Device on the

Stereo mini plug (3-pole)

Digital Keyboard AUDIO IN jack (3.5mm stereo mini jack)

Portable audio player, etc.

Digital Keyboard

Connection requires commercially available connecting cords, supplied by you.

• The connecting cord should have a stereo mini plug (3pole) on one end for connection to the Digital Keyboard and a plug that matches the configuration of the output jack of external device on the other end.

• When sounding input from an external device with the Digital Keyboard, use the external device controls to adjust the volume level. In this case, you cannot adjust the volume level on the Digital Keyboard.

• Turn off the Digital Keyboard before connecting. Before turning power on or off, turn down the volume level of the Digital Keyboard and external devices.

• After connecting, turn on the external device and then the Digital Keyboard.

• If external device notes sounded by the Digital Keyboard are distorted, lower the external device’s volume level.

Configuring Function Settings

Configuring Settings

Use the procedure below to configure settings.

Press FUNCTION.

This displays the [FUNCTION] screen.

Use the U and I buttons to select a setting item.

• To go back to the previous screen, press the EXIT button.

Rotate the dial to change the setting.

• After you rotate the dial once to select an option, you also will be able to change the selection using the – and + buttons.

• To go back to the previous screen, press the BACK button.

Press FUNCTION to exit the setting screen.

EN-37

Configuring Function Settings

Setting Item List

Function Name Description Display Name Setting Options

Transpose Raises or lowers the overall pitch in semitone steps. You

can use this feature to raise or lower the key of the keyboard to make it easier to play a piece written in a difficult key, or to adjust to a key that better matches a vocalist, another musical instrument, etc.

Touch Response Specifies how volume changes in accordance with how

strongly keyboard keys are pressed.

Key Light When enabled, keyboard keys light as notes are played. Key Light Off, On

Reverb Specifies the type of reverb to be applied. Reverb Off, Room 1, Room 2,

Pedal Assigns a damper function to a pedal. The pedal can be

Intro/Ending Assigns an intro that sounds when a rhythm starts or an

Chord Mode Specifies the chord fingering mode. Chord Mode CASIO Chord, Fingered 1,

Rhythm volume Adjusts the rhythm volume level. Rhythm Volume 0 to 127

Song volume Adjusts the song volume level. Song Volume 0 to 127

Lesson Evaluation When enabled, lesson evaluation is performed at the end

Simplified Lesson Accompaniment

Dance Music volume level

Tuning Fine tunes the overall pitch of the Digital Keyboard by

MIDI Out Channel Specifies the channel to output MIDI messages. MIDI Out Ch 1 to 16

MIDI Out Octave Shift

MIDI Out Velocity Specifies the velocity of the note on message for MIDI

MIDI IN Navigate Navigate function that causes the Key Light function to

MIDI IN Navigate Right-hand Channel

MIDI IN Navigate Left-hand Channel

Power On Volume Level

MY SETUP Power OnWhen enabled, automatically configures MY SETUP

Local Control When enabled, mutes notes when something is played

used to sustain notes and to apply other effects during performances.

ending when the rhythm is stopped.

of a lesson.

When enabled, accompaniment is simplified to make lesson notes easier to hear during a lesson using a song that includes chord information.

Adjusts the dance music volume level. Dance Volume 0 to 127

changing the frequency of A4 in 0.1Hz units.

Specifies, in octave units, the note message key number for MIDI Out.

Out.

be controlled by MIDI IN note messages.

Changes the channel of the note message that operates as the right-hand melody for the navigate function.

Changes the channel of the note message that operates as the left-hand melody for the navigate function.

Specifies the power on volume level. PowerOnVolume 1 to 10

settings when the Digital Keyboard is turned on.

on the Digital Keyboard.

Transpose –12 to 0 to +12

Touch Response Off, Light, Normal

Room 3, Room 4, Hall 1, Hall 2, Hall 3, Hall 4, Stadium 1, Stadium 2

Pedal Pedal Sustain, Sostenuto,

Intro/Ending Off, On

Lesson Eval Off, On

LessonPlainAcmp Off, On

Tuning 415.5 to 440.0 to 465.9

MIDIOutOctShift –3 to 0 to +3

MIDIOutVelocity Off, 1 to 127

MIDIInNavigate Off, Listen, Right Hand Off,

MIDIInNavi R Ch 1 to 16

MIDIInNavi L Ch 1 to 16

PowerOnMySetup Off, On

Local Control Off, On

Soft, Start/Stop

Fingered 2, Fingered on Bass, Fingered Assist, Full Range Chord

Left Hand Off, BothHand Off

EN-38

Configuring Function Settings

Function Name Description Display Name Setting Options

Auto Power Off Enables/disable Auto Power Off. Auto Power Off Off, On

Power On Alert Enables or disables Power-On Alert. Power-On Alert Off, On

Batteries Specifies the type of batteries being used. Battery Alkaline, Ni-MH

LCD Contrast Adjusts display contrast. LCD Contrast 1 to 12

Initialize Returns all settings to their factory defaults. Initialize

Version Information

• Turning power off and back on again returns tone and other settings to their initial defaults (page EN-8).

• The settings below are retained even when power is turned off.

− Key Light

− MIDI Out Channel

− MIDI Out Octave Shift

− MIDI Out Velocity

− MIDI IN Navigate

− MIDI IN Navigate Right-hand Channel

− MIDI IN Navigate Left-hand Channel

− Startup volume level

− MY SETUP Startup

− Auto Power Off

− Power On Alert

− Battery type

− LCD contrast

Shows version information. Version

EN-39

Configuring Function Settings

Returning Settings to Their Initial Factory Defaults

Press FUNCTION.

This displays the [FUNCTION] screen.

Use the U and I buttons to select “Initialize”.

Press the ENTER button.

This causes “Sure?” to appear on the display.

Press the YES button.

After initialization is complete, the message “GOING TO RESTART” appears on the display for a few seconds, and then the Digital Keyboard restarts.

Checking Version Information

Press FUNCTION.

This displays the [FUNCTION] screen.

Use the U and I buttons to select “Version”.

This displays version information.

• To go back to the previous screen, press the EXIT button.

Press FUNCTION to exit.

EN-40

Reference

Troubleshooting

Symptom Required Action

Included Accessories

I can’t find included items during unpacking. Carefully check inside all of the packing materials.

Power Requirements

Power does not turn on. • Check the AC adaptor or make sure that the batteries are facing correctly

(page EN-4).

• Replace the batteries with new ones. Or use AC adaptor power (page

EN-4).

The Digital Keyboard suddenly turns off after outputting a loud sound.

The Digital Keyboard suddenly powers down after about 30 minutes.

Display

The display keeps going dark or keeps flickering.

Screen contents are visible only from a fixed angle.

Sound

Nothing happens when I press a keyboard key.

Nothing happens or notes do not play normally when I play on the accompaniment (left-side) keyboard.

Nothing happens when I start an Auto Accompaniment.

Nothing happens when I start playing a song’s Auto Accompaniment.

The metronome does not sound. • Check and adjust the metronome volume level (page EN-11).

Notes keep sounding, without stopping. • Try turning the Digital Keyboard off and then back on again (page EN-8) to

Some notes are cut off while they are playing.

The volume level or tone setting I configured has changed.

Replace the batteries with new ones. Or use AC adaptor power (page EN-4).

Disable Auto Power Off (page EN-9).

Replace the batteries with new ones. Or use AC adaptor power (page EN-4).

This is due to Digital Keyboard’s production limitations. It does not indicate malfunction.

• Adjust the volume level (page EN-10).

• Check if something is plugged into the PHONES/OUTPUT jack on the back of the Digital Keyboard.

• Try turning the Digital Keyboard off and then back on again (page EN-8) to initialize settings.

Press the ACMP button to disable chord input with the accompaniment keyboard (page EN-31).

• With rhythms 76 and 77, nothing will sound if you do not play a chord on the keyboard. Try playing a chord (page EN-31).

• Check and adjust the rhythm volume level (page EN-29).

• Try turning the Digital Keyboard off and then back on again (page EN-8) to initialize settings.

• It takes a little time after you press the button until the song starts to play. Wait for the song to start.

• Check and adjust the song volume level (page EN-18).

• Try turning the Digital Keyboard off and then back on again (page EN-8) to initialize settings.

initialize settings.

• Replace the batteries with new ones. Or use AC adaptor power (page

EN-4).

Notes are cut off whenever the number of notes being sounded exceeds the maximum polyphony value of 48 (24 for some tones). This does not indicate malfunction.

• Adjust the volume level (page EN-10).

• Try turning the Digital Keyboard off and then back on again (page EN-8) to initialize settings.

• Replace the batteries with new ones. Or use AC adaptor power (page

EN-4).

EN-41

Symptom Required Action

With certain volume levels and tones, the sound of notes played in one keyboard range will sound different from those played in another keyboard range.

With some tones, octaves do not change at the far ends of the keyboard.

The pitch of the notes does not match other accompanying instruments or notes sound strange when played along with other instruments.

The reverb of notes seems to change suddenly.

Connecting to a computer

I can’t perform MIDI data transfers. • Check to make sure that the USB cable is connected to the Digital

This is due to system limitations and does not indicate malfunction.

• Check and adjust the transpose setting (page EN-14) and tuning setting (page EN-14).

• Try turning the Digital Keyboard off and then back on again (page EN-8) to initialize settings.

• Check and adjust the reverb setting (page EN-13).

• Try turning the Digital Keyboard off and then back on again (page EN-8) to initialize settings.

Keyboard and computer, and that the correct device is selected with your computer’s music software (page EN-35).

• Turn off the Digital Keyboard and then exit the music software on your computer. Next, turn the Digital Keyboard back on and then restart the music software on your computer.

Reference

Product Specifications

Model LK-S250 Keyboard 61 keys Touch Response 2 levels, Off Maximum Polyphony 48 notes

Tones

Preset Tones 400 preset tones (1 stereo piano tone)

Effects Reverb (10 types, Off)

Metronome

Beat Off, 1 to 16 beats Tempo 20 to 255

Song Bank

Preset Songs 60 songs Part Off Left hand, right hand, both hands Other Next Note Guide

Lesson Function

Lesson Types 4 lesson types (EASY, LISTEN, WATCH, REMEMBER) Lesson Parts Left-hand, right-hand, both-hand Other AB repeat, next note guide, evaluation points

Auto Accompaniment

Preset Rhythms 77 types One Touch Presets 77 types Other INTRO, ENDING; chord input mode switching

Dance Music Mode

Preset Patterns 50 types; Dance Music effects

Demo Play Looped play of all built-in Song Bank songs (60 songs) Function Volume Adjustment Metronome, Rhythm, Song, Dance Music

EN-42

Reference

Other Functions

Transpose ±1 octave (–12 to 0 to +12 semitones) Tuning A4 = 415.5 to 465.9 Hz (Initial Default: 440.0 Hz)

MIDI 16 multi-timbre received, GM Level 1 standard

APP function

Supported Devices iOS, Android (USB terminal connection)

Jacks

USB Port Micro-B PEDAL jack Standard jack (6.3mm) (Pedal sustain, sostenuto, soft, start/stop) PHONES/OUTPUT jack Stereo mini jack (3.5mm) AUDIO IN jack Stereo mini jack (3.5mm)

MIC IN jack Standard jack (6.3mm)

AC adaptor terminal 9.5V DC Power Requirements 2-Way Power

Batteries 6 AA-size alkaline batteries or AA-size rechargeable nickel metal hydride batteries Continuous operation Approximately 8 hours (alkaline batteries), approximately 7 hours (rechargeable nickel metal

AC Adaptor AD-E95100L (JEITA Standard, with unified polarity plug) Auto Power Off After approximately 30 minutes of non-operation, Can be disabled.

Speakers 13cm × 6cm (oval) × 2 (Output: 2.5W + 2.5W) Power Consumption 9.5V = 5.5W Dimensions 93.0 (W) × 25.6 (D) × 7.3 (H) cm (36 5/8 × 10 1/16 × 2 7/8 inch) Weight Approximately 3.4kg (7.5 lbs) (Excluding batteries)

* Measured values while using eneloop batteries.

eneloop is a trademark of Panasonic Corporation.

• Specifications and designs are subject to change without notice.

Input impedance: 10 kΩ, Input sensitivity: 200 mV

Input impedance: 3 kΩ, Input sensitivity: 10 mV

hydride batteries)* Actual battery life may be shorter depending on battery type, performance style, or operation environment.

EN-43

Reference

AC Adaptor Handling Precautions

Model: AD-E95100L

1. Read these instructions.

2. Keep these instructions on hand.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this product near water.

6. Clean only with a dry cloth.

7. Do not install near radiators, heat registers, stoves, or any other source of heat (including amplifiers).

8. Use only attachments and accessories specified by the manufacturer.

9. Refer all servicing to qualified service personnel. Servicing is required after any of the following occurs: when the product is damaged, when the power supply cord or plug is damaged, when liquid is spilled into the product, when a foreign object falls into the product, when the product is exposed to rain or moisture, when the product does not operate normally, when the product is dropped.

10. Do not allow the product to be exposed to dripping or splashing liquid. Do not place any object containing liquid on the product.

11. Do not allow the electrical load output to exceed the label rating.

12. Make sure the surrounding area is dry before plugging into a power source.

13. Make sure the product is oriented correctly.

14. Unplug the product during lightning storms or when you do not plan to use it for a long time.

15. Do not allow product ventilation openings to become blocked. Install the product in accordance with the manufacturer’s instructions.

16. Take care the power cord is located where it will not be stepped upon or bent severely, particularly in locations close to plugs and convenience receptacles, and in locations where it exits from the product.

17. The AC adaptor should be plugged into a power outlet as close to the product as possible to allow immediate disconnection of the plug in case of emergency.

The symbol below is an alert indicating un-insulated hazardous voltage inside the product’s enclosure, which may be sufficient to constitute the risk of electric shock to users.

’

The symbol below is an alert indicating the presence of important operating and maintenance (servicing) instructions in the documentation that accompanies the product.

EN-44

Tone List

Reference

No. Tone Name

PIANO

1 STEREO GRAND PIANO 0 2 2 GRAND PIANO 0 1 3 BRIGHT PIANO 1 2 4 MODERN PIANO 1 3 5 DANCE PIANO 1 1 6 MELLOW PIANO 0 3 7 STRINGS PIANO 0 8 8 HONKY-TONK 3 2

9 OCTAVE PIANO 3 9 10 BASS/PIANO 0 9 11 ELEC.GRAND PIANO 2 2 12 MODERN E.G.PIANO 2 3 13 HARPSICHORD 6 2 14 HARPSICHORD & STRINGS 6 1

ELECTRIC PIANO

15 ELEC.PIANO 4 2 16 FM E.PIANO 5 5 17 60’S E.PIANO 4 5 18 CHORUS E.PIANO 1 4 9 19 CHORUS E.PIANO 2 4 6 20 MODERN E.PIANO 5 2 21 SOFT E.PIANO 4 8 22 SYNTH-STR.E.PIANO 4 3 23 CLEAN E.PIANO 4 4 24 CLAVI 1 7 2 25 CLAVI 2 7 3 26 SOFT CLAVI 7 1 27 DETUNE CLAVI 7 8 28 SEQUENCE CLAVI 7 9

CHROMATIC PERC.

29 VIBR APHONE 1 11 2 30 VIBRAPHONE 2 11 1 31 SOFT VIBRAPHONE 1 11 3 32 SOFT VIBRAPHONE 2 11 4 33 MARIMBA 12 2 34 SOFT MARIMBA 12 1 35 CELESTA 1 8 2 36 CELESTA 2 8 1 37 GLOCKENSPIEL 9 2 38 MUSIC BOX 1 10 2 39 MUSIC BOX 2 10 1 40 XYLOPHONE 13 2 41 TUBULAR BELL 14 2 42 DULCIMER 15 2

ORGAN

43 DRAWBAR ORGAN 1 16 2 44 DRAWBAR ORGAN 2 16 1 45 PERC.ORGAN 1 17 2 46 PERC.ORGAN 2 17 3 47 ELEC.ORGAN 1 16 8 48 ELEC.ORGAN 2 16 4 49 JAZZ ORGAN 1 17 4 50 JAZZ ORGAN 2 17 6 51 ROCK ORGAN 1 18 2 52 ROCK ORGAN 2 18 1 53 FULL DRAWBAR 16 9 54 CLICK ORGAN 18 7 55 8’ORGAN 17 5 56 CHURCH ORGAN 1 19 2 57 CHURCH ORGAN 2 19 3 58 CHAPEL ORGAN 19 8 59 THEATER ORGAN 19 6 60 REE D ORGAN 20 2 61 ACCORDION 21 2 62 BANDONEON 23 2 63 HARMONICA 1 22 2 64 HARMONICA 2 22 8

GUITAR

65 NYLON STR.GUITAR 24 2

Program

Change

Bank

Select

MSB

No. Tone Name

66 STEEL STR.GUITAR 25 2 67 12 STR.GUITAR 25 8 68 CHORUS STEEL GT 25 9 69 JAZZ GUITAR 26 2 70 OCT.JAZZ GUITAR 26 8 71 CLEAN GUITAR 1 27 2 72 CLEAN GUITAR 2 27 1 73 MUTE GUITAR 28 2 74 OVERDRIVE GUITAR 29 2 75 DISTORTION GUITAR 30 2 76 POWER DIST.GUITAR 30 5 77 FEEDBACK GUITAR 31 8 78 DIST.GUITAR & BASS 30 6

BASS

79 ACOUSTIC BASS 32 2 80 FINGERED BASS 33 2 81 PICKED BASS 34 2 82 FRETLESS BASS 35 2 83 SLAP BASS 37 2 84 SAW SYNTH-BASS 38 2 85 SQUARE SYNTH-BASS 39 2 86 DIGI ROCK BASS 39 1 87 TRANCE BASS 38 4 88 SINE BASS 39 6

STR/ORCHESTRA

89 VIOLIN 40 2 90 SLOW VIOLIN 40 8 91 VIOLA 41 2 92 CELLO 42 2 93 SLOW CELLO 42 1 94 CONTRABASS 43 2 95 VIOLIN & CELLO 40 3 96 CELLO SECTION 42 4 97 PIZZICATO STRINGS 45 2 98 HARP 1 46 2 99 HARP 2 46 1

100 CHORUS HARP 46 8

ENSEMBLE

101 STRINGS 48 2 102 SLOW STRINGS 49 2 103 WIDE STRINGS 48 16 104 CHAMBER 48 3 105 OCTAVE STRINGS 48 32 106 STRINGS SFZ 48 8 107 TREMOLO STRINGS 49 1 108 FLUTE & STRINGS 49 3 109 CHOIR STRINGS 52 3 110 SYNTH-STRINGS 1 50 2 111 SYNTH-STRINGS 2 51 2 112 SYNTH-STRINGS 3 51 3 113 FAST SYNTH-STRINGS 50 3 114 CHOIR AAHS 52 2 115 VOICE DOO 53 2 116 SYNTH-VOICE 54 2 117 SYNTH-VOICE PAD 54 8 118 CHORUS SYNTH-VOICE 54 9 119 ORCHESTRA HIT 1 55 2 120 ORCHESTRA HIT 2 55 1

BRASS

121 TRUMPET 56 2 122 MELLOW TRUMPET 56 8 123 TRUMPET SFZ 56 1 124 TROMBONE 57 2 125 TUBA 58 2 126 MUTE TRUMPET 59 2 127 FRENCH HORN 60 2 128 FRENCH HORN SECTION 60 1 129 BRASS 61 2 130 BRASS SECTION 1 61 3 131 BRASS SECTION 2 61 6

Program

Change

Bank

Select

MSB

EN-45

Reference

No. Tone Name

132 BRASS SECTION 3 61 7 133 MELLOW BRASS 61 1 134 HARD BRASS 61 5 135 BRASS SFZ 61 8 136 BRASS & STRINGS 61 4 137 SYNTH-BRASS 1 62 2 138 SYNTH-BRASS 2 63 2 139 ANALOG SYNTH-BRASS 1 62 8 140 ANALOG SYNTH-BRASS 2 62 9

REED/PIPE

141 ALTO SAX 1 65 1 142 ALTO SAX 2 65 2 143 HARD A.SAX 65 3 144 BREATHY A.SAX 65 8 145 TENOR SAX 66 1 146 SOPRANO SAX 1 64 2 147 SOPRANO SAX 2 64 1 148 BARITONE SAX 1 67 2 149 BARITONE SAX 2 67 1 150 SAX SECTION 65 9 151 CLARINET 71 2 152 OBOE 68 2 153 SOLO OBOE 68 4 154 BASSOON 70 5 155 FLUTE 1 73 2 156 FLUTE 2 73 1 157 PURE FLUTE 73 8 158 PICCOLO 72 2 159 RECORDER 74 2 160 PAN FLUTE 75 2 161 BOTTLE BLOW 1 76 2 162 BOTTLE BLOW 2 76 1 163 WHISTLE 78 2 164 OCARINA 79 2 165 FLUTE & OBOE 73 3

SYNTH-LEAD

166 SQUARE LEAD 1 80 2 167 SQUARE LEAD 2 80 3 168 SQUARE LEAD 3 80 1 169 SAW LEAD 1 81 2 170 SAW LEAD 2 81 1 171 SAW LEAD 3 81 5 172 MELLOW SAW LEAD 81 8 173 SQUARE PULSE LEAD 80 5 174 SEQUENCE SAW 81 9 175 SEQUENCE SINE 80 9 176 SINE LEAD 80 8 177 SS LEAD 81 3 178 SEQUENCE SQUARE 80 7 179 SEQUENCE PULSE 80 16 180 SLOW SAW LEAD 81 4 181 CALLIOPE 82 2 182 VENT LEAD 82 5 183 VENT SYNTH 82 1 184 CHIFF LEAD 83 2 185 SEQUENCE LEAD 1 83 5 186 SEQUENCE LEAD 2 83 3 187 VOICE LEAD 85 2 188 DISTORTION LEAD 84 8 189 CHARANG 84 2 190 CHURCH LEAD 85 4 191 SYNTH-VOICE LEAD 85 7 192 FIFTH LEAD 86 4 193 FIFTH SAW LEAD 86 2 194 FIFTH SQUARE LEAD 86 3 195 FIFTH SEQUENCE 86 1 196 BASS+LEAD 87 2 197 DANCE SQUARE LEAD 80 48 198 DANCE SYNC SQUARE LEAD 80 49 199 DANCE SAW LEAD 81 48 200 DANCE SYNC SAW LEAD 81 49 201 DANCE POLY SAW LEAD 81 50 202 DANCE SAW BASS 87 48

Program

Change

Bank

Select

MSB

No. Tone Name

SYNTH-PAD

203 FANTASY 1 88 2 204 FANTASY 2 88 3 205 WARM VOX 89 8 206 WARM PAD 89 2 207 SINE PAD 89 3 208 SOFT PAD 89 4 209 OLD TAPE PAD 89 6 210 POLYSYNTH 1 90 2 211 POLYSYNTH 2 90 1 212 POLY SAW 90 8 213 SPACE CHOIR 91 1 214 HEAVEN 91 2 215 SQUARE PAD 92 1 216 BOWED PAD 92 2 217 GLASS PAD 92 3 218 ETHNIC PAD 93 2 219 HARD METAL PAD 93 4 220 CHORUS PAD 94 1 221 HALO PAD 94 2 222 SWEEP PAD 95 2 223 RAIN DROP 96 2 224 SPACE VOICE 97 1 225 SOUND TRACK 1 97 2 226 SOUND TRACK 2 97 3 227 RAVE 97 8 228 CRYSTAL 98 2 229 CHORAL BELL 98 16 230 CELESTA PAD 99 1 231 ATMOSPHERE 99 2 232 BRIGHT BELL PAD 100 1 233 BRIGHTNESS 100 2 234 GOBLIN 101 2 235 ECHO PAD 102 2 236 ECHO DROP 102 3 237 POLY DROP 102 4 238 STAR THEME 103 2 239 SPACE PAD 103 8 240 DANCE SAW PAD 90 48 241 DANCE SQUARE PAD 1 90 49 242 DANCE SQUARE PAD 2 90 50

INDIAN

243 SITAR 1 104 2 244 SITAR 2 104 3 245 TANPURA 1 104 32 246 TANPURA 2 104 33 247 HARMONIUM 1 20 32 248 HARMONIUM 2 20 33 249 SHANAI 1 111 2 250 SHANAI 2 111 3 251 SANTUR 1 15 3 252 SANTUR 2 15 4 253 TABLA 116 16

ETHNIC

254 YANG QIN 1 15 8 255 YANG QIN 2 15 9 256 DI ZI 72 16 257 ZHENG 107 1 258 SHENG 109 8 259 SUO NA 111 32 260 XIAO 77 32 261 PI PA 105 32 262 BANJO 105 2 263 THUMB PIANO 108 2 264 STEEL DRUMS 114 2 265 RABAB 105 8 266 KOTO 107 2

GM TONES

267 GM PIANO 1 0 0 268 GM PIANO 2 1 0 269 GM PIANO 3 2 0 270 GM HONKY-TONK 3 0 271 GM E.PIANO 1 4 0

Program

Change

Bank

Select

MSB

EN-46

Reference

No. Tone Name

272 GM E.PIANO 2 5 0 273 GM HARPSICHORD 6 0 274 GM CLAVI 7 0 275 GM CELESTA 8 0 276 GM GLOCKENSPIEL 9 0 277 GM MUSIC BOX 10 0 278 GM VIBRAPHONE 11 0 279 GM MARIMBA 12 0 280 GM XYLOPHONE 13 0 281 GM TUBULAR BELL 14 0 282 GM DULCIMER 15 0 283 GM ORGAN 1 16 0 284 GM ORGAN 2 17 0 285 GM ORGAN 3 18 0 286 GM PIPE ORGAN 19 0 287 GM REED ORGAN 20 0 288 GM ACCORDION 21 0 289 GM HARMONICA 22 0 290 GM BANDONEON 23 0 291 GM NYLON STR.GUITAR 24 0 292 GM STEEL STR.GUITAR 25 0 293 GM JAZZ GUITAR 26 0 294 GM CLEAN GUITAR 27 0 295 GM MUTE GUITAR 28 0 296 GM OVERDRIVE GUITAR 29 0 297 GM DISTORTION GUITAR 30 0 298 GM GUITAR HARMONICS 31 0 299 GM ACOUSTIC BASS 32 0 300 GM FINGERED BASS 33 0 301 GM PICKED BASS 34 0 302 GM FRETLESS BASS 35 0 303 GM SLAP BASS 1 36 0 304 GM SLAP BASS 2 37 0 305 GM SYNTH-BASS 1 38 0 306 GM SYNTH-BASS 2 39 0 307 GM VIOLIN 40 0 308 GM VIOLA 41 0 309 GM CELLO 42 0 310 GM CONTRABASS 43 0 311 GM TREMOLO STRINGS 44 0 312 GM PIZZICATO 45 0 313 GM HARP 46 0 314 GM TIMPANI 47 0 315 GM STRINGS 1 48 0 316 GM STRINGS 2 49 0 317 GM SYNTH-STRINGS 1 50 0 318 GM SYNTH-STRINGS 2 51 0 319 GM CHOIR AAHS 52 0 320 GM VOICE DOO 53 0 321 GM SYNTH-VOICE 54 0 322 GM ORCHESTRA HIT 55 0 323 GM TRUMPET 56 0 324 GM TROMBONE 57 0 325 GM TUBA 58 0 326 GM MUTE TRUMPET 59 0 327 GM FRENCH HORN 60 0 328 GM BRASS 61 0 329 GM SYNTH-BRASS 1 62 0 330 GM SYNTH-BRASS 2 63 0 331 GM SOPRANO SAX 64 0 332 GM ALTO SAX 65 0 333 GM TENOR SAX 66 0 334 GM BARITONE SAX 67 0 335 GM OBOE 68 0 336 GM ENGLISH HORN 69 0 337 GM BASSOON 70 0 338 GM CLARINET 71 0 339 GM PICCOLO 72 0 340 GM FLUTE 73 0 341 GM RECORDER 74 0 342 GM PAN FLUTE 75 0 343 GM BOTTLE BLOW 76 0 344 GM SHAKUHACHI 77 0

Program

Change

Bank

Select

MSB

No. Tone Name

345 GM WHISTLE 78 0 346 GM OCARINA 79 0 347 GM SQUARE LEAD 80 0 348 GM SAW LEAD 81 0 349 GM CALLIOPE 82 0 350 GM CHIFF LEAD 83 0 351 GM CHARANG 84 0 352 GM VOICE LEAD 85 0 353 GM FIFTH LEAD 86 0 354 GM BASS+LEAD 87 0 355 GM FANTASY 88 0 356 GM WARM PAD 89 0 357 GM POLYSYNTH 90 0 358 GM SPACE CHOIR 91 0 359 GM BOWED GLASS 92 0 360 GM METAL PAD 93 0 361 GM HALO PAD 94 0 362 GM SWEEP PAD 95 0 363 GM RAIN DROP 96 0 364 GM SOUND TRACK 97 0 365 GM CRYSTAL 98 0 366 GM ATMOSPHERE 99 0 367 GM BRIGHTNESS 100 0 368 GM GOBLINS 101 0 369 GM ECHOES 102 0 370 GM SF 103 0 371 GM SITAR 104 0 372 GM BANJO 105 0 373 GM SHAMISEN 106 0 374 GM KOTO 107 0 375 GM THUMB PIANO 108 0 376 GM BAGPIPE 109 0 377 GM FIDDLE 110 0 378 GM SHANAI 111 0 379 GM TINKLE BELL 112 0 380 GM AGOGO 113 0 381 GM STEEL DRUMS 114 0 382 GM WOOD BLOCK 115 0 383 GM TAIKO 116 0 384 GM MELODIC TOM 117 0 385 GM SYNTH-DRUM 118 0 386 GM REVERSE CYMBAL 119 0 387 GM GUITAR FRET NOISE 120 0 388 GM BREATH NOISE 121 0 389 GM SEASHORE 122 0 390 GM BIRD 123 0 391 GM TELEPHONE 124 0 392 GM HELICOPTER 125 0 393 GM APPLAUSE 126 0 394 GM GUNSHOT 127 0

DRUM SET

395 STANDARD SET 1 0 120 396 STANDARD SET 2 1 120 397 DANCE SET 29 120 398 BRUSH SET 40 120 399 ORCHESTRA SET 48 120 400 INDIAN SET 49 120

Program

Change

Bank

Select

MSB

EN-47

Drum Assignment List

STANDARD SET 1 STANDARD SET 2

C-1

D-1

E-1

F-1

G-1

A-1

B-1

C-1

E-1

F-1

A-1

B-1

C0

E0

F0

A0

B0



E1

F1

A1

B1

C2

E2

F2

A2

B2

C3

E3

F3

A3

B3

C4

E4

F4

A4

B4

C5

E5

F5

A5

B5

C6

E6

F6

A6

B6

C7

E7

F7

A7



C8

E8

F8

A8

B8

C9

E9

F9

BRUSH SETDANCE SET

DRUMS SET NAME

ORCHESTRA SET INDIAN SET

0 1 2 3 4 5 6 7 8

9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 97 98 99

100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120 121 122 123 124 125 126 127

Xiao Luo Bang Gu Applause

Metronome Click Metronome Bell Standard Kick 2 Standard Kick 1 Side Stick Standard Snare 1 Standard Hand Clap Standard Snare 2 Low Tom 2 Closed Hi-Hat Low Tom 1 Pedal Hi-Hat Mid Tom 2 Open Hi-Hat Mid Tom 1 High Tom 2 Crash Cymbal 1 High Tom 1 Ride Cymbal 1 Chinese Cymbal Ride Bell Tambourine Splash Cymbal Cowbell Crash Cymbal 2 Vibraslap Ride Cymbal 2 High Bongo Low Bongo Mute High Conga Open High Conga Open Low Conga High Timbale Low Timbale High Agogo Low Agogo Cabasa Maracas Short High Whistle Long Low Whistle Short Guiro Long Guiro Claves High Wood Block Low Wood Block Mute Cuica Open Cuica Mute Triangle Open Triangle Shaker Cheer Short Cheer Cheer Long Cheer Fade Out Explotion 1 Explotion 2

  

 

Room Kick 2 Room Kick 1



Room Snare 1



Room Snare 2

                                         

Power Kick 2 Power Kick 1 Power Snare 1 Power Hand Clap Power Snare 2

  

 

Synth Kick 2 Synth Kick 1



Synth Snare 1 Synth Hand Clap Synth Snare 2 Synth Low Tom 2



Synth Low Tom 1



Synth Mid Tom 2



Synth Mid Tom 1 Synth High Tom 2



Synth High Tom 1

                               

Dance Kick 1 Dance Kick 2 Dance Q Dance Snare 1 Dance Clap Dance Snare 2 HipHop Close Hat Noise Rise HipHop Open Hat

  

 

Brush Kick 2 Brush Kick 1



Brush Snare 1 Brush Slap Brush Snare 2 Brush Low Tom 2



Brush Low Tom 1



Brush Mid Tom 2



Brush Mid Tom 1 Brush High Tom 2



Brush High Tom 1

                               

  

Closed Hi-Hat Pedal Hi-Hat Open Hi-Hat Ride Cymbal

       

Timpani F Timpani F# Timpani G Timpani G# Timpani A Timpani A# Timpani B Timpani C+ Timpani C#+ Timpani D+ Timpani D#+ Timpani E+ Timpani F+

                            

  

                                     

Tabla Ge Tabla Ka Tab la Te Tab l a Na Tab la Tun

      

Key Note No.

Reference

•“” indicates a key is assigned the same tones as it is for STANDARD SET 1.

EN-48

Reference

Song List

No. Title

PIANO/CLASSICS

1 FÜR ELISE 2 VALSE op.64 no.1 “PETIT CHIEN” 3 TURKISH MARCH (MOZART) 4TRÄUMEREI 5 ETUDE op.10 no.3 “CHANSON DE L’ADIEU” 6 LIEBESTRÄUME no.3 7 NOCTURNE op.9 no.2 (CHOPIN) 8 CANON (PACHELBEL)

9 MARY HAD A LITTLE LAMB 10 LE CYGNE FROM “LE CARNAVAL DES ANIMAUX” 11 AIR FROM “SUITE no.3” 12 SPRING FROM “THE FOUR SEASONS” 13 HUNGARIAN DANCES no.5 14 MINUET IN G MAJOR 15 GAVOTTE (GOSSEC) 16 ARABESQUE (BURGMÜLLER) 17 DECK THE HALL 18 ODE TO JOY 19 AVE MARIA (GOUNOD) 20 PRELUDE op.28 no.7 (CHOPIN) 21 GOING HOME FROM “FROM THE NEW WORLD” 22 SONATA op.27 no.2 “MOONLIGHT” 1st Mov. 23 THE ENTERTAINER 24 FRÖHLICHER LANDMANN 25 LA CHEVALERESQUE 26 JESUS BLEIBET MEINE FREUDE 27 MARCH FROM “THE NUTCRACKER” 28 CHANSON DU TOREADOR FROM “CARMEN” 29 INVENTIONEN no.1 30 PRAELUDIUM no.1 (J.S.BACH)

EVENT

31 SILENT NIGHT 32 JINGLE BELLS 33 WE WISH YOU A MERRY CHRISTMAS 34 JOY TO THE WORLD 35 O CHRISTMAS TREE

WORLD

36 WHEN THE SAINTS GO MARCHING IN 37 GREENSLEEVES 38 ANNIE LAURIE 39 AMAZING GRACE 40 TWINKLE TWINKLE LITTLE STAR 41 GRANDFATHER’S CLOCK 42 ON TOP OF OLD SMOKEY 43 COME BIRDS 44 DID YOU EVER SEE A LASSIE? 45 DANNY BOY 46 MY BONNIE 47 HOME SWEET HOME 48 AURA LEE 49 ALOHA OE 50 LONDON BRIDGE 51 UNDER THE SPREADING CHESTNUT TREE 52 SIPPIN’ CIDER THROUGH A STRAW 53 BEAUTIFUL DREAMER 54 MY DARLING CLEMENTINE 55 LITTLE BROWN JUG 56 YANKEE DOODLE 57 I’VE BEEN WORKING ON THE RAILROAD 58 OH! SUSANNA 59 TURKEY IN THE STRAW 60 FURUSATO

Dance Music Mode List

No. Pattern Name

EDM

1 ELECTRO DANCE 1 2 ELECTRO DANCE 2 3 ELECTRO DANCE 3 4 BIG BEAT TECHNO 1 5 BIG BEAT TECHNO 2 6 SPEED SHUFFLE 1 7 SPEED SHUFFLE 2 8 POP TRANCE 1

9 POP TRANCE 2 10 SLOW SOUL 1 11 DIGITAL SHUFFLE 1 12 DIGITAL SHUFFLE 2 13 POWER POP 1 14 POWER POP 2 15 POWER POP 3 16 NEO TRANCE 1 17 NEO TRANCE 2 18 HARD SHUFFLE 1 19 HARD SHUFFLE 2 20 ELECTRO BOUNCE 1 21 ELECTRO BOUNCE 2 22 POWER ELECTRO 1 23 POWER ELECTRO 2 24 ACID DANCE 25 POWER DANCE 1 26 POWER DANCE 2 27 FUTURE DANCE 28 DANCE RAGGA 29 ACID ELECTRO 1 30 ACID ELECTRO 2 31 HARD ELECTRO 32 ACID TECHNO 1 33 ACID TECHNO 2 34 FANTASTIC DANCE 35 FUTURE POP

HOUSE

36 ELECTRIC POP 37 DIGITAL SHUFFLE 3 38 POP DANCE 1 39 POP DANCE 2 40 FUTURE HOUSE 1 41 FUTURE HOUSE 2 42 SPEED HOUSE 1 43 SPEED HOUSE 2 44 URBAN DANCE 1 45 URBAN DANCE 2

HIP-HOP

46 DEEP SOUL 1 47 DEEP SOUL 2 48 SLOW SOUL 2 49 ELECTRO BOUNCE 3 50 ELECTRO RAGGA

EN-49

Rhythm List

Reference

No. Rhythm name

8 BEAT

1 STRAIGHT 8 BEAT 2 8 BEAT

16 BEAT

3 16 BEAT 4 16 BEAT SHUFFLE 1 5 16 BEAT SHUFFLE 2

BALLAD

6 MODERN BALLAD 7 16 BEAT BALLAD 8 POP BALLAD 9 6/8 BALLAD

DANCE

10 EDM 1 11 EDM 2 12 DISCO POP 13 MODERN R&B

POPS

14 POP 15 POP ROCK 16 60’s SOUL

ROCK

17 STRAIGHT ROCK 18 SHUFFLE ROCK 19 SLOW ROCK 20 ROCK WALTZ

JAZZ

21 BIG BAND 22 SLOW SWING 23 JAZZ WALTZ 24 FOX TROT

EUROPEAN

25 POLKA 26 WALTZ 1 27 SLOW WALTZ 28 VIENNESE WALTZ 29 FRENCH WALTZ 30 TANGO 31 MARCH 1 32 MARCH 2

LATIN

33 BOSSA NOVA 34 SAMBA 35 MAMBO 36 RHUMBA 37 CHA-CHA-CHA 38 MERENGUE 39 BOLERO 40 SALSA 41 REGGAE 42 POP REGGAE 43 SKA 44 CUMBIA

INDIAN

45 BHANGRA 46 DADRA 47 GARBA 48 KEHARWA 49 TEEN TAAL 50 DANDIYA

No. Rhythm name

51 BHAJAN 52 INDIAN POP 1 53 INDIAN POP 2 54 INDIAN POP 3 55 INDIAN POP 4 56 QAWWALI 57 KERALA 58 RAJASTHANI

WORLD

AMERICAN

59 COUNTRY BALLAD 60 BLUEGRASS 61 DIXIE 62 TEX-MEX 63 FAST GOSPEL 64 HAWAIIAN

EASTERN EUROPEAN

65 RUSSIAN CHANSON

ARABIC

66 ADANI

CHINESE

67 JIANGNAN 68 DONGBEIYANGGE 69 JINGJU 70 HUANGMEIXI 71 MIAOZU 72 XINJIANG

INDONESIAN

73 DANGDUT

VARIOUS

74 CHRISTMAS WALTZ 75 STRING QUARTET

PIANO RHYTHMS

76 ARPEGGIO 77 WALTZ 2

EN-50

Fingering Guide

Cdim

Caug



Csus4

Csus2

CmM7

Cdim7

C6 *1

Cm6 *2

CaugM7

CdimM7

Caug7

Cm7

CM7

Cm7



CM7



C7sus4



*4*4*4

Cmadd9

C69

Cm69

Cadd9



D C



F C

GCA



A C

AmCBm

Ddim

Fdim

FM7CAM7CFm7



Gdim

AdimCBdim

A7

Fm7



CmCDmCFm

zzzzz zz z z z

zz zz zz z

Am

Fm

zzzzz zz

Gm7

Aadd9

zz z z

Cdim

Fdim

Adim

■ FINGERED 1, FINGERED 2 Chords

Reference

*1 With FINGERED 2, interpreted as Am7. *2 With FINGERED 2, interpreted as Am7 *3 Inverted form not supported in some cases. *4 These fingerings are special fingerings for Digital

Keyboard chord input, and so they are not suitable for normal keyboard play.

■ FINGERED ON BASS, FULL RANGE CHORD

In addition to the chords that can be fingered with FINGERED 1 and FINGERED 2, the chords below also are recognized.

• With FINGERED ON BASS, the lowest note fingered is interpreted as the base note. Inverted forms are not supported.

• With FULL RANGE CHORD, when the lowest note fingered is a certain distance from the neighboring note, the chord is interpreted as a fraction chord.

• Unlike FINGERED 1, 2, and FINGERED ON BASS, FULL RANGE CHORD requires pressing of at least three keys to form a chord.

EN-51

Chord Example List

dim

aug

sus4

sus2



7sus4

add9

madd9

mM7

dim7

FCC



/(D



)

(



)



Reference

*1 Root *2 Chord Type

• Since the chord input range is limited, this model may not support some of the chords shown above.

EN-52

Reference

dim

aug

sus4

sus2



7sus4

add9

madd9

mM7

dim7

(

)

BF/(G

)

(

)











*1 Root *2 Chord Type

• Since the chord input range is limited, this model may not support some of the chords shown above.

EN-53

Function Transmitted Recognized Remarks

Basic

Channel

1 - 16

Default

Changed

Note

Number

0 - 127

True voice

After

Touch

Control

Change

Pitch Bender

Key’s

Ch’s

Velocity

9nH v = 1 - 127

9nH v = 0, 8nH v =

O 9nH v = 1 - 127

X 8nH v = 64

Note ON

Note OFF

Mode

Mode 3

Default

Messages

Altered

015

6, 38

1011646566

Bank select

Modulation

Portamento Time

Data entry LSB/MSB

Volume

Pan

Expression

Hold 1

Portamento Switch

Sostenuto

Model: LK-S250 Version : 1.0

XXXXX

XOX

*3*

OOOOOOOOO

MIDI Implementation Chart

**: no relation

Program

Change

True #

Exclusive

System

Common

XXX

Song Pos

Song Sel

Tune

Aux

Messages

Remarks

XXXXX

OXO

All sound off

Reset all controller

Local ON/OFF

All notes OFF

Active Sense

System Reset

System

Real Time

Clock

Commands

67717273748491

100, 101

Soft pedal

Filter resonance

Release time

Attack time

Brightness

Portamento Control

Reverb send level

RPN LSB/MSB

Mode 1 : OMNI ON, POLY

Mode 3 : OMNI OFF, POLY

Mode 2 : OMNI ON, MONO

Mode 4 : OMNI OFF, MONO

O : Yes

X : No

OXO

XXXXX

OOOOOOO

0 - 127

https://support.casio.com/global/en/emi/manual/LK-S250/

*1: Depends on tone.

*2: For details about RPN and system exclusive messages, see MIDI Implementation at

*3: In accordance with pedal effect setting.

MA1908-A

Casio LK-S250 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

General Guide

Getting Ready to Play

Preparing a Power Supply

Preparing the Music Stand

Connecting Headphones (Sold Separately)

Connecting a Pedal (Sold Separately)

Connecting a Microphone (Commercially Available)

Display Screen Contents

3 Buttons

Dial Operations

HOME Button

Key Light Function

Playing on the Keyboard

Turning Power On or Off

Adjusting the Volume Level

Using the Metronome

Listening to Demo Play

Controlling the Sound of a Performance

Selecting a Musical Instrument Tone

Changing Keyboard Response to Touch Pressure (Touch Response)

Using a Pedal

Using the SUSTAIN Button

Adding Reverb to Notes

Changing the Pitch in Semitone Steps (Transpose)

Fine Tuning Pitch (Tuning)

Saving and Loading Instrument Settings (MY SETUP)

Saving to MY SETUP

Recalling From MY SETUP

Playing a Built-in Song

Songs

Selecting a Song to Play

Assigning the Song Tone to the Keyboard (Tone Sync)

Practicing a Song Part

Sounding a Count in Time with a Song

Using a Lesson to Master Song Play

Lessons

Selecting a Song and Taking a Lesson

Looping Part of a Song as a Lesson (Loop Lesson)

Playing in the Dance Music Mode

Dance Music Mode

Playing Dance Music

Using the Recommended Tone

Using a Dance Music Voice

Using Effects

Building Performance Tension

Playing with a Rhythm Backing

Rhythm

Playing a Rhythm

Using Recommended Rhythm Settings

Changing the Rhythm Pattern

Inserting a Fill-in Phrase Fingering a Chord to Play a

Inserting an Intro or an Ending

Connecting with External Devices

Linking with a Smart Device (APP Function)

Connecting to a computer and Using MIDI

Connecting with Audio Equipment

Configuring Function Settings

Configuring Settings

Setting Item List

Reference

Troubleshooting

Product Specifications

Tone List

Drum Assignment List

Song List

Dance Music Mode List

Rhythm List

Fingering Guide

Chord Example List

MIDI Implementation Chart
