Casio 5576 User Manual

User’s Guide 5576

For a full Operation Guide and Q&A information about this product, go to the website below.

http://world.casio.com/manual/wat/

E-2

Charging the Watch

x While wearing the watch, take care so your sleeve does not

block its face (solar panel) from light. Charging efficiency may be reduced if the face (solar panel) is blocked from light, even partially.

x When you are not wearing the watch, leave it where its face

(solar panel) is exposed to bright light for charging.

x To help ensure stable operation, expose the face of the

watch to about a half day of direct sunlight each month to charge it.

Caution

x The case of the watch may become extremely hot when charging. Guard against

burn injury.

E-4

Congratulations upon your selection of this CASIO watch.

Important!

x Keep the watch’s face exposed to light as much as possible. x This manual provides a brief overview of your watch.

ENGLISH

E-1

Contents

Charging the Watch ........................................................................................... E-4

To recover from the sleep state ...................................................................... E-7

Configuring Home City, Time and Date Settings ............................................. E-8

To configure Home City, time, and date settings ............................................ E-8

Mode Selection and Operations .....................................................................E-12

Misaligned Hands............................................................................................. E-16

Specifications ................................................................................................... E-17

E-3

Important!

x If the watch is not exposed to light for long periods, it will disable some functions

and eventually stop timekeeping.

x For information about how long it takes to charge, refer to the Operation Guide

available at the CASIO website.

x If timekeeping stops, you will need to expose the watch to light for anumber of

hours before it will restart.

Power Levels

x If the battery power indicator shows LO or is not displayed at all, it means that

battery power is very low. Expose the watch to bright light for charging as soon as possible.

In the Timekeeping Mode, press C to display the battery power indicator.

E-5

Power Saving

When turned on, Power Saving enters a sleep state automatically whenever the watch is left for a certain period in an area where it is dark.

Elapsed Time in Dark Digital Displays Operation

60 to 70 minutes (display sleep) Blank

6 or 7 days (function sleep) Blank

x The watch will not enter a sleep state between 6:00 AM and 9:59 PM. If the watch

is already in a sleep state when 6:00 AM arrives, however, it will remain in the sleep state.

x The watch will not enter a sleep state while it is in the Countdown Timer Mode or

Stopwatch Mode.

E-6

Digital display is disabled, but all functions are enabled.

Hour and minute hands stop at 12o’clock. All functions are disabled, but timekeeping is maintained.

Configuring Home City, Time and Date Settings

x Configure Home City and summer time settings first. After that, configure time and

date settings.

To configure Home City, time, and date settings

City code

E-8

1. In the Timekeeping Mode, hold down A for about two

seconds until ADJ is displayed.

To recover from the sleep state

Move the watch to a well-lit area, press any button, or angle the watch towards your face for reading.

2. Press C to move the flashing in the sequence shown below to select a setting.

Home City and Summer Time

City Code

Power Saving

C C C

DST Seconds

Time and Date

12/24-Hour Format

Hour

Minute

YearMonthDayButton Operation Tone On/Off

CCC

E-7

E-9

User’s Guide 5576

3. Use B and D to change the selected setting.

Screen This setting item: Operation

E-10

Home City

Summer time

OFF: Standard time ON: Summer time

Toggle between 12-hour (12H) and 24-hour (24H) timekeeping

Reset the seconds to 00

x 30 to 59 seconds: Adds 1 to minutes

Change the hour or minute

Change the year, month, or day

Use D (East) and B (West).

Press D.

Use D (+) and B (–).

Mode Selection and Operations

x Press C to change the mode. x In any mode (except when a setting screen is on the display), press B to illuminate

the face of the watch.

Timekeeping Mode Battery Power Indicator

E-12

World Time Mode

Reset

World Time ModeAlarm Mode

Countdown Timer ModeStopwatch Mode

Countdown Timer Mode

Screen This setting item: Operation

4. Press A to exit the setting screen.

Timekeeping Mode

x A (two seconds): Displays setting (Home

City, time, date, etc.) screen.

x A: Changes digital display contents.

Month, day day of the week

second Hour, minute

Stopwatch Mode

Split/Reset

Enabling and disabling the button tone

KEY : ON (enabled) MUTE: OFF (disabled)

Enabling and disabling power saving

Turns on illumination.

x The battery power indicator shows you the

current power level of the rechargeable battery.

Toggle on

and off.

Press D.

E-11

Battery Power Indicator

E-13

Alarm Mode

Scrolls the selected city.

x A + B: Swaps Home Time and World

Time.

x Holding down A for about two seconds

will toggle summer time (DST) between on and off.

E-14

x A (two seconds while the start time is

displayed): Displays timer time setting screen. B, D: Use to change the selected setting.

x A: Exits the setting screen.

Start/Stop

Misaligned Hands

The analog hands may become misaligned as described below if the watch is exposed to strong magnetism, impact, or other abnormal conditions.

x Analog time and digital time are different from each other

If this happens, refer to “Hand Home Position Adjustment” in the Operation Guide available at the CASIO website and adjust the hand alignment.

E-16

Stopwatch:

Measuring unit: 1/100 second Measuring capacity: 59'59.99" Measuring modes: Elapsed time, split time, two finishes

Alarm: Daily alarm; Hourly Time Signal Other: Battery power indicator, Power Saving, Button operation tone on/off, LED

light (Super illuminator)

Power Supply: Solar panel and one rechargeable battery

Approximate battery operating time: 11 months under the following conditions:

x Display on 18 hours per day, sleep state 6 hours per day x 1 illumination operation (1.5 seconds) per day x 10 seconds of alarm operation per day

Frequent use of illumination runs down the battery.

Specifications are subject to change without notice.

Start/Stop

D D A

Start Stop Reset

x A (two seconds): Displays alarm time setting

screen.

C: Selects hour or minutes. B, D: Use to change the selected setting.

x A: Exits the setting screen.

Alarm Screen/ Hourly Time singnal Screen

E-15

Specifications

Accuracy at normal temperature: ±30 seconds a month Timekeeping: Hour, minutes, seconds, p.m. (P), year, month, day, day of the week,

alarm countdown Time format: 12-hour and 24-hour Calendar system: Full Auto-calendar pre-programmed from the year 2000 to

2099 Other: Home City code (can be assigned one of 48 city codes); Standard Time/

Daylight Saving Time (summer time)

World Time: 48 cities (31 time zones)

Other: Daylight Saving Time/Standard Time

Countdown Timer:

Measuring unit: 1 second Countdown range: 60 minutes Setting unit: 1 minute

E-17

L-1E-18
