Casio DT-810M50RC User Manual
Data Collector
Colector de Datos
Datenerfassungsgerät
Collecteur de Données
User’s Guide
Guía del usuario
Benutzerhandbuch
Guide de l’utilisateur
• Congratulations upon your selection of
the CASIO DT-810M50RC/M70RC Data
Collector.
• Be sure to familiarize yourself with the
basic operations described in this
manual before actually trying to operate
the Data Collector.
M50RC/M70RC
• Enhorabuena por la selección del
colector de datos DT-810M50RC/M70RC
CASIO.
• Antes de intentar utilizar este colector
de datos, familiarícese con las
operaciones básicas descritas en este
manual.
• Mit dem Datenerfassungsgerät CASIO
DT-810M50RC/M70RC haben Sie eine
gute Wahl getroffen.
• Bitte machen Sie sich mit den in
diesem Handbuch beschriebenen
Grundfunktionen vertraut, bevor Sie
beginnen, mit dem
Datenerfassungsgerät zu arbeiten.
• Nous vous remercions d‘avoir choisi le
Collecteur de Données
Casio DT-810M50RC/M70RC.
• Veuillez vous familiariser avec les
démarches de base, décrites dans le
présent manuel, avant d’essayer
d’utiliser le Collecteur de Données.
Safety Precautions
Congratulations upon your selection of this CASIO Product. Be sure to read
the following Safety Precautions before trying to use it for the first time.
Keep this manual in a handy place for future reference.
Markings and Symbols
Danger!
Warning!
Caution!
Marking examples
The following are the meanings of the markings and symbols
used in these Safety Precautions to warn you against the
possibility of personal injury and/or material damage or loss
to you and others. Take a few moments to become familiar
with these markings and symbols so you can avoid future
problems.
This symbol indicates information that, if ignored or
applied incorrectly, creates the danger of death or serious
personal injury.
This symbol indicates information that, if ignored or
applied incorrectly, can create the possibility of death or
serious personal injury.
This symbol indicates information that, if ignored or
applied incorrectly, can create the possibility of personal
injury or material damage.
A triangular shape indicates you should exercise
caution. The symbol shown here indicates you
should take care to avoid breakage.
A circle indicates something you should not
do. This symbol indicates you should not try to
take something apart.
E-2
A black circle indicates something you must
do. This symbol indicates you should unplug
something.
■ Lithium-ion Battery Pack
●Never allow the battery pack to become wet with either fresh water or salt
water. Water can create the danger of battery pack heat emission, explosion,
and fire.
●Never use or leave the battery pack next to open flame, near a stove, or any
other area exposed to high heat. Doing so creates the danger of battery pack
heat emission, explosion, and fire.
●Never use the battery pack with any device other than this unit. Doing so can
create the danger of battery pack heat emission, explosion, and fire.
●Note that the battery pack’s positive (+) and negative (–) terminals must be
oriented correctly when it is loaded into the charger unit or the Data
Collector. Connecting the battery pack with its terminals reversed creates the
danger of battery pack fluid leakage, heat emission, explosion, and fire.
●Never dispose of the battery pack by incinerating it or otherwise expose it to
heat. Doing so creates the danger of battery pack heat emission, explosion,
and fire.
●Never allow the positive (+) and negative (–) terminals of the battery pack to
become connected (shorted) by metal. Doing so creates the danger of
battery pack heat emission, explosion, and fire.
●Never transport or store the battery pack together with a necklace, hair pins
or other metal objects. Doing so can short battery pack terminals, creating
the danger of battery pack heat emission, explosion, and fire. Be sure to
place the battery pack in its case whenever transporting or storing it.
●Never throw the battery pack or otherwise subject it to strong impact. Doing
so creates the danger of battery pack heat emission, explosion, and fire.
●Never pierce the battery pack with nails, hit it with a hammer, or step on it.
Doing so can create the danger of battery pack heat emission, explosion,
and fire.
●Never try to take apart the battery pack or modify it in any way . Doing so
creates the danger of battery pack heat emission, explosion, and fire.
Danger!
●Use only the specified charger unit to charge the battery pack. Use of
another type of charger unit creates the danger of battery pack heat
emission, explosion, and fire.
E-3
Warning!
■ Disassembly and Modification
●Never try to disassemble or modify the unit in any way. High voltage inside
creates the danger of electrical shock.
■ Interior Parts and Components
●Never touch interior high-voltage parts or components. Doing so creates the
danger of electrical shock.
■ Abnormal Conditions
●Should the unit become hot or start to emit smoke or a strange odor,
immediately turn off power and contact your original dealer or authorized
CASIO service provider. Continued use creates the danger of fire and
electrical shock.
■ Foreign Objects
●Should any foreign matter ever get into the unit, immediately turn off power
and contact your original dealer or an authorized CASIO service provider.
Continued use creates the danger of fire and electrical shock.
■ Dropping and Damage
●Should you drop the unit and damage it, immediately turn off power and
contact your original dealer or an authorized CASIO service provider.
Continued use creates the danger of fire and electrical shock.
■ Moisture
●Keep the unit away from vases, planters, cups, glasses and other containers
■ Laser Beam
●Never look directly into the laser beam. Doing so can cause serious eye
E-4
of liquid. Also keep it away from metal. Water and metal getting into the unit
creates the danger of fire and electrical shock.
damage.
■ Backup Battery Handling
●Do not throw the battery into fire, or heat, take apart or modify them. Doing
so can damage the insulation or safety valves, and can create the danger of
battery leakage, heat emission, and rupture.
●Do not use the battery with its positive (+) and negative (–) terminals
reversed. Doing so can cause abnormal reactions by charging and shorting,
and can create the danger of battery leakage, heat emission, and rupture.
Do not connect the positive (+) and negative (–) terminals of the battery with
●
wire, or transport or store the battery with a necklace, hair pins or other metal
objects. Doing so can short the battery and cause excessive current to flow,
and can create the danger of battery leakage, heat emission, and rupture.
●Do not peel off or scratch the outer label on the battery. Doing so can short
the battery, and can create the danger of battery leakage, heat emission,
and rupture.
●Do not drop or throw the battery, or subject them to strong impact. Doing so
can create the danger of battery leakage, heat emission, and rupture.
●Do not deform the battery. Doing so can damage the insulation or safety
valves, and can create the danger of battery leakage, heat emission, and
rupture.
●Never charge the backup battery. Doing so can cause the battery fluid to boil
or internal pressure to rise due to the generation of gas. This can create the
danger of battery leakage, heat emission, rupture, and fire.
Never directly solder the backup battery. Heat can damage the insulation, and
●
can create the danger of battery leakage, heat emission, rupture, and fire.
●Keep the battery out of the reach of small children. Should small children
swallow a battery , consult a physician immediately.
●If the backup battery starts to leak or emits a strange odor, immediately
move it away from any nearby flame. Leaking battery fluid is combustible.
●When storing and disposing of backup batteries, insulate the terminals with
insulating tape. Mixing batteries together or with other metallic objects shorts
the battery terminals, and can create the danger of battery leakage, heat
emission, rupture, and fire.
Warning!
E-5
Warning!
■ Lithium-ion Battery Pack
●Never place the battery pack into a microwave oven or any other high-
voltage device. Doing so creates the danger of battery pack heat emission,
explosion, and fire.
●Should the battery pack emit a strange odor or heat, change color or shape,
or exhibit any other abnormal behavior, immediately stop using it. Continued
use creates the danger of battery pack heat emission, explosion, and fire.
●If the battery pack does not achieve full charge after the normal charging
time has passed, stop charging. Continued charging creates the danger of
battery pack heat emission, explosion, and fire.
●Should the battery pack start to leak or emit a strange odor, immediately
move it away from any nearby flame. Leaking battery fluid is combustible,
and exposure to flame creates the danger of explosion and fire.
●Should fluid from the battery pack accidentally get into your eyes, do not rub
them. Immediately rinse your eyes with clean tap water and then consult a
physician immediately .
■ Optional Optical Communication Unit and Charger Unit
●Power the Optical Communication Unit and charger unit only with a power
outlet whose voltage matches that marked on the Optical Communication
Unit and charger unit. Do not plug the Optical Communication Unit and
charger unit into an extension shared by other appliances. Doing so creates
the danger of fire and electrical shock.
●Avoid conditions that can cause damage or breaks in the power cord. Do not
place heavy objects on the power cord and keep it away from sources of
heat. Any of these conditions can damage the power cord, creating the
danger of fire and electrical shock.
●Never modify, sharply bend, twist, or pull on the power cord. Doing so
creates the danger of fire and electrical shock.
E-6
●Use only the AC adaptor model and charger specified in this manual. When
using the Optical Communication Unit, always use the AC adapter suplied
with the Optical Communication Unit. Use of another AC adaptor model or
charger creates the danger of fire and electrical shock.
●Should the power cord ever become severely damaged (to the point that
wires are exposed or broken), contact your original dealer or CASIO service
provider about repair or replacement. Use of a damaged electrical cord
creates the danger of fire and electrical shock.
Warning!
■ Make back-up copies of all important data
●Note that CASIO Computer Co., Ltd. shall not be held liable to you or any
third party for any damages or loss caused by deletion or corruption of data
due to use of this, malfunction or repair of this unit or its peripherals, or due
to batteries going dead.
●This unit employs electronic memory to store data, which means that
memory contents can be corrupted or deleted if power is interrupted due to
batteries going dead or incorrect battery replacement procedures. Data
cannot be recovered once it is lost or corrupted. Be sure to make back-up
copies of all important data. One way to do this is to use the optional Optical
Communication Unit to transfer data to a computer.
Caution!
■ Foreign Objects
●Take care to ensure that metal or combustible objects are not inserted into
the openings of the unit. Such objects create the danger of fire and electrical
shock.
■ Location
●Do not locate the unit on a surface that is unstable or uneven. Doing so
creates the danger of the unit falling or tipping over, which can cause
personal injury.
●Do not locate the unit in an area subjected to large amounts of humidity or
dust. Doing so creates the danger of fire and electrical shock.
●Do not leave the unit for long periods in a car parked in direct sunlight.
■ Heavy Objects
●Never place heavy objects on top of the unit. Doing so creates the danger of
loss of balance and the object falling, which can cause personal injury.
■ LCD Screen
●
Never apply strong pressure to the screen or subject it to strong impact. Doing
so can crack the LCD panel glass and create the danger of personal injury.
●Should the LCD panel glass ever break, never touch the liquid inside. Doing
so can cause skin irritation and inflammation.
• Should liquid from the LCD panel accidentally get into your mouth,
immediately wash your mouth with water and then consult a physician.
• Should liquid from the LCD panel accidentally get into your eyes or onto
your skin, immediately rinse for at least 15 minutes with clean tap water
and then consult a physician.
E-7
■ Backup Battery Handling
●Do not leave batteries in locations subject to strong direct sunlight or in high
temperature locations such as in a car. Doing so can create the danger of
battery leakage, heat emission, and rupture.
●Do not allow batteries to get wet with water. Doing so can create the danger
of heat emission.
●Remove completely used batteries from the equipment immediately . Leaving
used batteries for a long time still connected to the equipment can cause gas
to be generated from the battery. This can create the danger of battery
leakage, heat emission, and rupture, or damage the equipment.
●If batteries are to be used in a completely sealed structure, follow the
instructions in the equipment’s Instruction Manual.
●If the equipment is not to be used for a long time, back up important data
and remove the batteries. Leaving batteries for a long time in the equipment
can cause gas to be generated from the battery. This can create the danger
of battery leakage, heat emission, and rupture, or damage the equipment.
●Battery specifications or performance sometimes is not fully achieved
depending on how they are used or the equipment they are used on.
Correctly use batteries in a way suited to the application in accordance with
the equipment’s Instruction Manual or precautions.
●Avoid storing batteries in the direct sunlight or in high temperature and
humidity locations. Doing so can create the danger of battery leakage, impair
battery performance or shorten the service life of the battery.
●Used batteries may be disposed of as general unburnable rubbish. However,
dispose of used batteries in accordance with any local bylaws and
regulations.
●Use only battery types that are specified for this unit.
●The positive (+) and negative (–) terminals sometimes contact the metallic
sections of some equipment near the battery insertion area. Insert batteries
into equipment taking care not to short the terminals.
●Risk of explosion if battery is replaced by an incorrect type. Dispose of used
batteries according to the instructions.
Caution!
E-8
Caution!
■ Lithium-ion Battery Pack
●Never leave the battery pack in an area exposed to direct sunlight, in a car
parked in direct sunlight, or any other very hot area. Doing so creates the
danger of heat emission and fire, as well as deterioration of battery pack
performance and shortening of its service life.
●Do not use the rechargeable battery pack in areas where static electricity is
being generated. Doing so creates the danger of battery pack heat emission,
explosion, and fire.
●Temperature ranges for battery pack use, charging, and storage are
specified below. Temperatures outside these ranges create the danger of
deterioration of battery pack performance and shortening of its service life,
as well as fluid leakage and heat generation.
Operating T emperature: –10°C to 50°C
Charging T emperature: 0°C to 40°C
Storage T emperature: –20°C to 60°C
●Should fluid from the battery pack accidentally get onto clothing or your skin,
immediately rinse it off with clean tap water. Prolonged contact with battery
pack fluid can cause skin irritation.
●Keep the battery pack out of the reach of small children. Do not let small
children remove the battery pack from the charger unit or the unit it is
powering.
●Risk of explosion if battery is replaced by an incorrect type. Dispose of used
batteries according to the instructions.
■ Optional Optical Communication Unit and Charger Unit
●Keep the power cord away from stoves and other sources of extreme heat.
Heat can melt the insulation of the power cord and create the danger of fire
and electrical shock.
●Never pull on the power cord when unplugging it. Doing so can damage the
cord and create the danger of personal injury, fire and electrical shock.
Always hold onto the plug when unplugging it from the wall outlet.
●Never touch the plug while your hands are wet. Doing so can create the
danger of electrical shock.
●Be sure to unplug the power cord from the wall outlet before moving the
Optical Communication Unit and Charger Unit. Failure to do so can result in
damage to the power cord caused by pulling it, which creates the danger of
fire and electrical shock.
●Be sure to unplug the power cord from the wall outlet before cleaning the
Optical Communication Unit and Charger Unit.
●Be sure to turn the power OFF and unplug the power cord after use.
●Unplug the power cord from the wall outlet whenever leaving the Optical
Communication Unit and Charger Unit unattended for long periods.
E-9
The following details are declared in the 15-country EU Union and 4-country EFTA Union.
Product description/Intended use
EU/EFTA member states intended for use
Member states with restrictive use
Manufacturer
Brand
Type
is tested to and conforms with the essential requirements for protection of health and the
safety of the user and any other person and Electromagnetic Compatibility, as included in
following standards:
Standard
EN60950
ETS300 826
and is tested to and conforms with the essential radio test suites so that it effectively uses
the frequency spectrum allocated to terrestrial/space radio communication and orbital
resources so to as to avoid harmful interference, as included in following standards:
EU: Austria, Belgium, Denmark, Finland,
France, Germany, Greece, Ireland, Italy,
Luxembourg, The Netherlands, Portugal,
Spain, Sweden, United Kingdom
EFTA: Switzerland, Iceland,
Liechtenstein, Norway
NONE
CASIO COMPUTER CO., LTD.
CASIO
DT-810M50RC, DT -810M70RC
Standard
ETS300 328
and therefore complies with the essential requirements and provisions of the Directive
1999/5/EC of the European Parliament and of the council of March 9, 1999 on Radio
equipment and Telecommunications Terminal Equipment and the mutual recognition of their
conformity and with the provisions of Annex IV (Conformity Assessment procedure referred
to in article 10).
E-10
The following Notified Bodies have been consulted in the Conformity Assessment procedure:
Notified Body number
0122
The technical documentation as required by the Conformity Assessment procedure is kept at
the following address:
Company
Address, City
Country
Phone number
Fax number
To operate this mobile device in France, there may be National regulatory restrictions to
comply with. For detail please consult “Autorie de Regulation des Telecommunications
(phone no. 01 40 47 71 33)”.
Name and address
NMi Certin B.V., PO Box 15, 9822 ZG Niekerk,
The Netherlands
CASIO ELECTRONICS CO. LTD.
Unit 6, 1000 North Circular Road, London NW27JD
United Kingdom
0181-450-9131
0181-452-6323
E-11
• The contents of this manual are subject to change without notice.
• The term “Data Collector” as used in this User's Guide refers to the CASIO DT-810 Data
Collector unless otherwise noted.
• CASIO COMPUTER CO., LTD. assumes no responsibility for any loss or claims by third
parties which may arise from the use of this manual.
• This manual does not cover programming or the uploading of data. See the separate
manual for details of these procedures.
Contents
Safety Precautions ............................................... E-2
Unpacking ........................................................... E-14
Introduction ......................................................... E-15
Handling Precautions...........................................................E-15
Data Collector Handling Precautions ............... E-15
DT-810 System Diagram..................................... E-16
General Guide ..................................................... E-17
Power Supply ...................................................... E-18
Installing the Lithium-ion Battery Pack................................. E-19
Installing the Back-up Battery ..............................................E-20
E-12
Attaching the Wrist Strap................................... E-23
Keys and Their Functions .................................. E-24
Stroke Key Functions........................................................... E-24
T ouch Panel Keys ................................................................ E-25
Before Using the Data Collector
for the First Time ............................................. E-26
Aligning the Touch Panel Position........................................ E-26
Using the Bar Code Reader ............................... E-28
Performing a Bar Code Read Operation.............................. E-28
Scan Position .......................................................................E-29
Data Communication .......................................... E-30
DT-810 - DT-810 Data Communication ................................E-30
Specifications ..................................................... E-31
DT-824LI Lithium-ion Battery Pack Specifications ...............E-32
Using the Optional Optical
Communication Unit ....................................... E-33
General Guide .....................................................................E-33
Setting up the Optical Communication Unit and
connect the Data Collector.............................................. E-35
Charging the Battery Pack ................................................... E-36
Setting the Optical Communication Unit ..............................E-37
Connecting Two or More Optical Communication Units.......E-39
DIP Switch Settings ............................................................. E-40
DT-860IOE Optical Communication Unit Specifications ...... E-41
Using the High-Speed Charger Unit.................. E-42
General Guide .....................................................................E-42
Charging a Battery Pack...................................................... E-42
DT-820CHG High-Speed Charger Unit Specifications.........E-44
E-13
Unpacking
When unpacking the Data Collector, check carefully to make sure that all of the items shown
below are included. If anything is missing or damaged, contact your original dealer or your
nearest CASIO Service Provider.
• Data Collector
• Wrist Strap
• Lithium-ion battery pack
• Back-up battery (lithium)
• Touch panel stylus
• Soft case for Lithium-ion
battery pack
E-14
Loading...
