Casio JD6000, JD-7000 Service Manual

Download

JD-6000(LX-172)

INDEX

JD-7000(LX-173)

MAR. 1994

(without price)

JD-7000

CONTENTS

1. SCHEMATIC DIAGRAM................................................................................................ 1

2. SPECIFICATIONS ......................................................................................................... 3

3. GENERAL GUIDE ......................................................................................................... 7

4. RESET OPERATIONS ................................................................................................ 12

5. BATTERY REPLACEMENT........................................................................................ 14

6. ERROR MESSAGE ..................................................................................................... 16

7. LSI PIN FUNCTION ..................................................................................................... 17

8. OPERATION CHECK .................................................................................................. 20

9. TO SAVE THE DATA TO OTHER MACHINE............................................................. 21

10. TROUBLESHOOTING................................................................................................. 24

11. EXPLODED VIEW ....................................................................................................... 27

12. PARTS LIST ................................................................................................................ 29

1. SCHEMATIC DIAGRAM

— 1 —

NOTES

Power supply checking point. Function checking point.

2. SPECIFICATIONS

Telephone Directory Mode

Storage and recall of telephone directory data (name, telephone number, address, etc.). Each item can contain up to 380 characters with a Fun Face. Includes secret memory area and auto sort function.

Schedule Mode

Storage and recall of appointments for any date in the range of January 1901 through December 2099. Each item can contain up to 372 characters with an icon. Includes secret memory area and auto sort function.

Calendar Mode

Full-month calendars in the range of January 1901 through December 2099. Includes highlighting of important dates and holidays.

Data Memo "Diary" Mode

Storage and recall of memos. Each item can contain up to 381 characters. Includes secret memory area and auto sort function.

Timekeeping Mode

Average of accuracy ±3 seconds per day under normal temperatures: Home Time (year/month/date, AM/PM, day of the week, city name, daylight saving/standard time): World Time: full automatic calendar: 12/24 hour timekeeping format

Alarm Mode

Daily Alarm (20-second electronic buzzer): Schedule Alarm (20-second electronic buzzer): Hourly Time Signal (beeps every hour on the hour)

Conversion Mode

Six built-in conversion pairs (4-character unit name + 10 digit rate; user-definable)

Fortune Telling Mode

Fortune telling on any date from January 1, 1901 to December 31, 2099.

Match Maker Mode

Compatibility of any two people whose birthdays are from January 1, 1901 to December 31, 2099.

Calculator Mode

10-digit arithmetic calculations; constant calculations; memory calculations; 20-digit approximations; percentage calculations; square roots; sign changes; function command signs

Remote Control Modes (JD-6000)

Television (Power on/off, TV/VCR mode select, Channel +/Cannel –, direct channel input, volume control); Video Tape Deck (Power on/off, TV/VCR mode select, Cannel +/Cannel –, play, record, stop, pause, fast forward, rewind, TV volume control): manufacturer name registrasion.

Game Mode (JD-7000)

Battle Game

Other functions

Contrast adjustment

— 3 —

General

Display: Liquid crystal display Memory Capacity: 4,096 bytes Power Supply: Main batteries – Two AAA-size batteries (LR03 (AM-4) or R03 (UM-4))

Back-up battery – One lithium battery (CR2032)

Power Consumption: 0.2W Battery Life: Main batteries –

LR03 (AM-4)

•approximately 240 hours continuous operation

•approximately 1 year (1 hour use per day)

R03 (UM-4)

•approximately 200 hours continuous operation

•approximately 10 months (1 hour use per day)

Back-up battery – approximately 3 years after the low main battery warning

appears on the display

Auto Power Off: Approximately 6 minutes after last key operation Ambient Temperature Range: 0°C ~ 40°C (32°F ~ 104°F) Dimensions: Open: 13.5 (H) × 145 (W) × 179.5 (D) mm

(1/2" (H) × 5 3/4" (W) × 7 1/8" (D))

Closed: 15.1 (H) × 145 (W) × 96.5 (D) mm

(5/8" (H) × 5 3/4 " (W) × 3 3/4" (D))

Weight: 138.2 g (4.9 oz) including batteries

— 4 —

Current consumption

Check point TYP [µA] Max [µA] OFF CP1 - CP3 — 28 ON (Menu) CP1 - CP3 230 300

ON (Buzzer) CP1 - CP3 — 1720

ON (Infrared) CP1 - CP3 — 63000

Memory Capacity Screen

Use the following procedures to check the status of the memory. One procedure displays the amount of memory used and the how much memory is remaining. The other shows you how many data items you have stored in each mode.

To display the memory capacity:

1. While the main menu is displayed, or any time you are in the Telephone Directory, Schedule, Data Memo "Diary", or Calendar mode, press FUNCTION.

2. Use and to select "Memory Capacity" and then press EXE.

Memory Capac i ty

Remaining memory (Unit: bytes)

Memory used (Unit: bytes)

F ree 3929 Used 167

Memory used

4 %

• The memory values shown above are the total for both the Open Memory Area and the Secret Memory Area.

• Press AC/ON to clear the memory capacity screen.

To display the number of items in each mode:

1. While the main menu is displayed, press FUNCTION.

2. Use and to select "Number of items" and then press EXE.

Open Memory Area

Tel(Busi) : 15 Tel(Pers) : 8 Schedule : 3 Data Memo : 7

Secret Memory Area

Tel(Busi) : 3 Tel(Pers) : 4 S chedule : 2

Data Memo : 11

• If you perform the above procedure while in the Open Memory Area, the number of items stored in the Open Memory Area only are displayed. To see the number of items in the Secret Memory Area, you must perform the above operation while accessing the Secret Memory Area.

How memory capacity is calculated

There is no limit on the amount of memory you can use in each mode, but the total amount of data that can be stored is 4,096 bytes. The following shows how many bytes the data in each mode takes up. One character (each newline operation counts as a character also) takes up one byte.

— 5 —

Mode Bytes per Data Item

Telephone Directory (name) + (telephone number) + (address. etc.)

+ 15 Schedule (description) + 12 Calendar 6 bytes per calendar that contains highlighted

dates Data Memo "Diary" (memo name) + (memo contents) + 3

Examples:

Telephone Directory data only

When all items use 10 characters for the name, 12 characters for the phone number, and 16 characters of the address, you can store approximately 70 items.

Schedule data only

When all items use 20 characters, you can store approximately 120 items.

Data Memo "Diary" data only

When all items use 10 characters for the memo name and 10 characters for the memo content, you can store approximately 170 items.

Sort Sequence

The following table shows the sequence used for sorting data in the Telephone Directory and the Data Memo "Diary" Mode.

1 2 3 4 5 6 7 8

9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29

→

←

Space

” # $

’

(

)

∗

, –

•

/ 0 1 2 3 4 5 6 7

30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54 55 56 57 58

117

118

119

120

;

121

„

“

95 96 97 98

99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116

> ~ Á É

Í Ó Ú Ã Õ Ñ

á é

ó ú ã õ

ñ À È

122 123 124 125 126 127 128 129 130 131 132 133 134 135 136 137 138 139 140 141 142 143 144 145

Ä Ë

Ü Æ Œ

æ œ

Z à è

ì ò ù ç

. z

" ä

ï ö ü

146 147 148 149 150 151 152 153 154 155 156 157 158 159 160 161 162 163 164 165 166 167 168 169 170 171 172 173 174

o Â Ê

Î Ô Û Å

. U

â ê

ô û å

u A E C D N R S

c d'

175 176 177 178 179 180 181 182 183 184 185 186 187 188 189 190 191 192 193 194 195 196 197

r s t' A E

Z Z

´ n

´ s

´ y

´ z

Ø ø ß

— 6 —

3. GENERAL GUIDE

Very important stuff! Here's where we tell you how not to lose important data stored in memory. Also, be sure to perform the all-reset operation before using the JD-6000/7000 for the first time. The all-reset operation is described on page 12.

Please be sure you understand the following before using the JD-6000/7000.

Make back-up copies of important data!

The electronic memory in the JD-6000/7000 store and recall information quickly and easily. But that information is retained only as long as power is supplied by the batteries. Should the batteries go dead, or should you remove both batteries at the same time, data stored in memory can be lost entirely. Data can also be corrupted or lost due to a strong electrostatic charge, strong impact, or extremes in temperature and humidity. All of this means that you should always keep written back-up copies of important data.

General Precautions

Warning!

• Never expose the unit or batteries to direct heat or flame.

• Avoid use or storage in very low temperatures. This may cause display response to slow down or fail entirely. Very low temperatures can also shorten battery life.

• Avoid use or storage in very high temperatures. Even prolonged exposure to direct sunlight can damage the unit. Leaving it on the dashboard of a closed car, or on a heater, is even worse.

• Avoid using or storing the unit where there is high humidity or a lot of dust. Never allow liquids to come into contact with the unit.

• Avoid dropping the unit or otherwise subjecting it to strong impact.

• Never bend or twist the unit. Carrying it in your back pocket, for instance, can subject the JD-6000/7000 to abnormal bending and twisting.

• Never try to take the unit apart.

• Do not press the unit's keys with a pen, pencil, or other sharp object.

• To clean the JD-6000/7000, wipe it with a soft cloth. When necessary, you may wipe the exterior with a soft cloth that has been dipped in a weak solution of a mild, neutral detergent and water.

• Never use strong liquid cleaners such as lacquer thinner or benzine to clean the unit.

• In no event will CASIO or its suppliers be liable to you or any other person for any damages, including any incidental or consequential expenses, lost profits, lost savings, or any other damages arising out of the use of this product.

MENU Key

Game Mode Key

Timekeeping Mode Key*

FUNCTION Key

Display

CODE Key

Clear Key

AC/ON Key

SHIFT Key

SERCH Key Cursor Keys

Connector Terminal OFF Key EXE Key SPACE/Return Key

* In this manual, all references to the HOME TIME/WORLD TIME key are indicated by TIME.

— 7 —

Displaying the Main Menu

The main menu appears on the display when you switch the power on. Whenever you are viewing any other screen, you can always press MENU to return to the main menu.

Main Menu

Menu Icons

1 Telephone Directory 6 Magic Beam Mode

Business Mode 7 Calculator Mode

2 Telephone Directory 8 Conversion Mode

Personal Mode 9 Alarm Mode

3 Schedule Mode 0 Data Memo "Diary" Mode 4 Calendar Mode A Fortune Telling Mode 5 Secret Memory Area B Match Maker Mode

12 3 456

78 9 0AB

Changing Modes

To change modes:

1. Display the main menu.

2. The icon of the current mode is highlighted on the display . Use , , , and to select another menu icon.

3. When you have highlighted the mode you wish to select, press EXE.

To enter the Timekeeping Mode, press TIME key. To enter the Remote Control Modes, press REMOTE CONTROLLER (for JD-6000.) To enter the Game Mode, press BATTLE (for JD-7000.) You cannot select these modes from the main menu.

— 8 —

Using the FUNCTION Key

To view the function menu, press FUNCTION. To select a function:

1. Use or to highlight the function you want to choose.

2. Press EXE.

If another function menu appears repeat steps 1 and 2. To backstep to a previous display, press FUNCTION. To exit the function menu, press AC/ON.

Setting the System Language

The JD-6000/7000 can produce display messages in any one of ten language: English, Spanish, Italian, German, French, Danish, Swedish, Dutch, Finnish, and Portuguese.

* Forture Telling and Match Maker mode messages can be displayed only when the display message language is set to English.

To set the system to another language:

1. Display the main menu.

2. Press FUNCTION, then use or to highlight "Language." Press EXE.

3. Use or to highlight the language you want. Press EXE.

Also note the word "Language" is displayed in each language.

To Adjust the Display Contrast

1. Display the main menu.

2. To darken the figures on the display, press . To make them lighter, press .

To Switch the Key Input Tone On or Off

1. Display the main menu.

2. Use , , , and to highlight . Press EXE.

3. Press FUNCTION. Then use to highlight "Sound," Press EXE.

4. Use to highlight "Key Tone." Use and to switch the key tone on and off. Press EXE.

Auto Power Off Function

This function automatically switches off the power if you do not touch any of the unit's keys for about six minutes. To restore power, press AC/ON.

If you do not touch any keys for six minutes while entering or editing data, setting the current time, or setting an alarm time, power cuts off without storing the data.

If you have set an alarm to go off, and the unit has been shut down by auto power off, the alarm will sound anyway at its appropriate time.

— 9 —

Features and Functions

Telephone Directory Mode

Use this to keep names, phone numbers, and addresses. There are two storage areas, so you can keep business and personal data separate. You can also include fun faces of the people whose names and addresses you keep.

Schedule Mode

Stores the date, time, and type of each appointment. You can select icons to indicate each appointment at a glance.

Calendar Mode

Displays the calendar for any month from January, 1901 to December, 2099. You can specify holidays for highlighting.

Data Memo "Diary" Mode

Stores notes and special thoughts. Diary entry consists of a memo name and the memo's contents.

Secret Memory Area

Stores your private thoughts you wish to keep confidential. No one can gain access to the Secret Memory Area without knowing your password.

Timekeeping Mode

Home Time displays the current time where you are. World Time shows the time in any of 29 zones around the globe. You can use 24-hour or 12-hour format, and can even specify daylight savings time.

Alarm Mode

Lets you set alarms to the minute, for alarms to go off every hour, or for a single time each day. You can also set the Schedule Alarm and control the key input tone.

Fortune Telling Mode

Once you have entered your birthday, you can check your fortune today, or for any day. Have fun telling your friend's fortune too.

Match Maker Mode

Tells you whether or not you are compatible with that special someone.

Conversion Mode

Helps you compare US dollar values against six foreign currencies (monies), or with combinations of currency units.

Calculator Mode

A 10-digit calculator performs most common numerical operations including percents, square roots and memory.

Remote Control Modes (for JD-6000)

Let you use the JD-6000 for remote control of your TV or video tape deck.

Game Mode (for JD-7000)

An exciting game that you can play by challenging the JD-7000 or your friends.

— 10 —

Magic Beam Mode

Mask it possible to communicate with another JD-6000/7000 using infrared light, without direct communication.

Effective range

Approximately 8 meters

20°

(8.7 yards)

Data Communication Function

Exchanges data with another unit. To communicate with a friend, you'll need an optional SB-62 communication cable to connect the JD-6000/7000 to another.

About the "Check time!" Display

When the message, "Check time!" appears on the display, press any key to display the current time. Make sure the JD-6000/7000 have the correct time before performing any other operation. If the setting is not correct, use the procedure for "Setting the Date and Time" in the Operation Manual to change it.

List of Manufacturers (for JD-6000)

The following is a list of manufacturers that can be registered for the TV and VCR Remote Control Modes.

Manufactures

EMERSON GE 1 GE 2 GOLDSTAR HITACHI JERROLD 1 (C)* JERROLD 2 (C)* JVC 1 JVC 2 JVC 3 MAGNAVOX 1 MAGNAVOX 2 MAGNAVOX 3 MAGNAVOX 4 MITSUBISHI PANASONIC 1 PANASONIC 2 PANASONIC 3 (C)* PHILIPS PIONNER (C)* RCA 1 RCA 2 RCA 3 SAMSUNG 1 SAMSUNG 2 SCIENTIFIC ATC (ATLANTIC) 1 (C)* SCIENTIFIC ATC (ATLANTIC) 2 (C)* SHARP SONY TOSHIBA 1 TOSHIBA 2

VCR

Manufactures

EMERSON 1 EMERSON 2 EMERSON 3 GE GOLDSTAR 1 GOLDSTAR 2 HITACHI JVC 1 JVC 2 JVC 3 JVC 4 MITSUBISHI 1 MITSUBISHI 2 PANASONIC 1 PANASONIC 2 PHILIPS 1 PHILIPS 2 RCA 1 RCA 2 RCA 3 SAMSUNG 1 SAMSUNG 2 SHARP 1 SHARP 2 SONY 1 SONY 2 SONY 3 TOSHIBA 1 TOSHIBA 2

* "(C)" indicates cable box.

— 11 —

4. RESET OPERATIONS

RESET button

RESET

Two kinds of reset operations can be performed:

•

All-reset operation

•

Secret-reset operation

Important!

• Do not use a very sharp pencil to press the RESET button. Doing so can damage the JD-6000/7000.

• Be sure to perform the all-reset operation before you use the JD-6000/7000 for the first time.

• After check to make sure that the main batteries and back-up battery are correctly installed, perform the

RESET operation.

To Perform All-Reset:

1. Switch the power off.

2. Remove the screw that holds the battery compartment cover in place, then remove the battery

compartment cover.

3. Press the RESET button on the back of the JD-

6000/7000 with a thin, pointed object.

4. Press to select "Reset," then press EXE.

5. Press to select "Yes, " then press EXE.

6. The main menu will appear and all data will be

deleted.

7. Replace the battery compartment cover and

the screw that secures it in place. If you want to cancel the reset operation immediately after you have pressed the RESET button, select "Exit," then press EXE.

deletes all data in memory.

deletes only your password and the data in the Secret Memory Area.

— 12 —

To Perform Secret Reset:

• Perform the steps described under "To Perform All-reset" above, but select "Del Secret Data" in place

of "Reset" in step 4.

For JD-6000

Following are the initial settings produced by the all-reset operation:

Home Time Zone: London (LON) Home Time Setting: 12:00 AM, January 1, 1990 World Time: New York (NYC) 12/24-Hour Clock: 12-Hour Clock Alarm: OFF Alarm Time: 12:00 AM Hourly Time Signal: OFF Key Input Tone: ON Date Format: Month/Day/Year Language: English TV Manufacturer: EMERSON VCR Manufacturer: EMERSON 1

For JD-7000

Following are the initial settings produced by the all-reset operation:

When the JD-6000/7000 Does Not Work Correctly...

If the JD-6000/7000 are jolted by a strong electrostatic charge or by severe impact, it may not work properly. In such a case, first check to make sure that the main batteries and back-up battery are correctly installed, and then perform the following operation:

1. Remove the screw that holds the battery compartment cover in place and remove the battery

compartment cover.

2. Press the RESET button with a thin, pointed object.

3. Look for the message, "Exit," to be highlighted on the display.

4. Press EXE. Now the message, "Check time!" should be on the display.

— 13 —

5. BATTERY REPLACEMENT

Low Battery Warning

The message, "Main Battery Getting Weak! Replace it!" appears whenever battery power drops below a certain level. Replace the main battery immediately after this message appears. When the battery is getting weak between 2.85V and 2.55V, the unit will show the message. Whenever the low battery warning message appears, the OFF key will be the only function that works. If you don't turn the unit off yourself, power will switch off automatically about 30 seconds after the low battery warning appears.

Replacing Batteries

• Main Batteries Two AAA size batteries (LR03 (AM-4) or R03 (UM-4)) are used for the main power supply. The JD-6000/ 7000 will not operate at all if main batteries are not installed.

• Back-up Battery One CR2032 lithium battery supplies power to the memory and protects its contents.

Memory contents are lost when both the main batteries and the back-up battery are removed. Be sure always to leave one of the batteries or back-up battery in place to protect memory contents. If, however, you remove the main battery for any time, memory retention will depend entirely on the condition of the back-up battery. Over a long period of time with just the back-up battery in place, memory contents are likely to be damaged. If memory seems corrupted, clear it using the RESET procedure described on page 12.

Important!

Incorrect use of batteries can cause them to burst or leak, possibly damaging the interior of the JD-6000/7000. Note the following precautions:

• Be sure that the positive (+) and negative (-) poles of the batteries are facing in the proper direction.

• Never leave dead batteries in the battery compartment.

• Remove the batteries if you expect not to be using the JD-6000/7000 for a long period of time.

• To avoid damage to the unit from leaky batteries, replace the main batteries at least every two years, and

the back-up battery every three years. Batteries should be replaced no matter how much you use the unit during that time.

• Never mix batteries of different types.

Warning!

• Never try to recharge the batteries supplied with the JD-6000/7000.

• Do not expose batteries to direct heat, short-circuit them, or try to take them apart.

• Keep batteries out of the reach of small children. If swallowed, consult a physician immediately.

— 14 —

To replace the main batteries

1. Switch power off.

2. Loosen the screw of the large battery compartment cover on the back of the unit, and slide the battery

compartment cover in the direction noted by the arrow. (Figure 1)

3. Remove the old batteries.

4. Making sure that the positive (+) and negative (-) ends of the batteries are facing correctly, load two new

batteries into the compartment. (Figure 2)

• Be sure to replace both old batteries with two new ones.

5. Insert the tabs on the bottom of the battery compartment cover into the slots of the battery compartment

and carefully close the cover. Secure the cover in place with the screw. (Figure 3)

Figure 1 Figure 2 Figure 3

To replace the back-up battery

1. Switch power off.

2. Loosen the screw of the small battery compartment cover on the back of the unit, and remove the back-

up battery compartment cover. (Figure 4)

3. Remove the old battery.

4. Wipe off a new battery with a soft cloth.Then, load it into the compartment making sure that positive (+) side

is facing up (so you can see it.) (Figure 5)

5. Insert the tabs on the bottom of the battery compartment cover into the slots of the battery compartment

and carefully close the cover. Secure the cover in place with the screw. (Figure 6)

Figure 4 Figure 5 Figure 6

— 15 —

6. ERROR MESSAGE

Message

Memory Full!

No Record!

Not Found!

Password Mismatch!

Main Battery Getting Weak! Replace it!

Communication Error

Send Error! Receive Error!

Meaning

Not enough room to store the data you are trying to save.

You tried to perform a search operation while there is no data stored in memory.

There is no data that matches your search specification.

The password you input to access the Secret Memory Area does not match the one that is registered.

The main batteries are weak.

•Error during data communications using Magic Beam.

• Magic Beam data communications interrupted.

Poor connections or some other problem has caused data transfer be aborted.

Action

Press AC/ON and then delete data you no longer need from memory.

Input data before attempting search operations.

Press or to recall your search data. You can then edit the previous data or input new data.

Input the password correctly.

Replace the batteries in accordance with the instructions of this manual.

Correct problem and try again.

Correct the problem and try again.

— 16 —

7. LSI PIN FUNCTION

1. CPU (HC3000-06-F1)

Pin No. Signal In/Out Function

1 VREG3 Out Power supply for RAM / 3(V) 2 DMY – Not used

3 ~ 5 KO10 ~ 12 Out Not used

6 ~ 14 KO1 ~ 9 Out Key scan signal

15 KI8 In Not used

16 ~ 22 KI1~7 In Key input signal

23 , 25 TRANS, DUMMY – Not used

24 BUFON Out Power supply control for ROM 26 IT2 In Interrupt signal input 27 IT0 In Reception data input 28 AO17 Out Not used

29 ~ 45 A0 ~ A16 Out Address bus

46 OEB0 Out Output enable signal for RAM and ROM 47 WEB0 Out Write enable signal for RAM

48 ~ 52 – Not used

53 CS7B0 Out Chip enable signal for RAM 54 CS6 Out Chip enable signal for ROM

55, 56 Out Not used

57 ~ 64 IO0 ~ IO7 In/Out Data bus

65, 66 – Not used

67 OPT6 Out Turn on signal for Photo Sensor 68 OPT5 Out Turn on signal for LED (Infrared) 69 OPT4 In Communication data through Photo Sensor

70 ~ 73 – Not used

74 PORT7 – Interrupt port

— 17 —

Pin No. Signal In/Out Function

75 ~ 77 PORT4~6 In/Out For data communication 78 ~ 80 PORT1~3 – Interrupt port

81, 82 – Not used 83, 84 PI, PO In/Out Main clock terminal (3,45 MG)

85 DUMMY – Not used

86, 87 XI, XO In/Out Clock terminal (DT-26S)

88 DUMMY – Not used

89 ~ 184 S1 ~ S96 Out Segment signal for display

185 ~ 216 C1 ~ C32 Out Common signal for display

217 VSSR In GND / 0[V]

218 ~ 222 V0 ~ V4 Out The voltage for LCD drive

OFF : 0[V] ON; V0 : 3.6 (Min) ~ 5.8 (Max) [V]

V1 : 2.9 (Min) ~ 4.6 (Max) [V] V2 : 2.1 (Min) ~ 3.5 (Max) [V] V3 : 1.4 (Min) ~ 2.4 (Max) [V] V4 : 0.7 (Min) ~ 1.2 (Max) [V]

223, 224 VSS In GND / 0[V]

225 DUMMY – Not used 226 VCC In Power supply / 3[V]

227 VREG2 Out 2 [V] 228, 229 TS1, 2 – Test for manufacturer 230, 231 BZ1, 2 Out Buzzer terminal

232 SW1 In 2.6[V]

While pushing the reset button: 0[V] 233, 234 VD1, 2 – VD1: 4.7[V] VD2: 1.6[V] 235, 236 VD3, 4 – VD3: 4.7[V] VD4: 1.6[V]

— 18 —

Pin No. Signal In/Out Function

237 VDB In Low battery detection

VDB < 4.4[V] ⇒ Low battery message

238, 239 VREG1, 4 – VREG1: 2.6 [V]

VREG4: 5.0 [V]

240 ~ 243 VT1 ~ VT4 – VT1 : 1.0[V] VT2 : 2.9[V]

VT3 : 2.0[V] VT4 : 3.9[V]

244 VLCD Out 5.9 [V]

2. RAM (LC3564QM-85)

Pin No. Signal In/Out Function

1 NC – No connect

2 ~ 10 A0~A7, A12 In Address bus

11 ~ 13 I/O 0 ~ I/O 2 In/Out Data bus

14 GND In GND / 0[V]

15 ~ 19 I/O 3 ~ I/O 7 In/Out Data bus

20 CE In Chip enable signal 21 A10 In Address bus 22 OE In Output enable signal

23 ~ 25 A8, A9, A11 In Address bus

26 CE2 In Chip enable signal 27 WE In Write enable signal 28 VCC In Power supply / 3[V]

— 19 —

8. OPERATION CHECK

CAUTION : If customer's data are stored in the unit, all data will be corrupted by this operation.

STEP OPERATION DISPLAY NOTE

MENU Then short in the checkpad

about two seconds.

EXE

Caution!

This is TEST

To Escape

Press AC KEY

1. RAM, ROM 2. DISP

3. KEY 4. TRANS

5. RESET 6. FCC

7. OPT AC. Esc

8K RAM OK!

ROM OK!

1. RAM, ROM 2. DISP

3. KEY 4. TRANS

5. RESET 6. FCC

7. OPT

All dots display

No display

The checkpad is located right side of the back-up battery switch.

RAM check

ROM check

DISPLAY check

EXE

· · · · · · · M SPACE

TIME

FUNC

Checker display

Reverse checker display

Frame display

1. RAM, ROM 2. DISP

3. KEY 4. TRANS

5. RESET 6. FCC

7. OPT

TIME, FUNC, · · · SPACE/

1. RAM, ROM 2. DISP

3. KEY 4. TRANS

5. RESET 6. FCC

7. OPT

Key check Push the key sequentially appeared on the display.

Check the key sound.

RESET!

— 20 —

After a harf second, the main menu will appear.

9. TO SAVE THE DATA TO OTHER MACHINE

• JD-6000/7000 can transfer customers data (both open and secret area) to other JD-6000/7000 unit when replacing the LCD or the outer case.

• Turn off both units and connect them using a SB-60 or a SB-62 cable. 1 To set up the slave unit.

1. Perform the reset operation.

2. Change the Home Time zone to Paris. HOME TIME

AC ,

WORLD TIME

FUNCTION

Use ∇ to select "Zone Change", and press

Use to select "<PAR>", and

EXE .

∇

press EXE .

LONDON FEB/12/1990 MON

7:XX XX

DST ON / OFF

Date Format 12 / 24 Hours Time Set

<LON>

FEB 12

PARIS FEB/12 /1990 MON

7 : XX

3. Set the date and time as follows.

1901 – 1 – 1 12:00 am

FUNCTION

Use ∆ to select "Time Set", and press EXE .

— 21 —

8 : XX XX

Date Format 12 / 24 Hours Time Set

Zone Change

PARIS 02/12/1990

08 : XX

∇

Use or to move the flashing selection, and use the number keys to input

∇

values for the flashing year, month, day, and item digits.

After setting, press EXE .

4. Set up the slave unit for data receiving.

MENU , FUNCTION

Use ∇ to select "Communication", and press EXE .

Use ∇ to select "Receive Data", and press

EXE .

PARIS JAN/1/1901 TUE

12:00 XX

Memory Capacity

Number of Items Delete Mode Data Language

Send Data

Receive Data Set Up

Reseive OK! To Stop

Press AC Key

2 To set up the master unit.

1. Set the hardware parameters as follows.

Parity : None, BPS : 9600

FUNCTION

AC ,

Use ∆ or ∇ to select "Communication", and press EXE .

Use ∆ or ∇ to select "Set Up", and press EXE .

Memory Capacity

Number of Items Delete Mode Data Language

Send Data

Receive Data Set Up

Parity

Even / Odd / None

BPS

4800 / 9600

— 22 —

Use ∆, ∇, or to select

∆

"None", "9600", and press EXE .

Send Data Receive Data

Set UP

Use ∆ to select "Send data", and press EXE .

Use ∇ to select "All data", and press EXE .

Use to select "Yes", and press

∆

EXE .

Mode Data

All Data

Send OK ?

Yes / No

Now sending ! To stop

Press AC Key

Now receiving !

To stop Press AC Key

About 10 seconds later, both unit change to menu display.

— 23 —

10. TROUBLESHOOTING

1. Intermittent display

2. Erratic display

3. No display

— 24 —

— 25 —

11. EXPLODED VIEW

— 27 —

DISASSEMBLY

1. Remove 2 screws P, then remove battery cover E and F.

2. Remove 2 AAA-size batteries and 1 lithium battery.

3. Remove 3 screws \, then remove the Lower case 0.

4. Remove 3 screws S, then remove the L172-1 ass’y 8.

12. PARTS LIST

— 29 —

— 30 —

— 31 —

— 32 —

8-11-10, Nishi-Shinjuku Shinjuku-ku, Tokyo 160, Japan Telephone: 03-3347-4926

Casio JD6000, JD-7000 Service Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
