•This guide uses Mac OS X v10.3 screen shots and procedures in
the explanations. The screen shots and procedures may vary
slightly if you are using another version of the Mac OS.
REFERENCE
Supplementary explanations and procedures follow this symbol.
Read these topics as you see fit.
4ImageBrowser Software User Guide
Chapter 1
What is ImageBrowser?
What Can ImageBrowser Do?
This section provides a brief explanation of the ImageBrowser features.
What You Can Do with a Camera Connected
• Download images from the camera to the computer.
• Save computer images to the camera.
• Operate the camera shutter remotely from the computer
(only on models supporting remote shooting).
• Set up camera slide shows or DPOF print settings (only
available on some models).
• Check and modify camera settings.
• Set the My Camera Settings (start-up image, start-up sound,
operation sound, self-timer sound and shutter sound).
View Images
• Display the downloaded images and their shooting
information.
• Switch between display modes (Preview, List and TimeTunnel)
Use the Additional Features
•Print images.
•Edit images and movies.
•Stitch panoramic images.
•Convert RAW images to standard images (only available on
some models).
•Format images as screensaver and wallpaper files.
•Export image shooting information as a text file.
REFERENCE
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
•The Canon CD-ROM supplied with the camera contains My
Camera Settings files. These files are automatically copied to
your computer when ImageBrowser is installed.
Organize Images
• Assign a Star Rating or keywords to images.
• Sort images according to their shooting date or Star Rating.
• Perform image searches.
5ImageBrowser Software User Guide
Chapter 1
What is ImageBrowser?
This section briefly introduces the purposes and features of the two
main windows for operating ImageBrowser.
Guide to the ImageBrowser Windows (1/2)
Camera Control Window
The Camera Control Window is the window that automatically
opens when you connect a camera to the computer or insert a
memory card into a memory card reader. You can download
the camera or memory card images in a few easy steps. You
can also use the computer to change some camera settings.
Browser Window
This window opens when you start ImageBrowser. The Browser
Window is for displaying and organizing downloaded images.
6ImageBrowser Software User Guide
Chapter 1
What is ImageBrowser?
Using Contextual Menus
When you hold down the [control] key and click the mouse
button, a menu is displayed. This is a contextual menu.
In ImageBrowser, you can access many useful functions through
contextual menus.
For example, the following contextual menu appears when you
press and hold the [control] key and click an image in the
Browser Area.
Guide to the ImageBrowser Windows (2/2)
A contextual menu is, as its name implies, a menu whose
options vary according to the context. It is a collection of the
most commonly used buttons and commands that apply to a
given situation.Contextual menus allow you to use ImageBrowser more
efficiently. When you feel comfortable with ImageBrowser, try
using the contextual menus in different situations.
7ImageBrowser Software User Guide
Contextual menu
Chapter 2
Downloading and Printing Images
Downloading Images to Your Computer (1/6)
This chapter explains a sequence of ImageBrowser basic procedures in
order, such as downloading images from the camera and printing
downloaded images. This section starts by explaining the procedures for
downloading images from the camera.
IMPORTANT
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
• This guide assumes that all the relevant software programs
and drivers have been correctly installed on your computer. If
you have not yet installed them, read the guides for the
software supplied with your camera and install them.
Auto Start Settings the First Time ImageBrowser Is Used
This section explains the settings for automatically opening the
Camera Control Window when you connect your camera to a
computer.
IMPORTANT
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
• You must perform this step before connecting the camera to a
computer for the first time.
1.
2.
3.
4.
5.
Mac OS X v10.2/v10.3
Start Image Capture.
Image Capture is a program supplied as part of Mac OS X. It is
usually contained in the Applications folder.
In the [Image Capture] menu, select [Preferences].
In the [When a camera is connected, open:] list box,
select [Other].
Select [CameraWindow] in the application selection
window and click [Open].
CameraWindow is found by opening the [Applications] folder,
followed by the [Canon Utilities] and [CameraWindow] folders.
Click [OK] and close Image Capture.
8ImageBrowser Software User Guide
Chapter 2
Downloading and Printing Images
Mac OS X v10.1
Downloading Images to Your Computer (2/6)
1.
2.
3.
4.
Start Image Capture.
Image Capture is a program supplied as part of Mac OS X. It is
usually contained in the Applications folder.
In the [Hot Plug Action] list box, select [Other].
Select [CameraWindow] in the application selection
window.
CameraWindow is found by opening the [Applications] folder,
followed by the [Canon Utilities] and [CameraWindow] folders.
Close Image Capture.
9ImageBrowser Software User Guide
Chapter 2
Downloading and Printing Images
Downloading Images to Your Computer (3/6)
Connecting the Camera to Download
This section describes two methods for downloading images
shot with the camera to a computer.
Downloading Images with Camera Commands
You can use this method to download images with cameras
that support the direct transfer function.
Downloading Images with Computer Commands
This method uses commands entered on the computer to
download images from a memory card in a camera or in a
memory card reader. This method can be used regardless of
whether your camera supports the direct transfer function or not.
This method is explained later in the Using ComputerCommands to Download Images section.
REFERENCE
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
• This section uses the “Download All Camera Images Not Yet
Downloaded” method, a simple method, to download images.
Chapter 3 explains in greater detail how to select images for
downloading from a camera or memory card and how to
perform tasks such as changing the file destination.
• If images shot on different dates are contained on the memory
card, the images will be grouped in folders by shooting date
when they are downloaded and the folder with the most recent
shooting date will display.
1.
Using Camera Commands to Download Images
You can download images using camera commands if your
camera supports the direct transfer function (camera has a
(Print/Share) button).
Connect the camera to the computer with the
interface cable.
If a Camera Control Window similar to the one below opens,
proceed directly to Step 2. If your camera features a
Share) button, it will flash and a Direct Transfer menu similar to
the lower right one will appear on the camera’s LCD monitor.
Camera Control Window
IMPORTANT
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
* If the Direct Transfer menu does not appear in the camera's
LCD monitor, you cannot download images using camera
procedures.
(Print/
10ImageBrowser Software User Guide
Chapter 2
Downloading and Printing Images
Downloading Images to Your Computer (4/6)
2.
Some camera models must have settings, such as the Playback
mode, set to communicate with the computer. If your camera
requires this, consult your Camera User Guide to set the
necessary settings for communication.
REFERENCE
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
• If a remote shooting window opens, the Camera Control Window
will not open. Please close the remote shooting window.
• A dialog will appear if a camera and a memory card reader are
both connected to allow you to select the device from which
images are shown. Select the desired device from the list box
and click [OK].
Set the Direct transfer settings on the camera, and
push the
REFERENCE
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
• See your Camera User Guidefor explanations of the settings
and commands related to the Direct Transfer menu that appears
in the camera’s LCD monitor.
• If you click Settings on the computer, you can change the
destination folder for image files. See “Downloading Images
Automatically” in Chapter 3 for instructions on how to change
the destination folder.
• By the default settings, downloaded images are saved to the
[Pictures] folder.
(Print/Share) button or [SET] button.
The images will begin to download. The downloaded images
will be saved into folders according to the shooting date.
The images will display in the Main Window when the
download is complete.
Downloaded Images
11ImageBrowser Software User Guide
Chapter 2
Downloading and Printing Images
Downloading Images to Your Computer (5/6)
Using Computer Commands to Download Images
1.
Connect the camera to the computer with the
interface cable.
The Camera Control Window will display.
Some camera models must be set, such as setting the camera
to Playback mode, to communicate with the computer. If your
camera requires this, consult your Camera User Guide to set the
necessary settings for communication.
REFERENCE
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
•If you are using a memory card reader, you can set it using the
same procedures as with the camera to have the Camera
Control Window open automatically. After you set the settings,
the Camera Control Window will open automatically when you
insert a memory card into the reader. The window appears
slightly different from the camera version, but functions
similarly.
12ImageBrowser Software User Guide
Camera ControlWindow with aCamera Connected
Camera Control
Window with a
Memory Card
Reader Connected
•Different windows from those shown here may appear for
some camera models. In that case, please read the user guides
provided with the software bundled with the camera.
Chapter 2
Downloading and Printing Images
Downloading Images to Your Computer (6/6)
2.
REFERENCE
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
• A dialog will appear if multiple memory card readers are con-
nected and loaded with memory cards, or if a camera and a
memory card reader are both
connected, to allow you to
select the device from which
images are shown. Select the
desired device from the list box
and click [OK].
Click [Starts to download images].
All the images that have yet to be downloaded will start to
download.When downloading is complete, ImageBrowser's Browser
Window will open and display the downloaded images.
REFERENCE
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
• According to the default settings, folders named according to
the image shooting dates are created within the [Pictures] folder
and the images are downloaded to them.
13ImageBrowser Software User Guide
Chapter 2
Downloading and Printing Images
Printing Images (1/2)
This section explains the procedures for printing downloaded images on
a printer.
REFERENCE
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
• Images recorded in the Adobe RGB color space will appear
unsaturated when printed using PhotoRecord. Color space
settings are only available on select camera models.
1.
2.
Click an image in the Browser Window to print.
A blue frame appears around the image.
REFERENCE
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
• You can select multiple images by pressing and holding the
[shift] key or [
you hold down the [option] and [shift] keys together and click
on two images, you can select all the images between them.
] (command) key while clicking on images. If
Click [Print] and select [Layout Printing] from the
displayed menu.
3.
In the Layout Options dialog, leave the [Custom layout
printing]option selected and click [Next].
Print Window
Layout Options Dialog
The Layout Options dialog and Print window open.
The selected images are automatically laid out in the Print
window. You can select a layout option in the Layout Options
dialog. For the moment, just print the images without making
any changes.
14ImageBrowser Software User Guide
Chapter 2
Downloading and Printing Images
Printing Images (2/2)
4.
5.
If the Page Setup window appears, set the settings as
appropriate and click [OK].
The Layout Options dialog will close.
In the Print window, click [PRINT].
6.
If the Print dialog appears, click [Print].
REFERENCE
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
•You cannot click [Print] in the Print window while the Layout
Options dialog is open.
•For details on print operations, see the Printing Images section
in Chapter 6.
15ImageBrowser Software User Guide
Chapter 3
What You Can Do with a
Camera Connected
Camera Control Window (1/2)
This chapter explains the procedures performed with the Camera
Control Window.
Opening the Camera Control Window
When you are using the camera's
Direct Transfer function, the
downloading procedures for
camera images are explained here.
You can download all
images at once using
computer procedures.
Or you can check the
images and then
download them using
computer procedures.
Selects a Camera Windowfunction.
Sets the download method, filedestination and auto download settings.
■Auto Start Settings Selected
When you connect the camera to the computer and prepare it
for communication, the Camera Control Window will
automatically open.
■Auto Start Settings Not Selected
After you connect the camera to the computer, double-click the
[Canon CameraWindow] icon on the desktop to open the
Camera Control Window.
REFERENCE
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
•Depending on the selections you make during installation, the
Canon CameraWindow icon may not appear on the desktop. In
this case, open the Camera Control Window by double-clicking
the [Applications] folder, followed by the [Canon Utilities] and
[CameraWindow] folders, and double-click the
[CameraWindow] icon.
16ImageBrowser Software User Guide
Chapter 3
What You Can Do with a
Camera Connected
To open the Camera Control Window from ImageBrowser’s
Browser Window , click [Canon Camera] in the Explorer Panel
section or on the Control Panel.
Camera Control Window (2/2)
Closing the Camera Control Window
Click [Quit] to close the Camera Control Window.
You can also open the Camera Control Window by clicking the
[File] menu and selecting the [Canon Camera] submenu,
followed by [Connect to Camera].
Set the Direct Transfer settings on the camera, and
start the direct transfer.
This will download images automatically to the computer.
REFERENCE
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
• See your Camera User Guidefor explanations of the settings
and commands related to the Direct Transfer menu that appears
in the camera’s LCD monitor.
Changing the Auto Downloading Settings
Change the destination folder for images downloaded to the
computer.
2.
3.
Select [Change direct transfer download destination
folder] and click [Next].
Select a destination folder for the downloaded
images and set the new folder creation method for
downloads, then click [Finish].
1.
18ImageBrowser Software User Guide
Click [Preferences].
This concludes the settings procedure.
Chapter 3
What You Can Do with a
Camera Connected
Downloading Images Automatically
—
Computer Operations (1/3)
1.
Starting Auto Downloading
Click [Starts to download images] in the Camera
Control Window.
This will download all the images automatically that have not
yet been downloaded to the computer.
1.
2.
Changing the Auto Download Settings
Change the type of image to download or the destination
folder.
Click [Preferences].
Select [Change auto download settings] and click
[Next].
19ImageBrowser Software User Guide
Chapter 3
What You Can Do with a
Camera Connected
Downloading Images Automatically
—
Computer Operations (2/3)
3.
4.
Select the type of image to download and click [Next].
Select a destination folder for the downloaded
images and set the new subfolder creation method
for downloads, then click [Next].
5.
Set the process to initiate after the images are
downloaded and click [Next].
Tosimply display the images in ImageBrowser's Browser
Window, select [Display the folder at the save destination]. To
have a different process initiated, select [Perform selected
processes consecutively], click [Select] and select a process in
the process selection window.
20ImageBrowser Software User Guide
Chapter 3
What You Can Do with a
Camera Connected
Downloading Images Automatically
—
Computer Operations (3/3)
6.
7.
To initiate the selected auto download process
immediately after the camera and computer are
connected, place a check mark beside [Images are
automatically downloaded to computer while camera
is connected].
Click [Finish].
This concludes the settings procedure.
21ImageBrowser Software User Guide
Chapter 3
What You Can Do with a
Camera Connected
Checking Images in the Camera before Downloading (1/2)
1.
Selecting Images and Initiating the Download
Click [Lets you select and download images] in the
Camera Control Window.
The Camera Browser Window will open and display the images
contained in the camera.
Camera Browser Window
2.
3.
Select images for downloading in the Camera Browser
Window.
A blue frame displays around selected images.
You can select multiple images by pressing and holding the
[shift] key or [images. You can also select a series of adjacent images by
pressing and holding the [option] and [shift] keys together
while clicking on the first and last images.
Click [Download Images].
] (command) key while you click on successive
22ImageBrowser Software User Guide
A window for setting the destination folder and other settings
will open.
Chapter 3
What You Can Do with a
Camera Connected
Checking Images in the Camera before Downloading (2/2)
4.
Set whether or not to change the file name, specify a
destination folder and click [Start Download].
The image will be saved.
To change the file name, set
the text characters for the
file prefix and the
consecutive numbering
system.
Specify a folder as the
destination for downloaded
images.
Set whether or not to create
a subfolder and specify the
name.
Click here to change the
destination folder.
23ImageBrowser Software User Guide
Chapter 3
What You Can Do with a
Camera Connected
Deleting Images from the Camera
This section explains how to use the Camera Browser Window to delete
images from the camera.
1.
Click [Lets you select and download images] in the
Camera Control Window.
2.
3.
Select images for deleting in the Camera Browser
Window.
A blue frame displays around selected images.
You can select multiple images by pressing and holding the
[shift] key or [images. You can also select a series of adjacent images by
pressing and holding the [option] and [shift] keys together
while clicking on the first and last images.
Click(Delete).
] (command) key while you click on successive
Camera Browser Window will open.
24ImageBrowser Software User Guide
4.
A confirmation dialog will display.
Click [Erase].
The image will be deleted.
Chapter 3
What You Can Do with a
Camera Connected
Other Features of the Camera Browser Window
This section explains the other features of the Camera Browser
Window.
Selects whether the image border and image number are
shown or hidden.
Changes the size of the image
thumbnail (tiny version).
Selects the image selection
method.
REFERENCE
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
•You can also download images displayed in the Camera
Browser Window by dragging and dropping them into
ImageBrowser’s Browser Area or Explorer Panel section.
Selects whether the image information at thewindow’s right is shown or hidden.
Starts ImageBrowser.
Displays separate histograms of
brightness or RGB data.
Histogram
25ImageBrowser Software User Guide
Image Information
Chapter 3
What You Can Do with a
Camera Connected
This section explains how to save the “My Camera Settings” on your
computer to the camera or vice versa.
Saving the “My Camera Settings” to the Camera (1/8)
What are the My Camera settings?
Displaying the My Camera window
Display the existing My Camera Settings supplied with
ZoomBrowser EX.
The start-up image for the camera and sounds such as the
start-up sound, the shutter sound, operation sound and the
self-timer sound are collectively referred to as the My Camera
Settings. You can add your favorite images and sounds from
your computer to the My Camera Settings in the camera.
1.
2.
Click the [Set to Camera] tab in the Camera Control
Window.
Click [Set My Camera].
The My Camera window displays.
26ImageBrowser Software User Guide
Chapter 3
What You Can Do with a
Camera Connected
Saving the “My Camera Settings” to the Camera (2/8)
3.
Change the [Type].
The My Camera Settings (image and sound files) display in the
Computer list. The current camera settings display in the
Camera list. Only the settings that can be changed display.
Switches between
settings types.
You can save the files that appear in this list as My Camera
Settings to your camera.
REFERENCE
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
•You can also open the My Camera window when the
ImageBrowser's Browser Window is open by clicking the [File]
menu and selecting [Canon Camera], followed by [My Camera]
from the submenu.
•The theme in the [Type] list box contains a start-up image, startup sound, operation sound, selftimer sound and shutter sound
regrouped as a set. By selecting a theme, you can change the
start-up image, start-up sound, operation sound, selftimer
sound and shutter sound in one easy step.
•You can also add new files as My Camera Settings to the Computer list (the procedure is explained later in this section).
My Camera Settings that are
already on your computer
display here.
27ImageBrowser Software User Guide
My Camera Settings inyour camera display here.
Chapter 3
What You Can Do with a
Camera Connected
Saving the “My Camera Settings” to the Camera (3/8)
1.
Saving the My Camera Settings to the camera
This topic explains how to save the previously prepared My
Camera Settings files to the camera.
Select a settings type.
2.
In the [Computer] list, select a setting you would like
to add to the camera.
When you select [Theme]:When you select a setting, the image will preview in the area to
the right and the start-up sound, the operation sound, the selftimer sound and the shutter sound will play in order.
When you select [Start-up Image]:
When you select a setting, the image will preview in the area to
the right.
When you select [Sound]:When you select a setting, the sound will play automatically.
28ImageBrowser Software User Guide
Chapter 3
What You Can Do with a
Camera Connected
Saving the “My Camera Settings” to the Camera (4/8)
3.
In the [Camera] list, select a setting that you would
like to change and click
When you click [OK] in the confirmation dialog, the settings file
in the camera will now be replaced with the one you specified
from the computer.
REFERENCE
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
• Please note that the original settings file in the camera is over-
written and permanently erased. To restore the original settings
file, you must add it once more to the camera. Before you
overwrite a settings file in the camera, confirm that it appears in
the Computer list.
.
4.
5.
Click the [Save to Camera] button.
The settings files in the Camera list are saved to the camera.
Click the [Close] button to close the window.
This concludes the procedure for adding settings to the camera.
See your Camera User Guidefor instructions on changing the
start-up image, start-up sound and other settings.
IMPORTANT
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
•Never detach the interface cable, turn off the camera power
or do anything to stop communication between the camera
and computer while the My Camera Settings are being saved
to the camera.
Select the setting you want to replaceand click
Repeat steps 1-3 to replace all the settings files with those you
wish to save to the camera.
Up to this stage, only the settings in the Camera list change,
not those in the camera itself.
29ImageBrowser Software User Guide
.
Chapter 3
What You Can Do with a
Camera Connected
REFERENCE
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
• To delete settings files in the Camera list, select the file and click
the [Delete] button.
• You can check the settings in the camera (sounds) by clicking
[Play].
Saving the “My Camera Settings” to the Camera (5/8)
Adding new files to the My Camera Settings
Create a new image or sound file and save it to the computer
and then add that file as a My Camera Settings file.
Click here to delete a filefrom the list.
Click here to check thecamera settings (sounds).
Displays the camera settingswhen an image file is selected.
30ImageBrowser Software User Guide
Loading...
+ 85 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
