CareFusion Alaris TIVA User Manual

Alaris® TIVA Syringe Pump

Directions For Use

en

s

Contents

Page

Introduction ..............................................................................................2

About This Manual ........................................................................................2

Quick Start Guide .........................................................................................2

Features of the Alaris® TIVA Syringe Pump ..................................................................3

Controls & Indicators ......................................................................................4

Symbol Definitions ........................................................................................5

Main Display Features .....................................................................................6

Operating Precautions ....................................................................................7

Getting Started ...........................................................................................9

Basic Features ............................................................................................15

Alarms and Warnings .....................................................................................18

Configured Options ......................................................................................19

Specifications ............................................................................................24

Compatible Syringes .....................................................................................25

Associated Products ......................................................................................25

Compatible Extension Sets ...............................................................................26

Maintenance .............................................................................................28

Occlusion Pressure Limits .................................................................................30

IrDA, RS232 and Nurse Call Specification ..................................................................31

Trumpet Curves & Start-up Curves ........................................................................32

Spare Parts ...............................................................................................33

Service Contacts .........................................................................................34

1000DF00330 Issue 4

1/34

Introduction

The Alaris® TIVA Syringe Pump (herein after referred to as "pump") is a fully featured syringe pump which provides the anaesthetist with
a pump which has been designed to work in the way drugs are delivered in the operating theatre, including dose based calculations of
induction and maintenance rates.

The Alaris® TIVA Syringe Pump is compatible with a wide range of standard, single-use, disposable Luer lock syringes. It accepts syringe
sizes from 5 ml to 50 ml. See the 'Compatible Syringes' section for a full list of compatible syringes.

Intended Purpose

The Alaris® TIVA Syringe Pump is intended for use by medical staff for purposes of controlling infusion rate and volume.

Conditions of Use

The Alaris® TIVA Syringe Pump should only be operated by a clinician competent in use of automated syringe pumps and post-placement
management of intravenous catheters.

CareFusion cannot guarantee the continued system accuracy with other manufacturer’s syringes as identified in the

A

Indications

The Alaris® TIVA Syringe Pump is indicated for infusion of therapeutics including:

‘Compatible Syringes’ table. Manufacturers may change syringe specification significant to system accuracy without
prior notification.

• analgesics

• antimicrobials

• blood products

• chemotherapy

• subcutaneous

• nutrition

Contraindications

The Alaris® TIVA Syringe Pumps is contraindicated for:

• enteral therapies

• epidural

About This Manual

The user must be thoroughly familiar with the Alaris® TIVA Syringe Pump described in this manual prior to use.

All illustrations used in this manual show typical settings and values which may be used in setting up the functions of the pump. These
settings and values are for illustrative use only. Where stated, a minimum infusion rate refers to a nominal rate of 1.0ml/h, and an
intermediate infusion rate refers to a nominal rate of 5.0ml/h. The complete range of infusion rates, settings and values are shown in the
Specifications section.

It is important to ensure that you only refer to the most recent version of the Directions for Use and Technical Service

A

Manual for your CareFusion products. These documents are referenced on www.carefusion.com. Copies can be
obtained by contacting your local CareFusion representative.

Quick Start Guide

1. Press the a button to turn the pump on.

2. NEW DRUG - NO retains previous drug data. YES clears previous drug data.

3. Select drug.

4. Enter patient weight.

5. Confirm protocol.

6. Load syringe.

7. Confirm correct size and brand of syringe.

8. Ensure extension set is attached to syringe, but disconnected from patient.

If the PURGE SYRINGE option has been enabled then the prompt to purge screen is displayed and the set can be purged as
required.

9. INFUSION RATE - Change rate if necessary using the

10. PURGE - Press the

11. Connect extension set to the patient access device.

12. Press the

b button to start the infusion.

i button followed by the PURGE softkey.

1000DF00330 Issue 4

f keys.

2/34

Features of the Alaris® TIVA Syringe Pump

ON/OFF

RUN

Display

Release lever for

MDI

High visibility

Alarm Indicator

PURGE/BOLUS

MUTE

PRESSURE

OPTION

Finger

Grips

Extension

set hook

Rating Plate (see Symbol Definitions for

an explanation of the symbols used)

Release

lever for

Rotating

Cam

(

M

D

I

)

Syringe Clamp

Positive Plunger

Grippers

HOLD

Shelf for chevron
keys and softkeys

M

e

d

i

c

a

l

D

e

v

i

c

e

I

n

t

e

r

f

a

c

e

Rotating Cam to

lock on to horizontal

rectangular bars

Carrying

Handle

IR Communications

Potential

Equalisation

(PE) connector

port

Folded Pole

Clamp

1000DF00330 Issue 4

3/34

RS232

Connector

Extension set

hook

Controls:

Symbol Description

ON/OFF button - Press once to switch the pump ON. Press and hold down for 3

seconds to switch the pump OFF.

a

RUN button - Press to start the infusion. The green LED will flash during infusion.

b

HOLD button - Press to put the infusion on hold. The amber LED will be lit while on
hold.

h

MUTE button - Press to silence alarm for 2 minutes (configurable). The alarm will
resound after this time. Press and hold until 3 beeps are heard for 60 minutes

c

silence.

PURGE/BOLUS button - Press to access PURGE or BOLUS soft keys. Press and hold
down soft key to operate.

PURGE the extension set during set up.

l Pump is on hold

l Extension set is not connected to the patient

l Volume Infused (VI) is not added

i

BOLUS - fluid or drug delivered at an accelerated rate.

l Pump is infusing

l Extension set is connected to the patient

l VI is added

Controls & Indicators

OPTION button - Press to access optional features (see Basic Features).

d

PRESSURE button - Use this button to display the pumping pressure and alarm
level.

e

CHEVRON keys - Double or single for faster/slower increase or decrease of values

f

shown on display.

BLANK SOFTKEYS - Use in conjunction with the prompts shown on the display.

g

Indicators:

Symbol Description

BATTERY indicator - When illuminated the pump is running on the internal battery.

When flashing the battery power is low with less than 30 minutes of use remaining.

j

AC POWER indicator - When illuminated the pump is connected to an AC power
supply and the battery is being charged.

S

1000DF00330 Issue 4

4/34

Labelling Symbols:

Symbol Description

Attention (Consult accompanying documents)

w

Potential Equalisation (PE) Connector

x

RS232/Nurse call Connector (Optional)

y

Defibrillation-proof type CF applied part (Degree of protection against electrical
shock)

l

Symbol Definitions

O

r

s
T

t

U

W

Protected against vertically falling drops of water

Alternating Current

Device complies with the requirements of Council Directive 93/42/EEC as amended
by 2007/47/EC.

Date of Manufacture

Manufacturer

Not for Municipal Waste

Fuse Rating

A

EC REP

Important information

Authorised representative in the European Community

1000DF00330 Issue 4

5/34

Main Display Features

Pump

Status

Infusion

Rate

Screen Icons:

Symbol Description

TIME REMAINING DISPLAY icon - Indicates time before syringe will require replacing.

l

N

C

BATTERY icon - Indicates battery charge level to highlight when the battery will require recharging.

Induction Phase Dose (Displayed on protocol confirmation screen)

Syringe type fitted /

Drug name

INFUSING

56.0

ml/h

8.00

+ ADJUST -

mg/kg/h

Volume
Infused

SYRINGE NAME

DOSE

0.0

mg

0.00

ml

VOLUME

0h 00m 40s

Volume Infused

Option

Pressure

Information

VTBI

D

E

F

Duration of Induction Phase (Displayed on protocol confirmation screen)

Duration of Hands Free Bolus (Displayed in bolus set-up screen)

Maintenance Phase Dose Rate (Displayed on protocol confirmation screen)

1000DF00330 Issue 4

6/34

m

o

G
H

Operating Precautions

Disposable Syringes and Extension Sets

• Always clamp or otherwise isolate the patient line before unclamping or removing a syringe from the

pump. Failure to do so may result in unintended administration.

• This Alaris® TIVA Syringe Pump has been calibrated for use with single-use disposable syringes. To ensure

correct and accurate operation, only use 3 piece Luer lock versions of the syringe make specified on
the pump or described in this manual. Use of non-specified syringes or extension sets may impair the
operation of the pump and the accuracy of the infusion.

• Uncontrolled flow or syphoning may result if the syringe is located incorrectly in the pump, or if it is

removed from the pump before the extension set is properly isolated from the patient. Isolation may
include closing a tap in the patient line or activating a flow stop clamp.

• Secure the extension set to the pump using the extension set hook at the rear of the pump. This provides

protection against accidental dislodging of the syringe from the pump.

• When combining several apparatus and/or instruments with extension sets and other tubing, for example

via a 3-way tap, the performance of the pump may be impacted and should be monitored closely.

Mounting the Pump

• The pump must be mounted within 1.0m above or below the patient’s heart. The most accurate pressure

monitoring in the extension set is achieved when the pump is positioned close to the patients heart
level.

I

• Do not mount the pump in a vertical position with the syringe pointing upwards as this could lead to

an infusion of air which may be in the syringe. To protect against the introduction of air the user should
regularly monitor the progress of the infusion, syringe, extension line and patient connections and follow
the priming procedure specified herein.

Operating Environment

• When using any infusion pump in conjunction with other pumps or devices requiring vascular access,

extra care is advised. Adverse delivery of medication or fluids can be caused by the substantial variation in
pressures created within the local vascular system by such pumps. Typical examples of those pumps are
used during dialysis, bypass or cardiac assist applications.

• This pump is suitable for use in Hospital and clinical environments other than domestic establishments

and those directly connected to the public single phase AC mains power supply network that supplies
buildings used for domestic purposes. However, it may be used in domestic establishments under the
supervision of Medical professionals with additional necessary appropriate measures. (Consult Technical
Service Manual, appropriately trained technical personnel or CareFusion for further information).

• This pump is not intended to be used in the presence of a flammable anaesthetic mixture with air or

oxygen or nitrous oxide.

Operating Pressure

• This is a positive pressure pump designed to achieve very accurate fluid administration by automatically

compensating for resistance encountered in the infusion system.

• The pumping pressure alarm system is not designed to provide protection against, or detection of, IV

complications which can occur.

J

Alarm Conditions

• Several alarm conditions detected by this pump will stop the infusion and generate visual and audible

alarms. Users must perform regular checks to ensure that the infusion is progressing correctly and no
alarms are operating.

1000DF00330 Issue 4

7/34

M

Operating Precautions (continued)

Electromagnetic Compatibility and Interference

• This pump is protected against the effects of external interference, including high energy radio frequency
emissions, magnetic fields and electrostatic discharge (for example, as generated by electrosurgical and
cauterising equipment, large motors, portable radios, cellular telephones etc.) and is designed to remain
safe when unreasonable levels of interference are encountered.

• Therapeutic Radiation Equipment: Do not use the pump in the vicinity of any Therapeutic Radiation
Equipment. Levels of radiation generated by the radiation therapy equipment such as Linear Accelerator,
may severely affect functioning of the pump. Please consult manufacturer’s recommendations for
safe distance and other precautionary requirements. For further information, please contact your local
CareFusion representative.

• Magnetic Resonance Imaging (MRI): The pump contains ferromagnetic materials which are susceptible
to interference with magnetic field generated by the MRI devices. Therefore, the pump is not considered
an MRI compatible pump as such. If use of the pump within an MRI environment is unavoidable, then
CareFusion highly recommends securing the pump at a safe distance from the magnetic field outside
the identified ‘Controlled Access Area’ in order to evade any magnetic interference to the pump; or
MRI image distortion. This safe distance should be established in accordance with the manufacturers’
recommendations regarding electromagnetic interference (EMI). For further information, please refer to
the product technical service manual (TSM). Alternatively, contact your local CareFusion representative for
further guidance.

• Accessories: Do not use any non-recommended accessory with the pump. The pump is tested and
compliant with the relevant EMC claims only with the recommended accessories. Use of any accessory,
transducer or cable other than those specified by CareFusion may result in increased emissions or
decreased pump immunity.

K

A

V

L

• This pump is a CISPR 11 Group 1 Class A device and uses RF energy only for its internal function in the normal
product offering. Therefore, its RF emissions are very low and are not likely to cause any interference with
the nearby electronic equipment. However, this pump emits a certain level of electromagnetic radiation
which is within the levels specified by IEC/EN60601-1-2 and IEC/EN60601-2-24. If the pump interacts with
other equipment, measures should be taken to minimise the effects, for instance by repositioning or
relocation.

• In some circumstances the pump may be affected by an electrostatic discharge through air at levels close
to or above 15kv; or by radio frequency radiation close to or above 10v/m. If the pump is affected by
this external interference the pump will remain in a safe mode; the pump will duly stop the infusion and
alert the user by generating a combination of visual and audible alarms. Should any encountered alarm
condition persist even after user intervention, it is recommended to replace that particular pump and
quarantine the pump for the attention of appropriately trained technical personnel. (Consult Technical
Service Manual for further information).

Hazards

• An explosion hazard exists if the pump is used in the presence of flammable anaesthetics. Exercise care to
locate the pump away from any such hazardous sources.

• Dangerous Voltage: An electrical shock hazard exists if the pump’s casing is opened or removed. Refer all
servicing to qualified service personnel.

• When connected to an external power source, a three-wire (Live, Neutral, Earth) supply must be used. If the
integrity of the external protective conductor in the installation or its arrangement is in doubt, the pump
should be operated from the battery.

• Do not open the RS232/Nurse Call protective covering when not in use. Electrostatic discharge
(ESD) precautions are required when connecting RS232/Nurse Call. Touching the pins of the
connectors may result in ESD protection failure. It is recommended that all actions must be taken by
appropriately trained personnel.

• If this pump is dropped, subjected to excessive moisture, fluid spillage, humidity or high temperature, or
otherwise suspected to have been damaged, remove it from service for inspection by a qualified service
engineer. When transporting or storing the pump, use original packaging where possible, and adhere
to temperature, humidity and pressure ranges stated in the Specifications section and on the outer
packaging.

1000DF00330 Issue 4

8/34

Getting Started

Initial Set-up

Before operating the pump read this Directions For Use manual carefully.

A

1. Check that the pump is complete, undamaged and that the voltage rating specified on the label is compatible with your AC power
supply.

2. Items supplied are:

l Alaris® TIVA Syringe Pump
l User Support CD (Directions For Use)
l AC Power Cable (as requested)
l Protective Packaging

3. Connect the pump to the AC power supply for at least 2½ hours to ensure that the internal battery is charged (verify that the S is
lit).

Language Selection

1. On initial start-up the pump will display the Select Language screen.

2. Select the required language from the list displayed using the

3. Press the OK softkey to confirm your selection.

f keys.

A

The pump will automatically operate from its internal battery if the pump is switched on without being connected
to the AC power supply.

Should the pump fail to perform correctly, replace in its original protective packaging, where possible and contact
a qualified service engineer for investigation.

1000DF00330 Issue 4

9/34

Getting Started (continued)

Do not mount the pump with the AC power inlet or the syringe pointing upwards. This could affect the electrical
safety in the event of a fluid spill or lead to the infusion of air which may be in the syringe.

A

Pole Clamp Installation

The pole clamp is fitted to the rear of the pump and will provide secure fixing to vertical I.V. poles of a diameter between 15 and 40 mm.

Recessed area

1. Pull the folded pole clamp towards you and unscrew the clamp to

leave enough room for the size of the pole.

2. Place pump around pole and tighten screw until the clamp is

secured to the pole.

A

A

Ensure the pole clamp is folded away and
stored within the recessed area at the rear
of the pump before connecting to a Docking
Station/Workstation* or when not in use.

Never mount the pump such that the IV infusion
stand becomes top heavy or unstable.

Prior to each use, check the pole clamp:

• does not show any signs of excessive wear,

• does not show any signs of excessively loose movement in the extended, mountable position.

If these signs are observed, the pumps should be taken out of service for examination by qualified service personnel.

Docking Station/Workstation* or Equipment Rail Installation

Rectangular bar

Release lever (push to release)

*

Rotating cam

*

The rotating cam can be fitted to the rectangular bar on the Docking Station/Workstation* or the equipment rail measuring 10 by 25 mm.

1. Align the rotating cam on the rear of the pump with the rectangular bar on the Docking Station/Workstation* or the equipment rail.

2. Hold the pump horizontally, push the pump firmly onto the rectangular bar or equipment rail.

Ensure that the pump 'clicks' securely into position onto the bar.

3. To release, push the release lever and pull the pump forwards.

*Alaris® DS Docking Station and Alaris® Gateway Workstation.

1000DF00330 Issue 4

10/34

A

Getting Started (continued)

Loading and Confirming a Syringe

Warning: To securely load and confirm a syringe carefully follow the steps below. An incorrect loading of a syringe
may result in misidentification of the syringe type and size. If then confirmed, this may lead to significant inaccuracy
of the infusion rate and may also affect pump performance.

Only use a syringe of the type stated on the pump or in this manual. Using an incorrect syringe could adversely affect
the accuracy of the infusion rate and may also affect pump performance.

When drawing fluid into the syringe, draw enough to compensate for any 'dead space' volume in the extension set and
syringe at the end of infusion as this cannot be fully infused.

Syringe
Barrel

Barrel
Flange

Plunger
Grippers

Syringe
Clamp

Plunger
Flange



Plunger



Finger
Grips

Plunger
Holder

Syringe Flange Clamp

Place the pump on a stable horizontal surface or secure as described previously.

Prepare, load and prime the single-use disposable syringe and extension set using standard aseptic techniques.

1. Squeeze the finger grips together on the plunger holder and slide the mechanism to the right.

2. Pull the syringe clamp forward and down.

1000DF00330 Issue 4

11/34

3. Insert the syringe ensuring that the barrel flange is located in the slots on the syringe flange
clamp.

To ensure the syringe is loaded correctly, place the barrel flange in the space

A

4. Lift the syringe clamp until it locks against the syringe barrel.

5. Squeeze the finger grips on the plunger holder and slide the mechanism to the left until it

6. Release the finger grips. Ensure that the plunger grippers are securing the plunger in place

between the syringe clamp and the syringe flange clamp. This is correct if the
syringe remains in position before the syringe clamp is closed.

reaches the plunger end.

and the finger grip returns to its original position.

7. Ensure that the syringe type and size match those displayed on the pump then press CONFIRM. If required, the make of syringe
can be changed by pressing the TYPE softkey.

ON HOLD

Note: If the PURGE SYRINGE option has been enabled then the prompt to purge screen is displayed and the extension set can be

purged as required, however ensure that the extension set is not connected to the patient during this process.

CareFusion recommends to limit the number of configured syringe types and sizes available for selection on the

A

pump.

Secure the extension set using the extension set hook at the rear of the pump. This provides protection against
accidental dislodging of the syringe from the pump.

Ensure that both plunger grippers are fully locked onto the plunger flange and the upper finger grip has returned to
its original position.

IVAC 50

CONFIRM

TYPE

1000DF00330 Issue 4

12/34

Getting Started (Continued)

There are no Volume To Be Infused (VTBI) features in the Alaris® TIVA Syringe Pump during either maintenance or
no drug mode. Thus infusion will continue until manual intervention or end of syringe.

A

A

Configuration allows the user to define drug names, and typical defaults for the information entered in the start sequence below. If there
have been no drugs configured these steps will not appear and the pump will operate in normal mode. See “Starting the Pump - NORMAL
Mode”.

1. Connect the pump to an AC power supply using the AC power cable. Press the a button.

2. NEW DRUG - If you wish to reset the drug information press the YES softkey. If you want to use the previous drug information press the
NO softkey. Go to step 4.

The start-up drug configuration is:

3. SELECT DRUG - Select a drug from the list displayed. If there are no drugs programmed refer to the configured options to set up the drug
protocols.

Exercise care when entering or adjusting any settings, to ensure that the data and units entered are correct.

Starting the Pump - TIVA Mode

The sequence of operation in TIVA mode is INDUCTION*, PAUSE* and MAINTENANCE. The active mode of this
pump is displayed in large characters on the upper left side of the display.

*These modes are optional and can be enabled in the drug setup dialog.

4. WEIGHT (if required for dosing) - Enter the patient weight using the f keys. Press the OK softkey to enter.

5. Press OK softkey to confirm the induction and maintenance rates are set up correctly. Go to step 12. Load syringe, or press MODIFY to
change.

6. WEIGHT (if required for dosing) - Enter the patient weight using the f keys. Press the OK softkey to enter.

7. CONC - Enter the drug concentration, for example in mg/ml between the limits set in the drug protocol. Press the OK softkey to enter.

If the drug default concentration, minimum concentration and the maximum concentration are equal, this step is bypassed.

8. INDUCTION - Using the f keys, enter the induction dose amount per kg (if required for dosing) of patient weight. Press the OK
softkey to enter. The Induction feature may be disabled. Refer to Drug Set-Up to disable/enable the Induction feature.

9. TIME - Enter the induction time in seconds over which the induction dose will be delivered. Press the OK softkey to enter.

10. MAINTENANCE - Set the maintenance dose rate in the drug protocol units. Press the OK softkey to enter.

11. Press OK softkey to confirm the induction and maintenance rates are set up correctly. Load syringe, or press MODIFY to change.

12. Load the syringe according to the 'Loading a Syringe' section.

13. CONFIRM SYRINGE - Check that the syringe type and size being used matches the display. If required, the type of syringe can be
changed by pressing the TYPE button. Press CONFIRM when the correct type and size are shown. Purge extension set if necessary.

If the PURGE SYRINGE option has been enabled then the prompt to purge screen is displayed and the set can be purged as required.

14. PURGE (If required) - See instructions in 'Purge' section.

15. CONNECT PATIENT - Connect the extension set to the patient access device.

16. START - Press b to commence operation. INDUCTION will be displayed. The AMBER STOP light will be replaced by the flashing GREEN
START light to indicate that the pump is operating.

1000DF00330 Issue 4

13/34

Getting Started (Continued)

Starting the Pump - NORMAL Mode

When a drug is selected the pump enters TIVA Mode - see Starting the Pump - TIVA Mode.

1. Connect the pump to an AC power supply using the AC power cable. Press the a button.

2. NEW DRUG - To reset the drug information press the YES softkey. If you want to use the previous drug information press the NO softkey,
continue in TIVA mode as above.

3. Select the NO DRUG option from the list displayed.

4. Load the syringe according to the 'Loading a Syringe' section.

5. CONFIRM SYRINGE - Check that the syringe type and size being used matches the display. If required, the type of syringe can be changed
by pressing the TYPE softkey. Press CONFIRM when the correct type and size are shown. Purge extension set if necessary.

If the PURGE SYRINGE option has been enabled then the prompt to purge screen is displayed and the set can be purged as
required.

6. SET INFUSION RATE - Set the desired infusion rate in ml/h using the f keys.

7. PURGE (If required) - See instructions in 'Purge' section.

8. CONNECT PATIENT - Connect the extension set to the patient access device.

9. START - Press the b button to commence operation. INFUSING will be displayed. The AMBER STOP light will be replaced by the flashing
GREEN START light to indicate that the pump is operating.

1000DF00330 Issue 4

14/34

Basic Features

During the pause and maintenance modes the bolus function is enabled. During hold mode the bolus function is
disabled.

A

Purge

The purge feature is available before the infusion has been started and when the syringe is changed, the syringe
must be reconfirmed to activate the purge feature. No alarms are disabled during the operation of the purge

A

The

i button allows the delivery of a limited volume of fluid in order to purge the extension set prior to being connected to a patient or

after changing a syringe.

1. Press the

2. Press and hold the PURGE softkey until fluid flows and the purging of the IV infusion set is complete. The volume used during purging
will be displayed, but it is not added to the volume infused.

3. When purging is complete release the PURGE softkey. Press the QUIT softkey to exit back to the main display.

feature.

i button when the pump is not infusing. Ensure that the extension set is not connected to the patient.

During PURGE the pressure limit alarms are temporarily increased to their maximum level.

A

Bolus Infusion

The hands free bolus will be cancelled following any interruption in delivery, even if the bolus delivery is
incomplete.During BOLUS the pressure limit alarm is temporarily increased to the maximum level.

A

BOLUS Infusion

The Bolus feature is enabled in Drug Set Up, refer to 'Drug Set Up' section. It is not possible to deliver a bolus during an induction or if bolus
is disabled.
To use this feature ensure that the hands free bolus option is disabled. Refer to the 'Drug Set Up' section.

1. During the maintenance phase infusion press the

2. The bolus delivery rate can be adjusted using the RATE softkey.

3. To deliver the bolus, press the BOLUS softkey. The pump will display the volume being delivered.

4. When the desired bolus has been delivered, release the BOLUS softkey. The bolus volume will be added to the total volume infused. To
exit the bolus feature press the QUIT softkey.

BOLUS Infusion - Hands Free

During induction it is not possible to deliver a bolus.
This option is enabled/disabled within the drug set-up.

1. During maintenance phase infusion press the

2. Use the f to set the bolus dose required. If necessary press the RATE softkey to select the bolus delivery rate.

3. Press the BOLUS softkey once to begin the delivery of the bolus dose. The display will revert to the main display, showing the bolus being
delivered, counting down on the review section of the screen. On completion of the bolus the pump will automatically revert to the
maintenance rate.

The pump will display:
BOLUS

nn.nmg
nn.nml

4 To exit the bolus feature press the QUIT softkey.

5. To terminate a bolus being delivered either press the
softkey. This will stop the bolus and continue infusing at the maintenance rate.

i button once. This displays the bolus screen.

i button. This will display the bolus screen.

h button and restart the infusion, or press the i button and press the STOP

1000DF00330 Issue 4

15/34

Basic Features (Continued)

Pressure Level

1. To check and adjust the pressure level press the e button. A bar graph will be displayed showing the pressure alarm level and the

current pressure level.

2. Press the

3. Press OK to exit the screen.

A

If Rate Titration is enabled the rate can be adjusted while infusing:

1. Select the new rate using the
The message < START TO CONFIRM > will flash on screen and pump continues to infuse at the original rate.

2. Press the

If Rate Titration is disabled the rate can only be adjusted whilst on hold:

1. Press the

2. Select the new rate using the

3. Press the

This option enables the volume infused to be cleared.

1. Press the VOLUME softkey to display the CLEAR VOLUME option.

2. Press the YES softkey to clear the volume. Press the NO softkey to retain the volume.

Selecting YES resets the volume infused in the 24H LOG option.

f keys to increase or decrease the alarm level. The new level will be indicated on the display.

The interpretation of pressure readings and occlusion alarms are the responsibility of the clinician depending on
the specific application.

During a bolus or induction phase the pressure level is set to maximum. The level remains at maximum for 10
seconds after the end of the phase.

Rate Titration

f keys.

b button to confirm the new infusion rate and start infusing at the new rate.

h

button to put the pump on hold.

f keys.

b button to start infusing at the new rate.

Clear Volume

Clear Induction (TIVA Mode only)

1. To clear the induction, press the h button.

2. The CLEAR INDUCTION prompt is shown.

l To clear the induction press the YES softkey.
l Answering NO to the CLEAR INDUCTION prompt will leave the pump in the ON HOLD state; the induction can continue by

pressing the

b button.

? Set by Doserate / Set by ml/h (TIVA Mode only)

To set doserate or flowrate in precise increments it may be necessary to switch between the rate adjust options SET BY DOSERATE and
SET BY ml/h. An arrow to the left of the rate display shows the rate changed when the

infusion rate.

To set a doserate precisely the arrow must be pointing to the doserate (mg/kg/h); the flowrate will be calculated from the doserate.

To precisely set a flowrate the arrow must be pointing to flowrate (ml/h); the doserate will be calculated from the flowrate.

Selecting the Set By ml/h Option

1. Whilst the pump is infusing, press the

2. Select the SET BY ml/h option using the
flowrate option, the arrow on the display will automatically select the flowrate, the flowrate can be adjusted if necessary.

Selecting the Set By Doserate Option

1. Whilst the pump is infusing, press the

2. Select the SET BY DOSERATE option using the
by doserate option, the arrow on the display will automatically select the doserate, the doserate can be adjusted if necessary.

d button to access the options menu.

f keys and press the OK softkey indicated on the screen. This will select the set by

d button to access the options menu.

f keys and press the OK softkey indicated on the screen. This will select the set

f keys are used to increase/decrease the

1000DF00330 Issue 4

16/34

Basic Features (Continued)

? Repeat Operation

When activating REPEAT OPERATION the protocol used for the preceeding operation will be used. This includes
any changes made to the concentration, induction dose rate, induction time and maintenance dose rate prior to

A

This option will only appear in the options menu when the infusion has been stopped.

1. Press the d button to access the options menu.

2. Select the REPEAT OPERATION option using the f keys.

3. Press the OK softkey indicated on the screen.

This will revert the pump to the initial programming WEIGHT step (if the drug protocol is weight dependant), without powering down the
pump.

This option will only appear in the options menu when the infusion has been stopped.

1. Press the d button to access the options menu.

2. Select the END OF OPERATION option using the f keys.

3. Press the OK softkey indicated on the screen. The pump will display the NEW DRUG prompt, and will not be powered down. If you wish
to reset the information press the YES softkey. If you wish to use the previous information press NO.

confirmation.

? End of Operation

? 24 Hour Log

This option allows the 24 hour log of volume infused to be reviewed.

1. Press the

2. Select the 24H LOG option using the

The display shows the hourly volume infused. The volume infused shown in brackets is the total volume infused since the volume was
last cleared. See example below:

07:48 - 08:00 4.34ml (4.34ml)

08:00 - 09:00 2.10ml (6.44ml)

09:00 - 10:00 2.10ml (8.54ml)

VOLUME CLEARED

3. Press the QUIT softkey to exit the log.

d button to access the options menu.

f keys and press the OK softkey.

? Event Log

This option allows the event log to be reviewed. It can be enabled/disabled.

1. Press the

2. Select the EVENT LOG option using the

3. Scroll through the log using the

d button to access the options menu.

f keys and press the OK softkey.

f keys. Press the QUIT softkey to exit the log.

? Dosing Summary (TIVA Mode only)

1. Press the d button to access the options menu.

2. Select the DOSING SUMMARY option using the

3. Press the QUIT softkey to exit the menu.

1000DF00330 Issue 4

f keys and press the OK softkey.

17/34

Alarms and Warnings

Alarms are indicated by a combination of an audible alarm, flashing alarm indicator and a descriptive message in the display.

1. First press the
to cancel the alarm message.

2. If the infusion has stopped, rectify the cause of the alarm then press the

A

c button to silence the alarm for a maximum of 2 minutes*, then check the display for an alarm message. Press CANCEL

b button to resume the infusion.

If the pump initiates a safety processor alarm condition (an audible high pitched continuous shrill accompanied with a red
alarm indicator) and there is no error message displayed on the pump, remove the pump from service for examination by
a qualified service engineer.

Display Description and Troubleshooting Guide

DRIVE DISENGAGED

OCCLUSION

CHECK SYRINGE

BATTERY LOW

BATTERY EMPTY

NEAR END OF INFUSION

END OF INFUSION

The drive system has been disengaged during operation. Check the finger grips and the position
of the syringe.

Excessive pressure measured at the syringe plunger exceeding the alarm limit. Identify and
remove the cause of the blockage in the drive, syringe, or administration system before restarting
the infusion.

Incorrect size of syringe has been fitted, the syringe has not been positioned correctly or has
been disturbed during operation. Check the syringe location and the position.

Battery charge low with 30 minutes operation remaining. Battery indicator will flash and after 30
minutes a continuous audible alarm will indicate that the battery is exhausted. Reconnect to the
AC power supply to continue operation and charge the internal battery.

The internal battery is exhausted. Connect the pump to the AC power supply.

The pump is nearing the end of the infusion.This value can be configured.

The pump has reached the end of the infusion. A pre-set volume will remain in the syringe to
minimise the risk of the infusion of air bubbles into the set. This value can be configured.

TITRATION NOT CONFIRMED The infusion rate has been changed, but has not been confirmed and 2 minutes* has

expired without any operation. Press the c button to silence the alarm, then press the CANCEL
softkey to clear this message and silence the alarm. Check infusion rate and confirm by pressing

the

b button or press the h button to revert to the previous rate. Press the b button to start

infusion. (This alarm only occurs if rate titration is enabled).

AC POWER FAIL

AC Power has been disconnected and the pump is operating on battery power, if this occurs
when the pump is infusing the message "INFUSION CONTINUES" will be displayed. Reconnect

AC power supply or press the
The alarm will automatically cancel if the AC power supply is reconnected.

c button to silence the alarm and continue with battery operation.

Error Code and Message

ATTENTION (with “3 Beeps”)

The alarm system has detected an internal malfunction. Note the malfunction code. Remove
pump from service for examination by a qualified service engineer.

Three beeps will sound if the pump has been left ON for more than 2 minutes* (referred to as
CALLBACK in the log) without starting the operation. Press the
for a further 2 minutes*. Alternatively press and hold down the

in succession, this will put the warning alarm on standby for 60 minutes.

Alarm Indicator Colour Alarms indicated

AMBER

RED

AC POWER FAIL; NEAR END OF INFUSION; ATTENTION; TITRATION NOT CONFIRMED; BATTERY
LOW.

All others.

c button to silence the alarm

c button and wait for 3 beeps

*Configurable option.

1000DF00330 Issue 4

18/34

Configured Options

This menu comprises a list of options which are configurable by the user.

1. Turn the pump OFF.

2. Whilst holding down the

3. The main display will show 000. Enter the access code for Configured Options using the

the digits. A full list of access codes can be found in the Technical Service Manual.

4. When the complete code shows on screen, press OK to enter. The Configured Options menu will be displayed.

1. Select GENERAL OPTIONS from the menu using the

2. Select the option you wish to enable/disable or adjust and press the MODIFY softkey.

3. When all the desired modifications have been carried out press the QUIT softkey.

4. Either select the next configuration option from the menu or turn the pump OFF, returning it to operation as required.

NURSE CALL FITTED Enables Nurse Call (hardware option).

NURSE CALL INVERT When enabled, the nurse call output is inverted.

RS232 SELECTED Sets the pump's communications to use RS232 (hardware option).

NEOI WARNING Sets the Near End Of Infusion warning time, as time left to End Of Infusion.

EOI POINT Sets the End Of Infusion point.

KVO AT EOI When enabled the pump will switch to running at the KVO rate when EOI is reached.

KVO RATE Sets the Keep Vein Open (KVO) rate at which the pump will operate if KVO at EOI is enabled.

BACK OFF When enabled the motor will reverse to relieve line pressure when an occlusion occurs.

AC FAIL When enabled the AC Power Failure Alarm will sound if the AC power is disconnected.

PRESSURE DISPLAY Enables / disables the Pressure Icon on the main display.

PRESSURE DEFAULT Sets the default occlusion alarm level.

WEIGHT Sets up default patient weight, for TIVA mode only.

PURGE RATE Sets the purge rate.

PURGE VOLUME LIMIT Sets the maximum permissible purge volume.

PURGE SYRINGE Prompt to purge syringe after conrmation.

HANDS FREE BOLUS Enables / disables the hands free bolus feature.

DEFAULT BOLUS VOL Sets the default hands free bolus volume, for no drug mode only.

DEFAULT BOLUS RATE Sets the default bolus rate.

MANUAL BOLUS Volume infused will be increased if plunger is manually moved in and syringe remains conrmed.

CALL BACK TIME Adjusts the time for the pump to sound the call back alarm.

EVENT LOG DISPLAY Enables / disables the event log.

BATTERY ICON Enables / disables the Battery Icon on the main display.

AUDIO VOLUME Sets the alarm volume of the pump at high, medium or low.

AUTO NIGHT MODE Backlight dims between hours 21:00 and 06:00.

b button turn the pump ON.

f keys, pressing NEXT to move through

General Options

f keys and press the OK softkey.

1000DF00330 Issue 4

19/34

Configured Options (Continued)

Clock Set

1. Select CLOCK SET from the Configured Options menu using the f keys and press the OK softkey.

2. Use the

3. When the correct time and date are displayed press the OK softkey to return to the Configured Options menu.

This option allows the user to programme in the name of the hospital, ward or department. This will appear during the power-up display
sequence.

1. Select HOSPITAL NAME from the Configured Options menu using the

2. Use the keys to adjust the character displayed, pressing NEXT to access the next position.

3. When the correct name is displayed press OK to return to the Configured Options menu.

This option is used to pre-configure the type and size of syringe permitted for use on the pump. Select all possible syringes which may be
used and disable any that should not be used.

1. Select ENABLE SYRINGES from the Configured Options menu using the

2. Use the
within the brand.

3. When all modifications are complete press OK to return to the Configured Options menu.

f keys to adjust the date displayed, pressing the NEXT softkey to access the next field.

Hospital Name

f keys and press the OK softkey.

Enable Syringes

f keys and press the OK softkey.

f keys to scroll through the list of syringes, pressing MODIFY to enable/disable a syringe brand and individual models

Language

This option is used to set the language of messages shown on the pump display.

1. Select LANGUAGE from the Configured Options menu using the

2. Use the

3. When the desired language has been selected press SELECT softkey to return to the Configured Options menu.

f keys to select the language.

f keys and press the OK softkey.

Contrast

This option is used to set the contrast on the pump display.

1. Select CONTRAST from the Configured Options menu using the

2. Use the

3. When the desired value has been reached press the OK softkey to return to the Configured Options menu.

f keys to select a contrast ratio value. The contrast of the display will change when scrolling through the numbers.

f keys and press the OK softkey.

1000DF00330 Issue 4

20/34

Alaris® TIVA Syringe Pump Configured Options Record

General Options

Option Default Range Setting

Software Version 1.6.2 & 2.1.0

NURSE CALL FITTED Disabled Disabled Enabled/Disabled

NURSE CALL INVERT Disabled Disabled Enabled/Disabled

RS232 SELECTED Disabled Disabled Enabled/Disabled

NEOI WARNING 1min 5mins 1min - 15mins

EOI POINT 1.0% 1.0% 0.1% - 5% of syringe volume

KVO AT EOI Enabled Enabled Enabled/Disabled

KVO RATE 1.0ml/h 1.0ml/h 0.1ml/h - 2.5ml/h

BACK OFF Disabled Enabled Enabled/Disabled

AC FAIL Enabled Enabled Enabled/Disabled

PRESSURE DISPLAY Disabled Enabled Enabled/Disabled

PRESSURE DEFAULT L-5 L-3 L0 - 10(50mmHg -1000mmHg)

WEIGHT 70.0Kg 70.0Kg 0.01Kg - 250Kg

Enter the pump-specific information for your records on a copy of this page.

1.9.x &

2.3.x and above

PURGE RATE 200ml/h 200ml/h 100ml/h - 500ml/h

PURGE VOLUME LIMIT 2.0ml 2.0ml 0.5ml - 5.0ml

PURGE SYRINGE Enabled Disabled Enabled/Disabled

HANDS FREE BOLUS Enabled Enabled Enabled/Disabled

DEFAULT BOLUS VOL 5.0ml 5.0ml 0.1ml - 100ml

DEFAULT BOLUS RATE 1200ml/h 1200ml/h 150ml/h - 1200ml/h

MANUAL BOLUS Disabled Enabled/Disabled

CALLBACK TIME 2.0mins 0.1mins - 15.0mins

EVENT LOG DISPLAY Disabled Enabled Enabled/Disabled

BATTERY ICON Enabled Enabled/Disabled

AUDIO VOLUME Medium Medium Low, Medium, High

AUTO NIGHT MODE Enabled Enabled Enabled/Disabled

Syringes Enabled

Make Size(s) Make Size(s)

Hospital Name Serial No. Software Version

Approved by Congured by

Date Date

1000DF00330 Issue 4

21/34

Configured Options (Continued)

Drug Set-up

1. Select the DRUG LIBRARY option using the f keys and press the OK softkey indicated on the screen.

2. To add a DRUG NAME press NEW softkey indicated on the screen and modify as indicated.

3. Select the required drug and press the MODIFY softkey.

4. To use a drug it must be enabled.

5. To change the drug name press the EDIT softkey indicated using the f keys to toggle through the alphabet. To select a letter
press the NEXT softkey. On completion press the OK softkey indicated on the screen.

6. Select the CONCENTRATION UNITS Units using the f keys, press the OK softkey to select the concentration units.

7. Select the MINIMUM CONCENTRATION of the drug selected. Use the f keys to increase/decrease the minimum concentration
shown on the screen. When the minimum concentration has been selected press the OK softkey.

8. Select the DEFAULT CONCENTRATION of the drug selected, use the f keys to increase/decrease the default concentration
shown on the screen. When the default concentration has been selected press the OK softkey.

9. Select the MAXIMUM CONCENTRATION of the drug selected. Use the f keys to increase/decrease the maximum concentration
shown on the screen. When the maximum concentration has been selected press the OK softkey.

If the default concentration, the minimum concentration and the maximum concentration are equal the start-up
sequence will bypass the concentration request.

A

10. Select the DOSE RATE UNITS required for maintenance doses, use the f keys to select the dose units required. When the dose
units required have been selected press the OK softkey.

11. Select the INDUCTION DOSE (in dose units) required, use the f keys to increase / decrease the induction displayed. When the
induction has been selected press the OK softkey.

If the setting is less than 0.01 then it turns the Induction setting off. It will disable the Induction Set-Up in TIVA mode.

12. Select the INDUCTION TIME required, use the f keys to increase/decrease the time over which the induction is to take place.
When the time has been selected press the OK softkey.

13. PAUSE AFTER INDUCTION. Select ENABLED and the infusion will stop after the induction period awaiting the operator pressing the b
button to continue at the chosen maintenance rate.

Select DISABLED and the infusion will continue to give the chosen maintenance rate after induction.

14. Select the MAINTENANCE RATE required, use the f keys to increase/decrease the maintenance rate. When the rate has been
selected press the OK softkey.

15. Select the BOLUS DOSE (selected in dose units) required. Use the f keys to increase / decrease the bolus dose. When the dose
has been selected press the OK softkey.

If the OFF softkey is pressed then it turns the Bolus setting off. It will disable the Bolus feature in TIVA mode.

16. Select the default BOLUS RATE required, use the f keys, to select from 150ml/h, 300ml/h, 600ml/h, 900ml/h or 1200ml/h.

When the rate has been selected press the OK softkey.

17. To select HANDS FREE BOLUS use the f keys to choose ENABLED/DISABLED. Press the OK softkey to confirm selection.

18. REVIEW THE DRUG SETUP DATA, press the OK softkey to confirm the data displayed. This will return the pump to the drug setup
menu.

1000DF00330 Issue 4

22/34

Hands

Rate

Bolus

Dose

Maintenance

after

Pause

Time

Free

(/)

(ml/h)

(–/Kg)

(/)

Induction

(sec)

Drug Protocol Record

* - 100 drug names with a maximum

of 17 characters are available for

V2.3.x software and above.

Alaris® TIVA Syringe Pump Drug Protocol Setup

(–/Kg)

(dose)

Induction

Dose Rate Units

Concentration

Min Default Max

Units

(–/ml)

Hospital Ward/Unit

Drug Name

(12 Chars max*)

No.

(1-50*)

1000DF00330 Issue 4

23/34

Serial Number Software Version

Approved by Congured by

Date Date

Specifications

Infusion Specifications -

Maximum infusion rate can be set as part of the configuration.

0.1ml/h - 150ml/h 5ml syringes

0.1ml/h - 300ml/h 10ml syringes

0.1ml/h - 600ml/h 20ml syringes

0.1ml/h - 900ml/h 30ml syringes

0.1ml/h - 1200ml/h 50ml syringes
The Volume Infused range is 0.0ml - 9990ml.

Bolus Specifications -

Selected maximum rates are shown below

150ml/h 5ml syringes
300ml/h 10ml syringes
600ml/h 20ml syringes
900ml/h 30ml syringes
1200ml/h 50ml syringes
The default bolus volume can be set as part of the configuration.
Minimum: 0.1ml;
Maximum 100.0ml
Increments of 0.1ml; default 5.0ml
During BOLUS the pressure limit alarms are temporarily increased to

their maximum level.

Critical Volume -

The bolus which can occur in the event of a single internal fault
condition with a 50 ml syringe is :

Maximum Overinfusion - 0.5ml

Purge Specifications -

The purge rate is limited to the maximum rate for the syringe and can
be set as part of the configuration.

100ml/h - 500ml/h.

The purge volume range is 0.5ml - 5ml.

During PURGE the pressure limit alarms are temporarily increased to
their maximum level.

Keep Vein Open (KVO) Rate -

0.1 ml/h - 2.5ml/h.

End Of Syringe Rate -

Stop, KVO (0.1ml/h to 2.5ml/h), or set rate if lower than KVO.

Near End Of Infusion Alarm -

1min - 15min to end of infusion, or 10% of syringe volume, whichever
is smaller.

End Of Infusion (EOI) Alarm -

0.1% - 5% of syringe volume

Electrical Classification -

Class I product. Continuous Mode Operation, Transportable

Maximum Pumping Pressure Limit -

Highest alarm level 1000mmHg (nominal at L-10)

Occlusion Accuracy (% of full scale)* -

Pressure mmHg

L-0

approx.

50 mmHg

Temp. 23°C

* - Using most common 50ml syringes under normal conditions
(95% confidence / 95% of pumps).

Battery Specifications -

Rechargeable sealed NiMH. Automatically charges when the pump is
connected to AC power.

Mean Time To Battery Empty from fully charged @ 5ml/h & 20°C under
normal conditions is 6 hours*

*95% lower confidence interval of 5 hours 50 minutes

Charging takes 2½ hours from discharge to 90% charge.

±18% ±21% ±23% ±28%

L-3

approx.

300 mmHg

L-5

approx.

500 mmHg

L-10

approx.

1000 mmHg

1000DF00330 Issue 4

Memory Retention -

The electronic memory of the pump will be retained for more than 6
months when not powered up.

System Accuracy -

Volumetric Mean +/- 2% (nominal).

Derating -

Temperature +/- 0.5% (5 - 40ºC)

High Rates +/-2.0% (rates > syringe volume/h eg.
>50ml/h in a 50ml syringe.)

Important: System accuracy is +/-2% typical by volume as measured
using the trumpet curve test method defined in IEC/EN60601-2-24 at
rates of 1.0ml/h (23ºC) and above when the pump is used with the
recommended syringes. Caution: Infusion volume accuracy may be
compromised at rates below 1.0ml/h. Differences in factors such as
size and plunger force in compatible syringes can cause variations in
accuracy and trumpet curves. See also trumpet curves section in this
manual.

Fuse Type -

2 x T 1.25A, slow blowing.

AC Power Supply -

115 - 230VAC, 50 - 60Hz, 20VA (nominal).

Dimensions -

310 mm (w) x 121 mm (h) x 200 mm (d). Weight: 2.7 kg (excluding power
cable).

Alarm Conditions -

Drive Disengaged Occlusion

Check Syringe Battery Low / Battery Empty

Near End Of Infusion End of Infusion

AC Power Fail Internal Malfunction

Attention (Nurse Callback) Titration not confirmed

Environmental Specifications -

Operating Temperature +5°C - +40°C

Operating Relative Humidity 20% - 90%

Operating Atmospheric Pressure 700hPa - 1060hPa

Transport & Storage Temperature -30°C - +50°C

Transport & Storage Relative Humidity 10% - 95%

Transport & Storage Atmospheric Pressure 500hPa - 1060hPa

Electrical/Mechanical Safety -

Complies with IEC/EN60601-1 and IEC/EN60601-2-24.

Protection against fluid ingress -

IPX1 - Protected against vertically falling drops of water.

EMC -

Complies with IEC/EN60601-1-2

Conversion Factor

Dosing Conversion:

1.0 µg = 1000 ng

1.0 mg/h = 24.0 mg/24 h

1.0 mg/min = 60.0 mg/h

1.0 mg = 1000 µg

Volume / Unit Time = Dose Rate / Concentration

1.0 ml/h = 1.0 mg/h / 1.0 mg/ml

The formula is:

Volume/Rate =

(.......µg/kg/min) x (.......kg) x (60 min/h) = µg/h = ml/h

conc. in mg/ml x 1000 µg/mg µg/ml

Drug Units Available:

ml/h, ng/min, ng/kg/min

µg/min, µg/kg/min, µg/h, µg/kg/h, µg/24h, µg/kg/24h

mg/min, mg/kg/min, mg/h, mg/kg/h, mg/24h, mg/kg/24h,

g/h, g/24h, U/min, U/kg/min, U/h, U/kg/h, U/24h, U/kg/24h,

kU/24h, mmol/h

and IEC/EN60601-2-24.

24/34

Compatible Syringes

The pump is calibrated and labelled for use with single-use disposable Luer lock syringes. Only use the size and type of syringe specified on
the pump display. The full list of permitted syringe models is dependent on the software version of the pump.

5ml 10ml 20ml 30ml 50ml
IVAC®
AstraZeneca
B Braun Omnix
B Braun Perfusor
BD Perfusor
BD Plastipak
BD Precise
Codan
Codan Perfusion
Fresenius Injectomat
Monoject**
Pentaferte
Rapiject*
Terumo

* - The Rapiject 50ml syringe is a specialised syringe with a large diameter barrel. To provide protection against accidental dislodging always

ensure the infusion line is secured using the infusion set hook - see Loading a Syringe section.
** - TYCO / Healthcare KENDALL - MONOJECT.

ü ü ü ü ü

ü ü

ü ü ü ü ü

ü ü

ü ü ü ü

ü ü
ü ü ü ü ü
ü ü ü ü

ü ü ü ü ü

ü
ü

ü

ü

ü

The Alaris® DS Docking Station

Associated Products

The Alaris® Gateway Workstation

1000DF00330 Issue 4

25/34

Compatible Extension Sets

The pump uses standard, single-use, disposable extension sets and syringes with Luer lock connectors. The user is responsible for verifying
the suitability of a product used, if it is not recommended by Cardinal Health.

For availability please contact your local CareFusion representative because new sets are continuously being
developed for our customers.

A

Standard Sets

G40015 Standard PVC Syringe Extension Set (150 cm).

Priming Volume: 2.6ml

G40020B Standard PVC Syringe Extension Set (200 cm).

Priming Volume: 1.5ml

G402EP Extension set, Luer lock connectors. Kink resistant DEHP free PVC yellow striped tubing. Bore 1mm. Length 200cm.

Priming volume 1.6ml.

Light Protected Sets

G40215 Amber PVC Syringe Extension Set (150 cm).

Priming Volume: 1.2ml

G40320 White PVC Syringe Extension Set (200 cm).

Priming Volume: 3.6ml

04105010509 Polyethylene Syringe Extension Set (100 cm).

Priming Volume: 1ml

Low Sorbing Sets

G40615 Polyethylene Syringe Extension Set (150 cm).

Priming Volume: 1.5ml

G40620 Polyethylene Syringe Extension Set (200 cm).

Priming Volume: 1.6ml

G40720 Polyethylene Lined Syringe Extension Set with clamp. (200 cm).

Priming Volume: 1.5ml

It is recommended that extension sets are changed in accordance with the Directions for Use.

Carefully read the Directions For Use supplied with the extension set prior to use.

Please note these drawings are not to scale

1000DF00330 Issue 4

26/34

Compatible Extension Sets (Continued)

The pump uses standard, single-use, disposable extension sets and syringes with Luer lock connectors. The user is responsible for verifying
the suitability of a product used, if it is not recommended by CareFusion.

For availability please contact your local CareFusion representative because new sets are continuously being
developed for our customers.

A

Patient Controlled Analgesia (PCA) Sets

30822 PVC Syringe Extension Set with clamp (152 cm).

Priming Volume: 0.5ml

30832 PVC ‘Y’ Syringe Extension Set with back check valve and 2 clamps (178 cm).

Priming Volume: 1.5ml

30842E PVC Syringe Extension Set with back check valve, SmartSite® Needle-Free Valve Port and clamp (30 cm).

Priming Volume: 1.4ml

30852 PVC ‘Y’ Syringe Extension Set with anti-siphon valve, back check valve and 2 clamps (183 cm).

Priming Volume: 1.8ml

30862 PVC Syringe Extension Set with anti-siphon valve and clamp (156 cm).

Priming Volume: 0.6ml

04102215162

04100010162

PVC Syringe Extension Set with rotating luer. (150 cm).
Priming Volume: 2.9ml

PVC Syringe Extension Set (105 cm).
Priming Volume: 7.2ml

It is recommended that extension sets are changed in accordance with the Directions for Use.

Carefully read the Directions For Use supplied with the extension set prior to use.

Please note these drawings are not to scale

1000DF00330 Issue 4

27/34

Maintenance

Routine Maintenance Procedures

To ensure that this pump remains in good operating condition, it is important to keep it clean and carry out the routine maintenance
procedures described below.

Interval Routine Maintenance Procedure

As per Hospital Policy Thoroughly clean external surfaces of the pump before and after prolonged period of storage.

Each usage 1. Inspect AC power supply plug and cable for

2. Inspect case, keypad and plunger for damage.

3. Check Start up self test operation is correct.

Before the transfer of the pump to a
new patient and as required

If the pump is dropped, damaged, subjected to excessive moisture or high temperature, immediately take it out of
service for examination by a qualified service engineer.

A

All preventative and corrective maintenance and all such activities shall be performed at a compliant work place in
accordance with the information supplied. CareFusion will not be responsible should any of these actions be
performed outside the instructions or information supplied by CareFusion. For Preventative and Corrective
Maintenance instructions please refer to the Technical Service Manual (TSM).

All servicing should only be performed by a qualified service engineer with reference to the TSM.

Clean the pump by wiping over with a lint-free cloth lightly dampened with warm water and a
standard disinfectant / detergent solution.

damage.

Please refer to Technical Service Manual for calibration procedures. The units of measurement used in the
calibration procedure are standard SI (The International System of Units) units.

A

Battery Operation

The internal rechargeable battery allows continued operation when the AC power is unavailable, for example during patient transfer or AC
power failure. Mean Time To Battery Empty from fully charged @ 5ml/h & 20°C under normal conditions is 6 hours*. From the battery low
alarm it will take about 2½ hours to 90% charge when reconnected to the AC power supply, whether the pump is in use or not.

The battery is maintenance free, sealed Nickel Metal Hydride and requires no routine servicing. However, to achieve optimum operation,
ensure that the battery is fully recharged after full discharge, before storage, and at regular 3 month intervals during storage.

Charge retention will eventually degrade. Where retention is critical the internal battery should be replaced every 3 years.

It is recommended that only a qualified service engineer replaces the battery. For further information regarding the replacement of
batteries refer to the Technical Service Manual.

The battery pack used in this Alaris® Syringe Pump is manufactured by CareFusion and includes a proprietary PCB (printed circuit board)
designed specifically for the Alaris® Syringe Pump, and in conjunction with Alaris® Syringe Pump software, controls battery use, charge
and temperature. Any use of battery packs that are not manufactured by CareFusion in the Alaris® Syringe Pump is at your sole risk, and
CareFusion does not provide any warranty for or endorsement on any battery packs that are not manufactured by CareFusion. CareFusion’s
product warranty shall not apply in the event the Alaris® Syringe Pump has suffered damage or premature wear, or malfunctions or
otherwise operates incorrectly, as a result of use with a battery pack that is not manufactured by CareFusion.

*95% lower confidence interval of 5 hours 50 minutes

1000DF00330 Issue 4

28/34

Maintenance (continued)

Cleaning and Storage

Before the transfer of the pump to a new patient and periodically during the use, clean the pump by wiping over with a lint-free cloth lightly
dampened with warm water and a standard disinfectant / detergent solution.

Recommended cleaners are:

Brand Concentration

Hibiscrub 20% (v/v)

Virkon 1% (w/v)

Do not use the following disinfectant types:

• Disinfectants which are known to be corrosive to metals must not be used, which include:

• NaDcc (such as Presept),

• Hypochlorites (such as Chlorasol),

• Aldehydes (such as Cidex),

• Cationic Surfactants (such as Benzalkonium Chloride).

• Use of Iodine (such as Betadine) will cause surface discoloration.

• Concentrated Isopropyl alcohol based cleaners will degrade plastic parts.

The syringe and extension sets are disposable single use items and should be discarded after use according to their manufacturers’
instructions.

If the pump is to be stored for an extended period it should be first cleaned and the internal battery fully charged. Store in a clean, dry
atmosphere at room temperature and, if available, employ the original packaging for protection.

Once every 3 months during storage, carry out functional tests as described in the Technical Service Manual and ensure that the internal
battery is fully charged.

Before cleaning always switch OFF and disconnect from the AC power supply. Never allow liquid to enter the casing
and avoid excess fluid build up on the pump. Do not use aggressive cleaning agents as these may damage the exterior

A

Information on Disposal for Users of Waste Electrical & Electronic Equipment

U symbol on the product and/or accompanying documents means that used electrical and electronic products should

This
not be mixed with household waste.

If you wish to discard electrical and electronic equipment, please contact your CareFusion affiliate office or distributor for
further information.

Disposing of this product correctly will help to save valuable resources and prevent any potential negative effects on human
health and the environment which could otherwise arise from inappropriate waste handling.

Information on Disposal in Countries outside the European Union

This symbol is only valid in the European Union. The product should be disposed of taking environmental factors into
consideration. To ensure no risk or hazard, remove the internal rechargeable battery and the Nickel Metal Hydride battery
from the control board and dispose of as outlined by the local country regulations. All other components can be safely
disposed of as per local regulations.

surface of the pump. Do not steam autoclave, ethylene oxide sterilise or immerse this pump in any fluid.

Disposal

1000DF00330 Issue 4

29/34

Occlusion Pressure Limits

Time to alarm following occlusion is achieved in less than 30 minutes at rates of 1 ml/h and higher by the appropriate selection of occlusion
levels.
The following graphs show the typical values for time to alarm and bolus volume that can be expected in the event of an occlusion when
the BD Plastipak 50 ml syringe is selected with a G40020B standard extension set.

Time to alarm - 5.0 ml/h

typical

Occlusion Level

Bolus Volume with back off

typical

Occlusion Level

hr:min:sec

ml

Time to alarm - 1.0 ml/h

typical

hr:min:sec

Occlusion Level

Bolus Volume without back off

typical

ml

Occlusion Level

Tests at low alarm levels may alarm immediately - the force at these levels is commonly less than the friction in the syringe (with no
additional fluid pressure). The result is that the pressure relating to the low forces will be less than the nominal quoted occlusion pressure.

Bolus volume following occlusion will be minimised by the back off feature if enabled. The back off will reduce the line pressure by removing
the volume stored in the occluded line and deducting this volume from the volume infused.

1000DF00330 Issue 4

30/34

IrDA, RS232 and Nurse Call Specification

IrDA / RS232 / Nurse Call Feature

The RS232 / Nurse call feature is an optional feature on Alaris®
Syringe Pumps. It allows the pump to be monitored remotely
and/or controlled via a suitable central monitoring or computer
system.

When the pump is started by a command from the serial interface,
communication must take place over the serial interface, a
communication must take place every 15 seconds or the pump
will alarm, display communications failure and stop infusing. This
failure protects against failure of the communications, including
the removal of the RS232 cable.

The nurse call interface provides a remote
backup to the internal audible alarm. It should

A

not be relied upon to replace monitoring of
the internal alarm.

Refer to the Technical Service Manual for
further information regarding the RS232
interface. Since it is possible to control the
syringe pump using the RS232 interface at
some distance from the pump and hence
remote from the patient, responsibility for the
control of the pump is vested in the software
run on the computer control system.

The assessment for the suitability of any
software used in the clinical environment to
control or receive data from the pump lies
with the user of the equipment. This software
should include detection of the disconnection
or other failure of the RS232 cable. The protocol
is detailed in the Technical Service Manual and
is for general information only.

Any connected analogue and digital
components are required to meet IEC/EN60950
for data processing and IEC/EN60601 for
medical devices. Anyone connec ting additional
devices to the signal input or output is a system
configurator and responsible for meeting the
requirements of the system standard IEC/
EN60601-1-1.

IrDA

Baud Rate 38.4 kBaud

Start Bits 1 Start Bit

Data Bits 8 Data Bits

Parity No Parity

Stop Bits 1 stop bit

RS232 / Nurse Call Connection Data

Nurse call Specification -

Connector D Type - 9 Pin

TXD/RXD EIA RS232-C Standard

TXD Output Voltage Range Minimum: -5V (mark), +5V

(space)

Typical: -7V (mark), +7V (space)
with 3kΩ load to ground

RXD Input Voltage Range -30V - +30V max.

RXD Input Thresholds Low: 0.6V minimum / High: 3.0V

maximum

RXD Input Resistance 3kΩ minimum

Enable Active, Low:-7V to -12V

Active, High:+7V to +12V,
powers up the isolated RS232
circuitry

Inactive: Floating/open circuit,
allows isolated RS232 circuitry
to power down.

Isolation Socket/Pump 1.5kV (dc, or ac peak)

Baud Rate 38.4 kBaud

Start Bits 1 Start Bit

Data Bits 8 Data Bits

Parity No Parity

Stop Bits 1 stop bit

Nurse Call Relay Contacts Pins 1, 8 + 9, 30V dc, 1A rating

Typical Connection Data -

1 Nurse call (Relay) Normally Closed (NC C)

2 Transmit Data (TXD) Output

3 Received Data (RXD) Input

4 Power Input (DSR)

5 Ground (GND)

6 Not used

7 Power Input (CTS)

8 Nurse call (Relay) Normally open (NC O)

9 Nurse call (Relay) Common (NC COM)

1000DF00330 Issue 4

31/34

Trumpet Curves & Start-up Curves

In this pump, as with all infusion systems, the action of the pumping mechanism and variations in individual syringes cause short-term fluctuations
in rate accuracy.

The following curves show typical performance of the system in two ways: 1) the delay in onset of fluid flow when infusion commences (start-up
curves), and 2) the accuracy of fluid delivery over various time periods is measured (trumpet curves).

The start-up curves represent continuous flow versus operating time from the start of the infusion. They exhibit the delay in onset of delivery due
to mechanical compliance and provide a visual representation of uniformity. Trumpet curves are derived from the second hour of this data. Tests
performed per IEC/EN60601-2-24 standard.

Trumpet curves are named for their characteristic shape. They display discrete data averaged over particular time periods or 'observation windows',
not continuous data versus operating time. Over long observation windows, short term fluctuations have little effect on accuracy as represented
by the flat part of the curve. As the observation window is reduced, short term fluctuations have greater effects as represented by the "mouth" of
the trumpet.

Knowledge of system accuracy over various observation windows may be of interest when certain drugs are being administered. Short term
fluctuations in rate accuracy may have clinical impact depending on the half-life of the drug being infused, therefore the clinical effect cannot be
determined from the trumpet curves alone.

Start-up and trumpet curves may not be indicative of operation under negative pressure.
Differences in factors such as size and plunger force in compatible syringes produced by other manufacturers can cause

A

variations in accuracy and trumpet curves as compared to those represented. Additional curves for compatible syringes are
available upon written request.

For applications where flow uniformity is a concern, rates of 1.0 ml/h or above are recommended.

Rate (ml/h)

Rate (ml/h)

Start-up Trend. BD Plastipak 50ml @ 0.1ml/h

Time (mins)

Start-up Trend. BD Plastipak 50 ml @ 1.0 ml/h

Trumpet Curve. BD Plastipak 50ml @ 0.1ml/h

Error (%)

Observation Window (mins)

Trumpet Curve. BD Plastipak 50 ml @ 1.0 ml/h

Error (%)

Rate (ml/h)

Time (mins)

Start-up Trend. BD Plastipak 50 ml @ 5.0 ml/h

Time (mins)

1000DF00330 Issue 4

Observation Window (mins)

Trumpet Curve. BD Plastipak 50 ml @ 5.0 ml/h

Error (%)

Observation Window (mins)

32/34

Spare Parts

A comprehensive list of spare parts for this pump is included within the Technical Service Manual.

The Technical Service Manual (1000SM00001) is now available in electronic format on the World Wide Web at :-

www.carefusion.co.uk/alaris-technical/

A username and password are required to access our manuals. Please contact local customer services representative to obtain login details.

Part Number Description

1000SP01122

1001FAOPT91

1001FAOPT92

Internal Battery Pack

AC Power Lead - UK

AC Power Lead - European

1000DF00330 Issue 4

33/34

Service Contacts

For service contact your local Affiliate Office or Distributor.

AE DE HU PT

CareFusion,
PO Box 5527,
Dubai, United Arab Emirates.

Tel: [phone] Tel: [phone] Tel: [phone]

Fax: [phone] Fax: [phone] Fax: [phone] Fax: [phone]

AU DK IT SE

CareFusion,
3/167 Prospect Highway,
PO Box 355
Seven Hills, NSW 2147,
Australia.

Tel: [phone] Tlf. (45)70 20 30 74 Tél: [phone] Tel: [phone]

Fax: [phone] Fax. [phone] Fax: [phone] Fax: [phone]

BE ES NL US

CareFusion,
Leuvensesteenweg 248 D,
1800 Vilvoorde,
Belgium.

Tel: [phone] Tel: [phone] Tel: [phone] Tel: [phone]

Fax: [phone] Fax: [phone] Fax: [phone] Fax: [phone]

CA FR NO ZA

CareFusion,
235 Shields Court,
Markham,
Ontario L3R 8V2,
Canada.

Tel: [phone] Tél: [phone] Tel: [phone] Tel: (27) (0) 860 597 572

Fax: [phone] Fax: [phone] Fax: [phone]

CH FI NZ

CareFusion,
A-One Business Centre
Zone d’activitiés Vers-la-Pièce
n° 10
1180 Rolle / Switzerland

Ph.: 0848 244 433 Tel: [phone] Tel: [phone]

Fax: [phone] Fax: [phone]

CN GB PL

康尔福盛（上海）商贸有限公司
地址：上海市浦东新区张杨路
500号24楼E.F.G.H单元

电话：[phone]
 4008788885

传真：[phone]

CareFusion,
Pascalstr. 2,
52499 Baesweiler,
Deutschland.

CareFusion,
Firskovvej 25 B,
2800 Lyngby,
Danmark.

CareFusion,
Edificio Veganova,
Avenida de La Vega, nº1,
Bloque 1 - Planta 1,
28108 Alcobendas, Madrid,
España.

CareFusion,
Parc d’affaire le Val Saint Quentin
2, rue René Caudron
78960 Voisins le Bretonneux
France

CareFusion,
Kuortaneenkatu 2,
00510 Helsinki

CareFusion,
The Crescent, Jays Close,
Basingstoke,
Hampshire, RG22 4BS,
United Kingdom.

Tel: [phone] Tel: [phone]

Fax: [phone] Fax: [phone] Rev. L

CareFusion,
Döbrentei tér 1,
H-1013 Budapest,
Magyarország.

Tel: [phone]

CareFusion,
Via Ticino 4,
50019 Sesto Fiorentino,
Firenze, Italia.

CareFusion,
De Molen 8-10,
3994 DB Houten,
Nederland.

CareFusion,
Fjordveien 3
1363 HØVIK
Norge.

CareFusion,
14B George Bourke Drive,
Mt Wellington 1060,
PO Box 14-518,
Panmure 1741, Auckland,
New Zealand

Freephone: 0508 422734

CareFusion,
ul. Rzymowskiego 53,
02-697 Warszawa,
Polska.

CareFusion,
Avda. São Miguel, 296 Atelier 14
2775-751 Carcavelos, Lisboa
Portugal

Tel: [phone]

CareFusion,
Hammarbacken 4B,
191 46 Sollentuna,
Sverige.

CareFusion,
10020 Pacific Mesa Blvd.,
San Diego, CA 92121,
USA.

CareFusion,
Unit 2 Oude Molen Business Park,
Oude Molen Road, Ndabeni,
Cape Town 7405, South Africa.

Tel: [phone]

1000DF00330 Issue 4

34/34

Alaris, Guardrails and IVAC are registered
trademarks of CareFusion Corporation or one of its
aliates. All rights reserved.
All other trademarks are property of their
respective owners.

© 2000-2015 CareFusion Corporation or one of its
aliates. All rights reserved.

This document contains proprietary information
of CareFusion Corporation or one of its aliates,
and its receipt or possession does not convey any
rights to reproduce its contents, or to manufacture
or sell any product described. Reproduction,
disclosure, or use other than for the intended
purpose without specic written authorization of
CareFusion Corporation or one of its aliates is
strictly forbidden.

CareFusion Switzerland 317 Sarl,
A-One Business Centre, Z.A Vers –La-

t

Pièce n° 10, CH-1180, Rolle

CareFusion UK 305 Ltd., The Crescent,

EC REP

Jays Close, Basingstoke, Hampshire,
RG22 4BS, UK

1000DF00330 Issue 4

carefusion.com
